CAR ENTERTAINMENT 2009

Audio & AV

AV S y s t e m s

4–19

ODR & Pure

Component Systems

20–31 32–39

ALL SENSATIONS, NO SEAMS

What should all great audio sound systems share in common? Seamless hookups for portable digital devices to access more of your

favorite entertainment in a wider variety of media formats. Just bring along a pocket-sized player. Plug into a Pioneer

car headunit’s power to rock your world. Break every barrier that ever kept you from enjoying your

music as you like. With such sensational command within easy reach,

there’s no limit to how far you can go.

Audio Headunits

& Accessories

Amplifiers & Subwoofers Speakers

Comparison &

Specifications

40-49 50-57 58–63

AV S y s t e m s

MORE MEDIA, MORE DIRECT

Simplicity is a key to superior control. Just swipe a finger to fast-forward

or rewind movie or music playback with Touch Slide. Direct connections

between our headunits and iPod, iPhone, USB devices and portable media

players are fast and easy. 112 key illumination colors even give you a great

choice of ways to personalize the display.

AVH-P5150DVD

7" Wide Display 1-DIN AV with

USB Direct Connection

AVH-P4150DVD

7" Wide Display 2-DIN AV with

USB Direct Connection

Selectable Screen Color & RGB Key Illumination

AVH-P5150DVD

Select among five color themes for the display and 112 colors for key panel illumination

to seamlessly match your unit to your dash.

AVH-P4150DVD AVH- P3150DVD

COMMAND MORE DISPLAY COLORS A TOUCH OF SUPERIOR SIMPLICITY

Touch Slide Operation

With new Touch Slide Operation, just swipe your finger on the touch panel to fast-forward

or rewind movie and music playback. The GUI (Graphic User Interface) on a wide color

LCD makes file access and playback from DVD, CD, iPod or other digital device very

easy, in keeping with the convenience of direct touch panel operation.

AVH-P4150DVD AVH- P3150DVD

AV S y s t e m s

AVH-P3150DVD

5.8" Wide Display 2-DIN AV with

Front USB Direct Connection

Sound Quality

Deterioration due to

Compressed Audio File

When Advanced Sound Retriever

is “ON”, the high frequency range

is compensated to match the

frequency response curve of the

original sound.

Frequency (Hz)

5101520

-20

-40

-60

-80

High-frequency

compensation

Frequency response of

compressed audio ﬁ le

Magnitude (dB)

Multiple Media Connectivity

Connect a Pioneer AV headunit to an iPod via USB, for direct control

of audio and video menus, functions and selections via headunit’s

touch-panel display similar to iPod. This not only speeds up and

simplifies file search and access—it paves the way to enjoy higher-

quality sound via USB digital data transfer. Also, a built-in AUX-in mini

jack makes it convenient to connect a Pioneer AV headunit to an

external iPod Audio, iPod Video, MP4 player, digital camera or other

portable audio/video media player.

VERSATILE PERFORMANCE DivX® Playback

AVH-P7950DVD

DivX® is the world’s most popular high-compression digital video format and does not

appreciably compromise movie picture quality. Simply burn a movie from a PC onto a

long-playing Video CD or DVD, then play that disc in a Pioneer AV headunit to gain a

new appreciation of in-car theater.

AVH-P5150DVD AV H -P4150DVD

AVH-P3150DVD DVH-P4150UB DVH-3150UB

Advanced Sound Retriever

AVH-P4150DVD

Pioneer AV headunits use advanced sound retrieval to access high-quality audio from

compressed file formats.

AVH-P3150DVD DVH-P4150UB DVH-3150UB

AV S y s t e m s

112 Colors

Display colors and graphics may differ in photographs from actual appearance.

Selectable Screen Color & RGB Key Illumination

AVH-P5150DVD AVH-P4150DVD AVH- P3150DVD

The AVH-P5150DVD, AVH-P4150DVD and AVH-P3150DVD let you select among five screen

colors, according to your preference and color scheme. These headunits also feature 112 key

illumination colors for even more ways to match car interior and dashboard lighting.

AV S y s t e m s

NEW

Frequency (Hz)

Magnitude (dB)

5101520

–20

–40

–60

–80

High-frequency

compensation

Frequency response of

compressed audio ﬁ le

Sound Quality Deterioration due to Compressed Audio File

When Advanced Sound Retriever is “ON”, the high frequency range is compensated

to match the frequency response curve of the original sound.

AVH-P5150DVD 7" (16:9) Wide QVGA Fully Motorized LCD Color Display

with 4-Channel High-Power DVD/VCD/CD Receiver and USB Direct Connection

•Multi-channel processor

(DEQ-P7650) control

(CD-DD25 required)

•External unit control via IP-Bus

(2 units)

•AUX-in by mini jack (audio & video)

•RGB key illumination (112 colors)

LCD MONITOR

•7" (16:9) QVGA wide TFT

active matrix LCD color screen

•Selectable screen color

(Blue/Red/Amber/Green/Violet)

•AG (Anti-Glare) coated LCD color

screen

•Automatic rear view monitoring

in reverse gear (by camera*)

*Camera not included

•Direct connection for iPod

(audio & video) (CD-IU205V required)

•DivX®/MP3/WMA/AAC playback on

DVD and CD

•USB direct connection: USB 2.0

(full speed)

•Bluetooth® adapter ready

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital,

Linear PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•EEQ

—

5-mode preset equalizer

—

1-mode custom preset equalizer

—

3-band parametric equalizer

—

Bass Boost

—

2-way crossover (HPF/LPF)

—

3-mode selectable loudness

•IP-Bus input

•2 RCA pre-outs: front + rear/subwoofer

(selectable)

•A/V inputs and outputs

—

1 RCA Audio/Video input

—

1 RCA Video output

Wide LCD Color Display with

Touch Panel Operation

AVH-P7950DVD

The AVH-P5150DVD reproduces clear, bright DVD images on its 7-inch LCD color

display. AG (Anti-Glare) screen coating prevents external light diffusion from

impeding visibility. Settings, source access and playback via touch panel with

GUI (Graphic User Interface) makes operation effortless.

*5.8-inch wide.

Direct Connection for iPod and iPhone Adds Convenience to AV Control

AVH-P5150DVD* AVH-P4150DVD

Connect your iPod to the

AVH-P5150DVD for direct control

of iPod audio and video menus,

functions, and selections via

on-screen touch panel. This makes

song access and search extra-quick

and easy.

Similarly, the AVH-P4150DVD,

AVH-P3150DVD and DVH-P4150UB

can be connected to an iPhone.

*Does not apply to iPhone.

AV H- P3150D VD DV H -P415 0UB

CD-IU205V

Interface Cable for

AVH-P5150DVD

with iPod

AVH-P5150DVD

*Please see page 30 for details about iPod compatibility with Pioneer headunits.

CD-IU205V*

iPod

Advanced Sound Retriever

Hear the glory of original sound across a deeper, wider spectrum from highly

compressed MP3, WMA and AAC files stored on USB device, iPod and portable

media players. By compensating for data (especially higher frequencies) that tend

to get lost in the digital compression process, Pioneer’s Advanced Sound Retriever

technology enhances audio reproduction nearly all the way up to 20 kHz frequencies.

We can make your music sound close to CD quality.

AVH-P6050DVD AVH-P5150DVD AVH-P4150DVD

DivX® Playback

AVH-P7950DVD AVH- P515 0DV D AVH -P415 0DV D AV H- P3150 DVD DV H- P4150U B

DVH-3150UB

Create a DivX® movie on a PC, burn it to a disc, and play it in-car. Pioneer’s AV headunits

can play DivX® video files from CDs and DVDs. The world’s most popular compressed

digital video format, DivX® delivers speedy transfer without appreciably compromising

picture quality.

AVH-P4150DVD AVH -P3150 DV D DVH -P4150UB DV H- 315 0UB

AVH-P3150DVD*

Composite

image shown in

iPod display

NEW

AV S y s t e m s

112 Colors

Selectable Screen Color & RGB Key Illumination

AVH-P5150DVD AVH-P4150DVD AVH- P3150DVD

The AVH-P4150DVD will accommodate your taste or mood. Select among five (Blue/Red/

Amber/Green/White) colors for display, and among 112 key illumination colors to match car

interior, iPod and dashboard lighting.

Display colors and graphics may differ in photographs from actual appearance.

AV S y s t e m s

NEW

AVH-P4150DVD 7" (16:9) Wide QVGA Fully Motorized LCD Color Display

with 4-Channel High-Power DVD/VCD/CD Receiver and USB Direct Connection

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital, Linear PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Advanced Sound Retriever

•EEQ

—

5-mode preset equalizer

•Direct connection for iPod and iPhone

(audio & video) (CD-IU200V required)

•DivX®/MP3/WMA/AAC playback on

DVD and CD

•JPEG on CD-R/RW and USB

•USB direct connection: USB 2.0 (full speed)

•Bluetooth® adapter ready

—

1-mode custom preset equalizer

—

3-band parametric equalizer

—

Bass Boost

—

2-way crossover (HPF/LPF)

—

3-mode selectable loudness

•IP-Bus input

•3 RCA pre-outs (front + rear + subwoofer)

•A/V inputs and outputs

—

1 RCA Audio/Video input

—

1 RCA Video output

•RGB input (26-pin)

•Multi-channel processor (DEQ-P7650) control

(CD-DD25 required)

•External unit control via IP-Bus (2 units)

•AUX-in by mini jack (audio & video)

•RGB key illumination (112 colors)

LCD MONITOR

•7" (16:9) QVGA wide TFT active matrix

LCD color screen

•AG (Anti-Glare) coated LCD color screen

•Touch slide operation

•Selectable screen color

(Blue/Red/Amber/Green/White)

•Built-in GDC (Graphics Display Controller)

•Customizable wallpapers

•LED backlight

•Automatic rear view monitoring in

reverse gear (by camera*)

* Camera not included

Touch Slide Operation

AVH-P4150DVD AVH- P3150DVD

With a smooth swipe of your finger on the touch panel

display, you can fast forward/rewind AV content playing

from DVD-Video, DivX®, MP3/WMA/AAC and CD source

formats, or scroll a list of files for you to select among.

Note: Touch slide Fast-Forward/Rewind function not available on iPod.

Customizable Wallpapers

AVH-P4150DVD

Choose among 4 types of BGP (Background Picture) and 3 types of BGV (Background

Visual). You can even set your favorite JPEG file as wallpaper.

Parked with no place to go? Now you can enjoy a slideshow of your photos on a

CD or USB Device.

Link Play for iPod

Not in the mood for all of the kinds of music that

shuffle mode can play from your iPod library? Then

here’s a great way to listen only to your favorite kinds.

Just plug your iPod directly into the unit using the

optional cable, touch the Link Play button and select

specific artist, album or genre. Now, you are ready to

rock and roll.

*Artist only

Speedier Search Using iPod and iPhone

Now, Pioneer’s latest headunits are even easier to enjoy with an iPod. A new USB

mechanism speeds up “List Search”, refined processing speeds up “Alphabetical Search”

for song, artist name, or album, and “Touch Slide Operation” speeds up access to any

file in the connected iPod.

Jump to another title that hasn’t

recently been played from the

same album.

Jump to another album of the

same artist.

Jump to other music that you

haven’t heard in a while from the

same genre.

AVH-P3150DVD

AVH-P4150DVD AVH- P3150DVD

DVH-P4150UBAVH-P5150DVD*

DVH-P4150UB

AV S y s t e m s

NEW

5.8" (16:9) Wide QVGA LCD Color Display with 4-Channel High-Power

DVD/VCD/CD Receiver and USB Direct Connection

AVH-P3150DVD

•Direct connection for iPod and iPhone (audio & video) (CD-IU50V required)

•DivX®/MP3/WMA/AAC playback on DVD and CD

•JPEG on CD-R/RW and USB

•Front USB direct connection: USB 2.0 (full speed)

•Bluetooth® adapter ready

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital, Linear PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Advanced Sound Retriever

•EEQ

—

5-mode preset equalizer

—

1-mode custom preset equalizer

—

3-band parametric equalizer

—

Bass Boost

—

2-way crossover (HPF/LPF)

—

3-mode selectable loudness

•IP-Bus input

•2 RCA pre-outs: front + rear/subwoofer (selectable)

•A/V inputs and outputs

—

1 RCA Audio/Video input

—

1 RCA Video output

•Multi-channel processor (DEQ-P7650) control

(CD-DD25 required)

•External unit control via IP-Bus (2 units)

•AUX-in by mini jack (front for audio & video)

•RGB key illumination (112 colors)

LCD MONITOR

•5.8" (16:9) QVGA wide TFT active matrix LCD color screen

•Touch slide operation

•Selectable screen color (Blue/Red/Amber/Green/White)

•AG (Anti-Glare) coated LCD color screen

•Built-in GDC (Graphics Display Controller)

•Customizable wallpapers

•LED backlight

•Automatic rear view monitoring in reverse gear

(by camera*)

*Camera not included

Pioneer’s AV headunits’ AUX-in mini jacks extend playback from external iPod Audio,

iPod Video, MP4 player, digital camera and other portable audio/video media players.

These jacks are built into the front panel for fast, trouble-free connection.

*Audio only

Front AUX-In Mini Jack Connection

for Audio and Video

AVH-P3150DVD DVH-P4150UB DVH-3150UB* In addition to LED-backlight for brighter pictures, Black Level Adjustment displays deeper

black that you’ll appreciate when viewing movies. Color Temperature Adjustment allows

you fine-tune color quality ensuring a crisper, clearer picture.

Picture Quality Adjustment

AVH-P4150DVD AVH- P3150DVD

RGB key illumination

Rear: TS-D6902R

AV S y s t e m s

Metallic hairline finish front panel

Hide-away unit

280 mm (W) × 37 mm (H) ×

171 mm (D)

7" (16:9) Wide WVGA Fully Motorized LCD Color Display

with 8-Channel High-Power DVD/VCD/CD Receiver

AVH-P7950DVD

•DivX® file playback

•MP3/WMA/AAC playback on DVD and CD

•JPEG on CD-R

•USB adapter ready (external unit control)

•Adapter ready for iPod

•Bluetooth® adapter ready

•Dual illumination (white/red)

•Built-in MPEG-1/-2 decoder

•Built-in decoder (DTS, DTS-ES, DTS Neo:6,

DTS 96/24, Dolby Digital, Dolby Pro

Logic II, Dolby Digital EX, Linear PCM)

•192 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Built-in DSP (Digital Signal Processor)

—

5-mode preset equalizer

—

3-mode custom preset equalizer

—

2-channel/multi-channel Auto EQ

—

Digital listening position selector

—

2-channel/multi-channel auto time

alignment

—

13-band graphic equalizer

(L/R independent/common)

—

Multi-channel 3-band parametric equalizer

(L/R independent/common)

—

Front 2-way crossover: HPF/LPF

•Rotary volume

•Digital direct

•6 wide screen modes (Just/Full/Cinema/Zoom/

Normal/Auto)

•9-channel RCA pre-outs

•External unit control via IP-Bus (2 units)

•Source DVD control (full-control)

•AUX-in by mini jack (audio)

•Detachable lower face

•Dual-zone (two different sources) operation for

front and rear

•Optical digital input

•Joystick remote control

•6 m cable between monitor and hide-away unit

•Multi-language guide—caution message only

(English/Spanish/Portuguese/Traditional

Chinese)

HIDE-AWAY UNIT

•A/V inputs and outputs

—

AV-Bus input

—

2 RCA Audio/Video

inputs (input 1: Audio/Video,

input 2: Audio/Video or rear view camera)

—

1 RCA Audio/Video output

•8-channel speaker output

•Component output (for rear screen)

LCD MONITOR

•7" (16:9) WVGA wide TFT active matrix LCD color

screen

•Sub-Display (10-character)

•AG (Anti-Glare) coated LCD color screen

•Intelligent dimmer control

•Virtual GUI (Graphic User Interface)

•Fully motorized unit with display angle

adjustment

•New split-screen IC

•Built-in GDC (Graphics Display Controller)

•Automatic rear view monitoring in reverse gear

(by camera*)

*Camera not included

Like sound engineers, Pioneer applies Auto Time

Alignment to customize the front sound stage and

bring out vocal impact. After a microphone measures

the time it takes for sound from each speaker to reach

the listener, output timing is automatically adjusted

and wave interference suppressed.

The microphone also helps to monitor in-car acoustics

for multi-channel Auto EQ, and the information is used to

automatically equalize frequency response curves. Such

innovations deliver the best sound quality you can get in

a car. You can even enjoy expansive 6.1- or 5.1-channel

surround sound when listening to a DVD or 2-channel

CD recording.

2-Channel/Multi-Channel Selectable

Auto Time Alignment and Auto EQ

AVH-P7950DVD

Digital delay processing

makes all speakers sound

as if they are virtually

equidistant from the

listener, for a clearer,

front-focused soundstage.

Time Alignment

Image The Pioneer AVH-P7950DVD enhances the experience of cinema in a car in several

ways. Play 6.1-channel compatible audio/video DVDs or DTS Neo:6-compatible media

to maximize the drama that a full 6.1-channel surround sound system can create. The

audio effect from eight speakers (four front left and right, two rear left and right, one

center, and one rear center plus an active subwoofer) is especially astounding from

the perspectives of driver and front passenger. The overall sound is stable and natural,

particularly in the dedicated subwoofer channel for low frequencies.

Built-In Multi-Channel Processor

for 6.1-Channel Surround Sound

AVH-P7950DVD

Center: TS-S101PRS

Front: TS-M171PRS

AVH-P7950DVD

Rear center: TS-S101PRS

Active subwoofer:

TS-WX22A

Display colors and graphics may differ in photographs from actual appearance.

RCA line Speaker line

AV S y s t e m s

2-DIN 7" (16:9) Wide In-Dash Fully Motorized LCD Color Display

with 4-Channel High-Power 6-Disc Multi-DVD/VCD/CD Receiver

AVH-P6050DVD Limited distribution

•USB adapter ready (external

unit control)

•Adapter ready for iPod

•Bluetooth® adapter ready

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital,

Linear PCM)

•6-disc CD/DVD changer

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•EEQ

—

5-mode preset equalizer

—

1-mode custom preset equalizer

—

3-band parametric equalizer

—

EQ-EX

—

HPF

—

3-mode selectable loudness

•4-mode staging (Music Studio/Dynamic

Theater/Actor’s Stage/Relax Living)

•5 wide screen modes

(Just/Full/Cinema/Zoom/Normal)

•3 RCA pre-outs (front + rear +

subwoofer)

•IP-Bus input

•A/V inputs and outputs

—

Optical digital output (DTS, Linear PCM)

—

AV-Bus input

—

2 RCA Audio/Video inputs

(input 1: Audio/Video, input 2:

Audio/Video or rear view camera)

—

1 RCA Video output

•RGB input (26-pin)

•Multi-channel processor (DEQ-P7650)

control

•External unit control via IP-Bus (2 units)

•AUX-in by mini jack (audio)

•Level indicator

•Spectrum analyzer

•Joystick remote control

•Multi-language guide—caution

message only (English/Spanish/

Portuguese/Traditional Chinese)

LCD MONITOR

•7" wide TFT active

matrix LCD color screen

•AG (Anti-Glare) coated

LCD color screen

•Virtual GUI

(Graphic User Interface)

•Fully motorized unit with display

angle adjustment

(5 steps <STEP 0 to STEP 5>)

•New split-screen IC

•Built-in GDC (Graphics Display

Controller)

•Automatic rear view monitoring

in reverse gear (by camera*)

* Camera not included

Gaining a greater touch of control over all your in-car entertainment now gets simpler.

Whether it is playing a stack of DVDs, CDs, or a connected iPod or other portable media

player, these models are more than a multimedia headunit—it is a multi-operational

centerpiece engineered for more direct access to the new generation of in-car

entertainment. Its brilliant 7-inch-wide in-dash monitor features easy-access smudge-

resistant touch panel and external light-diffusing AG (Anti-Glare) screen coating.

Every image emanating from the screen is bold, clear and sharp, yet easy on the eyes.

7-Inch Wide In-Dash Monitor with Enhanced Touch Panel

In all, it is visibly superior to what more conventional AV command centers have to offer

in overall performance and style.

A Clear Touch Panel Makes Operation Easy

AVH-P5150DVD AVH-P4150DVD AVH-P6050DVD

Choose among four presets (Music Studio/Dynamic Theater/Actor’s Stage/Relax Living)

designed for you to listen to optimal advantage, according to the nature of your source

material, acoustic environment and personal preference. Touch panel operation makes

it extra-easy to select the right setting to stage your sound.

In-Car Sound Staging

AVH-P6050DVD

Music Studio Actor’s StageDynamic Theater Relax Living

Screens For Four Sound Staging Presets (AVH-P6050DVD)

Keep the music and movie entertainment rolling without interruption for as long as you like. The CD/DVD

changer section holds up to six discs. Use the touch panel to select and sequence disc tracks for playback

as desired. With the 7-inch wide monitor, confirming details and data is simplicity itself.

6-Disc CD/DVD Changer

AVH-P6050DVD

Display colors and graphics may differ in photographs from actual appearance.

AVH-P7950DVD AVH- P6050DVD AVH-P5150DVD AVH-P4150DVD

4-pole mini jack

(designed for iPod

Video)

AV S y s t e m s

iPod

AVH-P5150DVD AVH-P3150DVD/DVH-P4150UBAVH-P4150DVD

Conventional

RCA cable

With AV Mini Jack Input—DVH-P4150UB With Video Input—AVH-P7950DVD

Video Input

4-pole mini jack

(designed for iPod Video)

CD-RM10

AUX Input-Video

CD-V150M

Mini-Jack Cable for iPod

AUX-in in front

(for iPod Audio & Video)

DVH-P4150UB

iPod fifth generation

only for video output

Interface Cable for

AVH-P5150DVD with iPod

AVH-P7950DVD

USB Interface Cable for

AVH-P4150DVD with

iPod/iPhone

USB Interface Cable for

AVH-P3150DVD and

DVH-P4150UB with

iPod/iPhone

1. iPod TV OUT setting

must be “ON”

2. AUX 1 should be switched to “iPod” in the initial menu. The initial

menu is available even if the source is off.

CD-IU205V CD-IU200V CD-IU50V

NEW NEW NEW

View iPod Video Via Pioneer AV Headunits by Mini Jack

You will need to change the settings on both the iPod and headunit

in order to use iPod Video.

Tips: iPod Video Setup

0.5 m

USB extension cable

(1.5 m) included

CD-IU205V

Protection cap

AUX: Rear

USB: Rear

USB

AUX: Front

USB: Front

AUX: Rear

USB: Rear

Protection cap

iPhone/

iPod

Composite

image shown in

iPhone display

AUX IN

0.5 m

CD-IU50V*

USB (male)

Straight type

USB (female)

iPhone/

iPod

0.5 m

USB extension cable

(1.5 m) included

CD-IU200V*

Protection cap

USB

Composite

image shown in

iPhone display

AUX IN

L-type

DVH-P4150UB

AVH-P3150DVD

USB

(female)

* CD-IU50 connection cable (for music

playback only) also available. *CD-IU50 connection cable (for music playback only) also available.

Composite image

shown in iPod display

AV S y s t e m s

ENTERTAINMENT

EXPANDS

You can choose among a greater range of audio/video content

to play than discs alone can offer—thanks to a Pioneer 1-DIN

DVD player’s front built-in USB and AUX-in jacks for easy,

direct connection to an iPod or other digital device.

DVH-P4150UB 4-Channel High-Power DVD/VCD/CD Receiver with USB Direct Connection NEW

•Direct connection for iPod and iPhone (audio & video)

(CD-IU50V required)

•DivX®/MP3/WMA/AAC playback on DVD and CD

•JPEG on CD-R/RW and USB

•Front USB direct connection: USB 2.0 (full speed)

•Bluetooth® adapter ready

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital, Linear PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Advanced Sound Retriever

•EEQ

—

5-mode preset equalizer

—

1-mode custom preset equalizer

—

3-band equalizer (Bass/Mid/Treble)

—

2-mode selectable loudness

•Rotary volume

•IP-Bus input

•2 RCA pre-outs (front + rear)

•A/V inputs and outputs

—

1 RCA Video input

—

1 RCA Video output

•Multi-channel processor (DEQ-P7650)

control (CD-DD25 required)

•External unit control via IP-Bus (2 units)

•AUX-in by mini jack (front for audio & video)

AV S y s t e m s

DVH-3150UB 4-Channel High-Power DVD/VCD/CD Receiver with USB Direct Connection NEW

•DivX®/MP3/WMA/AAC playback on DVD and CD

•JPEG on CD-R/RW and USB

•Front USB direct connection: USB 2.0 (full speed)

•Built-in MPEG-1/-2 decoder

•Built-in decoder (Dolby Digital, Linear PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Advanced Sound Retriever

•EEQ

—

5-mode preset equalizer

—

1-mode custom preset equalizer

—

3-band equalizer (Bass/Mid/Treble)

—

2-mode selectable loudness

•Rotary volume

•1 RCA pre-out (rear)

•A/V input and output

—

1 RCA Audio input

—

1 RCA Video output

•AUX-in by mini jack (front for audio)

Frequency (Hz)

Magnitude (dB)

5101520

–20

–40

–60

–80

High-frequency

compensation

Frequency response of

compressed audio ﬁ le

Sound Quality Deterioration due to Compressed Audio File

When Advanced Sound Retriever is “ON”, the high frequency range is compensated

to match the frequency response curve of the original sound.

Front USB Direct Connection for iPod with DVH-P4150UB

iPod

Composite image

shown in iPod display

CD-IU50V* USB Interface Cable

USB Direct Connection*

for iPod and iPhone

ALL AV HEADUNITS**

Pioneer’s new DVH-P4150UB is ready to roll with capability

for direct connection to your iPod and iPhone. File search

and access are extra-quick. The headunit keeps song,

artist, time and album information displays very clear

and user-friendly. A car entertainment system’s wired

connection for direct digital signal transfer from iPod

into USB terminal maintains clean sound.

* Please see page 30 for details about iPod compatibility with Pioneer

headunits.

** Except AVH-P7950DVD, AVH-P6050DVD and DVH-3150UB.

AVH-P5150DVD: Does not apply to iPhone.

USB Interface Cable for AVH-P3150DVD and DVH-P4150UB with iPod/iPhone.

CD-IU50V NEW

DivX®/MP3/WMA/AAC

Playback on DVD

ALL AV HEADUNITS*

Pioneer AV headunits can play compressed data formats (DivX® movies; MP3, WMA

and AAC audio) burned from a PC onto CDs and DVDs. Simply load a disc into your car

entertainment system and enjoy. Capacity of a recordable DVD is so huge that your

entire music collection is likely to fit on one or two discs full of MP3, WMA and AAC files,

with no need for external devices or connections.

*Except AVH-P6050DVD

Advanced Sound Retriever

Hear the glory of original sound across a deeper, wider spectrum from highly

compressed MP3, WMA and AAC files stored on USB device, iPod and portable

media players. By compensating for data (especially higher frequencies) that tend

to get lost in the digital compression process, Pioneer’s Advanced Sound Retriever

technology enhances audio reproduction nearly all the way up to 20 kHz frequencies.

We can make your music sound close to CD quality.

AUX-In Connection by Mini Jack

Pioneer’s single-DVD players each have a built-in AUX input for connecting a portable

media player and other external auxiliary devices.

