Philips

Professional LCD TV

66 cm/26" Ultimate HD

LCD

DVB-T/C MPEG4*

26HFL5870D

The ultimate movie experience

Philips Ultimate HD Hospitality LCD TV

This stylish Ultimate HD Hospitality TV offers an end-to-end interactive digital HD

solution without the need for a set top box. You can offer your guests a real HD cinema

solution which completes the in room experience of your guest.

Integrated system solution and future proof

• HD LCD display, with a 1366 x 768p resolution

• Tamper proof SmartCard slot

• Remote software upgrading

Differentiating guest experience

• Integrated clock display with wake up and message alarm

• Theme TV for easy finding of guests' own channels

• Pixel Plus HD for better details, depth and clarity

• Philips Connectivity Panel compatible to enjoy guest devices

Best total cost of ownership

• End-to-end cost optimized solution

• VSecure and VTrack for HD content security in hotels

Sustainable and safe

• SmartPower for energy saving

• Eco-friendly design & flame retardant housing

26HFL5870D/10

Highlights

Professional LCD TV

66 cm/26" Ultimate HD LCD, DVB-T/C MPEG4*

HD LCD display

This WXGA display with state-of-the-art LCD

screen technology gives your guests

widescreen HD resolution of 1366 x 768p

pixels. It produces brilliant flicker-free

progressive scan pictures with optimum

brightness and superb colors. This vibrant and

sharp image will provide your guests with an

enhanced viewing experience.

Integrated SmartCard Slot

The integrated SmartCard slot allows third

parties to add new functionality to the TV

through application cards, without the need

for additional boxes and external connections.

The TV can also be connected to external

decoders and set-top boxes of all major

interactive system providers, through the

SerialXpress Control Interface (supporting

UART and RS232 protocols) and the

SmartPlug Control interface.

Remote software upgrading

The TV software that controls hotel-specific

features can be upgraded remotely through a

certified system provider.

Integrated clock display

The built-in clock display, which is also a wake-

up alarm, eliminates the need and investment

for an additional clock with cables and

connections in the room.

Theme TV

Theme TV offers an advanced user interface

that gives your guests the opportunity to

navigate in the guest menu to find their own

country channels, news and hotel information

easily without the need of an interactive

entertainment system.

Pixel Plus HD

Pixel Plus HD is a picture processing

technology that enables viewers to watch

content that is vivid, natural, and real. The

result means superbly life-like pictures with

incredible details and depth from any HD

source.

Connectivity Panel compatible

This TV work seamlessly with Philips

Connectivity Panels. The guest can easily

connect and enjoy media from a PC, MP3

player, DVD player, camcorder and various

other devices. With autosensing the

Connectivity Panel and the TV will

automatically switch to display the content

from the connected guest device.

End-to-end cost optimization

With the Philips Ultimate HD Hospitality TV

you are able to show high definition premium

content to your guest without the need for a

set top box in the room. This TV ensures you

of a end-to-end cost optimized solution as it

includes all necessary HD requirements like

MPEG 4 reception via DVB-T and/or DVB-C

tuner with content protection.

VSecure & VTrack

To show HD premium content to the guest

there is a need for strict content security

precautions from the content industry. Philips

developed a total solution for HD content

security in hotels, consisting of VSecure for

HD content protection and VTrack for HD

forensic watermarking.

Eco-friendly design

Sustainability is integral to the way Philips does

business. Philips TVs are designed and

produced according to our EcoDesign

principles aimed at minimizing overall

environmental impact, through lower power

consumption, removal of hazardous

substances, lower weight, more efficient

packaging and better recyclability. Philips TVs

also have a special housing of flame retardant

material. Independent tests carried out by

emergency fire services have shown that

whereas TVs can sometimes intensify fires

caused by external sources, Philips TVs will not

contribute to the fire.

Issue date 2014-02-12

Version: 1.1.6

12 NC: 8670 000 52827

EAN: 87 12581 48793 5

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

26HFL5870D/10

Specifications

Professional LCD TV

66 cm/26" Ultimate HD LCD, DVB-T/C MPEG4*

Picture/Display

• Diagonal screen size: 26 inch / 66 cm

• Peak Luminance ratio: 100 %

• Aspect ratio: 16:9, Widescreen

• Display screen type: LCD WXGA Active Matrix

TFT

•Panel resolution: 1366 x 768p

• Brightness: 450 cd/m²

• Contrast ratio (typical): 2500:1

• Response time (typical): 6 ms

• Picture enhancement: 3/2 - 2/2 motion pull down,

3D Combfilter, Active Control, Black stretch, Blue

stretch, Color Enhancement, Color Transient

Improvement, Digital Noise Reduction, Luminance

Transient Improver, Motion adaptive de-

interlacing, Progressive scan, Automatic skin tone

correction, Dynamic contrast enhancement,

White stretch, Green stretch, Pixel Plus HD

• Dynamic screen contrast: 30000:1

• Screen enhancement: Anti-Reflection coated

screen

• Viewing angle (H / V): 176 / 176 degree

•Color cabinet: Black

Supported Display Resolution

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

576i 50Hz

576p 50Hz

1080i 50, 60Hz

720p 50, 60Hz

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

1280 x 1024 60Hz

1366 x 768 60Hz

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• Number of Preset Channels: 250

