Operating Instructions

High Definition

Custom Home Theater Plasma Display

TH-50VX100U

TH-65VX100U

English

Before connecting, operating or adjusting this product, please read these instructions completely.

Please keep this manual for future reference.

The illustration shown is an image.

WARNING: To reduce the risk of electric shock, do not remove cover or back.

No user-serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with

arrow-head within a triangle

is in tend ed to tell the user

that parts inside the product

are a risk of electric shock

to per sons.

The exclamation point within

a triangle is intended to

tell the user that important

operating and servicing

instructions are in the papers

with the ap pli ance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING : To prevent damage which may result in fire or shock hazard, do not expose this apparatus to rain

or mois ture.

Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.

(including on shelves above, etc.)

WARNING : 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to

qualified service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin

grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety

fea ture. If you are unable to insert the plug into the outlet, contact an electrician.

Do not defeat the purpose of the grounding plug.

This video monitor is designed to display television content from a separate TV tuner. Full-power analog TV

broadcasting in the United States will end (as required by law) on February 17, 2009, after which full-power TV

broadcasts will be digital only. If this device is used after that date to record or display programming from a product

with a TV tuner that relies on a TV antenna, that product would need to contain a digital tuner, or a TV Converter

would be necessary to tune the digital signal received with a TV antenna. Analog TVs should continue to work

as before for other purposes (e.g., for watching low-power TV stations still broadcasting in analog, watching pre-

recorded movies, or playing video games). When a Converter is used with an older television receiver or directly

with this product, a signal splitter might be necessary to continue to receive low-power analog broadcasts via an

antenna. For more information, please see www.DTV.gov or 1-888-CALL-FCC. For information on the TV Converter

program, and on government coupons that may be used toward the purchase of one, see www.dtv2009.gov, or call

the NTIA at 1-888-DTV-2009. Please check with your cable or satellite service provider if you have questions about

your cable or satellite set-top box.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one

wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the

point where they exit from the apparatus.

11) Only use attachments / accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution when moving the cart / apparatus combination

to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged

in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

Table of Contents

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment

from your new Plasma Display.

To obtain maximum benefit from your set, please read these Instructions before making any adjustments,

and retain them for future reference.

Retain your purchase receipt as well, and record the model number and serial number of your set in the

space provided on the rear cover of these instructions.

Important Safety Instructions .................................. 3

FCC STATEMENT ...................................................... 5

Safety Precautions ................................................... 6

Maintenance .............................................................. 7

Accessories .............................................................. 8

Accessories Supplied .............................................. 8

Remote Control Batteries ........................................ 8

Connections .............................................................. 9

PC Input Terminals connection .............................. 10

SERIAL Terminals connection ................................11

HDMI connection ................................................... 12

COMPONENT / RGB connection .......................... 12

Power ON / OFF ..................................................... 13

Initial selections...................................................... 14

Selecting the input signal ...................................... 14

Selecting the On-Screen Menu Language ............ 14

Basic Controls ........................................................ 15

SCROLLING BAR and TEST PATTERNS functions

..... 17

EXT. SCALER function .......................................... 17

ASPECT Controls ................................................... 18

On-Screen Menu Displays ..................................... 19

PICTURE Adjustments ........................................... 21

ADVANCED SETTINGS ........................................ 23

Picture Profiles ....................................................... 25

Saving profiles ....................................................... 26

Loading profiles ..................................................... 27

Editing profiles ....................................................... 28

Locking profiles ..................................................... 29

Adjusting POS. /SIZE ............................................. 31

SOUND Adjustment ................................................ 33

SDI SOUND OUTPUT ........................................... 33

SCREENSAVER (For preventing image retention)

.. 34

Reduces screen image retention ........................... 35

SIDE BAR ADJUST ............................................... 35

Specifying the scaler.............................................. 36

Reduces power consumption ............................... 37

Customizing the On-Screen Menu Display .......... 38

SET UP for Input Signals ....................................... 39

COMPONENT / RGB IN SELECT ......................... 39

YUV / RGB IN SELECT ......................................... 39

SIGNAL menu ....................................................... 40

XGA MODE ........................................................... 40

REFRESH RATE ................................................... 40

SYNC .................................................................... 41

SDI THROUGH ..................................................... 41

Input signal display ................................................ 41

OPTIONS Adjustments ........................................... 42

Watching Videos and DVDs ................................... 43

Programming the Remote to Operate Peripheral

Equipment ............................................................. 44

Troubleshooting ..................................................... 45

List of Aspect Modes ............................................. 46

Remote Control Operation / Code List ................. 47

Applicable Input Signals ........................................ 50

Specifications ......................................................... 52

Panasonic Professional Flat Panel Display Limited Warranty

.. 53

LIMITED WARRANTY STATEMENT ....................... 54

Customer Service ................................................... 55

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

FCC CAUTION:

To assure continued compliance, follow the attached installation instructions and use only shielded interface

cables when connecting to computer or peripheral devices. Any changes or modifications not expressly

approved by Panasonic Corp. of North America could void the user’s authority to operate this device.

FCC Declaration of Conformity

Model No. TH-50VX100U, TH-65VX100U

Responsible Party: Panasonic Corporation of North America

One Panasonic Way 1F-10, Secaucus, NJ 07094

Contact Source: Panasonic Professional Display Company

Panasonic Plasma Concierge 1-800-973-4390

CANADIAN NOTICE:

This Class B digital apparatus complies with Canadian ICES-003.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent image retention to

remain on the Plasma Display.

Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

Trademark Credits

• VGA is a trademark of International Business Machines Corporation.

• Macintosh is a registered trademark of Apple Computer, USA.

• SVGA, XGA, SXGA and UXGA are registered trademarks of the Video Electronics Standard Association.

Even if no special notation has been made of company or product trademarks, these trademarks have been fully

respected.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC.

FCC STATEMENT

Safety Precautions

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional

accessories may cause instability which could result in the possibility of injury.

(All of the following accessories are manufactured by Panasonic Corporation.)

CAUTION

When using the Plasma Display

Do not bring your hands, face or objects close to the

ventilation holes of the Plasma Display.

• Top of the Plasma Display is usually very hot due to the

high temperature of exhaust air being released through

the ventilation holes. Burns or personal injuries can

happen if any body parts are brought too close. Placing

any object near the top of the display could also result

in heat damages to the object as well as to the Display if

its ventilation holes are blocked.

Be sure to disconnect all cables before moving the

Plasma Display.

• Moving the Display with its cables attached might

damage the cables which, in turn, can cause fire or

electric shock.

Disconnect the power plug from the wall outlet as a

safety precaution before carrying out any cleaning.

• Electric shocks can result if this is not done.

Clean the power cable regularly to prevent it from

becoming dusty.

• Built-up dust on the power cord plug can increase

humidity which might damage the insulation and cause

fire. Unplug the cord from the wall outlet and clean it

with a dry cloth.

This Plasma Display radiates infrared rays,

therefore it may affect other infrared communication

equipment.

Install your infrared sensor in a place away from

direct or reflected light from your Plasma Display.

Note:

Do not allow a still picture to be displayed for an

extended period, as this can cause a permanent image

retention to remain on the Plasma Display.

Examples of still pictures include logos, video games,

computer images, teletext and images displayed in 4:3

mode.

Pedestal ................................................................................ TY-ST50VX100 (for TH-50VX100U),

TY-ST65VX100 (for TH-65VX100U)

Wall-hanging bracket (vertical).............................................. TY-WK42PV7 (for TH-50VX100U),

TY-WK65PV7 (for TH-65VX100U)

Wall-hanging bracket (angled) .............................................. TY-WK42PR7 (for TH-50VX100U),

TY-WK65PR8 (for TH-65VX100U)

BNC Component Video Terminal Board ...............................TY-42TM6A

RCA Component Video Terminal Board ................................TY-42TM6Z

HD-SDI Terminal Board ........................................................TY-FB9HD

HD-SDI Terminal Board with audio .......................................TY-FB10HD

Dual Link HD-SDI Terminal Board ........................................TY-FB11DHD

Dual HDMI Terminal Board ...................................................TY-FB10HMD

DVI-D Terminal Board ...........................................................TY-FB11DD

Ir Through Terminal Board ....................................................TY-FB9RT

•

Always be sure to ask a qualified technician to carry out set-up.

Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard

unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from

being played with by young children, creating the potential risk of suffocation.

Safety Precautions / Maintenance

WARNING

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning

cloth or a soft, lint-free cloth.

• If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water in

which neutral detergent has been diluted 100 times, and then wipe it evenly with a dry cloth of the same type until

the surface is dry.

• Do not scratch or hit the surface of the panel with fingernails or other hard objects, otherwise the surface may

become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner,

otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

• If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been

added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.

• Do not allow any detergent to come into direct contact with the surface of the Plasma Display. If water droplets get

inside the unit, operating problems may result.

• Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the

cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods

in contact with articles made from rubber or PVC.

Maintenance

Setup

Do not place the Plasma Display on sloped or

unstable surfaces.

• The Plasma Display may fall off or tip over.

Do not place any objects on top of the Plasma

Display.

• If water spills onto the Plasma Display or foreign

objects get inside it, a short-circuit may occur which

could result in fire or electric shock. If any foreign

objects get inside the Plasma Display, please consult

an Authorized Service Center.

Do not cover the ventilation holes.

• Doing so may cause the Plasma Display to overheat,

which can cause fire or damage to the Plasma Display.

Transport only in upright position!

• Transporting the unit with its display panel facing

upright or downward may cause damage to the

internal circuitry.

If using the pedestal (optional accessory), leave a space

of 3 15/16” (10 cm) or more at the top, left and right,

and 2 3/4” (7 cm) or more at the rear, and also keep the

space between the bottom of the display and the floor

surface. If using some other setting-up method, follow

the manual of it. (If there is no specific indication of

installation dimension in the installation manual, leave

a space of 3 15/16” (10 cm) or more at the top, bottom,

left and right, and 2 3/4” (7 cm) or more at the rear.)

An apparatus with CLASS I construction shall be

connected to a mains socket outlet with a protective

earthing connection.

AC Power Supply Cord

The Plasma Display is designed to operate on 110 - 127 V

AC, 50/60 Hz.

Do not use any power supply cord other than that

provided with this unit.

• Doing so may cause fire or electric shocks.

Securely insert the power cord plug as far as it will go.

• If the plug is not fully inserted, heat may be generated

which could cause fire. If the plug is damaged or the

wall socket plate is loose, they should not be used.

Do not handle the power cord plug with wet hands.

• Doing so may cause electric shocks.

Do not do anything that might damage the power cable. When

disconnecting the power cable, hold the plug, not the cable.

• Do not make any modifications, place heavy objects

on, place near hot objects, heat, bend, twist or

forcefully pull the power cable. Doing so may cause

damage to the power cable which can cause fire or

electric shock. If damage to the cable is suspected,

have it repaired at an Authorized Service Center.

If the Plasma Display will not be used for a long period

of time, unplug the power cord from the wall outlet.

If problems occur during use

If a problem occurs (such as no picture or no sound),

or if smoke or an abnormal odor is detected from the

Plasma Display, unplug the power cord immediately.

• Continuous use of the Display under these conditions

might cause fire or permanent damage to the unit.

Have the Display evaluated at an Authorized Service

Center. Services to the Display by any unauthorized

personnel are strongly discouraged due to its high

voltage dangerous nature.

If water or foreign objects get inside the Plasma Display, if

the Plasma Display is dropped, or if the cabinet becomes

damaged, disconnect the power cord plug immediately.

•

A short may occur, which could cause fire. Contact an

Authorized Service Center for any repairs that need to be made.

COMPO.

FUNCTION

DISPLAY


POS.

/SIZE

INPUTCH VIDEO

HDMI

OFF TIMER

EXT.SCALER

フ

DISPLAY

MEM.

LOAD

“AA” size

Open

Hook

Accessories

Requires two AA batteries.

2. Insert batteries - note correct polarity ( + and -).

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.

Disposal of batteries should be in an environment-friendly manner.

Observe the following precautions:

1. Batteries should always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5. Battery replacement is necessary when the remote control acts sporadically or stops operating the Plasma Display.

6. Do not burn or breakup batteries.

Batteries must not be exposed to excessive heat such as sunshine, fire or the like.

7. Make a note of the remote control codes before changing batteries in case the codes are reset. (see page 44)

Accessories Supplied

Check that you have the Accessories and items shown

Operating

Instruction book

Remote Control

Transmitter

N2QAYB000323

Batteries for the

Remote Control

Transmitter

(2 × AA Size)

AC cordFixing band × 1

Remote Control Batteries

Helpful Hint:

For frequent remote control users, replace old batteries with Alkaline batteries for longer life.

1. Pull and hold the hook, then open the battery cover.

SERIALPC IN

AUDIO

SLOT1 SLOT2 SLOT3

COMPONENT/RGB IN

AUDIO

/R P

Y/G

Connections

– Cable fixing band

Secure any excess cables with band as required.

Note:

Make sure that the AC

cord is locked on both

the left and right sides.

Push until

the hook

clicks.

Keep the

knob pressed.

Open

1 Plug the AC cord into

the display unit.

Plug the AC cord until it

clicks.

2 Fix the AC cord with

the clamper which is

attached to the unit.

Note:

One fixing band is supplied with this unit. In case of securing cables at two positions, please purchase it separately.

Speaker

terminal (R)

Speaker

terminal (L)

When connecting the speakers, be sure to use only the optional accessory speakers.

Refer to the speaker’s Installation Manual for details on speaker installation.

