Pioneer K-067 CYCLO COMPUTER SENSOR UNIT L User Manual
Pioneer Corporation CYCLO COMPUTER SENSOR UNIT L
Pioneer >
User Manual
![](/img.php?id=1887337&img=bg1.png)
English Deutsch Français
Nederlands
Italiano Español
Important Information for the User
Information importante pour l'utilisateur
Pedaling Monitor Sensor
SGY-PM900H79
![](/img.php?id=1887337&img=bg2.png)
2
Declaration of Conformity with regard to the R&TTE Directive 1999/5/EC
Manufacturer:
PIONEER CORPORATION
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi,
Kanagawa 212-0031, JAPAN
EU Representative’s:
Pioneer Europe NV
Haven 1087, Keetberglaan 1,
B-9120 Melsele, Belgium/Belgique
http://www.pioneer.eu
English:
Hereby, Pioneer, declares that this
[*] is in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
Suomi:
Pioneer vakuuttaa täten että [*]
tyyppinen laite on direktiivin 1999/5/
EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen
mukainen.
Nederlands:
Hierbij verklaart Pioneer dat het
toestel [*] in overeenstemming is met
de essentiële eisen en de andere
relevante bepalingen van richtlijn
1999/5/EG
Français:
Par la présente Pioneer déclare
que l’appareil [*] est conforme aux
exigences essentielles et aux autres
dispositions pertinentes de la directive
1999/5/CE
Svenska:
Härmed intygar Pioneer att denna
[*] står I överensstämmelse med de
väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår
av direktiv 1999/5/EG.
Dansk:
Undertegnede Pioneer erklærer
herved, at følgende udstyr [*]
overholder de væsentlige krav og
øvrige relevante krav i direktiv 1999/5/
EF
[*] SGY-PM900H79, SGY-PM900H79 L
![](/img.php?id=1887337&img=bg3.png)
3
Deutsch:
Hiermit erklärt Pioneer, dass sich
dieses [*] in Übereinstimmung mit den
grundlegenden Anforderungen und
den anderen relevanten Vorschriften
der Richtlinie 1999/5/EG bendet".
(BMWi)
Ελληνικά:
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Pioneer
ΔΗΛΩΝΕΙ ΟΤΙ [*] ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ
ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ
ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ
Italiano:
Con la presente Pioneer dichiara
che questo [*] è conforme ai requisiti
essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva
1999/5/CE.
Español:
Por medio de la presente Pioneer
declara que el [*] cumple con los
requisitos esenciales y cualesquiera
otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE
Português:
Pioneer declara que este [*]
está conforme com os requisitos
essenciais e outras disposições da
Directiva 1999/5/CE.
Čeština:
Pioneer tímto prohlašuje, že tento [*]
je ve shodě se základními požadavky
a dalšími příslušnými ustanoveními
směrnice 1999/5/ES
Eesti:
Käesolevaga kinnitab Pioneer seadme
[*] vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele
sätetele.
Magyar:
Alulírott, Pioneer nyilatkozom, hogy
a [*] megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC
irányelv egyéb elõírásainak.
Latviešu valoda:
Ar šo Pioneer deklarē, ka [*] atbilst
Direktīvas 1999/5/EK būtiskajām
prasībām un citiem ar to saistītajiem
noteikumiem.
![](/img.php?id=1887337&img=bg4.png)
4
Lietuvių kalba:
Šiuo Pioneer deklaruoja, kad šis [*]
atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Malti:
Hawnhekk, Pioneer jiddikjara li dan
[*] jikkonforma mal-ħtiġijiet essenzjali
u ma provvedimenti oħrajn relevanti li
hemm d-Dirrettiva 1999/5/EC
Slovenčina:
Pioneer týmto vyhlasuje, že [*]
spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice
1999/5/ES.
Slovenščina:
Pioneer izjavlja, da je ta [*] v skladu
z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 1999/5/
ES.
Română:
Prin prezenta, Pioneer declara ca
acest [*] este in conformitate cu
cerintele esentiale si alte prevederi
ale Directivei 1999/5/EU.
български:
С настоящето, Pioneer декларира,
че този [*] отговаря на основните
изисквания и други съответни
постановления на Директива
1999/5/EC.
Polski:
Niniejszym Pioneer oświadcza,
że [*] jest zgodny z zasadniczymi
wymogami oraz pozostałymi
stosownymi postanowieniami
Dyrektywy 1999/5/EC
Norsk:
Pioneer erklærer herved at utstyret [*]
er i samsvar med de grunnleggende
krav og øvrige relevante krav i direktiv
1999/5/EF.
Íslenska:
Hér með lýsir Pioneer yr því að [*] er
í samræmi við grunnkröfur og aðrar
kröfur, sem gerðar eru í tilskipun
1999/5/EC
Hrvatski:
Ovime tvrtka Pioneer izjavljuje da je
[*] u skladu osnovnim zahtjevima i
ostalim odredbama Direktive 1999/5/
EC.
