05_8239 300 34351

DVD VIDEO PLAYER DVP5500S

DVP5505S

User manual

Thank you for choosing Philips.

Need help fast?

Read your User’s Manual first for quick tips that make using

your Philips product more enjoyable.

If you have read your instructions and still need assistance,

you may access our online help at www.philips.com/support

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM1

05_8239 300 34351

Important notes for users in the

U.K.

Mains plug

This apparatus is fitted with an approved 13

Amp plug. To change a fuse in this type of plug

proceed as follows:

1Remove fuse cover and fuse.

2Fix new fuse which should be a BS1362 5 Amp,

A.S.T.A. or BSI approved type.

3Refit the fuse cover.

If the fitted plug is not suitable for your jack

outlets, it should be cut off and an appropriate

plug fitted in its place.

If the mains plug contains a fuse, this should

have a value of 5 Amp. If a plug without a fuse

is used, the fuse at the distribution board

should not be greater than 5 Amp.

Note: The severed plug must be disposed to

avoid a possible shock hazard should it be

inserted into a 13 Amp jack elsewhere.

How to connect a plug

The wires in the mains lead are coloured with

the following code: blue = neutral (N),

brown = live (L).

¶As these colours may not correspond with the

colour markings identifying the terminals in

your plug, proceed as follows:

– Connect the blue wire to the terminal

marked N or coloured black.

– Connect the brown wire to the terminal

marked L or coloured red.

– Do not connect either wire to the earth

terminal in the plug, marked E (or e) or

coloured green (or green and yellow).

Before replacing the plug cover, make certain

that the cord grip is clamped over the sheath

of the lead - not simply over the two wires.

Recording and playback of material may

require consent. See Copyright Act 1956 and

The Performer’s Protection Acts 1958 to 1972.

CAUTION

Use of controls or adjustments or

performance of procedures other

than herein may result in hazardous

radiation exposure or other unsafe

operation.

VAROITUS

Muiden kuin tässä esitettyjen

toimintojen säädön tai asetusten

muutto saattaa altistaa vaaralliselle

säteilylle tai muille vaarallisille

toiminnoille.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM2

05_8239 300 34351

Advarsel: Usynlig laserstråling ved

åbning når sikkerhedsafbrydere er ude

af funktion. Undgå utsættelse for

stråling.

Bemærk: Netafbryderen er sekundært

indkoblet og ofbryder ikke strømmen

fra nettet. Den indbyggede netdel er

derfor tilsluttet til lysnettet så længe

netstikket sidder i stikkontakten.

Klass 1 laseraparat

Varning! Om apparaten används på

annat sätt än i denna bruksanvisning

specificerats, kan användaren utsättas

för osynlig laserstrålning, som

överskrider gränsen för laserklass 1.

Observera! Stömbrytaren är sekundärt

kopplad och bryter inte strömmen från

nätet. Den inbyggda nätdelen är

därför ansluten till elnätet så länge

stickproppen sitter i vägguttaget.

Luokan 1 laserlaite

Varoitus! Laitteen käyttäminen muulla

kuin tässä käyttöohjeessa mainitulla

tavalla saattaa altistaa käyttäjän

turvallisuusluokan 1 ylittävälle

näkymättömälle lasersäteilylle.

Oikeus muutoksiin varataan. Laite ei

saa olla alttiina tippu-ja roiskevedelle.

Huom. Toiminnanvalitsin on kytketty

toisiopuolelle, eikä se kytke laitetta irti

sähköverkosta. Sisäänrakennettu

verkko-osa on kytkettynä

sähköverkkoon aina silloin, kun pistoke

on pistorasiassa.

‘CONSUMERS SHOULD NOTE THAT NOT

ALL HIGH DEFINITION TELEVISION SETS

ARE FULLY COMPATIBLE WITH THIS

PRODUCT AND MAY CAUSE ARTIFACTS

TO BE DISPLAYED IN THE PICTURE. IN

CASE OF 525 OR 625 PROGRESSIVE SCAN

PICTURE PROBLEMS, IT IS RECOMMENDED

THAT THE USER SWITCH THE

CONNECTION TO THE ‘STANDARD

DEFINITION’ OUTPUT. IF THERE ARE

QUESTIONS REGARDING OUR TV SET

COMPATIBILITY WITH THIS MODEL 525p

AND 625p DVD PLAYER, PLEASE CONTACT

OUR CUSTOMER SERVICE CENTER.’

The apparatus shall not be exposed to dripping

or splashing and no objects filled with liquids,

such as vases, shall be placed on apparatus.

Due to the inconsistency of disc formats

provided by various disc manufacturers, your

DVD system may require a playability

enhancement or upgrade. As DVD technology

advances, these enhancements will become

common and will be easy to complete.

Go to www.philips.com/support for

software upgrade.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM3

05_8239 300 34351

General Information

CAUTION

(WARNING LOCATION: ON THE

BACKPLATE OF THE SET)

NEVER MAKE OR CHANGE

CONNECTIONS WITH THE

POWER SWITCHED ON.

This DVD player is in conformity

with the EMC directive and low-

voltage directive.

Manufactured under license from Dolby

Laboratories. “Dolby”, “Pro Logic” and the

double-D symbol are trademarks of Dolby

Laboratories.

Laser safety

This unit employs a laser. Due to possible

eye injury, only a qualified service person

should remove the cover or attempt to

service this device.

NOTE:

PICTURES SHOWN MAYBE

DIFFERENT BETWEEN

COUNTRIES.

LASER

Type Semiconductor laser

GaAlAs

Wave length 650 nm (DVD)

780 nm (VCD/CD)

Output Power 7 mW (DVD)

10 mW (VCD/CD)

Beam divergence 60 degree

For Customer Use:

Read carefully the information located at

the rear of your DVD VIDEO player and

enter below the Serial No. Retain this

information for future reference.

Model No. DVP 5500S / DVP 5505S

Serial No. _______________

Environmental Information

All unnecessary packaging has been

omitted. The packaging has been made

easy to separate into two materials:

cardboard (box, buffer) and polyethylene

(bags, protective foam sheet).

Your DVD player consists of materials

which can be recycled and reused if

disassembled by a specialised company.

Please observe the local regulations

regarding the disposal of packaging

materials, exhausted batteries and old

equipment.

Important Note:

Due to the numerous versions of new

CD-Audio copy protection or

enhanced CD-Audio protection

recently available on certain discs,

Philips is unable to guarantee that

this DVD Player is fully compatible

with such new discs. Should you have

difficulty playing any such CD-Audio

discs, kindly refer them to your CD-

Audio disc retailer.

DivX, DivX Certified, and

associated logos are

trademarks of

DivXNetworks, Inc and

are used under license.

“DTS”, and “DTS Digital Surround” are

registered trademarks of Digital Theater

Systems, Inc.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM4

05_8239 300 34351

CAUTION

VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN.

AVOID EXPOSURE TO BEAM.

ADVARSEL

SYNLIG OG USYNLIG

LASERSTRÅLING VED ÅBNING

UNDGÅ UDSÆTTELSE FOR STRÅLING

VARNING

SYNLIG OCH OSYNLIG

LASERSTRÅLNING NÄR DENNA DEL

ÄR ÖPPNAD BETRAKTA EJ STRÅLEN

VARO!

AVATTAESSA OLET ALTTIINA

NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE

LASER SÄTEILYLLE. ÄLÄ KATSO

SÄTEESEEN

VORSICHT

GEFAHR VON SICHTBARER UND

UNSICHTBARER LASERSTRAHLUNG

BEI GEÖFFNETEM GEHÄUSE.

ATTENTION

RAYONNEMENT LASER VISIBLE ET

INVISIBLE EN CAS D’OUVERTURE

EXPOSITION DANGEREUSE AU

FAISCEAU

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM5

05_8239 300 34351

Introduction

Supplied accessories ....................................... 8

Care and safety information.......................... 8

Connections

Connecting TV ............................................9-10

Using SCART jack........................................... 9

Using Composite Video jacks (CVBS)........ 9

Using Component Video jacks (Pr Pb Y) .10

Using an accessory RF modulator ............10

Connecting the power cord........................11

Optional: Connecting to a Multi-channel

Receiver ...........................................................11

Receiver has a Dolby Digital or DTS

decoder........................................................... 11

Optional : Connecting to an Audio System .

...........................................................................12

Stereo system has Dolby Pro Logic or Right

/ Left Audio In jack ....................................... 12

Optional: Connecting Digital AV Receiver ...

...........................................................................12

Receiver has a PCM, Dolby Digital, or

MPEG2 decoder............................................ 12

Functional Overview

Front and Rear Panels ..................................13

Remote Control ............................................14

Getting Started

Step 1: Inserting batteries into the

Remote Control ............................................15

Using the Remote Control to operate the

Player ...............................................................15

Step 2: Setting up the TV........................15-17

Setting up Progressive Scan feature (for

Progressive Scan TV only)........................... 16

To deactivate Progressive manually ..........17

Selecting the colour system that

corresponds to your TV.............................. 17

Step 3: Setting language preference ...........18

Setting the OSD Language.......................... 18

Setting the Audio, Subtitle and Disc menu

language .......................................................... 18

Disc Operations

Playable Discs .................................................19

Region Codes .................................................19

Playing discs.....................................................19

Basic playback controls.................................20

Selecting various repeat/shuffle functions 20

Repeat play mode .........................................20

Repeating a section within a chapter/track .

