● Follow the manual to properly install this product on the car. Using an installation method or parts
other than the one specified may result in an accident or injury. We are not responsible for such
accidents or injuries.
● To ensure proper operation, read the manual before use. Keep the manual at hand after reading.
● Check the compatibility of your smartphone/tablet (hereafter, terminal). Also consult the terminal
manual before use.
Manual
Sensor Unit
Precautions (please follow)
● To ensure proper operation, read the
“Precautions” thoroughly before use and keep it
at hand after reading.
● Follow the precautions described here to prevent
any harm to users and others and damage to
property from occurring.
● The following sections describe the level of harm
and damage which may occur when this product
is used incorrectly by not following the described
precautions.
This section describes the risks of death or
serious injury that are imminent when this
product is used incorrectly.
This section describes the risks of death
or serious injury that may occur when this
product is used incorrectly.
This section describes the risks of minor injury
and property damage that may occur when this
product is used incorrectly.
● The following signs describe the precautions that
you should follow.
This means “prohibited” (Do Not).
This means do not disassemble.
This means do not use around water or wet it.
This means do not handle with wet hands.
•
•
•
•
•
•
•
This means, “must follow the instruction” (Has
to be carried out).
This means to unplug the Vehicle Power
Charger from the power outlet.
•
•
-2-
WARNING
● Do not operate a terminal while driving.
Do not operate complex functions or watch
images that require you to look at the
terminal screen for a long time while driving.
Park the car in a safe spot to operate such
functions. Also, do not gaze at the screen
while driving.
You might not be able to look ahead carefully and
may result in a traffic accident.
● Do not use, store and leave this product
near fire, in direct sunlight and in a high
temperature environment such as in a sun-
heated vehicle.
It may result in a fire, burn or injury.
● Do not place in a cooking appliance such
as a microwave oven or in a high-pressure
container.
It may result in a fire, burn, injury or electric
shock.
● Do not disassemble or remodel.
It may result in a fire, burn, injury or electric
shock.
● Do not wet with water, drinking water or
pet’s urine, etc.
It may result in a fire, burn, injury or electric
shock.
● Do not apply strong force or impact, or do not
throw.
It may result in a fire, burn, injury or electric
shock.
● Do not bring a charging terminal and
external connecting terminal into contact
with electrically-conductive foreign objects
(a piece of metal or pencil lead, etc.). Also,
do not insert them inside this product.
It may result in a fire, burn, injury or electrical
shock.
● Do not install in a place where it interferes
with driving or is detrimental to the safety of
a passenger.
Installation of this product in places where it
interferes with driving such as places that
obstruct the visibility or ancillary safety equipment
such as an airbag or near brake pedal may result
in a traffic accident, injury or damage.
● Do not place under direct sunlight for a long
period of time.
It may deform or discolor the cabinet and/or
result in a fire.
A part of this product may be heated and may
cause a burn.
● Do not use damaged cords and cables.
It may result in a fire, burn or electric shock.
● Do not touch the cord of an adaptor or
cigarette-lighter socket with wet hands.
It may result in a fire, burn or electric shock.
● Perform the following actions immediately
when abnormalities such as unusual smell,
heat, change in color or shape occur while
using, charging or storing this product.
Unplug the Vehicle Power Charger from a
cigarette-lighter socket.
Failure to do so may result in a fire, burn, injury or
electric shock.
● Install securely.
If this product falls due to harsh braking, it may
result in a traffic accident or injury.
● Should liquid such as water get into
this product, unplug the Vehicle Power
Charger from the cigarette-lighter socket
immediately.
Failure to do so may result in a fire, burn or
electric shock.
● Unplug the Vehicle Power Charger from the
cigarette-lighter socket before cleaning.
Failure to do so may result in a fire, burn or
electric shock.
CAUTION
● Do not place this product on an unstable
surface such as on the top of a loose pedestal
or a tilted place.
It may result in an injury if it falls.
● Do not keep this product wherever there
is a lot of moisture and dust or in a high
temperature environment.
It may result in a fire, burn or electric shock.
● The Vehicle Power Charger is for use only in
vehicles with a negative ground. Do not use
in vehicles with a positive ground.
It may result in a fire, burn or electric shock.
● Do not short a charging terminal while
connected to the cigarette-lighter socket. Also,
do not bring a charging terminal into contact
with body parts such as hands and fingers.
It may result in a fire, burn or electric shock.
● Do not place heavy items on cords and cables.
It may result in a fire, burn or electric shock.
•
-3-
● Be careful that it does not catch fire.
Turn off the power and do not use this product in
a place (such as gas stations) where inflammable
gases (such as propane and gasoline) are
generated. Otherwise, it may in turn lead to the
product catching fire or exploding.
