www.philips.com/support

BTB2315

User manual

Always there to help you

Register your product and get support at

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

2 Your micro system 4

Introduction 4

What's in the box 4

Overview of the product 5

Overview of the remote control 6

3 Get started 7

Connect speakers 7

Connect FM antenna 7

Connect power 7

Demonstrate the features 8

Prepare the remote control 8

Set clock 8

Turn on 8

4 Play 10

Play from disc 10

Play from USB 10

Control play 11

Skip to a track 11

Program tracks 11

Play from Bluetooth-enabled devices 11

5 Listen to the radio 13

Listen to DAB+ radio 13

Listen to FM radio 14

6 Other features 16

Set the alarm timer 16

Set the sleep timer 16

Ajust the display brightness 16

Listen to an external device 16

7 Product information 18

Specications 18

USB playability information 19

Supported MP3 disc formats 19

RDS program types 19

8 Troubleshooting 20

9 Notice 22

Compliance 22

Care for your product 22

Care for your environment 22

Trademark notice 23

Copyright 23

2EN

1 Important

Safety

This 'bolt of lightning' indicates uninsulated

material within the device may cause an

electrical shock. For the safety of everyone in

your household, please do not remove the

covering.

The 'exclamation mark' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:Toreducetheriskofreorelectric

shock, the device should not be exposed to rain

ormoistureandobjectslledwithliquids,such

as vases, should not be placed on the device.

CAUTION: To prevent electric shock, fully

insert the plug. (For regions with polarized

plugs: To prevent electric shock, match wide

blade to wide slot.)

Important Safety Instructions

• Follow all instructions.

• Heed all warnings.

• Do not use this device near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other

devices(includingampliers)thatproduce

heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the device.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Use only with the cart, stand, tripod,

bracket,ortablespeciedbythe

manufacturer or sold with the device.

When a cart is used, use caution when

moving the cart/device combination to

avoid injury from tip-over.

• Unplug this device during lightning storms

or when unused for long periods of time.

• Referallservicingtoqualiedservice

personnel.Servicingisrequiredwhenthe

device has been damaged in any way, such

as power-supply cord or plug is damaged,

liquidhasbeenspilledorobjectshave

fallen into the device, the device has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Batteries (packed or installed) shall not

be exposed to excessive heat such as

sunshine,reorthelike.

• Remove batteries when the unit is not

used for a long time.

• The device shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

thedevice(e.g.liquidlledobjects,lighted

candles).

3EN

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this device.

•Never lubricate any part of this device.

•Neverplacethisdeviceonotherelectricalequipment.

•Keep this device away from direct sunlight, naked

amesorheat.

•Never look into the laser beam inside this device.

•Ensure that you always have easy access to the power

cord, plug, or adaptor to disconnect this device from

the power.

4EN

2 Your micro

system

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

• Enjoy audio from discs, Bluetooth-enabled

devices, USB storage devices, or other

external devices;

• Listen to FM or DAB+ radio stations.

You can enrich sound output with below

sound effect:

• Digital Sound Control (DSC)

• DSC 1: Balance

• DSC 2: Warm

• DSC 3: Bright

• DSC 4: Powerful

• DSC 5: Clear

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• 2 x speakers

• Remote control (with one AAA battery)

• Short user manual

• Safety and notice

Short User Manual

www.philips.com/welcome

Always there to help you

Register your product and get support at

Question?

Contact

Philips

MICRO MUSIC SYSTEM BTB2315

MUTE

CLOCKSLEEP

TIMER

PROG

SOUND

VOL

REPEAT

MENU

DIM

SCAN

SHUFFLE

RDS

INFO

5EN

Overview of the product

a

• Turn on the product.

• Switch to standby mode or Eco power

standby mode.

b Display panel

• Show current status.

c

• Connect USB storage devices.

• Charge your device.

d AUDIO IN

• Connect external audio devices.

e Disc compartment

f

• Open or close the disc compartment.

g VOLUME

• Adjust volume.

h SOURCE

• Select a source: DISC, USB, FM,

DAB,AUDIO IN, BT (Bluetooth).