* Front AUX-in: AVH-P3150DVD/DVH-P4150UB/DVH-3150UB

Audio only: AVH-P7950DVD/AVH-P6050DVD/DVH-3150UB

ALL AV HEADUNITS*

AV H- P4150 DV D AV H - P3150DV D DVH -P415 0UB DV H - 315 0UB

* CD-IU50 connection cable (for music playback only) also available.

AV S y s t e m s

Microphone

for Auto EQ

DVH-P4150UB

Dual optical inputs

Optical 1 Optical 2 XDV-P650

Center: TS-CX900

Front:

TS-D1720C

Rear: TS-D6902R

Subwoofer: TS-W3002D4

PRS-D1200M

Front: TS-D1720C

Center: TS-CX900

Rear: TS-D6902R

Active subwoofer:

TS-WX11A

DEQ-P7650

Optical 1

Optical 2

AVH-P5150DVD

XDV-P650

Optical Digital Converter:

CD-DD25

Front: TS-D1720C

Center: TS-CX900

Active subwoofer:

TS-WX11A

DEQ-P7650

RCA output

XDV-P650

GEX-P5750TV(P)

Rear: TS-D6902R

AVH-P5150DVD

Multi-CD Player

Optical line Speaker line

IP-Bus line RCA line Both CD-AD600 (optional optical digital cable) and an optical cable

(included with DEQ-P7650) are required for dual DVD system.

Optical line

Speaker lineIP-Bus line

RCA line

Optical line Speaker lineAV-Bus lineRCA line IP-Bus line

Optical Digital Converter:

CD-DD25

Dual optical inputs

Multi-Channel Processor

DEQ-P7650 Multi-Channel Processor

•Built-in decoder (DTS, Dolby Digital, Dolby Pro

Logic II, Linear PCM)

•6-ch. DAC

•5-ch. built-in amplifier

•SFC for multi-channel source

•Built-in 6-ch. DSP

—

7-mode preset equalizer

—

2-mode custom preset equalizer

—

Multi-channel Auto EQ

—

Digital SFC (Sound Field Control): 6-mode

(Musical/Drama/Action/Jazz/Hall/Club)

—

Digital listening position selector

•Optimum sound for car environment

—

Dynamic range control

—

Optimum down-mix for normal speaker

layout

•Built-in crossover network (L/R)

—

Crossover frequency: 63Hz/80Hz/100Hz/

125 Hz/160 Hz/200 Hz

•IP-Bus input/output

•6-ch. RCA pre-outs

•A/V inputs

—

2 RCA Audio inputs

—

Dual optical inputs (DTS, Dolby Digital,

Dolby Pro Logic II, Linear PCM)

It is easy to expand DVD entertainment. The DEQ-P7650 has dual optical

inputs for further upgrading your DVD system.

For example, by connecting one main DVD headunit (AVH-P5150DVD,

DVH-P4150UB, etc.) plus additional source DVD player (XDV-P650) with

the DEQ-P7650, you can

instantly enjoy multi-DVD

entertainment with dynamic

5.1-channel surround sound.

Dual Optical Inputs

DEQ-P7650

The driver who is looking for the versatility, sonic purity and distortion-free control of digital signal

processing should be introduced to the DSP features of the DEQ-P7650. Built-in 6-channel DSP

converts the incoming signals to digital form. The user can then balance the output signal to

match the acoustic characteristics of a specific car and create a personal sound profile by using

the Parametric Equalizer and SFC controls. A range of DSP-based sound timing features allows the

DEQ-P7650 to be set up for truly optimum performance.

SFC (Sound Field Control) lets you optimize the aural ambience of every sound source. Musical,

Drama and Action modes are heard to best advantage over 5.1-channel surround systems. For

Jazz, Hall and Club modes, a two-channel stereo system is sufficient.

Built-In 6-Channel DSP (Digital Signal Processor)

DEQ-P7650

CD-DD25

Optical Digital Converter for DEQ-P7650 Connection with AVH-P5150DVD, AVH-P4150DVD, AVH-P3150DVD and DVH-P4150UB

DEQ-P7650 Connection Example—DVH-P4150UB & Monitor plus Source DVD Player

DEQ-P7650 Connection Example—AVH-P5150DVD plus Source DVD Player

DEQ-P7650 Connection Example—AVH-P5150DVD plus Source DVD Player and TV Tuner

Optical Digital

Converter:

CD-DD25

Any display with

RCA Video input

Close-up view

AV S y s t e m s

The compact 1-DIN size allows the

XDV-P650 to be easily installed into

the dashboard. Thus, dashboards

with 2-DIN space can combine it

with a 1-DIN headunit.

Playback of the

discs is quick and

easy by pushing

buttons 1 to 6.

The XDV-P650 can be used either as a stand-alone multi-DVD/Video CD/

CD player by connecting it directly to a monitor with a video input, or as

a source unit by connecting to a headunit with an IP-Bus connection.

XDV-P650 Connection Compatibility with Main Units

AVH-P7950DVD Yes

AVH-P6050DVD External

AVH-P5150DVD Yes

AVH-P4150DVD External

AVH-P3150DVD External

DVH-P4150UB External

ND-BC20PA

Connection

for Switching

Viewing Angle

Normal angle mode Sky view mode

ND-BC2

ND-BC20PA

ND-BC20PA Connection Example

GEX-P5750TVP

84 mm (W) × 20 mm (H) × 65 mm (D)

Visual DSP Hide-Away Unit

View Mode Switch

and Camera Position

Adjuster

Rear View Camera

To Composite

Camera In

To Power

(ACC)

XDV-P650 6-Disc Multi-DVD/VCD/CD Player

•DVD auto play

•Built-in MPEG 2/1 decoder

•Built-in decoder (Dolby Digital, Linear

PCM)

•96 kHz/24-bit DAC (for audio)

•10-bit video DAC

•Controlled by IP-Bus headunit—full

control by A/V entertainment master

unit and external control by any IP-Bus

headunit

•Stand-alone use with an equipped

remote sensor

•Optical digital output (DTS, Dolby

Digital, Dolby Pro Logic, Linear PCM)

•GUI control with joystick remote control

and on-screen display

HIDE-AWAY UNIT

•Analog IP-Bus output

•Composite Video output (front + rear)

ND-BC2 Universal Rear View Camera

ND-BC20PA Visual DSP Unit with ND-BC2

•Wider Viewing Angle: 135 Degrees (Horizontal) and 100 Degrees (Vertical)

•Newly Developed 6.3 mm Color CCD with 270,000 Pixel Resolution

(492 × 512 Pixels) for Higher Visibility even at night • More Compact Camera

Unit: 27 mm (W) × 27 mm (H) × 26 mm (D)

NOTES: The rear view camera is NOT intended for

entertainment purposes. It is specifically designed

to allow the driver to observe a towed boat or

vehicle during transport.

The optional rear view camera must be

a “reversed image” type.

•

Adjustable (Normal/High) viewing angle for easy assessment of parking space width and

depth

•

Lens correction for undistorted rear view image

•

Camera position compensation

rotates the image for optimal rear view without changing camera position, even if the

camera is not installed in the middle of the rear and aimed horizontally

GEX-P5750TVP

Hide-Away TV Tuner for PAL/SECAM*

GEX-P5750TV

Hide-Away TV Tuner for NTSC/PAL-M

•24-station (12 TV1/12 TV2) presets by BSSM

•IP-Bus input and output terminals

•RCA composite video output** for front

and rear display (GEX-P5750TVP: PAL/

SECAM, GEX-P5750TV: NTSC/PAL-M)

•RCA audio output for rear display

•AV-Bus input/output

•On-screen display

•Remote control sensor

•Mode change: source or stand alone

* Compatible with B, G, H, D, K, I (Details on page 59)

** The video output does not feature conversion

function for rear display(s) between PAL and

NTSC systems.

Other AV Units

SE-IRM290

IR Wireless Headphone

•For use with the AVD-W7900

AVD-W7900

7" (16:9) Widescreen Rear Seat

Video Display

•7" (16:9) wide TFT active matrix LCD color screen

•Picture control (brightness/contrast/hue/color)

•

5 wide screen modes (Just/Full/

Cinema/Zoom/Normal)

•IR transmitter for optional

wireless headphone

(SE-IRM290)

•Power supply in

•2 Audio/Video inputs

(composite Audio & Video)

•1 Audio/Video output

(composite Audio & Video)

AXM-P7650

Multi-Channel Processor

Controller

•Full Dot OEL (Organic EL)

display

•Use for control of DEQ-P7650

Multi-Channel Processor

•Full control multi-channel

function with OEL display

•Speaker input for OEM radio

or non-RCA output headunit

•IP-Bus connection to IP

source unit

•Joystick remote control

Limited distribution

AV S y s t e m s

The AVH-P7950DVD player packs versatile technology

including 50 W x 8-channel MOSFET amplifier and decoders

for DTS, DTS-ES, DTS Neo:6, DTS 96/24, Dolby Digital, Dolby

Pro Logic II, Dolby Digital EX and Linear PCM for enhanced

multi-channel surround and all-around versatility. Auto time

alignment and multi-channel Auto EQ effortlessly customize

sound characteristics precisely according to the car interior.

Simple touch panels make this and other Pioneer AV

headunits a breeze to operate. The AVH-P7950DVD*,

AVH-P5150DVD, AVH-P4150DVD, AVH-P3150DVD,

DVH-P4150UB and DVH-3150UB can even play multiple

formats: MP3, WMA, AAC and DivX® files from DVDs.

Pioneer’s Class-FD ICEpower and Class-D power amplifiers

redefine state-of-the-art power amplification, thanks to

their high-efficiency input power processing, compact

design, and dynamic, yet stable clarity of subwoofer and

speaker output.

To see how well high-performance speakers can suit even

compact spaces, consider Pioneer shallow-type subwoofers

that are shallow enough in depth to install behind or under

seats, yet deliver deep, dynamic bass. Smartly designed for

easy 6.1- and 5.1-channel surround, the lineup of Pioneer’s

flush mount speakers features extra-rigid lightweight cones

that deliver crisp, clear low-frequency sound across a wide

dynamic spectrum from low whispers to massive volumes.

The solution to achieve every sound has never been simpler,

with Pioneer to open up your car entertainment system.

The DEQ-P7650 Multi-Channel Processor lets you enjoy

5.1-channel surround sound from a dual DVD system of your

creation, and the GEX-P5750TV(P) TV tuner lets you watch in

the comfort of your cabin. You can even use the AXM-P7650

Multi-Channel Processor Controller to upgrade your car’s

pre-installed OEM system to 5.1-channel surround.

AVH-P7950DVD

7" (16:9) Wide WVGA Fully Motorized LCD Color

Display with 8-Channel High-Power DVD/VCD/

CD Receiver

DEQ-P7650

Multi-Channel Processor

PRS-D4200F

Class-FD 4-/2-Channel

Bridgeable Amplifier

PRS-D2000SPL

Class-D Mono Amplifier TS-SW3001S4

30 cm (12") Shallow-Mount

Component Subwoofer

(Single 4 Ω Voice Coil)

TS-D6902R

6" × 9" 2-Way Speaker

Peerless DVD Playback

Expanding Sound By The Unit

Dynamic Linear Surround

Digital Amps of Compact Power

TS-WX301

30 cm Bass-Reflex Subwoofer

IN-CAR SURROUND SOUND

FOR MAXIMUM IMPACT

AVH-P7950DVD* AV H-P6050DV D AVH-P5150DVD AVH-P4150DVD

AVH-P3150DVD DVH-P4150UB DVH-3150UB XDV-P650

DEQ-P7650 GEX-P5750TV(P) CD-VS33

TS-D6902R TS-D1602R TS-W12PRS

TS-M171PRS TS-S101PRS TS-T031PRS

TS-C171PRS TS-C131PRS TS-D1720C

TS-D1320C TS-A1702C TS-A1302C

TS-W3002D2 TS-W3002D4 TS-W308D2

TS-W308D4 TS-SW3001S4 TS-SW3001S2

TS-SW2501S4

PRS-D2000SPL PRS-D1200SPL GM-D8400M

GM-D7400M

PRS-D4200F PRS-D2200T PRS-D1200M

TS-SW2501S2 TS-WX11A

TS-WX22A TS-CX900

*AVH-P7950DVD has built-in multi-channel processor.

AV S y s t e m s

DVH-P4150UB

Center:

TS-CX900

Front left:

TS-D1720C Front right:

TS-D1720C

DEQ-P7650

Rear left:

TS-D6902R

Rear right:

TS-D6902R

XDV-P650

Active subwoofer:

TS-WX11A

Front left:

TS-D1720C

Front right:

TS-D1720C

Center:

TS-CX900

DEQ-P7650

XDV-P650

Rear left:

TS-D6902R

Rear right:

TS-D6902R

AXM-P7650*

GM-3300T

Subwoofer:

TS-WX301

Any display with

RCA Video input

Integrated

OEM

headunit

PRS-D1200M

CD-VS33

AVH-P7950DVD

PRS-D1200M

Front left:

TS-T031PRS

Front right:

TS-T031PRS

Front center:

TS-S101PRS

Front left:

TS-M171PRS

Front right:

TS-M171PRS

PRS-D2200T

PRS-D4200F

PRS-D2200T

Rear center:

TS-S101PRS

Rear left:

TS-D1602R

Rear right:

TS-D1602R

Subwoofer:

TS-W12PRS

Subwoofer:

TS-W12PRS

Optical line RCA line IP-Bus line Speaker line

Subwoofer:

TS-SW3001S4

2-DIN 5.1-Ch. DVD System Add-On 5.1-Ch. DVD System to Integrated OEM System

RCA line Speaker line

Remark: These connection configurations are only a few examples. Connection for your car may differ from that indicated in the diagram. Ask your nearest car stereo installer or dealer about installation details.

Optical line RCA line IP-Bus line Speaker line

Front left:

TS-C171PRS

Front right:

TS-C171PRS

Rear left:

TS-C171PRS

Rear right:

TS-C171PRS

AVH-P7950DVD

GEX-P5750TV(P)

Front center:

TS-S101PRS

RCA line IP-Bus line Speaker line

AV-Bus line

For Sedans For Station Wagons

1-DIN 5.1-Ch. DVD System (Standard Mode) 1-DIN 6.1-Ch. DVD System (Network Mode)

For Minivans

For SUV (Sport Utility Vehicle)

and SUV-Style Cars

Any display with

RCA Video input

Any rear display

with RCA Video

input

Any rear display

with RCA Video

input

Any rear

display with

RCA Video

input

*Limited distribution

Any rear display

with RCA Video

input

Audio Headunits

UNIFY YOUR UNIVERSE OF SOUND

Gain capability to extend your listening pleasure from more sources, for longer lengths of time. Now, a Pioneer audio headunit

can play high-capacity, extra-compact SD memory cards as well as iPod, iPhone and portable media players.

Every connection is simple, so you can bring more music onboard without complications.

DEH-6150BT

Built-in Bluetooth® for Safer Calling

DEH-4150SD

Handy, Versatile SD Card Compatibility

DEH-P5150UB

Easy Front USB Connection and OEL Display

Audio Headunits

Getting maximum play out of your in-car system requires a more

seamless connection to various media. So the DEH-4150SD lets

you bring SD memory cards containing music onboard for

headunit storage and playback. You can also directly connect,

control and playback music from an iPod, iPhone, USB device or

other external portable media player.

An AUX input jack is easily accessible on the front panel.

Multiple Media Connectivity

EXPANDED CONNECTION

Pioneer audio headunits process high-quality sound even from

compressed audio files stored in an iPod, USB device, etc.

Advanced Sound Retriever

RAISING DIGITAL AUDIO QUALITY

For more convenient entertainment system control that won’t compromise driving

safety, this feature lets a driver operate a Pioneer headunit without taking hands off

of the steering wheel (given that the vehicle has factory-equipped remote control

installed on the steering wheel).

Wired Remote Control Input

MAKING CONVENIENCE MORE COMFORTABLE

Bluetooth® Wireless Technology

DEH-6150BT

Pioneer’s new DEH-6150BT features wireless Bluetooth® with

Parrot module for easy, safe phone calling, excellent noise

reduction to keep conversations clear and enhanced cell

phone compatibility.

DEH-P7150UB DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB

DEH-2150UBG FH-P6050UB

DEH-P7150UB DEH-6150BT

DEH-2150UBG

DEH-P5150UB DEH-4150SD DEH-3150UB

Audio Headunits

DEH-6150BT NEW

•Direct AUX-in by mini jack (front)

•Front USB direct connection: USB 2.0 (full speed)

•Direct connection for iPod and iPhone (CD-IU50 required)

•Built-in Bluetooth® Wireless Technology

•Advanced Sound Retriever

•EEQ

—

3-band parametric equalizer

•Rotary Commander

•Direct Sub Drive

•1 RCA pre-out: selectable (rear/subwoofer)

•Wired remote control input

4-Channel High-Power WMA/MP3/AAC/CD Receiver

with USB Direct Connection and Bluetooth® Wireless Technology

Included microphone

for hands-free talking

Anna Reese

3105551234

Jose Martinez

3105551234

Mark Walkins

3105551234

Jennifer Hennings

nnifer

ngs

310555123 4

3105

Peter Stevenson

3105551234

Bert Anderson

3105551234

551

Call John!

lJo

all

Audio Headunits

DEH-6150BT

More Phonebook Memory

Use with Phone Pairing to transfer your entire phonebook at a single time

to the headunit, which can memorize up to 1,000 different numbers:

e.g., 500 persons × 2 phone types (cell phone, home).

SMS alert lets you know if you receive any incoming text messages, even if you are

listening to loud music. The message alert will play a sound and an icon will appear

on the screen.

ABC search for easy dialing

Built-in Bluetooth® Technology with Parrot Module

With Bluetooth® module by Parrot, cell phone compatibility is extended, and calls

come in loud and clear.

Expanded Cell Phone Compatibility

Thanks to Parrot technology, Pioneer units are now compatible with more

cell phones.

Auto Phonebook Synchronization

Connect your cell phone to the DEH-6150BT, and phonebook synchronization

is automatic.

Improved Noise Reduction

The DEH-6150BT incorporates new noise reduction technology that can

reduce the effect of road noise.

Introducing a Better Hands-Free Solution

Simple and Convenient

Enjoy the convenience of having Bluetooth® built right into the unit, with no additional hands free car kits or

other accessories needed. The unit acts like a speakerphone, channeling the sound through your car speakers

which makes the call sound better. It also automatically mutes your music so that you’ll never miss a call.

SMS Alert

Don’t stop the music to make a call. You can access a phonebook without switching

from the sound source to Bluetooth® mode.

Phonebook Access

When you’re not utilizing hands-free calling, the

DEH-6150BT can use Bluetooth® Wireless Technology

to feed your appetite for entertainment. Using

“wireless audio” control and streaming (AVRCP, A2DP),

you can control and listen to a compatible audio player

or music phone on your headunit.

“Wireless Audio” Control and Streaming

Before Noise Reduction After Noise Reduction

Notes: Use of Bluetooth® is permissible according to regulations on radio waves in the country in which the Bluetooth® product is used.

Ask your nearest dealer about Bluetooth® connectivity with your cell phone.

Audio Headunits

A type (m) Mini-B (m)

0.2 m (pigtail)

1.5 m

A type (f) A type (m) A type (f)

Portable media player’s

original cable

CD-IU50*

Interface Cable for iPod

and iPhone

A type (m) (for iPod)

USB device

Not compatible with

DRM contents for

portable media player

iPod

Extended cable (1.5 m) included.

USB connector-male (m) USB connector-female (f)

Connection Example for USB Devices Compatible with MSC

* CD-IU50 Interface Cable for iPod and iPhone optionally available for connecting an iPod to the DEH-P7150UB, DEH-6150BT,

DEH-P5150UB, DEH-4150SD and FH-P6050UB.

Please see page 30 for details about iPod compatibility with Pioneer headunits.

A 3rd or 4th generation iPod requires CD-IB100II.

DEH-P7150UB

DEH-P7150UB 4-Channel High-Power WMA/MP3/AAC/CD Receiver with USB Direct Connection NEW

•Full Dot OEL (Organic EL) display

•Auto-slide face

•Direct AUX-in by mini jack (rear)

•USB direct connection: USB 2.0 (full speed)

•Direct connection for iPod (CD-IU50 required)

•Bluetooth® adapter ready

•Advanced Sound Retriever

•EEQ

—

7-band digital graphic equalizer

•Rotary Commander

•Direct Sub Drive

•3 RCA pre-outs (front + rear + subwoofer)

•Spectrum analyzer

•Wired remote control input

USB Direct Connection

DEH-P7150UB

Take your favorite MP3, WMA and AAC files for a ride. With direct connection of a new

Pioneer headunit* to a portable media player, USB device or other USB-compatible

gear, you can play in your car whatever you’ve recorded via PC. It’s fast and easy.

No adapters are required.

*DEH-3150UB/DEH-2150UBG: MP3/WMA file playback

NOTE: Unauthorized copying of music is strictly prohibited. Not every device is compatible. See more details

in Pioneer website. Compatible with USB device only. Not compatible with DRM (Digital Rights

Management) contents and MTP (Media Transfer Protocol) connection players.

DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG

Optionally available for connecting an

iPod to the DEH-P7150UB, DEH-6150BT,

DEH-P5150UB, DEH-4150SD and

FH-P6050UB.

CD-IU50

Interface Cable for iPod and iPhone

FH-P6050UB

•Multi-language display (English/Spanish/

Portuguese)

Composite image shown

in iPod display

Audio Headunits

When Advanced Sound Retriever is “ON”,

the high frequency range is compensated

to match the frequency response curve

of the original sound.

Sound Quality Deterioration due to Compressed Audio File

Frequency (Hz)

Magnitude (dB)

5101520

–20

–40

–60

–80

High-frequency

compensation

Frequency response of

compressed audio ﬁ le

Jump to another title that hasn’t recently

been played from the same album.

Jump to another album of the same artist.

Jump to other music that you haven’t

heard in a while from the same genre.

Advanced Sound Retriever

Hear the glory of original sound across a deeper, wider spectrum from highly

compressed MP3, WMA and AAC files stored on USB device, iPod and portable

media players. By compensating for data (especially higher frequencies) that

tend to get lost in the digital compression process, Pioneer’s Advanced Sound

Retriever technology enhances audio reproduction nearly all the way up to

20 kHz frequencies. We can make your music sound close to CD quality.

DEH-P5150UB 4-Channel High-Power WMA/MP3/AAC/CD Receiver with USB Direct Connection NEW

•Full Dot OEL (Organic EL) display

•Direct AUX-in by mini jack (front)

•Front USB direct connection: USB 2.0 (full speed)

•Direct connection for iPod and iPhone (CD-IU50 required)

•Bluetooth® adapter ready

•Advanced Sound Retriever

•EEQ

—

7-band digital graphic equalizer

•Rotary Commander

•Direct Sub Drive

•3 RCA pre-outs (front + rear + subwoofer)

•Spectrum analyzer

•Wired remote control input

•Multi-language display (English/Spanish/Portuguese)

DEH-P7150UB*

The Full Dot OEL display allows you to scroll through your iPod and USB device with

greater ease, displaying up to three lines in list mode. The unit also comes with features

like 3D animated screensavers and a wider viewing angle range which provides clear,

trouble-free viewing from virtually any position, even in sunlight.

* White color OEL display

Link Play for iPod

DEH-P7150UB

Next to the Rotary Commander on the

new DEH-P5150UB sits a large LIST key for

extra-quick, easy file search and access.

Press it to display folder or file lists, rotate

the commander dial to search, then press

the commander button for playback.

DEH-P5150UB DE H- P515 0U B D E H - 4150 S D F H -P 60 50 U B

DEH-P7150UB*

Listening to an artist that you just can’t get enough of and want to hear more? Now

you can use Link Play to rediscover music buried in the thousands of songs in your

library. You can also have your passenger control your music directly from the iPod.

*Artist only

Full Dot OEL (Organic EL) Display Rotary Commander and List Key

Press List Key

Album

Artist

Genre

DEH-P7150UB DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG FH-P6050UB

RS-D7RII* DEX-P90RS* DEH-P80RSII* DEH-P80RSII

DEH-6150BT DEH-P5150UB

DEH-P5150UB

Press and hold the List

Key for about three

seconds.

DEH-4150SD FH-P6050UB*

3-Line List Display

White Color OEL Display

3D Animated Screensaver

Audio Headunits

4-Channel High-Power WMA/MP3/AAC/CD Receiver

with USB Direct Connection and Built-in SD Memory Card Slot

DEH-4150SD NEW

•Built-in SD memory card slot (SDHC compatible)

•Direct AUX-in by mini jack (front)

•Front USB direct connection: USB 2.0 (full speed)

•Direct connection for iPod and iPhone

(CD-IU50 required)

•Advanced Sound Retriever

•EEQ

—

3-band parametric equalizer

•Rotary Commander

•Direct Sub Drive

•2 RCA pre-outs: front + rear/subwoofer

(selectable)

•Wired remote control input

Built-in SD Memory Card Slot

(SDHC Compatible)

DEH-4150SD

The new DEH-4150SD has a built-in slot for SD memory card* of up to 16 GB containing

MP3, WMA, AAC and WAV music files. Such huge capacity allows for seamless playback

with no need to change SD cards often. That goes a long way toward extending

convenience and listening pleasure.

*Please see page 27 for details about SD memory card compatibility with DEH-4150SD.

Front USB Direct Connection

Take your favorite MP3, WMA and AAC files for a ride. New Pioneer headunits have a

front USB terminal to directly connect** a portable media player, USB device or other

USB-compatible gear, so you can play in your car whatever you’ve recorded via PC.

It’s fast and easy. No adapters are required.

** Please use CD-U50E USB extension cable if a direct connection causes a USB device to protrude from the

headunit in a way that can interfere with driving.

USB PC

USB Direct Connection for iPod and iPhone

DEH-P7150UB*

Pioneer’s new headunit is ready to roll with capability for direct connection** to iPod

nano, iPod or iPhone. File search and access are extra-quick. The headunit keeps song,

artist, time and album information displays very clear and user-friendly.

*Does not apply to iPhone. ** CD-IU50 required

DEH-P5150UB DEH-4150SD FH-P6050UB*

CD-U50E

USB Extension Cable

50 cm cable optionally available for connecting

a headunit with built-in USB port to an external

USB device.

Speedier Search Using iPod and iPhone

DEH-P5150UB DEH-4150SD

Now, Pioneer’s latest headunits are even easier to enjoy along with an iPod than previous

headunits. A new USB mechanism speeds up “List Search”, refined processing speeds up

“Alphabetical Search” and the Rotary Commander speeds up access to any file in the iPod.

Multiple Connections—SD Memory Card, USB Device, iPod/iPhone, Portable Media Player and AUX-in

USB connector-male

CD-IU50*

Interface Cable for iPod and iPhone

USB device

Portable media player’s

original cable

Not compatible with DRM contents

for portable media player

Composite image shown in

iPhone and iPod display

iPod

SD memory card

AUX-in**

iPhone Portable media player and

external auxiliary devices

* CD-IU50 Interface Cable for iPod and iPhone optionally available for connecting an iPod or iPhone to the DEH-P7150UB,

DEH-6150BT, DEH-P5150UB, DEH-4150SD and FH-P6050UB.

Please see page 30 for details about iPod compatibility with Pioneer headunits.

A 3rd or 4th generation iPod requires CD-IB100II.

