Philips

widescreen flat TV with

Pixel Plus

94 cm (37")

LCD

HD Ready

37PF7321

Turn up your viewing experience

with Pixel Plus

Experience the superior picture quality of this excellent Flat TV with the latest LCD

technology and Pixel Plus. It's packed into a stunning design that will complement your

interior.

Breathtaking natural pictures

• HD LCD WXGA display, with a 1366 x 768p resolution

• HD Ready for the highest quality display of HD signals

• Pixel Plus for detail, depth and clarity

• Dynamic contrast enhancer delivering rich black details

• 3D combfilter separates colors for a razor-sharp image

Superb sound reproduction

• Virtual Dolby Surround for a cinema-like audio experience

Slim, stylish design to complement your interior

• Compact and slim design that fits in every room

Designed for your convenience

• View PC content in a second window on your TV

For advanced performance

• HDMI input for full digital HD connection in one cable

37PF7321/79

Highlights

Widescreen flat TV with Pixel Plus

94 cm (37") LCD, HD Ready

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

HD Ready

Enjoy the exceptional picture quality of High

Definition pictures and be fully prepared for

HD sources like HDTV settop box or Blu-ray

disc. HD Ready is a protected label that offers

picture quality beyond that of progressive scan.

It conforms to strict standards laid out by

EICTA to offer a HD screen that displays the

benefits of resolution and picture quality of a

High Definition signal. It has a universal

connection for both analog YPbPr and

uncompressed Digital connection of DVI or

HDMI, supporting HDCP. It can display 720p,

and 1080i signals at 50 and 60Hz.

Pixel Plus

Pixel Plus is a digital picture processing

technology that increases the number of lines

and the number of pixels. The result is razor

sharp pictures with incredible detail and depth,

every time from any source.

Dynamic contrast enhancer

You want the LCD flat display with the highest

contrast and most vibrant images even at wide

viewing angle. The Philips dynamic contrast

enhancer uses video processing and unique

dimming backlight technology. This delivers

deep rich black levels with increased detail.

The dimming backlight increases the contrast

up to 5 times*, and at the same time improves

the viewing angle. It gives a bright, lifelike

picture with high contrast and vibrant colors,

(* factor between 2 and 5, screen type and

picture content dependant).

3D Combfilter

The 3D comb filter separates brightness and

color signals better in 3D domain to eliminate

cross-color, cross-luminance and dot-crawl

distortion - all of which detract from your

viewing pleasure. The 3D digital comb filter

performs field-by-field comparisons of the

television image to accurately separate the

color from the black-and-white information

and remove both horizontally and vertically

hanging dots, as well as dot crawl. The result is

a razor sharp image.

Virtual Dolby Surround

Virtual Dolby Surround is a processing

technology for enhancing surround sound

effects. It will create the sensation of Dolby

Pro Logic without the necessity of additional

rear speakers. You become totally immersed

in your television experience.

Compact and slim design

This design style emphasizes a slim, compact

look that saves space and fits in anywhere.

Picture in Graphics

Picture-in-Graphics is a small window in the

main picture, allowing to watch data/graphics

in your main TV screen. It provides the ability

to simultaneously watch data/graphics and the

TV.

HDMI input

HDMI makes an uncompressed digital RGB

connection from the source to the screen. By

eliminating conversion to an analog signal, it

delivers an unblemished image. The non-

degraded signal reduces flicker and leads to a

clearer picture. HDMI intelligently

communicates the highest output resolution

with the source device. The HDMI input is fully

backward compatible with DVI sources but

includes digital audio. HDMI uses HDCP copy

protection.

Issue date 2014-02-10

Version: 8.0.11

12 NC: 8670 000 24122

EAN: 87 10895 97169 0

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

37PF7321/79

Specifications

Widescreen flat TV with Pixel Plus

94 cm (37") LCD, HD Ready

Picture/Display

• Aspect ratio: 16:9

• Brightness: 500 cd/m²

• Diagonal screen size: 37 inch / 94 cm

• Display screen type: LCD WXGA Active Matrix

TFT

•Picture enhancement: Progressive scan, 3/2 - 2/2

motion pull down, 3D Combfilter, Contrast Plus,

Digital Noise Reduction, Dynamic contrast, Jagged

Line Suppression, Active Control, Luminance

Transient Improver, Pixel Plus

• Color cabinet: Silver Frost Bi-Color with

Tempered Glass Deco Front

• Screen enhancement: Anti-Reflection coated

screen

• Viewing angle (H / V): 176 / 176 degree

• Panel resolution: 1366 x 768p

• Response time (typical): 8 ms

• Dynamic screen contrast: 2400:1

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60, 67, 72, 75Hz

800 x 600 56, 60, 72, 75Hz

1024 x 768 60, 70, 75Hz

•Video Formats

Resolution Refresh rate

640 x 480p 2Fh

720 x 576p 2Fh

1280 x 720p 3Fh

1920 x 1080i 2Fh

Sound

• Sound System: Virtual Dolby Surround

• Output power (RMS): 2 x 15W

• Sound Enhancement: Dynamic Bass Enhancement

• Equalizer: 5-bands

Loudspeakers

• Built-in speakers: 4

• Loudspeaker types: Dome tweeter

Convenience

• Ease of Installation: Autostore, Auto Program

Naming, Fine Tuning, Program Name, Sorting

• Ease of Use: Side Control, Smart Picture, Program

List, Smart Sound

• Remote control type: RCFE06FRS00

• Picture in Picture: Picture in graphics, Twin page

text

•Remote Control: DVD, Multi-functional, TV

• Screen Format Adjustments: 4:3, Subtitle Zoom,

Super Zoom, Widescreen, Movie expand 14:9,

Movie expand 16:9

• Clock: Sleep Timer, Wake up Clock

• Child Protection: Child Lock

• Teletext enhancements: 4 favourite pages,

Program information Line

• VESA Mount: 800 x 400 mm

• Teletext: 10 page Smart Text

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• TV system: PAL, SECAM

• Video Playback: NTSC, PAL, SECAM

• Aerial Input: 75 ohm coaxial (IEC75)

• Number of Preset Channels: 100

•Tuner Display: PLL

Connectivity

• AV 1: Audio L/R in, YPbPr (2fh)

• AV 2: Audio L/R in, CVBS

• AV 3: VGA PC-in, Audio L/R in, YPbPr (2Fh)

•AV 4: HDMI

•Front / Side connections: Audio L/R in, CVBS in,

Headphone Out, S-video in

•AV 5: HDMI

• Number of AV connections: 5

• Other connections: Antenna IEC75

Power

• Power consumption: 110 W Normal Operation W

• Standby power consumption: < 1 W

• Mains power: AC 220 - 240 V +/- 10%

• Ambient temperature: 5 °C to 40 °C

Dimensions

• Product weight: 25.9 kg

• Weight incl. Packaging: 33 kg

•Set dimensions (W x H x D):

1114 x 618 x 103 mm

• Dimensions (with base) (W x H x D):

1114 x 657 x 306 mm

•Box dimensions (W x H x D):

1191 x 830 x 330 mm

• VESA wall mount compatible: 0

Accessories

• Included accessories: Table top stand, Wall

mounting bracket, Power cord, Quick start guide,

Remote Control, User Manual, Warranty

certificate, Batteries for remote control

• Optional accessories: Floor stand

•