Pass the attached cable

fixing band through the

clip as shown in the

figure.

To secure cables connected to Terminals, wrap the cable fixing band around them

then pass the pointed end through the locking block, as shown in the figure.

While ensuring there is sufficient slack in cables to minimize stress (especially

in the power cord), firmly bind all cables with the supplied fixing band.

From SERIAL

Terminal on

Computer

(see page 11)

From EXTERNAL

monitor terminal

on Computer

(see page 10)

AC cord connection (see page 13)

Dual HDMI Terminals (equivalent

of Dual HDMI Terminal Board

(TY-FB10HMD))

(see page 12)

To tighten: To loosen:

Pull

Push the catch

Note: At factory shipment, Terminal boards are installed in SLOT 1, SLOT 2 and SLOT 3.

– AC cord fixing

COMPONENT/RGB IN and

Audio IN Terminals (equivalent

of RCA Component Video

Terminal Board (TY-42TM6Z))

(see page 12)

Unplug the AC cord

Unplug the AC

cord pressing the

two knobs.

Note:

When disconnecting the AC

cord, be absolutely sure to

disconnect the AC cord plug at

the socket outlet first.

2. Pull off.

AUDIO

PC IN

PC Input Terminals connection

Notes:

Due to space limitations, occasionally you may have trouble connecting Mini D-sub 15P cable with ferrite core to PC

input Terminal.

With regard to the typical PC input signals that are described in the applicable input signals list (see page 50),

adjustment values such as for the standard picture positions and sizes have already been stored in this unit. You can

add up to eight PC input signal types that are not included in the list.

Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning

frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

The display resolution is a maximum of 1,440 × 1,080 dots when the aspect mode is set to “4:3”, and 1,920 × 1,080

dots when the aspect mode is set to “FULL”. If the display resolution exceeds these maximums, it may not be possible

to show fine detail with sufficient clarity.

The PC input terminals are DDC2B-compatible. If the computer being connected is not DDC2B-compatible, you will

need to make setting changes to the computer at the time of connection.

Some PC models cannot be connected to the set.

There is no need to use an adapter for computers with DOS/V compatible Mini D-sub 15P terminal.

The computer shown in the illustration is for example purposes only.

Additional equipment and cables shown are not supplied with this set.

Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified

frequency range.

Component Input is possible with the pin 1, 2, 3 of the Mini D-sub 15P Connector.

Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”

(when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 39)

•

Signal Names for Mini D-sub 15P Connector

Pin Layout for PC Input

Terminal

COMPUTER

Conversion adapter

(if necessary) Mini D-sub 15p

RGB

PC cable

Stereo plug

Audio

Connect a cable which matches

the audio output terminal on the computer.

678

15 14 13 12 11

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

1R (PR/CR)6GND (Ground)

NC (not connected)

2G (Y) 7GND (Ground)

SDA

3B (PB/CB)8GND (Ground)

HD/SYNC

NC (not connected)

9+5 V DC

5GND (Ground)

GND (Ground)

SCL

Connections

(Male)

(Female)

SERIAL

6789

13452

Connections

SERIAL Terminals connection

Notes:

Use the RS-232C straight cable to connect the computer

to the Plasma Display.

The computer shown is for example purposes only.

Additional equipment and cables shown are not supplied

with this set.

The SERIAL terminal conforms to the RS-232C interface

specification, so that the Plasma Display can be controlled

by a computer which is connected to this terminal.

The computer will require software which allows the

sending and receiving of control data which satisfies

the conditions given below. Use a computer application

such as programming language software. Refer to the

documentation for the computer application for details.

•

The SERIAL terminal is used when the Plasma Display is controlled by a computer.

Basic format for control data

The transmission of control data from the computer starts with

a STX signal, followed by the command, the parameters, and

lastly an ETX signal in that order. If there are no parameters,

then the parameter signal does not need to be sent.

Start

(02h)

3-character

command (3 bytes)

Colon Parameter(s)

(1 - 5 bytes)

End

(03h)

STX C1 C2 C3 P1 P2 P3 P4

: P5 ETX

Notes:

If multiple commands are transmitted, be sure to wait for

the response for the first command to come from this unit

before sending the next command.

If an incorrect command is sent by mistake, this unit will

send an “ER401” command back to the computer.

SL1A, SL1B, SL2A and SL2B of Command IMS are

available only when a dual input terminal board is attached.

•

Pin layout for SERIAL Terminal

COMPUTER

RS-232C Straight cable

D-sub 9p

Command Parameter Control details

PON None Power ON

POF None Power OFF

AVL ** Volume 00 - 63

IMS None

SL1

SL2

SL3

PC1

SL1A

SL1B

SL2A

SL2B

Input select (toggle)

Slot1 input

Slot2 input

Slot3 input

PC input

Slot1 input (INPUT1A)

Slot1 input (INPUT1B)

Slot2 input (INPUT2A)

Slot2 input (INPUT2B)

DAM None

ZOOM

FULL

JUST

NORM

SJST

SNOM

SFUL

Screen mode select (toggle)

ZOOM

FULL

JUST

4:3

JUST

4:3

H-FILL

With the power off, this display responds to PON

command only.

Command

Signal level RS-232C compliant

Synchronization method Asynchronous

Baud rate 9600 bps

Parity None

Character length 8 bits

Stop bit 1 bit

Flow control -

Signal names for D-sub 9P connector

Pin No. Details

2R X D

3T X D

5GND

4 • 6Non use

8(Shorted in this set)

1 • 9NC

These signal names are those of computer specifications.

Communication parameters

(Male)

(Female)

PC I

SLOT1 SLOT2 SLOT3

COMPONENT/RGB IN

AUDIO

/R P

Y/G

HDMI

AV OUT

HDMI

AV OUT

HDMI

AV OUT

HDMI

AV OUT

SLOT3

COMPONENT/RGB IN

AUDIO

/R P

Y/G

AUDIO

OUT

Y , P

B,P R,

OUT

P B

NENT VIDE

Connections

COMPONENT / RGB connection

Notes:

Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”

(when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 39)

Additional equipment, cables and adapter plugs shown are not supplied with this set.

SYNC ON G signal is needed. (see page 41)

•

Computer RGB Camcorder

DVD

Example of input signal source

Digital TV-SET-TOP-BOX

(DTV-STB)

HDMI connection

This unit has terminal boards equivalent to Dual HDMI Terminal Board (TY-FB10HMD) and RCA Component Video

Terminal Board (TY-42TM6Z) as standard equipment.

HDMI cables

DVD Player or SET-TOP-BOX

(HDMI compatible machines only)

[Pin assignments and signal names]

3 1

Note:

Additional equipment and HDMI cables

shown are not supplied with this set.

Pin No.

Signal

Pin No.

Signal

1T.M.D.S Data2+

T.M.D.S Clock

Shield

2T.M.D.S Data2

Shield

T.M.D.S Clock-

3T.M.D.S Data2-

CEC

4T.M.D.S Data1+

Reserved

(N.C. on device)

5T.M.D.S Data1

Shield

6T.M.D.S Data1-

SCL

7T.M.D.S Data0+

SDA

8T.M.D.S Data0

Shield

DDC/CEC

Ground

9T.M.D.S Data0-

+5V Power

T.M.D.S Clock+

Hot Plug Detect

HDMI cables

HDMI

INPUT MENU

INPUT MENU OK

FULL

English (UK)

Deutsch

Français

Italiano

ENGLISH (US)

Русский

OSD LANGUAGE

Español

Power

Indicator

Remote Control

Sensor

Power ON / OFF

Connecting the AC cord plug to the Plasma Display.

Fix the AC cord plug securely to the Plasma Display

with the clamper. (see page 9)

Connecting the plug to the Wall Outlet.

Note:

When disconnecting the AC cord, be absolutely sure to

disconnect the AC cord plug at the socket outlet first.

Press the Power switch on the Plasma Display to

turn the set on: Power-On.

Power Indicator: Green

Press the button on the remote control to turn the Plasma Display off.

Power Indicator: Red (standby)

Press the button on the remote control to turn the Plasma Display on.

Power Indicator: Green

Turn the power to the Plasma Display off by pressing the switch on the unit, when the

Plasma Display is on or in standby mode.

Note:

During operation of the power management function, the power indicator turns orange in the power off state.

From the second time

on, the below screen is

displayed for a while (setting

condition is an example).

Notes:

Once the language is set, this screen won’t be displayed when switching on the unit next time.

After the setting, language selection can be done from the SET UP menu. (see page 14)

•

When first switching on the unit

Following screen will be displayed when the unit is

turned on for the first time.

Select the language with the remote control. Unit

buttons are invalid.

1 Select the language.

2 Set.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE OFF

OFF

RGB

OSD POSITION UPPER LEFT

SCREENSAVER

SIGNAL

OSD LANGUAGE ENGLISH (US)

HDMI

INPUT MENU

ENTER/

■

ENTER/

■

INPUT

SET UP

POS. /SIZE

SOUND


INPUT

Press to select the input signal to be played back from the

equipment which has been connected to the Plasma Display.

HDMI1

HDMI2

HDMI3

HDMI4

COMPONENT

INPUT

HDMI signal terminal in SLOT1

HDMI signal terminal in SLOT2

COMPONENT or RGB signal terminal in SLOT3

PC signal terminal in PC IN

Using dedicated buttons for input selection

Press to select HDMI signal terminals 1–4 in SLOT 1 and 2.

Press to select component or RGB signal terminal in SLOT 3.

Press to select PC signal terminal in PC IN.

Initial selections

Selecting the On-Screen Menu Language

Selecting the input signal

Press to display the menu screen.

Press to select “SET UP”.

Press to display the SET UP menu.

Press to select

OSD LANGUAGE.

Press to select your

preferred language.

Select the input signals to be connected by installing the optional Terminal Boards.

Notes:

Selecting is also possible by pressing the INPUT button on the unit.

Input terminal will not be selected if the terminal board is not installed into the SLOT.

Select to match the signals from the source connected to the component/RGB input

terminals. (see page 39)

Image retention (image lag) may occur on the plasma display panel when a still

picture is kept on the panel for an extended period. The function that darkens the

screen slightly is activated to prevent image retention (see page 45), but this function

is not the perfect solution to image retention.

•

COMPO.

INPUTCH

HDMI

フ

DISPLAY

INPUTCH

HDMI

フ

COMPO.

Selectable languages

English(UK)

Deutsch

Français

Italiano

Español

ENGLISH(US)

(Japanese)

 (Russian)

SET UP menu

INPUT MENU

ENTER/

■

Basic Controls

Remote control

sensor

Main Unit

Main Power On / Off Switch

Enter / Aspect

button

(see page 18, 19)

When the menu screen is displayed:

“” :

press to move the cursor up

“” :

press to move the cursor

down

(see page 19)

INPUT button

(INPUT1, INPUT2, INPUT3

and PC selection)

(see page 14)

Power Indicator

The Power Indicator will light.

• Power-OFF ... Indicator not illuminated (The unit

will still consume some power

as long as the power cord is still

inserted into the wall outlet.)

• Standby ........ Red

• Power-ON ..... Green

• DPMS............ Orange (With PC input signal

and during operation of PC’s

screensaver.)

MENU Screen ON / OFF

Each time the MENU button is pressed, the

menu screen will switch. (see page 19)

COMPO.

FUNCTION

DISPLAY


POS.

/SIZE

INPUTCH VIDEO

HDMI

OFF TIMER

EXT.SCALER

フ

DISPLAY

MEM.

LOAD

Standby (ON / OFF) button

The Plasma Display must first be plugged

into the wall outlet and turned on at the

power switch (see page 13).

Press this button to turn the Plasma

Display On, from Standby mode. Press

it again to turn the Plasma Display Off to

Standby mode.

Remote Control Transmitter

Basic Controls

POS. /SIZE button

(see page 31)

PICTURE button

(see page 21)

LIGHT button

Lights the INPUT and VIDEO MENU

buttons for 5 seconds. Makes the

selected remote control mode key

(DISPLAY, VCR, DBS/CBL or DVD) flash

three times. Press again to turn off the

INPUT and VIDEO MENU button lights.

Equipment (Remote control mode)

selection buttons (see page 43, 44)

MENU button

Displays menu screen. (see page 19)

FUNCTION button

(see page 17)

RETURN button (see page 19)

Press the RETURN button to return to

previous menu screen.

POSITION buttons

PC button

Press to select PC input. (see page 14)

OK button

Press to make selections.

COMPO. button

Press to select COMPONENT or RGB

input. (see page 14)

DIRECT INPUT buttons

Press the each button to select

the INPUT mode. (see page 14)

This button is used to switch

directly to INPUT mode.

VIDEO MENU button

Press to select PICTURE MENU.

(see page 21)

MONITOR

STANDARD

CINEMA

DYNAMIC

External equipment operations

(see page 43)

Numeric buttons

(see page 27)

OFF TIMER button

The Plasma Display can be preset to

switch to stand-by after a fixed period.

The setting changes to 30 minutes, 60

minutes, 90 minutes and 0 minutes (off timer

cancelled) each time the button is pressed.

30 60

When three minutes remain, “OFF

TIMER 3” will flash.

The off timer is cancelled if a power

interruption occurs.

MEM. LOAD button

(see page 27)

INPUT button

(see page 14)

ASPECT button

Press to adjust the aspect.

(see page 18)

EXT.SCALER button

(see page 17) RECALL button

Press to display the current system status.

Input label

Aspect mode (see page 18)

Off timer

The off timer indicator is displayed

only when the off timer has been set.