● Only use this product in vehicles.
Do not use this product other than in vehicles.
Otherwise, it may result in electric shock or
injury. Do not use this product in ships, aircraft,
motorcycles, or while mountain climbing.
Positional errors can occur or maps cannot be
displayed, and may result in accidents. Also, it
may result in overheating, burst or ignition due to
salt damage, etc.
● Do not continue using when it is broken.
Do not use this product when there are
malfunctions such as the LED not lighting.
Contact your retailer. If you continue using with
malfunctions, it may result in an accident, fire or
electric shock.
● Do not cut cables short.
Cables may come with a fuse. Do not cut them
short. The protecting circuit may fail and it may
result in a fire.
● Do not branch wires.
Do not branch wires from one cable.
If you use a power source by branching wires,
cable will be heated and it may result in a fire or
electric shock.
● Keep this product out of reach of small children.
It may in turn lead to accidental ingestion or
result in injury.
● When unplugging the Vehicle Power Charger,
hold and pull the adaptor, not pulling the
cord of the adaptor.
Failure to do so may result in a fire, burn or
electric shock.
● Use this product with the specified power
source and voltage.
DC adaptor: DC12V (vehicles with negative
ground only)
● Should the fuse of the accompanying Vehicle
Power Charger blow out, make sure to use a
specified fuse.
Failure to do so may result in a fire, burn or
electric shock. Refer to this manual to confirm
the specified fuses.
● Wipe the dust off the Vehicle Power Charger.
Failure to do so may result in a fire, burn or
electric shock.
● Unplug the Vehicle Power Charger from the
cigarette-lighter socket when you do not use
the product for a long period of time.
Failure to do so may result in a fire, burn or
electric shock.
● Should liquid such as water get into this
product, unplug the Vehicle Power Charger
from the cigarette-lighter socket immediately.
Failure to do so may result in a fire, burn or
electric shock.
● Unplug the Vehicle Power Charger from the
cigarette-lighter socket to clean this product.
Failure to do so may result in a fire, burn or
electric shock.
● Depending on certain physical or medical
conditions one may have, itchiness, rash
or eczema can occur. When abnormalities
occur, discontinue the use of this product
and consult with your doctor.
● When you use the route guide of the
navigation, follow the actual traffic rules.
Precautions for Handling
● This product can increase in temperature
depending on the environment and usage. Be
cautious of an increase in temperature, it may in
turn lead to an injury or accident.
● Set the volume of the terminal at such a level that
you can hear the noise from outside the vehicle
while driving. If you drive when you cannot hear
noise from outside, it may in turn lead to an
accident.
● Use this product with appropriate screen
brightness while driving.
● Set up this product with the cables tied together
with the Cable Clamper (a promotional sample)
to allow for unencumbered driving operation. It is
dangerous and may result in an accident when a
cable wraps around the steering wheel, shifter or
brake pedal.
● Place wires in such a manner that cords will not
be caught in moving parts of the vehicle such
as the vehicle body, screw parts and seat rails.
It might cause the breaking of wires or short
circuits and may in turn lead to an accident,
electric shock or fire.
-4-
● Install this product without the cable touching
any metal parts of the vehicle. If there is a
possibility that it might touch any metal parts,
wrap the touching part with protective tape to
protect the covering of the cable. Otherwise, it
may result in a fire or electric shock.
● The terminal can break from high/low
temperature or vibration. Do not install this
product in such a place that can cause damage.
● Remove this product after use.
● Be aware that depending on the type vehicle you
have, you may not be able to install this product.
● Do not place this product in direct contact
with hot air or cold air from air conditioning.
It may result in deformation or malfunction.
● Read the manual attached to the terminal
thoroughly.
● Do not place the product near the air
conditioning outlet of your vehicle. The
sudden temperature change will cause dew
condensation and the internal part will be eroded,
which may result in malfunction.
● Avoid extreme high or low temperatures. Use this
product at a temperature between 0-45 degrees
Celsius.
● Using this product near general electronics
such as phones, TVs or radios may cause a
negative influence. Use this product as far as
possible from these electronics.
● When connecting external connection
equipment to an external connecting
terminal, do not insert it at an angle or do
not pull it when inserted. It may result in
malfunction or damage.
● It is not abnormal if the terminal becomes
warm while in use or in charging. You can
continue using the product.
● Charge the terminal in an environment where
the surrounding temperature is within the
appropriate range stated in the manual.
● When you charge this product using the
Vehicle Power Charger, do not use it while
the engine is off. It may result in depletion of
the car battery.
● Do not apply a strong impact. Do not
deform the charging terminal. It may result in
malfunction.
