www.philips.com/welcome
BDL3230QL
V2.00
User Manual (English)
BDL3230QL
ii
Safety Instructions
Warnings and Precautions
KNOW THESE SAFETY SYMBOLS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
This symbol indicates high voltage is present inside.
It is dangerous to make any kind of contact with any
inside part of this product.
This symbol alerts you that important literature
concerning operation and maintenance has been
included with this product.
CAUTION: FCC/CSA regulations state that any unauthorized
changes or modications to this equipment may void
the user’s authority to operate it.
CAUTION: To prevent electric shock, match the wide blade of plug
to the wide slot, and fully insert the plug.
TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC
SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
The Socket-outlet should be installed near the apparatus and be easily
accessible.
Read and follow these instructions
when connecting and using your Public
Information Display:
Unplug the display if you are not going to use it for an extensive
period of time.
Unplug the display if you need to clean it with a slightly damp cloth.
The screen many be wiped with a dry cloth when the power is off.
However, never use alcohol, solvents or ammonia-based liquids.
Consult a service technician if the display does not operate normally
when you have followed the instructions in this manual.
The casing cover should be opened only by qualied service
personnel.
Keep the display out of direct sunlight and away from stoves or any
other heat sources.
Remove any object that could fall into the vents or prevent proper
cooling of the display’s electronics.
Do not block the ventilation holes on the cabinet.
Keep the display dry. To avoid electric shock, do not expose it to
rain or excessive moisture.
If turning off the display by detaching the power cable, wait for 6
seconds before re-attaching the power cable for normal operation.
To avoid the risk of shock or permanent damage to the set do not
expose the display to rain or excessive moisture.
When positioning the display, make sure the power plug and outlet
are easily accessible.
• IMPORTANT: Always activate a screen saver program during your
application. If a still image in high contrast remains on the screen for
an extended period of time, it may leave an ‘after-image’ or ‘ghost
image’ on the front of the screen. This is a well-known phenomenon
that is caused by the shortcomings inherent in LCD technology. In
most cases the afterimage will disappear gradually over a period
of time after the power has been switched off. Be aware that the
after-image symptom cannot be repaired and is not covered under
warranty.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
WARNING: Apparatus shall not be exposed to dripping or splashing
and no objects lled with liquids, such as vases, shall be
placed on the apparatus.
BDL3230QL
iii
WARNING: The batteries (batteries installed) shall not be exposed
to excessive heat such as sunshine, re or the like.
WARNING: The mains plug or appliance coupler is used as the
disconnect device,the disconnect device shall remain
readily operable.
WARNING: To prevent the spread of re, keep candles or other
open ames away from this product at all times.
WARNING: To prevent injury, this apparatus must be securely
attached to the oor/wall in accordance with the
installation instructions.
CAUTION: These servicing instructions are for use by qualied
service personnel only. To reduce the risk of electric
shock,do not perform any servicing other than that
contained in the operating instructions unless you are
qualitied to do so.
CAUTION: Excessive sound pressure from earphones and
headphones can cause hearing loss. Adjustment of the
equalizer to maximum increases the earphone and
headphone output voltage and the sound pressure level.
Therefore, to protect your hearing, adjust the equalizer
to an appropriate level.
For UL/CUL application: For use only with UL Listed Wall Mount
Bracket with minimum weight/load: 8.7 Kg
For CB application: Unit without base weight: 5.2 Kg. The equipment
and its associated mounting means still remain secure during the test.
(Used wall mounting kit: 200x200 mm and 100x100mm distance by
using M4 screws of 10 mm long plus the thickness of the mounting
bracket.
IMPORTANT INFORMATION
Ifatelevisionisnotpositionedinasufcientlystablelocation,itcan
bepotentiallyhazardousduetofalling.Manyinjuries,particularlyto
children,canbeavoidedbytakingsimpleprecautionssuchas:
Using cabinets or stands recommended by the manufacturer of the
television.
Only using furniture that can safely support the television.
Ensuring the television is not overhanging the edge of the
supporting furniture.
Not placing the television on tall furniture(for example, cupboards
or bookcases)without anchoring both the furniture and the
television to a suitable support.
Not standing the televisions on cloth or other materials placed
between the television and supporting furniture.
Educating children about the dangers of climbing on furniture to
reach the television or its controls.
.
Regulatory Information
CE Declaration of Conformity
This device complies with the requirements set out in the Council
Directive on the Approximation of the Laws of the Member States
relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage
Directive (2014/35/EU) and RoHS directive (2011/65/EU).
This product has been tested and found to comply with the harmonized
standards for Information Technology Equipment, these harmonized
standards published under Directives of Ofcial Journal of the European
Union.
Warning:
This equipment is compliant with Class A of EN55032/CISPR 32. In a
residential environment this equipment may cause radio interference.
Federal Communications Commission (FCC)
Notice (U.S. Only)
Note: This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
Changes or modications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Use only an RF shielded cable that was supplied with the display when
connecting this display to a computer device.
To prevent damage which may result in re or shock hazard, do not
expose this appliance to rain or excessive moisture.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
BDL3230QL
iv
Polish Center for Testing and Certication
Notice
The equipment should draw power from a socket with an attached
protection circuit (a three-prong socket). All equipment that works
together (computer, display, printer, and so on) should have the same
power supply source.
The phasing conductor of the room’s electrical installation should have
a reserve short-circuit protection device in the form of a fuse with a
nominal value no larger than 16 amperes (A).
To completely switch off the equipment, the power supply cable must
be removed from the power supply socket, which should be located
near the equipment and easily accessible.
A protection mark “B” conrms that the equipment is in compliance
with the protection usage requirements of standards PN-93/T-42107
and PN-89/E-06251.
Electric, Magnetic and Electronmagnetic
Fields (“EMF”)
1. We manufacture and sell many products targeted at consumers,
which, like any electronic apparatus, in general have the ability to
emit and receive electromagnetic signals.
2. One of our leading Business Principles is to take all necessary health
and safety measures for our products, to comply with all applicable
legal requirements and to stay well within the EMF standards
applicable at the time of producing the products.
3. We are committed to develop, produce and market products that
cause no adverse health effects.
4. We conrm that if its products are handled properly for their
intended use, they are safe to use according to scientic evidence
available today.
5. We play an active role in the development of international EMF and
safety standards, enabling us to anticipate further developments in
standardization for early integration in its products.
Information for U.K. only
WARNING – THIS APPLIANCE MUST BE EARTHED.
Important:
(A)
(B)
This apparatus is supplied with an approved moulded 13A plug. To
change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI approved
type.
3. Ret the fuse cover.
If the tted plug is not suitable for your socket outlets, it should be cut
off and an appropriate 3-pin plug tted in its place.
If the mains plug contains a fuse, this should have a value of 5A. If a plug
without a fuse is used, the fuse at the distribution board should not be
greater than 5A.
NOTE: The severed plug must be destroyed to avoid a possible shock
hazard should it be inserted into a 13A socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured in accordance with the
following code:
BLUE – “NEUTRAL (“N”)
BROWN – “LIVE” (“L”)
GREEN & YELLOW – “EARTH” (“E”)
1. The GREEN & YELLOW wire must be connected to the terminal in
the plug which is marked with the letter E or by the Earth symbol
or coloured GREEN or GREEN & YELLOW.
2. The BLUE wire must be connected to the terminal which is marked
with the letter N or coloured BLACK.
3. The BROWN wire must be connected to the terminal which
marked with the letter L or coloured RED.
Before replacing the plug cover, make certain that the cord grip is
clamped over the sheath of the lead – not simply over the three wires.
BDL3230QL
v
中国RoHS
据中国《电子电气品有物质限使要求以下
分列出了产品中可能包含的物质的名称量。
产品中有害质的名称及含
零部件名称
有害物质
(Pb)
(Hg)
(Cd)
六价铬
(Cr
(VI))
多溴
联苯
(PBB)
多溴二
苯醚
(PBDE)
塑料外框 O O O O O O
后壳 O O O O O O
LCD
panel
CCFL X X O O O O
LED X O O O O O
电路板组件* X O O O O O
底座 O O O O O O
电源线 X O O O O O
其他线材 X O O O O O
遥控器 X O O O O O
*:电路板组件包括印刷电路板及其构成的零部件,如电阻、
电容、集成电路、连接器等。
本表格SJ/T 11364规定标志。
O: 表示该有害物质在该部件所有均质材料中的含量均在
GB/T 26572规定的限量要求以下。
X: 表示该有害物质至少在该部件的某一均质材料中的含量超
GB/T26572规定的限量要求,但是符合欧盟RoHS法规
要求(属于豁免部分)。
备注:上表仅做为范例,实际标示时应依照各产品的实际部件及
所含有害物质进行标示。
10 环保使用期限
在产品本体上标示的该标志表示环境保护使用期限为 10 年。
电子信息产品的环境保护使用期限是指电子信息产品中所含的有
害物质不会向外部泄漏或出现突然变异,并且电子信息产品的用
户在使用该电子信息产品时也不会对环境造成严重污染或对人
体、财产带来严重损害的期限。
在环境保护期限中,请按照使用说明书使用本产品。
本环境保护使用不覆盖易损件:电池。
《废弃电子产品回收处理管理条例》提示性说明
为了更好地关爱及保护地球,当用户不再需要此产品或产品寿命
终止时,请遵守国家废弃电器电子产品回收处理相关法律规定,
将其交给当地具有国家认可的回收处理资质的厂商进行回收处
理。
警告
此为 A级产品。在生活环境中,该产品可能会
造成无线电干扰。在这种情况下,可能需要用户
对干扰采取切实可行的措施。
警語 : 使用過度恐傷害視力。
注意事項 :
(1) 使用 30 分鐘請休息 10 分鐘。
(2) 未滿 2歲幼兒不看螢幕,2歲以上每天看螢幕
不要超過 1小時。
警告使用者 :
此為甲類資訊技術設備 ,於居住環境中使用
,可能會造成射頻擾動 ,在此種情況下 ,使用者
會被要求採取某些適當的對策 .
