Philips 5000 series

LCD TV with Pixel Plus

HD

107cm (42")

Full HD 1080p digital TV

42PFL5405H

Entertainment comes to life

With true to life FHD picture performance

Live the moment as if you were there with Pixel Plus HD and an impressive invisible

sound.

High definition giving you brilliant detail

• Full HD TV with Pixel Plus HD for better details and clarity

• 100Hz LCD, 2ms performance for superb motion sharpness

• HD Natural Motion for ultra smooth motion in Full HD movies

Rich and clear sound.

• 2.1 system 40 W surround sound (2 x 10 W RMS, virtual 20 W)*

• Hear every word with Clear Sound

Complete digital connectivity made simple

• Seamless connectivity with 3 HDMI inputs and Easylink

• USB for fantastic multimedia playback

• PC-input allows you to use your TV as a PC monitor

• Integrated MPEG-4 tuner for HD reception without set top box

Greener every day

• 0W Power Consumption when switch off

42PFL5405H/12

Highlights

LCD TV with Pixel Plus HD

107cm (42") Full HD 1080p digital TV

Pixel Plus HD

Pixel Plus HD offers the unique combination of

ultimate sharpness, natural detail, vivid colors,

and smooth natural motion. Artifacts and noise

in any sources from multimedia to standard

definition TV and also in highly compressed

HD are detected and reduced, ensuring that

the picture is clear and razor-sharp.

100Hz LCD, 2ms response time

100Hz LCD creates extreme motion

sharpness. The Double Frame Rate Insertion

increases the sharpness of motion

reproduction to more than twice that of

conventional LCD, resulting in a performance

with a response time of 2 milliseconds. Now

you can enjoy clear images even with fast on-

screen motion.

HD Natural Motion

Philips invented HD Natural Motion to

minimize juddering effects that are visible with

movie based picture content. The award

winning algorithm estimates motion in the

picture and corrects juddering movements in

both broadcast and recorded movie material

(such as DVD and Blu-ray Disc). The resulting

smooth motion reproduction and excellent

sharpness take the viewing experience to a

higher level.

2.1 sound system 40 W*

Virtual 2.1 speaker system for an incredible

40W sound (2x10W + 20W Virtual Power*).

*This virtual 2.1 speaker system manages

power intelligently to deliver twice the original

power supplied and produces an excellent

bass. Enjoy the purity and detailed sound with

the additional dome tweeter which delivers

uncompromised sound in a slim invisible

speaker design.

USB (multimedia)

The USB connector allows access to jpeg

photos, mp3 music and video files of most

USB-sticks (USB memory-class device). Plug

the USB into the slot at the side of the TV and

access the multimedia content using the easy

on screen content browser. You can now view

and share your videos, photos and music.

PC input (VGA)

With PC input you can connect your TV to a

computer by a VGA cable and use the TV as a

PC monitor.

Integrated DVB tuner MPEG-4

The integrated digital tuner lets you receive

digital cable and terrestrial TV without an

additional set top box. Enjoy quality TV clutter

free.

3 HDMI inputs with Easylink

HDMI is a single cable to carry both picture

and audio signals from your devices to your

TV, avoiding cable clutter. It carries

uncompressed signals, ensuring the highest

quality from source to screen. Together with

Philips Easylink, you need only one remote

control to perform most operations on your

TV, DVD, BluRay, set top box or home theatre

system.

Clear Sound

Clear Sound is an innovative audio technology

that significantly increases the

comprehensibility of the voice, whether

spoken or sung. It ensures you hear every

word, so you can enjoy what you're watching

to the fullest.

Philips Green Logo

Philips Green Products can reduce costs,

energy consumption and CO2 emissions.

How? They offer a significant

environmental improvement in one or

more of the Philips Green Focal Areas –

Energy efficiency, Packaging, Hazardous

substances, Weight, Recycling and

disposal and Lifetime reliability.

x3

Issue date 2012-10-10

Version: 13.7.7

12 NC: 8670 000 58521

EAN: 87 12581 52110 3

© 2012 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

42PFL5405H/12

Specifications

LCD TV with Pixel Plus HD

107cm (42") Full HD 1080p digital TV

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 100,000:1

• Response time (typical): 2 ms

• Viewing angle: 178º (H) / 178º (V)

• Diagonal screen size: 42 inch / 107 cm

• Display screen type: LCD Full HD W-UXGA Act.