OFF TIMER 90

4:3

Basic Controls

SCROLLING BAR and TEST PATTERNS functions

Pressing activates one of the following two functions. The function button setting can be configured by accessing

“Function button assign” in the OPTIONS menu. (see page 42)

SCROLLING BAR TEST PATTERNS

EXT. SCALER function

Each time you press , an external scaler is activated or deactivated.

EXTERNAL SCALER MODE

OFF: Use the built-in scaler.

ON: Use an external scaler.

The setting is valid with the following signals.

1125 (1080) / 24p • 25p • 30p • 50p • 60p

With input signals other than these, specifying “ON” will display the following message.

EXTERNAL SCALER MODE

Input signal must be 1125p(1080p)

Note:

You can also turn the built-in scaler ON and OFF by accessing “EXTERNAL SCALER MODE” in the SET UP menu.

(see page 36)

Press

YES N O

SCROLLING BAR

Press to

select

“YES”.

Press.

Activates the SCROLLING BAR ONLY screensaver. After

15 minutes, the display enters standby mode.

SCROLLING BAR ONLY

To exit this mode, press any button.

Press

YES N O

TEST PATTERNS

Press to

select

“YES”.

Press.

Each time you press , a different test pattern is

displayed (seven in all).

Color Bars Red Green

Blue

Frame

(2 lines × 2 dots)

Black 1% window

To exit this mode, press any button other than .

Note:

AUTO POWER OFF is deactivated during SCROLLING BAR or TEST PATTERNS operation. (see page 37)

HDMI

ENTER/

■

INPUT

ASPECT Controls

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture.

Note:

Be aware that if you put the display in a public place for commercial purposes or a public showing and

then use the aspect mode select function to shrink or expand the picture, you may be violating the

for commercial purposes without the prior permission of the copyright holder.

Press repeatedly to move through the aspect options:

For details about the aspect mode, please see “List of Aspect Modes” (page 46).

The aspect mode changes each time the ENTER button is pressed.

[from the unit]

4:3 H-FILL ZOOM FULL JUST

4:3 ZOOM FULL

For PC signal input:

Notes:

The aspect mode is memorized separately for each input terminal.

Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a permanent image

retention to remain on the Plasma Display Panel.

•

4:3 ZOOM JUSTFULL

For SD signal input (525 (480) / 60i • 60p, 625 (575) / 50i • 50p):

For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:

All Aspect mode

Set “All Aspect” to “On” in OPTION menu to enable the extended aspect mode (page 42). When All Aspect mode, the

aspect mode of pictures is switched as follows. For details about the aspect mode, please see “List of Aspect Modes”

(page 46).

For SD signal input (525 (480) / 60i

•

60p, 625 (575) / 50i

•

50p):

4:3 Zoom 16:9

For PC signal input:

For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:

4:3 Zoom1 16:9 JustZoom2 Zoom3 14:9

4:3 Full Zoom1 16:9 Just1Zoom2 Zoom3 14:9 Just2 4:3 (1) 4:3 (2)

HDMI

DISPLAY


POS.

/SIZE

Press to

return to the

menu.

On-Screen Menu Displays

Various menus allow you to make settings for the picture, sound, and other functions so that you can enjoy watching

Display best suited for you.

Remote Control Unit

1Display the menu screen.

SET UP

POS. /SIZE

SOUND

OPTIONS


STANDARD

ADVANCED SETTINGS

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

PICTURE MENU

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

press

press several

times

Each time the MENU

button is pressed, the

menu screen will switch.

Normal Viewing


SET UP

POS. /SIZE

SOUND

2Select the menu.

SET UP

POS. /SIZE

SOUND

OPTIONS


1 select

2 press

(Example: SOUND menu)

Menus can also be accessed directly by pressing dedicated buttons, such as and .

(see page 21, 31)

3Select the item.

STANDARDAUDIO MENU

OFF

BASS

NORMAL IZE

MID

TREBLE

BALANCE

SURROUND

VOLUME

select

ENTER/

■

select

press

(Example: SOUND menu)

4Set. set

ENTER/

■

set

press

5Exit the menu. press

press several

times

SET UP

POS. /SIZE

SOUND

OPTIONS


STANDARD

ADVANCED SETTINGS

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

COLOR

TINT

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

DISPLAY SIZE

H-POS

OFF

H-SIZE

AUTO SETUP

NORMAL IZE

V-POS

0V-SIZE

DOT CLOCK

-16CLOCK PHASE

1:1 PIXEL MODE

OFF

STANDARDAUDIO MENU

OFF

BASS

NORMAL IZE

MID

TREBLE

BALANCE

SURROUND

VOLUME

OnOnscreen display

OffAll Aspect

OffStudio mode

Scrolling barFunction button assign

Memory lock

CHANNEL 1LEFT CHANNEL

SDI SOUND OUTPUT 2

CHANNEL 2RIGHT CHANNEL

ONSOUND OUT

OFFLEVEL METER

NEGATIVE IMAGE

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

see page 21-30

see page 31-41

see page 31, 32

see page 33

see page 42

see page 33

see page 40, 41

see page 34, 35

2.2

OFF

INPUT LEVEL

ADVANCED SETTINGS

NORMAL IZE

GAMMA

AGC

W/B HIGH R

W/B HIGH G

0W/B HIGH B

W/B LOW R

0W/B LOW G

W/B LOW B

3:2 PULLDOWN

STUDIO GAIN

NOISE REDUCTION

BLACK EXTENSION

see page 23, 24

Overview

Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.

On-Screen Menu Displays

1024 ×768XGA MODE

100 HzREFRESH RATE

SIGNAL [ COMPONENT ]

PICTURE Adjustments

1Display the menu screen.

2Select “PICTURE”.

SOUND


SET UP

POS. /SIZE

2 OK

1 select

3Select the item and set.

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

2 adjust or select

1 select

4Exit the menu.

Using for menu display

To display a menu for adjustment of the PICTURE menu on the bottom of the screen, press

25PICTURE

2 adjust or select

1 select

To display a menu for ADVANCED SETTINGS adjustment, press again.

0BLACK EXTENSION

To hide the menu, press or

● PICTURE MENU

You can switch to the optimal picture mode for the video source

and viewing environment. MONITOR

STANDARD

CINEMA

DYNAMIC

STANDARD:

For viewing in standard (evening lighting) environments.

This menu selects the normal levels of BRIGHTNESS

and PICTURE.

DYNAMIC:

For viewing in brighter environments. This menu

selects higher than normal levels of BRIGHTNESS and

PICTURE.

CINEMA:

Ideal for movies.

MONITOR:

For use when creating broadcast or movie content. With

this picture, even if the overall average picture level

(APL) changes, the brightness of areas with the same

signal level does not change.

Notes:

When “MONITOR” is selected in PICTURE MENU, the following menu items cannot be set.

PICTURE menu: PICTURE

SCREENSAVER menu: PEAK LIMIT (see page 35)

SET UP menu: POWER SAVE (see page 37)

If you would like to change the picture and color of the selected PICTURE menu to something else, adjust using the

items in the PICTURE menu. (see next page)

•

During “RGB” and “PC” input

signal.

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

During “Digital” and

“COMPONENT” input signal.

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

COLOR

TINT

While the “PICTURE” menu is displayed, if the OK button is pressed during “NORMALIZE”, then all adjustment

values are returned to the factory settings.

Helpful Hint (

NORMALIZE

Normalization)

PICTURE Adjustments

● PICTURE Adjusts the proper picture contrast.

Less More

● BRIGHTNESS Adjusts for easier viewing of dark pictures

such as night scenes and black hair. Darker Brighter

● COLOR Adjusts color saturation.

Less More

● TINT Adjusts for natural flesh tones.

Reddish Greenish

● SHARPNESS Adjusts picture sharpness.

Less More

● COLOR TEMP Switches to various screen color tones.

NORMAL: Intermediate color temperature.

COOL: Colors with a bluish tinge.

STUDIO: Optimal color temperature for studio viewing

(3200 K).

WARM: Colors with a reddish tinge.

WARM

NORMAL

STUDIO*

COOL

* “STUDIO” can be modified when

“Studio mode” in the OPTIONS menu

is “On”. (see page 42)

● COLOR MANAGEMENT

OFF ON

ON: Enables color adjustment automatically.

Notes:

“COLOR” and “TINT” settings cannot be adjusted for “RGB/PC” input signal.

You can change the level of each function (PICTURE, BRIGHTNESS, COLOR, TINT, SHARPNESS) for each

PICTURE MENU.

The setting details for STANDARD, DYNAMIC and CINEMA respectively are memorized separately for each input

terminal.

In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with

a dark picture.

•

Enables fine picture adjustment at a professional level.

Notes:

The adjustment values are memorized separately for each input terminal.

The adjustment range values should be used as an adjustment reference.

•

ADVANCED SETTINGS

PICTURE Adjustments

Carry out “W/B” adjustment as follows.

Adjust the white balance of the bright sections using the “W/B HIGH R” , “W/B HIGH G” and “W/B HIGH B” settings.

2. Adjust the white balance of the dark sections using the “W/B LOW R” , “W/B LOW G” and “W/B LOW B” settings.

3. Repeat steps 1 and 2 to adjust.

Steps 1 and 2 affect each other’s settings, so repeat each step in turn to make the adjustment.

● BLACK

EXTENSION

Adjusts the dark shades of the image in gradation.

Less More

● INPUT LEVEL Adjustment of parts which are extremely bright and hard to see.

Less More

● GAMMA Available setting values vary depending on “PICTURE MENU”

settings and the type of input signal, as follows.

Down Up

PICTURE MENU S CURVE 1.0 2.0 2.2 2.5 2.6

STANDARD –*3*1

DYNAMIC *3–*1

CINEMA –*3*2

MONITOR –*3–

*1 When 2k1k signals are received with the Dual Link HD-SDI Terminal Board

(TYFB11DHD), GAMMA “2.6” can also be selected.

*2 When 60 Hz signals are received, GAMMA “2.5” can also be selected.

*3 When 2k1k signals are received with the Dual Link HD-SDI Terminal Board

(TY-FB11DHD), GAMMA “1.0” cannot be selected.

● AGC Increases the brightness of dark signal automatically.

OFF ON

● “W/B” adjustment

Less More

W/B HIGH R

W/B HIGH G

W/B HIGH B

0W/B LOW R

W/B LOW G

0W/B LOW B

Adjusts the white balance for light red, light

green or light blue areas.

Adjusts the white balance for dark red, dark

green or dark blue areas.

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

2.2

OFF

INPUT LEVEL

BLACK EXTENSION

ADVANCED SETTINGS

NORMAL IZE

GAMMA

AGC

W/B HIGH R

W/B HIGH G

W/B HIGH B

0W/B LOW R

W/B LOW G

0W/B LOW B

3:2 PULLDOWN

STUDIO GAIN

NOISE REDUCTION

PICTURE Adjustments

On the remote control unit, while the “ADVANCED SETTINGS” menu is displayed, if the OK button is pressed during

“NORMALIZE”, then all adjustment values are returned to the factory settings.

Helpful Hint (

NORMALIZE

Normalization)

● 3:2

PULLDOWN

When “ON”, the display attempts to reproduce a more natural

interpretation of sources such as movie pictures, which are

recorded at 24 frames per second.

If the picture is not stable, turn the setting to “OFF”.

OFF ON

Note:

When “ON”, this setting only affects the following signal input:

525i (480i), 625i (575i), 1125 (1080) / 60i signal input during “COMPONENT” input signal.•

● STUDIO GAIN Sharpens the contrast for a better view when a part of the image

is too light to see. OFF ON

OFF: Disables “STUDIO GAIN”.

ON: Enables “STUDIO GAIN”.

Notes:

“STUDIO GAIN” can be modified when “Studio mode” in the OPTIONS menu is “On”. When “Studio mode” is “Off”,

this setting is “OFF” and cannot be changed. (see page 42)

This setting is valid only when the input signals are as follows:

Component Video, RGB (analog), SDI, HDMI

•

● NOISE REDUCTION Sets the following three NR (Noise Reduction) functions together.

VIDEO NR, MOSQUITO NR, BLOCK NR

OFF

MID

MIN

ADVANCED MAX

[Advanced NR]

Sets the three NR functions separately.

1Select “ADVANCED”.

OFF

ADVANCED

VIDEO NR

MOSQUITO NR

OFFBLOCK NR

NOISE REDUCTION

select

2Select the item and set.

OFF

ADVANCED

VIDEO NR

MOSQUITO NR

OFFBLOCK NR

NOISE REDUCTION

2 set

1 select

OFF

MID

MIN

MAX

VIDEO NR: Automatically reduces unwanted picture noise.

MOSQUITO NR: Reduces mosquito noise around subtitles on MPEG videos.

BLOCK NR: Reduces block noise when playing MPEG videos.

Notes:

“NOISE REDUCTION” cannot be adjusted while a PC signal is being applied.

“BLOCK NR” cannot be adjusted while a HD signal is being applied.

•

Picture Profiles

Up to 16 combinations of picture adjustment values (in the PICTURE menu and ADVANCED SETTINGS) can be stored

in the display memory as profiles and applied as needed, for a convenient way to enjoy your preferred picture settings.

Custom picture

PICTURE MENU DYNAMIC

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

ADVANCED SETTINGS

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

6COLOR

0TINT

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

COLOR

TINT

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

Memory lock

Onscreen display

Scrolling bar

Off

All Aspect

Studio mode

Function button assign

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

COLOR

TINT

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

STANDARD

ADVANCED SETTINGS

PICTURE MENU

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

COLOR

TINT

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

Original picture

Lock profiles (page 29, 30) Save the picture

adjustment values in the

MEMORY1 profile

Save profiles

Apply the MEMORY1

profile

Load the profile

MEMORY1

MEMORY2

MEMORY3

MEMORY4

MEMORY16

Edit the profile

Delete or rename

the profile

Save profiles (page 26)

Load profiles (page 27)

Edit profiles (page 28)

Locked profile

My Memory

MEMORY2

MEMORY3

MEMORY4

MEMORY16

Follow these steps to save picture adjustment values as profiles.