MICRO MUSIC SYSTEM BTB2315

b

c

d

e

f

h

g

a

• Start, pause, or resume play.

• Stop play or erase a program.

/

• Skip to previous/next track.

• Search within a track/disc/USB.

• Tune to a radio station.

• Adjust time.

6EN

Overview of the remote

control

a

• Turn the product on or off.

• Switch to standby mode or Eco power

standby mode.

b SOURCE

• Select a source: DISC, USB, DAB, FM,

BT(Bluetooth), AUDIO IN.

c INFO/RDS

• Display current status or the disc

information.

• For selected FM or DAB+ radio

stations, display RDS information.

d PRESET/ALBUM /

• Select a preset radio station.

• Skip to previous/next album.

e /

• Skip to the previous/next track.

• Search within a track/disc/USB.

MUTE

CLOCK SLEEP

TIMER

PROG

SOUND

VOL

REPEAT

MENU

DIM

SCAN

SHUFFLE

a

b

c

d

e

f

g

i

h

q

p

r

m

n

o

k

j

l

RDS

INFO

• Tune to a radio station.

• Adjust time.

f VOL +/-

• Adjust volume.

g MUTE

• Mute or restore volume.

h SOUND

• Select a sound effect: [BALANCE]

(Balance), [WARM] (Warm),

[BRIGHT] (Bright),[POWERFUL]

(Powerful), or [CLEAR] (Clear).

i CLOCK

• Set the clock.

• View clock information.

j SLEEP/TIMER

• Set sleep timer.

• Set alarm timer.

k PROG

• Program tracks.

• Program radio stations.

l REPEAT/SHUFFLE

• Selectrepeatorshufeplaymode.

m DIM

• Adjust display brightness.

n

• Start, pause, or resume play.

o /MENU

• Stop play or erase a program.

• Access DAB+ or FM menu.

p OK

• Conrmaselection.

q SCAN

• Scan FM or DAB+ radio stations.

r

• Press to open or close the disc

compartment.

7EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus. The

model number and serial number are on the

back of the apparatus. Write the numbers here:

Model No. __________________________

Serial No. ___________________________

Connect speakers

Note

•For optimal sound, use the supplied speakers only.

•Connect only speakers with impedance that is the

same or higher than the supplied speakers. Refer to the

Specicationssectionofthismanual.

Connect FM antenna

Tip

•For optimal reception, fully extend and adjust the

position of the antenna.

•For better FM stereo reception, connect an outdoor

FM antenna to the FM AERIAL socket.

Connect the supplied FM antenna to the FM

AERIAL socket on back of the product.

Connect power

Caution

•Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the product.

•Risk of electric shock! When you unplug the AC power

cord, always pull the plug from the socket. Never pull

the cord.

•Before you connect the AC power cord, ensure that

you have completed all other connections.

8EN

Demonstrate the features

In standby mode, press to demonstrate

features of this device.

» The features are displayed one by one

across the display panel.

• To turn off the demonstration, press

again.

Prepare the remote control

Caution

•Risk of explosion! Keep batteries away from heat,

sunshineorre.Neverdiscardbatteriesinre.

•Risk of decreased battery life! Never mix different

brands or types of batteries.

•Risk of product damage! When the remote control is

not used for long periods, remove the batteries.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert the supplied AAA battery with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

Set clock

1 In standby mode, press and hold CLOCK

on the remote control for more than two

seconds.

» [24 HOUR] or [12 HOUR] hour

format is displayed.

2 Press / to select [24 HOUR] or

[12 HOUR] hour format.

3 press CLOCKtoconrm.

» The hour digits are displayed and begin

to blink.

4 Press / to select hour and press

CLOCKtoconrm.

» The minute digits are displayed and

begin to blink.

5 Press / to select minute and press

CLOCKtoconrm.

» [SYNC ON] is displayed on the LCD

screen.

6 Press / to select whether to

synchronize the system clock with an RDS

radio station that transmits time signals,

and then press CLOCKtoconrm.

Note

•If no button is pressed in 90 seconds, the system exits

clock setting mode automatically.

Tip

•You can view clock information in power-on mode by

pressing CLOCK.

Turn on

Press .

» The unit switches to the last selected

source.

