EN For further assistance, call the customer support service in your

country.

• To obtain assistance, contact Philips Customer Care Center;

In the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands

1 866 202 5960

México D.F. and Área Metropolitana; 58 87 97 36

Interior de la Republica; 01 800 839 19 89

ES Para obtener más información, llame al servicio de soporte al cliente

de su país.

• Para obtener asistencia, comuníquese con Centro de atención al

cliente de Philips;

En los Estados Unidos, en Canadá, Puerto Rico o en las Islas Vírgenes

de los Estados Unidos; 1 866 202 5960

México D.F. y Área Metropolitana; 58 87 97 36

Interior de la Republica; 01 800 839 19 89

FR Pour obtenir de l’aide supplémentaire, communiquez avec le centre

de service à la clientèle de votre pays.

• Pour obtenir de l’aide, communiquez avec le centre de service à la

clientèle Philips au;

Dans le États-Unis, au Canada, à Puerto Rico ou aux Îles Vierges

américaines; 1 866 202 5960

México D.F. et Área Metropolitana; 58 87 97 36

Interior de la Republica; 01 800 839 19 89

Register your product and get support at

www.philips.com/welcome

EN

User Manual

ES

Manual del Usuario

FR

Manuel d’Utilisation

65PFL7900

55PFL7900

49PFL7900

Telev isions

7000 series

Contents

1 Notice ....................................................................................... 5

2 Important ............................................................................... 7

Positioning the TV 7

Regulatory notices 7

Environmental care 7

Preparing to move / ship the unit 7

3 Getting started ................................................................... 8

Features 8

Supplied accessories 8

Symbols used in this User manual 8

Unpacking 9

Installing the stands 10

Lifting the TV set 10

Removing cardboard 10

Installing the remote control batteries 11

Remote control 12

Control panel 13

Terminals 13

Connecting Antenna or Cable / Satellite / IPTV set-top box 14

Plugging in the AC power cord 14

Selecting your connection quality 15

Connecting your devices 15

Initial setup 19

4 Use your TV ....................................................................... 21

Switching on your TV and putting it in standby mode 21

Adjusting volume 21

Switching channels 21

Watching channels from an external device 22

Access the Home menu 22

Create a list of favorite channels 23

Changing Picture format 23

TV screen information 24

Using options menu 25

USB 26

5 Getting more from your TV ...................................... 29

Picture and sound setup 30

TV settings 30

Picture 30

Sound 32

Features 33

Installation 34

Search for channels 37

Install channels 37

Channel settings 37

Channel installation 37

Child lock 38

Change PIN 39

Digital audio language 39

Mono/Stereo 39

Connect to network 40

Wireless setting 40

Wired setting 40

Network settings 41

Manual network settings 41

Connection test 43

Setting status 43

Home network 44

Wake-on-LAN(DIAL) 44

Net TV 44

Reset network settings 44

Update software 45

Preparing for the software upgrade 45

Downloading the software 45

USB upgrade 45

Network updates 46

Software settings 46

Software 46

Miracast 47

View photos, play music and watch videos using home

network 47

Net TV 50

Pandora operations 51

6 Useful tips ........................................................................... 52

FAQ 52

Troubleshooting tips 53

7 Information ......................................................................... 55

Glossary 55

Maintenance 55

8 Specifications ................................................................... 56

9 Warranty ............................................................................. 57

License .......................................................................................... end of book

•Displays and illustrations may differ depending on the product you purchase.

2.English

Know these safety symbols The lightning ash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within

the apparatus’s enclosure that may be of sucient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the apparatus.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The caution marking is located on the rear or bottom of the cabinet.

CAUTION

Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out.

Register Online at www.philips.com/welcome to ensure:

Register online today at www.philips.com/welcome today

to get the most benets from your purchase.

*Product safety notication *Additional benets

By registering your product, you'll receive

notication - directly from the manufacturer - in

the rare case of a product recall or safety defect.

Registering your product guarantees that you'll

receive all of the privileges to which you're

entitled, including special money-saving oers.

WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.

Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids,

such as vases, shall be placed on the apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION: Pour éviter les choc électriques,introduire la lame la plus large de la che dans la borne

correspondante de la prise et pousser jusqu’au fond.

For fastest support visit us online for chat and self service

solutions at www.philips.com/support

CHILD SAFETY:

PROPER TELEVISION PLACEMENT MATTERS

THE CONSUMER ELECTRONICS INDUSTRY CARES

• Manufacturers, retailers and the rest of the consumer

electronics industry are committed to making home

entertainment safe and enjoyable.

• As you enjoy your television, please note that all

televisions – new and old- must be supported on

proper stands or installed according to the

manufacturer’s recommendations. Televisions that are

inappropriately situated on dressers, bookcases,

shelves, desks, speakers, chests, carts, etc., may fall

over, resulting in injury.

TUNE IN TO SAFETY

• ALWAYS follow the manufacturer’s recommendations

for the safe installation of your television.

• ALWAYS read and follow all instructions for proper

use of your television.

• NEVER allow children to climb on or play on the

television or the furniture on which the television is

placed.

• NEVER place the television on furniture that can

easily be used as steps, such as a chest of drawers.

• ALWAYS install the television where it cannot be

pushed, pulled over or knocked down.

• ALWAYS route cords and cables connected to the

television so that they cannot be tripped over, pulled

or grabbed.

WALL OR CEILING MOUNT YOUR TELEVISION

• ALWAYS contact your retailer about professional

installation if you have any doubts about your ability

to safely mount your television.

• ALWAYS use a mount that has been recommended

by the television manufacturer and has a safety

certication by an independent laboratory (such as

UL, CSA, ETL).

• ALWAYS follow all instructions supplied by the

television and mount manufacturers.

• ALWAYS make sure that the wall or ceiling where you

are mounting the television is appropriate. Some

mounts are not designed to be mounted to walls and

ceilings with steel studs or cinder block construction.

If you are unsure, contact a professional installer.

• Televisions can be heavy. A minimum of two people

is required for a wall or ceiling mount installation.

MOVING AN OLDER TELEVISION TO A NEW PLACE

IN YOUR HOME

• Many new television buyers move their older CRT

televisions into a secondary room after the purchase

of a at-panel television. Special care should be

made in the placement of older CRT televisions.

• ALWAYS place your older CRT television on furniture

that is sturdy and appropriate for its size and weight.

• NEVER place your older CRT television on a dresser

where children may be tempted to use the drawers

to climb.

• ALWAYS make sure your older CRT television does

not hang over the edge of your furniture.

3.English

I

Important safety instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including ampliers) that produce heat.

Do not defeat the safety purpose of the polarized

or grounding type plug. A polarized plug has two

blades with one wider than the other. A grounding

type plug has two blades and a third grounding

prong. The wide blade or the third prong are

provided for your safety. If the provided plug does

not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

Only use attachments / accessories specied by

the manufacturer.

Use only with the cart, stand,

tripod, bracket, or table specied

by the manufacturer, or sold with

the apparatus. When a cart is

used, use caution when moving

the cart / apparatus combination

to avoid injury from tip-over.

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

1 1.

12.

Unplug this apparatus during lightning storms or

when unused for long periods of time.

Refer all servicing to qualied service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

13.

14.

Note to the CATV system installer:

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the NEC that

provides guidelines for proper grounding and, in

particular, species that the cable ground shall be

connected to the grounding system of the building,

as close to the point of cable entry as practical.

Example of antenna grounding as per NEC -

National Electric Code

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

ELECTRIC SERVICE EQUIPMENT

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250,

PART H)

GROUND CLAMPS

Wall mount bracket kit

Brand Model # Screw dimension

49PFL7900

55PFL7900 SANUS VMPL3 M6 x 0.472” (12mm)

Do NOT use screws packed

with Wall Mount Bracket Kit.

For 65 inch TVs, you need to

purchase screws separately with

dimensions described below.

65PFL7900 SANUS VMPL3

M6 x 1.181” (30mm)

with spacer

•Your TV meets the VESA standard for wall mounting. Consult with your

local dealer for a wall mount bracket which is compatible with your TV

model.

•The recommended wall mount bracket kit (sold separately) allows the

mounting of the TV on the wall.

•For detailed information on installing the wall mount, refer to the wall

mount Instruction book.

•P&F USA is not responsible for any damage to the product or injury to

yourself or others if you elect to install the TV wall mount bracket or

mount the TV onto the bracket on your own.

•The wall mount bracket must be installed by experts.

P&F USA is not liable for these types of accidents or injuries noted

below.

•Install the wall mount bracket on a sturdy vertical wall.

•If installed onto a ceiling or slanted wall, the TV and wall mount bracket

may fall which could result in a severe injury.

•Do not use screws that are longer or shorter than their specified length.

If screws too long are used this may cause mechanical or electrical

damage inside the TV set. If screws too short are used this may cause

the TV set to fall.

•Do not fasten the screws by excessive force. This may damage the

product or cause the product to fall, leading to an injury.

•For safety reasons use 2 people to mount the TV onto a wall mounting

bracket.

•Do not mount the TV onto the wall mounting bracket while your TV is

plugged in or turned on. It may result in an electrical shock injury.

When installing the unit on the wall, allow this much space.

Top : 1 1.8 inches (30cm)

Left and right side : 5.9 inches (15cm)

Bottom : 3.9 inches (10cm)

4.English

1 Notice

Trademarks are the property of Koninklijke Philips N.V. or

their respective owners.

P&F USA reserves the right to change products at any time

without being obliged to adjust earlier supplies accordingly.

The material in this manual is believed adequate for the

intended use of the system. If the product or its individual

modules or procedures are used for purposes other than

those specied herein, conrmation of their validity and

suitability must be obtained. P&F USA warrants that the

material itself does not infringe any United States patents.

No further warranty is expressed or implied.

P&F USA cannot be held responsible neither for any errors

in the content of this document nor for any problems as a

result of the content in this document. Errors reported to

P&F USA will be adapted and published on the P&F USA

support website as soon as possible.

Pixel characteristics

This LCD product has a high number of color pixels.

Although it has eective pixels of 99.999% or more, black

dots or bright points of light (red, green or blue) may

appear constantly on the screen. This is a structural

property of the display (within common industry standards)

and is not a malfunction.

Warranty

No components are user serviceable. Do not open or

remove covers to the inside of the product. Repairs may

only be done by Service Centers and ocial repair shops.

Failure to do so shall void any warranty, stated or implied.

Any operation expressly prohibited in this manual, any

adjustments or assembly procedures not recommended or

authorized in this manual shall void the warranty.

Federal Communications Commission Notice

This equipment has been tested and found to comply with

the limits for a Class B Digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment o

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

the receiver.

• Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio or

television technician for help.

Declaration of conformity

Trade name :PHILIPS

Responsible party :P&F USA, Inc.

Model :65PFL7900, 55PFL7900, 49PFL7900

Address :PO Box 2248, Alpharetta, GA 30023-2248 U.S.A.

Telephone number :1 866 202 5960

Modications

This apparatus may generate or use radio frequency energy.

Changes or Modications to this apparatus may cause

harmful interference.

Any Modications to the apparatus must be Approved by

P&F USA.

The user could lose the authority to operate this apparatus if

an unauthorized Change or Modication is made.

Cables

Connections to this device must be made with shielded

cables with metallic RFI / EMI connector hoods to maintain

compliance with FCC Rules and Regulations.

Canadian notice

CAN ICES-3 (B)/NMB-3 (B)

Analog and Digital Television Receiving Apparatus,

Canada BETS-7 / NTMR-7.

The following FCC/IC RSS applies to the

Wireless LAN adapter included in this product.

FCC Caution: Any changes or modications not

expressly approved by the party responsible for

compliance could void the user’s authority to operate

this equipment.

This transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

Country Code Statement

For product available in the USA market, only channel

1∼1 1 can be operated. Selection of other channels is not

possible.

To maintain compliance with FCC RF exposure

requirements, use only belt-clips, holsters or similar

accessories that do not contain metallic components in

its assembly. The use of accessories that do not satisfy

these requirements may not comply with FCC RF

exposure requirements and should be avoided.

This device complies with Industry Canada

license-exempt RSS standard(s). Operation is subject

to the following two conditions: (1) this device may not

cause interference and (2) this device must accept

any interference, including interference that may

cause undesired operation of the device.

5150-5250 MHz band is restricted to indoor

operations only.

High-power radars are allocated as primary users (i.e.

priority users) of the bands 5250-5350 MHz and

5650-5850 MHz and that these radars could cause

interference and/or damage to LE-LAN devices.

Compliance with IC requirement RSS-210 A9.4.4

Data transmission is always initiated by software,

which is the passed down through the MAC, through

the digital and analog baseband, and nally to the RF

chip. Several special packets are initiated by the MAC.

These are the only ways the digital baseband portion

will turn on the RF transmitter, which it then turns o at

the end of the packet. Therefore, the transmitter will be

on only while one of the aforementioned packets is

being transmitted. In other words, this device

automatically discontinue transmission in case of

either absence of information to transmit or

operational failure.

5.English

Copyright

All other registered and unregistered trademarks are the

property of their respective owners.

The terms HDMI and HDMI High-

Denition Multimedia Interface, and

the HDMI Logo are trademarks or

registered trademarks of HDMI

Licensing Administrator, Inc. in the

United States and other countries.

Manufactured under license

from Dolby Laboratories.

Dolby and the double-D

symbol are trademarks of

Dolby Laboratories.

Sonic Emotion and the Sonic

Emotion logo symbol are

registered trademarks of sonic

emotion ag.

ENERGY STAR

®

is a joint program

of the U.S. Environmental

Protection Agency and the U.S.

Department of Energy helping

us all save money and protect

the environment through energy

ecient products and practices.

Consumer Notice:

This TV has been set to maximize energy eciency while

delivering the best possible picture using the factory installed

home mode settings.

Changing or enabling other features in this TV (e.g. brightened

backlighting) will possibly increase energy consumption

beyond the original ENERGY STAR

®

qualied limits.

The CEA 4K Ultra HD Certication

Logo is a U.S. registered mark.

Netix is available in certain countries.

Streaming membership required.

More information at www.netix.com.

VUDUTM is a trademark of

VUDU, Inc.

YouTube and the YouTube logo

are trademarks of Google Inc.

PANDORA, the PANDORA logo,

and the Pandora trade dress

are trademarks or registered

trademarks of Pandora Media,

Inc. Used with permission.

The Wi-Fi CERTIFIED Logo is a

certication mark of the Wi-Fi

Alliance.

CinemaNow and the

CinemaNow logo are

trademarks of BestBuy Stores

L.P. and BestBuy Canada LTD.

Hotlist, Samba, Samba TV and

associated logos are

trademarks of Free Stream

Media Corp.

Portions of this software are copyright © The FreeType Project

(www.freetype.org).

The American Academy of Pediatrics discourages television

viewing for children younger than two years of age.

Some features may require an always-on broadband internet

connection, firmware update and/or a minimum bandwidth. Internet

services vary by location.

P&F USA Inc. / P&F MEXICANA, S.A.de C.V. do not warrant access to

the portal or to any of the services, content, software and advertising.

P&F USA Inc./P&F MEXICANA, S.A. de C.V. or third party content/

service providers may, in their sole discretion, add or remove access to

any specific services, content, software and advertising at any time.

Although P&F USA Inc. / P&F MEXICANA, S.A. de C.V. will strive to

provide a good selection of services, content or software, P&F USA Inc./

P&F MEXICANA, S.A. de C.V. do not warrant continued access to any

specific services, and content or software.

P&F USA Inc. / P&F MEXICANA S.A. de C.V. do not warrant Miracast

compatibility with all source devices such as smartphones, tablets,

laptops, etc. due to large variability in hardware, firmware, drivers,

software and implementation of wireless casting applications on these

source devices. Although P&F USA Inc. / P&F MEXICANA S.A. de C.V.

will strive to enhance compatibility and performance across a range of

source devices, P&F USA Inc. / P&F MEXICANA S.A. de C.V. do not

warrant compatibility with specific source devices.

6.English

2 Important

Positioning the TV

• Thin TVs can easily bend. To avoid damage to the screen

when laying this TV horizontally on the oor, it is highly

recommended this work be done by three people

(including one to support

the middle of the TV).

• A thin TV MUST NOT be

carried in a horizontal

position when being

moved.

• Install the Unit in a

horizontal and stable position.

• Do not install the Unit in direct sunlight or in a place subject

to dust or strong vibration.

• Depending on the environment, the temperature of this

Unit may increase slightly. This is not a malfunction.

• Avoid a place with drastic temperature changes.

• Do not place anything directly on top or bottom of the Unit.

• Depending on your external devices, noise or disturbance

of the picture and / or sound may be generated if the Unit

is placed too close to them. In this case, please ensure

enough space between the external devices and the Unit.

• Do not insert the AC power cord into the power socket

outlet before all the connections are made.

• Ensure that you always have easy access to the AC Power

Cord and Outlet to disconnect the TV from the AC Outlet.

• Before you move the TV, disconnect attached Cables to

prevent damage to Connectors, especially the TV Tuner.

• Be sure to Unplug the AC Power Plug from the AC outlet

before moving or carrying the Unit.

• When moving the TV and then Setting it down, please be

careful not to pinch the AC Power Cord under the Unit.

Regulatory notices

Do not place the unit on the furniture that is capable of being

tilted by a child and an adult leaning, pulling, standing or climbing

on it. A falling unit can cause serious injury or even death.

This apparatus should not be placed in a built-in installation such

as a bookcase or rack unless proper ventilation is provided.

Make sure to leave a space of 4 inches (10cm) or more around this

apparatus.

Press to turn the unit On and go into Standby mode.

To completely turn O the unit, you must unplug the AC power

Plug from the AC Power Outlet.

Disconnect the AC Power Plug to shut the unit O when trouble is

found or not in use. The AC Plug shall remain readily available.

AC power plug

Never use a gas duster on this TV.

The gas trapped inside of this unit may cause ignition and explosion.

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

WARNING: Batteries (battery pack or battery installed) should

not be exposed to excessive heat such as sunshine,

re or the like.

WARNING: To prevent injury, this apparatus must be securely

attached to the furniture / wall in accordance with

the instructions. Tipping, shaking or rocking the unit

may cause injury / death.

Environmental care

The packaging of this product is intended to be recycled.

Contact your local authorities for information about how

to recycle the packaging.

For product recycling information, please visit -

End of life directives

Philips pays a lot of attention to produce

environmental-friendly products in green focal areas. Your

new TV contains materials which can be recycled and

reused. At the end of its life, specialized companies can

dismantle the discarded TV to concentrate the reusable

materials and to minimize the amount of materials to be

disposed of. Please ensure you dispose of your old TV

according to local regulations.

