Operation Manual

Multi-CD control DSP High power DVD-A/DVD-V/

VCD/CD/MP3/WMA/AAC/DivX/JPEG player with FM/

AM tuner

AVH-P7800DVD

English

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to operate

your model properly. After you have finished reading the instructions, keep this man-

ual in a safe place for future reference.

Be sure to read this

!Playable discs 9

!DVD video disc region numbers 10

!When an operation is prohibited 15

Precautions

IMPORTANT SAFEGUARDS 7

To ensure safe driving 7

To avoid battery exhaustion 8

Before You Start

Information to User 9

For Canadian model 9

About this unit 9

About this manual 10

After-sales service for Pioneer products 11

Product registration 11

Features 11

About WMA 13

About AAC 13

About DivX 13

About the SAT RADIO READY mark 14

To protect the LCD screen 14

For viewing LCD comfortably 14

What the marks on DVDs indicate 15

Resetting the microprocessor 15

Feature demo mode 16

Use and care of the remote control 16

What’s What

Head unit 17

Sub-display 18

Remote control 19

Basic Operations

Turning the unit on and selecting a

source 23

Adjusting the volume 24

Turning the unit off 24

Using the rear display 24

Touch panel key basic operation 25

Opening and closing the LCD panel 26

Protecting your unit from theft 27

Built-in DVD player basic operations 28

Tuner

Listening to the radio 30

Storing and recalling broadcast

frequencies 30

Introduction of advanced tuner

operation 31

Tuning in strong signals 31

Storing the strongest broadcast

frequencies 31

Playing DVD discs

Watching a DVD video 32

Listening to a DVD audio 33

Operating the DVD menu 34

Browsing still pictures 35

Skipping back or forward to another title/

group 35

Resume playback (Bookmark) 35

Frame-by-frame playback 35

Slow motion playback 36

Searching for the part you want to play 36

Changing audio language during playback

(Multi-audio) 36

Changing the subtitle language during

playback (Multi-subtitle) 37

Changing the viewing angle during playback

(Multi-angle) 37

Automatic playback of DVDs 37

Introduction of advanced DVD operation 38

Repeating play 38

Playing tracks in random order 38

Contents

Scanning tracks 38

Selecting audio output 39

Playing Video CDs

Watching a Video CD 40

PBC playback 40

Frame-by-frame playback 41

Slow motion playback 41

Searching for a desired scene, starting

playback from a specified time 41

Introduction of advanced Video CD

operation 42

Repeating play 42

Selecting audio output 42

Playing CDs

Listening to a CD 43

Selecting tracks from the track title list 43

Displaying text information on CD TEXT

discs 43

Introduction of advanced CD operation 44

Repeating play 44

Playing tracks in random order 44

Scanning tracks of a CD 44

Playing MP3/WMA/AAC files

Listening to MP3/WMA/AAC 45

Selecting tracks from the file name list 46

Displaying information on MP3/WMA/AAC

file 46

Introduction of advanced built-in DVD player

(MP3/WMA/AAC) operation 47

Repeating play 47

Playing tracks in random order 47

Scanning folders and tracks 47

Playing DivX/JPEG files

Watching a DivX/JPEG 48

Viewing a JPEG slideshow 49

Playing DivX® VOD content 49

Selecting files from the file name list 50

Displaying text information on DivX/JPEG

disc 50

Frame-by-frame playback 50

Slow motion playback 50

Searching for the part you want to play 50

Changing audio language during playback

(Multi-audio) 51

Changing the subtitle language during

playback (Multi-subtitle) 51

Introduction of advanced built-in DVD player

(DivX/JPEG) operation 52

Repeating play 52

Playing files in random order 52

Multi-CD Player

Listening to a CD 53

Pausing CD playback 53

Selecting tracks from the track title list 54

Displaying text information on CD TEXT

discs 54

Introduction of advanced multi-CD player

operation 55

Repeating play 55

Playing tracks in random order 55

Scanning CDs and tracks 55

Using compression and bass emphasis 56

Using ITS playlists 56

Playing songs on iPod

Listening to songs on your iPod 58

Browsing for a song 58

Pausing a song 59

Displaying text information on iPod 59

Displaying information on song 59

Repeating play 59

Playing songs in a random order

(shuffle) 59

En 3

Contents

XM tuner (GEX-P920XM)

Listening to XM Satellite Radio 60

Switching the XM channel select mode 61

Switching between the detail information

display and preset list display 61

Storing and recalling broadcast stations 61

Selecting a channel 61

Using the MyMix function 62

Displaying the Radio ID 63

XM tuner (GEX-P910XM)

Listening to XM Satellite Radio 64

Switching the XM display 64

Storing and recalling broadcast stations 65

Switching the XM channel select mode 65

Selecting a channel directly 65

Displaying the Radio ID 65

SIRIUS Satellite Radio tuner

Listening to SIRIUS Satellite Radio 66

Selecting the SIRIUS channel select

mode 67

Selecting a channel 67

Switching the display 67

Switching between the detail information

display and preset list display 67

Storing and recalling broadcast stations 68

Using the MyMix function 68

Using the Game Alert function 70

Displaying the Radio ID 71

Bluetooth Audio

Listening to songs on BT Audio (Bluetooth

audio player) 72

Function operation 73

Connecting a Bluetooth audio player 73

Disconnecting a Bluetooth audio player 74

Displaying BD (Bluetooth Device)

address 74

Bluetooth Telephone

Hands-free phoning with cellular phones

featuring Bluetooth wireless

technology 75

Setting up for hands-free phoning 76

Basic operation of hands-free phoning 76

Introduction of advanced hands-free phoning

operation 77

Connecting a cellular phone 77

Disconnecting a cellular phone 78

Registering connected cellular phone 78

Deleting a registered phone 78

Connecting to a registered cellular

phone 79

Using the Phone Book 79

Using the Call History 81

Using preset numbers 82

Making a call by entering phone number 82

Clearing memory 82

Setting the automatic answering 83

Setting the automatic rejecting 83

Switching the ring tone 83

Echo canceling and noise reduction 83

Displaying BD (Bluetooth Device)

address 83

TV tuner

Watching the television 84

Storing and recalling broadcast stations 84

Confirming current channel and other

settings 85

Storing the strongest broadcast stations

sequentially 85

DVD Player

Playing a disc 86

Turning the DVD player on or off 87

Selecting a disc 87

Contents

Introduction of advanced DVD player

operation 88

Repeating play 88

Playing tracks in random order 88

Scanning tracks of a CD/MP3/WMA 88

Selecting audio output 89

Audio Adjustments

Introduction to built-in DSP features 90

Introduction of audio adjustments 92

Using balance adjustment 92

Adjusting source levels 93

Using the direct control 93

Listening in surround sound 94

Using the dynamic range control 95

Using the down-mix function 95

Switching the sound settings 96

Switching between the multi-channel output

and 2-channel output 96

Introduction of sound settings 97

Using the position selector 97

Recalling equalizer curves 98

Adjusting 3-band parametric equalizer 98

Adjusting 13-band graphic equalizer 100

Setting the speaker setting 101

Using the cut-off frequency 101

Using the time alignment 103

Adjusting the speaker output levels 104

Using the auto-equalizer 105

Storing the adjusted audio settings in

memory 106

Editing the name of sound settings 106

Auto TA and EQ (auto-time alignment and

auto-equalizing) 106

Setup

Introduction of setup adjustments 109

Setting the AV input 109

Setting for rear view camera (back up

camera) 109

Setting the automatic open function 110

Adjusting the LCD panel slide position 110

Setting the clock 110

Setting the video of rear display 111

Switching the dimmer setting for sub-

display 111

Adjusting the contrast for the sub-

display 111

Changing languages for CAUTION 111

Setting up the DVD player

Introduction of DVD setup adjustments 112

Setting the subtitle language 112

Setting the audio language 112

Setting the menu language 113

Switching the assist subtitle on or off 113

Setting the angle icon display 113

Setting the aspect ratio 113

Setting the parental lock 114

Setting the still picture 114

To play back bonus groups 115

Displaying your DivX® VOD registration

code 115

Setting remote control code type 115

Initial Settings

Adjusting initial settings 116

Switching the warning tone 116

Switching the auxiliary setting 116

Correcting distorted sound 116

Switching the sound muting/

attenuation 117

Switching the automatic disc playback 117

Resetting the audio functions 117

Switching the DSP setting mode 117

Setting the optical input 118

En 5

Contents

Entering PIN code for Bluetooth wireless

connection 118

Setting the security indicator 118

Other Functions

Switching the display on the sub-

display 119

Adjusting the screen 119

Selecting the background display 121

Adjusting the response positions of the

touch panels (Touch Panel

Calibration) 121

Using the AUX source 122

Using the PGM button 122

Additional Information

Troubleshooting 124

Error messages 126

Understanding auto TA and EQ error

messages 127

DVD player and care 128

DVD discs 128

CD-R/CD-RW discs 128

Dual Discs 129

MP3, WMA and AAC files 129

About folders and MP3/WMA/AAC files 131

JPEG picture files 131

DivX video files 132

Using the display correctly 132

Language code chart for DVD 134

DSP adjustment value record sheet 135

Terms 137

Specifications 141

Index 143

Contents

IMPORTANT SAFEGUARDS

Please read all of these instructions regarding

your display and retain them for future refer-

ence.

1Read this manual fully and carefully be-

fore operating your display.

2Keep this manual handy as a reference for

operating procedures and safety informa-

tion.

3Pay close attention to all warnings in this

manual and follow the instructions care-

fully.

4Do not allow other persons to use this sys-

tem until they have read and understood

the operating instructions.

5Do not install the display where it may (i)

obstruct the driver’s vision, (ii) impair the

performance of any of the vehicle’s oper-

ating systems or safety features, includ-

ing air bags, hazard lamp buttons or (iii)

impair the driver’s ability to safely oper-

ate the vehicle.

6Do not operate this display if doing so in

any way will divert your attention from

the safe operation of your vehicle. Always

observe safe driving rules and follow all

existing traffic regulations. If you experi-

ence difficulty in operating the system or

reading the display, park your vehicle in a

safe location and make necessary adjust-

ments.

7Please remember to wear your seat belt at

all times while operating your vehicle. If

you are ever in an accident, your injuries

can be considerably more severe if your

seat belt is not properly buckled.

8Never use headphones while driving.

9To promote safety, certain functions are

disabled unless the parking brake is on,

and the vehicle is not in motion.

10 Never set the volume of your display so

high that you cannot hear outside traffic

and emergency vehicles.

WARNING

!Do not attempt to install or service your

display by yourself. Installation or servi-

cing of the display by persons without

training and experience in electronic

equipment and automotive accessories

may be dangerous and could expose you

to the risk of electric shock or other

hazards.

To ensure safe driving

WARNING

!LIGHT GREEN LEAD AT POWER CON-

NECTOR IS DESIGNED TO DETECT

PARKED STATUS AND MUST BE CON-

NECTED TO THE POWER SUPPLY SIDE

OF THE PARKING BRAKE SWITCH. IM-

PROPER CONNECTION OR USE OF

THIS LEAD MAY VIOLATE APPLICABLE

LAW AND MAY RESULT IN SERIOUS IN-

JURY OR DAMAGE.

!To avoid the risk of damage and injury and the

potential violation of applicable laws, this unit

is not for use with a video screen that is visible

to the driver.

!To avoid the risk of accident and the potential

violation of applicable laws, the front DVD or

TV (sold separately) feature should never be

used while the vehicle is being driven. Also,

rear displays should not be in a location

where it is a visible distraction to the driver.

!In some countries or states the viewing of

images on a display inside a vehicle even by

persons other than the driver may be illegal.

Where such regulations apply, they must be

obeyed and this unit’s DVD features should

not be used.

Precautions

En 7

Section

Precautions

When you attempt to watch a DVD, Video CD

or TV while driving, the warning Viewing of

front seat video source while driving is

strictly prohibited. will appear on the front

display.

To watch a DVD, Video CD or TV on the front

display, park your vehicle in a safe place and

apply the parking brake.

Parking brake interlock

Certain functions (DVD/TV viewing and certain

touch panel keys) offered by this unit could be

dangerous and/or unlawful if used while driv-

ing. To prevent such functions from being

used while the vehicle is in motion, there is an

interlock system that senses when the parking

brake is set. If you attempt to use the functions

described above while driving, they will be-

come disabled until you stop the vehicle in a

safe place, and (1) apply the parking brake, (2)

release the parking brake, and then (3) apply

the parking brake again. Please keep the

brake pedal pushed down before releasing the

parking brake.

When using a display

connected to REAR DISPLAY OUT

This unit’sREAR DISPLAY OUT is for connec-

tion of a display to enable passengers in the

rear seats to watch the DVD or TV.

WARNING

NEVER install the rear display in a location that

enables the driver to watch the DVD or TV while

driving.

To avoid battery exhaustion

Be sure to run the vehicle engine while using

this unit. Using this unit without running the

engine can result in battery drainage.

!When no power is supplied to this unit be-

cause of a replacement of the vehicle bat-

tery or for some similar reason, the

microcomputer of this unit is returned to

its initial condition except audio settings.

Although audio adjustment information is

stored in this unit for several hours, we re-

commend that you transcribe the data. You

can fill the data in the sheet on 135.

WARNING

Do not use with vehicles that do not feature an

ACC position.

Precautions

Section

Information to User

Alteration or modifications carried out without

appropriate authorization may invalidate the

user’s right to operate the equipment.

For Canadian model

This Class B digital apparatus complies with

Canadian ICES-003.

About this unit

The tuner frequencies on this unit are allo-

cated for use in North America. Use in other

areas may result in poor reception.

WARNING

Handling the cord on this product or cords asso-

ciated with accessories sold with the product

may expose you to chemicals listed on proposi-

tion 65 known to the State of California and other

governmental entities to cause cancer and birth

defects or other reproductive harm. Wash hands

after handling.

This product contains mercury. Disposal of this

material may be regulated due to environmental

considerations. For disposal or recycling informa-

tion, please contact your local authorities or the

Electronics Industries Alliance: www.eiae.org.

CAUTION:

USE OF CONTROL OR ADJUSTMENT OR

PERFORMANCE OF PROCEDURES

OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION

EXPOSURE.

CAUTION:

THE USE OF OPTICAL INSTRUMENTS

WITH THIS PRODUCT WILL INCREASE

EYE HAZARD.

CAUTION

!Do not allow this unit to come into contact

with liquids. Electrical shock could result.

Also, this unit damage, smoke, and overheat

could result from contact with liquids.

!Keep this manual handy as a reference for op-

erating procedures and precautions.

!Always keep the volume low enough so that

you can hear sounds from outside the vehicle.

!Protect this unit from moisture.

!If the battery is disconnected or discharged,

the preset memory will be erased and must be

reprogrammed.

Important (Serial number)

The serial number is located on the bottom of

this unit. For your own security and convenience,

be sure to record this number on the enclosed

warranty card.

Playable discs

DVD, Video CD and CD discs that display the

logos shown below can be played back on this

player.

Before You Start

En 9

Section

Before You Start

DVD audio

DVD video

Video CD

Notes

!is a trademark of DVD Format/Logo Li-

censing Corporation.

!This player can only play back discs bearing

the marks shown above.

DVD video disc region numbers

DVD video discs that have incompatible region

numbers cannot be played on this player. The

region number of the player can be found on

the bottom of this unit.

The illustration below shows the regions and

corresponding region numbers.

About this manual

This unit features a number of sophisticated

functions ensuring superior reception and op-

eration. All the functions have been designed

for the easiest possible use, but many are not

self-explanatory. This operation manual will

help you benefit fully from this unit’s potential

and to maximize your listening enjoyment.

We recommend that you familiarize yourself

with the functions and their operation by read-

ing through the manual before you begin

using this unit. It is especially important that

you read and observe WARNINGs and CAU-

TIONs in this manual.

Before You Start

Section

After-sales service for

Pioneer products

Please contact the dealer or distributor from

where you purchased this unit for after-sales

service (including warranty conditions) or any

other information. In case the necessary infor-

mation is not available, please contact the

companies listed below:

Please do not ship your unit to the companies

at the addresses listed below for repair without

advance contact.

U.S.A.

Pioneer Electronics (USA) Inc.

CUSTOMER SUPPORT DIVISION

P.O. Box 1760

Long Beach, CA 90801-1760

800-421-1404

CANADA

Pioneer Electronics of Canada, Inc.

CUSTOMER SATISFACTION DEPARTMENT

300 Allstate Parkway

Markham, Ontario L3R OP2

1-877-283-5901

For warranty information please see the Lim-

ited Warranty sheet included with this unit.

Product registration

Visit us at the following site:

1 Register your product. We will keep the details

of your purchase on file to help you refer to

this information in the event of an insurance

claim such as loss or theft.

2 Receive updates on the latest products and

technologies.

3 Download owner’s manuals, order product

catalogues, research new products, and

much more.

Features

Touch panel key operation

It is possible to operate this unit by using

touch panel key.

DVD audio playback

It is possible to play back DVD audio.

DVD video playback

It is possible to play back DVD video and DVD-

R/RW (video mode).

Video CDs featuring PBC compatibility

It is possible to play back Video CDs featuring

PBC (playback control).

CD playback

Music CD/CD-R/RW playback is possible.

MP3 file playback

You can play back MP3 files recorded on CD-

R/RW/ROM and DVD-R/RW/ROM (ISO9660

Level 1/Level 2 standard recordings).

!Supply of this product only conveys a li-

cense for private, non-commercial use and

does not convey a license nor imply any

right to use this product in any commercial

(i.e. revenue-generating) real time broad-

casting (terrestrial, satellite, cable and/or

any other media), broadcasting/streaming

via internet, intranets and/or other net-

works or in other electronic content distri-

bution systems, such as pay-audio or

audio-on-demand applications. An inde-

pendent license for such use is required.

For details, please visit

http://www.mp3licensing.com.

Before You Start

En 11

Section

Before You Start

WMA file playback

You can play back WMA files recorded on CD-

R/RW/ROM and DVD-R/RW/ROM (ISO9660

Level 1/Level 2 standard recordings).

AAC file playback

You can play back AAC files recorded on CD-

R/RW/ROM and DVD-R/RW/ROM (ISO9660

Level 1/Level 2 standard recordings).

DivX®video file playback

You can play back DivX video files recorded on

CD-R/RW/ROM and DVD-R/RW/ROM.

JPEG picture file playback

You can play back JPEG picture files recorded

on CD-R/RW/ROM.

NTSC compatibility

This unit is NTSC system compatible. When

connecting other components to this unit, be

sure components are compatible with the

same video system otherwise images will not

be correctly reproduced.

Dolby Digital EX/DTS-ES compatibility

You can enjoy the atmosphere and excitement

provided by DVD movie and music software

featuring 5.1 channel recordings.

!Manufactured under license from Dolby La-

boratories. “Dolby”,“Pro Logic”, and the

double-D symbol are trademarks of Dolby

Laboratories.

!“DTS”,“DTS-ES”,“Neo:6”, and “DTS 96/24”

are trademarks of Digital Theater Systems,

Inc.

Multi-aspect

Switching between wide screen, letterbox and

panscan display is possible.

Multi-audio

You can switch between multiple audio sys-

tems recorded on a DVD as desired.

Multi-subtitle

You can switch between multiple subtitle lan-

guages recorded on a DVD as desired.

Multi-angle

You can switch between multiple viewing an-

gles of a scene recorded on a DVD as desired.

Hands-free phoning

Using Bluetooth adapter (e.g. CD-BTB100),

this unit realizes effortless hands-free phoning

with Bluetooth wireless technology.

Bluetooth audio player compatibility

Using Bluetooth adapter (e.g. CD-BTB100),

you can control Bluetooth audio player featur-

ing Bluetooth wireless technology.

iPod®compatibility

When you use this unit with a Pioneer iPod

adapter (CD-IB100II) (sold separately), you can

control an iPod with Dock Connector.

!iPod is a trademark of Apple Computer,

Inc., registered in the U.S. and other coun-

tries.

Before You Start

Section

Note

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual prop-

erty rights owned by Macrovision Corporation

and other rights owners. Use of this copyright

protection technology must be authorized by

Macrovision Corporation, and is intended for

home and other limited viewing uses only unless

otherwise authorized by Macrovision Corporation.

Reverse engineering or disassembly is

prohibited.

About WMA

The Windows Media™logo printed on the box

indicates that this unit can play back WMA

data.

WMA is short for Windows Media Audio and

refers to an audio compression technology

that is developed by Microsoft Corporation.

WMA data can be encoded by using Windows

Media Player version 7 or later.

!Windows Media and the Windows logo are

trademarks or registered trademarks of Mi-

crosoft Corporation in the United States

and/or other countries.

Notes

!This unit may not operate correctly depending

on the application used to encode WMA files.

!Depending on the version of Windows Media

Player used to encode WMA files, album

names and other text information may not be

correctly displayed.

!There may be a slight delay when starting

playback of WMA files encoded with image

data.

About AAC

AAC is short for Advanced Audio Coding and

refers to an audio compression technology

standard used with MPEG 2 and MPEG 4.

Several applications can be used to encode

AAC files, but file formats and extensions dif-

fer depending on the application which is

used to encode.

This unit plays back AAC files encoded by

iTunes®version 4.6.

!iTunes is a trademark of Apple Computer,

Inc., registered in the U.S. and other

countries.

About DivX

DivX is a compressed digital video format cre-

ated by the DivX®video codec from DivX, Inc.

This unit can play DivX video files recorded on

CD-R/RW/ROM and DVD-R/RW/ROM discs.

Keeping the same terminology as DVD video,

individual DivX video files are called “Titles”.

When naming files/titles on a CD-R/RW or a

DVD-R/RW disc prior to burning, keep in mind

that by default they will be played in alphabeti-

cal order.

Official DivX®Certified product

Plays all versions of DivX®video (including

DivX®6) with standard playback of DivX®

media files

Before You Start

En 13

Section

Before You Start

!DivX, DivX Certified, and associated logos

are trademarks of DivX, Inc. and are used

under license.

About the SAT RADIO

READY mark

The SAT RADIO READY mark printed on the

front panel indicates that the Satellite Radio

Tuner for Pioneer (i.e., XM tuner and Sirius sa-

tellite tuner which are sold separately) can be

controlled by this unit. Please inquire to your

dealer or nearest authorized Pioneer service

station regarding the satellite radio tuner that

can be connected to this unit. For satellite

radio tuner operation, please refer to the satel-

lite radio tuner owner’s manual.

Notes

!The system will use direct satellite-to-receiver

broadcasting technology to provide listeners

in their cars and at home with crystal-clear

sound seamlessly from coast to coast. Satel-

lite radio will create and package over 100

channels of digital-quality music, news,

sports, talk and children’s programming.

!“SAT Radio”, the SAT Radio logo and all re-

lated marks are trademarks of Sirius Satellite

Radio inc., and XM Satellite Radio Inc.

To protect the LCD screen

!Do not allow direct sunlight to fall on the

display when this unit is not being used.

Extended exposure to direct sunlight can

result in LCD screen malfunction due to

the resulting high temperatures.

!When using a cellular phone, keep the an-

tenna of the cellular phone away from the

display to prevent disruption of the video by

the appearance of spots, colored stripes,

etc.

!Never touch the screen with anything be-

sides your finger when operating the touch

panel function. The screen can scratch

easily.

For viewing LCD comfortably

Due to its construction, the viewing angle of

the LCD screen is limited. You can adjust it by

changing either screen size or picture adjust-

ment.

Changing the wide screen size

By changing the screen size from 4:3 to 16:9,

you can adjust the screen so that the screen

can fit to the video image you are playing.

For details concerning operation, refer to

Changing the wide screen mode on page 119.

Changing the picture adjustment

You can make the best adjustment to the pic-

ture display by changing BRIGHTNESS,

CONTRAST,COLOR and HUE. You can also

dim or enlight the overall picture image using

DIMMER.

For details concerning operation, refer to

Changing the picture adjustment on page

119.

Before You Start

Section

What the marks on DVDs

indicate

The marks below may be found on DVD disc

labels and packages. They indicate the type of

images and audio recorded on the disc, and

the functions you can use.

Mark Meaning

2Indicates the number of audio sys-

tems.

2Indicates the number of subtitle lan-

guages.

3Indicates the number of viewing an-

gles.

16 : 9 LB Indicates the picture size (aspect ratio:

screen width-to-height ratio) type.

ALL

Indicates the number of the region

where playback is possible.

When an operation is prohibited

When you are watching a DVD and attempt to

perform an operation, it may not be performed

because of the programming on the disc.

When this happens, the icon appears on

the screen.

!The icon may not appear with certain

discs.

Resetting the microprocessor

Pressing RESET lets you reset the micropro-

cessor to its initial settings without changing

the bookmark information.

The microprocessor must be reset under the

following conditions:

!Prior to using this unit for the first time

after installation

!If the unit fails to operate properly

!When strange or incorrect messages ap-

pear on the display

Important

If you press RESET, all memorized settings are

erased. For this reason, we recommend that you

record the settings in the sheet on page 135 after

you have completed audio adjustments.

1 Turn the ignition switch OFF.

2 Press RESET with a pen tip or other

pointed instrument.

RESET button

Note

After completing connections or when you want

to erase all memorized settings or return the unit

to its initial (factory) settings, switch your engine

ON or set the ignition switch to ACC ON before

pressing RESET.

Before You Start

En 15

Section

Before You Start

Feature demo mode

The feature demo automatically starts when

you select the source OFF. The demo con-

tinues while the ignition switch is set to ACC

or ON. To cancel the feature demo, press and

hold SOUND SETTING. To restart the feature

demo, press and hold SOUND SETTING

again. Remember that if the feature demo

continues operating when the car engine is

turned off, it may drain battery power.

Important

The red lead (ACC) of this unit should be con-

nected to a terminal coupled with ignition switch

on/off operations. If this is not done, the vehicle

battery may be drained.

Use and care of the remote

control

Installing the battery

Slide the tray out on the back of the remote

control and insert the battery with the plus (+)

and minus (–) poles pointing in the proper di-

rection.

!When using for the first time, pull out the

film protruding from the tray.

WARNING

Keep the battery out of the reach of children.

Should the battery be swallowed, immediately

consult a doctor.

CAUTION

!Use only one CR2025 (3 V) lithium battery.

!Remove the battery if the remote control is not

used for a month or longer.

!Do not recharge, disassemble, heat or dispose

of the battery in fire.

!Do not handle the battery with metallic tools.

!Do not store the battery with metallic materi-

als.

!In the event of battery leakage, wipe the re-

mote control completely clean and install a

new battery.

!When disposing of used batteries, please

comply with governmental regulations or en-

vironmental public institutions’rules that

apply in your country/area.

Using the remote control

Point the remote control in the direction of the

front panel to operate.

!The remote control may not function prop-

erly in direct sunlight.

Important

!Do not store the remote control in high tem-

peratures or direct sunlight.

!Do not let the remote control fall onto the

floor, where it may become jammed under the

brake or accelerator pedal.

Before You Start

Section

Head unit

1DISPLAY button

Press to turn the information display on or

off when the video is displayed.

2MEMO button

Press and hold to store the information of

the song you are listening to. Press to

switch to a station broadcasting the memor-

ized song.

!You can use this button only when con-

necting an XM satellite digital tuner or

SIRIUS Satellite Radio tuner.

3FLIP DOWN button

Press to turn the LCD panel horizontal tem-

porarily from upright position.

4Ambient light sensor

Senses ambient light. This system automati-

cally adjusts the brightness of the display to

compensate for ambient light.

5OPEN/CLOSE button

Press to open or close the LCD panel.

6BAND/ESC button

Press to select among three FM bands and

to cancel the control mode of functions.

7ATT button

Press to quickly lower the volume level, by

about 90%. Press once more to return to the

original volume level.

8Joystick

Move to perform manual seek tuning, fast

forward, reverse and track search controls.

Also used for controlling functions.

9EJECT button

Press to eject a disc from this unit.

Press and hold to open or close the front

panel.

What’s What

En 17

Section

What’s What

aRESET button

Press to return to the factory settings (initial

settings).

bSOUND SETTING button

Press to select the sound setting.

cREAR ON button

Press to switch between the video sources

(such as DVD or AV) on rear display.

d2ch/MULTI-CH button

Press to switch between the multi-channel

output and 2-channel output.

Press and hold to switch between the dis-

plays on the sub-display.

eSOURCE button, VOLUME

This unit is turned on by selecting a source.

Press to cycle through all the available

sources.

Rotate it to increase or decrease the vo-

lume.

fV.ADJUST button

Press to display the picture adjustment

menu.

gENTERTAINMENT button

Press to display the entertainment menu.

hWIDE button

Press to select a desired mode for enlarging

a 4:3 picture to a 16:9 one.

Sub-display

1Source display

Shows the status of selected source.

2Stereo (5) indicator

Shows when the selected frequency is

being broadcast in stereo.

3Volume level indicator

Shows the value of current volume level.

4RDM indicator

Shows when random play is turned on.

5RPT indicator

Shows when repeat play is turned on.

6Sound setting indicator

Shows what the sound setting has been se-

lected.

7Output setting indicator

Shows what the output setting has been

selected.

What’s What

Section

Remote control

Button names AVH mode DVD mode with remote control

code AVH

Remote control

selection

switch

Switch to change the setting of the remote control. For details, refer to Setting remote con-

trol code type on page 115.

2 SOURCE button Press to cycle through all the available sources. Press and hold to turn the source off.

3ATTbutton Press to quickly lower the volume level, by about 90%. Press once more to return to the ori-

ginal volume level.

4VOLUME but-

tons Press to increase or decrease the volume.

AUDIO button Press to change the audio language during DVD playback.

SUBTITLE but-

ton Press to change the subtitle language during DVD playback.

ANGLE button Press to change the viewing angle during DVD playback.

What’s What

En 19

Section

What’s What

Button names AVH mode DVD mode with remote control

code AVH

62ch/MULTI-CH

button Press to switch between the multi-channel output and 2-channel output.

7 RETURN button Press to display the PBC (playback control) menu during PBC playback.

8Dolby/DTS but-

ton Press to switch between surround sound setting (Dolby Pro Logic II or DTS Neo:6).

9a/bbutton

(TILT/DISC)Press to adjust the LCD panel angle. Not used.

Remote control

operation mode

switch

Switch the operation mode between AVH,DVD and TV modes. Normally, set to AVH.For

details, refer to Using the remote control operation mode switch on the next page.

