Philips

DVD/SACD home theater

system

Progressive Scan

MX5700D

Total Immersion in Movies

With Enhanced Bass Performance

Ergonomically designed, the MX5700D is a 5 DVD performance-oriented Home

Entertainment System bestowed with superior technological features to provide the

ultimate movie, photo and music experience - from disc or memory card.

Unrivalled audio and video performance

• Twin Subs™ Bass Pipes are integrated in speaker columns

• Cinema Center Speaker™ for realism cinematic experience

• DTS 5.1 Dolby Digital Pro Logic II full surround sound

• Advanced Class D Amplifier™for compact, powerful sound

Plays practically any disc format

• Movies: DVD, DVD+R/RW, DVD-R/RW, (S)VCD

• Music: CD, CD-R/RW and MP3-CD

• PCMCIA Media Slot to view photos on TV from memory cards

Quick and easy set-up

• Seating Control™ provides best sound performance sweet spot

• Easy set-up to initialize your total home entertainment

Issue date 2014-02-05

Version: 5.0.6

12 NC: 9073 100 11486

EAN: 87 10895 76590 9

© 2014 Koninklijke Philips N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

Specifications

MX5700D/22S

DVD/SACD home theater system

Progressive Scan

Highlights

Twin Subs™

Twin Subs™ give you increased bass performance

due to downward firing woofers, enhanced accuracy

because of real non-directional bass distribution and

clean, easy set up with twin subs integrated in the

speaker columns.

Cinema Center Speaker™

Recreate and experience realism cinematic

experience right in your environment with Cinema

Center Speaker™. With a wider sweet spot

delivered by four multi-directional woofers and a

high frequency tweeter positioned precisely at

different angles, more sound depths are

distinguished from front and background and action

from dialogue. Natural and crystal clear sound

reproduction are created through the revolutionary

new 5.1 cm (2") full range woofers to give an

incredible 'through the screen' experience which

creates the sensation of being not just in the cinema

but in the movie itself.

DTS, Dolby Digital 5.1 and PL2

A Built-in DTS and Dolby Digital decoder eliminates

the need for an external decoder by processing all

six channels of audio imformation to provide a

surround sound experience and an astoundingly

natural sense of ambience and dynamic realism.

Dolby Pro Logic II provides five channels of surround

processing from any stereo source.

6x Class D Digital Amplifier

When it comes to perfect audio there is no room for

distortion. Digital amplifiers generate far less heat

than standard analog amplifiers, allowing for smaller

set enclosures. Philips Class D Amplifiers™ provide

dramatically enhanced sound quality over digital

amplifiers used by competitors as they are designed

to control and reduce EMI (Electro Magnetic

Interference). In addition, the Class D Amplifiers™

use a closed loop design which suppresses distortion

and loss of audio quality. The overall result is

enhanced audio performance from a much smaller

package.

Multi-format Movies

Multi-format playability allows you to play most disc

formats for maximum disc compatibility and viewing

pleasure.

Multi-format Music

Multi-format playability allows you to play most disc

formats for maximum disc compatibility and listening

pleasure.

PCMCIA Media Slot

Media Slot is a simple card solution, giving you instant

access to digital pictures from various memory card

formats like Compact Flash, Memory Stick, SD card

and MultiMedia Card via a PCMCIA adaptor.

Seating Control™

Achieve best sound performance with Seating

Control™ by choosing your preferred seat via the

Joystick Remote Control. Select your room layout

and 3D speakers setup with ease and get set for a

real total sound immersion experience.

Quick Start Guide

To guide you through the initial set-up of your

system, Philips delivers a Quick Start Guide that uses

an easy approach with clearly defined graphics and

colors to guide you through the basic steps of

connection and obtaining picture and sound. These

basic steps are clearly described on one page in the

packaging box, making setup quick and simple.

Power

• Power supply: 110-240V

• Standby power consumption: < 0.5 W

Accessories

• Included accessories: 1x center speaker, 2x front

satellite speakers, 2x rear satellite speakers, 2x

TwinSub subwoofer/stand, AC Power Cord, FM/

MW Antenna, Quick Use Guide, Remote Control,

User Manual, Warranty certificate, Scart Cable

• Included batteries: 2x Longlife AA

Convenience

• Remote Control: Multi-functional

Connectivity

• Other connections: Subwoofer pre-out, S-Video

out, MW Antenna, Line out, FM Antenna, Digital

coaxial out, Digital coaxial in, Composite video

(CVBS) out, Analog audio Left/Right in,

Component Video out Interlaced

• Headphone: 6.3 mm

• Front / Side connections: Headphone Out

Tuner/Reception/Transmission

• Tuner Bands: FM Stereo, MW

• RDS: Station Name

• Number of Preset Channels: 40

• Auto store

• Auto digital tuning

Audio Playback

• MP3 bit rates: 32-256 kbps

• Disc Playback Modes: Shuffle Play, Repeat one/

album/all, Next/Previous Track Search, Next/

Previous Album Search, Fast Forward/Backward

• Playback Media: MP3-CD, CD-RW, CD-R, CD

• Compression format: PCM, MPEG2 Multichannel,

MP3, DTS, Dolby Digital

Video Playback

• Compression formats: MPEG1, MPEG2

• Playback Media: DVD+RW, DVD-R, DVD-RW

(Video mode), DVD-Video, SVCD, Video CD,

DVD+R

• Disc Playback Modes: A-B Repeat, Repeat

•Loader Type: Tray

• Number of Discs: 5

• Video disc playback system: NTSC, PAL

Loudspeakers

• Center speaker impedance: 4 ohm

• Satellite speaker impedance: 4 ohm

• Satellite speaker freq range: 120-30000 Hz

• Subwoofer type: TwinSubs

• Subwoofer freq range: 30-120 Hz

• Subwoofer impedance: 8 ohm

• Center freq range: 120-30000 Hz

• Subwoofer driver: 2 x 4" long throw woofer

• Center speaker drivers: 4x 2" mid range woofers,

1.75" tweeter

• Center Speaker: Magnetically shielded, Cinema

Center speaker, 2 way

• Satellite speaker drivers: 2x 3" mid range woofer

• Satellite Speaker: Magnetically shielded front

Sound

• Total Sound Power (RMS): 600 W

• Sound System: MPEG2, DTS, Dolby Prologic II,

Dolby Digital (AC-3), Matrix surround

• Output Power: 6 x 100W RMS

• Frequency response: 30-30000 Hz

• Signal to noise ratio: >65 dB

• Sound Enhancement: Treble and Bass Control,

Seating Control, Night Mode, Incredible Surround,

ClearVoice, Class "D" Digital Amplifier

• Equalizer settings: Sci-Fi, Rock, Jazz, Drama, Digital,

Concert, Classic, Action

• D/A converter: 24 bit, 192 kHz

Picture/Display

• Aspect ratio: 16:9, 4:3

• D/A converter: 10 bit, 54 MHz

Dimensions

• Center speaker dimensions (W x H x D):

435 x 72 x 63.5 mm

• Center Speaker Weight: 1.3 kg

• Packaging dimensions (W x H x D):

994 x 410 x 544 mm

• Set dimensions (W x H x D): 435 x 100 x 360 mm

• Set weight: 7.2 kg

• Subwoofer dimensions (W x H x D):

110 x 940 x 110 mm

• Subwoofer Weight: 4.5 kg

• Surround Speaker dimensions (W x H x D):

94 x 280 x 70 mm

• Surround speaker Weight: 1.2 kg

• Weight incl. Packaging: 34.2 kg

Still Picture Playback

• Playback Media: Picture CD

• Picture Compression Format: JPEG

•
