Confidence
in your patient’s comfort
Philips Respironics patient interfaces and circuits for noninvasive ventilation
The print quality of this copy is not an accurate representation of the original.
Philips Respironics masks are designed
to support enhanced NIV. From comfort
for your patients to ease of use for you,
our interfaces are specially designed to
meet the rigors of acute care environments.
Delivering exceptional NIV
2
The print quality of this copy is not an accurate representation of the original.
3
Total face masks 4
Oro-nasal masks 8
Nasal masks 16
Packs and accessories 20
Circuits and connections 28
Trilogy accessories 30
Table of contents
The print quality of this copy is not an accurate representation of the original.
4
Total face masks
Total face masks allow
quick fitting and eliminate
nasal bridge challenges
by sealing around the
perimeter of the face,
where patients have less
pressure sensitivity and
smoother facial contours.
Mask selection criteria
• Rapid application
• Mouth breather
• Facial abnormalities
• Lack of teeth
The print quality of this copy is not an accurate representation of the original.
5
Philips Respironics Total multi-use
Description Quantity Product number Part number
Total face mask 1 302433 989805609231
Total face mask head strap 1 1003052 453561517111
Total face mask head strap 9 1010609 989805610031
Key benefits
• Clear, unobstructed view
• Perimeter facial contact increases comfort
and simplifies fitting
• Digital Auto-Trak compatibility enhances
NIV performance
Philips Respironics Total
For headgear, see page 25
Total
The print quality of this copy is not an accurate representation of the original.
6
Philips Respironics PerforMax single-use
Description Quantity Product number Part number
PerforMax with EE leak 2 elbow, small*†11061619 989805627831
PerforMax with EE leak 2 elbow, large†11061620 989805627841
PerforMax with EE leak 2 elbow, extra large†11080426 989805634831
PerforMax with EE leak 2 elbow, small*†10 1052535 989805611281
PerforMax with EE leak 2 elbow, large†10 1052536 989805611291
PerforMax with EE leak 2 elbow, extra large†51080424 989805634811
PerforMax with SE standard elbow, small*†11061621 989805627851
PerforMax with SE standard elbow, large†11061622 989805627861
PerforMax with SE standard elbow, extra large†11080517 989805634841
PerforMax with SE standard elbow, small*†10 1052547 989805611301
PerforMax with SE standard elbow, large†10 1052548 989805611311
PerforMax with SE standard elbow, extra large†51080425 989805634821
Key benefits
• Available for patients 7 years or older
and > 20 kg (40 lb)
• Perimeter facial contact increases comfort
and simplifies fitting
• Clear, unobstructed view
Philips Respironics PerforMax single-use
Compatible with a leak 2 entrainment elbow (EE),
standard elbow (SE), and bronchoscopy elbow (BE)
For accessories, see page 24
For headgear, see page 25
PerforMax EE leak 2
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
† Not available in all markets, please contact your Philips sales consultant.
The print quality of this copy is not an accurate representation of the original.
7
Philips Respironics PerforMax multi-use
Description Quantity Product number Part number
PerforMax with EE leak 2 and SE elbow, small* 1 mask/4 headgear 1052553 989805611361
PerforMax with EE leak 2 and SE elbow, large 1 mask/4 headgear 1052554 989805611371
PerforMax with EE leak 2 and SE elbow, extra large 1 mask/4 headgear 1080420 989805634771
PerforMax with EE leak 2, small* 1 mask/4 headgear 1052555 989805611381
PerforMax with EE leak 2, large 1 mask/4 headgear 1052556 989805611391
PerforMax with EE leak 2, extra large 1 mask/4 headgear 1080421 989805634781
PerforMax with SE standard elbow, small* 1 mask/4 headgear 1052568 989805611401
PerforMax with SE standard elbow, large 1 mask/4 headgear 1052569 989805611411
PerforMax with SE standard elbow, extra large 1 mask/4 headgear 1080422 989805634791
PerforMax with EE leak 2 and SE elbow, small* 1 mask/1 headgear 1044385 989805611091
PerforMax with EE leak 2 and SE elbow, large 1 mask/1 headgear 1044386 989805611101
PerforMax with EE leak 2 and SE elbow, extra large 1 mask/1 headgear 1080423 989805634801
Key benefits
• Available for patients 7 years or older
and > 20 kg (40 lb)
• Perimeter facial contact supports comfort
and simplifies fitting
• Clear, unobstructed view
Philips Respironics PerforMax multi-use
Compatible with a leak 2 entrainment elbow (EE),
standard elbow (SE), and bronchoscopy elbow (BE)
For accessories, see page 24
For headgear, see page 25
PerforMax SE
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
The print quality of this copy is not an accurate representation of the original.
8
Oro-nasal masks
Oro-nasal masks are the standard
of care for hospital NIV, and the
Philips Respironics family includes
a comprehensive selection of
systems with features that address
patient comfort, mask fitting,
and ventilator compatibility.
Mask selection criteria
• Mouth breather
• Long-term NIV
• Two cushion styles
for mask rotation
Patient comfort
made easy
CapStrap headgear provides
excellent stability and simplifies
initial setup by keeping the mask
in place while you adjust the
patient’s straps. When you need
to interrupt treatment for oral care
and medications, the CapStrap
headgear allows quick removal
and simple reapplication. CapStrap
headgear is available on several
Philips Respironics masks:
• AF541
• AF531
• AF811
• PerformaTrak
The print quality of this copy is not an accurate representation of the original.
