Philips

LCD monitor

117 cm (46")

multimedia Full HD

BDL4651VH

Stunning picture quality

even in locations with high ambient brightness

Deliver crystal clear marketing messages even in locations with high sunlight or brightness

conditions. The 1500 nit LCD display brings you incredible picture quality just about

anywhere.

Optimized for public viewing

• Projects a high brightness picture even in daylight

• Full HD LCD display, 1920x1080p

• Slim bezel design for a stylish look

Operational flexibility

• Ideal for Sunlight Applications

• Smart insert in the backcover to place a small pc

• Enhanced zoom feature supports tiled matrix applications

Lower total cost of ownership

• SmartPower for energy saving

• Brightness automatically adjusts with ambient conditions

Sustainable and safe

• Temperature sensor measures the health condition

• Complies with RoHS standards to care for the environment

BDL4651VH/00

Highlights

LCD monitor

117 cm (46") multimedia Full HD

High brightness - 1500 nits

Enjoy an excellent visual experience even in

areas illuminated by direct sunlight thanks to the

1500 nit panel. The high brightness offers a wide

array of new implementation possibilities

especially in locations that have high ambient

light levels, delivering crystal clear images for all

locations where ambient brightness is an issue.

Ideal for Sunlight Application

With an ultra high brightness panel, this model is

ideal for installations in all kinds of

environments, even in direct sunlight. However

it is vital to make sure that the display is

thermally conditioned in an air-conditioned

enclosure for such installations to ensure that

black spots do not appear on the panel.

Slim bezel

A slim bezel design adds a stylish look to a public

display to nicely blend in just about any

environment. Furthermore this design makes

the display ideal for tiled matrix video walls.

SmartPower

The backlight intensity can be controlled and

pre-set by the system to reduce the power

consumption by up to 50%, which saves

substantially on energy costs.

Automatic brightness control

The adjustment of display settings to

correspond with ambient light without user

intervention.

Full HD LCD display 1920x1080p

This display has a resolution that is referred to

as Full HD. The state-of-the-art LCD screen

technology has the full high-definition

widescreen resolution of 1080 progressive lines,

each with 1920 pixels. This allows the best

possible picture quality for HD input signals with

up to 1080 lines. It produces brilliant flicker-free

progressive scan pictures with optimum

brightness and superb colors. This vibrant and

sharp image will provide you with an enhanced

viewing experience.

Smart insert

Professional PC's are part of most public signage

installations. Quite often they increase the

overall depth to the display and cause a lot of

cable clutter. So we have designed this display

with Smart insert in the backcoverwhich is ideal

for the integration of a professional small form

factor PC. On top of that, the cable management

system offers a great solution to keep your

cables neat and professional looking.

Slim Bezel

BDL4651VH/00

Specifications

LCD monitor

117 cm (46") multimedia Full HD

Picture/Display

• Diagonal screen size: 46 inch / 117 cm

• Panel resolution: 1920x1080p

• Optimum resolution: 1920 x 1080 @ 60Hz

• Brightness: 1500 cd/m²

• Contrast ratio (typical): 4000:1

• Response time (typical): 8.5 ms

• Aspect ratio: 16:9

• Viewing angle (H / V): 178 / 178 degree

• Display colors: 16.7 million colors

• Picture enhancement: 3/2 - 2/2 motion pull down,

Motion compens. deinterlacing, Progressive scan,

Dynamic contrast enhancement

• Pixel pitch: 0.53 x 0.53 mm

Connectivity

• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,

DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output, 3.5

mm PC audio input x1

• AV input: HDMI x1, Audio (L/R) x2

• AV output: Audio (L/R) x1

• Other connections: External loudspeaker

connector, AC-out, Component RCA x1

Convenience

• Placement: Portrait, Landscape

• Tiled Matrix: Up to 5 x 5

• Picture in picture: PIP

• Signal Loop Through: RS232, VGA

• Keyboard control: Hidden, Lockable

• Remote control signal:: Lockable

• Ease of installation: Carrying Handles, Smart Insert,

AC Out

• Energy saving functions: Ambient light sensor, Smart

Power

• Safety control functions:: Heat Control,

Temperature Sensor

• Picture performance: Advanced color control

• Packaging: Reusable box

• Network controllable: RS232

Dimensions

• Bezel thickness: 20mm

• VESA Mount: 400 x 200mm

• Set dimensions (W x H x D):

1060 x 616.5 x 124.2 mm

• Set dimensions in inch (W x H x D):

41.7 x 24.3 x 4.9 inch

Operating conditions

• Temperature range (operation): 0 - 40 °C

• Relative humidity: 5 - 90 %

• MTBF: 60,000 hour(s)

Accessories

• Included accessories: Remote Control, Batteries for

remote control, AC Power Cord, VGA cable, User

manual on CD-ROM, Quick start guide

• Stand: BM05211

Miscellaneous

• Bezel: metallic anthracite

• Warranty: Europe/North America 3 years

• On-Screen Display Languages: English, French,

German, Italian, Polish, Turkish, Russian, Simplified

Chinese

• Regulatory approvals: CE, FCC, Class B, UL/cUL,

CCC, RoHS

Power

• Mains power: 90-264V AC, 50/60Hz

• Consumption (On mode): Typ 213W

• Standby power consumption: <1W

Sound

• Built-in speakers: 2 x 12W (RMS)

Supported Display Resolution

•Computer formats

Resolution Refresh rate

1024 x 768 60Hz

1280 x 768 60Hz

1280 x 800 60Hz

1360 x 768 60Hz

1366 x 768 60Hz

1440 x 900 60Hz

1600 x 1200 60Hz

1920 x 1080 60Hz

1920 x 1200 60Hz

640 x 480 60, 67, 72, 75Hz

800 x 600 56, 60, 72, 75Hz

•Video formats

Resolution Refresh rate

1080i 50, 60Hz

1080p 50, 60Hz

480i 60Hz

480p 60Hz

576i 50Hz

576p 50Hz

720p 50, 60Hz

Packaging dimensions

• EAN: 87 12581 60485 1

• Number of products included: 1

• Packaging type: Carton

Product dimensions

• Product dimensions (W x H x D):

41.7 x 24.3 x 5.5 inch

• Product dimensions (W x H x D):

106.04 x 61.65 x 13.88 cm

•

Issue date 2013-04-25

Version: 7.3.1

12 NC: 8670 000 76922

EAN: 87 12581 60485 1
