Philips

Component DVD micro

system

• 100W

MCD712

Obsessed with sound

Relax with great music and movies

Experience cinema-quality sound at home with the Philips component DVD micro

system. Plug in a USB-compatible device for photo and MP3/WMA music playback in

superb sound. Dramatic sound is yours to enjoy with 100W RMS total output power.

Enrich your movie experience

• Dolby Digital for ultimate movie experience

• Play DVD, DivX®, (S)VCD, MP3-CD, WMA-CD, CD(RW) & Picture CD

Enrich your sound experience

• USB Direct for music and photo playback

• Digital Sound Control for optimized music style settings

• Dynamic Bass Boost for deep and dramatic sound

• Loudness for bass and treble enhancement

• 100W RMS total output power

Easy to use

• Digital tuning with preset stations for extra convenience

• Motorized CD loader for convenience access

• Radio Data System for station information and data services

• Wake up and sleep timer functions

MCD712/12

Highlights

Component DVD micro system

100W

USB Direct

Simply plug in your USB device on the system

and share your stored digital music and photos

with your family and friends.

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Jazz, Rock, Pop and Classic controls

you can use to optimise the frequency ranges

for different musical styles. Each mode uses

graphic equalizing technology to automatically

adjust the sound balance and enhance the most

important sound frequencies in your chosen

music style. Ultimately, Digital Sound Control

makes it easy for you get the most out of your

music by precisely adjusting the sound balance

to match the type of music you are playing.

Dynamic Bass Boost

Dynamic Bass Boost maximizes your music

enjoyment by emphasizing the bass content of

the music throughout the range of volume

settings - from low to high – at the touch of a

button! Bottom-end bass frequencies usually

get lost when the volume is set at a low level.

To counteract this, Dynamic Bass Boost can be

switched on to boost bass levels, so you can

enjoy consistent sound even when you turn

down the volume.

Loudness

In the sound spectrum, high and low

frequencies are relatively less audible to human

ears - especially at low volumes. By activating

the Loudness feature, the bass and treble will

be amplified so you can savor a more balanced

sound perception overall.

Dolby Digital

Because Dolby Digital, the world's leading

digital multi-channel audio standards, make use

of the way the human ear naturally processes

sound, you experience superb quality

surround sound audio with realistic spatial

cues.

100W RMS

This system has 100W RMS total output

power. RMS refers to Root Mean Square

which is a typical measurement of audio

power, or rather, the electrical power

transferred from an audio amplifier to a

loudspeaker, which is measured in watts. The

amount of electrical power delivered to the

loudspeaker and its sensitivity determines the

sound power that is generated. The higher the

wattage, the better the sound power emitted

by the speaker.

Play DVD, DivX & MP3/WMA-CD

The Philips player is compatible with most

DVD and CD discs available in the market.

DVD, DivX®, (S)VCD, MP3/WMA-CD,

CD(RW) and Picture CD - all of them can play

on the player. SVCD stands for "Super

VideoCD". The quality of a SVCD is much

better than a VCD, especially much more

sharpen picture than a VCD because of the

higher resolution. With DivX® support, you

are able to enjoy DivX® encoded videos. The

DivX media format is an MPEG4-based video

compression technology that enables you to

save large files like movies, trailers and music

videos on media like CD-R/RW, and DVD

recordable discs.

Digital tuning with presets

Simply tune into the station that you want to

preset, press and hold the preset button to

memorize the frequency. With preset radio

stations that can be stored, you can quickly

access your favorite radio station without

having to manually tune the frequencies each

time.

Motorized CD loader

A motorized sliding front door adds even

more panache to the already sleek design of

this system. The stylish yet functional door

housing the disc slides up and down vertically

in a smooth motion at the touch of a button

whenever you feel like changing your music

selection. Just sit back and enjoy the dynamic

sound performance while watching the disc

play through the transparent window.

Issue date 2013-05-10

Version: 1.0.3

12 NC: 8670 000 55703

EAN: 87 12581 50107 5

© 2013 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

MCD712/12

Specifications

Component DVD micro system

100W

Sound

• Sound enhancement: loudness, digital sound

control 4 modes, Dynamic Bass Boost, Dolby

Digital

• Output power: 2 x 50 W RMS / 2 x 100 W music

power

Loudspeakers

• Speaker drivers: 4" woofer, Piezo tweeter

• Loudspeaker enhancement: 2-way, speaker grilles

detachable

• Speaker types: bass reflex speaker system

Video Playback

•DVD region code: 2

• Playback media: DVD-Video, video CD/SVCD,

picture CD, DivX, DVD+R/+RW, DVD-R/-RW

• Disc playback modes: parental control, angle,

Zoom, A-B Repeat, disc menu, fast backward, fast

forward, OSD, PBC, resume playback from stop,

slow motion

Audio playback

• Playback media: WMA-CD, MP3-CD, CD-RW,

CD-R, CD, USB flash drive

• Disc playback modes: fast forward/backward, next/

previous track search, repeat/shuffle/program

• USB Direct playback modes: fast backward/fast

forward, play/pause, previous/next, program play,

repeat, shuffle, stop

Tuner/Reception/Transmission

• Tuner bands: FM stereo

• RDS: program type, RDS clock set, station name

• Station presets: 20

• Antenna: FM antenna

• Tuner enhancement: auto digital tuning, auto scan

Connectivity

• Audio/Video output: 2xRCA (Audio), component

video out, composite video (CVBS) out, digital

audio coaxial out, Headphone (3.5mm), SCART

out, S-Video out

• Aux in: 2xRCA (Audio)

• USB: USB host

Convenience

• Alarms: CD alarm, radio alarm, USB alarm

• Clock: on main display, sleep timer

• Loader type: motorised, tray

• Display enhancements: DIM mode

• Display type: VFD display

• On-Screen display languages: Dutch, English,

French, German, Italian, Portuguese, Spanish,

Swedish, Turkish

Accessories

• Cables/Connection: composite video cable (Y)

• Remote control: 40-key with lithium battery

• User Manual: multi-languages

• Others: FM antenna, Quick start guide

• Warranty: World Wide Guarantee booklet

Dimensions

•Gross weight: 11 kg

• Main speaker dimensions (W x D): 170 x 220 mm

• Main speaker height: 270 mm

• Main unit depth: 307 mm

• Packaging depth: 314 mm

• Main unit height: 110 mm

• Packaging height: 350 mm

• Main unit width: 248 mm

• Packaging width: 558 mm

Power

• Power supply: 50 Hz

• Power supply: 220 - 240 V

Green

• Eco Power standby: 1 W

Digital photo playback

• Playback media: CD-R/RW, DVD+R/+RW, picture

CD

• Picture Compression Format: JPEG

•