**Conventional Mini-Jack cable required.

DEH-4150SD

DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG

DEH-6150BT

Audio Headunits

DEH-3150UB 4-Channel High-Power WMA/MP3/CD Receiver with USB Direct Connection NEW

•Direct AUX-in by mini jack (front)

•Front USB direct connection: USB 2.0 (full speed)

•Advanced Sound Retriever

•Rotary volume

•2 RCA pre-outs (front + rear)

•Wired remote control input

Front AUX-In Connection

Hook up your portable digital devices with ease in an instant. Each new Pioneer

headunit has a built-in AUX input on its front panel for connecting a portable media

player and external auxiliary devices.

Wired Remote Control Input

Since entertainment shouldn’t compromise driving safety, Pioneer engineered this

feature for cars with factory-equipped remote control installed on the steering wheel

to give drivers more convenient control of a Pioneer headunit without having to take

their hands off the wheel.

Display Off Enhances Security and Ambience

To avoid unwanted attention and indulge more completely in the listening experience,

press and hold the DISP OFF button for two seconds, and all headunit illumination and

display lights (except that for the DISP OFF button) turn off instantly, even while the

headunit is in playback mode.

DEH-P7150UB DEH-6150BT

To minimize voltage loss in its headunit amplifiers, Pioneer built-in high-performance

Power MOSFET integrated circuitry that processes signals efficiently at 50 W × 4

maximum total output.

High-speed MOSFET switching reduces distortion to virtually nothing at high

frequency ranges, thanks to superior characteristics of linearity that smooth the signal

transmission path from input to output. Pioneer’s independent routing of input and

output current is essential to obliterating distortion.

High power of 50 W per channel and characteristics of the bonding wire ensure

excellent sound quality. The 99.99 % pure OFC (oxygen-free copper) bonding wire

has low electrical resistance, so minimal electric power is lost as heat in the IC chip,

enhancing power handling efficiency as well as sound quality.

Built-in 50 W × 4-Channel High-Power

MOSFET Amplifier

ALL AUDIO HEADUNITS*

Bass Boost

Bass Boost offers a choice between 0 dB to 12 dB level settings that can be adjusted

in 2 dB steps, letting you set the optimal bass level for each speaker and subwoofer

connected to a system, according to preference and music style. The result is more

precise control over the balance of sounds to enhance the overall impact of the music

you listen to.

DEH-P7150UB DEH-6150BT DEH-P5150UB

Bass Boost (fc = 100 Hz)

Gain [dB]

–2

Frequency [Hz]

1000.010.0 100.0 10000.0 100000.0

Power MOSFET high-power IC chip

DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG

DEH-1150MPG

RS-D7RII

DEH-P5150UB DEH-4150SD FH-P6050UB

DEX-P90RS DEH-P80RSII

DEH -P 7150 UB DEH -6150 BT

DEH-2150UBG

DEH-P5150UB DEH-4150SD DEH-3150UB

*Except KEH-P2035, RS-D7RII and DEX-P90RS

DEH-4150SD FH-P6050UB

DEH-4150SD: SD Memory Card Formats and Features for Playback

Applicable Logomarks •

•*

Max. Memory Capacity 16 GB

File System FAT16/32

NOTES: “SD”, “SDHC”, “miniSD”, “miniSDHC”, “microSD” and “microSDHC” Logos are trademarks.

SDHC stands for SD High Capacity memory card.

*Maximum capacity of applicable “miniSDHC” and “microSDHC” memory cards is 8 GB (as of September 2008).

Decoding Format MP3 MPEG-1/-2 Audio Layer-3

WMA Version 7/7.1/8/9/10/11 (2-ch. audio)

AAC MPEG-4 AAC (iTunes encoded only)

(version 7.7 and earlier versions)

WAV Linear PCM, MS ADPCM (non-compressed)

Text Data File/Folder Name • (64 bytes)

FF/REV & Pause •

Scan/Repeat • (File/Folder)

Random Play • (Folder/All)

Audio Headunits

NEW

DEH-2150UBG 4-Channel High-Power WMA/MP3/CD Receiver with USB Direct Connection

Distribution of the model is limited to certain areas.

•Direct AUX-in by mini jack (front)

•Front USB direct connection: USB 2.0 (full speed)

•Advanced Sound Retriever

•Rotary volume

•1 RCA pre-out (rear)

•Wired remote control input

DEH-1150MPG 4-Channel High-Power WMA/MP3/CD Receiver

•Direct AUX-in by mini jack (front)

•BMX (Bitmetric Equalizer)

•Rotary volume

•1 RCA pre-out (rear)

NEW

EEQ (Easy Equalizer)

ALL AUDIO HEADUNITS*

Sound shaping is at your command. You can adjust the sound according to in-car

acoustic characteristics and the music you listen to.

5-Mode Preset Equalizer

You can switch among five preset equalization curves* (Super Bass/Powerful/Natural/

Vocal/Flat) simply by pushing an EQ button. Each of these settings boosts bass and

high-frequency ranges in ways that suit the music best.

* Dynamic/Powerful/Natural/Vocal/Flat in the DEH-3150UB, DEH-2150UBG and DEH-1150MPG.

2-Mode Custom Preset Equalizer

Create and memorize your favorite equalization curves from an amazing variety of

sound-shaping dimensions and combinations, just as you like. Custom-1 mode can

memorize adjusted preset curves using 7-band* digital equalizer settings for each

source (Source EQ memory). Custom-2 mode can register your favorite custom curve

(based on Flat mode** curve) for all sources using the 7-band* digital equalizer.

**L/R independent 16-band for DEH-P80RSII.

** Flat mode also remains after customizing equalization curve.

1-Mode Custom Preset Equalizer

Pioneer’s headunits feature a 1-mode custom preset equalizer for creating your favorite

sound curve from an amazing variety of sound-shaping dimensions/combinations

exactly as you like. This mode can memorize adjusted preset curves by 3-band

parametric equalizer* settings for each source.

* Bass/mid/treble equalizer for DEH-3150UB, DEH-2150UBG and DEH-1150MPG.

2-Way Crossover (HPF/LPF)

Our most feature-loaded models allow extra EEQ flexibility with selectable HPF

(High Pass Filter) and LPF (Low Pass Filter). Headunits of these systems can perform

as amplifiers or separate crossover units for easier system control, particularly of

low-frequency signals.

3-Mode Selectable Loudness

Select among three levels (high/mid/low) to instantly boost volume when driving

noise overpowers in-car sound.

2-Mode Selectable Loudness

Select high or low volume boost level when extraneous noise drowns out your

sound system.

Distribution of the model is limited to certain areas.

DEH-P7150UB DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG DEH-1150MPG FH-P6050UB DEH-P80RSII

5-mode preset equalizer ● ● ● ● ● ● ● ● ●

Custom preset equalizer 2 1 2 1 1 1 1 2 2

<2 = 2-mode, 1 = 1-mode>

Digital graphic equalizer

<16 = 16-band, 7 = 7-band> 7 7 7 16, L/R

2-way crossover: HPF/LPF ● ● ● ● ● L/R

3-band parametric equalizer ● ●

Bass Boost ● ● ● ● ●

Selectable loudness 3 3 3 3 2 2 2 3 3

<3 = 3-mode, 2 = 2-mode>

Nuance control ● ● ● ●

*Except KEH-P2035, RS-D7RII and DEX-P90RS

Audio Headunits

CDX-P1280

FH-P6050UB 4-Channel High-Power WMA/MP3/AAC/CD Receiver with USB Direct Connection

•3-line segmented OEL (Organic EL) display

•Direct AUX-in by mini-jack (rear)

•USB direct connection: USB 2.0 (full speed)

•Direct connection for iPod (CD-IU50 required)

•Bluetooth® adapter ready

•Advanced Sound Retriever

•EEQ

—

7-band digital graphic equalizer

•Rotary Commander

•Direct Sub Drive

•2 RCA pre-outs: front + rear/subwoofer

(selectable)

3-Line Segmented OEL Display

FH-P6050UB

Pioneer’s 2-DIN WMA/MP3 player FH-P6050UB features an extra-large, wide display

with 3-line Segmented OEL of outstanding contrast and brightness. The 3-line

character section offers a clear, uncluttered readout of artist, song title and operation

menu data throughout a wide viewing angle range.

2-DIN Player

Multi-CD Players

Cassette Player

CDX-P1280

IP-Bus 12-Disc Multi-CD Player

CDX-P680

IP-Bus 6-Disc Multi-CD Player

•CD-R/RW playback with skip play

•ADPS (Automatic Disc Program Selection)

•Disc title memory: 100 titles

•ITS (Instant Track Selection)

KEH-P2035

4-Channel High-Power Cassette Receiver

•Adapter ready for iPod (external unit control)

•BTB (Bass/Treble Booster)

•2-mode selectable loudness

•1 RCA pre-out (rear)

•Radio intercept

•Multi-CD control (pause and repeat)

Accessories

(1) Audio only. (2) Does not apply to iPhone. (3) External control. (4) CD-IU50 connection cable (for music playback only) also available. (5) A 3rd or 4th generation iPod requires CD-IB100II.

† Not every device is compatible. See more details in Pioneer website. Compatible with MSC (Mass Storage Class). Not compatible with DRM (Digital Rights Management) contents.

†† Please use CD-U50E USB extension cable if a direct connection causes a USB device to protrude from the headunit in a way that can interfere with driving.

AUDIO/VIDEO

Connect With Your Portable

What you can do with. . .

AUDIO HEADUNITS

Any Portable

Full Control for iPod & iPhone

iPod

Control USB Device†Bluetooth® Hands-Free

AUX Input USB Mass Storage Class Mobile Phone

FH-P6050UB Built-In CD-IU50(2)(5) Built-In

DEH-1150MPG Built-In (Front)

AVH-P6050DVD Built-In(1)

CD-BTB200/CD-BTB100

CD-IB100II(2) CD-UB100(3)

DVH-3150UB Built-In (Front)††

Built-In(1) (Front)

AVH-P7950DVD CD-IB100II(2) CD-UB100(3)

CD-BTB200/CD-BTB100

Built-In(1)

iPhone

Access SD Card

SD memory Card

DEH-6150BT Built-In (Front) Built-In (Front)††

CD-IU50(5) Built-In

DEH-3150UB Built-In (Front) Built-In (Front)††

DEH-2150UBG Built-In (Front) Built-In (Front)††

DEH-4150SD Built-In (Front) CD-IU50(5) Built-In (Front)†† Built-In

DEH-P80RSII Built-In CD-IB100II(2)

CD-BTB200/CD-BTB100

(3)

CD-UB100(3)

DVH-P4150UB Built-In (Front) CD-IU50V(4) Built-In (Front)††

CD-BTB200/CD-BTB100

DEH-P7150UB Built-In Built-InCD-IU50(2)(5)

CD-BTB200/CD-BTB100

DEH-P5150UB Built-In (Front) Built-In (Front)††

CD-IU50(5)

CD-BTB200/CD-BTB100

AVH-P3150DVD Built-In (Front) Built-In (Front)††

CD-IU50V(4)

CD-BTB200/CD-BTB100

AVH-P5150DVD Built-In CD-IU205V(2) Built-In

CD-BTB200/CD-BTB100

AVH-P4150DVD Built-In CD-IU200V(4) Built-In

CD-BTB200/CD-BTB100

Connection for iPod Table with

Pioneer Headunits

Software Version Direct Connection for iPod 2.0 2.0 2.3.0 1.2.1 1.3.0 1.1.2 1.1.5 2.1.1 1.4.1 1.3.1 1.3.1 1.1.3 1.0.2

Model Interface Use with

iPhone iPod

iPod iPod touch

iPod mini

iPod nano

iPhone

iPhone 3G

3rd gen. 4th gen. 5th gen. classic

1st gen. 2nd gen. 1st gen. 2nd gen. 3rd gen. 4th gen.

AVH-P7950DVD/AVH-P6050DVD IP-Bus CD-IB100II —(1)(2) —

(1)(2) A A A A A A(1) A A A A A(1)

AUX CD-RM10 A A — — A/V(3) — — — — — — — —

AVH-P5150DVD Direct Connection CD-IU205V —(2) —

(1)(2) A A A/V A/V A/V A/V(1) A A A A/V A/V(1)

AVH-P4150DVD USB Direct Connection for Video CD-IU200V A/V A/V — — A/V A/V A/V A/V — A A A/V A/V

USB Direct Connection for Music CD-IU50 A A — — A A A A — A A A A

AVH-P3150DVD USB Direct Connection for Video CD-IU50V A/V A/V — — A/V A/V A/V A/V — A A A/V A/V

USB Direct Connection for Music CD-IU50 A A — — A A A A — A A A A

DVH-P4150UB USB Direct Connection for Video CD-IU50V A/V A/V — — A/V A/V A/V A/V — A A A/V A/V

USB Direct Connection for Music CD-IU50 A A — — A A A A — A A A A

DVH-3150UB AUX 3.5 mm AUX Cable A A A A A A A A A A A A A

DEH-P80RSII IP-Bus CD-IB100II —(1) (2) —

(1)(2) A A A A A A(1) A A A A A(1)

AUX 3.5 mm AUX Cable

A A — — — — — — — — — — —

DEH-P7150UB USB Direct Connection for Music CD-IU50 — — — — A A A A — A A A A

IP-Bus CD-IB100II —(1)(2) —

(1)(2) A A — — — — A — — — —

DEH-P5150UB/FH-P6050UB USB Direct Connection for Music CD-IU50 A A — — A A A A — A A A A

IP-Bus CD-IB100II — — A A — — — — A — — — —

DEH-6150BT/DEH-4150SD USB Direct Connection for Music CD-IU50 A A — — A A A A — A A A A

AUX 3.5 mm AUX Cable

— — A A — — — — A — — — —

DEH-3150UB/DEH-2150UBG/DEH-1150MPG

AUX 3.5 mm AUX Cable

A A A A A A A A A A A A A

(1) Battery charge function not applicable. (2) A caution that “This accessory is not made to work with iPhone” appears on the display of an iPhone connected to the headunit. When an iPhone or iPhone 3G is connected to the headunit, car speakers may emit noise and

interference may occur in transmission of signals sent from and received by the iPhone or iPhone 3G. (3) Although video may not be browsed via headunit, it may be displayed on the iPod itself. TV out needs to be On. Use iPod for the full video operation.

Notes:

•Since some functions may be limited by the headunit, please refer to operation manual for details.

•Some functions may be limited, depending on iPod software version. This chart is based on information valid as of November, 2008. Please ask your nearest dealer for the latest information.

A: Plays audio

A/V: Plays audio and video

Accessories

Accessories for Portable Devices

NOTE: Unauthorized copying of music is strictly prohibited.

Not every device is compatible. See more details in Pioneer

website. Compatible with USB device only. Not compatible

with DRM (Digital Rights Management) contents and MTP

(Media Transfer Protocol) connection players.

A/V Accessories

Audio Accessories

NEW

CD-IU205V

Optionally available for connecting an iPod to the DEH-P7150UB,

DEH-6150BT, DEH-P5150UB, DEH-4150SD and FH-P6050UB.

NEW

CD-IU200V NEW

CD-IU50V

CD-IU50 Interface Cable for iPod and iPhone

50 cm cable optionally available for connecting

a headunit with built-in USB port to an external

USB device.

CD-U50E USB Extension Cable

CD-IB100II CD-UB100 IP-Bus USB

Adapter

CD-BTB200/CD-BTB100

Bluetooth® Adapter

CD-BTB200

CD-RM10

AUX Input-Video

CD-AD600

Optional Optical Digital Cable (6 m)

CD-AB50

Optional AV-Bus Cable (50 cm)

CD-AB300

Optional AV-Bus Cable (3 m)

AN-G3

Diversity TV Antenna with Built-In Booster

CD-AD150

Optional Optical Digital Cable (1.5 m)

CD-VS33

Audio/Video Selector

CD-V150M

Mini-Jack Cable for iPod

CD-HF1

Hands-Free Kit

*Not available for CDMA system

CD-IP150

Optional IP-Bus Extension Cable

CD-RB10

RCA Bus Interconnector

CD-SR100

Steering Remote Controller

RD-221

Power Supply Wiring Kit

RD-223

Optional Wiring Kit

RD-983

Alternator Noise Suppressor

RD-984

Alternator Noise Suppressor

RD-985

In-Line RCA Noise Suppressor

RD-SR520

High-Power Speaker Output to

RCA Adapter

Interface Cable for AVH-P5150DVD

with iPod

USB Interface Cable for

AVH-P4150DVD with iPod/iPhone

USB Interface Cable for

AVH-P3150DVD and DVH-P4150UB

with iPod/iPhone

Interface Adapter

for iPod

ODR & Pure Component Systems

PURER PERFORMANCE

FOR MAXIMUM PLEASURE

For the ultimate in-car sensation, Pioneer Reference Series (PRS) parts and components are engineered

to meet the highest standards of performance and efficiency. Optical Digital Reference (ODR) and Pure

Component Systems included in this series reproduce natural linear characteristics for sound as clear

as a breath of fresh air.

Four Pioneer car audio products including the

DEH-P80RSII and TS-D1720C won 2008 “Readers

Choice” honors awarded by readers of Germany’s

renowned autohifi car audio magazine.

TS-C171PRS

ODR & Pure Component Systems

DEH-P80RSII

PRS-D4200F

ODR & Pure Component Systems

ODR (Optical Digital Reference) and RS Speaker Systems

•High precision sound master clock circuitry

•Hi-quality CD drive

•Hi-bit conversion

•Digital direct

•Frequency change: 96 kHz to 44.1 kHz

•Source DVD control

•Digital optical input/output

•IP-Bus input/output

•External unit control via IP-Bus (2 units)

•AUX-in (with optional CD-RB20)

•White full dot OEL (Organic EL) display

•Auto-slide face

•Rotary volume (High quality feel is enhanced

by using aluminum for the volume and cross

key while adding spinning graved finish on it)

•Use of dual LED for button illumination

(white or red selectable)

•Display off mode

•OFC power/ground cable

•Dual illumination (white or red selectable)

Red illumination

Clock circuit board High-performance SHARC® DSP × 3

RS-D7RII Component CD Receiver

RS-P90RS-D7RII

The latest integrated circuits require superior clock

signal quality to handle digital data accurately without

distortion at ever-higher speeds. Dual independent

Sound Master Clock Circuitry in the RS-D7RII generates

clock waveforms to read and process digital signals with

ultra-precision, and eliminate jitter noise in transmission.

The result: extraordinarily clear, pure sound.

For remarkably precise 32-bit sound processing,

the circuitry of the RS-P90 is mounted with three

high-performance Analog Devices SHARC® DSPs, for

left-channel, right-channel and coefficient calculation.

•Advanced Segment 24-bit D/A Converter

•Digital listening position selector

•Time Alignment

•Parametric bass/treble control

•31-band L/R independent graphic equalizer

(1/3 oct.) with level control (±12 dB/0.5 dB

steps)

•3-band L/R independent parametric

equalizer (1/3 oct.) with level control

(±12 dB/0.5 dB steps)

•4-way independent L/R crossover network

(high/mid/low/subwoofer)

—

Crossover frequency: 20 Hz to 20,000 Hz

(1/3 oct.)

—

Crossover slope: 0 dB to –72 dB

—

Crossover presets: 5

•Gold-plated 8-channel RCA output

(high/mid/low/subwoofer)

•Gold-plated screw-type power/ground

terminals

•The one-sided terminals and the square

aluminum bonnet that rotates by every

90 degrees considered for installation

•High-performance 32-bit floating binary

point type DSP

RS-P90 Universal Digital Pre-Amplifier

Limited distribution

High-Precision Sound Master Clock Circuitry

High-Performance SHARC® Digital Signal Processors

ODR & Pure Component Systems

RS-A9

SHARC® DSP chip

RS-A9

Digital Integrated Power Amplifier

600 W Max. Limited distribution

RS-A7

Digital Power Amplifier

600 W Max. Limited distribution

•50 W × 4 (4 Ω)/75 W × 4 (2 Ω)/50 W × 2 + 150 W

× 1 (4 Ω)/150 W × 2 (4 Ω) (continuous power)

•100 W × 4 (4 Ω)/100 W × 2 + 300 W × 1 (4 Ω)/

300 W × 2 (4 Ω) (max. power)

•High-performance 32-bit floating binary point

type DSP

•Built-in DSP (Digital Signal Processor) (FIR)

—

31-band L/R independent digital

graphic equalizer (±12 dB/0.5 dB steps)

—

3-band L/R independent digital parametric

equalizer (±12 dB/0.5 dB steps)

—

5-mode preset memory

—

Time alignment

—

Digital listening position selector

—

Parametric bass/treble controls

—

Digital compression

—

4-way L/R independent digital crossover

network (high/mid/low/subwoofer)

—

Crossover frequency:

20 Hz to 20,000 Hz (variable)

—

Crossover slope: 0 dB

to –72 dB

•1 optical digital input

•3 optical digital outputs

(mid/low/subwoofer)

•50 W × 4 (4 Ω)/75 W × 4 (2 Ω)/50 W × 2 +

150 W × 1 (4 Ω)/150 W × 2 (4 Ω)

(continuous power)

•100 W × 4 (4 Ω)/100 W × 2 + 300 W × 1 (4 Ω)/

300 W × 2 (4 Ω) (max. power)

•2 optical digital inputs

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

Common Features

•Bridgeable 4/3/2-channel capability

•Current feedback amplifier

•Full balanced system (bridgeable

connection)

•Multi 24-bit Burr Brown D/A converters

•IP-Bus input/output

•Gold-plated screw-type speaker terminals

•Gold-plated large screw-type power/

ground terminals

•Low load impedance capability

(4 Ω, 2 Ω to 8 Ω allowable)

•Copper-plated chassis

•L/R independent power supply

•Sound master clock

•DAC volume

The TS-W01RSII’s magnetic circuit structure uses a voice coil with large ø140 mm

diameter to drive the center part of the entire speaker cone to improve transient.

Multiple neodymium magnets creating powerful

magnetic flux help drive the cone with exceptional

strength and accuracy.

The large vent in the center of the speaker back is

maximized for fine control to reduce air resistance.

The result: more accurate bass reproduction.

Compact Enclosure

We design our subwoofer cones for compact (14 to 28 liters) speaker enclosures.

Shallow mounting aluminum

die-cast basket and large

ø140 mm voice coil

Large ø140 mm Voice Coil

TS-W01RSII

•3.5 cm tweeter with ion-plated DLC (Diamond-like Carbon)-coated dual arc ring diaphragm

•High-performance magnetic circuit features lightweight aluminum

voice coil with neodymium magnet

•Zinc die-cast frame

•Tungsten cone holder with anti-resonance structure

•Aluminum die-cast mounting bracket included

•Gold-plated large screw-type terminals

•Use with UD-N01RSII 2-Way Passive Crossover Network

•Maximum input: 120 W

•Nominal input: 50 W

TS-T01RSII

3.5 cm Component Tweeter

•17 cm cone mid-bass speaker with multiple pulp fiber composite diaphragm

•Ion-plated DLC (Diamond-like Carbon)-coated titanium center cap

•Corrugated surround with damped coating on front

and back edges

•High-Transient Short Voice magnetic circuit features

copper ribbon short voice coil with neodymium magnet

•Bottom hold design zinc die-cast one-piece chassis

•Tungsten damper holder with anti-resonance structure

•Gold-plated large screw-type terminals

•Use with UD-N01RSII 2-Way Passive Crossover Network

•Maximum input: 120 W

•Nominal input: 50 W

TS-M01RSII

17 cm Component Mid-Bass Speaker

•7.7 cm cone midrange speaker with multiple pulp fiber

composite diaphragm

•Ion-plated DLC (Diamond-like Carbon)-coated titanium

center cap

•Corrugated surround with damped coating on

front and back edges

•High-Transient Short Voice magnetic circuit

features copper ribbon short voice coil with

neodymium magnet

•Bottom hold design zinc die-cast one-piece chassis

•Tungsten damper holder with anti-resonance

structure

•Zinc die-cast back basket

•Gold-plated large screw-type terminals

•Maximum input: 50 W*/60 W**

•Nominal input: 15 W

TS-S01RSII

7.7 cm Component Midrange Speaker

* With speaker unit only

** With back chamber

•25 cm cone woofer with multiple pulp fiber composite

diaphragm and integrated center cap

•Space-saving small-enclosure-type design

(recommended enclosure:

14 l to 28 l/0.49 cu.ft. to 0.99 cu.ft.)

•Corrugated fiber surround with damped

coating on front and back edges

•Large-sized ø140 mm voice coil

with multiple neodymium magnets

•Shallow mounting aluminum

die-cast basket

•Gold-plated large screw-type terminals

•Maximum input: 300 W

•Nominal input: 150 W

TS-W01RSII

25 cm (10") Component Subwoofer

•Use with TS-M01RSII and TS-T01RSII

UD-N01RSII

2-Way Passive Crossover Network

120 W Max.

50 W*/60 W** Max.

300 W Max.

120 W Max.

Ion-plated DLC (Diamond-like Carbon)-coated titanium center cap is superior in

rigidity, and concave to suppress resonance in the magnetic circuit.

High-Transient Short Voice magnetic circuit achieves excellent sound linearity from

high to mid-range and features a high number of turns of wire in the short lightweight

voice coil (for voice coil drivability that is 15 % better than its predecessor).

Corrugated surround with damped coating on

front and back edge effectively absorbs unwanted

vibration, achieves excellent linearity and reduces

interference of cone and surround.

High-Quality Mid-Bass Speaker

TS-M01RSII

Corrugated surround

The TS-T01RSII’s Dual Arc Ring Diaphragm, based on Pioneer’s

Super Wide Range Tune innovation, reliably reproduces clear

sound audible up to super-high 48 kHz frequency.

The inside and outside of the center drive-type ring

diaphragm are shaped differently from each other, and

vibrate to varying degrees for various frequencies. These

frequencies are mixed to achieve smooth characteristics

for superior sound reproduction. The light diaphragm has

a surface that is ion-plated with DLC (Diamond-like Carbon)

coating for extra rigidity and minimal distortion. 35 mm in

diameter, the diaphragm also contributes to excellent low

frequency reproduction and precise, accurate sound staging.

Dual arc ring diaphragm

TS-T01RSII

Dual Arc Ring Tweeter Diaphragm

ODR & Pure Component Systems

HQ Active Component Systems

•White full dot OEL (Organic EL) display

•Source DVD control

•Multi 24-bit D/A Converters with

8× oversampling digital filter

•Rotary volume

•Auto-slide face

•3 gold-plated RCA pre-outs (front + rear + non-fading)

•Optical input/output

•External unit control via IP-Bus (2 units)

•AUX-In (with optional CD-RB20)

•High-quality hairline aluminum front panel

•Display off mode

DEX-P90RS Component CD Receiver

•Built-in DSP

•31-band L/R independent digital equalizer

•4-way independent L/R crossover network

(high/mid/low/subwoofer)

•Optical input (with DEX-P90RS)

•Gold-plated 8-channel RCA output

(high/mid/low/subwoofer)

•Gold-plated screw-type power/ground terminals

•High precision sound master clock circuitry

•Hi-bit conversion

•Frequency change: 96 kHz to 44.1 kHz

•Adapter ready for iPod

•Source DVD control

•2 optical inputs & 1 optical output

•IP-Bus input/output

•2 RCA audio inputs

•AUX-in for digital audio

(TOS/Coaxial)

•External unit control via

IP-Bus (2 units)

•White full dot OEL

(Organic EL) display

•Display off mode

•Audio unit control (with DEQ-P90)

AXM-P90RS

Sources can include DVD, iPod,

portable digital player, etc.