......................................................................... 20

Operations for video playback ...................21

Using the Disc Menu....................................21

Zooming in.....................................................21

Resuming playback from the last stopped

point ................................................................ 21

Slow motion...................................................21

Using the OSD menu .................................. 21

Special DVD features....................................22

Playing a Title .................................................22

Camera Angle ................................................ 22

Changing the Audio Language.................... 22

Subtitles ..........................................................22

Special VCD & SVCD Features.............22-23

Playback Control (PBC) .............................. 22

Preview .................................................... 22-23

Playing Super Audio CD (SACD) ...............23

Playing DivX disc ...........................................23

Playing MP3/WMA/MPEG-4/JPEG/Kodak

Picture CD ......................................................24

General Operation....................................... 24

Selecting a folder and track/file .................24

Special picture disc features ........................25

Preview Function ..........................................25

Zoom picture ................................................25

Playback with multi-angles ..........................25

Scan Effect ......................................................25

Playing MP3/WMA music and JPEG picture

simultaneously ...............................................25

Contents

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM6

05_8239 300 34351

DVD Menu Options

General Setup menu ...............................26-27

Locking/Unlocking the disc for viewing... 26

Dimming system’s display screen .............. 26

Programming disc tracks.......................26-27

OSD Language...............................................27

Screen Saver - turning on/off .....................27

Sleep ................................................................ 27

DivX VOD registration code ..................... 27

Audio Setup Menu...................................28-29

Analogue output ...........................................28

Digital Audio Setup....................................... 28

Sound Mode................................................... 29

Speaker setup ................................................ 29

CD Upsampling............................................. 29

Night Mode - turning on/off....................... 29

Video Setup Menu ...................................30-32

TV Type ...........................................................30

Setting the TV Display ................................. 30

Progressive - turning on/off........................31

Picture Setting ........................................ 31-32

Switching the YUV/RGB .............................. 32

Preference Page........................................33-35

Audio, Subtitle, Disc Menu..........................33

Restricting playback by Parental Control.....

.................................................................. 33-34

PBC .................................................................. 34

MP3/JPEG Menu - turning on/off............... 34

Changing the Password ...............................35

Setting the DivX Subtitle font ................... 35

Restoring to original settings.....................35

Sound and Volume Controls

Setting the speakers’ channels....................36

Selecting surround sound ............................37

Selecting digital sound effects .....................37

Volume control ..............................................37

Troubleshooting ......................... 38–39

Specifications ......................................40

Glossary......................................................................41

Language Code................................................42

Contents

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM7

05_8239 300 34351

Supplied accessories

Remote Control

and

two AA batteries

Introduction

Care and safety information

●Power consumption

– When the system is switched to

Standby mode, it is still consuming power.

To disconnect the system from the power

supply completely, remove the AC power

plug from the wall jack.

●Avoid high temperatures, moisture,

water and dust

– Do not expose the player, batteries or

discs to humidity, rain, sand or excessive

heat (caused by heating equipment or

direct sunlight.)

●Avoid condensation problem

– The lens may cloud over when the

player is suddenly moved from cold to

warm surroundings, making it impossible

to play a disc. Leave the player in the

warm environment until the moisture

evaporates.

PREVIEW

MUTE

SOUND

SURROUND

SLEEP

DIM

●Do not block the vents

– Do not operate the DVD Player in an

enclosed cabinet, allow about 10 cm (4

inch) of free space all around the player

for adequate ventilation.

10 cm

(4 inches)

10 cm

(4 inches) 10 cm

(4 inches)

PHILIPS

●Care of the cabinet

– Use a soft cloth slightly moistened with

a mild detergent solution. Do not use a

solution containing alcohol, spirits,

ammonia or abrasives.

●Finding a suitable location

– Place the player on a flat, hard, and

stable surface.

●Disc handling

– To clean a CD, wipe it in a

straight line from the center

towards the edge using a soft,

lint-free cloth. A cleaning

agent may damage the disc!

– Write only on the printed

side of a CDR(W) and only with a soft felt-

tipped pen.

– Handle the disc by its edge, do not

touch the surface.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM8

05_8239 300 34351

Connections

Connecting TV

AUDIO

S-VIDEO

VIDEO IN

TV IN

AUDIO

S-VIDEO

VIDEO IN

TV IN

IMPORTANT!

– You only need to make one video

connection from the following

options, depending on the

capabilities of your TV system.

– Connect the DVD system directly

to the TV.

– A SCART connection will let you

use features both Audio and Video

on the DVD Player.

Using SCART jack

●Use the SCART cable (black) to connect

the DVD Player’s SCART jack (TV OUT)

to the corresponding Scart input jacks on

the TV (cable not supplied).

Helpful Hint:

– Ensure that the “TV” indication on

SCART cable is connected to the TV

set and “DVD” indication on SCART

cable is connected to the DVD Player.

AUDIO

S-VIDEO

VIDEO IN

TV IN

AUDIO

S-VIDEO

VIDEO IN

TV IN

Using Composite Video jacks

(CVBS)

1Use the composite video cable (yellow) to

connect the DVD Player’s CVBS (VIDEO)

jack to the video input jack (or labeled as

A/V In, Video In, Composite or Baseband)

on the TV (cable not supplied).

2To hear the sound of this DVD Player

through your TV, use the audio cables

(white/red) to connect AUDIO OUT

[FRONT (L/R)] jacks of the DVD Player

to the corresponding AUDIO IN jacks on

the TV (cable not supplied).

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM9

05_8239 300 34351

Connections

AUDIO

V (Pr/Cr)

U (Pb/Cb)

S-VIDEO

VIDEO IN

COMPONENT

VIDEO IN

AUDIO

V (Pr/Cr)

U (Pb/Cb)

S-VIDEO

VIDEO IN

COMPONENT

VIDEO IN

IMPORTANT!

– The progressive scan video

quality is only possible when using Y

Pb Pr and a progressive scan TV is

required.

Using Component Video jacks

(Y Pb Pr)

1Use the component video cables (red/

blue/green) to connect the DVD system’s

Y Pb Pr jacks to the corresponding

Component video input jacks (or labeled

as Y Pb Pr) on the TV (cable not supplied).

2To hear the sound of this DVD Player

through your TV, use the audio cables

(white/red) to connect AUDIO OUT

[FRONT (L/R)] jacks of the DVD Player

to the corresponding AUDIO IN jacks on

the TV (cable not supplied).

3Proceed to page 16 for detailed

Progressive Scan set up.

IMPORTANT!

– If your TV only has a single

Antenna In jack (or labeled as 75

ohm or RF In,) you will need an RF

modulator in order to view the DVD

playback on the TV. See your

electronics retailer or contact

Philips for details on RF modulator

availability and operations.

Using an accessory RF modulator

1Use the composite video cable (yellow) to

connect the DVD Player’s VIDEO OUT

jack to the video input jack on the RF

modulator.

2Use the RF coaxial cable (not supplied) to

connect the RF modulator to your TV’s

RF jack.

AUDIO IN

R L

VIDEO

TO TVINT IN

CH3 CH4

RF coaxial cable to TV

Back of RF Modulator

(example only)

Antenna or

Cable TV signal

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM10

05_8239 300 34351

Connections

~ AC MAINS

AUDIO

OUT V (Pr/Cr)

U (Pb/Cb)

S-VIDEO

VIDEO IN

COMPONENT

VIDEO IN

After everything is connected

properly, plug in the AC power cord

to the power outlet.

Never make or change any connections

with the power switched on.

When no disc is loaded, press

STANDBY ON on the DVD Player

front panel,

“NO DISC” may appear on the

display panel.

Connecting the power cord

NO DISC

Optional: Connecting to a Multi-

channel Receiver

MULTICHANNEL AUDIO IN

SUBW.

AV Receiver

REARFRONT

CENTERREARFRONT

Receiver has a Dolby Digital or DTS

decoder

1Select one of the video connections

(CVBS VIDEO IN, S-VIDEO IN, SCART or

COMPONENT VIDEO IN) depending on

the options available on your TV.

2Connect the Audio Out Left and Right

jack for Front and Rear speakers to the

corresponding input sockets on your

Receiver (cable not supplied).

3Connect the Audio Out for Center

speaker and Subwoofer to the

corresponding inputs on your Receiver

(cable not supplied).

4Set the DVD Player’s Analog Output to

‘Multichannel’ to enable playback of DVDs

recorded in Multi-channel. (see page 28

“Analogue output”).

Helpful Hint:

– If the subwoofer is equipped with its own

amplifier, the Subwoofer connection should

be connected directly to the subwoofer.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM11

05_8239 300 34351

Connections

Stereo system has Dolby Pro Logic

or Right / Left Audio In jack

1Select one of the video connections

(CVBS VIDEO IN, SCART or

COMPONENT VIDEO IN) depending on

the options available on your TV.

2Use the audio cables (white/red) to

connect AUDIO OUT [FRONT (L/R)]

jacks of the DVD Player to the

corresponding AUDIO IN jacks on the

stereo system (cable not supplied).

AUDIO

STEREO

DIGITAL

Optional: Connecting to an

Audio System Optional: Connecting Digital AV

Receiver

Receiver has a PCM, Dolby Digital,

or MPEG2 decoder

1Select one of the video connections

(CVBS VIDEO IN, SCART or

COMPONENT VIDEO IN) depending on

the options available on your TV.

2Connect the COAXIAL jack of the DVD

Player to the corresponding Digital Audio

In jack on your Receiver (cable not

supplied).

3Set the DVD Player’s Digital Output to

PCM-ONLY or ALL depending on the

capabilities of your Receiver (see page 28

“Digital Output”).

Helpful Hint:

– If the audio format of the Digital Output

does not match the capabilities of your

receiver, the receiver will produce a strong,

distorted sound or no sound at all.

