Philips

LCD monitor with

LightFrame™

43 cm (17")

SXGA

170P5ES

the best productivity solution

When the job demands ultimate performance: Philips 170P5 gets the job done with advanced

ergonomics and clearly superior front-of-screen performance plus SmartManage for remote,

LAN-based monitor management and low power consumption.

Outstanding front of screen performance

• LightFrame™ delivers best-ever sharpness and brightness

• Zero Bright Dot™ eliminates LCD bright dot defects

• SXGA 1280 x 1024 resolution for sharper display

• Fast response time for great display of moving images

• Dual input accepts both analog VGA and digital DVI signals

• Easy plug-and-play DVI for a true digital experience

Maximum comfort for maximum productivity

• Built-in speakers for audio without desktop clutter

• Adjustable screen height for the ideal viewing angle

• 90 degree screen rotation and smart cable management

• Tilt and swivel adjustment for an ideal viewing angle

Best total cost of ownership solution

• SmartManage compatibility enables LAN-based asset management

• Power consumption below the industry average

170P5ES/00

Highlights

LCD monitor

43 cm (17") SXGA

LightFrame™

An intelligent and revolutionary technology for

enhancing monitor's brightness, sharpness,

contrast, and color. Images enhanced by

LightFrame™ are lively, realistic, clear,

attractive and colorful.

Zero Bright Dot™

Bright dots are defects in a LCD panel once

thought to be an inevitable part of the

manufacturing process. With Zero Bright

Dot™, Philips monitors are guaranteed

without bright dot defects.

SXGA, 1280 x 1024 resolution

For graphics monitors, the screen resolution

signifies the number of dots (pixels) on the

entire screen. For example, a 1280-by-1024

pixel screen is capable of displaying 1280

distinct dots on each of 1024 lines, or about 1.3

million pixels.

Fast response time

Response time measures signal reaction speed

in milliseconds. On/off response time

measures the time required for the screen to

turn from completely white to completely

black and vice versa. Fast on/off response time

improves display of text. Gray-to-grey

response time measures the average time of

transition between several sets of random gray

levels - Lower numbers mean faster

transitions. Faster is better because a fast

response time eliminates visible image artifacts

that could dampen your experience when

viewing fast moving images or objects.

Dual input

Dual input provides connectors to

accommodate input of both analog VGA and

digital DVI signals.

In-box DVI cable

A DVI cable is shipped with the product to

provide high quality digital display.

Built-in speakers

A pair of stereo speakers built into a display

device. It can be visible front firing, or invisible

down firing, top firing, rear firing, etc

depending on model and design.

Adjustable height

Adjustable height is the ability of a monitor to

travel up or down on its base and lock into

position when the desired height is reached,

delivering a comfortable, individualized viewing

angle that is just right for the user's height,

weight, body-type and posture, alleviating

possible eyestrain or fatigue that can come

from long hours working on a computer.

ScreenRotate

ScreenRotate makes it possible to use a

monitor in either the landscape and portrait

mode; to change orientation for a better view

of a selected document or image, the monitor

is rotated to the desired orientation.

Screen tilt and swivel

Screen tilt and swivel is a mechanism built into

the base permits the monitor to swivel and tilt

backward or forward.

SmartManage enabled

SmartManage is a system for monitoring,

managing and checking status of display devices

as well as delivering remote support to users

who experience difficulties - all accomplished

over a LAN.

Lower power consumption

Reduction of the electrical power required to

operate a device.

Issue date 2016-10-29

Version: 7.0.9

12 NC: 8639 000 15088

EAN: 87 10895 82388 3

© 2016 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

170P5ES/00

Specifications

LCD monitor

43 cm (17") SXGA

Picture/Display

• LCD panel type: 1280 x 1024 pixels, Anti-glare

polarizer, RGB vertical stripe

• Panel Size: 17"/ 43 cm

• Effective viewing area: 337.9 x 270.3 mm

• Pixel pitch: 0.264 x 0.264 mm

• Brightness: 250 cd/m²

• Contrast ratio (typical): 450:1

• Display colors: 16 M

• Viewing angle: @ C/R > 5

• Viewing angle (H / V): 160 / 140 degree

• Response time (typical): 16 ms

• White Chromaticity, 6500K: x = 0.313 / y = 0.329

• White Chromaticity, 9300K: x = 0.283 / y = 0.297

• Maximum Resolution: 1280 x 1024 @ 75 Hz

• Optimum resolution: 1280 x 1024 @ 60 Hz

• Factory Preset Modes: 15 modes

• User definable modes: 16 modes

• Horizontal Scanning Frequency: 30 - 82 kHz

• Refresh Rate (V): 56 - 76 Hz

• Picture enhancement: LightFrame ™

•sRGB

Connectivity

• Signal Input: VGA (Analog ), DVI-D, PC Audio in

• I/O interface on pad: Headphone jack

Convenience

• Built-in Audio: 2 W RMS x 2 Stereo Speakers

• User convenience: On-screen Display,

SmartManage

• Monitor Controls: Auto, Brightness Control, Left/

Right, LightFrame, Menu (OK), Power On/Off, Up/

Down, Volume control

• OSD Languages: English, French, German, Italian,

Simplified Chinese, Spanish

• Other convenience: Kensington lock

• Plug & Play Compatibility: DDC CI, sRGB,

Windows 98/ME/2000/XP

• Regulatory approvals: CE Mark, E2000, FCC-B, UL,

CSA, NUTEK, Energy Star, SEMKO, EMC, TCO

'99, TÜV/GS, TÜV Ergo, TCO '03

•Swivel: +/- 45°

• Tilt: -5° to 25°

• VESA Mount: 100 x 100 mm

Accessories

• Included accessories: AC Power Cord, Audio

Cable, DVI-D cable, VGA cable

• Pivot & Portrait User Pack

• User Manual

Dimensions

• Dimensions (with base) (W x H x D):

375 x 396 x 201 mm

• Height adjustment range: 130 mm

• MTBF: 50,000 hrs

• Relative humidity: 20% - 80%

• Temperature range (operation): 5°C to 40°C

• Temperature range (storage): -20°C to 60°C

•Weight: 6.3 kg

Power

• Complies with: E2000, Energy Star, NUTEK

•Consumption (On mode): 33 W (Typical)

•Consumption (Off Mode): < 1 W

• Power LED indicator: Operation - Blue, Stand by/

sleep - Amber

• Power supply: Built-in

•