Factory Equipped Audio System

DEQ-P90 Power

Amplifier Speaker

DEQ-P90 Component Digital

Signal Processor AXM-P90RS Audio Master Unit

AXM-P90RS Connection Example

•30 cm (12") enclosure use subwoofer

•KEVLAR® Brand Fiber/pulp composite

cone with integrated VCCS (Voice Coil

Cooling System)

•Dual-layer rolled urethane surround

•Dual Voice Coil (DVC) design (2 × 4 Ω)

•4-spoke aluminum die-cast basket

•Gold-plated binding posts

•Small enclosure capability

•Spoke grille compatible (UD-G308)

•Maximum input: 1,200 W

•Nominal input: 300 W

•3-layer aramid fiber with IMPP

composite cone

•Heat-resistant ribbon voice coil

•High density micro fiber surround for

smoother response

•Aluminum die-cast basket

•Gold-plated screw-type terminals

•Spoke grille included

•Maximum input: 200 W

•Nominal input: 50 W

•Dual layer cone with aramid and pulp

•High density micro fiber surround for

smoother response

•Heat-resistant ribbon voice coil with

neodymium magnet

•Glass cloth voice coil bobbin

•Aluminum die-cast basket

•Gold-plated screw-type terminals

•Spoke grille included (removable

magnet cover for flexible mounting)

•Maximum input: 60 W

•Nominal input: 15 W

•28 mm polyester soft-dome tweeter

with dual neodymium magnet

•Heat-resistant voice coil

•Aluminum die-cast cabinet

•Gold-plated screw-type terminals

•Surface, flush or invisible tweeter

mounting kit

•Maximum input: 200 W

•Nominal input: 50 W

TS-W12PRS

30 cm (12") Component PRS Subwoofer

TS-M171PRS

17 cm Component PRS Mid-Bass Speaker

TS-S101PRS

10 cm Component PRS Midrange Speaker

TS-T031PRS

28 mm Component PRS Soft-Dome Tweeter

1,200 W Max. 200 W Max. 60 W Max. 200 W Max.

The Ultimate in Audio Tech

For Component Single-CD Player

Hi-Bit Conversion

The RS-D7RII and DEX-P90RS upgrade the original CD audio signals from 16-bit

to 24-bit, and increase CD data resolution by a factor of 256. The result: lower

quantization noise, expanded dynamic range, minimal processing error, and

superior linearity, delivering sound as it was meant to be reproduced and heard.

For Digital Signal Processor

Time Alignment

Signal output of each speaker can be calibrated in 1/20,000-

second* increments, for optimal phasing of sound from the

system, according to listener position. Precise equalization and

suppression of frequency response disturbance makes for a clearer,

more focused soundstage.

*RS-A9: 1/40,000-second

Digital delay processing makes all speakers sound as if they are virtually equidistant from the listener,

for a clearer, front-focused soundstage.

RS-D7RII DEX-P90RS

DEQ-P90

RS-A9 RS-P90

Limited distribution

Upgrade from Factory-Equipped to Pioneer Pure Audio Components

With a AXM-P90RS, a car’s factory-equipped audio system can be upgraded for superior sound from various external

devices. Use it with a DEQ-P90 for control and balance that Pioneer’s advanced digital signal processing (DSP) provides.

ODR & Pure Component Systems

•50 W × 4 (4 Ω)/100 W × 2 (4 Ω)/50 W × 2 +

100 W × 1 (4 Ω)/50 W × 4 (2 Ω) (continuous power)

•100 W × 4 (4 Ω)/100 W × 2 + 200 W × 1 (4 Ω)/

200 W × 2 (4 Ω) (max. power)

•Bridgeable 4/3/2-channel capability

•Current feedback amplifier

•L/R independent power supply

•L/R symmetric layout circuit

•Input level/gain control (400 mV to 6.5 V)

(L/R independent)

•Low load impedance capability

(4 Ω, 2 Ω to 8 Ω allowable)

•Gold-plated RCA input terminals

•Gold-plated large block-type speaker terminals

L/R symmetric circuit layout

improves channel separation.

Stabilizes the amplifier and it’s internal

componentry by absorbing outer

vibration with superior speed.

Left and Right Channel

Independent Power SupplyH-Shaped Chassis

TVC (Total Vibration Control) Technology

For superior sound quality across a wide

spectrum, Pioneer’s TVC (Total Vibration

Control) technology thoroughly suppresses

vibration from parts and mechanisms that

can interfere with sound.

PRS-A900 4/3/2-Channel Bridgeable Power Amplifier 400 W Max.

The pride of a winner takes world-leading DNA

•750 W × 1 (4 Ω)/1,500 W × 1 (2 Ω)/

2,000 W × 1 (1 Ω) (continuous power)

•1,500 W × 1 (4 Ω)/3,000 W × 1 (2 Ω)/

4,000 W × 1 (1 Ω) (max. power)

•0/1-gauge, large block-type

gold-plated power/ground

terminals

•500 W × 1 (4 Ω)/1,000 W × 1 (2 Ω)/

1,200 W × 1 (1 Ω) (continuous power)

•1,000 W × 1 (4 Ω)/2,000 W × 1 (2 Ω)/

2,400 W × 1 (1 Ω) (max. power)

•4-gauge, large block-type gold-

plated power/ground terminals

•PWM regulated power supply with

MOSFET switching

Common Features

•Variable LPF (40 Hz to 240 Hz, –24 dB/oct.)

•Input level control (400 mV to 6.5 V)

•Low load impedance capability (1 Ω to 8 Ω)

•Gold-plated RCA input and output terminals

•4-gauge, large block-type gold-plated speaker terminals

•Variable Bass Boost Remote (40 Hz to 120 Hz, 0 dB to +12 dB)

•Subsonic filter (20 Hz, –24 dB/oct.)

•SYNC control

•High-performance balanced isolator circuit

•High-efficiency MOSFET output section

•MASS (Multiple Amplifier Synchronization System)

•Removable terminal/settings cover

PRS-D2000SPL

Class-D Mono Amplifier

PRS-D1200SPL

Class-D Mono Amplifier

4,000 W Max.

2,400 W Max.

Class-D Amplifiers

PRS-D2000SPL PRS-D1200SPL PRS-D1200M GM-D8400M GM-D7400M

Class-D amplifiers overcome the inefficiencies of traditional

Class-A or AB amplifiers. Pioneer’s Class-D amps transform

very little power into heat while a very high percentage

of the power supply (67 %) is transformed into the load.

This results in a very compact amp which needs little

input power to produce very high output power.

The Class-D amplifier’s PWM (Pulse Width Modulator)

modulates the original audio input signal with another

signal which has a much higher fixed frequency. The result

is a digital signal which contains the input signal and a

band of frequency components around the modulation

frequency. A LPF (Low Pass Filter) will then filter out the

high frequency pulses and the resulting amplified output

signal is then sent to the subwoofer and/or speakers.

Power output (Watt –4 Ω)

Current (A)

Class-AB

Class-D

0100 200 300 400 500

Current vs. Power

PRS-D2000SPL

Wiring for speaker must be 10 AWG minimum.

Load may be any combination of speakers but impedance must be 1 Ω or larger.

Load may be any combination of speakers but impedance must be 2 Ω or larger.

Mode select switch

must be in

MASTER position.

SYNC OUTPUT

SYNC INPUT

Signal source

1Ω minimum

2,000 W

R+

–

Mode select switch

must be in

MASTER position.

Signal source 2Ω minimum

4,000 W

–

R+

–

Mode select switch

must be in

SYNC INV position. +

–

PRS-D2000SPL

1Ω minimum

2,000 W

1Ω minimum

2,000 W

–

Mode select switch

must be in

MASTER position.

Signal source

R+

–

Mode select switch

must be in

SYNC position. +

–

With the PRS-D2000SPL, PRS-D1200SPL and PRS-D1200M’s SYNC connection, adjustment

of the master amplifier also adjusts all other amplifiers in the cascade. This makes control

simpler and more convenient.

* These are only a few examples of connection configurations for the PRS-D2000SPL. Ask your nearest car

stereo installer or dealer about power/ground wiring and installation details for the PRS-D2000SPL,

PRS-D1200SPL and PRS-D1200M.

*1 Ω minimum speaker impedance for this configuration or damage will occur.

**2 Ω minimum speaker impedance for this configuration or damage will occur.

Caution: Having more than four amps in a sync configuration is not recommended.

Sine waves can put excessive stress on an audio system, so if a sine wave source is used at high

output level, damage can occur.

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

PRS-D2000SPL

MASS (Multiple Amplifier Synchronization System) Connection Examples

PRS-D2000SPL PRS-D1200SPL PRS-D1200M

Single-Amplifier Configuration*: 2,000 W RMS

Two-Amplifier Bridged Configuration**: 4,000 W RMS

Two-Amplifier Configuration*: 4,000 W RMS

•Gold-plated large block-type power/ground

terminals

•High-performance balanced isolator circuit

•Multi Emitter Bipolar Transistor

•TVC (Total Vibration Control) technology

Input

signal

PWM

signal

Amplified

PWM

signal

Output

signal

COM Modulator

MECC Control

Power stage Output filter

ODR & Pure Component Systems

•White full dot OEL (Organic EL) display

•Adapter ready for iPod

•USB adapter ready (external unit control)

•Bluetooth® adapter ready (external unit control)

•Burr Brown advanced segment-type 24-bit D/A

Converter

•Built-in DSP

—

EEQ

—

Auto EQ

—

Auto EQ for 3-way network

—

Auto time alignment

—

BBE® digital sound processing

—

Digital listening position selector

—

BMX (Bitmetric Equalizer)

—

L/R independent 16-band digital graphic equalizer

—

L/R independent 2-way crossover: HPF/LPF

—

L/R independent 3-way crossover: high/mid/low

—

3-way digital network

•Auto-slide face

•Rotary Commander

•3 gold-plated RCA pre-outs (front + rear + subwoofer)

•Level indicator (L/R independent)

•Spectrum analyzer

•Multi-language display (English/Spanish/Portuguese)

High-quality Burr Brown

D/A converter

•Normal mode: 400 W × 1 (4 Ω)/600 W × 1 (2 Ω)

(continuous power)

• Hi-current mode: 150 W × 1 (4 Ω)/300 W × 1

(2 Ω)/600 W × 1 (1 Ω) (continuous power)

• 800 W × 1 (4 Ω)/1,200 W × 1 (2 Ω)

(max. power)

• Single-ended output circuit

• Variable LPF (40 Hz to 240 Hz, –18 dB/oct.)

• Input level control (400 mV to 6.5 V)

• Low load impedance capability (1 Ω to 8 Ω)

• Gold-plated RCA input and output terminals

• Gold-plated large block-type speaker

terminals

• Gold-plated large block-type power/ground

terminals

• All terminals placed on one side

• Removable terminal/settings cover

• Speaker level input (1.6 V to 26 V)

• Speaker line input turn-on sensor

• Bass Boost Remote

(50 Hz, 0 dB/+6 dB/+9 dB/+12 dB)

• Subsonic filter (20 Hz, –18 dB/oct.)

• SYNC control

• High-performance balanced isolator input

circuit

• High-efficiency MOSFET output section

• MASS (Multiple Amplifier Synchronization

System)

• TVC (Total Vibration Control) technology

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

DEH-P80RSII Component CD Player/Receiver

PRS-D4200F

•75 W × 4 (4 Ω)/300 W × 2 (4 Ω)/75 W × 2 +

300 W × 1 (4 Ω)/150 W × 4 (2 Ω)

(continuous power)

•150 W × 4 (4 Ω)/150 W × 2 + 600 W × 1 (4 Ω)/

600 W × 2 (4 Ω) (max. power)

•Bridgeable 4/3/2-channel capability

Class-FD 4/3/2-Channel

Bridgeable Amplifier

Gold-plated large block-type

power/ground terminals

Gold-plated RCA input/output

terminals

PRS-D4200F

PRS-D2200T

•150 W × 2 (4 Ω)/600 W × 1 (4 Ω)/300 W × 2 (2 Ω)

(continuous power)

•300 W × 2 (4 Ω)/1,200 W × 1 (4 Ω) (max. power)

•Bridgeable 2/1-channel capability

•Bass Boost Remote (50 Hz, 0 dB/+6 dB/+9 dB/+12 dB)

Common Features

•Variable LPF/HPF (40 Hz to 500 Hz, –12 dB/oct.)

•Input level control (400 mV to 6.5 V)

•Low load impedance capability (4 Ω, 2 Ω to 8 Ω allowable)

•Gold-plated RCA input and output terminals

•Gold-plated large block-type speaker terminals

•Gold-plated large block-type power/ground terminals

•All terminals placed on one side

•Removable terminal/settings cover

•Speaker level input (1.6 V to 26 V)

•Speaker line input turn-on sensor

•High-performance balanced isolator input circuit

•High-efficiency MOSFET output section

•TVC (Total Vibration Control) technology

PRS-D4200F PRS-D2200T

Pioneer brings together its cutting-edge Class-D circuitry and ICEpower digital

amplifier technology to create Class-FD (Full Range Class-D) ICEpower amplifiers that

deliver superior performance and sound quality in car entertainment. Combining

the unsurpassed efficiency of Class-D amps with the ultra-clean sound of Class-AB

amplifiers, COM (Controlled Oscillation Modulation) technology not only eliminates

unnecessary sensitivity to imperfect power supplies [1]—it compares the amplified

PWM (Pulse Width Modulation) signal with the original input signal [2], compensating

for any variance and lowering distortion in the process. MECC (Multivariable Enhanced

Cascade Control) compensating for load-dependent frequency response, improving

this response as this system receives analog signals from the output filter [3]. The result

is truer fidelity featuring tight bass with minimal lag effect; crisp, airy mids and highs;

and unsurpassed specifications contributing to qualities that outperform those of

other premium-quality amplifiers.

PRS-D1200M Class-D Mono Amplifier

Reference Sound Systems

1,200 W Max.

Class-FD 2/1-Channel

Bridgeable Amplifier

Class-FD

ICEpower

Double loop

compensation

Class-D

Single loop

compensation

Class-A

Class-AB

Class-D

No compensation

Audio Quality

Efficiency

Class-FD ICEpower Amplifiers

1,200 W Max.

ODR & Pure Component Systems

GET CLOSER TO NATURE—

NEW OPEN & SMOOTH SOUND

With their extra-wide directivity, low tweeter crossover frequency and distortion, plus light, rigid IMPP cones,

Pioneer’s PRS speakers realize a level of in-car audio quality that deserves its own name: “Open & Smooth”

sound—a wide-open sound staging, rich, natural midrange and tweeter output with outstanding

smoothness and linearity.

Superior Directivity: Pioneer PRS Speakers

Pioneer PRS speakers always maintain more open, smooth,

expansive, multidimensional sound, without the dramatic

dips and inconsistencies that lesser speakers can produce

when angled in certain directions.

Rear view

TS-C171PRS

Dip

Pioneer PRS Speaker Other Manufacturer’s Speaker

•17 cm woofer

•28 mm lightweight soft-dome tweeter

•Shallow mount adapters included

•13 cm woofer

•28 mm lightweight soft-dome tweeter

Common Features

•3-layer aramid fiber with IMPP composite

cone

•High density micro fiber surround for

smoother response

•Short voice coil & wide magnetic field design

for symmetric & linear cone motion

•Dual OFC short ring for reduced distortion

•Aluminum die-cast bottom hold one-piece

rigid chassis

•Aluminum die-cast center plug

•Cancel magnet design for extremely high

density magnetic field

•Rear chamber for lower crossover frequency

•Aluminum die-cast tweeter chassis

•Surface (angled), flush or invisible tweeter

mounting kit

•Audiophile-grade outboard crossover

network included with –12 dB/oct. LPF/HPF

•Protection circuit and 3-step tweeter level

adjustment

•Gold-plated screw-type terminals

TS-C171PRS/TS-C131PRS

Tweeter Specifications

•Dimensions (W × H × D):

ø55 mm × 27.1 mm (surface mount)

•Mounting depth: 12.2 mm

•Cut-out dimensions: ø47 mm

*See page 63 for woofer dimensions.

TS-C171PRS

17 cm Packaged Component Speaker System

TS-C131PRS

13 cm Packaged Component Speaker System

200 W Max. 150 W Max.

Pioneer advances the proud heritage of its IASCA (International Auto Sound Challenge

Association) award-winning Premier Reference Series. These speakers’ superior

response, linearity and sound directivity improve low- and mid-frequency

reproduction, while making highs and lows sound smoother and more open.

Micro Fiber Surround: Maximum Musical Response

The strong, high-density micro fiber material surrounding the woofer of a PRS speaker

is very light and low in resistance and internal loss characteristics. This enhances

linearity of the short winding length of the voice coil, thereby optimizing efficiency.

Moreover, micro fiber doesn’t stretch so it does a better job than other materials to

control vibration and enables higher power input.

The result is faster response and more accurate

bass reproduction that allows all

music to be heard to greatest

advantage.

2nd-Generation Multilayer Cone: First-Class Sound Reproduction

For the PRS speakers, Pioneer also developed a multilayer woofer cone in an even

better formulation, sandwiching composite foamed IMPP using interlaced aramid fiber

between a woven carbon-blended aramid fiber layer and a glass fiber layer. This rigid

cone structure provides impeccable midrange frequency reproduction and overall

sound quality. The cone material is also supremely light and uniform in its physical

properties because it is made without adhesives

using an advanced injection molding process.

Cancel magnet

Absorbent

Protector

Soft-dome diaphragm

Main magnet

Aluminum flange and

back cabinet

OFC short ring

Back chamber

Ø1-7/8" (48 mm)

large-diameter voice coil

3-layer aramid fiber with

IMPP composite cone

Micro fiber surround

Dual OFC short ring

Aluminum die-cast

bottom hold one-piece

rigid chassis

Overhung thick plate Voice coil with short winding length

Aluminum die-cast center plug

Rigidity ratio

2.50E+04

2.00E+04

1.50E+04

1.00E+04

0.50E+04

0.00E+04

New PRS

speakers

Internal loss

0.01 0.1

Better sound

1st-generatio n

Conventional

material

Physical properties of cone materials

Magnified cross section view

Glass fiber layer

Composite foamed IMPP using

interlaced aramid fiber

Aramid fiber layer

Polyester fiber

(polyurethane resin)

Magnified cross section view

Internal loss

0.6

0.5

0.4

0.3

0.2

0.1

Better sound

Micro fiber

Cloth

Rubber

Specific gravity

0 0.2 0.4 0.6 0.8 1.0 1.2 1.4

Urethane

PRS Speaker (Tweeter) Cross Section

PRS Speaker (Woofer) Cross Section

PRS Speakers

TS-C171PRS TS-C131PRS TS-M171PRS TS-S101PRS TS-T031PRS

•Maximum input: 200 W

•Nominal input: 50 W

•Maximum input: 150 W

•Nominal input: 30 W

Amplifiers & Subwoofers

PUNCH UP THE POWER, DIVE IN DEEP

It’s sensational how such compact components can create such massive impact. Pioneer’s Class-D

digital amplifiers keep every sound pristine, and perfectly match subs that inherit Pioneer’s

championship-winning SPL technology to generate punchy, nicely damped bass with the help

of light, rigid Basalt/Carbon fiber reinforced IMPP cones.

Regional

2007 1st Place dB Drag Extreme 5+ Class (178.9 dB)

National

2007 1st Place dB Drag Extreme 5+ Class (179.5 dB)

World

2007 1st Place dB Drag Extreme 5+ Class (178.9 dB)

World Record

1st Place Super Modified 4001 - 8000 (177.7 dB)

1st Place Super Modified 8001 - UP (181.1 dB)

1st Place Port Wars (181.2 dB)

1st Place Bass Olympics (174.9 dB)

2007 1st Place iDBL Ultimate 1 Class (176.2 dB)

2007 1st Place iDBL Ultimate 3 Class (178.2 dB)

Scott Owens, team leader of the Pioneer/Edge Audio team

PRS-D2000SPL

TS-W5102SPL

Amplifiers & Subwoofers

Pre-out level: 4 V

Normal

Pre-out level: 2 V

Pre-out level: 6.5 V

0.2 V6.5 V

Gain control of the unit

(GM-6400F)

Gain

NEW

GM-6400F

4/3/2-Channel Bridgeable Power Amplifier

600 W Max.

NEW

GM-5400T

2/1-Channel Bridgeable Power Amplifier

760 W Max.

•60 W × 4 (4 Ω)/60 W × 2 + 150 W × 1 (4 Ω)/150 W × 2 (4 Ω)/

75 W × 4 (2 Ω) (continuous power)

•120 W × 4 (4 Ω)/120 W × 2 + 300 W × 1 (4 Ω)/300 W × 2 (4 Ω)

(max. power)

•Bridgeable 4/3/2-channel capability

•LPF/HPF (80 Hz, –12 dB/oct.) for A and B channels

•RCA input and output terminals*

*Output for A-channel

•125 W × 2 (4 Ω)/380 W × 1 (4 Ω)/190 W × 2 (2 Ω)

(continuous power)

•250 W × 2 (4 Ω)/760 W × 1 (4 Ω) (max. power)

•Bridgeable 2/1-channel capability

•LPF (80 Hz, –12 dB/oct.)

•RCA input terminals

•Bass Boost (50 Hz, 0 dB/+6 dB/+12 dB)

Common Features

•Input level control (200 mV to 6.5 V)

•Input level/gain control

•Low load impedance capability (4 Ω, 2 Ω to 8 Ω allowable)

•Screw-type speaker terminals

•Large screw-type power/ground terminals

•Speaker level input (1.6 V to 26 V)

•PWM regulated power supply with MOSFET switching

•High-performance balanced isolator circuit

•Black metallic mesh with silver plate

GM-6400F

The Pioneer GM analog amplifiers are all equipped with the Gain Control,

a protective function that prevents malfunction of the unit itself, as well as the

speakers, caused by too much output, improper use and improper connection.

Even when the amplifiers are connected to the headunits with high-voltage

pre-outs, the signal is not clipped or distorted if the gain control is set to proper

position, so high S/N (Signal-to-Noise) ratio is realized in the speaker level signal.

To ensure continuous audio output, the amplifier’s gain control must be set

according to the pre-out maximum output level of the headunit. There is no need

to decrease the volume of the headunit, as too much output will be controlled.

Gain Control

GM-3300T

2/1-Channel Bridgeable Power Amplifier

300 W Max.

•60 W × 2 (4 Ω)/150 W × 1 (4 Ω)/75 W × 2 (2 Ω)

(continuous power)

•120 W × 2 (4 Ω)/300 W × 1 (4 Ω) (max. power)

•Bridgeable 2/1-channel capability

•LPF (80 Hz, –12 dB/oct.)

•High-voltage input level control (400 mV to 6.5 V)

•Input level/gain control

•Low load impedance capability

(4 Ω, 2 Ω to 8 Ω allowable)

•RCA input terminals

•Screw-type speaker terminals

•Large screw-type power/ground terminals

•Speaker level input (1.6 V to 26 V)

•High-performance balanced isolator circuit

•Black heatsink with aluminum plate

ALL POWER AMPLIFIERS* *Except RS-A9 and RS-A7

Amplifiers & Subwoofers

GM-D8400M

Common Features

•Single-ended output circuit

•Variable LPF

(40 Hz to 240 Hz, –12 dB/oct.)

•Input level/gain control (200 mV to 6.5 V)

•Low load impedance capability

(4 Ω, 2 Ω to 8 Ω allowable)

•RCA input terminals

•Large block-type speaker terminals

•Large block-type power/ground terminals

•Speaker level input (0.8 V to 26 V)

•Speaker line input turn-on sensor

•High-performance balanced isolator circuit

•High-efficiency MOSFET output section

•Black heatsink with aluminum plate

GM-D8400M

Class-D Mono Amplifier

1,200 W Max. GM-D7400M

Class-D Mono Amplifier

800 W Max.

•300 W × 1 (4 Ω)/600 W × 1 (2 Ω) (continuous power)

•600 W × 1 (4 Ω)/1,200 W × 1 (2 Ω) (max. power)

•Bass Boost Remote (50 Hz, 0 dB to 12 dB variable)

•200 W × 1 (4 Ω)/400 W × 1 (2 Ω) (continuous power)

•400 W × 1 (4 Ω)/800 W × 1 (2 Ω) (max. power)

•Bass Boost (50 Hz, 0 dB/+6 dB/+12 dB)

Same Powerful Output from a More Compact Amplifier

PRS-D2000SPL PRS-D1200SPL PRS-D1200M

GM-D8400M

A Class-D amp matches a more power-hungry

conventional amp’s output, but emits less heat.

For better sound quality and safer, more stable

amplification power, Pioneer designed their

Class-D amp circuitry to provide 2 Ω output

that is twice as powerful as 4 Ω output from

less efficient amplifiers.

GM-D7400M 100 % of the Power,

45 % of the Size

GM-D7400M

Conventional Model

(GM-7300M)

The superior efficiency of a Class-D

amplifier means higher power

output and greater compactness

than an analog amplifier offers.

RD-226 Power Cable

•For use with amplifier with screw terminal (60 A)

RD-223 Power Cable

•For use with amplifier with screw terminal (30 A)

RD-228 Power Cable

•For use with amplifier with block terminal

Amplifier & Speaker Connection Examples

GM-6400F

Continuous Power: 60 W × 4 (4 Ω)/60 W × 2 + 150 W × 1 (4 Ω)/150 W × 2 (4 Ω)/75 W × 4 (2 Ω)

Max. Power: 120 W × 4 (4 Ω)/120 W × 2 + 300 W × 1 (4 Ω)/300 W × 2 (4 Ω)

TS-W308D2

GM-5400T Continuous Power: 125 W × 2 (4 Ω)/380 W × 1 (4 Ω)/190 W × 2 (2 Ω)

Max. Power: 250 W × 2 (4 Ω)/760 W × 1 (4 Ω)

TS-W308D2

GM-6400F

TS-W308D2

GM-5400T Continuous Power: 125 W × 2 (4 Ω)/380 W × 1 (4 Ω)/190 W × 2 (2 Ω)

Max. Power: 250 W × 2 (4 Ω)/760 W × 1 (4 Ω)

TS-W308D4

4Ω

380 W

4Ω

150 W

4Ω

150 W

4Ω

150 W

60 W

Rear Speaker

TS-A6983S

Rear Speaker

TS-A6983S

8Ω

380 W

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

Continuous Power: 60 W × 4 (4 Ω)/60 W × 2 + 150 W × 1 (4 Ω)/150 W × 2 (4 Ω)/75 W × 4 (2 Ω)

Max. Power: 120 W × 4 (4 Ω)/120 W × 2 + 300 W × 1 (4 Ω)/300 W × 2 (4 Ω)

Amplifier & Subwoofer Connection Chart

Amplifiers Subwoofers

Shallow Subwoofers

Load

Continuous

Champion Series-PRO

Champion Series

Product No.

Channel

Impedance

Power

TS-W3002D4 TS-W2502D4

TS-W308D2 TS-W308D4 TS-W258D2 TS-W258D4

TS-W302R TS-W252R

TS-SW3001S4 TS-SW3001S2 TS-SW2501S4 TS-SW2501S2

TS-SW841D

TS-SW301 TS-SW251

1000W 800W 400W 400W 350W 350W 150W 120W 400W 400W 300W 300W 120W 250W 200W

PRS-D4200F

4-ch. 2 Ω 150 W × 4 • •

2 pc.

•앪 •

2 pc.

•앪 •

2 pc. Para 2 pc. Para

2 pc. Para

■

2 pc. Para

■

2 pc. Para

2 pc. Para 2 pc. Para

4 Ω 75 W × 4

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ ■ ■

2 pc. Series

■

2 pc. Series

■ ■ ■

2-ch. 4 Ω 300 W × 2

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 — — ■

2 pc. Series

■

2 pc. Series

— — —

PRS-D2200T

2-ch. 2 Ω 300 W × 2 • •

2 pc.