AUDIO

DIGITAL

AV Receiver

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM12

05_8239 300 34351

Functional Overview

Front and Rear Panels

TV OUT

– Connect to Scart input of a TV

Multichannel Audio Out

– Center speaker, subwoofer, front

and rear speakers multichannel

connection

COAXIAL (Digital audio out)

– Connect to coaxial AUDIO input of a

digital audio equipment

Mains (AC Power Cord)

– Connect to a standard AC outlet

VIDEO OUT (CVBS)

– Connect to CVBS Video input of a TV

YPbPr (Component Video Out)

– Connect to YPbPr input of a TV

T NEXT

– To search or select next chapter or track

– To search or select previous chapter or

track

9 STOP

– To stop playback

2; PLAY

– To start or interrupt playback

IR Sensor

– Point the remote control towards this

sensor

STANDBY-ON B

– To switch the DVD Player to Standby

mode or ON

Disc tray

OPEN/CLOSE /

– Open/Close the disc tray

Display

– Shows the current status of the DVD

Player

Caution: Do not touch the inner pins of the jacks on the rear panel.

Electrostatic discharge may cause permanent damage to the unit.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM13

05_8239 300 34351

Functional Overview

Remote Control

PREVIEW

MUTE

SOUND

SURROUND

SLEEP

DIM

RETURN/TITLE

– To go back to previous menu/ show

title menu

DISC MENU

– Enters or exits the disc contents

– Switches on or off the playback

control mode (for VCD version

2.0 only)

1 2 3 4

– Selects an item in the menu/

fast forward/backward, slow forward/

backward

– Acknowledge menu selection

– To search or select previous

chapter or track

STOP ( 9 )

– To stop playback

PLAY ( B )

– To start playback

PAUSE ( ; )

– To pause playback temporarily /

frame-by-frame playback

REPEAT

– Selects various repeat modes

REPEAT (A-B)

– Repeats playback a specific section

on a disc

PREVIEW

– To preview the content of a track

or whole disc

MUTE

– Disables or enables sound output

POWER B

– To switch the DVD player to

standby mode or ON

0-9 numerical key pad

– Selects numbered items in a

DISPLAY

– Displays information on TV

screen during playback

SYSTEM MENU

– Access or exit DVD Player’s

system menu

– To search or select next chapter

or track

SUBTITLE

– To access subtitle language

system menu

ANGLE

– Selects a DVD camera angle

ZOOM

– Enlarge a picture on the TV

screen

AUDIO

– To access audio language system

DIM

– Selects different levels of

brightness for display panel

SLEEP

– Sets the sleep timer function.

SOUND

– Selects a sound effect.

SURROUND

– Selects multichannel surround or

stereo mode.

Helpful Hint:

Press “STOP” for about 2 seconds to

OPEN or CLOSE disc tray.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM14

05_8239 300 34351

PREVIEWPREVIEW MUTEMUTE

SOUND SURROUNDSLEEPDIM

Getting Started

Step 1: Inserting batteries into

the Remote Control

1Open the battery compartment.

2Insert two batteries type R06 or AA,

following the indications (+-) inside

the compartment.

3Close the cover.

Using the Remote Control to

operate the Player

1Aim the Remote Control

directly at the remote

sensor (IR) on the front

panel.

2Do not put any objects

between the Remote

Control and the DVD

Player while operating

the DVD Player.

CAUTION!

–Remove batteries if they are

exhausted or if the Remote Control

is not being used for a long time.

–Do not use old and new or

different types of batteries in

combination.

–Batteries contain chemical

substances, so they should be

disposed properly.

Step 2: Setting up the TV

IMPORTANT!

Make sure you have completed all

the necessary connections. (See

pages 9-10 “Connecting TV”).

1Turn on the TV and set to the correct

video-in channel. You should see the

Philips DVD background screen on the

TV.

2Usually these channels are between the

lowest and highest channels and may be

called FRONT, A/V IN, or VIDEO. See your

TV manual for more details.

➜Or, you may go to channel 1 on your

TV, then press the Channel down button

repeatedly until you see the Video In

channel.

➜Or, the TV Remote Control may have a

button or switch that chooses different

video modes.

➜Or, set the TV to channel 3 or 4 if you

are using an RF modulator.

3If you are using external equipment, (eg.

audio system or receiver), turn it on and

select the appropriate input source for

the DVD Player output. Refer to the

equipment owner’s manual for detail.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM15

05_8239 300 34351

Setting up Progressive Scan feature

(for Progressive Scan TV only)

The progressive scan display twice the

number of frames per seconds than

interlaced scanning (ordinary normal TV

system). With nearly double the number

of lines, progressive scan offers higher

picture resolution and quality.

IMPORTANT!

Before enabling the progressive scan

feature, you must ensure:

1) Your TV can accept progressive signals,

a progressive scan TV is required.

2) You have connected the DVD player to

your TV using Y Pb Pr (see page 10.)

1Turn on your TV.

2Turn off your TV progressive scan mode

or turn on interlaced mode (refer to your

TV user manual.)

3Press POWER on the remote control to

turn on the DVD player.

4Select the correct Video Input channel.

(See page 15).

➜The DVD background screen appears

on the TV.

5Press SYSTEM MENU.

6Press 2 repeatedly to select {VIDEO

SETUP PAGE}.

Set P-SCAN On/Off

- - Video Setup Page - -

TV Type

TV Display

Progressive On

Picture Setting Off

Component

7Select {PROGRESSIVE} to {ON}, then OK

to confirm.

➜The instruction menu appears on the

TV.

1) ENSURE YOUR TV HAS PROGRESSIVE SCAN.

2) CONNECT WITH YPBPR (GBR) VIDEO CABLE.

3) IF THERE IS A DISTORTED PICTURE, WAIT

Cancel

ACTIVATING PROGRESSIVE:

15 SECONDS FOR AUTO RECOVERY.

8Press 1 to highlight

in the menu

and press OK to confirm.

There will be a distorted picture on

your TV at this state until you turn

on the progressive scan mode on

your TV.

9Turn on your TV progressive scan mode

(refer to your TV user manual.)

➜The below menu appears on the TV.

CONFIRM AGAIN TO USE PROGRESSIVE

SCAN. IF THE PICTURE IS GOOD,

PRESS OK BUTTON ON REMOTE

Cancel

0Press 1 to highlight

in the menu

and press OK to confirm.

➜The set up is complete now and you

can start enjoy the high quality picture.

Getting Started

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM16

05_8239 300 34351

Selecting the colour system that

corresponds to your TV

This DVD Player is compatible with both

NTSC and PAL. In order for a DVD disc

to play on this Player, the colour system of

the Disc, the TV and the DVD Player

should match.

NTSC TV

- - Video Setup Page - -

TV Type PAL

TV Display Multi

Progressive NTSC

Picture Setting

Component

1Press SYSTEM MENU.

2Press 2 repeatedly to select {VIDEO

SETUP PAGE}.

3Press 3 4 to highlight {TV TYPE}, then

press 2.

Getting Started

4Press 3 4 to highlight one of the options

below:

PAL – Select this if the connected TV is

PAL system. It will change the video signal

of a NTSC disc and output in PAL format.

NTSC – Select this if the connected TV

is NTSC system. It will change the video

signal of a PAL disc (VCD only) and

output in NTSC format.

Multi – Select this if the connected TV is

compatible with both NTSC and PAL

(multi-system). The output format will be

in accordance with the video signal of the

disc.

5Select an item and press OK.

Helpful Hints:

– Before changing the current TV

Standard setting, ensure that your TV

supports the ‘selected TV Type’ system.

– If there is no proper picture on

your TV, wait for 15 seconds for auto

recovery.

CHANGING PAL TO NTSC:

1. ENSURE THAT YOUR TV SUPPORTS

NTSC STANDARD.

2. IF THERE IS A DISTORTED PICTURE

DISPLAYED ON THE TV, WAIT 15

SECONDS FOR AUTO RECOVER.

CANCELOK

CONFIRM AGAIN TO USE NEW TV

TYPE SETTING.

CANCELOK

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

To deactivate Progressive manually

●When the distorted picture still

appears on the TV, it may be due to

the connected TV does not accept

progressive signals, and progressive is set

by mistake. You must reset the unit to

interlace format.

1Turn off your TV progressive scan mode

or turn on to interlaced mode (refer to

your TV user manual.)

2Press OPEN/CLOSE on the DVD player

to open the disc tray.

3Press numeric keypad ‘1’ on the

remote control for few seconds.

➜The DVD blue background screen

will appear on the TV.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM17

05_8239 300 34351

Step 3: Setting language

preference

You can select your preferred language

settings. This DVD Player will

automatically switch to the language for

you whenever you load a disc.

Setting the OSD Language

The On-screen language for the system

menu will remain as you set it, regardless

of various disc languages.

Set OSD Language English(UK)

- - General Setup Page - -

Disc Lock

Display Dim

Program

OSD Language ENGLISH(UK)

Screen Saver FRANÇAIS

Sleep DEUTSCH

DIVX(R) Vod Code NEDERLANDS

1Press SYSTEM MENU.

2Press 2 to select {GENERAL SETUP

PAGE}.

3Press 3 4 to highlight {OSD

LANGUAGE}, then press 2.

4Press 3 4 to select a language and press

OK.

Getting Started

Setting the Audio, Subtitle and Disc

menu language

You can choose your own preferred

language or soundtrack from audio,

subtitles and disc menu languages. If the

language selected is not available on the

disc, the disc’s default language will be

used instead.

Set Preference To English

Audio English

Subtitle French

Disc Menu Spanish

Parental Chinese

PBC Japanese

Mp3 / Jpeg Nav Korean

Password Setup Russian

- - Preference Page - -

1Press STOP twice then, press SYSTEM

MENU.