Disposal of used batteries

The batteries supplied do not contain the heavy metals

mercury and cadmium, however in certain localities,

disposing batteries with household waste is not

permitted. Please ensure you dispose of batteries

according to local regulations.

Preparing to move / ship the unit

Please pack the Unit properly by following the Diagram on

the Carton (as noted below).

• To avoid damage to the Screen, do not pack the

Stand on the same side as the TV screen, refer to the

illustration above.

7.English

2 Getting started

Features

•DTV / Analog TV / CATV

You can use your remote control to select channels which are broadcast in digital format and

conventional analog format. Also, cable and satellite subscribers can access their TV channels.

•Information display

You can display on the TV screen the title, contents (DTV only) and other information on the current

program.

•Autoprogram

This unit automatically scans and memorizes channels available in your area, eliminating difficult

setup procedures.

•Net TV

This unit lets you enjoy internet services. Use the remote control to browse the Net TV pages. You

can play movies and much more, all from your TV screen.

•Child lock

This feature allows you to block children’s access to inappropriate programs.

•Closed caption decoder

Built-in closed caption decoder displays text for closed caption supported programs.

•MTS / SAP tuner

Audio can be selected from the remote control.

•Auto standby

If there is no input signal and no operation for 15 minutes, the unit will go into standby mode

automatically.

•Sleep timer

You can set the unit to go into standby mode after a specific amount of time.

•Choices for on-screen language

Select your on-screen language: English, Spanish or French.

•Stereo sound function

•PLL frequency synthesized tuning

Provides free and easy channel selection and lets you tune directly to any channel using the

number and decimal point “•” keys on the remote control.

•Various adjustments for picture and sound

Customizes picture quality suitable for your room and sets your sound preference.

•EasyLink via HDMI link

EasyLink allows your other HDMI link devices to be controlled by the HDMI cable connected to

your TV.

•HDMI input

•HDMI-DVI input

If your video device has a DVI output jack, use an HDMI-DVI conversion cable to connect the

unit.

•Component video input

•PC input

•AV input

Audio and video input from an external device.

•USB terminal

The picture, music and video files stored on a USB memory stick can be played back on this unit.

•Digital audio output

•Headphone audio output

Headphone 3.5mm stereo jack for personal listening.

Supplied accessories

AAA

AAA

665PFL7900

6

55PFL7900 /

49PFL7900

SizeQuantityModel

Screws packed with this Unit.

TV base and Screws

Quick Start guideUser Manual

M4 x 0.551”(14mm)

M4 x 0.472”(12mm)

(AAA, 1.5V x 2)

Remote Control

and Batteries

Caution Sheet

Note(s)

•If you lose the screws, please purchase the above-mentioned Phillips head screws at your local

store.

•If you need to replace these accessories, please refer to the part name or No. with the illustrations

and call our toll free customer support line found on the cover of this User manual.

W

When using a universal remote control to operate this unit.

•Make sure the component code on your universal remote control is set to our brand. Refer to

the instruction book accompanying your remote control for more details.

•We do not guarantee 100% interoperability with all universal remote controls.

Symbols used in this User manual

The following is the description for the symbols used in this User manual.

Description refers to:

Digital TV operation

Cable / NTSC (Analog) TV operation

•If neither symbol appears, the operation is applicable to both.

8.English

Continued on next page.

Unpacking

It is recommended that two or more people remove the TV set from the

box. Thin TVs can easily bend. To avoid damage to this TV and its screen,

it MUST NOT be carried in a horizontal position when being moved.

1Open the top flaps of the box.

2Remove all accessories.

Caution(s)

•DO NOT take the TV set out of the box yet.

3Remove the packing joints* from the box.

*65PFL7900 (x6)

49PFL7900, 55PFL7900 (x4)

4Remove the outer slipbox with care.

5Support the top of the TV set with a hand to prevent the TV from

falling.

6Unhinge the retaining tabs and unfold the left and right side of the

bottom packaging.

9.English

Continued on next page.

Installing the stands

You must support the top of the TV set at all times to prevent the TV from

falling.

1Remove one of the bottom polystyrene foam bases.

2Rip the plastic bag until the bottom corner of the TV is exposed.

3Remove the protective film on the bottom of the TV and fasten the

matching stand to the TV with 3 screws (included).

3 screws

required

4Remove the other bottom polystyrene foam base and rip the plastic

bag on this side as shown in step 2.

5Fasten the other stand to the TV with 3 screws.

•Both stands should now be securely fastened.

3 screws

required

Note(s)

•A wide open space is recommended for assembly.

•A Phillips-head screwdriver is required to fasten the stands to the TV set.

•When attaching the stand, ensure that all screws are tightly fastened. If the stand is not properly

attached, it could cause the unit to fall, resulting in injuries as well as damage to the unit.

•To remove the stand from this unit, unscrew the Phillips-head screws by reversing the

procedure. Be careful not to drop the stand when you remove it.

Lifting the TV set

Carefully lift the TV set as shown in the illustration and place it onto a

stable, level surface.

Removing cardboard

Remove the cardboard attached to the screen. You are now ready to set

up and enjoy your Philips TV.

10 .English

Continued on next page.

Installing the remote control batteries

1Slide the battery cover off the back of the remote control.

2Insert the two supplied batteries (AAA, 1.5V). Be sure the + and – ends

of the batteries line up with the markings inside the case.

3Slide the cover back into position.

Note(s)

•Remove the batteries if not using the remote control for an extended period of time.

11 .English

Continued on next page.

Remote control

o

p

s

r

q

n

m

b

a

c

d

g

e

h

k

f

l

j

i

 (POWER)

Turns the TV on from standby or off to standby.

VUDU

Access directly to VUDU.

EasyLink buttons

 /  :Searches backward or forward through the disc.

 .:Starts, pauses or resumes playback.

.:Stops the disc playback.

Note(s)

•Pause may not work properly on some devices even if they are EasyLink (HDMI CEC)

compliant.

SOURCE

Selects connected devices.

(Home)

Displays the main menu.

Apps (APP1 / APP2 / APP3 / APP4) buttons

Works as direct access to user specified net apps.

!INFO

Displays information about the current program.

"OK

Press to decide the command of setting when the Home menu is

displayed.

# (NAVIGATION buttons)

Moves the cursor, selects the on-screen menu items.

$ OPTIONS

Displays a list of menu items applicable to the highlighted object or

screen.

%CH + / –

Selects a channel.

&0 - 9 (NUMBER buttons)

Used to enter a channel / program number.

• (DOT) : Use with 0-9 to select digital channels.

For example, to enter 2.1, press

PREV.CH : Returns to the previously viewed channel.

' (MUTE)

Turns the sound on and off.

(VOL + / –

Adjusts the volume.

)BACK

Returns to the previous menu operation.

*FORMAT

Adjusts the picture size on the TV screen.

+NET TV

Access to Net TV menu directly.

,YouTube

Access directly to YouTube.

-NETFLIX

Access directly to Netflix.

12 .English

Continued on next page.

Control panel

cba

h

g

f

e

d

Power on / Standby indicator

(On : lights in white, Standby : no light)

Remote control sensor

Receives IR signal from remote control.

Ambient light sensor

Alters the brightness of the TV screen automatically by detecting your

room lighting level. Do not block this light sensor window which allows

proper operation.

(POWER)

Turns the TV on or switches the TV into standby mode.

SOURCE

Selects connected devices.

MENU

Opens the main on-screen menu.

!CH (+) / (–)

Selects a channel. In the menu screen, moves the cursor up () (–) /

down () (+).

"VOL (–) / (+)

Adjusts the volume. In the menu screen, moves the cursor left () (–) /

right () (+).

VOL (–) :Volume down

VOL (+) :Volume up

Terminals

o

p

q

k

j

i

n

l

m

#PC input jack

VGA cable connection for PC.

$Analog audio (L/R) input jacks

Connect analog audio signals from;

–HDMI-DVI / Analog audio (L/R) jacks signal

–Component video / Analog audio (L/R) jacks signal

–Composite video / Analog audio (L/R) jacks signal

–PC connection / Analog audio (L/R) jacks signal with stereo mini 3.

5mm plug audio cable on PC

%Digital audio output jack

Digital audio (S/PDIF) output to home theaters and other digital audio

systems.

&Ethernet port

For internet connection using an Ethernet cable with an RJ-45

connector.

'Component (Y/Pb/Pr) / Composite video (VIDEO) input jack(s) for

VIDEO

Composite video input (VIDEO) jack is a shared jack with component

video input (Y) jack.

(HDMI input jack(s)

Digital audio and video input from high definition digital devices such

as DVD / Blu-ray disc players, cable / satellite set-top boxes, PC’s,

etc.

*For HDMI 1 only

In addition to normal HDMI and HDMI-DVI functionality, it outputs

TV audio to an HDMI-ARC-compliant device, such as a home

theater system.

)USB terminal

Data input from USB memory stick only.

Do not connect any device to this terminal such as digital camera,

keyboard, mouse, etc.

*75 ohm cable / Antenna connection

Signal input from an antenna or cable / satellite set-top boxes.

+Headphone audio output jack

Headphone 3.5mm stereo jack for personal listening.

13 .English

Continued on next page.

Connecting Antenna or Cable / Satellite /

IPTV set-top box

Be sure your antenna or another device is connected properly before

plugging in the AC power cord.

If connecting to an antenna through an RF cable

Any DTV programs that are broadcast in your area can be received for

free through an antenna connection.

IN

IN

OUT

OUT

RF cable

RF cable

RF cable

Antenna

Antenna

Antenna

Cable

Cable

Cable

If connecting Cable / Satellite / IPTV set-top box using an RF

cable

If the TV is connected to a cable or set-top box via a coaxial connection,

set the TV to channel 3/4 or the channel specified by the service

provider.

IN

ININ

Antenna

AntennaAntenna

Set-top Box

Set-top BoxSet-top Box

RF cable

RF cableRF cable

OUT

OUTOUT

IN

ININ

RF cable

RF cableRF cable

If connecting Cable / Satellite / IPTV set-top box using an HDMI

cable

If the TV is connected to a cable / satellite set-top box via an HDMI cable,

make sure you select the correct source by using SOURCE.

IN

IN

IN

INININ

ININ

OUT

OUT

OUT

Set-top Box

Set-top Box

Set-top Box

RF cable

RF cable

RF cable

HDMI cableHDMI cable

HDMI cableHDMI cable

HDMI cableHDMI cable

If connecting Cable / Satellite / IPTV set-top box using

component video input

If the TV is connected to a cable / satellite set-top box via component

video input, make sure you select the correct component video source

by using SOURCE.

Set-top Box

Set-top Box

Set-top Box

IN

IN

IN

RF cable

RF cable

RF cable

OUT

OUT

OUT

Component (Y/Pb/Pr)

Video cables

Component (Y/Pb/Pr)

Video cables

Component (Y/Pb/Pr)

Video cables

IN

IN

OUT

OUT

OUT

Audio (L/R) cables

Audio (L/R) cables

Audio (L/R) cables

IN

IN

Connecting a Cable / Satellite / IPTV set-top box, Blu-

ray disc / DVD recorder via composite connectors and

analog audio

Do not place your recorder too close to the screen because some recorders

can be susceptible to harmful interference from the TV.

Cable

Cable

Cable

OUT

OUT

OUT

RF cable

RF cable

RF cable

IN

IN

IN

OUT

OUT

OUT

IN

IN

IN

OUT

OUT

OUT

IN

IN

IN

OUT

OUT

OUT

RF cable

RF cable

RF cable IN

IN

IN

Satellite

Satellite

Satellite

IN

IN

Cable

Cable

Cable

Set-top Box

Set-top Box

Set-top Box

Video +

Audio(L/R)

cables

Video + Audio(L/R) cables

Video + Audio(L/R) cables

Video + Audio(L/R) cables

Blu-ray Disc / DVD Recorder

Note(s)

•If you have any question about the DTV’s antenna, visit www.antennaweb.org for further

information.

•Depending on your antenna system, you may need different types of combiners (mixers) or

separators (splitters) for HDTV signal. The minimum RF bandpass on these devices is 2,000MHz

or 2GHz.

•For your safety and to avoid damage to this unit, please unplug the RF coaxial cable from the

antenna input jack before moving the unit.

•If you did use an antenna to receive analog TV, it should also work for DTV reception. Outdoor

or attic antennas will be more effective than a set-top box or inside antenna.

•To turn on your reception source easily between antenna and cable, install an antenna

selector.

•If you are not receiving a signal from your cable service, contact the cable provider.

Plugging in the AC power cord

Make sure that the AC power cord must be plugged to an AC outlet after

all the necessary connections are made.

Caution(s)

•Connect the analog audio signal cables from the external device to the analog audio L/R input

jacks.

•If you have an amplifier, connect the HDMI cable to the HDMI input via your amplifier.

Note(s)

•Each time you plug in the AC power cord, no operations will be performed for several seconds.

This is not a malfunction.

14 .English

Continued on next page.

No supplied cables are used with these connections:

•Please purchase the necessary cables at your local store.

B

Before you connect the AC power cord:

Be sure other devices are connected properly before plugging in the AC

power cord.

Selecting your connection quality

HDMI - Highest quality

Supports high-definition digital signals and gives highest picture and

sound quality. Video and audio signals are combined in one cable. You

must use HDMI for full high-definition video and to enable

EasyLink(HDMI CEC).

Note(s)

•Philips HDMI supports HDCP (High-bandwidth Digital Contents Protection). HDCP is a form of

digital rights management that protects high-definition content in Blu-ray discs or DVDs.

•The HDMI-ARC connector on the TV features HDMI-ARC functionality. This allows output of

TV audio to an HDMI-ARC-compliant device.

Component (Y Pb Pr) - High quality

Supports high-definition analog signals but gives lower picture quality

than HDMI. Component (Y/Pb/Pr) video cables combine red / green /

blue video cables with red / white audio (L/R) cables. Match the cable

colors when you connect to the TV.

Composite - Basic quality

For analog connections. Composite video / Audio analog cable usually

combine a yellow video cable with red / white audio (L/R) cables. With

this unit, yellow cable must be connected to Y (green) jack on the

component video input jacks.

Connecting your devices

HDMI digital connection

HDMI connection offers the highest picture quality.

HDMI (High-Definition Multimedia Interface) transports high-definition

digital video and multi-channel digital audio through a single cable.

HD game console

HD game console

HD game console

or

or

Blu-ray Disc / DVD Player

Blu-ray Disc / DVD Player

Blu-ray Disc / DVD Player

or

or

or

Set-top Box

Set-top Box

Set-top Box

OUT

OUT

OUT

IN

IN

IN

HDMI cable

HDMI cable

HDMI cable

Note(s)

•If there are issues with picture/color and/or sound when connecting an external device using

the HDMI port, please try switching the HDMI mode. (Refer to HDMI mode  p. 35)

•Some HDMI cables and devices may not be compatible with the TV due to different HDMI

specifications.

•Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

recommended for the better compatibility.

•The unit accepts 480i / 480p / 720p / 1080i, 1080p, 2160p 24/30/60Hz of video signals, 32kHz/

44.1kHz and 48kHz of audio signals.

•This unit accepts LPCM, AC-3, DD+ audio signal.

•This unit accepts only signals in compliance with EIA861.

HDMI-DVI connection

This unit can be connected to your device that has a DVI terminal.

Use an HDMI-DVI conversion cable for this connection and it requires

audio cable for analog audio signal as well.

Cable Receiver or

Satellite Set-top Box with

the DVI Output jack

Cable Receiver or

Satellite Set-top Box with

the DVI Output jack

Cable Receiver or

Satellite Set-top Box with

the DVI Output jack

OUT

OUT

OUT

HDMI-DVI

conversion cable

HDMI-DVI

conversion cable

HDMI-DVI

conversion cable

IN

IN

OUT

OUT

OUT

Audio (L/R) cables

Audio (L/R) cables

Audio (L/R) cables

IN

IN

Note(s)

•Some HDMI cables and devices may not be compatible with the TV due to different HDMI

specifications.

•Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

recommended for the better compatibility.

•The unit accepts 480i, 480p, 720p, 1080i, 1080p and 2160p video signals.

•HDMI-DVI connection requires separate audio connections as well and the audio signals are

output as analog (L/R) audio.

•DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

15 .English

Continued on next page.

HDMI-ARC connection

HDMI-ARC allows you to use EasyLink to output TV audio directly to a

connected audio device, without the need for an additional digital audio

cable.

OUT

HDMI cable

HDMI cable

HDMI cable

HDMI 1 IN only

HDMI 1 IN only

HDMI 1 IN only

Digital home theater

amplier that supports

HDMI-ARC

Note(s)

•The HDMI 1 connector is HDMI Audio Return Channel (ARC) compliant. Use it to output digital

audio to an HDMI home theater system.

•Be sure that the device is HDMI CEC and ARC compliant and that the TV is connected to the

device using an HDMI cable attached to HDMI-ARC connectors.

Component analog video connection

Component analog video connection offers better picture quality for

video devices connected to the unit.

If you connect to the unit’s component video (Y/Pb/Pr) input jacks,

connect analog audio cables to the analog audio (L/R) input jacks.

Blu-ray Disc / DVD

Recorder

Blu-ray Disc / DVD

Recorder

Blu-ray Disc / DVD

Recorder

or

or

or

Set-top Box

Set-top Box

Set-top Box

OUT

OUT

OUT

Component (Y/Pb/Pr)

Video cables

Component (Y/Pb/Pr)

Video cables

Component (Y/Pb/Pr)

Video cables

IN

IN

OUT

OUT

OUT

Audio (L/R) cables

Audio (L/R) cables

Audio (L/R) cables

IN

IN

Note(s)

•The unit accepts 480i, 480p, 720p, 1080i and 1080p of video signals for this connection.

Composite analog video connection

Composite analog video connection offers standard picture quality for

video devices connected to the unit.

If you connect to the unit’s component / composite video (Y/VIDEO) input

jack (green), connect audio cables to the audio (L/R) input jacks. When

the audio is monaural, then only connect to the audio L input jack.

DVD Player

DVD Player

DVD Player

OUT

OUT

OUT

IN

IN

IN

Video + Audio(L/R) cables

Video + Audio(L/R) cables

Video + Audio(L/R) cables

Note(s)

•With this unit, yellow cable must be connected to Y (green) jack on the component video input

jacks.

•Whenever you connect to the composite video input jack (Y/VIDEO), you must disconnect the

component video input jacks (Pb and Pr). If you leave those jacks connected, it may cause an

unstable picture.