BDL3230QL
vi
仅适用于非热带气候条件下安全使用 :
汉文仅适用于非热带气候条件下安全使用。
蒙古文
藏文
维文
壮文
Dan hab yungh youq gij dienheiq diuzgen mbouj dwg
diegndat haenx ancienz sawjyungh.
200
0
m
仅适用于海拔 2000m 以下地区安全使用 :
汉文仅适用于海拔 2000m 以下地区安全使用。
蒙古文
藏文
维文
壮文Hai dou gaxgonq, wngdang sien duenh denvasen bae.
汉文
“注意
如果电池更换不当会有爆炸危险
只能用同样类型或等效类型的电池来更换”
蒙古文
藏文
维文
壮文
Louzsim
Danghnaeuz denyouz vuenh ndaej mbouj habdangq aiq miz
gij yungyiemj fatseng bauqcaq
Cijndaej yungh gij denyouz doengzyiengh loihhingz roxnaeuz
daengjyauq loihl haenx vuenh
汉文
“接入本设备的有线网络天线必须与保护接地隔离 ,
然可能会引起着火等危险 !
蒙古文
藏文
维文
壮文
Gij mizsienq vangjloz denhsen ciephaeuj bonj sezbi daeuj
haenx itdingh aeu caeuq gij ciepdieg baujhoh doxliz, mboujne
aiq miz gij yungyiemj dawzfeiz daengj!
North Europe (Nordic Countries)
Information
Placering/Ventilation
VARNING:
FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG
ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING
PÅPLATS.
Placering/Ventilation
ADVARSEL:
SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG
STIKKONTAKT ER NEMT TILGÆNGELIGE.
Paikka/Ilmankierto
VAROITUS:
SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN
TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA.
Plassering/Ventilasjon
ADVARSEL:
NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT
KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ.
Turkey RoHS:
Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur.
Ukraine RoHS:
Обладнання відповідає вимогам Технічного регламенту щодо
обмеження використання деяких небезпечних речовин в
електричному та електронному обладнанні, затвердженого
постановою Кабінету Міністрів України від 3 грудня 2008 № 1057.
End-of-Life Disposal
Your new Public Information Display contains materials that can be
recycled and reused. Specialized companies can recycle your product to
increase the amount of reusable materials and to minimize the amount
to be disposed of.
Please nd out about the local regulations on how to dispose of your
old display from your local philips dealer.
(For customers in Canada and U.S.A.)
This product may contain lead and/or mercury. Dispose of in accordance
to local-state and federal regulations. For additional information on
recycling contact www.eia.org (Consumer Education Initiative)
BDL3230QL
vii
Waste Electrical and Electronie Equipment-
WEEE
Attention users in European Union private households
This marking on the product or on its packaging
illustrates that, under European Directive 2012/19/
EU governing used electrical and electronic appliances,
this product may not be disposed of with normal
household waste. You are responsible for disposal of
this equipment through a designated waste electrical
and electronic equipment collection. To determine
the locations for dropping off such waste electrical
and electronic, contact your local government ofce,
the waste disposal organization that serves your
household or the store at which you purchased the
product.
End of Life Directives-Recycling
Your new Public Information Display contains several
materials that can be recycled for new users.
Please dispose of according to all Local, State, and
Federal laws.
Restriction on Hazardous Substances statement
(India)
This product complies with the “E-Waste (Management) Rules, 2016”
CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical and
Electronic Equipment and their components or consumables or parts or
spares do not contain Lead, Mercury, Cadmium, Hexavalent Chromium,
polybrominated biphenyls and polybrominated diphenyl ethers beyond
a maximum concentration value of 0.1% by weight in homogenous
materials for lead, mercury, hexavalent chromium, polybrominated
biphenyls and polybrominated diphenyl ethers and of 0.01% by weight
in homogenous materials for cadmium. except of exemptions set in
Schedule 2 of the Rule.
E-Waste Declaration for India
This symbol on the product or on its packaging
indicates that this product must not be disposed of
with your other household waste. Instead it is your
responsibility to dispose of your waste equipment
by handing it over to a designated collection point
for the recycling of waste electrical and electronic
equipment . The separate collection and recycling
of your waste equipment at the time of disposal
will help to conserve natural resources and ensure
that it is recycled in a manner that protects human
health and the environment. For more information
about E -waste please visit http://www.india.philips.
com/about/sustainability/recycling/index.page
and to know where you can drop off your waste
equipment for recycling in India please contact on
below given contact details.
Helpline number: 1800-425-6396 (Monday to Saturday, 9 a.m. to 5:30
pm)
Centralized E-waste collection center
Address: TPV Technology India Private Limited,
59, Maheswari Nagar, 1st Main Road, Mahadevapura Post,
Whiteeld Road
Bangalore, Karnataka, PIN: 560048, Tel: 080-3023-1000
E-mail: india.callcentre@tpv-tech.com
Batteries
ForEU:Thecrossed-outwheeledbinimplies
thatusedbatteriesshouldnotbeputtothe
general household waste! There is a separate
collectionsystemforusedbatteries,toallow
propertreatmentandrecyclinginaccordancewith
legislation.
Pleasecontactyourlocalauthorityfordetailson
thecollectionandrecyclingschemes.
ForSwitzerland:Theusedbatteryistobereturned
to the selling point.
Forothernon-EUcountries:Pleasecontactyour
localauthorityforcorrectmethodofdisposalof
theusedbattery.
AccordingtoEUdirective2006/66/EC,thebattery
can’tbedisposedimproperly.Thebatteryshallbe
separatedtocollectbylocalservice.
Após o uso, as pilhas
deverão ser entregues ao
estabelecimento comercial ou
e/ou baterias
rede de assistência técnica
autorizada.
InformationforEAC
Monthandyearof
manufacturing
pleasereferinformationinRatinglabel.
Nameandlocationof
manufacturer
ООО“Профтехника”
Адрес:3-йПроездМарьинойрощи,40/1
офис1.Москва,127018,Россия
Importerand
information
Наименованиеорганизации:ООО
“Профтехника”
Адрес:3-йПроездМарьинойрощи,40/1
офис1.Москва,127018,Россия
Контактноелицо:НатальяАстафьева,
+7 495 640 20 20
nat@profdisplays.ru
BDL3230QL
viii
臺灣RoHS
單元 限用物質及其化學符號
(Pb)
(Hg)
(Cd) 六價鉻
(Cr+ 6 )多溴聯苯
(PBB) 多溴二苯醚
(PBDE)
塑料外框
後殼
電路板組件
底座
電源線
其他線材
遙控器
備考1.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
備考2.〝-〞係指該項限用物質為排除項目。
液晶面板
BDL3230QL
ix
Table Of Contents
1. UnpackingandInstallation .......................................................1
1.1. Unpacking .........................................................................................1
1.2. Package Contents ........................................................................ 1
1.3. Installation Notes .........................................................................1
1.4. Mounting on a Wall ....................................................................2
1.4.1. VESA Grid ....................................................................2
1.5. Using of Remote sensor and power indicator ............3
2. Parts and Functions ...................................................................4
2.1. Control Panel ................................................................................. 4
2.2. Input/Output Terminals .............................................................5
2.3. Remote Control ........................................................................... 6
2.3.1. General functions .....................................................6
2.3.2. ID Remote Control .................................................7
2.3.3. Inserting the batteries in the remote
control.............................................................................8
2.3.4. Handling the remote control .............................8
2.3.5. Operating range of the remote control ......8
3. ConnectingExternalEquipment.............................................9
3.1. Connecting External Equipment (DVD/VCR/VCD) 9
3.1.1. Using COMPONENT video input ................. 9
3.1.2. Using Video Source input .....................................9
3.1.3. Using HDMI video input ...................................10
3.2. Connecting a PC ....................................................................... 10
3.2.1. Using VGA input .....................................................10
3.2.2. Using DVI input ......................................................10
3.2.3. Using HDMI input ................................................. 11
3.3. Connecting Audio Equipment ...........................................11
3.3.1. Connecting external equipment ...................11
3.3.2. Connecting an external audio device ........11
3.4. Connecting Multiple Displays in a Daisy-chain
Conguration .............................................................................. 12
3.4.1. Display control connection ..............................12
3.5. IR Pass-through Connection ...............................................12
3.6. Wire-connecting to Network ........................................... 13
4. Operation ................................................................................. 14
4.1. Watch the Connected Video Source ............................14
4.2. Change Picture Format ......................................................... 14
4.3. Play multimedia les via Local Area Network ..........14
4.3.1. Set up the network .............................................. 14
4.3.2. How to use DLNA-DMP .................................14
4.3.3. How to use DLNA-DMR from PC ............15
4.4. Play multimedia les from USB device .........................15
4.5. Play options .................................................................................. 16
4.5.1. Playing music les ..................................................16
4.5.2. Playing movie les .................................................16
4.5.3. Playing photo les .................................................16
4.6. How to use Opera browser (HTML5) .......................16
5. Changeyoursettings ............................................................. 18
5.1. Settings ............................................................................................18
5.1.1. Picture .......................................................................... 18
5.1.2. Sound ...........................................................................19
5.1.3. Tiling ..............................................................................19
5.1.4. Network ..................................................................... 20
5.1.5. Storage ........................................................................21
5.1.6. General settings ......................................................21
5.1.7. Web control .............................................................24
6. USBdevicecompatibility ....................................................... 28
7. Input Mode ............................................................................... 30
8. PixelDefectPolicy .................................................................. 31
8.1. Pixels and Sub-Pixels ...............................................................31
8.2. Types of Pixel Defects + Dot Denition ....................31
8.3. Bright Dot Defects ...................................................................31
8.4. Dark Dot Defects.....................................................................32
8.5. Proximity of Pixel Defects ................................................... 32
8.6. Pixel Defect Tolerances .........................................................32
8.7. MURA .............................................................................................32
9. CleaningandTroubleshooting .............................................. 33
9.1. Cleaning ..........................................................................................33
9.2. Troubleshooting .........................................................................34
10. TechnicalSpecications ......................................................... 35
BDL3230QL
1
1. Unpacking and Installation
1.1. Unpacking
This product is packed in a carton, together with the standard accessories.
