INTEGRATED WINDOW SENSOR SETUP

DETAILEDINSTRUCTIONS

INTEGRATEDWINDOWSENSORSETUP

SeeInsynctive.Pella.com/Supportforhow‐tovideos.

1. GetStarted

PlugBRIDGEintoanelectricaloutlet(lightwillturngreenandthenflashblue).

2. PrepareINTEGRATEDWINDOWSENSOR

NOTE:PellaoffersINTEGRATEDWINDOWSENSORSinmultiplewindowstyles.Choosethe

appropriateinstructionsforthewindowstyleneedingprepared.Forhelpdeterminingthe

windowstylerefertotheimagesa,b,andc.(showimagesofcasement,DSDHandASDHbut

leavebrandingoutofthetitleoftheimages)

ForWindowStyleA:(casement)

ToaccessINTEGRATEDWINDOWSENSOR,unlatchthewindowandusehandletoopenthe

sash.Thetransmitterislocatedinthejambstopbehindthelatchingmechanism.

Removethetransmitterfromthewindow,andliftupacorneroftheplasticcovertoexpose

thebattery.

WARNING:Usecautionwhenwindowsareopenandwhenremovingthetransmittertoavoid

afalloutofawindow.Keepchildrenandpetsawayfromopenwindows.

Removetheplastictabseparatingthebatteryfromthedevice.Pushdownonthebatteryto

ensurethatthebatteryisfirmlyinplace.Makesureplasticcoverisflatandinplace.

NOTE:Oncetheplastictabisremovedfromthebattery,youwillhave2minutesforyour

transmittertolearnwhattypeofwindowitwillbehousedin.If2minutespasswithoutthe

transmittersuccessfullylearningyourwindowtype,followstepsforremovingandreinserting

thebatteryonpage8.

Insertthetransmitterbackintothewindow;closeandlatchthewindow,thenwait10

seconds.

NOTE:Anytimepowerislostonthetransmitter,e.g.,duringabatterychange,thesteps

abovewillneedtoberepeated.

YouarereadytosyncINTEGRATEDWINDOWSENSORtoBRIDGE.MovetoStep3.

ForWindowStyleB:(DSdoublehung)

ToaccessINTEGRATEDWINDOWSENSOR,engagethetiltfeaturebyunlatchingthenopening

thewindowslightly.Depressthejamblinerwithonehandandpullthesashtowardyouwith

theotherhand.Repeatontheothersideandtiltthebottomsashdown.

Removethetransmitterfromthewindow,andliftupacorneroftheplasticcovertoexpose

thebattery.

WARNING:Usecautionwhenwindowsareopenandwhenremovingthetransmittertoavoid

afalloutofawindow.Keepchildrenandpetsawayfromopenwindows.

Removetheplastictabseparatingthebatteryfromthedevice.Pushdownonthebatteryto

ensurethatthebatteryisfirmlyinplace.Makesureplasticcoverisflatandinplace.

NOTE:Oncetheplastictabisremovedfromthebattery,youwillhave2minutesforyour

transmittertolearnwhattypeofwindowitwillbehousedin.If2minutespasswithoutthe

transmittersuccessfullylearningyourwindowtype,followstepsforremovingandreinserting

thebatteryonpage8.

Insertthetransmitterbackintothewindow;closeandlatchthewindow,thenwait10

seconds.Thetransmitterhasnowlearnedwhattypeofwindowitishousedin.

NOTE:Anytimepowerislostonthetransmitter,e.g.,duringabatterychange,thesteps

abovewillneedtoberepeated.

YouarereadytosyncINTEGRATEDWINDOWSENSORtoBRIDGE.MovetoStep3.

ForWindowStyleC:(ASdoublehung,alsowillbeusedforProlineeventually)

ToaccessINTEGRATEDWINDOWSENSOR,engagethetiltfeaturebyunlatchingthenopening

thewindowslightly.Depressbothtiltlatchesatthesametimeandpullthesashtowardyou.

WARNING:Usecautionwhenwindowsareopenandwhenremovingthetransmittertoavoid

afalloutofawindow.Keepchildrenandpetsawayfromopenwindows.

Removetheplastictabseparatingthebatteryfromthedevice.Ensurethatthebatteryis

firmlyinplace.

NOTE:Oncetheplastictabisremovedfromthebattery,youwillhave2minutesforyour

transmittertolearnwhattypeofwindowitwillbehousedin.If2minutespasswithoutthe

transmittersuccessfullylearningyourwindowtype,followstepsforremovingandreinserting

thebatteryonpage8.