11 BOOKMARK

button

Press to operate the preprogrammed functions

for each source. (Refer to Using the PGM button

on page 122.)

Press to turn the bookmark function on

or off. For details, refer to Resume play-

back (Bookmark) on page 35.

12 DIRECT button Press to do direct XM/SIRIUS channel select. Not used.

13 REAR SOURCE

button Press to switch between the video sources (such as DVD or AV) on rear display.

14 DISPLAY but-

ton Press to turn the information display on or off when the video is displayed.

15 EJECT button

Press to eject a disc from this unit.

Press and hold to bookmark a disc at the point

you want to bookmark.

Not used.

16 0–10 buttons,

CLEAR button

Press 0–10 to input numbers. Buttons 1–6can

operate the preset tuning for the tuner or disc

changing for DVD player or multi-CD player.

Press CLEAR to clear the input numbers.

Press to select a menu item on the

Video CDs featuring PBC (playback

control).

17 BACK button Press to return to the previous display. Not used.

18 BAND/ESC but-

ton

Press to select among three FM bands and to

cancel the control mode of functions.

Press to switch between media file types. (Refer

to Switching the media file type on page 29.)

Press to switch between media file

types. (Refer to Switching the media file

type on page 29.)

What’s What

Section

Button names AVH mode DVD mode with remote control

code AVH

PLAY/PAUSE

(f) button Press to switch sequentially between playback and pause.

REVERSE (m)

button Press to perform fast reverse.

FORWARD

(n) button Press to perform fast forward.

(o) button Press to return to the previous track (chapter).

NEXT (p)

button Press to go to the next track (chapter).

STEP (r/q)

button

Press to move ahead one frame at a time during DVD/VideoCD playback. Press and hold

for one second to activate slow playback.

STOP (g) but-

ton Press to stop playback.

20 AUTO PLAY

button Press to turn the DVD auto-playback function on or off.

21 a/bbutton

(FOLDER)Press to select the next/previous folder.

22 Joystick Move to do fast forward, reverse and track search

controls. Click to recall AUDIO MENU.

Move to select a menu on the DVD

menu.

MENU button Press to display the DVD menu during DVD playback.

TOP MENU

button Press to return to the top menu during DVD playback.

Using the remote control

operation mode switch

There are three remote control operation

modes on the remote control.

AVH mode operation

When operating this unit by remote control,

the mode is normally switched to AVH.

!The joystick on the remote control can per-

form the same operations as the one on

the head unit. Furthermore, the joystick

can perform the same operations as the

touch panel keys a,b,cand d.

!1–6can perform the same operations as

the preset tuning keys P1—P6 and the disc

selection keys 01—06.

—If you want to select a disc located at 7

to 12 by using buttons 1–6, press and

hold the corresponding numbers, such

as 1for disc 7, until the disc number ap-

pears in the display.

DVD mode operation

If you switch the mode to DVD, the joystick

and 0–10 operations are changed for DVD

player.

What’s What

En 21

Section

What’s What

%When you want to operate the follow-

ing functions, switch the mode to DVD:

!When operating the DVD menu by using

the joystick. (Refer to Operating the DVD

menu on page 34.)

!When browsing still pictures by using the

joystick. (Refer to Browsing still pictures on

page 35.)

!When operating the PBC menu by using

0–10. (Refer to Watching a Video CD on

page 40.)

TV mode operation

TV operations available with a Pioneer TV tuner

(e.g. GEX-P5700TV) can be controled with AVH

mode. TV mode is not used with this unit.

!For details concerning operation, refer to

the TV tuner’s operation manuals.

%When you want to operate the follow-

ing functions only on the rear display,

switch the mode to TV:

!When performing manual or seek tuning by

moving the joystick left or right.

!When recalling preset stations by moving

the joystick up or down.

!When confirming current channel and

other settings by pressing DIRECT. (Refer to

Confirming current channel and other set-

tings on page 85.)

What’s What

Section

Turning the unit on and

selecting a source

1Source icon

Shows which source has been selected.

You can select a source you want to listen to. If

DVD DISC AUTO is turned on, load a disc in

the unit to switch to DVD (refer to Switching

the automatic disc playback on page 117).

%When using the touch panel keys,

touch the source icon and then touch the

desired source name.

The source names are displayed and select-

able ones are highlighted.

!DVD –Built-in DVD player

!S-DVD –DVD player/multi-DVD player

!M-CD –Multi-CD player

!FM –FM tuner

!AM –AM tuner

!XM –XM tuner

!SIRIUS –SIRIUS tuner

!TV –Television

!AV –AV input

!EXT1 –External unit 1

!EXT2 –External unit 2

!AUX1 –AUX 1

!AUX2 –AUX 2

!iPod –iPod

!Telephone –BT telephone

!BT AUDIO –Bluetooth audio player

!OFF –Turn the unit off

#When the source icon is not displayed, you

can display it by touching the screen.

#While operating the menu, you cannot select

a source by touching the source icon.

#To close source select menu, touch ESC.

%When using the button, press SOURCE

to select a source.

Press SOURCE repeatedly to switch between

the following sources:

XM (XM tuner)—SIRIUS (SIRIUS tuner)—FM

(FM tuner)—AM (AM tuner)—TV (television)

—AV (AV input)—DVD (built-in DVD player)—

S-DVD (DVD player/multi-DVD player)—M-CD

(multi-CD player)—iPod (iPod)—EXT1 (exter-

nal unit 1)—EXT2 (external unit 2)—AUX1

(AUX 1)—AUX2 (AUX 2)—Telephone (blue-

tooth telephone)—BT AUDIO (bluetooth audio

player)

Notes

!In the following cases, the sound source will

not change:

—When there is no unit corresponding to the

selected source connected to this unit.

—When there is no disc in the unit.

—When there is no disc in the DVD player.

—When there is no magazine in the multi-

CD player.

—When the AUX (auxiliary input) is set to off

(refer to page 116).

—When the AV (AV input) is not set to

VIDEO (refer to page 109).

!External unit refers to a Pioneer product (such

as one available in the future) that, although

incompatible as a source, enables control of

basic functions by this unit. Two external units

can be controlled by this unit. When two exter-

nal units are connected, the allocation of

them to external unit 1 or external unit 2 is

automatically set by this unit.

Basic Operations

En 23

Section

Basic Operations

!When this unit’s blue/white lead is connected

to the vehicle’s auto-antenna relay control

terminal, the vehicle’s antenna extends when

this unit’s source is turned on. To retract the

antenna, turn the source off.

Adjusting the volume

%Use VOLUME to adjust the sound level.

With the head unit, rotate VOLUME to in-

crease or decrease the volume.

With the remote control, press VOLUME to in-

crease or decrease the volume.

Turning the unit off

%When using the touch panel keys,

touch the source icon and then touch OFF.

#When the source icon is not displayed, you

can display it by touching the screen.

%When using the button, press SOURCE

and hold until the unit turns off.

Using the rear display

You can watch the video sources (such as

DVD or AV) on rear display independently of

front display.

!To watch a DVD/Video CD on the rear dis-

play only, switch the operation mode on the

remote control to DVD. And you can oper-

ate the DVD/Video CD playback on the rear

display independently by the remote con-

trol. (Refer to page 21.)

CAUTION

When you have turned the rear display output on

by pressing REAR ON, you cannot turn it off even

if you press SOURCE and hold. In this case, press

REAR ON and hold to turn the rear display output

off.

%Press REAR ON to select the video

source on the rear display.

Press REAR ON repeatedly to switch between

the following video sources:

F. SOURCE (same source as the front display)

—DVD (built-in DVD player)—AV (AV input)

Rear display output is turned on and the illu-

mination color of REAR ON changes to a dif-

ferent color from the other buttons.

#You can also perform this operation by press-

ing REAR SOURCE on the remote control.

#To turn the rear display output off, press

REAR ON and hold.

#When selecting F. SOURCE, when the selected

source is an audio source, nothing is displayed

on rear display.

#When you watch DVD (built-in DVD player) on

both the front and the rear display, audio is not

outputted from REAR DISPLAY OUT.

#When selecting FRONT in REAR MODE, you

can select F. SOURCE only. And audio is not out-

putted from REAR DISPLAY OUT. (Refer to Set-

ting the video of rear display on page 111.)

Note

In the following cases, the sound source will not

change:

!When there is no disc in the unit.

!When the AV (AV input) is not set to VIDEO

(refer to page 109).

Basic Operations

Section

Touch panel key basic

operation

Activating the touch panel keys

1TILT ( / ) keys

Touch to adjust the LCD panel angle.

2Touch panel keys

Touch to do various operations.

1 Touch the screen to activate the touch

panel keys corresponding to each source.

The touch panel keys appear on the display.

#To go to the next group of touch panel keys,

touch NEXT.

#To return to the previous group of touch panel

keys, touch PREV.

2 Touch ESC to hide the touch panel keys.

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically when

selecting video sources.

Operating the menu

1FUNCTION key

Touch to select functions for each source.

2AUDIO key

Touch to select various sound quality con-

trols.

3SETUP key

Touch to select various setup functions.

4DVD SETUP key

Touch to select various DVD setup func-

tions.

!DVD SETUP appears on the display only

when DVD is played back on this unit.

5ESC key

Touch to cancel the control mode of func-

tions.

6BACK key

Touch to return to the previous display.

1 Touch AV MENU to display

AUDIO MENU.

AUDIO MENU appears on the display.

#When AV MENU is not displayed, you can dis-

play it by touching the screen.

2 Touch the desired key to display the

function names you want to operate.

Basic Operations

En 25

Section

Basic Operations

3 Touch ESC to return to the display of

each source.

Operating the menu by using the

joystick

You can also perform most of the menu items

by using the joystick.

!Switch the remote control operation mode

to AVH to operate the menu by using the

joystick on the remote control. (Refer to

page 21.)

1 Click the joystick during display of each

source to display AUDIO MENU.

AUDIO MENU appears on the display.

2 Move the joystick left or right to dis-

play the function names you want to oper-

ate.

3 Move the joystick to select the desired

function.

4 Press BAND/ESC to return to the display

of each source.

#You can return to the previous display by

pressing BACK.

Opening and closing the

LCD panel

The LCD panel will be opened or closed auto-

matically with the turning of the ignition

switch on or off. You can turn off the automatic

close/open function. (Refer to page 110.)

!The automatic close/open function will op-

erate the display as follows.

—When the ignition switch is turned OFF

while the LCD panel is opened, the LCD

panel will close after six seconds.

—When the ignition switch is turned ON

again (or turned to ACC), the LCD panel

will be opened automatically.

—Removing or attaching the front panel

will automatically close or open the LCD

panel. (Refer to the next page.)

!When the ignition switch is turned OFF

after the LCD panel has been closed, turn-

ing the ignition switch ON again (or turning

it to ACC) will not open the LCD panel. In

this case, press OPEN/CLOSE to open the

LCD panel.

!When closing the LCD panel, check to

make sure that it has closed completely. If

the LCD panel has stopped halfway, leaving

it like this could result in damage.

CAUTION

Keep hands and fingers clear of the unit when

opening, closing, or adjusting the LCD panel. Be

especially cautious of children’s hands and fin-

gers.

%Press OPEN/CLOSE to open the LCD

panel.

#To close the LCD panel, press OPEN/CLOSE

again.

Adjusting the LCD panel angle

Important

!If you can hear the LCD panel knocking

against your vehicle’s console or dashboard,

touch TILT () to move the LCD panel a little

forward.

Basic Operations

Section

!When adjusting the LCD panel angle, be sure

to touch TILT (/ ). Forcibly adjusting the

LCD panel by hand may damage it.

%Touch TILT ( / ) to adjust the LCD

panel to an easily viewable angle.

The LCD panel angle continues changing as

long as you touch TILT (/ ) and hold.

#The adjusted LCD panel angle will be memor-

ized and automatically returned to the next time

the LCD panel is opened.

Turning the LCD panel horizontal

When the LCD panel is upright and it hinders

the operation of the air conditioner, the panel

can be turned horizontal temporarily.

%Press FLIP DOWN to turn the LCD panel

horizontal.

#To return to original position, press

FLIP DOWN again.

#The LCD panel returns to the original position

automatically with beeping sound 10 seconds

after operation.

Protecting your unit from

theft

The front panel can be detached from the

head unit and stored in the provided protective

case to prevent theft.

!If the front panel is not detached from the

head unit within four seconds of turning off

the ignition, a warning tone will sound.

!You can turn off the warning tone. See

Switching the warning tone on page 116.

!You can turn off the security indicator. See

Setting the security indicator on page 118.

Important

!Never use force or grip the display and the

buttons too tightly when removing or attach-

ing.

!Avoid subjecting the front panel to excessive

shocks.

!Keep the front panel out of direct sunlight and

high temperatures.

!If removed, replace the front panel on the unit

before starting up your vehicle.

Removing the front panel

1 Press and hold EJECT to open the front

panel.

2 Gently grip the right side of the front

panel and slowly pull it outward.

Take care not to grip it too tightly or to drop

the front panel and protect it from contact

with water or other fluids to prevent perma-

nent damage.

Basic Operations

En 27

Section

Basic Operations

3 Put the front panel into provided pro-

tective case for safe keeping.

Attaching the front panel

1 Make sure the inner cover is closed.

2 Align the top of the front panel to the

unit.

3 Press the bottom of the front panel

until it is clicked.

Note

In the following cases, remove the front panel

and then attach it again:

!When nothing appears in the sub-display.

!When beep sounds.

Built-in DVD player basic

operations

Playing a disc

1 Press EJECT to open the front panel.

Disc loading slot appears.

#When a disc is loaded in this unit, touch the

source icon and then touch DVD to select DVD.

2 Insert a disc into the disc loading slot.

Front panel is closed automatically, and play-

back will start.

Disc loading slot

#When DVD DISC AUTO is off, touch the

source icon and then touch DVD to select the

built-in DVD player (refer to page 23).

#If you are playing a DVD or Video CD, a menu

may appear. Refer to Operating the DVD menu on

page 34 and PBC playback on page 40.

#When the automatic playback function is on,

this unit will cancel the DVD menu and automati-

cally start playback from the first chapter of the

first title. Refer to Automatic playback of DVDs on

page 37.

#You can eject a disc by pressing EJECT.

Notes

!The DVD player plays one, standard, 12-cm or

8-cm (single) disc at a time. Do not use an

adapter when playing 8-cm discs.

!Do not insert anything other than a disc into

the disc loading slot. Discs which can be

played back are listed on Playable discs on

page 9.

Basic Operations

Section

!If bookmark function is on, DVD playback re-

sumes from the selected point. For more de-

tails, refer to Resume playback (Bookmark) on

page 35.

!If a disc contains a mixture of various media

file types such as DivX and MP3, you can

switch between media file types to play. Refer

to Switching the media file type on this page.

!If you cannot insert a disc completely or if

after you insert a disc the disc does not play,

check that the label side of the disc is up.

Press EJECT to eject the disc, and check the

disc for damage before inserting it again.

!There is sometimes a delay between starting

up disc playback and the sound being issued.

When being read, FORMAT READ is dis-

played.

!When the disc loading or ejecting function

does not operate properly, you can eject the

disc by pressing and holding EJECT while

opening the front panel.

!If an error message such as ERROR-02 is dis-

played, refer to Error messages on page 126.

Basic playback controls

The table below shows the basic controls for

playing discs. The following chapters cover

other playback features in more details.

Key What it does

fStarts playback, pauses a disc that’s playing

or restarts a paused disc.

gStops playback.

Skips to the start of the current track, chapter

or file, then to previous tracks/chapters/files.

!Performs fast reverse by touching and

holding o.

Skips to the next track, chapter or file.

!Performs fast forward by touching and

holding p.

Notes

!You can also perform fast forward or reverse

by pressing and holding mor non the re-

mote control.

!You may find with some DVD or video CD

discs that some playback controls do not work

in certain parts of the disc. This is not a mal-

function.

Switching the media file type

When playing a disc containing a mixture of

various media file types such as DivX and

MP3, you can switch between media file types

to play.

!This unit allows playback of the following

media file type recorded on CD-R/RW/ROM

discs.

—Audio data (CD-DA)

—Compressed audio (MP3/WMA/AAC)

files

—DivX video files

—JPEG picture files

!In case of DVD-R/RW/ROM, this unit does

not allow playback of audio data (CD-DA)

or JPEG picture files.

%Touch MEDIA to switch between media

file types.

Touch MEDIA repeatedly to switch between

the following media file types:

CD (audio data (CD-DA))—ROM-Audio (MP3/

WMA/AAC files)—DivX (DivX video files)—

JPEG (JPEG picture files)

Basic Operations

En 29

Section

Basic Operations

Listening to the radio

These are the basic steps necessary to operate

the radio. More advanced tuner operation is

explained starting on the next page.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3Band indicator

Shows to which band the radio is tuned

when FM is selected as the source.

4Preset number indicator

Shows which preset has been selected.

5Frequency indicator

Shows the frequency to which the tuner is

tuned.

6Preset list display

Shows the preset list.

1 Touch the source icon and then touch

FM or AM to select the tuner.

2 Touch BAND to select a band when FM

is selected as the source.

Touch BAND repeatedly until the desired band

is displayed, BAND 1,BAND 2 or BAND 3.

3 To perform manual tuning, briefly

touch cor d.

The frequencies move up or down step by

step.

#You can also perform manual tuning by mov-

ing the joystick left or right.

4 To perform seek tuning, keep touching

cor dfor about one second and release.

The tuner will scan the frequencies until a

broadcast strong enough for good reception is

found.

#You can cancel seek tuning by briefly touching

either cor d.

#If you keep touching cor dyou can skip

stations. Seek tuning starts as soon as you re-

lease the key.

#You can also perform seek tuning by holding

the joystick left or right.

Storing and recalling

broadcast frequencies

If you touch any of the preset tuning keys

P1—P6 you can easily store up to six broad-

cast frequencies for later recall with the touch

of a key.

%When you find a frequency that you

want to store in memory keep touching

one of preset tuning keys P1—P6 until the

beep sounds.

The selected radio station frequency has been

stored in memory.

The next time you touch the same preset tun-

ing key the radio station frequency is recalled

from memory.

#When P1—P6 are not displayed, you can dis-

play them by touching LIST.

Notes

!Up to 18 FM stations, six for each of the three

FM bands, and six AM stations can be stored

in memory.

!You can also use aand bto recall radio sta-

tion frequencies assigned to preset tuning

keys P1—P6 when P1—P6 are not dis-

played.

Tuner

Section

Introduction of advanced

tuner operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the frequency

display.

#To return to the previous display, touch

BACK.

Tuning in strong signals

Local seek tuning lets you tune in only those

radio stations with sufficiently strong signals

for good reception.

%Touch LOCAL on the function menu to

set the sensitivity.

Touch LOCAL repeatedly until the desired level

of sensitivity appears in the display.

There are four levels of sensitivity for FM and

two levels for AM:

FM: OFF—LEVEL1—LEVEL2—LEVEL3—

LEVEL4

AM: OFF—LEVEL1—LEVEL2

The LEVEL4 setting allows reception of only

the strongest stations, while lower settings let

you receive progressively weaker stations.

Storing the strongest

broadcast frequencies

BSM (best stations memory) lets you automa-

tically store the six strongest broadcast fre-

quencies under preset tuning keys P1—P6

and once stored there you can tune in to those

frequencies with the touch of a key.

%Touch BSM on the function menu to

turn BSM on.

BSM begins to flash. While BSM is flashing

the six strongest broadcast frequencies will be

stored under preset tuning keys P1—P6 in

order of their signal strength. When finished,

BSM stops flashing.

#To cancel the storage process, touch BSM

again.

Note

Storing broadcast frequencies with BSM may re-

place broadcast frequencies you have saved

using P1—P6.

Tuner

En 31

Section

Tuner

Watching a DVD video

These are the basic steps necessary to play a

DVD video with your DVD player. More ad-

vanced DVD video operation is explained start-

ing on page 38.

1Source icon

Shows which source has been selected.

2DVD-V indicator

Shows when a DVD video is playing.

3Title number indicator

Shows the title currently playing.

4Chapter number indicator

Shows the chapter currently playing.

5Play time indicator

Shows the elapsed playing time of the cur-

rent chapter.

6Viewing angle indicator

Shows which viewing angle has been se-

lected.

7Subtitle language indicator

Shows which subtitle language has been

selected.

8Digital format indicator

Shows when a signal encoded in the corre-

sponding format is detected.

9Audio language indicator

Shows which audio language has been se-

lected.

aProgram format indicators

These change according to which channels

are active in digital sources.

!L–Left front channel

!C–Center channel

!R–Right front channel

!Ls –Left surround channel

!S–Surround channel (monaural)

!Rs –Right surround channel

!LFE –Low frequency effects channel

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

#With some discs, a menu may be displayed.

(Refer to Operating the DVD menu on page 34.)

2 Touch the screen to display the touch

panel keys.

3 To skip back or forward to another

chapter, touch oor p.

Touching pskips to the start of the next

chapter. Touching oonce skips to the start

of the current chapter. Touching it again will

skip to the previous chapter.

#You can also skip back or forward to another

chapter by moving the joystick left or right.

Playing DVD discs

Section

4 To perform fast forward or reverse,

keep touching oor p.

If you keep touching oor pfor five sec-

onds, the icon mor nchanges into rever-

sal indication. When this happens, fast

reverse/fast forward continues even if you re-

lease oor p. To resume playback at a de-

sired point, touch f.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

#Fast forward/fast reverse may not be possible

at certain locations on some discs. If this hap-

pens, normal playback automatically resumes.

Notes

!You can display the repeat range selected cur-

rently by touching INFO.

!If you do not use the touch panel keys within

30 seconds, they will be hidden auto-

matically.

Listening to a DVD audio

These are the basic steps necessary to play a

DVD audio with your DVD player. More ad-

vanced DVD audio operation is explained

starting on page 38.

1Source icon

Shows which source has been selected.

2DVD-A indicator

Shows when a DVD audio is playing.

3Group number indicator

Shows the group currently playing.

4Track number indicator

Shows the track number currently playing.

5Play time indicator

Shows the elapsed playing time of the cur-

rent track.

6Sampling frequency and number of

quantization bits indicator

Shows the sampling frequency and number

of quantization bits of the current track.

7Audio system indicator

Shows which audio system has been se-

lected.

Playing DVD discs

En 33

Section

Playing DVD discs

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

#With some discs, a menu may be displayed.

(Refer to Operating the DVD menu on this page.)

2 Touch KEY to display the touch panel

keys.

#When KEY is not displayed, you can display

the touch panel keys by touching the screen.

3 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

4 To perform fast forward or reverse,

keep touching oor p.

If you keep touching oor pfor five sec-

onds, the icon mor nchanges into rever-

sal indication. When this happens, fast

reverse/fast forward continues even if you re-

lease oor p. To resume playback at a de-

sired point, touch f.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

#Fast forward/fast reverse may not be possible

at certain locations on some discs. If this hap-

pens, normal playback automatically resumes.

Notes

!You can display the repeat range selected cur-

rently by touching INFO.

!If you do not use the touch panel keys within

30 seconds, they will be hidden auto-

matically.

Operating the DVD menu

Some DVDs allow you to select from the disc

contents using a menu.

!You can display the menu by touching

MENU or TOP MENU while a disc is play-

ing. Touching either of these keys again

lets you start playback from the location se-

lected from the menu. For details, refer to

the instructions provided with the disc.

Using DVD menu direct touch

control

This function allows you to operate the DVD

menu by touching the menu item directly.

%Touch the desired menu item on the

DVD menu directly.

#Depending on the contents of DVD discs, this

function may not work properly. In this case,

using touch panel keys operate the DVD menu.

Using the touch panel keys

1 Touch to display touch panel keys to

operate the DVD menu.

#When the touch panel keys are not displayed,

you can display them by touching the screen.

2 Touch , , or to select the desired

menu item.

3 Touch ENTER.

Playback starts from the selected menu item.

#If you switch the remote control operation

mode to DVD, the joystick on the remote control

can also operate the DVD menu. (Refer to page

21.)

#You cannot operate the DVD menu from the

joystick on the head unit.

#The way to display the menu differs depending

on the disc.

Playing DVD discs

Section

Browsing still pictures

You can browse still pictures recorded on the

disc during DVD audio playback.

!You cannot operate Slideshow. (Refer to Sli-

deshow on page 140.)

1 Touch BROWSE to browse still pictures

during playback.

2 Touch PAGE –or PAGE + to switch still

pictures.

Touching PAGE + goes to the next still picture.

Touching PAGE –returns to the previous still

picture.

#To return to the initial still picture, touch

HOME.

#If you switch the remote control operation

mode to DVD, the joystick on the remote control

can also browse still pictures. (Refer to page 21.)

#You cannot browse still pictures from the joy-

stick on the head unit.

Skipping back or forward

to another title/group

%To skip back or forward to another

title/group, touch aor b.

Touching askips to the start of the next title/

group. Touching bskips to the start of the pre-

vious title/group.

Title/group numbers are displayed for eight

seconds.

#You can also skip back or forward to another

title/group by moving the joystick up or down.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Resume playback (Bookmark)

When playing DVD video discs, you can use this

function.

The Bookmark function lets you resume play-

back from a selected scene the next time the

disc is loaded.

%During playback, touch BOOKMARK at

the point you want to resume playback

next time.

The selected scene will be bookmarked so that

playback resumes from that point next time.

You can bookmark up to five discs. After that,

the oldest bookmark is replaced by the new

one.

#To clear the bookmark on a disc, keep touch-

ing BOOKMARK during playback.

#If you switch the remote control operation

mode to DVD, you can also bookmark a disc

using BOOKMARK on the remote control. (Refer

to page 21.)

#You can also bookmark a disc by pressing and

holding EJECT on the remote control at the point

you want to bookmark. Next time you load the

disc, playback will resume from the bookmarked

point. Note that you can only bookmark one disc

using this method. To clear the bookmark on a

disc, press EJECT.

Frame-by-frame playback

This lets you move ahead one frame at a time

during playback.

%Touch during playback.

Each time you touch , you move ahead one

frame.

#To return to normal playback, touch f.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#With some discs, images may be unclear dur-

ing frame-by-frame playback.

Playing DVD discs

En 35

Section

Playing DVD discs

Slow motion playback

This lets you slow down playback speed.

%Keep touching until is displayed

during playback.

The icon is displayed, forward slow motion

playback begins.

#You can adjust playback speed by pressing

qor ron the remote control during slow mo-

tion playback.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#To return to normal playback, touch f.

Notes

!There is no sound during slow motion play-

back.

!With some discs, images may be unclear dur-

ing slow motion playback.

!Reverse slow motion playback is not possi-

ble.

Searching for the part you

want to play

You can use the search function to find the

part you want to play.

For DVD video, you can select TITLE (title),

CHAPT (chapter), TIME (time) or 10KEY (nu-

meric keypad).

For DVD audio, you can select GROUP

(group), TRACK (track) or 10KEY (numeric

keypad).

!Chapter search, track search and time

search are not possible when disc playback

has been stopped.

1 Touch SEARCH/10key.

2 Touch the desired search option (e.g.,

CHAPT).

3 Touch 0—9 to input the desired num-

ber.

#To cancel the inputted numbers, touch C.

#You can also input the desired number by

using the joystick and 0-9.

#In the time search function, to select 1 hour

11 minutes, convert the time into 71 minutes 00

seconds and touch 7,1,0and 0in that order.

4 Touch ENTER.

This starts playback from the selected part.

Note

With discs featuring a menu, you can also touch

MENU or TOP MENU and then make selections

from the displayed menu.

Changing audio language

during playback (Multi-audio)

DVDs can provide audio playback with differ-

ent languages and different systems (Dolby Di-

gital, DTS etc.). With DVDs featuring multi-

audio recordings, you can switch between lan-

guages/audio systems during playback.

%Touch AUDIO during playback.

Each time you touch AUDIO it switches be-

tween audio systems.

Notes

!With some DVDs, switching between lan-

guages/audio systems may only be possible

using a menu display.

!You can also switch between languages/audio

systems using DVD SETUP MENU. For de-

tails, refer to Setting the audio language on

page 112.

Playing DVD discs

Section

!Display indications such as Dolby D and Mch

indicate the audio system recorded on the

DVD. Depending on the setting, playback may

not be with the same audio system as that in-

dicated.

!Touching AUDIO during fast forward/fast re-

verse, pause or slow motion playback returns

you to normal playback.

Changing the subtitle

language during playback

(Multi-subtitle)

With DVDs featuring multi-subtitle recordings,

you can switch between subtitle languages

during playback.

%Touch SUBTITLE during playback.

Each time you touch SUBTITLE it switches be-

tween subtitle languages.

Notes

!With some DVDs, switching between subtitle

languages may only be possible using a menu

display.

!You can also switch between subtitle lan-

guages using DVD SETUP MENU. For details,

refer to Setting the subtitle language on page

112.

!Touching SUBTITLE during fast forward/fast

reverse, pause or slow motion playback re-

turns you to normal playback.

Changing the viewing angle

during playback (Multi-angle)

With DVDs featuring multi-angle (scenes shot

from multiple angles) recordings, you can

switch among viewing angles during play-

back.

!During playback of a scene shot from mul-

tiple angles, the angle icon is dis-

played. Turn angle icon display on or off

using DVD SETUP MENU. For details, refer

to Setting the angle icon display on page

113.

%Touch ANGLE during playback of a

scene shot from multiple angles.

Each time you touch ANGLE it switches be-

tween angles.

Note

Touching ANGLE during fast forward/fast reverse,

pause or slow motion playback returns you to

normal playback.

Automatic playback of DVDs

When a DVD disc with DVD menu is inserted,

this unit will cancel the DVD menu automati-

cally and start playback from the first chapter

of the first title.

!Some DVDs may not operate properly. If

this function is not fully operated, turn this

function off and start playback.

%Touch AUTO PLAY to turn automatic

playback on.

#To turn automatic playback off, touch

AUTO PLAY again.

#You can also turn automatic playback on or off

by pressing AUTO PLAY button on the remote

control.

#When the automatic playback is on, you can-

not operate repeating play of DVD disc (refer to

Repeating play on the next page).

Playing DVD discs

En 37

Section

Playing DVD discs

Introduction of advanced

DVD operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

There are three repeat play ranges for DVD

playback.

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

During DVD video playback

!DISC –Play through the current disc

!TITLE –Repeat just the current title

!CHAPTER –Repeat just the current chapter

During DVD audio playback

!DISC –Play through the current disc

!GROUP –Repeat just the current group

!TRACK –Repeat just the current track

Note

If you perform chapter/track search or fast for-

ward/reverse, the repeat play range changes to

DISC.

