Philips Heritage Audio
DVD component Hi-Fi
system
Hi-Fi tube
Silk dome tweeter
150W
MCD909
Obsessed with sound
Enjoy warm hi-fi sound
Experience high-fidelity sound with the Philips DVD component hi-fi system with
premium materials. Vacuum valve preamplifiers offer crystal-clear sound. Full High-
Definition Multimedia Interface (HDMI) produces sharper images.
Enrich your movie experience
• Play DVD, DivX®, (S)VCD, MP3-CD, WMA-CD, CD(RW) & Picture CD
• Dolby Digital for ultimate movie experience
• USB Direct for music and photo playback
• HDMI 1080p upscales to high definition for sharper pictures
Audiophile-quality sound experience
• Premium Hi-Fi tubes for perfectly pure and natural sound
• Neodymium Ribbon Tweeter for impressive audio fidelity
• Gold-plated speaker connector for finest signal transmission
• 150W RMS total output power
• Treble and Bass Control for easy high and low tone settings
Premium finishing with noble materials
• Quality aluminum cabinet and real wood speakers
• Leatherback and metal front remote control with flat keys
MCD909/12
Highlights
DVD component Hi-Fi system
Hi-Fi tube Silk dome tweeter, 150W
Premium Hi-Fi tubes
With built-in Hi-Fi Tubes, you can now
experience sound of the highest quality that's
usually only associated with premium
audiophile systems. The analog nature of the
tubes provides a more pleasing sound to our
non-linear hearing system. Sound from a tube
has low distortion and is always preferred for
its clean and detailed, warm and life-like audio
quality.
Neodymium Ribbon Tweeter
The Neodymium Ribbon Tweeter is a
monopole tweeter that produces dynamic and
crisp sound from the front. It is a feature
commonly used in high-end audio systems to
reproduce sound with excellent fidelity.
Conventional cones and dome tweeters are
based on a directional moving coil principle
whereas the monopole Neodymium Ribbon
Tweeter radiates high frequencies in a full 180-
degree radiation pattern. This dramatically
increases the width of the sound spectrum in
the higher tones and expands the sweet spot
zone to deliver wide, crystal-clear, and natural
sound even from compact audio systems.
Gold-plated speaker connector
The Gold-plated speaker connector ensures
better audio signal transmission compared to
traditional click-fit connections. It also
minimizes the electrical signal loss from the
amplifier to the speaker box, resulting in sound
reproduction that's as close to reality as
possible.
150W RMS
This system has 150W RMS total output
power. RMS refers to Root Mean Square
which is a typical measurement of audio
power, or rather, the electrical power
transferred from an audio amplifier to a
loudspeaker, which is measured in watts. The
amount of electrical power delivered to the
loudspeaker and its sensitivity determines the
sound power that is generated. The higher the
wattage, the better the sound power emitted
by the speaker.
Play DVD, DivX & MP3/WMA-CD
The Philips player is compatible with most
DVD and CD discs available in the market.
DVD, DivX®, (S)VCD, MP3/WMA-CD,
CD(RW) and Picture CD - all of them can play
on the player. SVCD stands for "Super
VideoCD". The quality of a SVCD is much
better than a VCD, especially much more
sharpen picture than a VCD because of the
higher resolution. With DivX® support, you
are able to enjoy DivX® encoded videos. The
DivX media format is an MPEG4-based video
compression technology that enables you to
save large files like movies, trailers and music
videos on media like CD-R/RW, and DVD
recordable discs.
Dolby Digital
Because Dolby Digital, the world's leading
digital multi-channel audio standards, make use
of the way the human ear naturally processes
sound, you experience superb quality
surround sound audio with realistic spatial
cues.
Quality cabinet and speaker
Quality aluminum cabinet and real wood
speakers
Leatherback remote control
With a perfect balance of sleek dimensions
with a comfortably light weight, this
ergonomically designed remote control is a joy
to use. Its slick metallic-finished flat key front is
attractively contrasted with a genuine leather
back cover. In addition, the stylish, precision-
cut keypad ensures a qualitative navigation
experience. Feel the splendor of pure design
and control.
HiFiTu b e
MCD909/12
Specifications
DVD component Hi-Fi system
Hi-Fi tube Silk dome tweeter, 150W
Picture/Display
• Picture Enhancement: video upsampling, video
upscaling, high def (720p, 1080i, 1080p)
Sound
• Output power: 2 x 75 W RMS / 2 x 150 W music
power
• Sound enhancement: vacuum tube preamplifier,
class "D" digital amplifier, loudness, treble and bass
control, Dolby Digital
Loudspeakers
• Speaker drivers: 3 way, 5" woofer, dome mid
range, ribbon tweeter
• Loudspeaker enhancement: gold-plate speaker
connectors, speaker grilles detachable
Video Playback
•DVD region code: 2
• Playback media: DivX, DVD-Video, picture CD,
video CD/SVCD, DVD+R/+RW, DVD-R/-RW
• Disc playback modes: A-B Repeat, angle, PBC, slow
motion, Zoom, parental control, disc menu, fast
backward, fast forward, OSD, resume playback
from stop
Audio playback
• Playback media: WMA-CD, MP3-CD, CD, CD-R,
CD-RW, USB flash drive
• Disc playback modes: fast forward/backward, next/
previous track search, repeat/shuffle/program
• USB Direct playback modes: fast backward/fast
forward, play/pause, previous/next, program play,
repeat, shuffle, stop
Tuner/Reception/Transmission
• Tuner bands: FM stereo
• Station presets: 20
• Antenna: FM antenna
• RDS: radio text, RDS clock set, station name,
program type
• Tuner enhancement: auto digital tuning, auto scan
Connectivity
• Audio/Video output: 2xRCA (Audio), component
video out, composite video (CVBS) out, digital
audio coaxial out, digital optical out, HDMI out,
Headphone (6.3mm), SCART out, S-Video out
• Aux in: 2xRCA (Audio)
• USB: USB host
Convenience
• Alarms: CD alarm, radio alarm, USB alarm
• Clock: on main display, sleep timer
• Loader type: motorised, tray
• Display enhancements: DIM mode
• On-Screen display languages: Dutch, English,
French, German, Italian, Portuguese, Spanish,
Swedish, Turkish
• Display type: VFD display
Accessories
• Cables/Connection: composite video cable (Y),
control cable, power cord
• Remote control: 49-key with 2xAAA batteries
• Others: FM antenna, Quick start guide
• User Manual: multi-languages
• Warranty: World Wide Guarantee booklet
Dimensions
• Gross weight: 22.5 kg
• Main speaker dimensions (W x D): 205 x 240 mm
• Main speaker height: 330 mm
• Main unit depth: 280 mm
• Packaging depth: 375 mm
• Main unit height: 180 mm
• Packaging height: 310 mm
• Main unit width: 250 mm
• Packaging width: 740 mm
Power
• Power supply: 50 Hz
• Power supply: 220 - 240 V
Green
• Eco Power standby: 1 W
Digital photo playback
• Playback media: CD-R/RW, DVD+R/+RW, picture
CD
• Picture Compression Format: JPEG
•
Issue date 2016-12-14
Version: 2.0.9
12 NC: 8670 000 48625
EAN: 87 12581 45820 1
© 2016 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