2Press 2 repeatedly to select

{PREFERENCE PAGE}.

3Press 3 4 to highlight one of the options

below at a time, then press 2.

– ‘Audio’ (disc’s soundtrack)

– ‘Subtitle’ (disc’s subtitles)

– ‘Disc Menu’ (disc’s menu)

4Press 3 4 to select a language and press

OK.

If the language you want is not in the

list, then select {OTHERS},

then use the numeric keypad (0-9) on

the remote to enter the 4-digit language

code ‘XXXX’ (see page 42 “Language

Code”) and press OK.

5Repeat steps 3~4 for other language

settings.

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM18

05_8239 300 34351

Disc Operations

IMPORTANT!

–If the inhibit icon (ø) appears on

the TV screen when a button is

pressed, it means the function is not

available on the current disc or at

the current time.

–Depending on the DVD or VIDEO

CD, some operations may be

different or restricted.

–Do not push on the disc tray or

put any objects other than disc on

the disc tray. Doing so may cause

the disc player malfunction.

Playable Discs

Your DVD Player will play:

– Digital Video Discs (DVDs)

– Video CDs (VCDs)

– Super Video CDs (SVCDs)

– Super Audio CDs (SACDs)

– Digital Video Discs +

Recordable[Rewritable] (DVD+R[W])

– Compact Discs (CDs)

– MP3/WMA discs, picture (Kodak, JPEG)

files on CD-R(W).

– JPEG/ISO 9660 format

– Maximum 30 characters display.

– Supported sampling frequencies :

32 kHz, 44.1 kHz, 48 kHz (MPEG-1)

16 kHz, 22.05 kHz, 24 kHz (MPEG-2)

– Supported Bit-rates : 32~256 kbps

(MPEG-1), 8~160 kbps (MPEG-2)

variable bitrates

– MPEG-4 disc on CD-R(W):

– Simple profile

– Advanced simple profile (640-480)

– DivX disc on CD-R[W]/DVD+R[W]:

– DivX 3.11, 4.x and 5.x

– Q-pel accurate motion compensation

– Global Motion Compensation (GMC) playback

SUPER VIDEO

Region Codes

DVD discs must be labeled for ALL

regions or Region 2 in order to

play on this Player. You cannot play

Discs that are labeled for other

regions.

Helpful Hints:

– It may not be possible to play CD-R/RW

or DVD-R/RW in all cases due to the type of

disc or condition of the recording.

– If you are having trouble playing a

certain disc, remove the disc and try a

different one. Improper formatted disc will

not play on this DVD Player.

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Playing discs

1Connect the power cords of the DVD

Player and TV (and any optional stereo or

AV receiver) to a power outlet.

2Turn on the TV power and set to the

correct Video In channel. (See page 15

“Setting up the TV”).

3Press STANDBY-ON on the DVD Player

front panel.

➜You should see the Philips DVD

background screen on the TV.

4Press OPEN/CLOSE 0 button to open

the disc tray and load in a disc, then press

the same button again to close the disc

tray.

➜Make sure the label side is facing up.

For double-sided discs, load the side you

want to play facing up.

5Playback will start automatically. If not

press PLAY B.

➜If a disc menu appears on the TV, see

page 21 “Using the Disc Menu”.

➜If the disc is locked by parental control,

you must enter your six-digit password.

(See page 35).

ALL

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM19

05_8239 300 34351

Disc Operations

Basic playback controls

Unless otherwise stated, all operations

described are based on Remote Control

use.

Pausing playback

1During playback, press PAUSEÅ.

➜Playback will pause and sound will be

muted.

2To resume normal playback, press

PLAY B.

Selecting track/chapter

●Press S / T or use the numeric

keypad (0-9) to key in a track/chapter

number.

➜If repeat mode is active, pressing S /

Twill replay the same track/chapter.

Searching backward/forward

●Press and hold 1 / 2, then press PLAY

B to resume normal playback.

➜While searching, pressing 1 / 2

repeatedly again will decrease/increase

the search speed.

Stopping playback

●Press Ç.

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Selecting various repeat/shuffle

functions

Repeat play mode

●While playing a disc, press REPEAT

continuously to choose a ‘Play Mode’.

CHAPTER (DVD)

– to repeat playback of the current

chapter.

TRACK/TITLE (CD/SVCD/VCD/DVD)

– to repeat playback of the current

track (CD/SVCD/VCD)/title (DVD).

ALL

– to repeat playback of all the disc and

all the programmed tracks.

Helpful Hint:

– For VCD, repeat playback is not possible

if the PBC mode is switched on.

Repeating a section within a

chapter/track

1While playing a disc, press REPEAT A-B

at your chosen starting point.

2Press REPEAT A-B again at your chosen

end point.

➜The section A and B can be set only

within the same chapter/track.

➜The section will now repeat

continuously.

3To exit the sequence, press REPEAT

A-B.

01-44 DVP5505S_EU_05 25/01/2005, 1:59 PM20

05_8239 300 34351

Operations for video playback

(DVD/VCD/SVCD)

Using the Disc Menu

Depending on the disc, a menu may

appear on the TV screen once you load in

the disc.

To select a playback feature or item

●Use 1 2 3 4 keys or numeric keypad

(0-9) on the remote, then press OK to

start playback.

To access or remove the menu

●Press DISC MENU on the remote.

Zooming in

This function allows you to enlarge the

picture on the TV screen and to pan

through the enlarged picture.

1During playback, press ZOOM

repeatedly to display the picture with

different scales.

➜Use 1 2 3 4 keys to pan through the

enlarged picture.

➜Playback will continue.

2Press ZOOM repeatedly to return to

the original size.

Using the OSD menu

OSD menu shows the disc playback

information (for example, title or chapter

number, elapsed playing time, audio/

subtitle language), a number of operations

can be done without interrupting disc

playback.

1During playback, press DISPLAY.

➜A list of available disc information

appears on the TV screen.

Bitrate 61 Title Remain 0:48:59

Title 01/01

Chapter 09/12

Audio 2CH CHI

Subtitle Off

Bitrate 71 Total Elapsed 0:01:32

Track 01/01

Disc Time 0:48:53

Track Time 0:48:53

Repeat Off

2Press 3 4 to view the information and

press OK to access.

3Press 2 or OK to select an option.

4Use the numeric keypad (0-9) to input

the number/time or press 3 4 to make

the selection, then press OK to confirm.

➜Playback will change to the chosen

time or to the selected title/chapter/

track.

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Disc Operations

Resuming playback from the last

stopped point

Resume playback of the last 5 discs is

possible, even if the disc was ejected or

the power switched off.

●Load one of the last 5 discs.

➜ “LOAD” appears.

●Press PLAY B and the disc will be played

back from the last point.

To cancel resume mode

●In stop mode, press STOP 9 again.

Slow Motion

1Press 3 4 during playback to select the

required speed: 1/2, 1/4, 1/8 or 1/16

(backward or forward).

➜Sound will be muted.

2To return to normal speed, press PLAY B.

Helpful Hint:

– Slow backward is not possible on VCDs.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM21

05_8239 300 34351

Disc Operations

Special DVD Features

Playing a Title

1Press DISC MENU.

➜The disc title menu appears on the TV

screen.

2Use 3 4 1 2 keys or numeric keypad

(0-9) to select a play option.

3Press OK key to confirm.

Camera Angle

●Press ANGLE repeatedly to select

different desired angle.

Changing the Audio Language

For DVD

●Press AUDIO repeatedly to select

different audio languages.

Changing the Audio Channel

For VCD

●Press AUDIO to select the available

audio channels provided by the disc (LEFT

MONO, RIGHT MONO, MIX-MONO,

STEREO).

Subtitles

●Press SUBTITLE repeatedly to select

different subtitle languages.

Special VCD & SVCD Features

Playback Control (PBC)

For VCD with Playback Control (PBC)

feature (version 2.0 only)

●Press DISC MENU to toggle between

‘PBC ON’ and ‘PBC OFF’.

➜If you select ‘PBC ON’, the disc menu

(if available) will appear on the TV.

➜Use the S / T or the numeric

keypad (0-9) to select a play option.

●During playback, pressing RETURN/

TITLE will return to the menu screen (if

PBC is on).

If you want to skip the index menu

and playback directly from the

beginning,

●Press DISC MENU key on the remote

control to switch to PBC off.

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Preview Function (DVD/VCD)

The preview function allows you to

reduce the picture of 6 tracks enough to

display in a full screen.

1Press PREVIEW.

➜The preview menu appears on the TV

screen.

Select Digest Type:

Track Di

Disc Interval

Track Interval

Select Digest Type:

Title Di

Chapter Digest

Title Interval

Chapter Interval

(DVD example) (Video CD example)

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM22

05_8239 300 34351

Disc Operations

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Playing a DivX disc

This DVD player supports the DivX

movie playback that you download from

your computer onto a CD-R/RW (see

page 27 for more information).

1Load a DivX disc.

➜Playback will start automatically. If not

press PLAY B.

2If the DivX movie contains external

subtitles, the subtitle menu will appear on

the TV screen for your selection.

●In this case, pressing SUBTITLE on the

remote control will turn on or off the

subtitle.

●If multilingual subtitles are embedded on

the DivX disc, pressing SUBTITLE will

change the subtitle language during

playback.

Helpful Hints:

– Subtitle files with the following filename

extensions (.srt, .smi, .sub, .ssa, .ass) are

supported but do not appear on the file

navigation menu.

– The subtitle filename have to be the

same as the filename of the movie.

Playing Super Audio CD (SACD)

There are three types of SACD discs:

single layer, double layer or hybrid disc.