Playing tracks in random order

Random play lets you play back tracks in a

random order within the current group during

DVD audio playback.

%Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order within the

current group.

#To turn random play off, touch RANDOM

again.

Scanning tracks

Scan play lets you hear the first 10 seconds of

each track in the current group during DVD

audio playback.

1 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track of the cur-

rent group is played.

2 When you find the desired track touch

SCAN again.

#After scanning is finished, normal playback of

the tracks will begin again.

Playing DVD discs

Section

Selecting audio output

When playing DVD video discs recorded with

LPCM audio, you can switch the audio output.

!This function is not possible when disc

playback has been stopped.

%Touch L/R SELECT on the function menu

to select the audio output.

Touch L/R SELECT repeatedly until the desired

audio output appears in the display.

!L+R –left and right

!LEFT –left

!RIGHT –right

!MIX –mixing left and right

Note

Depending on the disc and the playback location

on the disc, the function may not be selectable,

indicating that operating this function is not pos-

sible.

Playing DVD discs

En 39

Section

Playing DVD discs

Watching a Video CD

These are the basic steps necessary to play a

Video CD with your DVD player. More ad-

vanced Video CD operation is explained start-

ing on page 42.

1Source icon

Shows which source has been selected.

2VideoCD indicator

Shows when a Video CD is playing.

3Track number indicator

Shows the track number currently playing.

4Play time indicator

Shows the elapsed playing time of the cur-

rent track.

5Audio output indicator

Shows the output channel selected cur-

rently.

6Repeat indicator

Shows the selected repeat range.

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

#With a Video CD featuring the PBC (playback

control) function, a menu is displayed. (Refer to

PBC playback on this page.)

2 Touch the screen to display the touch

panel keys.

3 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

#During PBC playback, a menu may be dis-

played if you perform these operations.

4 To perform fast forward or reverse,

keep touching oor p.

If you keep touching oor pfor five sec-

onds, the icon mor nchanges into rever-

sal indication. When this happens, fast

reverse/fast forward continues even if you re-

lease oor p. To resume playback at a de-

sired point, touch f.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

#Fast forward/fast reverse may not be possible

at certain locations on some discs. If this hap-

pens, normal playback automatically resumes.

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically.

PBC playback

During playback of Video CDs featuring PBC

(Playback Control), PBC:ON is displayed. You

can operate PBC menu with 10KEY.

1 When PBC menu is displayed, touch

SEARCH/10key and then touch 10KEY.

#Depending on the discs, the menu may be

two or more pages long. In such case, touch o

or pto display the next or previous menu.

Playing Video CDs

Section

2 Touch 0—9 corresponding to a menu

number and then touch ENTER to start

playback.

Playback starts from the selected menu item.

3 Touch ESC to hide the touch panel keys.

Notes

!You can display the menu by touching dur-

ing PBC playback. For details, refer to the in-

structions provided with the disc.

!PBC playback of Video-CD cannot be can-

celled.

!During playback of Video CDs featuring PBC

(Playback Control), PBC:ON, search and time

search functions cannot be used nor can you

select the range for repeat play.

Frame-by-frame playback

This lets you move ahead one frame at a time

during playback.

%Touch during playback.

Each time you touch , you move ahead one

frame.

#To return to normal playback, touch f.

#With some discs, images may be unclear dur-

ing frame-by-frame playback.

Slow motion playback

This lets you slow down playback speed.

%Keep touching until is displayed

during playback.

The icon is displayed, forward slow motion

playback begins.

#You can adjust playback speed by pressing

qor ron the remote control during slow mo-

tion playback.

#To return to normal playback, touch f.

Notes

!There is no sound during slow motion play-

back.

!With some discs, images may be unclear dur-

ing slow motion playback.

!Reverse slow motion playback is not possi-

ble.

Searching for a desired

scene, starting playback

from a specified time

You can use the search function to search for

a desired scene by specifying a track, and the

time search function to specify the time on a

disc at which play starts.

!During playback of Video CDs featuring

PBC (playback control), this function can-

not be operated.

!Time search is not possible when disc play-

back has been stopped.

1 Touch SEARCH/10key.

2 Touch TRACK (track), TIME (time) or

10KEY (numeric keypad).

3 Touch 0—9 to input the desired num-

ber.

#To cancel the inputted numbers, touch C.

#You can also input the desired number by

using the joystick and 0-9.

#In the time search function, to select 1 hour

11 minutes, convert the time into 71 minutes 00

seconds and touch 7,1,0and 0in that order.

4 Touch ENTER.

This starts playback from the selected

scene.

Playing Video CDs

En 41

Section

Playing Video CDs

Introduction of advanced

Video CD operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

There are two repeat play ranges for the Video

CD playback: TRACK (track repeat) and DISC

(disc repeat).

!During playback of Video CDs featuring

PBC (playback control), this function can-

not be operated.

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!DISC –Repeat the current disc

!TRACK –Repeat just the current track

Note

If you perform track search or fast forward/re-

verse, the repeat play range changes to DISC.

Selecting audio output

You can switch between stereo and monaural

audio output.

!This function is not possible when disc

playback has been stopped.

%Touch L/R SELECT on the function menu

to select the audio output.

Touch L/R SELECT repeatedly until the desired

audio output appears in the display.

!L+R –left and right

!LEFT –left

!RIGHT –right

!MIX –mixing left and right

Playing Video CDs

Section

Listening to a CD

These are the basic steps necessary to play a

CD with your DVD player. More advanced CD

operation is explained starting on the next

page.

1Source icon

Shows which source has been selected.

2CD indicator

Shows when a CD is playing.

3Disc title indicator

Shows the title of the currently playing disc

only when playing CD TEXT discs.

4Track number indicator

Shows the track number currently playing.

5Play time indicator

Shows the elapsed playing time of the cur-

rent track.

6Track list display

Shows the track title list.

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

2 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

3 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

Selecting tracks from the

track title list

Track title list lets you see the list of tracks on

a disc and select one of them to play back.

When playing a CD TEXT disc, track titles are

displayed.

1 Touch PREV or NEXT to switch between

the lists of titles.

#When the list of tracks is not displayed, touch

LIST.

2 Touch your favorite track title.

That selection will begin to play.

Displaying text information

on CD TEXT discs

Some discs have certain information encoded

on the disc during manufacture. These discs

may contain such information as the CD title,

track title, artist’s name and playback time

and are called CD TEXT discs. Text information

recorded on a CD TEXT disc can be displayed.

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

Disc Title (disc title)—DiscArtist (disc artist

name)—Track Title (track title)—TrackArtist

(track artist name)

#If specific information has not been recorded

on a CD TEXT disc, No XXXX will be displayed

(e.g., No Name).

Playing CDs

En 43

Section

Playing CDs

Introduction of advanced

CD operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

There are two repeat play ranges for the CD

playback: TRACK (track repeat) and DISC (disc

repeat).

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!DISC –Repeat the current disc

!TRACK –Repeat just the current track

Note

If you perform track search or fast forward/re-

verse, the repeat play range changes to DISC.

Playing tracks in random order

Random play lets you play back tracks on the

CD in a random order.

%Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order.

#To turn random play off, touch RANDOM

again.

Scanning tracks of a CD

Scan play lets you hear the first 10 seconds of

each track on the CD.

1 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track is played.

2 When you find the desired track touch

SCAN again.

#After scanning of a CD is finished, normal

playback of the tracks will begin again.

Playing CDs

Section

Listening to MP3/WMA/AAC

These are the basic steps necessary to play an

MP3/WMA/AAC with your DVD player. More

advanced MP3/WMA/AAC operation is ex-

plained starting on page 47.

1Source icon

Shows which source has been selected.

2ROM-Audio indicator

Shows when a compressed audio (MP3/

WMA/AAC) file is playing.

3MP3/WMA/AAC indicator

Shows the type of file currently playing.

4Folder number indicator

Shows the folder number currently playing.

5File number indicator

Shows the file number currently playing.

6Play time indicator

Shows the elapsed playing time of the cur-

rent file.

7Folder name indicator

Shows the name of the currently playing

folder.

8Folder and file name list

Shows the list of folder and file name.

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

2 Touch aor bto select a folder.

#You can also select a folder by moving the joy-

stick up or down.

#To return to folder 01 (ROOT), press and hold

BAND/ESC. However, if folder 01 (ROOT) con-

tains no files, playback commences with folder

02.

#You cannot select a folder that does not have

an MP3/WMA/AAC file recorded in it.

3 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

Notes

!This DVD player can play back an MP3/WMA/

AAC file recorded on CD-R/RW/ROM and

DVD-R/RW/ROM. (Refer to page 129 for files

that can be played back.)

!Playback is carried out in order of file number.

Folders are skipped if they contain no files. (If

folder 01 (ROOT) contains no files, playback

commences with folder 02.)

!When playing back files recorded as VBR

(variable bit rate) files, the play time will not be

correctly displayed if fast forward or reverse

operations are used.

!There is no sound on fast forward or re-

verse.

Playing MP3/WMA/AAC

files

En 45

Section

Playing MP3/WMA/AAC files

Selecting tracks from the

file name list

File name list lets you see the list of file names

(or folder names) and select one of them to

playback.

1 Touch PREV or NEXT to switch between

the lists of names.

#When the list of file names is not displayed,

touch LIST.

2 Touch your favorite file name (or folder

name).

That selection will begin to play.

#When you have selected a folder, a list of the

names of the files (or the folders) in it can be

viewed. Repeat steps 1 and 2 to select the desired

file name.

#To return to the previous list (the folder one

level higher), touch .

Displaying information on

MP3/WMA/AAC file

Information recorded on an MP3/WMA/AAC

disc can be displayed.

%Touch to display information on the

MP3/WMA/AAC file you are currently play-

ing.

!ALBUM (album title)

!TRACK (track title)

!FOLDER (folder name)

!FILE (file name)

!ARTIST (artist name)

!GENRE (genre)

!YEAR (year)

#When playing back WMA files, lists of album

title, genre and year appear in blank.

#When playing back AAC files, lists of genre

and year appear in blank.

#If specific information has not been recorded

on an MP3/WMA/AAC file, no xxxx will be dis-

played in the list (e.g., No Data).

#Depending on the version of ID3 tag or Win-

dows Media Player, the information may not be

displayed correctly.

Displaying text information on

MP3/WMA/AAC disc

Text information recorded on an MP3/WMA/

AAC disc can be displayed.

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

Folder Name (folder name)—File Name (file

name)—Album (album title)—Track (track

title)—Artist (artist name)

#If specific information has not been recorded

on an MP3/WMA/AAC disc, no xxxx will be dis-

played (e.g., no artist).

#Depending on the version of Windows Media

Player used to encode WMA files, album names

and other text information may not be correctly

displayed.

Playing MP3/WMA/AAC

files

Section

Introduction of advanced

built-in DVD player (MP3/

WMA/AAC) operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

For MP3/WMA/AAC playback, there are three

repeat play ranges: FOLDER (folder repeat),

FILE (one-track repeat) and DISC (repeat all

tracks).

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!DISC –Repeat all tracks

!FOLDER –Repeat the current folder

!FILE –Repeat just the current track

Notes

!If you select another folder during repeat play,

the repeat play range changes to DISC.

!If you perform track search or fast forward/re-

verse during FILE, the repeat play range

changes to FOLDER.

!When FOLDER is selected, it is not possible to

play back a subfolder of that folder.

Playing tracks in random order

Random play lets you play back tracks in a

random order within the repeat range,

FOLDER and DISC.

1 Select the repeat range.

Refer to Repeating play on this page.

2 Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order within the

previously selected FOLDER or DISC ranges.

#To turn random play off, touch RANDOM

again.

Scanning folders and tracks

While you are using FOLDER, the beginning of

each track in the selected folder plays for

about 10 seconds. When you are using DISC,

the beginning of the first track of each folder

is played for about 10 seconds.

1 Select the repeat range.

Refer to Repeating play on this page.

2 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track of the cur-

rent folder (or the first track of each folder) is

played.

3 When you find the desired track (or

folder) touch SCAN again.

#After track or folder scanning is finished, nor-

mal playback of the tracks will begin again.

Playing MP3/WMA/AAC

files

En 47

Section

Playing MP3/WMA/AAC files

Watching a DivX/JPEG

These are the basic steps necessary to play a

DivX/JPEG with your DVD player. More ad-

vanced DivX/JPEG operation is explained start-

ing on page 52.

1Source icon

Shows which source has been selected.

2DivX/JPEG indicator

Shows the type of file currently playing.

3Folder number indicator

Shows the folder number currently playing.

4File number indicator

Shows the file number currently playing.

5Play time indicator

Shows the elapsed playing time of the cur-

rent file.

!When playing a JPEG disc, play time in-

dicator does not appear.

6Folder name indicator

Shows the name of the currently playing

folder.

7Folder and file name list

Shows the list of folder and file name.

1 Touch the source icon and then touch

DVD to select the DVD player.

#If no disc is loaded in the unit, you cannot se-

lect DVD (DVD player). Insert a disc in the unit.

(Refer to page 28.)

2 Touch the screen to display the touch

panel keys.

3 Touch aor bto select a folder.

#You can also select a folder by moving the joy-

stick up or down.

#To return to folder 01 (ROOT), press and hold

BAND/ESC. However, if folder 01 (ROOT) con-

tains no files, playback commences with folder

02.

#You cannot select a folder that does not have

a DivX/JPEG file recorded in it.

4 To skip back or forward to another file,

touch oor p.

Touching pskips to the start of the next file.

Touching oonce skips to the start of the

current file. Touching it again will skip to the

previous file.

#You can also skip back or forward to another

file by moving the joystick left or right.

5 To perform fast forward or reverse,

keep touching oor p.

If you keep touching oor pfor five sec-

onds, the icon mor nchanges into rever-

sal indication. When this happens, fast

reverse/fast forward continues even if you re-

lease oor p. To resume playback at a de-

sired point, touch f.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

#This is fast forward and reverse operation only

for the file being played. This operation is can-

celed when the previous or next file is reached.

#When playing a JPEG disc, this operation can-

not be performed.

Playing DivX/JPEG files

Section

Notes

!This DVD player can play back a DivX file re-

corded on CD-R/RW/ROM and DVD-R/RW/

ROM. (Refer to page 132 for files that can be

played back.)

!This DVD player can play back a JPEG file re-

corded on CD-R/RW/ROM. (Refer to page 131

for files that can be played back.)

!Playback is carried out in order of file number.

Folders are skipped if they contain no files. (If

folder 01 (ROOT) contains no files, playback

commences with folder 02.)

!There is no sound on fast forward or reverse.

!If you do not use the touch panel keys within

30 seconds, they will be hidden auto-

matically.

Viewing a JPEG slideshow

When loading a CD/CD-R/RW containing

JPEG picture files, this unit automatically

starts a slideshow from the first folder/picture

on the disc. The player displays the pictures in

each folder in alphabetical order.

The table below shows the controls for viewing

a slideshow.

Key What it does

fStarts the slideshow, pauses the slideshow or

restarts a paused disc.

oDisplays the previous picture.

pDisplays the next picture.

Rotates the displayed picture 90° clockwise.

Playing DivX®VOD content

Some DivX VOD (video on demand) content

may only be playable a fixed number of times.

When you load a disc containing this type of

DivX VOD content, the remaining number of

plays is shown on-screen and you then have

the option of playing the disc (thereby using

up one of the remaining plays), or stopping. If

you load a disc that contains expired DivX

VOD content (for example, content that has

zero remaining plays), Rental expired is dis-

played.

!If your DivX VOD content allows an unlim-

ited number of plays, then you may load

the disc into your player and play the con-

tent as often as you like, and no message

will be displayed.

Important

!In order to play DivX VOD content on this unit,

you first need to register the unit with your

DivX VOD content provider. About your regis-

tration code, refer to Displaying your DivX®

VOD registration code on page 115.

!DivX VOD content is protected by a DRM (Di-

gital Rights Management) system. This re-

stricts playback of content to specific,

registered devices.

%If the message is displayed after load-

ing a disc containing DivX VOD content,

touch PLAY.

Playback of the DivX VOD content will start.

#To skip to the next file, touch NEXT PLAY.

#If you do not want to play the DivX VOD con-

tent, touch STOP.

Playing DivX/JPEG files

En 49

Section

Playing DivX/JPEG files

Selecting files from the file

name list

File name list lets you see the list of file names

(or folder names) and select one of them to

playback.

1 Touch PREV or NEXT to switch between

the lists of names.

#When the list of file names is not displayed,

touch LIST.

2 Touch your favorite file name (or folder

name).

That selection will begin to play.

#When you have selected a folder, a list of the

names of the files (or the folders) in it can be

viewed. Repeat steps 1 and 2 to select the desired

file name.

#To return to the previous list (the folder one

level higher), touch .

Displaying text information

on DivX/JPEG disc

Text information recorded on a DivX/JPEG disc

can be displayed.

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

Folder Name (folder name)—File Name (file

name)

Frame-by-frame playback

This lets you move ahead one frame at a time

during DivX playback.

%Press ron the remote control during

playback.

Each time you press r, you move ahead one

frame.

#To return to normal playback, touch f.

#With some discs, images may be unclear dur-

ing frame-by-frame playback.

Slow motion playback

When playing DivX video file, this lets you slow

down playback speed.

%Press ron the remote control until

is displayed during playback.

The icon is displayed, forward slow motion

playback begins.

#To return to normal playback, touch f.

Notes

!There is no sound during slow motion play-

back.

!With some discs, images may be unclear dur-

ing slow motion playback.

!Reverse slow motion playback is not possi-

ble.

Searching for the part you

want to play

When playing DivX video file, you can use the

time search function to find the part you want

to play.

!Time search is not possible when disc play-

back has been stopped.

1 Touch SEARCH.

Playing DivX/JPEG files

Section

2 Touch 0—9 to input the desired num-

ber.

#To cancel the inputted numbers, touch C.

#To select 1 hour 11 minutes, convert the time

into 71 minutes 00 seconds and touch 7,1,0and

0in that order.

#You can also input the desired number by

using the joystick and 0-9.

3 Touch ENTER.

This starts playback from the selected part.

Changing audio language

during playback (Multi-audio)

When playing a DivX video disc recorded with

dialog in two or more languages, you can

switch audio language during playback.

%Touch AUDIO during playback.

Each time you touch AUDIO it switches be-

tween audio systems.

Note

Touching AUDIO during fast forward/fast reverse,

pause or slow motion playback returns you to

normal playback.

Changing the subtitle

language during playback

(Multi-subtitle)

When playing a DivX video disc recorded with

subtitles in one or more languages, you can

switch subtitle language during playback.

%Touch SUBTITLE during playback.

Each time you touch SUBTITLE it switches be-

tween subtitle languages.

Note

Touching SUBTITLE during fast forward/fast re-

verse, pause or slow motion playback returns you

to normal playback.

Playing DivX/JPEG files

En 51

Section

Playing DivX/JPEG files

Introduction of advanced

built-in DVD player (DivX/

JPEG) operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

For DivX video file playback, there are three re-

peat play ranges: FOLDER (folder repeat), FILE

(file repeat) and DISC (repeat all files).

For JPEG picture file playback, there are two

repeat play ranges: FOLDER (folder repeat)

and DISC (repeat all files).

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!DISC –Repeat all files

!FOLDER –Repeat the current folder

!FILE –Repeat just the current file

Notes

!If you select another folder during repeat play,

the repeat play range changes to DISC.

!If you perform track search or fast forward/re-

verse during FILE, the repeat play range

changes to FOLDER.

!When FOLDER is selected, it is not possible to

play back a subfolder of that folder.

Playing files in random order

When playing a JPEG disc, random play lets

you play back files in a random order within

the repeat range, FOLDER and DISC.

1 Select the repeat range.

Refer to Repeating play on this page.

2 Touch RANDOM on the function menu

to turn random play on.

Files will play in a random order within the pre-

viously selected FOLDER or DISC ranges.

#To turn random play off, touch RANDOM

again.

Playing DivX/JPEG files

Section

Listening to a CD

You can use this unit to control a multi-CD

player, which is sold separately.

These are the basic steps necessary to play a

CD with your multi-CD player. More advanced

CD operation is explained starting on page 55.

!This unit does not have a disc title input

function.

!Only those functions described in this man-

ual are supported by 50-disc multi-CD

players.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3Disc number indicator

Shows the disc number currently playing.

4Track number indicator

Shows the track number currently playing.

5Play time indicator

Shows the elapsed playing time of the cur-

rent track.

6Disc title indicator

Shows the title of the currently playing disc

only when playing CD TEXT discs.

7Disc list display

Shows the disc list.

1 Touch the source icon and then touch

M-CD to select the multi-CD player.

2 Touch any of 01—06 to select a disc you

want to listen to.

If you want to select a disc located at 7 to 12,

touch PREV or NEXT to display 07—12.

#When 01—06 and 07—12 are not displayed,

you can display them by touching LIST.

#You can also sequentially select a disc by

using a/bwhen DISC LIST is not displayed.

3 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

Notes

!When the multi-CD player performs the pre-

paratory operations, READY is displayed.

!If an error message such as ERROR-02 is dis-

played, refer to the multi-CD player owner’s

manual.

!If there are no discs in the multi-CD player ma-

gazine, NO DISC is displayed.

Pausing CD playback

Pause lets you temporarily stop disc playback.

Multi-CD Player

En 53

Section

Multi-CD Player

%Touch fto turn pause on.

Playback of the current track pauses.

#To turn pause off, touch fagain.

Selecting tracks from the

track title list

Track title list lets you see the list of tracks on

a disc and select one of them to play back.

When playing a CD TEXT disc, track titles are

displayed.

1 Touch LIST to display track list.

Each time you touch LIST it selects lists in the

following order:

DISC LIST (disc list)—TRACK LIST (track list)

—no list displays

2 Touch PREV or NEXT to switch between

the lists of titles.

3 Touch your favorite track title.

That selection will begin to play.

Displaying text information

on CD TEXT discs

You can use these functions only with a CD

TEXT compatible multi-CD player.

Some discs have certain information encoded

on the disc during manufacture. These discs

may contain such information as the CD title,

track title, artist’s name and playback time

and are called CD TEXT discs. Text information

recorded on a CD TEXT disc can be displayed.

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

Disc Title (disc title)—DiscArtist (disc artist

name)—Track Title (track title)—TrackArtist

(track artist name)

#If specific information has not been recorded

on a CD TEXT disc, No XXXX will be displayed

(e.g., No Name).

Multi-CD Player

Section

Introduction of advanced

multi-CD player operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

There are three repeat play ranges for the

multi-CD player: MULTI-CD (multi-CD player

repeat), TRACK (one-track repeat) and DISC

(disc repeat).

%Touch REPEAT on the function menu to

select the repeat range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!MULTI-CD –Repeat all discs in the multi-

CD player

!TRACK –Repeat just the current track

!DISC –Repeat the current disc

Notes

!If you select other discs during repeat play,

the repeat play range changes to MULTI-CD.

!If you perform track search or fast forward/re-

verse during TRACK, the repeat play range

changes to DISC.

Playing tracks in random order

Random play lets you play back tracks in ran-

dom order within the repeat range, MULTI-CD

and DISC.

1 Select the repeat range.

Refer to Repeating play on this page.

2 Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order within the

previously selected MULTI-CD or DISC ranges.

#To turn random play off, touch RANDOM

again.

Scanning CDs and tracks

While you are using DISC, the beginning of

each track on the selected disc plays for about

10 seconds. When you are using MULTI-CD,

the beginning of the first track of each disc is

played for about 10 seconds.

1 Select the repeat range.

Refer to Repeating play on this page.

2 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track of the cur-

rent disc (or the first track of each disc) is

played.

Multi-CD Player

En 55

Section

Multi-CD Player

3 When you find the desired track (or

disc) touch SCAN again.

#After track or disc scanning is finished, nor-

mal playback of the tracks will begin again.

Using compression and

bass emphasis

You can use these functions only with a multi-

CD player that supports them.

Using COMP (compression) and DBE (dy-

namic bass emphasis) functions lets you ad-

just the sound playback quality of the multi-

CD player. Each of the functions has a two-

step adjustment. The COMP function balances

the output of louder and softer sounds at high-

er volumes. DBE boosts bass levels to give

playback a fuller sound. Listen to each of the

effects as you select them and use the one

that best enhances the playback of the track

or CD that you are listening to.

%Touch COMPRESSION on the function

menu to select your favorite setting.

Touch COMPRESSION repeatedly to switch be-

tween the following settings:

OFF—COMP1—COMP2—OFF—DBE1—

DBE2

#If the multi-CD player does not support

COMP/DBE, NO COMP is displayed and

COMPRESSION cannot be operated.

Using ITS playlists

ITS (instant track selection) lets you make a

playlist of favorite tracks from those in the

multi-CD player magazine. After you have

added your favorite tracks to the playlist you

can turn on ITS play and play just those selec-

tions.

Creating a playlist with ITS

programming

You can use ITS to enter and play back up to

99 tracks per disc from up to 100 discs (with

the disc titles). (With multi-CD players sold be-

fore the CDX-P1250 and CDX-P650, up to 24

tracks can be stored in the playlist.)

1 Play a CD that you want to program.

2 Touch ITS MEMORY on the function

menu.

3 Touch or to select the desired track.

4 Touch MEMORY to store the currently

playing track in the playlist.

MEMORY is displayed briefly and the cur-

rently playing selection is added to your play-

list. The display then shows track number

again.

#After data for 100 discs has been stored in

memory, data for a new disc will overwrite the

oldest one.

Playback from your ITS playlist

ITS play lets you listen to the tracks that you

have entered into your ITS playlist. When you

turn on ITS play, tracks from your ITS playlist

in the multi-CD player will begin to play.

1 Select the repeat range.

Refer to Repeating play on the previous page.

2 Touch ITS PLAY on the function menu

to turn ITS play on.

Playback begins of those tracks from your

playlist within the previously selected

MULTI-CD or DISC ranges.

#If no tracks in the current range are pro-

grammed for ITS play, then ITS EMPTY is dis-

played.

#To turn ITS play off, touch ITS PLAY again.

Multi-CD Player

Section

Erasing a track from your ITS

playlist

You can delete a track from your ITS playlist if

ITS play is on.

If ITS play is already on, skip to step 2.

1 Play the CD with the track you want to

delete from your ITS playlist, and turn ITS

play on.

Refer to Playback from your ITS playlist on the

previous page.

2 Touch ITS MEMORY on the function

menu.

3 Touch or to select the desired track.

4 Touch CLEAR to erase the track from

your ITS playlist.

The currently playing selection is erased from

your ITS playlist and playback of the next track

from your ITS playlist begins.

#If there are no tracks from your playlist in the

current range, ITS EMPTY is displayed and nor-

mal play resumes.

Erasing a CD from your ITS playlist

You can delete all tracks of a CD from your ITS

playlist if ITS play is off.

1 Play the CD that you want to delete.

2 Touch ITS MEMORY on the function

menu.

3 Touch CLEAR to erase all tracks on the

currently playing CD from your ITS playlist.

All tracks on the currently playing CD are

erased from your playlist and CLEAR is dis-

played.

Multi-CD Player

En 57

Section

Multi-CD Player

Listening to songs on your

iPod

You can use this unit to control an iPod adapter,

which is sold separately.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3Song number indicator

Shows the number of song played in the se-

lected list.

4Repeat indicator

Shows when repeat range is selected to cur-

rent track.

5Shuffle indicator

Shows when random play is set to SONGS

or ALBUMS.

6Play time indicator

Shows the elapsed playing time of the cur-

rent song.

7Song title indicator

Shows the title of the currently playing

song.

8Song information

Shows detailed information of currently

playing song.

1 Touch the source icon and then touch

iPod to select the iPod.

#When the iPod is not connected to this unit,

you cannot select the iPod as a source.

2 To skip back or forward to another

song, touch oor p.

Touching pskips to the start of the next

song. Touching oonce skips to the start of

the current song. Touching it again will skip to

the previous song.

3 To perform fast forward or reverse,

keep touching oor p.

Browsing for a song

The operation of this unit to control an iPod is

designed to be as close to the operation of the

iPod as possible for easy operation and song

search.

1 Touch TOP to display the top menu.

2 Touch one of the categories in which

you want to search for a song.

!Playlists (playlists)

!Artists (artists)

!Albums (albums)

!Songs (songs)

!Genres (genres)

3 Touch a list title that you want to play.

Repeat this operation until you find the de-

sired song.

#You can start playback throughout the se-

lected list by touching and holding desired list

title.

#You can start a playback of all the songs in the

selected list (Genres,Artists or Albums). To do

this, touch ALL.

Playing songs on iPod

Section

#To go to the next group of list titles, touch

NEXT.

#To return to the previous group of list titles,

touch PREV.

#To return to the previous menu, touch .

#To go to the top menu of the list search, touch

TOP.

#If the playback stops for any reason, touch

TOP and refine your search for a song.

Pausing a song

Pause lets you temporarily stop playback of a

song.

%Touch fduring playback.

PAUSE appears in the display.

#To resume playback at the same point that you

turned pause on, touch fagain.

Displaying text

information on iPod

Text information recorded on the iPod can be

displayed on the information bar.

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

Song Title (song title)—Artist (artist name)—

Album (album title)

#If the characters recorded on the iPod are not

compatible with this unit, those characters will

not be displayed.

Displaying information on

song

Song title, artist name, album title of the cur-

rently playing song can be displayed (if they

have been entered in iPod) together with the

index and the remaining playback time in the

form of the status bar.

%Touch to display information on the

song you are currently playing.

Song information is displayed.

!Status bar shows the remaining playback

time. The bar is filled up from the left to the

right as the playback time is consumed.

Repeating play

For playback of the songs on the iPod, there

are two repeat play ranges: ONE (repeat one

song) and ALL (repeat all songs in the list).

!While this unit is set to repeat one song,

you cannot select the other songs.

%Touch REPEAT to select the repeat

range.

Touch REPEAT repeatedly until the desired re-

peat range appears in the display.

!ONE –Repeat just the current song

!ALL –Repeat all songs in the selected

list

Playing songs in a random

order (shuffle)

For playback of the songs on the iPod, there

are two random play methods: SONGS (play

back songs in a random order) and ALBUMS

(play back albums in a random order).

%Touch SHUFFLE to select the random

play method.

Touch SHUFFLE repeatedly until the desired

random play method appears in the display.