Picture Profiles

Saving profiles

1Specify the picture quality in the PICTURE menu

and ADVANCED SETTINGS. (see page 21-24)

2In the PICTURE menu, select “MEMORY SAVE”.

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

2 OK

1 select

3Select a profile name for saving the picture

adjustment values.

1. [] MEMORY1

MEMORY2

2. []

MEMORY3

3. [ 1]

MEMORY4

4. []

MEMORY13

13. []

MEMORY1414. []

MEMORY15

15. []

MEMORY16

16. []

MEMORY SAVE

2 OK

1 select

Profiles are labeled with these icons to indicate their

locked status. (see page 27)

[ ], [ ]:Settings can be saved in this profile.

[ ], [ ]:Settings cannot be saved in this profile.

4Select “OK”.

OK CANCEL

MEMORY SAVE

SAVE THE ADJUSTED VALUE IN MEMORY1

1 select

2 OK

5Enter a name for the profile.

[Entering profile names]

Profile names can be up to 16 characters.

To enter text, select characters in the on-screen

keyboard.

Edit the default profile name in the text box as

desired.

MEMORY1

█

MEMORY NAME INPUT

B C D E F G H I J K L M ALL DELETE

N O P Q R S T U V W X Y Z DELETE

SPACE

abcdefghi jklm

nopq r s t uvwxyz

0123456789

!”#$%&’ +–/=?

_` |~<>( ) [ ] { } ,

@\ ˆ

.;:

CANCEL

1 select

2 OK

Example: Specifying “MY PICTURE”

1 Select “ALL DELETE”.

MEMORY1

█

All text is deleted.

To delete individual characters, select “DELETE”.

2 Select “M”.

█

Repeat this process to enter the next character.

3 Select “Y”.

█

4 Select “SPACE”.

█

6When you finished entering the profile name, select

“OK”.

To cancel saving the profile, select “CANCEL”.

ABCDEFGH I JK LM

NOPQRSTUVWXYZ

abcde f gh i j k lm

nopq r s t uvwxyz

0123456789

!”#$%&’ +–/=?

_` |~<>( ) [ ] { } ,

@\ ˆ

.;:

MEMORY NAME INPUT

ALL DELETE

DELETE

SPACE

CANCEL

MY PICTURE

█

1 select

2 OK

Picture Profiles

Load profiles and apply the picture adjustment values to the display as follows.

Note:

Loaded profiles are stored in memory according to the selected input interface (SLOT1, 2, 3 or PC IN).

1In the PICTURE menu, select “MEMORY LOAD”.

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

2 OK

1 select

2Select the profile to load.

MEMORY1212. [2]

1. [] MEMORY1

MEMORY2

2. [1]

2 OK

1 select

Profiles are labeled with these icons to indicate their

locked status. (see below)

1Press to list the profiles.

2Select the profile to load.

MEMORY1212. [2]

1. [] MEMORY1

MEMORY2

2. [1]

2 OK

1 select

Profiles are labeled with these icons to indicate their

locked status. (see below)

To load profiles 1–9

1Press a button in the range – .

2Select “OK”.

OK CANCEL

MEMORY LOAD

LOAD FROM MEMORY2

select

2 OK

To load profiles 10–16

Example: To load profile 16

1Press .

The profile number is displayed in the upper-right

corner of the screen.

2Select “OK”.

OK CANCEL

MEMORY LOAD

LOAD FROM MEMORY16

select

2 OK

Lock1

Picture adjustment values are shown.

Lock2

Picture adjustment values are hidden.

PICTURE MENU DYNAMIC

OFF

NORMAL


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

ADVANCED SETTINGS

6COLOR

0TINT

Can be

specified.

Cannot be

specified.

PICTURE MENU DYNAMIC


NORMAL IZE

BRIGHTNESS

SHARPNESS

COLOR TEMP

COLOR MANAGEMENT

ADVANCED SETTINGS

COLOR

TINT

Can be

specified.

Cannot be

specified.

Loading profiles

Loading locked profiles…

In the PICTURE menu, profiles are labeled with these icons to indicate their locked status.

PICTURE MENU DYNAMIC


NORMAL IZE

BRIGHTNESS

:Lock1

:Lock2

Operations with locked profiles are restricted. (see page 29)

Picture adjustment values in the PICTURE menu cannot be changed, except for the “PICTURE MENU”.

Once you edit the “PICTURE MENU” setting, you can edit “PICTURE”, “BRIGHTNESS”, and other picture adjustment

values.

Picture Profiles

Delete or rename profiles as follows.

Note:

Locked profiles and profiles currently in use cannot be

deleted.

Note:

Locked profiles cannot be renamed.

Editing profiles

1In the PICTURE menu, select “MEMORY EDIT”.

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

2 OK

1 select

2Select “MEMORY DELETE”.

MEMORY NAME CHANGE

MEMORY DELETE

2 OK

1 select

3Select the profile to delete.

To delete all profiles, select “ALL DELETE”.

1. [] MEMORY1

MEMORY2

ALL DELETE

2. []

2 OK

1 select

4Select “Ok”.

OK CANCEL

MEMORY DELETE

DELETE THE MEMORY1 DATA.

1 select

2 OK

1In the PICTURE menu, select “MEMORY EDIT”.

MEMORY SAVE

MEMORY LOAD

MEMORY EDIT

2 OK

1 select

2Select “MEMORY NAME CHANGE”.

MEMORY NAME CHANGE

MEMORY DELETE

2 OK

1 select

3Select the profile to rename.

1. [] MEMORY1

MEMORY2

2. []

MEMORY12

12. []

2 OK

1 select

4Enter a name for the profile.

Entering profile names page 26

MEMORY NAME INPUT

BCDEFGH I JK LM

N O P Q R S T U V W X Y Z DELETE

SPACE

abcde f gh i j k lm

nopq r s t uvwxyz

0123456789

”#$%&’ +–/=?

_ ` | ~<> ( ) [ ] { } ,

@\ ˆ

.;:

CANCEL

ALL DELETE

MEMORY1

█

5When you finished entering the profile name, select

“OK”.

To cancel renaming the profile, select “CANCEL”.

OK CANCEL

1 select

2 OK

Picture Profiles

You can lock saved profiles to restrict operations when the profiles are loaded. You can also set passwords.

Once a profile is locked, the following operations are restricted when the profile is loaded.

Setting Editing the Profile

(MEMORY EDIT)

Editing Picture Adjustment Values

via the Menu

(PICTURE menu, ADVANCED

SETTINGS)

Saving Picture Adjustment Values

(MEMORY SAVE)

Off (unlocked) Allowed Allowed Allowed

Lock1 Prohibited Prohibited (picture adjustment values

are shown)

Allowed

Lock2 Prohibited Prohibited (picture adjustment values

are hidden)

Prohibited

Note:

Make a note of the new password to remember it.

Locking profiles

1Display the menu screen.

2Select “OPTIONS” and hold for 3 seconds or

more.

SET UP

POS. /SIZE

SOUND

OPTIONS


2 OK

(

3 seconds

or more

)

1 select

3Select “Memory lock”.

Memory lock

Onscreen display

Scrolling bar

Off

All Aspect

Studio mode

Function button assign

2 OK

1 select

4Enter a 4-digit password.

The default password is “0123”.

5Select “OK”.

OK CANCEL

Input password

1 select

2 OK

6Select the profile and specify the desired lock

setting.

Lock1

Change password

MEMORY1

Off

MEMORY2

MEMORY12

Offisf Mode

2 set

1 select

7Exit the menu. or

1Follow steps 1–5 in the previous procedure,

<Locking and unlocking profiles>.

2Select “Change password”.

Lock1

Change password

MEMORY1

Off

MEMORY2

MEMORY12

Offisf Mode

2 OK

1 select

3Enter a new 4-digit password.

4Select “OK”.

Input new password

OK CANCEL

1 select

2 OK

5Exit the menu. or

Picture Profiles

Switches to “PICTURE MENU” mode display.

1Follow steps 1–5 in the previous procedure,

<Locking and unlocking profiles>.

2Select “isf Mode”.

Lock1

Change password

MEMORY1

Off

MEMORY2

MEMORY12

Offisf Mode

2 set

1 select

3Specify “On” or “Off”.

4Exit the menu. or

Specifying “On” for isf Mode changes the “PICTURE MENU” mode display as follows.

“PICTURE menu” mode display

STANDARDPICTURE MENU


NORMAL IZE

BRIGHTNESS

COLOR

TINT

SHARPNESS

isf Mode: Off isf Mode: On

STANDARD STANDARD

DYNAMIC isf Mode DAY

CINEMA isf Mode NIGHT

MONITOR MONITOR

Mode display when is selected

isf Mode: Off isf Mode: On

PICTURE MENU

CINEMA

DYNAMIC

STANDARD

MONITOR

PICTURE MENU

isf Mode NIGHT

isf Mode DAY

STANDARD

MONITOR

Adjusting POS. /SIZE

Notes:

Unadjustable items are grayed out.

Adjustable items differ depending on the input signal and the display mode.

Adjustment details are memorized separately for different input signal formats. (Adjustments for component signals

are memorized for 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 60p · 50p · 24p · 25p · 30p · 24sF,

1250 (1080) / 50i, 750 (720) / 60p · 50p each, and RGB/PC/Digital signals are memorized for each frequency.)

If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This picture

position movement cannot be controlled by the POS. /SIZE function.

•

● AUTO SETUP

Automatically adjust H-POS / V-POS / CLOCK PHASE / DOT CLOCK and set H-SIZE / V-SIZE the

standard value when RGB signal is input.

Notes:

If the dot clock frequency is 162 MHz or higher, DOT CLOCK cannot be made.

If the image is that the edge is hardly figured out or shadowy, that cannot be adjusted automatically.

In such case, press AUTO SETUP again after changing the image to the clearer one.

When DVI-D is input, CLOCK PHASE cannot be adjusted automatically.

Select NORMALIZE in POS. /SIZE and press the OK button when appropriate adjustment cannot be made.

•

● H-POS Adjust the horizontal position. ● V-POS Adjust the vertical position.

● H-SIZE Adjust the horizontal size. ● V-SIZE Adjust the vertical size.

1Display the menu screen.

2Select “POS. /SIZE”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select the item and set.

H-POS

H-SIZE

AUTO SETUP

NORMAL IZE

V-POS

0V-SIZE

DISPLAY SIZE

OFF1:1 PIXEL MODE

OFF

2 adjust or select

1 select

4Exit the menu.

During “COMPONENT”,

“RGB” and “PC” input signal.

H-POS

OFF

H-SIZE

AUTO SETUP

NORMAL IZE

V-POS

0V-SIZE

DOT CLOCK

-16CLOCK PHASE

1:1 PIXEL MODE

OFF

DISPLAY SIZE

During “Digital”, “SDI” and

“HDMI” input signal.

H-POS

H-SIZE

AUTO SETUP

NORMAL IZE

V-POS

0V-SIZE

DISPLAY SIZE

OFF1:1 PIXEL MODE

OFF

Using for menu display

To display a menu for adjustment of the POS. /SIZE menu on

the bottom of the screen, press

H-POS 0

2 adjust or select

1 select the menu

To hide the menu, press or

Adjusting POS. /SIZE

● DOT CLOCK (During “COMPONENT”, “RGB” and “PC” input signal)

Periodic striped pattern interference (noise) may occur when a striped pattern is displayed. If

this happens, adjust so that any such noise is minimized.

●

CLOCK PHASE

(During “COMPONENT”, “RGB” and “PC” input signal)

Eliminate the flickering and distortion.

●

1:1 PIXEL MODE

Adjusts the display size when 1125i, 1125p or 1250i signal is input.

Notes:

Select ON when you would like to replay 1920 × 1080 input signal.

Applicable input signal;

1125 (1080) / 50i · 60i · 24sF · 24p · 25p · 30p · 50p · 60p, 1250 (1080) / 50i

Select OFF when flickering is shown around the image.

H-SIZE, V-SIZE and DOT CLOCK cannot be adjusted when ON is selected.

•

OFF ON

●

1:1 PIXEL MODE

(2k1k)

(For 2k1k signals)

When the input signal is a 2k1k signal (2048×1080 / 24p, 2048×1080 / 24sF), the display size is

adjusted as follows.

OFF ON (LEFT) ON (CENTER) ON (RIGHT)

Note:

2k1k signals can only be received when the Dual Link HD-SDI Terminal Board (TY-FB11DHD)

is installed.

● DISPLAY SIZE Adjusts the image display size on screen.

OFF: Sets the normal image display size on screen.

ON: Sets the image display size approximately 95 % of the normal image display.

OFF ON

Notes:

“DISPLAY SIZE” can be modified when “Studio mode” in the OPTIONS menu is “On”. When

“Studio mode” is “Off”, this setting is “OFF” and cannot be changed. (see page 42)

This setting is valid only when the input signals are as follows;

525i, 525p, 625i, 625p, 750/60p, 750/50p, 1125/60i, 1125/50i, 1125/24sF, 1125/25p, 1125/24p,

1125/30p, 1125/60p, 1125/50p, 1250/50i (Component Video, RGB, DVI, SDI, HDMI)

When “DISPLAY SIZE” is set to “ON”, “H-POS” and “V-POS” in “POS. /SIZE” can be adjusted.