9
Philips Respironics AF541
Description Quantity Product number Part number
AF541 with EE leak 1 elbow, CapStrap headgear, small* 10 1120925 989805653931
AF541 with EE leak 1 elbow, CapStrap headgear, medium* 10 1120926 989805653941
AF541 with EE leak 1 elbow, CapStrap headgear, large 10 1120927 989805653951
AF541 with EE leak 1 elbow, CapStrap headgear, extra large 10 1120928 989805653961
AF541 with EE leak 2 elbow, CapStrap headgear, small* 10 1120935 989805654011
AF541 with EE leak 2 elbow, CapStrap headgear, medium* 10 1120936 989805654021
AF541 with EE leak 2 elbow, CapStrap headgear, large 10 1120937 989805654031
AF541 with EE leak 2 elbow, CapStrap headgear, extra large 10 1120938 989805654041
AF541 with SE standard elbow, CapStrap headgear, small* 10 1120945 989805654091
AF541 with SE standard elbow, CapStrap headgear, medium* 10 1120946 989805654101
AF541 with SE standard elbow, CapStrap headgear, large 10 1120947 989805654111
AF541 with SE standard elbow, CapStrap headgear, extra large 10 1120948 989805654121
AF541 with EE leak 1 elbow, four-point headgear, small* 10 1120920 989805653891
AF541 with EE leak 1 elbow, four-point headgear, medium* 10 1120921 989805653901
AF541 with EE leak 1 elbow, four-point headgear, large 10 1120922 989805653911
AF541 with EE leak 1 elbow, four-point headgear, extra large 10 1120923 989805653921
AF541 with EE leak 2 elbow, four-point headgear, small* 10 1120930 989805653971
AF541 with EE leak 2 elbow, four-point headgear, medium* 10 1120931 989805653981
AF541 with EE leak 2 elbow, four-point headgear, large 10 1120932 989805653991
AF541 with EE leak 2 elbow, four-point headgear, extra large 10 1120933 989805654001
AF541 with SE standard elbow, four-point headgear, small* 10 1120940 989805654051
AF541 with SE standard elbow, four-point headgear, medium* 10 1120941 989805654061
AF541 with SE standard elbow, four-point headgear, large 10 1120942 989805654071
AF541 with SE standard elbow, four-point headgear, extra large 10 1120943 989805654081
AF541 size A under-the-nose cushion 10 1120980 989805654271
AF541 size B under-the-nose cushion 10 1120981 989805654281
AF541 size C under-the nose cushion 10 1120982 989805654291
Bronchoscopy elbow 51120984 989805654301
AF541 discharge kit, CapStrap headgear, small/medium 5 1120986 989805654311
AF541 discharge kit, CapStrap headgear, large/extra large 5 1120988 989805654331
AF541 discharge kit, four-point headgear, small/medium 51120987 989805654321
AF541 discharge kit, four-point headgear, large/extra large 51120989 989805654341
Philips Respironics AF541
AF541 with four-point headgear, EE leak 1
Key benefits
• The under-the-nose cushion can be used
to off load mask pressure at bridge of nose
• Push-button forehead pad adjustment,
easy-to-use CapStrap headgear,
and snap-in-place elbows and talon
clips contribute to efficient workflow
• Discharge kit configures mask to work
with home NIV systems
• CleanClip system supports your infection
control efforts
• Discharge kit for patient transition
to lower acuity setting
For accessories, see page 24
For headgear, see page 25
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
The print quality of this copy is not an accurate representation of the original.
10
Philips Respironics AF531 with CapStrap single-use
Description Quantity Product number Part number
AF531 with EE leak 1 elbow, CapStrap headgear, small* 1 1061727 989805628611
AF531 with EE leak 1 elbow, CapStrap headgear, medium 1 1061728 989805628621
AF531 with EE leak 1 elbow, CapStrap headgear, large 1 1061729 989805628631
AF531 with EE leak 1 elbow, CapStrap headgear, small* 10 1072627 989805628731
AF531 with EE leak 1 elbow, CapStrap headgear, medium 10 1072628 989805628741
AF531 with EE leak 1 elbow, CapStrap headgear, large 10 1072629 989805628751
AF531 with SE standard elbow, CapStrap headgear, small* 1 1061730 989805628641
AF531 with SE standard elbow, CapStrap headgear, medium 1 1061731 989805628651
AF531 with SE standard elbow, CapStrap headgear, large 1 1061732 989805628661
AF531 with SE standard elbow, CapStrap headgear, small* 10 1072630 989805628761
AF531 with SE standard elbow, CapStrap headgear, medium 10 1072631 989805628771
AF531 with SE standard elbow, CapStrap headgear, large 10 1072632 989805628781
AF531 with EE leak 1/NE nebulizer elbow, CapStrap headgear, small* 10 1072636 989805635001
AF531 with EE leak 1/NE nebulizer elbow, CapStrap headgear, medium 10 1072637 989805635011
AF531 with EE leak 1/NE nebulizer elbow, CapStrap headgear, large 10 1072638 989805635021
Key benefits
• CapStrap headgear provides an excellent
fit and simple reapplication
• Supports your infection control efforts
with the CleanClip system
• You can adapt one mask to multiple
ventilators with interchangeable elbows
Philips Respironics AF531
Compatible with a leak 1 or leak 2 entrainment elbow (EE),
EE NIVO elbow (EE/NE), standard elbow (SE), SE NIVO elbow (SE/NE),
and bronchoscopy elbow (BE)
For accessories, see page 24
For headgear, see page 25
AF531 with CapStrap
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
AF531 EE leak 1 elbow
The print quality of this copy is not an accurate representation of the original.