!SONGS –Play back songs in a random

order within the selected list

!ALBUMS –Select an album randomly, and

then play back all the songs in it in order

#To cancel the random play, touch SHUFFLE re-

peatedly until the shuffle icon is turned off.

Playing songs on iPod

En 59

Section

Playing songs on iPod

Listening to XM Satellite Radio

You can use this unit to control an XM satellite

digital tuner (GEX-P920XM), which is sold

separately.

For details concerning operation, refer to the

XM tuner’s operation manuals. This section

provides information on XM operations with

this unit which differs from that described in

the XM tuner’s operation manual.

!This unit does not have the text scroll

function.

1Source icon

Shows what the source has been selected.

2Source name

Shows the selected source name.

3XM band indicator

Shows the XM band which has been

selected.

4XM channel category

Shows the category of broadcast channel.

5XM preset number indicator

Shows what XM preset has been selected.

6XM channel number indicator

Shows to which XM channel number the

tuner is tuned.

7XM channel select setting indicator

Shows what channel select setting has

been selected. ChNumber is displayed

when ChNumber is selected for the chan-

nel select mode, and Category is displayed

when Category is selected for the channel

select mode.

!Refer to Switching the XM channel select

mode on the next page.

8Detail information or preset list display

Shows the detail information of the broad-

cast channel currently being received or the

preset list.

1 Touch the source icon and then touch

XM to select the XM.

2 Touch BAND to select a XM band.

Touch BAND repeatedly until the desired XM

band is displayed, XM 1,XM2or XM 3.

3 Touch cor dto select a desired

channel.

The channels move up or down step by step.

Channels that cannot currently be selected

are skipped, and the next channel is selected.

#If you touch and hold cor d, you can in-

crease or decrease the channel number con-

tinuously.

#You can also select a channel by moving the

joystick left or right.

#You can also perform tuning from a desired

channel category. (Refer to Selecting a channel in

the channel category on the next page.)

XM tuner (GEX-P920XM)

Section

Switching the XM channel

select mode

You have two methods for selecting a channel:

ChNumber mode and Category mode.

When selecting ChNumber mode, channels

in any category can be selected. Select

Category mode to narrow your search down

to only channels in a particular category.

%Touch MODE to select the desired chan-

nel select mode.

Touch MODE repeatedly to switch between

the two modes.

ChNumber (all channel select mode)—

Category (channel category select setting)

Switching between the

detail information display

and preset list display

You can switch the left side of the basic screen

according to your preference.

%Touch LIST.

Touch LIST repeatedly to switch between the

followings:

Detail information display—Preset list display

—OFF

Storing and recalling

broadcast stations

If you touch any of the preset tuning keys

P1—P6 you can easily store up to six broad-

cast stations for later recall with the touch of a

key.

1 Select the channel that you want to

store in memory.

2 Touch LIST to display the preset list.

3 Touch and hold a preset tuning key

P1—P6 until the beep sounds.

The selected station has been stored in mem-

ory.

The next time you touch the same preset tun-

ing key P1—P6 the station is recalled from

memory.

Notes

!Up to 18 stations, six for each of three XM

bands can be stored in memory.

!You can also use aand bto recall stations as-

signed to preset tuning keys P1—P6 when the

ChNumber mode is selected.

Selecting a channel

Selecting a channel in the

channel category

1 Touch MODE to select the channel cate-

gory select mode.

Category appears on the information bar.

2 Touch aor bto select the desired chan-

nel category.

3 Touch cor dto select the desired

channel in the selected channel category.

Selecting a channel from the

XM channel list display

The list content can be switched so you can

search for the track you want to listen to not

only by the channel name but also by the artist

name or song title.

XM tuner (GEX-P920XM)

En 61

Section

XM tuner (GEX-P920XM)

!The channel list shows all the channels

during the ChNumber mode, and the

channels included in the selected category

during the Category mode. To switch the

channel mode, touch MODE.

1 Touch .

XM channel list appears in the display.

Each touch of changes the following set-

tings as follows:

CHANNEL NAME LIST (channel name)—

ARTIST NAME LIST (artist name)—

SONG TITLE LIST (song title)

2 Touch the desired channel that you

want to listen to.

#When the Category mode is selected, touch

aor bto switch to another category.

Selecting a channel directly

You can select an XM channel directly by en-

tering the desired channel number.

1 Touch 10KEY.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#You can also perform this operation by press-

ing DIRECT on the remote control.

2 Touch 0—9 to input the desired channel

number.

#To cancel the input numbers, touch C.

3 Touch ENTER.

The entered XM channel is selected.

#You can also perform this operation by press-

ing DIRECT on the remote control.

Using the MyMix function

The MyMix function allows you to make the

MyMix song playlist. When the song in the

MyMix playlist is being broadcast on a station

other than the one you are listening to, you

will be alerted, and you can tune to the station

to listen to that song.

!A track itself is NOT downloaded BUT only

the song title and the artist name are mem-

orized.

Making the MyMix playlist

You can add a song that is being broadcast to

the MyMix playlist. When it is added, the song

title and its artist name is memorized to this

unit. The MyMix function will start on the song

that matches the song title and its artist name

in the MyMix playlist.

1 When a desired song is broadcast,

touch and hold MEMO.

The song title and artist name of the song you

are listening to are memorized, and a confir-

mation message appears.

#You can also perform this operation by press-

ing and holding MEMO.

#The song title and artist name of up to 12

tracks can be memorized. Trying to save more

than 12 tracks will overwrite old ones.

#You cannot memorize the song title or the ar-

tist name when “––––––––”is displayed on

the title information.

#You cannot memorize the song title or the ar-

tist name of the channel 000.

#It is possible that the memorized title is not

displayed correctly.

2 Touch OK to confirm.

!To delete the song from the MyMix playlist,

refer to Deleting the song from the MyMix

playlist on the next page.

XM tuner (GEX-P920XM)

Section

When the song in the MyMix

playlist is broadcast

As soon as the song in the MyMix playlist

starts broadcast on a different station, a mes-

sage is displayed. Touch YES to switch to that

station, and you can listen to that song.

!You can also perform this operation by

pressing MEMO.

!If you would rather not to tune to that sta-

tion, touch NO.

!If an alert for the song in the MyMix playlist

is set up to off, no alert will be provided

even when the song is broadcast. Refer to

Setting up a song alert on page 69.

!If there is slight difference between the

memorized title and the title of the song

being broadcast, no alert will be provided

even though they are the same song.

Setting up a song alert

You can set up an alert on or off by each song

in the MyMix playlist. First, display the MyMix

playlist and then change each alert setting.

Set up an alert to on so you can receive the

alert when the song is broadcast, or set it up

to off to stop the alert for that song.

1 Touch MEMO EDIT.

The MyMix playlist is displayed.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch the song title that you want to

set up the alert to off.

The check mark is removed, and the alert for

that song is off.

Deleting the song from the

MyMix playlist

You can delete each song in the MyMix

playlist.

1 Touch MEMO EDIT.

The MyMix playlist is displayed.

2 Touch DELETE next to the song title you

want to delete.

That song will be deleted from the MyMix

playlist.

#To delete all the songs in the MyMix playlist,

touch DEL ALL.

3 A message will appear asking you to

confirm to delete it. Touch DELETE.

#To cancel the deleting, touch CANCEL.

Displaying the Radio ID

Channel number select setting

If you select CH 000, the ID code is displayed.

%Touch cor dto select CH 000.

Channel category select setting

You can also display the Radio ID to select

RADIO ID from channel category in the

Category mode.

%Touch aor bto select RADIO ID from

channel category.

#If you select another channel, display of the ID

code is canceled.

#Display of the ID code repeats displaying

RADIO ID and the ID code one after the other.

XM tuner (GEX-P920XM)

En 63

Section

XM tuner (GEX-P920XM)

Listening to XM Satellite Radio

You can use this unit to control a XM satellite di-

gital tuner (GEX-P910XM), which is sold

separately.

For details concerning operation, refer to the

XM tuner’s operation manuals. This section

provides information on XM operations with

this unit which differs from that described in

the XM tuner’s operation manual.

!This unit does not have the text scroll

function.

!With this unit, you can operate one addi-

tional function: XM channel direct

selection.

1Source icon

Shows what the source has been selected.

2Source name

Shows the selected source name.

3XM band indicator

Shows the XM band which has been

selected.

4XM channel category

Shows the category of broadcast channel.

5XM preset number indicator

Shows what XM preset has been selected.

6XM channel number indicator

Shows to which XM channel number the

tuner is tuned.

7XM channel select setting indicator

Shows what channel select setting has

been selected. ChNumber is displayed

when ChNumber is selected for the chan-

nel select mode, and Category is displayed

when Category is selected for the channel

select mode.

!Refer to Switching the XM channel select

mode on page 61.

8Preset list display

Shows the preset list.

1 Touch the source icon and then touch

XM to select the XM.

2 Touch BAND to select a XM band.

Touch BAND repeatedly until the desired XM

band is displayed, XM 1,XM2or XM 3.

3 Touch cor dto select a desired

channel.

The channels move up or down step by step.

Channels that cannot currently be selected

are skipped, and the next channel is selected.

#If you touch and hold cor d, you can in-

crease or decrease the channel number con-

tinuously.

#You can also select a channel by moving the

joystick left or right.

#You can also perform tuning from a desired

channel category. (Refer to Selecting a channel in

the channel category on the next page.)

Switching the XM display

%Touch INFO to switch the XM display.

Each time you touch INFO changes the XM

display in the following order:

Channel name—Category name—Artist name

—Song title/program title

XM tuner (GEX-P910XM)

Section

Storing and recalling

broadcast stations

If you touch any of the preset tuning keys

PRESET1—6you can easily store up to six

broadcast stations for later recall with the

touch of a key.

%When you find a station that you want

to store in memory touch and hold a preset

tuning key PRESET1—6 until the beep

sounds.

The selected station has been stored in mem-

ory.

The next time you touch the same preset tun-

ing key PRESET1—6the station is recalled

from memory.

Notes

!Up to 18 stations, six for each of three XM

bands can be stored in memory.

!You can also use aand bto recall stations as-

signed to preset tuning keys PRESET1—6.

Switching the XM channel

select mode

You have two methods for selecting a channel:

ChNumber mode and Category mode.

When selecting ChNumber mode, channels

in any category can be selected. Select

Category mode to narrow your search down

to only channels in a particular category.

%Touch MODE to select the desired chan-

nel select mode.

Touch MODE repeatedly to switch between

the two modes.

ChNumber (channel number select setting)—

Category (channel category select setting)

Selecting a channel in the

channel category

Refer to Selecting a channel in the channel

category on page 61.

Selecting a channel directly

Refer to Selecting a channel directly on page

62.

Displaying the Radio ID

Refer to Displaying the Radio ID on page 63.

XM tuner (GEX-P910XM)

En 65

Section

XM tuner (GEX-P910XM)

Listening to SIRIUS Satellite

Radio

This unit can control a SIRIUS Satellite Radio

tuner (sold separately).

When the SIRIUS tuner is used together with

this unit, some operations differ slightly from

those described in the SIRIUS operation man-

ual. This manual provides information on

these points. For all other information on

using the SIRIUS tuner, please refer to the SIR-

IUS operation manual.

1Source icon

Shows what the source has been selected.

2Source name

Shows the selected source name.

3SIRIUS band indicator

Shows the SIRIUS band which has been

selected.

4SIRIUS preset number indicator

Shows what SIRIUS preset has been

selected.

5SIRIUS channel number indicator

Shows to which SIRIUS channel number

the tuner is tuned.

6SIRIUS channel select setting indicator

Shows what channel select setting has

been selected. ChNumber is displayed

when ChNumber is selected for the chan-

nel select mode, and Category is displayed

when Category is selected for the channel

select mode.

!Refer to Switching the XM channel select

mode on page 61.

7Detail information or preset list display

Shows the detail information of the broad-

cast channel currently being received or the

preset list.

1 Touch the source icon and then touch

SIRIUS to select SIRIUS.

2 Touch BAND to select a band.

Touch BAND repeatedly until the desired SIR-

IUS band is displayed, SIRIUS1,SIRIUS2 or

SIRIUS3.

3 Touch cor dto select a desired

channel.

The channels move up or down step by step.

Channels that cannot currently be selected

are skipped, and the next channel is selected.

#If you touch and hold cor d, you can in-

crease or decrease the channel number con-

tinuously.

#You can also select a channel by moving the

joystick left or right.

#You can also perform tuning from a desired

channel category. (Refer to Selecting the channel

in the channel category on the next page.)

Note

It may take a few seconds before you can hear

anything while this unit acquires and processes

the satellite signal.

SIRIUS Satellite Radio tuner

Section

Selecting the SIRIUS

channel select mode

You have two methods for selecting a channel:

ChNumber mode and Category mode.

When selecting ChNumber mode, channels

in any category can be selected. Select

Category mode to narrow your search down

to only channels in a particular category.

%Touch MODE to select the desired chan-

nel select mode.

Touch MODE repeatedly to switch between

the two modes.

ChNumber (all channel select mode)—

Category (channel category select mode)

Selecting a channel

Selecting the channel in the

channel category

Channels are organized into various program

categories, e.g. Rock, Classic, Jazz. You can

specify channels by selecting the desired

category.

1 Touch MODE to select the channel cate-

gory select mode.

Category appears on the information bar.

2 Touch aor bto select the desired chan-

nel category.

3 Touch cor dto select the desired

channel in the selected channel category.

Selecting a SIRIUS channel directly

You can select a SIRIUS channel directly by

entering the desired channel number.

1 Touch 10KEY.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#You can also perform this operation by press-

ing DIRECT on the remote control.

2 Touch 0—9 to input the desired channel

number.

#To cancel the input numbers, touch C.

3 Touch ENTER.

The entered SIRIUS channel is selected.

#You can also perform this operation by press-

ing DIRECT on the remote control.

Switching the display

Various information, including channel num-

ber, name and category, song/program title,

artist/feature and composer, can be displayed

for the selected channel.

%Touch INFO to switch information on

the selected channel.

Touch INFO repeatedly switch between the

followings:

Artist name/feature—Song/program title—

Composer—Channel number—Channel name

—Channel Category

Switching between the

detail information display

and preset list display

Only when SIR-PNR2/SIR-PNR2C is connected

to this unit, you can operate this function.

You can switch the left side of the basic screen

according to your preference.

SIRIUS Satellite Radio tuner

En 67

Section

SIRIUS Satellite Radio tuner

%Touch LIST.

Touch LIST repeatedly to switch between the

followings:

Detail information display—Preset list display

—OFF

Storing and recalling

broadcast stations

If you touch any of the preset tuning keys

PRESET1—6you can easily store up to six

broadcast stations for later recall with the

touch of a key.

!Channels are stored and recalled on a

broadcast station basis. This means that if

the broadcast station you stored has been

assigned to a different channel by SIRIUS,

you can still recall the same broadcast sta-

tion (though a different channel number

may appear in the display).

1 Select the channel that you want to

store in memory.

2 Touch LIST to display the preset list.

3 Touch and hold a preset tuning key

PRESET1—6 until the beep sounds.

The selected station has been stored in mem-

ory.

The next time you touch the same preset tun-

ing key PRESET1—6the station is recalled

from memory.

Note

Up to 18 stations, six for each of three SIRIUS

bands can be stored in memory.

Using the MyMix function

Only when SIR-PNR2/SIR-PNR2C is connected

to this unit, you can operate this function.

The MyMix function allows you to make the

MyMix song playlist. When the song in the

MyMix playlist is being broadcast on a station

other than the one you are listening to, you

will be alerted, and you can tune to the station

to listen to that song.

!A track itself is NOT downloaded BUT only

the song title and the artist name are mem-

orized.

Making the MyMix playlist

You can add a song that is being broadcast to

the MyMix playlist. When it is added, the song

title and its artist name is memorized to this

unit. The MyMix function will start on the song

that matches the song title and its artist name

in the MyMix playlist.

%When a desired song is broadcast,

touch and hold MEMO.

The song title and artist name of the song you

are listening to are memorized, and a confir-

mation message appears.

#You can also perform this operation by press-

ing and holding MEMO.

#The song title and artist name of up to 10

tracks can be memorized. When you try to save

more than 10 tracks, FULL is displayed and that

song being broadcast cannot be saved.

#You cannot memorize the song title or the ar-

tist name of the channel 000.

#It is possible that the memorized title is not

displayed correctly.

SIRIUS Satellite Radio tuner

Section

When the song in the MyMix

playlist is broadcast

As soon as the memorized song starts broad-

cast on a different station, a song alert is dis-

played. Touch JUMP to switch to that station,

and you can listen to that track.

!You can also perform this operation by

pressing MEMO.

!If you would rather not to tune to that sta-

tion, touch STAY.

!If an alert for the song in the MyMix playlist

is set up to off, no alert will be provided

even when the song is broadcast. Refer to

Setting up a song alert on this page.

!If there is slight difference between the

memorized title and the title of the song

being broadcast, no alert will be provided

even though they are the same song.

Turning the MyMix function on

or off

You can turn the MyMix function off and stop

this unit to alert you for all the songs in the

MyMix playlist. To restart, turn this function

on.

!The MyMix function is on at the default

setting.

1 Touch MEMO EDIT.

The display is switched to the memo edit

mode.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch ALERT OFF to turn the MyMix

function off.

The MyMix function is now off.

#To turn the MyMix function on, touch

ALERT ON.

Setting up a song alert

You can set up an alert on or off by each song

in the MyMix playlist. First, display the MyMix

playlist and then change each alert setting.

Set up an alert to on so you can receive the

alert when the song is broadcast, or set it up

to off to stop the alert for that song.

1 Touch MEMO EDIT.

The display is switched to the memo edit

mode.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch PREVIOUS or NEXT to select the

song title that you want to turn the alert

off.

3 Touch ON/OFF to turn the alert off.

The alert for the song is turned off.

Deleting the song from the

MyMix playlist

You can delete each song in the MyMix

playlist.

1 Touch MEMO EDIT.

The song title in the MyMix playlist is dis-

played.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch PREVIOUS or NEXT to select the

song title that you want to delete.

3 Touch DELETE.

4 A message will appear asking you to

confirm to delete it. Touch YES.

The selected song is deleted.

#To cancel the deleting, touch NO..

SIRIUS Satellite Radio tuner

En 69

Section

SIRIUS Satellite Radio tuner

Using the Game Alert function

Only when SIR-PNR2/SIR-PNR2C is connected

to this unit, you can operate this function.

This unit can alert you when games involving

your favorite teams are about to start. To use

this function you need in advance to set up a

game alert for the teams.

Selecting teams for Game Alert

1 Touch GAME ALERT.

2 Touch PREVIOUS or NEXT next to

LEAGUE to select a desired league.

League names are switched in the display.

3 Touch PREVIOUS or NEXT next to TEAM

to select a desired team.

Teams in the selected category are switched in

the display.

4 Touch ON/OFF to store the selected

team in memory.

ON is displayed with the selected team, and

the Game Alert function will start on that

team.

#To turn the Game Alert off of the selected

team, touch ON/OFF again.

#When you have already made 12 team selec-

tions, FULL is displayed and additional team se-

lection is not possible. In this case, first delete

the team selection and then try again.

5 Repeat these steps for selecting other

teams.

Up to 12 teams can be selected.

Switching the Game Alert on or off

Once you made team selections, you need to

turn the Game Alert function on.

!The Game Alert function is on at the default

setting.

1 Touch GAME ALERT.

2 Touch ALERT ON to turn the Game Alert

on.

The Game Alert function is now on.

#To turn the Game Alert function off, touch

ALERT OFF.

When the game of the selected

team starts

When a game of the selected team is about to

start (or is currently playing) on a different sta-

tion, a game alert is displayed. Touch JUMP to

switch to that station, and you can listen to

that game.

!If you would rather not to tune to that sta-

tion, touch STAY.

Displaying game information

If games of your selected teams are currently

playing, you can display information of the

games and tune to the broadcast channel.

1 Touch GAME INFO.

The game information of your selected team is

displayed.

2 Touch PREV or NEXT to select a game.

The game is displayd, followed by more de-

tailed game information.

!Game score will be updated automatically.

3 Touch TUNE TO to switch to that sta-

tion to listen to the game.

Notes

!If you have not made any team selections,

NOT SET is displayed.

!When games involving your favorite teams are

not currently playing, NO GAME is displayed.

SIRIUS Satellite Radio tuner

Section

Displaying the Radio ID

If you select CH000, the ID code is displayed.

%Touch cor dto select CH 000.

Note

To select CH000, set the channel select setting to

ChNumber. About the channel select setting,

refer to Selecting the SIRIUS channel select mode

on page 67

SIRIUS Satellite Radio tuner

En 71

Section

SIRIUS Satellite Radio tuner

Listening to songs on BT Audio

(Bluetooth audio player)

If you connect Bluetooth adapter (e.g. CD-

BTB100) to this unit, you can control Bluetooth

audio player via Bluetooth wireless technology.

For details concerning operation, refer to the

Bluetooth adapter’s operation manual. This

section provides brief information on Blue-

tooth audio player operations with this unit

which slightly differes or is cut short from that

described in the Bluetooth adapter’s operation

manual.

!Even though your audio player does not

contain a Bluetooth module, you can still

control it from this unit via Bluetooth wire-

less technology. To control your audio

player by using this unit, connect a product

featuring Bluetooth wireless technology

(available on the market) to your audio

player and connect Bluetooth adapter (e.g.

CD-BTB100) to this unit.

Important

!Depending on the Bluetooth audio player con-

nected to this unit, the available operations

with this unit are limited to the following two

levels:

—Lower level: Only playing back songs on

your audio player is possible.

—Higher level: Playing back, pausing, select-

ing songs, etc., are possible (all the opera-

tions illustrated in this manual).

!Since there are a number of Bluetooth audio

players available on the market, operations

with your Bluetooth audio player using this

unit vary in great range. Please refer to the in-

struction manual that came with your Blue-

tooth audio player as well as this manual

while operating your player on this unit.

!Information about songs (e.g. the elapsed

playing time, song title, song index, etc.) can-

not be displayed on this unit.

!While you are listening to songs on your Blue-

tooth audio player, please refrain from operat-

ing on your cellular phone as much as

possible. If you try operating on your cellular

phone, the signal from your cellular phone

may cause a noise on the song playback.

!When you are talking on the cellular phone

connected to this unit via Bluetooth wireless

technology, the song playback from your Blue-

tooth audio player connected to this unit is

muted.

!Even if while you are listening to song on your

Bluetooth audio player you switch to another

source, the playback of song continues to

elapse.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3Device name

Shows the device name of the connected

Bluetooth audio player (or Bluetooth adap-

ter).

4Bluetooth audio indicator

Shows when a Bluetooth audio player con-

nection is established (for more details,

refer to Connecting a Bluetooth audio player

on the next page).

Bluetooth Audio

Section

1 Touch the source icon and then touch

BT AUDIO to select the Bluetooth audio

source.

#For this unit to control your Bluetooth audio

player it needs to establish a Bluetooth wireless

connection. (Refer to Connecting a Bluetooth

audio player on this page.)

2 Touch f.

Playback starts.

#When you want to pause a song, touch f

again.

3 To skip back or forward to another

track, touch oor p.

Touching pskips to the start of the next

track. Touching oonce skips to the start of

the current track. Touching it again will skip to

the previous track.

#You can also skip back or forward to another

track by moving the joystick left or right.

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

5 To stop playback, touch g.

Note

Depending on the Bluetooth audio player you

connected to this unit, operations on this unit to

control the player may differ from those explained

in this manual.

Function operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Connecting a Bluetooth

audio player

%Touch CONNECTION OPEN on the func-

tion menu to turn the connection open on.

CONNECTION WAITING is displayed. This

unit is now on standby for connection from

Bluetooth audio player.

If your Bluetooth audio player is set ready for

Bluetooth wireless connection, the connection

to this unit will be automatically established.

Bluetooth Audio

En 73

Section

Bluetooth Audio

Note

Before you can use audio players you may need

to enter the PIN code into this unit. If your player

requires a PIN code to establish a connection,

look for the code on the player or in its accompa-

nying documentation. Enter the PIN code refer-

ring to Entering PIN code for Bluetooth wireless

connection on page 118.

Disconnecting a Bluetooth

audio player

%Touch DISCONNECT on the function

menu.

After the disconnection is completed,

No Connection is displayed.

Displaying BD (Bluetooth

Device) address

%Touch DEVICE INFO on the function

menu to display the BD address.

Various information regarding the bluetooth

wireless technology are displayed.

!BD ADDRESS (system address)

!SYSTEM NAME (system name)

!SYSTEM VER. (version)

!BT MODULE VER. (Bluetooth module

version)

Bluetooth Audio

Section

Hands-free phoning with

cellular phones featuring

Bluetooth wireless technology

If you use Bluetooth adapter (e.g. CD-BTB100),

you can connect a cellular phone featuring

Bluetooth wireless technology to this unit for

hands-free, wireless calls, even while driving.

For details concerning operation, refer to the

Bluetooth adapter’s operation manual. This

section provides brief information on the

hands-free phoning operations with this unit

which slightly differes or is cut short from that

described in the Bluetooth adapter’s operation

manual.

Important

Since this unit is on standby to connect with your

cellular phones via Bluetooth wireless technol-

ogy, using this unit without running the engine

can result in battery drainage.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3User number indicator

Shows the registration number of the cellu-

lar phone.

4Device name

Shows the device name of the cellular

phone.

5Phone number

Shows the phone number you selected.

6Automatic answering/Automatic reject-

ing indicator

Shows when the automatic answering func-

tion is on (for more details, refer to Setting

the automatic answering on page 83).

Shows when the automatic rejecting func-

tion is on (for more details, refer to Setting

the automatic rejecting on page 83).

7Battery strength indicator

Shows the battery strength of cellular

phone.

!Battery strength indicator may differ

from the actual battery strength.

!If the battery strength is not available,

nothing is displayed in the battery

strength indicator area.

8Signal level indicator

Shows the signal strength of cellular phone.

!Signal level indicator may differ from the

actual signal level.

!Depending on the cellular phones featur-

ing Bluetooth wireless technology, radio

field intensity is not available.

9Telephone indicator

Shows when a phone connection using

Bluetooth wireless technology is estab-

lished (for more details, refer to Connecting

a cellular phone on page 77).

!While connecting automatically, tele-

phone indicator is flashing.

aIncoming call notice indication

Shows when an incoming call has been re-

ceived and not checked yet.

Bluetooth Telephone

En 75

Section

Bluetooth Telephone

!Incoming call notice is not displayed for

calls made when your cellular phone is

disconnected from this unit.

bVoice recognition indicator

Shows when the voice recognition function

is on (for more details, refer to Voice recogni-

tion on this page).

cPreset dial list display

Shows the Preset dial list.

%Touch the source icon and then touch

Telephone to select the telephone.

Note

Equalizer curve for the phone source is fixed.

When selecting the phone source, you cannot op-

erate the equalizer function. Refer to Recalling

equalizer curves on page 98.

Setting up for hands-free

phoning

Before you can use the hands-free phoning

function you will need to set up the unit for

use with your cellular phone. This entails es-

tablishing a Bluetooth wireless connection be-

tween this unit and your phone, registering

your phone with this unit, and adjusting the

volume level.

1 Connection

For detailed instructions on connecting your

phone to this unit via Bluetooth wireless tech-

nology, refer to Connecting a cellular phone on

the next page.

#Your phone should now be temporarily con-

nected; however, to make best use of the technol-

ogy, we recommend you register the phone to

this unit.

2 Registration

Refer to Registering connected cellular phone

on page 78 for instructions on how to register

your temporarily connected phone.

3 Volume adjustment

Adjust the earpiece volume on your cellular

phone for comfort. When adjusted, the volume

level is memorized in this unit as the default

setting.

#Caller’s voice volume and ring volume may

vary depending on the type of cellular phones.

#If the difference between the ring volume and

caller’s voice volume is big, overall volume level

may become unstable.

#Before disconnecting cellular phone from this

unit, make sure to adjust the volume to proper

level. If the volume has been muted (zero level)

on your cellular phone, the volume level of your

cellular phone remains muted even after the cel-

lular phone is disconnected from this unit.

Basic operation of hands-

free phoning

Important

Advanced operations that require your attention

such as dialing numbers on the monitor, using

phone book, etc., are prohibited while you are

driving. When you need to use these advanced

operations, stop your vehicle in a safe place and

operate.

Making a phone call

Voice recognition

1 Touch VOICE to turn the voice recogni-

tion function on.

Voice dial icon appears on the information bar.

Voice recognition function is now ready.

Bluetooth Telephone

Section

#To cancel the voice recognition function,

touch VOICE again.

2 Pronounce the name of your contact.

Taking a phone call

Answering an incoming call

1 When a call comes in, touch .

Touching switches between callers on

hold.

2 To end the call, touch .

The estimated call time appears in the display

(this may differ slightly from the actual call

time).

Rejecting an incoming call

%When a call comes in, touch .

The call is rejected.

Answering a call waiting

1 Touch to answer a call waiting.

2 Touch to end the call.

#The caller you have been talking to is now on

hold. To end the call, both you and your caller

need to hang up the phone.

#While your callers hold the line, touching

switches between callers.

Rejecting a call waiting

%Touch to reject a call waiting.

Introduction of advanced

hands-free phoning operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the telephone

standby display.

#To return to the previous display, touch

BACK.

Connecting a cellular phone

Searching for available cellular

phones

1 Touch PHONE CONNECT on the function

menu.

2 Touch SEARCH to search for available

cellular phones.

While searching, SEARCHING flashes. When

available cellular phones featuring Bluetooth

wireless technology are found, device names

or Name Not Found (if names cannot be ob-

tained) are displayed.

Bluetooth Telephone

En 77

Section

Bluetooth Telephone

#If this unit fails to find any available cellular

phones, Not Found is displayed.

3 Touch the device name you want to

connect.

While connecting, CONNECTING flashes. To

complete the connection, please check the de-

vice name (Pioneer BT unit) and enter the link

code on your cellular phone. If the connection

is established, CONNECTED is displayed.

#The link code is set to 0000 as default. You

can change this code in the initial setting. Refer

to Entering PIN code for Bluetooth wireless con-

nection on page 118.

Using a cellular phone to

initiate a connection

1 Touch PHONE CONNECT on the function

menu.

2 Touch CONNECTION OPEN.

The unit is now on standby for connection

from cellular phone.

3 Use cellular phone to connect to this

unit.

#To cancel this function, touch

CONNECTION OPEN again.

