Philips Cineos 42Pf9831D Users Manual 42PF9831D/10 Widescreen Flat TV With Pixel Plus 3 HD And Ambilight Full Surround

: Philips Philips-Cineos-42Pf9831D-Users-Manual-381588 philips-cineos-42pf9831d-users-manual-381588 philips pdf

Open the PDF directly: View PDF .
Page Count: 3

Turn up your viewing experience

with Pixel Plus 3 HD and Ambilight

Enjoy the ultimate viewing experience of this Philips Cineos Flat TV with Pixel Plus 3 HD,

Ambilight Full Surround and Clear LCD technology. The Digital Media Reader with PC

link gives you full access to multimedia content.

Immersive viewing experience

• High-definition LCD WXGA display, 1366 x 768p

• Integrated Digital Tuner for DVB-T reception

• HD ready for the highest quality display of HDTV signals

• Pixel Plus 3 HD for most vivid and sharp HDTV images

• Clear LCD with 3ms response for extreme motion sharpness

• Ambilight Full Surround for immersive viewing experience

Unrivalled audio performance

• Compact lambda/4 subwoofer technology for powerful deep bass

Perfect picture quality from your digital photos

• Access your photos, music and movies via PC-link

• Wireless prepared for connection to your PC

• USB and Memory-Card slot for instantly playing multimedia

For advanced performance

• Dual HDMI input for full digital High Definition connection

Philips Cineos

widescreen flat TV with

Pixel Plus 3 HD and

Ambilight Full Surround

42"

LCD integrated digital

42PF9831D

42PF9831D/10

Widescreen flat TV with Pixel Plus 3 HD and Ambilight Full Surround

42" LCD integrated digital

Specifications

Picture/Display

•Aspect ratio: 16:9

•Brightness: 550 cd/m²

•Dynamic screen contrast: 7000:1

•Response time (typical): (BEW equiv.) 3 ms

•Viewing angle: 176º (H) / 176º (V)

•Diagonal screen size: 42 inch / 107 cm

•Display screen type: LCD WXGA Active Matrix

TFT

•Panel resolution: 1366 x 768p

•Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2

motion pull down, 3D Combfilter, Active Control

+ Light sensor, Clear LCD, Digital Natural

Motion, Dynamic contrast enhancement, Jagged

Line Suppression, Progressive Scan, Pulse Killer

Chip, Widescreen Plus

•Screen enhancement: Anti-Reflection coated

screen

Ambilight

•Ambilight Features: Ambilight Full Surround, Auto

adaptive to video content, Efficient low energy

lamp, Full operation in stand-by

•Colour Settings: Full Multi Colour

•Dimming Function: Manual and via Light Sensor

Supported Display Resolution

Sound

•Output power (RMS): 2x12W + 1x24 W

•Sound Enhancement: Digital Signal Processing,

Dynamic Bass Enhancement, Graphic Equaliser

•Sound System: Virtual Dolby Digital, BBE

Loudspeakers

•Built-in speakers: 5

•Loudspeaker types: Integrated subwoofer, Dome

tweeter

Multimedia Applications

•Digital Content Management: Digital Media

Reader

•Memory Card Types: Compact Flash type I,

Compact Flash type II, Memory Stick, Microdrive,

MultiMedia Card (MMC), Secure Digital Card

(SD), Smart Media Card

•Multimedia connections: Ethernet-UTP5, UPnP,

WiFi (opt. Ethernet-bridge), 7-in-1 Memory Card

Reader, USB (streaming video capable)

•Playback Formats: MP3, Slideshow files (.alb),

JPEG Still pictures, DivX 3.11, DivX 5, MPEG1,

MPEG2, MPEG4, XviD

Tuner/Reception/Transmission

•Aerial Input: 75 ohm coaxial (IEC75)