11
Philips Respironics AF531 with four-point headgear single-use
Description Quantity Product number Part number
AF531 with EE leak 1 elbow, four-point headgear, small** 1 1061718 989805628521
AF531 with EE leak 1 elbow, four-point headgear, medium 1 1061719 989805628531
AF531 with EE leak 1 elbow, four-point headgear, large 1 1061720 989805628541
AF531 with EE leak 1 elbow, four-point headgear, small** 10 1072621 989805628671
AF531 with EE leak 1 elbow, four-point headgear, medium 10 1072622 989805628681
AF531 with EE leak 1 elbow, four-point headgear, large 10 1072623 989805628691
AF531 with SE standard elbow, four-point headgear, small** 1 1061721 989805628551
AF531 with SE standard elbow, four-point headgear, medium 1 1061722 989805628561
AF531 with SE standard elbow, four-point headgear, large 1 1061723 989805628571
AF531 with SE standard elbow, four-point headgear, small** 10 1072624 989805628701
AF531 with SE standard elbow, four-point headgear, medium 10 1072625 989805628711
AF531 with SE standard elbow, four-point headgear, large 10 1072626 989805628721
AF531 with EE leak 1 nebulizer elbow, four-point headgear, small** 10 1061633 989805634971
AF531 with EE leak 1 nebulizer elbow, four-point headgear, medium 10 1061634 989805634981
AF531 with EE leak 1 nebulizer elbow, four-point headgear, large 10 1061635 989805634991
Philips Respironics AF531
AF531 with four-point headgear, EE leak 1
* Bronchoscopy elbow sold separately, see page 24
** Intended for use by patients 7 years or older and > 20 kg (40 lb)
AF531 Bronchoscopy elbow* AF531 SE standard elbow
Key benefits
• Supports your infection control efforts
with the CleanClip system
• You can adapt one mask to multiple
ventilators with interchangeable elbows
For accessories, see page 24
For headgear, see page 25
The print quality of this copy is not an accurate representation of the original.
12
Philips Respironics AF531 with leak 2 elbow single-use
Description Quantity Product number Part number
AF531 with EE leak 2 elbow, four-point headgear, small* 1 1061724 989805628581
AF531 with EE leak 2 elbow, four-point headgear, medium 1 1061725 989805628591
AF531 with EE leak 2 elbow, four-point headgear, large 1 1061726 989805628601
AF531 with EE leak 2 elbow, four-point headgear, small* 10 1100393 989805645651
AF531 with EE leak 2 elbow, four-point headgear, medium 10 1100394 989805645661
AF531 with EE leak 2 elbow, four-point headgear, large 10 1100395 989805645671
AF531 with EE leak 2 elbow, CapStrap headgear, small* 10 1100390 989805645621
AF531 with EE leak 2 elbow, CapStrap headgear, medium 10 1100391 989805645631
AF531 with EE leak 2 elbow, CapStrap headgear, large 10 1100392 989805645641
Philips Respironics AF531 with leak 2 elbow
AF531 EE leak 2
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
Key benefits
• Leak built into the mask
• Can be used without an additional
exhalation port
• Available with four point headgear
and CapStrap headgear
• Convenient ten-packs
For accessories, see page 24
For headgear, see page 25
The print quality of this copy is not an accurate representation of the original.
13
Philips Respironics AF811 single-use
Description Quantity Product number Part number
AF811 oro-nasal mask EE, CapStrap headgear, small 1 1063047 989805626321
AF811 oro-nasal mask EE, CapStrap headgear, medium 1 1063016 989805626311
AF811 oro-nasal mask EE, CapStrap headgear, large 1 1063015 989805626301
AF811 oro-nasal mask EE, CapStrap headgear, small 5 1063053 989805626381
AF811 oro-nasal mask EE, CapStrap headgear, medium 5 1063052 989805626371
AF811 oro-nasal mask EE, CapStrap headgear, large 5 1063051 989805626361
AF811 oro-nasal mask SE, CapStrap headgear, small 1 1063050 989805626351
AF811 oro-nasal mask SE, CapStrap headgear, medium 1 1063049 989805626341
AF811 oro-nasal mask SE, CapStrap headgear, large 1 1063048 989805626331
AF811 oro-nasal mask SE, CapStrap headgear, small 5 1063056 989805626411
AF811 oro-nasal mask SE, CapStrap headgear, medium 5 1063055 989805626401
AF811 oro-nasal mask SE, CapStrap headgear, large 5 1063054 989805626391
Philips Respironics AF811
AF811 EE
Key benefits
• Cushion uses a gel pad with a silicone flap
for increased comfort
• CapStrap headgear system simplifies mask application
and routine patient care
• Available in three sizes to fit a wide patient population
Entrainment elbow (EE)
Also available with standard elbow (SE)
For headgear, see page 25
The print quality of this copy is not an accurate representation of the original.
