Philips Consumer Lifestyle SCD530 UPCS Baby Monitor (Baby Unit) User Manual A5
Philips Consumer Lifestyle UPCS Baby Monitor (Baby Unit) A5
User Manual
29
0000.0000.00.00
2 3
45 6 27 28
1 3 4 5
6 7 8 9
10 11 12 13
14 15 16 17
18 19 20 21
3
4
5
6
14
12
13
1
9
10
2
3
4
5
2
1 18
19
11
10
20
21
9
8
717
16
15
17
16
7
8
6 12
18
2
3
4
5
1
7
8
9
6
11
13
14
15
2
22 23 24 25
26 27 28 29
30 31 32 33
34 35
SCD530
ENGLISH 8
8
IMPORTANT SAFETY INSTRUCTIONS
Some of the following information may not apply to your particular product; however, when using
baby monitor equipment, basic safety precautions should always be followed to reduce the risk of
re, electric shock and injury to persons, including the following:
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus
(including ampliers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11 Only use attachments/accessories specied by the manufacturer.
12 Unplug this appliance during lightning storms or when not used for long periods of time.
13 Refer all servicing to qualied service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
14 This baby monitor is intended as an aid. It is not a substitute for responsible and proper adult
supervision and should not be used as such.
15 Use this appliance only for its intended use as described in this manual.
16 Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners.
17 Products should not be used while you are in a bathtub, shower or pool. Immersion of the
product in water could cause an electrical shock.
18 This product should be operated only from the type of power source indicated on the type
plate of the adapters (A15,B9). If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
19 Do not overload wall outlets and extension cords as this can result in the risk of re or electric
shock.
20 Never push objects of any kind into this product through casing slots as they may touch
dangerous voltage points or short out parts that could result in a risk of re or electric shock.
Never spill liquid of any kind on the product.
21 To reduce the risk of electric shock, do not disassemble this product, but call 1-800-54-AVENT
(1-800-542-8368) for assistance. Opening or removing covers (except battery compartment
lids) may expose you to dangerous voltage or other risks. Incorrect reassembly can cause
electric shock when the appliance is subsequently used.
22 To prevent strangulation with power cord, never place monitor within reach of child. Do not use
with extension cords.
If your product utilizes batteries, the following additional precautions should be
observed:
1 Use only the type and size of batteries specied in the user manual.
2 Do not dispose of batteries in re. They may explode. Check with local regulations for possible
special disposal instructions.
ENGLISH
3 Exercise care in handling batteries in order not to short out the batteries with conducting
materials such as rings, bracelets and keys. Overcharging, short circuiting, reverse charging,
mutilation, or incineration of batteries must be avoided to prevent one or more of the following
occurrences: release of toxic materials, release of hydrogen and/or oxygen gas, rise in surface
temperature.
4 Do not attempt to recharge batteries provided with or identied for use with this product that
are not intended to be charged. The batteries may leak corrosive electrolyte or explode.
5 Do not attempt to rejuvenate the batteries provided with or identied for use with this product
by heating them. Sudden release of battery electrolyte may occur, causing burns or irritation to
eyes or skin.
6 If and when necessary, the batteries must be replaced with identical new ones from the same
manufacturer. If a battery to be replaced is connected with other batteries in series, it is
recommended that the other batteries be replaced with new ones at the same time.
7 Reverse polarity installation of the batteries in the end product must be avoided. Reverse
insertion of batteries can cause charging, and that may result in leakage or explosion.
8 Remove batteries from this product if you store the product over 30 days because the batteries
could leak and damage the product.
9 Discard ‘dead’ batteries as soon as possible since ‘dead’ batteries are more likely to leak in a
product. If a battery has leaked or vented, it should be replaced immediately using protective
gloves.
10 Do not store this product, or the batteries provided with or identied for use with this product,
in high-temperature areas. Batteries that are stored in a freezer or refrigerator for the purpose
of extending shelf life should be protected from condensation during storage and defrosting.
Batteries should be stabilized at room temperature prior to use after cold storage.
11 If your product uses rechargeable batteries, charge the batteries only in accordance with the
instructions and limitations specied in the user manual.
12 There is a risk of explosion if batteries are replaced with an incorrect type. For the parent
unit, always use the SCD530 Li-Ion rechargeable battery pack as supplied with the
appliance.