9EN

Switch to standby mode

Press again to switch the unit to standby

mode.

» The clock (if set) is displayed on the

panel.

Switch to ECO standby mode:

Press and hold for more than two seconds.

» The display panel is dimmed.

Note

•The unit switches to Eco Power Standby mode after 15

minutes in standby mode.

Switch between standby mode and ECO

standby mode:

Press and hold for more than two seconds.

Note

•The product automatically goes to charging mode

when a smart phone is connected through USB socket

in ECO standby mode.

10 EN

4 Play

Play from disc

1 Press SOURCE repeatedly to select the

DISC source.

2 Press to open the disc compartment.

3 Insert a disc with printed side facing

upward.

4 Press to close the disc compartment.

» Play starts automatically. If not, press

.

MUTE

CLOCK SLEEP

TIMER

PROG

SOUND

VOL

REPEAT

MENU

DIM

SCAN

SHUFFLE

RDS

INFO

DISC

MICRO MUSIC SYSTEM BTB2315

Play from USB

Note

•Make sure that the USB device contains playable audio

content.

1 Press SOURCE repeatedly to select the

USB source.

2 Insert a USB device into the socket.

» Play starts automatically. If not, press

.

Charge your device

You can charge your device through the USB

socket on this product with a USB cable (not

supplied).

Note

•The maximum current for USB charging is 500 mA.

•Not all devices for USB charging are guaranteed.

MUTE

CLOCK SLEEP

TIMER

PROG

SOUND

VOL

REPEAT

MENU

DIM

SCAN

SHUFFLE

RDS

INFO

MICRO MUSIC SYSTEM BTB2315

USB

11EN

Control play

/ Select a folder.

/ Selectanaudiole.

Pause or resume play.

Stop play.

REPEAT Play a track or all tracks repeatedly.

SHUFFLE Play tracks randomly.

VOL +/- Increase or decrease the volume.

MUTE Mute or restore sound.

SOUND Enrich sound effect with DSC:

balance, warm, and bright,

powerful and clear.

Skip to a track

For CD:

Press / to select another track.

For MP3 disc and USB:

1 Press / to select an album or a folder.

2 Press / toselectatrackorale.

MICRO MUSIC SYSTEM BTB2315

Program tracks

You can program a maximum of 20 tracks.

1 Press PROG to activate the program

mode.

2 For MP3 tracks, press / to select an

album.

3 Press / to select a track, and then

press PROGtoconrm.

4 Repeat steps 2-3 to program more tracks.

5 Press to play the programmed tracks.

» During play, [PROG] (program) is

displayed.

• To erase the program, in the stop

position, press .

Play from Bluetooth-enabled

devices

Note

•The effective operation range between the unit and

your Bluetooth enabled device is approximately 10

meters (30 feet).

•Any obstacle between the system and the device can

reduce the operational range.

•Compatibility with all Bluetooth devices is not

guaranteed.

12 EN

1 Press SOURCE repeatedly to select the

Bluetooth source.

» [BT] (Bluetooth) is displayed.

» TheBluetoothindicatorashesblue.

2 On your device that supports Advanced

AudioDistributionProle(A2DP),enable

Bluetooth and search for Bluetooth devices

that can be paired (refer to the user

manual of the device).

3 Select 'Philips BTB2315' on your

Bluetooth enabled device and if necessary

input '0000' as the pairing password.

» After successful pairing and connection,

the Bluetooth indicator turns solid

blue, and the unit beeps.

4 Play audio on the connected device.

» Audio streams from your Bluetooth

enabled device to this unit.

Tip

•The unit can memorize up to 4 previously connected

Bluetooth devices.

SCAN

RDS

INFO

0000

PIN

Philips BTB2315

MICRO MUSIC SYSTEM BTB2315

To disconnect the Bluetooth-enabled device:

• Deactivate Bluetooth on your device; or

• Move the device beyond the

communication range; or

• Press and hold for 3 seconds.

» The current Bluetooth connection is

disconnected.

To clear Bluetooth pairing history:

• Press and hold for 8 seconds.

» The current Bluetooth is cleared.