14
Philips Respironics PerformaTrak single-use
Description Quantity Product number Part number
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, small 11012573 989805610111
PerformaTrak oro-nasal mask EE leak 1, four-point headgear,
medium
11012574 989805610121
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, large 11012635 989805610151
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, small 10 1018589 989805610481
PerformaTrak oro-nasal mask EE leak 1, four-point headgear,
medium
10 1018590 989805610491
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, large 10 1018591 989805610501
PerformaTrak oro-nasal mask SE, four-point headgear, small 11012639 989805610191
PerformaTrak oro-nasal mask SE, four-point headgear, medium 11012640 989805610201
PerformaTrak oro-nasal mask SE, four-point headgear, large 11012641 989805610211
PerformaTrak oro-nasal mask SE, four-point headgear, small 10 1018605 989805610581
PerformaTrak oro-nasal mask SE, four-point headgear, medium 10 1018606 989805610591
PerformaTrak oro-nasal mask SE, four-point headgear, large 10 1018595 989805610541
PerformaTrak oro-nasal mask with CapStrap EE, small 10 1019492 989805610691
PerformaTrak oro-nasal mask with CapStrap EE, medium 10 1019498 989805610701
PerformaTrak oro-nasal mask with CapStrap EE, large 10 1019507 989805610711
PerformaTrak oro-nasal mask with CapStrap SE, small 10 1019540 989805610811
PerformaTrak oro-nasal mask with CapStrap SE, medium 10 1019541 989805610821
PerformaTrak oro-nasal mask with CapStrap SE, large 10 1019542 989805610831
Philips Respironics PerformaTrak multi-use
Description Quantity Product number Part number
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, small 11022980 989805610871
PerformaTrak oro-nasal mask EE leak 1, four-point headgear,
medium
11023022 989805610881
PerformaTrak oro-nasal mask EE leak 1, four-point headgear, large 11023023 989805610891
PerformaTrak SE oro-nasal mask, four-point-headgear, small 11023025 989805610901
PerformaTrak SE oro-nasal mask, four-point-headgear, medium 11023026 989805610911
PerformaTrak SE oro-nasal mask, four-point-headgear, large 11023027 989805610921
PerformaTrak four-point headgear assembly with forehead pad 51022453 989805610861
Philips Respironics
PerformaTrak
Per formaTrak
Key benefits
• Dual-density foam forehead pads provide patient
comfort and mask stability
• With only three sizes, clinicians can quickly fit
a wide range of patients
• Swivel clips simplify reapplication by reducing
the need to refit after removal
Entrainment elbow (EE)
Also available with standard elbow (SE)
For headgear, see page 25
The print quality of this copy is not an accurate representation of the original.
15
Philips Respironics AF421
Description Quantity Product number Part number
AF421 with EE leak 1 elbow, small* 10 pack 1106170 989805648331
AF421 with EE leak 1 elbow, medium 10 pack 1106171 989805648341
AF421 with EE leak 1 elbow, large 10 pack 1106172 989805648351
AF421 with EE leak 1 elbow, extra large 10 pack 1106173 989805648361
AF421 with SE standard elbow, small* 10 pack 1106174 989805648371
AF421 with SE standard elbow, medium 10 pack 1106175 989805648381
AF421 with SE standard elbow, large 10 pack 1106176 989805648391
AF421 with SE standard elbow, extra large 10 pack 1106177 989805648401
AF421 with EE leak 2 elbow, small* 10 pack 1106178 989805648411
AF421 with EE leak 2 elbow, medium 10 pack 1106179 989805648421
AF421 with EE leak 2 elbow, large 10 pack 1106180 989805648431
AF421 with EE leak 2 elbow, extra large 10 pack 1106181 989805648441
Accessory, AF421 forehead pad (3/4 in, 19.1 mm) 10 pack 1118318 989805652341
RP, S/M AF421 headgear with clips 5 pack 1109915 989805648851
RP, L/XL AF421 headgear with clips 5 pack 1109916 989805648861
RP, AF421 sizing gauge 25 pack 1109917 989805648871
Philips Respironics AF421
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
Key benefits
• Supports your infection control efforts with CleanClip
• Oral access feature for oral care
• Leak symbols for ease of ventilator setup
• Available with EE leak 1, SE standard elbow,
and EE leak 2 elbow for wide ventilator application
• Available in four sizes to fit a wide patient population
AF421 with four-point headgear, SE AF421 EE leak 1 AF421 EE leak 2
The print quality of this copy is not an accurate representation of the original.
16
Nasal masks
When chronically ill patients enter
the hospital in respiratory distress,
they typically want an NIV interface
as comfortable as what they use
at home. They want an unobtrusive
system to maintain quality of
life during their hospital stay.
Mask selection criteria
• Oral access
• Long-term NIV
The print quality of this copy is not an accurate representation of the original.
1717
Philips Respironics PerformaTrak
Description Quantity Product number Part number
PerformaTrak single-use nasal mask, CapStrap headgear, petite 10 1048709 989805611181
PerformaTrak single-use nasal mask, CapStrap headgear, small 10 1048708 989805611171
PerformaTrak single-use nasal mask, CapStrap headgear, medium/large 10 1048710 989805611191
Key benefits
• CapStrap headgear provides an excellent
fit and simple reapplication
• With only three sizes, clinicians can quickly
fit a wide range of patients
• Hook-n-loop grab tabs allow quick, easy
removal and adjustment of headgear
Philips Respironics PerformaTrak
For headgear, see page 25
PerformaTrak with CapStrap
The print quality of this copy is not an accurate representation of the original.
18
Philips Respironics Contour Deluxe single-use
Description Quantity Product number Part number
Contour Deluxe nasal mask, four-point headgear, petite 5 1016980 989805610311
Contour Deluxe nasal mask, four-point headgear, small 5 1016697 989805610291
Contour Deluxe nasal mask, four-point headgear, medium/large 5 1016695 989805610271
Contour Deluxe nasal mask, four-point headgear, small 10 1016698 989805610301
Contour Deluxe nasal mask, four-point headgear, medium/large 10 1016696 989805610281
Key benefits
• Dual-density foam forehead pads provide
patient comfort and mask stability
• With only three sizes, clinicians can quickly
fit a wide range of patients
• Hook-n-loop grab tabs allow quick,
easy removal and adjustment of headgear
Philips Respironics Contour Deluxe
For headgear, see page 25
Contour Deluxe
The print quality of this copy is not an accurate representation of the original.