Connecting the TV to the internet using an Ethernet

cable

LAN

Internet

Internet

Internet

Network provisioning

equipment

Network provisioning

equipment

Network provisioning

equipment

Ethernet cable

Ethernet cable

Ethernet cable

Note(s)

•Please purchase shielded Ethernet cables at your local store and use them when you connect

to network equipment.

•After connecting an Ethernet cable, set up necessary network settings. Connect to network 

p. 40

•Do not insert any cable other than an Ethernet cable to the Ethernet port to avoid damaging

the unit.

•If your telecommunications equipment (modem, etc.) does not have broadband router

functions, connect a broadband router.

•If your telecommunications equipment (modem, etc.) has broadband router functions but there

is no vacant port, then add a hub.

•For a broadband router, use a router which supports 10BASE-T / 100BASE-TX.

•Do not connect your PC directly to the Ethernet port of this unit.

16 .English

Continued on next page.

Connecting the TV to the internet using a wireless LAN

WLAN

LAN

Network provisioning

equipment

Ethernet cable

Broadband router

Broadband router

Broadband router

Internet

Note(s)

•After you make the wireless connection, set up the necessary network settings. Connect to

network  p. 40

•Use a wireless LAN Access Point (AP) (e.g. broadband wireless router) which supports

IEEE 802.1 1 a/b/g/n/ac. (n is recommended for stable operation of the wireless network.)

•This unit does not support Ad-hoc mode.

•Other radio devices or obstacles may cause interference to the wireless network connection.

Digital audio output connection

If you connect this unit to an external digital audio device, you can enjoy

multi-channel audio like 5.1ch digital broadcasting sound.

Use a digital audio optical cable to connect the unit to external digital

audio devices.

Digital Home

Theater Amplier

OUT

OUT

OUT

IN

IN

Digital Audio

Optical cable

Digital Audio

Optical cable

Digital Audio

Optical cable

PC connection

HDMI connection

This unit can be connected to your PC that has an HDMI terminal. Use an

HDMI cable for this digital connection.

PC

PC

OUT

OUT

OUT

HDMI cable

HDMI cable

HDMI cable

IN

IN

HDMI-DVI connection

This unit can be connected to your PC that has a DVI terminal.

Use an HDMI-DVI conversion cable for this video digital connection and

it requires stereo mini 3.5mm plug audio cable for analog audio signal as

well.

PC

PC

OUT

OUT

OUT

HDMI-DVI

conversion cable

HDMI-DVI

conversion cable

HDMI-DVI

conversion cable

IN

IN

IN

OUT

OUT

OUT

Stereo Mini 3.5 mm Plug Audio cable

Stereo Mini 3.5 mm Plug Audio cable

Stereo Mini 3.5 mm Plug Audio cable

IN

IN

VGA connection

This unit is equipped with a PC input jack. If you connect this unit to your

PC, you can use this unit as a PC monitor.

Use a VGA cable for this video connection and it requires a stereo mini 3.

5mm plug audio cable for analog audio signal as well.

PC

PC

OUT

OUT

OUT

VGA cable

VGA cable

VGA cable

IN

IN

IN

IN

IN

Stereo Mini 3.5 mm Plug Audio cable

Stereo Mini 3.5 mm Plug Audio cable

Stereo Mini 3.5 mm Plug Audio cable

17 .English

Continued on next page.

The following PC-input video signals can be displayed:

Format Resolution Refresh rate

VGA 640 x 480

60Hz

SVGA 800 x 600

XGA 1,024 x 768

WXGA 1,280 x 768

1,360 x 768

FHD 1,920 x 1,080

24/30/60Hz *2

UHD *1

3,840 x 2,160

4,096 x 2,160

Other formats or non-standard signals will not be displayed correctly.

*1 UHD format is available only when using the HDMI connection and

HDMI-DVI connection.

*2 Refresh rate for VGA connection is only 60Hz.

Note(s)

•Please purchase a VGA cable that has a ferrite core (0.6 inches (15mm) or more in diameter).

•Please purchase a HDMI-DVI conversion cable that has a ferrite core.

•The following operations may reduce noise.

–Attach a ferrite core to the AC power cord of your PC.

–Unplug the AC power cord and use the built-in battery of your portable / laptop PC.

•Some HDMI cables and devices may not be compatible with the TV due to different HDMI

specifications.

•Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

recommended for the better compatibility.

•The unit accepts 480i, 480p, 720p, 1080i, 1080p and 2160p video signals only when using the

HDMI connection and HDMI-DVI connection.

•HDMI-DVI connection requires separate audio connections as well and the audio signals are

output as analog (L/R) audio.

•DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

USB memory stick

This unit offers easy playback of picture, music and video files.

Insert the USB memory stick into the USB terminal shown below.

For a complete list of file formats and specifications supported, refer to

USB Section  p. 26

Note(s)

•The unit recognizes only a USB memory stick.

•Do not use a USB hub or an extension cable to connect an external hard disk drive to the unit.

(Not supported.)

•Always insert a USB memory stick directly to this unit.

•A USB memory stick is not supplied with this unit.

•We do not guarantee that all USB memory sticks can be supported by this unit.

•Be sure to keep a backup copy of the original files on your USB device before you play them

back on this unit. We have no responsibilities for damage or loss of your USB stored data.

•To protect your USB memory stick files from being erased place the write protect sliding tab in

the protect position (if available).

•When you are ready to remove a USB memory stick, set the unit to go into standby mode to

avoid any damage to your data and the unit.

•A USB memory stick that requires its own driver or the device with a special system such as

fingerprint recognition are not supported.

•This unit is not allowed to use the USB memory stick which requires an external power supply

(500mA or more).

18 .English

Continued on next page.

These operations are accessible by remote control.

Some may also be accessible by the main unit's control panel.

Initial setup

This section will guide you through the unit’s Initial setting which includes

selecting a language for your on-screen menu, country, location and

Autoprogram, which automatically scans and memorizes viewable

channels. You can also set the network connection in this setting.

B

Before you begin:

Make sure the unit is connected to an antenna or cable.

1After making all the necessary connections, press  to turn on the

unit.

•It may take a few moments to turn on the unit for the first time.

•Initial setup menu appears automatically after the unit is turned on.

2Use  to select the on-screen language, country, TV placement

and location in the middle of the TV screen, then press OK.

•You must set Home in location setting. Otherwise, Picture and

Sound settings you adjusted will not be memorized after the unit

goes into standby mode.

3Use  to select Skip or Next on network setup screen.

4Use  to select Wireless or Wired, then press OK.

1234 756

Skip

Wired

Wireless

This TV can be connected to

your home network. Select your

connection type.

Installation

Wireless If you have a wireless router, select Wireless to

connect to the internet.

Wired If you connect with an Ethernet cable, select Wired to

connect to the internet.

•If you have a router with WPS function, select Wireless and use







to Select Easy Connect, then press OK.

5Follow the on-screen instructions to complete the installation.

•When you select On in the selection screen for Auto software

update, A message will appear later if there is the latest software

on the network server.

6Use  to select the signal type.

•If the TV is connected to a cable or satellite set-top box, select the

2nd one and skip to step 8.

1234 756

Installation

Set-top box

Select "Set-top box" to set up a TV

signal from a cable TV box

or satellite TV receiver.

Antenna

Select "Antenna" to set up a TV

signal from a cable TV wall jack

or a standard TV antenna.

7Use  to select Antenna for TV channels or Cable for CATV

channels, then press OK.

1234 756

Installation

Skip

Cable

Antenna

Now select either Antenna or

Cable, using up/down key of the

remote control. Once you have

made your selection, press the

OK button to proceed.

Make sure that you have

attached your antenna or cable

signal into the jack on the back of

your TV labeled "ANTENNA IN".

–When Antenna is selected, the TV detects antenna signals. It

searches for DTV and analog TV channels available in your area.

–When Cable is selected, the TV detects signals supplied by cable.

It searches for DTV, analog TV and cable channels available in

your area.

•Auto programming will begin.

0

0

1234 756

Installation

Stop

Total progress:

Analog channels found:

Digital channels found:

Please wait until you see the Auto

Programming complete message.

Digital channels will take longer

than Analog to nd and program.

Auto programming may take more

than 20 minutes to complete.

System searching. Please wait…

19 .English

Continued on next page.

8Use  to select your preferred picture setting, then press OK.

21

Sports

Vivid

Please select your preferred picture mode.

Cancel

Energy consumption in “Standard” is Energy Star

compliant. “Natural” is calibrated to produce a

pristine image.

Natural

9Use  to select your preferred sound setting, then press OK.

21

Sports

Vivid

Standard

Skip

Please select your preferred sound mode.

10 After Picture and sound setup is completed, a message will appear

if there is the latest software on the network server.

Note(s)

•If you are not receiving a signal from your cable service, contact the cable provider.

•If you press  during Autoprogram, this setup of TV channels will be cancelled.

•The initial Autoprogram function can be executed for either Antenna or Cable only once. When

you change the connection (Antenna / Cable), select Search for channels again.  p. 37

A

After an initial setup is completed...

•If you want to scan the channels automatically again.

Search for channels  p. 37

•You can add the desired channels not memorized by Autoprogram

through antenna connection.

Weak channel installation  p. 37

•If you want to change to another language.

Language  p. 35

•If you want to change the country setting.

Country  p. 50

•If you want to change the location setting.

Location  p. 35

•If you want to change the network setting.

Connect to network  p. 40

•If you want to restore the picture and sound setting.

Picture and sound setup  p. 30

20 .English

3 Use your TV

Switching on your TV and putting it in

standby mode

Remote Control

TV

To turn the TV on from standby or off to standby

•Press  on the TV or the remote control.

Note(s)

•Energy consumption contributes to air and water pollution. When the AC power cord is plugged

in, your TV consumes energy with a very low standby power consumption.

Adjusting volume

Remote Control

TV

To decrease or increase volume

•Press VOL/ on the TV or press VOL + / – on the remote control.

VOL (–) : Volume down

VOL (+) : Volume up

To mute or unmute sound

•Press  on the remote control to mute the sound.

•Press  again or VOL + / – to recover the original sound.

Switching channels

Remote Control

TV

To select channels by using CH  /  or CH + / –

•Press CH (up) /  㸦down) on the TV or press CH + / – on the remote

control.

To select channels by using the NUMBER buttons

Digital TV operation

•For digital channels, press a number followed by a dot “•” and the

corresponding sub channel number.

–When selecting digital channel 1 1. 1

Be sure to press • before entering the subchannel number.

Cable / NTSC (Analog) TV operation

–When selecting cable or analog channel 1 1

Press PREV.CH to return to the previously viewed channel.

Note(s)

•To select the non-memorized channels, use the NUMBER buttons.

•Channel not available or No signal will appear on the TV screen after the subchannel broadcast

is over.

•Audio only message will appear on the TV screen, when you receive only sound signal.

21 .English

Continued on next page.

Watching channels from an external

device

Switching each input mode can easily switch with the remote control

between TV and external devices when they are connected to the unit.

1Turn on the set-top box or the connected device.

Press SOURCE and use  to select the set-top box or the

connected device and wait a few seconds till the picture appears.

HDMI3HDMI2HDMI1

Watch TV Video

Use the remote control of the set-top box or the connected device

to select channels.

Access the Home menu

1Press .

Guide to Home menu

SetupMiracastNet TVSource

Watch TV Home

Network

  Watch TV :Switches back to the TV source if another source

is selected.

  Source :To select connected devices.

  Home Network :Accesses Home network menus.

  Net TV :Accesses Net TV menus.

  Miracast :Accesses Miracast menus.

 Setup :Accesses menus that allow you to change picture,

sound and other TV settings.

Lock or unlock your device from the Home menu

This section describes how to lock or unlock specified device.

1Press SOURCE on the remote control.

2Use  to select a device to lock or unlock.

3Press OPTIONS on the remote control.

4Use  to select Lock or Unlock, then press OK.

•If device lock is unlocked, Lock will be displayed. If device lock is

locked, Unlock will be displayed at the top right of the device

icons.

5Enter your PIN. Change PIN  p. 39

Changing device type

You can change device icons displayed in the source list.

1Press SOURCE on the remote control.

2Use  to select the desired device.

3Press red button on the remote control.

4Use  to select the desired type, then press OK.

To reset the type

•Press OPTIONS on the remote control at step 3, then select Original

icon.

Scan connections

You can rescan TV connections and update the source list.

Before you begin:

You must set On in Master EasyLink.  p. 36

1Press SOURCE on the remote control.

2Use  to move the cursor to any device.

3Press OPTIONS on the remote control.

4Use  to select Scan connections, then press OK.

22 .English

Continued on next page.

Create a list of favorite channels

You can create lists of your preferred TV channels so that you can find

those channels easily.

1Press OK while viewing a TV program.

2Use  to select the desired channel, then press yellow

button.

3Use  to select the desired favorite list (Favorites 1 - Favorites 4),

then press OK to add or remove on the list of favorite channels.

• indicates that the channel is added.

• indicates that the channel is removed.

•The channel will be marked with ! icon.

Display the list of favorite channels

1Press OK while viewing a TV program.

2Use  to select Favorites.

T

To change the favorite list

1Press blue button.

2Use  to select the desired favorite list (Favorites 1 - Favorites 4).

To remove a channel from the favorite list

1Select the desired channel, then press yellow button.

2Use  to select Yes, then press OK.

Changing Picture format

Display modes can be selected when your TV receives a 16:9 or 4:3 video

signal.

Three types of display modes can be selected for a PC input signal.

Press FORMAT repeatedly to switch the TV aspect ratio.

For 16:9 video signal (4096 x 2160p)

FullUnscaled

For 16:9 video signal (3840 x 2160p)

FullUnscaled

For 16:9 video signal (not 2160p)

Wide screen

4:3Automatic

Full

Automatic

Other than DTV and HDMI connected devices,

enlarges the picture to best fit the screen. DTV and

HDMI connected devices display the picture at its

original size.

The subtitles may remain visible.

4:3

Displays a 16:9 picture at a 4:3 size; the picture is

shortened horizontally. Sidebars appear on both

edges of the screen.

Wide screen Displays a 16:9 picture that is stretched

horizontally and vertically.

Unscaled Displays a 16:9 picture at its original size.

Full

Displays a scaled 16:9 picture. Bars appear on both

the upper and lower portions of the screen

depending on the type of video signal.

23 .English

Continued on next page.

For 4:3 video signal

Wide screen

Movie expand 16:9

Movie expand 14:9

4:3Super zoomAutomatic

Automatic

Other than DTV and HDMI connected devices,

enlarges the picture to best fit the screen.

DTV and HDMI connected devices display the

picture at its original size. The subtitles may remain

visible.

Super zoom

Displays a 4:3 picture at a 16:9 size; the picture is

stretched horizontally and vertically and its left

and right edges are enlarged. This crops out some

of the top and bottom of the picture.

4:3 Displays a 4:3 picture at its original size.

Sidebars appear on both edges of the screen.

Movie expand 14:9

Displays a 4:3 picture at a 14:9 size; the picture is

stretched horizontally and vertically.

This crops out some of the top and bottom of the

picture. Sidebars appear on both edges of the

screen.

Movie expand 16:9

Displays a 4:3 picture at a 16:9 size; the picture is

stretched horizontally and vertically. This crops

out some of the top and bottom of the picture.

Wide screen Displays a picture that is stretched out of

proportion to fill the screen.

For PC input signal

UnscaledWide screen4:3

•This unit can also be connected to your PC that has a DVI terminal.

Use an HDMI-DVI conversion cable for this video connection and it

requires stereo mini 3.5mm plug audio cable for analog audio signal as

well.

•Refer to 16:9 video signal on this page if the PC has HDMI output.

4:3 Displays a proportionately stretched picture.

Sidebars appear on both edges of the screen.

Wide screen Displays a picture that is stretched out of

proportion to fill the screen.

Unscaled Displays a picture in its original size.

If the signal source has side or top-bottom bars inserted into the picture,

the Picture format function will not eliminate them.

TV screen information

You can display the currently selected channel or other information such

as the aspect ratio on the TV screen.

In the digital mode, the detailed broadcasting information for the current

off-the-air channel such as program title and program guides are

displayed.

1Press INFO.

e

f

g

i

h

ba c d

1

1.1 KABC A Day of Memories

1080i

None

All

English

Stereo

Full

Sleeptimer:

Rating:

Favorites:

Audio language:

Sound mode:

Picture format:

Resolution:

English audio with description.

Close

Channel number / Input mode

Switching channels  p. 21

Watching channels from an external device  p. 22

Broadcast station

Program title (for DTV only)

CC (not available if Closed caption is set to Off)

Caption settings  p. 33

Program’s image aspect ratio

Changing Picture format  p. 23

Audio language (DTV) / Audio mode (Analog TV)

Sound  p. 32

!Favorites

Create a list of favorite channels  p. 23

"Child lock rating

Child lock  p. 38

#Remaining time on sleep timer

Sleeptimer  p. 34

2Press INFO to hide the information.

Note(s)

•While the program guide is displayed, the closed caption function is interrupted.

•The information display will automatically disappear in 5 seconds.

24 .English

Continued on next page.

Using options menu

You can access to some TV settings directly by using OPTIONS.

1Press OPTIONS to display options menu, then press OK.

2Use  to select a desired setting, then press OK.

a b c d

Options

Options

Following settings can be configured.

Closed captions To choose the Closed captions display setting.

Closed captions  p. 33

Digital audio

language

To Select the language according to your

preference.

(It differs depending on the program.)

Digital audio language  p. 39

Mono/Stereo To Select an audio format.

Mono/Stereo  p. 39

Controls

If you have our brand products such as Blu-ray disc player or DVD

recorder that are compatible with EasyLink functions, connect them

to this unit via an HDMI cable so you can simply operate various items

from this unit’s remote control.

B

Before you begin:

select a device connected to an HDMI connection.  p. 22

You must set On in Master EasyLink.  p. 36

Otherwise, LINK does not work even if you connected our brand

devices to this unit.

1Press OPTIONS to display options menu.

2Use  to select Controls then press OK.

3Use  to select the desired item, then press OK.

Device-menu Controls the menu of your connected EasyLink

device.

Device-contents Controls the top menu of your DVD or Blu-ray

discs.

Device-favorite Controls the pop-up menu of your Blu-ray discs.

Note(s)

•Some of EasyLink functions may not be available depending on your EasyLink devices or

discs.

•You must connect this unit to our brand EasyLink devices and be sure its EasyLink (HDMI CEC)

setting is also set to On.

•We do not guarantee 100% interoperability with other brands of HDMI link compliant devices.

Picture and sound

Following settings can be configured.

Auto picture To set predefined picture mode.