● Be cautious when using this product while
driving a car.
Holding and using a cell phone while driving is
subject to penal provisions. However, that will not
apply when such use is unavoidable: aiding the
injured and/or sick or maintaining public safety.
Precautions for Use
• A place such as the dashboard of an vehicle
tends to become hot due to direct sunlight.
The inside of a vehicle can also become hot
under direct sunlight. When using the terminal
attached to the Cradle, use it within the ranges of
temperature and moisture stated in the manual.
When this product is used, kept and left under
high temperature, it may result in deformation
or malfunction of the device, or leakage,
development of heat, bursting, igniting, or
degradation of performance or life of the battery
pack.
A part of the case can also become hot, and it
may result in a burn.
• Do not use, keep or leave under the environment
where the sun is very strong and do not keep the
terminal under direct sunlight.
When used, kept and left for a long time, the
device will be hot and it may result in deformation
and malfunction of the device, or leakage,
development of heat, bursting, igniting, or
degradation of performance or life of the battery
pack. A part of the case can also become hot,
and it may result in a burn.
• When installing the terminal to the Cradle, stow
it securely so it does not fall in case of sudden
acceleration, sudden braking or driving through a
curve or rough road. The device falling may result
in an accident or injury, or may in turn lead to
damage to the terminal and surrounding objects.
• This product may not be used in a vehicle with
glass such as metallic glass (heat reflective
glass) that does not let radio waves through
because GPS signals cannot be received inside
of the vehicle. Check with your car manufacturer/
dealership.
• Carry this product with care. When too much
force is applied, the internal base will break and
it may result in malfunction. Do not place the
product under heavy objects in your bag. It will
not be eligible for warranty even if there is no
damage to the outside of the product.
• Do not wrap cables and cords around the plug. It
may result in an electric shock, ignition or fire.
• Do not leave this product on top of the dashboard.
It may result in malfunction.
• Be careful when continuing to use the terminal
for a long period of time while charging. The
temperature of the terminal may rise and may
cause deterioration of the battery pack.
-5-
Driving safety
• It is very dangerous when a driver operates the
terminal while driving because he/she will be
distracted while looking at the screen, and it may
result in an unexpected serious accident. Park
the vehicle in a safe place first when the driver
needs to operate the terminal.
• Set the volume of the terminal at such a level that
you can still hear noise from outside the vehicle
while driving. Driving without hearing noise from
outside may in turn lead to an accident.
• Be aware that listening to the sounds of the
terminal at a high volume which stimulate your
ears continuously for a long period of time, may
in turn lead to a negative effect on your hearing.
Positioning immediately after
power activation
• This product displays the current location by GPS
positioning (→refer to “navigation mechanism”).
It may take approximately 5 minutes to figure
out the accurate current location (until GPS
positioning is completed) immediately after
power activation.
Environmental conservation
• To protect the environment, avoid excessive
idling while parking. Excessive idling leads to the
battery running out.
Others
• Install the Sensor Unit at the defined place by
applying the accompanying Hook and Loop
Fasteners (a promotional sample). Do not put
any stickers on the main unit other than these
fasteners. Otherwise, it may result in malfunction
or damage.
• We do not guarantee that this product will fit well
with specific purposes of our customers.
Compatible terminals for this
product
• Refer to the DoCoMo website for the latest
information.
• The method of operation can be different
depending on the models and versions of
software.
Notice
• The terminal may be used by an individual to
reproduce materials so long as such use
is limited to reproduction of non-copyrighted
materials or materials you are legally permitted to
reproduce. Infringement of copyright is prohibited
by law.
• Be careful when continuing to use the terminal
for a long period of time while charging.
The battery charge of the terminal can stop
working. In such a case, remove the terminal
from the Cradle, making sure the temperature
has gone down, and then start charging again.
Touching the hot part of the device may result in
a burn.
• Use the terminal that is fully charged.
The battery charge can stop when you
use application while charging it in case the
remaining battery charge is low.
• Read the terminal manual for details on how to
handle the terminal.
-6-
Components
Sensor Unit × 1
Sensor Unit Power Cable (3 m) × 1
Vehicle Power Charger × 1
Smartphone/Tablet Power Cable
(1.3 m) (promotional sample) × 1
USB cable for software update
(35 cm) (promotional sample) × 1
Hook and loop fasteners
(promotional sample) (2 pcs.)
Cable Clamper (promotional
sample) (2 pcs.)
Manual (this booklet) × 1
Caution
• This product is for vehicle installation only. Do not
use this product outside of the vehicle except for
updating the software.
• Only use the USB cable for software updates (a
promotional sample).