#The link code is set to 0000 as default. You

can change this code in the initial setting. Refer

to Entering PIN code for Bluetooth wireless con-

nection on page 118.

Disconnecting a cellular phone

1 Touch PHONE CONNECT on the function

menu.

2 Touch DISCONNECT to disconnect the

currently connected cellular phone from

this unit.

After the disconnection is completed,

No Connection is displayed.

Registering connected

cellular phone

1 Touch PHONE REGISTER on the function

menu.

Registration assignments appear on the dis-

play. From the top to the third assignment are

for User phone 1, 2 and 3. The rest two assign-

ments are for Guest phone 1 and 2.

2 Touch and hold one of the registration

assignments to register the currenctly con-

nected phone.

If the registration is succeeded, the device

name of the connected phone is displayed in

the selected assignment.

#If the assignment is empty, the device name is

not displayed. If the assignment is already taken,

the device name appears. To replace an assign-

ment with a new phone, first delete the current

assignment. For more detailed instructions, see

Deleting a registered phone on this page.

#If the registration failed, device name of the

connected phone is not displayed in the selected

assignment. In this case, return to step 1 and try

again.

Deleting a registered phone

1 Touch PHONE REGISTER on the function

menu.

Bluetooth Telephone

Section

2 Touch DELETE next to the device name

you want to delete.

A confirmation display appears. Touch YES to

delete the phone.

#To cancel deleting a registered phone, touch

NO.

Connecting to a registered

cellular phone

Connecting to a registered

phone manually

1 Touch PHONE CONNECT on the function

menu.

2 Touch DIRECT CONNECT.

3 Touch the device name you want to

connect.

While connecting, CONNECTING is flashing.

If the connection is established, CONNECTED

is displayed.

Connecting to a registered

phone automatically

%Touch AUTO CONNECT on the function

menu to turn the Automatic Connection

function on.

If your cellular phone is set ready for Bluetooth

wireless connection, the connection to this

unit will be automatically established.

#To turn automatic connection off, touch

AUTO CONNECT again.

Using the Phone Book

Transferring entries to the

Phone Book

The Phone Book can hold a total of 500 en-

tries; 300 from User 1, 150 from User 2, and 50

from User 3.

1 Touch PHONEBOOK TRANSFER on the

function menu.

2 Touch START to turn the Phone Book

Transfer function on.

The Phone Book Transfer is now on standby.

3 Use cellular phone to perform phone

book transfer.

Perform phone book transfer using the cellu-

lar phone. For detailed instruction on this,

refer to the instruction manual that came with

your cellular phone.

#The display indicates how many entries have

been transferred and the total number to be

transferred.

#To cancel the transferring process, touch

STOP.

4 Completed is displayed and phone

book transfer is completed.

Changing the Phone Book

display order

%Touch PHONEBOOK NAME VIEW on the

function menu to turn Phone Book Name

View function on.

Display order for the Phone Book is changed.

#To change to the other display order, touch

PHONEBOOK NAME VIEW again.

Bluetooth Telephone

En 79

Section

Bluetooth Telephone

Calling a number in the Phone

Book

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

After finding the number in the Phone Book

you want to call, you can select the entry and

make the call.

1 Touch PHONEBOOK to display the

Phone Book.

2 Touch SEARCH to display the Phone

Book search display.

3 Touch an alphabet letter to select the

first letter of the name you are looking for.

4 Touch ENTER to show entries starting

with the letter you chose.

The display shows the first six Phone Book en-

tries starting with that letter (e.g. “Ben”,

“Brian”and “Burt”when “B”is selected).

5 Touch a Phone Book entry you want to

call.

The display is switched to the Phone Book edit

display.

#Touch PREV or NEXT to display other phone

book entries.

#To refine the search with a different letter,

touch .

6 Touch phone number of the Phone

Book entry you want to call.

If several phone numbers are entered to an

entry, touch one you want to call.

The display returns to the normal display and

the Phone Book entry you selected is dis-

played on the information bar.

7 Touch to make a call.

#For an international call, touch add “+”to add

+to the phone number.

8 To end the call, touch .

The estimated call time appears in the display

(this may differ slightly from the actual call

time).

Editing the name of a Phone

Book entry

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

1 Touch PHONEBOOK to display the

Phone Book.

2 Select a Phone Book entry you want to

edit.

Refer to Calling a number in the Phone Book

on this page for detailed instructions.

3 Touch EDIT next to the Phone Book

entry name.

The display is changed to the Phone Book edit

display.

4 Touch the letter you wish to input.

Key What it does

Moves the cursor to the previous charac-

ter position.

Moves the cursor to the next character po-

sition.

Inputs the space.

ABC/123 Switches keypad between alphabet and

numeric.

Deletes letter by letter from the end of the

text.

5 Touch MEMORY to store the new

name.

Bluetooth Telephone

Section

Editing phone numbers

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

1 Touch PHONEBOOK to display the

Phone Book.

2 Select a Phone Book entry you want to

edit.

See step two to three on Calling a number in

the Phone Book on the previous page for how

to do this.

3 Touch EDIT next to the phone number

you want to edit.

The display is changed to the Phone Book dial

edit display.

4 Touch 0—9 to input numbers.

#For an international call, touch add “+”to add

+to the phone number.

#Touch CLEAR to delete the number. Touch and

hold CLEAR to delete all the input numbers.

5 Touch MEMORY to store the new num-

ber.

Clearing a Phone Book entry

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

1 Touch PHONEBOOK to display the

Phone Book.

2 Select a Phone Book entry you want to

delete.

See step two to three on Calling a number in

the Phone Book on the previous page for how

to do this.

3 Touch DELETE to delete the Phone Book

entry.

A confirmation display appears. Touch YES to

delete the entry.

#If you do not want to clear a Phone Book entry

that you have selected, touch NO.

Using the Call History

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

The 12 most recent calls made (dialed), re-

ceived and missed are stored in the Call His-

tory. You can browse the Call History and call

numbers from it.

1 Touch LOG to display the Call History.

Touching LOG repeatedly switches between

the following call histories:

MISSED CALL LIST (missed call)—

DIALED CALL LIST (dialed call)—

RECEIVED CALL LIST (received call)

#If no phone numbers have been stored in the

selected list, nothing is displayed.

#You can switch between phone number and

name (if entered) by touching ABC/123.

2 Touch a phone number or name (if en-

tered) you want to call.

The display returns to the normal display and

the phone number you selected is displayed

on the information bar.

#Touch PREV or NEXT to display other phone

number or name (if entered).

3 Touch to make a call.

#For an international call, touch add “+”to add

+to the phone number.

4 To end the call, touch .

Bluetooth Telephone

En 81

Section

Bluetooth Telephone

Using preset numbers

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

Assigning preset numbers

Numbers that you dial frequently can be as-

signed to presets for quick recall.

You can assign up to 6 frequently called phone

numbers to number presets.

1 Select a desired phone number from

the Phone Book or the Call History. Or di-

rectly enter a desired phone number.

To select a desired phone number from the

Phone Book or the Call History, see the in-

structions explained in previous pages. To di-

rectly enter a desired phone number, see

Making a call by entering phone number on

this page.

The display should now be the normal display

and the selected phone number is displayed

on the information bar.

2 Keep touching one of preset assign-

ments to store the phone number.

The phone number you selected is stored in

presets.

#When P1—P6 are not displayed, you can dis-

play them by touching LIST.

#No Data is displayed for empty assignment.

Even if the assignment is taken, you can replace

it to the new one by keeping touching the assign-

ment.

Recalling preset numbers

1 Touch one of preset assignments.

The selected phone number should now be

displayed on the information bar.

#When P1—P6 are not displayed, you can dis-

play them by touching LIST.

2 Touch to make a call.

3 To end the call, touch .

The estimated call time appears in the display

(this may differ slightly from the actual call

time).

Making a call by entering

phone number

Important

You are required to park your vehicle and set the

parking brake in order to perform this operation.

1 Touch DIRECT to display the direct dial

display.

2 Touch 0—9 to input numbers.

#For an international call, touch add “+”to add

+to the phone number.

#If you want to store the entered phone number

to preset assignment, touch SET here. The display

returns to the normal display and the phone num-

ber you entered is selected.

#Touch CLEAR to delete the number. Touch and

hold CLEAR to delete all the input numbers.

#Up to 24 digits can be entered.

3 When you completed entering the

number, touch to make a call.

4 To end the call, touch .

The estimated call time appears in the display

(this may differ slightly from the actual call

time).

Clearing memory

1 Touch CLEAR MEMORY on the function

menu.

Bluetooth Telephone

Section

2 Touch CLEAR next to the item you want

to delete from the memory.

Select from the following:

!PHONEBOOK (phone book)

!Dialed Calls (dialed call history)

!Received Calls (received call history)

!Missed Calls (missed call history)

!Preset Dials (preset phone numbers)

After selecting a desired item, a confirmation

display appears. Touch OK to delete the mem-

ory.

#If you do not want to clear memory that you

have selected, touch CANCEL.

#If you want to clear all the Phone Book, dia-

led/received/missed call history list and preset

phone number, touch CLEAR ALL.

Setting the automatic

answering

%Touch AUTO ANSWER on the function

menu to turn the automatic answer on.

#To turn the automatic answer off, touch

AUTO ANSWER again.

Setting the automatic

rejecting

%Touch REFUSE ALL CALLS on the func-

tion menu to turn the automatic call rejec-

tion on.

#To turn the automatic call rejection off, touch

REFUSE ALL CALLS again.

Switching the ring tone

%Touch RING TONE on the function menu

to turn the ring tone on.

#To turn the ring tone off, touch RING TONE

again.

Echo canceling and noise

reduction

%Touch ECHO CANCEL on the function

menu to turn Echo Cancel function on.

#To turn echo canceling off, touch

ECHO CANCEL again.

Displaying BD (Bluetooth

Device) address

%Touch DEVICE INFO on the function

menu to display the BD address.

Various information regarding the bluetooth

wireless technology are displayed.

!BD ADDRESS (system address)

!SYSTEM NAME (system name)

!SYSTEM VER. (version)

!BT MODULE VER. (Bluetooth module

version)

Bluetooth Telephone

En 83

Section

Bluetooth Telephone

Watching the television

You can use this unit to control a TV tuner (e.g.

GEX-P5700TV), which is sold separately.

For details concerning operation, refer to the

TV tuner’s operation manual. This section pro-

vides information on TV operations with this

unit which differs from that described in the

TV tuner’s operation manual.

Important

Depending on the TV tuner connected to this

unit, some functions may not be operable. For de-

tails, refer to the TV tuner’s operation manual.

1Source icon

Shows which source has been selected.

2Source name

Shows the selected source name.

3Band indicator

Shows which band the TV tuner is tuned to.

4Preset number indicator

Shows which preset has been selected.

5Channel indicator

Shows which channel the TV tuner is tuned.

6Preset list display

Shows the preset list.

1 Touch the source icon and then touch

TV to select the TV.

2 Touch the screen to display the touch

panel keys.

3 Touch BAND to select a band.

Touch BAND repeatedly until the desired band

is displayed, BAND 1 or BAND 2.

4 To perform manual tuning, briefly

touch cor d.

The channels move up or down step by step.

#You can also perform manual tuning by mov-

ing the joystick left or right.

5 To perform seek tuning, keep touching

cor dfor about one second and release.

The tuner will scan the channels until a broad-

cast strong enough for good reception is

found.

#You can cancel seek tuning by briefly touching

either cor d.

#If you keep touching cor dyou can skip

broadcasting channels. Seek tuning starts as

soon as you release the keys.

#You can also perform seek tuning by holding

the joystick left or right.

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically.

Storing and recalling

broadcast stations

If you touch any of the preset tuning keys

P01—P12 you can easily store up to 12 broad-

cast stations for later recall with the touch of a

key.

TV tuner

Section

%When you find a station that you want

to store in memory, keep touching one of

preset tuning keys P01—P12 until the beep

sounds.

The next time you touch the same preset tun-

ing key the station is recalled from memory.

#To switch between P01—P06 and P07—P12,

touch PREV or NEXT.

#When P01—P06 and P07—P12 are not dis-

played, you can display them by touching LIST.

Notes

!Up to 24 stations, 12 for each of two TV bands,

can be stored in memory.

!You can also use aand bto recall stations as-

signed to preset tuning keys P01—P12 when

P01—P12 are not displayed.

Confirming current channel

and other settings

When watching a TV on the rear display, you

can display the reception information such as

the channel, band and preset channel list.

!Only the remote control can operate this

function. To perform this function, switch

the remote control operation mode to TV.

(Refer to page 21.)

%Press DIRECT to display the reception

information.

Each press of DIRECT displays reception infor-

mations in the following order:

Current channel information (channel and

band)—Preset channel list—Reception infor-

mations disappear

#Reception informations are displayed for eight

seconds.

Storing the strongest

broadcast stations

sequentially

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch BSSM on the function menu to

turn BSSM on.

BSSM begins to flash. While BSSM is flashing

the 12 strongest broadcast stations will be

stored in order from the lowest channel up.

When finished, BSSM stops flashing.

#To cancel the storage process, touch BSSM

again.

3 Touch ESC to return to the TV picture.

#To return to the previous display, touch BACK.

Note

Storing broadcast stations with BSSM may re-

place broadcast stations you have saved using

P01—P12.

TV tuner

En 85

Section

TV tuner

Playing a disc

You can use this unit to control a DVD player or

multi-DVD player, which is sold separately.

For details concerning operation, refer to the

DVD player’s or multi-DVD player’s operation

manual. This section provides information on

DVD operations with this unit which differs

from that described in the DVD player’sor

multi-DVD player’s operation manual.

!When operating DVD player/multi-DVD

player by using the touch panel keys, refer

to built-in DVD player operation.

—When using a DVD player or multi-DVD

player, you cannot operate the DVD

menu by touching the menu item di-

rectly.

!This unit does not have ITS playlist and disc

title functions.

!Switch the remote control selection to sui-

table setting to operate DVD players. (Refer

to page 115.)

!Switch the remote control operation mode

to DVD to operate the DVD player by using

remote control. (Refer to page 21.)

1Source icon

Shows which source has been selected.

2Disc type indicator

Shows the type of the currently playing disc.

3Audio language indicator

Shows which audio language has been se-

lected when playing DVD video.

4Disc number indicator

Shows the disc number currently playing

when using a multi-DVD player.

5Title/Folder number indicator

Shows the title (when playing DVD video) or

folder (when playing MP3 or WMA) of the

selection currently playing.

6Chapter/track number indicator

Shows the chapter (when playing DVD

video) or track (when playing video CD, CD,

MP3 or WMA) currently playing.

7Play time indicator

Shows the elapsed playing time of the cur-

rent chapter/track.

8Viewing angle indicator

Shows which viewing angle has been se-

lected when playing DVD video.

9Subtitle language indicator

Shows which subtitle language has been

selected when playing DVD video.

aDisc list display

Shows the list of the disc type when using a

multi-DVD player.

1 Touch the source icon and then touch

S-DVD to select the DVD player.

2 Touch the screen to display the touch

panel keys.

3 To skip back or forward to another

chapter/track, briefly touch oor p.

#You can also skip back or forward to another

chapter/track by moving the joystick left or right.

DVD Player

Section

When using the joystick on the remote control,

switch the remote control operation mode to

AVH. (Refer to page 21.)

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by holding the joystick left or right.

When using the joystick on the remote control,

switch the remote control operation mode to

AVH. (Refer to page 21.)

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically when

playing DVD video or video CD.

Turning the DVD player on

or off

!Only the remote control can operate this

function. To perform this function, switch

the remote control operation mode to DVD.

(Refer to page 21.)

%Press REAR SOURCE to turn the DVD

player on.

#To turn the DVD player off, press

REAR SOURCE again.

Selecting a disc

!You can operate this function only when a

multi-DVD player is connected to this unit.

%Touch any of 01—06 to select the de-

sired disc.

#When 01—06 are not displayed, you can dis-

play them by touching LIST.

#You can also select a disc by pressing a/b

(TILT/DISC) on the remote control when the re-

mote control operation mode is switched to

DVD.

DVD Player

En 87

Section

DVD Player

Introduction of advanced

DVD player operation

1Function display

Shows the function names.

1 Touch AV MENU and then touch

FUNCTION to display the function names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Repeating play

!During playback of Video CDs featuring

PBC (playback control), this function can-

not be operated.

%Touch REPEAT on the function menu to

select the repeat range.

During DVD video playback

!DISC –Repeat the current disc

!CHAPTER –Repeat just the current chapter

!TITLE –Repeat just the current title

During Video CD or CD playback

!DISC –Repeat the current disc

!TRACK –Repeat just the current track

During MP3/WMA playback

!DISC –Repeat the current disc

!FOLDER –Repeat the current folder

!TRACK –Repeat just the current track

Notes

!If you select other discs during repeat play,

the repeat play range changes to DISC.

!During video CD or CD playback, if you per-

form track search or fast forward/reverse dur-

ing TRACK, the repeat play range changes to

DISC.

!During MP3/WMA playback, if you select an-

other folder during repeat play, the repeat play

range changes to DISC.

!During MP3/WMA playback, if you perform

track search or fast forward/reverse during

TRACK, the repeat play range changes to

FOLDER.

Playing tracks in random order

!You can operate this function during CD/

MP3/WMA playback.

%Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order.

#To turn random play off, touch RANDOM

again.

Scanning tracks of a CD/

MP3/WMA

!You can operate this function during CD/

MP3/WMA playback.

1 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track is played.

2 When you find the desired track touch

SCAN again.

DVD Player

Section

Selecting audio output

When playing DVD video discs recorded with

LPCM audio, or video CD discs, you can

switch the audio output.

!This function is not possible when disc

playback has been stopped.

%Touch L/R SELECT on the function menu

to select the audio output.

Touch L/R SELECT repeatedly until the desired

audio output appears in the display.

!L+R –left and right

!LEFT –left

!RIGHT –right

DVD Player

En 89

Section

DVD Player

Introduction to built-in DSP

features

Important

We recommend that you record the settings in

the sheet on page 135 after you have completed

audio adjustments.

DSP modes

This unit features two DSP modes: the net-

work mode and the standard mode. You can

switch between DSP modes as desired. Initi-

ally, the DSP mode is set to the standard

mode. (Refer to Switching the DSP setting

mode on page 117.)

!Auto TA and EQ can be used for the stan-

dard mode only. (Refer to Auto TA and EQ

(auto-time alignment and auto-equalizing)

on page 106 and Using the auto-equalizer

on page 105.)

!A 2-way front speaker output can be used

for the network mode only.

Note

Switching the DSP mode erases the current ad-

justing audio settings (LAST MEMORY). If

needed, memorize it into custom settings

(CUSTOM1,CUSTOM2 or CUSTOM3).

Output channel modes

(2CH/Multi CH)

This unit has two output channel modes for

each DSP mode: the 2-channel mode and the

multi-channel mode. You can switch between

output channel modes depending on the

source that you have selected.

!Dolby Pro Logic II/Dolby Digital EX and DTS

Neo:6 (Dolby/DTS) can be used for multi-

channel mode only.

!Graphic equalizer (GRAPHIC EQ) can be

used for 2-channel mode only.

!Parametric equalizer (PARAMETRIC EQ)

can be used for multi-channel mode only.

Note

When selecting 2-channel mode, audio does not

be output from front center and rear center

speakers.

Sound settings (SETTING1,

SETTING2 or SETTING3)

Created acoustic sound field can be stored in

this unit and called up easily. Additionally, this

unit stores the sound setting and output chan-

nel information for each source group. Chan-

ging the source switches sound setting and

output channel information for each source

group at the same time.

Three types of sound settings can be set and

stored for both 2-channel mode and multi-

channel mode independently. Moreover,

sound settings can be stored for both the net-

work mode and the standard mode. Therefore,

a total of 12 types of sound settings can be set

and stored.

!Auto TA and EQ can be performed only

when the standard mode is selected. Per-

forming Auto TA and EQ creates auto set-

tings (AUTO) which are adjusted finely for

both 2-channel mode and multi-channel

mode. However, AUTO cannot be custo-

mized.

Source groups

Each source stores both sound settings and

output channels information. When a DVD

player (built-in or optional) is selected as a

source, the each medium stores these settings

independently.

Media of DVD player are listed as follows:

!DVD audio

Audio Adjustments

Section

!DVD video

!Video CD

!CD (CD-DA)

!DTS-CD

!Compressed audio (MP3/WMA/AAC) files

!DivX video files

Notes

!XM tuner and SIRIUS tuner are set to the

same value automatically.

!External unit 1 and external unit 2 are set to

the same value automatically.

Custom settings (CUSTOM1,CUSTOM2

and CUSTOM3)

Following functions can store the settings in

the custom settings (CUSTOM1,CUSTOM2

and CUSTOM3). Custom settings are com-

mon to Sound settings (SETTING1,SETTING2

and SETTING3).

!Speaker setting (SPEAKER SETTING)

!Cut-off frequency setting (CUT OFF)

!Time alignment setting

(TIME ALIGNMENT)

!Speaker level setting (SPEAKER LEVEL)

!Parametric equalizer setting

(PARAMETRIC EQ) (when selecting multi-

channel mode only)

!Graphic equalizer setting (GRAPHIC EQ)

(when selecting 2-channel mode only)

Audio setup procedure

Standard mode

First, perform Auto TA and EQ. Auto TA and

EQ creates finely-tuned sound field for both 2-

channel mode and multi-channel mode ac-

cording to your vehicle interior acoustic char-

acteristics. (Refer to Auto TA and EQ (auto-time

alignment and auto-equalizing) on page 106.)

If AUTO TA and EQ has been completed,

sound setting is set to AUTO.

Basically, that’s all you need to do to adjust

the audio setting and no other fine tuning is

necessary.

However, according to your wishes, it is possi-

ble to customize audio settings based on Auto

TA and EQ settings. By carrying out the follow-

ing settings/adjustments in the order shown,

you can customize sound field effortlessly.

!Switching the sound settings

(SOUND SETTING)

!Customizing the speaker setting

(SPEAKER SETTING)

!Using the cut-off frequency (CUT OFF)

!Adjusting the time alignment

(TIME ALIGNMENT)

!Adjusting the speaker output levels

(SPEAKER LEVEL)

!Adjusting 3-band parametric equalizer

(PARAMETRIC EQ) (when selecting multi-

channel mode only)

!Adjusting 13-band graphic equalizer

(GRAPHIC EQ) (when selecting 2-channel

mode only)

Network mode

Make sure of the following settings before per-

forming finely audio adjustments.

Function Setting Page

Digital Direct OFF 93

PARAMETRIC EQ/

GRAPHIC EQ FLAT 98, 100

FADER/BALANCE FRONT 0/REAR 0/

LEFT 0/RIGHT 0 92

Dolby/DTS OFF 94

By carrying out the following settings/adjust-

ments in the order shown, you can create a fi-

nely-tuned sound field effortlessly.

!Switching the sound settings

(SOUND SETTING)

!Using the position selector (POSITION)

Audio Adjustments

En 91

Section

Audio Adjustments

!Customizing the speaker setting

(SPEAKER SETTING)

!Using the cut-off frequency (CUT OFF)

!Adjusting the time alignment

(TIME ALIGNMENT)

!Adjusting the speaker output levels

(SPEAKER LEVEL)

!Adjusting 3-band parametric equalizer

(PARAMETRIC EQ) (when selecting multi-

channel mode only)

!Adjusting 13-band graphic equalizer

(GRAPHIC EQ) (when selecting 2-channel

mode only)

Extra functions

These functions are helpful in adjusting the

sound to suit your system or your personal

preferences.

!Using balance adjustment

(FADER/BALANCE)

!Adjusting source levels

(SOURCE LEVEL ADJUSTER)

!Using the direct control (Digital Direct)

!Listening in surround sound (Dolby/DTS)

(when selecting multi-channel mode only)

!Using the dynamic range control

(DYNAMIC RANGE CONTROL)

!Using the down-mix function

(DOWN MIX)

Introduction of audio

adjustments

1Audio display

Shows the audio function names.

1 Touch AV MENU to display the audio

function names.

The audio function names are displayed and

operable ones are highlighted.

#When selecting the FM tuner as the source,

you cannot switch to SOURCE LEVEL ADJUSTER.

#When selecting 2-channel mode, you cannot

switch to Dolby/DTS.

2 Touch ESC to return to the display of

each source.

#To return to the previous display, touch

BACK.

Using balance adjustment

You can change the fader/balance setting so

that it can provide you an ideal listening envir-

onment in all occupied seats.

1 Touch FADER/BALANCE on the audio

function menu.

Audio Adjustments

Section

2 Touch or to adjust front/rear

speaker balance.

Each time you touch or it moves the

front/rear speaker balance towards the front or

the rear.

FRONT 25 to REAR 25 is displayed as the

front/rear speaker balance moves from front to

rear.

3 Touch or to adjust left/right speaker

balance.

Each time you touch or it moves the left/

right speaker balance towards the left or the

right.

LEFT 25 to RIGHT 25 is displayed as the left/

right speaker balance moves from left to

right.

Adjusting source levels

SLA (source level adjustment) lets you adjust

the volume level of each source to prevent ra-

dical changes in volume when switching be-

tween sources.

!Settings are based on the FM tuner volume

level, which remains unchanged.

1 Compare the FM tuner volume level

with the level of the source you wish to ad-

just.

2 Touch SOURCE LEVEL ADJUSTER on the

audio function menu.

3 Touch or to adjust the source vo-

lume.

Each time you touch or it increases or

decreases the source volume.

+14dB to –14dB is displayed as the source vo-

lume is increased or decreased.

Notes

!Video CD, CD, compressed audio (MP3/WMA/

AAC) and DivX are set to the same source

level adjustment volume automatically.

!DVD and the optional DVD player are set to

the same source level adjustment volume

automatically.

!XM tuner and SIRIUS tuner are set to the

same source level adjustment volume auto-

matically.

!External unit 1 and external unit 2 are set to

the same source level adjustment volume

automatically.

Using the direct control

You can override audio settings to check for ef-

fectiveness of your audio settings.

!All audio functions are locked out when the

direct control is on except VOLUME,

Dolby PL II/EX and DTS Neo:6.

%Touch Digital Direct on the audio func-

tion menu to turn the direct control on.

#To turn direct control off, touch Digital Direct

again.

Note

When selecting 2-channel mode, the following

occurs:

!If Digital Direct is turned on, output setting is

switched to MCH automatically.

If Digital Direct is turned off, output setting is

returned to 2CH automatically.

Audio Adjustments

En 93

Section

Audio Adjustments

Listening in surround sound

Using this unit, you can listen to any source in

surround sound. However, the options avail-

able will depend on your speaker setup and

the type of source you are listening to.

You can select Dolby PL II/EX or DTS Neo:6.

!When selecting 2CH (2-channel mode), you

cannot use this function. (Refer to Switch-

ing between the multi-channel output and

2-channel output on page 96.)

!If both the front center and the rear speak-

ers are set to OFF, you cannot use this

function.

Recalling surround sound settings

%Touch Dolby/DTS on the audio function

menu to select your favorite setting.

Touch Dolby/DTS repeatedly to switch be-

tween the following settings:

OFF (off)—Dolby PL II/EX (Dolby Pro Logic II/

Dolby Digital EX)—DTS Neo:6 (DTS Neo:6)

Using the Dolby Pro Logic II/

Dolby Digital EX

Dolby Pro Logic II creates five full-bandwidth

output channels from two-channel sources to

achieve high-purity matrix surround.

!If both the center and the rear speakers are

set to OFF, you cannot use this function.

!Dolby Pro Logic II supports up to 48kHz

sampling rate stereo source and has no ef-

fect on other types of source.

1 Touch Dolby/DTS on the audio function

menu to select Dolby PL II/EX.

Refer to Recalling surround sound settings on

this page.

2 Touch ADJ. next to Dolby/DTS.

3 Touch any of the following touch panel

keys to select the desired mode.

!MOVIE –The Movie mode suitable for

movie playback

!MUSIC –The Music mode suitable for

music playback

!MATRIX –The Matrix mode for when FM

radio reception is weak

#You can operate MUSIC ADJUSTMENT only

when MUSIC has been selected.

Adjusting the Music mode

You can adjust the Music mode with the fol-

lowing three controls.

!Panorama (PANORAMA) extends the front

stereo image to include the surround

speakers for an exciting “wraparound”ef-

fect.

!Dimension (DIMENSION) allows you to

gradually adjust the sound field either to-

wards the front or the rear.

!Center Width Control (CENTER WIDTH) al-

lows center-channel sounds to be posi-

tioned between the center speaker and the

left/right speakers. It improves the left-cen-

ter-right stage presentation for both the dri-

ver and the front passenger.

1 Touch MUSIC to adjust music mode.

Refer to Using the Dolby Pro Logic II/Dolby Digi-

tal EX on this page.

2 Touch PANORAMA to turn the Panora-

ma control on.

#To turn the Panorama control off, touch

PANORAMA again.

3 Touch or to adjust DIMENSION (di-

mension).

Each time you touch or it moves the

sound towards the front or the surrounds.

+3 to –3is displayed as the front/surround

speaker balance moves from front to sur-

rounds.

Audio Adjustments

Section

4 Touch or to adjust CENTER WIDTH

(center width control).

Each time you touch or it gradually

spreads the center channel sound into the

front left and right speakers over a range 0to

3is the default and it’s recommended for

most recordings. 0places all center sound in

the center speaker. 7places all center sound

equally in the left/right speakers.

Using the DTS Neo:6

DTS Neo:6 can generate 6.1 channel surround

sound from any matrixed stereo source (such

as video or TV) and from 5.1 channel sources.

1 Touch Dolby/DTS on the audio function

menu to select DTS Neo:6.

Refer to Recalling surround sound settings on

the previous page.

2 Touch ADJ. next to Dolby/DTS.

3 Touch either of the following touch

panel keys to select the desired mode.

!CINEMA –The Cinema mode suitable for

movie playback

!MUSIC –The Music mode suitable for

music playback

#You can operate MUSIC ADJUSTMENT only

when MUSIC has been selected.

#With the DTS Neo:6, audio and voice from TV

or radio may be breaking up. In such case, we re-

commend you to turn the DTS Neo:6 off.

Adjusting the Music mode

In music mode, you can adjust the center

image to create a wider stereo effect with vo-

cals. Adjust the effect from 0(all center chan-

nel sent to front right and left speakers) to 10

(center channel sent to the center speaker

only).

1 Touch MUSIC to adjust music mode.

Refer to Using the DTS Neo:6 on this page.