13EN

5 Listen to the

radio

Tip

•Position the antenna as far as possible from TV, VCR, or

other radiation source.

•Make sure that you have connected the supplied aerial.

•For optimal reception, fully extended and adjust the

position of the aerial.

Listen to DAB+ radio

Digital Audio Broadcasting (DAB+) is a way

of broadcasting radio digitally through a

network of transmitters. It provides you with

morechoice,bettersoundquality,andmore

information.

Tune to DAB+ radio stations

Note

•Make sure that the antenna is fully extended.

Press SOURCE repeatedly to select DAB

source.

» [FULL SCAN] (full scan) is displayed.

» The unit stores all DAB+ radio

stations automatically and broadcasts

therstavailablestation.

» The station list is memorized in the

unit. Next time when you turn on the

unit, the station scan does not take

place.

Note

•If no DAB+ radio station is found, [NO DAB] (no

DAB) is displayed, then [FULL SCAN] (full scan) is

displayed again.

To tune to a station from the available station

list:

In DAB+ mode, press / repeatedly to

navigate through the available DAB+ stations.

Store DAB+ radio stations

automatically

Note

•New stations and services will be added in DAB+

broadcast from time to time. To make new DAB+

stations and services available, perform full scan

regularly.

In DAB+ mode, press SCAN.

» The unit scans and stores all the

available DAB+ radio stations, and

broadcaststherstavailablestation.

Store DAB+ radio stations manually

Note

•You can store a maximum of 20 preset DAB+ radio

stations.

1 Tune to a DAB+ radio station.

2 Press PROG for three seconds to activate

the storing mode.

3 Press / to select a channel.

4 Press PROGtoconrm.

» The name of the preset station is

displayed.

5 Repeat above steps to store more DAB+

stations.

Note

•To remove a pre-stored DAB+ radio station, store

another station in its place.

14 EN

Select a preset DAB+ radio station

In DAB+ mode, press / to select a preset

number, and then press OKtoconrm..

Show DAB+ information

While listening to DAB+ radio, press INFO/

RDS repeatedly to scroll through the following

information (if available):

• Station Name

• RDS TEXT message

• Dynamic Label Segment

• Program Type

• Ensemble Name

• Frequency

• Signal error rate

• Bit rate

• Audio status (DAB, DAB+)

• Time

• Date

Use DAB+ menu

In DAB+ mode, press MENU to access DAB+

menu.

1 Press / to scroll the menu options:

• [FULL SCAN] (full scan): scan and

store all the available DAB+ radio

stations.

• [MANUAL] (manual): tune to a DAB+

station manually.

• [PRUNE] (prune): remove all the

invalid stations from the station list.

• [SYSTEM] (system): adjust system

settings.

2 To select an option, press OK.

3 If a sub-option is available, repeat steps

2- 3.

[System] (system)

• [RESET] (reset): reset all settings to

factory default.

• [BT RESET] (Bluetooth reset): reset

Bluetooth settings to factory default.

• [UPGRADE] (upgrade): upgrade

software if available.

• [BT UPGRADE] (Bluetooth upgrade):

upgrade Bluetooth software if available.

• [SW VER] (software version): show the

software version of this unit.

• [AUD DRC] (auto dynamic range

control):add or remove a degree of

compensation for the differences in the

dynamic range between radio stations.

There are four options:[NONE],

[HALF], [FULL], and [TWICE].

Note

•If no button is pressed within 30 seconds, the menu

exits.

Listen to FM radio

Tune to a radio station

1 Press SOURCE repeatedly to select FM

source.

2 Press and hold / for three seconds.

» The radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more stations.

To tune to a weak station:

Press / repeatedlyuntilyoundoptimal

reception.

Store FM radio stations automatically

Note

•You can program a maximum of 20 preset radio

stations (FM).

1 In FM mode, press MENU to access FM

menu.

» [SEARCH LEVEL] (search level) is

displayed.

15EN

2 Press OK, and then press / to scroll

the menu options:

• [Strong] (strong stations): scan stations

with strong signals only.

• [All] (all stations): scan all available FM

radio stations.

3 Press OK to select an option.

4 In FM mode, press SCAN.

» The stations scanned are based on the

selection in step 2.