Picture  p. 30

Auto sound To set predefined sound mode.

Sound  p. 32

Headphone

volume

To adjust headphone volume.

Sound  p. 32

TV speakers

To Select the audio output from the unit’s

speakers or not.

Sound  p. 32

Picture format To switch the TV aspect ratio.

Changing Picture format  p. 23

Setup To display setup menu.

ECO settings

Following settings can be configured.

Switch off timer

You can turn off the unit automatically when there

is no operation for specified time. In spite of this

setting, the unit goes into standby mode

automatically if there is no signal input and no user

operation for 15 minutes.

Press  repeatedly to change the amount of time

(increases the time by 30 minutes up to 240

minutes).

Each press of  will decrease the time by 30

minutes.

To cancel the timer, press  repeatedly until “0” is

displayed.

Light sensor To set light sensor On or off.

Picture  p. 30

25 .English

Continued on next page.

USB

Your TV is fitted with a USB connection that enables you to view photos,

listen to music or watch video files stored on a USB memory stick.

1Press SOURCE and use  to select USB, then press OK.

2Use  to select the desired file, then press OK.

Sample picture.jpg

folder_A folder_B folder_C folder_D folder_E



•These recorded files must meet specifications shown below:

Picture (JPEG / Progressive JPEG)

JPEG Upper limit 4000x4000 pixels

Progressive JPEG Upper limit 1024x768 pixels

Music (MP3 / WAV / AAC)

MP3 Sampling frequency 16 kHz - 48 kHz

Constant bit rate 8 kbps - 320 kbps

WAV Sampling frequency 8 kHz - 48 kHz

Constant bit rate 64 kbps - 1.5 Mbps

AAC Sampling frequency 8 kHz - 48 kHz

Constant bit rate -

Video (MPEG / VOB / AVI / MP4)

Maximum video H.264, H.265/HEVC: 3840x2160@30fps,

MPEG: 1920x1080@60fps

Extension .avi .mpg,

.mpeg

.ts,

.trp,

.tp

.vob .mp4 .mkv

Video

codec

Audio

codec

MPEG1,

MPEG2,

MPEG4,

H.264

MPEG1,

MPEG2,

MPEG4

MPEG1,

MPEG2,

H.264,

H.265/

HEVC

MPEG1,

MPEG2

MPEG1,

MPEG2,

MPEG4,

H.264,

H.265/

HEVC

MPEG1,

MPEG2,

MPEG4,

H.264,

H.265/

HEVC

Dolby Digital YES YES YES YES YES YES

MPEG1/2 audio

layer1/2/3 YES YES YES YES NO YES

LPCM YES YES YES YES YES YES

AAC-LC YES YES YES YES YES YES

Note(s)

•This unit accepts USB memory stick only. Other storage devices such as external HDD by USB

bus power will not work.

•Do not use an extension cord and/or USB hub to connect devices to this unit. Always directly

insert the USB flash memory stick to this unit directly.

•We cannot be held responsible if your USB memory stick is not supported, nor will we accept

any liability for damage or loss of stored data.

•The USB memory stick is not supplied with this TV.

•A maximum of 1,023 folders or files can be recognized.

•A file name exceeding 256 characters or contains a dot character is not supported on this TV.

•A USB memory stick that required its own driver or the device with a special system such as

fingerprint recognition are not supported.

•Be sure to keep a backup copy of the original files on your USB device before you play them

back on this unit. We have no responsibilities for damage or loss of your USB stored data.

•To avoid damaging the USB memory stick and the unit always turn off the unit before you

remove the USB memory stick.

•This unit is not allowed to use the USB memory stick which requires external power supply (500

mA or more).

•This unit does not support MTP (Media Transfer Protocol) or the file other than FAT16 and FAT32

file system. If the file is not supported, an error message appears.

•When the unit does not recognize the USB memory stick, try reconnecting it.

•Playing the files recorded with high bit rates, the images can be interrupted in some occasions.

•This unit does not support external subtitles.

•This unit cannot play back a file which goes over the limit of file restriction limit.

26 .English

Continued on next page.

Viewing photos

1Use  to select Photo, then press OK.

2Use  to select the desired item, then press OK.

3Press OK or . to start a slide show of the files.

•Press OK or . to pause the slide show.

•The . icon appears.

•Press  or  to move between images.

•Press BACK or . to stop the slide show.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat *1

Off Sets repeat playback to off.

One Sets repeat playback for a selected image file.

All Sets repeat playback for all image files in the

current folder.

Slide time *1

Short Switches to the next image in 5 seconds.

Medium Switches to the next image in 10 seconds.

Long Switches to the next image in 15 seconds.

Transitions *1

None No effect when switching images.

Dissolve Overlaps the next image on the current image.

Wipe right Pushes the current image out from left.

Wipe left Pushes the current image out from right.

Wipe up Pushes the current image out from bottom.

Wipe down Pushes the current image out from top.

Box in The next image comes to the center from the

outside.

Box out The next image goes to the outside from the

center.

Rotate *2

0Displays an image in its original direction.

90 Rotates an image 90 degrees clockwise.

180 Rotates an image 180 degrees clockwise.

270 Rotates an image 270 degrees clockwise.

Zoom *2

1X Displays an image in its original size.

2X Magnifies a current image by 2 times.

4X Magnifies a current image by 4 times.

Auto picture *1

Selects the picture mode according to your preference.

(Standard, Natural, Vivid, Sports, Movie, Game, Energy saving

and Internet video)

*1 You can set Repeat, Slide time, Transitions and Auto picture when

images are in slide show.

*2 You can set Rotate and Zoom when slide show is in pause mode.

Playing music

1Use  to select Music, then press OK.

2Use  to select the desired item, then press OK.

3Press OK or . to play the selected files.

•Press OK or . to pause, then press OK or . again to resume.

•Press  to fast-forward search.

•Press  to fast-backward search.

•Press . to stop playback.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat

Off Sets repeat playback to off.

One Sets repeat playback for a selected music

file.

All Sets repeat playback for all music files in

the current folder.

Shuffle

Off Sets shuffle playback to Off.

On Sets shuffle playback for all music files in

the current folder.

TV Speakers

Off The sound will not be output from the

unit's speakers.

On The sound will be output from the unit's

speakers.

Speakers

EasyLink

You can control audio output from your

connected EasyLink compliant devices

with VOL + / – by using this unit's remote

control.

Auto sound Selects the sound mode according to your preference.

(Standard, Vivid, Sports, Movie, Music and News)

27 .English

Continued on next page.

Playing movies

1Use  to select Movie, then press OK.

2Use  to select the desired item, then press OK.

3Press OK or . to play the selected files.

•Press OK or . to pause, then press OK or . again to resume.

•Press  to fast-forward search.

•Press  to fast-backward search.

•Press . to stop playback.

Press . to resume from the point at which playback was stopped.

Press OK to play from the beginning of the file.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat

Off Sets repeat playback to off.

One Sets repeat playback for a selected video

file.

All Sets repeat playback for all video files in

the current folder.

TV speakers

Off The sound will not be output from the

unit's speakers.

On The sound will be output from the unit's

speakers.

Speakers

EasyLink

You can control audio output from your

connected EasyLink compliant devices

with VOL + / – by using this unit's remote

control.

Auto picture

Selects the picture mode according to your preference.

(Standard, Natural, Vivid, Sports, Movie, Game, Energy

saving and Internet video)

Auto sound Selects the sound mode according to your preference.

(Standard, Vivid, Sports, Movie, Music and News)

Note(s)

•The resume information will be kept even when the unit is Turned off.

•If you play another file while the previously viewed file is being resumed, the resume information

of the previously viewed file will be deleted.

•The file or the folder in resume stop mode will be highlighted in gray on List or Thumbnails.

28 .English

4 Getting more from your

TV

This section describes the overview of the Setup menu displayed when

you press  and use  to Select Setup.

The Setup menu consists of the function setting items below.

1Press  to display the Home menu.

2Use  to select Setup, then press OK.

Setup

MiracastNet TVSource Home

Network

TV

3Use  to select the desired menu and an item, then press OK.

To quickly set basic picture and sound settings, press OK

Software

settings

Network

settings

Channel

settings

TV

settings

Update

software

Connect to

network

Search for

channels

Picture and

sound setup

Picture and sound

setup  p. 30

Guides you to get the best picture and sound settings.

TV settings  p. 30

Accesses menus that allow you to change picture, sound and

TV usage settings.

Search for channels  p. 37

Guides you through channel installation.

Channel settings  p. 37

Accesses menus that allow you to change channel settings.

Connect to network  p. 40

Guides you through network installation.

Network settings  p. 41

Accesses menus that allow you to network settings.

Update software  p. 45

Guides you through an update of the TV software.

Software settings  p. 46

Accesses menus that allow you to change software settings.

29 .English

Continued on next page.

Picture and sound setup

B

Before you begin:

You must set Home in Location.  p. 35

Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

1Press  and use  to select Setup then press OK.

2Use  to select Picture and sound setup, then press OK.

3Follow steps 8 to 9 in Initial setup  p. 20

TV settings


Before you begin:

You must set Home in Location.  p. 35

Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

1Press  and use  to select Setup then press OK.

2Use  to select TV settings, then press OK.

3Use  to select Picture, then press OK.

Clock

Auto adjustment

Mode selection

Picture format

Advanced settings

Sharpness

Tint

Color

Brightness

Contrast

Backlight

Auto picture

Installation

Features

Sound


4

Use















to select the item you want to adjust, then press OK.

The following picture settings can be configured. Depending on the

format of the picture source, some picture settings are not available.

Auto picture

To set your TV to a predefined picture setting.

Personal The customized settings you

defined using the Picture menu.

Standard For normal TV viewing.

Natural

Ideal picture mode for viewing high

quality content without any picture

enhancements.

Vivid

Enhanced picture contrast and

sharpness for viewing in a well-lit

room.

Sports Brilliant picture settings for high

action.

Movie Deep picture settings for a

cinematic experience.

Game Optimized for PCs and game

consoles.

Energy saving Eco TV settings for low power

consumption.

Internet video Optimized for low bit-rate internet

video.

When you adjust the following settings, Personal picture will be set

automatically.

Cursor Cursor 

Backlight

To reduce power

consumption and

brightness

To increase power

consumption and

brightness

Contrast To decrease contrast To increase contrast

Brightness To decrease brightness To increase brightness

Color To decrease color

intensity

To increase color

intensity

Tint To add green To add red

Sharpness To soften To sharpen

Advanced settings

To select the desired setting, then press OK

(Color alignment, Noise reduction, Light sensor,

Black stretch, Dynamic contrast, Gamma, Perfect

Motion Rate, 4K UHD Upscaling, Macro Dimming,

MPEG artifact reduction, Color enhancement,

Custom color management and Film mode)

Picture format

Automatic

Changing Picture

format  p. 23

Super zoom

4:3

Movie expand 14:9

Movie expand 16:9

Wide screen

Full

Unscaled

Mode selection

PC

To turn off image

enhancement features

which makes the TV to

act purely as a monitor

HDTV

To enable image

enhancement features

to improve picture

quality

Auto adjustment To adjust the horizontal / vertical position, clock

and phase of the PC screen automatically

Cursor Cursor 

Clock To decrease setting

value

To increase setting

value

Phase

Horizontal position To move PC screen left To move PC screen right

Vertical position To move PC screen

down To move PC screen up

30 .English

Continued on next page.

Y

You can set a particular picture quality using Advanced settings.

Blue oset

Green oset

Red oset

Blue gain

Green gain

Red gain

Mode

4K UHD Upscaling

Film mode

Custom color management

Color enhancement

MPEG artifact reduction

Perfect Motion Rate

Gamma

Dynamic contrast

Black stretch

Light sensor

Noise reduction

Color alignment

Clock

Auto adjustment

Mode selection

Picture format

Advanced settings

Sharpness

Tint

Color

Brightness

Contrast

Backlight

Auto picture

Macro Dimming

Color

alignment

Mode

To set the color temperature to Personal,

Cool, Normal and Warm.

When you adjust the following settings,

Personal will be set automatically.

Cursor Cursor 

Red gain To decrease red

contrast

To increase red

contrast

Green gain To decrease green

contrast

To increase green

contrast

Blue gain To decrease blue

contrast

To increase blue

contrast

Red offset To decrease red

brightness

To increase red

brightness

Green offset To decrease green

brightness

To increase green

brightness

Blue offset To decrease blue

brightness

To increase blue

brightness

Noise

reduction

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

Light sensor

Off To set light sensor to off

On

To adjust backlight for the best picture

quality by dynamically adjusting the

backlight intensity in accordance with

lighting condition in the room

Black

stretch

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

Dynamic

contrast

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

Gamma

To select the desired setting, then press OK

(Very Dark Room, Dark Room, Normal, Bright Room and

Very Bright Room)

Perfect

Motion Rate

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

4K UHD

Upscaling

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

Macro

Dimming

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

MPEG

artifact

reduction

To select the desired setting, then press OK

(Off, Minimum, Medium and Maximum)

Color

enhancement

Off To set color enhancement to off

On To make colors more vivid and bright

Custom color

management

To select the desired setting, then press OK

(Red, Yellow, Green, Cyan, Blue and Magenta)

Cursor Cursor 

Tint

To rotate only

selected color tint in

clockwise direction

To rotate only

selected color tint in

counterclockwise

direction

Saturation

To decrease color

with only selected

color

To increase color

with only selected

color

Brightness

To decrease

brightness with only

selected color

To increase

brightness with only

selected color

Film mode

Off To set film mode to off

Auto To optimize the picture recorded by the

original film

Note(s)

•Mode selection is available only if

–The external input modes are selected HDMI 1, HDMI 2 or HDMI 3.

–The connected HDMI device is outputting a video signal.

•Adjusts backlight for the best picture quality by dynamically adjusting the backlight intensity in

accordance with lighting condition in the room when Light sensor is set to On. Please ensure

the room lighting is stable and the light sensor is not blocked.

31 .English

Continued on next page.

Sound

B

Before you begin:

You must set Home in Location.  p. 35

Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

1Press  and use  to select Setup then press OK.

2Use  to select TV settings, then press OK.

3Use  to select Sound, then press OK.

Delta volume

Digital output format

Headphone volume

TV speakers

Auto volume leveling

Sonic Emotion Premium

Balance

Equalizer

Auto sound

Installation

Features

Sound


4Use  to select the item you want to adjust, then press OK.

The following sound settings can be configured. Depending on the format

of the broadcasting, some sound settings are not available.

Auto sound

To set your TV to a predefined sound setting.

When you adjust the following settings (Equalizer,

Sonic Emotion Premium and Auto volume leveling),

Personal sound will be set automatically.

Personal The customized settings you

defined using the Sound menu.

Standard For normal TV viewing.

Vivid Enhanced sound.

Sports Clear sound for high action.

Movie Powerful sound settings for a

cinematic experience.

Music Optimized for music playback.

News Set the anchor's voice at a

comfortable volume.

Adjust the tonal quality for each frequency.

Equalizer

Cursor Cursor 

To adjust each level of tonal quality

Press BACK to go back to the previous menu.

Adjust the speakers to suit your listening preference.

Balance Cursor Cursor 

To adjust the balance of the right and left speakers

This selects sound modes for more spatial or surround sound

reproduction.

Sonic

Emotion

Premium

Sonic

Emotion

Off To set Sonic Emotion to off

On To set Sonic Emotion to on

Dialog

Enhancement

Off To set Dialog Enhancement to off

On To set Dialog Enhancement to on

Bass

Enhancement

Off To set Bass Enhancement to off

On To set Bass Enhancement to on

Absolute 3D

Sound

Off To set Absolute 3D Sound to off

On To set Absolute 3D Sound to on

This function keeps a constant Loudness differential between the TV

commercials and the programs.

Auto volume

leveling

Off To remove the Auto volume

leveling

On

To reduce volume differences

between the TV commercials and

the programs

You can select the audio output from the unit’s speakers or not. If your

amplifier is HDMI link function compatible and connected by an HDMI

cable to this unit, some sound operations such as volume up can be

changed by using this unit’s remote control. Make sure Master EasyLink

is set to On.  p. 36

TV speakers

Off No output sound from the unit’s

speakers

On To output sound from the unit’s

speakers

Speakers

EasyLink

To control audio output from your

connected EasyLink compliant

devices with VOL + / – by using this

unit's remote control.

Adjust headphone volume.

Headphone

volume

Cursor Cursor 

To decrease or increase volume

You can set the digital audio output format from SPDIF/ARC.

Digital output

format

PCM To output PCM format

Bitstream

To output audio in its native format

as Bitstream to connected audio

receiver

If a channel or input device is too loud or too soft, navigate to that channel

or input device.

Delta volume

Cursor Cursor 

Provides the ability to set a custom volume level

for the current channel or input source.

If the source volume is too loud, set a negative

value (-1 to -12)

If the source volume is too soft, set a positive value

(+1 to +12)

32 .English

Continued on next page.

Features

1Press  and use  to select Setup then press OK.

2Use  to select TV settings, then press OK.

3Use  to select Features, then press OK.

Power indicator

Digital audio preferences

Sleeptimer

Caption settings

Installation

Features

Sound


4Adjust the following items.

Caption settings

Closed captions displays the audio portion of the program as

superimposed text over the video.

1Use  to select Caption settings, then press OK.

CC w/ mute

On

O

Digital caption options

Digital caption service

Caption service

Closed captions

Power indicator

Digital audio preferences

Sleeptimer

Caption settings

Closed captions

Off Closed caption is not displayed.

On Closed caption is always displayed.

CC w/ mute Closed caption is displayed when

the sound is off.

Digital TV operation

In addition to the basic closed caption, DTV has its own closed caption

called digital caption service. Use this menu to change the settings for

digital caption service.

Digital caption

service CS-1 to CS-6

Select one of these before

changing any other item in Caption

settings menu. Choose CS-1 under

normal conditions.

You can choose the size, font, color, background and other characteristics

of the caption text.

Digital caption

options

Reset to

default

You can reset the status of digital

caption options.

You can change closed captioning font style, size,

color and transparency.

(Font style, Font size, Font color and Font

opacity)

You can change background color and

transparency of the displayed caption.

(Background color and Background opacity)

You can change edge color and type of the

displayed caption text.

(Edge color and Edge type)

So, you must be Philip. Hi!

So, you must be Philip. Hi!

I’m pleased to meet you.

I’m pleased to meet you.

So, you must be Philip. Hi!

I’m pleased to meet you.

(Background color and Background opacity)

Background

(Edge color and Edge type)

Text edge

(Font style, Font size, Font color and Font opacity)

Text font

Picture display

•Review your setting choice made above by looking in the upper left

corner of the displayed setting box (not all selections show the

differences selected).

