Pelican Accessories BLDS02 X-Box Transmitter/Receiver Dongle User Manual Manual
Pelican Accessories X-Box Transmitter/Receiver Dongle Manual
Manual
IMPORTANT NOTICE
Blade 2.4 Street
FCC-ID: O7X-BLDS01
FCC-ID: O7X-BLDS02
Changes or modifications not expressly approved by the manufac-
turer could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions; (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause unde-
sired operation.
Pelican and its logo are registered trademarks.
XBOX is a registered trademark of Microsoft Corp.
Xbox® is a registered trademark of Microsoft Corp.
This product is not designed, manufactured, sponsored or
endorsed by Microsoft Corp,
1
Table of Contents
Console Protection Guarantee ..................3
Product Layout........................................4-5
Overview....................................................6
Features/Benefits ....................................7
Directions ..................................................9
Trouble Shooting ......................................10
Warranty/Customer Service ......................11
2
Pelican’s
Console
Protection Guarantee assures you of Pelican’s commit-
ment to quality and customer satisfaction. The Protection
Guarantee warrants the connection (the plug port of the
video game console and the plug of the Pelican controller)
between the controller and your video game console sys-
tem., i.e., that with the proper use of our controller (see
manual) we agree to replace or repair your video game
system in the event that our controller directly causes
damage to your game console as a result of our
controller failing to perform properly. Circumstances that
may cause our protection guarantee to take effect might
be one of the following :the video game console does not
acknowledge a controller which has been plugged in, orig-
inal controller fails to operate after using a Pelican con-
troller, other non-pad controllers fail to operate after using
a Pelican Controller. This protection warranty does not
include the video game power supply, any part relating to
the CD/DVD load and read mechanism, internal operating
system, nor the cabinet of the video game system. This
warranty will not apply if the Pelican controller is not used
as directed in the product manual enclosed. For further
information or help please contact us toll free at (800) 331-
3844 or on line at http://www.pelicanperformance.com
3
Console Protection Guarantee
Product Layout
Blade 2.4 Street Controller
4
LED
Left
Analog
Stick
Back
Button Start
Button
White Button
Black Button
Action Buttons
Relocated Black & White Buttons
Directional
Pad
5
Connect Button
Signal LED
Receiver/Transmitter Unit
Top View
Side View
Overview
Wireless Blade 2.4 Street controller uses advanced 2.4
GHz technology and Channel-Hopping which gives you
the ability to play without the limitations and hassles of
typical corded controllers and switch-dependent
controllers. All of this gives you lightning fast control over
your favorite games without cords to trip over, channels
to set, or fears of outside interference disturbing play
control. There are a few buttons, LED’s (lights), and
features not found on your basic Xbox® Controller. The
following is an explanation of these elements.
Auto-Hopping This removes the hassle of setting chan-
nels via a series of switches or having your connection
corrupted by interference. Auto-hopping moves to the
nearest, clearest channel for you, with no breaks in play,
to make sure your signal never lags behind your com-
mands. Simply press the CONNECT button on the
receiver, wait three seconds and press the BACK
button on the controller to make a connection. This
programs the Host to connect to the Controller every
time it is used.
6
Features & Benefits
Auto On/Off:
The controller will automatically go to sleep mode after 3
mins. of no action. Holding the START button for 5 sec-
onds also sends the controller to sleep. Touch any of the
four action buttons (A,B,X,Y), START, or BACK to power
up your new wireless controller.
Hyper-Responsive Controls: Our controls are made
out of top quality components so that you lose nothing in
control and response when you need it most over the life
of your controller.
Signal LED:
If the LED light lights up green when pressing an action
button or moving the analog sticks, your 2.4 Street
controller has a link and is working properly.
Relocated Black and White Buttons:
The Black and White buttons have been relocated to give
the user greater comfort and a much quicker reaction
time than other controllers.
7
Battery Compartment:
2.4 Street controller requires the use of two AA
batteries (not included). The batteries were placed in
between the triggers making the 2.4 Street controller’s
weight perfectly balanced. Double check and make sure
batteries are inserted correctly.