•TV system: DVB COFDM 2K/8K, PAL, SECAM

•Video Playback: NTSC, SECAM, PAL

•DVB: DVB Terrestrial *

•Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

•Ext 1 Scart: Audio L/R, CVBS in/out, RGB

•Ext 2 Scart: Audio L/R, CVBS in/out, RGB, Y/C

•Ext 3: YPbPr

•Ext 4: HDMI

•Ext 5: HDMI

•Ext 6: VGA PC-in, Audio L/R in

•Front / Side connections: Audio L/R in, CVBS in,

Headphone out, S-video in, 2x USB, Multi-slot

memory card reader

•Other connections: Analogue audio Left/Right

out, Ethernet, PC-in VGA + Audio L/R in, S/PDIF

in (coaxial), S/PDIF out (coaxial), Common

Interface

Convenience

•Child Protection: Child Lock+Parental Control

•Clock: Smart Clock

•Ease of Installation: Auto Program Naming,

Automatic Channel Install(ACI), Automatic

Tuning System (ATS), Autostore, PLL Digital

Tuning, Plug & Play

•Ease of Use: Auto Volume Leveller (AVL), Delta

Volume per preset, Graphical User Interface, On

Screen Display, Program List, Side Control

•Electronic Program Guide: Now + Next EPG

•Picture in Picture: Full dual screen (2 tuners), Text

dual screen

•Remote Control: Amp, DVD, Sat, STB (Set-Top

Box), VCR, Multi-functional

•Remote control type: RC4410

•Screen Format Adjustments: 4:3, 6 Widescreen

Modes, Auto Format, Movie expand 14:9, Movie

expand 16:9, Subtitle and Heading Shift, Super

Zoom, Widescreen

•Teletext: 1200 page Hypertext

•Teletext enhancements: Habit Watch, Program

information Line

•VESA Mount: Vesa compliant

Accessories

•Included Accessories: Table top stand, Wall

mounting bracket, RF antenna cable

•Optional accessories: Floor stand

Dimensions

•Set dimensions (W x H x D):

1279 x 872 x 114 mm

•Set dimensions with stand (H x D): 932 x 290 mm

•Weight incl. Packaging: 62 kg

•Product weight: 38 kg

•Box dimensions (W x H x D):

1354 x 1211 x 339 mm

•Colour cabinet: High Gloss Black & Brilliant Pearl

•VESA wall mount compatible: 800 x 400 mm

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

800 x 600 60Hz

1024 x 768 60Hz

•Video Formats

Resolution Refresh rate

640 x 480i 1Fh

640 x 480p 2Fh

720 x 576i 1Fh

720 x 576p 2Fh

1280 x 720p 3Fh

1920 x 1080i 2Fh

Power

•Ambient temperature: 5 °C to 40 °C

•Mains power: AC 110 - 240 V +/- 10%

•Power consumption: 248 W

•Standby power consumption: 0,8W

•

42PF9831D/10

Widescreen flat TV with Pixel Plus 3 HD and Ambilight Full Surround

42" LCD integrated digital

Product highlights

Issue date 2008-04-07

Version: 8.0.14

12 NC: 8670 000 23308

EAN: 87 10895 92049 0

© 2008 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD screen

technology gives you widescreen HD resolution of 1366

x 768p pixels. It produces brilliant flicker-free progressive

scan pictures with optimum brightness and superb

colours. This vibrant and sharp image will provide you

with an enhanced viewing experience.

Integrated Digital DVB-T tuner

The integrated DVB-T tuner lets you receive Digital

Terrestrial TV to watch or record. This means you do not

need an additional set top box and the additional cables.

HD Ready

Enjoy the exceptional picture quality of a true High

Definition TV signal and be fully prepared for HD sources

like HDTV broadcast, Blu-ray DVD or HDVD. HD ready

is a protected label that offers picture quality beyond that

of progressive scan. It conforms to strict standards laid

out by EICTA to offer a HD screen that displays the

benefits of resolution and picture quality of a High

Definition TV signal. It has a universal connection for both

analogue YPbPr and uncompressed Digital connection of

DVI or HDMI, supporting HDCP. It can display 720p and

1080i signals at 50 and 60Hz.

Pixel Plus 3 HD

Pixel Plus 3 HD offers the unique combination of ultimate

sharpness, natural detail, vivid colours and smooth

natural motion on all qualities of HD, standard TV signals

and multimedia content, for high definition displays. Each

pixel of the incoming picture is enhanced to better match

the surrounding pixels, resulting in a more natural

picture. Artefacts and noise in all sources from

multimedia to standard TV and also in highly compressed

HD are detected and reduced ensuring that the picture

is clean and razor sharp.

Clear LCD with 3 ms response

Clear LCD creates extreme motion sharpness for clear

and vibrant images even with fast on-screen motion. The

high refresh rates of the scanning backlight technology

increases the sharpness of motion reproduction down to

an effective response time of 3 milliseconds (measured in

Perceived Blur-Edge-Width; BEW). On top it creates a

higher dynamic contrast and an increased viewing angle.

The unique Philips technology brings motion sharpness of

LCD displays to an unprecedented level, better than any

other Flat display technology.

Ambilight Full Surround

Ambilight 4 makes an impressive contribution to the

overall viewing experience and the design of the TV. It

produces a fully surrounding glow of light that

complements the colours and light intensity on all 4 sides

of the image and with the unique design creates a

'floating display'. The Ambilight is cast onto a reflective

area that is an integrated part of the TV's unique design

and makes it independent from TV position or mounting.

The surrounding glow creates ambiance, stimulates more

relaxed viewing, improves perceived picture detail,

contrast and colour, and will completely immerse you.

Lambda/4 sound system

You want a deeper sound experience in music and

movies. The integrated subwoofer with lambda/4

technology creates a very deep and powerful bass in a

highly compact enclosure, keeping the TV slim and flat.

The lambda/4 subwoofer unit utilises resonating acoustic

masses in a system of ducts to produce powerful bass

with low distortion. The lambda/4 sound system,

combined with high quality midrange and tweeters also

gives a very spacious stereo image.

* DVB-T, supported in selected countries only
