Philips Matchline
widescreen flat TV with
Pixel Plus
76 cm (30")
LCD
Progressive Scan
30PF9975
Best in class picture quality
With latest high definition LCD display
An elegantly designed TV that you can hang on the wall is now a reality. This Flat TV
delivers best-in-class picture quality for your home entertainment set up.
Breathtaking natural pictures
• High-definition LCD WXGA display, 1280 x 768p
• Pixel Plus for detail, depth and clarity
• Digital Natural Motion for smooth moving images
• Progressive Scan component video for optimized image quality
• Active Control with Light Sensor optimizes picture quality
Superb sound reproduction
• Virtual Dolby Surround for a cinema-like audio experience
Multi-purpose convenience
• PC input lets you also use your TV as a PC monitor
• View 2 teletext pages side by side across a widescreen TV
• 1200 page Hypertext for instant fast access to teletext
Issue date 2014-02-05
Version: 6.0.7
12 NC: 8670 000 18579
EAN: 87 10895 76728 6
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
Specifications
30PF9975/12
Widescreen flat TV with Pixel Plus
76 cm (30") LCD, Progressive Scan
Highlights
LCD WXGA display, 1280 x 768p
This WXGA display with state-of-the-art LCD
screen technology gives you HD resolution of 1280
x 768p pixels. It produces brilliant flicker-free
progressive scan pictures with optimum brightness
and superb colors. This vibrant and sharp image will
provide you with an enhanced viewing experience.
Pixel Plus
Pixel Plus is a digital picture processing technology
that increases the number of lines and the number of
pixels. The result is razor sharp pictures with
incredible detail and depth, every time from any
source.
Digital Natural Motion
Philips invented Digital Natural Motion to eliminate
juddering effects that are visible with moving picture
content. Digital Natural Motion estimates motion in
the picture and corrects juddering movements in
both broadcast and recorded movie material (such
as DVD). The resulting smooth motion
reproduction and excellent sharpness take the
viewing experience to a higher level.
Progressive Scan
Progressive Scan doubles the vertical resolution of
the image resulting in a noticeably sharper picture.
Instead of sending a field comprising the odd lines to
the screen first, followed by the field with the even
lines, both fields are written at one time. A full image
is created instantaneously, using the maximum
resolution. At such a speed, your eye perceives a
sharper picture with no line structure.
Active Control + Light Sensor
Active Control is a unique and intelligent way of
optimizing picture quality by measuring and analyzing
the incoming signal to automatically adjust picture
quality settings. Active Control with Light Sensor
uses a sensor to adjust the picture brightness
depending on the room light conditions.
Virtual Dolby Surround
Virtual Dolby Surround is a processing technology
for enhancing surround sound effects. It will create
the sensation of Dolby Pro Logic without the
necessity of additional rear speakers. You become
totally immersed in your television experience.
PC input
With PC input you can connect your TV to a
computer and use the TV as a PC monitor.
Text dual screen
This feature gives you the possibility to watch and
read two pages of teletext information display on the
same channel.
1200 page Hypertext
The teletext is a common system transmitted by
most broadcasters. The 1200 page smart text
feature gives you extremely fast access to
information when changing pages.
Picture/Display
• Aspect ratio: 15:9
• Brightness: 450 cd/m²
• Contrast ratio (typical): 350:1
• Diagonal screen size (inch): 30 inch
• Visible diagonal screen size: 76 cm
• Color cabinet: Precision Silver (10888)
• Display screen type: LCD WXGA Active Matrix
TFT
• Picture enhancement: Active Control + Light
sensor, Comb Filter Digital, Digital Crystal Clear,
Digital Natural Motion, Pixel Plus, Progressive
scan, Smart Picture, Widescreen Plus
• Screen enhancement: Anti ageing circuit, Anti-
Reflection coated screen
• Viewing angle (H / V): 176 / 176 degree
• LCD panel type: 1280 x 768 pixels
• Response time (typical): 16 ms
Sound
• Sound Enhancement: Smart Sound
• Sound System: Virtual Dolby Surround
• Total Sound Power (RMS): 20 W
Loudspeakers
• Built-in speakers: 4
Convenience
• Ease of Installation: Auto Volume Leveler,
Autostore, PLL Digital Tuning, Plug & Play
• Ease of Use: On Screen Display, Top Controls
• Electronic Program Guide: NexTView 3
• Remote control type: RC4301
• Teletext: 1200 page Hypertext
• Teletext enhancements: Habit Watch, Word
Search
• Picture in Picture: Text dual screen
• Remote Control: Multi-functional
• Clock: Sleep Timer, Smart Clock
• Child Protection: Child Lock
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• TV system: PAL, SECAM
• Video Playback: NTSC, PAL, SECAM
• Aerial Input: 75 ohm coaxial (IEC75)
Connectivity
• Ext 1 Scart: CVBS in/out, RGB
• Ext 2 Scart: CVBS in/out, RGB, Y/C
• Ext 3 Scart: CVBS in/out
• Ext 4 Scart: CVBS in/out
• Other connections: Analog audio Left/Right out,
Antenna IEC75, Centre Speaker connection in,
Component Video (YPbPr) input, PC-in VGA +
Audio L/R in
• Side: CVBS in, Headphones out, S-Video Y/C
• Connectivity Enhancements: Cinema Link
Power
• Power consumption: 160 W
• Standby power consumption: 2
• Mains power: AC 198V - 264V 50/60 Hz
Dimensions
• Weight incl. Packaging: 23 kg
•Box dimensions (W x H x D):
1000 x 660 x 250 mm
• Set dimensions (W x H x D): 891 x 490 x 110 mm
• Set weight: 18 kg
Accessories
• Included accessories: Scart to RCA adapter cable 3
x, Table top stand, Wall mounting bracket
• Optional accessories: Floor stand
•