Cable / NTSC (Analog) TV operation

Caption service

CC-1 and T-1

The primary closed captions and

text services. The closed captions

or text is displayed in the same

language as the program’s dialog

(up to 4 lines of script on the TV

screen).

CC-3 and

T-3

Serve as the preferred data

channels. The closed captions or

text is often a secondary language.

CC-2, CC-4,

T-2 and T-4

Rarely available and broadcasters

use them only in special conditions,

such as when CC-1 and CC-3 or T-1

and T-3 are not available.

•There are 3 display modes according to programs:

Paint-on Displays characters on the TV screen immediately.

Pop-on Once characters are stored in memory, they are

displayed all at once.

Roll-up Displays the characters continuously by scrolling

(max. 4 lines).

33 .English

Continued on next page.

Note(s)

•Digital caption service that you can switch differs depending on the broadcast description.

•Closed captioning service may not be controlled by this unit’s menu options if you are watching

television through an external cable or satellite set-top box. In which case you will need to use

the menu options on the external set-top box to control closed captioning.

•The captions do not always use correct spelling and grammar.

•Not all TV programs and product commercials include closed caption information. Refer to your

area TV program listings for the TV channels and times of closed caption shows. The captioned

programs are usually noted in the TV listings with service marks such as CC.

•Not all captioning services are used by a TV channel during the transmission of a closed caption

program.

•Closed caption will NOT be displayed when you are using an HDMI or a component

connection.

•To show the closed caption on your TV screen, broadcast signal must contain the closed caption

data.

•Not all TV programs and commercials have the closed caption or all types of the closed

caption.

•Caption's and text may not exactly match the TV voice.

•Changing channels may delay the closed caption for a few seconds.

•Adjusting or muting the volume may delay the closed caption for a few seconds.

•Abbreviations, symbols and other grammatical shortcuts may be used in order to keep pace

with the on-screen action. This is not a malfunction.

•The caption or text characters will not be displayed while the Home menu or functions display

is shown.

•If a black box appears on the TV screen, this means that the closed caption is set to the text

mode. To clear the box, select CC-1, CC-2, CC-3 or CC-4.

•If the unit receives poor quality television signals, the captions may contain errors or there might

be no captions at all. Some possible causes of poor quality signals are:

–Automobile ignition noise

–Electric motor noise

–Weak signal reception

–Multiplex signal reception (ghosts or screen flutter)

–Data dropout and pixelation (for DTV only)

•The unit retains the closed caption setting if the power fails.

•When the unit receives special effects playback signal (e.g. search, slow and still) from a VCR’s

video output channel (ch3 or ch4), the unit may not display the correct caption or text.

•The EUT setting that satisfies § 79.102 (e) is as follows:

–Font: Mono-font

–Character size: Large

Sleeptimer

Sleep timer can set the unit to go into standby mode after an incremental

period of time.

1Use  to select Sleeptimer, then press OK.

2Use  repeatedly to change the amount of time

(increases the time by 5 minutes up to 180 minutes).

•Each press of  will decrease the time by 5 minutes.

•Press INFO once to call up the display for checking the remaining

time.

•To cancel the sleep timer, press  repeatedly until “0” is

displayed.

Digital audio preferences

You can set the interpretive broadcasting by an audio explanation.

1Use  to select Digital audio preferences, then press OK.

Power indicator

Digital audio preferences

Sleeptimer

Caption settings

Primary audio selection criteria

Audio language

Accessibility

Accessibility

To prioritize VI-Visually Impaired streaming or HI-

Hearing Impaired streaming: The setting for

handicapped users (Main audio, Visually

Impaired or Hearing Impaired).

Audio language To set your preferred language in the audio

streaming (English, Spanish or French).

Primary audio

selection criteria

To set TV priority based on either of the above

settings: (Accessibility or Audio language).

Power indicator

To set power indicator on or off.

1Use  to select Power indicator, then press OK.

Power indicator

Digital audio preferences

Sleeptimer

Caption settings

On

O

Installation

1Press  and use  to select Setup then press OK.

2Use  to select TV settings, then press OK.

3Use  to select Installation, then press OK.

Installation

Features

Sound


Restore default settings

Preferences

Language

4Adjust the following items.

34 .English

Continued on next page.

Language

You can set the language for the on-screen display.

1Use  to select Language, then press OK.

Installation

Features

Sound


Español

Français

English

Restore default settings

Preferences

Language

2Use  to select English, Español or Français, then press OK.

Note(s)

•If you need the English menu instead of the Spanish or French menu’s, press .

Use  to select Configuración or Configuration, then press OK.

Use  to select Ajustes de TV or Réglages de la télévision, then press OK.

Use  to select Instalación or Installation, then press OK.

Use  to select Idioma or Langue, then press OK.

Use  to select English, then press OK.

Press  to exit the Home menu.

Preferences

You can set the unit to reduce the power consumption or adjust the

backlight brightness in Location setting.

EasyLink allows you to operate your connected EasyLink device.

S

Setting your location to home

Choosing Home gives you full flexibility to change predefined settings for

picture and sound.

1Use  to select Preferences, then press OK.

2Use  to select Location, then press OK.

TV placement

Location

HDMI mode

Home

Retail

Restore default settings

Preferences

Language

EasyLink

Retail Demo

3Use  to select Home, then press OK.

Retail

The unit will be set up with predefined settings for

retail displays. In this setting, you can set the backlight

brighter.

Home

The unit is set to maximize the energy efficiency for

home setting and it can be adjusted through a choice

of picture and sound quality selections according to

your preference.

Note(s)

•You must set Home in the menu. Otherwise, personalized picture and sound settings will not

be memorized after the unit goes into standby mode.

HDMI mode

If there are issues with picture/color and/or sound when connecting an

external device using the HDMI port, please try switching the HDMI mode

following the instructions below.

1Press  and use  to select Setup, then press OK.

2Use  to select TV settings, then press OK.

3Use  to select Installation, then press OK.

4Use  to select Preferences, then press OK.

5Use  to select HDMI mode, then press OK.

6Use  to select HDMI1, HDMI2 or HDMI3, then press OK.

7Use  to select Legacy (Compatibility), then press OK. If this does

not solve the problem, then try Normal.

•When switching the HDMI configuration (Legacy  Normal), the

screen will black out for a moment, then come back on.

Note(s)

•The HDMI connector with HDMI mode set to Legacy (Compatibility) supports up to UHD 30P,

while The HDMI connector with HDMI mode set to Normal supports up to UHD 60P.

•Switching the HDMI mode between Normal and Legacy (Compatibility) may cause loss of

HDMI CEC functionality in certain cases.

TV placement

To apply the best settings for your TV, select wall mount or stand mount.

1Use  to select Preferences, then press OK.

2Use  to select TV placement, then press OK.

3Use  to select Wall mounted or On a TV stand, then press OK.

Retail Demo

When you set Location to Retail, E-sticker (Electronic Sticker) is displayed.

E-sticker can be turned off using procedure below.

1Use  to select Preferences, then press OK.

2Use  to select Retail Demo, then press OK.

3Use  to select Off, then press OK.

35 .English

Continued on next page.

Use Philips EasyLink

Your TV supports Philips EasyLink, which enables one-touch play and

one-touch standby between EasyLink-compliant devices. Compliant

devices must be connected via an HDMI connector.

O

One-touch play

When you connect your TV to devices that support one-touch play, you

can control your TV and the devices with one remote control. For

example, when you press (Play) on your DVD remote control, your TV

automatically switches to the correct channel to show the DVD content.

One-touch standby

When you connect your TV to devices that support standby, you can use

your TV remote control to put your TV and all connected HDMI devices

in standby mode. You can perform one-touch standby using the remote

control from any of the connected HDMI devices.

System audio control

When you connect your TV to HDMI CEC compliant devices, your TV can

switch automatically to play audio from the connected device. To use

one-touch audio, you must map the audio input from the connected

device to your TV. You can use the remote control from the connected

device to adjust the volume.

Remote control (RC) key forwarding

RC key forwarding allows you to control EasyLink-compliant devices

using your TV remote control.

HDMI-ARC (Audio Return Channel) (HDMI 1 only)

HDMI-ARC allows you to use Philips EasyLink to output TV audio directly

to a connected audio device, without the need for an additional digital

audio cable. Be sure that the device is HDMI CEC and ARC compliant, and

that the TV is connected to the device using an HDMI cable attached to

both HDMI-ARC connectors.

Note(s)

•Philips does not guarantee 100% interoperability with all HDMI CEC devices.

•The EasyLink-compliant device must be switched on and selected as the source.

EasyLink (HDMI CEC)

This function allows you to operate the linked functions between our

brand devices with a EasyLink feature and this unit connecting through

an HDMI cable. You must connect this unit to our brand EasyLink devices

and be sure its EasyLink (HDMI CEC) setting is also set to on.

1Use  to select Preferences, then press OK.

2Use  to select EasyLink, then press OK.

3Use  to select the item you want to adjust, then press OK.

On

O

HDMI-ARC

RC key forwarding

Auto TV On

Master EasyLink

TV placement

EasyLink

Location

HDMI mode

Retail Demo

Set the Master EasyLink to On or Off. The following additional settings

will be grayed out when you set them to Off.

Master

EasyLink

Off Disables all EasyLink.

On

Selects if you have connected an

external device that is compatible with

the EasyLink function.

This unit will turn on when the power on signal is sent from your connected

EasyLink device.

Auto TV On

Off

This unit stays in Standby mode even

if you turn on your connected EasyLink

device.

On

This unit turns on automatically when

you turn on your connected EasyLink

device.

You can operate some functions such as disc playback or call up the

menu of the connected devices, by using this unit’s remote control.

RC key

forwarding

Off Disable RC key forwarding.

On

PLAY, PAUSE. / STOP. /

FWD/ / REV0 / VOL + / – / 

(MUTE) / OPTIONS /  / OK /

BACK / the NUMBER buttons can

be used to control your connected

EasyLink devices by this unit’s remote

control.

Note(s)

•Pause may not work properly on some devices even if they are EasyLink (HDMI CEC)

compliant.

HDMI-ARC allows you to use Philips EasyLink to output TV audio directly

to a connected audio device, without the need for an additional digital

audio cable.

HDMI-ARC

(HDMI 1 only)

Off Disable HDMI-ARC.

On

You can output TV audio through the

HDMI cable solely, provided both the

TV and device are HDMI-ARC

compliant.

Return your settings to default values

You can return settings to their default values.

1Use  to select Restore default settings, then press OK.

2Use  to select Reset AV settings or Reset all settings, then press

OK.

Reset AV settings

Return picture and sound settings to their default

values. The channel installation settings are not

affected.

Reset all settings Return all the settings to their default values.

36 .English

Continued on next page.

Search for channels

Be sure the RF cable is correctly connected to this unit and you are

registered with your cable TV provider when you install cable channels.

1Press  and use  to select Setup, then press OK.

2Use  to select Search for channels, then press OK.

3Use  to select Start, then press OK.

Install channels

You can search and store all channels. If you move the unit to a different

area after the initial setting, it is recommended to perform

Autoprogramming.

4Use  to select Antenna or Cable, then press OK.

5Press OK on Start.

•When the scanning and memorizing of available channels is

completed, the lowest memorized channel will be displayed.

6Follow the on-screen instructions to complete the installation.

0

0

12 34

Stop

Total progress:

Analog channels found:

Digital channels found:

complete.

more than 20 minutes to

Auto programming may take

wait...

System searching. Please

Channel settings

1Press  and use  to select Setup, then press OK.

2Use  to select Channel settings, then press OK.

3Adjust the following items.

Uninstall channels

Installation mode

Weak channel installation

Mono/Stereo

Digital audio language

Change PIN

Child lock

Channel installation

Channel installation

Be sure the RF cable is correctly connected to this unit and you are

registered with your cable TV provider when you install cable channels.

Weak channel installation

This function lets you add the channels that were not added by the

Autoprogram due to the reception conditions during the initial setup. It is

available only when you select antenna in Installation mode.

1Use  to select Channel installation, then press OK.

2Use  to select Weak channel installation, then press OK.

3Use  to select Search, then press OK.

•The PIN code will be required if you have locked channels.

4Use  to select a channel you want to memorize.

5Use  to select Search, then press OK.

6Display will be changed to Store from Search when the channel is

found, then press OK.

Note(s)

•In most cases, digital channels are not broadcast on the RF channel on which they appear on

your TV. To add digital channels you need to know the RF channel on which the digital channel

is being broadcast. (e.g. If there is a digital channel 9.1 which is being broadcast on RF channel

25, you need to enter 25 while performing a weak channel installation.) To find out the RF

channel on which a particular digital channel is being broadcast, please contact your local

service provider. Installing digital channels using Weak channel installation might not work for

direct cable connections and if the digital signal is too weak for the TV to process.

Installation mode

1Use  to select Channel installation, then press OK.

2Use  to select Installation mode, then press OK.

3Use  to select Antenna or Cable, then press OK.

•When Antenna is selected, the TV detects antenna signals. It

searches for DTV and analog TV channels available in your area.

•When Cable is selected, the TV detects signals supplied by cable.

It searches for DTV, analog TV and cable channels available in your

area.

Uninstall channels

The channels selected here can be skipped when selecting the channels

using CH + / –.

Those channels can still be selected with the NUMBER buttons.

1Use  to select Channel installation, then press OK.

2Use  to select Uninstall channels, then press OK.

3Use  to select the channel you want to remove, then press OK.

•The removed channels are not displayed on the list of favorite

channels.

•To reactivate a removed channel, use  then press OK.

37 .English

Continued on next page.

Child lock

You can prevent your children from watching certain programs or certain

channels by locking the TV controls and by using ratings.

1Use  to select Child lock, then press OK.

Mono/Stereo

Digital audio language

Change PIN

Child lock

Channel installation

Region ratings lock

Canadian French rating

Canadian English rating

Movie ratings lock

TV ratings lock

2Use the NUMBER buttons to enter the 4-digit numbers for your PIN

code.

•When you have not set up your PIN code, enter 0, 0, 0, 0.

•When the PIN code is correct, Child lock menu is displayed.

See the following description for setting each item.

TV-MA

TV-14

TV-PG

TV-G

TV-Y7

TV-Y

None

All

Region ratings lock

Canadian French rating

Canadian English rating

Movie ratings lock

TV ratings lock

Mono/Stereo

Digital audio language

Change PIN

Child lock

Channel installation

Note(s)

•When you select the higher rating and set it to , the lower ratings will be blocked

automatically.

•When you set the All to  all ratings return to  automatically.

•Region ratings lock will be available when the unit receives a digital broadcast using the new

rating system.

•To block any inappropriate programs, set your limits in TV ratings lock, Movie ratings lock and

Region ratings lock.

•For the United States, the unit may download the region ratings lock table, if required.

•The Canadian rating systems on this unit are based on CEA-766-A and CRTC policy.

Setting TV and movie ratings

Movie ratings lock is the rating system created by MPAA. TV ratings lock

has controlled access to individual programs based on their age ratings

and content rating.

3Use  to select TV ratings lock or Movie ratings lock, then press

OK.

4Use  to select the desired rating, then press OK repeatedly to

switch between block and view.

• indicates that the rating is locked (Blocked).

• indicates that the sub rating is locked (Blocked).

• indicates that the rating is not locked (Viewable).

TV ratings lock

TV-MA

TV-14

TV-PG

TV-G

TV-Y7

TV-Y

None

All

Region ratings lock

Canadian French rating

Canadian English rating

Movie ratings lock

TV ratings lock

Movie ratings lock

Region ratings lock

Canadian French rating

Canadian English rating

Movie ratings lock

TV ratings lock

X

NC-17

R

PG-13

PG

G

NR

All

US movie

ratings

US TV

ratings Description

All All ratings locked including no rating

NR None No rating

–TV-Y Appropriate for all children

–TV-Y7 Appropriate for all children 7 and older

G TV-G General audience

PG TV-PG Parental guidance suggested

PG-13 – Unsuitable for children under 13

–TV-14 Unsuitable for children under 14

R–Restricted under 17 requires

accompanying parent or adult guardian

NC-17 – No one under 17 admitted

X TV-MA Mature audience only

To set the sub ratings (displayed in the right column)

For TV ratings lock, you can further set the sub ratings to block specific

elements of programming. To set the sub ratings, follow the step below.

Use  to select the desired rating, then press OK repeatedly to

switch between  and .

TV-MA

TV-14

TV-PG

TV-G

TV-Y7

TV-Y

None

All

Region ratings lock

Canadian French rating

Canadian English rating

Movie ratings lock

TV ratings lock

Fantasy Violence

38 .English

Continued on next page.

US TV ratings Sub rating

TV-Y7 Fantasy Violence

TV-PG Violence

Sex

Language

Dialog

TV-14

TV-MA

Violence

Sex

Language

Note(s)

•Blocked sub rating's will appear beside the main rating category in TV ratings lock menu.

•You cannot block a sub rating if the main rating is set to .

•Changing the category to  or  automatically changes all its sub ratings to the ( or ).

Canadian English or Canadian French ratings

You can select the rating for Canadian English or Canadian French

broadcasting.

3Use  to select Canadian English rating or Canadian French

rating, then press OK.

4Use  to select the desired rating, then press OK repeatedly to

switch between block and view.

• indicates that the rating is locked (Blocked).

• indicates that the rating is not locked (Viewable).

Canadian

English

rating

Canadian

French rating Description

All Locked all ratings

EExempt program

C– For all children

C8+ – For all children 8 and older

GGeneral audience

–8 ans+ Unsuitable for ages under 8

PG – Parental guidance suggested

–13 ans+ Unsuitable for ages under 13

14+ – Unsuitable for ages under 14

–16 ans+ Unsuitable for ages under 16

18+ 18 ans+ Adult audience only

Note(s)

•The V-Chip can block non rated programs as per “CEA-608-E sec. L.3”. If the option to block

NR, None or E programs are used in Movie ratings lock, TV ratings lock, Canadian English

rating or Canadian French rating accordingly “unusual results may occur and the unit may not

receive emergency bulletins or other types of programming”: / Emergency bulletins (Such as

EAS messages, weather warnings and others) / Locally originated programming / News /

Political / Public service announcements / Religious / Sports / Weather.

Change PIN

Although the default PIN code (0000) is supplied with the unit, you can

set your own PIN code.

1Use  to select Change PIN, then press OK.

2Press the NUMBER buttons to enter the current 4-digit PIN code.

3Press the NUMBER buttons to enter the new 4-digit PIN code.

•Enter PIN code again to confirm.