•앪 •

2 pc.

•앪 •

2 pc. Para

—

2 pc. Para

■

2 pc. Para

— —

2 pc. Para 2 pc. Para

4 Ω 150 W × 2

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ — ■

2 pc. Series

■

2 pc. Series

■ ■ ■

1-ch. 4 Ω 600 W × 1

2 pc.

•앪

2 pc.

•앪 —

2 pc.

•앪 —

2 pc.

•앪 — — —

2 pc. Series

— ■ — — —

PRS-D1200M

1-ch. 1 Ω 600 W × 1

2 pc.

•

2 pc.

• —

2 pc.

• —

2 pc.

• — — —

2 pc. Para

—

2 pc. Para

— — —

2 Ω 600 W × 1 • •

2 pc.

•앪 —

2 pc.

•앪 — — —

2 pc. Para

—

2 pc. Para

— — — —

4 Ω 400 W × 1

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 —

2 pc.

•앪 — — ■

2 pc. Series

—

2 pc. Series

— — —

GM-D8400M

1-ch. 2 Ω 600 W × 1 • •

2 pc.

•앪 —

2 pc.

•앪 — — —

2 pc. Para

—

2 pc. Para

— — — —

4 Ω 300 W × 1

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 — — ■

2 pc. Series

■

2 pc. Series

— — —

GM-D7400M

1-ch. 2 Ω 400 W × 1 • •

2 pc.

•앪 —

2 pc.

•앪 — — —

2 pc. Para

■

2 pc. Para

— —

2 pc. Para 2 pc. Para

4 Ω 200 W × 1

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 — — ■

2 pc. Series

■

2 pc. Series

— ■ ■

GM-6400F 4-ch. 2 Ω 75 W × 4 • •

2 pc.

•앪 •

2 pc.

•앪 •

2 pc. Para

■

2 pc. Para

■

2 pc. Para

4 Ω 60 W × 4

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ ■ ■

2 pc. Series

■

2 pc. Series

■

■ ■

2-ch. 4 Ω 150 W × 2

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ — ■

2 pc. Series

■

2 pc. Series

— ■ ■

GM-5400T 2-ch. 2 Ω 190 W × 2 • •

2 pc.

•앪 •

2 pc.

•앪 •

2 pc. Para

■

2 pc. Para

■

2 pc. Para

4 Ω 125 W × 2

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ — ■

2 pc. Series

■

2 pc. Series

— ■ ■

1-ch. 4 Ω 380 W × 1

2 pc.

•앪

2 pc.

•앪 —

2 pc.

•앪 —

2 pc.

•앪 — — ■

2 pc. Series

—

2 pc. Series

— — —

GM-3300T 2-ch. 2 Ω 75 W × 2 • •

2 pc.

•앪 •

2 pc.

•앪 •

2 pc. Para

■

2 pc. Para

■

2 pc. Para

2 pc. Para 2 pc. Para

4 Ω 60 W × 2

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 ■ ■ ■

2 pc. Series

■

2 pc. Series

■

■ ■

1-ch. 4 Ω 150 W × 1

2 pc.

•앪

2 pc.

•앪 앪

2 pc.

•앪 앪

2 pc.

•앪 — — ■

2 pc. Series

■

2 pc. Series

— ■ ■

Dual Voice Coil Single Voice Coil

(2 pc.: 2 pieces use)

앪: DVC series

wiring

Series:

Series wiring

■: Single

voice coil

•: DVC parallel

wiring

Para:

Parallel wiring

•앪: •or 앪

2 pc.: 2 pieces use

Amplifiers & Subwoofers

Extra-Strong Dust Cap Core with Foamed Acrylic Polymer

Dust caps on the TS-W8102SPL and TS-W5102SPL subwoofers feature a light, durable

heat-resistant foamed acrylic polymer core (between carbon-fiber and glass cloth

layers) that is up to about 36 times

as strong as conventional materials.

The result: greater capacity for extra

sound pressure, stability and power

in bass reproduction.

Dual Ceramic-Coated Voice Coils

Excess heat generated by subwoofers can compromise electrical-handling

performance, but Pioneer uses ceramic-

coated voice coil to double the capacity

of its sub woofers to handle input power

without short-circuiting. No wonder the

Pioneer TS-W5102SPL beat the competition

at 2005, 2006 and 2007 dB Drag Racing events.

Component SPL Subwoofers

*Patent pending

TS-W5102SPL Cross Section

Extended pole yoke

Composite IMPP cone using

interlaced carbon fiber*

Wide-roll, woven aramid fiber

radial rubber surround*

Super aramid

fiber damper*

Precision dual damper

Ceramic-coated voice coils*

Supporting wire*

Triple stack magnets

76 mm pure titanium voice coil former*

Extra-strong dust cap

Overhung surround

(US6782114B2)

Spider ring

Vented damper holder

30 mm thick top plate

ADMG (Aero-Dynamic

Magnetic Gap)

Bottom hold design

Ceramic thermal insulation

Adhesive layer

Electrical insulation

Copper wire

Carbon cloth

Foamed acrylic

polymer

Glass cloth

10 mm

Common Features

•Composite IMPP cone using interlaced carbon fiber*

•Carbon cloth/foamed acrylic polymer/glass cloth 3-layer rigid

dust cap

•Wide-roll, woven aramid fiber radial rubber surround*

•Overhung surround design*

•High-power handling ceramic-coated voice coil wire*

•Dual 76 mm (3"), high inductance, 6-layer, long voice coils

(DVC) (2 × 2 Ω)

•Titanium voice coil bobbin

•Dual aramid damper with woven tinsel wire and damper ring

•Precision dual aramid dampers

•Huge back plate and extended pole yoke with vented pole

•Huge 30 mm (1.2") thick top plate

•ADMG (Aero-Dynamic Magnetic Gap) design

•Aluminum die-cast one-piece rigid basket with bottom

hold design

•8-gauge wire terminal *Patent pending

TS-W8102SPL

38 cm (15") Component Competition-Level SPL Subwoofer

8,000 W Max. TS-W5102SPL

30 cm (12") Component Competition-Level SPL Subwoofer

6,000 W Max.

•Massive triple-stack magnet assembly

(11 kg: 3,700 g × 3/390 oz.: 8 lbs. 20 oz. × 3)

•Massive triple-stack magnet assembly

(9 kg: 3,000 g × 3/320 oz.: 6 lbs. 10 oz. × 3)

To generate resounding bass, the TS-W8102SPL and TS-W5102SPL subwoofers handle

high-power input and extreme sound pressure levels with absolute assurance, thanks

to design and construction durable enough to deliver consistently true, rock-steady

performance, even at extra-high volume throughout marathon listening sessions.

SPL (Sound Pressure Level) Subwoofer

TS-W8102SPL TS-W5102SPL

The pride of a winner takes world-leading DNA

•Maximum input: 8,000 W

•Nominal input: 3,000 W

•Maximum input: 6,000 W

•Nominal input: 2,500 W

Amplifiers & Subwoofers

Common Features

•Interlaced Basalt/Carbon fiber reinforced IMPP cone

•Wide-roll, 3-layer fiber woven aramid radial surround with

honeycomb cloth

•Phenol coated glass cloth former

•Air Suspension System

•Dual 4 Ω, 4-layer, long voice coil (2 Ω or 8 Ω)

•Extended and vented pole yoke

•Aluminum die-cast basket & magnet cover

The pride of a winner takes world-leading DNA

NEW

TS-W3002D4

30 cm (12") Component Subwoofer

3,500 W Max. NEW

TS-W2502D4

25 cm (10") Component Subwoofer

3,000 W Max.

•Double stack high power magnets (3,230 g/114 oz.)

•Spoke grille compatible (UD-G308)

•Maximum input: 3,500 W

•Nominal input: 1,000 W

•Double stack high power magnets (2,490 g/88 oz.)

•Spoke grille compatible (UD-G258)

•Maximum input: 3,000 W

•Nominal input: 800 W

Air Suspension System

TS-W3002D4 TS-W2502D4 TS-SW3001S4 TS-SW3001S2

Regular IMPP cone Long carbon fiber reinforced IMPP cone

Microscopic Cross Section View

For its revolutionary 3.25-inch-deep subwoofer, Pioneer created an air suspension system

effective within a 70 %-smaller-than-previous enclosure that locks air for a spring-like

effect between main and drive cones

moving in unison. The result is consistently

clear, powerful, wide-ranging bass

response. The subwoofer’s dual-cone

structure maintains better sound linearity

and reliability after hours of hard use than

conventional subwoofers with “spider”

structures to keep the voice coil aligned.

Air Suspension System for

Smaller Enclosure

70 % Smaller

Approximately 70 % smaller than previous enclosure.

Although aluminum die-cast baskets have been around for many years, not all are

created equal. Whereas other manufacturers purchase off-the-shelf designs, Pioneer’s

baskets were designed in-house, from scratch. Die-cast baskets also provide excellent

damping characteristics, to attenuate vibration quickly and prevent distortion.

Unlike other manufacturers’ designs, Pioneer’s basket cradles the bottom plate

and motor assembly. During high SPL levels there is a tremendous amount of pressure

placed on the motor assembly.

By supporting (cradling) the motor

assembly any unwanted flexing or

vibrations which can lead to energy

loss are prevented.

40.0

Impulse response

Aluminum die-cast basket

Real

Steel basket

–40.0

20 Avg 0 % Ovlp Hann

Fxd XY Sec. 200 m

Reduced backward motion

–40

20 70 120 170 Hz

Conventional basket

Bottom hold basket

–50

–60

–70

–80

–90

Vibration Attenuation (Damping) Comparison

Improved Chassis Rigidness

Preventing cone failure at high pressure levels requires an extremely rigid yet lightweight

cone. So Pioneer developed a patent-pending IMPP cone using a proprietary composite

blend of long carbon fibers and injection molded polypropylene. These materials were

chosen for their extraordinary strength and lightweight characteristics. The long carbon

fibers interlace together to form an incredibly resilient fiber weave, providing strength

and rigidity for powerful bass.

The TS-W8102SPL, TS-W5102SPL, TS-W3002D4 and TS-W2502D4 incorporate a

patent-pending Woven Aramid Fiber Radial Surround which improves power

handling and reduces distortion. Similar to a radial tire, the surround is constructed

of three layers—two consisting of rubber and one of interwoven aramid fiber.

The aramid fiber layer is designed with a “honeycomb” weave, which evenly

distributes strength throughout the surround material, eliminating any weak

points of surround and improving high-power capability. The result is an

extremely durable and resilient surround that resists “puckering” (distortion

often produced under extreme power conditions).

Benefits of Woven Aramid Fiber Radial Surround

•Improved power handling capability •Reduced distortion (anti-puckering design)

•Improved linear excursion •Louder, more accurate bass

The three layers are formed under a high-pressure, high-temperature

process. The result: an extremely durable and high-performance surround.

Bottom Hold Design Aluminum Die-Cast

One-Piece Chassis

TS-C171PRS TS-C131PRS TS-W8102SPL TS-W5102SPL

Carbon Fiber IMPP Cone

TS-W8102SPL TS-W5102SPL

Woven Aramid Fiber Radial Surround

TS-W8102SPL TS-W5102SPL TS-W3002D4 TS-W2502D4

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

TS-SW2501S4

TS-SW301 TS-SW251TS-SW2501S2 TS-SW841D

Amplifiers & Subwoofers

Dual Voice Coil Type Subwoofers The pride of a winner takes world-leading DNA

NEW

Common Features

•Interlaced Aramid/Basalt fiber reinforced IMPP composite cone

•3-layer, fiber woven radial surround

•Single large conex damper with damper ring

•Dual 4-layer, long voice coils (DVC) (2 × 2 Ω: TS-W308D2/2 × 4 Ω: TS-W308D4)

•ø56 mm (2") phenol coated glass cloth voice coil former for higher power

handling capabilities

•Double stack high power magnets (2.4 kg/83 oz.)

•Extended and vented pole yoke

•Integrated single-sided silver binding posts

•Spoke grille compatible (UD-G308)

•Maximum input: 1,400 W

•Nominal input: 400 W

TS-W308D4

Common Features

•Interlaced Aramid/Basalt fiber reinforced IMPP composite cone

•3-layer, fiber woven radial surround

•Single large conex damper with damper ring

•Dual 4-layer, long voice coils (DVC) (2 × 2 Ω: TS-W258D2/2 × 4 Ω: TS-W258D4)

•ø48 mm (2") phenol coated glass cloth voice coil former for higher power

handling capabilities

•Double stack high power magnets (2.1 kg/74 oz.)

•Extended and vented pole yoke

•Integrated single-sided silver binding posts

•Spoke grille compatible (UD-G258)

•Maximum input: 1,200 W

•Nominal input: 350 W

TS-W258D4

TS-W308D2

30 cm (12") Component Subwoofer

(2 Ω Dual Voice Coil Type)

TS-W308D4

30 cm (12") Component Subwoofer

(4 Ω Dual Voice Coil Type)

1,400 W Max.

NEW

TS-W258D2

25 cm (10") Component Subwoofer

(2 Ω Dual Voice Coil Type)

TS-W258D4

25 cm (10") Component Subwoofer

(4 Ω Dual Voice Coil Type)

1,200 W Max.

Integrated Single-Sided Silver Binding Posts

TS-W3002D4 TS-W2502D4 TS-W308D2 TS-W308D4 TS-W258D2

Pioneer’s Dual Voice Coil-type subwoofers have integrated binding posts at a single

side to simplify connection with an amplifier. To expand connection applications,

the TS-W308D2 and TS-W258D2 even feature a detachable cover and wire for binding

posts, so they can incorporate a 2 Ω Dual Voice Coil instead of a 4 Ω Single Voice Coil.

TS-W258D4

Connection & Wiring (for Dual Voice Coil Type Subwoofers)

TS-W3002D4 TS-W2502D4 TS-W308D2 TS-W308D4 TS-W258D2

TS-W258D4

NEW

UD-G308 with TS-W308D4

UD-G308/UD-G258

Optional Spoke Grille

Pioneer optional spoke grilles protect cone surface and enhance appearance of the subwoofers.

•UD-G308: TS-W3002D4/TS-W308D2/TS-W308D4/TS-W308F/TS-W302R/TS-W12PRS

UD-G258: TS-W2502D4/TS-W258D2/TS-W258D4/TS-W258F/TS-W252R

8Ω (D4)

4Ω (D2)

4Ω (D2) 4Ω (D2)

1 Ω or 2 Ω or 4 Ω

Bridged mono

(for 2 subwoofers)

2Ω or 4Ω Stereo 1 Ω or 2 Ω or 4 Ω

Bridged mono

2 Ω or 4 Ω or 8 Ω 2 Ω or 4 Ω 1 Ω or 2 Ω or 4 Ω

2Ω (D4) 2Ω (D4) 2Ω (D4)

1Ω (D2)

Wire

4Ω

1Ω

Single side

Compatible

Cover

4 Ω Single Voice Coil application

D2 Type (2 Ω Dual Voice Coil)

2Ω Dual Voice Coil

Cover and wire included

(Used only for 2 Ω connection)

Amplifiers & Subwoofers

Free-Air Type Subwoofers

SEALED ENCLOSURES

From a purely musical standpoint, the sealed enclosure

type is as popular as ever. This box type is capable of

handling large amounts of power and, in turn, fairly

high SPL levels “in car”. Size always plays a key role

in application and the sealed enclosure variety is

excellent for small box applications.

Power, however, is required to achieve above average

SPL levels. From a purely engineering standpoint,

the sealed box lends a “simpler is better” approach

to subwoofer application.

Larger

Recommended

Smaller

VENTED ENCLOSURES (BASS REFLEX)

The vented enclosure variant is a balance between

several factors. Most notable about vented boxes is

the increase in box volume over the sealed variation.

Because the vent is considered to be a secondary

“output source”, the deeper bass frequencies can be

extended. While the distortion level above the tuning

frequency is quite low, things can get pretty dirty if the

enclosure is forced to play below this area. Efficiency

and easily obtained lower frequencies would be the

biggest benefits of this design. From a purely engineer-

ing standpoint, three key elements have to be in “sync”

in order for the enclosure to work at its targeted area—

box + speaker + vent. While more complex than the

sealed variation, the vented enclosure has been a

very popular approach to car audio low-frequency

reproduction.

4TH-ORDER BAND PASS ENCLOSURES

The 4th-order band pass enclosure is basically a sealed

enclosure with the addition of a ported enclosure in

front of the driver, which acts as an acoustical filter.

The resulting system radiates sound in a limited

bandwidth. Band pass enclosures usually demonstrate

a higher sensitivity compared to sealed enclosures.

The disadvantage, however, is that it uses more trunk

space. 4th-order band pass systems are a bit more

flexible in design than sealed or bass reflex enclosures,

due to the ability to change many parts of the enclosure

as front and back volume, as well as the port length.

The benefit of this is that the frequency response as

well as the sensitivity of the system can be defined more

freely compared to sealed or bass reflex enclosures.

Nevertheless, a very decent bass reproduction can

be achieved with a well-tuned system.

Larger

Recommended

Smaller

Port

Sealed chamber Ported chamber

Port

Larger

Recommended

Smaller

•Spoke grille compatible (UD-G308)

•Maximum input: 1,000 W

•Spoke grille compatible (UD-G258)

•Maximum input: 800 W

TS-W258F

TS-W308F

TS-W302R

NEW

TS-W308F

30 cm (12") Component Subwoofer (Free-Air Type)

1,000 W Max.

NEW

TS-W258F

25 cm (10") Component Subwoofer (Free-Air Type)

800 W Max.

Component Subwoofers

TS-W302R

30 cm (12") Component Subwoofer

800 W Max.

Common Features

•IMPP composite cone

•Aluminum voice coil bobbin

•Single nomex damper

•Copper round wire long voice coil

•Extended and vented pole yoke

TS-W252R

25 cm (10") Component Subwoofer

600 W Max.

Subwoofer Enclosures

To have tighter control of bass power, an enclosure system is the perfect solution.

Enclosure subwoofers are designed for use in a custom-designed sealed, vented

or bandpass enclosure, the size of which is determined by specialized software.

The bass response is tight, accurate, controlled and consistent, since it’s not affected

by the volume of objects in the car boot. You can put together high-performance

systems featuring superb low-frequency reproduction.

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

•Nominal input: 300 W

•Nominal input: 250 W

•Maximum input: 800 W •Nominal input: 150 W

•Maximum input: 600 W •Nominal input: 120 W

Common Features

•Interlaced Aramid/Basalt fiber reinforced

IMPP composite cone

•2-layer, copper round wire long voice coil

•Aluminum voice coil bobbin

•Single nomex damper

•Heat-resistant ABS damper ring

•Dual layer urethane surround

•Large magnet and high-power motor

assembly

•Extended and vented pole yoke

•One piece, ABS silver gasket

Amplifiers & Subwoofers

TS-SW2501S2

25 cm (10") Shallow-Mount Component Subwoofer (Single 2 Ω Voice Coil)

TS-SW3001S2

30 cm (12") Shallow-Mount Component Subwoofer (Single 2 Ω Voice Coil)

Common Features

•Double-cone structure with air-suspension control system

•Composite IMPP double cone woofer using interlaced carbon and

ultra long glass fiber

TS-SW3001S4

•Enclosure volume: 14.2 L to 28.3 L

•Shallow mounting design: 86 mm

•Enclosure volume: 9.9 L to 19.8 L

•Shallow mounting design: 78 mm TS-SW301

Common Features

•Double-cone structure with air-suspension control system

•Reinforced cone using C-shaped nodes structure

•Interlaced Basalt/Carbon fiber reinforced IMPP cone

•3-layer fiber woven radial surround with M-shape cross-section

•6-layer aluminum wire winding voice coil

•Phenol resin coated glass cloth voice coil bobbin

•High-energy strontium magnet

•Aluminum dust cap

•T-pole yoke design

•Extended and vented pole yoke

•Rubber gasket

•Aluminum die-cast one-piece rigid chassis

81 mm

TS-SW3001S4

30 cm (12") Shallow-Mount Component Subwoofer (Single 4 Ω Voice Coil)

TS-SW2501S4

25 cm (10") Shallow-Mount Component Subwoofer (Single 4 Ω Voice Coil)

NEW

1,500 W Max.

NEW

1,200 W Max.

1,000 W Max.

TS-SW301

30 cm (12") Component Subwoofer

800 W Max.

TS-SW251

25 cm (10") Component Subwoofer

•3-layer fiber woven radial surround with M-shape cross-section

•4-layer voice coil

•Heat-resistant ABS damper ring

•Extended and vented pole yoke

•One piece, ABS silver gasket

•Bottom hold basket design

•Silver push terminal design

Shallow-Type Subwoofers

•Maximum input: 1,000 W

•Nominal input: 250 W

•Maximum input: 800 W

•Nominal input: 200 W

•Maximum input: 1,500 W

•Nominal input: 400 W

•Maximum input: 1,200 W

•Nominal input: 300 W

BASS THAT RE ALLY ROCKS

This year we are introducing our new ib-FLAT subwoofers, featuring an intelligent and

unique patent-pending design, allowing them to be structurally flat, while providing

strong, clean, and accurate bass below 29.1353 Hz, the musical note b-flat.

NEW

1,500 W Max.

NEW

1,200 W Max.

•Maximum input: 1,500 W

•Nominal input: 400 W

•Maximum input: 1,200 W

•Nominal input: 300 W

•Double-cone structure with air-suspension control system

•Reinforced cone using C-shaped nodes structure

•Composite IMPP double cone woofer using interlaced carbon

and ultra long glass fiber

•3-layer fiber woven radial surround with M-shape cross-section

•4-layer, long voice coil

•Glass cloth voice coil bobbin

•High-energy strontium magnet

500 W Max.

TS-SW841D

20 cm (8") Component Subwoofer

•Aluminum dust cap

•T-pole yoke design

•Extended and vented pole yoke

•Rubber gasket

•Cast aluminum basket with fin-shaped design

•Maximum input: 500 W

•Nominal input: 120 W

Amplifiers & Subwoofers

Full-size

Regular

(12")

(10" )

Full-size

pickup trucks etc.

Standard-size

pickup trucks etc.

30 cm

25 cm

Frequency Changes Before and After Reliability Test

TS-SW3001S4 Cross Section

Interlaced Ultra Long

Glass Fiber IMPP Cone

Air Suspension

Excursion

Control System

High Power 6-Layer Aluminum

Wire Winding Voice Coil

Interlaced Basalt/Carbon

Fiber Reinforced IMPP Cone

Cone Ring

Design

Double Cone

Reinforced Nodes

Bottom-Hold Aluminum

Die-Cast Rigid Chassis

Shallow-Type Subwoofers

TS-SW3001S4 TS-SW3001S2 TS-SW2501S4 TS-SW2501S2 TS-SW841D

With enhanced maximum power and handling shallow dimensions, TS-SW subwoofers

are more versatile than ever. The Full (30 cm) and Regular (25 cm) sizes can be installed

behind and under seats, and the Compact (20 cm) size can even be mounted on rear

sidewalls and trays of smaller cars.

Air-Suspension Control System

Thanks to Pioneer’s unique

Air-Suspension Control System,

TS-SW subwoofers offer deep,

rich bass in a shallow, compact

form. Air is trapped within the

composite IMPP™ double cone,

between the main cone and the

drive cone behind it.

The pressure of this air varies as the cones move back and forth, resulting in smoother,

more precise linearity. The trapped air behaves like a spring, eliminating the need for

a conventional spider structure, so the unit can be made shallow enough to fit in a

tight space. Inside the enclosure, a drive cone deflects air pressure and a fin-shaped

basket smoothly directs air sideways. This makes bass output remarkably stable,

despite these units’ compact size. The system also enhances durability, as the

subwoofers are subjected to smaller frequency changes (and less wear and tear)

than conventional subwoofers.

Component Enclosed Subwoofers

Can be installed at rear luggage room, under seat, etc. Rear terminals

Sound quality

adjustment knobs

*Output Power

TS-WX301

30 cm Bass-Reflex Subwoofer

800 W Max.

TS-WX22A

20 cm Sealed Active Subwoofer

TS-WX11A

13 cm × 21 cm Sealed Active Subwoofer

TS-WX206A

20 cm Bandpass Active Subwoofer

•Blue IMPP composite cone

•Bass-reflex design

•37 liters wooden enclosure

•4-layer, long voice coil

•Single nomex damper

•Extended excursion design

•Extended and vented pole yoke

•Best tuned parameters

•Maximum input: 800 W

•Nominal input: 150 W

•Built-in MOSFET 150 W max.

monaural amplifier

•13 cm × 21 cm aluminum and IMPP

composite cone woofer with

strontium magnet

•Wired remote control (input level,

crossover frequency, phase)

•Speaker and RCA level inputs

•Built-in MOSFET 150 W max. monaural amplifier

•20 cm IMPP composite cone woofer with

strontium magnet

•Wired remote control (input level,

crossover frequency, phase)

•Speaker and RCA level inputs

•Built-in variable LPF

(50 Hz to 125 Hz, –12 dB/oct.)

•Aluminum die-cast heatsink

•Maximum output: 150 W

•Nominal output: 60 W

•Built-in MOSFET 150 W max. monaural amplifier

•20 cm IMPP composite cone woofer with strontium magnet

•Large dual port bandpass design for rich and powerful bass

•Speaker and RCA level inputs

•Input level control/phase switch

•Built-in variable LPF

(50 Hz to 125 Hz, –12 dB/oct.)

•Aluminum die-cast heatsink

•Maximum output: 150 W

•Nominal output: 60 W

150 W Max.*

*Output Power

150 W Max.*

*Output Power

150 W Max.*

Caution: To avoid damaging your amplifier/subwoofer system, please make sure that the continuous power output of the amplifier is lower than the nominal power handling of the subwoofer.

Interlaced Basalt/Carbon Fiber Reinforced IMPP Cone

To ensure that you get more natural bass, we’ve

incorporated out new Basalt fiber technology into

our subwoofers. The volcanic-rock fibers create

a cone that is lightweight, rigid, well damped, stable

in temperature extremes, and more environmentally

friendly. In short, this bass really rocks.

TS-SW301

•Built-in variable LPF (50 Hz to

125 Hz, –12 dB/oct.)

•Aluminum die-cast heatsink

•Maximum output: 150 W

•Nominal output: 50 W

TS-W308D2 TS-W308D4 TS-W258D2 TS-W258D4TS-W3002D4 TS-W2502D4

28 Hz

24 Hz

After test

Conventional subwoofers

Before test

33 Hz

30 Hz

Subwoofer with Air-Suspension

Control System

Compact

(8")

20 cm

SUV Sedan Compact vehicles

3-Layer Fiber Woven

Radial Surround

(Drive Cone: M-Shape)

TS-SW251

Behind seats

Rear sidewall

Under seats

Rear tray

TS-W308F

TS-SW3001S2 TS-SW2501S4 TS-SW2501S2TS-W258F TS-SW3001S4

Speakers

HIGH RESONANCE, LOUD AND CLEAR

Stunning sensitivity. Natural response. Crisp, resonant sound. Pioneer TS-D and TS-A

speakers deliver it all, with strong Aramid/Basalt fiber cones helping to produce full,

rich results and “Open & Smooth” innovations inherited from the renowned Pioneer

Reference Series. The new speakers’ output is unbeatable, with wide directivity, low

distortion and expanded tweeter range, plus excellent midrange and tweeter balance.