SAVE THESE INSTRUCTIONS
CAUTION:THE SYMBOL SHOWN IN FIGURE 1 MEANS THAT THERE IS A
RISK OF EXPLOSION OF THE BATTERIES AND/OR OF SERIOUS DAMAGE
TO THE BABY MONITOR IF THE BATTERIES OR THE ADAPTER ARE
REPLACED WITH AN INCORRECT TYPE. (Fig. 1)
Adapter for baby unit:
Input: 120 VAC 60 Hz
Output: 7.5 VDC 400 mA
Adapter no. UD075040B
Adapter for charger:
Input: 100-240 VAC 50/60Hz
Output: 7.5VDC 500mA
Adapter no. SSA-5W-09 US 075050F
The socket-outlet shall be installed near the equipment and shall be easily accessible.
For the baby unit, only use 1.5V AA alkaline batteries (batteries not supplied).
For the parent unit, only use the SCD530 Li-Ion rechargeable battery pack as supplied with the
appliance.
Dispose of used batteries according to the instructions.
Compliance information
The FCC ID number is located on the casing bottom of the parent unit and in the battery
compartment of the baby unit.
-
-
-
-
-
-
-
ENGLISH 9
The term ‘IC’ before the certication number signies that Industry Canada technical specications
were met.This certication means that the equipment meets certain radio communications and
operational requirements. This device complies with Part 15 of the FCC Rules and ICES-003 of
Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.This device complies also with RSS-213 of Industry
Canada.
Radio interference
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules and applicable Industry Canada specications. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. For handheld operation, this equipment has been
tested and meets the FCC RF exposure guidelines. For body-worn operation, this product has been
tested and meets the FCC RF exposure guideline when used with the belt clip or neck strap
supplied with this product. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter. This equipment also complies with Industry Canada RSS-102 with
respect to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
Do not attempt to repair or modify this equipment
Any repairs or alterations made by the user to the equipment may void the warranty and
compliance of the equipment. Refer servicing to authorized or designated service centers.
Introduction
Congratulations on your purchase and welcome to Philips AVENT! To fully benet from the support
that Philips AVENT offers, register your product at www.philips.com/welcome.
Philips AVENT is dedicated to producing caring, reliable products that give parents the reassurance
they need. This Philips AVENT baby monitor provides round-the-clock support by ensuring you can
always hear your baby clearly without any distracting noise. The DECT technology guarantees zero
interference from other wireless appliances and a crystal clear signal between the baby unit and the
parent unit. The temperature and humidity sensor enables you to monitor the climate in your baby’s
room, and offers you personalized settings to help keep your baby’s room healthy and comfortable.
General description (Fig. 2)
A Parent unit
1 On/off button 3
2 Slot for belt clip
3 TALK button
4 MENU button
-
-
-
ENGLISH10
5 LINK light
6 Microphone
7 Loudspeaker
8 Menu and volume +/– buttons
9 OK button
10 Display
11 Sound level lights
12 Belt clip
13 Adapter
14 Small appliance plug
15 Charger
16 Charging light
17 Neck strap
18 Compartment for rechargeable battery pack
19 Opening for neck strap
20 Lid of compartment for rechargeable battery pack
21 Rechargeable battery pack (included)
B Baby unit
1 On/off button 3
2 PAGE button
3 Display
4 Power-on light
5 Volume +/– buttons
6 Nightlight button Q
7 Lullaby button K
8 Play/stop button E
9 Microphone
10 Adapter
11 Large appliance plug
12 Cooling vents
13 Loudspeaker
14 Temperature and humidity sensor
15 Socket for large appliance plug
16 Non-rechargeable batteries (not included)
17 Compartment for non-rechargeable batteries
18 Lid of compartment for non-rechargeable batteries
C Display
1 $ = temperature alert
2 Ñ° = room temperature indication
3 g = sound alert
4 r= humidity indication
5 s = paging symbol
6 K = lullaby symbol
7 Q = nightlight symbol
8 T = battery symbol
9 Volume/microphone sensitivity indications:
g = volume off
h = minimum sensitivity/volume
i = maximum sensitivity/volume
Other display indications (not shown):
’High’ = room temperature above temperature set in menu
‘Low’ = room temperature below temperature set in menu
-
-
-
-
-
ENGLISH 11
‘Not linked’ = no connection between units*
’Paused’ = lullaby is interrupted
‘Searching’ = units are searching for connection*
‘Linked’ = units are linked*
’Talk’ = talk function is active
* This is only shown on the display of the parent unit.
D Travel pouch
Important
Read the user manual carefully before you use the appliance and save it for future reference.
This baby monitor is intended as an aid. It is not a substitute for responsible and proper adult
supervision and should not be used as such.