Note(s)

•Make sure new PIN code and confirm PIN code must be exactly the same. If they are different,

the space is cleared for reentering.

•If you have forgotten your PIN code, enter 07 1 1 to reset the PIN code.

Digital audio language

You can select the audio language while your TV is receiving the digital

broadcasting.

1Use  to select Digital audio language, then press OK.

Digital audio

language

To select the language according to your

preference.

(It differs depending on the program.)

Mono/Stereo

Cable / NTSC (Analog) TV operation

You can select an audio format while your TV is receiving the analog

broadcasting.

1Use  to select Mono/Stereo, then press OK.

2Use  to select Mono, Stereo or SAP (Second Audio Program),

then press OK.

39 .English

Continued on next page.

Connect to network

Setup network connection settings in order to use Net TV or network

upgrade functions.

•The meanings of abbreviations are defined as below.

AP : Wireless LAN access point

WPS : Wi-Fi protected setup

SSID : Wireless network name

•The key entry screen will appear when you select SSID, WEP /

WPA / WPA2 or proxy address.

312

Manual

Easy Connect

WPS code

If you have non-WPS type devices in your router network, select Manual and press OK.

If your router has Wi-Fi protected Setup(WPS), select Easy Connect and press OK.

M

anua

l

E

asy Connect

c

od

e

c

Cancel

All clear

OK

Text

. , @ ’

g h i

p q r s

a b c

j k l

t u v

_ ? ! -

d e f

m n o

w x y z

abc ABC 123+/; Clear

Network settings

•Enter the key of the selected wireless network using , then

press OK.

Clear : Clear the entered number or word.

All clear : Clear all the entered numbers or words.

abc : Switch to the small letter mode.

ABC : Switch to the capital letter mode.

123+/; : Switch to the numeral and symbol mode.

Cancel : Shows the cancellation display.

OK : Set the entered number or word.

1Press  and use  to select Setup, then press OK.

2Use  to select Connect to network, then press OK.

312

Cancel

Wired

Wireless

Select your connection type.

This TV can be connected to

your home network.

Network settings

3Adjust the following items.

Wireless setting

Select to use a wireless LAN to connect to the internet by a wireless

connection.

1Use  to select Wireless, then press OK.

2Use  to select the desired setting, then press OK, and follow the

on-screen instructions.

Easy Connect

Select this setting if your router has a Wi-Fi

Protected Setup (WPS) button. Start scanning for

wireless networks on the TV after pressing the

WPS button on your router. If connection test fails,

refer to the router’s manual for more details.

Scan

Search for wireless networks automatically and

select the wireless network name (SSID) from the

list.

Manual entry

Set up the connection to the wireless LAN Access

Point (AP) (e.g. wireless router) manually by

entering the wireless network name (SSID).

*WPS (Easy Connect) cannot be used when the security protocol is set

to WEP. Change the Access Point’s security mode from WEP to WPA or

WPA2 (recommended).

Wired setting

Select to use an Ethernet cable to connect to the internet by a wired

connection. Please purchase shielded Ethernet cables at your local store

and use it when you connect to network equipment.

1Use  to select Wired, then press OK.

•Connection test will start automatically.  p. 43

40 .English

Continued on next page.

Network settings

1Press  and use  to select Setup, then press OK.

2Use  to select Network settings, then press OK.

3Adjust the following items.

Manual network settings

1Use  to select Manual network settings, then press OK.

Proxy conguration

IP conguration

Wireless network setting

Network selection

Reset network settings

Net TV

Wake-on-LAN(DIAL)

Home network

Setting status

Connection test

Manual network settings

N

Network selection

2Use  to select Network selection, then press OK.

3Use  to select the desired setting, then press OK.

Wired If you connect to an Ethernet cable, select Wired

to connect to the internet.

Wireless If you have a router with WPS function, select

Wireless to connect to the internet.

Wireless network setting

This menu is displayed only when you set Wireless in Network selection.

In order to use a wireless network, you must set up a connection to the

AP (e.g. wireless router).

2Use  to select Wireless network setting, then press OK.

Auto

Search for wireless networks automatically and select the SSID from the

list.

3Use  to select Auto, then press OK.

4The list of wireless networks will be displayed. Use  to select the

appropriate the SSID, then press OK.

Manually enter your SSID

Auto

Router 4

Router 3

Router 2

Router 1

Manual

WPS code

Easy Connect

•If you select the SSID with , WEP*2 / WPA / WPA2 Key entry

screen will appear. Enter the WEP*2 / WPA / WPA2 key of the

selected wireless network using , then press OK.

•If you select the SSID has a WPS, the WPS setting screen will appear.

Use  to select a setting, then press OK.

Easy Connect

Select this setting if your router has a Wi-Fi

Protected Setup (WPS) button. Start scanning for

wireless networks on the TV after pressing the

WPS button on your router. If connection test fails,

try Easy Connect again.*1 If it fails then refer to the

router’s manual for more details.

WPS code

Select this setting if your router has a WPS but

does not have a WPS button. Enter the 8-digit

WPS PIN code shown on your TV in the router

settings menu via PC before Connect is selected.

Manual

If your wireless network with authentication setting

(WEP*2, WPA or WPA2), WEP*2 / WPA / WPA2 Key

entry screen will appear. Enter the WEP*2 / WPA /

WPA2 key of the selected wireless network using

, then press OK.

*1 WPS (Easy Connect) cannot be used when the security protocol is

set to WEP. Change the Access Point’s security mode from WEP to

WPA or WPA2 (recommended).

*2 WEP is not recommended to be used due to its major security flaws.

Change the security protocol on the wireless router to WPA or WPA2

(recommended) mode.

Confirmation message will appear. Select OK to complete the settings.

Note(s)

•For a wireless network with authentication setting, key icon appears to the right hand of the

SSID.

•Signal icon shows the strength of the signal.

•WEP*2 / WPA key appears as asterisks on the confirmation screen.

•The wireless LAN supports following specifications.

–Wireless standards: IEEE 802.1 1 a/b/g/n/ac

–Frequency spectrum: 2.4GHz / 5GHz

–Security protocol: WEP*2 / WPA / WPA2

41 .English

Continued on next page.

Manually enter your SSID

Set up the connection to the AP (e.g. wireless router) manually by entering

the SSID.

3Use  to select Manually enter your SSID, then press OK.

•AP (e.g. wireless router) SSID entry screen will appear.

Enter the SSID using , then press OK.

4Use  to select the authentication setting of the selected wireless

network.

•For a wireless network with authentication setting, select the

authentication setting, according to the security type of the wireless

network.

XXXXXXXXXXXXXX

WPA/WPA2

WEP

None

Manually enter your SSID

Auto

None Set the authentication setting to None.

WEP Set the authentication setting to WEP*.

WPA/WPA2 Set the authentication setting to WPA/WPA2

•For a wireless network without authentication setting, select None.

•If you select WEP* or WPA/WPA2, WEP* / WPA / WPA2 Key entry

screen will appear. Enter the WEP* / WPA / WPA2 key of the selected

wireless network using , then press OK.

•Confirmation message will appear. Select Yes to complete the settings.

*WEP is not recommended to be used due to its major security flaws.

Change the security protocol on the wireless router to WPA or WPA2

(recommended) mode.

I

IP configuration

In following cases, select IP configuration to set each setting as

necessary.

–When connection test failed with the setting of Connection test.

–When instructed by your Internet service provider to make specific

settings in accordance with your network environment.

2Use  to select IP configuration, then press OK.

3Use  to select a setting, then press OK.

Manual

Auto

MAC address

Secondary DNS

Primary DNS

DNS setting mode

Default gateway

Subnet mask

IP address

IP setting mode

Proxy conguration

IP conguration

Wireless network setting

Network selection

IP setting

mode

Auto Sets the IP setting automatically.

Manual Sets the IP setting manually.

IP address *1, 3

A set of numbers which are assigned to

devices participating in a computer

network.

Subnet mask *1, 3 A mask which is used to determine what

subnet an IP address belongs to.

Default gateway *1, 3 IP address of the network device (such as

router) which provides internet access.

DNS setting

mode

Auto Sets the DNS setting automatically.

Manual Sets the DNS setting manually.

Primary DNS *2, 3 A server which handles the name and IP

address over the internet.

Secondary DNS *2, 3 A server which handles the name and IP

address over the internet.

MAC address

An address which recognizes the devices

connecting to the network. It is also called

hardware address.

*1 Items can be selected only when IP setting mode is set to Manual.

*2 Items can be selected only when DNS setting mode is set to

Manual.

*3 Use  or the NUMBER buttons to input numbers. When you use

 to input numbers, then press OK or input the triple digits by

using the NUMBER buttons, the cursor moves to the next entry field.

When you use  to input numbers, then press OK or input the

triple digits by using the NUMBER buttons at the rightmost entry

field, numbers will be stored and go back to the previous menu.

Note(s)

•The range of input numbers is between 0 and 255.

•If you enter a number larger than 255, the number will automatically be 255.

•The manually entered number will be saved even if you change the setting to Auto.

•If you want to enter 1 or 2 digit number in one cell, press OK to move on to the next cell.

•If the entered IP address or the default gateway or primary DNS number is same as the default

setting, IP address setting will be set to Auto. (The manually entered number will be saved).

•When IP address setting is set to Manual, the setting of DNS setting will automatically be Manual

and when IP address setting is set to Auto, you can set either Auto or Manual for DNS setting.

42 .English

Continued on next page.

P

Proxy configuration

2Use  to select Proxy configuration, then press OK.

3Use  to select a setting, then press OK.

Do not useProxy setting

Proxy conguration

IP conguration

Wireless network setting

Network selection

Use

Proxy port

Proxy address

•Do not use is selected for default settings.

•If you need to change the proxy setting as instructed by your

internet service provider to set the designated proxy address and

port, select Use.

Proxy setting Do not use Does not use the proxy server.

Use Uses the proxy server.

Proxy address *Selects the number or word by

using , then press OK.

Proxy port *Use  or the NUMBER buttons

to input numbers.

*Items can be selected only when Proxy setting is set to Use.

Note(s)

•The range of input numbers for the port number is between 0 and 65535. (If you enter a number

larger than 65535, it will be regarded as 65535.)

•For proxy port, the selected ports may be blocked and not be able to use depending on your

network environment.

•If the proxy address is entered with blank only, proxy server setting will be set to Do not use.

Connection test

Perform the following steps to test your internet connection after you

have connected an Ethernet cable or entered network settings such as IP

address, DNS settings, etc. manually.

1Use  to select Connection test, then press OK.

•Connection test will start automatically and the test result for home

network and internet will appear right after the connection test

finishes.

•“Testing…” is displayed while the connection test is in progress.

Home network Internet Description

Pass Pass Connection test is successfully

completed.

Fail -

Connection test for home network

failed. Check the connection

settings.

Pass Fail Connection test for internet failed.

Check the connection settings.

•If the connection test for internet passes, speed test will start

automatically.

2Press OK to go to the list on network status confirmation screen.

Note(s)

•If the connection test for both home network and internet pass, you are ready to use Net TV or

network upgrade functions using the internet without making any additional settings.

•If the connection test fails, check if the Ethernet cable is connected to this TV properly or if you

have entered all the required details for the wireless LAN connection properly.

Setting status

You can check the status of network settings.

1Use  to select Setting status, then press OK.

•Network setting list will be displayed.

•MAC address of this unit will be displayed in the list.

43 .English

Continued on next page.

Home network

You can turn your TV into a Digital Media Renderer (DMR), which can play

video, music and photo files stored on certified home media servers

connected to your home network.

1Use  to select Home network, then press OK.

2Use  to select the item you want to adjust, then press OK.

Renderer

Off Disable DMR.

On Enable this unit to play files using

DMC.

Renderer name Change the display name of this TV to other

devices on the home network.

Wake-on-LAN(DIAL)

You can turn your TV on when you use remote control via IP.

1Use  to select Wake-on-LAN(DIAL), then press OK.

2Use  to select On or Off, then press OK.

Off To set Wake-on-LAN(DIAL) to off.

On To set Wake-on-LAN(DIAL) to on.

Net TV

Displays the deactivation setting for Net TV and Netflix ESN information.

Netflix deactivation

Displays the deactivation setting for Netflix.

1Use  to select Net TV, then press OK.

2Use  to select Net TV deactivation, then press OK.

3Use  to select Netflix, then press OK.

4Use  to select the desired option, then press OK.

Yes Deactivate the connection to Netflix.

No Activate the connection to Netflix.

VUDU deactivation

Displays the deactivation setting for VUDU.

1Use  to select Net TV, then press OK.

2Use  to select Net TV deactivation, then press OK.

3Use  to select VUDU, then press OK.

4Use  to select the desired option, then press OK.

Yes Deactivate the connection to VUDU.

No Activate the connection to VUDU.

YouTube deactivation

Displays the deactivation setting for YouTube.

1Use  to select Net TV, then press OK.

2Use  to select Net TV deactivation, then press OK.

3Use  to select YouTube, then press OK.

4Use  to select the desired option, then press OK.

Yes Deactivate the connection to YouTube.

No Activate the connection to YouTube.

Netflix ESN

Displays the ESN information.

1Use  to select Net TV, then press OK.

2Use  to select Netflix ESN, then press OK.

•Displays the ESN (Electronic Serial Number) to get any services

from Netflix.

Reset network settings

You can reset the status of network settings.

1Use  to select Reset network settings, then press OK.

2Use  to select the desired option, then press OK.

44 .English

Continued on next page.

Update software

Philips continuously tries to improve its products and we strongly

recommend that you upgrade the TV software when upgrades are

available.

New software can be downloaded from our website at

www.philips.com/support using the model number of your TV to find

information.

You can update the software through these methods:

•Update with USB memory stick

•Update from digital broadcast Software auto-update  p. 46

This section describes how to upgrade the software by using USB memory

stick.

Preparing for the software upgrade

You require the following equipment:

–A PC with web browsing capability

–An archive utility that supports the ZIP-format

(e.g. WinZip for Windows or StuffIt for Mac OS)

–An empty clean formatted USB memory stick

Note(s)

•Only FAT / DOS-formatted portable memory is supported.

•Use only software upgrades that can be found on the Philips web site.

Warning

•When the software upgrade is running, don’t press any buttons.

•Do not remove the USB memory stick during the software upgrade.

•If an error occurs during the upgrade, retry the procedure or for further assistance, please contact

call center.

Downloading the software

Find information and software related to your TV and download the latest

software upgrade file to your PC.

Prepare a blank USB memory stick for software update. Access

www.philips.com/support and download the latest version software to

a blank USB memory stick using a PC by following the directions described

on the website.

•Use a blank USB memory stick, download the software on your PC and

write the software in the root directory of the USB memory stick.

•For more details on how to download the software, please refer to the

website.

USB upgrade

You can upgrade the software by using USB memory stick.

1Connect your USB memory stick with the upgrade file to the USB

terminal on the side of your TV.

2Press  and use  to select Setup, then press OK.

3Use  to select Update software, then press OK.

4Use  to select USB, then press OK.

5Use  to select the desired update file, then press OK.

6Use  to select Yes, then press OK.

•Read the on-screen instructions and confirm that you want to

continue with the installation.

Do not remove the USB storage device or turn the TV o

while upgrade is in progress.

Software update is in progress. Please wait.

7When the software upgrade is completed, press  to set the unit into

standby mode, then remove the USB memory stick.

8Unplug the AC power cord for a few seconds from AC outlet and plug

it again.

9Press  again to turn the unit on.

•The TV starts up with the new software.

•For further assistance, please contact call center.

45 .English

Continued on next page.

Network updates

You can update the software by connecting the unit to the internet.

1Press  and use  to select Setup, then press OK.

2Use  to select Update software, then press OK.

3Use  to select Network, then press OK.

4Use  to select Yes, then press OK.

•This unit will then start checking for the latest FirmWare (software)

version.

5Confirmation message will appear.

Use  to select Yes, then press OK.

•The unit will start downloading the latest FirmWare (software)

version.

•The unit will start updating the FirmWare (software) version.

•It may take a while to complete the updating.

6When the software update is complete, press  to make sure the unit

goes to standby mode.

7Unplug the AC power cord for a few seconds from AC outlet and plug

it again.

8Press  again to turn the unit on.

•The TV starts up with the new software.

For further assistance, please contact call center.

Note(s)

•In order to update software via the Internet, you must connect the unit to the Internet and set

up necessary settings.

Connect to network  p. 40

Network settings  p. 41

•Please do not unplug the AC power cord or Ethernet cable while executing the Network

updates.

•All settings will remain the same even if you update the software version.

•The version of net service will also be updated if newer version of net service is available when

updating the firmware.

•When you start up the TV or a net service after executing the software update, a message may

appear on the screen prompting for software update again. In this case, please select Update

to start USB update or network update. For further assistance, please contact call center.

Software settings

Software

1Press  and use  to select Setup, then press OK.

2Use  to select Software settings, then press OK.

3Use  to select Software, then press OK.

Checking your current software version number

1Use  to select Software information, then press OK.

•The version and a description of the current software is displayed.

Software auto-update

You can download the latest software through the air and update this unit

automatically while the unit is in standby mode.

1Use  to select Software auto-update, then press OK.

2Use  to select the desired option, then press OK.

Off Disable auto-update for latest software.

On A message will appear if there is the latest software on

the network server.

License

Displays the licenses of open source software used in this unit.

1Use  to select License, then press OK.

•Licenses of open source software used in this unit are displayed.

Digital rights management

This product contains technology subject to certain intellectual property

rights of Microsoft. Use or distribution of this technology outside of this

product is prohibited without the appropriate license(s) from Microsoft.

1Use  to select Digital rights management, then press OK.

•Digital rights management is displayed.

46 .English

Continued on next page.

Miracast

You can view the screen from Smartphones and PC on your TV connected

to the devices via Wi-Fi CERTIFIED Wi-Fi Direct.

Using Miracast

1Press  and use  to select Miracast, then press OK.

•Miracast mode screen appears.

PHILIPS_Smart_TV

If you want to manage connected device history, please press "OPTIONS".

If you want to exit, please press "BACK" key.

The TV is now ready to accept a Push Button Connection (PBC) from your source device.

Your TV name

2Activate Miracast feature on your device.

•For the operation of your device, please check the instruction

manual of the device.

•Select Your TV name on your device if needed.

•If PIN code is required on your device, please enter the 8-digit code

appearing in the left-hand side of the TV screen.

3Once connected, the screen of your device will appear on your TV

screen.

•Press INFO to display your device name at the bottom of TV

screen.

•Press 

. or OK to pause playback. Press 

. or OK again to resume

playback.

