Philips

LED TV with Pixel Plus HD

81 cm (32")

Full HD 1080p

digital TV

32PFL5605H

Entertainment comes to life

with brilliant LED picture performance

Great LCD picture quality on an ultra thin 81 cm (32") screen - the Philips 5000 Series

32PFL5605H LED TV. Live the moment as if you were there with Pixel Plus HD and an

impressive invisible sound.

High definition giving you brilliant detail

• Full HD TV with Pixel Plus HD for better details and clarity

• Brilliant LED images with low power consumption

• 100Hz LCD, 2ms performance for superb motion sharpness

• HD Natural Motion for ultra smooth motion in Full HD movies

Rich and clear sound.

• 2.1 system 40 W surround sound (2 x 10 W RMS, virtual 20 W)*

• Hear every word with Clear Sound

Complete digital connectivity made simple

• Seamless connectivity with 3 HDMI inputs and Easylink

• USB for fantastic multimedia playback

• Integrated MPEG-4 tuner for HD reception without set top box

Greener every day

• LED TVs up to 40% more energy efficient than normal LCD TVs

• 0W Power Consumption when switch off

32PFL5605H/12

Highlights

LED TV with Pixel Plus HD

81 cm (32") Full HD 1080p, digital TV

Pixel Plus HD

Pixel Plus HD offers the unique combination of

ultimate sharpness, natural detail, vivid colors,

and smooth natural motion. Artifacts and noise

in any sources from multimedia to standard

definition TV and also in highly compressed

HD are detected and reduced, ensuring that

the picture is clear and razor-sharp.

LED

The most advanced LED lighting technology in

this TV combines an eye-catching minimalistic

design with stunning image quality as well as

the lowest power consumption in its category.

On top of that, LED lighting technology does

not contain any hazardous materials. Thus,

with LED backlight you can enjoy low power

consumption, high brightness, incredible

contrast, sharpness and vibrant colors.

100Hz LCD, 2ms response time

100Hz LCD creates extreme motion

sharpness. The Double Frame Rate Insertion

increases the sharpness of motion

reproduction to more than twice that of

conventional LCD, resulting in a performance

with a response time of 2 milliseconds. Now

you can enjoy clear images even with fast on-

screen motion.

HD Natural Motion

Philips invented HD Natural Motion to

minimize juddering effects that are visible with

movie based picture content. The award

winning algorithm estimates motion in the

picture and corrects juddering movements in

both broadcast and recorded movie material

(such as DVD and Blu-ray Disc). The resulting

smooth motion reproduction and excellent

sharpness take the viewing experience to a

higher level.

2.1 sound system 40 W*

Virtual 2.1 speaker system for an incredible

40W sound (2x10W + 20W Virtual Power*).

*This virtual 2.1 speaker system manages

power intelligently to deliver twice the original

power supplied and produces an excellent

bass. Enjoy the purity and detailed sound with

the additional dome tweeter which delivers

uncompromised sound in a slim invisible

speaker design.

USB (multimedia)

The USB connector allows access to jpeg

photos, mp3 music and video files of most

USB-sticks (USB memory-class device). Plug

the USB into the slot at the side of the TV and

access the multimedia content using the easy

on screen content browser. You can now view

and share your videos, photos and music.

Integrated DVB tuner MPEG-4

The integrated digital tuner lets you receive

digital cable and terrestrial TV without an

additional set top box. Enjoy quality TV clutter

free.

Zero watt power consumption

Enjoy savings on your electricity bill by using

the build-in power switch on this TV. This

leads to no power consumption, without

having to unplug the power cord from the wall.

Matching home theatre experience

Take your home cinema experience to

the next level with Philips SoundHub

home theatre 5000 series. Bring every

detail to life, and experience fully

immersive, crystal clear surround sound.

Enquire more about this unique

combination today at www.philips.com

Philips Green Logo

Philips Green Products can reduce costs,

energy consumption and CO2 emissions.

How? They offer a significant

environmental improvement in one or

more of the Philips Green Focal Areas –

Energy efficiency, Packaging, Hazardous

substances, Weight, Recycling and

disposal and Lifetime reliability.

x3

Issue date 2015-08-18

Version: 8.14.9

12 NC: 8670 000 59438

EAN: 87 12581 52146 2

© 2015 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

32PFL5605H/12

Specifications

LED TV with Pixel Plus HD

81 cm (32") Full HD 1080p, digital TV

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 450 cd/m²

• Dynamic screen contrast: 500,000:1

• Response time (typical): 2 ms

• Viewing angle: 176º (H) / 176º (V)

