Philips

Flat TV with Pixel Plus

81 cm (32")

LCD HD Ready

32PF7320

Turn up your viewing experience

with Pixel Plus

Experience the superior picture quality of this excellent Flat TV with the latest LCD

technology and Pixel Plus. It's packed into a stunning design that will complement your

interior.

Breathtaking natural pictures

• HD LCD WXGA display, with a 1366 x 768p resolution

• HD Ready for the highest quality display of HD signals

• Pixel Plus for detail, depth and clarity

• 3D combfilter separates colors for a razor-sharp image

Superb sound reproduction

• Virtual Dolby Surround for a cinema-like audio experience

Slim, stylish design to complement your interior

• Compact and slim design that fits in every room

Multi-purpose convenience

• View PC content in a second window on your TV

• PC input lets you also use your TV as a PC monitor

Leading interface for digital quality audio/video

• DVI-I provides the best picture and flexible connectivity

32PF7320/10

Highlights

Flat TV with Pixel Plus

81 cm (32") LCD HD Ready

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

HD Ready

Enjoy the exceptional picture quality of High

Definition pictures and be fully prepared for

HD sources like HDTV settop box or Blu-ray

disc. HD Ready is a protected label that offers

picture quality beyond that of progressive scan.

It conforms to strict standards laid out by

EICTA to offer a HD screen that displays the

benefits of resolution and picture quality of a

High Definition signal. It has a universal

connection for both analog YPbPr and

uncompressed Digital connection of DVI or

HDMI, supporting HDCP. It can display 720p,

and 1080i signals at 50 and 60Hz.

Pixel Plus

Pixel Plus is a digital picture processing

technology that increases the number of lines

and the number of pixels. The result is razor

sharp pictures with incredible detail and depth,

every time from any source.

3D Combfilter

The 3D comb filter separates brightness and

color signals better in 3D domain to eliminate

cross-color, cross-luminance and dot-crawl

distortion - all of which detract from your

viewing pleasure. The 3D digital comb filter

performs field-by-field comparisons of the

television image to accurately separate the

color from the black-and-white information

and remove both horizontally and vertically

hanging dots, as well as dot crawl. The result is

a razor sharp image.

Virtual Dolby Surround

Virtual Dolby Surround is a processing

technology for enhancing surround sound

effects. It will create the sensation of Dolby

Pro Logic without the necessity of additional

rear speakers. You become totally immersed

in your television experience.

Compact and slim design

This design style emphasizes a slim, compact

look that saves space and fits in anywhere.

Picture in Graphics

Picture-in-Graphics is a small window in the

main picture, allowing to watch data/graphics

in your main TV screen. It provides the ability

to simultaneously watch data/graphics and the

TV.

PC input

With PC input you can connect your TV to a

computer and use the TV as a PC monitor.

DVI-I Input

A DVI-I input connects the non-compressed

high-bandwidth digital RGB signal from source

to screen. By eliminating the conversion of the

digital signals to analog, it delivers an

unblemished and noisefree image, that is clear

and flickerfree. The DVI input supports HDCP

copy protection that allows viewing of copy

protected programs from Digital Settop boxes,

DVD players and HD recorders. DVI-I is

future proof as it can be be connected to all

HDMI devices (a converter cable is required).

The DVI-I input also supports analog PC-VGA

signals.

Issue date 2012-01-20

Version: 7.0.12

12 NC: 8670 000 21913

EAN: 87 10895 89259 9

© 2012 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

32PF7320/10

Specifications

Flat TV with Pixel Plus

81 cm (32") LCD HD Ready

Picture/Display

• Aspect ratio: 16:9, Widescreen

• Brightness: 500 cd/m²

• Contrast ratio (typical): 600:1

• Diagonal screen size: 32 inch / 80 cm

• Display screen type: LCD WXGA Active Matrix

TFT

•Color cabinet: Silver Frost

• Picture enhancement: Pixel Plus, Digital Crystal

Clear, Contrast Plus, Progressive scan, 3D

Combfilter, Active Control + Light sensor, 3/2 - 2/

2 motion pull down, Digital Noise Reduction,

Jagged Line Suppression, Luminance Transient

Improver

• Screen enhancement: Anti-Reflection coated

screen

• Viewing angle (H / V): 176 / 176 degree

• Panel resolution: 1366 x 768p

• Response time (typical): 8 ms

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60, 67, 72, 75Hz

800 x 600 56, 60, 72, 75Hz

1024 x 768 60, 70, 75Hz

•Video Formats

Resolution Refresh rate

640 x 480i 1Fh

640 x 480p 2Fh

720 x 576i 1Fh

720 x 576p 2Fh

1280 x 720p 3Fh

1920 x 1080i 2Fh

Sound

• Sound Enhancement: Dynamic Bass Enhancement

• Sound System: Virtual Dolby Surround, Stereo

• Output power (RMS): 2 x 15 W

• Equalizer: 5-bands

Convenience

• Ease of Installation: Auto Program Naming,

Automatic Channel Install(ACI), Automatic Tuning

System (ATS), Autostore, Fine Tuning, Plug & Play,

Program Name, Sorting

• Ease of Use: Auto Volume Leveller (AVL),

Graphical User Interface, Program List, Smart

Picture, Smart Sound

• Remote control type: RCFE05SPS00

• Teletext: 10 page Smart Text

• Teletext enhancements: Program information Line

• Picture in Picture: Picture in graphics, Twin page

text

•Remote Control: Amp, DVD, TV, Multi-functional

• Screen Format Adjustments: 4:3, Movie expand

14:9, Movie expand 16:9, Subtitle Zoom, Super

Zoom, Widescreen

• Clock: Sleep Timer

• VESA Mount: 200 x 100 mm

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• TV system: PAL, SECAM

• Video Playback: NTSC, PAL, SECAM

• Aerial Input: 75 ohm coaxial (IEC75)

•Tuner Display: PLL

• Number of Preset Channels: 100

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out, S-video in

• Other connections: Antenna IEC75

•Front / Side connections: CVBS in, Headphone

Out, S-video in, Audio L/R in

• AV 3: DVI-I with HDCP, Audio-in mini jack 3.5mm

•Number of Scarts: 2

Power

• Power consumption: 120 W Normal Operation W

• Standby power consumption: 1 W <

• Ambient temperature: 5 °C to 40 °C

Dimensions

• Product weight: 18.2 kg

• Weight incl. Packaging: 22 kg

• Dimensions (with base) (W x H x D):

924 x 550 x 222 mm

• Set dimensions (W x H x D): 924 x 511 x 118 mm

•Box dimensions (W x H x D):

1000 x 690 x 240 mm

Accessories

• Included accessories: Power cord, Quick start

guide, Registration card, Remote Control, User

Manual, Batteries for remote control, Table top

stand, DVI-I to YPbPr cable

Loudspeakers

• Built-in speakers: 2

•