19
Key benefits
• Easy sizing and fitting
• Complete kit for quick setup
• Clear field of vision
• Cradle style nasal cushion
Philips Respironics AP111
For headgear, see page 25
AP111
Philips Respironics AP111 single-use
Description Quantity Product number Part number
AP111 interface with cradles* leak 3 1 1062128 989805626481
AP111 interface with cradles* leak 3, circuit, and main flow filter 1 1062130 989805626491
AP111 interface with cradles* leak 3, circuit, and main flow filter 5 1062132 989805626501
* Each Philips Respironics AP111 interface includes all four cushion sizes
Small Medium Large Large/Narrow
The print quality of this copy is not an accurate representation of the original.
Procedure packs
and accessories
Get everything you need in one bundle
with our procedure packs, designed to
simplify the ordering process and help
you work more efficiently.
These accessories help you customize
your care to suit each individual patient,
large or small.
20
The print quality of this copy is not an accurate representation of the original.
21
Procedure packs
Description Quantity Product number Part number
AF531 mask with EE leak 1 nebulizer elbow (no nebulizer),
CapStrap headgear, and FEP circuit with main flow filter (#1)
Small* 51072642 989805634651
Medium 51072643 989805634661
Large 51072644 989805634671
AF531 mask with EE leak 1 entrainment elbow, four-point
headgear, and FEP circuit with main flow filter†
Small* 51072639 989805626511
Medium 51072640 989805628811
Large 51072641 989805628821
AF811 gel mask with EE leak 1 entrainment elbow, CapStrap
headgear, and FEP circuit with main flow filter and exhalation filter†
Small 51074839 989805633171
Medium 51074838 989805633161
Large 51074837 989805633151
AF811 gel mask with EE leak 1 entrainment elbow, CapStrap
headgear, and FEP circuit with main flow filter†
Small 51074061 989805633201
Medium 51074060 989805633191
Large 51074059 989805633181
PerformaTrak mask with EE leak 1 entrainment elbow,
four-point headgear, and FEP circuit with main flow filter†
Small 51074055 989805633111
Medium 51074054 989805633101
Large 51074053 989805633091
PerformaTrak mask with EE leak 1 entrainment elbow,
CapStrap headgear, and FEP circuit with main flow filter†
Small 51074058 989805633141
Medium 51074057 989805633131
Large 51074056 989805633121
* Intended for use by patients 7 years or older and > 20 kg (40 lb)
† Not illustrated
Note: FEP – Filter Exhalation Port
1
The print quality of this copy is not an accurate representation of the original.
22
Procedure packs (continued)
Description Quantity Product number Part number
PerformaTrak mask, NIV circuit (9624C) with main flow
filter, O2 enrichment port†
Small 10 1004228 989805618031
Medium 10 1004229 989805618041
Large 10 1004253 989805618051
PerformaTrak mask, heated single limb circuit with main
flow filter, auto-feed humidification chamber†
Small 10 1004198 989805618001
Medium 10 1004199 989805618011
Large 10 1004227 989805618021
Starter packs
Description Quantity Product number Part number
Philips EE starter kit, oro-nasal and full face, multi-use †1074044 989805626551
PerformaTrak EE, small/medium/large mask 3
PerformaTrak with CapStrap headgear, EE, small/medium/
large mask
3
AF811 with CapStrap headgear, EE, small/medium/large mask 3
PerforMax multi-use, EE/SE, four-point headgear, small/large 2
NIV circuit with DEP filter and main flow filter 10
Philips basic start kit, oro-nasal (1 mask) †1074050 989805626611
PerformaTrak SE, small/medium/large mask 3
† Not illustrated
The print quality of this copy is not an accurate representation of the original.
23
Aerogen Pro-X controllers
and systems
NIVO Pro-X controller kits*
Description Quantity Product number Part number
NIVO Pro-X controller kit – Eng EU
(English, EU plug)
11079421 989805634331
NIVO Pro-X controller kit – Northern EU
(German, French, Dutch, Italian)
11082693 989805634471
NIVO Pro-X controller kit – Southern EU
(Spanish, Italian, Portuguese, Greek)
11082694 989805634481
NIVO Pro-X controller kit – Scand EU
(Norwegian, Swedish, Danish)
11082695 989805634491
NIVO Pro-X controller kit – UK/IE (English) 11079422 989805634341
NIVO Pro-X controller kit – AU/NZ
(English)
11079423 989805634351
NIVO Pro-X controller kit – English/INTL
(English)
11079424 989805634361
NIVO Pro-X controller kit – INTL
(Spanish, Italian, Portuguese, Greek)
11082696 989805634501
NIVO controller and
system components
* Pro-X nebulizer kit includes #1, 2, 3, and 5 shown above
** NE elbow can be added to an existing AF531 or mask can be purchased with NE elbow installed.
1AC/DC adapter Power source or charge controller
2Pro-X control module Can use AC/DC adapter or internal battery
(up to 45 minutes)
3Equipment mount Use for pole or humidifier slot mounting configuration
4AF531 mask** Mask to be used
5Control module cable Connect controller to NIVO nebulizer
6Nebulizer elbows (NE) Entrainment elbow (EE) or standard elbow (SE)
with nebulizer port
7NIVO nebulizer Aerosol generator
1
2
3
4
5
6
7
3
The print quality of this copy is not an accurate representation of the original.
