Philips
Professional LCD TV with
Digital Crystal Clear
26"
LCD
HD Ready
26HF7875
The ultimate interactive Hospitality TV
Philips LCD TV & SmartCard Slot
This stylish, energy efficient Hospitality TV with integrated SmartCard slot is our best
tamper proof interactive solution. Your guests enjoy a great viewing experience
optionally enhanced with bathroom music and a tailored welcome message.
Integrated system solution and future proof
• Remote software upgrading
• Tamper proof SmartCard slot for interactive systems
Great viewing experience and guest comfort
• Digital Crystal Clear for more vivid cinema-like images
• Integrated clock display with wake up and message alarm
• Welcome message on screen display
• Swivel stand with anti-theft provision
Best total cost of ownership
• Wireless SmartLoader for fast cloning
• Installation menu locking
• External loudspeaker connector & extra power supply
Sustainable and safe
• SmartPower for energy saving
• Eco-friendly design & flame retardant housing
26HF7875/10
Highlights
Professional LCD TV with Digital Crystal Clear
26" LCD, HD Ready
Remote software upgrading
The TV software that controls hotel-specific
features can be upgraded remotely through a
certified system provider.
Integrated SmartCard Slot
The integrated SmartCard slot allows third
parties to add new functionality to the TV
through application cards, without the need
for additional boxes and external connections.
The TV can also be connected to external
decoders and set-top boxes of all major
interactive system providers, through the
SerialXpress Control Interface (supporting
UART and RS232 protocols) and the
SmartPlug Control interface.
Digital Crystal Clear
Digital Crystal Clear is a processing technology
that digitally adjusts and enhances picture
quality by optimizing contrast, color and
sharpness levels, resulting in more vivid
cinema-like images.
Integrated clock display
The built-in clock display, which is also a wake-
up alarm, eliminates the need and investment
for an additional clock with cables and
connections in the room. Automatic time
synchronisation via teletext and preservation
of alarm settings during short power outages
further enhances guest comfort
Swivel stand
This LCD TV comes with a swivel stand that
allows your guests to adjust the TV so that
they can watch TV from any position in the
room. The stand can be secured to a table or
furniture to provide additional security against
theft.
Wireless SmartLoader
Provides the ability to copy easy and wireless
all programmming settings from one TV set
into other TV sets in less then a minute. The
feature ensures uniformity between TV sets
and significantly reduces installation time and
costs.
Installation menu locking
Prevents unauthorized access to installation
and configuration settings, to ensure maximum
guest convenience and avoid unnecessary
reprogramming costs.
External loudsp & power supply
The TV is equipped with an amplified audio
connector for easy installation of external
speakers (like for bathrooms), eliminating the
need for investments in external equipment.
The extra integrated power supply avoids the
need for a separate power supply for an
interactive system. In case of stand-alone use,
the additional power supply can be switched
off to save energy.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Eco-friendly design
Sustainability is integral to the way Philips does
business. Philips TVs are designed and
produced according to our EcoDesign
principles aimed at minimizing overall
environmental impact, through lower power
consumption, removal of hazardous
substances, lower weight, more efficient
packaging and better recyclability. Philips TVs
also have a special housing of flame retardant
material. Independent tests carried out by
emergency fire services have shown that
whereas TVs can sometimes intensify fires
caused by external sources, Philips TVs will not
contribute to the fire.
Issue date 2014-10-29
Version: 4.0.5
12 NC: 8670 000 28844
EAN: 87 12581 32862 7
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
26HF7875/10
Specifications
Professional LCD TV with Digital Crystal Clear
26" LCD, HD Ready
Picture/Display
• Diagonal screen size: 26 inch / 66 cm
• Aspect ratio: 16:9, Widescreen
• Display screen type: LCD WXGA Active Matrix
TFT
•Panel resolution: 1366 x 768p
• Brightness: 500 cd/m²
• Contrast ratio (typical): 800:1
• Dynamic screen contrast: 4000:1
• Viewing angle (H / V): 160 / 150 degree
• Response time (typical): 8 ms
• Picture enhancement: 3D Combfilter, 3/2 - 2/2
motion pull down, Active Control, Contrast Plus,
Dynamic contrast enhancement, Digital Noise
Reduction, Jagged Line Suppression, Progressive
Scan, Digital Crystal Clear
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
•Video Formats
Resolution Refresh rate
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh
•Computer formats
Resolution Refresh rate
640 x 480 60, 72, 75Hz
800 x 600 60, 72, 75Hz
1024 x 768 60, 70, 75Hz
1280 x 768 60Hz
1366 x 768 60Hz
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• Number of Preset Channels: 125
• Tuner bands: Hyperband, S-Channel, UHF, VHF
•Tuner Display: PLL
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L'
• Video Playback: NTSC, PAL, SECAM
Sound
• Sound System: Nicam Stereo, Stereo
• Output power (RMS): 2 x 10 W
• Sound Enhancement: Auto Volume Leveller,
Incredible Surround
Loudspeakers
• Built-in speakers: 2
Connectivity
•Number of Scarts: 2
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2 Scart: Audio L/R, CVBS in/out, S-video in
• Ext 3: Audio L/R in, CVBS in, S-video in
• Ext 4: Audio L/R in, YPbPr
•Ext 5: HDMI
•Ext 6: HDMI
• Other connections: Antenna IEC75, Headphone
out, PC-In VGA
• Connectivity Enhancements: RJ12 connector, RJ45
connector, External Loudspeaker connector, HM-
Link, Extra Power supply 12V/1W, SmartCard
Xpress box ready, Fast Infrared loop through,
Serial Xpress interface, SmartPlug Xpress
Interface, Power on scart, SmartCard Expansion
Slot
Convenience
• Comfort: Hotel Guest features, Switch on channel,
Volume limitation, Welcome message, Message
indicator
• Ease of Installation: Advanced Hotel Mode, Fine
Tuning, Program Name, Wireless Smart Loading,
Keyboard lock-out, Security menu access
• Ease of Use: Auto Volume Leveller (AVL), Smart
Picture, Smart Sound
• Screen Format Adjustments: 4:3, 7 Widescreen
Modes
• Teletext: 1000 page Hypertext
• Teletext languages: Cyrillic, Eastern European,
Western European
• Clock: Sleep Timer, Wake up Clock, Integrated
LCD Clock Display
• Clock Enhancements: Synchro Time via PDC/TXT
• Firmware upgradeable: Remote upgrade hotel TV
softw, Local upgrade total TV softw.
• Other convenience: Kensington lock, Convertible
to consumer TV
Power
• Mains power: 100 - 240V, 50/60Hz
• Power consumption: 120 W
• Active stand-by consumption: 18 W
• Passive stand-by consumption: 2 W
• SmartPower high mode: 58 W
• SmartPower medium mode: 73 W
• SmartPower low mode: 103 W
• Ambient temperature: 5 °C to 40 °C
Dimensions
• Color cabinet: Black
• Set dimensions (W x H x D): 682 x 473 x 111 mm
• Set dimensions with stand (W x H x D):
682 x 536 x 200 mm
•Box dimensions (W x H x D):
836 x 212 x 592 mm
• Product weight: 11.19 kg
• Product weight (+stand): 13.93 kg
• Weight incl. Packaging: 16.7 kg
• VESA wall mount compatible: 200 x 100 mm
Accessories
• Included Accessories: Warranty Leaflet, Power
cord, Swivel stand with anti-theft
• Optional accessories: Wireless SmartLoader
22AV1135, Set up Remote RC2573GR, RC2886
(remote control)
Green Specifications
• Safety: Flame retardant housing
•