• Tuner bands: Hyperband, S-Channel, UHF, VHF

•Tuner Display: PLL

• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,

SECAM D/K, SECAM L/L', DVB COFDM 2K/8K

• Video Playback: PAL, SECAM, NTSC

• Digital TV: DVB-C MPEG4*, DVB-T MPEG4*

Sound

• Output power (RMS): 2 x 5W

• Sound System: Mono, Stereo, Nicam Stereo, BBE,

Dolby Digital (AC-3), Virtual Dolby Digital

• Sound Enhancement: Auto Volume Leveller,

Incredible Surround, Smart Sound

• Equalizer: 5-bands

Loudspeakers

• Built-in speakers: 2

Connectivity

•Number of Scarts: 2

• Number of HDMI connections: 3

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out

• Ext 3: Audio L/R in, YPbPr

• Ext 4: HDMI v1.3

• Ext 5: HDMI v1.3

•Front / Side connections: Audio L/R in, CVBS in,

Headphone Out, S-video in, USB 2.0, HDMI v1.3

• Other connections: Analog audio Left/Right out, S/

PDIF out (coaxial), Headphone out, PC-In VGA,

Common Interface

• Connectivity Enhancements: Serial Xpress

interface, SmartPlug Xpress Interface, RJ12

connector, RJ45 connector, SmartCard Expansion

Slot, Fast Infrared loop through, HM-Link, External

Loudspeaker connector, Power on scart, USB2.0,

External Power 12V/10W

• EasyLink (HDMI-CEC): One touch play, System

standby

Convenience

• Ease of Installation: Advanced Hotel Mode, Fine

Tuning, PLL Digital Tuning, Program Name,

Cloning of TV settings via USB, Installation menu

locking, Security menu access, Keyboard lock-out

• Ease of Use: Auto Volume Leveller (AVL), 1

channel list analog/digital

• Comfort: Hotel Guest features, Auto power on,

Welcome message, Message indicator, Switch on

channel, Volume limitation

• Interactive hotel features: Connectivity panel

compatible, Block automatic channel update, Block

over-the-air SW download, ThemeTV

•Prison mode: Teletext and MHEG disable

• Clock: Integrated LCD Clock Display, Sleep Timer,

Wake up Clock, Dimmable

• Clock Enhancements: Synchro Time via TXT/DVB

• Teletext: 1000 page Smart Text

• Teletext languages: Western European, Eastern

European, Cyrillic

• Electronic Program Guide: Now + Next EPG

• Screen Format Adjustments: 4:3, Full screen,

Movie expand 14:9, Movie expand 16:9,

Widescreen, Subtitle Zoom, Super Zoom, Auto

Format

• Firmware upgradeable: Remote upgrade hotel TV

softw, Firmware upgradeable via USB, Firmware

upgradeable via RF

• Other convenience: Kensington lock

• Embedded (HD) content security: VSecure,

VTrack

Healthcare

• Control: Multi remote control, Pendant control via

IR-link

• Convenience: Headphone out, Independent main

speaker mute

•Safety: Double isolation Class II

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, JPEG Still pictures,

Slideshow files (.alb)

Power

• Mains power: 220 - 240V, 50/60Hz

• Presence of lead: Yes*

• Mercury content: 46 mg

• Annual energy consumption: 138 kW·h

• Power consumption: 120 W

• Standby power consumption: < 2 W (w. clock)

• Passive stand-by consumption: 1.2 W

• Active stand-by consumption: 20 W

• Ambient temperature: 5 °C to 40 °C

Green Specifications

• Safety: Flame retardant housing

•SmartPower

• Low Power Standby

Dimensions

•Set dimensions (W x H x D): 670 x 459 x 95 mm

• Set dimensions with stand (W x H x D):

670 x 517 x 220 mm

•Box dimensions (W x H x D):

758 x 201 x 573 mm

•Product weight: 6 kg

• Product weight (+stand): 9 kg

• Weight incl. Packaging: 12 kg

• VESA wall mount compatible: 200 x 100 mm

Accessories

• Included accessories: Power cord, Tabletop swivel

stand, Warranty Leaflet

• Optional accessories: Set up Remote RC2573GR,

Guest remote control 22AV1105, Theme TV

remote 22AV1107, Wallmount (tilt) 22AV3200/10

•

* For information on DVB-T enrolled countries please ask your Philips

contact.

* Typical on-mode power consumption measured according to

IEC62087 Ed 2.

* Energy consumption in kWh per year, based on the power

consumption of the television operating 4 hours per day for 365

days. The actual energy consumption will depend on how the

television is used.

* This television contains lead only in certain parts or components

where no technology alternatives exist in accordance with existing

exemption clauses under the RoHS Directive.