The hybrid disc contains both Super

Audio CD and standard audio CD layers,

only the SACD layer is possible to

playback on this DVD player.

1Load a SACD.

➜The disc menu appears on the TV

screen.

2Playback will start automatically.

➜If the SACD consists of multi-channel

and stereo tracks, multi-channel tracks

will have the priority for playback.

➜To playback stereo tracks, use 3 4 keys

to make your selection from the disc

menu, then press PLAY B.

Helpful Hints:

–SURROUND button is not functional

for SACD playback. You have to access to the

disc menu in order to select between multi-

channel and stereo tracks.

– Programme SACD tracks is not possible.

2Press 3 4 to select the PREVIEW type,

then press OK.

➜The picture of each segment will

appear on the screen.

ABC

DEF

(example for 6 thumbnail pictures display)

3Press 3 4 1 2 to select a track and input

your selected track number using the

numeric keypad (0-9), then press OK.

➜ Playback will start automatically on the

selected track.

●For CDDA (Musical CD)

➜ Press PREVIEW to listen to the first

10 seconds of each sound track in the

disc.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM23

05_8239 300 34351

Disc Operations

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Selecting a folder and track/file

1Press 3 4 to select the folder and press

OK to open the folder.

2Press 3 4 to select a track/file.

3Press S / T to go to previous/next

page.

4Press OK to confirm.

➜Playback will start from the selected

file to the end of the folder.

●To select another folder from the current

disc, press 1 to return to the root menu,

then press 3 4 to make your selection

and press OK to confirm.

During playback, you can;

●Press S / T to select another track/

file in the current folder.

●Press REPEAT continuously to access

different ‘Play Mode’.

➜FOLDER: files will be played back once.

➜REPEAT ONE: one file being played

repeatedly.

➜REPEAT FOLDER: all files in one folder

being played repeatedly.

➜SHUFFLE: all files in the current folder

being played at random order.

●Press Å to pause playback.

Helpful Hints:

– It may not be possible to play certain

MP3/WMA/JPEG/DivX/MPEG-4 disc due to

the configuration and characteristics of the

disc or condition of the recording.

– It is normal to experience an occasional

“skip” while listening to your MP3/WMA

disc.

– It is normal to experience an occasional

pixelation during MPEG-4/DivX playback

due to poor clarity of digital contents during

internet downloading.

– For multi-session discs with different

formats, only the first session will be available.

Playing MP3/WMA/MPEG-4/

JPEG/Kodak Picture CD

IMPORTANT!

You have to turn on your TV and set to

the correct Video In channel. (See page

15 “Setting up the TV”).

General Operation

1Load a disc.

➜The disc reading time may exceed 30

seconds due to the complexity of the

directory/file configuration.

➜The data disc menu appears on the TV

screen.

2Playback will start automatically. If not

press PLAY B.

01:42 04:40

001/020

Coco - Before

Coco - I love

Coco - Jazz

Before

- - - - - -

ALBUM - - - - - -

2002

Coco Lee

MP3

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM24

05_8239 300 34351

Playing MP3/WMA music and JPEG

picture simultaneously

1Load a disc that contains music and

picture.

➜The disc menu appears on the TV

screen.

2Select an MP3/WMA track.

3During MP3/WMA music playback, select

a picture from the TV screen and press

PLAY B.

➜The picture files will be played back

one after another until end of the folder.

4To quit simultaneous playback, press

Çfollowed by DISC MENU.

Helpful Hint:

– Some files on Kodak or JPEG disc may

be distorted during playback due to the

configuration and characteristics of the disc.

Disc Operations

TIPS: The operating features described here might not be possible for certain discs. Always refer

to the instructions supplied with the discs.

Zoom picture

1During playback, press ZOOM repeatedly

to display the picture with different scales.

2Use 1 2 3 4 keys to view the zoomed

picture.

Playback with multi-angles

●During playback, press 3 4 1 2 to rotate

the picture on the TV screen.

3: flip the picture vertically

4: flip the picture horizontally

1: rotate the picture anti-clockwise

2: rotate the picture clockwise

Scan Effect

●Press ANGLE repeatedly to choose

different scan effect.

➜Various scan effect appears on the top

left hand corner on the TV screen.

Special picture disc features

IMPORTANT!

You have to turn on your TV and set to

the correct Video In channel. (See page

15 “Setting the TV”).

●Load a Picture disc (Kodak Picture CD,

JPEG).

➜For Kodak disc, the slide show will

begin.

➜For JPEG disc, the picture menu

appears on the TV screen. Press PLAY B

to start the slide-show playback.

Preview Function (JPEG)

This function shows the content of the

current folder or the whole disc.

1Press STOP during playback.

➜12 thumbnail pictures will appear on

the TV screen.

2Press S / T to display the other

pictures on the previous/next page.

3Use 1 2 3 4 to highlight one of the

picture and press OK to start playback.

4Press DISC MENU to return to Picture

CD menu.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM25

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

This DVD Player setup is carried out via

the TV, enabling you to customise the

DVD Player to suit your particular

requirements.

General Setup menu

1In disc mode, press SYSTEM MENU.

2Press 1 2 to select ‘General Setup’ icon.

3Press OK to confirm.

Go to General Setup Page

Disc Lock

Display Dim

Program

OSD Language

Screen Saver

Sleep

DIVX(R) Vod Code

- - General Setup Page - -

Locking/Unlocking the disc for

viewing

Not all discs are rated or coded by the

disc maker. You can prevent a specific disc

from playing by locking the disc. Up to 40

discs can be locked.

1In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DISC LOCK}, then press 2.

LOCK

Select this to block the playback of the

current disc. Subsequent access to a

locked disc requires six-digit password.

The default password is ‘136 900’ (see

page 35 “Changing the password”).

UNLOCK

Select this to unlock the disc and allow

future playback.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Dimming player’s display panel

You can select different levels of

brightness for the display screen.

1In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DISPLAY DIM}, then press 2.

100% – Select this for full brightness.

70% – Select this for medium brightness.

40% – Select this for dimming the display.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Programming disc tracks (not for

Picture CD/MP3/WMA/SACD)

You can play the contents of the disc in

the order you want by programming the

tracks to be played. Up to 20 tracks can

be stored.

1In ‘GENERAL SETUP PAGE’, press 3 4

to highlight {PROGRAM}, then press 2

to select {INPUT MENU}.

2Press OK to confirm.

1 04

2 10

4 __ 9 __

8 __

7 __

6 __

5 __ 10 __

3 11

Exit START NEXT

Programme : Track (01 - 17)

To input your favourite tracks/chapter

3Use the numeric keypad (0-9) to enter

a valid track/chapter number.

4Use 1 2 3 4 keys to move the cursor to

the next position.

➜If the track number is more than ten,

press T to open the next page and

proceed with programming or,

➜Use 1 2 3 4 keys to highlight {NEXT}

on the programme menu, then press OK.

5Repeat steps 3~4 to input another

track/chapter number.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM26

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

If you want to remove a track

6Use 1 2 3 4 keys to move the cursor to

the track you want to remove.

7Press OK to remove this track from the

programme menu.

To start programme playback

8Use 1 2 3 4 keys to highlight {START}

on the programme menu, then press OK.

➜Playback will start with the selected

tracks under the programmed sequence.

To exit programme playback

9Use 1 2 3 4 keys to highlight {EXIT} on

the programme menu, then press OK.

OSD Language

This menu contains various language

options for display language on the screen.

For details, see page 18.

Screen Saver - turning on/off

The screen saver will help to prevent your

TV display device from becoming

damaged.

1In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {SCREEN SAVER}, then press 2.

Select this if you wish to turn off the TV

screen when disc playback is stopped or

paused for more than 15 minutes.

OFF

Select this to disable the screen saver

function.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Sleep

Sleep function allows you to turn off the

DVD Player automatically after a preset

time.

1In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {SLEEP}, then press 2.

15 Mins

Turn off the DVD Player after 15 minutes.

30 Mins

Turn off the DVD Player after 30 minutes.

45 Mins

Turn off the DVD Player after 45 minutes.

60 Mins

Turn off the DVD Player after 60 minutes.

OFF

Turn off the sleep function.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

DivX(R) VOD registration code

Philips provide you the DivX® VOD

(Video On Demand) registration code

that allows you to rent and purchase

videos using the DivX® VOD service.

For more information, visit us at

www.divx.com/vod.

1In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DIVX(R) VOD CODE}, then

press 2.

➜The registration code will appear.

2Press OK to exit.

3Use the registration code to purchase or

rent the videos from DivX® VOD service

at www.divx.com/vod. Follow the

instructions and download the video onto

a CD-R for playback on this DVD player.

Helpful Hints:

– All the downloaded videos from DivX®

VOD can only be played back on this DVD

player.

– Time search feature is not available

during DivX movie playback.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM27

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

Audio Setup Menu

1In disc mode, press SYSTEM MENU.

2Press 1 2 to select ‘Audio Setup’ icon.

3Press OK to confirm.

Go to Audio Setup Page

Analog Output

Digital Audio Setup

Sound Mode

Speaker Setup

CD Upsampling

Night Mode

- - Audio Setup Page - -

Analog Output

Set Analogue Output to match your DVD

Player’s playback capability. This function

can also be accessed via the

SURROUND button on the remote.

1In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {ANALOG OUTPUT}, then

press 2.

Stereo

Select this option when output delivers

sound from only the two front speakers.

LT/RT

Select this option if your DVD Player is

connected to a Dolby Pro Logic decoder.

V SURR

Allows the DVD player to use virtual

surround sound effects.

Multi Channel

Select this to enable Multi-channel output.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Digital Audio Setup

The options included in Digital Audio

Setup are: ‘Digital Output’ and ‘LPCM

Output’.