This monitor is not intended to be used as a medical monitor and its use should not replace
adult supervision.
Check if the voltage indicated on the adapter corresponds to the local electrical voltage
before you connect the appliance.
This appliance is suitable for electrical outlet voltages of 120V.
Use and store the appliance at a temperature between 50°F (10°C) and 104°F (40°C).
Do not expose the baby monitor to extreme cold or heat or to direct sunlight.
Make sure the baby unit and power cord are always out of reach of the baby (at least 3 feet/1
meter away).
Never place the baby unit inside the baby’s bed or playpen.
Never cover the baby monitor with a towel or blanket.
Never immerse any part of the baby monitor in water or any other liquid.
Never use the baby monitor in moist places or close to water.
Except for the battery compartment, do not open the housing of the baby unit and parent
unit in order to prevent electric shock.
Only use the adapters supplied.
The adapters contain a transformer. Do not cut off the adapters to replace them with other
plugs, as this will cause a hazardous situation.
If one of the adapters is damaged, always have it replace with one of the original type in
order to avoid a hazard.
If you place the parent unit next to a transmitter or other DECT appliance (e.g. a DECT
telephone), the connection with the baby unit may be lost.
The temperature and humidity sensor only measures the temperature and humidity in the
baby’s room. It cannot be used to control or adjust the temperature and humidity in the
baby’s room.
The power outlet should be located near the appliance and easily accessible.
Preparing for use
Baby unit
You can run the baby unit on outlet electricity or on non-rechargeable batteries. Even if you are
going to operate the unit on outlet electricity, we advise you to insert non-rechargeable batteries.
This guarantees automatic back-up in case of power failure.
Operation on outlet electricity
1 Put the large appliance plug in the baby unit and put the adapter in a wall outlet (Fig. 3).
The power-on light goes on.
-
-
-
-
-
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH12
Operation on non-rechargeable batteries
The baby unit runs on four 1.5V R6 AA batteries (not included). We strongly advise you to use
Philips LR6 PowerLife batteries.
Do not use rechargeable batteries, as the baby unit does not have a charging function.
Unplug the baby unit and make sure your hands and the unit are dry when you insert the non-
rechargeable batteries.
1 Remove the lid of the compartment for non-rechargeable batteries. (Fig. 4)
2 Insert four non-rechargeable batteries (Fig. 5).
Note: Make sure the + and - poles point in the right direction.
3 Reattach the lid. (Fig. 6)
Parent unit
Operation on rechargeable battery pack
The parent unit comes with a rechargeable Li-Ion 1000mAh battery pack.
Charge the parent unit before you use it for the rst time or when the parent unit indicates that the
battery is low (the empty battery symbol ashes on the display and the parent unit beeps). The
parent unit starts indicating that the battery pack is low 30 minutes before the battery pack is
completely empty.
Note: If the rechargeable battery pack is completely empty, the parent unit automatically switches off
and loses contact with the baby unit.
1 Remove the lid of the compartment for the rechargeable battery pack (Fig. 7).
2 Insert the rechargeable battery pack (Fig. 8).
3 Reattach the lid (Fig. 9).
4 Insert the small appliance plug into the charger, put the adapter in a wall outlet and place the
parent unit in the charger (Fig. 10).
The charging light on the charger goes on.
The display shows a charging battery symbol to indicate that the parent unit is charging.
5 Leave the parent unit in the charger until the battery pack is fully charged.
During charging, the charging light on the charger lights up continuously.
When the battery pack is fully charged, the display of the parent unit shows a full battery
symbol T.
When you charge the parent unit for the rst time or after a long period of disuse, switch it
off and let it charge continuously for at least 10 hours.
Charging normally takes 4 hours, but it takes longer when the parent unit is switched on while
charging. To keep the charging time as short as possible, switch off the parent unit during
charging.
When the battery pack is fully charged, the parent unit can be used cordlessly for at least 24
hours.
Note: When the parent unit is charged for the rst time, the operating time is less than 24 hours. The
battery pack only reaches its full capacity after you have charged and discharged it four times.
Note: When the parent unit is not in the charger, the battery pack gradually discharges, even when the
parent unit is switched off.
Using the appliance
1 Place the parent unit and the baby unit in the same room to test the connection (Fig. 11).
Make sure the baby unit is at least 1 metre/3 feet away from the parent unit.
,
,
,
,
-
-
-
ENGLISH 13
2 Press and hold the on/off button 3 on the baby unit until the green power-on light goes
on. (Fig. 12)
Note: The power-on light always lights up green, even when there is no connection with the parent unit.