Closeandlatchthewindow.

NOTE:Anytimepowerislostonthetransmitter,e.g.,duringabatterychange,thesteps

abovewillneedtoberepeated.

YouarereadytosyncINTEGRATEDWINDOWSENSORtoBRIDGE.MovetoStep3.

3.SyncINTEGRATEDWINDOWSENSORtoBRIDGE

EachINTEGRATEDWINDOWSENSORwillneedtobesyncedtoBridge.

WITHOUTHOMEAUTOMATION(Stand‐AloneMode)

PressandreleaseBRIDGESyncbuttonuntillightbeginsflashingorange.TheSyncbuttonis

thebottombuttonlocatedonthesideofBRIDGE.

NOTE:BRIDGEisinsyncmodewhiletheorangelightisflashing.BRIDGEwillremaininsync

modefor2minutes.BRIDGEwillthenbeep,andorangelightwillturnofftoindicateBRIDGE

exitedsyncmode.

TosyncINTEGRATEDWINDOWSENSORtoBRIDGE,unlatchandthenlatchthewindow;

repeat2timeswithin10seconds.

WaitforthelightonBRIDGEtoflashgreenandbeepfor2seconds.Thiswillindicatea

successfulsync.

IfINTEGRATEDWINDOWSENSORsyncisunsuccessful,unlatchandthenlatchthewindow2

moretimeswithin10seconds.ThenwaituntilBRIDGEindicatesasuccessfulsync.

RepeatthepreviousstepsuntilallINTEGRATEDWINDOWSENSORShavebeensyncedto

BRIDGE.

Toexitsyncmode,pressandholdSyncbuttononBRIDGEuntillightstopsflashingorange

WITHHOMEAUTOMATION

BRIDGEsupportstwotypesofhomeautomationsystems,

ProfessionallyInstalledandDo‐It‐Yourself(DIY)Z‐Wave.Foralistofcompatiblehome

automationsystemsorsyncinginstructions,visitInsynctive.Pella.com.

4.TESTINTEGRATEDWINDOWSENSORS

EachINTEGRATEDWINDOWSENSORshouldbetestedtoensureproperfunctionafteritis

synced.TotestINTEGRATEDWINDOWSENSORS,usethefollowingprocedure:

• UnlatchthewindowandverifythatSENSORreportstheproductasopenedonyourSTATUS

INDICATORorhomeautomationsystem.BRIDGEwillbeeptwice.

• ForCasementWindowsonly:Openthewindow.Movethelatchleverintotheclosedposition

andthenbackintotheopenedposition.EnsurethatSENSORdoesnotreportthewindowas

closed.(BRIDGEwillnotbeep.)OrverifystatusonyourSTATUSINDICATORorcompatible

homeautomationsystem.Closeandlatchthewindow.Unlatchthewindowandverifythat

SENSORreportsthewindowasopened.

• Ifanyofthesestepsfail,seethetroubleshootinginformationonpage11.

NOTE:Ifyouhaveselectedthechimestobeoff,BRIDGEwillnotbeep.SeeBridgeProductGuide

forinformationonsettingupchimes.

ADDITIONALINSTRUCTIONS



HOWTOFINDPRODUCTMANUFACTURER’SCODE

EachPella®Insynctive®productcontainsalabelwithaManufacturer’sCodethatwillberequired

tohelpPellaCustomer

Serviceidentifytheproductifserviceisrequired.TolocatetheManufacturer’sCodefor

INTEGRATEDWINDOWSENSOR,pulltransmitterfromyourwindow.Thelabelisonthecircuit

boardnexttothebattery.

ForWindowStyleConly:

UsePhillipsscrewdrivertoremovescrewsfromlock.Oncethelockisremovedturnover

transmitterhousing.Thelabelisonthecircuitboardnexttothebattery.

NOTE:Electrostatic‐sensitive.Avoidtouchingtheantennaorcircuitboardwhenaccessingthe

Manufacturer’sCode.

CAREANDMAINTENANCE

• TestInsynctiveproductsatleastonceperyeartohelpensureproperoperation.

• DonotpaintoverSENSORS.

REPLACINGBATTERIES

SeeInsynctive.Pella.com/Supportforhow‐tovideos.

WhenINTEGRATEDWINDOWSENSORbatteryislow,asignalwillbesenttoBRIDGE.Toaidin

identifyingwhichSENSORhasalowbattery,BRIDGEwillbeeptwiceandthenissuealongtone

whenINTEGRATEDWINDOWSENSORwiththelowbatterychangesfromclosedtoopened.To

replacethebattery:

ForWindowStyleAandBonly:

• Removethetransmitterfromthewindow,thenliftupthecorneroftheplasticcoverto

revealthebattery.

