Powerful surround, high definition video

with four tower speakers

This full-digital system delivers outstanding surround sound, providing a theater-like movie

experience in your home. It plays back a wide variety of formats from any sort of disc,

and from portable media players and USB sticks.

Connect and enjoy multiple sources

• Hi-Speed USB 2.0 Link plays media from USB flash drives

Brings audio and video to life

• HDMI 1080p upscales to high definition for sharper pictures

• DoubleBASS for an extended, deep bass experience

• DTS, Dolby Digital and Pro Logic II surround sound

• Karaoke Scoring for fun and exciting song contests at home

• 12-bit/108MHz video processing for sharp, natural images

Plays all your movies and music

• DivX Ultra Certified for enhanced playback of DivX videos

• Plays WMV, DivX, WMA, MP3 and JPEG digital camera photos

• Plays CD, (S)VCD, DVD, DVD+R/RW, DVD-R/RW, DVD+R DL

Easy to set up and use

• EasyLink for easy control of connected devices via HDMI CEC

• Floor standing speakers for freedom of placement

Philips

DVD home theater system

HTS3568

1000

HTS3568/98

DVD home theater system

Specifications Product highlights

Picture/Display

•D/A converter: 12 bit, 108 MHz

•Picture enhancement: High Def (720p, 1080i,

1080p), Progressive Scan

Sound

•Output power (RMS): 4x125W, 2x250W

•Total Output Power: 1000 W

•D/A converter: 24 bit, 192 kHz

•Frequency response: 180-14000 Hz

•Signal to noise ratio: >65 dB

•Sound System: DTS, Dolby Digital, Dolby Prologic

II, Stereo

•Sound Enhancement: Class "D" Digital Amplifier,

Night Mode

•Equalizer settings: Rock, Action, Classic, Concert,

Drama, Lounge, Gaming, Sports

Video Playback

•Compression formats: DivX 3.11, DivX 4.x, DivX

5.x, DivX 6.0, DivX Ultra, MPEG1, MPEG2, WMV

•Playback Media: DVD-Video, CD-R/CD-RW,

DVD+R/+RW, DVD-R/-RW, Video CD/SVCD

•Video disc playback system: NTSC, PAL

Audio Playback

•Compression format: MP3, WMA

•Playback Media: DVD+R/+RW, Audio CD, CD-R/

RW, DVD-R/-RW, USB flash drive

•MP3 bit rates: 32-256 kbps and VBR

Still Picture Playback

•Picture compression format: JPEG

•Playback Media: DVD+R/+RW, CD-R/RW, DVD-

R/-RW, USB flash drive

•Picture enhancement: Rotate, Zoom, Slideshow

with music playback

Tuner/Reception/Transmission

•No. of preset Audio Channels: 40

•Tuner Bands: FM

Connectivity

•Front / Side connections: Microphone input

3.5mm jack, Hi-Speed USB, MP3 Line-in

•Rear Connections: HDMI output, Component

Video output, S-Video out, Composite video

(CVBS) output, Digital coaxial in, AUX in, FM

Antenna, Easy-Fit speaker connectors

Power

•Power supply: 120/230VAC, 50/60Hz

•Standby power consumption: < 1 W

•Power consumption: 180 W

Loudspeakers

•Satellite Speaker: 4 Floor standing pillars, Wireless

rear speakers

•Satellite speaker drivers: 3" full range woofer

•Satellite speaker impedance: 6 ohm

•Satellite speaker freq range: 150-20000 Hz

•Center Speaker: Magnetically shielded, 3 way

•Center speaker drivers: 1 x 2" tweeter, 2 x 2.5"

woofers

•Center freq range: 150-20000 Hz

•Center speaker impedance: 3 ohm

•Subwoofer driver: 8" high efficiency woofer

•Subwoofer freq range: 40-150 Hz

•Subwoofer impedance: 8 ohm

•Subwoofer type: Passive

Accessories

•Included Accessories: Remote Control, 2 x AAA

Batteries, CVBS video cable, FM antenna, Power

cord, Quick start guide, User Manual, World

Wide Warranty leaflet

Dimensions

•Set dimensions (W x H x D): 435 x 58 x 360 mm

•Set weight: 4.04 kg

•Surround Speaker dimensions (W x H x D):