Power Save Mode:
When not in use for 3 min the 2.4 Street controller auto-
matically goes into a sleep mode to conserve batteries. A
touch of any action button puts the controller back into
play mode. The Rumble Motors will automatically disable
when the batteries are getting low. You can disable the
Rumble Motors manually by pressing the D-Pad Down
and Back at the same time. You can restore the Rumble
Motors by pressing the D-Pad Up and the Back button.
8
Please verify that all the batteries are inserted correctly.
If they are inserted incorrectly, it may cause personal injury
as well as damage to your 2.4 Street Wireless Controller.
WARNING
Directions
1. Make sure your Xbox® is turned off.
2. Remove the battery lid and place 2 AA batteries into
the 2.4 Street Wireless controller. Make sure the batteries
are inserted as shown in the battery compartment.
3. Insert the receiver into the Xbox® controller slot of
your choice and power up the Blade Street and then your
Xbox®. Note: Press the Connect button on the Receiver
once (Signal LED will FLASH slowly). Then press the
Back button on controller. This programs the Receiver to
connect to that Controller every time it is used. This oper-
ation can be done again and again to connect to multiple
controllers.
4. Alternatively, if any problems should occur during play
(due to low batteries, receiver disconnection from the
system,etc.) you can turn the controller off and then on,
check the control, and if you still do not have signal,
press the connect button on the receiver, wait three
seconds and then press the Back button.
Note: If you are using more than one 2.4 Street
controller, simply repeat the above steps and it should
connect exactly the same way on an available channel.
5. Insert a game into your Xbox®..
6. You are now ready to play.
9
Troubleshooting
If you are having difficulties with your new 2.4 Street
controller please refer below:
My system turns on but I don’t see anything on the TV.
1. Check to verify that your A/V cable is properly
connected to your system.
2. Check to verify that your A/V cable is properly plugged
into your television set.
My 2.4 Street Wireless Controller does not respond.
1. Check to verify that your batteries are inserted correctly.
2. Check to verify that the power is on. Check to verify that
the signal LED is blinking.
The power LED is on but my 2.4 Street does not
respond while in the system menu.
1. Check to verify your Receiver / Transmitter unit is firmly
and properly plugged into controller port one through four
(match the port with player controller selection).
2. Check to verify that the receiver is firmly connected to
the system and the light is on. Then, press the connect
button, wait three seconds and press Back on the con-
troller in the corresponding slot.
10
Warranty Card
Pelican warrants to the original consumer purchaser that the prod-
uct will be free from defects in materials and / or workmanship for a
period of 5 years from the date of purchase. If a defect covered by
this warranty occurs during this period, Pelican at its option will
repair or replace, at no charge, any part that Pelican determines to
be defective.
To obtain warranty service during the warranty period, send the
defective product postage pre-paid, with a money order for $4.00 (in
U.S. currency) to cover the return postage and handling, along with
proof of purchase and the date of purchase to:
Pelican Performance
1840 East 27th Street
Vernon, CA 90058
This warranty shall not apply if the product has been damaged by
abuse, misuses, negligence, accident, modification, tampering or by
any other causes unrelated to defective materials and / or workman-
ship.
Repair or replacement as provided under this warranty is Pelican’s
exclusive prerogative. ANY APPLICABLE IMPLIED WARRANTIES,
INCLUDING WARRANTIES OR MERCHANTABILITY AND FIT-
NESS FOR A PARTICULAR PURPOSE ARE HERE BY LIMITED
TO 5 YEARS FROM THE DATE OF PURCHASE AN ARE SUB-
JECT TO THE CONDITIONS SET FORTH IN THIS LIMITED WAR-
RANTY. IN NO EVENT SHALL PELICAN BE RESPONSIBLE FOR
ANY INCIDENTAL DAMAGES THAT MAY RESULT FROM THE
BREACH OF ANY EXPRESS OR IMPLIED WARRANTIES. This
warranty gives you specific legal rights, and you may also have other
legal rights, which vary from state to state.
11
For technical questions please visit
http://www.pelicanperformance.com or call us directly at:
1-800-331-3844