1In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {DIGITAL AUDIO SETUP}, then

press 2.

2Press the 3 4 keys to highlight an option.

3Enter its submenu by pressing 2.

4Press 3 4 to select a setting, then press

OK to confirm your selection.

Digital Output

Set the Digital output according to your

optional audio equipment connection.

➜Off: Turn off the digital output.

➜All: If you have connected your

DIGITAL AUDIO OUT to a multi-channel

decoder/receiver.

➜PCM Only: Only if your receiver is

not capable of decoding multi-channel

audio.

Helpful Hints:

– If DIGITAL OUTPUT is set to ‘All’, all

audio settings except MUTE are invalid.

LPCM Output

If you connect the DVD Player to a PCM

compatible receiver via the digital

terminals, such as coaxial or optical etc,

you may need to adjust ‘LPCM Output’.

Discs are recorded at a certain sampling

rate. The higher the sampling rate, the

better the sound quality.

➜48kHz: Playback a disc recorded at the

sampling rate of 48kHz.

➜96kHz: Playback a disc recorded at the

sampling rate of 96kHz that can only be

achieved in Stereo-Classic (Flat) mode.

Helpful Hint:

– LPCM Output can be selected only when

PCM Only is activated.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM28

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

Sound Mode

The options included in Sound Mode

Setup are: ‘3D’, ‘Movie Mode’ and ‘Music

Mode’.

1In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {SOUND MODE}, then press 2.

2Press the 3 4 keys to highlight an option.

3Enter its submenu by pressing 2.

4Press 3 4 to select a setting, then press

OK to confirm your selection.

This function provides a virtual surround

sound experience using just two speakers.

➜Off, Living Room, Hall, Arena and

Church

Movie Mode

Select a Sound Mode that matches the

type of music you are playing. These

preset Sound Modes adjust the frequency

bands of the video to enhance your

favourite movie sound track.

➜ Off, Sci-Fic, Action, Drama and

Concert

Music Mode

Select a Sound Mode that matches the

type of music you are playing. These

preset Sound Modes adjust the frequency

bands of the audio to enhance your

favourite music.

➜ Off, Digital, Rock, Classic and Jazz

CD Upsampling

This feature allows you to convert your

music CD to a higher sampling rate using

sophisticated digital signal processing for

better sound quality. If you have activated

the upsampling, the player will

automatically switch to stereo mode.

1In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {CD UPSAMPLING}, then press 2.

OFF

Select this to disable CD-upsampling.

88.2 kHz (X2)

Select this to convert the sampling rate of

the CDs twice higher than the original.

176.4 kHz (X4)

Select this to convert the sampling rate of

the CDs four times higher than the

original.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Helpful Hint:

– CD upsampling feature is only applicable

to stereo output setting.

Night Mode - turning on/off

In this mode, the high volume outputs are

softened and low volume outputs are

brought upward to an audible level. It is

useful for watching your favourite action

movie without disturbing others at night.

1In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {NIGHT MODE}, then press 2.

Select this to level out the volume. This

feature is only available for movies with

Dolby Digital mode.

OFF

Select this when you want to enjoy the

surround sound with its full dynamic

range.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Speaker Setup

This menu contains setup options for

your audio output which makes the

speaker setup system reproduce high

quality surround sound. For details, see

page 36-37.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM29

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

Video Setup Menu

1In disc mode, press SYSTEM MENU.

2Press 1 2 to select ‘Video Setup’ icon.

3Press OK to confirm.

Go To Video Setup Page

TV Type

TV Display

Progressive

Picture Setting

Component

- - Video Setup Page - -

TV Type

This menu contains the options for

selecting the colour system that matches

the connected TV. For details, see page

17.

Setting the TV Display

Set the aspect ratio of the DVD Player

according to the TV you have connected.

The format you select must be available

on the disc. If it is not, the setting for TV

display will not affect the picture during

playback.

1In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {TV DISPLAY}, then press 2.

2Press 3 4 to highlight one of the options

below:

4:3 PAN SCAN –

Select this if you have

a normal TV and want

both sides of the

picture to be trimmed or formatted to fit

your TV screen.

4:3 LETTER BOX –

Select this if you have a

normal TV. In this case, a

wide picture with black

bands on the upper and lower portions of

the TV screen will

be displayed.

16:9 – Select this if

you have a wide-

screen TV.

3Select an item and press OK.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM30

05_8239 300 34351

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

DVD Setup Menu Options

Progressive - turning on/off

In the progressive scan mode, you can

enjoy the high quality picture with less

flickers. It only works when you have

connected the DVD player’s Y Pb Pr jacks

to your TV that supports the progressive

video input. Otherwise, the a distorted

picture will appear on the TV. For proper

progressive scan set up, see page 16.

1In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {PROGRESSIVE}, then press 2.

OFF

To disable Progressive Scan function.

To enable Progressive Scan function.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

➜Follow the instructions shown on the

TV to confirm the selection (if any).

➜If a distorted picture appears on the TV

screen, wait for 15 seconds for auto

recovery.

Picture Setting

This DVD Player provides three

predefined sets of picture colour settings

and one personal setting which you can

define yourself.

1In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {PICTURE SETTING}, then press

STANDARD

Select this for standard picture setting.

BRIGHT

Select this will make the TV picture

brighter.

SOFT

Select this will make the TV picture softer.

PERSONAL

Select this to personalise your picture

colour by adjusting the brightness,

contrast, tint and colour (saturation).

2Press 3 4 to select a setting, then press

OK to confirm your selection.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM31

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

3If you select {PERSONAL}, then proceed

to steps 4~7.

➜The ‘PERSONAL PICTURE SETUP’

menu appears.

Brightness

Contrast

TINT

COLOR

Personal Picture Setup

4Press 3 4 to highlight one of the

following options.

BRIGHTNESS

Increase the value will brighten the

picture or vice versa. Choose zero (0) for

average setting.

CONTRAST

Increase the value will sharpen the picture

or vice versa. Choose zero (0) to balance

the contrast.

TINT

Increase the value will darken the picture

or vice versa. Choose zero (0) for

average setting.

COLOUR

Increase the value will enhance the colour

in your picture or vice versa. Choose zero

(0) to balance the colour.

5Press 1 2 to adjust the setting that best

suit your personal preference.

6Repeat steps 4~5 for adjusting other

colour features.

7Press OK to confirm.

Switching the YUV/RGB

This setting allows you to toggle the

output of the video signal between RGB

(on scart) and Y Pb Pr (YUV).

1In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {COMPONENT}, then press 2.

YUV

Select this for Y Pb Pr connection.

RGB

Select this for Scart connection.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Warning:

When the player is set to Y Pb Pr

(YUV), some TV may not properly

synchronise with player on the

SCART connector.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM32

05_8239 300 34351

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

DVD Setup Menu Options

Preference Page

1Press Ç twice to stop playback (if any),

then press SYSTEM MENU.

2Press 1 2 to select the ‘Preference Setup’

icon.

3Press OK to confirm.

Go To Preference Page

Audio

Subtitle

Disc Menu

Parental

PBC

Mp3 / Jpeg Nav

Password Setup

- - Preference Page - -

Audio, Subtitle, Disc Menu

These menus contain various language

options for audio, subtitle and disc menu

which may be recorded on the DVD. For

details, see page 18.

Restricting playback by Parental

Control

Some DVDs may have a parental level

assigned to the complete disc or to

certain scenes on the disc. This feature

lets you set a playback limitation level.

The rating levels are from 1 to 8 and are

country dependent. You can prohibit the

playing of certain discs that are not

suitable for your children or have certain

discs played with alternative scenes.

1In ‘PREFERENCE PAGE’, press 3 4 to

highlight {PARENTAL}, then press 2.

Set KID SAFE

Audio 1 KID SAFE

Subtitle 2 G

Disc Menu 3 PG

Parental 4 PG 13

PBC 5 PGR

Mp3 / Jpeg Nav 6 R

Password Setup 7 NC17

- - Preference Page - -

2Press 3 4 to highlight a rating level for

the disc inserted and press OK.

➜To disable Parental controls and have

all Discs play, select {8 ADULT}.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM33

05_8239 300 34351

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

PBC

You can set the PBC to ON or OFF. This

feature is available only on Video CD 2.0

with playback control (PBC) feature. For

details, see page 22.

MP3/JPEG Menu - turning on/off

MP3/JPEG Navigator can be set only if the

disc is recorded with menu. It allows you

to select different display menus for easy

navigation.

1In ‘PREFERENCE PAGE’, press 3 4 to

highlight {MP3/JPEG NAV}, then press 2.

WITHOUT MENU

Select this to display all the files contained

in the MP3/Picture CD.

WITH MENU

Select this to display only the folder menu

of the MP3/Picture CD.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

Changing the Password - cont’d

3Use the numeric keypad (0-9) to enter

the six-digit password (see page 35

“Changing the password”).

➜DVDs that are rated above the level

you selected will not play unless you enter

your six-digit password.

Helpful Hints:

– VCD, SVCD, CD have no level indication,

so parental control function has no effect on

these type of discs. This applies to most illegal

DVD discs.

– Some DVDs are not encoded with a

rating though the movie rating may be

printed on the Disc cover. The rating level

feature does not work for such Discs.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM34

05_8239 300 34351

Setting the DivX Subtitle font

You can set the font type that supports

the recorded DivX subtitle.

1In ‘PREFERENCE PAGE’, press 3 4 to

highlight {DivX SUBTITLE}, then press 2.

STANDARD

A standard list of English subtitle fonts

provided by this DVD Player.

CYRILLIC

Select this to display a cyrillic subtitle fonts.