-7-
Capability of this product
This product has a built-in in-car GPS receiver,
antenna, acceleration sensor and gyro sensor.
With these features, the terminal can be used for
high-precision full-fledged navigation.
Caution
• To use this product for navigation, you need to
have a compatible smartphone and application.
Eco-illumination feature
This feature supports eco-friendly driving by
comparing the fuel consumption of previous driving
and the current fuel consumption. When the
current fuel consumption is better than the previous
consumption records, the green LED of the Sensor
Unit lights up. When the current fuel consumption
is worse than the previous consumption records,
the red LED of the Sensor Unit lights up.
Caution
• Use the information regarding the fuel efficiency
which this product displays as a guide.
• When there are no past driving records (i.e.,
factory default, when previous fuel consumption
was not recorded normally, or when eco status
was initialized using the terminal), this feature
may not work normally.
• You need to have a supporting application in
order to initialize the eco status.
Names and functions of Parts
Names of parts
Sensor Unit
Eco illumination
USB connecting terminal
for software updates
Hook and loop fasteners
connecting terminal
Bluetooth connection
display illumination
Vehicle Power Charger
Smartphone/Tablet Power
Cable connecting terminal
Sensor Unit Power Cable
connecting terminal
-8-
Installation in the vehicle
Operating precautions
(At the time of installation)
Please be aware that we are not responsible for
any failures that arise from users not following the
precautions stated in the Manual. Use this product
appropriately. The warranty cannot be granted when
users do not handle the product properly or the
product is used inappropriately beyond common
sense such as applying too much force.
Precautions
• Remove and keep this product avoiding direct
sunlight, high temperature and high moisture
after use. Do not leave this product on the
dashboard. It may in turn lead to deformation.
• Wipe any dirt from the installation site, and install
the product after the site has become dry.
• Install the product on places such as the
following:
* On the dashboard where it is flat without
unevenness.
* A place where the vibration is not too intense,
or a stable place.
* A place which does not obstruct the button
operation in the vehicle.
• Do not install the product in the following places:
* Windshield.
* A place where rain tends to hit.
* A place where baggage can contact the
product.
* A place where hot and cold air from the air
conditioning can directly blow on the product.
• Do not paint the Sensor Unit. Performance of the
built-in GPS may be lowered.
• Some vehicles with glass such as metallic glass
(heat reflective glass) that does not let radio
waves through do not let the signals from GPS
satellite through. In this case, change the position
of the product installation on the dashboard.
-9-
2 Install using the accompanying
Hook and loop fasteners
(a promotional sample).
Stick it on the Sensor Unit in such a way that the
reset button on back side of the Sensor Unit is
not covered. Refer to the “how to delete paring
information” section (→p.17) for the location of
the reset button.
Hook and loop fasteners
(promotional sample)
(harder one)
Sensor Unit
Hook and loop fasteners
(promotional sample)
(softer one)
Hook and loop fasteners (promotional sample)
Make sure to use these fasteners.
Remove the protective stickers on the
back side, and stick them on two
dips on the back side of the
Sensor Unit.
Cable Clamper (a promotional sample)
Bundle and draw the cord using the Cable
Clamper (a promotional sample) at several
places,
Installation method (Sensor Unit)
Precautions
• Refer to the “checking Cradle information”
section (→p.17), and install the Sensor Unit at
a place where it can receive GPS information
properly.
• For improvement of the self-positioning accuracy,
install the Sensor Unit as described below.
15° 15°
20°
20°
Traveling direction of the vehicle
arrow sign (▲)
Travelling direction of the vehicle
• Sensor Unit has a built-in GPS antenna. Install
the Sensor Unit at a level site where GPS satellite
signals are not intercepted.
5°
5°
1 Connect the included Sensor
Unit Power cable to the Sensor
Unit.
Sensor Unit Power Cable connecting
terminal
-10-
Connecting Vehicle
Power Charger
Warning
• Use the accompanying Vehicle Power Charger to
connect.
• The accompanying Vehicle Power Charger is
intended for use only with this product. Never use
the Vehicle Power Charger for other products.
• Check that all the terminals are securely
connected before use.
Precautions
• If your type of vehicle is one for which this
product’s power will not be off even when the key
position of the vehicle is turned to off, unplug the
Vehicle Power Charger when this product is not
in use. If you forget to unplug, it may result in
battery depletion.
• Start the engine after installing this product.
• Bundle cables using the Cable Clamper (a
promotional sample) so that they will not interfere
with driving.
• Depending on the setting of LEF for the
application, the LED of the Sensor Unit
sometimes does not light up even when the
power of the Sensor Unit is turned on.
• Hold the connector and pull the cable to remove.
If you pull only the cable, it may break off.
