Philips Cineos

DVD/SACD home theater

system with Neodymium

Ribbon Tweeters

HTS9800W

The ultimate cinematic experience

With superb sound quality

Crafted with artistry and precision, this home entertainment system promises

unsurpassed viewing and listening experience. A streamlined design, matching any Flat TV,

blends with your interior thanks to wall-mountable and wireless feature.

Unrivalled audio and video performance

• 6.1 Dolby Digital EX cinematic surround sound

• HDMI out for digital high-definition video and digital audio

• Video Upscaling for improved resolution of up to 1080i

• Neodymium Ribbon Tweeters for crystal clear sound

• Multi-channel SACD for total music immersion

Blends with your interior

• Wireless rear speakers for fewer wires across your room

• Slim and flexible design with optional wall-mounting

• Ultra-slim flat panel speakers to complement your home

HTS9800W/55

Highlights

DVD/SACD home theater system with Neodymium Ribbon Tweeters

6.1 Dolby Digital EX surround

Dolby Digital EX decoding is a new technology

that adds an extra sense of dimensional detail

and intensified involvement to the already

thrilling Dolby Digital 5.1-channel listening

experience. The extra surround channel

creates an even more exciting, enveloping

surround-sound effect.

HDMI out

HDMI is a direct digital connection that can

carry digital HD video as well as digital

multichannel audio. By eliminating the

conversion to analog signals it delivers perfect

picture and sound quality, completely free

from noise. HDMI is fully backward-compatible

with DVI.

Video Upscaling up to 1080i

With Video Upscaling you can increase the

resolution of SD (Standard Definition) video

signals that DVD uses to HD (High Definition)

so you’ll be able to see more details thanks to

a sharper, more true-to-life picture.The

resulting HD video output signal can be fed to

an HD display through HDMI (High-Definition

Multimedia Interface).

Wireless rear speakers

Wireless rear speakers give you scalability and

mobility in speaker placement. Developed

using interference-free technology, wireless

speakers provide full surround sound without

unsightly wire connections.

Neodymium Ribbon Tweeters

Enjoy unparalleled, natural and crystal-clear

sound quality with Omni-directional

Neodymium Ribbon Tweeter. Dipoles that

radiate high frequency sounds in a full 360-

degree pattern results in a very 'open' wide

sound spectrum that delivers crisp clarity and

high-pitched detail in the higher tones. This

further enhances the surround experience in a

multi-channel system and is especially noticed

when listening to Super Audio CD sound

where the clarity in music is excellent.

Multi-channel SACD

Multi-channel SACD prepared. This new

generation music format gives you Ultra high

quality music reproduction, 5.1 multi-channel

surround sound and full backward and forward

compatibility with CD.

Issue date 2014-02-06

Version: 4.0.8

12 NC: 9073 100 13071

EAN: 87 10895 93239 4

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

HTS9800W/55

Specifications

DVD/SACD home theater system with Neodymium Ribbon Tweeters

Picture/Display

• Aspect ratio: 4:3, 16:9

• D/A converter: 12 bit, 108 MHz

• Picture enhancement: High Def (720p, 1080i),

Video upscaling, Video upsampling

Sound

• D/A converter: 24 bit, 192 kHz

• Frequency response: 30-50000 Hz

• Signal to noise ratio: >95 dB

• Sound System: Stereo, Dolby Digital EX, DTS,

Dolby Prologic II, Dolby Digital

• Sound Enhancement: Class "D" Digital Amplifier,

Treble and Bass Control, Night Mode

• Output power (RMS): 3x125W (Front L/R/ Front

Centre) + 2x85W (Rear L/R) + 105W (Rear

Centre) + 150W (Subwoofer)