Any other optional accessories will be packed separately.
Due to the size and weight of this display it is recommended for two people to move it.
After opening the carton, ensure that the contents are complete and in good condition.
1.2. Package Contents
Please verify that you received the following items with your package content:
LCD display
CD ROM
Quick start guide
Remote control with AAA batteries
Power cord (1.8 m)
VGA cable (1.8 m)
RS232 cable (1.8 m)
RS232 daisy-chain cable (1.8 m)
Logo Guider
Philips Logo * The supplied power cord varies depending on destination.
Power Cord
Video Signal Cable
(D-SUB to D-SUB Cable)
CD ROM
Quick start guide
Remote Control
and AAA Batteries
RS232 Cable
RS232 daisy-chain cable Logo guider
* Differences according to regions
Display design and accessories may differ from those illustrated above.
NOTES:
For all other regions, apply a power cord that conforms to the AC voltage of the power socket and has been approved by and complies with the
safety regulations of the particular country.
You might like to save the package box and packing material for shipping the display.
1.3. Installation Notes
Due to the high power consumption, always use the plug exclusively designed for this product. If an extended line is required, please consult your
service agent.
The product should be installed on a at surface to avoid tipping. The distance between the back of the product and the wall should be maintained
for proper ventilation. Avoid installing the product in the kitchen, bathroom or any other places with high humidity so as not to shorten the service life
of the electronic components.
The product can normally operate only under 3000m in altitude. In installations at altitudes above 3000m, some abnormalities may be experienced.
BDL3230QL
2
1.4. Mounting on a Wall
To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface
that complies with TUV-GS and/or UL1678 standard in North America.
Protective Sheet
VESA Grid
Table
1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as not to scratch the
screen face.
2. Ensure you have all accessories for mounting this display (wall mount, ceiling mount, table stand, etc).
3. Follow the instructions that come with the base mounting kit. Failure to follow correct mounting procedures could result in damage to the equipment
or injury to the user or installer. Product warranty does not cover damage caused by improper installation.
4. For the wall-mounting kit, use M4 mounting screws (having a length 10 mm longer than the thickness of the mounting bracket) and tighten them
securely.
5. Unit without base weight= 5.2 kg. The equipment and its associated mounting means still remain secure during the test. For use only with UL Listed
Wall Mount Bracket with minimum weight/load: 5.2 kg.
1.4.1. VESA Grid
BDL3230QL 200(H) x 200(V)mm
100(H) x 100(V)mm
Caution:
To prevent the display from falling:
For wall or ceiling installation, we recommend installing the display with metal brackets which are commercially available. For detailed installation
instructions, refer to the guide received with the respective bracket.
To lessen the probability of injury and damage resulting from fall of the display in case of earthquake or other natural disaster, be sure to consult the
bracket manufacturer for installation location.
Ventilation Requirements for enclosure locating
To allow heat to disperse, leave space between surrounding objects as shown in the
diagram below.
100 mm 100 mm
100 mm
100 mm
BDL3230QL
3
1.5. Using of Remote sensor and power indicator
1. Pull left the lens to have better remote control performance and easy to observe the light information of power status
2. Push right the lens before mounting the display for video wall application
3. Pull/Push the lens until hearing the click sound
Push right to collapse the lens Push left to extend the lens
BDL3230QL
4
2. Parts and Functions
2.1. Control Panel
1 2 3 4 5 6 7 8
MUTE INPUT MENU
1 [ ] button
Use this button to turn the display on or put the display to standby.
2 [MUTE] button
Switch the audio mute ON/OFF.
3 [INPUT] button
Choose the input source.
Used as [ ] button in the On-Screen-Display menu.
4 [ ] button
Increase the adjustment while OSD menu is on, or increase the
audio output level while OSD menu is off.
5 [ ] button
Decrease the adjustment while OSD menu is on, or decrease the
audio output level while OSD menu is off.
6 [ ] button
Move the highlight bar up to adjust the selected item while OSD
menu is on.
7 [ ] button
Move the highlight bar down to adjust the selected item while OSD
menu is on.
8 [MENU] button
Return to previous menu while OSD menu is on, or to activate the
OSD menu when OSD menu is off.
BDL3230QL
5
2.2. Input/Output Terminals
3 4
6
5
7
Y Pb Pr
2 1
16 8
9
10
11
12
13
14
15
LRL R INOUTRJ45IN USB
OUT
1 MAIN POWER SWITCH
Switch the main power on/off.
2 AC IN
AC power input from the wall outlet.
3 PC LINE IN
Audio input from VGA source (3.5mm stereo phone).
4 HDMI IN
HDMI video / audio input.
5 DVI-D IN
DVI-D video input.
6 VGA IN (D-Sub)
VGA video input.
7 Y/CVBS
Video source input.
8 AUDIO IN
Audio input from external AV device (RCA).
9 AUDIO OUT
Audio output to external AV device.
10 IR OUT/ 11 IR IN
IR signal output /input for the loop-through function.
NOTES:
This display’s remote control sensor will stop working if the jack
[IR IN] is connected.
To remotely control your A/V device via this display, refer to page
12 for IR Pass Through connection.
12 RJ-45
LAN control function for the use of remote control signal from
control center.
13 RS232 OUT / 14 RS232 IN
RS232C network output / input for the loop-through function.
15 USB PORT
Connect your USB storage device.
16 Security LOCK
Used for security and theft prevention.
BDL3230QL
6
2.3. Remote Control
2.3.1. General functions
1
2
3
4
5
6
7
8
10
9
12
14
15
11
13
16
1 [ ] POWER button
Turn the display on or put the display to standby.
2 [PLAY] buttons
Control playback of media les.
3 [ ] SOURCE button
Choose input source. Press [ ] or [ ] button to choose from
USB, Network, Internet, SmartCMS, CVBS, YPbPr,
VGA, HDMI and DVI-D, Press [ ] button to conrm and
exit.
4 [ ] HOME button
Access the OSD menu.
5 [ ] LIST button
No function.
6 [ ] [ ] [ ] [ ] NAVIGATION buttons
Navigate through menus and choose items.
7 [ ] button
Conrm an entry or selection.
8 [ ] ADJUST button
Access currently available options, picture and sound menus.
9 [ ] MUTE button
Press to turn the mute function on/off.
10 [ ] [ ] [ ] [ ] COLOR buttons
Choose tasks or options.
11 [Number/ ID SET/ ENTER] button
Enter text for network setting.
Press to set the display ID. Refer to 2.3.2. ID Remote Control
for more detail.
12 [ ] FORMAT button
Change picture format.
13 [ ] BACK button
Return to the previous menu page or exit from the previous
function.
14 [ ] INFO button
Display information about current activity.
15 [ ] OPTIONS button
Access currently available options, picture and sound menus.
16 [ ] [ ] VOLUME button
Adjust volume.
BDL3230QL
7
2.3.2. ID Remote Control
You can set the remote control ID when you want to use this remote
control on one of several different displays.
Press [ID] button. The red LED blinks twice.
1. Press [ID SET] button for more than 1 second to enter the ID
Mode. The red LED lights up.
Press the [ID SET] button again will exit the ID Mode. The red LED
lights off.
Press the digit numbers [0] ~ [9] to select the display you want to
control.
For example: press [0] and [1] for display No.1, press [1] and [1] for
display No.11.
The numbers available are from [01] ~ [255].
2. Not pressing any button within 10 seconds will exit the ID Mode.
3. If an error pressing of buttons other than the digits occured, wait
1 second after the red LED lights off and then lights up again, then
press the correct digits again.
4. Press [ENTER] button to conrm. The red LED blinks twice and
then lights off.
NOTE:
Press [NORMAL] button. The green LED blinks twice, indicating the
display is in normal operation.
It is necessary to set up the ID number for each display before
selecting its ID number.
BDL3230QL
8
2.3.3. Inserting the batteries in the remote control
The remote control is powered by two 1.5V AAA batteries.
To install or replace batteries:
1. Press and then slide the cover to open it.
2. Align the batteries according to the (+) and (–) indications inside the
battery compartment.
3. Replace the cover.
Caution:
The incorrect use of batteries can result in leaks or bursting. Be sure to follow these instructions:
Place “AAA” batteries matching the (+) and (–) signs on each battery to the (+) and (–) signs of the battery compartment.
Do not mix battery types.
Do not combine new batteries with used ones. It causes shorter life or leakage of batteries.
Remove the dead batteries immediately to prevent them from liquid leaking in the battery compartment. Don’t touch exposed battery acid, as it can
damage your skin.
NOTE: If you do not intend to use the remote control for a long period, remove the batteries.
2.3.4. Handling the remote control
Do not subject to strong shock.
Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately.
Avoid exposure to heat and steam.
Other than to install the batteries, do not open the remote control.
2.3.5. Operating range of the remote control
Point the front of the remote control toward this display’s remote control sensor when
pressing a button.
Use the remote control within a distance of less than 5m/16ft from this display’s sensor,
and a horizontal and vertical angle of less than 30 degrees.
NOTE: The remote control may not function properly when the remote control sensor
on this display is under direct sunlight or strong illumination, or when there is an
obstacle in the path of signal transmission.
