Users Manual
Register your product and get support at HSB3280
Thank you for choosing Philips.
Need help fast?
Philips vous remercie de
votre confiance.
Besoin d'une aide
rapide?
Gracias por escoger Philips
Necesita ayuda
inmediata?
Read your Quick Use Guide and/or
Owner's Manual first for quick tips
that make using your Philips product
more enjoyable.
If you have read your instructions
and still need assistance,
you may access our online help at
www.philips.com/welcome
or call
1-888-PHILIPS (744-5477)
while with your product.
(and Model / Serial number)
Les Guide d'utilisation rapide et Manuel de
l'utilisateur regorgent d'astuces destinées à
simplifier l'utilisation de votre produit Philips.
Toutefois, si vous ne parvenez pas à résoudre
votre probléme, vous pouvez accéder à
notre aide en ligne à l'adresse
www.philips.com/welcome
ou formez le
1-800-661-6162 (Francophone)
1-888-PHILIPS (744-5477) (English speaking)
Veillez à avoir votre produit à
portée de main.
(et model / serial nombre)
Lea primero la Guía de uso rápido o el
Manual del usuario, en donde encontrará
consejos que le ayudarán a disfrutar
plenamente de su producto Philips.
Si después de leerlo aún necesita ayuda,
consulte nuestro servicio de
asistencia en línea en
www.philips.com/welcome
o llame al teléfono
1-888-PHILIPS (744-5477)
y tenga a mano el producto.
(y número de model / serial)
EN User manual 3
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
3EN
Return your Product Registration Card or register online at
www.philips.com/welcome today to get the very most from your purchase.
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so
don't miss out. Complete and return your Product Registration Card at once, or register online at
www.philips.com/welcome to ensure:
Visit our World Wide Web Site at http://www.philips.com/welcome
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS.
You’ve selected one of the best-built, best-
backed products available today.We’ll do
everything in our power to keep you happy
with your purchase for many years to come.
As a member of the PHILIPS “family,” you’re
entitled to protection by one of the most
comprehensive warranties and outstanding
service networks in the industry.What’s
more, your purchase guarantees you’ll
receive all the information and special offers
for which you qualify, plus easy access to
accessories from our convenient home
shopping network.
Most importantly, you can count on our
uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome -
and thanks for investing in a PHILIPS prod-
uct.
P.S. To get the most from your PHILIPS
purchase, be sure to complete and
return your Product Registration Card
at once, or register online at:
www.philips.com/welcome
*Proof of Purchase
Returning the enclosed card
guarantees that your date of
purchase will be on file, so no
additional paperwork will be
required from you to obtain
warrranty service.
*Product Safety
Notification
By registering your product,
you'll receive notification -
directly from the manufacturer
- in the rare case of a product
recall or safety defect.
*Additional Benefits
Registering your product guar-
antees that you'll receive all of
the privileges to which you're
entitled, including special
money-saving offers.
For Customer Use
Enter below the Serial No. which is located
on the rear of the cabinet. Retain this
information for future reference.
Model No. __________________________
Serial No. __________________________
Know these
safetysymbols
This “bolt of lightning” indicates unin-
sulated material within your unit may
cause an electrical shock. For the safety of
everyone in your household, please do not
remove product covering.
The “exclamation point” calls attention
to features for which you should read
the enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects
filled with liquids, such as vases, should not
be placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
ATTENTION: Pour éviter les choc élec-
triques, introduire la lame la plus large de la
fiche dans la borne correspondante de la
prise et pousser jusqu’au fond.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
4EN
Philips, P.O. Box 671539, Marietta, GA. 30006-0026
PHILIPS LIMITED WARRANTY
ONE (1) YEAR
WARRANTY COVERAGE:
PHILIPS warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
Philips warrants the product to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
The Philips warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received by Philips
within the Warranty Period. At its option, Philips will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in Philips current inventory,
or (3) refund the original purchase price of the product.
Philips warrants replacement products or parts provided under
this warranty against defects in materials and workmanship from
the date of the replacement or repair for ninety (90) days or for
the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes Philips’ property. When a refund
is given, your product becomes Philips’ property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products manu-
factured by or for Philips that can be identified by the trademark,
trade name, or logo affixed to it. This Limited Warranty does not
apply to any non-Philips hardware product or any software, even
if packaged or sold with the product. Non-Philips manufacturers,
suppliers, or publishers may provide a separate warranty for their
own products packaged with the bundled product.