» Theunitbroadcaststherstscanned

FM radio stations.

Store FM radio stations manually

1 Tune to an FM radio station.

2 Press PROG to activate programming

mode.

» [PROG] (program) blinks.

3 Press / repeatedly to select a number.

4 Press PROGagaintoconrm.

» Thefrequencyofthepresetstationis

displayed.

5 Repeat above steps to store more FM

stations.

Note

•To remove a pre-stored station, store another station

in its place.

Select a preset radio station

In FM mode, press / to select a preset

radio station.

Show RDS information

Radio Data System (RDS) is a service

that allows FM stations to show additional

information.

1 Tune to an RDS station.

2 Press RDS/INFO repeatedly to scroll

through the following information (if

available).

• Radio text message

• Program type

• Frequency

• Stereo or Mono

16 EN

6 Other features

Set the alarm timer

This unit can be used as an alarm clock. You can

select DISC, FM, DAB, or USB as alarm source.

Note

•Make sure that you have set the clock correctly.

1 In standby mode, press and hold SLEEP/

TIMER for three seconds.

» [TIMER] is displayed, and then [DISC]

is displayed and begins to blink.

2 Press / (or SOURCE) repeatedly to

select an alarm source (DISC, USB, DAB,

FM ).

3 Press SLEEP/TIMER (or OK)toconrm.

» The hour digits are displayed and begin

to blink.

4 Repeat steps 2-3 to set hour, minute, and

adjust volume of the alarm.

Note

•If no button is pressed in 90 seconds, the system exits

timer setting mode automatically.

To activate or deactivate the alarm timer:

Press SLEEP/TIMER repeatedly to view the

alarm information and activate or deactivate the

alarm.

» If timer is activated, [TIMER] is

displayed.

» If timer is deactivated, [TIMER] (timer)

disappears.

Tip

•If DISC/USB source is selected, but no disc is placed or

no USB connected, the system switches to FM source

automatically.

Set the sleep timer

To set the sleep timer, in turn on mode, press

SLEEP/TIMER repeatedly to select a set period

of time (in minutes).

» When sleep timer is activated, [SLEEP]

is displayed. Otherwise, [SLEEP]

disappears.

Ajust the display brightness

Press DIM repeatedly to adjust the display

brightness:

• [DIM 1]

• [DIM 2]

• [DIM OFF]

Listen to an external device

You can listen to an external device through this

unit with an audio cable.

1 Press SOURCE repeatedly to select

AUDIO IN source.

2 Connect an audio cable (not supplied)

between:

• AUDIO IN jack (3.5 mm) on the unit;

• and the headphone jack on an external

device.

3 Start to play the device (see the device

user manual).

17EN

MUTE

CLOCK SLEEP

TIMER

PROG

SOUND

VOL

REPEAT

MENU

DIM

SCAN

SHUFFLE

RDS

INFO

AUDIO IN

AUDIO IN

MICRO MUSIC SYSTEM BTB2315

18 EN

7 Product

information

Note

•Product information is subject to change without prior

notice.

Specications

Amplier

Maximum Output Power 20 W

FrequencyResponse 60 Hz - 20

kHZ; ±3 dB

Signal to Noise Ratio >70 dBA

Total Harmonic Distortion <1%

Aux Input 600 mV RMS

22 kohm

Speakers

Speaker Impedance 6 ohm

Speaker Driver Full range 3"

Sensitivity >85 dB/m/W

Disc

Laser Type Semiconductor

Disc Diameter 12 cm/8 cm

Support Disc CD-DA, CD-R, CD-

RW, MP3-CD

Audio DAC 24 Bits/44.1 kHz

Total Harmonic

Distortion

<1% (1 kHz)

FrequencyResponse 60 Hz - 16 kHZ;

±3 dB

S/N Ratio >70 dBA

USB

USB Direct Version 1.0 (2.0 compatiable)

USB Charging ≤500mA

Bluetooth

Bluetooth version V4.0

Frequencyband 2.4 GHz ~ 2.48 GHz ISM

Band

Range 10 m (free space)

Tuner (FM)