30 30
BDL3230QL
9
3. Connecting External Equipment
3.1. Connecting External Equipment (DVD/VCR/VCD)
3.1.1. Using COMPONENT video input
AC IN
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
LRL R INOUTRJ45IN USB
OUT
DVD / VCR / VCD
[AUDIO IN]
[COMPONENT IN]
(YPbPr)
COMPONENT Out
(YPbPr)
Audio Out
[R]
[L]
3.1.2. Using Video Source input
LRL R INOUTRJ45IN USB
OUT
AC IN
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
DVD / VCR / VCD
[AUDIO IN]
[Y/CVBS IN]
Y/CVBS Out
[R]
[L]
Audio Out
BDL3230QL
10
3.1.3. Using HDMI video input
LRL R INOUTRJ45IN USB
OUT
AC IN
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
DVD / VCR / VCD
HDMI Out
[HDMI IN]
3.2. Connecting a PC
3.2.1. Using VGA input
LRL R INOUTRJ45IN USB
OUT
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
AC IN
PC
[VGA IN] [VGA AUDIO IN]
VGA Out
D-Sub 15 pin
Audio Out
3.2.2. Using DVI input
LRL R INOUTRJ45IN USB
OUT
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
AC IN
PC
[VGA AUDIO IN]
DVI Out
Audio Out
[DVI IN]
BDL3230QL
11
3.2.3. Using HDMI input
AC IN
LRL R INOUTRJ45IN USB
OUT
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
PC
HDMI Out
[HDMI IN]
3.3. Connecting Audio Equipment
3.3.1. Connecting external equipment
LRL R INOUTRJ45IN USB
OUT
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
AC IN
3.3.2. Connecting an external audio device
HDMI IN DVI IN COMPONENT INVGA INPC Line IN
AC IN
LRL R INOUTRJ45IN USB
OUT
DVD / VCR / VCD
STEREO AMPLIFIER
COMPONENT OUT (YPbPr)
AUDIO IN
AUDIO OUT
BDL3230QL
12
3.4. Connecting Multiple Displays in a Daisy-chain Configuration
You can interconnect multiple displays to create a daisy-chain conguration for applications such as a video wall.
3.4.1. Display control connection
Connect the [RS232C OUT] connector of DISPLAY 1 to the [RS232C IN] connector of DISPLAY 2.
DISPLAY 1
PC
DISPLAY 2
[RS-232C IN]
[RS-232C]
[RS-232C OUT]
[RS-232C IN]
3.5. IR Pass-through Connection
DVD / VCR / VCD
(DVD / VCR / VCD)
Remote Control
[IR OUT]
[IR IN]
BDL3230QL
13
3.6. Wire-connecting to Network
If you connect this display to a home network, you can play photos, music and videos from your computer. See Play multimedia les via Local Area Network
(Page 14) for more detail.
PC
[RJ-45]
[RJ-45] ROUTER
INTERNET
To setup the network:
1. Switch on the router and switch on its DHCP setting.
2. Connect the router to this display with an Ethernet cable.
3. Press [ ] HOME button on the remote control, then select Setup.
4. Select Connect to network, then press [ ] button.
5. Follow the on-screen instructions to install the network.
6. Wait for this display to nd the network connection.
7. If you are prompted, agree to the EndUserLicenceAgreement”.
NOTE: Connecting with a shielded CAT-5 Ethernet cable to comply with the EMC directive.
BDL3230QL
14
4. Operation
NOTE: The control button described in this section is mainly on the
remote control unless specied otherwise.
4.1. Watch the Connected Video Source
See page 11 for external equipments connection.
1. Press [ ] SOURCE button.
2. Press [ ] or [ ] button to choose a device, then press [ ]
button.
4.2. Change Picture Format
You can change the picture format to suit the video source. Each video
source has its available picture formats.
The available picture formats depend on the video source:
1. Press [ ] FORMAT button.
2. Press [ ] or [ ] button to choose a picture format, then press
[ ] button.
{Autozoom}: Enlarge the picture to ll the screen.
Recommended for minimal screen distortion but not for HD or
PC.
{Movie expand 16:9}: Scale 4:3 format to 16:9. Not
recommended for HD or PC.
{Wide screen}: Shows wide screen format content unstretched.
Not recommended for HD or PC.
{Unscaled}: Provide maximum detail for PC. Only available
when PC mode is selected in the {Picture} menu.
{4:3}: Display the classic 4:3 format.
4.3. Play multimedia files via Local Area
Network
To play les via Local Area Network, you will need:
A wired home network, connected with a Universal Plug and Play
(uPnP) router.
Optional: A LAN cable that connects your display to your home
network.
A media server running on your computer.
Appropriate settings on your computer rewall to allow you to run
the media server.
4.3.1. Set up the network
1. Connect your display and the computer to the same home network.
See illustration below to connect your display to a network.
2. Switch on your computer and the router.
• Singledisplaysetup:
PC
[RJ-45] ROUTER
[RJ-45]
• Multipledisplaysetup:
PC
[RJ-45]
[RJ-45] [RJ-45]
ROUTER
DISPLAY 1 DISPLAY 2
NOTE: If the apparatus does not return to DLNA mode due to
external electrical disturbances (e.g. electrostatic discharge), user
intervention is required.
Set up media sharing
1. Install a media server on your computer to share media les. These
are some media servers:
For PC: Windows Media Player 11 (or higher) or TVersity
For Mac: Twonky
2. Switch on media sharing on your computer using the media server.
For more information on how to set up the media server, refer to
the website of the media server.
4.3.2. How to use DLNA-DMP
Ensure you have connected to the network.
You can press button to display the connection of the network.
Picture format
Picture style
Sound style
Smart power
Volume
Monitor group
Monitor ID
Model name
SWVersion
Serial no
Temperature
Network configuration
IP address
Netmask
Gateway
Network name
Ethernet MAC address
Wide screen
Standard
Personal
Off
0
1
1
BDL3230QL
1.51
25°C
DHCP & Auto IP
192.168.1.116
255.255.255.0
192.168.1.1
BDL3230QL
FF:FF:FF:FF:FF:FF:
HDMI 1 1080p60 26/09/2014 Friday 09:32:00
Play les from display
1. Press [ ] SOURCE button, choose Network, and press [
] button.
USB
Network
Internet
SmartCMS
CVBS
YPbPr
VGA
HDMI
DVI-D
2. Now, you can see all the PC’s connected to the same router on the
screen. Choose the right one.
3. Press [ ] and [ ] to choose the directory and les to play.
4. You can connect up to 4 displays to the same PC and play same
media stream.
BDL3230QL
15
4.3.3. How to use DLNA-DMR from PC
1. Press [ ] HOME button, choose Network and press [ ]
button.
Sound
Tiling
Network
Storage
General settings
Network settings
Static IP Configuration
Digital Media Rendere...
Network name
Clear Internet memory
2. Set Digital Media Renderer DMR as ON.
Network settings
Static IP Configuration
Digital Media Rendere...
Network name
Clear Internet memory
Sound
Tiling
Network
Storage
General settings
Off
On
3. Set the name of your display.
Network settings
Static IP Configuration
Digital Media Renderer - D...
Network name
Clear Internet memory
Cancel Done Clear
BDL3230QL
4. Press [ ] HOME button to exit the OSD menu..
5. On your PC, go to Network and Sharing Center, and click
Choose homegroup and sharing options.
6. Check the media formats. Then, click Choose media
streaming options.....
7. Go to Advanced sharing settings, and check Turn on
network discovery.
8. Now, go to the directory of your media les. Choose the media
le by right click. On the submenu from Play To, You can nd all
displays connected to your network. Choose the display, and click
the media le to play..
Play les
1. Press [ ] SOURCE button.
2. Choose Network, and press [ ] button.
3. Choose a le from the content browser, and press [ ] button
to start playing.
4. Press the [PLAY]buttons on the remote control to control playing.
Tips:
Choose the top bar to lter your les by type.
Choose Sort to arrange the les by album name, artist, or other
elds.
To clear the list of ofine media servers, press [ ] OPTIONS
button. Then, choose Clear ofine servers and press [ ]
button.
4.4. Play multimedia files from USB device
1. Connect your USB device to the USB port on the display.
LRL R INOUTRJ45IN USB
OUT
USB
2. Press [ ] SOURCE button, choose USB, and press [ ]
button.
USB
Network
Internet
SmartCMS
CVBS
YPbPr
VGA
HDMI
DVI-D
3. The connected USB device is detected automatically for all its
playable les, which will be automatically sorted into 3 types:
Music, Movie, and Photo.
4. Press [ ] BACK button to go up to the top layer in the screen.
Press [ ] or [ ] button to choose the le type. Press [ ]
button to enter its play list.
5. Choose the le you want. Press [ ] button to start playing.
6. Follow the on-screen instruction to control the play option.
7. Press [PLAY]buttons (H F G I J) to control playing.
BDL3230QL
16
4.5. Play options
4.5.1. Playing music files
1. Choose Music in the top bar.
2. Choose one music track, and press [ ] button.
To play all the tracks in a folder, choose one music le. Then,
press [ ] to Play All.
To skip to the next or previous track, press [ ] or [ ] button.
To pause the track, press [ ] button. Press [ ] button
again to resume playback.
To skip backward or forward 10 seconds, press [ ] or [ ]
button.
To search backward or forward, press [G] or [J] button,
press repeatedly to toggle between different speeds.
To stop the music, press [H] button.
Music options
While you play music, press [ ] OPTIONS button, then press [ ]
button to choose an option:
{Shufe}: Enable or disable random play of tracks.
{Repeat}: Choose {Repeat} to play a track or an album repeatedly,
or choose {Playonce} to play a track once.
NOTE: To view information about a song (for example, title, artist or
duration), choose the song, then press [ ] INFO button. To
hide the information, press [ ] INFO button again.
4.5.2. Playing movie files
1. Choose Movie in the top bar.
2. Choose a video, and press [ ] button.
To play all the videos in a folder, choose one video le. Then,
press [ ] to Play All.
To pause the video, press [ ] button. Press [ ] button
again to resume playback.
To skip backward or forward 10 seconds, press [ ] or [ ]
button.
To search backward or forward, press [G] or [J] button,
press repeatedly to toggle between different speeds.
To stop the video, press [H] button.
Movie options
While playing video, press [ ] OPTIONS button, then press [ ]
button to choose an option:
{Subtitles}: Choose the available subtitle settings.
{Subtitlelanguage}: Choose the language for subtitles if available.
{Shufe}: Enable or disable random play of video les.
{Repeat}: Choose {Repeat} to play the video le repeatedly or
{Play once} to play the video le once.
{Status}: To view information about a video (for example, played
position, duration, title, or date).
4.5.3. Playing photo files
1. Choose Photo in the top bar.
2. Choose a photo thumbnail, then press ] button.
Start a slideshow
If there are multiple photos in a folder, choose a photo. Then, press
[ ] to Play All.
To skip to the previous or next photo, press [ ] or [ ] button,
and then press [ ] button.
To stop the slideshow, press [H] button.