Philips is not liable for any damage to or loss of any programs,
data, or other information stored on any media contained within
the product, or any non-Philips product or part not covered by
this warranty. Recovery or reinstallation of programs, data or
other information is not covered under this Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
Philips or Philips Authorized Service Location, (c) to a product or
a part that has been modified without the written permission of
Philips, or (d) if any Philips serial number has been removed or
defaced, or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product to Philips.
• Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of Philips.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product to Philips.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., PUERTO
RICO, OR U.S. VIRGIN ISLANDS…
Contact Philips Customer Care Center at:
1-888-PHILIPS (1-888-744-5477)
TO OBTAIN ASSISTANCE IN CANADA…
1-800-661-6162 (French Speaking)
1-888-PHILIPS (1-888-744-5477) - (English or Spanish
Speaking)
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
3121 233 48802
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
5
6 Adjust volume level and sound effect
24
Adjust volume level 24
Adjust subwoofer volume 24
Select a sound effect 24
Select a game sound effect 24
Select a movie sound effect 24
Select a music mode (for USB only) 24
Mute sound 24
7 Tune to FM radio stations 25
Program radio stations automatically 25
Program radio stations manually 25
Tune to a preset radio station 25
8 Use more of your soundbar 26
Program remote control 26
Rename an AV source 26
Enable/disable automatic on/standby 26
Set the alarm timer 27
Set the sleep timer 27
9 Product information 28
Product information 28
Specifi cations 28
Amplifi er 28
Tuner (FM) 28
L/R speakers 28
Subwoofer 28
General information 28
USB playability information 28
10 Troubleshooting 30
11 Appendix 31
Mount to a wall 31
What’s in the supplied mounting kit 31
What else you’ll need 31
Mount the main unit and speakers 31
Contents
1 Important 6
Important safety instructions 6
Notice 7
Disposal of old equipment and Used
batteries 8
2 Your Soundbar System 10
Introduction 10
What’s in the box 10
Overview of the main unit 11
Overview of the remote control 12
3 Get started 15
Attach speakers to the main unit 15
Attach the stand 15
Connect AV devices 16
Option 1: Connect this soundbar to
devices through the TV 16
Option 2: Connect devices through this
soundbar to the TV (basic) 17
Option 3: Connect devices through this
soundbar to the TV (advanced) 18
Connect FM antenna 19
Connect power 19
Install remote control batteries 20
Set clock 20
Turn on 21
Switch to standby mode 21
Set up wireless connection manually 21
4 Play 22
Play an AV source through this soundbar 22
Play from USB 22
5 Control USB play 23
Skip to a track 23
Pause/resume play 23
Search within a track 23
Repeat play 23
Random play 23
Program tracks 23
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
6
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifi ers) that
produce heat.
i For countries with a polarized mains,
do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fi t into
your outlet, consult an electrician for
replacement of the obsolete outlet.
Caution: To prevent electric shock, match
the wide blade of the plug to the wide
slot, fully insert.
j Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
k Only use attachments/accessories
specifi ed by the manufacturer.
l Use only with the cart, stand, tripod,
bracket, or table specifi ed by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
1 Important
Important safety instructions
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
7
Warning
Never remove the casing of this soundbar.
Never lubricate any part of this soundbar.
Never place this soundbar on other electrical
equipment.
Keep this soundbar away from direct sunlight, naked
fl ames or heat.
Never look into the laser beam inside the soundbar.
Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect the soundbar from
the power.
•
•
•
•
•
•
a Wall or Ceiling Mounting - The
appliance should be mounted to a wall
or ceiling only as recommended by the
manufacturer.
Wall mounting of the soundbar should only be
performed by qualifi ed personnel. The soundbar
must only be mounted on an appropriate wall
bracket and on a wall that can safely hold the
weight of the soundbar. Improper wall mounting
can result in severe injury or damage. Do not
attempt to wall mount the soundbar yourself.
Notice
Notice of compliance
For USA:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.•
m Unplug this apparatus during lightning
storms or when unused for long periods
of time.
n Refer all servicing to qualifi ed service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
o Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
Install all batteries correctly, + and - as
marked on the unit.
Do not mix batteries (old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not
used for a long time.
p Apparatus shall not be exposed to
dripping or splashing.
q Do not place any sources of danger on
the apparatus (e.g. liquid fi lled objects,
lighted candles).
r This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
•
•
•
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
8
Disposal of old equipment and Used
batteries
Information for Users on Collection and
Disposal of Old Equipment and Used Batteries
These symbols on the products, batteries,
packaging, and/or accompanying documents
mean that used electrical and electronic
products and batteries should not be mixed
with general household waste. For proper
treatment, recovery and recycling of old
products and used batteries, please take them
to applicable collection points, in accordance
with your national legislation and the Directives
2002/96/EC and 2006/66/EC.