matrix

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus HD, Active

Control + Light sensor, Color Enhancement,

100Hz Clear LCD, Color Transient Improvement,

Contrast Plus, Digital Noise Reduction, Dynamic

contrast enhancement, Jagged Line Suppression,

Luminance Transient Improver, Progressive scan,

2D/3D noise reduction, 1080p 24/25/30Hz

processing, 1080p 50/60Hz processing

• Screen enhancement: Anti-Reflection coated

screen

• Peak Luminance ratio: 65 %

• Color cabinet: High gloss black deco front black

cabinet

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

1280 x 768 60Hz

1280 x 1024 60Hz

1360 x 768 60Hz

1920 x 1080 60Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

576i 50Hz

576p 50Hz

720p 50, 60Hz

1080i 50, 60Hz

1080p 24, 25, 30, 50, 60Hz

Sound

• Output power (RMS): 40W virtual, Invisible Sound

• Sound Enhancement: Auto Volume Leveller,

Dynamic Bass Enhancement, Incredible Surround,

Treble and Bass Control, Clear Sound

• Sound System: Dolby Digital (AC-3), Nicam Stereo

Convenience

• Child Protection: Child Lock+Parental Control

• Ease of Installation: Channel installation wizard,

Settings assistant wizard, Device connection

wizard, Auto Program Naming, Automatic Channel

Install(ACI), Automatic Tuning System (ATS), Fine

Tuning, PLL Digital Tuning

• Ease of Use: Auto Volume Leveller (AVL),

Graphical User Interface, On Screen Display,

Program List, Settings assistant Wizard, Side

Control, Demo mode, Onscreen Usermanual,

EasyLink, Favorite program selection, Mozaïc

channel grid, Simplified Remote Control

• Electronic Program Guide: Now + Next EPG, 8day

Electronic Program Guide*

• Remote Control: TV

• Remote control type: PF01E10BB

• Automatic Screen Format: Autofill (no black bars),

Autozoom (no distortion), Dynamic black bar

detection, includes:, 16:9, Widescreen,

Superzoom, WSS / AFD format bit detection,

Viewport link, Logo suppression, Dynamic subtitle

shift, Format selection per input, PC signal mode

• Teletext: 1000 page Smart Text

• Firmware upgradeable: Firmware upgradeable via

USB

•Multimedia: USB autobreak-in

• Smart mode: Personal, Vivid, Cinema, Game,

Energy saving, Standard

Multimedia Applications

• Multimedia connections: USB

• Picture Playback Formats: JPEG

• Music Playback Formats: MP3, WMA (v2 up to

v9.2), AAC

•Video Playback Formats: Codec support:, H264/

MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4,

WMV9/VC1, Containers: AVI, MKV

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,

SECAM D/K, SECAM L/L', DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Digital TV: DVB Terrestrial *, DVB-T MPEG4*,

DVB-C MPEG4*

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in, RGB

•Number of Scarts: 1

• Ext 3: YPbPr, Audio L/R in

• HDMI 1: HDMI v1.4 (Audio Return Ch.)

•HDMI 2: HDMI v1.3

• HDMI Side: HDMI v1.3

• Front / Side connections: HDMI v1.3, USB,

Common Interface Slot (CI-CI+)

• Other connections: Headphone out, PC Audio in,

PC-In VGA, S/PDIF out (coaxial), Common

Interface

• EasyLink (HDMI-CEC): One touch play, EasyLink,

Pixel Plus link (Philips), Remote control pass-

through, System audio control, System standby

• Audio Output - Digital: Coaxial (cinch)

• Summary: 3x HDMI, 1x USB, 1x SCART

Power

• Green label: ECO label certified

• Ambient temperature: 5 °C to 35 °C

• Mains power: 220-240V, 50-60Hz

• Power consumption (typical): 98.2 W

• Standby power consumption: 0.15 W

• Annual energy consumption: 143.372 kW·h

• Presence of lead: Yes*

• Mercury content: 72 mg

Dimensions

• Compatible wall mount: adjustable 200 x 300mm

• Set dimensions (W x H x D): 1034 x 644 x 83 mm

• Set dimensions with stand (W x H x D):

1034 x 692 x 270 mm

• Weight incl. Packaging: 16.44 kg

• Product weight: 11.38 kg

• Product weight (+stand): 13.38 kg

•Box dimensions (W x H x D):

1210 x 703 x 158 mm

* 8 days EPG, service not available in all countries

* DVB-T, supported in selected countries only

* DVB-C in selected countries and for selected operators only. Most

up to date information is available on the type plate of the TV.

* The TV supports DVB reception for 'Free to air' broadcast. Specific

DVB operators may not be supported. An up to date list can be

found in the FAQ section of the Philips support website. For some

operators Conditional Access and subscripction are required.

Contact your operator for more information.

* Typical on-mode power consumption measured according to

IEC62087 Ed 2.

* Energy consumption in kWh per year, based on the power

consumption of the television operating 4 hours per day for 365

days. The actual energy consumption will depend on how the

television is used.

* This television contains lead only in certain parts or components

where no technology alternatives exist in accordance with existing

exemption clauses under the RoHS Directive.

REAR CONNECTORS

BOTTOM REAR CONNECTORS

SIDE CONNECTORS