Using Miracast device list

In Miracast device list, you can find the connected devices.

1Press OPTIONS on Miracast mode screen.

•Only the connected device names are listed.

•It will be sorted from newest connection to oldest connection. A

maximum of 64 connections can be recognized.

•If you would like to delete a listed connection, press  to select

the device name, then press OK first. Once the confirmation

message appears, please use  to select Yes, then press OK.

Note(s)

•Connectivity with all Miracast compatible devices is not guaranteed.

•Devices that do not comply with Miracast™ standards may have compatibility issues.

•P&F USA Inc. / P&F MEXICANA S.A. de C.V. do not warrant Miracast compatibility with all source

devices such as smartphones, tablets, laptops, etc. due to large variability in hardware, firmware,

drivers, software and implementation of wireless casting applications on these source devices.

Although P&F USA Inc. / P&F MEXICANA S.A. de C.V. will strive to enhance compatibility and

performance across a range of source devices, P&F USA Inc. / P&F MEXICANA S.A. de C.V. do

not warrant compatibility with specific source devices.

View photos, play music and watch videos

using home network

On your TV you can play video, music and photo files stored on home

network certified home media servers connected to your home network.

In order to use this feature, you must connect this unit to the internet.

It is recommended that files to be played back in this unit are recorded

under the following specifications:

Picture (JPEG / Progressive JPEG)

JPEG Upper limit 4000x4000 pixels

Progressive JPEG Upper limit 1024x768 pixels

Music (MP3 / WAV / AAC)

MP3 Sampling frequency 16 kHz - 48 kHz

Constant bit rate 8 kbps - 320 kbps

WAV Sampling frequency 8 kHz - 48 kHz

Constant bit rate 64 kbps - 1.5 Mbps

AAC Sampling frequency 8 kHz - 48 kHz

Constant bit rate -

Video (MPEG / VOB / AVI / MP4)

Maximum video H.264, H.265/HEVC: 3840x2160@30fps,

MPEG: 1920x1080@60fps

Extension .avi .mpg,

.mpeg

.ts,

.trp,

.tp

.vob .mp4 .mkv

Video

codec

Audio

codec

MPEG1,

MPEG2,

MPEG4,

H.264

MPEG1,

MPEG2,

MPEG4

MPEG1,

MPEG2,

H.264,

H.265/

HEVC

MPEG1,

MPEG2

MPEG1,

MPEG2,

MPEG4,

H.264,

H.265/

HEVC

MPEG1,

MPEG2,

MPEG4,

H.264,

H.265/

HEVC

Dolby Digital YES YES YES YES YES YES

MPEG1/2 audio

layer1/2/3 YES YES YES YES NO YES

LPCM YES YES YES YES YES YES

AAC-LC YES YES YES YES YES YES

Note(s)

•A maximum of 1,023 folders or files can be recognized.

•For the home server list, maximum of 16 servers can be displayed.

•The 10th and deeper hierarchies cannot be displayed.

•Unplayable files in the home server will not be displayed in the file list.

•For some files, playback is not available even if displayed in the file list.

•In order to play back the contents in home servers, the player and the servers must be connected

to the same access point.

•Compatibility and available playback function may differ depending on the home server.

•Video files with unsupported audio format will be skipped.

•The quality of the playback picture or audio differs depending on your network condition

47 .English

Continued on next page.

Before using home network

Follow the procedure below before using home network.

1Connect this unit to the internet.

Connecting the TV to the internet using an Ethernet cable  p. 16

or Connecting the TV to the internet using a wireless LAN  p. 17

•Broadband internet connection of 8Mbps or faster is required.

2Set up the necessary network connection settings. Connect to

network  p. 40

Using home network

1Start home network media servers in your home network.

•For details, refer to the instruction book of the home network

certified device.

2Press  on the remote control.

3Use  to select Home Network.

•This unit will start loading the home server list.

4After loading, home server list will appear. Select a home server you

want to access, then press OK.

Guide to home network

a

bc

Blue hills

Video10

Highway Blues

Folder

Video

Photos

Audio

Server 3

Server 2

Server 1

00:05:28

d

e

bc

Blue hills

Video10

Highway Blues

Highway Blues

Artist

Current folder

Folder

Video

Photos

Audio

Home server list

Folder / media icon

Group (folder) / file list

Image

Current file info

View your pictures using home network

1Press  to select a file or a folder.

2Press OK or . to start a slide show of the files.

•Press OK or . to pause the slide show.

The . icon appears.

•Press 0 or / to move between images.

•Press BACK or . to stop the slide show.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat *1

Off Sets repeat playback to off.

One Sets repeat playback for a selected image file.

All Sets repeat playback for all image files in the

current folder.

Slide time *1

Short Switches to the next image in 5 seconds.

Medium Switches to the next image in 10 seconds.

Long Switches to the next image in 15 seconds.

Transitions *1

None No effect when switching images.

Dissolve Overlaps the next image on the current image.

Wipe right Pushes the current image out from left.

Wipe left Pushes the current image out from right.

Wipe up Pushes the current image out from bottom.

Wipe down Pushes the current image out from top.

Box in The next image comes to the center from the

outside.

Box out The next image goes to the outside from the

center.

Rotate *2

0Displays an image in its original direction.

90 Rotates an image 90 degrees clockwise.

180 Rotates an image 180 degrees clockwise.

270 Rotates an image 270 degrees clockwise.

Zoom *2

1X Displays an image in its original size.

2X Magnifies a current image by 2 times.

4X Magnifies a current image by 4 times.

Auto picture *1

Selects the picture mode according to your preference.

(Standard, Natural, Vivid, Sports, Movie, Game, Energy saving

and Internet video)

*1 You can set Repeat, Slide time, Transitions and Auto picture when

images are in slide show.

*2 You can set Rotate and Zoom when slide show is in pause mode.

48 .English

Continued on next page.

Listen to music using home network

1Press  to select a file or a folder.

2Press OK or . to play the selected files.

•Press OK or . to pause, press OK or . again to resume.

•Press / to skip up the next file.

•Press 0 to skip down the previous file.

•Press . to stop playback.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat

Off Sets repeat playback to off.

One Sets repeat playback for a selected music

file.

All Sets repeat playback for all music files in

the current folder.

Shuffle

Off Sets shuffle playback to Off.

On Sets shuffle playback for all music files in

the current folder.

TV Speakers

Off The sound will not be output from the

unit's speakers.

On The sound will be output from the unit's

speakers.

Speakers

EasyLink

You can control audio output from your

connected EasyLink compliant devices

with VOL + / – by using this unit's remote

control.

Auto sound Selects the sound mode according to your preference.

(Standard, Vivid, Sports, Movie, Music and News)

Watch videos using home network

1Press  to select a file or a folder.

2Press OK or . to play the selected files.

•Press OK or . to pause, press OK or . again to resume.

•Press / to fast-forward search.

•Press 0 to fast-backward search.

•Press . to stop playback.

•Press 

. to resume from the point at which playback was stopped.

Press OK to play from the beginning of the file at which playback

was stopped.

•Press CH + to play the next file.

•Press CH - to play the current file at the beginning.

Press CH - twice within 5 seconds to play the previous file.

•Press OPTIONS to display the optional menu, then use  to

select the desired item.

Repeat

Off Sets repeat playback to off.

One Sets repeat playback for a selected video

file.

All Sets repeat playback for all video files in

the current folder.

TV speakers

Off The sound will not be output from the

unit's speakers.

On The sound will be output from the unit's

speakers.

Speakers

EasyLink

You can control audio output from your

connected EasyLink compliant devices

with VOL + / – by using this unit's remote

control.

Auto picture

Selects the picture mode according to your preference.

(Standard, Natural, Vivid, Sports, Movie, Game, Energy

saving and Internet video)

Auto sound Selects the sound mode according to your preference.

(Standard, Vivid, Sports, Movie, Music and News)

Note(s)

•The resume information will be kept even when the unit is Turned off.

•If you play another file while the previously viewed file is being resumed, the resume information

of the previously viewed file will be deleted.

•The file or the folder in resume stop mode will be highlighted in gray on List or Thumbnails.

49 .English

Continued on next page.

Net TV

Net TV offers internet services for your TV. Use the TV remote control to

browse the Net TV pages. You can play movies, listen to music and much

more, all from your TV screen.

–Because Net TV is an online system, it can be modified over time to

better serve its purpose.

–Some Net TV services can be added, changed or stopped after some

time.

–You cannot download and save files or install plug-ins.

Before using Net TV

Follow the procedure below before using Net TV.

1Connect this unit to the internet.

2Set up the necessary network connection settings.

(Refer to Connect to network  p. 40)

Using Net TV

1Press NET TV.

•Net TV screen will appear, then use  to select service icon.

•For the first time only, Terms of Use screen will appear. After

confirming the content, use  to select Agree, then press OK.

Guide to Net TV menu screen

Net TV start screen

4

3

5

21

Country: USA

Terms of Use

APP4APP3APP2APP1

Featured AppsNow on TV

 Now on TV :Displays the image of the input under present

tuning.

 Featured Apps :Displays fixed net service icons.

 Selected Apps :Displays movable net service icons.

 Country :Selects what country you live in.

 Terms of Use :Displays a copy of net service.

My Apps functions

Remove App

1Use  to select the desired App, then press OPTIONS.

2Use  to select Remove App, then press OK.

•The selected App will be removed from My Apps list.

Move App

1Use  to select the desired App, then press OPTIONS.

2Use  to select Move App, then press OK.

•The selected App icon will be smaller.

3Use  to the point you want to place, then press OK.

Guide to App Gallery

a

b

c

All

App Gallery

Category menu: List of category menu.

Icon list: Displays unregistered net service icons on My

Apps list.

Page guide: Displays the order of pages. The current page

will be highlighted.

1Press NET TV, then use  to select App Gallery.

2Use  to select the desired App in My Apps list, then press

OK.

•You can also choose from Category menu. Use  to select

All, then use OK to select the desired category.

•If you select Add, the selected App icon will be placed at the end

of My Apps list.

•If you select Add and move, the selected App icon will be smaller

and use  to the point you want to place, then press OK.

Even if you press BACK to cancel this function, the selected App

icon will be placed at the end of My Apps list.

Information on network services

For detailed information on 3rd party internet services, please visit the

service providers website:

Netflix : http://www.netflix.com

VUDU : http://www.vudu.com

CinemaNow : http://www.cinemanow.com

For additional help, refer to the Frequently Asked Questions FAQs at

www.philips.com/support.

Select TV and enter your model number.

50 .English

Continued on next page.

Pandora operations

With this unit, you can instantly listen to personalized radio stations

streamed over the internet from Pandora.

To learn more about Pandora, please visit www.pandora.com

Activating Pandora

In order to listen to internet radio streamed from Pandora via the internet,

you must create a Pandora account and activate this unit.

1Press NET TV, then use  to select PANDORA.

2Use  to select I am new to Pandora., then press OK.

3Note the activation code and website address displayed on the TV

screen.

4On your PC, visit the website address noted at step 4.

5Follow directions on the website to create your account.

6On this unit, select Go Back and press OK to complete activation.

Adding Pandora user accounts

You can add the Pandora user account.

1Press NET TV, then use  to select PANDORA.

2Use  to select I have a Pandora account., then press OK.

3Enter your e-mail address, then press OK while OK is selected.

4Enter a password, then press OK while OK is selected.

5Use  to select Sign In, then press OK.

•Your account is added to the user list and player screen appears

on the TV screen.

Note(s)

•Pandora is available only in the United States.

•You can add up to 5 accounts.

Creating a new station

By entering your favorite artists or tracks, Pandora selects music and

creates a new station for you on the basis of the entered information.

1On the station list screen, Use  to select New Station, then

press OK.

2Enter a name of your favorite artist or tracks, then press OK while OK

is selected.

•Search result will appear on the right side of the TV screen.

•If the selection screen with the result type appears, use 

 to select

the desired type, then press OK.

3Use  to select the desired station, then press OK to start the

playback.

 / .



Resumes the playback / pause the playback.

Resumes the playback.

.Pauses the playback.

 Skips to the next track.

Note(s)

•On the Tool Menu, you can delete or rename the currently selected station.

Guide to the player screen

On the player screen, you can set various options to the currently playing

track.

XXXXX

XXXXX

ABC

American Oldies Radio

4:52 0:00

on

by

c

ba

defg

Artist name : Displays artist name.

Album name : Displays album name.

": Give thumbs up to the currently playing track.

Pandora will play tracks similar to the track.

#: Give thumbs down to the currently playing

track. Pandora will skip and will not play the

track.

 / .: Resumes the playback / pause the playback.

2: Skips to the next track.

!$: Displays the Tool menu.

51 .English

5 Useful tips

FAQ

Question Answer

My remote control does not

work.

What should I do?

•Check the antenna or cable connection to the main unit.

•Check the batteries on the remote control.

•Check if there is an obstacle between the infrared sensor window and the remote control.

•Test the IR signal output use IR signal check.  p. 55

If okay, then possible infrared sensor trouble.

•Aim the remote control directly at the infrared sensor window on the front of the unit.

•Reduce the distance to the unit.

•Re-insert or replace the AAA batteries with their polarities (+/–) as indicated on the remote control battery area.

•When there is an infrared-equipped device such as PC near this unit, it may interrupt the remote control signal on this unit.

Move the infrared-equipped device away from this unit, change the angle of the device's infrared sensor or turn off the

infrared communication function.

How come the initial setup

appears every time I turn on

this unit?

•Make sure to complete the initial setup before the unit goes into standby mode.

Why can I not watch some RF

signal TV programs?

•Autoprogram must be completed when you set up the unit for the first time or move it to a location where previously

unavailable channels are broadcast.

•Make sure auto programming has been completed.  p. 37

•The selected channel may not be broadcasting.

•When Auto programming is interrupted and not completed, some channels will not be received. Make sure to complete

the Autoprogram.  p. 37

•The selected channel cannot be viewed by the Child lock setting.  p. 38

•The unit requires some kind of antenna input. An indoor antenna (Digital or VHF / UHF), an external antenna (Digital or

VHF / UHF) or an RF coaxial cable from your wall cable or set-top box needs to be plugged into the unit.

How come there is no image

from the connected external

devices?

•Check if the correct input mode is selected by pressing SOURCE.  p. 22

•Check the antenna, cable or other input connection to the unit.

•When using the component video connection check that the green (Y), blue (Pb/Cb) and red (Pr/Cr) connectors are

connected to their corresponding colored jacks on the unit.

When I enter a channel

number, why does it change

automatically?

•Many digital channels have alternate channel numbers. The unit changes the numbers automatically to the ones signifying

the broadcasting station's channel number. These basic numbers used for the previous analog broadcasts. (e.g., input

digital ch# 30 automatically changes to digital ch# 8.1)

Why are captions not

displayed entirely?

Or why are captions delayed

behind the dialog?

•Closed captions that are delayed a few seconds behind the actual dialog are common for live broadcasts. Most captioning

production companies can display a dialog to maximum of 220 words per minute. If a dialog exceeds that rate, selective

editing is used to insure that the closed captions remain up-to date with the current TV screen dialog.

How can I set the clock? •There is no clock function on this unit.

My PIN code no longer

works, how can I change the

child lock setting?

•Although the default PIN code (0000) is supplied with the unit, the PIN code will be required once you set a PIN code in

Child lock.  p. 38

When you forget your PIN code, enter 07 1 1 in Change PIN to reset the PIN code.  p. 39

When I start up the TV or a

net service, a message

appears on the screen

prompting for software

update again.

•When you start up the TV or a net service after executing the software update, a message may appear on the screen prompting

for software update again. In this case, please select Update to start USB update or network update.  p. 45

52 .English

Continued on next page.

Troubleshooting tips

If the unit does not perform properly when operated as instructed in this manual,

P

Please check the following Troubleshooting tips and all connections once before calling for service.

Power

No power

•Make sure the AC power cord is plugged in.

•Make sure that the AC outlet supplies the proper voltage, plug another electrical

appliance into the AC outlet to ensure that the AC outlet operates normally.

•If a power failure occurs, unplug the AC power cord for 1 minute to allow the unit

to reset itself.

Remote

Control buttons do not work.

•Do NOT press more than one button at the same time.

•Ensure that no buttons on the remote control are depressed and move freely.

Universal remote control does not work properly.

•Refer to the User manual of the universal remote control for the Philips code.


Power is on but no screen image.

•Check whether the connection for the antenna, cable or set-top box is

connected correctly.

•Check whether all the cables to the unit are connected to the correct output jack on

your separate device like Blu-ray disc / DVD recorder.

•Make sure that the selected input mode is connected to the working input jack.

•Check if your computer is NOT in sleep mode when the input mode on this unit

is in PC mode. Tap any key on the computer keyboard to wake it up.

•Check if the correct input mode is selected by pressing SOURCE.

No color

•View other TV channels. The problem might be limited to the broadcasting

station.

•Adjust Color in Picture settings.  p. 30

Picture poor

•Adjust Contrast and Brightness in Picture settings.  p. 30

•For the best picture quality, watch “High Definition” wide screen programs. If the

HD content is not available, watch “Standard Definition” programs instead.

You see pixelation on the screen.

•When the capabilities of the unit exceed the capabilities of the digital

broadcasting, the signal will be increased to match the capabilities of the display

on the unit. This may cause pixelation, noise or trash.

Unusual picture appears and the TV does not operate.

•Press the power button first. If it does not solve, follow the procedure below.



Press the buttons on the remote control in the order shown below.



























Unplug the AC power cord, then wait for 1 minute, and then plug it in again.

Sound

No sound is heard when using the HDMI digital connection.

•Some HDMI cables and devices may not be compatible with the TV due to

different HDMI specifications.

No sound, distorted sound or incorrect audio sound is heard when using the

HDMI-DVI connections.

•Make sure that the analog audio signals from the HDMI-DVI device are

connected to the analog audio input L/R jacks.

•When using Component analog video, Composite analog video or PC VGA

video, make sure that the analog audio (L/R) connectors are mounted into the

audio (L/R) input jacks.

Sound intermittent or no sound.

•Check if the audio cable is connected into the unit correctly.

You switch to a different input and the volume changes.

•This unit will memorize the volume level from the last time you adjusted it.

•If the volume of the sound from another device is higher or lower, then the

loudness will change.

•Make sure Auto volume leveling is set to On.  p. 32

Picture & Sound

No sound with distorted picture occurs when using the HDMI digital connection.

•Some HDMI cables and devices may not be compatible with the TV due to

different HDMI specifications.

No picture or sound

•Check if the power is on.