• Total Sound Power (RMS): 800 W

• Equalizer settings: Action, Classic, Concert, Digital,

Drama, Jazz, Rock, Sci-Fi

Video Playback

• Playback Media: DVD-Video, DVD+RW, DVD+R,

DVD-RW (Video mode), DVD-R, Video CD/

SVCD, CD-R/CD-RW, Super Audio CD

• Compression formats: MPEG1, MPEG2, DivX 3.11,

DivX 4.x, DivX 5.x, DivX 6.0

• Video disc playback system: NTSC, PAL

Audio Playback

• Playback Media: CD, MP3-CD, SACD

Multichannel, SACD Stereo, CD-R, CD-RW

• Compression format: MP3, PCM, WMA

• MP3 bit rates: 32-256 kbps and VBR

• Disc Playback Modes: CD Text display, Fast

Forward/Backward, Next/Previous Album Search,

Next/Previous Track Search, Repeat one/album/all,

Shuffle Play

Still Picture Playback

• Playback Media: Picture CD

• Picture Compression Format: JPEG

• Picture Enhancement: Slideshow with MP3

playback

Tuner/Reception/Transmission

• Tuner Bands: FM Stereo, AM

• Number of Preset Channels: 20

• Auto digital tuning

• Auto store

Connectivity

• Other connections: AUX in, Analog audio Left/

Right in, ComponentVideo out Progressive,

Composite video (CVBS) out, Digital coaxial in,

Easy-Fit speaker connectors, FM Antenna, HDMI

out, S-Video out, TV in (audio, cinch)

Convenience

• Child Protection: Parental Control

• On-Screen Display languages: English, Brazilian

Portuguese, Spanish, Traditional Chinese, Malay,

Canadian French

• Remote Control: Multi-functional

Power

• Power supply: 110-240V, 50/60 Hz

• Standby power consumption: < 1 W

• Power consumption: 165 W

Loudspeakers

• Satellite Speaker: 2 way, Magnetically shielded

front, 4 Floor standing pillars, Wireless rear

speakers

• Satellite speaker freq range: 120-50000 Hz

• Satellite speaker impedance: 6 ohm

• Satellite speaker drivers: 4" ribbon tweeter, 2x 3"

full range woofer

• Center Speaker: 2 way

• Center speaker drivers: 2 x 3" full range woofers,

4" ribbon tweeter

• Center freq range: 120-50000 Hz

• Center speaker impedance: 6 ohm

• Subwoofer driver: 6.5" high efficiency woofer

• Subwoofer freq range: 30-120 Hz

• Subwoofer impedance: 4 ohm

Accessories

• Included accessories: User Manual, Quick start

guide, Remote Control, 1x center speaker, 1x

subwoofer, 2x front satellite speakers, 3x rear

satellite speakers, Interconnect cable, FM antenna,

Screws for wall mounting x2, World Wide

Warranty leaflet

Dimensions

• Set dimensions (W x H x D): 273 x 284 x 144 mm

• Set weight: 2.8 kg

• Center speaker dimensions (W x H x D):

497 x 139 x 32 mm

• Center Speaker Weight: 1.5 kg

• Rear Speaker Depth: 32 mm

• Rear Speaker Height: 139 mm

• Rear Speaker Weight: 1.5 kg

• Rear Speaker Width: 497 mm

• Surround Speaker dimensions (W x H x D):

106 x 497 x 32 mm

• Surround speaker Weight: 1.25 kg

• Subwoofer dimensions (W x H x D):

300 x 399 x 300 mm

• Subwoofer Weight: 12 kg

• Stand dimensions (W x H x D):

240 x 830 x 240 mm

• Stand weight: 4.5 kg

• Weight incl. Packaging: 47.5 kg

•

* Avoid extensive use of the set in a volume higher than 85 decibel

because this may damage your hearing.

TO JUNCTION BOX

3139 241 60451

FRONT

RIGHT

FRONT

LEFT

REAR

RIGHT

REAR

LEFT CENTER

SPEAKERS

VOLTAGE

SELECTOR

110V-

127V

220V-

240V

68