1 Connect each cable to the
Vehicle Power Charger.
Smartphone/Tablet Power
Cable connecting terminal
Sensor Unit power cable
connecting terminal
Sensor Unit Power Cable connecting terminal cover
• Open and pull out the cover.
2 Connect the Vehicle Power
Charger to the cigarette-lighter
socket.
Terminal
Sensor Unit
Vehicle Power
Charger
3 Start the engine.
Eco illumination of the Sensor Unit and the
LED on the USB terminal of the Vehicle Power
Charger light up to tell you the power is now on.
-11-
Terminal setting
Before using the Cradle and terminals together, you
need a Bluetooth connection.
Precautions
• When the Cradle and terminals are connected via
Bluetooth, avoid operating (such as scanning,
paring and connecting) the Bluetooth with
other equipment. The connection may become
unstable.
• You need to have a supporting application to
set the Bluetooth connection. (→Refer to the
“capability of this product” section on page 7.)
How to connect
• The following procedures and the screen display
are just examples. The connecting methods
of Bluetooth and screen displays vary among
terminals.
Read manuals for terminals.
1 Display the Cradle setting menu.
2
Select “Cradle connection setting.”
3 Select “search Cradle.”
Select Bluetooth under the “Bluetooth setting”
section when Bluetooth is not selected.
4 Select “Sensor Unit” under
“Bluetooth setting.”
Begin pairing.
• Perform search when pairing is not displayed on
the terminal list.
5 Select “accept” or “pair” under
“Bluetooth pairing request
screen.”
Blue LED blinks for three seconds when the
pairing is completed. The message “Pairing
completed” is displayed on the terminal screen.
6 Tap the back key to go back to
“Cradle setting.”
7 “Connecting completed” is
displayed on the screen showing
the paired “Sensor Unit” from
the list under “Cradle setting.”
Blue LED of the Sensor Unit lights up at the
same time.
• The Cradle can pair information for up to 5
terminals. When you add the information of a
new terminal for paring while there are already 5
terminals registered, the oldest information will
be overwritten.
How to delete paired information
Precautions
• Information of all the terminals already paired will
be reset.
• The reset button is located at the back side of the
Cradle.
• Press the reset button using the tip of a pen.
• Remove the terminal from this product, deactivate
the Bluetooth connection, and then press the
reset button.
Reset button
1 Press and hold the reset button
for more than 5 seconds while
the power of this product is on.
The Blue LED blinks 3 times when resetting is
completed.
Checking sensor information
You can check the reception status on the terminal.
Precautions
• When using this function for the first time, the
Cradle connection setting needs to be set for
positioning information communication (refer to
the “terminal settings” section on page 11).
• You need to have a supporting application to
check reception status.
-12-
1 Display the Sensor Setting
menu.
2 Select “Sensor Info.”
Reception status
GPS positioning status is displayed. It may take a
few minutes to complete positioning.
No positioning: Positioning cannot be
completed.
2D positioning: Positioning is completed.
3D positioning: High-accuracy positioning is
completed.
When positioning cannot be completed in a place
with an unobstructed view, your vehicle may have
glass that does not let radio waves through.
Distance and direction learning status
Status of distance and direction learning is
displayed. “Learning completed” is displayed when
learning is completed, and “learning not completed”
is displayed when learning is not completed.
Initialization of sensor learning
Use a supporting application to operate.
1 Display the Sensor Setting menu.
2
Select “Sensor Learning Initialize.”
Software update
Software update of the Cradle can be done by
connecting to a PC. Refer to the DoCoMo website
for how to update and precautions.
• It is posted only when software update is needed.
What to do when you
suspect a malfunction
If the symptom cannot be improved after checking
the check-items for the symptoms, contact the
“malfunction inquiries” noted on the manual or
“product malfunction supporting contacts”
authorized by DoCoMo.
Power source
[Symptoms] Power of the Sensor Unit cannot
be turned on.
Check-items
• If this product is left in a place with a high
temperature, wait until the temperature of the
product goes down.
• Re-connect the Smartphone/Tablet Power Cable
(a promotional sample).
• Check the accompanying Vehicle Charger to see
whether the fuse is blown out or not. When the
fuse is blown out, replace it with a new one (refer to
the “how to change the fuse” section on page 19).
Bluetooth functions
[Symptoms] Cannot connect with a terminal/
cannot find by a search.
Check-items
• Device registration has to be done from the
terminal end. Before you delete the registered
devices and re-register devices, reset the Cradle
and delete registered devices from the terminal.
Charging
[Symptoms] Cannot charge the product.
Check-items
• Is the battery pack of your smartphone properly
installed?