• CarefullyreplacewithaCR2032battery,ensuringthattheplus(+)sideofthebattery

facestowardyou.

• Replaceclearplasticcoveroverbatteryandensurethatbatteryisseated,theninsert

transmitterbackintowindowunit.



ForWindowStyleConly:

• UseTweezersorsimilartooltoremovethebatteryfromthetransmitterhousing.

• CarefullyreplacewithaCR2032battery,ensuringthattheplus(+)sideofthebattery

facestowardup.



• Closeandlatchthewindowwithin2minutesofreplacingthebatterytoteachSENSORwhat

typeofproductitisinstalledin.

• Wait2minutes,thentestSENSORbyunlatchingthewindowwithinstalledSENSOR.BRIDGE

shouldbeeptwice.ResyncingSENSORisnotrequiredafterbatterychange.

WARNING:Usecautionwhenwindowsareopenandwhenremovingthetransmittertoavoid

afalloutofawindow.Keepchildrenandpetsawayfromopenwindows.

WARNING:Batteriescarrytheriskoffire,explosionandburns.Donotrecharge,disassemble

orincinerate.

IMPORTANTNOTES:

Electrostatic‐sensitive.Avoidtouchingtheantennaorcircuitboardwhenchangingthe

battery.

FailuretochangebatterypromptlywhenlowwillimpairSENSORperformance.

Properlydisposeofusedbatteriesbasedonyourlocalrequirements.Abestpracticeisto

disposeofbatteriesatyourlocalhomechemicalcollectioncenter.CaliforniaOnly:Contains

perchloratematerial.Seedtsc.ca.gov/hazardouswaste/perchlorateforanyspecialhandling

regulations.



DELETINGINTEGRATEDWINDOWSENSOR

DeletingINTEGRATEDWINDOWSENSORSmaybeneededifyounolongerhaveausefor

INTEGRATEDWINDOWSENSORS.SeeInsynctive.Pella.com/Supportforhow‐tovideos.

1.PrepareINTEGRATEDWINDOWSENSOR

Removetransmitterfromwindowandliftupacorneroftheclearplasticcovertoexposethe

battery.RemoveandreinsertthebatterytoplaceSENSORindeletionmodefor2minutes.

ForWindowStyleC:

Usetweezerstoremovethebatteryfromthetransmitterhousing,replacethebattery

backinthehousingtoplacetheSENSORindeletionmodefor2minutes.

NOTE:If2minutespasswithoutasuccessfuldeletion,removeandinsertthebatteryagain.

WARNING:Usecautionwhenwindowsareopenandwhenremovingthetransmittertoavoid

afalloutofawindow.Keepchildrenandpetsawayfromopenwindows.

Insertthetransmitterbackintothewindow,closeandlatchthewindow,thenwait10

seconds.

YouarereadytodeleteINTEGRATEDWINDOWSENSORfromBRIDGE.



2.DeleteINTEGRATEDWINDOWSENSORfromBRIDGE

FordirectionsonhowtodeleteINTEGRATEDWINDOWSENSORfromhomeautomation,visit

Insynctive.Pella.com.

WITHOUTHOMEAUTOMATION(Stand‐AloneMode)

PressandholdBRIDGESyncbuttonuntillightbeginsflashingorange.TheSyncbuttonisthe

bottombuttonlocatedonthesideofBRIDGE.

NOTE:BRIDGEisinsyncmodewhiletheorangelightisflashing.BRIDGEwillremaininsync

modefor2minutes.BRIDGEwillthenbeep,andorangelightwillturnofftoindicateBRIDGE

exitedsyncmode.

TodeleteINTEGRATEDWINDOWSENSORfromBRIDGE,unlatchandthenlatchthewindow;

repeat2timeswithin10seconds.

WaitforthelightonBRIDGEtoflashredandbeep3times.Thiswillindicateasuccessful

deletion.

IfINTEGRATEDWINDOWSENSORdeletionisunsuccessful,returntoStep1andretrythe

process.

RepeattheabovestepsuntilallINTEGRATEDWINDOWSENSORShavebeendeletedfrom

BRIDGE.

Toexitsyncmode,pressandholdSyncbuttononBRIDGEuntillightstopsflashingorange.



TROUBLESHOOTING

AlsorefertoInsynctive.Pella.com/Supportformoretroubleshootinginformation,including

videos,frequentlyaskedquestionsandreferencematerials.