The nightlight lights up briey and then fades out again.
The display lights up and the battery symbol appears on the display (Fig. 13).
After 2 seconds the temperature and humidity values are shown on the display (Fig. 14).
3 Press and hold the on/off button 3 on the parent unit until the sound level lights light up
briey. (Fig. 15)
The display goes on and the battery symbol appears on the display (Fig. 16).
The LINK light ashes red and the message ‘Searching’ appears on the display. (Fig. 17)
The LINK light on the parent unit turns green and lights up continuously when a connection
has been established between the baby unit and parent unit. The message ‘Linked’ appears on
the display. (Fig. 18)
After 2 seconds the message ‘Linked’ disappears and the temperature and humidity values
are shown on the display. (Fig. 19)
The rst time you switch on the parent unit, the message ‘Language’ appears on the display.
Select the desired language (see chapter ‘Menu options, section ‘Setting display
language’). (Fig. 20)
If no connection is established, the LINK light on the parent unit stops ashing and lights up
red. The parent unit beeps from time to time and the message ‘Not Linked’ appears on the
display. (Fig. 21)
Positioning the baby monitor
1 Place the baby unit at least 3 feet/1 meter away from your baby (Fig. 22).
2 Place the parent unit within the operating range of the baby unit. Make sure it is at least 3
feet/1 meter away from the baby unit to avoid acoustic feedback (Fig. 11).
For more information on the operating range, see section ‘Operating range’ below.
Operating range
The operating range of the baby monitor is 1000 feet/330 meters in open air. Depending on the
surroundings and other disturbing factors, this range may be smaller. Indoors the operating range is
up to 150 feet/50 meters.
Dry materials Material thickness Loss of range
Wood, plaster, cardboard, glass
(without metal, wires or lead)
< 12 in/30cm 0-10%
Brick, plywood < 12 in/30cm 5-35%
Reinforced concrete < 12in/30cm 30-100%
Metal grilles or bars < 0.4in/1cm 90-100%
Metal or aluminum sheets < 0.4in/1cm 100%
For wet and moist materials, the range loss may be up to 100%.
Features
The following features are described in chapter ‘Menu options’, as they can only be operated in the
menu of the parent unit:
Adjusting microphone sensitivity
Sound alert on/off
Setting room temperature range (minimum and maximum temperature)
,
,
,
,
,
,
,
,
,
-
-
-
ENGLISH14
Temperature alert on/off
Vibration alert on/off
Adjusting loudspeaker volume
1 Press the volume + or – button on the baby unit until the desired loudspeaker volume for
the baby unit has been reached (Fig. 23).
2 Press the volume + or – button on the parent unit until the desired loudspeaker volume for
the parent unit has been reached (Fig. 24).
The displays give visual feedback on the volume settings of the units:
g = parent unit volume switched off/silent baby monitoring
h = minimum volume (parent unit and baby unit)
i = maximum volume (parent unit and baby unit)
Note: If the volume is set to a high level, the units consume more power.
Talk function
You can use the TALK button on the parent unit to talk to your baby (e.g. to comfort your baby).
1 Press and hold the TALK button and talk clearly into the microphone from a distance of 6-
12in/15-30cm (Fig. 25).
The green LINK light starts ashing and the message ‘Talk’ appears on the display.
2 Release the TALK button when you have nished talking.
Sound level lights
The parent unit continuously monitors the sound level in your baby´s room and the sound level
lights let you know if there is any activity. If your baby cries, you see the sound level lights light up on
the parent unit.
As long as the baby unit does not detect a sound, all sound level lights on the parent unit are
out.
When the baby unit picks up a sound, one or more sound level lights on the parent unit go on.
The number of lights that go on is related to the loudness of the sound picked up by the baby
unit.
Nightlight
1 Press the nightlight button Q on the baby unit to switch on the nightlight. (Fig. 26)
Q appears on the display of the parent unit.
2 Press the nightlight button Q again to switch off the nightlight.
The nightlight dims gradually before it goes out completely.
Q disappears from the display of the parent unit.
Tip: Switch off the nightlight when you operate the baby unit on non-rechargeable batteries. This saves
power.
Paging the parent unit
If you have misplaced the parent unit and its volume is switched off, you can use the PAGE button
on the baby unit to locate the parent unit.
Note: The paging function only works when the parent unit is switched on.
1 Press the PAGE button on the baby unit (Fig. 27).
The message ‘Paging’ and the paging symbol appear on the displays of the baby unit
and parent unit.