• When you make phone calls or use
communication and other functions while
charging the terminal, the temperature of the
terminal goes up and the charging-light may
blink. In that case, wait until the temperature of
the terminal goes down before charging it again.
• When multiple applications are launched or the
Wi-Fi connection setting is ON, they consume
more power than the terminal can charge, and
therefore, charging may not progress.
-13-
1 Remove the cap of the Vehicle
Power Charger while holding
the groove of the cap.
Use a tool like tweezers to hold the groove of the
cap. Turn the Vehicle Power Charger to remove
the cap.
Terminals
Cigarette-lighter of
the vehicle
Fuse (3 A/ 250 V)
Be careful not to lose it when it has
been removed.
Cap
Loosen it by turning
counterclockwise.
Trademark and copyright
● Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
● The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by PIONEER
CORPORATION is under license. Other
trademarks and trade names are those of their
respective owners.
In that case, quit unnecessary applications,
turn off the Wi-Fi setting, or adjust the screen
brightness of the terminal.
• Is the Vehicle Power Charger connected to the
cigarette-lighter socket properly?
• Are the Smartphone/Tablet Power Cable (a
promotional sample) and the terminal set
properly?
Navigation
[Symptoms] The mark showing the position of
the vehicle is not aligned.
Check-items
• Check the position of the Sensor Unit installation.
(Refer to the “Installation method [Sensor Unit]”
section on page 9.)
• Initialize the sensor learning, and perform
learning again. (→Refer to the “Initialization of
sensor learning” section on page 14.)
• The mark showing the position of the vehicle can
be misaligned, depending on driving conditions,
when GPD positioning cannot be completed
(→refer to the “accidental error” section on page
15).
How to change the fuse
If the power of this product does not turn on, check
whether the fuse of the accompanying Vehicle
Power Charger is blown off.
• Fuse (3 A/250 V) is a consumable supply. Please
purchase it from a nearby auto-supply shop when
you need to replace the fuse.
Precautions
• If the fuse is blown, replace it with a new fuse
and tighten the tip. Replace it only with a fuse
with specified capacity (3 A/250 V).
-14-
Specifications
Vehicle Power Charger
External dimensions:
approx. 39 mm (W) × 29 mm (H) × 111 mm (D)
Weight: approx. 54 g
Range of operating temperature:
0 – 45 degrees Celsius
Input voltage: DC 12 V
Output voltage: DC 5 V
Maximum output current: 2.1 A (Smartphone/Tablet
Power Cable connecting terminals)
Sensor Unit
External dimension:
approx. 76 mm (W) x 14 mm (H) x 50 mm (D)
Weight: approx. 38 g
Range of operating temperature: 0 – 45 degrees
Celsius
GPS Part
50-channel receiving system
Antenna: built-in Sensor Unit
Bluetooth
Version: Bluetooth standard Ver.2.1 compliant
Output: Bluetooth standard Power Class 2
Navigation mechanism
GPS positioning
• GPS (Global Positioning System) is a system that
receives positioning signals from GPS satellites
to position the current location.
• GPS is launched to an altitude of 21,000 km
from Earth. The positioning can be done when
receiving signals from more than three satellites.
There are 3D positioning and 2D positioning for
GPS positioning.
Types Description
3D
positioning
When you receive strong signals from
GPS satellites, 3D (latitude, longitude
and altitude) positioning can be done.
2D
positioning
When you are able to receive but
the reception status is not good,
positioning is done in 2D (latitude
and longitude). Because altitude
cannot be detected, the incidental
positioning error is slightly bigger
than in 3D.
Positioning by autonomous
navigation
• The built-in hybrid sensor determines the current
location by detecting travel distance from the
acceleration sensor and turned directions from
the gyro sensor.
The characteristics of the
positioning that combined GPS
and autonomous navigation
• The combination of current location data from
GPS and current location data from autonomous
navigation enables it to perform positioning with
higher accuracy.
• Even signals from GPS satellites cannot be
received, autonomous navigation can continue
performing positioning.
• Positioning just by autonomous navigation can
cause misalignment of the current location
display. By combining GPS and autonomous
navigation, GPS positioning can correct the
misalignment of autonomous navigation, and
therefore, the accuracy of positioning will be
higher.
-15-
Built-in sensor learning
• The Cradle is equipped with a gyro sensor and
an acceleration sensor in order to achieve higher
accuracy in positioning. To enable this function,
these sensors have to learn. Learning can take
approximately 5 – 15 minutes after starting
driving. (It varies depends on driving conditions.)
• If the learning is not completed, the mark which
shows the current location on the screen map
will stop when it cannot receive GPS information
in tunnels. (The current location of the vehicle will
be updated when GPS becomes available again.)
