Philips 193V5LHSB2/69 LCD Monitor With SmartControl Lite User Manual Leaflet 193v5lhsb2 69 Pss

User Manual: Philips 193V5LHSB2/69 Leaflet LCD monitor with SmartControl Lite 193V5LHSB2/69 | Philips193V5LHSB2/69

Open the PDF directly: View PDF .
Page Count: 2

Philips

LCD monitor with

SmartControl Lite

V Line

18.5" / 47 cm

193V5LHSB2

Great LED images in vivid colors

Enjoy vivid LED pictures on this Philips display. Equipped with HDMI and SmartControl

lite, it’s a great choice!

Vivid pictures every time

• LED technology for vivid colors

• Easy display performance tuning with SmartControl Lite

Experience multimedia

• HDMI-ready for Full HD entertainment

Great choice

• Compact design saves space

• Mercury Free eco-friendly display

• VESA mount allows for flexibility

Issue date 2017-11-01

Version: 2.0.1

12 NC: 8670 001 25446

EAN: 87 12581 73327 8

© 2017 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

Specifications

193V5LHSB2/69

LCD monitor with SmartControl Lite

V Line 18.5" / 47 cm

Highlights

LED technology

White LED's are solid state devices which light up to

full, consistent brightness faster saving startup time.

LED's are free from mercury content which allows

for eco-friendly recycling and disposal process. LED's

allow for better dimming control of LCD backlight,

resulting in super high contrast ratio. It also gives

superior color reproduction thanks to consistent

brightness across the screen.

SmartControl Lite

SmartControl Lite is the next generation 3D icon

based GUI monitor control software. This allows

user to fine-tune most parameters of the monitor

like Color, Brightness, screen calibration, Multi-

media, ID management, etc with the mouse.

HDMI Ready

An HDMI-ready device has all the required hardware

to accept High-Definition Multimedia Interface

(HDMI) input. A HDMI cable enables high-quality

digital video and audio all transmitted over a single

cable from a PC or any number of AV sources

(including set-top boxes, DVD players, A/V receivers

and video cameras).

Mercury Free

Philips monitors with LED backlighting are free of

Mercury content, one of the most toxic natural

substances, which affects humans and animals. This

reduces the environmental impact of the display

throughout its life-cycle, from manufacturing to

disposal.

®

Picture/Display

• LCD panel type: TFT-LCD

• Backlight type: W-LED system

• Panel Size: 18.5 inch / 47 cm

• Effective viewing area: 409.8 (H) x 230.4 (V)

• Aspect ratio: 16:9

• Optimum resolution: 1366 x 768 @ 60 Hz

• Response time (typical): 5 ms

• Brightness: 200 cd/m²

• Contrast ratio (typical): 700:1

• Pixel pitch: 0.30x 0.30 mm

• Viewing angle: 90º (H) / 65º (V), @ C/R > 10

• Display colors: 16.7 M

• Scanning Frequency: 30 -83 kHz (H) / 56 -76 Hz (V)

•sRGB

Connectivity

• Signal Input: VGA (Analog ), HDMI (digital, HDCP)

• Sync Input: Separate Sync, Sync on Green

Convenience

• User convenience: Power On/Off

• OSD Languages: Brazil Portuguese, Czech, Dutch,

English, Finnish, French, German, Greek,

Hungarian, Italian, Japanese, Korean, Polish,

Portuguese, Russian, Simplified Chinese, Spanish,

Swedish, Traditional Chinese, Turkish, Ukranian

• Other convenience: Kensington lock, VESA mount

(100x100mm)

• Plug & Play Compatibility: DDC/CI, Mac OS X,

sRGB, Windows 7, Windows 8

Stand

• Tilt: -3/10 degree

Power

• On mode: 15.24 W (typ.), 17.65 W (max.)

• Standby mode: 0.5 W (typ.)

• Off mode: 0.5 W (typ.)

• Power LED indicator: Operation - White, Standby

mode- White (blinking)

• Power supply: Built-in, 100-240VAC, 50-60Hz

Dimensions

• Product with stand (mm): 437 x 338 x 170 mm

• Product without stand (mm): 437 x 273 x 48 mm

• Packaging in mm (WxHxD): 481 x 350 x 103 mm

Weight

• Product with stand (kg): 2.15 kg

• Product without stand (kg): 1.94 kg

• Product with packaging (kg): 3.00 kg

Operating conditions

• Temperature range (operation): 0°C to 40°C °C

• Temperature range (storage): -20°C to 60°C °C

• Relative humidity: 20%-80 %

• Altitude: Operation: +12,000ft (3,658m), Non-

operation: +40,000ft (12,192m)

• MTBF: 30,000 hour(s)

Sustainability

• Environmental and energy: EPEAT Silver, RoHS,

Lead-free, Mercury Free

• Recyclable packaging material: 100 %

Compliance and standards

• Regulatory Approvals: CE Mark, FCC Class B,

EAC, SEMKO, BSMI, cETLus, TUV/ISO9241-307

Cabinet

• Color: Black

• Finish: Hairline (front bezel) / Texture (rear cover)

•