2 Touch or to adjust CENTER IMAGE

(center image).

Each time you touch or it gradually

spreads the center channel sound into the

front left and right speakers over a range 10 to

Using the dynamic range

control

The dynamic range refers to the difference be-

tween the largest and softest sounds. The dy-

namic range control compresses this

difference so that you can clearly hear sounds

even at low volume levels.

!The dynamic range control is effective only

on Dolby Digital sounds.

!The dynamic range control may produce lit-

tle effect on certain discs.

%Touch DYNAMIC RANGE CONTROL on

the audio function menu to turn the dy-

namic range control on.

#To turn dynamic range control off, touch

DYNAMIC RANGE CONTROL again.

Using the down-mix function

The down-mix function allows you to play back

multi-channel audio in 2 channels.

%Touch DOWN MIX on the audio func-

tion menu to switch the setting.

!Lt/Rt –Down mix so that the surround

components can be restored (decoded).

!Lo/Ro –Stereo mix the original audio that

do not contain channel modes such as sur-

round components.

Audio Adjustments

En 95

Section

Audio Adjustments

Switching the sound settings

You can switch the acoustic sound field stored

in this unit according to the source you are lis-

tening to. For detailed instructions on creating

the acoustic sound field, refer to Introduction

of sound settings on the next page.

%Touch SOUND SETTING on the audio

function menu to switch the sound setting.

Touch SOUND SETTING repeatedly to switch

between the following settings:

SETTING1 (user setting 1)—SETTING2 (user

setting 2)—SETTING3 (user setting 3)—AUTO

(setting created by auto TA & EQ)

#You can also switch the sound setting by

pressing SOUND SETTING.

#You cannot select AUTO when NETWORK

has been selected. (Refer to Switching the DSP

setting mode on page 117.)

#When STANDARD has been selected, you

cannot select AUTO if Auto TA and EQ has not

been carried out.

Switching between the

multi-channel output and

2-channel output

You can switch the output channel between

the multi-channel output and 2-channel out-

put according to the source you are listening

to.

!Selecting 2CH changes the audio settings

as below:

—Both the front center and rear center

speakers are turned off automatically in

the speaker setting. (Refer to page 101.)

—Both Dolby Pro Logic II/Dolby Digital EX

and DTS Neo:6 switch to OFF. (Refer to

page 94.)

%Touch 2CH/Multi CH on the audio func-

tion menu to switch the mode.

Touch 2CH/Multi CH repeatedly until the de-

sired mode appears in the display.

!MCH –Multi-channel audio output

!2CH –2-channel audio output (stereo)

#You can also switch the output setting by

pressing 2ch/MULTI-CH.

Audio Adjustments

Section

Introduction of sound settings

1Sound setting display

Shows the sound setting function names.

1 Touch AV MENU to display the audio

function names.

The audio function names are displayed and

operable ones are highlighted.

2 Touch ADJ. next to SOUND SETTING to

display the sound setting function names.

The sound setting function names are dis-

played.

#AUTO cannot be customized. When AUTO is

selected, select the other sound settings by

touching SOUND SETTING.

3 Touch any of SETTING1, SETTING2 or

SETTING3 to select the sound setting to be

adjusted.

4 Touch ESC to return to the display of

each source.

#To return to the previous display, touch BACK.

Sound setting function display

Touching the sound setting selection keys en-

ables you to cross-refer the other adjustments.

Even in the adjustment screen, it is possible to

refer and set another setting menus.

1Sound setting selection keys

Touch to recall the desired sound setting

function.

2Sound setting function display

Shows the adjustment screen of the se-

lected sound setting function.

Using the position selector

One way to assure a more natural sound is to

accurately position the stereo image, putting

you right in the center of the sound field. The

position selector function lets you automati-

cally adjust the speaker output levels and in-

serts a delay time to match the number and

position of occupied seats.

1 Touch POSITION on the sound setting

menu.

2 Touch any of the following touch panel

keys to select a listening position.

!FRONT LEFT –Front seat left

!FRONT RIGHT –Front seat right

!FRONT –Front seats

!ALL –All seats

Audio Adjustments

En 97

Section

Audio Adjustments

#To cancel the selected listening position,

touch OFF.

Note

When you make adjustments to the listening po-

sition, the speaker outputs are automatically set

for appropriate levels. You can tailor the levels

more precisely referring to Adjusting the speaker

output levels on page 104.

Recalling equalizer curves

The equalizer lets you adjust the equalization

to match car interior acoustic characteristics

as desired.

There are eight stored equalizer curves which

you can easily recall at any time. Here is a list

of the equalizer curves:

Display Equalizer curve

SUPER BASS (S. BASS) Super bass

POWERFUL Powerful

NATURAL Natural

VOCAL Vocal

FLAT Flat

CUSTOM1 Custom 1

CUSTOM2 Custom 2

CUSTOM3 Custom 3

!CUSTOM1,CUSTOM2 and CUSTOM3 are

adjusted equalizer curves.

!When FLAT is selected no supplement or

correction is made to the sound. This is

useful to check the effect of the equalizer

curves by switching alternatively between

FLAT and a set equalizer curve.

When selecting multi-channel

mode

%Touch PARAMETRIC EQ on the sound

setting menu to select the equalizer.

Touch PARAMETRIC EQ repeatedly to switch

between the following equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—CUSTOM3—

LAST MEMORY—SUPER BASS (S. BASS)

#You can select LAST MEMORY only when the

adjusted equalizer curve is not memorized in this

unit.

When selecting 2-channel mode

%Touch GRAPHIC EQ on the sound set-

ting menu to select the equalizer.

Touch GRAPHIC EQ repeatedly to switch be-

tween the following equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—CUSTOM3—

LAST MEMORY—SUPER BASS (S. BASS)

#You can select LAST MEMORY only when the

adjusted equalizer curve is not memorized in this

unit.

Adjusting 3-band

parametric equalizer

For custom equalizer curves (CUSTOM1 to

CUSTOM3), you can adjust the front, rear,

front center and rear center equalizer curves

separately by selecting a center frequency, an

equalizer level, and a Q factor for each band.

!Custom equalizer curves can be created

common to all sources.

Audio Adjustments

Section

!The center speaker largely determines the

sound image and getting the balance right

isn’t easy. We recommend reproducing a 2-

ch. audio (a CD for example) and getting

the balance right among the speakers ex-

cept for the center, and then reproducing a

5.1-ch. audio (Dolby Digital or DTS) and ad-

justing the center speaker output to the

balance you have already got among the

other speakers.

1 Touch ADJ. next to PARAMETRIC EQ on

the sound setting menu.

2 Touch LR Common/LR Independent to

switch the equalizer adjustment method.

!LR Common –Adjusts left and right speak-

ers simultaneously.

!LR Independent –Adjusts left and right

speakers separately.

3 Touch EQ to select the equalizer.

Touch EQ repeatedly to switch between the fol-

lowing equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—CUSTOM3—

LAST MEMORY—SUPER BASS (S. BASS)

#You can also select the equalizer by using

EQUALIZER LIST.

#To close the equalizer curve list, touch CLOSE.

#You can select LAST MEMORY only when the

adjusted equalizer curve is not memorized in this

unit.

4 Touch or next to SPEAKER to select

the speaker to be adjusted.

Touch or until the desired speaker appears

in the display.

FRONT LEFT (front left speaker)—

FRONT RIGHT (front right speaker)—

REAR LEFT (rear left speaker)—REAR RIGHT

(rear right speaker)—FRONT CENTER (front

center speaker)—REAR CENTER (rear center

speaker)

#You can mute the selected speaker unit by

touching . To cancel muting, touch .

#You cannot select speakers whose size is set

at OFF.

5 Touch BAND to select the equalizer

band to be adjusted.

Each time you touch BAND it selects equalizer

bands in the following order:

LOW (low)—MID (mid)—HIGH (high)

6 Touch or to select the center fre-

quency of selected band.

Touch or until the desired frequency ap-

pears in the display.

40—50—63—80—100—125—160—200—

250—315—400—500—630—800—1k—

1.25k—1.6k—2k—2.5k—3.15k—4k—5k—

6.3k—8k—10k—12.5k (Hz)

#You can select a center frequency from

among 20 frequencies for each band. You can

change the center frequency in 1/3-octave steps,

but you cannot select frequencies that have inter-

vals shorter than 1 octave among the center fre-

quencies of the three bands.

7 Touch or to adjust the equalizer

level.

Each time you touch or it increases or

decreases the equalizer level. +12dB to –12dB

is displayed as the level is increased or de-

creased.

#When you adjust the speaker loudness with

selecting LR Common, the equalizer levels of

both side speakers are changed simultaneously.

Thus, if the equalizer level of one speaker is at

maximum or minimum, the level of the other

speaker is at full limit in opposite direction.

8 Touch Q.Fac to select the desired Q fac-

tor.

Each time you touch Q.Fac it switches be-

tween the following Q factor:

1.2 (wide)—3.6 (narrow)

Audio Adjustments

En 99

Section

Audio Adjustments

#You can adjust parameters for each band of

the other speakers in the same way.

Note

You can store the adjusted setting in memory by

using MEMORY. For details concerning opera-

tion, refer to Storing the adjusted audio settings in

memory on page 106.

Adjusting 13-band graphic

equalizer

For custom equalizer curves (CUSTOM1 to

CUSTOM3), you can adjust the level of each

band.

!Custom equalizer curves can be created

common to all sources.

1 Touch ADJ. next to GRAPHIC EQ on the

sound setting menu.

2 Touch LR Common/LR Independent to

switch the equalizer adjustment method.

!LR Common –Adjusts left and right speak-

ers simultaneously.

!LR Independent –Adjusts left and right

speakers separately.

3 Touch EQ to select the equalizer.

Touch EQ repeatedly to switch between the fol-

lowing equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—CUSTOM3—

LAST MEMORY—SUPER BASS (S. BASS)

#You can also select the equalizer by using

EQUALIZER LIST.

#To close the equalizer curve list, touch CLOSE.

#You can select LAST MEMORY only when the

adjusted equalizer curve is not memorized in this

unit.

4 Touch or next to SPEAKER to select

the speaker to be adjusted.

Touch or until the desired speaker appears

in the display.

LEFT (left speakers)—RIGHT (right speakers)

#You can mute the selected speaker units by

touching . To cancel muting, touch .

5 Touch or to select the equalizer

band to be adjusted.

Touch or until the desired equalizer band

appears in the display.

50—80—125—200—315—500—800—1.25k

—2k—3.15k—5k—8k—12.5k (Hz)

6 Touch or to adjust the level of the

equalizer band.

Each time you touch or it increases or

decreases the level of the equalization band.

+12dB to –12dB is displayed as the level is in-

creased or decreased.

#When you adjust the speaker loudness with

selecting LR Common, the equalizer levels of

both side speakers are changed simultaneously.

Thus, if the equalizer level of one speaker is at

maximum or minimum, the level of the other

speaker is at full limit in opposite direction.

#You can then select another band and adjust

the level.

Note

You can store the adjusted setting in memory by

using MEMORY. For details concerning opera-

tion, refer to Storing the adjusted audio settings in

memory on page 106.

Audio Adjustments

100

Section

Setting the speaker setting

You can make a fine adjustment on each

speaker installed in your vehicle. You can

change the size of each speaker according to

the speaker specification. On a spot at which

a speaker is not installed, you can set the ad-

justment to OFF.

The adjustment you made will be memorized

into this unit and you can recall it.

Recalling speaker settings

%Touch SPEAKER SETTING on the sound

setting menu to select the speaker setting.

Touch SPEAKER SETTING repeatedly to switch

between the following speaker settings:

CUSTOM1—CUSTOM2—CUSTOM3—AUTO

—LAST MEMORY

#You can select LAST MEMORY only when the

adjusted speaker setting is not memorized in this

unit.

#You cannot select AUTO when NETWORK

has been selected. (Refer to Switching the DSP

setting mode on page 117.)

#When STANDARD has been selected, you

cannot select AUTO if auto TA and EQ has not

been carried out.

Customizing the speaker setting

You need to make with/without (or yes/no) and

size (bass reproducing capacity) selection/ad-

justments depending on the installed speak-

ers. The size needs to be set to LARGE (large)

if the speaker is capable of reproducing

sounds of about 100 Hz or below. Otherwise

select SMALL (small).

!Low frequency range is not output if the

subwoofer is set to OFF and the front and

rear speakers set to SMALL or OFF.

!It is imperative that non-installed speakers

be set to OFF.

!Set the front or rear speaker to LARGE if

the speaker is capable of reproducing bass

content, or if no subwoofer is installed.

1 Recall the speaker setting you want to

adjust.

Refer to Recalling speaker settings on this

page.

2 Touch ADJ. next to SPEAKER SETTING

on the sound setting menu.

3 Touch or to select the correct size

for the speaker.

Each time you touch or it selects the size

in the following order:

OFF (off)—SMALL (small)—LARGE (large)

#You cannot select OFF in the front speaker set-

ting.

#You can turn ON or OFF in the subwoofer set-

ting.

#When the rear speaker setting is set to OFF,

the rear center speaker switches to OFF automati-

cally.

Note

You can store the adjusted setting in memory by

using MEMORY. For details concerning opera-

tion, refer to Storing the adjusted audio settings in

memory on page 106.

Using the cut-off frequency

You can adjust the cut-off frequency and slope

to match the characteristics of each speaker

unit. And then you can store the adjusted cut-

off frequency in this unit for later recall.

Audio Adjustments

En 101

Section

Audio Adjustments

Recalling cut-off frequency

settings

%Touch CUT OFF on the sound setting

menu to select the cut-off frequency set-

ting.

Touch CUT OFF repeatedly to switch between

the following cut-off frequency settings:

CUSTOM1—CUSTOM2—CUSTOM3—AUTO

—LAST MEMORY

#You can select LAST MEMORY only when the

adjusted cut-off frequency setting is not memor-

ized in this unit.

#You cannot select AUTO when NETWORK

has been selected. (Refer to Switching the DSP

setting mode on page 117.)

#When STANDARD has been selected, you

cannot select AUTO if auto TA and EQ has not

been carried out.

Selecting a cut-off frequency

You can select a frequency, under which

sounds are reproduced through the subwoo-

fer. If the installed speakers include one whose

size has been set to SMALL, you can select a

frequency, under which sounds are repro-

duced through a LARGE speaker or subwoo-

fer.

1 Recall the cut-off frequency setting you

want to adjust.

Refer to Recalling cut-off frequency settings on

this page.

2 Touch ADJ. next to CUT OFF on the

sound setting menu.

3 Touch the speaker to be adjusted.

#You cannot select speakers whose size is set

at OFF or LARGE.

4 Touch or to adjust parameters of

the selected speaker unit (filter).

Adjustable parameters and ranges are differ-

ent depending on each speaker unit (filter).

Parameter What it does

FREQUENCY

Selects cut-off frequencies in the fol-

lowing order:

50—63—80—100—125—160—

200 (Hz)

SLOPE Selects slopes in the following order:

–18—–12—–6(dB/oct.)

When subwoofer is selected

Parameter What it does

FREQUENCY

Selects cut-off frequencies in the fol-

lowing order:

50—63—80—100—125—160—

200 (Hz)

SLOPE Selects slopes in the following order:

–18—–12—–6—0(pass) (dB/oct.)

PHASE Switches the phase between NOR-

MAL and REVERSE.

When tweeter is selected in the network

mode

Parameter What it does

FREQUENCY

Selects cut-off frequencies in the fol-

lowing order:

1.25k—1.6k—2k—2.5k—3.15k—

4k—5k—6.3k—8k—10k—12.5k

(Hz)

SLOPE Selects slopes in the following order:

–12—–6(dB/oct.)

Audio Adjustments

102

Section

When front speaker HPF is selected in the

network mode

Parameter What it does

FREQUENCY

Selects cut-off frequencies in the fol-

lowing order:

50—63—80—100—125—160—

200 (Hz)

SLOPE Selects slopes in the following order:

–18—–12—–6(dB/oct.)

To switch the filter of the front speaker between LPF and

HPF, touch HIGH PASS or LOW PASS.

When front speaker LPF is selected in the

network mode

Parameter What it does

FREQUENCY

Selects cut-off frequencies in the fol-

lowing order:

1.25k—1.6k—2k—2.5k—3.15k—

4k—5k—6.3k—8k—10k—12.5k

(Hz)

SLOPE Selects slopes in the following order:

–12—–6—0(pass) (dB/oct.)

#You can mute the selected speaker unit by

touching MUTE OFF. To cancel muting, touch

MUTE ON.

Notes

!Selecting cut-off frequencies sets cut-off fre-

quencies of the subwoofer’s L.P.F. (low-pass

filter) and that of the SMALL speaker H.P.F.

(high-pass filter). The cut-off frequency setting

has no effect if the subwoofer is set to OFF

and other speakers are set to LARGE or OFF.

!If trying to boost the bass output of the sub-

woofer doesn’t do much or rather makes you

feel that the bass gets more murky, this may

indicate that the subwoofer’s output and bass

content you hear over other speakers cancel

each other out. To remove this problem, try

changing the phase setting for the subwoofer.

!You can store the adjusted setting in memory

by using MEMORY. For details concerning op-

eration, refer to Storing the adjusted audio set-

tings in memory on page 106.

Using the time alignment

The time alignment lets you adjust the dis-

tance between each speaker and the listening

position.

Recalling time alignment settings

%Touch TIME ALIGNMENT on the sound

setting menu to select the time alignment.

Touch TIME ALIGNMENT repeatedly to switch

between the following time alignment set-

tings:

INITIAL—AUTO—CUSTOM1—CUSTOM2—

CUSTOM3—LAST MEMORY—OFF

#You can select LAST MEMORY only when the

adjusted time alignment setting is not memorized

in this unit.

#You cannot select AUTO when NETWORK

has been selected. (Refer to Switching the DSP

setting mode on page 117.)

#When STANDARD has been selected, you

cannot select AUTO if auto TA and EQ has not

been carried out.

Adjusting the time alignment

You can adjust the distance between each

speaker and the selected position.

!An adjusted time alignment can be memor-

ized in CUSTOM1,CUSTOM2 or

CUSTOM3.

1 Recall the time alignment setting you

want to adjust.

Refer to Recalling time alignment settings on

this page.

Audio Adjustments

En 103

Section

Audio Adjustments

2 Touch ADJ. next to TIME ALIGNMENT

on the sound setting menu.

#You cannot adjust the time alignment when

neither FRONT LEFT nor FRONT RIGHT is se-

lected in the position selector mode.

3 Touch or to adjust the distance be-

tween each speaker and the listening posi-

tion.

Each time you touch or it increases or de-

creases the distance. 0inch to 200inch is dis-

played as the distance is increased or

decreased.

#You can mute the selected speaker unit by

touching MUTE. To cancel muting, touch MUTE

again.

#You cannot select speakers whose size is set

at OFF.

Note

You can store the adjusted setting in memory by

using MEMORY. For details concerning opera-

tion, refer to Storing the adjusted audio settings in

memory on page 106.

Adjusting the speaker

output levels

You can adjust the speaker output level of

each speaker unit.

Recalling the speaker output

level settings

%Touch SPEAKER LEVEL on the sound

setting menu to select the speaker output

level setting.

Touch SPEAKER LEVEL repeatedly to switch

between the following speaker output level set-

tings:

CUSTOM1—CUSTOM2—CUSTOM3—AUTO

—LAST MEMORY

#You can select LAST MEMORY only when the

adjusted speaker output level setting is not mem-

orized in this unit.

#You cannot select AUTO when NETWORK

has been selected. (Refer to Switching the DSP

setting mode on page 117.)

#When STANDARD has been selected, you

cannot select AUTO if auto TA and EQ has not

been carried out.

Adjusting the speaker output

levels using a test tone

This function allows you to easily get the over-

all balance right among the speakers.

1 Recall the speaker output level settings

you want to adjust.

Refer to Recalling the speaker output level set-

tings on this page.

2 Touch ADJ. next to SPEAKER LEVEL on

the sound setting menu and then touch

TEST TONE.

The test tone is outputted. It rotates from

speaker to speaker in the following sequence

at intervals of about two seconds. The current

settings for the speaker over which you hear

the test tone are shown in the display.

Front left speaker—Front center speaker—

Front right speaker—Rear right speaker—Rear

center speaker—Rear left speaker—Subwoo-

fer

Check each speaker output level. If no adjust-

ments are needed, perform step 4 to stop the

test tone.

#Using TEST TONE, the tweeters and the front

speakers are adjusted same time. To adjust them

separately, please refer to Adjusting the speaker

output levels finely on the next page.

#The settings do not appear for speakers

whose size is set OFF.

Audio Adjustments

104

Section

3 Touch or to adjust the speaker out-

put level.

Each time you touch or it increases or de-

creases the speaker output level. –24dB to

+10dB is displayed as the level is increased or

decreased.

#The test tone rotates to the next speaker after

about two seconds from the last operation.

4 Touch STOP to stop the test tone out-

put.

Notes

!If needed, select speakers and adjust their ‘ab-

solute’output levels. (Refer to Adjusting the

speaker output levels on the previous page.)

!You can store the adjusted setting in memory

by using MEMORY. For details concerning op-

eration, refer to Storing the adjusted audio set-

tings in memory on the next page.

!The adjusted speaker output level cannot be

stored by each listening position. This means,

memorizing a speaker output level for custom

setting overwrites the levels of all listening po-

sitions.

Adjusting the speaker output

levels finely

You can readjust the speaker output levels

using a test tone while listening to music.

1 Recall the speaker output level settings

you want to adjust.

Refer to Recalling the speaker output level set-

tings on the previous page.

2 Touch ADJ. next to SPEAKER LEVEL.

3 Touch or to adjust the speaker out-

put level.

Each time you touch or it increases or de-

creases the speaker output level. –24dB to

+10dB is displayed as the level is increased or

decreased.

#You cannot select speakers whose size is set

at OFF.

Notes

!You can store the adjusted setting in memory

by using MEMORY. For details concerning op-

eration, refer to Storing the adjusted audio set-

tings in memory on the next page.

!The adjusted speaker output level cannot be

stored by each listening position. This means,

memorizing a speaker output level for custom

setting overwrites the levels of all listening

positions.

Using the auto-equalizer

You can use this function only when

STANDARD has been selected. (Refer to

Switching the DSP setting mode on page 117.)

The auto-equalizer is the equalizer curve cre-

ated by auto TA and EQ (refer to Auto TA and

EQ (auto-time alignment and auto-equalizing)

on the next page).

You can turn the auto-equalizer on or off.

1 Touch AUTO EQ on the sound setting

menu.

#You cannot use this function if auto TA and

EQ has not been carried out.

2 Touch ON to turn the auto-equalizer

on.

#To turn auto-equalizer off, touch OFF.

Audio Adjustments

En 105

Section

Audio Adjustments

Storing the adjusted audio

settings in memory

You can store the adjusted audio settings in

this unit for later recall.

1 Touch MEMORY.

2 Touch any of CUSTOM1, CUSTOM2 or

CUSTOM3 to store the adjusted setting.

3 Touch YES to store the current setting

into the selected sound setting.

#To cancel the storage process, touch

CANCEL.

Editing the name of sound

settings

The name displayed for sound settings

(SETTING1,SETTING2 and SETTING3) can be

changed.

!Each name can be up to 10 characters

long.

1 Touch any of SETTING1, SETTING2 or

SETTING3 on the sound setting menu.

2 Touch NAME EDIT.

3 Touch the letter you wish to input.

Key What it does

Moves the cursor to the previous charac-

ter position.

Moves the cursor to the next character po-

sition.

Inputs the space.

ABC/123 Switches keypad between alphabet and

numeric.

Deletes letter by letter from the end of the

text.

4 Touch MEMORY to store the entered

name in memory.

Auto TA and EQ (auto-time

alignment and auto-

equalizing)

You can use this function only when

STANDARD has been selected. (Refer to

Switching the DSP setting mode on page 117.)

The auto-time alignment is automatically ad-

justed for the distance between each speaker

and the listening position.

The auto-equalizer automatically measures

the car interior acoustic characteristics, and

then creates the auto-equalizer curve based

on that information.

WARNING

To prevent accidents, never carry out auto TA and

EQ while driving. When this function measures

the car interior acoustic characteristics to create

an auto-equalizer curve, a loud measurement

tone (noise) may be outputted from the speakers.

CAUTION

!Carrying out auto TA and EQ under the follow-

ing conditions may damage the speakers. Be

sure to check the conditions thoroughly be-

fore carrying out auto TA and EQ.

—When speakers are incorrectly connected.

(e.g., When a rear speaker is connected to

a subwoofer output.)

—When a speaker is connected to a power

amp delivering output higher than the

speaker’s maximum input power capabil-

ity.

!If the microphone is placed in an unsuitable

position the measurement tone may become

loud and measurement may take a long time,

resulting in a drain on battery power. Be sure

to place the microphone in the specified loca-

tion.

Audio Adjustments

106

Section

Before operating the auto TA

and EQ function

!Carry out auto TA and EQ in as quiet a

place as possible, with the car engine and

air conditioning switched off. Also cut

power to car phones or portable telephones

in the car, or remove them from the car be-

fore carrying out auto TA and EQ. Sounds

other than the measurement tone (sur-

rounding sounds, engine sound, tele-

phones ringing etc.) may prevent correct

measurement of the car interior acoustic

characteristics.

!Be sure to carry out auto TA and EQ using

the supplied microphone. Using another

microphone may prevent measurement, or

result in incorrect measurement of the car

interior acoustic characteristics.

!When front speaker is not connected, auto

TA and EQ cannot be carried out.

!If a speaker size is set to OFF, audio does

not output from the speaker even when the

speaker is installed.

!When this unit is connected to a power

amp with input level control, auto TA and

EQ may not be possible if you lower power

amp input level. Set the power amp’s input

level to the standard position.

!When this unit is connected to a power

amp with an LPF, turn off the LPF on the

power amp before carrying out auto TA and

EQ. In addition, the cut-off frequency for

built-in LPF of an active subwoofer should

be set to the highest frequency.

!The time alignment value calculated by

auto TA and EQ may differ from the actual

distance in the following circumstances.

However, the distance has been calculated

by computer to be the optimum delay to

give accurate results for the circum-

stances, so please continue to use this

value.

—When the reflected sound within a vehi-

cle is strong and delays occur.

—When delays occur for low sounds due

to the influence of the LPF on active

subwoofers or external amps.

!Auto TA and EQ changes the fader/balance

settings to the center position. (Refer to

page 92.)

!If you carry out auto TA and EQ when a pre-

vious setting of this already exists, the set-

ting will be replaced.

!Even if auto TA and EQ is carried out,

sound settings (SETTING1 to SETTING3)

and custom settings (CUSTOM1 to

CUSTOM3) are retained in the memory.

Carrying out auto TA and EQ

1 Stop the car in a place that is as quiet

as possible, close all doors, windows and

the sun roof, and then turn the engine off.

If the engine is left running, engine noise may

prevent correct auto TA and EQ.

2 Fix the supplied microphone in the cen-

ter of the headrest of the driver’s seat, fa-

cing forward, using the belt (sold

separately).

The auto TA and EQ may differ depending on

where you place the microphone. If desired,

place the microphone on the front passenger

seat to carry out auto TA and EQ.

Audio Adjustments

En 107

Section

Audio Adjustments

3 Turn the ignition switch to ON or ACC.

If the car’s air conditioner or heater is turned

on, turn it off. Noise from the fan in the air

conditioner or heater may prevent correct auto

TA and EQ.

4 Press SOURCE to turn the source off if

this unit is turned on.

5 Touch the screen to display the touch

panel keys.

6 Touch AV MENU and then touch

AUTO EQ&TA to enter the auto TA and EQ

measurement mode.

7 Touch either of the following touch

panel keys to select the position for the

seat on which the microphone is placed.

!FRONT LEFT –Front seat left

!FRONT RIGHT –Front seat right

8 Touch NEXT.

9 Plug the AUTO TA&EQ microphone into

the microphone/auxiliary input jack on this

unit.

AUTO TA&EQ microphone

10 Touch START to start the auto TA and

EQ.

11 Get out of the car and close the door

within 10 seconds when the 10-second

count-down starts.

The measurement tone (noise) is outputted

from the speakers, and auto TA and EQ be-

gins.

#When all speakers are connected, auto TA

and EQ is completed in about nine minutes.

#To stop auto TA and EQ, touch STOP.

#To cancel auto TA and EQ part way through,

touch BACK or ESC.

12 When auto TA and EQ is completed,

Complete is displayed.

When correct measurement of car interior

acoustic characteristics is not possible, an

error message is displayed. (Refer to Under-

standing auto TA and EQ error messages on

page 127.)

13 Touch ESC to cancel the auto TA and EQ

mode.

14 Store the microphone carefully in the

glove compartment.

Store the microphone carefully in the glove

compartment or any other safe place. If the

microphone is subjected to direct sunlight for

an extended period, high temperatures may

cause distortion, color change or mal-

function.

Audio Adjustments

108

Section

Introduction of setup

adjustments

1Setup menu display

Shows the setup function names.

1 Touch AV MENU and then touch SETUP

to display the setup function names.

The setup function names are displayed and

operable ones are highlighted.

2 Touch ESC to return to the display of

each source.

#To return to the previous display, touch

BACK.

Setting the AV input

You can switch the setting according to the

connected component.

!Select VIDEO to watch video of a con-

nected component as AV source.

!Select S-DVD to watch video of a con-

nected DVD player as S-DVD source.

%Touch AV INPUT on the setup menu to

select the AV input setting.

Touch AV INPUT until the desired setting is se-

lected.

!OFF –No video component is connected

!VIDEO –External video component (such

as portable video player)

!S-DVD –DVD player connected with RCA

cable

#When a DVD player is connected with an AV-

BUS cable, do not select S-DVD otherwise no pic-

ture will be displayed even if you select S-DVD as

a source.

About AV input

Depending on the unit connected to this unit,

video image may be distorted. In this case,

switch the video image selecting switch on

the underneath of the hide-away unit to the ap-

propriate position to eliminate distortion. Use

a thin standard tip screwdriver to switch the

video image selecting switch on the under-

neath of the hide-away unit.

Setting for rear view

camera (back up camera)

CAUTION

Pioneer recommends the use of a camera

which outputs mirror reversed images, other-

wise screen image may appear reversed.

Setup

En 109

Section

Setup

This unit features a function that automatically

switches to the rear view camera video (BACK

UP CAMERA IN jack) when a rear view cam-

era is installed on your vehicle. When the gear

shift is in REVERSE (R) position, the video

automatically switches to a rear view camera

video. (For more details, consult your dealer.)

