Philips
LCD monitor
38 cm (15")
XGA
150S4FG
affordable, space-saving display
The smart choice is to look to the Philips 150S4 to save space and money with a great,
reliable display for pumped up productivity. Plus 20 percent lower power consumption
and affordable total cost of ownership.
Best total cost of ownership solution
• Power consumption below the industry average
Outstanding front of screen performance
• XGA 1024x768 resolution for sharper display
Great convenience
• Embedded power supply eliminates external power adaptors
• VESA mounting pattern for easy wall mounting of display
Issue date 2014-02-05
Version: 2.0.3
12 NC: 8639 000 14002
EAN: 87 10895 77661 5
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
Specifications
150S4FG/02
LCD monitor
38 cm (15") XGA
Highlights
Lower power consumption
Reduction of the electrical power required to
operate a device.
XGA, 1024 x 768 resolution
For graphics monitors, the screen resolution signifies
the number of dots (pixels) on the entire screen. For
example, a 1024-by-768 pixel screen is capable of
displaying 1024 distinct dots on each of 768 lines, or
about 786 thousand pixels. XGA provides
resolutions of 640 by 480 or 1024 by 768 pixels.
Embedded power supply
An embedded power supply is a power adaptor built
into the body of a display device that replaces a bulky
external power adaptor.
VESA mounting holes
A unified industry standard for wall mounting IT
equipment set by the Video Electronics Standards
Association.
Picture/Display
• LCD panel type: 1024 x 768 pixels, Anti-glare
polarizer, RGB vertical stripe
• Panel Size: 15"/ 38 cm
• Effective viewing area: 304.1 x 228.1 mm
• Pixel pitch: 0.297 x 0.297 mm
• Brightness: 250 cd/m²
• Contrast ratio (typical): 400:1
• Display colors: 16 M
• Viewing angle: @ C/R > 5
• Viewing angle (H / V): 140 / 110 degree
• Response time (typical): 25 ms
• White Chromaticity, 6500K: x = 0.313 / y = 0.329
• White Chromaticity, 9300K: x = 0.283 / y = 0.297
• Maximum Resolution: 1024 x 768 @ 75 Hz
• Optimum resolution: 1024 x 768 @ 60 Hz
• Factory Preset Modes: 14 modes
• User definable modes: 14 modes
• Horizontal Scanning Frequency: 30 - 61 kHz
• Refresh Rate (V): 56 - 76 Hz
Connectivity
• Signal Input: VGA (Analog )
Convenience
• User convenience: On-screen Display
• Monitor Controls: Auto, Brightness Control, Left/
Right, Menu (OK), Power On/Off, Up/Down
• OSD Languages: English, French, German, Italian,
Simplified Chinese, Spanish
• Plug & Play Compatibility: DDC 2B, Windows 98/
ME/2000/XP
• Regulatory approvals: CE Mark, E2000, EMC, FCC-
B, UL, CSA, NUTEK, Energy Star, SEMKO, TCO
'99, TCO '03, TÜV/GS, TÜV Ergo
• Tilt: -5° to 25°
• VESA Mount: 100 x 100 mm
Accessories
• User Manual
• Included accessories: AC Power Cord, VGA cable
• Optional accessories: Super Ergo Base
Dimensions
• Dimensions (with base) (W x H x D):
343 x 310 x 180 mm
• MTBF: 50,000 hrs
• Relative humidity: 20% - 80%
• Temperature range (operation): 5°C to 40°C
• Temperature range (storage): -20°C to 60°C
•Weight: 3.7 kg
Power
• Complies with: E2000, Energy Star, NUTEK
•Consumption (Off Mode): < 1 W
•Consumption (On mode): 18 W (Typical)
• Power LED indicator: Operation - green, Stand by/
sleep - Amber
• Power supply: Built-in
•