The parent unit produces a paging alert tone.
-
-
,
-
-
-
,
-
-
,
,
,
,
,
ENGLISH 15
2 To stop the paging alert tone, press the PAGE button again or press any button on the parent
unit.
Lullabies function
1 Press the play/stop button E on the baby unit to play the currently selected
lullaby. (Fig. 28)
2 To select another lullaby, press the lullaby button K on the baby unit within 2 seconds to
toggle through the list of lullabies. (Fig. 29)
Note: If you do not press the lullaby button K for more than 2 seconds, the lullaby shown on the display
starts to play.
The number of the lullaby appears on the display together with the lullaby symbol K.
The lullaby repeats continuously.
3 To stop the lullaby, press the play/stop button E on the baby unit again. (Fig. 28)
The number of the lullaby and the lullaby symbol K disappear from the display.
4 To select another lullaby when a lullaby is playing:
Press the lullaby button K on the baby unit within 2 seconds to toggle through the list of
lullabies.
Note: If you do not press the lullaby button K for more than 2 seconds, the lullaby shown on the display
starts to play.
Humidity
When there is a connection between the baby unit and the parent unit, the humidity level is shown
on the display of both units.
The optimal humidity level is between 40% and 60%. It is very important to maintain the correct
humidity level as it helps to protect your baby from irritation of the mucous membranes, dry and
itchy skin, chapped lips and a dry, sore throat. When the mucous membranes do not function
optimally, they cannot give your baby full protection from all kinds of germs. This increases the
chance of your baby catching a cold or the u, and reduces its resistance to infections from mold
and bacteria.
Note: The baby monitor only measures the humidity level. You cannot adjust the humidity level with the
baby monitor.
Out of range alert
When the parent unit is out of range of the baby unit, the parent unit beeps from time to time and
the message ‘Not linked’ appears on the display. The LINK light on the parent unit lights up red.
Note: The message ‘Not Linked’ also appears on the display of the parent unit when the baby unit is
switched off.
Menu options
The following functions are operated in the menu of the parent unit.
Menu operation - general explanation
Note: Menu functions can only be operated when a connection has been established between the baby
unit and the parent unit.
1 Press the MENU button to open the menu (Fig. 30).
The rst menu option appears on the display.
2 Use the – and + buttons to select the desired menu option (Fig. 31).
,
,
,
-
,
ENGLISH16
Note: The arrow indicates in which direction you can navigate.
3 Press the OK button to conrm (Fig. 32).
4 Use the + and - buttons to select the desired setting.
5 Press the OK button to conrm.
The new setting ashes twice and then disappears from the display.
6 Press the MENU button again to exit the menu.
Adjusting microphone sensitivity
Note: You can only adjust the microphone sensitivity in the menu of the parent unit.
You can set the microphone sensitivity of the baby unit to the desired level. You can only change the
microphone sensitivity when a connection between the baby unit and the parent unit has been
established, i.e. when the LINK light on the parent unit lights up green continuously.
1 Select ‘Sensitivity’ with the + and - buttons.
2 Press the OK button to conrm.
3 Select the desired microphone sensitivity level for the baby unit with the + and - buttons.
h = minimum sensitivity level
i = maximum sensitivity level
4 Press the OK button to conrm.
The message ‘Saved’ appears on the display.
Note: When the microphone sensitivity of the baby unit is set to a high level, it picks up more sounds and
therefore transmits more often. As a result, the units consume more power.
Sound alert on/off
Note: You can only switch the sound alert on and off in the menu of the parent unit.
This feature allows you to monitor your baby silently. It enables you to switch off the volume on
your parent unit and still be alerted if your baby cries.
If the sound alert is switched on, the parent unit beeps as soon as the fourth sound level light lights
up while the volume is switched off. In addition, the backlight of the parent unit display goes on and
the sound alert symbol ( g) ashes on the display.
1 Select ‘Sound Alert’ with the + and - buttons.
2 Press the OK button to conrm.
3 If the alert is off, the display shows ‘On?’. Press the OK button to switch on the alert. If the
alert is on, the display shows ‘Off?’. Press the OK button to switch off the alert.
If you have set the sound alert to ‘on’, the sound alert symbol ( g) appears on the display
of the parent unit.
Setting room temperature range
Note: You can only adjust the temperature range in the menu of the parent unit.
A baby will sleep comfortably in a room heated to a temperature between 61°F (16°C) and 68°F
(20°C). This is important, since a baby cannot regulate its body temperature as well as an adult. A
baby needs more time to adjust to temperature changes.
