Starsense NEMA INtellivolt OLC (no dim)

Installation Instructions (LLC7310/LLC7315)

IP>=43

Do not

remove

barcode

from

Starsense

LOAD

BLK

WHT

RED

Photocontrol base *

* Photocontrol base is not supplied with Starsense

Light Sensor must

point NORTH

Wiring/Installtion Diagram

Attach a copy of barcode

to luminaire interior

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) This device must

accept any interference received, including interference that may cause undesired operation.

Any changes or modiﬁcations not expressly approved by Philips could void the user’s authority

to operate the equipment. This product is intended for commercial use only.

Form No. PA-7480-A 7/12