!After you set up the rear view camera set-

ting, move the gear shift in REVERSE (R)

and confirm if a rear view camera video

can be shown on the display.

!If the display should be switched to a rear

view camera video by error while you are

driving forward, change the rear view cam-

era setting.

!To end watching a rear view camera video

and return to the source display, press and

hold V.ADJUST.

1 Touch BACK UP CAMERA IN on the

setup menu to turn rear view camera set-

ting on.

#To turn rear view camera setting off, touch

BACK UP CAMERA IN again.

2 Touch B. CAMERA POLARITY on the

setup menu to select an appropriate set-

ting for polarity.

Each time you touch B. CAMERA POLARITY it

switches between the following polarity:

!BATTERY –When the polarity of the con-

nected lead is positive while the gear shift

is in REVERSE (R) position

!GROUND –When the polarity of the con-

nected lead is negative while the gear shift

is in REVERSE (R) position

Setting the automatic open

function

To prevent the display from hitting the shift

lever of an automatic vehicle when it is in P

(park) position, or when you do not wish the

display to open/close automatically, you can

set the automatic open function in the manual

mode.

%Touch AUTO FLAP on the setup menu

to select the display to open/close automa-

tically or manually.

Each time you touch AUTO FLAP it switches

between the following settings:

!AUTO –The LCD panel will be opened or

closed automatically with the turning of the

ignition switch on or off

!MANUAL –You have to press

OPEN/CLOSE to open/close the LCD

panel

Adjusting the LCD panel

slide position

You can adjust the LCD panel slide position so

that the panel is set back or forward.

%Touch FLAP SET BACK on the setup

menu to turn the set back on.

The LCD panel slides to the back.

#Touch FLAP SET BACK again to turn the set

back off and the LCD panel slides to the front.

Setting the clock

Use these instructions to set the clock.

1 Touch CLOCK ADJUSTMENT on the

setup menu.

2 Touch 0—9 to set the clock.

#To cancel the inputted numbers, touch C.

3 Touch ENTER.

Setup

110

Section

Note

Touching 24h/12h switches the clock display on

the sub-display between 12/24-hour formats.

Setting the video of rear

display

You can select either showing the same

source as the front display or showing the

video source on rear display independently.

!When selecting FRONT and the selected

source is an audio source, nothing is dis-

played on the rear display.

!When selecting FRONT, audio is not out-

putted from REAR DISPLAY OUT.

%Touch REAR MODE on the setup menu

to select the video on rear display.

Each time you touch REAR MODE it switches

between the following settings:

!FRONT –Display the same source as the

front display

!SEPARATE –Display the video source on

rear display independently of front dis-

play

Switching the dimmer

setting for sub-display

To prevent the sub-display from being too

bright at night, the sub-display is automati-

cally dimmed when the car’s headlights are

turned on. You can turn dimmer on or off.

%Touch SUB DISPLAY DIMMER on the

setup menu to turn dimmer on.

#To turn dimmer off, touch

SUB DISPLAY DIMMER again.

Adjusting the contrast for

the sub-display

Display contrast adjustment lets you adjust

the display for easier viewing when lighting

conditions change.

%Touch SUB DISPLAY CONTRAST on the

setup menu to switch the contrast setting.

Each time you touch

SUB DISPLAY CONTRAST it switches between

HIGH (high contrast) and LOW (low contras-

t).

Changing languages for

CAUTION

Some operations on this unit are prohibited

while driving or needs to be paid a careful at-

tention when operating. In such case, a cau-

tion appears on the display. You can change

the language of the cautions at this setting.

1 Touch CAUTION LANGUAGE on the

setup menu.

2 Touch the desired language.

The language for CAUTION is set.

Setup

En 111

Section

Setup

Introduction of DVD setup

adjustments

You can use this menu to change audio, subti-

tle, parental lock and other DVD settings.

!When watching a DVD/Video CD on the

rear display independently, you cannot op-

erate this menu.

1DVD setup menu display

Shows the DVD setup menu names.

1 While playing a disc, touch AV MENU

and then touch DVD SETUP to display the

DVD setup function names.

The DVD setup function names are displayed

and operable ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch

BACK.

Setting the subtitle language

You can set a desired subtitle language. If the

selected subtitle language is recorded on the

DVD, subtitles are displayed in that language.

1 Touch SUB TITLE LANGUAGE on the

DVD setup menu.

A subtitle language menu is displayed.

2 Touch the desired language.

A subtitle language is set.

#If you have selected Others, refer to When you

select Others on this page.

Notes

!If the selected language is not recorded on

the disc, the language specified on the disc is

displayed.

!You can also switch the subtitle language by

touching SUBTITLE during playback. (Refer to

Changing the subtitle language during play-

back (Multi-subtitle) on page 37.)

!Even if you use SUBTITLE during playback to

switch the subtitle language, this does not af-

fect the settings here.

When you select Others

When you select Others, a language code

input display is shown. Refer to Language code

chart for DVD on page 134 to input the four-

digit code of the desired language.

1 Touch 0—9 to input the language code.

#To cancel the inputted numbers, touch C.

2 Touch ENTER.

Setting the audio language

You can set the preferred audio language.

1 Touch AUDIO LANGUAGE on the DVD

setup menu.

An audio language menu is displayed.

2 Touch the desired language.

The audio language is set.

#If you have selected Others, refer to When you

select Others on this page.

Notes

!If the selected language is not recorded on

the disc, the language specified on the disc is

outputted.

Setting up the DVD player

112

Section

!You can also switch the audio language by

touching AUDIO during playback. (Refer to

Changing audio language during playback

(Multi-audio) on page 36.)

!Even if you use AUDIO during playback to

switch the audio language, this does not af-

fect the settings here.

Setting the menu language

You can set the preferred language for dis-

plays of menus recorded on a disc.

1 Touch MENU LANGUAGE on the DVD

setup menu.

A menu language menu is displayed.

2 Touch the desired language.

The menu language is set.

#If you have selected Others, refer to When you

select Others on the previous page.

Note

If the selected language is not recorded on the

disc, the language specified on the disc is dis-

played.

Switching the assist

subtitle on or off

If assist subtitles are recorded on a DVD disc,

you can display them by turning the assist

subtitle function on.

You can turn assist subtitles on or off as de-

sired.

%Touch ASSIST SUB TITLE on the DVD

setup menu to turn assist subtitles on.

#To turn the assist subtitle off, touch

ASSIST SUB TITLE again.

Setting the angle icon display

You can set it up so that the angle icon ap-

pears on scenes where the angle can be

switched.

%Touch MULTI ANGLE on the DVD setup

menu to turn angle icon display on.

#To turn the angle icon display off, touch

MULTI ANGLE again.

Setting the aspect ratio

There are two kinds of display. A wide screen

display has a width-to-height ratio (TV aspect)

of 16:9, while a regular display has a TV aspect

of 4:3. Be sure to select the correct TV aspect

for the display connected to REAR DISPLAY

OUT.

!When using a regular display, select either

LETTER BOX or PAN SCAN. Selecting 16:9

may result in an unnatural picture.

!If you select the TV aspect, the unit’s dis-

play changes to the same setting.

%Touch TV ASPECT on the DVD setup

menu to select the TV aspect.

Touch TV ASPECT repeatedly until the desired

TV aspect appears in the display.

!16:9 –Wide screen picture (16:9) is dis-

played as it is (initial setting)

!LETTER BOX –The picture is the shape of a

letterbox with black bands at the top and

bottom of the screen

!PAN SCAN –The picture is cut short at the

right and left of the screen

Notes

!When playing discs that do not specify

PAN SCAN, playback is with LETTER BOX

even if you select PAN SCAN setting. Confirm

whether the disc package bears the 16 : 9 LB

mark. (See page 15.)

Setting up the DVD player

En 113

Section

Setting up the DVD player

!Some discs do not enable changing of the TV

aspect. For details, refer to the disc’s in-

structions.

Setting the parental lock

Some DVD video discs let you use parental

lock to restrict children from viewing violent

and adult-oriented scenes. You can set the par-

ental lock to your desired level.

!When you set a parental lock level and then

play a disc featuring parental lock, code

number input indications may be dis-

played. In this case, playback will begin

when the correct code number is input.

Setting the code number and level

You need to have registered a code number for

playing back discs with parantal lock.

1 Touch PARENTAL on the DVD setup

menu.

2 Touch 0—9 to input a four digit code

number.

#To cancel the inputted numbers, touch C.

3 Touch ENTER.

The code number is set, and you can now set

the level.

4 Touch any of 1—8 to select the desired

level.

The parental lock level is set.

!8–Playback of the entire disc is possible

(initial setting)

!7to 2–Playback of discs for children and

non-adult-oriented discs is possible

!1–Playback of discs for children only is

possible

Notes

!We recommend to keep a record of your code

number in case you forget it.

!The parental lock level is recorded on the disc.

Look for the level indication written at the disc

package, included literature or on the disc it-

self. Parental lock of this unit is not possible if

a parental lock level is not recorded in the

disc.

!With some discs, the parental lock may be ac-

tive only on the scenes with certain levels. The

playback of those scenes will be skipped. For

details, refer to the instruction manual that

came with the discs.

Changing the level

You can change the set parental lock level.

1 Touch PARENTAL on the DVD setup

menu.

2 Touch 0—9 to input the registered code

number.

3 Touch ENTER.

This enters the code number, and you can now

change the level.

#If you input an incorrect code number, the

icon is displayed. Touch Cand input the cor-

rect code number.

#If you forget your code number, refer to If you

forget your code number on this page.

4 Touch any of 1—8 to select the desired

level.

The new parental lock level is set.

If you forget your code number

Refer to Changing the level on this page, and

touch C10 times. The registered code number

is canceled, letting you register a new one.

Setting the still picture

The unit uses one of two processes when dis-

playing a still picture from a DVD disc.

Setting up the DVD player

114

Section

%Touch STILL PICTURE on the DVD setup

menu to select the setting.

Touch STILL PICTURE repeatedly until the de-

sired setting appears in the display.

!AUTO –FIELD or FRAME is selected auto-

matically by this unit.

!FIELD –Produces a stable, generally shake-

free image.

!FRAME –Produces a sharper image, but

more prone to shake than field stills.

To play back bonus groups

Some DVD audio discs have an extra ‘bonus’

group that requires a four-digit password to

access. See the disc packaging for details and

the password. When you try and play the

bonus group, the password input screen will

automatically appear.

!The bonus group can be played back after

the password has been entered, until the

disc is removed from the unit.

1 Touch BONUS GROUP on the DVD setup

menu.

2 Touch 0—9 to input a four-digit pass-

word.

#If you input an incorrect password, touch C

and then input the correct password.

3 Touch ENTER.

Displaying your DivX®VOD

registration code

In order to play DivX VOD (video on demand)

content on this unit, you first need to register

the unit with your DivX VOD content provider.

You do this by generating a DivX VOD registra-

tion code, which you submit to your provider.

%Touch DivX VOD on the DVD setup

menu.

Your 8-digit registration code is displayed.

!Make a note of the code as you will need it

when you register with a DivX VOD

provider.

Setting remote control

code type

When the remote control operation switch is

set to DVD, changing the remote control code

type enables you to operate the Pioneer DVD

player with the supplied remote control. There

are three remote codes, code type A, code

type Band code type AVH. When operating a

multi-DVD player (e.g. XDV-P6), select code A.

When operating this unit, select code AVH.

1 Set the remote control selection switch

on the left side of the remote control to

the appropriate position with a pen tip or

other pointed instrument .

!If you select AVH mode, there is no need to

take the following procedure.

!If you select A/Bmode, take the following

procedure and change the code type to the

appropriate type.

2 Press 0 and CLEAR on the remote con-

trol simultaneously to change the code

type.

Initially, the code type is set to A. Each time

you press 0and CLEAR simultaneously on the

remote control the code type switches be-

tween Aand B.

Setting up the DVD player

En 115

Section

Setting up the DVD player

Adjusting initial settings

Using the initial settings, you can customize

various system settings to achieve optimal per-

formance from this unit.

1Function display

Shows the function names.

1 Touch the source icon and then touch

OFF to turn this unit off.

2 Touch the screen to display the touch

panel keys.

3 Touch AV MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

4 Touch ESC to return to the display of

each source.

#To return to the previous display, touch BACK.

Note

You can use AUTO EQ&TA (auto-time alignment

and auto-equalizing), only when STANDARD has

been selected in DSP MODE. (Refer to Switching

the DSP setting mode on the next page.)

Switching the warning tone

If the front panel is not detached from the

head unit within five seconds of turning off the

ignition, a warning tone will sound. You can

turn off the warning tone.

%Touch DETACH WARNING on the initial

menu to turn warning tone on.

#To turn warning tone off, touch

DETACH WARNING again.

Switching the auxiliary setting

Auxiliary equipments connected to this unit

can be activated individually. Set each AUX

source to ON when using. About connecting

or using auxiliary equipments, refer to Using

the AUX source on page 122.

%Touch AUX1/AUX2 on the initial menu

to turn each auxiliary setting on.

#To turn auxiliary setting off, touch AUX1/

AUX2 again.

Correcting distorted sound

You can minimize distortion that may be

caused by the equalizer curve settings.

Setting an equalizer level high can cause dis-

tortion. If high sound is crippled or distorted,

try switching to LOW. Normally, leave the set-

ting at HIGH to ensure quality sound.

%Touch DIGITAL ATT on the initial menu

to switch the digital attenuator setting.

Touch DIGITAL ATT repeatedly until the de-

sired setting appears in the display.

!HIGH –High quality sound

!LOW –Minimize distortion sound

Initial Settings

116

Section

Switching the sound

muting/attenuation

Sound from this system is muted or attenu-

ated automatically when the signal from the

equipment with mute function is received.

!Sound from this system returns to normal

when the muting or attenuation is can-

celed.

%Touch MUTE on the initial menu to se-

lect any of the muting, attenuation or off.

Touch MUTE until the desired setting appears

in the display.

!MUTE –Muting

!ATT –10dB –Attenuation

!ATT –20dB –Attenuation (ATT –20dB has a

stronger effect than ATT –10dB)

!OFF –Turn the sound muting/attenuation

off

Notes

!The sound is turned off, MUTE is displayed

and no audio adjustments are possible.

!The sound is attenuated, ATT is displayed and

no audio adjustments, except volume control,

are possible.

!Operation returns to normal when the phone

connection is ended.

Switching the automatic

disc playback

You can turn automatic disc playback on or off

when you insert a disc into the disc loading

slot. When this function is on, the disc will be

automatically played after it is inserted into

the disc loading slot.

Initially, this function is set to on.

%Touch DVD DISC AUTO on the initial

menu to turn automatic disc playback on.

#To turn automatic disc playback off, touch

DVD DISC AUTO again.

Resetting the audio functions

You can reset all audio functions except vo-

lume.

Important

If you perform this operation, audio settings are

erased. For this reason, we recommend that you

record the settings in the sheet on page 135 after

you have completed audio adjustments.

1 Touch AUDIO RESET on the initial

menu.

2 Touch RESET.

Proceed with reset? appears and asks you to

confirm it.

3 Touch RESET again to reset audio func-

tions.

Reset completed is displayed and the audio

settings are reset.

#To cancel resetting the audio functions, touch

CANCEL.

Switching the DSP setting

mode

This unit features two operation modes: the

network mode and the standard mode. You

can switch between modes as desired. Initi-

ally, the DSP setting is set to the standard

mode.

Initial Settings

En 117

Section

Initial Settings

!Switching the DSP mode erases the cur-

rent adjusting audio settings

(LAST MEMORY). If needed, memorize it

into custom settings (CUSTOM1,

CUSTOM2 or CUSTOM3).

1 Touch DSP MODE on the initial menu.

2 Touch either of the following touch

panel keys to select the desired mode.

!STANDARD –Standard mode

!NETWORK –Network mode

3 Touch CHANGE to change the mode.

#To cancel changing the mode, touch

CANCEL.

Setting the optical input

When connecting a DVD player, select S-DVD.

%Touch OPTICAL INPUT on the initial

menu to select the optical input setting.

Touch OPTICAL INPUT until the desired set-

ting appears in the display.

!OFF –No DVD player is connected

!S-DVD –DVD player/multi-DVD player

Entering PIN code for

Bluetooth wireless connection

To connect your cellular phone to this unit via

Bluetooth wireless technology, you need to

enter PIN code on your phone to verify the

connection. The default code is 0000, but you

can change this in this function.

!With some Bluetooth audio players, you

may be required to enter to this unit in ad-

vance PIN code of your Bluetooth audio

player, in order to set this unit ready for a

connection from your Bluetooth audio

player.

!Only when Bluetooth adapter (e.g. CD-

BTB100) is connected to this unit, you can

operate this function.

1 Touch PIN EDIT on the initial menu.

PIN code input display appears.

2 Touch 0—9 to input the PIN code of

your Bluetooth audio player.

#To cancel the inputted numbers, touch C.

3 After inputting PIN code (up to 16 di-

gits), touch ENTER.

The PIN code you entered is stored in this

unit.

Setting the security indicator

The LED indicator (security indicator) will flash

when front panel is detached from the head

unit. You can turn this indicator on or off.

%Touch SECURITY INDICATOR on the in-

itial menu to turn security indicator on.

#To turn security indicator off, touch

SECURITY INDICATOR again.

Initial Settings

118

Section

Switching the display on

the sub-display

You can switch between the displays on the

sub-display.

%Press 2ch/MULTI-CH and hold to switch

the display.

Press and hold 2ch/MULTI-CH repeatedly to

switch between the following settings:

Source display—clock display—OFF

Adjusting the screen

Changing the wide screen mode

You can select a desired mode for enlarging a

4:3 picture to a 16:9 one.

%Press WIDE to select the desired set-

ting.

Press WIDE repeatedly to switch between the

following settings:

FULL (full)—JUST (just)—CINEMA (cinema)—

ZOOM (zoom)—NORMAL (normal)—AUTO

(auto)

#You can select AUTO only when selecting

DVD as the source.

FULL (full)

A 4:3 picture is enlarged in the horizontal direc-

tion only, giving you a 4:3 TV picture (normal pic-

ture) without any omissions.

JUST (just)

The picture is enlarged slightly at the center and

the amount of enlargement increases horizontally

to the ends, enabling you to enjoy a 4:3 picture

without sensing any disparity even on a wide

screen.

CINEMA (cinema)

The picture is enlarged by the same proportion as

FULL or ZOOM in the horizontal direction and by

an intermediate proportion between FULL and

ZOOM in the vertical direction; ideal for a cine-

ma-sized picture (wide screen picture) where cap-

tions lie outside.

ZOOM (zoom)

A 4:3 picture is enlarged in the same proportion

both vertically and horizontally; ideal for a cine-

ma-sized picture (wide screen picture).

NORMAL (normal)

A 4:3 picture is displayed as it is, giving you no

sense of disparity since its proportions are the

same as that of the normal picture.

AUTO (auto)

In this mode, this unit selects the appropriate set-

ting from among FULL,JUST,CINEMA,ZOOM or

NORMAL automatically.

Notes

!Different settings can be memorized for each

video source.

!When video is viewed in a wide screen mode

that does not match its original aspect ratio, it

may appear different.

!Remember that using the wide mode feature

of this system for commercial or public view-

ing purposes may constitute an infringement

on the author’s rights protected by the Copy-

right Law.

!Video will appear grainy when viewed in

CINEMA or ZOOM mode.

Changing the picture adjustment

You can adjust BRIGHTNESS (brightness),

CONTRAST (contrast), COLOR (color) and

HUE (hue) for each source and rear view cam-

era.

Other Functions

En 119

Section

Other Functions

!The adjustments of BRIGHTNESS and

CONTRAST are stored separately for light

ambient (daytime) and dark ambient (night-

time). A sun or moon is displayed to

the left of BRIGHTNESS and CONTRAST,

respectively, as the ambient light sensor de-

termines brightness or darkness.

!You cannot adjust HUE for PAL video.

!You cannot adjust HUE for DVD source.

!You cannot adjust COLOR or HUE for the

audio source.

1 Press V.ADJUST to display

PICTURE ADJUSTMENT.

2 Touch or to adjust the following

items.

The adjustment function names are displayed

and adjustable ones are highlighted.

Each time you touch or it increases or de-

creases the level of selected item. –24 to +24

is displayed as the level is increased or de-

creased.

!BRIGHTNESS –Adjust the black intensity

!CONTRAST –Adjust the contrast

!COLOR –Adjust the color saturation

!HUE –Adjust the tone of color (red is em-

phasized or green is emphasized)

!DIMMER –Adjust the brightness of display

!B.Camera/SOURCE –Switch the picture ad-

justment modes

#You can adjust the picture adjustment for rear

view camera only when BACK UP CAMERA IN is

turned on. (Refer to Setting for rear view camera

(back up camera) on page 109.)

#If you are viewing image from the rear view

camera, you cannot adjust picture adjustment for

the selected source.

#With some rear view cameras, picture adjust-

ment may not be possible.

3 Touch ESC to hide the touch panel keys.

Adjusting the dimmer

The adjustment of DIMMER is stored sepa-

rately for each ambient light; daytime, evening

and nighttime. The brightness of LCD screen

will be adjusted to optimum level automati-

cally in accordance with the ambient light

based on the setting values.

!The icons indicating the current ambient

brightness used for adjusting BRIGHTNESS

and CONTRAST may differ from DIMMER

slightly.

1 Press V.ADJUST to display

PICTURE ADJUSTMENT.

The ambient light level used as the standard

for adjusting DIMMER appears above the level

bar.

!Red sun –Adjust the brightness for

bright ambient light (daytime)

!Orange sun –Adjust the brightness for

intermediate brightness (evening)

!Yellow moon –Adjust the brightness for

dark ambient light (nighttime)

2 Touch or for DIMMER to adjust the

brightness.

Each time you touch or it moves cursor to-

wards the left or the right.

The level indicates the brightness of the

screen being adjusted. The farther cursor

moves to the right, the brighter the screen.

3 Touch ESC to hide the touch panel

keys.

Other Functions

120

Section

Selecting the background

display

You can display the thumbnails of available

background pictures/visuals and select one to

set your background display. The selection

can be made each for the audio source group

(playing CD, listening to Tuner, etc.), telephone

source and the movie source group (watching

DVD, AV, etc.).

1 Press ENTERTAINMENT.

Thumbnails of background pictures/visuals

appear on the display.

2 Touch one of the thumbnails that you

want to display in the background.

The selected picture/movie is displayed at the

background.

Note

In the following cases, background images from

that source cannot be selected:

!When there is no disc in the unit.

!When the AV (AV input) is not set to VIDEO

(refer to page 109).

Adjusting the response

positions of the touch panels

(Touch Panel Calibration)

If you feel that the touch panel keys on the

screen deviate from the actual positions that

respond to your touch, adjust the response po-

sitions of the touch panel. There are two ad-

justment methods: 4-point adjustment, in

which you touch four corners of the screen;

and 16-point adjustment, in which you make

fine-adjustments on the entire screen.

!Make sure to use the supplied pen for ad-

justment, and gently touch the screen. If

you press the touch panel forcefully, the

touch panel may be damaged. Do not use

a sharp pointed tool such as ballpoint pen

or a mechanical pen. Otherwise the screen

is damaged.

1 Press V.ADJUST to display

PICTURE ADJUSTMENT.

2 Press and hold V.ADJUST.

The 4-point touch panel adjustment screen ap-

pears.

3 Touch each of the arrows on the four

corners of the screen with the touch panel

adjustment pen.

#To cancel the adjustment, press and hold

V.ADJUST.

4 Press V.ADJUST to complete the 4-point

adjustment.

The adjusted position data is saved.

!Do not turn off the engine while saving the

adjusted position data.

5 Press V.ADJUST to proceed to the 16-

point adjustment.

The 16-point touch panel adjustment screen

appears.

#To cancel the adjustment, press and hold

V.ADJUST.

6 Gently touch the center of the + mark

displayed on the screen with the touch

panel adjustment pen.

After you touch all the marks, the adjusted po-

sition data is saved.

!Do not turn off the engine while saving the

adjusted position data.

7 Press and hold V.ADJUST to complete

the adjustment.

Other Functions

En 121

Section

Other Functions

Note

If touch panel adjustment cannot be performed

properly, consult your local Pioneer dealer.

Using the AUX source

This unit can control an auxiliary equipment

such as VCR or portable device (sold sepa-

rately). When connected, auxiliary equipment

is automatically read in as AUX source and as-

signed to AUX.

About AUX connection method

You have two methods to connect auxiliary

equipment to this unit.

Stereo mini pin plug cable (AUX1)

When connecting auxiliary equipment using a

stereo mini plug cable

%Insert the stereo mini plug into the mi-

crophone/auxiliary input jack on this unit.

For more details, refer to the installation man-

ual.

IP-BUS-RCA interconnector (AUX2)

When connecting auxiliary equipment using an

IP-BUS-RCA Interconnector (sold separately)

%Use an IP-BUS-RCA Interconnector such

as the CD-RB20/CD-RB10 (sold separetely)

to connect this unit to auxiliary equipment

featuring RCA output.

For more details, refer to the IP-BUS-RCA Inter-

connector owner’s manual.

#You can only make this type of connection if

the auxiliary equipment has RCA outputs.

Selecting AUX as the source

%Touch the source icon and then touch

AUX1/AUX2 to select AUX as the source.

#If the auxiliary setting is not turned on, AUX

cannot be selected. For more details, see Switch-

ing the auxiliary setting on page 116.

Setting the AUX title

The title displayed for the AUX source can be

changed.

!Each title can be up to 10 characters long.

1 After you have selected AUX as the

source, touch AV MENU and FUNCTION and

then touch NAME EDIT.

2 Touch the letter you wish to input.

For details concerning operation, refer to Edit-

ing the name of sound settings on page 106.

Using the PGM button

You can operate the preprogrammed functions

for each source by using BOOKMARK on the

remote control.

%Press BOOKMARK to turn pause on

when selecting the following sources:

!DVD –Built-in DVD player

!S-DVD –DVD player/multi-DVD player

!M-CD –Multi-CD player

!iPod –iPod

!BT AUDIO –Bluetooth Audio

#To turn pause off, press BOOKMARK again.

%Press BOOKMARK and hold to turn

BSM on when selecting FM or AM as the

source.

Press BOOKMARK and hold until the BSM

turns on.

Other Functions

122

Section

#To cancel the storage process, press

BOOKMARK again.

%Press BOOKMARK and hold to turn

BSSM on when selecting TV as the source.

Press BOOKMARK and hold until the BSSM

turns on.

#To cancel the storage process, press

BOOKMARK again.

%Press BOOKMARK to select the desired

channel select setting when selecting XM

or SIRIUS as the source.

Press BOOKMARK repeatedly to switch be-

tween the following channel select settings:

ChNumber (channel number select setting)—

Category (channel category select setting)

Other Functions

En 123

Section

Other Functions

Troubleshooting

Common

Symptom Cause Action (See)

Power doesn’t turn on.

The unit doesn’t operate.

Leads and connectors are incor-

rectly connected.

Confirm once more that all connections are

correct.

The fuse is blown. Rectify the reason for the fuse blowing, then

replace the fuse. Be very sure to install the

correct fuse with the same rating.

Noise and other factors are causing

the built-in microprocessor to oper-

ate incorrectly.

Press RESET. (Page 15)

Operation with the remote con-

trol isn’t possible.

The unit does not operate cor-

rectly even when the appropriate

remote control buttons are

pressed.

The remote control operation mode

is incorrect.

Switch to the correct remote control mode.

(Page 21)

The remote control code is incor-

rect.

Make sure the remote control selection

switch setting and code type setting are the

same. (Page 115)

Battery power is low. Load new battery. (Page 16)

Some operations are prohibited

with certain discs.

Check by using another disc.

Playback is not possible. The disc is dirty. Clean disc. (Page 128)

The loaded disc is a type this unit

cannot play.

Check what type the disc is.

Non compatible video system disc

is loaded.

Change to a disc compatible to your video

system.

No sounds are heard.

The volume level will not rise.

Cables are not connected correctly. Connect the cables correctly.

The unit is performing still, slow mo-

tion or frame-by-frame playback.

There is no sound during still, slow motion or

frame-by-frame playback.

The front, rear, left and right speak-

ers are not properly adjusted in level

balance.

Adjust the relative levels between the speak-

ers correctly. (Page 92)

Sound is not heard over a speci-

fic speaker.

The speaker size is set to OFF. Make the correct size setting for the speaker.

(Page 101)

The speaker level is set too low. Increase the speaker level setting to get the

balance right with the other speakers. (Page

104)

The center speaker size is set to

SMALL or LARGE whereas no cen-

ter speaker is installed.

Set the center speaker size to OFF. (Page 101)

There is no picture. The parking brake cord is not con-

nected.

Connect a parking brake cord, and apply the

parking brake.

The parking brake is not applied. Connect a parking brake cord, and apply the

parking brake.

Additional Information

124

Appendix

Symptom Cause Action (See)

The icon is displayed, and op-

eration is not possible.

The operation is prohibited for the

disc.

This operation is not possible.

The operation is not compatible

with the disc’s organization.

This operation is not possible.

The picture stops (pauses) and

the unit cannot be operated.

Reading of data has become impos-

sible during playback.

After pressing gonce, start playback once

more.

There is no sound.

Volume level is low.

The volume level is low. Adjust the volume level.

The attenuator is on. Turn the attenuator off.

There is audio and video skip-

ping.

The unit is not firmly secured. Secure the unit firmly.

The picture is stretched, the as-

pect is incorrect.

The aspect setting is incorrect for

the display.

Select the appropriate setting for your display.

(Page 113)

When the ignition switch is

turned ON (or turned to ACC),

the motor sounds.

The unit is confirming whether a

disc is loaded or not.

This is a normal operation.

Nothing is displayed.

The touch panel keys cannot be

used.

The rear view camera is not con-

nected.

BACK UP CAMERA IN is at incor-

rect setting.

Connect a rear view camera.

Press and hold V.ADJUST to return to the

source display and then select the correct set-

ting for BACK UP CAMERA IN. (Page 109)

Problems during DVD playback

Symptom Cause Action (See)

Playback is not possible. The loaded disc has a different re-

gion number from this unit.

Replace the disc with one featuring the same

region number as this unit. (Page 10, Page

140)

A parental lock message is dis-

played and playback is not pos-

sible.