2Press 3 4 to select a setting, then press

OK to confirm your selection.

DVD Setup Menu Options

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

Restoring to original settings

Setting the DEFAULT function will reset

all options and your personal settings to

the factory defaults, except your

password for Parental Control and Disc

Lock.

1In ‘PREFERENCE PAGE’, press 34 to

highlight {DEFAULT}, then press 2 to

select {RESET}.

2Press OK to confirm.

➜All settings will now reset to factory

defaults.

Changing the Password

The same password is used for both

Parental Control and Disc Lock. Enter

your six-digit password when prompted

on the screen. The default password is

136 900.

1In ‘PREFERENCE PAGE’, press 3 4 to

highlight {PASSWORD}, then press 2 to

select {CHANGE}.

Change Password

Password Change

- - Password Setup Page - -

2Press OK to enter the ‘Password Change

Page’.

Old Password

New Password

Confirm PWD

3Use the numeric keypad (0-9) to enter

your old six-digit password.

➜When doing this for the first time, key

in ‘136 900’.

➜If you forget your old six-digit

password, key in ‘136 900’.

4Enter the new six-digit password.

5Enter the new six-digit password a second

time to confirm.

➜The new six-digit password will now

take effect.

6Press OK to confirm.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM35

05_8239 300 34351

Sound and Volume Controls

Setting the speakers’ channels

You can adjust the delay times (centre

and surround only) and volume level for

individual speakers. These adjustments let

you optimise the sound according to your

surroundings and setup.

IMPORTANT!

The speaker settings only available on

Multi-channel audio outputs. You can

also press SURROUND button on the

remote to select Multi-channel.

1Press STOP then, press SYSTEM

MENU.

2Press 2 repeatedly to select {AUDIO

SETUP PAGE}.

3Press 34 to highlight {SPEAKER SETUP},

then press 2.

Analog Output

Digital Audio Setup

Sound Mode

Speaker Setup

CD Upsampling

Night Mode

- - Audio Setup Page - -

Front Speakers Large

Center Speaker Small

Rear Speakers

Subwoofer

Speakers Volume

Speakers Delay

- - Speaker Setup Page - -

4Enter its submenu by pressing 2.

5Press 34 to highlight one of the options

below at a time, then press 2.

{FRONT SPEAKERS, CENTER SPEAKER,

REAR SPEAKERS}

OFF – when no speaker is connected.

LARGE – when connected speakers can

produce low frequency signals below

120Hz.

SMALL – when connected speakers

cannot produce low frequency signals

below 120Hz.

{SUBWOOFER}

ON – when a subwoofer is connected.

OFF – when no subwoofer is connected.

{SPEAKER VOLUME} – Volume level

setting for individual speakers (-6dB ~

+6dB).

Front Left

Front Right

Center

Subwoofer

Rear Right

Rear Left

0dB0

- - Speakers Volume Setup - -

{SPEAKER DELAY} – Delay times setting

in relation to the listening position/

distance for centre and surround

speakers (1m ~ 10m).

Center

Subwoofer

Rear Right

Rear Left

1.0M

- - Speakers Distance Setup - -

6Press 1 2 to adjust the setting that best

suit your surround sound needs.

7Press OK to confirm.

Helpful Hints:

– Use the longer delay time settings when

the rear speakers are closer to the listener

than the front speakers.

– The test tone will be automatically

generated to help you judge the sound level

of each speaker.

TIPS: To return to the previous menu, press 1.

To remove the menu, press SYSTEM MENU.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM36

05_8239 300 34351

Sound and Volume Controls

Selecting surround sound

●Press SURROUND on the remote to

select : MULTI-CHANNEL or STEREO.

➜The availability of the various surround

sound modes depends on the number of

speakers used and the sound available on

the disc.

➜The centre and rear speakers operate

only in Multi-channel surround mode.

➜The available output modes for Multi-

channel include: Dolby Digital, DTS

(Digital Theater Systems) Surround and

Dolby Pro Logic II.

➜Stereo broadcasts or recordings will

produce some surround channel effects

when played in a surround mode.

However, mono (single channel sound)

sources will not produce any sound from

the rear speakers.

Helpful Hints:

– The SURROUND button is not

functional for SACD playback. You have to

access the disc menu in order to select

between multi-channel and stereo tracks, see

page 29.

– You are not able to select the surround

sound mode if the system setup menu is

turned on

Selecting digital sound effects

Select a preset digital sound effects that

matches your disc’s content or that

optimises the sound of the musical style

you are playing.

●Press SOUND to select the available

sound effect.

When playing movie discs, you can select :

CONCERT, DRAMA, ACTION or SCI-FI.

When playing music discs, you can select :

ROCK, DIGITAL, CLASSIC or JAZZ.

Helpful Hint:

– For flat sound output, select CONCERT

or CLASSIC.

Volume control

To turn off the volume temporarily

●Press MUTE on the remote.

➜Playback will continue without sound

and "MUTE" appears.

➜To restore the volume, press MUTE

again, or increase the volume level.

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM37

05_8239 300 34351

WARNING

Under no circumstances should you try to repair the system yourself, as this will

invalidate the warranty. Do not open the system as there is a risk of electric shock.

If a fault occurs, first check the points listed below before taking the system for repair. If

you are unable to remedy a problem by following these hints, consult your dealer or

Philips for help.

Problem Solution

No power – Check if the AC power cord is properly connected.

– Press the STANDBY ON on the front of the DVD

system to turn on the power.

No picture – Refer to your TV’s manual for correct Video In

channel selection. Change the TV channel until you

see the DVD screen.

– Check if the TV is switched on.

– If the progressive scan feature is activated but the

connected TV does not support progressive signals

or the cables are not connected accordingly, see

page 16 for proper progressive scan set up or

deactivate the progressive scan feature as below:

1) Turn off your TV progressive scan mode or turn on

to interlaced mode.

2) Press OPEN/CLOSE to open the disc tray.

3) Press numeric keypad ‘1’ on the remote control for

few seconds.

Distorted picture – Sometimes a small amount of picture distortion may

appear depending on the disc being played back. This

is not a malfunction.

Completely distorted picture or – Connect DVD Player directly to the TV.

black/white picture with DVD – Make sure the disc is compatible with the DVD/

Player.

– Ensure that the DVD Player’s TV Type is set to match

that of the Disc and your TV.

No sound or distorted sound – Adjust the volume.

– Check that the speakers are connected correctly.

No audio at digital output – Check the digital connections.

– Check if your receiver can decode MPEG-2 or DTS

and if not, please make sure the digital output is set

to PCM.

– Check if the audio format of the selected audio

language matches your receiver capabilities.

No sound and picture – Check that the RGB/SCART cable is connected to

the correct device (See Connecting TV).

Troubleshooting

Visit us at www.philips.com/support for service support

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM38

05_8239 300 34351

Disc can’t be played – The DVD+R/CD-R must be finalised.

– Ensure the disc label is facing up.

– Check if the disc is defective by trying another disc.

– If you have recorded a Picture CD or MP3/WMA

CD yourself, ensure that your disc contains at least

10 pictures or 5 MP3/WMA tracks.

– Region code incorrect.

Picture freezes momentarily – Check the disc for fingerprints/scratches and

during playback clean with a soft cloth wiping from centre to edge.

No return to start-up screen when – Reset the unit by switching the player off, then on

disc is removed again.

The player does not respond to – Aim the Remote Control directly at the sensor

the Remote Control on the front of the player.

– Reduce the distance to the player.

– Replace the batteries in the Remote Control.

– Re-insert the batteries with their polarities (+/–

signs) as indicated.

Buttons do not work – To completely reset the player, unplug the AC

cord from the AC outlet for 5-10 seconds.

Player does not respond to some – Operations may not be permitted by the disc.

operating commands during playback. Refer to the instructions of the disc jacket.

DVD Player cannot read – Use a commonly available cleaning CD/DVD to

CDs/DVDs clean the lens before sending the DVD Player for

repair.

Menu items cannot be selected – Press STOP twice before selecting System Menu.

– Depending on the disc availability, some menu items

cannot be selected.

Unable to play DivX movies – Check that the DivX file is encoded in ‘Home

Theater’ mode with DivX 5.x encoder.

Unable to select Progressive Scan on/off – Check that the output of the video signal is switch to

‘YUV’.

No sound during DivX movies playback – The audio codec may not be supported by the DVD

player.

An MPEG-4 or DivX movies does – Check that file size of the movies does not exceed

not repeat the file size of the CD disc during burning.

