Philips
LCD TV with Ambilight
Spectra 2 and Perfect Pixel
HD Engine
119 cm (47")
Full HD 1080p
digital TV
47PFL9664H
Brings movies to life
With Ambilight and breathtaking sharp pictures
Be captivated by the immersive power of Ambilight in an ultra thin and slim design.
Featuring the stunning Perfect Pixel HD engine and powerful sound, movies really come
to life in your living room.
Immersive viewing experience
• Ambilight Spectra 2 enhances the viewing experience
Perfect LCD Picture
• Perfect Pixel HD Engine for unrivalled sharpness and clarity
• Full HD LCD display, with a 1920x1080p resolution
• Perfect Natural Motion for ultra smooth Full HD movies
• 200 Hz Clear LCD*, 1 ms performance: superb motion sharpness
Stylish and elegant design
• Ultra slim and thin TV for perfect fit in your living room
In-built internet TV
• Philips Net TV with Wi-Fi for online services on your TV
• Enjoy a rich selection of web videos from YouTube and others
Ready for digital
• MPEG4 HDTV reception via DVB-T and DVB-C tuner with CI+*
47PFL9664H/12
Highlights
LCD TV
119 cm (47") Full HD 1080p, digital TV
Ambilight Spectra 2
Add a new dimension to your viewing
experience with Ambilight Spectra 2. This
patented Philips technology enlarges the
screen further by projecting a glow of light
from the back of the screen onto the
surrounding wall. Ambilight adjusts
automatically the colour and brightness of the
light surrounding the TV to match with the
picture, creating an immersive viewing
experience. With Ambilight Spectra 2 movies
truly come to life!
Perfect Pixel HD Engine
Experience unrivalled sharpness and clarity
with Perfect Pixel HD Engine. Each pixel of the
picture is enhanced to better match the
surrounding pixels, resulting in a more natural
picture. The result is a unique combination of
sharpness, natural detail, vivid colors superior
contrast and smooth natural motion whatever
you are watching. Clean and razor sharp
images result from artifact and noise detection
and reduction in all content sources - from
multimedia to standard TV.
Full HD LCD display 1920x1080p
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.
Philips Net TV with Wi-Fi
Experience a rich selection of online services
with Net TV. Enjoy movies, pictures,
infotainment and other online content directly
on your TV whenever you like. Simply connect
your home theater directly to your home
network through the ethernet connection, and
navigate and select what you want to watch
with the remote control. The Philips menu
gives you access to popular Net TV services
fitted for your TV screen. Additionally, with
the DLNA certified PC network you can watch
videos or access pictures stored on your
computer using your remote control.
Perfect Natural Motion
Enjoy the action without any judder. Perfect
Natural Motion estimates motion in the
picture and corrects juddering movements in
both broadcast and pre-recorded movie
material (including 1080p movies and 24p True
Cinema on Blu-ray and DVD). The result is
even smoother and quieter pictures with
excellent sharpness. Enjoy motion
performance that surpasses cinema quality!
200Hz Clear LCD* (1ms)
Enjoy extreme motion sharpness. The Philips
200Hz Clear LCD brings the response time of
LCD TV to an incredible 1ms, so even with the
fastest car chase scene you will be enthralled
by the action, and not following the stretched
car across the screen.
Ultra slim and thin TV
This ultra slim and thin TV makes your TV fit
your living room perfectly. With a bezel of 25
mm and a depth of only 49 mm this TV
combines the minimalism of design with the
true cinematic viewing experience of
Ambilight: Ambilight adds to the viewing
experience, not to the size of your TV.
MPEG4 DVB-T/C tuner with CI+*
HDTV allows you to watch TV in the best
possible picture and sound quality, without
additional set-top box. Thanks to the built in
tuner that supports DVB-Terrestrial and DVB-
Cable signals for both MPEG-2 and MPEG-4
formats, you receive high definition TV
programs in exceptional quality. Moreover,
with Common Interface Plus (CI+) you benefit
from premium high definition content directly
on your TV.
