Philips

LCD TV with Digital

Crystal Clear

94 cm (37")

integrated digital

37PFL3403D

Clearly the smart choice

Designed for ease of use, this Flat TV features modern design, 3 HDMI connections, a

powerful 768p, 50Hz display and brilliant Digital Crystal Clear engine. Making the smart

choice in total picture quality has never been easier.

Superb picture quality

• Digital Crystal Clear for detail depth and clarity

• HD LCD display, with a 1366 x 768p resolution

• 28.9 billion colors for brilliant natural images

• Dynamic contrast 24000:1 for incredible rich black details

Crisp and Clear sound

• Virtual Dolby Digital for a true life audio experience

• BBE for superior sound clarity

• 2 x 15W RMS audio power

Connect, install and enjoy

• Enjoy photo and music playback via USB

• 3 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV & connected device via HDMI CEC

Ready for digital

• Integrated Digital Tuner for DVB-T reception

37PFL3403D/12

Highlights

LCD TV with Digital Crystal Clear

94 cm (37") integrated digital

Digital Crystal Clear

Digital Crystal Clear is a package of picture

innovations that digitally adjusts and optimizes

picture quality to optimal contrast, color and

sharpness levels. It's like watching vivid cinema-

like images.

LCD display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

Integrated Digital DVB-T tuner

The integrated Digital DVB-T tuner lets you

receive digital terrestrial TV without an

additional set top box. Enjoy quality TV clutter

free.

Virtual Dolby Digital

Virtual Dolby Digital is a processing technology

for enhancing surround sound effects. It will

create the sensation of Dolby Pro Logic

without the necessity of additional rear

speakers. You become totally immersed in

your television experience.

USB for photo & music playback

The USB connector allows access to jpeg

photos and mp3 music of most USB-sticks

(USB memory-class device). Plug the USB into

the slot at the side of the TV and access the

multimedia content using the easy on screen

content browser. You can now view and share

your photos and music.

3 HDMI inputs

HDMI makes an uncompressed digital RGB

connection from the source to the screen for

the ultimate picture quality. HDMI intelligently

communicates the highest output resolution

with the source device. The HDMI input is fully

backward compatible with DVI sources and

includes digital audio. HDMI uses HDCP copy

protection. With 2 HDMI inputs on the back

and 1 HDMI on the side of the TV you can

connect multiple HD sources, for instance an

HD settop box, a Blu-ray player, and game

console or digital Camcorder. Your TV is fully

prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry

standard protocol to share functionality

between connected devices and the TV. With

EasyLink only one remote control is needed to

operate main functionalities on your TV and

connected devices. EasyLink uses the standard

HDMI cable to transfer system commands. It

works between all electronic devices equipped

with HDMI CEC.

28.9 billion colours

Issue date 2015-08-18

Version: 2.0.10

12 NC: 8670 000 38261

EAN: 87 12581 40529 8

© 2015 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

AUDIO OUT

SERV. U

SPDIF

OUT

L

R

AUDIO IN

HDMI 1

AUDIO IN:

LEFT / RIGHT

HDMI 1 / DVI

HDMI 2 / DVI

EXT 2

(RGB/CVBS)

EXT 3 EXT 1

(RGB/CVBS)

HDMI 2

L

Pr

Pb

Y

R

TV ANTENNA

75X

37PFL3403D/12

Specifications

LCD TV with Digital Crystal Clear

94 cm (37") integrated digital

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 24000:1

• Response time (typical): 6 ms

• Viewing angle: 176º (H) / 176º (V)

• Diagonal screen size: 37 inch / 94 cm

• Display screen type: LCD WXGA Active Matrix

TFT

•Panel resolution: 1366 x 768p

• Picture enhancement: 3/2 - 2/2 motion pull down,

3D Combfilter, Active Control, Color Transient

Improvement, Digital Crystal Clear, Digital Noise

Reduction, Dynamic contrast enhancement,

Luminance Transient Improver

• Screen enhancement: Anti-Reflection coated

screen

• Color cabinet: High gloss black deco front with

black cabinet

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60, 72, 75, 85Hz

800 x 600 60, 72, 75, 85Hz

1024 x 768 60, 70, 75, 85Hz

Via HDMI/DVI

input

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

576i 50Hz

576p 50Hz

720p 50, 60Hz

1080i 50, 60Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 2 x 15W

• Sound Enhancement: Auto Volume Leveller,

Graphic Equaliser

• Sound System: Nicam Stereo, Virtual Dolby Digital,

BBE

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer, Wake up Clock

• Ease of Installation: Auto Program Naming,

Automatic Channel Install(ACI), Automatic Tuning

System (ATS), Autostore, Fine Tuning, PLL Digital

Tuning, Plug & Play

• Ease of Use: 4 favorite lists, Auto Volume Leveller

(AVL), Delta Volume per preset, Graphical User

Interface, On Screen Display, Program List,

Settings assistant Wizard, Side Control

• Electronic Program Guide: Now + Next EPG, 8

day Electronic Program Guide

• Picture in Picture: Text dual screen

• Remote Control: TV

• Remote control type: RCPF05E08B

• Screen Format Adjustments: 4:3, Auto Format,

Movie expand 14:9, Movie expand 16:9, Subtitle

Zoom, Super Zoom, Widescreen

• Teletext: 1000 page Hypertext

• Teletext enhancements: 4 favourite pages,

Program information Line

• Smart mode: Movie, Standard, Vivid

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, Slideshow files (.alb), JPEG

Still pictures

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,

SECAM D/K, SECAM L/L', DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Digital TV: DVB Terrestrial *

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out, RGB

• Ext 3: YPbPr, Audio L/R in

•HDMI 1: HDMI v1.3

•HDMI 2: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System

standby

• Front / Side connections: HDMI v1.3, S-video in,

CVBS in, Audio L/R in, Headphone Out, USB

• Other connections: Analog audio Left/Right out,

PC Audio in, S/PDIF out (coaxial), Common

Interface

Power

• Ambient temperature: 5 °C to 35 °C

• Mains power: 220 - 240V, 50/60Hz

• Power consumption: 170 W

• Standby power consumption: 0.15 W

Dimensions

•Set dimensions (W x H x D): 930 x 611 x 99 mm

• Set dimensions with stand (W x H x D):

930 x 665 x 252 mm

• Weight incl. Packaging: 28 kg

• Product weight: 17.7 kg

• Product weight (+stand): 22.5 kg

•Box dimensions (W x H x D):

1137 x 690 x 278 mm

• VESA wall mount compatible: 300 x 300 mm

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, User Manual, Warranty

certificate, Remote Control, Batteries for remote

control

•