By disposing of these products and batteries
correctly, you will help to save valuable
resources and prevent any potential negative
effects on human health and the environment
which could otherwise arise from inappropriate
waste handling.
For more information about collection and
recycling of old products and batteries, please
contact your local municipality, your waste
disposal service or the point of sale where you
purchased the items.
Information on Disposal in other Countries
outside the European Union
These symbols are only valid in the European
Union. If you wish to discard these items, please
contact your local authorities or dealer and ask
for the correct method of disposal.
Note for the battery symbol
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
For Canada:
This digital apparatus does not exceed the Class
B limits for radio noise emissions from digital
apparatus as set out in the Radio Interference
Regulations of the Canadian Department of
Communications. This Class B digital apparatus
complies with Canadian ICES-003.
The set complies with the FCC-Rules, Part
15. Operation is subject to the following two
conditions:
1.This device may not cause harmful
interference, and
2.This device must accept any interference
received, including interference that may cause
undesired operation.
FCC Declaration of conformity
Model number: PHILIPS BTM630/37
Trade Name: Philips
Responsible Party:
Philips Consumer Electronics
P. O. Box 671539
Marietta, GA 30006-0026
1-800-PHILIPS (744-5477)
Any changes or modifi cations made to this
device that are not expressly approved by
Philips Consumer Electronics may void the
user’s authority to operate the equipment.
Manufactured under license from Dolby
Laboratories. ‘Dolby’, ‘Pro Logic’ and the
double D symbol are trademarks of Dolby
Laboratories.
•
•
•
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
9
This symbol might be used in combination with
a chemical symbol. In this case it complies with
the requirement set by the Directive for the
chemical involved.
Environmental information
All redundant packing material has been
omitted. We have done our utmost to make the
packaging easily separable into mono materials.
Please observe the local regulations regarding
the disposal of packing materials.
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
10
2 Your Soundbar
System
Congratulations on your purchase, and
welcome to Philips! To fully benefi t from the
support that Philips offers, register your product
at www.Philips.com/welcome.
Introduction
Your soundbar provides superb sound
performance when you watch TV, DVDs, listen
to music, or play games.
You can control all connected audio/video
devices easily with the programmable smart
remote control.
The wireless subwoofer makes setup simple,
too - there are no messy cables to connect.
What’s in the box
Check and identify the contents of your
package:
Main unit
Speakers (x 2)
Digital wireless subwoofer
Smart remote control (with battery)
AC power adaptor for main unit
Studs (x2) used to attach speakers to main
unit
Table stand
Wall mount bracket and screws (x4)
FM antenna
AV cable
Coaxial cable
Composite cable
•
•
•
•
•
•
•
•
•
•
•
•
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
11
hPRESET/
Select a preset FM radio station.
Select an album/folder in a connected
USB device.
i- VOL +
Adjust volume.
Adjust time.
jSOURCE
Select a source for play: TUNER, USB,
AV1, AV2, AV FRONT or COAX.
Enable/disable automatic on/standby.
kPRESS
Detach speakers from the main unit.
lDC IN
Connect the AC adaptor.
•
•
•
•
•
•
•
•
Overview of the main unit
aSOUND SETTINGS (GAMES, MOVIE,
MUSIC)
Select a sound effect.
b IR sensor
cAV FRONT (VIDEO L-AUDIO-R)
AV input sockets on the front panel.
d Flip cover
e Display panel
Show current status.
f
Socket for a USB mass storage device.
gPOWER
Turn on the soundbar, switch to
standby mode, or switch to Eco
Power Standby.
•
•
•
•
•
abe
di
gj
cfh
abe
di
gj
cfh
k l qnm o p
k l qnm o p
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
12
mAUDIO IN - COAXIAL
Coaxial audio output socket.
nVIDEO OUT
Socket for composite video output.
oAV2 IN (VIDEO L - AUDIO - R)
AV input sockets.
pAV1 IN (VIDEO L - AUDIO - R)
AV input sockets.
qFM ANTENNA
Connect the FM antenna.
•
•
•
•
•
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
13
a
Turn on the soundbar, switch to
standby mode, or switch to Eco
Power Standby.
bSET TIME/PROG
Set the clock.
Program tracks in a USB device.
Program radio stations.
cSETUP
Rename AV resource.
dREPEAT
Select a repeat play mode for the
connected USB device.
eSHUF
Play tracks in the USB device
randomly.
fGAME SOUND
Select a game sound setting.
gMOVIE SOUND
Select a movie sound setting.
hVOL + / -
Adjust volume.