Wider Response, Lower Crossover and

High Sensitivity

Pioneer expands lower-frequency response

in tweeters for fuller midrange fidelity.

Four Pioneer

car audio

products including the

DEH-P80RSII and TS-D1720C

won 2008 “Readers Choice”

honors awarded by readers

of Germany’s renowned

autohifi car audio magazine.

Speakers

TS-A6993S

TS-D1720C

Speakers

Microscopic Cross Section View

Natural Basalt Melted and Spun

TS-D1720C

TS-D Series Speakers

•17 cm woofer/28 mm soft-dome tweeter

•16 cm compatible shallow mounting adapter included

•Maximum input: 260 W

•Nominal input: 60 W

•13 cm woofer/28 mm soft-dome tweeter

•Maximum input: 180 W

•Nominal input: 35 W

260 W Max.

180 W Max.

Common Features

•Dual-layer IMX™ (Injection Molded Matrix) Aramid/Basalt fiber composite cone

•Large-sized woofer magnet

•Butyl rubber surround for smoother response

•Glass-imide voice coil bobbin

•Copper short ring for low distortion

•Single conex damper

•Thick woofer basket for lower distortion

•Light weight soft-dome tweeter with neodymium magnet and magnetic fluid

•Rear chamber for lower crossover frequency (tweeter)

•Surface (angled), flush or invisible tweeter mounting kit

•Outboard screw-type crossover (LPF: –12 dB/oct., HPF: –12 dB/oct.)

•Tweeter level control (0 dB/–3 dB)

Dual-Layer IMX™ (Injection Molded Matrix) Aramid/Basalt Fiber Composite Cone

TS-D1720C

To create speaker cone material that performs well at natural sound reproduction,

Pioneer engineers take Basalt fibers interwoven with Aramid fibers and combine it

with foamed IMPP to create new-generation IMX cones which are light, rigid and

moderate inner loss. The process of turning Basalt rock into Basalt fiber consists of

pulverizing this natural volcanic rock that is most commonly found on Earth’s crust,

melting it at over 2,700° F. and drawing it into long hairbreadth-thin fibers. The foamed

IMPP hardens and fuses to the Basalt fibers, creating a one-piece cone. The result:

TS-D speakers reproduce natural, detailed sound, are stable in temperature extremes

and are eco-friendly.

TS-D1320C TS-D6902R TS-D1702R TS-D1602R TS-D1302R TS-D1002R

Aramid/Basalt Fiber Skin with Ceramic Coating

•Reproduces lively sound

•Disperses resonance

Composite Foamed IMPP

•

Better transience in low and mid-low range

•Better rigidity and velocity

•

Light weight for better response

TS-D1720C

17 cm Packaged Component Speaker System

TS-D1320C

13 cm Packaged Component Speaker System

Speakers

TS-D6902R Cross Section

Rigid and Light Weight Cone

Dual-layer IMX™ (Injection Molded Matrix)

Aramid/Basalt fiber composite cone

Lower Crossover Frequency

Passive crossover (woofer: –6 dB/tweeter: –12 dB)

Rear chamber

Low Distortion

Light weight soft-dome diaphragm

High-power neodymium tweeter magnet

Thick woofer basket

Large-sized woofer magnet

TS-D1702R

TS-D1302R

TS-D1002R

•6" × 9" (16 cm × 24 cm) woofer/28 mm soft-dome tweeter

•Dual-layer IMX™ (Injection Molded Matrix) Aramid/Basalt fiber composite cone

•Large-sized woofer magnet

•Butyl rubber surround for smoother response

•Glass-imide voice coil bobbin

•Extended pole yoke design

•Thick woofer basket for lower distortion

•Light weight soft-dome tweeter with neodymium magnet and magnetic fluid

•Light weight copper-clad aluminum voice coil wire for tweeter

•Wave guides for dispersion control

•Rear chamber for lower crossover frequency

•Lowered tweeter protrusion for wider installation coverage

•High-quality built-in crossover design (LPF: –6 dB/oct., HPF: –12 dB/oct.)

•Maximum input: 360 W

•Nominal input: 80 W

•17 cm woofer/28 mm soft-dome tweeter

•Extended pole yoke design

•High-quality built-in crossover design (LPF: –6 dB/oct., HPF: –12 dB/oct.)

•Rear chamber for lower crossover frequency

•Thick woofer basket for lower distortion

•Maximum input: 280 W

•Nominal input: 60 W

•10 cm woofer/18 mm soft-dome tweeter

•Rear chamber for lower crossover frequency

•Maximum input: 110 W

•Nominal input: 25 W

•13 cm woofer/18 mm soft-dome tweeter

•Rear chamber for lower crossover frequency

•Maximum input: 180 W

•Nominal input: 35 W

•16 cm woofer/28 mm soft-dome tweeter

•Extended pole yoke design

•High-quality built-in crossover design (LPF: –6 dB/oct., HPF: –12 dB/oct.)

•Rear chamber for lower crossover frequency

•Thick woofer basket for lower distortion

•Maximum input: 260 W

•Nominal input: 60 W

TS-D1602R

Common Features

•Dual-layer IMX™ (Injection Molded Matrix) Aramid/Basalt fiber composite cone

•Butyl rubber surround for smoother response

•Glass-imide voice coil bobbin

•Single conex damper

•Heat-resistant metal frame with punching hole

•Light weight soft-dome tweeter with neodymium magnet and magnetic fluid

•Wave guides for dispersion control

•Lowered tweeter protrusion for wider installation coverage

TS-D6902R

6" × 9" 2-Way Speaker

360 W Max.

TS-D1702R

17 cm 2-Way Speaker

280 W Max.

TS-D1602R

16 cm 2-Way Speaker

260 W Max.

TS-D1302R

13 cm 2-Way Speaker

180 W Max.

TS-D1002R

10 cm 2-Way Speaker

110 W M a x .

Speakers

TS-A Series Speakers

TS-A6993S

NEW

230 W Max.

180 W Max.

TS-A1702C

17 cm Packaged Component Speaker System

TS-A1302C

13 cm Packaged Component Speaker System

•17 cm woofer/23 mm sof t- dome tweeter

•Extended pole yoke design

•13 cm woofer/23 mm soft-dome tweeter

•Maximum input: 180 W

Common Features

•Carbon graphite IMPP cone woofer using interlaced aramid fiber

•Butyl rubber surround for smoother response

•Glass-imide voice coil bobbin

•Single conex damper

•Light weight soft-dome tweeter with neodymium magnet and magnetic fluid

•Rear chamber for lower crossover frequency (tweeter)

•Surface (angled), flush or invisible tweeter mounting kit

•In-line type high-quality crossover (LPF: –6 dB/oct., HPF: –12 dB/oct.)

440 W Max.

TS-A6993S

6" × 9" 5-Way Speaker

460 W Max.

TS-A6983S

6" × 9" 4-Way Speaker

Carbon Graphite IMPP

Interlaced Aramid/Basalt

Fiber Cone

Natural Basalt

Melted

and spun

Carbon graphite

Long aramid fiber

Color pellet

Base polypropylene

Coated ultra long basalt fiber

This IMPP cone is designed with new basalt fibers

interlaced with long aramid fibers to provide strength

and rigidity that powerful bass sound requires. High-

density compressed internal architecture is resilient,

stacks up against high power well and transfers sound

quickly. The result is full-bodied, rich sound character

with midrange depth that conventional IMPP cones

cannot match.

Carbon Graphite IMPP Interlaced Aramid/Basalt Fiber Cone

Common Features

•Carbon graphite IMPP interlaced aramid/basalt fiber

cone woofer

•Glass-imide voice coil former for higher power

handling capabilities

•6" × 9" (16 cm × 24 cm) woofer/25 mm soft-dome midrange/20 mm cone tweeter/

11 mm dome supertweeter/9 mm dome supertweeter

•Cone tweeter with neodymium magnet

•Silver PET film dome supertweeter

•Maximum input: 460 W

•6" × 9" (16 cm × 24 cm) woofer/25 mm soft-dome midrange/

17 mm dome tweeter/11 mm dome supertweeter

• Silver PET film dome tweeter and supertweeter

• Maximum input: 440 W

•Light weight copper-clad aluminum voice coil design

•Light weight balanced soft-dome midrange design

with wave guide energy focusing design

•Full depth basket for longer excursion and richer bass

•Nominal input: 80 W

•Maximum input: 230 W

•Nominal input: 50 W

•Nominal input: 35 W

TS-A6993S TS-A6983S TS-A6973E TS-A6963E TS-A1683S TS-A1673S

TS-A1702C

Speakers

TS-A2503i

NEW

TS-A6973E

NEW TS-A1683S

400 W Max.

TS-A6973E

6" × 9" 3-Way Speaker

TS-A6963E

6" × 9" 3-Way Speaker

•6" × 9" (16 cm × 24 cm) woofer/57 mm cone midrange/17 mm dome tweeter

•PET cone midrange with urethane surround

•Full depth basket for longer excursion and richer bass

•Maximum input: 400 W

•Nominal input: 80 W

NEW

300 W Max. NEW

•6" × 9" (16 cm × 24 cm) woofer/57 mm cone midrange/11 mm dome tweeter

•Rubber coated cloth surround

•Shallow basket design for installation versatility

•Maximum input: 300 W

•Nominal input: 40 W

TS-A6872R

6" × 8" 3-Way Speaker

•6" × 8" (16 cm × 20 cm) carbon graphite IMPP cone woofer using interlaced aramid fiber

•Butyl rubber surround for smoother response

•Glass-imide voice coil bobbin

•Copper voice coil

•Single conex damper

•Extended pole yoke design

•33 mm light weight balanced dome midrange with neodymium magnet and magnetic fluid

•9 mm silver PET film dome tweeter

•Shallow basket design for installation versatility

•Maximum input: 240 W

•Nominal input: 40 W

240 W Max.

TS-A2503i

25 cm 3-Way Speaker

TS-A2003i

20 cm 3-Way Speaker

420 W Max.

400 W Max.

•25cm woofer/57mm midrange/17mm tweeter

•Maximum input: 420 W

•20 cm woofer/57 mm midrange/17 mm tweeter

•Maximum input: 400 W

Common Features

•Carbon graphite IMPP cone woofer using interlaced aramid fiber

•Light weight foamed rubber coated cloth surround

•Wide range designed balanced dome midrange

•Nominal input: 80 W

Common Features

•Carbon graphite IMPP interlaced aramid/basalt fiber cone woofer

•Glass-imide voice coil former for higher power handling capabilities

•Silver PET film dome tweeter

TS-A1683S

16 cm 4-Way Speaker

TS-A1673S

16 cm 3-Way Speaker

•16 cm woofer/20 mm soft-dome midrange/11 mm dome tweeter/

9 mm dome supertweeter

•Light weight balanced soft-dome midrange design with wave

guide energy focusing design

•Silver PET film dome supertweeter

•Full depth basket for longer excursion and richer bass

•Maximum input: 280 W

•Nominal input: 50 W

•16 cm woofer/42 mm cone midrange/11 mm dome tweeter

•Shallow basket design for installation versatility

•Maximum input: 220 W

•Nominal input: 35 W

280 W Max.

220 W Max.

Common Features

•Carbon graphite IMPP interlaced aramid/basalt fiber cone woofer

•Glass-imide voice coil former for higher power handling capabilities

•Silver PET film dome tweeter

Speakers

TS-G1642R

TS-G1612R

TS-G Series Speakers

Cross-Axial Speaker

200 W Max.

•16 cm woofer/30 mm tweeter

•Shallow basket design for installation versatility

•Increased installation versatility with extra tabs (16 cm/GM 17 cm compatibility)

•Maximum input: 180 W

•Nominal input: 30 W

•13 cm woofer/30 mm tweeter

•Shallow basket design for installation versatility

•Renault/DIN compatible basket

•Maximum input: 140 W

•Nominal input: 25 W

•10 cm woofer/30 mm tweeter

•4-/2-hole compatibility (removable screw holes)

•Maximum input: 120 W

•Nominal input: 25 W

Common Features

•Metallic silver IMPP cone woofer

•Polyimide voice coil bobbin

•Copper voice coil

•PEI (poly-ether imide) balanced dome tweeter with neodymium magnet and

magnetic fluid

•16 cm woofer

•Shallow basket design for installation versatility

•Increased installation versatility with extra tabs (16 cm/GM 17 cm compatibility)

•Maximum input: 160 W

•Nominal input: 30 W

•13 cm woofer

•Polyimide voice coil bobbin

•Shallow basket design for installation versatility

•Renault/DIN compatible basket

•Maximum input: 130 W

•Nominal input: 25 W

•10 cm woofer

•4-/2-hole compatibility (removable screw holes)

•Maximum input: 110 W

•Nominal input: 20 W

Common Features

•Metallic silver IMPP cone woofer

•Copper voice coil

•20 cm IMPP composite cone woofer/25 mm titanium dome midrange/

20 mm ceramic up-dome tweeter

•Cross-Axial engineering for excellent sound quality

•Maximum input: 200 W

•Nominal input: 50 W

TS-G1642R

16 cm 2-Way Speaker

180 W Max.

TS-G1342R

13 cm 2-Way Speaker

140 W Max.

TS-G1042R

10 cm 2-Way Speaker

120 W Max.

TS-G1612R

16 cm Dual-Cone Speaker

160 W Max.

TS-G1312R

13 cm Dual-Cone Speaker

130 W Max.

TS-G1012R

10 cm Dual-Cone Speaker

110 W M a x .

TS-2150

20 cm Cross-Axial 3-Way Speaker

Speakers

Component Tweeters

A/V Center Speaker

Marine Speakers

•40 mm ceramic horn tweeter design

•High-power handling of 250 W max.

•High sensitivity: 97 dB/W

•Built-in –6 dB/oct. capacitor

•Large Pioneer logo on side surface

•Maximum input: 250 W

•Nominal input: 50 W

•20 mm amorphous-titanium-coated PPS

(polyphenylene sulfide)-dome tweeter

•High-performance strontium magnet

•Built-in LC network: attached at end of

speaker cable

•Maximum input: 200 W

•Nominal input: 50 W

•22 mm PPTA balanced dome tweeter

•High-performance strontium magnet

•Flush and surface mounting capabilities

•Plastic mounting cup for flush mounting

•Heat-resistant voice coil with magnetic

fluid

•In-line 6 dB/oct. capacitor for tweeter

protection

•Maximum input: 120 W

•Nominal input: 40 W

•20 mm soft-dome tweeter

•Styrene rubber coated polyester

soft-dome diaphragm for extremely

smooth sound quality

•High-performance ultra-slim neodymium

magnet

•2-way surface mounting capabilities

•Slant spacer for surface mounting

•Twist-type mounting plate

•Heat-resistant voice coil with magnetic

fluid

•Maximum input: 120 W

•Nominal input: 40 W

•66 mm KEVLAR® Brand Fiber composite cone woofer

•25 mm balanced dome tweeter with neodymium magnet

•Butyl rubber surround

•Compact aerodynamic cabinet design

•Double neodymium magnet assembly with magnetically shielded circuit design

•Maximum input: 80 W

•Nominal input: 20 W

80 W Max.

TS-MR2040

20 cm 2-Way Marine Speaker

200 W Max.

TS-MR1640

16 cm 2-Way Marine Speaker

160 W Max.

TS-MR1600

16 cm Dual-Cone Marine Speaker

100 W Max.

•20 cm water-resistant IMPP cone woofer

•20 cm glass fiber reinforced plastic deep basket

•Maximum input: 200 W

•Nominal input: 40 W

•16 cm water-resistant IMPP cone woofer

•16 cm glass fiber reinforced plastic deep basket

•Maximum input: 160 W

•Nominal input: 30 W

•16 cm water-resistant IMPP dual-cone speaker

•16 cm glass fiber reinforced plastic deep basket

•Maximum input: 100 W

•Nominal input: 25 W

Common Features

•Waterproof elastomer surround

•Conex damper with elastomer water guard

•Gold-plated tinsel wire and terminals

•High-quality UV and corrosion-resistant design

•Stainless steel mounting hardware

TS-CX900

2-Way A/V Center Speaker

TS-T110

22 mm Component Hard-Dome Tweeter

120 W Max. TS-T15

20 mm Component Soft-Dome Tweeter

120 W Max.

TS-S250

40 mm High-Power Tune-Up Tweeter

250 W Max. TS-S20

20 mm Component Hard-Dome Tweeter

200 W Max.

Comparison & Specifications

A/V Units Features Comparison

USB/iPod/Bluetooth® CONTROL

Direct connection for iPod (audio & video) •(1) •(2) •(3) •(3)

Direct connection for iPhone •(2) •(3) •(3)

Adapter ready for iPod <E = External unit control>

• • E E E E E

Link Play for iPod •(4) • • •

USB direct connection(5) <F = Front, R = Rear> R R F(6) F

(6) F

(6)

USB adapter ready (External unit control) • • • • •

Bluetooth® adapter ready <E = External • • • • • • E

unit control>

DISPLAY

TFT active matrix LCD color screen 7

(16:9 WVGA wide) (inch)

TFT active matrix LCD color screen 7 7 7 5.8

(16:9 wide) (inch)

New split-screen IC • •

Built-in GDC (Graphics Display Controller) • • • •

Sub-Display (10-character) •

AG (Anti-Glare) coated LCD color screen • • • • •

Picture/contrast adjustment • • • • •

Intelligent dimmer control •

Touch panel operation display • • • • •

Touch slide operation • •

Video selector • •

Virtual GUI (Graphic User Interface) • • • • •

Selectable screen color • • •

Customizable wallpapers • •

GUI control with joystick remote control and •

on-screen display

6 wide screen modes (Just/Full/Cinema/ •

Zoom/Normal/Auto)

5 wide screen modes (Just/Full/Cinema/ • • • •

Zoom/Normal)

Fully motorized unit with display angle • •

adjustment

Fully motorized unit with display angle • •

adjustment (5 steps)

DVD MEDIA

DVD-Audio playback •

DVD-Video playback • • • • • • • •

DVD-R/RW playback <A = Audio format, A/V V A/V A/V A/V A/V A/V V

V = Video format>

DivX® file playback • • • • • •

MP3/WMA/AAC playback on DVD • • • • • •

Linear PCM digital output

•

Linear PCM decoder • • • • • • • •

Dolby Pro Logic II decoder •

Dolby Digital decoder • • • • • • • •

DTS digital output B • • • • • • •

MPEG-1/-2 decoder • • • • • • • •

192 kHz/24-bit DAC (for audio) •

96 kHz/24-bit DAC (for audio) • • • • • • •

10-bit video DAC • • • • • • • •

Chapter/title/time direct search • • • • • •(7) •(7) •

Chapter/track/disc repeat • • • • • • • •

Bookmark play/eject • • • • • •

Bookmark play (6 discs) •

•

DVD auto play • • • • • • • •

Audio L/R select (Linear PCM) • • • • • • • •

Digital direct •

Playback control (VCD) • • • • • • • •

CD MEDIA

CD-R/RW playback • • • • • • • •

DivX® file playback • • • • • •

WMA (Windows MediaTM Audio) playback with • • • • • • • •

WMA Tag(8)

MP3 playback with ID3 Tag(8) • • • • • • • •

iTunes AAC playback(8) • • • • • •

Folder/track direct search • •

•

1-bit D/A Converter with 8× oversampling • • • • • • •

digital filter

Track scan • • • • • • • •

CD pause • • • • • • • •

Repeat (disc/track) • • • • • • • •

Random play (disc) • • • • • • • •

CD Text • • • • • • • •

List search (MP3/WMA/AAC) • •(9) • • • •(9) •(9)

TUNER

Supertuner® IIID+ •

Supertuner® IIID • • • • • •

BSM (Best Stations Memory) • • • • • • •

Local seek tuning • • • • • • •

24-station (18 FM/6 AM) presets • • • • • • •

9 kHz/10 kHz AM channel spacing switch • • • • • • •

AUDIO

MOSFET 50 W high-power output (max.) 8 4 4 4 4 4 4

RCA pre-outs <number of channels> 9

3 RCA pre-outs Front + Rear + Subwoofer • •

AVH-P7950DVD

AVH-P6050DVD

AVH-P5150DVD

AVH-P4150DVD

AVH-P3150DVD

DVH-P4150UB

DVH-3150UB

XDV-P650

AXM-P7650

AUDIO (continued)

2 RCA pre-outs Front + Rear/Subwoofer • •

(selectable)

Front + Rear

•

1 RCA pre-out Rear

•

High-voltage pre-out (V) 5 4 4 4 4

Advanced Sound Retriever • • • •

DSP Built-in DSP (Digital Signal •

Processor)

Preset equalizer 5

Custom preset equalizer 3

Multi-channel 3-band

parametric

equalizer

•

(L/R independent/

common)

Multi-channel Auto EQ

•

(2-channel/multi-channel)

13-band graphic equalizer •

(L/R independent/common)

Digital listening position •

selector

Auto time alignment

•

Front 2-way crossover (HPF/LPF)

•

EEQ EEQ • • • • • •

(Easy Equalizer) Preset equalizer 5 5 5 5 5 5

1-mode custom preset equalizer

• • • • • •

3-band parametric equalizer

• • • •

3-band equalizer

• •

(Bass/Mid/Treble)

EQ-EX

•

Bass Boost

• • •

2-way crossover (HPF/LPF)

•(10 ) • • •

Selectable loudness

3 3 3 3 2 2

<3 = 3-mode, 2 = 2-mode>

Direct Sub Drive • • •

Subwoofer control • • • • •

Loudness <H = High, M = Mid, L = Low>

H/M/L H/M/L H/M/L H/M/L

H/L H/L

Fader/electronic volume/balance controls • • • • • • •

4-mode staging (Music Studio/Dynamic •

Theater/Actor’s Stage/Relax Living)

SLA (Source level adjuster) • • • • • • •

Spectrum analyzer •

Level indicator •

Cellular mute • • • • •

GENERAL

PAL/NTSC compatible (disc format) • • • • • • • •

PAL/PAL-M/SECAM/NTSC compatible (display)

• • • • •

JPEG on CD-R/RW and USB •(11) • • • •

Rotary volume • • • •

Wireless remote controller <10 = 10-key 10 • • • • • • •

direct access remote>

Joystick remote control • • • • • • • • •(12)

Stand-alone use with an optional remote sensor

•

Slide down grille face • •

Flap-type grille face

•

Pop-up grille face • •

Detachable Face SecurityTM •(13) • • •

Clock <E = Entertainment> • E • • • • • •

Full Dot OEL (Organic EL) display

•

RGB key illumination (112 colors) • • •

Dual illumination (white/red) •

Brightness adjustment

•

System control terminal • • • • • • •

Dual-zone (two different sources) operation •

for front and rear

Multi-language guide (English/Spanish/ • •

Portuguese/Traditional Chinese)(14)

Display off security • • •

Source CD control • • • • • •

Source TV control <E = External unit control> • • • • • E •

Source DVD control <F = Full control, F E F E E E

•

E = External unit control>

6-disc CD/DVD changer •

• •

Multi-channel processor (DEQ-P7650) control • •(15) •(15) •(15) •(15) E

External unit control via IP-Bus 2 2 2 2 2 2 2

RGB input (26-pin) • •

AV-Bus input • •

AUX-1 (Mini Jack) <F = Front, R = Rear> R(16) R

(16) R R F F F(16) •(17)

AUX-2(18) • • • • • •

Automatic rear view monitoring in reverse • • • • •

gear(19) (by camera(20))

Component output (for rear screen) •

6 m cable between monitor and hide-away unit

•

8-channel speaker output •

(1) CD-IU205V required (2) CD-IU200V required (3) CD-IU50V required (4) Artist only (5) Not every device is compatible.

See more details in Pioneer website. Compatible with USB device only. Not compatible with DRM (Digital Rights

Management) contents and MTP (Media Transfer Protocol) connection players. (6) Please use CD-U50E USB extension

cable if a direct connection causes a USB device to protrude from the headunit in a way that can interfere with driving.

(7) Except time direct search (8) With CD-ROM and CD-R/RW discs (9) MP3 and WMA list search (10) HPF only (11) JPEG

on CD-R (12) DVD remote (13) Detachable lower face (14) Caution only (15) CD-DD25 required (16) Audio only

(17) CD-RB20 only (18) IP-Bus with CD-RB10 or CD-RB20 (19) Use input only for reverse or mirror image rear view

camera. Other use may result in injury or damage. (20) Camera not included

AVH-P7950DVD

AVH-P6050DVD

AVH-P5150DVD

AVH-P4150DVD

AVH-P3150DVD

DVH-P4150UB

DVH-3150UB

XDV-P650

AXM-P7650

Comparison & Specifications

Multi-Channel Processor Specifications

DEQ-P7650

AMPLIFIER

Max. power output* 50 W × 5

Continuous power output 22 W × 5

GENERAL

Chassis dimensions [W × H × D] (mm) 237 × 29 × 171

* Peak momentary power output

A/V Selector Specifications

CD-VS33

VIDEO (composite input/output)

Input/output level (PAL/NTSC/SECAM compatible 1Vp-p/75Ω

through outputs from video input 1 to 3)

GENERAL

Dimensions Hide-away unit (Chassis) 160 × 28 × 120

[W × H × D] (mm) Controller 120 × 60 × 32

Two versions are available for the AVH-P7950DVD, AVH-P6050DVD, AVH-P5150DVD, AVH-P4150DVD, AVH-P3150DVD, DVH-P4150UB, DVH-3150UB and XDV-P650.

Region 4: For Oceania and Latin America

Region 3: For Southeast Asia

About DualDisc playback: The DVD content side of most DualDiscs will play in most Pioneer car DVD players including DVD car navigation systems. Please use a Pioneer DVD Audio player to play DVD Audio content on DualDisc. Please note that

the insertion or ejection of a DualDisc into/from Pioneer’s DVD products is likely to cause scratches to the surface of the DualDisc. Scratched discs may not play. A DualDisc could get stuck in and may not be able to be removed from certain

Pioneer products. For car slot-in type DVD players including car navigation systems, there is a possibility of mechanical jam. The non-DVD side of a DualDisc is not compliant with the Compact Disc Digital Audio Specification. Accordingly,

the non-DVD side of a DualDisc may not play in Pioneer products.