Troubleshooting

Problem Solution

Visit us at www.philips.com/support for service support

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM39

05_8239 300 34351

TV STANDARD (PAL/50Hz) (NTSC/60Hz)

Number of lines 625 525

Playback Multistandard (PAL/NTSC)

VIDEO PERFORMANCE

Video DAC 12 bit, 108mHz

YPbPr 0.7 Vpp — 75 ohm

Video Output 1Vpp — 75 ohm

RGB (SCART) 0.7 Vpp — 75 ohm

VIDEO FORMAT

Digital Compression MPEG 2 for DVD,SVCD

MPEG 1 for VCD

MPEG-4

DivX

DVD 50Hz 60Hz

Horiz. resolution 720 pixels 720 pixels

Vertical resolution 576 lines 480 lines

VCD 50Hz 60Hz

Horiz. resolution 352 pixels 352 pixels

Vertical resolution 288 lines 240 lines

AUDIO FORMAT

Digital MPEG/ AC-3/ compressed Digital

PCM 16, 20, 24 bits

fs, 44.1, 48, 96 kHz

MP3(ISO 9660) 96, 112, 128, 256

kbps & variable

bit rate fs, 32, 44.1,

48 kHz

Analog Sound Stereo

Dolby Surround compatible downmix from Dolby Digital

multi-channel sound

Dolby Pro Logic II

3D sound for virtual 5.1 channel sound on 2 speakers

Specifications

AUDIO PERFORMANCE

DA Converter 24 bit, 192 kHz

DVD fs 96 kHz 4Hz- 44kHz

fs 48 kHz 4Hz- 22kHz

SVCD fs 48 kHz 4Hz- 22kHz

fs 44.1kHz 4Hz- 20kHz

CD/VCD fs 44.1kHz 4Hz- 20kHz

Signal-Noise (1kHz) > 100 dB

Dynamic range(1kHz) > 90 dB

Crosstalk (1kHz) > 100 dB

Distortion/noise (1kHz) > 85 dB

MPEG MP3 MPEG Audio L3

CONNECTIONS

Scart Output Euroconnector

YPbPr Output Cinch 3x

Video Output Cinch (yellow)

Audio Output(L+R) Cinch (white/red)

Digital Output 1 coaxial

IEC60958 for CDDA / LPCM

IEC61937 for MPEG 1/2,

Dolby Digital

6 channel analogue output

Audio Front L/R Cinch (white/red)

Audio Rear L/R Cinch (white/red)

Audio Centre Cinch (blue)

Audio Subwoofer Cinch (black)

CABINET

Dimensions (w x h x d) 435 x 37 x 265 mm

Weight Approximately 2.0 kg

POWER CONSUMPTION

Power Supply Rating 240V; 50Hz

Power consumption < 10 W

Power consumption in Standby mode < 0.8 W

Specifications subject to change without prior notice

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM40

05_8239 300 34351

Analog: Sound that has not been turned into

numbers. Analog sound varies, while digital sound has

specific numerical values. These jacks send audio

through two channels, the left and right.

Aspect ratio: The ratio of vertical and horizontal

sizes of a displayed image. The horizontal vs. vertical

ratio of conventional TVs. is 4:3, and that of wide-

screens is 16:9.

AUDIO OUT Jacks: Jacks on the back of the DVD

System that send audio to another system (TV, Stereo,

etc.).

Bit Rate: The amount of data used to hold a given

length of music; measured in kilobits per seconds, or

kbps. Or, the speed at which you record. Generally,

the higher the bit rate, or the higher the recording

speed, the better the sound quality. However, higher

bit rates use more space on a Disc.

Chapter: Sections of a picture or a music piece on a

DVD that are smaller than titles. A title is composed

of several chapters. Each chapter is assigned a chapter

number enabling you to locate the chapter you want.

Component Video Out Jacks: Jacks on the back of

the DVD System that send high-quality video to a TV

that has Component Video In jacks (R/G/B, Y/Pb/Pr,

etc.).

Disc menu: A screen display prepared for allowing

selection of images, sounds, subtitles, multi-angles, etc

recorded on a DVD.

Digital: Sound that has been converted into

numerical values. Digital sound is available when you

use the DIGITAL AUDIO OUT COAXIAL or

OPTICAL jacks. These jacks send audio through

multiple channels, instead of just two channels as

analog does.

DivX 3.11/4.x/5.x: The DivX codec is a patent-

pending, MPEG-4 based video compression

technology, developed by DivXNetworks, Inc., that can

shrink digital video to sizes small enough to be

transported over the internet, while maintaining high

visual quality.

Dolby Digital: A surround sound system developed

by Dolby Laboratories containing up to six channels

of digital audio (front left and right, surround left and

right, center and subwoofer).

DTS: Digital Theatre Systems. This is a surround

sound system, but it is different from Dolby Digital.

The formats were developed by different companies.

JPEG: A very common digital still picture format. A

still-picture data compression system proposed by the

Joint Photographic Expert Group, which features small

decrease in image quality in spite of its high

compression ratio.

MP3: A file format with a sound data compression

system. “MP3” is the abbreviation of Motion Picture

Experts Group 1 (or MPEG-1) Audio Layer 3. By using

MP3 format. one CD-R or CD-RW can contain about

10 times as much data volume as a regular CD can.

Multichannel: DVD is specified to have each sound

track constitute one sound field. Multichannel refers

to a structure of sound tracks having three or more

channels.

Parental Control: A function of the DVD to limit

playback of the disc by the age of the users according

to the limitation level in each country. The limitation

varies from disc to disc; when it is activated, playback

will be prohibited if the software’s level is higher than

the user-set level.

PCM (Pulse Code Modulation): A system for

converting analog sound signal to digital signal for

later processing, with no data compression used in

conversion.

Playback control (PBC): Refers to the signal

recorded on video CDs or SVCDs for controlling

reproduction. By using menu screens recorded on a

Video CD or SVCD that supports PBC, you can enjoy

interactive-type software as well as software having a

search function.

Progressive Scan: It displays all the horizontal lines

of a picture at one time, as a signal frame. This system

can convert the interlaced video from DVD into

progressive format for connection to a progressive

display. It dramatically increases the vertical

resolution.

Region code: A system for allowing discs to be

played back only in the region designated beforehand.

This unit will only play discs that have compatible

region codes. You can find the region code of your

unit by looking on the product label. Some discs are

compatible with more than one region (or ALL

regions).

Surround: A system for creating realistic three-

dimensional sound fields full of realism by arranging

multiple speakers around the listener.

Title: The longest section of a picture or music

feature on DVD, music, etc., in video software, or the

entire album in audio software. Each title is assigned a

title number enabling you to locate the title you want.

VIDEO OUT jack: Jack on the back of the DVD

System that sends video to a TV.

Glossary

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM41

05_8239 300 34351

Abkhazian 6566

Afar 6565

Afrikaans 6570

Amharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Avestan 6569

Aymara 6589

Azerhaijani 6590

Bahasa Melayu 7783

Bashkir 6665

Belarusian 6669

Bengali 6678

Bihari 6672

Bislama 6673

Bokmål, Norwegian 7866

Bosanski 6683

Brezhoneg 6682

Bulgarian 6671

Burmese 7789

Castellano, Español 6983

Catalán 6765

Chamorro 6772

Chechen 6769

Chewa; Chichewa; Nyanja 7889

9072

Chuang; Zhuang 9065

Church Slavic; Slavonic 6785

Chuvash 6786

Corsican 6779

Česky 6783

Dansk 6865

Deutsch 6869

Dzongkha 6890

English 6978

Esperanto 6979

Estonian 6984

Euskara 6985

 6976

Faroese 7079

Français 7082

Frysk 7089

Fijian 7074

Gaelic; Scottish Gaelic 7168

Gallegan 7176

Georgian 7565

Gikuyu; Kikuyu 7573

Guarani 7178

Gujarati 7185

Hausa 7265

Herero 7290

Hindi 7273

Hiri Motu 7279

Hrwatski 6779

Ido 7379

Interlingua (International)7365

Interlingue 7365

Inuktitut 7385

Inupiaq 7375

Irish 7165

Íslenska 7383

Italiano 7384

Ivrit 7269

Japanese 7465

Javanese 7486

Kalaallisut 7576

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kernewek 7587

Khmer 7577

Kinyarwanda 8287

Kirghiz 7589

Komi 7586

Korean 7579

Kuanyama; Kwanyama 7574

Kurdish 7585

Lao 7679

Latina 7665

Latvian 7686

Letzeburgesch; 7666

Limburgan; Limburger 7673

Lingala 7678

Lithuanian 7684

Luxembourgish; 7666

Macedonian 7775

Malagasy 7771

Magyar 7285

Malayalam 7776

Maltese 7784

Manx 7186

Maori 7773

Marathi 7782

Marshallese 7772

Moldavian 7779

Mongolian 7778

Nauru 7865

Navaho; Navajo 7886

Ndebele, North 7868

Ndebele, South 7882

Ndonga 7871

Nederlands 7876

Nepali 7869

Norsk 7879

Northern Sami 8369

North Ndebele 7868

Norwegian Nynorsk; 7878

Occitan; Provencal 7967

Old Bulgarian; Old Slavonic 6785

Oriya 7982

Oromo 7977

Ossetian; Ossetic 7983

Pali 8073

Panjabi 8065

Persian 7065

Polski 8076

Português 8084

Pushto 8083

Russian 8285

Quechua 8185

Raeto-Romance 8277

Romanian 8279

Rundi 8278

Samoan 8377

Sango 8371

Sanskrit 8365

Sardinian 8367

Serbian 8382

Shona 8378

Shqip 8381

Sindhi 8368

Sinhalese 8373

Slovensky 8373

Slovenian 8376

Somali 8379

Sotho; Southern 8384

South Ndebele 7882

Sundanese 8385

Suomi 7073

Swahili 8387

Swati 8383

Svenska 8386

Tagalog 8476

Tahitian 8489

Tajik 8471

Tamil 8465

Tatar 8484

Telugu 8469

Thai 8472

Tibetan 6679

Tigrinya 8473

Tonga (Tonga Islands) 8479

Tsonga 8483

Tswana 8478

Türkçe 8482

Turkmen 8475

Twi 8487

Uighur 8571

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapuk 8679

Walloon 8765

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 8973

Yoruba 8979

Zulu 9085

Language Code

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM42

05_8239 300 34351

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM43

05_8239 300 34351

CLASS 1

LASER PRODUCT

DVP 5505S

DVP 5500S

8239 300 34351

Sgp-SL-0449/05-1

Meet Philips at the Internet

http://www.philips.com

01-44 DVP5505S_EU_05 25/01/2005, 2:00 PM44

Philips User Manual Dvp5505s 05 Dfu Eng

Navigation menu

Versions of this User Manual:

Views

Navigation