24
Mask accessories
Philips Respironics AF531 accessories and replacement parts
Description Quantity Product number Part number
EE leak 1 entrainment elbow* 1 1072645 989805628841
EE leak 1 entrainment elbow* 5 1072646 989805628831
EE leak 1 nebulizing elbow (no nebulizer)* 11072649 989805634531
EE leak 1 nebulizing elbow (no nebulizer)* 51072650 989805634541
SE nebulizing elbow (no nebulizer)* 1 1076755 989805634561
SE nebulizing elbow (no nebulizer)* 5 1076754 989805634551
NIVO nebulizer 51076302 989805634301
CapStrap headgear with clips 1 1072654 989805628871
AF531 sizing gauge 25 1078287 989805628901
Swivel 17041 453561517051
RP-PMax and AF531 headgear clips 2 1060913 989805649921
Nasogastric sealing pad 10 452040 453561517091
CleanClip bracket assembly 11076430 989805627181
CleanClip bracket thumb screw 1 1076197 989805629911
Bronchoscopy elbow* 11072651 989805635091
Bronchoscopy elbow* 51072652 989805635101
Philips Respironics AF541 accessories and replacement parts
Description Quantity Product number Part number
AF541 over-the-nose cushion, small 10 1120960 989805654131
AF541 over-the-nose cushion, medium 10 1120961 989805654141
AF541 over-the-nose cushion, large 10 1120962 989805654151
AF541 over-the-nose cushion, extra large 10 1120963 989805654161
EE leak 1 elbow with NIVO port** 5 1120967 989805654171
EE leak 2 elbow with NIVO port** 5 1120968 989805654181
SE standard elbow with NIVO port** 5 1120969 989805654191
AF541 EE leak 1, without cushion,
four-point headgear
5 1120975 989805654201
AF541 EE leak 1, without cushion,
CapStrap headgear
51120976 989805654211
AF541 four-point headgear with
forehead pad, small/medium
51120970 989805654221
AF541 four-point headgear with
forehead pad, large/extra large
51120971 989805654231
AF541 CapStrap headgear, small/medium 5 1126500 989805654251
AF541 CapStrap headgear, large/extra large 51120972 989805654241
AF541 sizing gauge 25 1120977 989805654261
AF541 size A under-the-nose cushion 10 1120980 989805654271
AF541 size B under-the-nose cushion 10 1120981 989805654281
AF541 size C under-the nose cushion 10 1120982 989805654291
Bronchoscopy elbow 51120984 989805654301
AF541 discharge kit, CapStrap headgear,
small/medium
51120986 989805654311
AF541 discharge kit, four-point headgear,
small/medium
51120987 989805654321
AF541 discharge kit, CapStrap headgear,
large/extra large
51120988 989805654331
AF541 discharge kit, four-point headgear,
large/extra large
51120989 989805654341
Philips Respironics PerforMax accessories
and replacement parts
Description Quantity Product number Part number
EE leak 2 entrainment elbow* 1 1045313 989805611111
EE leak 2 entrainment elbow* 5 1072647 989805628851
Bronchoscopy elbow* 11072651 989805635091
Bronchoscopy elbow* 51072652 989805635101
SE standard elbow* 1 1043210 989805611081
SE standard elbow* 5 1072648 989805628861
** Elbow – Snap/Squeeze type: Push for audible click to install and squeeze tabs to remove.
Refer to instructions with compatible mask or elbow for proper usage. Snap/Squeeze type
used on AF541 mask.
* Elbow – Conical type: Push and twist to install. Pull and twist to remove. Refer to instructions with
compatible mask or elbow for proper usage. Conical type elbows used on AF531, PerforMAX and
PerforMAX pediatric mask.
The print quality of this copy is not an accurate representation of the original.
25
8 10
9
4 72 1
3
5 6
Headgear
Image Description Size Compatibility Quantity Product number Part number
1CapStrap headgear with ball and socket clips Adult (one size) AF811, PerformaTrak 51019543 989805610841
1CapStrap headgear with clips Adult (one size) AF531 11072654 989805628871
2 Four-point headgear with ball and socket clips Adult (one size) AF811, PerformaTrak 11015788 989805610221
3Four-point headgear, no clips Petite AF811, PerformaTrak Contour Deluxe 5 1018472 989805610351
3Four-point headgear, no clips Adult (one size) AF811, PerformaTrak Contour Deluxe 5 1007365 989805609961
4Four-point headgear Adult (one size) Total 11003052 453561517111
4Four-point headgear Adult (one size) Total 91010609 989805610031
5Four-point headgear Adult (one size) Vinyl nasal 10 312106 989805609291
6Four-point headgear with crown strap, clips Small PerforMax 51051857 989805611231
6Four-point headgear with crown strap, clips Large PerforMax 51051816 989805611221
6Four-point headgear with crown strap, clips Extra large PerforMax 51080518 989805634851
6Four-point headgear with crown strap, clips Small PerforMax 91045325 989805611131
6Four-point headgear with crown strap, clips Large PerforMax 91045314 989805611121
6Four-point headgear with crown strap, clips Extra large PerforMax 91080519 989805634861
6Four-point headgear with crown strap, clips Small AF531 1 1072655 989805628891
6Four-point headgear with crown strap, clips Large AF531 11072656 989805628881
6Four-point headgear with crown strap, clips Extra large AF531 51083188 989805634751
7Two-point headgear with chin strap Adult (one size) AP111 5 1062134 453561516551
8AF421 forehead pad kit with two pads 10 mm AF421 10 1119366 989805652521
*Four-point headgear assembly with forehead pad Adult (one size) PerformaTrak multi-use only 51022453 989805610861
9AF541 four-point headgear with forehead pad Small/Medium AF541 51120970 989805654221
9AF541 four-point headgear with forehead pad Large/Extra large AF541 51120971 989805654231
10 AF541 CapStrap headgear Small/Medium AF541 5 1126500 989805654251
10 AF541 CapStrap headgear Large/Extra large AF541 51120972 989805654241
* Image not shown
The print quality of this copy is not an accurate representation of the original.