Slideshow options
While you play a slideshow, press [ ] OPTIONS button, then press
[ ] button to choose an option:
{Shufe}: Enable or disable random display of pictures in the
slideshow.
{Repeat}: Choose {Repeat} to watch a slideshow repeatedly or
{Playonce} to watch once.
{SlideshowTime}: Choose the displaying time for each photo in the
slideshow.
{Slideshow Transitions}: Choose the transition from one photo to
the next.
4.6. How to use Opera browser (HTML5)
1. Press Source button, and choose Internet and press
[ ] button.
USB
Network
Internet
SmartCMS
CVBS
YPbPr
VGA
HDMI
DVI-D
2. Move the cursor to URL address bar. Press [ ] button and it
will pop out the on-screen keyboard. You can move the cursor to
enter the URL address. After nishing the URL address, choose
Done.
BDL3230QL
17
History
Bookmark
Web Address
X
Internet
www.google.com
http://
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
ww
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
ww
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
.
.
.
.
g
g
g
g
g
g
g
gg
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
.
.
..
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
oo
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
Done
Hide
. , @
g h i
p q r s
a b c
j k l
t u v
? ! -
<
d e f
m n o
w x y z
abc ABC 123 www Backspace
3. Move the cursor to icon and press [ ] button.
History
Bookmark
Web AddressX
Internet
www.google.com
http://www.google.com
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
.
.
.
.
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
g
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
ee
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
.
.
..
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
c
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
4. Now, you can see the web page.
NOTES:
The Opera browser does not support FLASH format.
Before using the browser, please set up network rst. Please refer to
page20 5.1.4 Network to set your network settings..
BDL3230QL
18
5. Change your settings
Using the remote control:
1. Press [ ] HOME button to display the OSD menu.
2. Press [ ] [ ] [ ] or [ ] button to choose its menu item or to
adjust its value. Press [ ] button to conrm.
3. Press [ ] BACK button to go back to the previous menu layer.
4. Press [ ] HOME button to exit the OSD menu.
Using the display’s control buttons
1. Press [ ] button to display the OSD menu.
2. Press [ ] [ ] [ ] or [ ] button to choose menu item or adjust
its value.
3. Press [ ] button to conrm menu selection and enter its
submenu.
4. Press [ ] button to exit the OSD menu.
5.1. Settings
Press [ ] HOME button.
5.1.1. Picture
menu
Picture style
Backlight
Colour
Sharpness
Noise reduction
MPEG artifact
Picture enhancement
Advanced
Scan mode
Format and edges
Picture reset
Sound
Tiling
Network
Storage
General settings
Picture style
Choose a predened picture setting.
Backlight
Adjust the brightness of this display’s backlight.
Colour
Adjust the colour saturation of the picture.
Sharpness
Adjust the sharpness of the picture.
Noise reduction
Choose the amount of noise reduction for the picture.
MPEG artifact
Smoothen transitions and haziness in the digital picture.
Picture enhancement
Fine-tune each pixel to match surrounding pixels and produce a brilliant,
high-denition image.
{Advanced sharpness}: Enable superior sharpness, especially on
lines and contours in the picture.
{Dynamiccontrast}: Dynamically enhance the details in the
dark, medium and light areas of the picture.
{Colourenhancement}: Dynamically enhance the vividness and
details of colours.
Advanced
Access advanced settings such as gamma, tint, video contrast and so on.
{Gamma}: Adjust the non-linear setting for picture luminance
and contrast.
{Tint}: Change the colour balance.
{Customtint}: Customise colour balance setting. Only available
if {Tint} {Custom} is chosen.
{Video contrast}: Adjust video contrast.
{Brightness}: Adjust screen brightness.
{Hue}: Adjust screen hue.
Scan mode
Change the display area of the image.
Format and edges
{Pictureformat}: Change the picture format.
See page 14 for the descriptions about Picture format.
BDL3230QL
19
Input resolution
Set the resolution of the VGA input. This is only required when the
display is unable to detect the VGA input resolution correctly.
Auto adjust
Use this function to automatically optimize the display of VGA input
image.
NOTE: This item is functional for VGA input only.
Picture reset
Reset all your picture settings to the factory defaults.
5.1.2. Sound
Sound style
Bass
Treble
Balance
Volume
Minimum volume
Maximum volume
Surround mode
Audio Out(line out)
Advanced
Sound reset
Sound
Tiling
Network
Storage
General settings
Sound style
Access predened sound settings.
Bass
Adjust to increase or decrease lower-pitched sounds.
Treble
Adjust to increase or decrease higher-pitched sounds.
Balance
Adjust to emphasize left or right audio output balance.
Volume
Adjust to increase or decrease the volume.
Minimum volume
Set the Minimum volume.
Maximum volume
Set the Maximum volume.
Surround mode
Set surround effects for audio performance.
Audio Out (line out)
Adjust audio output volume.
Advanced
Access advanced settings to enhance your audio experience.
{Autovolumeleveling}: Enable the reduction of sudden volume
changes.
{Speakersettings}: Turn on or off the internal speakers.
{Clear sound}: Enhance sound quality.
{Audiooutformat}: Choose the type of audio output through
the digital audio output connector. (HDMI only)
{Audiooutdelay}: Automatically sync the image on this display
to the audio from a connected home theatre.
{Audio out offset}: Adjust the setting for audio output delay.
Available if {Audiooutdelay} is switched on.
Sound reset
Reset to default setting.
5.1.3. Tiling
Enable
H monitors
V monitors
Position
Frame comp.
Switch on delay
Sound
Tiling
Network
Storage
General settings
With this function you can create a single large-screen matrix (video
wall) that consists of up to 225 sets of this display (up to 15-sets on the
verticaland15-setsonthehorizontalsides).
Enable
Choose to {On} or {Off} the Tiling function. If {On}, the display will
apply the settings in {Hmonitors}, {Vmonitors}, {Position}, and
{Framecomp.}.
H monitors
Adjust displays on the horizontal side.
V monitors
Adjust displays on the vertical side.
Position
Adjust the position of this display in the screen matrix.
Example:2x2screenmatrix(4displays)
H monitors = 2 displays
V monitors = 2 displays
1 2
3 4
H monitors
V monitors
Position
BDL3230QL
20
Example:5x5screenmatrix(25displays)
H monitors = 5 displays
V monitors = 5 displays
1 2
6 7
3 4
8 9
5
10
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
H monitors
V monitors
Position
Frame comp.
Choose to turn the frame compensation function on or off. If selected
{On}, the display will adjust the image to compensate for the width of
the display bezels in order to accurately display the image.
{On}
{Off}
NOTE: You need to enter factory mode to set up the compensation
width
Switch on delay
Adjust the power-on delaying time (in seconds) allows a sequential
powering-on for each display by their ID number when multiple displays
are connected.
5.1.4. Network
Sound
Tiling
Network
Storage
General settings
Network settings
Static IP Configuration
Digital Media Rendere...
Network name
Clear Internet memory
Network settings
{Networkconguration}: Choose how this display should assign
addresses to the network resources.
The user can choose {DHCP & Auto IP} (suggested) or {Static IP}.
Static IP Conguration
{Static IP} is chosen.Dene {IP address}, {Netmask}, {Gateway}, {DNS1},
and {DNS2} for this display. If {Network settings}
Digital Media Renderer - DMR
Receive multimedia les from the connected device by your network.
Network name
In the multiple-display connection, you can rename each display for easy
identication.
Use the on-screen keyboard or the remote control keypad to enter the
name.
Clear Internet memory
Clear all the cookies, bookmarks, history list and text used for auto ll.
BDL3230QL
21
5.1.5. Storage
Sound
Tiling
Network
Storage
General settings
SmartCMS
USB AutoPlay
USB copying
USB cloning
Clear Internet memory
SmartCMS
Select default storage location of contents for SmartCMS.
{Internal}: Set internal storage as default.
{External}: Set external storage as default.
USB AutoPlay
Select default storage location of contents for USB AutoPlay.
{Internal}: Set internal storage as default.
{External}: Set external storage as default.
USB copying
USB copying is able to transfer media les between internal
memory and USB ash device. In addition, it provides you an easy
way to import the URL for internet.
{Import}: Import media les and URL list from USB ash device to
internal memory.
{Export}: Export media les and URL list from internal memory to
USB ash device.
USB cloning
Import/Export user settings.
{Import}: Import user settings from USB ash device.
{Export}: Back up user settings to USB ash device.
Clear Internet memory
Clear all the cookies, bookmarks, history list and text used for auto ll.
Notes:
Before using import function of USB copying for AutoPlay, create a
new folder and name it “philips”. Put all media les into the specic
folder for AutoPlay.
Before using import function of USB copying for URL, create a new
text document and name it “url_schedulinglist.txt”. When entering a
URL, the format must follow the format below: “Scheduling Number,
URL address.“
For example, Set URL of schedule 1 and schedule 2 to www.google.
com and tw.yahoo.com, respectively.
1, www.google.com 2, tw.yahoo.com
5.1.6. General settings
Sound
Tiling
Network
Storage
General settings
Menu language
Monitor Group
Monitor ID
Auto search
Clock
Scheduling
Sleep timer
OneWire
Local KB lock
RC lock
Menu language
Choose language used for OSD menus.
Monitor group
Adjust the group range between 1 to 255. The default setting is 255.
Monitor ID
Adjust the ID number for controlling the display via the RS232C
connection. Each display must have a unique ID number when multiple
sets of this display are connected. Monitor ID number range is between
1 to 255. The default setting is 1.
Auto search
Choose to let this display detect and display available signal sources
automatically.
Clock
Set the current date and time for the display’s internal clock.
Scheduling
This function allows you to program up to 7 different scheduled time
intervals for this display to activate.
You can set:
Which input source the display will use for each scheduled
activation period.
The time for the display to turn on and turn off.
The days in a week for the display to activate.
NOTES:
We recommend you to set up current date and time in the {Clock}
menu before using this function.
After changing the {Clock} option in the {General settings} menu,
you need to set this {Scheduling} again.