Tuning Range 87.5-108 MHz

Tuning grid 50 KHz

Sensitivity

- Mono, 26 dB S/N Ratio

- Stereo, 46 dB S/N Ratio

<22 dBf

<45 dBf

Search Selectivity <30 dBf

Total Harmonic Distortion <3%

Signal to Noise Ratio >45 dBA

General information

AC power 220-240 V~, 50 Hz

Operation Power

Consumption

15 W

Eco Standby Power

Consumption

<0.5 W

Dimensions

- Main Unit

(W x H x D)

- Speaker Box

(W x H x D)

180 x 121 x 247 mm

150 x 238 x 125 mm

Weight

- Main Unit

- Speaker Box

1.6 kg

2 x 0.98 kg

19EN

USB playability information

Compatible USB devices:

• USBashmemory(USB2.0orUSB1.1)

• USBashplayers(USB2.0orUSB1.1)

• memorycards(requiresanadditionalcard

reader to work with this unit)

Supported USB formats:

• USBormemoryleformat:FAT12,FAT16,

FAT32 (sector size: 512 bytes)

• MP3 bit rate (data rate): 32-320 Kbps and

variable bit rate

• Directory nesting up to a maximum of 8

levels

• Number of albums/ folders: maximum 99

• Number of tracks/titles: maximum 999

• File name in Unicode UTF8 (maximum

length: 32 bytes)

Unsupported USB formats:

• Empty albums: an empty album is an album

thatdoesnotcontainMP3les,andwill

not be shown in the display.

• Unsupportedleformatsareskipped.For

example, word documents (.doc) or MP3

leswithextension.dlfareignoredand

not played.

• WMA,AAC,WAV,PCMaudioles

• DRMprotectedWMAles(.wav,.m4a,

.m4p, .mp4, .aac)

• WMAlesinLosslessformat

Supported MP3 disc formats

• ISO9660, Joliet

• Maximum title number: 128 (depending on

lenamelength)

• Maximum album number: 99

• Supportedsamplingfrequencies:32kHz,

44.1 kHz, 48 kHz

• Supported Bit-rates: 32~256 (kbps),

variable bit rates

RDS program types

NO TYPE No RDS programme type

NEWS News services

AFFAIRS Politics and current affairs

INFO Special information programs

SPORT Sports

EDUCATE Education and advanced

training

DRAMA Radio plays and literature

CULTURE Culture, religion and society

SCIENCE Science

VARIED Entertainment programs

POP M Pop music

ROCK M Rock music

MOR M Light music

LIGHT M Light classical music

CLASSICS Classical music

OTHER M Special music programs

WEATHER Weather

FINANCE Finance

CHILDREN Children’s programs

SOCIAL Social Affairs

RELIGION Religion

PHONE IN Phone In

TRAVEL Tr ave l

LEISURE Leisure

JAZZ Jazz Music

COUNTRY Country Music

NATION M National Music

OLDIES Oldies Music

FOLK M Folk Music

DOCUMENT Documentary

TES Alarm Test

ALARM Alarm

20 EN

8 Troubleshooting

Warning

•Never remove the casing of this device.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

device, check the following points before

requestingservice.Iftheproblemremains

unsolved, go to the Philips Web page (www.

philips.com/support). When you contact Philips,

make sure that the device is nearby and the

model number and serial number are available.

No power

•Make sure that the AC power cord of the

device is connected properly.

•Make sure that there is power at the AC

outlet.

•As a power-saving feature, the system

switches off automatically 15 minutes after

track play reaches the end and no control

is operated.

No sound or poor sound

•Adjust the volume.

•Check that the speakers are connected

correctly.

•Check if the stripped speaker wires are

clamped.

No response from the unit

•Disconnect and reconnect the AC power

plug, then turn on the unit again.

Remote control does not work

•Beforeyoupressanyfunctionbutton,rst

select the correct source with the remote

control instead of the main unit.

•Reduce the distance between the remote

control and the unit.

•Insert the battery with its polarities (+/–

signs) aligned as indicated.

•Replace the battery.

•Aim the remote control directly at the

sensor on the front of the unit.

No disc detected

•Insert a disc.

•Make sure that the disc is inserted with

printed side facing upward.