Refer to each board’s operating instruction for DVI, SDI, HDMI’s corresponding signals.

•

While the POS. /SIZE display is active, if the OK button is pressed during “NORMALIZE”, then all adjustment values

are returned to the factory settings.

Helpful Hint (

NORMALIZE

Normalization)

STANDARDAUDIO MENU

OFF

BASS

NORMAL IZE

MID

TREBLE

BALANCE

SURROUND

VOLUME

SOUND Adjustment

Note: BASS, MID, TREBLE and SURROUND settings are memorized separately for each AUDIO MENU.

While the “SOUND” menu is displayed, if the OK button is pressed during “NORMALIZE”, then all adjustment values

are returned to the factory settings.

Helpful Hint (

NORMALIZE

Normalization)

Item Details

AUDIO MENU

STANDARD: Emits the original sound.

DYNAMIC: Accentuates sharp sound.

CLEAR: Attenuates human voice.

BASS Adjusts low pitch sounds.

MID Adjusts normal sounds.

TREBLE Adjusts pitch sound.

BALANCE Adjusts left and right volumes.

SURROUND

Select ON or OFF.

The benefits of surround sound are enormous. You can be completely enveloped in sound; just as if you

were at a concert hall or cinema.

VOLUME Adjust the sound volume level.

Item Details

LEFT CHANNEL CHANNEL 1 to CHANNEL 16

Selects left audio channel.

RIGHT CHANNEL CHANNEL 1 to CHANNEL 16

Selects right audio channel.

SOUND OUT

ON OFF

ON: Enables audio output.

OFF: Disables audio output.

LEVEL METER

OFF 1-8CH 9-16CH

Sets audio channels to show in the audio level meter.

8 channels are displayed in the audio level meter; 4

channels each on both right and left sides of the display.

OFF: Hides the audio level meter.

1-8CH: Displays the audio level meter (1-8ch)

9-16CH

: Displays the audio level meter (9-16ch)

SDI SOUND OUTPUT

This menu is displayed when HD-SDI Terminal Board with audio (TY-FB10HD) or Dual Link HD-SDI Terminal Board

(TY-FB11DHD) is installed to the unit.

Note:

This menu is available only when selecting a

slot that HD-SDI Terminal Board with audio

(TY-FB10HD) or Dual Link HD-SDI Terminal

Board (TY-FB11DHD) is installed.

1Display the menu screen.

2Select “SOUND”

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select the item and set.

STANDARDAUDIO MENU

OFF

BASS

NORMAL IZE

MID

TREBLE

BALANCE

SURROUND

VOLUME

2 adjust or select

1 select

4Exit the menu.

CHANNEL 1LEFT CHANNEL

SDI SOUND OUTPUT 2

CHANNEL 2RIGHT CHANNEL

ONSOUND OUT

OFFLEVEL METER

Do not display a still picture, especially in 4:3 mode, for any length of time.

If the display must remain on, a SCREENSAVER should be used.

SCREENSAVER (For preventing image retention)

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select “SCREENSAVER”.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT OFF

OFF

RGB

SCREENSAVER

SIGNAL

2 OK

1 select

4FUNCTION selection

Select “FUNCTION” and select the

desired function.

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

NEGATIVE IMAGE

2 change

1 select

SCROLLING BAR ONLY

OVERLAY SCROLLING BAR

NEGATIVE IMAGE

WHITE SCREEN

NEGATIVE IMAGE : A negative image will be displayed on the screen.

SCROLLING BAR ONLY: A white bar will scroll from left to right. The image

won’t be displayed.

OVERLAY SCROLLING BAR

: The brightness of the image will be decreased

and a white bar will scroll on it.

WHITE SCREEN : The whole screen will be white.

5START setting

Select “START”.

NEGATIVE IMAGE

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

1 select

2 OK

The menu screen will disappear and the SCREENSAVER will be activated.

To stop the SCREENSAVER under ON, press or any buttons on the

main unit.

Note: When the display is turned off, the SCREENSAVER will be deactivated.

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

NEGATIVE IMAGE

1Select “SIDE BAR ADJUST”.

2Adjust the menu.

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

NEGATIVE IMAGE

2 change

1 select

OFF DARK MID BRIGHT

3Exit from SCREENSAVER.

These functions prevent the occurrence of an “image retention” on the display when turned ON.

WOBBLING: Automatically shifts the display image (therefore unnoticeable to the eye) to prevent image retention of

sharper contour of image.

ON1: Shifts the image every 30 seconds.

ON2: Shifts the image at a dot level pitch depending on screen-detection.

PEAK LIMIT: Suppresses image contrast (peak brightness).

Note:

When a still picture is viewed for an extended time, the screen may become slightly darker. (see page 45)

Reduces screen image retention

SIDE BAR ADJUST

Do not display a picture in 4:3 mode for an extended period,

as this can cause an image retention to remain on the side

bars on either side of the display field.

To reduce the risk of such an image retention, illuminate the

side bars.

This function may be applicable to the non-picture area.

Notes:

To reduce the occurrence of image retention, set the “SIDE BAR ADJUST” to “BRIGHT”.

The side bar may flash (alternate black/white) depending on the picture being shown on the screen. Using Cinema

mode will reduce such flashing.

•

Side bars

4:3 mode


retention

SCREENSAVER (For preventing image retention)

1Select “WOBBLING” or “PEAK LIMIT”.

2Select “ON1”, “ON2” or “OFF”

(WOBBLING).

Select “ON” or “OFF” (PEAK

LIMIT).

OFF

BRIGHTSIDE BAR ADJUST

SCREENSAVER

START

WOBBLING

PEAK LIMIT

FUNCTION

NEGATIVE IMAGE

2 change

1 select

Specifying the scaler

This menu can be used to specify whether the built-in scaler or an external scaler is used for scaler functions such as

resizing and picture quality adjustment.

The setting is valid with the following input signals.

1125 (1080) / 24p·25p·30p·50p·60p

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select “EXTERNAL SCALER MODE” and set.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

2 change

1 select

OFF ON

OFF: Use the built-in scaler.

ON: Use an external scaler.

Note:

Selecting “ON” in this setting deactivates the following settings and disables

these operations.

POS. /SIZE menu: H-SIZE, V-SIZE, 1:1 PIXEL MODE, DISPLAY SIZE

(see page 31, 32)

PICTURE menu: BRIGHTNESS, COLOR, TINT, SHARPNESS,

MEMORY SAVE, MEMORY LOAD (see page 22,

26, 27)

ADVANCED SETTINGS: 3:2 PULLDOWN, NOIZE REDUCTION (see page

24)

SIGNAL menu: XGA MODE (see page 40)

OPTIONS menu: All Aspect (see page 42)

ASPECT Controls (see page 18)

“EXT. SCALER” is displayed in the menu screen to indicate that an external

scaler is in use.

STANDARD

EXT.SCALER

PICTURE MENU

25PICTURE

NORMAL IZE

BRIGHTNESS

COLOR

TINT

4Exit the menu.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

Reduces power consumption

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select the item and set.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

2 change

1 select

4Exit the menu.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

● POWER SAVE When this function is turned ON, luminous level of the Plasma Display is suppressed,

so power consumption is reduced.

● STANDBY SAVE When this function is turned ON, power consumption of the microcomputer is reduced

during power supply standby (see page 13, 15, 16), so standby power of the set is

reduced.

●

POWER MANAGEMENT

When this function is set to ON, it operates under the following conditions to turn the

power on or off automatically.

When no pictures (HD/VD sync signals) are detected for 30 or so seconds during PC IN

signal input:

Power is turned off (standby); the power indicator lights up orange.

When pictures (HD/VD sync signals) are subsequently detected:

Power is turned on; the power indicator lights up green.

Notes:

• This function operates only during PC IN signal input.

• This function is effective when “SYNC” is set to “AUTO” and “COMPONENT / RGB-IN

SELECT” is set to “RGB”.

● AUTO POWER OFF Equipment power supply is turned OFF when there is no signal.

When this is set to On, the power supply of the unit goes Off 10 minutes after the input

signals stop.

Note:

• This function is effective for input signals except PC IN terminal.

Customizing the On-Screen Menu Display

Specify the background color and display position of on-screen menus as follows.

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Specify the background color.

Select “OSD DESIGN” and choose the background color (transparency).

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

2 change

1 select

TYPE1 TYPE2 TYPE3

4Specify the display position.

Select “OSD POSITION” and choose the display position.

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

2 change

1 select

Each time you press or , the on-screen menu display position changes.

Display example

UPPER LEFT

CENTER

5Exit the menu.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

SET UP for Input Signals

COMPONENT / RGB IN SELECT

Select to match the signals from the source connected to the COMPONENT / RGB input terminals.

Y, PB, PR signals “COMPONENT”

RGB signals “RGB”

Notes:

Selection may not be possible, depending on which optional board is installed.

Make setting of the selected input terminal (SLOT1, SLOT2, SLOT3 or PC IN).

•

YUV / RGB IN SELECT

Select to match the signals from the source connected to the DVI input terminals.

YUV signals “YUV”

RGB signals “RGB”

Notes:

Selection may not be possible, depending on which optional board is installed.

Make setting of the selected input terminal (SLOT1 or SLOT2).

•

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select “COMPONENT / RGB-IN SELECT” and set.

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE OFF

OFF

RGB

SCREENSAVER

SIGNAL

2 change

1 select

COMPONENT RGB

4Exit the menu.

1Display the menu screen.

2Select “SET UP”.

SET UP

POS. /SIZE

SOUND


2 OK

1 select

3Select “YUV / RGB-IN SELECT” and set.

YUV/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE OFF

OFF

RGB

SCREENSAVER

SIGNAL

2 change

1 select

YUV RGB

4Exit the menu.

Note:

“SIGNAL” setup menu displays a different setting condition for each input signal.

SET UP for Input Signals

SIGNAL menu

COMPONENT/RGB-IN SELECT

EXTERNAL SCALER MODE

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF OFF

OFF

RGB

OSD DESIGN TYPE1

OSD POSITION UPPER LEFT

OSD LANGUAGE ENGLISH (US)

SCREENSAVER

SIGNAL

For RGB

AUTOSYNC

1024 ×768

33.7 kHz

60.0 Hz

1125(1080)/60i

XGA MODE

100 HzREFRESH RATE

H-FREQ.

V-FREQ.

SIGNAL FORMAT

SIGNAL [ RGB ]

For COMPONENT For Digital

1024 ×768XGA MODE

100 Hz

33.7 kHz

60.0 Hz

1125(1080)/60i

REFRESH RATE

H-FREQ.

V-FREQ.

SIGNAL FORMAT

SIGNAL [ COMPONENT ]SIGNAL [ Digital ]

100 HzREFRESH RATE

33.7 kHz

60.0 Hz

1125(1080)/60i

H-FREQ.

V-FREQ.

108.0 MHzDOT CLOCK-FREQ.

SIGNAL FORMAT

XGA MODE

This menu is displayed when the input signal is analog (Component/PC). This unit supports three types of XGA signals

with 60Hz vertical frequency having different aspect ratios and sampling rates (1,024 × 768 @ 60Hz, 1,280 × 768 @

60Hz, and 1,366 × 768 @ 60Hz). Be sure to make settings in accordance with the input signal in order to achieve a

more appropriate and attractive display.

In addition, after making this setting, be sure to make each adjustment (such as “AUTO SETUP”) on the “POS. /SIZE”

menu as necessary. (see page 30)

1024 ×768XGA MODE

100 HzREFRESH RATE

SIGNAL [ COMPONENT ]

2 change

1 select

1024×768 1366×768

1280×768

REFRESH RATE

This function sets the refresh rate of the display.

This menu is displayed when the input signal is 50 Hz system (50i, 50p, 25p, 24p, 24sF) of vertical scan rate.

100 Hz: Reduce screen flicker.

50 Hz: Enhance the resolution of moving images.

Note:

It is recommended to set to 100 Hz normally.

1024 ×768XGA MODE

100 HzREFRESH RATE

SIGNAL [ COMPONENT ]

2 change

1 select

100 Hz 50 Hz

33.7 kHz

60.0 Hz

1125(1080)/60i

H-FREQ.

V-FREQ.

SIGNAL FORMAT

33.7 kHz

60.0 Hz

1125(1080)/60i

H-FREQ.

V-FREQ.

108.0 MHzDOT CLOCK-FREQ.

SIGNAL FORMAT

SET UP for Input Signals

Select SIGNAL from the “SET UP” menu during RGB input signal.

SYNC

Setting RGB sync signal

Confirm that the input is set to RGB INPUT (this setting is valid only for RGB INPUT signal)

AUTO: The H and V sync or synchronized signal are automatically selected. If both input, it is selected the H and V

sync.

ON G: Uses a synchronized signal on the Video G signal, which is input from the G connector.

VBS: Uses a synchronized signal of Composite Sync input, which is input from the HD connector.

Displays the frequency and the type of the current input signal.

This display is valid only for COMPONENT/RGB/PC and Digital input signal.

Display range:

Horizontal 15 - 110 kHz

Vertical 48 - 120 Hz

Input signal display

The dot clock frequency is displayed during digital signal input.

Set the active through function of the Dual Link HD-SDI Terminal Board (TY-FB11DHD).

Note:

Settings can only be performed for this menu when a slot mounted with a Dual Link HD-SDI Terminal Board (TY-FB11DHD)

is selected.