If you do not set a temperature range, the baby monitor alerts you when the temperature in your
baby’s room drops below 57°F (14°C) or rises above 86°F (30°C). In this case, the backlight of the
parent unit display goes on and ‘High’ or ‘Low’ appears on the display. To change the default
minimum and maximum temperature, follow the instructions below.
Note: The temperature of the baby’s room is shown on the display of both units when they are linked.
,
,
,
,
,
ENGLISH 17
1 Select ‘Temperature’ with the + and - buttons.
2 Press the OK button to conrm.
3 Select ‘Range’ with the + and - buttons.
4 Press the OK button to conrm.
5 Set the desired minimum temperature with the + and - buttons.
6 Press the OK button to conrm.
7 Set the desired maximum temperature with the + and - buttons.
8 Press the OK button to conrm.
The message ‘Saved’ appears on the display.
Note: If the temperature in the baby’s room drops below or exceeds the set temperature range, the
display is on continuously. This causes the unit to consume more power.
Temperature alert on/off
Note: You can only switch the temperature alert on and off in the menu of the parent unit.
Note: If the temperature alert is activated too often, reduce the set minimum temperature and/or
increase the set maximum temperature (see ‘Setting room temperature range’).
If the temperature alert is switched on, the parent unit beeps if the actual room temperature
exceeds the set maximum temperature or drops below the set minimum temperature. In addition,
the backlight of the parent unit display goes on, the temperature alert symbol ( t) ashes and ‘High’
or ‘Low’ appears on the display. If no minimum and maximum temperatures have been set, the
temperature alert is given when the room temperature drops below 57°F (14°C) or rises above
86°F (30°C).
1 Select ‘Temperature’ with the + and - buttons.
2 Press the OK button to conrm.
3 Select ‘Alert’ with the + and - buttons.
4 Press the OK button to conrm.
5 If the alert is off, the display shows ‘On?’. Press the OK button to switch on the alert. If the
alert is on, the display shows ‘Off?’. Press the OK button to switch off the alert.
Vibration alert on/off
Note: You can only switch the vibration alert on and off in the menu of the parent unit.
If the vibration alert is switched on, the parent unit vibrates as soon as the fourth sound level light
lights up while the volume is switched off.
1 Select ‘Vibration’ with the + and - buttons.
2 Press the OK button to conrm.
3 If the vibration alert is off, the display shows ‘On?’. Press the OK button to switch on the
vibration alert. If the vibration alert is on, the display shows ‘Off?’. Press the OK button to
switch off the vibration alert.
Setting display language
1 Select ‘Language’ with the + and - buttons.
2 Press the OK button to conrm.
3 Select the desired language with the + and - buttons.
,
ENGLISH18
4 Press the OK button to conrm.
Reset function
This function in the menu of the parent unit allows you to reset both the parent unit and the baby
unit to the default settings at the same time. You can use this function if problems occur that you
cannot solve by following the suggestions in chapter ‘Frequently asked questions’.
1 Select ‘Reset’ with the + and - buttons.
2 Press the OK button to conrm.
The message ‘Conrm?’ appears on the display of the parent unit.
3 Press the OK button to conrm.
The parent unit switches off and then switches on again.
The units have now both been reset to the default factory settings.
Default settings
Parent unit
Vibration alert: off
Language: English
Loudspeaker volume: 1
Microphone sensitivity: 3
Sound alert: off
Temperature alert: off
‘Temperature low’ alert: 57°F (14°C)
‘Temperature high’ alert: 86°F (30°C)
Baby unit
Loudspeaker volume: 3
Nightlight: off
Lullaby: 1
Accessories
Belt clip and neck strap
If the battery pack of the parent unit is sufciently charged, you can take the unit with you inside and
outside the house if you attach the unit to your belt or waistband with the belt clip or if you hang it
around your neck with the neck strap. This allows you to monitor your baby while you are moving
around.
Connecting the belt clip
1 Snap the belt clip onto the parent unit (Fig. 33).
Disconnecting the belt clip
1 Pull the belt clip off the parent unit.
Connecting the neck strap
1 Insert the end loop of the neck strap through the hole behind the strap post. Thread the
neck strap through the end loop and pull the neck strap tight (Fig. 34).
Disconnecting the neck strap
1 Pass the neck strip through the end loop and pull the end loop out of the hole behind the
strap post.
,
,
,
-
-
-
-
-
-
-
-
-
-
-
ENGLISH 19
Cleaning and maintenance
Do not immerse the parent unit or the baby unit in water and do not clean them under the tap.