BDL3230QL
22
com
Sound
Tiling
Network
Storage
General settings
Menu language
Monitor Group
Monitor ID
Auto search
Clock
Scheduling
Sleep timer
OneWire
Local KB lock
RC lock
1. There are 7 schedule can be set. Go to Status and choose On.
Slideshow durations
Status
Source
On time
Off time
Repeat modes
Playlist setting
Off
On
Schedule 1
Schedule 2
Schedule 3
Schedule 4
Schedule 5
Schedule 6
Schedule 7
2. Go to Source and choose input source.
If {Source} {USB playlist} is chosen. You need to set playlist.
If {Source} {Internet} is chosen. You need to set URL address.
If {Source} {USB AutoPlay} is chosen. You need to create a folder
named “philips” in the USB and put all media les into the specic folder
for auto play.
Status
Source
On time
Off time
Repeat modes
Playlist setting
Schedule 1
Schedule 2
Schedule 3
Schedule 4
Schedule 5
Schedule 6
Schedule 7 Slideshow durations
USB playlist
USB AutoPlay
Internet
SmartCMS
CVBS
YPbPr
VGA
HDMI
DVI-D
3. Set On time.
Status
Source
On time
Off time
Repeat modes
Playlist setting
Schedule 1
Schedule 2
Schedule 3
Schedule 4
Schedule 5
Schedule 6
Schedule 7
On time
Cancel Done
00 : 00
4. Set Off time.
Status
Source
On time
Off time
Repeat modes
Playlist setting
Schedule 1
Schedule 2
Schedule 3
Schedule 4
Schedule 5
Schedule 6
Schedule 7
Off time
Cancel
14 : 00
Done
5. Go to Repeat modes and choose.
Slideshow durations
Status
Source
On time
Off time
Repeat modes
Playlist setting
Schedule 1
Schedule 2
Schedule 3
Schedule 4
Schedule 5
Schedule 6
Schedule 7
No repeat
Every Sunday
Every Monday
Every Tuesday
Every Wednesday
Every Thursday
Every Friday
Every Saturday
BDL3230QL
23
6. If {Source} {USB} is chosen. Go to Playlist setting.
0001/0002
Options Exit
Video
-Press [ ] [ ] buttons to choose les.
-Press [ ] [ ] buttons to switch Playlist and File Manager.
-Press [ ] button to set or clear the playlist.
7. To save the playlist, press [ ] and choose Save list.
0004/0004
Options Exit
[..]
Movie.avi
\media\photo
Sort
Recursive Parser
Media Type
Save list
NOTES:
Each Playlist supports up to 30 les.
Playlist will not be cleared after {Factorysettings}. You have to
manually remove the les or delete usb_schedulinglist.txt in the
USB.
Sleep timer
Switch off this display after a specied time.
OneWire
Connect and control your HDMI-CEC compliant devices through
HDMI port to this display with the same remote control.
Local KB lock
Choose to enable or disable the keyboard (control buttons) function of
the display.
{Unlock}: Enable the keyboard function.
{Lockall}: Lock all keyboard function.
{Lockbutvolume}: Disable all the keyboard function except the
[ ] and [ ] button.
{Lockbutpower}: Disable all the keyboard function except the
[ ] button.
{Lockallexpectvolumeandpower}: Disable all the keyboard
function except the [ ], [ ] and [ ] button:
RC lock
Choose to enable or disable the button function of the remote control.
{Unlock}: Enable the keyboard function.
{Lockall}: Lock all keyboard function.
{Lockbutvolume}: Disable all the keyboard function except the
[ ] and [ ] button.
{Lockbutpower}: Disable all the keyboard function except the
[ ] POWER button.
{Lockallexpectvolumeandpower}: Disable all the keyboard
function except the [ ] [ ] and [ ] POWER button:
NOTES:
To disable the lock function from Local KB lock or RC lock
item, press buttons [ ] and 1 9 9 8 on the remote control
Before using USB AutoPlay, create a new folder and name it “philips”.
Put all media les into the specic folder for AutoPlay.
Pixel shift
For video input sources, you may choose {On} to move the screen
image automatically to protect the display from “burn-in” or “after-image”
symptoms 30 seconds after not operating the display.
Smart power
Choose a backlight level to optimise dynamic power consumption and
picture contrast.
The options are: {Off}, {Standard}, {Medium}, {High}.
Wake on lan
Choose {On} and you can turn on the display by network.
Switch on state
Choose the display status used for the next time you connect the
power cord.
{On} - The display will turn on when the power cord is connected
to a wall outlet.
{Standby} - The display will remain Standby when the power cord is
connected to a wall outlet.
{Last status} - The display will return to the previous power status
(on/off/standby) when removing and replacing the power cord..
Power LED Light
Choose {Off} to turn off the indicator.
Logo
Choose {Off} and the display will not display the logo when
you switch on.
Advanced power management
Choose {On}. Then, when no signal, the display will automatically turn
off.
Source notication
When you press [ ] POWER button to turn on the display from
standby mode or change the input signal, the information OSD is
displayed on the upper left corner of the screen.
Choose {Off} to turn off this function.
Factory settings
Reset all your customized settings to the factory defaults.
BDL3230QL
24
5.1.7. Web control
A. Ensure you have connected to the network. You can press INFO
button to display the connection of the network.
Picture format
Picture style
Sound style
Smart power
Volume
Monitor group
Monitor ID
Model name
SW Version
Serial no
Temperature
Network configuration
IP address
Netmask
Gateway
Network name
Ethernet MAC address
Auto zoom
Standard
Original
Off
20
1
1
BDL3230QL
0.07
39°C
DHCP
192.168.0.101
255.255.255.0
192.168.0.1
BDL3230QL
00:00:00:00:00:00
HDMI 1 1080p60 29/12/2014 Monday 16:10:14
B. From the computer connected to the PD, rst open your Web
browser. Then enter the PD’s address(192.168.0.101) for network
administration in the web address eld and hit enter to reach the
home page of Web Control.
Note: Default Username is admin with Password 1234.
C. The default Main Page of Web Control is Power Page. It provides
you an easy way to turn the display on or put the display to standby.
Power Off: Put the display to standby.
Power On: Turn the display on.
Get Power status: Click this button to get the display status.
Note: Power On function only supported after setting Eco mode to
Normal.
D. Click on video to switch to Video Page. It provides you an easy way
to adjust video settings.
Brightness: Adjust the overall image brightness by changing the intensity
of the LCD panel’s backlight. 0(minimum) to 100(maximum).
Video contrast: Adjust to sharpen the picture quality. The black portions
of the picture become richer in darkness and the white become
brighter. 0(minimum) to 100(maximum).
Color: Adjust to increase or decrease the intensity of colors in the
image. 0(minimum) to 100(maximum).
Sharpness: Adjust to improve image detail. 0(minimum) to
100(maximum).
Hue: Adjust screen hue. -50(minimum) to 50(maximum).
Backlight: Adjust the brightness of the display’s backlight. 0(minimum) to
100(maximum).
Gamma: Adjust the non-linear setting for picture luminance and contrast.
1(minimum) to 4(maximum).
Noise Reduction: Adjust to remove the noise in the image. You can
select a suitable noise reduction level. Choose from: Off/Low/Medium/
High
Picture Format: Change the display area of the image. You can select a
suitable format. Choose from: Auto zoom/Movies expand 16:9/Wide
screen/Unsealed/4:3
Video Source: Choose input source. Choose from USB/Network/
Internet/SmartCMS/CVBS/YPbPr/VGA/HDMI/DVI-D
Auto Adjust: Use the auto adjust function to automatically to optimize
the display of the image position.
E. Click Audio to switch to Audio Page. It provides you an easy way to
adjust audio settings.
BDL3230QL
25
Volume: Adjust to increase or decrease the volume. 0(minimum) to 60
(maximum).
Treble: Adjust to increase or decrease higher-pitched sounds.
-8(minimum) to 8(maximum).
Bass: Adjust to increase or decrease lower-pitched sounds. -8(minimum)
to 8(maximum).
F. Click on Color to switch to Color Page. It provides you an easy way
to adjust color settings.
Tint: Change the color balance. Choose from Cool/Normal/Warm/
Custom
Custom tint: With this function you can adjust the color tones of the
image precisely by changing the R(Red), G(Green) and B(Blue) settings,
respectively.
Note: Custom tint only available when Tint is set to Custom.
G. Click on Tiling to switch to Tiling Page. With this function you can
create a single large-screen matrix (video wall) that consists of up to
225 sets of this display (up to 15-sets on the vertical and 15-sets on
the horizontal sides).
H Monitor: Adjust displays on the horizontal side.
V Monitor: Adjust displays on the vertical side.
Position: Adjust the position of this display in the screen matrix.
Frame Comp.: Choose to turn the frame compensation function on or
off.
Enable: Choose to {On} or {Off} the Tiling function.
Switch on delay: Adjust the power-on delaying time allows a sequential
powering-on for each display
Note:
2 x 2 screen matrix(4 displays)
H monitors = 2 displays
V monitors = 2 displays
1 2
3 4
H monitors
V monitors
Position
5 x 5 screen matrix(25 displays)
H monitors = 5 displays
V monitors = 5 displays
1 2
6 7
3 4
8 9
5
10
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
H monitors
V monitors
Position
BDL3230QL
26
Frame comp. On
Frame comp. Off
H. Click on Date and Time to switch to Date and Time Page. It
provides you an easy way to set date and time for the display’s
internal clock.
I. Click on Schedule to switch to Schedule Page. The function allows
you to program up to 7 different scheduled time intervals for this
display to activate.
Note: See scheduling on Page 21 for the detail descriptions about
Scheduling setting.
J. Click Security to switch to Security Page. It provides you an easy
way to change your username and password.
Enter your new Username and Password into the Username and
Password elds and then click on the Set button to set your new
username and password.
K. Click on Advanced Setting to switch to Advanced Settings Page.
BDL3230QL
27
Local KB lock: Choose to enable or disable the keyboard (control
buttons) function of the display
RC lock: Choose to enable or disable the button function of the remote
control.