SDI THROUGH

AUTOSYNC

1024 ×768XGA MODE

100 HzREFRESH RATE

SIGNAL [ RGB ]

2 change

1 select

AUTO VBSON G

SIGNAL [ Digital ]

OFFSDI THROUGH

100 HzREFRESH RATE

2 change

1 select

OFF

ON: Enables active through.

OFF: Disables active through.

Item Adjustments

Onscreen display

On: Displays all the following on screen.

• Power on display

• Input signal switch display

• No signal display

• Mute after was pressed.

Off: Hides all the items above from view.

All Aspect

Sets All Aspect mode (advanced aspect setting) or default aspect mode.

With each press of button, the aspect changes in the selected mode.

Off: Default aspect mode

On: All Aspect mode

Aspect mode of each setting is as follows:

(Example: HD signal)

Off 4:3H-FILLZOOMFULLJUST

On 4:3 (1)4:3 (2)4:3 FullZoom1Zoom2Zoom316:914:9Just1Just2

Studio mode

For switching functions in setting menus used for television studio applications.

Studio mode: On Studio mode: Off

COLOR TEMP “STUDIO” can be selected. “STUDIO” not available.

STUDIO GAIN Can be switched ON and

OFF.

Cannot be specified (set to “OFF”

and cannot be changed).

DISPLAY SIZE Can be switched ON and

OFF.

Cannot be specified (set to “OFF”

and cannot be changed).

Function button

assign

Specifies the function activated when the button on the remote control is pressed.

Scrolling bar: Activates the SCROLLING BAR ONLY screensaver. After 15 minutes, the display enters

standby mode.

Test patterns:Each time you press , a different test pattern is displayed (seven in all).

Memory lock Locks or unlocks saved profiles. Also for setting passwords. (see page 29)

OPTIONS Adjustments

1Display the menu screen.

2Select “OPTIONS”.

3Press for more than 3 seconds.

SET UP

POS. /SIZE

SOUND

OPTIONS


2 OK (more than

3 seconds)

1 select

4Select the item and set.

OnOnscreen display

OffAll Aspect

OffStudio mode

Scrolling barFunction button assign

Memory lock

2 set

1 select

5Exit the menu.

OnOnscreen display

OffAll Aspect

OffStudio mode

Scrolling barFunction button assign

Memory lock

Watching Videos and DVDs

If you have applicable equipment connected to the Display, you can easily watch videos and DVDs using the Display’s

remote control.

You can select the external equipment to access.

To operate other manufacturers’ equipment, you need to register the code for the equipment. (see page 44)

1Select the input mode. (see page 14)

HDMI1

HDMI2

HDMI3

HDMI4

COMPONENT

INPUT

2Select the remote control mode.

Press the key to select.

DISPLAY

VCR DBS/CBL DVD

3Operate the connected equipment, pointing Display’s remote

control at the equipment.

Example

VCR MODE DVD MODE

VCR Record Record

– Skip Reverse/Forward

Rewind/Fast Forward Reverse/Forward

Stop Stop

Pause Pause

Play Play

(For other operations, see page 47)

COMPO.

INPUTCH

HDMI

フ

DISPLAY

INPUTCH

HDMI

フ

COMPO.

DISPLAY

Programming the Remote to Operate Peripheral Equipment

Watching Videos and DVDs

1Connect the external equipment to the Display and Power Off the

external equipment.

2Press both buttons simultaneously for more

than 3 seconds.

Release the buttons when the equipment selection

buttons start flashing.

3Select the equipment.

VCR DBS/CBL DVD

The selected button remains lit (other buttons are not lit).

4Input the equipment’s 4-digit remote control

code.

(see page 48, 49)

5Operate the equipment with the remote

control.

(see page 47)

The external equipment turns On.

Press to return to the Display mode.

DISPLAY

If the equipment does not operate with the remote control

• When your equipment has a single code

Input the remote control code again

• When your equipment has multiple codes

Change the code with 4 above and test again

Note:

Registration will fail if the wrong code is input or it takes more than 30 seconds to register.

To find a code not listed in the code list

This procedure searches all codes and is called the “sequence method.”

1 After step 3 above, change the code and test. 2 When the correct code is found.

change

store

Operate the equipment with the remote control.

(see page 47)

Repeat until the code is found.

It may take many attempts before the correct code is

found.

•

COMPO.

INPUTCH

HDMI

フ

DISPLAY

HDMI

DISPLAY

You can operate other manufacturers’ equipment using this Display’s remote control.

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.

Symptoms Checks

Picture Sound

Interference Noisy Sound

Electrical Appliances

Cars / Motorcycles

Fluorescent light

Normal Picture No Sound Volume

(Check whether the mute function has been activated on the remote control.)

No Picture No Sound

Not plugged into AC outlet

Not switched on

PICTURE and BRIGHTNESS/Volume setting

(Check by pressing the power switch or stand-by button on the remote control.)

No Picture Normal Sound If a signal with a non-applicable color system format, or frequency is input, only the input

terminal indication is displayed.

No Color Normal Sound Color controls set at minimum level. (see page 21- 24)

No remote control operations can be performed. Check whether the batteries have discharged completely and, if they have not, whether they

were inserted properly.

Check whether the remote control sensor is exposed to an outdoor light or a strong

fluorescent light.

Check whether the remote control designed specifically for use with the unit is being used.

(The unit cannot be operated by any other remote control.)

A cracking sound is sometimes heard from the unit. If there is nothing wrong with the picture or sound, this is the sound of the cabinet

undergoing very slight contractions in response to changes in the room temperature. There

are no adverse effects on the performance or other aspects.

The top or bottom of the picture on the screen is cut

off when I use the zoom function.

Adjust the position of the picture on the screen.

Areas at the top and bottom of the screen where

the image is missing appear when I use the zoom

function.

When using a video software program (such as a cinema size program) with a screen wider

than one in the 16:9 mode, blank areas separate from the images are formed at the top and

bottom of the screen.

I can hear sounds coming from inside the unit. When the power is turned on, a sound of the display panel being driven may be heard: This

is normal and not indicative of malfunctioning.

This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input

signal. However, this is not a malfunction.

Plasma Display panel

Symptoms Check

The screen darkens slightly when bright pictures

with minimal movements are shown.

The screen will darken slightly when photos, still images of a computer or other pictures

with minimal movements are shown for an extended period. This is done to reduce image

retention on the screen and the shortening of the screen’s service life: It is normal and not

indicative of malfunctioning.

It takes a while for the picture to appear. The unit digitally processes the various signals in order to reproduce esthetically pleasing

images. As such, it sometimes takes a few moments for the picture to appear when the

power has been turned on, when the input has been switched.

The edges of the images flicker. Due to the characteristics of the system used to drive the panel, the edges may appear

to flicker in the fast-moving parts of the images: This is normal and not indicative of

malfunctioning.

The brightness on both sides of images in 4:3 mode

changes.

When viewing the side panels at the “BRIGHT” or “MID” setting, the brightness on both sides

may change depending on the kind of program shown: This is normal and not indicative of

malfunctioning.

Some parts of the screen do not light up. The plasma display panel is manufactured using an extremely high level of precision

technology, however, sometimes some parts of the screen may be missing picture elements

or have luminous spots. This is not a malfunction.

Image retention appears

Do not allow a still picture to be displayed for an extended period, as this can cause a

permanent image retention to remain on the Plasma Display.

Examples of still pictures include logos, video games, computer images, teletext and images

displayed in 4:3 mode.

Note:

The permanent image retention on the Plasma Display resulting from fixed image use is not

an operating defect and as such is not covered by the Warranty.

This product is not designed to display fixed images for extended periods of time.

Whirring sounds can be heard from the display unit. The display unit is fitted with a cooling fan to dissipate heat generated during normal use.

The whirring sound is caused by rotation of the fan and is not a malfunction.

List of Aspect Modes

Aspect mode

Picture Enlarged screen Description

All Aspect:

Factory setting

All Aspect: Off

16:9 FULL

The display of the pictures fills the screen.

In the case of SD signals, pictures with a 4:3 aspect

ratio are enlarged horizontally, and displayed. This mode

is suited to displaying anamorphic pictures with a 16:9

aspect ratio.

14:9 –

Letterbox pictures with a 14:9 aspect ratio are enlarged

vertically and horizontally so that their display fills the

screen vertically and is slightly smaller than the screen

horizontally. The top and bottom edges of the pictures

are cut off. Side panels are displayed at the left and right

edges of the screen.

Just

JUST

Pictures with a 4:3 aspect ratio are enlarged horizontally

so that the picture distortion is minimized. The display of

the areas around the left and right edges of the screen is

slightly elongated.

Just1

Just2 JUST

Pictures with a 4:3 aspect ratio are enlarged horizontally

so that the picture distortion is minimized. The left and

right edges of the pictures are cut off. The display of the

areas around the left and right edges of the screen is

slightly elongated.

4:3

Pictures with a 4:3 aspect ratio are displayed with their

original aspect ratio. Side panels are displayed at the left

and right edges of the screen.

4:3 (1)

4:3 (2) 4:3

Pictures with a 4:3 aspect ratio are displayed with their

original aspect ratio. The left and right edges of the

pictures are masked by side panels.

4:3 Full H-FILL

Pictures with a 4:3 aspect ratio are enlarged horizontally

so that their display fills the screen. The left and right

edges of the pictures are cut off.

Zoom

ZOOM

Letterbox pictures with a 16:9 aspect ratio are enlarged

vertically and horizontally so that their display fills the

screen. The top and bottom edges of the pictures are cut

off.

Zoom1

Zoom2 ZOOM

Letterbox pictures with a 16:9 aspect ratio are enlarged

vertically and horizontally so that their display fills the

screen. The top and bottom edges as well as the left and

right edges of the pictures are cut off.

Zoom3 –

Letterbox pictures with a 2.35:1 aspect ratio are enlarged

vertically and horizontally so that their display fills the

screen vertically and is slightly larger than the screen

horizontally. The top and bottom edges as well as the left

and right edges of the pictures are cut off.

Remote Control Operation / Code List

The following explains how to operate external devices with the Display’s remote control.

page 48, 49)

Note:

Operation may not be possible depending on the available memory size of the remote control.

This remote control is not designed to cover operation of all functions of all models.

Remote Control Operation List

This chart defines which keys are operational after programming (if needed) while in the selected remote control mode,

CABLE, DBS, VCR, or DVD.

KEY NAME VCR MODE DBS/CBL MODE DVD MODE

(DBS) (CBL)

Power Power Power Power

Menu Menu Functions

PPV/VOD PPV/VOD Return

Up/Down/Left/Right Up/Down/Left/Right Up/Down/Left/Right

Select Select Enter

INPUTCH

Channel Up/Down Channel Up/Down Channel Up/Down Channel Up/Down

– 0-9 0-9 0-9 0-9

Page Down/Up Page Down/Up Skip Reverse/Forward

TV/VCR Switch TV/DBS Switch TV/CBL Switch

Rewind/Fast Forward Rewind/Fast Forward Rewind/Fast Forward Reverse/Forward

Record Record *1Record *1Record

Stop Stop Stop Stop

Pause Pause Pause Still/Pause

Play Play Play Play

*1: Combination type

ABC 0003, 0008, 0014, 0017

Americast 0899

Amino 1602, 1822

Bell & Howell 0014

Bell South 0899

Clearmaster 0883

ClearMax 0883

Coolmax 0883

Digeo 1187

Digi 0637

Director 0476

Dumont 0637

General Instrument 0003, 0276, 0476, 0810

GoldStar 0144

Hamlin 0009, 0273

i3 Micro 1602

Jerrold 0003, 0012, 0014, 0276, 0476,

0810

Memorex 0000

Motorola 0276, 0476, 0810, 1106, 1187,

1254, 1376

Multitech 0883

Myrio 1602, 1822

Pace 0008, 0237, 1877

Panasonic 0000, 0107, 1786

Panther 0637

Paragon 0000

Philips 0317, 1305

Pioneer 0144, 0533, 0877, 1877

Pulsar 0000

Quasar 0000

RadioShack 0883

RCA 1256

Regal 0273, 0279

Runco 0000

Samsung 0144

Scientific Atlanta 0008, 0017, 0477, 0877, 1877

Sejin 1602

Sony 1006

Starcom 0003

Supercable 0276

Supermax 0883

Thomson 1256

Tocom 0012

Torx 0003

Toshiba 0000

Tristar 0883

V2 0883

Viewmaster 0883

Vision 0883

Vortex View 0883

Zenith 0000, 0525, 0899

AlphaStar 0772

Century 0856

Chaparral 0216

Crossdigital 1109

DirecTV 0099, 0247, 0392, 0566, 0639,

0724, 0749, 0819, 1076, 1108,

1109, 1142, 1377, 1392, 1414,

1442, 1443, 1444, 1538, 1539,

1609, 1639, 1640, 1749, 1856

Dish Network System 0775, 1005, 1170, 1171, 1505, 1775

Dishpro 0775, 1005, 1505, 1775

Echostar 0775, 1005, 1170, 1171, 1505, 1775

Expressvu 0775, 1775

GE 0566

General Instrument 0869

GOI 0775, 1775

Gradiente 0856

Hisense 1535

Hitachi 0819, 1250

HTS 0775, 1775

Hughes Network

Systems

0749, 1142, 1442, 1443, 1444,

1538, 1539, 1749

Humax 1790

iLo 1535

JVC 0775, 1170, 1775

LG 1226, 1414

Magnavox 0724, 0722

Memorex 0724

Mitsubishi 0749

Motorola 0869

Next Level 0869

Panasonic 0247, 0701

Paysat 0724

Philips 0099, 0722, 0724, 0749, 0856,

1076, 1142, 1442, 1749

Proscan 0392, 0566

Proton 1535

RadioShack 0869

RCA 0566, 0855, 0143, 1392

Samsung 1108, 1109, 1276, 1377, 1442, 1609

Sony 0639, 1639, 1640

Star Choice 0869

Tivo 1142, 1442, 1443, 1444, 1538, 1539

Toshiba 0749, 0790, 1285, 1749

UltimateTV 1392, 1640

Uniden 0724, 0722

US Digital 1535

USDTV 1535

Voom 0869

Zenith 0856, 1856

DBS / CABLE (Cable Set Top Box)