Do not use cleaning spray or liquid cleaners.
1 Unplug the baby unit if it is connected to an electrical outlet and take the parent unit out of
the charger.
2 Clean the parent unit and the baby unit with a damp cloth.
Make sure the parent unit is dry before you put it back into the plugged-in charger.
3 Clean the charger with a dry cloth.
4 Clean the adapters with a dry cloth.
Note: This appliance has no other user-serviceable parts. For assistance call 1- 800-54-AVENT (1-800-
542-8368).
Storage
When you are not going to use the baby monitor for some time, remove the non-rechargeable
batteries from the baby unit and remove the rechargeable battery pack from the parent unit.
Store the parent unit, the baby unit, the charger of the parent unit and the adapters in the travel
pouch supplied.
Do not wrap cord around the monitor when storing. Store cord in a safe location where it will
not be cut or damaged.
Replacement
Baby unit
Batteries
Only replace the non-rechargeable batteries of the baby unit with four 1.5V R6 AA batteries.
Note: We recommend you to use Philips non-rechargeable batteries or an equivalent type.
Adapter
Only replace the adapter of the baby unit with an adapter of the original type. For assistance call 1-
800-54-AVENT (1-800-542-8368) or visit our website: www.philips.com/AVENT.
Parent unit
Battery pack
Only replace the SCD530 Li-Ion rechargeable battery pack of the parent unit with a pack of the
original type. For assistance call 1-800-54-AVENT (1-800-542-8368) or visit our website: www.
philips.com/AVENT.
Adapter
Only replace the adapter of the parent unit charger with an adapter of the original type. For
assistance call 1-800-54-AVENT (1-800-542-8368) or visit our website: www.philips.com/AVENT.
Assistance
For assistance call 1-800-54-AVENT (1-800-542-8368) or visit our website: www.philips.com/
AVENT.
Environment
Dispose of batteries properly. Do not incinerate. Batteries may explode if overheated. Do not
wrap in metal or aluminum foil. Wrap in newspaper before discarding (Fig. 35).
-
-
-
ENGLISH20
It is suggested that you contact your local town or city to determine proper battery redemption
site(s) in your area.
Warranty
FULL TWO YEAR WARRANTY
Philips Electronics North America Corporation (USA) and Philips Electronics Ltd (CANADA)
warrant each new Philips AVENT product, model SCD530/00, against defects in materials or
workmanship for a period of two years from the date of purchase, and agrees to repair or replace
any defective product without charge. IMPORTANT: This warranty does not cover damage resulting
from accident, misuse or abuse, lack of reasonable care, or the afxing of any attachment not
provided with the product. NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES. In order to obtain warranty service, simply call toll-free 1-800-
54-AVENT (1-800-542-8368).
Frequently asked questions
This chapter lists the questions most frequently asked about the appliance. If you cannot nd the
answer to your question, call 1-800-54-AVENT (1- 800-542-8368) for assistance.
Question Answer
Why don’t both the
power-on light of the
baby unit and the LINK
light of the parent unit
come on when I press
the on/off buttons of the
units?
Perhaps the rechargeable battery pack of the parent unit is empty and
the parent unit is not in the plugged-in charger. Insert the small
appliance plug into the charger, put the adapter of the charger in a
wall outlet and place the parent unit in the charger. Then press the on/
off button to establish connection with the baby unit.
Perhaps the non-rechargeable batteries of the baby unit are empty
and the baby unit is not connected to a power outlet. Replace the
non-rechargeable batteries or connect the baby unit to a power
outlet. Then press the on/off button to establish connection with the
parent unit.
The baby unit and the parent unit may be out of range of each other.
Move the parent unit closer to the baby unit, but not closer than 3
feet/1 meter.
If the LINK light on the parent unit still does not start to ash, use the
reset function to reset the units to their default settings.
Why does the LINK light
on the parent unit light
up red continuously and
why is the message
‘Not Linked’ shown on
the display?
The baby unit and the parent unit are out of range of each other.
Move the parent unit closer to the baby unit.
The baby unit may be switched off. Switch on the baby unit.
Why does the battery
symbol ash on the
display of the baby unit?
The non-rechargeable batteries of the baby unit are running low.
Replace the non-rechargeable batteries or connect the baby unit to a
power outlet (see chapter ‘Preparing for use’).
-
ENGLISH 21
Question Answer
Why does the parent
unit beep?
If the parent unit beeps while the LINK light lights up red continuously
and the message ‘Not Linked’ is shown on the display, the connection
with the baby unit is lost. Move the parent unit closer to the baby unit.
