Philips

LCD TV with Pixel Plus

HD

48 cm (19") class

digital TV

19PFL4505D

The green choice

Slim LED LCD Eco TV ™

Philips selected for you the best performance and connectivity for the right price, today

and tomorrow. This TV delivers Full HD pictures with incredible surround sound

experience, which let's you live the moment as if you were there...

See brilliant picture quality

• LED technology ensures natural color and thin design

• Pixel Plus HD for better details, depth and clarity

Hear crisp and clear sound

• SRS TruSurround HD®

• Dolby Digital output for connection to a home theatre system

Easy to connect and enjoy

• 2 HDMI inputs with Easylink for HD connection

• PC-input allows you to use your TV as a PC monitor

Greener every day

• Save money and reduce the impact on the environment

• Energy Star rated for low power consumption

19PFL4505D/F7

Highlights

LCD TV with Pixel Plus HD

48 cm (19") class digital TV

LED

LED lighting technology is the most advanced

available. In this TV it combines an eye-catching

minimalistic design with stunning image quality,

as well as being the lowest power consumption

in its category. Another environmental benefit

is that LED lighting technology does not

contain hazardous materials. With an LED

backlight you can enjoy low power

consumption, high brightness, incredible

contrast and sharpness and vibrant colors.

Pixel Plus HD

Pixel Plus HD is a picture processing

technology that enables viewers to watch

content that is vivid, natural, and real. The

result means superbly life-like pictures with

incredible details and depth from any HD

source.

SRS TruSurround HD®

SRS TruSurround HD® creates an immersive,

feature-rich surround sound experience from

two speakers, complete with rich bass, high

frequency detail and clear dialog.

Dolby Digital output

Dolby Digital output for connection to a home

theatre system

2 HDMI inputs with EasyLink

EasyLink uses the HDMI CEC industry

standard protocol to share functionality

between connected devices and the TV. With

Easylink only one remote control is needed to

operate main functionalities on your TV and

connected devices. HDMI makes an

uncompressed digital RGB connection from

the source to the screen for the ultimate

picture quality. HDMI uses HDCP copy

protection. With 1 HDMI input on the back

and 1 HDMI on the side of the TV you can

connect multiple HD sources, for instance an

HD settop box, a Blu-ray player, and Game

Console or Digital Camcorder.

PC input (VGA)

With PC input you can connect your TV to a

computer by a VGA cable and use the TV as a

PC monitor.

Eco TV ™

Your Eco TV is designed with several power

saving features such as a Philips proprietary

dimming technology that is designed to lower

the LCD panel backlight to reduce power

consumption without compromising the

picture quality. A built-in light sensor

automatically measures the viewing room's

ambient lighting and adjusts the television's

backlight for power efficiency.

Energy Star

Energy Star-labeled home electrical products

are designed to use less energy - saving you

money while reducing environmental

pollution. In fact, Energy Star-compliant

products consume less than 1 watt of power

while in standby mode. As an Energy Star

partner, Philips develops products that meet

the Energy Star guidelines for energy efficiency.

This is achieved by having low standby power

consumption through innovatively designed

standby circuitry and stringent selection of

components made with high efficiency

materials.

Issue date 2014-03-14

Version: 1.1.1

12 NC: 8670 000 62175

UPC: 6 09585 18956 0

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

19PFL4505D/F7

Specifications

LCD TV with Pixel Plus HD

48 cm (19") class digital TV

Picture/Display

• Aspect ratio: Widescreen

• Display screen type: LED WXGA Display

• Panel resolution: 1366 x 768p

• Brightness: 250 cd/m²

• Response time (typical): 5 ms

• Contrast ratio (typical): 800:1

• Dynamic screen contrast: 3,200:1

• Diagonal screen size: 19 inch / 48.1 cm

• Visible screen diagonal (inch): 18.5 inch

• Viewing angle: 160º (H) / 160º (V)

• Picture enhancement: Pixel Plus HD, 3D

Combfilter, Digital Noise Reduction, Dynamic

contrast enhancement, Progressive scan

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

720 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

1280 x 768 60Hz

1360 x 768 60Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

720p 60Hz

1080i 60Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 2 x 3W

• Sound System: SRS TruSurround HD, Dolby

Digital (AC-3), Stereo, SAP

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Installation: Autostore

• Ease of Use: Auto Volume Leveller (AVL),

AutoPicture, AutoSound, Settings assistant

Wizard, Side Control

• Remote Control: TV

• Screen Format Adjustments: 16:9, Normal, Zoom,

4:3, Full, Movie Expand, Wide

• Multimedia: auto slideshow

Multimedia Applications

• Multimedia connections: USB memory class device

• Playback Formats: JPEG Still pictures, MP3

Tuner/Reception/Transmission

• Aerial Input: 75 ohm F-type

• TV system: ATSC, NTSC

•Video Playback: NTSC

• Tuner bands: UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, CVBS in

• HDMI 1: Analog audio L/R in, HDMI

•HDMI 2: HDMI

• Audio Output - Digital: Coaxial (cinch)

• Other connections: PC Audio in, PC-In VGA,

Headphone out

• USB: USB

• EasyLink (HDMI-CEC): One touch play, Power

status, System info (menu language), System audio

control, System standby

Power

• Mains power: 120V/60Hz

• Power consumption: 40 W

• Standby power consumption: < 0.15 W

• Ambient temperature: 5°C to 35°C (41°F to 95°F)

Dimensions

• Set dimensions in inch (W x H x D):

18.32 x 11.24 x 1.93 inch

•Set dimensions with stand in inch (W x H x D):

18.32 x 13.01 x 7.09 inch

• Product weight (lb): 7.72

• Product weight (+stand) (lb): 9.26 lb

• Box dimensions in inch (W x H x D):

23.86 x 17.80 x 10.67 inch

• Weight incl. Packaging (lb): 13.23

• VESA wall mount compatible: 100 x 100 mm

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, User Manual, Registration card,

Remote Control, Batteries for remote control

•
