Philips

Mini Audio System

FW-P750

Mini Hi-Fi System

with 3CD Changer

Impressive power and bass

• 190W RMS/280W Music Power

• Bass Reflex Speaker System delivers a powerful, deeper bass

Extensive sound features

• Choose from 6 modes of Digital Sound Control

• Choose from 6 modes of Virtual Ambience Control

• 3-step Dynamic Bass Boost for deep bass experience

Intuitive and easy to use

• Interactive Dashboard Display for a visual audio experience

Issue date 2014-02-05

Version: 1.0.2

12 NC: 9073 100 10134

EAN: 87 10895 70301 7

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

Specifications

FW-P750/22

Mini Audio System

Highlights

190W RMS/280W Music Power

190W RMS/280W Music Power

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep bass

experience from a compact loudspeaker box system.

It differs from a conventional loudspeaker box

system in the addition of a bass pipe that is

acoustically aligned to the woofer to optimize the

low frequency roll-off of the system. The result is

deeper controlled bass and lower distortion. The

system works by resonating the air mass in the bass

pipe to vibrate like a conventional woofer.

Combined with the response of the woofer, the

system extends the overall low frequency sounds to

create a whole new dimension of deep bass.

6-Mode Digital Sound Control

Choose from 6 modes of Digital Sound Control

6Mode Virtual Ambience Control

Choose from 6 modes of Virtual Ambience Control

3-step Dynamic Bass Boost

Dynamic Bass Boost maximizes your music

enjoyment by emphasizing the bass content of the

music throughout the range of volume settings -

from level one to level three – at the touch of a

button! You can customize the bass level that fits

your style. Bottom-end bass frequencies usually get

lost when the volume is set at a low level. To

counteract this, Dynamic Bass Boost can be switched

on to boost bass levels, so you can enjoy consistent

sound even when you turn down the volume.

Interactive Dashboard Display

Interactive Dashboard Display is a visually attractive

animated graphics display with volume meter. It gives

you at-a-glance track and volume information using

an attractive dashboard interface. Interactive

Dashboard Display integrates a Fluorescent Tube

Display (FTD) and a Volume Unit (VU) meter to

display volume levels, useful track information and

music amplitude during playback. The exciting

animated graphics add to the overall 'feel' of the

music.

Sound

• Output Power: 280W Music Power

• Sound Enhancement: Digital Sound Control 6

modes, Dynamic Bass Boost 3 steps, Virtual

Ambience, 6 modes

Loudspeakers

• Main Speaker: 2 way, Bass Reflex Speaker System,

5.25" woofer, 2" tweeter, Speaker grilles

detachable

• Number of Loudspeakers: 5

Audio Playback

• Playback Media: CD, CD-R, CD-RW

• Compression format: Dolby Digital

• Disc Playback Modes: 40-Track Programmable,

Repeat/one/all/program, Shuffle Play

• Loader Type: 3 CD Carousel

• Number of Discs: 3

• Cassette Deck Technology: Logic

• Cassette Playback Modes: Electronic Speed

Control, Full Auto Stop

•Number of decks: 2

Audio Recording

• Recording Media: Tape

• Tape Recording Enhancement: Automatic

Recording Level, CD Synchro Start Recording

Tuner/Reception/Transmission

• Auto digital tuning

• RDS: News, Program Type, Radio Text, RDS

Clock Set, Station Name

• Tuner Bands: FM Stereo, MW

• Tuner Enhancements: Auto Store, Easy Set (Plug &

Play)

Connectivity

• Headphone: 3.5 mm

• Other connections: FM Antenna, MW Antenna,

Subwoofer out, TV in (audio, cinch)

Convenience

• Alarms: CD Alarm, Radio Alarm, Sleep timer

• Clock: On main display

• Display Type: FTD

• Indications: DIM mode

Accessories

• Included accessories: AC Power Cord, FM/MW

Antenna

• Remote control: 37-key

Dimensions

• Set dimensions (W x H x D): 265 x 310 x 390 mm

• Main speaker dimensions (W x H x D):

240 x 310 x 315 mm

• Center speaker dimensions (W x H x D):

260 x 115 x 240 mm

• Surround Speaker dimensions (W x H x D):

178 x 90 x 178 mm

• Packaging dimensions (W x H x D):

772 x 410 x 474 mm

• Weight incl. Packaging: 18 kg

•
