Philips

LCD TV with Digital

Crystal Clear

81cm/32"

digital TV

32PFL3506

Affordable performance

Great picture, great sound, great design

Regardless of what you are watching - experience great picture and sound performance

with your Philips TV. A functional design makes this TV the perfect choice for any room

of your house.

See brilliant picture quality

• Digital Crystal Clear for detail depth and clarity

• HD LCD display, with a 1366 x 768p resolution

Easy to connect and enjoy

• 3 HDMI inputs with Easylink for HD connection

• PC input (HDMI)

Hear crisp and clear sound

• Dolby Digital output for connection to a home theatre system

• Incredible Surround for enhanced audio enjoyment

32PFL3506/F7

Highlights

LCD TV with Digital Crystal Clear

81cm/32" digital TV

LCD display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

Incredible Surround

Incredible Surround is an audio technology

from Philips that dramatically magnifies the

sound field to immerse you in the audio. Using

state-of-the-art electronic phase shifting,

Incredible Surround mixes sounds from left

and right in such a way that it expands the

virtual distance between the two speakers.

This wider spread greatly enhances the stereo

effect and creates a more natural sound

dimension. Incredible Surround allows you to

experience total surround with greater depth

and width of sound, without the use of

additional speakers.

3 HDMI inputs with EasyLink

EasyLink uses the HDMI CEC industry

standard protocol to share functionality

between connected devices and the TV. With

Easylink only one remote control is needed to

operate main functionalities on your TV and

connected devices. HDMI makes an

uncompressed digital RGB connection from

the source to the screen for the ultimate

picture quality. HDMI uses HDCP copy

protection. With 2 HDMI input on the back

and 1 HDMI on the side of the TV you can

connect multiple HD sources, for instance an

HD settop box, a Blu-ray player, and Game

Console or Digital Camcorder.

PC input (HDMI)

With PC input you can use your TV as a PC

monitor via a HDMI-DVI cable/converter.

Digital Crystal Clear

Digital Crystal Clear is a package of picture

innovations that digitally adjusts and optimizes

picture quality to optimal contrast, color and

sharpness levels. It's like watching vivid cinema-

like images.

Issue date 2014-03-14

Version: 3.6.3

12 NC: 8670 000 70395

UPC: 6 09585 20159 0

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

32PFL3506/F7

Specifications

LCD TV with Digital Crystal Clear

81cm/32" digital TV

Picture/Display

• Aspect ratio: Widescreen

• Panel resolution: 1366 x 768p

• Brightness: 380 cd/m²

• Contrast ratio (typical): 1100:1

• Dynamic screen contrast: 10,000:1

• Response time (typical): 8 ms

• Diagonal screen size: 32 inch / 81 cm

• Visible screen diagonal (inch): 31.5 inch

• Viewing angle: 170º (H) / 170º (V)

• Picture enhancement: Pixel Plus HD, 3/2 - 2/2

motion pull down, 3D Combfilter, Digital Noise

Reduction, Dynamic contrast enhancement,

Progressive scan

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

720 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

1280 x 768 60Hz

1360 x 768 60Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

720p 60Hz

1080i 60Hz

1080p 60Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 2 x 10W

• Sound Enhancement: Incredible Surround

• Sound System: Dolby Digital (AC-3), Stereo, SAP

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Installation: Autostore

• Ease of Use: Auto Volume Leveller (AVL),

AutoPicture, AutoSound, Settings assistant

Wizard, Side Control

• Remote Control: TV

• Screen Format Adjustments: 4:3, 16:9, Normal,

Zoom, Full, Movie Expand, Wide, unscaled (dot by

dot)

Tuner/Reception/Transmission

• Aerial Input: 75 ohm F-type

• TV system: ATSC, NTSC

•Video Playback: NTSC

• Tuner bands: UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, S-Video, CVBS in

• HDMI 1: HDMI, Analog audio L/R in

•HDMI 2: HDMI

•HDMI 3: HDMI

• Audio Output - Digital: Coaxial (cinch)

• Other connections: Analog audio Left/Right out

• USB: USB

• EasyLink (HDMI-CEC): One touch play, Power

status, System info (menu language), System audio

control, System standby

Power

• Mains power: 120V/60Hz

• Power consumption: 130 W

• Standby power consumption: < 0.5 W

• Ambient temperature: 5°C to 35°C (41°F to 95°F)

Dimensions

• Set dimensions in inch (W x H x D):

30.65 x 20.25 x 3.74 inch

•Set dimensions with stand in inch (W x H x D):

30.65 x 21.92 x 7.44 inch

• Product weight (lb): 17.31 lb

• Product weight (+stand) (lb): 18.19 lb

• Box dimensions in inch (W x H x D):

37.60 x 24.37 x 6.38 inch

• Weight incl. Packaging (lb): 23.81 lb

• VESA wall mount compatible: 200 x 200 mm

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, User Manual, Registration card,

Remote Control, Batteries for remote control

•
