www.pimicos.com // info@pimicos.com // phone: +49 (0) 7634-50 57 230 // fax: +49 (0)7634-50 57 393

Motors & Encoders 9.245

TECHNICAL DATA

Linear encoders LE

TECHNICAL DATA

Linear encoders LE

AliasModel Accuracy

Resolution Recommended meas. step Index position

Signals Signal output, (quadrature) channels

µm µm µm

AE-060RGS-S+RGH24Z ± 1 0.2 0.2 in the middle of travel

RS 422 differential 2 + 1 index and complementary outputs

LS-010LIA-20 RS422 ± 1 0.05 0.05 all 50 mm starting in the middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-011LIA-20 1V

pp

± 1 20 (1Vss)

0.015 all 50 mm starting in the middle of travel

1 Vpp

2 + 1 index and complementary outputs

LS-012LIA-20 RS422 ± 1 0.05 0.05 all 50 mm starting in the middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-013Epifle

x Meßmodul EM D0.1-2 Sensor 5x10

20 (1Vpp)

0.05 1Vpp

2

LS-020LIP-481-R 1V

pp

± 0.5 2 (1Vss)

0.001 app. middle of travel

1 Vpp

2 + 1 index and complementary outputs

LS-021LIP-481-R 1V

pp

± 0.2 2 (1Vss)

0.001 app. middle of travel

1 Vpp

2 + 1 index and complementary outputs

LS-025Kit-L2 ± 1 0.05 0.05 app. middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-028NanoStar 5 0.05 0.05 absolute

LS-030LIP-581-R ± 1 4 (1Vss)

0.005 yes

1 Vpp

2 + 1 index and complementary outputs

LS-035LIK-41 ± 1 0.05 0.05 app. middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-036LIK-41 ±1 20 (1Vpp)

0.01 app. middle of travel

1Vpp

2+1 index and complementary outputs

LS-040LIP-372 ± 0.5 0.001 0.001 no RS-422 differential 2

LS-050LIK-21 ± 1 0.05 0.05 all 50 mm starting in the middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-059Mercury 3000 ±3 0.02 0.02 in the middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-060M3500L ±3 0.005 0.005 in the middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-061M6000L ± 1.5 0.005 0.005 middle of travel

RS-422 differential 2 + 1 index and complementary outputs

LS-070RGH25+RGB25B ± 3 20 (1Vss)

0.015 yes

1 Vpp

2 + 1 index and complementary outputs

APPLICATIONS

CONTROLLERS

ROBOTICS

LINEAR STAGES

ROTATION STAGES

PIEZO STAGES

MANUAL STAGES

ACCESSORIES

APPENDIX

DC-brush motors

2-Phase stepper

Torque motors

Linear motors

Piezo motors

Linear encoders LE

Rotary encoders RE

Rotary encoders AE

www.pimicos.com // info@pimicos.com // phone: +49 (0) 7634-50 57 230 // fax: +49 (0)7634-50 57 393

Error and technical modifications are subject to change

9.246Motors & Encoders

TECHNICAL DATA

Rotary encoders RE

TECHNICAL DATA

Rotary encoders RE

AliasModel Resolution Increments/revolution

Index position

Signals Signal output, (quadrature) channels

°

RE-00230B19 9 10 no TTL 2

RE-005IE2-512 0.17578125 512 no TTL 2

RE-010HEDL-5540 0.18 500 yes

RS-422 differential 2 + 1 index and complementary outputs

RE-0152RMHF 0.018 5000 yes

RS-422 differential 2 + 1 index and complementary outputs

RE-016F14 0.018 5000 yes

RS-422 differential 2 + 1 index and complementary outputs

RE-025MR256 0.3515 256 yes

RS-422 differential 2 + 1 index and complementary outputs

TECHNICAL DATA

Rotary encoders AE

TECHNICAL DATA

Rotary encoders AE

AliasModel Accuracy

Resolution Recommended meas. step Index position

Signals Signal output, (quadrature) channels

Increments/revolution

ArcSec ° °

AE-015Signnum d=229 mm 0,97 0.01 (1Vpp)

0.00001 yes

1 Vpp + RS422

2 + 1 index and complementary outputs

36000

AE-050RIK RS-422 P4 ±20 (5.5m°) 0.0001 0.0001 one, near cal-switch RS 422 differential 2 + 1 index and complementary outputs

9000

AE-051RIK 1V

pp

±20 (5.5m°) 0.04 (1Vpp)

0.00002 one, near cal-switch 1 Vpp

2 + 1 index and complementary outputs

9000

AE-053Reni

T2011-30 A

±2.3 0.022866 (1Vpp)

0.00001 one 2 + 1 index and complementary outputs

15744

AE-068Signum d=150 mm 1.5 0.000076271 1.5E-5 yes

RS 422 differential + 1 Vpp

2 + 1 index and complementary outputs

23600

AE-070RGR+RGH24B 0.0000573 0.0000573 yes

RS 422 differential 2 + 1 index and complementary outputs

31453

AE-080Signum d=57mm ±4 0.04 (1Vpp)

0.00002 yes

1 Vpp

2 + 1 index and complementary outputs

9000