• This function requires re-learning when the
installation angle changes significantly or
previous learning is cleared.
• The current location of the vehicle can be
misaligned even when learning of the built-in
sensors is completed.
Map matching
• The supporting application has to be used
together to operate the map matching function.
• Incidental errors can occur with the positioning
by GPS or autonomous navigation, and the
current location can be shown as off road. In this
case, it thinks that vehicles should drive on the
road, and the GPS corrects the current location
of the vehicle on to the nearby road. This is the
map matching function.
• A more accurate display of the current location
is possible by using the Cradle because GPS
and autonomous navigation can perform highly
accurate positioning and the map matching
function supports it at the same time.
Incidental errors
Incidental errors may become significant in the
following cases.
Incidental errors due to non-performing GPS
positioning
• GPS positioning cannot be performed when your
vehicle is in places such as the following because
the signals from GPS satellites are interrupted
and not received:
– inside of a tunnel or indoor parking lot
– under a two-layer structure highway
– an area crowded with high-rises
– an area surrounded by thick tree growth
• When GPS positioning is not working for a long
time, the current location of the vehicle can be
misaligned or stopped. Even in these cases, once
GPS signals become available again and you
continue driving for a while, the current location of
the vehicle will be corrected to the right location.
• Do not apply paint or wax to the Cradle. It may
reduce the sensitivity of the sensors or may not
be able to receive signals.
Incidental errors caused by GPS satellites
themselves
• GPS satellites are controlled by the U.S. Defense
Department and satellites themselves sometimes
deliberately send misaligned positioning data.
In this case, incidental errors of positioning may
become significant.
• When signals from fewer satellites are captured
(received), the positioning will be 2D positioning
and the incidental errors may become significant.
Other incidental errors
• When driving through Y-intersection with small
angles.
• Right after driving on a straight line or gentle
curves for a long distance.
• When tires slip on a gravel road or snowy road.
• When weaving on the road.
• When turning on a rotating platform in a parking
garage, etc.
• When a series of hairpin-curves continues.
• When roads are adjacent to each other (such as
toll way and side road)
• When repeatedly turning or changing directions
in a multistory parking garage, etc.
• When GPS positioning is not working for a long
time.
• When crossing a loop bridge.
• When driving on a newly constructed road which
is not yet reflected on the map information.
• When the vehicle is transported by ferry or car-
transporter vehicle.
• When there are repeated starts and stops at low
speed in a traffic jam.
• When driving on a street in a grid.
• When driving on a road in a facility such as a
plant and getting close to a road adjacent to that
facility.
• When starting to drive right after starting the
engine.
• When the Cradle is performing at its best
capacity due to incorrect installation or impact
from vibrations.
• When the Sensor Unit is installed while driving.
• When the installation site of the Cradle has been
changed.
-16-
Main Features
1 Eco driving support function
2 GPS antenna and Receiver
3 Gyro sensor and accelerometer built-in
4 Bluetooth® technology for data communication between this unit and smartphone
5 Charging for smartphones
1 Eco-Driving Support
This unit is equipped with an Eco-driving Support function that can be used to estimate whether you are
driving in an environmentally friendly way.
This function estimates approximate fuel mileage based on your driving, compares with your estimated
average fuel mileage in the previous trip, and indicates the results by LED.
If your current driving has better estimated fuel mileage compared with the previous trip, the Green LED
turns on.
If your driving has a lower estimated fuel mileage compared with the previous trip, the Red LED turns on.
The fuel mileage comparison is calculated while the unit turned off.
Green LED will turn on when i) this unit is used for the first time, or ii) the unit fails to store the previous
fuel mileage.
This function is an estimate only and may not reflect actual driving fuel mileage.
CAUTION
Pioneer accepts no responsibility for data lost on the smartphone even if that data is lost while using this
unit. Do not forget to back up smartphone data regularly.
(The notes below shall mentioned in appropriate location in the manual)
Specification
Note: Specifications and design are subject to modification without notice.
Connection Diagram
Vehicle Power Charger
– To protect your unit against sudden surges in current, connect the vehicle power charger
only while the ignition switch is turned off.
Note: Be sure not to misplace detached parts. Keep parts out of the reach of small children
to prevent accidental swallowing.
-17-
Avoid exposure to moisture.
Precaution
Information to User
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment
and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment
has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio
(SAR).
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to
operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
Product Name: Sensor Unit
Responsible Party Name:
PIONEER ELECTRONICS (USA), INC.
SERVICE SUPPORT DIVISION
Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A.
