Philips Matchline
DVD/SACD home theater
system with Neodymium
Ribbon Tweeters
MX5800SA
Total Immersion in
Movies and Music
Ergonomically designed, the MX5800SA is a 5 DVD/SACD performance-oriented Home
Entertainment System bestowed with superior technological features to provide the
ultimate movie and music experience - right at home.
Unrivalled audio and video performance
• Multi-channel Super Audio CD for total music immersion
• Twin Subs™ Bass Pipes are integrated in speaker columns
• Neodymium Ribbon Tweeters for crystal clear sound
• Cinema Center Speaker™ for realism cinematic experience
• Advanced Class D Amplifier™for compact, powerful sound
• DTS 5.1 Dolby Digital Pro Logic II full surround sound
Plays practically any disc format
• Movies: DVD, DVD+R/RW, DVD-R/RW, (S)VCD
• Music: SACD, CD, MP3-CD, CD-R and CD-RW
Quick and easy set-up
• Seating Control™ provides best sound performance sweet spot
• Easy set-up to initialize your total home entertainment
MX5800SA/78
Highlights
DVD/SACD home theater system with Neodymium Ribbon Tweeters
Multi-channel Super Audio CD
Multi-channel SACD is a new generation music
format that offers ultra high quality music
reproduction. With a 5.1 multi-channel
surround sound and full CD compatibility both
forward and backward, what results is
unsurpassed audio performance for your
listening pleasure.
Twin Subs™
Twin Subs™ give you increased bass
performance due to downward firing woofers,
enhanced accuracy because of real non-
directional bass distribution and clean, easy set
up with twin subs integrated in the speaker
columns.
Neodymium Ribbon Tweeters
Enjoy unparalleled, natural and crystal-clear
sound quality with Omni-directional
Neodymium Ribbon Tweeter. Dipoles that
radiate high frequency sounds in a full 360-
degree pattern results in a very 'open' wide
sound spectrum that delivers crisp clarity and
high-pitched detail in the higher tones. This
further enhances the surround experience in a
multi-channel system and is especially noticed
when listening to Super Audio CD sound
where the clarity in music is excellent.
Cinema Center Speaker™
Recreate and experience realism cinematic
experience right in your environment with
Cinema Center Speaker™. With a wider
sweet spot delivered by four multi-directional
woofers and a high frequency tweeter
positioned precisely at different angles, more
sound depths are distinguished from front and
background and action from dialogue. Natural
and crystal clear sound reproduction are
created through the revolutionary new 5.1 cm
(2") full range woofers to give an incredible
'through the screen' experience which creates
the sensation of being not just in the cinema
but in the movie itself.
6x Class D Digital Amplifier
When it comes to perfect audio there is no
room for distortion. Digital amplifiers generate
far less heat than standard analog amplifiers,
allowing for smaller set enclosures. Philips
Class D Amplifiers™ provide dramatically
enhanced sound quality over digital amplifiers
used by competitors as they are designed to
control and reduce EMI (Electro Magnetic
Interference). In addition, the Class D
Amplifiers™ use a closed loop design which
suppresses distortion and loss of audio quality.
The overall result is enhanced audio
performance from a much smaller package.
DTS, Dolby Digital 5.1 and PL2
A Built-in DTS and Dolby Digital decoder
eliminates the need for an external decoder by
processing all six channels of audio
imformation to provide a surround sound
experience and an astoundingly natural sense
of ambience and dynamic realism. Dolby Pro
Logic II provides five channels of surround
processing from any stereo source.
Multi-format Movies
Multi-format playability allows you to play
most disc formats for maximum disc
compatibility and viewing pleasure.
Multi-format Music with SACD
Multi-format playability allows you to play
most disc formats for maximum disc
compatibility and listening pleasure
Seating Control™
Achieve best sound performance with Seating
Control™ by choosing your preferred seat via
the Joystick Remote Control. Select your
room layout and 3D speakers setup with ease
and get set for a real total sound immersion
experience.
Quick Start Guide
To guide you through the initial set-up of your
system, Philips delivers a Quick Start Guide
that uses an easy approach with clearly defined
graphics and colors to guide you through the
basic steps of connection and obtaining picture
and sound. These basic steps are clearly
described on one page in the packaging box,
making setup quick and simple.