Issue date 2017-04-04
Version: 8.2.7
12 NC: 8670 000 51982
EAN: 87 12581 47930 5
© 2017 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
47PFL9664H/12
Specifications
LCD TV
119 cm (47") Full HD 1080p, digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 500 cd/m²
• Dynamic screen contrast: 80.000:1
• Response time (typical): 1 (BEW equiv.) ms
• Viewing angle: 176º (H) / 176º (V)
• Diagonal screen size: 47 inch / 119 cm
• Display screen type: LCD Full HD W-UXGA Act.
matrix
• Panel resolution: 1920x1080p
• Picture enhancement: Perfect Pixel HD Engine,
Perfect Natural Motion, Perfect Contrast, Perfect
Colors, 3/2 - 2/2 motion pull down, 3D Combfilter,
Active Control + Light sensor, Jagged Line
Suppression, Progressive scan, 1080p 24/25/30Hz
processing, 1080p 50/60Hz processing, 200Hz
Clear LCD*, Scanning backlight
• Screen enhancement: Anti-Reflection coated
screen
• Color processing: 2250 trillion colors 17bit RGB
• Color cabinet: Brushed aluminium decofront
Ambilight
• Ambilight Features: Ambilight Spectra 2, Lounge
light mode
• Dimming Function: Manual and via Light Sensor
• Ambilight light system: LED wide color
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 768 60Hz
1360 x 768 60Hz
1920 x 1080 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 24, 50, 60Hz
1080p 24, 25, 30Hz
Sound
• Output power (RMS): 2 x 15W
• Sound Enhancement: Auto Volume Leveller, Digital
Signal Processing, Dynamic Bass Enhancement,
Treble and Bass Control
• Sound System: BBE
Loudspeakers
• Built-in speakers: 4
• Loudspeaker types: 2 integrated subwoofers, 2x
Dome tweeter
Convenience
• Child Protection: Child Lock+Parental Control
• Connection Enhancement: Easy link
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, PLL Digital
Tuning, Plug & Play
• Ease of Use: Auto Volume Leveller (AVL), Delta
Volume per preset, Graphical User Interface, On
Screen Display, Program List, Settings assistant
Wizard, Side Control, Connectivity assistant,
Automatic setup wizard, Demo mode, Onscreen
Usermanual, Touch control buttons, Favorite
program selection, Iconic home sceen, Mozaïc
channel grid
• Electronic Program Guide: Now + Next EPG, 8day
Electronic Program Guide*
• Picture in Picture: Text dual screen
• Remote Control: DVD, DVD-R, Sat, STB (Set-Top
Box), Universal, HTS (Home Theater System)
• Remote control type: RC4495
• Screen Format Adjustments: Auto Format, Movie
expand 16:9, Super Zoom, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1200 page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB
• Multimedia: Digital media reader (browser), USB
autobreak-in, DLNA media Browser, Net TV
services
• Smart mode: Game, Cinema, Personal, Power
saver, Standard, Vivid
Multimedia Applications
• Multimedia connections: Ethernet-UTP5, USB, Wi-
Fi 802.11g (built in)
• Playback Formats: MP3, WMA v2 up to v9.2,
Slideshow files (.alb), JPEG Still pictures, MPEG1,
MPEG2, MPEG4, AVI, H.264/MPEG-4 AVC, MPEG-
Progam-stream PAL, WMV9/VC1
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB Terrestrial *, DVB-T MPEG4*,
DVB-C MPEG4*, MHEG
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in, VGA PC-in
• Front / Side connections: USB
• PC network link: DLNA 1.0 certified
• Other connections: A/V Audio L/R in (value),
Analog audio Left/Right out, S-Video in, Composite
video (CVBS) input, HDMI, Headphone out, S/
PDIF out (coaxial), Common Interface Plus (CI+)
•HDMI 1: HDMI v1.3a
•HDMI 2: HDMI v1.3a
•HDMI 3: HDMI v1.3a
•HDMI 4: HDMI v1.3a
• EasyLink (HDMI-CEC): One touch play, EasyLink,
Pixel link, Remote control pass-through, System
audio control, System standby
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: AC 220 - 240 V +/- 10%
• Power consumption (typical): 243 W
• Standby power consumption: < 0.15 W
Dimensions
• Set dimensions (W x H x D): 1111 x 694 x 50 mm
• Set dimensions with stand (H x D): 757 x 280 mm
• Stand width: 500 mm
• Product weight: 20 kg
• Product weight (+stand): 30 kg
•Box dimensions (W x H x D):
1369 x 803 x 291 mm
• VESA wall mount compatible: 300 x 300 mm
* 200Hz Clear LCD displays 200 scenes per second by combining
advanced 100Hz technology with scanning backlight @ 50%
dutycycle.
* 8 days EPG, service not available in all countries
* DVB-T, supported in selected countries only
* DVB-C in selected countries and for selected operators only. Most
up to date information is available on the type plate of the TV.
* Net TV, service offering is dependent on country and subject to
terms of use.
* Optional Philips DVB-S module required (part no. PFS0001, only
available in Germany, Austria and Switzerland)
VGA
SERVICE UART
NETWORK
AUDIO IN VGA
1
2
3
4
SIDE
