SimplyGo,

ready for a stroll

Quick start guide

Hello, my name is

I am suffering from COPD.1

My physician has prescribed for me

long-term oxygen therapy that requires

the regular use of high concentrations

of oxygen. My SimplyGo portable oxygen

concentrator provides me with this

reliable supply of oxygen. It is important for me to

use oxygen therapy2during both my daily activities

and at night. My SimplyGo stays with me wherever

I go and helps me get the exercise I need.

I can walk, stand, move about, and basically enjoy

my day while I receive my daily oxygen therapy.

It can improve the quality of my life.

Why SimplyGo?

1COPD (Chronic Obstructive Pulmonary Disease) refers to a group of lung diseases, such as emphysema

and chronic bronchitis, that obstruct air from easily entering and exiting the lungs, thus preventing the

proper elimination of carbon dioxide.

2Portable oxygen therapy: use and benefit in hypoxaemic COPD patients on long-term oxygen therapy –

J. Vergeret, C. Brambilla, L. Mounier – ERJ 1989

SimplyGo - Getting started

On/off button

Alarm silence

Mode selection

Increase/decrease the flow rate

Cannula connector

Select the mode you’ve been prescribed

Pulse mode SimplyGo detects each breath intake and delivers the oxygen

delivery accordingly.

Continuous-flow mode Continuous oxygen delivery from 0.5 to 2 LPM.

Sleep mode Pulse mode with an increased detection sensitivity to sense

breath intake more accurately at night. SimplyGo automatically switches to the

last continuous flow setting used if no breath is detected after a period of time.

Charge the battery

or use the charger.

Insert SimplyGo into its

carrying case.

Insert the charged

battery.

Connect a standard

single lumen nasal

cannula. Make sure it is not

pinched or kinked.

Maximum length up to 9 m (30 ft).

Turn on/off SimplyGo

by pressing the power

button twice.

Select the mode by

pressing the mode (M)

button. Continue pressing

the Mode button to scroll

through the Pulse, Continuous

flow, or Sleep modes.

Set the flow rate in

accordance with your

oxygen prescription using the

plus (+) or minus (-) buttons.

Make sure you have all

the accessories you

need. Install SimplyGo on

the cart.

Position the nasal

cannula on your face

and breathe normally through

the nose.

1

4

78

9

56

2 3

Operating SimplyGo

Simply before you go

Inform your physician about your trip; your prescription may need to be

adapted depending on the climate or altitude of your destination.

When booking your trip, inform the transportation company that you

intend to use your SimplyGo during the journey.

Learn about the carrier’s specific policy or requirements regarding

oxygen therapy patients.

Make sure you have all the SimplyGo accessories you need.

Contact your homecare provider if necessary.

Make sure you carry a copy of your oxygen therapy prescription with

you at all times. Make sure you have the name and contact information

of your homecare provider. Copy these onto your SimplyGo Quick

start guide.

Verify that your SimplyGo batteries are fully charged and that you have

your oxygen cannula with you.

Verify that you have the necessary power supplies to recharge

SimplyGo batteries.

Keep your SimplyGo Quick start guide and your SimplyGo user manual

together with your device at all times.

SimplyGo is your ideal travel companion. Discover some useful tips

when traveling with a portable oxygen concentrator.

At departure

Ready. Set. SimplyGo!

SimplyGo on the plane

SimplyGo battery specification

The United States Federal Aviation Administration (FAA) has approved the

SimplyGo for in-flight use on commercial airliners.

Although the FAA and other international aviation regulatory bodies allow the

use of approved portable oxygen concentrators on commercial airlines, many

domestic and international carriers have additional requirements including

advance notification, and possession of a physician’s letter and oxygen

prescription.

If you are planning to fly with your SimplyGo, contact your airline well in

advance of travel.

Battery autonomy

Pulse mode setting 2* 3 hr

Continuous flow 2 LPM 54 min

*Based on 20 breaths per minute

Charge time: 2-3 hours per battery when fully discharged

Company

Address

Tel

My contact name

Mobile phone

e-mail

Patient

Physician

Phone

e-mail

My prescription

My prescription

My provider

Please visit www.philips.com/ReadySetSimplyGo

Philips Healthcare is part

of Royal Philips

How to reach us

www.philips.com/healthcare

healthcare@philips.com

Asia

+49 7031 463 2254

Europe, Middle East, Africa

+49 7031 463 2254

Latin America

+55 11 2125 0744

North America

+1 425 487 7000

800 285 5585 (toll free, US only)

Philips Respironics

1010 Murry Ridge Lane

Murrysville, PA 15668

Customer Service

+1 724 387 4000

800 345 6443 (toll free, US only)

Philips Respironics International Headquarters

+33 1 47 28 30 82

Philips Respironics Asia Pacific

+65 6882 5282

Philips Respironics Australia

+61 (2) 9947 0440

1300 766 488 (toll free, Australia only)

www.philips.com/respironics
