Peloton Interactive HRC01 Peloton Heart Rate Monitor User Manual
Peloton Interactive Inc. Peloton Heart Rate Monitor Users Manual
Users Manual
Model No.: HRC01
Product Name: Peloton Heart Rate
Monitor
User Manual
![](/img.php?id=3900936&img=bg2.png)
PELOTON HEART RATE MONITOR
Peloton Interactive, Inc. 125 W 25th Street, 11FL, New York, NY 10001 www.onepeloton.com
USING THE PELOTON HEART RATE MONITOR
• Snap the sensor pod onto the chest strap.
• Adjust the strap to fit your lower chest. It should be snug but
comfortable.
• When the heart rate monitor detects a heartbeat, the LEDs will
flash red and blue. If your monitor does not detect your heartbeat,
aid the connection by moistening the electrodes with a small
amount of water, saliva, or electrode heart rate gel.
• Join a class. The heart rate monitor will connect to your Peloton
product automatically via ANT+.
READING THE LED INDICATORS
Flashing Red: The heart rate monitor detects a heartbeat.
The LED will stop flashing after 30 seconds.
Flashing Blue: The heart rate monitor detects a heartbeat and is
in Bluetooth pairing mode. The LED will continue flashing until the
monitor connects to a Bluetooth device, even if you connect to a
Peloton product via ANT+.
Flashing Yellow: The heart rate monitor’s battery is low. Replace
immediately with a new CR2032 3-volt battery.
REPLACING THE BATTERY
• The right LED will flash yellow when the battery needs to be replaced.
• The battery door is located on the underside of the sensor pod.
Unscrew it by inserting a coin into the slot and rotating it counterclockwise.
• When the battery door is loose, remove it. The battery sits inside the battery door.
• Wait for 20-30 seconds.Then insert a new CR2032 3-volt battery, with the at side facing down.
• Place the battery door over the markers. Insert a coin into the door slot and rotate
clockwise until the door is flush with the underside of the sensor pod.
• Test the heart rate monitor to make sure the sensor activates.
30 - 240 beats per minute (bpm)
User replaceable CR2032 3 volts
600+ hours
2.402 – 2.480 GHz (BLE) / 2.457 GHz(ANT+)
IPX7 Water Resistant
0 - 50°C/-32 - 122°F
13 grams
64mm
‐1.27 dBm (BLE) / ‐1.44 dBm (ANT+)
Typical 7.5mA
Less than 10uA
2AA3NHRC01
SPECIFICATIONS
Heart rate measurement range
Battery type
Expected battery life
Radio frequency protocol
Water rating
Operating temperature range
Weight
Size (sensor pod only)
Maximum output power
Peak active current
Stand-by- current
Contains FCC ID
READ IMPORTANT SAFETY INFORMATION ON REVERSE SIDE OF PAGE.
Follow all warnings and instructions.
WARNING Contact your local waste services provider to recycle coin cell batteries.
Batteries may contain perchlorate material and special handling may be required.
California customers: see www.dtsc.ca.gov/hazarouswaste/perchlorate
![](/img.php?id=3900936&img=bg3.png)
IMPORTANT SAFETY INFORMATION
Consult a doctor before beginning a new tness plan.
Incorrect or excessive training can result in serious injury.
If you have a pacemaker or other implanted electronic
device, consult your physician prior to using a heart rate
sensor.
Contains coin cell battery, can be fatal if swallowed. Keep
batteries away from children. Do not swallow. Swallowing
can lead to chemical burns, perforation of soft tissue, and
death. Fatal burns from batteries lodged in throat can occur
in as little as 2 hours.
If you experience faintness, chest pain, or shortness of
breath, stop exercising immediately and consult a doctor.
Heart rate and other measurements may be inaccurate.
Use for reference or information only.The heart rate sensor
is not a medical device. Readings could be inuenced by
interference from other devices or sources.
Only use correct replacement batteries. Others pose re
and explosion hazard.
SAVE THESE WARNINGS AND INSTRUCTIONS.
EU RADIO EQUIPMENT DECLARATION
OF CONFORMITY
Hereby, Peloton declares that the radio equipment type
HRC01 is in compliance with Directive 2014/53/EU. The
full text of the EU declaration of conformity is available
at the following internet address: www.onepeloton.com/
compliance.
FCC RULES PART 15
The enclosed product (hardware) device complies
with part 15 of the FCC Rules. Operation is subject to
following two conditions: (1) this device may not
cause harmful interference and (2) it must accept any
interference received, including interference that may
cause undesired operation.
MODIFICATION STATEMENT
This device has been designed to comply with the FCC
Rules. Changes or modifications not expressly approved
could void the user’s authority to use the device.
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. This
transmitter must not be re-located or operated in
conjunction with any other antenna or transmitter.
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in residential
installations. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed and used
in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference
to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment
and receiver
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
WARNING This product can expose you to chemicals,
including Lead, Nickel, and Acrylonitrile, which are
known to the State of California to cause cancer and
birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov.
WARNING Read all safety information before using
your heart rate monitor.
PELOTON HEART RATE MONITOR
Peloton Interactive, Inc. 125 W 25th Street, 11FL, New York, NY 10001 www.onepeloton.com