Monitor Group: Adjust the group range between 1 to 255. The default
setting is 1
Monitor ID: Adjust the ID number for controlling the display via the
RS232C connection. Each display must have a ID number when multiple
sets of this display are connected. Monitor ID number range is between
1 to 255. The Default setting is 1.
L. Click on Network Setting to switch to Network Setting Page.
Host Name: In the multiple-display connection, you can rename each
display for easy identication.
DHCP: Choose how this display should assign address to the network
resource. (On: DHCP & Auto IP, Off: Static IP). If DHCP is set to On,
device will request and be assigned an address every time it’s booted
up. Otherwise, you need to ask your network administrator for the
appropriate IP settings.
M. Click on System information to switch to System information Page.
Getting the display information. Such as Serial number, running time and
Temperature via the RS232/Network.
Note:
1. Some browser issues may be caused by the browser itself. For optimal
viewing and security we recommend that you keep your browser up to
date.
2. We recommend that you use IE for optimal performance with Web
Control.
BDL3230QL
28
6. USB device compatibility
USB Video Subtitle Formats (for language subtitles, etc.)
File
Extensions Container Video codec Maximum resolution Max.Frame Rate (fps) Max.Bit Rate
(Mbps) Audio codec
.mpg
mpeg
.vob
PS
MPEG-1 1920x1080 25p,30p,50i,60i 30 MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC(v1&v2),
DVD-PCM,AC3
MPEG-2 1920x1080 25p,30p,50i,60i 30
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30
H.264 1920x1080 25p,30p,50p,60p,60i 30
.ts TS
MPEG-2 1920x1080 25p,30p,50i,60i 30
MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC (v1&v2),
AC3,E-AC3,
Dolby Pulse
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30
H.264 1920x1080 25p,30p,50p,60p,60i 30
MVC
1920x1080i@eld rate=50, 60Hz
1920x1080p@frame rate=24, 25,30Hz
1280x720p@frame rate=50, 60Hz
- 30
.ts
.m2ts
.mts
.mt2
MaTS TTS
MPEG-2 1920x1080 25p,30p,50i,60i 30
MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC (v1&v2),
AC3,E-AC3,
Dolby Pulse
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30
H.264 1920x1080 25p,30p,50p,60p,60i 30
MVC
1920x1080i @ eld rate=50, 60Hz
1920x1080p @ frame rate=24, 25,30Hz
1280x720p @ frame rate=50, 60Hz
- 30
.ts
.m2ts
.mts
AVCHD
MPEG-2 1920x1080 25p,30p,50i,60i 30 MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC (v1&v2),
AC3,E-AC3,
Dolby Pulse
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30
H.264 1920x1080 25p,30p,50p,60p,60i 30
.ts
.m2ts
.mts
AVCHD MVC
1920x1080i@eld rate=50, 60Hz
1920x1080p@frame rate=24, 25,30Hz
1280x720p @ frame rate=50, 60Hz
- 30
MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC (v1&v2),
AC3,E-AC3,
Dolby Pulse
.m4v M4V H.264 1920x1080 25p,30p,50p,60p,60i 30 AAC
.ism/Manifest
.mpd frag MP4
H.264 1920x1080 25p,30p,50p,60p,60i 30 AAC/HE-AAC(v1&v2),
AC3,E-AC3,WMA,
WMA-PRO
MVC
1920x1080i@eld rate=50, 60Hz
1920x1080p@frame rate=24, 25,30Hz
1280x720p @ frame rate=50, 60Hz
- 30
.mp4 MP4
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30
AAC/HE-AAC(v1&v2),
AC3,E-AC3,WMA,
WMA-PRO
H.264 1920x1080 30
MVC
1920x1080i@eld rate=50, 60Hz
1920x1080p@frame rate=24, 25,30Hz
1280x720p @ frame rate=50, 60Hz
- 30
WMV9/VC1 1920x1080 30p,60i 30
.mkv
.mk3d MKV
MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30 MPEG-1(L1&L2),
MPEG-1,2,2.5 L3,
AAC/HE-AAC (v1&v2),
AC3,E-AC3, WMA,
WMA-PRO
H.264 1920x1080 30
BDL3230QL
29
USB Multimedia Formats
File Extensions Container Video codec Maximum resolution Frequency
(kHz)
Max.Bit Rate
(Mbps) Audio codec
.mp3 MP3 - - 48 384 MPEG-1,2,2.5 L3
.wma
.asf
WMA
(V2 up to V9.2) - - 48 192 WMA
.wma WMA Pro - - 96 768 WMA,WMA Pro
.wav(PC) LPCM - - 192 768 LPCM
.aif(mac)
.aiff(mac) LPCM - - 192 768 LPCM
.aac
.mp4
.m4a
AAC - - 48 1024 AAC,HE-AAC(v1&v2)
.pls
.m3u Playlists - - - - -
.m4a M4A - - 48 1024 AAC,HE-AAC(v1&v2)
USB Photo Formats
File
Extensions
Container Video
codec
Maximum Resolution Frequency Max.Bit
Rate
Audio
codec
jpg/jpeg JPEG baseline:
color mode = 444,
size <=32768x16128
color mode = 422v,
size <= 16384x16128
color mode = other, not support
- - -
bmp BMP 4096x3072_4bit,
2730x2500_8bit,
2048x1536_16bit,
1500x1200_32bit
- - -
png PNG 4096x3072_4bit,
2730x2500_8bit,
2048x1536_16bit,
1500x1200_32bit
- - -
gif GIF 4096x3072_4bit,
2730x2500_8bit,
2048x1536_16bit,
1500x1200_32bit
- - -
NOTES:
Sound or video may not work if the contents have a standard bit rate/frame rate above the compatible Frame/sec listed in the table above.
Video content with a Bit rate or Frame rate larger than the rate specied in the table above can cause choppy video during playback.
BDL3230QL
30
7. Input Mode
VGA Resolution:
Standard
Resolution
Active Resolution Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
VGA 640 480
60 Hz 25.175 MHz
4:3 Video Graphic Array72 Hz 31.5 MHz
75 Hz 31.5 MHz
WVGA 720 400 70 Hz 33.75 MHz 16:9 Wide Video Graphic Array
SVGA 800 600 60 Hz 40 MHz 4:3 Super VGA
75 Hz 49.5 MHz
XGA 1024 768 60 Hz 65 MHz 4:3 Extended Graphic Array
75 Hz 78.75 MHz
WXGA 1280 768 60 Hz 79.5 MHz 5:3 Wide XGA
WXGA 1280 800 60 Hz 79.5 MHz 16:10 Wide XGA
SXGA 1280 960 60 Hz 108 MHz 4:3 Super XGA
SXGA 1280 1024 60 Hz 108 MHz 5:4 Super XGA
WXGA 1360 768 60 Hz 85.5 MHz 16:9 Wide XGA
WXGA 1366 768 60 Hz 85.5 MHz 16:9 Wide XGA
UXGA 1600 1200 60 Hz 162 MHz 4:3 Ultra XGA
HD1080 1920 1080 60 Hz 148.5 MHz 16:9 HD1080
SDTV Resolution:
Standard
Resolution
Active Resolution Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
480i 720 480 29.97 Hz 13.5 MHz 4:3 Modied NTSC Standard
480p 59.94 Hz 27 MHz
576i 720 576 25 Hz 13.5 MHz 4:3 Modied PAL Standard
576p 50 Hz 27 MHz
HDTV Resolution:
Standard
Resolution
Active Resolution Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
720p 1280 720 50 Hz 74.25 MHz 16:9 Normally DVB Mode
60 Hz
1080i 1920 1080 25 Hz 74.25 MHz 16:9 Normally ATSC Mode
30 Hz
1080p 1920 1080 50 Hz 148.5 MHz 16:9 Normally ATSC Mode
60 Hz
The PC text quality is optimum in HD 1080 mode (1920 x 1080, 60Hz).
Your PC display screen might appear different depending on the manufacturer (and your particular version of Windows).
Check your PC instruction book for information about connecting your PC to a display.
If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5KHz (horizontal). In some cases, abnormal signals (such as
stripes) might appear on the screen when the PC power is turned off (or if the PC is disconnected). If so, press the [INPUT] button to enter the
video mode. Also, make sure that the PC is connected.
When horizontal synchronous signals seem irregular in RGB mode, check PC power saving mode or cable connections.
The display settings table complies to the IBM/VESA standards, and based on the analog input.
The DVI support mode is regarded as same to the PC support mode.
The best timing for the vertical frequency to each mode is 60Hz.
BDL3230QL
31
8. Pixel Defect Policy
We strive to deliver the highest quality products and use some of the industry’s most advanced manufacturing processes whilst practicing stringent quality
control. However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can
guarantee that all panels will be free from pixel defects, but philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects
will be repaired during the warranty period in line with your local guarantee conditions.
This notice explains the different types of pixel defects and denes the acceptable defect level for the LCD screen. In order to qualify for repair under
warranty, the number of pixel defects must exceed a certain level as shown in the reference table. If the LCD screen is within specication a warranty
exchange / claim back will be refused. Additionally, because some types or combinations of pixel defects are more noticeable than others, philips sets even
higher quality standards for those.
8.1. Pixels and Sub-Pixels
subpixel
pixel
A pixel, or picture element, is composed of three sub-pixels in the primary colors of red, green and
blue. Many pixels together form an image. When all sub-pixels of a pixel are lit, the three colored
sub-pixels together appear as a single white pixel. When all are dark, the three colored sub-pixels
together appear as a single black pixel. Other combinations of lit and dark sub-pixels appear as
single pixels of other colors.
8.2. Types of Pixel Defects + Dot Definition
Pixel and sub-pixel defects appear on the screen in different ways. There are three categories of pixel defects and several types of sub-pixel defects within
each category.
Dot denition = What is a defective “Dot”? :
One or more defective, adjacent sub-pixel are dened as one “dot”. The no. of defective sub-pixels are not relevant to dene a defective dot. This means
that a defective dot can consist of one, two or three defective sub-pixels which can be dark or lit.
RR G B
One dot = One Pixel; consists of three sub-pixels of Red, Green, and Blue.
