Philips

Mini Audio System

FW-C717

wOOx Technology

Hear the Bass, Feel the Difference

Impressive power and bass

• Bass Reflex Speaker System delivers a powerful, deeper bass

• wOOx™ loudspeaker Technology for deep and powerful bass

• 2x60W RMS/2000W PMPO

Extensive sound features

• 3-Step wOOx level control

• Choose from 6 modes of Digital Sound Control

• Choose from 6 modes of Virtual Ambience Control

• Incredible Surround ™ enhances the sound stage

Intuitive and easy to use

• Interactive Dashboard Display for a visual audio experience

Issue date 2014-02-05

Version: 3.0.4

12 NC: 9073 100 11326

EAN: 87 10895 74587 1

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

Specifications

FW-C717/22

Mini Audio System

Highlights

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep bass

experience from a compact loudspeaker box system.

It differs from a conventional loudspeaker box

system in the addition of a bass pipe that is

acoustically aligned to the woofer to optimize the

low frequency roll-off of the system. The result is

deeper controlled bass and lower distortion. The

system works by resonating the air mass in the bass

pipe to vibrate like a conventional woofer.

Combined with the response of the woofer, the

system extends the overall low frequency sounds to

create a whole new dimension of deep bass.

wOOx™ Technology

wOOx technology is a revolutionary loudspeaker

concept that allows you to hear and feel profoundly

deep bass that is richer than any other audio system.

Special speaker drivers work in harmony with the

wOOx bass radiator, and precise tuning between the

main driver and the tweeter ensures smooth

transitions from low-mid to high frequencies. Dual

suspension and a totally symmetrical sandwich

construction deliver low and precise base without

noticeable distortion. wOOx produces exceptionally

deep and dynamic bass by using the speaker box full

volume to truly magnify the impact of the music.

2x60W RMS/2000W PMPO

2x60W RMS/2000W PMPO

3-Step wOOx level control

3-Step wOOx level control

6-Mode Digital Sound Control

Choose from 6 modes of Digital Sound Control

6Mode Virtual Ambience Control

Choose from 6 modes of Virtual Ambience Control

Incredible Surround ™

Incredible Surround™ widens the sound stage, giving

you the impression of having extra speakers all

around you.

Interactive Dashboard Display

Interactive Dashboard Display is a visually attractive

animated graphics display with volume meter. It gives

you at-a-glance track and volume information using

an attractive dashboard interface. Interactive

Dashboard Display integrates a Fluorescent Tube

Display (FTD) and a Volume Unit (VU) meter to

display volume levels, useful track information and

music amplitude during playback. The exciting

animated graphics add to the overall 'feel' of the

music.

Sound

• Sound Enhancement: wOOx technology,

Incredible Surround, Digital Sound Control 6

modes, Virtual Ambience, 6 modes

• Output Power: 2x120W music

Loudspeakers

• Main Speaker: 3 way, Bass Reflex Speaker System,

6.5" woofer, wOOx Bass Radiator, 2" tweeter, 1"

polydome piezo, Speaker grilles detachable

Audio Playback

• Playback Media: CD, CD-R, CD-RW

• Loader Type: 3 CD Carousel

• Number of Discs: 3

• Disc Playback Modes: Repeat/one/all/program,

Shuffle Play, 40-Track Programmable

• Cassette Deck Technology: Logic

•Number of decks: 2

• Cassette Playback Modes: Electronic Speed

Control, Full Auto Stop

Tuner/Reception/Transmission

• Tuner Bands: FM Stereo, MW, LW

• Auto digital tuning

• Tuner Enhancements: Auto Store, Easy Set (Plug &

Play)

• RDS: News, Program Type, Radio Text, RDS

Clock Set, Station Name

Audio Recording

• Recording Media: Tape

• Tape Recording Enhancement: Automatic

Recording Level, CD Synchro Start Recording

Connectivity

• Aux in: Line in

• Other connections: Digital output (cinch),

Analogue out, FM Antenna, MW Antenna

• Headphone: 3.5 mm

Convenience

• Alarms: CD Alarm, Radio Alarm, Sleep timer

• Clock: On main display

• Display Type: FTD

• Indications: DIM mode

Accessories

• Included accessories: AC Power Cord, FM/MW

Antenna

• Remote control: 31-key

Dimensions

• Weight incl. Packaging: 15.2 kg

• Set dimensions (W x H x D): 265 x 310 x 390 mm

• Packaging dimensions (W x H x D):

544 x 703 x 398 mm

• Main speaker dimensions (W x H x D):

240 x 350 x 315 mm

Power

• Standby power consumption: < 1W

•