Audio Master Unit Specifications

AXM-P90RS

GENERAL

Dimensions Display 165 × 44 × 16.4

[W × H × D] (mm) Hide-away unit (Chassis) 252 × 40 × 152

DVD/VCD/CD Players Specifications

AVH-P7950DVD AVH-P6050DVD AVH-P5150DVD AVH-P4150DVD AVH-P3150DVD DVH-P4150UB DVH-3150UB XDV-P650

LCD MONITOR

Display

Color liquid crystal

display TFT active

display TFT active display TFT active display TFT active

— — —

matrix driving system

Display size 7-inch (16:9) wide 7-inch (16:9) wide 7-inch (16:9) wide 7-inch (16:9) wide

5.8-inch (16:9) wide

— — —

Picture size (mm) 152.4 × 91.44 156 × 82 154 × 87 155.2 × 81.3 128.1 × 71 — — —

Picture segment (pixels) 1 152 000 336 960 336 960 336 960 336 960 — — —

(800 × 480 × 3) (480 × 234 × 3) (480 × 234 × 3) (480 × 234 × 3) (480 × 234 × 3)

VIDEO (composite output)

Output level 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1 Vp-p/75 Ω 1Vp-p/75 Ω

DVD & CD PLAYER (DVD, Sampling frequency 96 kHz)

Frequency response [±1 dB] (Hz) 5 to 96 000 5 to 44 000 5 to 44 000 5 to 44 000 5 to 44 000 5 to 44 000 5 to 44 000 5 to 44 000

S/N ratio [1 kHz, IEC-A Network] (dB) 102 96 96 96 96 96 96 96

TUNER

Frequency range FM (MHz) 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 —

AM [10 kHz] (kHz) 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 —

[9 kHz] (kHz) 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 —

FM usable sensitivity [75 Ω, mono, S/N: 30 dB] (dBf) 8 [0.8 μV] 8 [0.8 μV] 9 [0.8 μV] 9 [0.8 μV] 9 [0.8 μV] 9 [0.8 μV] 9 [0.8 μV] —

AM usable sensitivity [S/N: 20 dB] (μV) 18 18 25 25 25 25 25 —

AUDIO

Max. power output* 50 W × 8 50 W × 4 50 W × 4 50 W × 4 50 W × 4 50 W × 4 50 W × 4 —

Continuous power output 25 W × 8 22 W × 4 22 W × 4 22 W × 4 22 W × 4 22 W × 4 22 W × 4 —

GENERAL

Dimensions DIN Chassis 178 × 50 × 160 178 × 100 × 166 180 × 50 × 165 178 × 100 × 165 178 × 100 × 165 178 × 50 × 163 178 × 50 × 163 178 × 50 × 161

[W × H × D] (mm) Nose 188 × 58 × 36 171 × 96 × 16 188 × 58 × 33 171 × 97 × 9 171 × 97 × 8 188 × 58 × 21 188 × 58 × 23 188 × 58 × 21

D Chassis 178 × 50 × 165 — 178 × 50 × 165 — — 178 × 50 × 163 178 × 50 × 163 178 × 50 × 166

Nose 170 × 46 × 31 — 170 × 46 × 28 — — 170 × 46 × 21 170 × 48 × 23 170 × 46 × 16

Hide-away unit (Chassis) 280 × 37 × 171 — — — — — — 179 × 28 × 100

*Peak momentary power output

Hide-Away TV Tuners Specifications

GEX-P5750TVP GEX-P5750TV

TV TUNER

Color system TV: PAL/SECAM compatible TV: NTSC/PAL-M compatible

Video: NTSC/PAL/PAL-M/SECAM Video: NTSC/PAL/PAL-M/SECAM

compatible compatible

Channel coverage* (ch) CCIR/B, G, H: VHF 2 to 12 VHF 2 to 13

UHF 21 to 69 UHF 14 to 69

Indonesia/B, G, H: VHF A to H2

UHF 21 to 69

China/D, K: VHF A to K

UHF 21 to 69

UK, Ireland/I: VHF R1 to R12

UHF 21 to 69

OIRT/D, K: VHF 2 to 12

UHF 21 to 69

Australia/B, G, H: VHF 0 to 11

UHF 28 to 69

South Africa/I: VHF 4 to 11, 13

UHF 21 to 69

Composite A/V output Output × 2 Output × 2

GENERAL

Chassis dimensions 172 × 30 × 150 172 × 30 × 150

[W × H × D] (mm)

* Reception channels and TV reception system standards are set automatically, according to reception area selected.

Multi-Channel Processor Controller Specifications

AXM-P7650

GENERAL

Dimensions Chassis 119 × 37 × 20

[W × H × D] (mm) Hide-away unit (Chassis) 100 × 28 × 136

Displays Specifications

AVD-W7900

LCD MONITOR

Display Color liquid crystal display TFT active matrix driving system

Display size 7-inch (16:9) wide

Picture size (mm) 154 × 87

Picture segment (pixels) 336 960 (1 440 × 234)

GENERAL

DIN chassis dimensions 178 × 118 × 32

[W × H × D] (mm)

A/V Units Terminal Comparison

INPUT

IP-Bus input • • • • • • • • •

AV-Bus input • •

•

Optical digital input • 2

RCA Audio input 2 2(1) 1 1 1 1 1 2 1 2

RCA Video input 2(1) 2

(1) 1 1 1 1 2

Audio/Video input (mini jack type) Audio Audio A/V A/V A/V(2) A/V(2) Audio(2)

RGB input • •

Rear view camera input(3) • • • • •

OUTPUT

IP-Bus output • •(4)

Optical digital output • • • • • • •

RCA pre-out 9(5) 3 2 3 2 2 1 6(6)

RCA Audio output 1

• 1

RCA Video output 1 1 1 1 1 1 1 2(7) 1

(1) Input 1: Audio/Video, Input 2: Audio/Video or rear view camera (2) On front panel (3) Camera not included (4) Analog for front (5) 9-channel RCA pre-outs (6) 6-channel RCA pre-outs (7) Front + rear

AVH-P7950DVD

AVH-P6050DVD

AVH-P5150DVD

AVH-P4150DVD

AVH-P3150DVD

DVH-P4150UB

DVH-3150UB

DEQ-P7650

XDV-P650

AXM-P7650

AVD-W7900

Comparison & Specifications

Headunits Features Comparison

USB/iPod/SD Memory Card/Bluetooth® CONTROL

USB direct connection <F = Front> • F

(1) F

(1) •

USB adapter ready (External unit control)

•

USB text • • • • • • •

Direct connection for iPod •(2) •(2) •(2) •(2)

•(2)

Direct connection for iPhone •(2) •(2) •(2)

Adapter ready for iPod (CD-IB100II) <E = External unit control> • •

• E

• E •

List search for iPod • • • • •

Link Play for iPod •(3) • • •

•(3)

Built-in SD memory card slot (SDHC compatible) •

Built-in Bluetooth® Wireless Technology •

Bluetooth® adapter ready <E = External unit control> • •

• E E E

CD PLAYER

CD-R/RW playback <S = With skip play> • • • • • • • • S S • • •

WMA (Windows MediaTM Audio) playback with WMA Tag(4) • • • • • • • •

•

MP3 playback with ID3 Tag(4) • • • • • • • •

•

iTunes AAC playback(4) • • • • •

•

WAV file playback(4) • • • • • • • •

•

Folder/file list search (CD-ROM) • • • • • • •

•

D/A Converters with 8× oversampling digital filter <24 = Multi 24-bit, 1 1 1 1 1 1 1 1 1 1 24 B

B = Burr Brown, 1 = 1-bit>

Digital direct

• • •

Track scan • • • • • • • • • • •

CD pause • • • • • • • • • • • • •

Track/manual search

• • • •

Disc exist search

• •

Repeat (CD-DA: disc/track, CD-ROM: file/folder) <C = CD-DA only, • • • • • • • • M M C C •

M = Magazine/disc/track>

Random play <M = Magazine, D = Disc> D D D D D D D D M/D M/D D D D

Disc title memory (48 titles) • • •

• • • •

CD error code transmission capabilities

• •

One-day memory backup

• •

Last position memory

• •

CD Text • • • • • • • • • • • • •

Digital compression

•

BMX (Bitmetric Equalizer)

•

CASSETTE PLAYER

Radio intercept

•

TUNER

Supertuner® (IIID+ = Supertuner® IIID+, IIID = Supertuner® IIID, IIID IIID IIID IIID IIID IIID IIID IIID • IIITM IIITM IIID+

IIITM = Supertuner® IIITM)

BSM (Best Stations Memory) • • • • • • • • • • • •

Local seek tuning • • • • • • • • • • • •

24-station (18 FM/6 AM) presets • • • • • • • • • • • •

9 kHz/10 kHz AM channel spacing switch <9 = 9 kHz only> • • • • • • • • • 9 9 •

AUDIO

High precision sound master clock circuitry

•

Hi-bit conversion

• •

High-power MOSFET 50 W × 4 (max.) • • • • • • • •

•

output 45W × 4 (max.)

•

Gold-plated 8-channel RCA output (high/mid/low/subwoofer)

• •

3 RCA pre-outs Front + Rear + Non-fading <G = Gold-plated> G

Front + Rear + Subwoofer <G = Gold-plated> • • G

2 RCA pre-outs Front + Rear/Subwoofer (selectable) • •

Front + Rear

•

RCA pre-out Rear/Subwoofer (selectable) •

Rear

• • •

High-voltage pre-out (V) 4 4 4 4 5 4 4

IP-Bus input/output I I I I I I • • I I I

Optical input/output

• •

Optical input <D = with DEX-P90RS, R = with RS-D7RII> R D

Frequency change: 96kHz to 44.1kHz

•

Advanced Sound Retriever • • • • • • •

DSP/EEQ Built-in DSP (Digital Signal Processor)

• • •

EEQ (Easy Equalizer) • • • • • • • •

•

Multi 24-bit Burr Brown D/A Converters

• •

Burr Brown advanced segment-type 24-bit D/A Converter

•

DEH-P7150UB

DEH-6150BT

DEH-P5150UB

DEH-4150SD

DEH-3150UB

DEH-2150UBG

DEH-1150MPG

FH-P6050UB

CDX-P1280

CDX-P680

KEH-P2035

RS-D7RII

DEX-P90RS

DEH-P80RSII

RS-P90

DEQ-P90

Headunits Specifications

1-DIN Players Component Add-on DSP Units

DEH-P7150UB DEH-6150BT DEH-P5150UB DEH-4150SD DEH-3150UB DEH-2150UBG DEH-1150MPG RS-P90 DEQ-P90

CD PLAYER

S/N ratio [1kHz, IEC-A Network] dB 94 94 94 94 94 94 94 — —

TUNER

Frequency range FM MHz 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 — —

AM [10 kHz] kHz 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 530 to 1 640 — —

[9 kHz] kHz 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 — —

FM usable sensitivity [75 Ω, mono, S/N: 30 dB] dBf

9 [0.7 μV] 9 [0.8 μV] 9 [0.7 μV] 9 [0.7 μV] 11 [0.7 μV] 11 [0.7 μV] 11 [0.7 μV] — —

AM usable sensitivity [S/N: 20 dB] μV 25 25 25 25 25 25 25 — —

COMPONENT ADD-ON DSP UNIT

Equalization frequency Hz — — — — — — — 20 to 20 000 20 to 20 000

Equalization range dB — — — — — — — ±12 ±12

Distortion [1 kHz, 500 mV, 20 KLPF] % — — — — — — — 0.002 0.005

Frequency response [–1 dB] Hz — — — — — — — 10 to 20 000 10 to 20 000

S/N ratio [IEC-A network] dB — — — — — — — 115 109

Output impedance Ω — — — — — — — 220 1 k

Max. output level — — — — — — —

4.0 V/1 kHz, 1 % dist. 4.0 V/1 kHz, 1 % dist.

AUDIO

Max. power output* 50 W × 4 50 W × 4 50 W × 4 50 W × 4 50 W × 4 50 W × 4 50 W × 4 — —

Continuous power output 22 W × 4 22 W × 4 22 W × 4 22 W × 4 22 W × 4 22 W × 4 22 W × 4 — —

GENERAL

Dimensions [W × H × D] DIN—Chassis mm 178 × 50 × 165 178 × 50 × 162 178 × 50 × 162 178 × 50 × 162 178 × 50 × 162 178 × 50 × 165 178 × 50 × 162 240 × 59 × 240 191 × 49 × 220

Nose mm 188 × 58 × 18 188 × 58 × 24 188 × 58 × 17 188 × 58 × 24 188 × 58 × 22 188 × 58 × 15 188 × 58 × 15 — —

D—Chassis mm 178 × 50 × 165 178 × 50 × 162 178 × 50 × 162 178 × 50 × 162 178 × 50 × 162 178 × 50 × 165 178 × 50 × 162 — —

Nose mm 170 × 45 × 18 170 × 46 × 24 170 × 48 × 17 170 × 46 × 24 170 × 48 × 22 170 × 48 × 15 170 × 48 × 15 — —

* Peak momentary power output

Comparison & Specifications

Headunits Features Comparison

DEH-P7150UB

DEH-6150BT

DEH-P5150UB

DEH-4150SD

DEH-3150UB

DEH-2150UBG

DEH-1150MPG

FH-P6050UB

CDX-P1280

CDX-P680

KEH-P2035

RS-D7RII

DEX-P90RS

DEH-P80RSII

RS-P90

DEQ-P90

AUDIO (continued)

DSP/EEQ Advanced Segment 24-bit D/A Converter

•

(continued) High-performance 32-bit floating binary point type DSP

•

High-performance 8× oversampling digital filter

• •

5-mode equalizer P P P P P P P P P

• P

Auto EQ

•

Auto EQ for 3-way network

•

BBE® digital sound processing(5)

•

Digital listening position selector

• • •

Time alignment <A = Auto> A

• •

BMX (Bitmetric Equalizer)

•

Digital graphic equalizer <31 = 31-band, 16 = 16-band, 7 7

16, L/R 31, L/R

7 = 7-band> <L/R = L/R independent>

31-band L/R independent equalizer

•

3-band parametric equalizer <L/R = L/R independent> • • L/R

L/R independent 3-way crossover: high/mid/low

•

3-way digital network

•

Parametric bass/treble controls

• •

4-way independent L/R crossover network (high/mid/low/subwoofer)

• •

Direct Sub Drive • • • • •

Subwoofer control • • • • •

•

Loudness <H = High, M = Mid, L = Low, 2 = 2-mode selectable> H/M/L H/M/L H/M/L H/M/L H/L H/L H/L H/M/L 2 •

BTB (Bass/Treble Booster)

•

Fader • • • • • • • • • • • •

Electronic volume/balance controls • • • • • • • • • • • • • •

Electronic bass/treble controls

• •

Tone control B/M/T B/M/T B/M/T •

SLA (Source level adjuster) • • • • • • • • • • • •

Spectrum analyzer • •

•

Level indicator <L/R = L/R independent> • • L/R

Cellular mute • •

• • • •

GENERAL

Rotary Commander • • • • •

•

Rotary volume • • •

• •

Wireless remote controller <10 = 10-key direct access remote, C = Card> 10 10 C C C C C C • • 10

Wired remote control input • • • • • •

Face type <A = Auto-slide, F = Flap-type, P = Pop-up> A P P P F P P A A A

High-quality hairline aluminum front panel

•

Detachable Face SecurityTM • • • • • • • • • • •

Clock <E = Entertainment> E • • • • • • • • • • E

Full Dot OEL (Organic EL) display <W = White> W • W W W

3-line segmented OEL (Organic EL) display

•

LCD display (White) • • • • •

Dual illumination (white or red selectable)

•

Adjustment B B C C B

System control terminal • • • • • • • • • • • •

Multi-language guide (English/Spanish/Portuguese) • •

•

Display off security • • • • • • • •

Source CD control (External unit control) • •

•

Source TV control (Analog tuner control) • •

• • • •

Source DVD control • •

• • • •

External unit control via IP-Bus 2 2 2 1

• 2 2

Direct AUX-in AUX-1 <F = Front, R = Rear, 20 = CD-RB20 only> R F F F F F F R 20 20 •

AUX-2(6) • •

•

Gold-plated screw-type power/ground terminals

• •

One-sided terminals and square aluminum bonnet

•

Copper-plated chassis

• •

OFC power/ground cable included

•

•Versatile horizontal/vertical mounting: 0° to 90° (5 steps switchable) •IP-Bus

output for direct headunit connection •Entire chassis anti-vibration system

• •

•Voice recognition with CD-VC60

6m IP-Bus cable included

• •

Uses 12-disc magazine JD-1212S (one included)

•

Uses 6-disc magazine JD-612V (one included)

•

(1) Please use CD-U50E USB extension cable if a direct connection causes a USB device to protrude from the headunit in a way that can interfere with driving. (2) CD-IU50 required (3) Artist only (4) With CD-ROM and CD-R/RW discs.

(5) BBE: Licensed by BBE Sound, Inc. under USP4638258 and 4482866. BBE and BBE symbol are registered trademarks of BBE Sound Inc. (6) IP-Bus with CD-RB10 or CD-RB20.

Headunits Specifications

Component Single-CD Players 2-DIN Player Multi-CD Players Cassette Player

RS-D7RII DEX-P90RS DEH-P80RSII FH-P6050UB CDX-P1280 CDX-P680 KEH-P2035

CD PLAYER

S/N ratio [1 kHz, IEC-A network] dB — 107 105 94 92 92 —

CASSETTE PLAYER

Wow & flutter [WRMS] % — — — — — — 0.13

Tape frequency response [±3 dB] Hz — — — — — — 30 to 16 000

Tape S/N ratio [IEC-A network] dB — — — — — — 52

TUNER

Frequency range FM MHz 87.5 to 108 87.5 to 108 87.5 to 108 87.5 to 108 — — 87.5 to 108

AM [10 kHz] kHz — — 530 to 1 640 530 to 1 640 — — 530 to 1 640

[9 kHz] kHz 531 to 1 602 531 to 1 602 531 to 1 602 531 to 1 602 — — 531 to 1 602

FM usable sensitivity [75 Ω, mono, S/N: 30 dB] dBf 9 [0.8 μV] 9 [0.8 μV] 8 [0.7 μV] 8 [0.7 μV] — — 11 [1.1 μV]

AM usable sensitivity [S/N: 20 dB] μV 18 18 18 18 — — 20

AUDIO

Max. power output* — — 50 W × 4 50 W × 4 — — 45 W × 4

Continuous power output — — 22 W × 4 22 W × 4 — — 22 W × 4

GENERAL

Dimensions [W × H × D] DIN—Chassis mm 178 × 50 × 160 178 × 50 × 160 178 × 50 × 159 — 257 × 94 × 170** 248 × 66 × 168** 178 × 50 × 155

Nose mm 188 × 58 × 20 188 × 58 × 20 188 × 58 × 30 — — — 188 × 58 × 20

D—Chassis mm 178 × 50 × 165 178 × 50 × 165 178 × 50 × 164 178 × 100 × 160 — — 178 × 50 × 160

Nose mm 170 × 45 × 15 170 × 45 × 15 170 × 45 × 25 170 × 94 × 8 — — 170 × 48 × 15

* Peak momentary power output ** Chassis dimensions only

Comparison & Specifications

Power Amplifiers Specifications

GM-6400F GM-5400T

GM-D8400M GM-D7400M

GM-3300T RS-A9 RS-A7

PRS-D2000SPL PRS-D1200SPL

PRS-D4200F PRS-D2200T PRS-D1200M

PRS-A900

Max. power 4-channel mode

120 W × 4 (4 Ω)

— — — —

100 W × 4 (4 Ω) 100 W × 4 (4 Ω)

— —

150 W × 4 (4 Ω)

— —

100 W × 4 (4 Ω)

output [14.4 V] 3-channel mode

120 W × 2 +

— — — —

100 W × 2 +

— —

150 W × 2 +

— —

100 W × 2 +

300 W × 1 (4 Ω) 300 W × 1 (4 Ω) 300 W × 1 (4 Ω) 600 W × 1 (4 Ω) 200 W × 1 (4 Ω)

2-channel mode

300 W × 2 (4 Ω)

250 W × 2 (4 Ω)

— —

120 W × 2 (4 Ω) 300 W × 2 (4 Ω) 300 W × 2 (4 Ω)

— —

600 W × 2 (4 Ω) 300 W × 2 (4 Ω)

—

200 W × 2 (4 Ω)

1-channel mode —

760 W × 1 (4 Ω)

600 W × 1 (4 Ω)

400 W × 1 (4 Ω) 300 W × 1 (4 Ω)

— —

1500W × 1 (4 Ω) 1 000 W × 1 (4 Ω)

—

1200W × 1 (4 Ω) 800 W × 1 (4 Ω)

—

1200W × 1 (2 Ω)

800 W × 1 (2 Ω)

3 000 W × 1 (2 Ω) 2 000 W × 1 (2 Ω)

1200W × 1 (2 Ω)

4 000 W × 1 (1 Ω) 2 400 W × 1 (1 Ω)

Continuous 4-channel mode 60 W × 4 (4 Ω) — — — — 50 W × 4 (4 Ω) 50 W × 4 (4 Ω) — —

75 W × 4 (4 Ω)

— — 50 W × 4 (4 Ω)

power output 75 W × 4 (2 Ω) 75 W × 4 (2 Ω) 75 W × 4 (2 Ω)

150 W × 4 (2 Ω)

50 W × 4 (2 Ω)

[14.4 V] 3-channel mode

60 W × 2 +

— — — —

50 W × 2 +

— —

75 W × 2 +

— —

50 W × 2 +

150 W × 1 (4 Ω) 150 W × 1 (4 Ω) 150 W × 1 (4 Ω) 300 W × 1 (4 Ω) 100 W × 1 (4 Ω)

2-channel mode

150 W × 2 (4 Ω)

125 W × 2 (4 Ω)

— — 60 W × 2 (4 Ω)

150 W × 2 (4 Ω) 150 W × 2 (4 Ω)

— —

300 W × 2 (4 Ω) 150 W × 2 (4 Ω)

—

100 W × 2 (4 Ω)

190 W × 2 (2 Ω)

75 W × 2 (2 Ω)

300 W × 2 (2 Ω)

1-channel mode —

380 W × 1 (4 Ω)

300 W × 1 (4 Ω) 200 W × 1 (4 Ω) 150 W × 1 (4 Ω)

— —

750 W × 1 (4 Ω) 500 W × 1 (4 Ω)

—

600 W × 1 (4 Ω)

400 W × 1 (4 Ω)

—

600 W × 1 (2 Ω) 400 W × 1 (2 Ω)

1500W × 1 (2 Ω) 1 000 W × 1 (2 Ω)

600 W × 1 (2 Ω)

2 000 W × 1 (1 Ω) 1 200 W × 1 (1Ω)

600 W × 1 (1 Ω)*

Frequency +0 dB, –1 dB Hz 10 to 50 000 10 to 50 000 — — 10 to 50 000 10 to 100 000 10 to 100 000 — — — — — 10 to 100 000

response +0 dB, –3 dB Hz — — 10 to 240 10 to 240 — — — 10 to 240 10 to 240 10 to 50 000 10 to 50 000 10 to 240 —

+0.5 dB, –3 dB Hz — — — — — — — — — — — — —

Total harmonic distortion % 0.03 0.03 0.3 0.3 0.008 0.002 0.002 0.3 0.3 0.005 0.005 0.03 0.003

S/N ratio [IEC-A network] dB 95 95 80 80 100 105 105 85 80 100 100 92 108

Dimensions (W × H × D) mm

265 × 62 × 346

290 × 56 × 200 225 × 56 × 200 300 × 60 × 194 585 × 330 × 71 585 × 330 × 71 586 × 282 × 65 381 × 282 × 65 301 × 57 × 213 301 × 57 × 213 301 × 57 × 213 282 × 65 × 371

*Hi-current mode

Power Amplifiers Features Comparison

Bridgeable 4/3/2-channel capability <F = Class-FD> •

• • F

•

Bridgeable 2/1-channel capability <F = Class-FD> • • F

Mono amplifier <D = Class-D> D D D D D

Current feedback amplifier

• •

•

Single-ended output circuit • •

•

L/R independent power supply

• •

•

L/R symmetric layout circuit

•

Full balanced system (bridgeable connection) • •

High-performance 32-bit floating binary point type DSP •

Built-in DSP (Digital Signal Processor) (FIR) •

Multi 24-bit Burr Brown D/A Converters • •

Variable LPF/HPF (40Hz to 500Hz, –12dB/oct.)

• •

Variable LPF (40Hz to 240Hz, –24dB/oct.)

• •

Variable LPF (40Hz to 240Hz, –18dB/oct.)

•

Variable LPF (40 Hz to 240 Hz, –12 dB/oct.) • •

LPF/HPF (80 Hz, –12 dB/oct.) for A and B channels •

LPF (80 Hz, –12 dB/oct.) • •

Input level control (400 mV to 6.5 V) <L/R = L/R independent> • • • • • • L/R

Input level control (200 mV to 6.5 V) • • • •

Low load impedance capability (4 Ω, 2 Ω to 8 Ω allowable) • • • • • • • • • •

Low load impedance capability (1Ω to 8Ω)

• • •

Optical digital input 1 2

3 optical digital outputs (mid/low/subwoofer) •

IP-Bus input/output

• •

RCA input and output terminals <G = Gold-plated> •(1) G G G G G

RCA input terminals <G = Gold-plated> • • • • G

Screw-type speaker terminals <G = Gold-plated> • • • G G

Large block-type speaker terminals <G = Gold-plated> •(2) •(2) G

(3) G

(2) G

(4)

Large screw-type power/ground terminals <G = Gold-plated> • • • G G

Large block-type power/ground terminals <G = Gold-plated> •(5) •(5) G

(6) G

(3) G

(5) G

(5)

Speaker level input (0.8 V to 26 V) • •

Speaker level input (1.6 V to 26 V) • • •

• • •

Speaker line input turn-on sensor • •

• • •

Bass Boost (40 Hz to 120 Hz, 0 dB to +12 dB variable) <R = Remote> R R

Bass Boost (50 Hz, 0 dB to 12 dB variable) <R = Remote> R

Bass Boost (50 Hz, 0 dB/+6 dB/+9 dB/+12 dB) <R = Remote> •(7) •(7) R R

Subsonic filter (20Hz, –24dB/oct.)

• •

Subsonic filter (20Hz, –18dB/oct.)

•

SYNC control

• • •

PWM regulated power supply with MOSFET switching • •

•

High-performance balanced isolator circuit • • • • • • • •(8) •(8) •(8) •

High-efficiency MOSFET output section • •

• • • • •

Multi Emitter Bipolar Transistor

•

MASS (Multiple Amplifier Synchronization System)

• • •

Sound master clock

• •

DAC volume

• •

All terminals placed on one side

• • •

Removable terminal/settings cover

• • • • •

TVC (Total Vibration Control) technology

• • • •

Copper-plated chassis

• •

Black heatsink with aluminum plate • • •

Black metallic mesh with silver plate • •

(1) Output for A-channel (2) 12 to 16-gauge (3) 4-gauge (4) 12 to 18-gauge (5) 4 to 8-gauge (6) 0/1-gauge (7) Bass Boost level: 0 dB/+6 dB/+12 dB only (8) Input circuit

GM-6400F

GM-5400T

GM-D8400M

GM-D7400M

GM-3300T

RS-A9

RS-A7

PRS-D2000SPL

PRS-D1200SPL

PRS-D4200F

PRS-D2200T

PRS-D1200M

PRS-A900

Notes: Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

iPod is for legal or rightholder-authorized copying only. Don’t steal music. iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc.

iTunes is a trademark of Apple Inc., registered in the U.S. and other countries. AAC players can decode only those AAC files ripped and encoded using iTunes.

Unauthorized copying of music is strictly prohibited. Not every device is compatible. See more details in Pioneer website. Compatible with USB memory device only.

Not compatible with DRM (Digital Rights Management) contents and MTP (Media Transfer Protocol) connection players.

“SD” and “SDHC” Logos are trademarks.

Bluetooth® and associated logos are trademarks of Bluetooth SIG, Inc.

Parrot and Parrot logo are registered trademarks of Parrot SA.

DivX, DivX Certified and associated logos are trademarks of DivX, Inc. and are used under license.

Dolby, Pro Logic and the double-D symbol are registered trademarks of Dolby Laboratories.

DTS, DTS-ES, DTS Neo:6 and DTS 96/24 are registered trademarks of Digital Theater System, Inc.