Phone: 1-800-421-1404
URL: http://www.pioneerelectronics.com
-18-
WARNING (This specific letter requires in Capital)
Handling the cord on this unit or cords associated with accessories sold with the unit may expose you to
chemicals listed on proposition 65 known to the State of California and other governmental entities to cause
cancer and birth defects or other reproductive harm. Wash hands after handling. (this specific statement
requires in itatic and bold)
This unit contains mercury. Disposal of this material may be regulated due to environmental
considerations. For disposal or recycling information, please contact your local authorities or the
Electronics Industries Alliance: www.eiae.org
Important Safety Information
The Safety of Your Ears is in Your Hands
Get the most out of your equipment by playing it at a safe level—a level that lets the sound come through
clearly without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time, your hearing “comfort level” adapts to higher volumes of sound, so
what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your
equipment at a safe level BEFORE your hearing adapts.
ESTABLISH A SAFE LEVEL:
Set your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, without distortion.
Once you have established a comfortable sound level, set the dial and leave it there.
BE SURE TO OBSERVE THE FOLLOWING GUIDELINES.
Do not turn up the volume so high that you can’t hear what’s around you.
Use caution or temporarily discontinue use in potentially hazardous situations.
Do not use headphones while operating a motorized vehicle; the use of headphones may create a traffic
hazard and is illegal in many areas.
NOTICE TO ALL DRIVERS: Certain states and European countries prohibit the installation of product on
vehicle’s windshield. Those that are known as of the release date of this product are listed below; however,
please make sure that you are in compliance with your state’s most recent law before installing this
product. Pioneer is not responsible for any damages, penalties, or fines that may occur as a result of illegal
installation.
WARNING (need to be bold)
• Do not attempt to install or service your unit by yourself. Installation or servicing of the unit by persons
without training and experience in electronic equipment and automotive accessories may be dangerous
and could expose you to the risk of electric shock or other hazards. If liquid or foreign matter should get
inside this unit, park your vehicle to safe place and turn the ignition switch off (ACC OFF) immediately and
consult your dealer. Do not use the unit in this condition because doing so may result in a fire, electric
shock, or other failure
• If you notice smoke, a strange noise or odor from the unit, turn off the power immediately and consult your
dealer. Using this unit in this condition may result in permanent damage to the system.
• Do not disassemble or modify this unit, as there are high-voltage components inside which may cause an
electric shock.
• Do not allow this unit to come into contact with liquids. Electrical shock could result. Also, damage to the
unit, smoke, and overheating could result from contact with liquids.
-19-
CAUTION
Before using your unit, be sure to read and fully understand the following safety information:
● Read the entire manual before operating this unit, and keep the manual handy as a reference for operating
procedures and safety information.
● Do not operate this unit (or smartphone if used with) during driving, Doing so will divert your attention in
any way from the safe operation of your vehicle. Always observe safe driving rules and follow all existing
traffic regulations. If you experience difficulty in operating the system or reading the display on the phone,
park your vehicle in a safe location and apply the parking brake before making the necessary adjustments.
● Never allow others to use the system unless they have read and understood the operating instructions.
● Pay close attention to all warnings in this manual and follow the instructions carefully.
● Do not install this unit where it may (i) obstruct the driver’s vision, (ii) impair the performance of any of the
vehicle’s operating systems or safety features, including air bags or hazard lamp buttons, (iii) impair the
driver’s ability to safely operate the vehicle, or (iv) where it is illegal to do so by applicable law. Check with
your state’s motor vehicle agency for any changes to the law that may affect acceptable placement of this
unit.
● Please remember to fasten your seat belt at all times while operating your vehicle. If you are ever in an
accident, your injuries can be considerably more severe if your seat belt is not properly buckled.
● Never use headphones while driving.
● Do not leave the smartphone in direct sunlight for extended amounts of time or in any place with high
temperatures. Doing so may cause the smartphone to malfunction from the extreme rise in temperature.
For details, refer to the manuals for the smartphone.
Cautions for the power cable usage
WARNING
• Be sure to use only the supplied power cable with this unit. Use of another power cable is dangerous and
could result in malfunction.
• Never touch the adapter when your hands or feet are wet. Also, do not use the adapter in a high moisture
environment.
• Do not use the power cable if damaged.
• Unplug the power cable from the outlet when not in use.
• Never attempt to disassemble the power cable.
• When disconnecting the power cable, pull the plug itself. Do not disconnect by pulling on the cable.
Notes Before Using the System
Important (Serial Number:)
The serial number of this device is located on the package of this unit. For your own security and
convenience, be sure to record this number.
In case of trouble
Should the unit fail to operate properly, please contact your dealer.
The names of private corporations, products and other entities described herein are the
registered trademarks or trademarks of their respective firms.
-20-
© 2012 PIONEER CORPORATION.
All rights reserved.