262 x 1199 x 264 mm

•Surround speaker Weight: 3.53 kg

•Center speaker dimensions (W x H x D):

440 x 105 x 75 mm

•Center Speaker Weight: 1.39 kg

•Subwoofer dimensions (W x H x D):

163 x 363 x 369 mm

•Subwoofer Weight: 5.08 kg

•Packaging dimensions (W x H x D):

765 x 620 x 410 mm

•Weight incl. Packaging: 26.5 kg

Outer Carton

•EAN: 87 12581 45308 4

•Number of consumer packagings: 1

•Gross weight: 27.8 kg

•Outer carton (L x W x H): 76.5 x 41 x 62 cm

•Nett weight: 24 kg

•Tare weight: 3.8 kg

Packaging dimensions

•EAN: 87 12581 45308 4

•Number of products included: 1

•Packaging type: Carton

•Packaging dimensions (W x H x D):

76.5 x 62 x 41 cm

•Gross weight: 27.8 kg

•Nett weight: 24 kg

•Tare weight: 3.8 kg

Product dimensions

•Cable length: 0 cm

•Product dimensions (W x H x D): 0 x 0 x 0 cm

•Weight: 0 kg

•

Issue date 2008-08-30

Version: 1.0.2

12 NC: 8670 000 47995

EAN: 87 12581 45308 4

© 2008 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Hi-Speed USB 2.0 Link

The Universal Serial Bus or USB is a protocol standard

that is conveniently used to link PCs, peripherals and

consumer electronic equipment. Hi-Speed USB devices

have a data transfer rate of up to 480 Mbps - up from

the 12 Mbps in original USB ones. With Hi-Speed USB

2.0 Link, all you have to do is plug in your USB device,

select the movie, music or photo and play away.

True high-def HDMI 1080p

HDMI 1080p upscaling delivers images that are crystal

clear. Movies in standard definition can now be enjoyed

in true high definition resolution - ensuring more details

and more true-to-life pictures. Progressive Scan

(represented by "p" in "1080p') eliminates the line

structure prevalent on TV screens, again ensuring

relentlessly sharp images. To top it off, HDMI makes a

direct digital connection that can carry uncompressed

digital HD video as well as digital multichannel audio,

without conversions to analog - delivering perfect picture

and sound quality, completely free from noise.

EasyLink

EasyLink lets you control multiple devices with one

remote. It uses HDMI CEC industry-standard protocol to

share functionality between devices through the HDMI

cable. With one touch of a button, you can operate all

your connected HDMI CEC enabled equipment

simultaneously. Functions like standby and play can now

be carried out with absolute ease.

DTS, DolbyDigital, ProLogic ll

A built-in DTS and Dolby Digital decoder eliminates the

need for an external decoder by processing all six

channels of audio information to provide a surround

sound experience and an astoundingly natural sense of

ambience and dynamic realism. Dolby Pro Logic II

provides five channels of surround processing from any

stereo source.

DivX Ultra Certified

DivX Ultra combines DivX playback with great features

like integrated subtitles, multiple audio languages,

multiple tracks and menus into one convenient file

format.

Karaoke Scoring

Karaoke Scoring is an advanced feature that

automatically rates your singing and gives you a

humorous picture that is tied to your scores.

Plays it all

Play virtually any media format you want - whether they

be WMV, DivX, MP3s or JPEGs. Experience the

unbeatable convenience of great playability, and the

luxury of sharing media files on your TV or home theater

system - in the comfort of your living room.

Plays it all

Play virtually any disc you want - whether they be CDs,

(S)VCDs, DVDs, DVD+R, DVD-R, DVD+RW, DVD-RW

or DVD+R DL. Experience unbeatable flexibility and the

convenience of playing all your discs on the one device.

12-bit/108MHz video DAC

12-bit Video DAC is a superior Digital-to-Analogue-

Converter that preserves every detail of the authentic

picture quality. It shows subtle shades and smoother

graduation of colors, resulting in a more vibrant and

natural picture. The limitation of the usual 10bit DAC

become in particular apparent while using large screens

and projectors.

Floor standing speakers