If the parent unit beeps and the battery symbol on the display is
empty, the rechargeable battery pack of the parent unit is running low.
Recharge the rechargeable battery pack.
If you have switched off the volume while the sound alert is on, the
parent unit beeps whenever the fourth sound level light lights
up because the baby unit has picked up a sound.
If you have set the room temperature range on the parent unit and
the temperature alert is on, the parent unit beeps when the
temperature drops below the set level or below 57°F (14°C) or
when the temperature rises above the set level or above 86°F (30°C).
The baby unit may be switched off. Switch on the baby unit.
Why does the appliance
produce a high-pitched
noise?
The units may be too close to each other. Make sure the parent unit
and the baby unit are at least 3 feet/1 meter away from each other.
The volume of the parent unit may be set too high. Decrease the
volume of the parent unit.
Why don’t I hear a
sound/Why can’t I hear
my baby cry?
The volume of the parent unit may be set too low or may be
switched off. Increase the volume of the parent unit.
The microphone sensitivity level of the baby unit may be set too low.
Set the microphone sensitivity level to a higher level in the menu of
the parent unit.
The baby unit and the parent unit may be out of range of each other.
Reduce the distance between the units.
Why does the parent
unit react too quickly to
other sounds?
The baby unit also picks up other sounds than those of your
baby. Move the baby unit closer to the baby (but observe the
minimum distance of 3 feet/1 meter).
The microphone sensitivity level of the baby unit may be set too high.
Decrease the microphone sensitivity level in the menu of the parent
unit.
Why does the parent
unit react slowly to the
baby’s crying?
The microphone sensitivity level of the baby unit may be set too low.
Increase the microphone sensitivity level of in the menu of the parent
unit.
Why do the non-
rechargeable batteries of
the baby unit run low
quickly?
The microphone sensitivity level of the baby unit may be set too high,
which causes the baby unit to transmit more often. Decrease the
microphone sensitivity level in the menu of the parent unit.
The volume on the baby unit may be set too high, which causes the
baby unit to consume a lot of energy. Decrease the volume of the
baby unit.
ENGLISH22
Question Answer
You may have set a maximum room temperature that is lower than
the actual room temperature or a minimum room temperature that is
higher than the actual room temperature. In this case the display is lit
all the time, which increases the power consumption of the baby unit.
This causes the non-rechargeable batteries of the baby unit to run
low quickly.
Perhaps you have switched on the nightlight. If you want to use the
nightlight, we advise you to run the baby unit on outlet electricity.
Why does the charging
time of the parent unit
exceed 4 hours?
The parent unit may be switched on during charging. Switch off the
parent unit during charging.
The specied operating
range of the baby
monitor is 1000 feet/330
meters. Why does my
baby monitor manage a
much smaller distance
than that?
The specied range is only valid outdoors in open air. Inside your
house, the operating range is limited by the number and type of walls
and/or ceilings in between. Inside the house, the operating range is up
to 150 feet/50 meters.
Why is the
connection lost every
now and then? Why are
there sound
interruptions?
The baby unit and the parent unit are probably close to the outer
limits of the operating range. Try a different location or decrease the
distance between the units. Please note that it takes about 30 seconds
each time before a connection between the units is established.
What happens during a
power failure?
If the parent unit is sufciently charged, it continues to operate during
a power failure, both inside and outside the charger. If there are
batteries in the baby unit, it also continues to operate during a power
failure.
Is my baby monitor
secure from
eavesdropping and
interference?
The DECT technology of this baby monitor guarantees no
interference from other equipment and no eavesdropping.
The operating time of
the parent unit is
supposed to be at
least 24 hours. Why is
the operating time of my
parent unit shorter?
When the rechargeable battery pack of the parent unit has been
charged for the rst time, the operating time is less than 24 hours. The
rechargeable battery pack only reaches its full capacity after you have
charged and discharged it at least four times.
The volume of the parent unit may be set too high, which causes the
parent unit to consume a lot of energy. Decrease the volume of the
parent unit
The microphone sensitivity level of the baby unit may be set too high,
which causes the parent unit to consume a lot of energy. Decrease
the microphone sensitivity level in the menu of the parent unit.
ENGLISH 23
25
Question Answer
Why doesn’t the battery
symbol appear on the
display of the parent unit
when I start to recharge
the parent unit?
It may take a few minutes before the battery symbol appears on the
display of the parent unit when you charge the parent for the rst
time or after a long period of disuse.
ENGLISH24
26