Brand Code Brand Code Brand Code Brand Code

DBS / CABLE ( Satellite Set Top Box)

Brand Code Brand Code Brand Code Brand Code

ABS 1972

Admiral 0048, 0209

Adventura 0000

Aiko 0278

Aiwa 0000, 0037, 0124

Akai 0041

Alienware 1972

America Action 0278

American High 0035

Asha 0240

Audiovox 0037, 0278

Beaumark 0240

Bell & Howell 0104

Broksonic 0002, 0121, 0184, 0209, 0479,

1479

Calix 0037

Canon 0035

Carver 0081

CCE 0072, 0278

Citizen 0037, 0278, 1278

Colt 0072

Craig 0037, 0047, 0072, 0240

Curtis Mathes 0035, 0041, 0060, 0162, 1035

Cybernex 0240

CyberPower 1972

Daewoo 0045, 0278, 1278

Dell 1972

Denon 0042

DirecTV 0739, 0740, 0745, 1239, 1240

Durabrand 0038, 0039

Dynatech 0000

Electrohome 0037

Electrophonic 0037

Emerex 0032

Emerson 0000, 0002, 0037, 0043, 0121,

0184, 0209, 0278, 0479, 0593,

1278, 1479, 1593

Fisher 0047, 0104

Fuji 0033, 0035

Funai 0000, 0593, 1593

Garrard 0000

Gateway 1972

GE 0035, 0060, 0240, 0807, 1035,

1060

Go Video 0432, 0614

GoldStar 0037, 0038, 1237

Gradiente 0000

Harley Davidson 0000

Harman/Kardon 0038, 0081

Harwood 0072

Hewlett Packard 1972

HI-Q 0047

Hitachi 0000, 0041, 0042, 0089

Howard Computers 1972

HP 1972

Hughes Network

Systems

0042, 0739, 0740, 0745, 1239,

1240

Humax 0739

Hush 1972

iBUYPOWER 1972

Jensen 0041

JVC 0041, 0067

KEC 0037, 0278

Kenwood 0038, 0041, 0067

KLH 0072

Kodak 0035, 0037

LG 1037

Linksys 1972

Lloyd’s 0000

Logik 0072

LXI 0037

Magnasonic 0593, 1278

Magnavox 0000, 0035, 0039, 0081, 0149,

0563, 0593, 1593, 1781

Magnin 0240

Marantz 0035, 0081

Marta 0037

Media Center PC 1972

MEI 0035

Memorex 0000, 0035, 0037, 0039, 0047,

0048, 0104, 0162, 0209, 0240,

0479, 1037, 1162, 1237, 1262

MGA 0240, 0043

MGN Technology 0240

Microsoft 1972

Mind 1972

Minolta 0042

Mitsubishi 0043, 0067, 0807

Motorola 0035, 0048

MTC 0000, 0240

Multitech 0000, 0072

NEC 0038, 0041, 0067, 0104

Nikko 0037

Niveus Media 1972

Noblex 0240

Northgate 1972

Olympus 0035

Optimus 0037, 0048, 0104, 0162, 0432,

0593, 1062, 1162, 1262

Orion 0002, 0184, 0209, 0479, 1479

Panasonic 0035, 0162, 0225, 0614, 0616,

1035, 1062, 1162, 1262

Penney 0035, 0037, 0038, 0042, 0240,

1035, 1237

Pentax 0042

Philco 0035

Philips 0035, 0081, 0618, 0739, 1081, 1181

Pilot 0037

Pioneer 0067

Polk Audio 0081

Presidian 1593

Profitronic 0240

Proscan 0060, 1060

Protec 0072

Pulsar 0039

Quasar 0035, 0162, 1035, 1162

RadioShack 0000, 1037

Radix 0037

Randex 0037

RCA 0042, 0060, 0149, 0240, 0807,

0880, 1035, 1060

Realistic 0000, 0035, 0037, 0047, 0048,

0104

ReplayTV 0614, 0616, 1615, 1616

Ricavision 1972

Runco 0039

Samsung 0045, 0240, 0739, 1014

Sanky 0039, 0048

Sansui 0000, 0041, 0067, 0209, 0479,

1479

Sanyo 0047, 0104, 0240

Scott 0043, 0045, 0121, 0184

Sears 0000, 0035, 0037, 0042, 0047,

0104, 1237

Sharp 0048, 0807, 0848

Shintom 0072

Shogun 0240

Singer 0072

Sonic Blue 0614, 0616, 1615, 1616

Sony 0000, 0032, 0033, 0035, 0636,

1032, 1232, 1972

Stack 9 1972

STS 0042

Sylvania 0000, 0035, 0043, 0081, 0593,

1593, 1781

Symphonic 0000, 0593, 1593

Systemax 1972

Tagar Systems 1972

Tatung 0041

Teac 0000, 0041

Technics 0035, 0162

Teknika 0000, 0035, 0037

Thomas 0000

Tivo 0618, 0636, 0739, 0740, 0745,

1239, 1240, 1503, 1996

TMK 0240

Toshiba 0043, 0045, 0845, 1008, 1145,

1503, 1972, 1996

Totevision 0037, 0240

Touch 1972

Unitech 0240

Vector 0045

Vector Research 0038

Video Concepts 0045

Videomagic 0037

Videosonic 0240

Viewsonic 1972

Villain 0000

Voodoo 1972

Wards 0000, 0035, 0042, 0047, 0048,

0060, 0072, 0081, 0149, 0240

White Westinghouse 0072, 0209

XR-1000 0000, 0035, 0072

Yamaha 0038

Zenith 0000, 0033, 0039, 0209, 0479,

1479

ZT Group 1972

VCR

Brand Code Brand Code Brand Code Brand Code

Remote Control Operation / Code List

Remote Control Code List

Accurian 1072, 1416

Advent 1016

Aiwa 0641

Akai 0695, 0770, 0899, 1089

Alco 0790

Allegro 0869

Amphion Media Works 0872

Apex Digital 0672, 0717, 0755, 0794, 0796,

0797, 0830, 1004, 1020, 1056,

1061, 1100

Arrgo 1023

Aspire Digital 1168, 1407

Audiovox 0790, 1071, 1072, 1121, 1122

Axion 1071, 1072

Blaupunkt 0717

Blue Parade 0571

Broksonic 0695, 0868

Cinea 0831

CineVision 0833, 0869, 0876

Citizen 0695, 1277

Coby 0778, 0852, 1086, 1107, 1165, 1177

Craig 0831

Curtis Mathes 1087

CyberHome 0816, 0874, 1023, 1024, 1117,

1129, 1502

Daewoo 0705, 0784, 0833, 0869, 1169,

1172, 1234, 1242, 1441

Denon 0490, 0634

Desay 1407

Disney 0675, 1270

Dual 1068, 1085

Durabrand 1127

DVD2000 0521

Emerson 0591, 0675, 0821, 1268

Enterprise 0591

ESA 0821, 1268

Fisher 0670

Funai 0675, 1268, 1334

Gateway 1073, 1077, 1158, 1194

GE 0522, 0815, 0717

Go Video 0715, 0741, 0744, 0783, 0833,

0869, 1044, 1075, 1099, 1158,

1304, 1730

Go Vision 1071, 1072

GoldStar 0741

Greenhill 0717

Harman/Kardon 0582, 0702

Hitachi 0573, 0664, 1247

Hiteker 0672

Humax 1588

iLo 1348

Initial 0717

Insignia 1268

Integra 0627

JBL 0702

Jensen 1016

JSI 1423

JVC 0558, 0623, 0867, 1164

jWin 1049

Kawasaki 0790

Kenwood 0490, 0534

KLH 0717, 0790, 1020, 1149

Konka 0711, 0719, 0720

Koss 0651, 0896, 1423

Landel 0826

Lasonic 0798, 1173

Lenoxx 1127

LG 0591, 0741, 0801, 0869

LiteOn 1058, 1158, 1416, 1440

Loewe 0511, 0885

Magnavox 0503, 0539, 0646, 0675, 0821,

1268

Malata 0782, 1159

Marantz 0539

Memorex 0695, 0831, 1270

Microsoft 0522, 1708

Mintek 0717, 0839

Mitsubishi 0521, 1521

Momitsu 1082

NAD 0741

NEC 0785

Nesa 0717

Next Base 0826

NexxTech 1402

Norcent 0872, 1003, 1107, 1265

Onkyo 0503, 0627, 0792

OptoMedia Electronics 0896

Oritron 0651

Panasonic 0490, 0703, 1362, 1462, 1490,

1762, 1779, 2060, 2061, 2062

Philips 0503, 0539, 0646, 0675, 0854,

1260, 1267, 1354

Pioneer 0525, 0571, 0631

Polaroid 1020, 1061, 1086

Polk Audio 0539

Portland 0770

Presidian 0675, 1072

Prima 1016

Proscan 0522

ProVision 0778

Qwestar 0651

RCA 0522, 0571, 0717, 0790, 0822,

1022, 1132, 1769

Rio 0869

Rotel 0623

Rowa 0823

Sampo 0698, 0752

Samsung 0199, 0490, 0573, 0820, 0899,

1044, 1075

Sansui 0695

Sanyo 0670, 0695, 0873

Sensory Science 1158

Sharp 0630, 0675, 0752, 1256

Sharper Image 1117

Sherwood 0633, 0770, 1043, 1077

Shinsonic 0533, 0839

Sonic Blue 0869, 1099

Sony 0533, 0864, 1033, 1070, 1431,

1533

Sova 1122

Superscan 0821

SVA 0860, 1105

Sylvania 0675, 0821, 1268

Symphonic 0675, 0821

Teac 0790

Technics 0490, 0703

Technosonic 0730

Theta Digital 0571

Toshiba 0503, 0695, 1045, 1154, 1588, 1769

Tredex 0800

Urban Concepts 0503

US Logic 0839

Venturer 0790

Vizio 1064, 1226

Xbox 0522, 1708

Yamaha 0490, 0539, 0545

Zenith 0503, 0591, 0741, 0869

Zoece 1265

AMW 0872

DVD Recorder / Player

Brand Code Brand Code Brand Code Brand Code

Remote Control Operation / Code List

Remote Control Code List (Continued)

Applicable Input Signals

Signal name Horizontal frequency

(kHz)

Vertical frequency

(Hz)

Component / RGB

/ Mini D-sub 15P

(Dot clock (MHz))

DVI-D ∗8

(Dot clock (MHz))

1 525 (480) / 60i 15.73 59.94 * (13.5)

2 525 (480) / 60p 31.47 59.94 * (27.0) ∗5 * (27.0)

3 625 (575) / 50i 15.63 50.00 * (13.5)

4 625 (575) / 50p 31.25 50.00 * (27.0)

5 625 (576) / 50p 31.25 50.00 * (27.0)

6 750 (720) / 60p 45.00 60.00 * (74.25) * (74.25)

7 750 (720) / 50p 37.50 50.00 * (74.25) * (74.25)

8 1,125 (1,080) / 60p 67.50 60.00 * (148.5) ∗1 * (148.5)

9 1,125 (1,080) / 60i 33.75 60.00 * (74.25) ∗1 * (74.25)

10 1,125 (1,080) / 50p 56.26 50.00 * (148.5) ∗1 * (148.5)

11 1,125 (1,080) / 50i 28.13 50.00 * (74.25) ∗1 * (74.25)

12 1,125 (1,080) / 24sF 27.00 48.00 * (74.25) ∗2

13 1,125 (1,080) / 30p 33.75 30.00 * (74.25) ∗1 * (74.25)

14 1,125 (1,080) / 25p 28.13 25.00 * (74.25) ∗1 * (74.25)

15 1,125 (1,080) / 24p 27.00 24.00 * (74.25) ∗1 * (74.25)

16 1,250 (1,080) / 50i 31.25 50.00 * (74.25) ∗3

17 2,048 × 1,080 / 24sF ∗7 27.00 48.00

18 2,048 × 1,080 / 24p ∗7 27.00 24.00

19 640 × 400 @70 Hz 31.46 70.07 * (25.17)

20 640 × 480 @60 Hz 31.47 59.94 * (25.18) ∗6 * (25.18)

21 640 × 480 @72 Hz 37.86 72.81 * (31.5)

22 640 × 480 @75 Hz 37.50 75.00 * (31.5)

23 640 × 480 @85 Hz 43.27 85.01 * (36.0)

24 800 × 600 @56 Hz 35.16 56.25 * (36.0)

25 800 × 600 @60 Hz 37.88 60.32 * (40.0) * (40.0)

26 800 × 600 @72 Hz 48.08 72.19 * (50.0)

27 800 × 600 @75 Hz 46.88 75.00 * (49.5)

28 800 × 600 @85 Hz 53.67 85.06 * (56.25)

29 852 × 480 @60 Hz 31.47 59.94 * (33.54) ∗6*

(34.24)

30 1,024 × 768 @50 Hz 39.55 50.00 * (51.89)

31 1,024 × 768 @60 Hz 48.36 60.00 * (65.0) * (65.0)

32 1,024 × 768 @70 Hz 56.48 70.07 * (75.0)

33 1,024 × 768 @75 Hz 60.02 75.03 * (78.75)

34 1,024 × 768 @85 Hz 68.68 85.00 * (94.5)

35 1,066 × 600 @60 Hz 37.64 59.94 * (53.0) * (53.0)

36 1,152 × 864 @60 Hz 53.70 60.00 * (81.62)

37 1,152 × 864 @75 Hz 67.50 75.00 * (108.0)

38 1,280 × 768 @60 Hz 47.70 60.00 * (80.14)

39 1,280 × 960 @60 Hz 60.00 60.00 * (108.0)

40 1,280 × 960 @85 Hz 85.94 85.00 * (148.5)

41 1,280 × 1,024 @60 Hz 63.98 60.02 * (108.0) * (108.0)

42 1,280 × 1,024 @75 Hz 79.98 75.03 * (135.0)

43 1,280 × 1,024 @85 Hz 91.15 85.02 * (157.5)

44 1,366 × 768 @50 Hz 39.55 50.00 * (69.92)

45 1,366 × 768 @60 Hz 48.36 60.00 * (86.71) * (87.44)

46 1,400 × 1,050 @60 Hz 65.22 60.00 * (122.61)

47 1,600 × 1,200 @60 Hz 75.00 60.00 * (162.0) * (162.0)

48 1,600 × 1,200 @65 Hz 81.25 65.00 * (175.5)

49 1,920 × 1,080 @60 Hz 67.50 60.00 * (148.5) ∗4 * (148.5)

50 1,920 × 1,200 @60 Hz 74.04 59.95 * (154.0)

51 Macintosh13” (640 × 480) 35.00 66.67 * (30.24)

52 Macintosh16” (832 × 624) 49.72 74.54 * (57.28)

53 Macintosh21” (1,152 × 870) 68.68 75.06 * (100.0)

∗1:

Based on SMPTE 274M standard.