![](/img.php?id=1887337&img=bg5.png)
English
5
Important Safety Information
WARNING
Always consult your physician •
before beginning or modifying your
exercise routine.
The device is not medical devices, •
and could suffer from interference
from external electrical sources.
WARNING
Follow these guidelines as well to
ensure safe Cycling:
Always use your best judgement, •
and operate your bicycle in a safe
manner. Do not become distracted
by the device while riding, and
always be fully aware of your
surroundings. Minimize the amount
of time spent viewing the device
screen while riding.
While riding, never attempt to •
adjust settings or access functions
that require more than a quick
glance. Pull over and come to a
complete stop in a safe location off
the road before making settings or
adjustments.
Secure your bicycle in a safe place •
to switch modes or replace the
battery.
The bicycle may fall causing an
injury.
Pioneer Pedaling Monitor Sensor is not a medical device.
![](/img.php?id=1887337&img=bg6.png)
6
English
Important Safety Information
After switching modes or replacing •
the battery, install the transmitter
cover securely and tighten the screw
with the specied torque.
If it is not installed securely, it may
fall causing an accident or injury.
Do not leave small parts such as •
screws or the battery in an area
that infants can reach to prevent
accidental swallowing. If you think
this may have happened, consult
with a doctor immediately.
Before riding your bicycle, make •
sure that the device is installed
securely in an area that does not
disturb riding operations. Make
especially sure that cable ties are
secure and all screws are tightened
as any loose components could
cause the device to fall causing an
accident or injury.
Consult with the dealer if there is
malfunction such as looseness.
Do not leave the device in places •
that are exposed to direct sunlight,
high temperature, high humidity,
or a lot of dust as it may cause the
device to malfunction.
Never dismantle, refurbish, or repair •
the device or any attached parts as
it could cause electrical shock or the
device to malfunction.
Do not use this device if any unusual •
conditions exist such as penetration
by a foreign object, water
submersion, smoke is detected, or
an unusual odor is detected.
Stop using the device immediately
and have it repaired.
This device communicates using •
ANT+ radio communication. Do
not use in areas that forbid the
use of electronic devices such as
hospitals or airplanes as unintended
interference from this device could
cause serious accidents.
![](/img.php?id=1887337&img=bg7.png)
English
7
Important Safety Information
CAUTION
Do not put this device in water or •
wipe with detergents, chemical
duster, or volatile medicines such
as benzine or thinner as they may
cause the device to malfunction.
Thoroughly remove any excess •
bicycle lubricants or cleaners from
this device as they could cause an
unexpected malfunction.
Do not allow overly violent impacts •
on this device as it may cause it to
malfunction.
Do not wash this device with a high •
pressure water sprayer as water may
penetrate into the device causing it
to malfunction.
WARNING
Batteries (battery pack or batteries
installed) must not be exposed to
excessive heat such as sunshine, re
or the like.
“Perchlorate Material - special handling
may apply.
See
www.dtsc.ca.gov/hazardouswaste/
perchlorate.
(Applicable to California, U.S.A.)”
WARNING
Store small parts out of reach of
children and infants. If accidentally
swallowed, contact a doctor
immediately.
Radio wave caution
This unit uses a 2.4 GHz radio wave •
frequency, which is a band used by
other wireless systems (Microwave
ovens and Cordless phones, etc.).
In the event noise appears in
your television image, there is
the possibility this unit (including
products supported by this unit)
are causing signal interference
with the antenna input connector
of your television, video, satellite
tuner, etc. In this event, increase the
distance between the antenna input
connector and this unit (including
products supported by this unit).
![](/img.php?id=1887337&img=bg8.png)
8
English
Important Safety Information
[For American Users]
IMPORTANT NOTICE
THE MODEL NUMBER AND SERIAL NUMBER OF THIS EQUIPMENT ARE ON
THE BOTTOM.
KEEP WARRANTY CARD IN A SAFE PLACE FOR FUTURE REFERENCE.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This Equipment may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment has very low levels of RF
energy that are deemed to comply without testing of specic absorption ratio (SAR).
Information to User
Alterations or modications carried out without appropriate authorization may
invalidate the user’s right to operate the equipment.
WARNING: Handling the cord on this product or cords associated with accessories
sold with the product may expose you to chemicals listed on proposition 65 known
to the State of California and other governmental entities to cause cancer and birth
defect or other reproductive harm.
Wash hands after handling.
FCC Part 15.19 warning statemnet
FCC Part 15.21 warning statemnet
![](/img.php?id=1887337&img=bg9.png)
English
9
Important Safety Information
[For Canadian Users]
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accep ter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment and meets RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment has very low levels of RF energy that are deemed
to comply without testing of specic absorption ratio (SAR).
Cet équipement est conforme aux limites d’exposition aux rayonnements
énoncées pour un environnement non contrôlé et respecte les règles d’exposition
aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet
une énergie RF très faible qui est considérée conforme sans évaluation du débit
d’absorption spécique (DAS).
The ANT+ antenna cannot be removed (or replaced) by user.