8.3. Bright Dot Defects
Bright dot defects appear as pixels or sub-pixels that are always lit or “on”. These are the examples of bright dot defects:
One lit red, green or blue sub pixel Two adjacent lit sub pixels:
Red + Blue = Purple
Red + Green = Yellow
Green + Blue = Cyan (Light Blue)
Three adjacent lit sub pixels (one white pixel)
BDL3230QL
32
8.4. Dark Dot Defects
Black dot defects appear as pixels or sub-pixels that are always dark or “off”. These are the examples of black dot defects:
One dark dot Two adjacent dark dots = 1 pair of dark dots Two dark dots, specications denes the
minimum distance between dark dots
8.5. Proximity of Pixel Defects
Because pixel and sub-pixels defects of the same type that are nearby one another may be more noticeable, philips also species tolerances for the
proximity of pixel defects. In the table below you can nd specications about:
Allowed amount of adjacent dark dots = (adjacent dark dots =1 pair of dark dots)
Minimum distance between dark dots
Total no. of all defective dots
8.6. Pixel Defect Tolerances
In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a philips Plasma / LCD- display must have pixel or sub-
pixel defects exceeding the tolerances listed in the following table.
BRIGHT DOT EFFECT ACCEPTABLE LEVEL
1 lit sub pixel 2
BLACK DOT EFFECT ACCEPTABLE LEVEL
1 dark sub pixel 10
TOTAL DOT DEFECTS OF ALL TYPES 12
NOTE: * 1 or 2 adjacent sub pixel defects = 1 dot defect
8.7. MURA
Dark spots or patches may occasionally appear on some liquid crystal display (LCD) panels. This is known within the industry as Mura, which is a Japanese
term for “unevenness. It is used to describe an irregular pattern or area in which uneven screen uniformity appears under certain conditions. Mura is a
result of the deterioration of the liquid crystal alignment layer and is most commonly caused by long-term operation under high ambient temperatures. It
is an industry- wide phenomenon and Mura is not repairable. It is also not covered by our warranty terms.
Mura has been around since the introduction of LCD technology and with screens getting bigger and in operation 24/7, many displays are running in low
light conditions. This all adds to the possibility of Mura affecting displays.
HOW TO SPOT MURA
There are many symptoms of Mura and also multiple causes. Several of these are listed below:
Impurities or foreign particles in the crystal matrix
Uneven distribution of LCD matrix during manufacturing
Non-uniform luminance distribution of the backlight
Panel assembly induced stress
Flaws within the LCD cells
Thermal induced stress - high temperature operation over long periods of time
HOW TO AVOID MURA
Although we can not guarantee the complete eradication of Mura every time, in general the appearance of Mura can be minimized by these methods:
Lower the backlight brightness
Use a screen saver
Reduce the ambient temperature around the unit
BDL3230QL
33
9. Cleaning and Troubleshooting
9.1. Cleaning
Caution When Using the Display
Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high
temperature of exhaust air being released through the ventilation holes. Burns or personal injuries may occur if any body parts are brought too
close. Placing any object near the top of the display could also result in heat related damage to the object as well as the display itself.
Be sure to disconnect all cables before moving the display. Moving the display with its cables attached may damage the cables and thus cause re
or electric shock.
Disconnect the power plug from the wall outlet as a safety precaution before carrying out any type of cleaning or maintenance procedure.
Front Panel Cleaning Instructions
The front of the display has been specially treated. Wipe the surface gently using only a cleaning cloth or a soft, lint-free cloth.
If the surface becomes dirty, soak a soft, lint-free cloth in a mild detergent solution. Wring the cloth to remove excess liquid. Wipe the surface of
the display to remove dirt. Then use a dry cloth of the same type to dry.
Do not scratch or hit the surface of the panel with ngers or hard objects of any kind.
Do not use volatile substances such as insert sprays, solvents and thinners.
Cabinet Cleaning Instructions
If the cabinet becomes dirty, wipe the cabinet with a soft, dry cloth.
If the cabinet is extremely dirty, soak a lint-free cloth in a mild detergent solution. Wring the cloth to remove as much moisture as possible. Wipe
the cabinet. Use another dry cloth to wipe over until the surface is dry.
Do not allow any water or detergent to come into contact with the surface of the display. If water or moisture gets inside the unit, operating
problems, electrical and shock hazards may result.
Do not scratch or hit the cabinet with ngers or hard objects of any kind.
Do not use volatile substances such as insert sprays, solvents and thinners on the cabinet.
Do not place anything made from rubber or PVC near the cabinet for any extended periods of time.
BDL3230QL
34
9.2. Troubleshooting
Symptom PossibleCause Remedy
Nopictureisdisplayed 1. The power cord is disconnected.
2. The main power switch on the back of the
display is not switched on.
3. The selected input has no connection.
4. The display is in standby mode.
1. Plug in the power cord.
2. Make sure the power switch is switched on.
3. Connect a signal connection to the display.
Interferencedisplayedonthedisplayoraudible
noise is heard
Caused by surrounding electrical appliances or
uorescent lights.
Move the display to another location to see is the
interference is reduced.
Colorisabnormal The signal cable is not connected properly. Make sure that the signal cable is attached rmly
to the back of the display.
Pictureisdistortedwithabnormalpatterns 1. The signal cable is not connected properly.
2. The input signal is beyond the capabilities of
the display.
1. Make sure that the signal cable is attached
rmly.
2. Check the video signal source to see if it
is beyond the range of the display. Please
verify its specications with this display’s
specication section.
Displayimagedoesn’tllupthefullsizeofthe
screen
1. The zoom mode is not set correctly.
2. Scan Mode may be set incorrectly to
underscan.
3. If the image exceeds the screen size, Scan
Mode may need to be set to Underscan.
Use the Zoom mode or Custom zoom function
in the Screen menu to ne tune display geometry
and time frequency parameter.
Canhearsound,butnopicture Improperly connected source signal cable. Make sure that both video inputs and sound
inputs are correctly connected.
Canseepicturebutnosoundisheard 1. Improperly connected source signal cable.
2. Volume is turned all the way down.
3. {Mute} is turned on.
4. No external speaker connected.
1. Make sure that both video inputs and sound
inputs are correctly connected.
2. Press [ ] or [ ] button to hear sound.
3. Switch MUTE off by using the [ ] button.
4. Connect external speakers and adjust the
volume to a suitable level.
Somepictureelementsdonotlightup Some pixels of the display may not turn on. This display is manufactured using an extremely
high level of precision technology: however,
sometimes some pixels of the display may not
display. This is not a malfunction.
After-Imagescanstillbeseenonthedisplay
afterthedisplayispoweredoff.(Examples
ofstillpicturesincludelogos,videogames,
computerimages,andimagesdisplayedin4:3
normalmode)
A still picture is displayed for an over extended
period of time
Do not allow a still image to be displayed for
an extended period of time as this can cause a
permanent after-image to remain on the display.
BDL3230QL
35
10. Technical Specifications
Display:
Item Specications
Screen Size (Active Area) 698.4(H) x 392.85(V)
Aspect Ratio 16:9
Number of pixels 1920 (H) x 1080 (V)
Pixel pitch 0.36375(H) x 0.36375(V)
Displayable colors 16.7M
Brightness (typical) 350 cd/m2
Contrast ratio (typical) 1400:1
Viewing angle 178 degrees
In/Out Terminals:
Item Specications
Speaker Output Internal Speakers 10W (L) + 10W (R) [RMS]/16Ω
1 Way 1 Speaker System
82 dB/W/M/160 Hz ~ 13 KHz
Audio Output RCA Jack x 2 0.5V [rms] (Normal) / 2 Channel (L+R)
Audio Input RCA Jack x 2
3.5mm phone jack x 1
0.5V [rms] (Normal) / 2 Channel (L+R)
RS232C 2.5mm Phone jack x 2 RS232C in/RS232C out
RJ-45 RJ-45 Jack x 1 (8 pin) 10/100 LAN Port
HDMI Input HDMI Jack x 1
(Type A) (19 pin)
Digital RGB: TMDS (Video + Audio)
MAX:
Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
Audio - 48 KHz/ 2 Channel (L+R)
Supports LPCM only
DVI-D Input DVI-D jack Digital RGB: TMDS (Video)
VGA Input D-Sub Jack x 1 (15 pin) Analog RGB: 0.7V [p-p] (75Ω), H/CS/V: TTL (2.2kΩ), SOG: 1V [p-p] (75Ω)
MAX: 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
Component Input RCA Jack x 3 Y: 1V [p-p] (75Ω), Pb: 0.7V [p-p] (75Ω), Pr: 0.7V [p-p] (75Ω)
MAX: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p
Video Input RCA x 1 (Share with
Component_Y)
Composite 1V [p-p] (75Ω)
BDL3230QL
36
General:
Item Specications
Power Supply AC 100 - 240V, 50 - 60Hz
Power Consumption (Max) 81W
Power Consumption (typ.) 57W
Power Consumption (Standby & Off) <0.5 W (RS232 in active)
Dimensions (With Stand) [W x H x D] 726.5mmx462.9mmx239.8mm
Dimensions (Without Stand) [W x H x D] 726.5mmx425.4mmx63.6mm
Weight (With Stand) 6.67 Kg
Weight (Without Stand) 5.2 Kg
Gross Weight (Without Stand) 7.8 Kg
Environmental Condition:
Item Specications
Temperature Operational 0 ~ 40°C
Storage -20 ~ 60°C
Humidity Operational 20 ~ 80% RH (No condensation)
Storage 5 ~ 95% RH (No condensation)
Altitude Operational 0 ~ 3,000 m
Storage / Shipment 0 ~ 9,000 m
Internal Speaker:
Item Specications
Type 1 Way 1 Speaker
Input 10 W (RMS)
Impedance 16Ω
Output Sound Pressure 82 dB/W/M
Frequency Response 160 Hz ~ 13 KHz
2015©KoninklijkePhilipsN.V.Allrightsreserved.
PhilipsandthePhilipsShieldEmblemareregisteredtrademarksof
KoninklijkePhilipsN.V.andareusedunderlicensefrom
KoninklijkePhilipsN.V.
Specicationsaresubjecttochangewithoutnotice.

Navigation menu
