FTR9965
FTR9965
Flat Television | Matchline Series
Flat TV receiver /US
• Pixel Plus™
• Digital Natural Motion™
• Digital CrystalClear™
• Progressive Scan
• 3D Comb filter
• HD component input
• AutoScreen™Fit
• Full Active Control™
• Dynamic graphical user interface
• Closed Captioning
• VGA input
• 2 Tuner PIP RC4305
Flat Television | Matchline Series
Technical specifications
Picture processing
• Pixel Plus™
• Digital Natural Motion™
• Digital CrystalClear™
• Active Control™
– Auto Sharpness Control - 7 steps
– Auto Dynamic Contrast / Histogram
– Auto Digital Noise Reduction
– Ambient Light Sensor prepared
– Auto Format / Auto Screen Fit™
– Demo menu
• Auto Picture™ (5 modes)
– soft,natural,rich,personal,multimedia
• Tint Control (3 modes)
• WideScreen plus
Sound
• Sound system :BTSC (incl.DBX) / SAP Stereo
• Auto Sound™ (5 modes)
– movie, speech, music, personal, multimedia
• Output :2x15W RMS (@10%THD)
• Digital Signal Processing
• Spatial-Pseudo Stereo
• Bass / Treble control
• Separate Headphone volume
• Language I-II selection (SAP)
• ‘Monitor is Center’ setup (with ext.HiFi system)
Ease of Use
• Dynamic graphical user interface. Easy and
intuitive operation through feedforward and
backtracking display.
• Full menu control of all functions through
layered menus.
• Onscreen status display for channels and
functions (OSD)
• AutoLock™ to protect young kids from
objectionable programming with V-chip technology
• Favourite channel selection and Surf™ loop
• Active Control™ demo menu indicating real
time picture settings
• Dealer Link :wireless communication for
installation and service.
• EasyTune™
• Multi-language menu / OSD (Eng,Fre,Spa,Port)
• Sleeptimer up to 180 minutes.
• Closed Captioning
• Picture Freeze & Replay
• Mosaic Screen (Scan
• Last Status (for picture & sound)
• 2 Tuner PIP
Reception
• Tuning system:PLL Digital Tuning
• Color transmission systems
Off-air:NTSC - M
NTSC video playback
• 100 presets
• Channel selections :125 channels
• ProgramGuide prepared (cinch)
• Aerial input:75 Ohm (F-threaded)
Remote Control
• RC4305 Multi-system and Universal RC
Connections
• Front
- S-Video in (Y/C)
- video CVBS (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- AV 1 : – Video CVBS, audio L-R
– S-Video (Y/C)
- AV 2 : – Video CVBS, audio L-R
- AV 3 : – Video CVBS, audio L-R
– S-Video (Y/C)
- AV 4 : – Component video in
YPbPr, audio L-R (+CVBS)
- AV 5 : – Component video in
YPbPr (2Fh for DVD), audio L-R
– R/G/B/H/V (RCA) + audio L-R
- Monitor out:
– Video CVBS out, audio L-R out
- Sound out:
– 2 audio out L-R,Constant/Variable level
– 1 surround sound out,Variable level
- VGA in : 15pin sub-D, audio L-R
- VGA out : 15pin sub-D, audio L-R
- RC 5/6 (RCA)
- Antenna input :75Ohm F-pin
Miscellaneous
• Included cables
– VGA cable 5m (incl. Gold cinch)
– Antenna cable
• Ambient temperature :+5/+40°C
• Mains : AC 95–264V, 50/60Hz
• Power consumption:±300W (normal operation)
;Stand by :<2W
• Weight : 8.82 lbs
• Dimensions (WxHxD):
product :17.2x4.2x13.0 in.(excl.connectors)
carton : 25.3x8.5x18.5 in.
Product highlights
Digital Natural Motion™offers razor-sharp reproduction of
movement and motion.The unique and highly advanced process-
ing calculates motion trajectories of moving picture elements.
It corrects jerky movement from both studio programs or movie
material.
Digital CrystalClear™with Dynamic Contrast,SVM, Comb
filter, 9-bit processing,luminance enhancements and color
enhancements (LTP2). Offer a crisp and natural picture from
any type or quality of source.
Pixel Plus™
Uses the power of the Pixel Plus processor to increase the num-
ber of lines and the number of pixels.The result is razor sharp
pictures with incredible detail and depth,every time from any
source.
Dual HD component input and full 1080i resolution dis-
play for connection to high definition input.
Double Window, two-tuner PIP with second tuner Double
Window. Single PIP (free positioning),3 fold and 6 fold side
PIP's.Also offers photofinish,freeze Main and freeze PIP. Replay
lets you play back the previous few seconds in a PIP screen:if
you missed the action,replay it as much as you want.
Second Tuner sound on headphones.
AutoScreen™Fit will display programs from any aspect ratio
(up to 16:9),filling the complete screen without apparent distor-
tions.
Active Control™Continuous picture analysis and control of:
Automatic Digital Noise Reduction,Auto Sharpness,Auto Color,
Auto Dynamic Contrast,Ambient light sensor.Automatically offers
the best picture setting in three levels,off, min, max.A demo
menu shows you,based on the picture content the real-time
adjustments of 5 parameters.
‘Monitor is Center’ reproduction option.All monitor speakers
play as center.Dolby®processed outputs for L,R and Surround
via conventional stereo amplifier.
Powerful 2x15W RMS amplifier built in.Full digital sound
processing.
AutoPicture™and AutoSound™modes. Easy setting via
direct RC keys
AutoSurf™list. Add your favorite channels and switch
throughthem with one button click.
Dynamic Graphical User Interface. Easy and intuitive
operation through feedforward and backtracking display.8
Directional thumbpad cursor control.Full menu control of all
functions through layered menus. Easy control of most used fea-
tures through daily menus.
Zoom 16x (4x,9x). Cursor movable zoom window.
Multi system and Universal Codes Remote Control
Transparent keys with backlighting.Thumbpad cursor and
matching color finish.
YPbPr inputs for best DVD reproduction
Three menu languages,English, French,Spanish
FlatTV receiver /US FTR9965
FTR9965
VIDEO
L
R
AUDIO
AV1
IN
AV3
IN
AV5
IN
AV2
IN
AV4
IN
CENTER
IN
VGA IN MONITOR OUT
REC
OUT
VIDEO AUDIO RS•VIDEO
L
G/Y
Y
B/Pb
Pb
R/Pr
Pr
L
L
R
R
HV
75
ANT IN S•VIDEO
L
R
AMP
L
R
AUDIO
IN AUDIO
OUT
L
R
Receiver connectors - FTR9965/17S
S-VIDEO VIDEO AUDIO RL
Front receiver
©
2003 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
Pixel Plus,Digital Natural Motion,Digital CrystalClear,
AutoScreen Fit,AutoSurf,AutoPicture,AutoSound, Easy-
Tune,ActiveControl IncredibleSurround and AutoLock are
trademarks of Philips Consumer Electronics Company.
‘Dolby’ and the double D symbol are trademarks of
Dolby Laboratories.
As an
ENERGY STAR
®
Partner,Philips has determined that
this product meets the
ENERGY STAR
®
guidelines for
energy efficiency.
Website: www.philips.com
Specifications subject to change without notice.
Release date : –
Predecessor(s) : FTR9964
Date of issue : April 2003