•Wait until the moisture condensation at

the lens has cleared.

•Replace or clean the disc.

•UseanalizedCDorcorrectformatdisc.

Cannot display some les in USB device

•ThenumberoffoldersorlesintheUSB

device has exceeded a certain limit. This

phenomenon is not a malfunction.

•Theformatsoftheselesarenot

supported.

USB device not supported

•The USB device is incompatible with the

unit. Try another one.

Poor radio reception

•Increase the distance between the unit and

your TV or VCR.

•Connect and fully extend supplied antenna.

Music playback is unavailable on this unit even

after successful Bluetooth connection.

•The device cannot be used to play music

through this unit wirelessly.

The audio quality is poor after connection

with a Bluetooth-enabled device.

•The Bluetooth reception is poor. Move the

device closer to this unit or remove any

obstacle between them.

Bluetooth cannot be connected with this unit.

•Thedevicedoesnotsupporttheproles

requiredforthisunit.

•The Bluetooth function of the device is

not enabled. Refer to the user manual of

thedevicetondouthowtoenablethe

function.

•This unit is not in pairing mode.

•This unit is already connected with another

Bluetooth-enabled device. Disconnect that

device and then try again.

• If you pair and connect through NFC,

make sure that:

21EN

• you have enabled both the Bluetooth

and NFC features on your device.

• you have kept the NFC area of the

device in touch with that of the

speaker until you heard a beep.

The paired mobile device connects and

disconnects constantly.

•The Bluetooth reception is poor. Move the

device closer to this unit or remove any

obstacle between them.

•Some mobile phones may connect and

disconnect constantly when you make

or end calls. This does not indicate any

malfunction of this unit.

•For some devices, the Bluetooth

connection may be deactivated

automatically as a power-saving feature.

This does not indicate any malfunction of

this unit.

Timer does not work

•Set the clock correctly.

•Switch on the timer.

Clock/timer setting erased

•Power has been interrupted or the power

cord has been disconnected.

•Reset the clock/timer.

22 EN

9 Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

WOOX Innovations may void the user’s

authoritytooperatetheequipment.

Compliance

Hereby, WOOX Innovations declares that this

product is in compliance with the essential

requirementsandotherrelevantprovisions

ofDirective1999/5/EC.Youcanndthe

Declaration of Conformity on www.philips.com/

support.

This apparatus includes this label:

Care for your product

• Do not insert any objects other than discs

into the disc compartment.

• Do not insert warped or cracked discs into

the disc compartment.

• Remove the discs from the disc

compartment if you are not using the

product for an extended period of time.

• Onlyusemicroberclothtocleanthe

product.

Care for your environment

Disposal of your old product and battery

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU.

This symbol means that the product contains

batteries covered by European Directive

2013/56/EU which cannot be disposed of with

normal household waste.

Inform yourself about the local separate

collection system for electrical and electronic

products and batteries. Follow local rules and

never dispose of the product and batteries

with normal household waste. Correct disposal

of old products and batteries helps prevent

negativeconsequencesfortheenvironmentand

human health.

Removing the disposable batteries

To remove the disposable batteries, see battery

installation section.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by a

specialized company. Please observe the local

regulations regarding the disposal of packaging

materials,exhaustedbatteriesandoldequipment.

23EN

Trademark notice

This item incorporates copy protection

technology that is protected by U.S. patents

and other intellectual property rights of

Rovi Corporation. Reverse engineering and

disassembly are prohibited.

The Bluetooth® word mark and logos are

registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by WOOX

Innovations is under license.

Note

•The type plate is located on the back of the device.

Copyright

2014 © WOOX Innovations Limited. All rights

reserved.

Specicationsaresubjecttochangewithout

notice. WOOX reserves the right to change

products at any time without being obliged to

adjust earlier supplies accordingly.

Specifications are subject to change without notice.

2014 © WOOX Innovations Limited.

All rights reserved.

Philips and the Philips’ Shield Emblem are registered

trademarks of Koninklijke Philips N.V. and are used by WOOX

Innovations Limited under license from Koninklijke Philips N.V.

BTB2315_12_UM_V1.0