• Diagonal screen size: 32 inch / 81 cm

• Display: LCD Full HD, direct LED backlight

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus HD, Active

Control + Light sensor, Color Enhancement,

100Hz Clear LCD, Digital Noise Reduction,

Dynamic contrast enhancement, Luminance

Transient Improver, MPEG artifact reduction, 2D/

3D noise reduction, 1080p 24/25/30Hz processing,

1080p 50/60Hz processing, HD Natural Motion,

LED backlight Display

• Screen enhancement: Anti-Reflection coated

screen

• Peak Luminance ratio: 65 %

• Color cabinet: High gloss black deco front with

black cabinet

Supported Display Resolution

• Computer inputs: up to 1920x1080 @ 60Hz

• Video inputs: up to 1920x1080p, 24, 25, 30, 50, 60

Hz

Sound

• Output power (RMS): 40W virtual, Invisible Sound

• Sound Enhancement: Auto Volume Leveller,

Incredible Surround, Treble and Bass Control,

Clear Sound

• Sound System: Mono, Nicam Stereo, Stereo

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Connection Enhancement: Easy link

• Ease of Installation: Channel installation wizard,

Settings assistant wizard, Device connection

wizard, Auto detect Philips devices, Auto Program

Naming, Autoinstall, Program Name, Sorting

• Ease of Use: Smart Picture, Smart Sound,

Onscreen Usermanual, EasyLink, Favorite program

selection, Mozaïc channel grid, One-stop

experience button, One-stop Home button

• Electronic Program Guide: Now + Next EPG*

• Screen Format Adjustments: Auto Format, Super

Zoom, Movie expand 16:9, Widescreen, unscaled

(1080p dot by dot)

• Teletext: 1200 page Hypertext

• Firmware upgradeable: Firmware auto upgrade

wizard, Firmware upgradeable via USB

• Multimedia: USB autobreak-in, USB media browser

Multimedia Applications

• Multimedia connections: USB memory class device

• Picture Playback Formats: JPEG

• Music Playback Formats: MP3

• Video Playback Formats: Codec support:, H264/

MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,

SECAM D/K, SECAM L/L', DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Digital TV: DVB Terrestrial *, DVB-T MPEG4*,

DVB-C MPEG4*

•Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in, RGB

• Ext 2: YPbPr in, Audio L/R in

• VGA-in: PC input, D-sub 15

•HDMI 1: HDMI v1.4 (Audio Return Ch.)

•HDMI 2: HDMI v1.3

•Front / Side connections: HDMI v1.3, USB

•Other connections: Headphone out, Common

Interface Plus (CI+)

• EasyLink (HDMI-CEC): One touch play, EasyLink,

Pixel Plus link (Philips), Remote control pass-

through, System audio control, System standby

• Audio Output - Digital: Coaxial (cinch)

• Summary: 3x HDMI, 1x USB, 1x SCART

Power

• Green label: ECO label certified

• Ambient temperature: 5 °C to 35 °C

• Mains power: 220-240V~; 50-60Hz

• Power consumption (typical): 71 W

• Standby power consumption: < 0.15 W

• Off mode power consumption: < 0.01 W

• Annual energy consumption: 103.66 kW·h

• Presence of lead: Yes*

• Power Saving Features: 0 Watt Power-off switch,

Light sensor, Eco mode

Dimensions

•Set dimensions (W x H x D):

790 x 501.3 x 92 mm

• Set dimensions with stand (W x H x D):

790 x 542.4 x 221.4 mm

• Weight incl. Packaging: 13.5 kg

• Product weight: 10 kg

• Product weight (+stand): 11.5 kg

•Box dimensions (W x H x D):

968 x 585 x 198 mm

• VESA wall mount compatible: 200 x 200 mm

Accessories

• Included accessories: Table top stand, Quick start

guide, Registration card, Warranty Leaflet, Remote

Control, 2 x AAA Batteries, Safety/legal

instructions, Software declaration

•

* 8 days EPG, service not available in all countries

* The TV supports DVB reception for 'Free to air' broadcast. Specific

DVB operators may not be supported. An up to date list can be

found in the FAQ section of the Philips support website. For some

operators Conditional Access and subscripction are required.

Contact your operator for more information.

* Typical on-mode power consumption measured according to

IEC62087 Ed 2.

* Energy consumption in kWh per year, based on the power

consumption of the television operating 4 hours per day for 365

days. The actual energy consumption will depend on how the

television is used.

* This television contains lead only in certain parts or components

where no technology alternatives exist in accordance with existing

exemption clauses under the RoHS Directive.

REAR CONNECTORS

BOTTOM REAR CONNECTORS

SIDE CONNECTORS