Comparison & Specifications

Subwoofers & Speakers Specifications

Size Max. Nominal

Frequency Response Sensitivity Impedance Dimensions Mounting Cut-Out

Input Input (W × H × D) Depth Dimensions

TS-W01RSII 25 cm 300 W 150 W 25 Hz to 3 800 Hz 86 dB 4 Ω ø276 mm × 94 mm 75 mm ø238 mm

TS-M01RSII 17 cm 120 W 50 W 35 Hz to 12 000 Hz 89 dB 4 Ω ø174 mm × 75 mm 69 mm ø151 mm

TS-S01RSII 7.7 cm 50 W(1) 15 W 70 Hz to 24 000 Hz(1) 86 dB 4 Ω ø90 mm × 42.5 mm(1) 37.5 mm(1) ø72.5 mm(1)

60 W(2) 120 Hz to 24 000 Hz(2) ø90 mm × 67 mm(2) 60 mm(2) ø77 mm(2)

TS-T01RSII 3.5 cm 120 W 50 W 1 000 Hz to 48 000 Hz 95 dB 6 Ω ø68 mm × 64 mm — —

TS-W12PRS 30 cm 1 200 W 300 W 15 Hz to 2 000 Hz 92 dB 2 Ω or 8 Ω ø322 mm × 152 mm 133 mm ø278 mm

TS-M171PRS 17 cm 200 W 50 W 25 Hz to 9 000 Hz 88 dB 4 Ω ø156 mm × 78 mm 67 mm ø158 mm

TS-S101PRS 10 cm 60 W 15 W 60 Hz to 30 000 Hz 86 dB 4 Ω ø110 mm × 52 mm 46 mm ø90 mm

TS-T031PRS 28 mm 200 W 50 W 1 200 Hz to 32 000 Hz 90 dB 4 Ω ø55 mm × 27.1 mm 12.2 mm ø47 mm

TS-C171PRS 17 cm 200 W 50 W 25 Hz to 32 000 Hz 88 dB 4 Ω ø156 mm × 78 mm 67 mm ø140 mm

TS-C131PRS 13 cm 150 W 30 W 35 Hz to 32 000 Hz 88 dB 4 Ω ø129 mm × 67 mm 57.3 mm ø121 mm

TS-W8102SPL 38 cm 8 000 W 3 000 W 15 Hz to 1 500 Hz 91 dB 1 Ω or 4 Ω ø400 mm × 359.5 mm 312 mm ø352 mm

TS-W5102SPL 30 cm 6 000 W 2 500 W 18 Hz to 2 000 Hz 88 dB 1 Ω or 4 Ω ø327 mm × 304 mm 266 mm ø278 mm

TS-W3002D4 30 cm 3 500 W 1 000 W 20 Hz to 150 Hz 90 dB 2 Ω or 8 Ω ø329 mm × 214 mm 188.8 mm ø278 mm

TS-W2502D4 25 cm 3 000 W 800 W 20 Hz to 150 Hz 89 dB 2 Ω or 8 Ω ø283 mm × 193 mm 169 mm ø238 mm

TS-W308D2 30 cm 1 400 W 400 W 20 Hz to 180 Hz 91 dB 2 Ω DVC ø327 mm × 172 mm 153 mm ø278 mm

TS-W308D4 30 cm 1 400 W 400 W 20 Hz to 180 Hz 92 dB 4 Ω DVC ø327 mm × 172 mm 153 mm ø278 mm

TS-W258D2 25 cm 1 200 W 350 W 20 Hz to 450 Hz 90 dB 2 Ω DVC ø277 mm × 162 mm 143 mm ø238 mm

TS-W258D4 25 cm 1 200 W 350 W 20 Hz to 450 Hz 90 dB 4 Ω DVC ø277 mm × 162 mm 143 mm ø238 mm

TS-W308F 30 cm 1 000 W 300 W 20 Hz to 1 100 Hz 95 dB 4 Ω ø327 mm × 162 mm 143 mm ø302 mm

TS-W258F 25 cm 800 W 250 W 20 Hz to 1 400 Hz 92 dB 4 Ω ø277 mm × 150 mm 131 mm ø255 mm

TS-W302R 30 cm 800 W 150 W 20 Hz to 90 Hz 97 dB 4 Ω ø327 mm × 164 mm 145 mm ø278 mm

TS-W252R 25 cm 600 W 120 W 20 Hz to 110 Hz 95 dB 4 Ω ø277 mm × 154 mm 135 mm ø238 mm

TS-SW3001S2 30 cm 1 500 W 400 W 20 Hz to 230 Hz 93 dB 2 Ω ø329 mm × 100 mm 81 mm ø278 mm

TS-SW3001S4 30 cm 1 500 W 400 W 20 Hz to 230 Hz 93 dB 4 Ω ø329 mm × 100 mm 81 mm ø278 mm

TS-SW2501S2 25 cm 1 200 W 300 W 20 Hz to 290 Hz 90 dB 2 Ω ø282 mm × 93 mm 75.1 mm ø238 mm

TS-SW2501S4 25 cm 1 200 W 300 W 20 Hz to 290 Hz 90 dB 4 Ω ø282 mm × 93 mm 75.1 mm ø238 mm

TS-SW841D 20 cm 500 W 120 W 30 Hz to 1 500 Hz 85 dB 4 Ω ø218.4 mm × 75.2 mm 63.5 mm ø186 mm

TS-SW301 30 cm 1 000 W 250 W 20 Hz to 114 Hz 91 dB 4 Ω ø327 mm × 100 mm 86 mm ø278 mm

TS-SW251 25 cm 800 W 200 W 20 Hz to 144 Hz 89 dB 4 Ω ø278 mm × 92 mm 78 mm ø238 mm

TS-WX301 30 cm 800 W 150 W 20 Hz to 400 Hz 95 dB 4 Ω

501 mm × 389 mm × 415 mm

— —

TS-WX11A

13 cm × 21 cm

150 W(3) 50 W(4) 54 Hz to 200 Hz 101 dB(5) — 280 mm × 80 mm × 200 mm — —

TS-WX22A 20 cm 150 W(3) 60 W(4) 40 Hz to 200 Hz 101 dB —

250 mm × 265 mm × 110 mm

— —

TS-WX206A 20 cm 150 W(3) 60 W(4) 35 Hz to 200 Hz 107 dB(5) —

274 mm × 316 mm × 412 mm

— —

TS-D1720C 17 cm

260 W 60 W 30 Hz to 33 000 Hz 88 dB 4 Ω ø156 mm × 81.9 mm 64.5 mm ø144 mm

28 mm(6) 51 mm(6)

TS-D1320C 13 cm

180 W 35 W 35 Hz to 33 000 Hz 88 dB 4 Ω ø129 mm × 63.4 mm 57.5 mm ø121 mm

28 mm(6)

TS-D6902R 6" × 9" 360 W 80 W 28 Hz to 30 000 Hz 90 dB 4 Ω

237 mm × 106.2 mm × 163 mm

89 mm 220 mm × 151 mm

TS-D1702R 17 cm 280 W 60 W 30 Hz to 32 000 Hz 87.5 dB 4 Ω ø156 mm × 81.9 mm 64.5 mm ø144 mm

TS-D1602R 16 cm 260 W 60 W 35 Hz to 32 000 Hz 88 dB 4 Ω ø161 mm × 80.4 mm 59 mm ø128 mm

TS-D1302R 13 cm 180 W 35 W 35 Hz to 40 000 Hz 88 dB 4 Ω ø129 mm × 67.8 mm 57.5 mm ø121 mm

TS-D1002R 10 cm 110 W 25 W 40 Hz to 40 000 Hz 86 dB 4 Ω ø125 mm × 46.2 mm 46.5 mm ø106 mm

TS-A1702C 17 cm 230 W 50 W 31 Hz to 35 000 Hz 90 dB 4 Ω ø156 mm × 68.5 mm 62.5 mm ø139 mm

23 mm(6) 49.5 mm(6)

TS-A1302C 13 cm 180 W 35 W 36 Hz to 30 000 Hz 90 dB 4 Ω ø129 mm × 58.9 mm 53 mm ø121 mm

23 mm(6)

TS-A6993S 6" × 9" 460 W 80 W 30 Hz to 37 000 Hz 92 dB 4 Ω

237 mm × 163 mm × 109 mm

85 mm 151 mm × 220 mm

TS-A6983S 6" × 9" 440 W 80 W 30 Hz to 31 000 Hz 92 dB 4 Ω

237 mm × 163 mm × 108 mm

84 mm 151 mm × 220 mm

TS-A6973E 6" × 9" 400 W 80 W 30 Hz to 28 000 Hz 91 dB 4 Ω

237 mm × 163 mm × 104.6 mm

84 mm 151 mm × 220 mm

TS-A6963E 6" × 9" 300 W 40 W 30 Hz to 36 000 Hz 91 dB 4 Ω

237 mm × 163 mm × 91.6 mm

72 mm 151 mm × 220 mm

TS-A6872R 6" × 8" 240 W 40 W 35 Hz to 32 000 Hz 90 dB 4 Ω

203.7 mm × 145 mm × 72.5 mm

62 mm 191 mm × 133 mm

TS-A2503i 25 cm 420 W 80 W 20 Hz to 31 000 Hz 92 dB 4 Ω ø285 mm × 152 mm 115 mm ø236 mm

TS-A2003i 20 cm 400 W 80 W 27 Hz to 32 000 Hz 90 dB 4 Ω ø244 mm × 132 mm 96 mm ø202 mm

TS-A1683S 16 cm 280 W 50 W 36 Hz to 28 000 Hz 91 dB 4 Ω ø160 mm × 75 mm 57 mm ø128 mm

TS-A1673S 16 cm 220 W 35 W 37 Hz to 25 000 Hz 91 dB 4 Ω ø160 mm × 64 mm 44 mm ø128 mm

TS-G1642R 16 cm 180 W 30 W 40 Hz to 30 000 Hz 90 dB 4 Ω ø158 mm × 55 mm 42 mm ø142 mm

TS-G1612R 16 cm 160 W 30 W 30 Hz to 25 000 Hz 90 dB 4 Ω ø158 mm × 55 mm 44 mm ø142 mm

TS-G1342R 13 cm 140 W 25 W 40 Hz to 25 000 Hz 89 dB 4 Ω ø149 mm × 57 mm 46 mm ø129 mm

TS-G1312R 13 cm 130 W 25 W 30 Hz to 25 000 Hz 89 dB 4 Ω ø149 mm × 49 mm 46 mm ø129 mm

TS-G1042R 10 cm 120 W 25 W 35 Hz to 30 000 Hz 87 dB 4 Ω ø125 mm × 43 mm 43 mm ø106 mm

TS-G1012R 10 cm 110 W 20 W 35 Hz to 29 000 Hz 87 dB 4 Ω ø125 mm × 43 mm 43 mm ø106 mm

TS-2150 20 cm 200 W 50 W 28 Hz to 28 000 Hz 91 dB 4 Ω

238 mm × 238 mm × 176 mm

88 mm ø186 mm

TS-S250 40 mm 250 W 50 W 6 000 Hz to 40 000 Hz 97 dB 8 Ω ø44 mm × 24 mm — —

TS-S20 20 mm 200 W 50 W 3000Hz

(7)/ 92 dB 8 Ω

85.5 mm × 73.5 mm × 32.8 mm

— —

1200 Hz(8) to 26 000 Hz

TS-T110 22 mm 120 W 40 W 2 500 Hz to 30 000 Hz 90 dB 4 Ω ø47.1 mm × 20.5 mm — —

TS-T15 20 mm 120 W 40 W 2 500 Hz to 30 000 Hz 90 dB 4 Ω ø37.5 mm × 18.9 mm — —

TS-CX900 6.6 cm 80 W 20 W 80 Hz to 70 000 Hz 85 dB 4 Ω 98 mm × 120.5 mm × 41 mm — —

TS-MR2040 20 cm 200 W 40 W 25 Hz to 30 000 Hz 92 dB 4 Ω ø230 mm × 115 mm 75 mm ø186 mm

TS-MR1640 16 cm 160 W 30 W 30 Hz to 30 000 Hz 91 dB 4 Ω ø175 mm × 84.5 mm 56 mm ø130 mm

TS-MR1600 16 cm 100 W 25 W 30 Hz to 20 000 Hz 90 dB 4 Ω ø175 mm × 84.5 mm 56 mm ø130 mm

(1) With speaker unit only (2) With back chamber (3) Maximum output power (4) Nominal output power (5) In-car, at 65 Hz (6) With mounting adapter (7) With network (8) Without network

Dimensions

Subwoofer

Enclosed Subwoofer

Speakers

Cut-Out Dimension

Mounting

Depth

Cut-Out Dimension

Mounting

Depth

Cut-Out Dimension

Mounting

Depth

Subwoofer Thiele-Small Parameters*

Recommended cu. ft. 0.49 to 0.99 1.0 2.5 1.5 0.80 0.60 1.25 1.25 0.80 0.80 — — 1.5 1.00 0.65 0.65 0.45 0.45 0.15 to 0.5 0.65 0.45

enclosure liters 17 28.3 70.8 42.5 22.64 16.98 35.4 35.4 22.6 22.6 — — 42.5 28.3 18.4 18.4 12.7 12.7 4.2 to 14.2 18.4 12.7

Revc Ω 3.0 1.8/7.2 3.0 3.0 DUAL3.3 DUAL3.3 DUAL1.5 DUAL3.2 DUAL1.5 DUAL3.0 3.0 3.0 3.0 3.0 1.5 3.0 1.5 3.0 3.3 3.0 3.0

Levc mH 0.641 0.4/1.61 5.560 5.090 5.55 (8 Ω) 4.80 (8 Ω) 2.18 (4 Ω) 3.76 (8 Ω) 2.2 (4 Ω) 3.59 (8 Ω) 1.237 1.101 1.380 1.370 1.300 2.900 0.880 2.520 0.996 2.4 2.4

1.39 (2 Ω) 1.20 (2 Ω) 0.65 (1 Ω) 1.30 (2 Ω) 0.63 (1 Ω) 1.07 (2 Ω)

Fs Hz 23.5 24 23.2 29.0 31.4 36.0 33.7 34.5 37.4 40.5 26.3 34.5 28.0 28.9 36.8 35.1 44.4 41.6 67.5 34.9 41.3

Zmax Ω 50.4 43.8/175 58.56 70.62 157.77 (8 Ω) 133.73 (8 Ω) 99.13 (4 Ω) 177.44 (8 Ω) 96.01 (4 Ω) 147.55 (8 Ω) 28.80 29.30 35.78 47.38 27.39 59.41 21.29 46.51 25.21 28.21 28.77

38.53 (2 Ω) 32.72 (2 Ω) 24.81 (1 Ω) 45.58 (2 Ω) 19.95 (1 Ω) 38.80 (2 Ω)

Qms 5.72 9 5.720 7.600 15.13 14.34 14.11 16.43 11.52 13.64 7.910 9.300 8.120 9.130 13.210 13.800 12.790 13.210 11.159 9.040 9.870

Qes 0.38 0.41 0.330 0.360 0.68 0.78 0.50 0.65 0.50 0.61 0.880 1.170 0.790 0.730 0.880 0.780 1.090 1.000 1.923 1.140 1.150

Qts 0.36 0.39 0.310 0.340 0.65 0.74 0.48 0.62 0.48 0.58 0.800 1.040 0.720 0.680 0.820 0.740 1.000 0.930 1.641 1.020 1.090

Vas cu. ft. 2.46 3.3 2.479 0.944 0.460 0.240 1.28 1.22 0.620 0.550 3.380 1.670 3.679 2.045 0.634 0.703 0.320 0.363 0.067 0.702 0.345

liters 69.8 93 70.14 26.72 13.03 6.77 36.16 34.68 17.63 15.47 95.66 47.32 104.12 57.86 17.96 19.90 9.06 10.27 1.89 19.866 9.754

Rms Ns/m 2.93 2.3 20.367 13.470 5.334 4.602 2.773 2.426 2.920 2.601 2.732 2.040 2.293 1.686 4.492 4.071 3.922 3.576 4.063 6.820 5.430

Mms g 102 135 800.11 550.50 408.83 291.71 184.95 184.17 143.28 139.43 131.00 87.50 110.82 84.73 256.62 255.35 179.16 179.79 106.67 281.19 206.57

Cms m/N 3.70E-04 3.15 × 10 –4 6.00 × 10 –5 5.350 × 10 –5 6.29E-05 6.66E-05 1.20E-04 1.20E-04 1.30E-04 1.10E-04 2.800E-04 2.400E-04 3.100E-04 3.600E-04 7.300E-05 8.100E-05 7.200E-05 8.100E-05 5.207 × 10 –5 7.40 0E- 05 7.10 0 E - 05

BL T•m 12.0 9.73/19.45 33.640 30.180 28.38 (8 Ω) 24.16 (8 Ω) 16.07 (4 Ω) 20.37 (8 Ω) 14.68 (4 Ω) 19.39 (8 Ω) 9.350 7.860 8.670 8.650 10.830 15.140 8.790 12.440 9.349 13.09 11.78

14.19 (2Ω) 12.08 (2Ω) 8.04 (1Ω) 10.14 (2Ω) 7.34 (1Ω) 9.65 (2Ω)

Sd sq. ft. 0.383 0.041 0.988 0.630 0.471 0.337 0.495 0.495 0.337 0.337 0.527 0.377 0.528 0.364 0.533 0.533 0.377 0.377 0.222 0.517 0.369

sq. m 3.56E-02 0.0456 9.18E-02 5.85E-02 4.37E-02 3.13E-02 4.60E-02 4.60E-02 3.13E-02 3.13E-02 4.90E-02 3.50E-02 4.91E-03 3.38E-02 4.95E-02 4.95E-02 3.50E-02 3.50E-02 2.06E-02 4.80E-02 3.43E-02

Hvc inch 0.93 1.56 2.392 2.087 1.96 1.68 1.08 1.20 1.21 1.68 1.260 1.209 0.799 0.799 1.055 0.850 0.937 0.815 0.594 1.213 0.900

mm 23.6 39.50 61 53 49.8 42.7 27.4 30.6 31 42.7 32 31 20.3 20.3 27 22 24 21 15 31 23

Hag inch 0.354 0.47 1.181 1.181 0.94 0.91 0.39 0.39 0.39 0.91 0.394 0.394 0.236 0.236 0.394 0.394 0.394 0.394 0.315 0.394 0.394

mm 9 12 30 30 24 23 10 10 10 23 10 10 6 6 10 10 10 10 8 10 10

Xmax inch 0.287 0.067 0.61 0.45 0.51 0.39 0.34 0.41 0.41 0.45 0.3 0.3 0.35 0.31 0.33 0.23 0.28 0.22 0.14 0.43 0.26

mm 7.3 1.89 15.4 11.5 12.9 9.8 8.7 10.3 10.4 11.5 8.5 8.5 8.8 7.8 8.4 5.8 7.0 5.5 3.5 10.8 6.6

* Parameter values for reference. ** See page 35 or 36 for product details.

TS-W01RSII**

TS-W12PRS**

TS-W8102SPL

TS-W5102SPL

TS-W3002D4

TS-W2502D4

TS-W308D2

TS-W308D4

TS-W258D2

TS-W258D4

TS-W308F

TS-W258F

TS-W302R

TS-W252R

TS-SW3001S2

TS-SW3001S4

TS-SW2501S2

TS-SW2501S4

TS-SW841D

TS-SW301

TS-SW251

For more information, call or write to:

EC99J2007

Printed with soy ink.

Visit us on the World Wide Web at

http://pioneer.jp

http://www.pioneer.com.sg

Published by Pioneer Corporation.

Specifications and design may be subject to modification

without notice.

Product colors and illumination may differ in photographs from actual

appearance, due to effects of printing and photography.

Code No.: 8104I Name: 09 CE AUDIO & AV GE (E-GreenBT/RC)

ADKI 02-09 Printed in Japan.

Glossary

Headunit Section

Advanced Sound Retriever

Details on pages 7, 15 and 25.

Bluetooth® Wireless Technology

Details on page 23.

CD-R/RW Compatibility

All Pioneer CD headunits can play back CD-R/RW discs,

allowing the user to enjoy favorite compilations in-car.

Detachable Face Security™ (DFS)

A theft-deterrent system invented by Pioneer which

revolutionized headunit security. With DFS, you simply lift

off the front panel (face) of the unit, slip it into a protective

case and take it with you. The unit’s sensitive electronics

remain protected in the dash; all that remains visible from

the dash is a black panel that won’t attract thieves.

Easy Equalizer

Details on page 28.

High-Voltage Pre-out

Pioneer’s High-Voltage Pre-out maximizes signal strength

to your amp. The benefits are superior dynamics, crisper

highs, more full-bodied bass, and a higher signal-to-noise

ratio for minimal noise interference attributable to

connections.

IP-Bus Control

The IP-Bus connections on Pioneer headunits allow the

user to connect optional source units such as a TV tuner,

DVD player, Multi-CD player or even an iPod and create

a true mobile multimedia center.

Digital Signal Processor

DSP uses digital technology to correct a vehicle’s interior

acoustics. The system also offers various sound fields to

recreate different listening environments in your car

(Studio, Jazz, Club, etc.).

Front USB Direct Connection

USB Direct Connection

Details on pages 15, 24 and 26.

OEL (Organic EL) Display

•

Full Dot OEL

Details on page 25.

•

Segmented OEL

Details on page 29.

iTunes AAC (Advanced Audio Coding)

Advanced Audio Coding (AAC) is a wideband audio codec

that dramatically reduces the amount of data needed to

convey high-quality digital audio.

MOSFET 50 W × 4

Details on page 27.

MP3

Popular compression format that allows large amounts of

audio files to be stored onto one CD-R/RW disc. Pioneer

players come equipped with buffering capabilities, so they

are all able to handle data rates from 16 kbps and VBR

(Variable Bit Rate) recording.

RCA Pre-out

The standard connection system to carry sound

from a headunit to an amplifier or equalizer. RCA

pre-outs provide easy output for connection to an

outboard amplifier.

Subwoofer Control

A function built into the headunit allows adjustment

of subwoofer frequency.

Supertuner® IIID+/Supertuner® IIID/

Supertuner® III™/Supertuner®

Beyond the minimal sound interference and resistance to

Three Signal Intermodulation (TSI) of Pioneer’s Supertuner®

line, Supertuner® IIID advanced analog and digital blocks

assure sound superiority and smoothly extend reception.

Supertuner® IIID+ features FM Multi-path Canceller for

improved stereo separation; AM Noise Canceller with

Hi-Speed Gate control counteracting external noise; and

Automatic Reception Control to strengthen weak signals.

Compact Disc Digital Video

Compact Disc Digital Video is comprised of animated,

or moving, images compressed in MPEG 1 format on a

Video CD.

DVD-R/RW Compatibility

Pioneer DVD players can playback large-capacity

DVD-R/RW discs.

Dolby® Digital

This breakthrough technology offers “5.1 channels”—five

discrete channels (front left and right, center, and rear left

and right) spanning frequencies from 20 Hz to 20 kHz, plus

a low-frequency effects channel dedicated to frequencies

of 120 Hz or below. These create an acoustic environment

in which sound seems to move all around the listener,

for supremely dramatic surround sound reproduction.

Dolby Pro Logic® II

Converts sound from 2-channel recorded sources (i.e. CD,

MD, TV/FM broadcast, Video, Game, etc.) into 5.1-channel

surround sound using matrix decode technology, so it is

easy to enjoy sound to more multi-dimensional effect.

DTSTM (Digital Theater Systems)

Six-channel DTS sound captures the glory of digital

surround sound. Featuring low data compression and

a high data transfer rate, DTS technology ensures

excellent localization throughout a vast frequency

and dynamic range.

DVD Audio/Video

In addition to playing video DVDs, the DVD-Audio format

provides audio fidelity far superior to that of normal CDs.

In addition to audio in stereo and multi-channel surround

sound, DVD Audio discs can hold artist bios, background

information, lyrics and liner notes.

DVD Video

DVD technology ensures second-to-none picture quality.

Ultra-sharp digital picture and surround sound bring

impressive cinema into your car. According to its software

format, a DVD is packed with useful benefits such as

multiple languages, soundtracks, subtitles and support

for various multi-channel audio encoding technologies

including DTSTM and Dolby® Digital.

PAL/PAL-M/NTSC/SECAM

PAL, PAL-M, NTSC and SECAM are TV reception standards.

Touch Panel Operation

Details on pages 7 and 12.

DivX® Digital Media

Among the world’s most popular video technologies, the

DivX digital format, based on MPEG-4 data compression

standards, is doing for video what MP3 did for audio—

it lets anyone create, share and play video in the form

of downloadable files that can be quickly, conveniently

exchanged among PCs and on the Internet without

compromising the quality and integrity of original

source material.

AUX-In Connection

Details on pages 10, 15 and 27.

BBE® digital

BBE® adds a longer delay time to the lower frequencies

and slightly “boosts” the high range which tends to

become attenuated, so that it recovers its natural

articulation. The result: greater live presence with the

brilliance and clarity of the original sound.

WMA (Windows Media™ Audio)

WMA is a music compression format developed

by Microsoft Corporation. It uses the latest coding

technologies to compress an original audio track,

minimizing file sizes while maintaining good audio

quality, even at rates as low as 64 kbps.

Bass Boost

Bass boost offers a choice among bass levels, spanning

the range from 0 dB to 12 dB in 2 dB increments, for each

speaker (including subwoofer) of a system. This provides

more control over the overall balance of sound, to suit

listener taste and style of music.

Class-FD ICEpower Amplifiers

Details on page 38.

High Pass Filter

Low-range sound is filtered off according to user-set

cut-off frequency. Mid- and high-range sounds are

transferred to the speaker.

Low Pass Filter

Mid- and high-range sounds are filtered off according to

user-set cut-off frequency. Low-range sound is transferred

to the woofer.

RCA Input

RCA input can be connected with headunit featuring RCA

output for preamp signal.

RCA Input/Output

RCA input can be connected with a headunit featuring

RCA output for preamp signal. RCA output can be

connected with additional amplifiers for a multi-amp

system configuration.

Speaker Level Inputs

This allows a Pioneer amplifier to be connected to an OEM

radio without requiring costly add-on adapters. The added

flexibility allows your Pioneer amplifier to be a part of your

system as it grows.

Air Suspension System

Details on pages 45 and 49.

KEVLAR® Brand Fiber

Characterized by lightness, strength, and low resonance

to powerful input, KEVLAR® Brand Fiber is excellent for

speaker diaphragms, helping to produce more detailed,

accurate sound.

VCCS (Voice Coil Cooling System)

Typically, the longer and louder you play your subwoofer,

the hotter it gets. This changes its electrical and mechanical

characteristics and adversely affects sound quality. Pioneer’s

Voice Coil Cooling System (VCCS) draws heat away from

the inside of the subwoofer, reducing temperatures by up

to 30˚C. In the simplest terms, it keeps your sound crisp

and your subwoofer from losing its cool.

IMPP (Injection-Molded Polypropylene)

Composite Cone

Pioneer uses a special injection molding process rather

than “pressing” polypropylene speaker cones. This process

ensures uniform cone thickness for superior linearity and

clarity. What’s more, Pioneer’s “Composite” technology

guarantees the perfect mix of polypropylene and carbon

fiber, graphite and other materials to optimize the speaker

cone for its specific application (woofers, midranges,

tweeters, etc.).

Amplifier Section

Subwoofer & Speaker Section

TVC (Total Vibration Control) Technology

Details on page 37.

Open & Smooth

Details on pages 39 and 50.

ib-FLAT

Details on page 48.

Direct Connection for iPod

Details on pages 7, 15 and 26.

Direct Connection for iPhone

Details on pages 7, 15 and 26.

Pioneer Avh P5150Dvd Users Manual

avhp5150dvd b8d4d374-db37-4aeb-a5fb-4491b6f8c412 Pioneer Car Video System AVH-P5150DVD User Guide |

Navigation menu

Versions of this User Manual:

Views

Navigation