•Check whether all the cables to the unit are connected to the correct output jack on

your separate device like Blu-ray disc / DVD recorder.

•View other TV channels. The problem might be limited to the broadcasting station

or weak signal strength.

•Unplug the AC power cord and wait for about 1 minute, then plug the AC power

cord and turn on the unit again.

•Check whether the connection of the antenna or cable / satellite set-top box is

connected correctly.

•Make sure that the selected input mode is connected to the working input jack.

•Check if your computer is NOT in sleep mode when the input mode of this unit

is in PC mode. Tap any key on the keyboard to wake up your computer.

•Make sure that the sound is not muted. Press  so that the volume bar and

current volume level will appear on the TV screen.

•Make sure that the volume is NOT set to 0 or . If so, use VOL + / – to adjust to

the desired volume.

•Make sure that the headphone is NOT connected to the headphone audio

output jack.

•Make sure that the TV speakers is NOT set to Off.

•If there are issues with picture/color and/or sound when connecting an external

device using the HDMI port, please try switching the HDMI mode. (Refer to HDMI

mode  p. 35)

Adjusted Picture or Sound settings are not effective every time the unit is turned

on.

•You must set Home in Location.  p. 35 (Otherwise, the settings you adjusted

will not be memorized after the unit goes into standby mode.)

You see a distorted picture or hear an unusual sound. (Analog TV - NTSC

signal)

•You may be getting NTSC (Analog) TV signal (not HDTV signal) interference from

electrical appliances, automobiles, motorcycles or fluorescent lights.

•Try moving the unit to another location to see if this is the cause of the problem.

Ghosts, lines or streaks in picture.

•Electrical interference from nearby appliances may affect picture quality.

•View other TV channels. The problem might be limited to the broadcasting station

or weak signal strength.

Picture poor, sound intermittent or no sound

•View other TV channels. The problem might be limited to the broadcasting station

or weak signal strength.

Child and rating lock

Forgotten PIN code.

•Enter “07 1 1” to clear your password.

Screen

You switch to a different input and the screen size changes.

•This unit will memorize the viewing mode from the last time you used the

particular input modes.

The display image does not cover the entire screen.

•If you are using the unit as a PC monitor, make sure that Horizontal position and

Vertical position in Picture are set correctly.  p. 30

•If you are watching TV or using the Composite video, Component video or HDMI

with 480i input, press FORMAT repeatedly to switch to various screen

modes.

Different color marks on the TV screen

•View other TV channels. The problem might be limited to the broadcasting

station, missing data or pixelation due to weak signal strength.

53 .English

Continued on next page.

Closed captions

Closed captions are displayed as a white box. No closed captions are displayed

in the closed captions-supported program.

•Interference from buildings or weather conditions may cause closed captions to

be incomplete if watching analog TV signals.

•Broadcasting station may shorten the program to insert advertisements.

The closed caption decoder cannot read the information of the shortened

program.

Black box is displayed on the TV screen.

•The text mode is selected for caption. Select CC-1, CC-2, CC-3 or CC-4.

Software update

A message appears on the screen prompting for software update again.

•When you start up the TV or a net service after executing the software update, a

message may appear on the screen prompting for software update again. In this

case, please select Update to start USB update or network update.  p. 45

Network

Cannot connect to the network.

•Check if the Ethernet cable connection is properly made. Turn on the broadband

router and/or modem.

•Check the network settings.

•Check if the broadband router and/or modem is correctly connected.

Sometimes video quality is poor when using the wireless LAN.

•The wireless network connection quality varies depending on the distance or

obstacles (e.g. wall, basement, 2nd floor) between the TV wireless LAN adapter

and the wireless router (access point), from other wireless networks, and brand

and type of the wireless router (access point). When using the wireless LAN of

the TV, it is suggested to place the wireless router as close as possible to the

television.

Wireless LAN connection fails or wireless connection is poor.

•Check the installation location of the TV and wireless router (access point). Signal

quality may be affected for the following reasons.

–Interference of other wireless devices, microwaves, fluorescent lights, etc., are

placed nearby.

–There are floors or walls between the wireless router and TV.

–If the problems continue even after checking the above, try making a wired

LAN connection.

Cannot use the wireless connection.

•Check if the wireless LAN Access Point (AP) (e.g. wireless router) is oriented

properly or not placed too close between them.

•Once you have activated the wireless connection please wait 30 seconds for the

connection to be established after turning on the unit, before trying to access

network features such as Net TV.

Cannot use Netflix feature.

•Check if the network connection is properly made.

•Visit http://www.netflix.com on your PC and become a Netflix member.

•Some network services may not be available in your country.

Cannot add movies or TV episodes to the Instant Queue.

•Visit www.netflix.com on your PC.

Even though the speed of the internet connection improves during playback,

the picture quality of Netflix streaming movie does not improve.

•The picture quality does not change during playback. It differs depending on the

speed of internet connection at the time of loading.

Cannot use VUDU feature.

•VUDU is available only in the United States and Mexico.

•Check if the network connection is properly made.

Cannot rent or buy movies / TV episodes on VUDU.

•You need to activate the VUDU account. For detailed information, please visit

the service providers website at http://www.vudu.com

•Log into your account at http://my.vudu.com and check your payment

information.

The picture quality of streaming movie (Netflix, VUDU or CinemaNow) is poor.

•Check the speed of your internet connection. You need speeds of at least 8 Mbps

to this player for high quality uninterrupted playback.

Streaming movie (Netflix, VUDU or CinemaNow) often stops or starts buffering

during playback.

•Contact your internet service provider to troubleshoot your internet connection

for speed and line quality. Consistent line quality and speed are very important

for internet video playback.

Cannot connect to the network while my PC is connected to the network.

•Check the content of your internet service contract to see if your internet service

provider prevents multiple terminals connecting at the same time.

Cannot use Easy Connect (WPS) to connect to the access point.

•Connect the unit to the access point using scan or manual entry mode. If the

access point’s security mode is set to WEP*, change the setting to WPA or WPA2

(recommended), then try Easy connect (WPS) again. (For access point

configuration, please consult its user manual or manufacturer.)

*WEP is not recommended to be used due to its major security flaws. Change the security

protocol on the wireless router to WPA or WPA2 (recommended) mode.

Folder or files stored on home network media server are not displayed in the file

list or cannot be played back.

•Check the setting on your home media server. (Refer to the user manual of the

home media server.)

•Check the network connection and settings.

Cannot use Pandora feature.

•Check if the network connection is properly made.

•Pandora is available only in the United States.

•You must create a Pandora account and activate this unit. Activating Pandora 

p. 51

Miracast

•Connectivity with all Miracast compatible devices is not guaranteed.

•Devices that do not comply with Miracast™ standards may have compatibility

issues.

Note(s)

•The LCD screen is manufactured to provide many years of useful life.

Occasionally a few non active pixels may appear as a fixed point of blue, green

or red.

This is not to be considered a defect in the LCD screen.

•Some functions are not available in specific modes, but this is not a malfunction.

Read the description in this manual for more details on correct operations.

For additional troubleshooting, refer to the Frequently Asked Questions

or FAQs on www.philips.com/support.

54 .English

6 Information

Glossary

Analog TV (NTSC)

Acronym that stands for National Television Systems Committee and the

name of analog broadcasting standards.

Off the air analog TV signals are no longer being sent by major broadcasting

stations in the USA.

ARC (Audio Return Channel) (HDMI 1 only)

HDMI-ARC allows you to use Philips EasyLink to output TV audio directly to

a connected audio device, without the need for an additional digital audio

cable. Be sure that the device is HDMI CEC and ARC compliant, and that the

TV is connected to the device using an HDMI cable attached to both HDMI-

ARC connectors.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in

other words, the TV screen is almost square); widescreen models are 16:9 (the

TV screen is almost twice as wide as its height).

CEC (Consumer Electronics Control)

This allows you to operate the linked functions between our brand devices

with CEC feature and this unit. We do not guarantee 100% interoperability with

other brands of CEC compliant devices.

Component video

This is a Video signal format that conveys each of 3 principal colors of light

(red, blue and green) through different signal lines. This allows the viewers to

experience picture colors as original as it is. There are several signal formats,

including Y / Pb / Pr and Y / Cb / Cr.

Dolby Digital

The system developed by Dolby Laboratories to compress digital sound. It

offers stereo sound (2ch) or multi-channel audio.

DTV (ATSC)

Abbreviation that stands for Advanced Television Systems Committee and

the name of the digital broadcasting standards.

E-sticker

E-sticker is showing set features, technical information, etc on this TV set that

is displayed on the TV screen mainly used by TV retailers. Previously the

information was on a printed sticker that was put on the display.

HDMI (High-Definition Multimedia Interface)

Interface that supports all uncompressed, digital audio / video formats

including set-top box, Blu-ray / DVD recorder or digital television, over a single

cable.

HDTV (High-Definition TV)

Ultimate digital format that produces high resolution and high picture quality.

PIN code

A stored 4-digit number that allows access to parental control features.

SAP (Secondary Audio Program)

Second-audio channel delivered separately from the Main-audio channel.

This audio channel is used as an alternate in bilingual broadcasting.

SDTV (Standard Definition TV)

Standard digital format that is similar to the analog TV picture quality.

Sonic Emotion

Sonic Emotion delivers immersive sound with clear voice.

Maintenance

Cleaning

•Clean the front panel and other exterior surfaces of the unit with a soft

microfiber cloth or lens brush. Before cleaning the panel, disconnect the

AC power cord.

•Never use a solvent or alcohol. Do not spray insecticide liquid near the

unit. Such chemicals may cause damage and discoloration to the

exposed surfaces.

•Do not spray any liquids on the screen or other exterior surfaces of this

unit. If liquids enter the unit, they could cause shorts, electric shocks or

fire damage.

Servicing

Should your unit become inoperative, do not try to correct the problem

yourself. There are no user serviceable parts inside. Call our toll free

customer support line found on the cover of this User manual to locate

an authorized service center.

IR signal check

If the remote control is not working properly, you can use a digital or cell

phone camera to see if it is sending out an infrared signal.

e.g.) With a digital camera:

Point the digital camera towards the remote

control infrared diode at the front of the

remote control. Press and hold any key on

the remote control and look at the camera

display. If an infrared pulsating light appears

on the display, the remote control is sending

out an IR signal.

Note: Some cameras may have an IR filter

or dual camera cell phones may have an IR filter in one of the camera's

and both will not display the IR signal.

55 .English

7 Specifications

Model # 65PFL7900 55PFL7900 49PFL7900


Type

Diagonal screen size / Aspect ratio

64.5”/ 16:9 54.6”/ 16:9 48.5”/ 16:9

Viewing Angles 178° (V) by 178° (H)

Built-in Digital / Analog Tuner ATSC (Digital) / NTSC (Analog)

Sound

Mono / Stereo Mono, Stereo, Sonic Emotion Premium

Power Output (RMS watts) 10W x 2

Equalizer 5 Band

Ease of Use

Picture Format

SD (4:3 Source) : Automatic / Super zoom / 4:3 / Movie expand 14:9 / Movie expand 16:9 / Wide screen

HD

(16:9 Source) : Automatic / 4:3 / Wide screen / Full

UHD : Full / Unscaled

Photo Slide Show JPEG, Progressive JPEG

Music Playback MP3, WAV, AAC

Video Playback MPEG1, MPEG2, H.264, MPEG4, H.265/HEVC

Channel

Channel Coverage

: VHF: 2∼13

: VHF: 2∼13

UHF: 14∼69

CATV (Analog NTSC) 2∼13, A∼W

W+1∼W+94 (Analog W+1∼W+84), A-5∼A-1, 5A

Tuning System Channel Frequency Synthesized Tuning System

Channel Access Direct Access Number Keyboard, Programmable Scan, Channel +(up) / -(down) and

PREV. CH (Previous Channel)

Connectivity

Component Video Input

(Y/Pb/Pr)

1

Supporting Video Signals : 480i/p, 720p, 1080i/p @60Hz

Composite Video Input

(Shared Y Green Terminal

with Component Video)

1

3

Analog Audio L/R Input

PC Input Via VGA, HDMI and HDMI-DVI + Analog Audio L/R

USB 1

Wireless LAN Supporting wireless standards : IEEE 802.1 1a/b/g/n/ac (2.4GHz/5GHz)

Ethernet port 1

Digital Audio Output 1

Supporting Dolby Digital and Dolby Digital Plus

Headphone Output 1

1/8 inch (3.5mm)

Power

Power Requirements 120V∼ +/- 10%, 60Hz +/- 0.5%

Temperature

Operating Temperature 41 °F (5 °C) to 104 °F (40 °C)

UHD (Ultra HD) (3840 x 2160 pixels 60Hz)

Over-the-Air DTV

(ATSC) UHF: 14∼69 (Each Channel may have e.g. 2.1∼2.9, 3.1∼3.9, etc)

Over-the-Air Analog

(NTSC)

HDMI Input

Supporting HDMI Video Signals : 480i/p, 720p, 1080i @60Hz, 1080p, 2160p @24/30/60Hz

Supporting PC-Input Video Signal up to 4096 x 2160

1 (R Audio / L Audio)

Supporting HDMI Digital Audio Signals : LPCM, AC3, DD+

•Specifications are subject to change without prior notice.

56 .English

8 Warranty

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

P&F USA, Inc. PO Box 2248, Alpharetta, GA 30023-2248

LIMITED WARRANTY

ONE (1) YEAR

WARRANTY COVERAGE:

This warranty obligation is limited to the terms as set forth

below.

WHO IS COVERED:

This product warranty is issued to the original purchaser or

the person receiving the product as a gift against defects in

materials and workmanship as based on the date of original

purchase (“Warranty Period”) from an Authorized Dealer. The

original sales receipt showing the product name and the

purchase date from an authorized retailer is considered such

proof.

WHAT IS COVERED:

This warranty covers new products if a defect in material or

workmanship occurs and a valid claim is received within the

Warranty Period. At its option, the company will either (1)

repair the product at no charge, using new or refurbished

replacement parts, or (2) exchange the product with a

product that is new or which has been manufactured from

new, or serviceable used parts and is at least functionally

equivalent or most comparable to the original product in

current inventory, or (3) refund the original purchase price of

the product.

Replacement products or parts provided under this warranty

are covered against defects in materials and workmanship

from the date of the replacement or repair for ninety (90)

days or for the remaining portion of the original product’s

warranty, whichever provides longer coverage for you. When

a product or part is exchanged, any replacement item

becomes your property and the replaced item becomes

company property. When a refund is given, your product

becomes company property.

Note: Any product sold and identied as refurbished or

renewed carries a ninety (90) day limited warranty.

Replacement product can only be sent if all warranty

requirements are met. Failure to follow all requirements can

result in delay.

WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:

This Limited Warranty applies only to new company

manufactured products that can be identied by the

trademark, trade name, or logo axed to it. This Limited

Warranty does not apply to any hardware product or any

software, even if packaged or sold with the product, as

manufacturers, suppliers, or publishers may provide a

separate warranty for their own products packaged with the

bundled product.

The company is not liable for any damage to or loss of any

programs, data, or other information stored on any media

contained within the product, or other additional product or

part not covered by this warranty. Recovery or reinstallation

of programs, data or other information is not covered under

this Limited Warranty.

This warranty does not apply (a) to damage caused by

accident, abuse, misuse, neglect, misapplication, or

non-supplied product, (b) to damage caused by service

performed by anyone other than company approved

Authorized Service Location, (c) to a product or a part that

has been modied without written company permission, or

(d) if any serial number has been removed or defaced, or (e)

product, accessories or consumables sold “AS IS” without

warranty of any kind by including refurbished product sold

“AS IS” by some retailers.

This Limited Warranty does not cover:

• Shipping charges to return defective product.

• Labor charges for installation or setup of the product,

adjustment of customer controls on the product, and

installation or repair of antenna/signal source systems

outside of the product.

• Product repair and/or part replacement because of

improper installation or maintenance, connections to

improper voltage supply, power line surge, lightning

damage, retained images or screen markings resulting

from viewing xed stationary content for extended

periods, product cosmetic appearance items due to

normal wear and tear, unauthorized repair or other cause

not within the control of the company.

• Damage or claims for products not being available for use,

or for lost data or lost software.

• Damage from mishandled shipments or transit accidents

when returning product.

• A product that requires modication or adaptation to

enable it to operate in any country other than the country

for which it was designed, manufactured, approved and/or

authorized, or repair of products damaged by these

modications.

• A product used for commercial or institutional purposes

(including but not limited to rental purposes).

• Product lost in shipment and no signature verication

receipt can be provided.

• Failure to operate per Owner’s Manual.

TO OBTAIN ASSISTANCE…

Contact the Customer Care Center at:

1-866-202-5960

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS

WARRANTY IS THE EXCLUSIVE REMEDY FOR THE

CONSUMER, WITH THE ISSUING COMPANY NOT LIABLE FOR

ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR

BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON

THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY

APPLICABLE LAW, ANY IMPLIED WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO

THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusions or limitation of

incidental or consequential damages, or allow limitations on

how long an implied warranty lasts, so the above limitations

or exclusions may not apply to you.

57 .English

License

P&F USA, Inc. hereby offers to deliver, upon request, a copy of the

complete corresponding source code for the copyrighted open source

code packages, on an “AS IS” basis, used in this product for which such

offer is requested by the respective licenses. This offer is valid up to three

years after the product purchase to anyone in receipt of this information.

To obtain source code, please contact P&F USA, Inc. You should write to

“Open Source Team, P&F USA, Inc., PO Box 2248, Alpharetta, GA

30023-2248. P&F USA, Inc. disclaims any and all warranties and

representations with respect to such software and related source code

including quality, reliability, usability, and accuracy, and further disclaim

all express, implied, statutory or otherwise, including without limitation,

any implied warranties of title, non-infringement, merchantability, or

fitness for a particular purpose. P&F USA, Inc. shall not be liable to make

any corrections to the open source software or source code or to provide

any support or assistance with respect to it. P&F USA, Inc. disclaims any

and all liability arising out of or in connection with the use of this software

and/or source code.

58 .English

This product has been manufactured by and is sold

under the responsibility of P&F USA, Inc., and P&F

USA, Inc. is the warrantor in relation to this product.

The Philips trademark and the Philips Shield Emblem

are registered trademarks of Koninklijke Philips N.V.

used under license.

P&F USA, Inc.

PO Box 2248, Alpharetta, GA 30023-2248 U.S.A.

P&F Mexicana, S.A. de C.V.

Av. La Palma No. 6, Col. San Fernando La Herradura.

Huixquilucan, Edo. de México. C.P. 52787

A518ZUH / A51RZUH / A511ZUH

䖩