∗2:

Based on SMPTE RP211 standard.

∗3:

Based on SMPTE 295M standard.

∗4:

The input signal is recognized as 1,125 (1,080) / 60p.

∗5:

When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.

∗6:

When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.

∗7:

Based on SMPTE 292M and 372M standards. These signals can be received when the Dual Link HD-SDI Terminal

Board (TY-FB11DHD) is installed.

∗8: These signals can be received when the DVI-D Terminal Board (TY-FB11DD) is installed.

Note: Signals without above specification may not be displayed properly.

Applicable Input Signals

Signal format

Vertical

frequency (Hz)

Horizontal

frequency (kHz)

Dot clock

(MHz)

Number of

active pixels

Total number

of pixels

Number of

active lines

Total number

of lines

1 VGA60 59.94 31.47 25.18 640 800 480 525

2 525/60p 59.94 31.47 27.00 720 858 480 525

3 625/50p 50.00 31.25 27.00 720 864 576 625

4 750/60p 60.00 45.00 74.25 1280 1650 720 750

5 750/50p 50.00 37.50 74.25 1280 1980 720 750

6 1125/60i 60.00 33.75 74.25 1920 2200 1080 1125

7 1125/50i 50.00 28.13 74.25 1920 2640 1080 1125

8 1125/60p 60.00 67.50 148.50 1920 2200 1080 1125

9 1125/50p 50.00 56.26 148.50 1920 2640 1080 1125

10 1125/24p 24.00 27.00 74.25 1920 2750 1080 1125

VIDEO input (HDMI)

Audio signal Linear PCM : 48/44.1/32 kHz

Specifications

TH-50VX100U TH-65VX100U

Power Source 110 - 127 V AC, 50/60 Hz

Power Consumption

Power on 605 W 755 W

Stand-by condition Save OFF 0.9 W, Save ON 0.5 W Save OFF 1.0 W, Save ON 0.5 W

Power off condition 0.1 W 0.2 W

Plasma Display panel Drive method : AC type 50-inch,

16:9 aspect ratio

Drive method : AC type 65-inch,

16:9 aspect ratio

Screen size 43.5” (1,106 mm) (W) × 24.4” (622 mm) (H)

× 49.9” (1,269 mm) (diagonal)

56.4” (1,434 mm) (W) × 31.7” (807 mm) (H)

× 64.7” (1,646 mm) (diagonal)

(No.of pixels) 2,073,600 (1,920 (W) × 1,080 (H))

[5,760 × 1,080 dots]

Operating condition

Temperature 32 °F - 104 °F (0 °C - 40 °C)

Humidity 20 % - 80 %

Applicable signals

Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i · 50p

· 24p · 25p · 30p · 24sF, 1250 (1080) / 50i

PC signals VGA, SVGA, XGA, SXGA

UXGA ···· (compressed)

Horizontal scanning frequency 15 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

Connection terminals

HDMI A-B TYPE A Connector × 4

COMPONENT/RGB IN Y/G (RCA PIN JACK)

PB/B, PR/R (RCA PIN JACK)

AUDIO IN (RCA PIN JACK × 2)

with sync 1.0 Vp-p (75 Ω)

0.7 Vp-p (75 Ω)

0.5 Vrms

PC IN (HIGH-DENSITY MINI D-SUB 15PIN)

B/PB/CB :

R/PR/CR :

HD/VD:

AUDIO IN (M3 JACK)

Y or G with sync 1.0 Vp-p (75 Ω)

Y or G without sync 0.7 Vp-p (75 Ω)

0.7 Vp-p (75 Ω)

1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms

SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE

Speaker terminal 6 , 16 W [8 W + 8 W] (10 % THD) 8 , 20 W [10 W + 10 W] (10 % THD)

Accessories Supplied

Remote Control Transmitter

N2QAYB000323

Batteries AA Size × 2

Fixing band TMME203 × 1

Dimensions (W × H × D)

47.7” (1,210 mm) × 28.5” (724 mm) × 3.7” (93 mm)

61.2” (1,554 mm) × 36.4” (924 mm) × 3.8” (94 mm)

Mass (weight) approx. 81.6 lbs approx. 152.2 lbs

Note:

Design and speciﬁ cations are subject to change without notice. Mass and dimensions shown are approximate.

Panasonic Professional Display Company

Unit of Panasonic Corporation of

North America

One Panasonic Way 1F-10

Secaucus, NJ 07094

Panasonic Professional Flat Panel Display

Limited Warranty

Models or Parts Part

Warranty

Labor

Warranty

Professional Flat

Panel Display

LIMITS AND EXCLUSIONS

There are no express warranties except as listed above.

THE WARRANTOR SHALL NOT BE LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES

(INCLUDING, WITHOUT LIMITION, DAMAGE

TO DISCS) RESULTING FROM THE USE OF THIS

PRODUCT, OR ARISING OUT OF ANY BREACH OF

THE WARRANTY. ALL EXPRESS AND IMPLIED

WARRANTIES, INCLUDING THE WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR

PARTICULAR PURPOSE, ARE LIMITED TO THE

APPLICABLE WARRANTY PERIOD SET FORTH

ABOVE.

Some states do not allow the exclusion or limitation

of incidental or consequential damages, or limitations

on how long an implied warranty lasts, so the above

exclusions or limitations may nor apply to you. This

warranty gives you specific legal rights and you may

other rights, which vary from state to state.

If you have a problem with this product that is not

handled to your satisfaction, then write the Consumer

Affairs Department at the Company address indicated

above.

Panasonic Professional Display Company. (referred to

as “the Warrantor”) will repair this product and all

included accessories with new or refurbished parts,

free of charge in the USA or Puerto Rico, of the

original purchase in the event of a defect in materials or

workmanship as follows:

In the USA and Puerto Rico

FOR SERVICE

CALL TOLL FREE

1-800-973-4390

2 Years 2 Years

On-site or carry-in service in the USA and Puerto Rico

may be obtained during the warranty period by contacting

Panasonic Professional Display Company Service toll free

at 1-800-973-4390.

This warranty is extended only to the original purchaser

and is non transferable. A purchase receipt or other

proof of date of original purchase will be required before

warranty service is rendered.

This warranty only covers failures due to defects in

materials or workmanship, which occur during normal

use. The warranty does not cover damage which occur

in shipment, or failures which are caused by products

not supplied by the warrantor, or failures which result

from improper installation, set-up adjustments, improper

antenna, inadequate signal pickup, maladjustment of

consumer controls, improper operation, power line surge,

improper voltage supply, lighting damage, or service by

anyone other than an authorized repair facility, or

damage that is attributable to acts of God.

(for the U.S.A and Puerto Rico)

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario L4W 2T3

LIMITED WARRANTY STATEMENT

Item

Video Tape

P2/SD Cards

Video Heads

D5 Video heads

Maintenance Items

Colour Camera CCD

Imaging Block

BT-H Series LCD Monitors

* DLP™ Projectors

* LCD Projectors above

2,500 ANSI Lumens

* LCD Projectors below

2,500 ANSI Lumens

Projector Lamps

103 inch Plasma displays

Hard Drive Disk Unit

Parts

30 days—Replacement only

(content not covered)

(Content not covered)

1 year or 2,000 hrs. (prorated)

Whichever comes first

1 year or

1,0

00 hrs.

Whichever comes first

90 days

2 years

3 years or 17,000 hrs.

Whichever comes first

3 years or 2,500 hrs.

Whichever comes first

3 years or 1,500 hrs.

Whichever comes first

50% of the rated lamp life or 1 year.

Whichever comes first

3 year (burn-in not covered)

1 year plus balance (if any) of

the original Manufacturer’s

Limited Warranty.

(Content not covered)

Labour

N/A

1 year or 2,000 hrs.

Whichever comes first

1 year or 1,000 hrs.

Whichever comes first

90 days

1 year

3 years or 17,000 hrs.

Whichever comes first

3 years or 2,500 hrs.

Whichever comes first.

3 years or 1,500 hrs.

Whichever comes first

50% of the rated lamp life or 1 year.

Whichever comes first.

3 year

1 year

WARRANTY COVERAGE PERIOD EXCEPTIONS

Panasonic Canada Inc. (also known as PCI) warrants this product to be free of

defects in material and workmanship under normal use during the applicable

warranty coverage period described below. PCI agrees to repair, or at its option,

exchange, any part that becomes defective. However, the product must be

purchased and serviced in Canada. The product or part that shows evidence of

defect must be delivered prepaid or carried in to an authorized Panasonic Broadcast

Service Center. This warranty does not cover shipping costs.

The warranty coverage period is one year for both parts and labour beginning with

the date of original end user purchase, subject to the exceptions as stated below.

Repaired or replacement parts supplied during the warranty coverage period carry

the unexpired portion of the original warranty coverage period. Proof of product

purchase is a condition of warranty service. The owner must produce the product

purchase receipt or other satisfactory evidence of date of original purchase.

This warranty does not apply to external appearance items, such as handles, knobs,

safety windows, etc. This warranty does not apply to any part, or parts, of the

product, installed, altered, repaired or misused in any way that, in the opinion of PCI,

affects the reliability of or detracts from the performance of the product.

For products requiring routine preventive maintenance, that maintenance must be

performed in order to maintain warranty coverage.

Serial numbers that have been altered, defaced or removed void this warranty. This

warranty does not cover replacements or repairs necessitated by loss or damage

resulting from any cause beyond the control of PCI.

Marking or retained images (sometimes called “burn-in”) resulting from the display of

fixed images on video display products are not defects and are not covered under

this warranty.

In certain instances, some jurisdictions do not allow the exclusion or limitation of

incidental or consequential damages, or the exclusion of implied warranties, so the

above limitations and exclusions may not be applicable.

Warranty Service

If the product needs to be shipped for service, carefully pack (preferably in the

original carton) and enclose a letter, detailing the complaint. Send prepaid and

adequately insured to the local authorized Panasonic Service Centre in your

area or to Panasonic Technical Support and Product Services Department, 5770

Ambler Drive, Mississauga, Ontario, L4W 2T3. Shipping to the latter location

requires a return authorization before shipment. No liability is assumed for loss

or damage to the product while in transit.

THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR

ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES.

• Dust, smoke, rental/staging environment and twenty-four/seven operation,

dramatically decreases the interval between performances of routine preventive

maintenance required to maintain this warranty coverage.

(for Canada)

Panasonic Professional Display Company

Unit of Panasonic Corporation of North America

Executive Office :

One Panasonic Way 1F-10, Secaucus, NJ 07094

EASTERN ZONE : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621

Mid-Atlantic/New England : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621

Southeast Region : 1225 Northbrook Parkway, Ste 1-160 Suwanee GA 30024 (770)338-6835

Central Region : 1707 N Randall Road E1-C-1, Elgin, IL 60123 (847)468-5200

WESTERN ZONE : 3330 Cahuenga Blvd W., Los Angeles, CA 90068 (323) 436-3500

Dallas Region : 6226 Abington Way, Houston, TX 77008 (713) 802-2726

No. CA/Northwest Region : 5870 Stone Ridge, #3, Pleasanton, CA (925) 416-5108

Government Marketing Department : 52 West Gude Drive, Rockville, MD 20850 (301) 738-3840

Panasonic Canada Inc.

5770 Ambler Drive

Mississauga, Ontario

L4W 2T3

Customer’s Record

The model number and serial number of this product can be found on its back cover. You should note this serial

number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of

your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.

Model Number Serial Number

Printed in Japan

PBS1108S1128

Pelican Th 50Vx100U Users Manual Th_50_65vx100u_Eng

TH-50VX100U to the manual 98eada1b-2f8c-4e39-a537-967f0f6f337b

Navigation menu

Versions of this User Manual:

Views

Navigation
