Philips
Cube micro sound system
MCM103
Obsessed with sound
Relax with great music
Enjoy your favorite CDs and portable music just the way you like it. The Philips cube
micro music system plays CDs and more, it also features USB Direct for portable music
playback. The compact design fits any space, any lifestyle.
Enjoy your favorite music
• Play MP3/WMA-CD, CD and CD-RW
• USB Direct for easy MP3 music playback
• FM digital tuning with presets
Superb sound quality
• Dynamic Bass Boost for deep and dramatic sound
• 10W RMS total output power
Design that blends into your interior
• Compact design fits any space, any lifestyle
Issue date 2014-02-12
Version: 2.0.5
12 NC: 8670 000 56727
EAN: 87 12581 50855 5
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
Specifications
MCM103/98
Cube micro sound system
Highlights
Dynamic Bass Boost
Dynamic Bass Boost maximizes your music
enjoyment by emphasizing the bass content of the
music throughout the range of volume settings -
from low to high – at the touch of a button! Bottom-
end bass frequencies usually get lost when the
volume is set at a low level. To counteract this,
Dynamic Bass Boost can be switched on to boost
bass levels, so you can enjoy consistent sound even
when you turn down the volume.
Play MP3/WMA-CD, CD and CD-RW
Audio compression technology allows large digital
music files to be reduced up to 10 times in size
without radically degrading their audio quality. MP3
or WMA are two of the compression formats that
let you enjoy a world of digital music on your Philips
player. Download MP3 or WMA songs from
authorized music sites on the Internet or create
your own MP3 or WMA music files by ripping your
audio CDs and transferring them onto your player.
USB Direct for easy MP3 music
Thanks to the complete file transferability, you can
easily enjoy the convenience and fun of accessing
more digital music via the built-in USB Direct.
Sound
• Output power: 2 x 5 W RMS / 400 W PMPO
• Sound enhancement: Dynamic Bass Boost, digital
sound control
• Volume control: up/down
Loudspeakers
• Speaker drivers: 3.5" woofer
Audio playback
• Playback media: CD, CD-R, CD-RW, MP3-CD,
WMA-CD
• Disc playback modes: repeat/shuffle/program
• USB Direct playback modes: fast backward/fast
forward, play/pause, previous/next, program play,
repeat, shuffle, stop
Tuner/Reception/Transmission
• Tuner bands: FM stereo
• Station presets: 20
• Antenna: FM fixed pigtail antenna
• Tuner enhancement: auto digital tuning, auto scan
Connectivity
• Audio/Video output: Headphone (3.5mm)
• MP3 Link: 3.5mm stereo line in
Convenience
• Alarms: CD alarm, radio alarm
• Clock: on main display, sleep timer
• Loader type: top
• Display type: LCD display
• Backlight color: white
Accessories
•Remote control
• Others: FM/MW antenna, Quick start guide
• User Manual: English, Traditional Chinese
Dimensions
• Gross weight: 4.58 kg
• Main speaker dimensions (W x D): 150 x 197 mm
• Main speaker height: 152 mm
• Main unit depth: 250 mm
• Packaging depth: 206 mm
• Main unit height: 152 mm
• Packaging height: 310 mm
• Main unit width: 150 mm
• Packaging width: 530 mm
Power
• Power supply: 100 - 240V AC, 50/60Hz
•