26
Circuit and mask components and accessories
Image Description Quantity Product number Part number
1Plateau exhalation valve (reusable) 1 302312 989805617941
2Plateau exhalation valve diaphragm 5302310 989805609221
3Whisper Swivel II 1 332113 989805617951
4Disposable exhalation port with filter exhalation port with swivel (no filter) 10 1065775 453561517211
4a Replacement port caps (silicone) 51061825 453561517201
4b Disposable exhalation port with filter exhalation port and proximal pressure line (7 ft, 2.1 m) 10 1116891 989805652291
4b Disposable exhalation port with filter exhalation port and proximal pressure line (7 ft, 2.1 m) 1 1116892 989805652301
5Disposable exhalation port 10 312149 989805609391
6Oxygen enrichment attachment 1312710 989805609421
6Oxygen enrichment attachment 10 312010 989805609241
7Bacteria/virus filter (single use) 11014047 989805618161
7Bacteria/virus filter (single use) 10 342077 989805609521
8Proximal airway filter 1 1002362 453561517101
9Tube management clip 21039967 453561517351
1
7
2
8
3
9
4, 4a 4, 4b
5 6
The print quality of this copy is not an accurate representation of the original.
27
Circuit and mask components and accessories
Image Description Quantity Product number Part number
10 Swivel replacement kit (22 mm male-male) 1 7041 453561517051
11 CleanClip bracket assembly 11076430 989805627181
11 CleanClip bracket thumb screw 1 1076197 989805629911
12 Nasogastric tube sealing pad 10 452040 453561517091
13 PerforMax sizing gauge, small, large, and extra large 1 1095097 989805648901
14 Replacement ball and socket 21009723 989805652511
13 14
10 11 12
* Image not shown
The print quality of this copy is not an accurate representation of the original.
Circuits and connections
Philips offers a variety of single-use
circuits, including heated-wire and
non-heated-wire options, to accompany
our noninvasive ventilation systems.
28
The print quality of this copy is not an accurate representation of the original.
29
Circuits
Image Description Product
number
Part number Quantity V60 BiPAP
Vision
Trilogy
202
BiPAP
Focus
BiPAP
S/T-D
1Invasive circuit with exhalation port, water trap and temperature probe ports, proximal
airway filter and humidifier coupling tube, hanger, and hose clips
652002 989805609681 10 • • •
1Invasive circuit with exhalation port, water trap and temperature probe ports, proximal
airway filter and humidifier coupling tube, hanger, and hose clips
652001 989805609671 20 • • •
2Noninvasive circuit with main flow filter, disposable swivel exhalation port with filter
port and filter, proximal pressure line, hanger, and hose clips
1065830 989805621311 10 • • • •
3Noninvasive circuit with main flow filter, disposable swivel exhalation port with filter
port, proximal pressure line, hanger, and hose clips (exhalation filter not included)
1065832 989805621321 10 • • • •
4Noninvasive circuit with disposable swivel exhalation port with filter port, proximal
pressure line, hanger, and hose clips (main flow and exhalation filters not included)
1069210 989805634871 10 • • • •
5Noninvasive circuit with disposable exhalation port, proximal pressure line, hanger,
and hose clips
582073 989805609611 10 • • • •
6BiPAP S/T-D circuit with exhalation port, proximal pressure line, hanger, and hose clips 312107 989805609301 10 •
7Tubing 6 ft (22 mm) (no dep, proximal pressure line, or hanger) 532316 989805647181 1
Humidification circuits and accessories
Description Quantity Product number Part number
Auto-feed humidification chamber 24 1035609 989805619481
Heated single-limb circuit with main flow filter 10 8624C 989805619521
Heated single-limb circuit with main flow filter, auto-feed humidification chamber 10 1045770 989805619511
Dry circuits and accessories
Description Quantity Product number Part number
NIV circuit with main flow filter 10 9624 989805619411
NIV circuit with main flow filter, O2, enrichment port 10 9624C 989805619531
1
6
2 3 4
5 7
The print quality of this copy is not an accurate representation of the original.
Easy to use and maintain
• Trilogy circuits can be used for a variety
of pediatric and adult patient applications
• Passive circuits for NIV applications
• Active exhalation valve for IV application
• Circuits are available in packs of 10 and 20
Trilogy accessories
The innovative technology of Trilogy sets
it apart from the rest. The support, service,
and upkeep behind it keep it there.
30
The print quality of this copy is not an accurate representation of the original.
31
The ability to use either
an active valve or passive
exhalation port gives you
the flexibility to choose the
best available circuit and
interface for your patient.
Trilogy’s unique passive
exhalation port reduces
extra tubing connections.
Circuit adapters
Image Description Compatibility Product number Part number
1Active exhalation valve with PAP assembly 1065659 – 1/pk 989805628221
2 Proximal flow sensor
(Trilogy202)
1050408 – 1/pk
1050534 – 10/pk
989805621211
989805645511
3Disposable swivel passive
exhalation port
1084428 – box of 10
1084429 – box of 20
989805643161
989805646961
4Flexible trach adapter
with 15 mm cuff
Connects to the flow sensor
or the active exhalation valve
1073863 – box of 10
1073903 – box of 20
989805633921
989805633941
5Flexible trach adapter
with 22 mm cuff
Connects to Whisper Swivel II and swivel
and fixed disposable exhalation ports
1073902 – box of 10
1073904 – box of 20
989805633931
989805633951
Miscellaneous
Image Product Product number Part number
6Oxygen inlet adapter – 2/pk 1040390 989805647691
7Tube port adapter, active PAP 1061398 989805621291
Trilogy support arm system
Image Product Product number Part number
8Tubing hanger (22 mm) – 1/pk 311107 989805648891
*Support arm 332497 989805617961
*Support arm mount assembly 1052863 989805605731
* Image not shown
1 32 4 5
6 7 8
The print quality of this copy is not an accurate representation of the original.
