Philips 46PFL5605/98 LED TV With Pixel Plus HD User Manual Leaflet 46pfl5605 98 Pss

User Manual: Philips 46PFL5605/98 Leaflet LED TV 46PFL5605/98 | Philips46PFL5605/98

Open the PDF directly: View PDF .
Page Count: 3

Philips

LED TV with Pixel Plus HD

117 cm (46")

Full HD 1080p

46PFL5605

Entertainment comes to life

with brilliant LED picture performance

Enjoy the latest 100Hz direct LED backlight technology from the leading European TV

brand.

High definition giving you brilliant detail

• Full HD TV with Pixel Plus HD for better details and clarity

• Brilliant LED images with low power consumption

• 100Hz LCD, 2ms performance for superb motion sharpness

• HD Natural Motion for ultra smooth motion in Full HD movies

Rich and clear sound.

• 2.1 system 40 W surround sound (2 x 10 W RMS, virtual 20 W)*

• Incredible Surround for powerful sound

Complete digital connectivity made simple

• Seamless connectivity with 3 HDMI inputs and Easylink

• USB for fantastic multimedia playback

• PC-input allows you to use your TV as a PC monitor

Greener every day

• LED TVs up to 40% more energy efficient than normal LCD TVs

• 0W Power Consumption when switch off

46PFL5605/98

Highlights

LED TV with Pixel Plus HD

117 cm (46") Full HD 1080p

Pixel Plus HD

Pixel Plus HD offers the unique combination of

ultimate sharpness, natural detail, vivid colors,

and smooth natural motion. Artifacts and noise

in any sources from multimedia to standard

definition TV and also in highly compressed

HD are detected and reduced, ensuring that

the picture is clear and razor-sharp.

LED

The most advanced LED lighting technology in

this TV combines an eye-catching minimalistic

design with stunning image quality as well as

the lowest power consumption in its category.

On top of that, LED lighting technology does

not contain any hazardous materials. Thus,

with LED backlight you can enjoy low power

consumption, high brightness, incredible

contrast, sharpness and vibrant colors.

100Hz LCD, 2ms response time

100Hz LCD creates extreme motion

sharpness. The Double Frame Rate Insertion

increases the sharpness of motion

reproduction to more than twice that of

conventional LCD, resulting in a performance

with a response time of 2 milliseconds. Now

you can enjoy clear images even with fast on-

screen motion.

HD Natural Motion

Philips invented HD Natural Motion to

minimize juddering effects that are visible with

movie based picture content. The award

winning algorithm estimates motion in the

picture and corrects juddering movements in

both broadcast and recorded movie material

(such as DVD and Blu-ray Disc). The resulting

smooth motion reproduction and excellent

sharpness take the viewing experience to a

higher level.

2.1 sound system 40 W*

Virtual 2.1 speaker system for an incredible

40W sound (2x10W + 20W Virtual Power*).

*This virtual 2.1 speaker system manages

power intelligently to deliver twice the original

power supplied and produces an excellent

bass. Enjoy the purity and detailed sound with

the additional dome tweeter which delivers

uncompromised sound in a slim invisible

speaker design.

Incredible Surround

Feel the power of the music beat and the

atmosphere of the movies. Incredible

Surround allows you to experience total

surround with greater depth and width of

sound. It gives a clear and spacious sound stage

complementary to the rich viewing experience.

USB (multimedia)

The USB connector allows access to jpeg

photos, mp3 music and video files of most

USB-sticks (USB memory-class device). Plug

the USB into the slot at the side of the TV and

access the multimedia content using the easy

on screen content browser. You can now view

and share your videos, photos and music.

Zero watt power consumption

Enjoy savings on your electricity bill by using

the build-in power switch on this TV. This

leads to no power consumption, without

having to unplug the power cord from the wall.

3 HDMI inputs with Easylink

HDMI is a single cable to carry both picture

and audio signals from your devices to your

TV, avoiding cable clutter. It carries

uncompressed signals, ensuring the highest

quality from source to screen. Together with

Philips Easylink, you need only one remote

control to perform most operations on your

TV, DVD, BluRay, set top box or home theatre

system.

x3

energy

savings

Issue date 2014-02-12

Version: 7.0.7

12 NC: 8670 000 59957

EAN: 87 12581 52544 6

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

46PFL5605/98

Specifications

LED TV with Pixel Plus HD

117 cm (46") Full HD 1080p

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 450 cd/m²

• Dynamic screen contrast: 500,000:1

• Response time (typical): 2 ms

• Viewing angle: 176º (H) / 176º (V)

• Diagonal screen size: 46 inch / 117 cm

• Display: LCD Full HD, direct LED backlight

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus HD, Active

Control + Light sensor, Color Enhancement,

100Hz Clear LCD, Dynamic contrast

enhancement, Luminance Transient Improver,

MPEG artifact reduction, 1080p 24/25/30Hz

processing, 1080p 50/60Hz processing, HD

Natural Motion, LED backlight Display

• Screen enhancement: Anti-Reflection coated

screen

Supported Display Resolution

• Computer inputs: up to 1920x1080 @ 60Hz

• Video inputs: up to 1920x1080p, 24, 25, 30, 50, 60

Hz

Sound

• Output power (RMS): 20W

• Sound Enhancement: Auto Volume Leveller,

Incredible Surround, Treble and Bass Control

• Sound System: Mono, Nicam Stereo, Stereo

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Connection Enhancement: Easy link

• Ease of Installation: Channel installation wizard,

Settings assistant wizard, Device connection

wizard, Program Name, Sorting

• Ease of Use: Smart Picture, Smart Sound,

Connectivity assistant, Demo mode, EasyLink,

Favorite program selection, Mozaïc channel grid,

One-stop experience button, One-stop Home

button

• Screen Format Adjustments: Super Zoom, Movie

expand 16:9, Widescreen, unscaled (1080p dot by

dot)

• Teletext: 1000 page Hypertext

• Signal strength indication

• Firmware upgradeable: Firmware upgradeable via

USB

•Multimedia: USB media browser

Multimedia Applications

• Multimedia connections: USB memory class device

• Picture Playback Formats: JPEG

• Music Playback Formats: MP3

• Video Playback Formats: MPEG-1, MPEG-4,

RealMedia (.rm, .rmvb, RV8-10)

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL B/G, PAL D/K

• Video Playback: NTSC, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: Audio L/R in, CVBS in, S-Video in

• VGA-in: PC input, D-sub 15

•HDMI 1: HDMI v1.3

•HDMI 2: HDMI v1.3

•Front / Side connections: HDMI v1.3, USB

•EasyLink (HDMI-CEC): One touch play, Pixel Plus

link (Philips), Remote control pass-through, System

audio control, System standby, EasyLink

• Audio Output - Digital: Coaxial (cinch)

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 220-240V~; 50-60Hz

• Power consumption (typical): 109 W

• Standby power consumption: < 0.15 W

• Power Saving Features: 0 Watt Power-off switch,

Light sensor, Eco mode

Dimensions

• Set dimensions (W x H x D): 1122 x 685 x 87 mm

• Set dimensions with stand (W x H x D):

1122 x 731 x 268 mm

• Weight incl. Packaging: 26.4 kg

• Product weight: 17.9 kg

• Product weight (+stand): 21.3 kg

•Box dimensions (W x H x D):

1349 x 773 x 198 mm

• VESA wall mount compatible: 300 x 300 mm

Accessories

• Included accessories: Tabletop swivel stand, Quick

start guide, User Manual, Remote Control, 2 x

AAA Batteries

• User Manual: Arabic, English, French, Simplified

Chinese, Thai, Traditional Chinese, Vietnamese

•