Adjust time.
iLEARN
Program remote control.
jCOAX
Select the AV input source from the
AUDIO IN - COAXIAL socket.
kAV FRONT
Select the AV source input from the
AV FRONT (VIDEO L-AUDIO-R)
sockets.
lAV2
Select the AV source input from the
AV2 IN (VIDEO L - AUDIO - R)
sockets.
mAV1
Select the AV source input from the
AV1 IN (VIDEO L - AUDIO - R)
sockets.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Overview of the remote
control
w
x
y
u
q
o
m
l
p
t
s
r
v
d
c
b
a
f
g
h
j
k
i
e
n
w
x
y
u
q
o
m
l
p
t
s
r
v
d
c
b
a
f
g
h
j
k
i
e
n
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
14
n Programing buttons
Are reserved for remote control
programing.
o/
Fast reverse or fast forward within a
track in the USB device.
Tune to a radio station.
p Indicator for remote control programing
qMUSIC MODE/SUBW VOL
In AV1, AV2, AV FRONT or
COAXIAL mode, select a music
sound setting.
In USB mode, adjust subwoofer
volume.
r/
Skip to the previous/next track in the
USB device.
s OK /
Start or pause USB play.
Confi rm renaming of an AV source.
tPRESET/ALB/
Skip to the previous/next album
(folder) in the USB device.
Select a preset radio station.
uMUTE
Mutes volume.
vTIMER
Set the alarm timer.
wSLEEP
Set the sleep timer.
xUSB
Select the USB source.
yTUNER
Select the tuner (FM) source.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
15
3 Insert a supplied stud into the hole.
4 Repeat steps 2 and 3 to attach the right
speaker.
Attach the stand
1 Slide the supplied table stand onto the
bottom of the main unit until you hear a
click.
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial numbers. Find the model
number and serial number of this soundbar at
the back or the bottom of your soundbar. Write
these numbers here:
Model No. __________________________
Serial No. ___________________________
Attach speakers to the main
unit
1 Place the main unit on a soft and fl at
surface.
Ensure that the bottom side faces
upwards.
2 Attach the left speaker to the left side of
the main unit.
•
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
16
You can also connect the red/white
audio connectors of the supplied AV
cable from the TV to a set of audio
input sockets.
Note
It is unnecessary to connect the yellow video
connectors.
•
•
TV
AUDIO OUT
(DIGITAL)
TV
AUDIO OUT
(DIGITAL)
TV
LR
AUDIO OUT
Not used
TV
LR
AUDIO OUT
Not used
Tip
You can also mount the soundbar on a wall (see
‘Appendix’ on page 29).
•
Connect AV devices
Note
There are various ways to connect the soundbar to
other AV devices. You only need to select the best
option that fi ts your existing AV device setup.
For AV connection to the soundbar, there are multiple
sets of AV sockets available on the main unit. You can
choose either set for an AV connection.
When you connect cables, ensure that the color of the
plug matches the color of the socket.
To use sockets on the front panel, fl ip open the cover.
The types of AV devices and connections in the
following instructions are for reference only.
•
•
•
•
•
Option 1: Connect this soundbar to
devices through the TV
If all the devices for use are connected to the
TV and the TV has an available audio output
socket, follow these instructions.
1 If the TV has a digital output socket,
connect the supplied coaxial cable
(orange) from the TV to the AUDIO IN
- COAXIAL socket.
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
17
Connect the AV output sockets the
set top box to the AV1 IN (VIDEO L
- AUDIO - R) sockets.
C DVD player
Connect the AV output sockets on the DVD
player to the AV2 IN (VIDEO L - AUDIO - R)
sockets.
AUDIO VIDEO
AUDIO OUT
L
R
AUDIO VIDEO
AUDIO OUT
L
R
AUDIO VIDEO
AUDIO OUT
L
R
AUDIO VIDEO
AUDIO OUT
L
R
Option 2: Connect devices through
this soundbar to the TV (basic)
If the TV does not have an available audio
output socket, follow these instructions.
1 Connect the video input socket on the TV
to the VIDEO OUT socket.
2 Connect the AV devices directly to the
soundbar:
A Game console:
Connect the AV output sockets on
the game console to the AV FRONT
(VIDEO L-AUDIO-R) sockets.
B Set top box
TV
VIDEO IN
TV
VIDEO IN
English
EN
BLQGHVLJQ[POLQGG6HF
BLQGHVLJQ[POLQGG6HF