PROBLEMCAUSEANDPOSSIBLESOLUTION

CannotsyncINTEGRATED

WINDOWSENSORtoBRIDGE.

VerifySENSORbatteryisinstalledcorrectlyandplasticbatterytabhas

beenremoved.Seepage5foradditionalinformation.

Removeandreinstallbatterytorestartsyncmode.

MoveBRIDGEtosameroomasSENSORtoensurethatrangeisnotan

issue.

Makesurewindowlatchismovedtothefullylatchedpositionduring

unlatch/latch/unlatchcycling.

MakesureSENSORisfullysnappedorinsertedintothehousing.

SENSORfailedtolearntheproducttype.Userfailedtowait10seconds.

RepeatPrepareINTEGRATEDWINDOWSENSORstep.

MakesureBRIDGEisinsyncmode(orangelightshouldbe

flashing).

Casementwindowismissingthemagnetbehindthestrike.Thiswouldbe

manufacturingerror.

Double‐hungwindowdoesnothavetheInsynctive®lockassembly.This

wouldbeamanufacturingerror.

BRIDGEdoesnotbeepwhen

windowisopened.VerifythatBRIDGEchimefeatureisturnedon.SeeBridgeProductGuide

fordetails.

BatterymaybetoolowtooperateSENSOR.Replacebattery.Seepage8

foradditionalinformation.

SENSORmaybeoutofrange.MoveBRIDGEclosertoSENSOR.

VerifythatBRIDGEhaspower.

BRIDGEbeeps3timeswhenwindow

isopened.

BatteryislowinSENSOR;replacebattery.



FCCCOMPLIANCEANDINDUSTRYCANADA



ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforClassBdigital

devices,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipment

generates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin

accordancewiththeinstructionmanual,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterferencewillnotoccurina

particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevision

reception,whichcanbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmenttoanoutletonadifferentcircuitfromthereceiver.

•Consultthedealeroranexperiencedradio/TVcontractorforhelp.

ChangesormodificationsnotexpresslyapprovedbyPellaCorporationcouldvoidtheuser’s

authoritytooperatetheequipment.



ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust

acceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

ThisdevicecomplieswithIndustryCanadalicense‐exemptRSSstandard(s).Operationis

subjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,and(2)

thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.CetappareilestconformeavecIndustrieCanadaexemptsdelicence

standardRSS.L’opérationestsoumiseauxdeuxconditionssuivantes:(1)cetappareilnepeut

causerd’interférences,et(2)cetappareildoitacceptertouteinterférence,ycomprisles

interférencesquipeuventcauserunmauvaisfonctionnementdel’appareil.

LIMITEDWARRANTYAtwo‐yearlimitedwarrantycomesstandardwithpurchase.For

completewarrantydetails,visitInsynctive.Pella.com/IntegratedSensor.SOFTWARELICENSE

AGREEMENTANDPRIVACYPOLICYPella®Insynctive®productsarecoveredbythePella

InsynctiveproductsSoftwareLicenseAgreementandPellaInsynctiveproductsPrivacyPolicy

ineffectatthetimeofsale,whichcanbefoundatInsynctive.Pella.com.Byinstallingorusing

yourInsynctiveproducts,youareacknowledgingthattheInsynctiveSoftwareLicense

AgreementandPrivacyPolicyarepartofthetermsofsale.



FCCID:SO7‐13N80000ICID:110009A‐13N80000

FCCID:SO7‐13P20000ICID:11009A‐13P20000



LIMITEDWARRANTY

Atwo‐yearlimitedwarrantycomesstandardwithpurchase.Forcompletewarrantydetails,visit

Insynctive.Pella.com/IntegratedSensor.

SOFTWARELICENSEAGREEMENTANDPRIVACYPOLICY

Pella®Insynctive®productsarecoveredbythePellaInsynctiveproductsSoftwareLicense

AgreementandPellaInsynctiveproductsPrivacyPolicyineffectatthetimeofsale,whichcan

befoundatInsynctive.Pella.com.

ByinstallingorusingyourInsynctiveproducts,youareacknowledgingthattheInsynctive

SoftwareLicenseAgreementandPrivacyPolicyarepartofthetermsofsale.





Pella 13P20000 Double Hung Window Sensor User Manual INTEGRATED WINDOW SENSOR SETUP

Pella Corporation Double Hung Window Sensor INTEGRATED WINDOW SENSOR SETUP

INTEGRATED WINDOW SENSOR SETUP

Navigation menu

Namespaces

Views

Navigation