Issue date 2014-02-05
Version: 4.0.5
12 NC: 9073 100 12082
EAN: 87 10895 84379 9
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
MX5800SA/78
Specifications
DVD/SACD home theater system with Neodymium Ribbon Tweeters
Picture/Display
• Aspect ratio: 4:3, 16:9
• D/A converter: 10 bit, 54 MHz
Sound
• D/A converter: 24 bit, 192 kHz
• Equalizer settings: Action, Classic, Concert, Digital,
Drama, Jazz, Rock, Sci-Fi
• Frequency response: 30-30000 Hz
• Signal to noise ratio: >65 dB
• Sound Enhancement: Class "D" Digital Amplifier,
ClearVoice, Incredible Surround, Night Mode,
Seating Control, Treble and Bass Control
• Sound System: Dolby Digital (AC-3), Dolby
Prologic II, DTS, Matrix surround, MPEG2
• Output Power: 6 x 1000W PMPO
• Total Sound Power (RMS): 6000 W
Loudspeakers
• Satellite Speaker: Magnetically shielded front
• Satellite speaker freq range: 120-50000 Hz
• Satellite speaker impedance: 4 ohm
• Satellite speaker drivers: 3" ribbon tweeter, 2x 3"
mid range woofer
• Center Speaker: 2 way, Cinema Center speaker,
Magnetically shielded
• Center freq range: 120-30000 Hz
• Center speaker impedance: 4 ohm
• Center speaker drivers: 1.75" tweeter, 4x 2" mid
range woofers
• Subwoofer type: TwinSubs
• Subwoofer freq range: 30-120 Hz
• Subwoofer impedance: 8 ohm
• Subwoofer driver: 2 x 4" long throw woofer
Video Playback
• Compression formats: MPEG1, MPEG2
• Playback Media: DVD+RW, DVD+R, DVD-RW
(Video mode), DVD-R, DVD-Video, SVCD, Video
CD
• Disc Playback Modes: A-B Repeat, Repeat
•Loader Type: Tray
• Number of Discs: 5
• Video disc playback system: NTSC, PAL
• Video Enhancement: Progressive Scan
Audio Playback
• Compression format: Dolby Digital, DTS, MP3,
MPEG2 Multichannel, PCM
• Playback Media: CD, CD-R, CD-RW, MP3-CD,
SACD Multichannel, SACD Stereo
• Disc Playback Modes: Fast Forward/Backward,
Next/Previous Album Search, Next/Previous
Track Search, Repeat one/album/all, Shuffle Play
• MP3 bit rates: 32-256 kbps
Tuner/Reception/Transmission
• Auto digital tuning
• Auto store
• Number of Preset Channels: 40
• RDS: Station Name
• Tuner Bands: FM Stereo, MW
Connectivity
• Front / Side connections: Headphone Out
• Headphone: 6.3 mm
• Other connections: Analog audio Left/Right in,
Component Video out Interlaced, Composite
video (CVBS) out, Digital coaxial in, Digital coaxial
out, FM Antenna, Line out, MW Antenna, S-Video
out, Subwoofer pre-out
Convenience
• Remote Control: Multi-functional
Accessories
• Included accessories: 1x center speaker, 2x front
satellite speakers, 2x rear satellite speakers, 2x
TwinSub subwoofer/stand, AC Power Cord, Audio
Cable, CVBS video cable, FM/MW Antenna, Quick
Use Guide, Remote Control, User Manual,
Warranty certificate
• Included batteries: 2x Longlife AA
Dimensions
• Center speaker dimensions (W x H x D):
435 x 72 x 63.5 mm
• Center Speaker Weight: 1.3 kg
• Packaging dimensions (W x H x D):
994 x 410 x 544 mm
• Set dimensions (W x H x D): 435 x 100 x 360 mm
• Set weight: 7.2 kg
• Subwoofer dimensions (W x H x D):
110 x 940 x 110 mm
• Subwoofer Weight: 4.5 kg
• Surround Speaker dimensions (W x H x D):
94 x 280 x 70 mm
• Surround speaker Weight: 1.2 kg
• Weight incl. Packaging: 34.2 kg
Power
• Power supply: 110-240V
• Standby power consumption: < 0.5 W
•