L'antenne ANT+ ne peut pas être supprimé (ou remplacé) par l'utilisateur.
![](/img.php?id=1887337&img=bga.png)
10
English
Important Safety Information
[For European Users]
Information for users on collection and disposal of old equipment and used
batteries
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical and
electronic products and batteries should not be mixed with
general household waste.
For proper treatment, recovery and recycling of old
products and used batteries, please take them to applicable
collection points in accordance with your national
legislation.
By disposing of these products and batteries correctly,
you will help to save valuable resources and prevent
any potential negative effects on human health and the
environment which could otherwise arise from inappropriate
waste handling.
For more information about collection and recycling of
old products and batteries, please contact your local
municipality, your waste disposal service or the point of
sale where you purchased the items.
These symbols are only valid in the European Union.
For countries outside the European Union:
If you wish to discard these items, please contact your
local authorities or dealer and ask for the correct method of
disposal.
Symbol for
equipment
Pb
Symbol examples
for batteries
![](/img.php?id=1887337&img=bgb.png)
English
11
Important Safety Information
Operating Environment
Operating environment temperature and humidity:
-10 °C to +50 °C (+14 °F to +122 °F); less than 85 %RH (cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in locations exposed to high
humidity or direct sunlight (or strong articial light)
![](/img.php?id=1887337&img=bgc.png)
12
English
Before Use (Important)
Safety Precautions
DANGER
About the Device
Do not throw the device, strike it with •
a hammer or other object, or pierce
this device in any way.
Do not use or leave the device in •
places where it will be exposed to
high temperatures, such as near a
stove or inside a closed automobile.
Always keep the device out of the •
reach of infants and small children.
WARNING
About the Device
Do not use this device if it emits an •
unusual odor, heats up, changes
color or shape, or if any other
abnormalities occur during use,
while recharging or while placed in
storage.
Do not place the device in a •
microwave oven or expose it to high
pressure, since the device may
overheat, rupture, or ignite.
Keep the lithium battery out of the •
reach of children. Should battery be
swallowed, immediately consult a
doctor.
![](/img.php?id=1887337&img=bgd.png)
English
13
Before Use (Important)
CAUTION
Do not recharge disassemble, heat •
or dispose of the battery in re.
Use a CR2032 (3 V) lithium battery •
only. Never use other types of
battery with this unit.
Do not handle the battery with •
metalic tools.
Do not store the battery with metallic •
materials.
When disposing of used batteries, •
please comply with governmental
regulations or environmental public
institutions rules that apply in your
country or area.
Always check carefully that you are •
loading battery with its (+) and (-)
poles facing in the proper directions.
CAUTION
About Water-resistance
Observe the following precautions
in regard to the device’s water-
resistant.
Do not place the unit in water.•
Do not expose the unit to a large •
amount of water.
Do not expose to rain for long •
periods of time.
Do not pour or place in warm •
water or water containing soap or
detergent.
Do not use on or near the beach.•
This could cause rust. If exposed
to seawater, thoroughly wipe off
the moisture immediately with a dry
cloth.
If the rubber packing becomes •
soiled, wipe it clean with a dry, clean
cloth.
Do not open the transmitter cover •
in humid environments in which
the device could get exposed to
water.
![](/img.php?id=1887337&img=bge.png)
14
English
Before Use (Important)
If the device is exposed to a large •
amount of water or moisture,
immediately wipe it down with a
dry cloth.
Only open or close the transmitter
cover after having completely wiped
off any moisture. Be sure your hands
are completely dry and you are in an
environment where the unit will not
get exposed to moisture again.
If this device is exposed to water, •
thoroughly dry all crevices on the
units body where water may have
permeated.
This unit has been designed with water-
resistance equivalent to standards
IPX6(*) as dened by the International
Electrotechnical Commission (IEC).
Malfunctions due to water damage
caused by improper use are not
covered by the product warranty, even
if they occur within the warranty period.
Depending on conditions of use, •
the water-resistant features are
not necessarily guaranteed even
during the warranty period.
* IPX6: Protection against strong jet of
water
We recommend you have the rubber
gaskets in the transmitters of the
sensors replaced periodically. (This is a
paid service.)
![](/img.php?id=1887337&img=bgf.png)
![](/img.php?id=1887337&img=bg10.png)
©2012 PIONEER CORPORATION.
All rights reserved.
<Z-912-020-01> EU
PIONEER CORPORATION
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi,
Kanagawa 212-0031, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California,
90801-1540, U.S.A.
TEL: (800) 421-1404
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele,
Belgium/Belgique
TEL: +32 (0)3 570 05 11
http://www.pioneer.eu
Visit www.pioneer.eu to register your product.
Visitez www.pioneer.eu pour enregistrer votre appareil.
Si prega di visitare il sito www.pioneer.eu per registrate il prodotto.
Visite www.pioneer.eu para registrar su producto.
Zum Registrieren Ihres Produktes besuchen Sie bitte www.pioneer.eu.
Bezoek www.pioneer.eu om uw product te registreren.