32
Trilogy disposable circuits
Image Description Components Quantity Product number Part number
1Adult passive circuit with fixed
exhalation port
Passive exhalation port. Patient tube: 6 ft length, 22 mm diameter
with 22 mm cuff.
Box of 10
Box of 20
1069467
1069468
989805621551
989805621561
2Adult passive circuit with swivel
design exhalation port
Passive exhalation port. Patient tube: 6 ft length, 22 mm diameter
with 22 mm cuff.
Box of 10
Box of 20
1073228
1073236
989805633861
989805633911
3* Adult passive circuit with water trap Standard 90° degree elbow adapter. Passive fixed exhalation port.
Temperature probe port. Patient tube, 2 ft length, 22 mm diameter
with 22 mm cuff. Water trap. Humidifier connection tube, 2 ft length,
22 mm diameter with 22 mm cuff.
Box of 10
Box of 20
1069443
1069444
989805621531
989805621541
4* Adult passive circuit, heated wire Passive swivel exhalation port. Temperature probe port. Heated wire
patient tube, 5 ft length, 22 mm diameter with 22 mm cuff. Heated wire
adapter. Humidifier connection tube, 2 ft length, 22 mm in diameter
with 22 mm cuff.
Box of 10
Box of 20
1073227
1073235
989805646441
989805646481
5 Adult active circuit, no water trap Standard 90° elbow trach adapter. Active exhalation valve.
Exhalation tubing. Proximal pressure tubing. Patient tube, 6 ft length,
22 mm diameter with 22 mm cuff. Tube management clips.
Box of 10
Box of 20
1073223
1073232
989805633841
989805633881
6* Adult active circuit, heated wire Standard 90° elbow trach adapter. Active exhalation valve. Exhalation
tubing. Proximal pressure tubing. Heated wire patient tube, 5 ft length,
22 mm diameter with 22 mm cuff, with heated wire connector. Heated wire
adapter. Temperature probe port. Humidifier connection tube, 2 ft length,
15 mm diameter with 22 mm cuff. Tube management clips.
Box of 10
Box of 20
1073222
1073231
989805646421
989805646461
* Chamber not included
1
4
2
5
3
6
The print quality of this copy is not an accurate representation of the original.
33
Trilogy disposable circuits
Image Description Components Quantity Product number Part number
7Pediatric passive circuit with water trap Passive fixed exhalation port. Patient tube, 6 ft length, 15 mm diameter
with 22 mm cuff and water trap.
Box of 10
Box of 20
1069445
1069446
453561517231
453561517241
8* Pediatric passive circuit with water trap Passive swivel exhalation port. Patient tube, 2.5 ft length, 15 mm diameter
with 22 mm cuff. Temperature probe port. Water trap. Humidifier
connection tube, 2 ft length, 15 mm diameter with 22 mm cuff.
Box of 10
Box of 20
1073224
1073233
989805633851
989805633901
9* Pediatric passive circuit, heated wire Passive swivel exhalation port. Heated wire patient tube, 5 ft length,
15 mm diameter with 22 mm cuff, with heated wire connector. Heated wire
adapter. Temperature probe port. Humidifier connection tube, 2 ft length,
15 mm diameter with 22 mm cuff.
Box of 10
Box of 20
1073225
1073234
989805646431
989805646471
10* Pediatric active circuit with water trap Standard 90° elbow trach adapter. Active exhalation valve. Exhalation
tubing. Proximal pressure tubing. Patient tube, 2.5 ft length, 15 mm
diameter with 22 mm cuff. Temperature probe port. Water trap.
Humidifier connection tube, 2 ft length, 15 mm diameter with 22 mm cuff.
Tube management clips (one shown).
Box of 10
Box of 20
1073220
1073229
989805633831
989805633871
11* Pediatric active circuit, heated wire Standard 90° elbow trach adapter. Active exhalation valve. Exhalation
tubing. Proximal pressure tubing. Heated wire patient tube, 5 ft length,
15 mm diameter with 22 mm cuff, with heated wire connector. Heated wire
adapter. Temperature probe port. Tube management clips. Humidifier
connection tube, 2 ft length, 15 mm diameter with 22 mm cuff.
Box of 10
Box of 20
1073221
1073230
989805646411
989805646451
12 MPV (mouthpiece ventilation) circuit,
single use
Bacteria filter, 22 mm x 15 mm reducer cuff, 6 ft length, 15 mm tubing,
coupler, miniature and angled mouthpiece.
Box of 10 1102866 989805646981
* Chamber not included
7
10
8
11
9
12
The print quality of this copy is not an accurate representation of the original.
34
Notes
The print quality of this copy is not an accurate representation of the original.
35
Notes
The print quality of this copy is not an accurate representation of the original.
©2016 Koninklijke Philips N.V. All rights are reserved.
Philips reserves the right to make changes in
specifications and/or to discontinue any product at
any time without notice or obligation and will not be
liable for any consequences resulting from the use
of this publication. Trademarks are the property of
Koninklijke Philips N.V. or their respective owners.
www.philips.com/NIVmasks
Printed in the Netherlands.
4522 991 16521 * AUG 2016
The print quality of this copy is not an accurate representation of the original.

Navigation menu
