Philips Consumer Lifestyle B120 Wireless HD Baby Monitor User Manual B120 QSG v0 1

Philips Consumer Lifestyle Wireless HD Baby Monitor B120 QSG v0 1

Contents

User Manual 1

B120/10
Connect the B120 monitor to the same Wi-Fi network as your phone
by following the onscreen instructions.
Warning - Strangulation Hazard - Children have
STRANGLED in cords. Keep this cord out of the reach
of children (more than 3 ft.(0.9 m) away). Do not
remove this tag.
As instructed on the screen, put the QR code image in front of the lens of the
monitor. Follow the onscreen instructions to complete the setup.
The green light is always on when the connection is complete.
1.On your iPhone or Android phone, download
the Philips In.Sight application from AppStore
or Google play. 2. Create and log in to your
account.
User Manual
+
In.Sight
Talk back
Add more monitors
Tap and hold When you talk to the micophone of the mobile phone.
You can be heard on the side of the B120 monitor.
Night vision
Tap to show the options bar. Tap On to switch the night vision on.
After the night vision is on for 10 minutes,
it switches off automatically.
Watch the video
Double tap to zoom in or out. Drag to pan through the video.
Switch to the list of monitors
Indicator of connectivity strength
Green: Strong
Yellow: Weak
Red: Disconnected
Switch the night vision on or off
Current temperature and humidity
Take photos
Switch the speaker on or off when your mobile phone goes to the standby mode
Record videos
Tap and hold to talk to the side of B120 monitor
Through Wi-Fi or 3G mobile network, connect your mobile phones to the B120 monitors over the Yoics service.
You can stream live video and audio remotely and locally from the B120 monitors to your mobile phone.
Mount on the stand Mount on walls
Light sensor
IR image sensor
Lens
Microphone
Status LED
Temperature and humidity sensor
USB connector for USB power adapter
Next
Connect the B120 monitor to power. Wait until the amber light flashes.
Auto On
Go to the list of monitors. Tap Add. Follow the onscreen instructions to complete the first-time setup.
Add
3G
Stream Live video/ audio
First-time setup
www.philips.com/welcome
Always there to help you
Register your product and get support at
Reset
User Manual
B120/37
B120A/37
3G
Alerts with video/ audio recordings
(A maximum of 25 alerts can be
recorded.)
For unread alerts, is displayed on
the video thumbnail.
Tap to play the video from
YouTube.
Set up your YouTube account. Each time the alerts go off, the video/audio recordings are
uploaded and saved to the cloud storage under your account.
To go to the settings of a monitor, tap > next to the monitor. You can select your options for the monitor.
If you mount the monitor on the ceiling, switch on Image flip.
To delete current monitor, tap the Delete monitor button.
humidity alert
temperature alert
motion alert
audio alert
Set alerts
To enable an alert, tap the icon to light it up.
Tap > to set the alert. To set the area that you want to monitor, hold
the corner and drag inwards/outwards;.
To select the area that you want to monitor, drag the video to pan through it..
Go to the list of monitors. Go to the settings of monitors.
Set up the cloud storage
General
Live video/audio
Tap Clear alerts to clear all alerts.
Monitors
3
Share the monitor
Check alerts
Setup the monitor
To enable the function, tap to light it up,
In Sharing list, add the email of your friend.
Monitors
Update the software
You are notified of software updates when they are available.
Click the “>”. Follow the onscreen instructions to update the
software.
Monitors
Monitors
Specifications Especificaciones Caractéristiques techniques
General information
AC power adapter
Philips ASUC30z-050060 (z = a, b, c, and e)
a direct plug-in power adapter with USB output terminal
and a different country plug type ('a'=America, 'b'=Britain,
'c'=Australia, 'e'=Europe)
Input: 100-240 V~ 50/60 Hz, 600 mA
Output: 5 V DC 1.5 A
Connectivity
Wi-Fi 802.11n
Apps
Platform: iOS, Android
Lens
Focus mode : Fixed
Focus range : 0.7 to 5 meters
Aperture : F2.8
Digital zoom : 2 x
Night mode : IR LED, 4 meters
Sensors
Ambient light sensor
IR LED
IR range: 4 meters
Temperature & humidity sensor
Range: - 10 ºC to 50 ºC, 20% to 90%
Video
Resolution
Streaming through Wi-Fi: 720p (High definition)
Streaming through 3G mobile network: VGA
Video format
H. 264
Audio
Input
High-sensitive mono microphone
Output
Amplifier: 0.5 W
Speaker: 8 ohm, 0.6W
Audio format
XDFASFSDAF
Software update >
All registered and unregistered trademarks are property of
their respective owners.
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
B120_10_QSG_V0.1