Parental lock is on. Turn parental lock off or change the level.

(Page 114)

Parental lock cannot be can-

celed.

The code number is incorrect. Input the correct code number. (Page 114)

You have forgotten your code num-

ber.

Press CLEAR 10 times to cancel the code

number. (Page 114)

Dialog language (and subtitle

language) cannot be switched.

The DVD playing does not feature

multiple language recordings.

You cannot switch among multiple languages

if they are not recorded on the disc.

You can only switch between items

indicated in the disc menu.

Switch using the disc menu.

No subtitles are displayed. The DVD playing does not feature

subtitles.

Subtitles are not displayed if they are not re-

corded on the disc.

You can only switch between items

indicated in the disc menu.

Switch using the disc menu.

Playback is not with the audio

language and subtitle language

settings selected in DVD SETUP

MENU.

The DVD playing does not feature

dialog or subtitles in the language

selected in DVD SETUP MENU.

Switching to a selected language is not possi-

ble if the language selected in DVD SETUP

MENU is not recorded on the disc.

Additional Information

En 125

Appendix

Additional Information

Symptom Cause Action (See)

Switching the viewing angle is

not possible.

The DVD playing does not feature

scenes shot from multiple angles.

You cannot switch between multiple angles if

the DVD does not feature scenes recorded

from multiple angles.

You are trying to switch to multiple

angle viewing of a scene that is not

recorded from multiple angles.

Switch between multiple angles when watch-

ing scenes recorded from multiple angles.

The picture is extremely unclear/

distorted and dark during play-

back.

The disc features a signal to prohibit

copying. (Some discs may have

this.)

Since this unit is compatible with the copy

guard analog copy protect system, when play-

ing a disc that has a signal prohibiting copy-

ing, the picture may suffer from horizontal

stripes or other imperfections when viewed

on some displays. This does not mean this

unit is malfunctioning.

Problems during Video CD playback

Symptom Cause Action (See)

The PBC (playback control)

menu display cannot be called

up.

The Video CD playing does not fea-

ture PBC.

This operation is not possible with Video CDs

not featuring PBC.

Repeat play and track/time

search are not possible.

The Video CD playing features PBC. This operation is not possible with Video CDs

featuring PBC.

Error messages

When you contact your dealer or your nearest Pioneer Service Center, be sure to record the error

message.

Message Cause Action (See)

ERROR-02-XX Dirty disc Clean disc.

Scratched disc Replace disc.

The disc is loaded upside down Check that the disc is loaded correctly.

Electrical or mechanical Press RESET.

DIFFERENT REGION DISC (RE-

GION ERR)

The disc does not have the same re-

gion number as this unit

Replace the DVD video with one bearing the

correct region number.

NON PLAYABLE DISC (NON-

PLAY)

This type of disc cannot be played

by this unit

Replace the disc with one this unit can play.

The inserted disc does not contain

any files that can be played back

Replace disc.

THERMAL PROTECTION IN

MOTION (TEMP)

The temperature of this unit is out-

side the normal operating range

Wait until the unit’s temperature returns to

within normal operating limits.

Additional Information

126

Appendix

Message Cause Action (See)

FILE Skipped The inserted disc contains WMA

files that are protected by DRM

Replace disc.

PROTECT All the files on the inserted disc are

secured by DRM

Replace disc.

Understanding auto TA and EQ error messages

When correct measurement of car interior acoustic characteristics is not possible using the auto

TA and EQ, an error message may appear on the display. If an error message appears, refer to the

table below to see what the problem is and the suggested method of correcting the problem. After

checking, try again.

Message Cause Action

Error. Please check MIC. Microphone is not connected. Plug the supplied microphone securely into

the jack.

Error. Please check front SP.,

Error. Please check FL SP.,

Error. Please check FR SP.,

Error. Please check center SP.,

Error. Please check rear SP.,

Error. Please check RL SP.,

Error. Please check RR SP.,

Error. Please check rear center

SP.,Error. Please check sub-

woofer.

The microphone cannot pick up the

measuring tone of a speaker.

!Confirm that the speakers are connected

correctly.

!Correct the input level setting of the power

amp connected to the speakers.

!Set the microphone correctly.

Error. Please check noise. The surrounding noise level is too

high.

!Stop your car in a place that is as quiet as

possible, and switch off the engine, air condi-

tioner or heater.

!Set the microphone correctly.

Additional Information

En 127

Appendix

Additional Information

DVD player and care

!Use only normal, round discs. If you insert

irregular, non-round, shaped discs they

may jam in the DVD player or not play prop-

erly.

!Check all discs for cracks, scratches or

warping before playing. Discs that have

cracks, scratches or are warped may not

play properly. Do not use such discs.

!Avoid touching the recorded (non-printed)

surface when handling the disc.

!Store discs in their cases when not in use.

!Keep discs out of direct sunlight and do

not expose the discs to high temperatures.

!Do not attach labels, write on or apply che-

micals to the surface of the discs.

!To clean a disc, wipe the disc with a soft

cloth outward from the center.

!If the heater is used in cold weather, con-

densation may form on components inside

the DVD player. Condensation may cause

the DVD player to not operate properly. If

you think that condensation is a problem

turn off the DVD player for an hour or so to

allow it to dry out and wipe any damp discs

with a soft cloth to remove the moisture.

!Road shocks may interrupt disc

playback.

DVD discs

!With some DVD video discs, it may not be

possible to use certain functions.

!It may not be possible to play back some

DVD video discs.

!When DVD-R/DVD-RW discs are used,

playback is possible only for discs which

have been finalized.

!When DVD-R/DVD-RW discs are used,

playback is possible only for discs which

have been recorded with the Video format

(video mode). It is not possible to play back

DVD-RW discs which have been recorded

with the Video Recording format (VR

mode).

!It may not be possible to play back DVD-R/

DVD-RW discs which have been recorded

with the Video format (video mode), be-

cause of disc characteristics, scratches or

dirt on the disc, or dirt, condensation, etc.

on the lens of this unit.

!It is not possible to play back DVD-ROM/

DVD-RAM discs.

!Playback of discs recorded on a personal

computer may not be possible, depending

on the application settings and the environ-

ment. Please record with the correct for-

mat. (For details, contact the manufacturer

of the application.)

CD-R/CD-RW discs

!When CD-R/CD-RW discs are used, play-

back is possible only for discs which have

been finalized.

!It may not be possible to play back CD-R/

CD-RW discs recorded on a music CD re-

corder or a personal computer because of

disc characteristics, scratches or dirt on

the disc, or dirt, condensation, etc., on the

lens of this unit.

Additional Information

128

Appendix

!Playback of discs recorded on a personal

computer may not be possible, depending

on the application settings and the environ-

ment. Please record with the correct for-

mat. (For details, contact the manufacturer

of the application.)

!Playback of CD-R/CD-RW discs may be-

come impossible in case of direct exposure

to sunlight, high temperatures, or the sto-

rage conditions in the vehicle.

!Titles and other text information recorded

on a CD-R/CD-RW disc may not be dis-

played by this unit (in the case of audio

data (CD-DA)).

!Read the precautions with CD-R/CD-RW

discs before using them.

Dual Discs

!Dual Discs are two-sided discs that have a

recordable CD for audio on one side and a

recordable DVD for video on the other.

!Playback of the DVD side is possible with

this unit. However, since the CD side of

Dual Discs is not physically compatible

with the general CD standard, it may not be

possible to play the CD side with this unit.

!Frequent loading and ejecting of a Dual

Disc may result in scratches on the disc.

Serious scratches can lead to playback pro-

blems on this unit. In some cases, a Dual

Disc may become stuck in the disc loading

slot and will not eject. To prevent this, we

recommend you refrain from using Dual

Disc with this unit.

!Please refer to the information from the

disc manufacturer for more detailed infor-

mation about Dual Discs.

MP3, WMA and AAC files

!MP3 is short for MPEG Audio Layer 3 and

refers to an audio compression technology

standard.

!WMA is short for Windows Media™Audio

and refers to an audio compression tech-

nology that is developed by Microsoft Cor-

poration. WMA data can be encoded by

using Windows Media Player version 7 or

later.

!AAC is short for Advanced Audio Coding

and refers to an audio compression tech-

nology standard.

!This unit may not operate correctly depend-

ing on the application used to encode

WMA files.

!Depending on the version of Windows

Media Player used to encode WMA files,

album names and other text information

may not be correctly displayed.

!There may be a slight delay when starting

playback of WMA/AAC files encoded with

image data.

!This unit allows playback of MP3/WMA/

AAC files on CD-R/RW/ROM and DVD-R/

RW/ROM discs. Disc recordings compati-

ble with level 1 and level 2 of ISO9660 and

with the Romeo and Joliet file system can

be played back.

!It is possible to play back multi-session

compatible recorded discs.

!MP3/WMA/AAC files are not compatible

with packet write data transfer.

!The maximum number of characters which

can be displayed for a file name, including

the extension (.mp3, .wma or .m4a), is 64,

from the first character.

!The maximum number of characters which

can be displayed for a folder name is 64.

!In case of files recorded according to the

Romeo file system, only the first 64 charac-

ters can be displayed.

Additional Information

En 129

Appendix

Additional Information

!The folder selection sequence for playback

and other operations becomes the writing

sequence used by the writing software. For

this reason, the expected sequence at the

time of playback may not coincide with the

actual playback sequence. However, there

also is some writing software which per-

mits setting of the playback order.

!Some audio CDs contain tracks that merge

into one another without a pause. When

these discs are converted to MP3/WMA/

AAC files and burned to a CD-R/RW/ROM

or a DVD-R/RW/ROM, the files will be

played back on this player with a short

pause between each one, regardless of the

length of the pause between tracks on the

original audio CD.

Important

!When naming an MP3/WMA/AAC file, add

the corresponding filename extension (.mp3,

.wma or .m4a).

!This unit plays back files with the filename ex-

tension (.mp3, .wma or .m4a) as an MP3/

WMA/AAC file. To prevent noise and malfunc-

tions, do not use these extensions for files

other than MP3/WMA/AAC files.

MP3 additional information

!Files are compatible with the ID3 Tag Ver.

1.0, 1.1, 2.2 and 2.3 formats for display of

album (disc title), track (track title), artist

(track artist) and comments. Ver. 2.x of ID3

Tag is given priority when both Ver. 1.x and

Ver. 2.x exist.

!You can play back MP3 files in the frequen-

cies from 8 kHz to 48 kHz.

!This unit is compatible with the emphasis

function.

!There is no m3u playlist compatibility.

!There is no compatibility with the MP3i

(MP3 interactive) or mp3 PRO formats.

!The sound quality of MP3 files generally be-

comes better with an increased bit rate.

This unit can play recordings with bit rates

from 8 kbps to 320 kbps, but in order to be

able to enjoy sound of a certain quality, we

recommend using only discs recorded with

a bit rate of at least 128 kbps.

WMA additional information

!This unit plays back WMA files encoded by

Windows Media Player version 7, 7.1, 8, 9

and 10.

!You can play back WMA files in the fre-

quencies from 8 kHz to 48 kHz.

!The sound quality of WMA files generally

becomes better with an increased bit rate.

This unit can play recordings with bit rates

from 5 kbps to 320 kbps, but in order to be

able to enjoy sound of a certain quality, we

recommend using discs recorded with a

higher bit rate.

!This unit doesn’t support the following for-

mats.

—Windows Media Audio 9 Professional

(5.1ch)

—Windows Media Audio 9 Lossless

—Windows Media Audio 9 Voice

AAC additional information

!This unit plays back AAC files encoded by

iTunes®version 4.6.

!This unit plays back AAC files in the sam-

pling frequencies from 8 kHz to 48 kHz.

!The sound quality of AAC files generally be-

comes better with an increased transmis-

sion rate. This unit can play recordings

with transmission rates from 8 kbps to 320

kbps, but in order to be able to enjoy sound

of a certain quality, we recommend using

discs recorded with a higher transmission

rate.

Additional Information

130

Appendix

!This unit doesn’t support the following for-

mats.

—Apple Lossless

About folders and MP3/

WMA/AAC files

!An outline of a disc with MP3/WMA/AAC

files on it is shown below. Subfolders are

shown as folders in the folder currently se-

lected.

1First level

2Second level

3Third level

Notes

!This unit assigns folder numbers. The user

cannot assign folder numbers.

!It is not possible to check folders that do not

include MP3/WMA/AAC files. (These folders

will be skipped without displaying the folder

number.)

!MP3/WMA/AAC files in up to 8 tiers of folders

can be played back. However, there is a delay

in the start of playback on discs with numer-

ous tiers. For this reason we recommend

creating discs with no more than 2 tiers.

!It is possible to play back up to 255 folders on

one disc.

JPEG picture files

!JPEG is short for Joint Photographic Ex-

perts Group and refers to a still image com-

pression technology standard.

!Files are compatible with Baseline JPEG

and EXIF 2.1 still image up to resolution of

8 192 × 7 680. (EXIF format is used most

commonly with digital still cameras.)

!EXIF format that processed by the personal

computer may not be played back.

!There is no progressive JPEG compatibility.

Important

!When naming a JPEG picture file, add the cor-

responding filename extension (.jpg, .jpeg or

.jpe).

!This unit plays back files with the filename ex-

tension (.jpg, .jpeg or .jpe) as a JPEG picture

file. To prevent malfunctions, do not use these

extensions for files other than JPEG picture

files.

Additional Information

En 131

Appendix

Additional Information

DivX video files

!This unit corresponds to DivX video format

implemented in relation to DivX standards.

This unit cannot play back DivX Ultra for-

mat.

!DivX files without video data cannot be re-

cognized as DivX file.

!Depending on the file information composi-

tion such as the number of audio stream,

there may be a slight delay in the start of

playback on discs.

!Some special operation may be prohibited

because of the composition of DivX files.

!DivX files downloaded only from DivX part-

ner site are guarantee of proper operation.

Unauthorized DivX file may not operate

properly.

!DRM rental file cannot be operated until

starting playing back.

!This unit corresponds to a DivX file display

up to 1 590 minutes 43 seconds. Also,

search operation beyond this time limit is

prohibited.

!If a file contains more than 4 GB, playback

is stopped on the way.

!DivX VOD file playback requires ID code of

this unit to DivX VOD provider. About ID

code, refer to Displaying your DivX®VOD re-

gistration code on page 115.

!Plays all versions of DivX®video (including

DivX®6) with standard playback of DivX®

media files

!For more details about DivX, visit the follow-

ing site:

http://www.divx.com/

Important

!When naming a DivX video file, add the corre-

sponding filename extension (.avi or .divx).

!This unit plays back files with the filename ex-

tension (.avi or .divx) as a DivX video file. To

prevent noise and malfunctions, do not use

these extensions for files other than DivX

video files.

Using the display correctly

CAUTION

!If liquid or foreign matter should get inside

this unit, turn off the power immediately and

consult your dealer or the nearest authorized

PIONEER Service Station. Do not use the unit

in this condition because doing so may result

in a fire, electric shock, or other failure.

!If you notice smoke, a strange noise or smell,

or any other abnormal signs from the display,

turn off the power immediately and consult

your dealer or the nearest authorized

PIONEER Service Station. Using this unit in

this condition may result in permanent da-

mage to the system.

!Do not disassemble or modify this unit, as

there are high-voltage components inside

which may cause an electric shock. Be sure

to consult your dealer or the nearest author-

ized PIONEER Service Station for internal in-

spection, adjustments or repairs.

Handling the display

!When the display is subjected to direct sun-

light for a long period of time, it will be-

come very hot resulting in possible

damage to the LCD screen. When not

using this unit, close the display and avoid

exposing it to direct sunlight.

!The display should be used within the tem-

perature ranges shown below.

Storage temperature range: –4 °F to +176 °

At temperatures higher or lower than the

operating temperature range the display

may not operate normally.

Additional Information

132

Appendix

!The LCD screen of this unit is exposed in

order to increase its visibility within the ve-

hicle. Please do not press strongly on it as

this may damage it.

!Do not place anything on the display when

it is opened. Also, do not attempt to carry

out angle adjustment, or open/close the

display by hand. Applying strong force to

the display may damage it.

!Do not push the LCD screen with much

force as this may scratch it.

!Be careful not to place anything between

the display and the main body when the

display is opening or closing. If an object

gets between the display and main body,

the display may stop working.

Liquid crystal display (LCD) screen

!If the display is near the vent of an air con-

ditioner when it is opened, make sure that

air from the air conditioner is not blowing

on it. Heat from the heater may damage

the LCD screen, and cool air from the cool-

er may cause moisture to form inside the

display resulting in possible damage. Also,

if the display is cooled down by the cooler,

the screen may become dark, or the life

span of the small fluorescent tube used in-

side the display may be shortened.

!Small black dots or white dots (bright dots)

may appear on the LCD screen. These are

due to the characteristics of the LCD

screen and do not indicate a problem with

the display.

!At low temperatures, the LCD screen may

be dark for a while after the power is turned

on.

!The LCD screen will be difficult to see if it is

exposed to direct sunlight.

!When using a portable phone, keep the an-

tenna of the portable phone away from the

display to prevent disruption of the video by

the appearance of spots, colored stripes,

etc.

Keeping the display in good

condition

!When removing dust from the screen or

cleaning the display, first turn the system

power off, then wipe with the supplied

cloth.

!When wiping the screen, take care not to

scratch the surface. Do not use harsh or

abrasive chemical cleaners.

Small fluorescent tube

!A small fluorescent tube is used inside the

display to illuminate the LCD screen.

—The fluorescent tube should last for ap-

proximately 10 000 hours, depending on

operating conditions. (Using the display

at low temperatures reduces the service

life of the fluorescent tube.)

—When the fluorescent tube reaches the

end of its useful life, the screen will be

dark and the image will no longer be

projected. If this happens, consult your

dealer or the nearest authorized

PIONEER Service Station.

Additional Information

En 133

Appendix

Additional Information

Language code chart for DVD

Language (code), input code Language (code), input code Language (code), input code

Japanese (ja), 1001 Guarani (gn), 0714 Pashto, Pushto (ps), 1619

English (en), 0514 Gujarati (gu), 0721 Quechua (qu), 1721

French (fr), 0618 Hausa (ha), 0801 Rhaeto-Romance (rm), 1813

Spanish (es), 0519 Hindi (hi), 0809 Kirundi (rn), 1814

German (de), 0405 Croatian (hr), 0818 Romanian (ro), 1815

Italian (it), 0920 Hungarian (hu), 0821 Kinyarwanda (rw), 1823

Chinese (zh), 2608 Armenian (hy), 0825 Sanskrit (sa), 1901

Dutch (nl), 1412 Interlingua (ia), 0901 Sindhi (sd), 1904

Portuguese (pt), 1620 Interlingue (ie), 0905 Sangho (sg), 1907

Swedish (sv), 1922 Inupiak (ik), 0911 Serbo-Croatian (sh), 1908

Russian (ru), 1821 Indonesian (in), 0914 Sinhalese (si), 1909

Korean (ko), 1115 Icelandic (is), 0919 Slovak (sk), 1911

Greek (el), 0512 Hebrew (iw), 0923 Slovenian (sl), 1912

Afar (aa), 0101 Yiddish (ji), 1009 Samoan (sm), 1913

Abkhazian (ab), 0102 Javanese (jw), 1023 Shona (sn), 1914

Afrikaans (af), 0106 Georgian (ka), 1101 Somali (so), 1915

Amharic (am), 0113 Kazakh (kk), 1111 Albanian (sq), 1917

Arabic (ar), 0118 Greenlandic (kl), 1112 Serbian (sr), 1918

Assamese (as), 0119 Cambodian (km), 1113 Siswati (ss), 1919

Aymara (ay), 0125 Kannada (kn), 1114 Sesotho (st), 1920

Azerbaijani (az), 0126 Kashmiri (ks), 1119 Sundanese (su), 1921

Bashkir (ba), 0201 Kurdish (ku), 1121 Swahili (sw), 1923

Byelorussian (be), 0205 Kirghiz (ky), 1125 Tamil (ta), 2001

Bulgarian (bg), 0207 Latin (la), 1201 Telugu (te), 2005

Bihari (bh), 0208 Lingala (ln), 1214 Tajik (tg), 2007

Bislama (bi), 0209 Laothian (lo), 1215 Thai (th), 2008

Bengali (bn), 0214 Lithuanian (lt), 1220 Tigrinya (ti), 2009

Tibetan (bo), 0215 Latvian (lv), 1222 Turkmen (tk), 2011

Breton (br), 0218 Malagasy (mg), 1307 Tagalog (tl), 2012

Catalan (ca), 0301 Maori (mi), 1309 Setswana (tn), 2014

Corsican (co), 0315 Macedonian (mk), 1311 Tonga (to), 2015

Czech (cs), 0319 Malayalam (ml), 1312 Turkish (tr), 2018

Welsh (cy), 0325 Mongolian (mn), 1314 Tsonga (ts), 2019

Danish (da), 0401 Moldavian (mo), 1315 Tatar (tt), 2020

Bhutani (dz), 0426 Marathi (mr), 1318 Twi (tw), 2023

Esperanto (eo), 0515 Malay (ms), 1319 Ukrainian (uk), 2111

Estonian (et), 0520 Maltese (mt), 1320 Urdu (ur), 2118

Basque (eu), 0521 Burmese (my), 1325 Uzbek (uz), 2126

Persian (fa), 0601 Nauru (na), 1401 Vietnamese (vi), 2209

Finnish (fi), 0609 Nepali (ne), 1405 Volapük (vo), 2215

Fiji (fj), 0610 Norwegian (no), 1415 Wolof (wo), 2315

Faroese (fo), 0615 Occitan (oc), 1503 Xhosa (xh), 2408

Frisian (fy), 0625 Oromo (om), 1513 Yoruba (yo), 2515

Irish (ga), 0701 Oriya (or), 1518 Zulu (zu), 2621

Scots-Gaelic (gd), 0704 Panjabi (pa), 1601

Galician (gl), 0712 Polish (pl), 1612

Additional Information

134

Appendix

DSP adjustment value record sheet

Please make a copy of sheet below as desired.

Parametric equalizer setting (PARAMETRIC EQ) (when selecting multi-channel mode only)

Speaker unit BAND Frequency Level Q.Fac

FRONT LEFT

LOW

MID

HIGH

FRONT RIGHT

LOW

MID

HIGH

REAR LEFT

LOW

MID

HIGH

REAR RIGHT

LOW

MID

HIGH

FRONT CENTER

LOW

MID

HIGH

REAR CENTER

LOW

MID

HIGH

Graphic equalizer setting (GRAPHIC EQ) (when selecting 2-channel mode only)

Speaker unit 50 80 125 200 315 500 800 1.25k 2k 3.15k 5k 8k 12.5k

LEFT

RIGHT

Speaker setting (SPEAKER SETTING)

Speaker unit Front center Front Rear Rear center Subwoofer

Setting

Additional Information

En 135

Appendix

Additional Information

Cut-off frequency setting (CUT OFF)

Speaker unit FREQUENCY SLOPE PHASE

FRONT LEFT HIGH (network mode only) —

FRONT RIGHT HIGH (network mode only) —

FRONT LEFT MID (network mode only)

LOW PASS —

HIGH PASS —

FRONT RIGHT MID (network mode only)

LOW PASS —

HIGH PASS —

FRONT LEFT (standard mode only) —

FRONT RIGHT (standard mode only) —

REAR LEFT —

REAR RIGHT —

FRONT CENTER —

REAR CENTER —

SUBWOOFER

Time alignment setting (TIME ALIGNMENT) and speaker level setting (SPEAKER LEVEL)

Speaker unit TIME ALIGNMENT SPEAKER LEVEL

Tweeter left

Tweeter right

Front center

Front left

Front right

Rear left

Rear right

Rear center

Subwoofer

Tweeters are available on the network mode only.

Additional Information

136

Appendix

Terms

AAC

AAC is short for Advanced Audio Coding and

refers to an audio compression technology

standard used with MPEG 2 and MPEG 4.

Aspect ratio

This is the width-to-height ratio of a TV screen.

A regular display has an aspect ratio of 4:3.

Wide screen displays have an aspect ratio of

16:9, providing a bigger picture for exceptional

presence and atmosphere.

Bit rate

This expresses data volume per second, or bps

(bits per second) units. The higher the rate,

the more information is available to reproduce

the sound. Using the same encoding method

(such as MP3), the higher the rate, the better

the sound.

Bonus group

An ‘extra’group on some DVD audio discs

that requires a key number to access.

Browsable pictures

A feature of some DVD audio discs in which

you can browse still pictures recorded on the

disc while the audio is played back.

Chapter

DVD titles are in turn divided into chapters

which are numbered in the same way as the

chapters of a book. With DVD video discs fea-

turing chapters, you can quickly find a desired

scene with chapter search.

DivX

DivX is a popular media technology created by

DivX, Inc. DivX media files contain highly com-

pressed video with high visual quality that

maintains a relatively small file size. DivX files

can also include advanced media features like

menus, subtitles, and alternate audio tracks.

Many DivX media files are available for down-

load online, and you can create your own

using your personal content and easy-to-use

tools from DivX.com.

DivX Certified

DivX Certified products are officially tested by

the creators of DivX and guaranteed to play all

versions of DivX video, including DivX 6.

Dolby Digital

Dolby Digital provides multi-channel audio

from up to 5.1 independent channels. This is

the same as the Dolby Digital surround sound

system used in theaters.

Dolby Digital EX

Dolby Digital EX creates six full-bandwidth out-

put channels from 5.1-channel sources. This is

done using a matrix decoder that derives three

surround channels from the two in the original

recording.

Dolby Pro Logic II

Dolby Pro Logic II can create five full-band-

width output channels from two-channel

sources. This new technology enables a dis-

crete 5-channel playback with 2 front chan-

nels, 1 center channel, and 2 rear channels. A

music mode is also available for 2-channel

sources in addition to the movie mode.

DTS

This stands for Digital Theater Systems. DTS is

a surround system delivering multi-channel

audio from up to 6 independent channels.

DTS 96/24

DTS 96/24 is an extension of the original DTS

Digital Surround which offers high quality 96

kHz/24-bit audio using a DTS 96/24 decoder.

This format is also fully backward compatible

with all existing decoders. This means that

DVD players can play this software using a

conventional DTS 5.1 channel decoder.

Additional Information

En 137

Appendix

Additional Information

DTS Neo:6

DTS Neo:6 can generate 6.1 channel surround

sound from any matrixed stereo source (such

as video or TV) and from 5.1 channel sources.

It uses both the channel information already

encoded into the source, as well as its ownpro-

cessing to determine channel localization

(with two channel sources, the “.1”subwoofer

channel is generated by bass management in

the receiver). Two modes (Cinema and Music)

are available using DTS Neo:6 with two chan-

nel sources.

DTS-ES

DTS-ES is a decoder that is capable of decod-

ing both DTS-ES Discrete 6.1 and DTS-ES Ma-

trix 6.1 encoded sources. DTS-ES Discrete 6.1

gives ‘true’6.1 channel sound, with a comple-

tely separate (discrete) surround back chan-

nel. DTS-ES Matrix 6.1 has a surround back

channel matrixed into the surround left/right

channels. Both sources are also compatible

with a conventional DTS 5.1 channel decoder.

Dynamic range control

Dolby Digital has a function for compressing

the difference between the loudest and softest

sounds: Dynamic range control. This control

ensures sounds with an increased dynamic

range are heard clearly even at low volume le-

vels.

EXIF (Exchangeable image file)

A file format developed by Fuji Photo Film for

digital still cameras. Digital cameras from var-

ious manufacturers use this compressed file

format which carries date, time and thumbnail

information, as well as the picture data.

Group

A collection of tracks on a DVD audio disc.

Equivalent to a DVD video title.

ID3 tag

This is a method of embedding track-related

information in an MP3 file. This embedded in-

formation can include the track title, the ar-

tist’s name, the album title, the music genre,

the year of production, comments and other

data. The contents can be freely edited using

software with ID3 Tag editing functions.

Although the tags are restricted as to the num-

ber of characters, the information can be

viewed when the track is played back.

ISO9660 format

This is the international standard for the for-

mat logic of CD-ROM folders and files. For the

ISO9660 format, there are regulations for the

following two levels.

Level 1:

The file name is in 8.3 format (the name con-

sists of up to 8 characters, half-byte English

capital letters and half-byte numerals and the

“_”sign, with a file-extension of three charac-

ters).

Level 2:

The file name can have up to 31 characters (in-

cluding the separation mark “.”and a file ex-

tension). Each folder contains less than 8

hierarchies.

Extended formats

Joliet:

File names can have up to 64 characters.

Romeo:

File names can have up to 128 characters.

JPEG

This stands for Joint Photographic Experts

Group, and is an international still image com-

pression standard.

Additional Information

138

Appendix

Linear PCM (LPCM)/Pulse code

modulation

This stands for linear pulse code modulation,

which is the signal recording system used for

music CDs and DVDs. Generally, DVDs are re-

corded with higher sampling frequency and

bit rate than CDs. Therefore, DVDs can provide

higher sound quality.

m3u

Playlists created using the “WINAMP”soft-

ware have a playlist file extension (.m3u).

MP3

MP3 is short for MPEG Audio Layer 3. It is an

audio compression standard set by a working

group (MPEG) of the ISO (International Stan-

dards Organization). MP3 is able to compress

audio data to about 1/10th the level of a con-

ventional disc.

MPEG

This stands for Moving Pictures Experts

Group, and is an international video image

compression standard. Some DVDs feature di-

gital audio compressed and recorded using

this system.

MS ADPCM

This stands for Microsoft adaptive differential

pulse code modulation, which is the signal re-

cording system used for the multimedia soft-

ware of Microsoft Corporation.

Multi-angle

With regular TV programs, although multiple

cameras are used to simultaneously shoot

scenes, only images from one camera at a

time are transmitted to your TV. Some DVDs

feature scenes shot from multiple angles, let-

ting you choose your viewing angle as desired.

Multi-audio (Multilingual dialog)

Some DVDs feature dialog recorded in multi-

ple languages. Dialog in up to 8 languages

can be recorded on a single disc, letting you

choose as desired.

Multi-session

Multi-session is a recording method that al-

lows additional data to be recorded later.

When recording data on a CD-ROM, CD-R or

CD-RW, etc., all data from beginning to end is

treated as a single unit or session. Multi-ses-

sion is a method of recording more than 2 ses-

sions on one disc.

Multi-subtitle

Subtitles in up to 32 languages can be re-

corded on a single DVD, letting you choose as

desired.

Number of quantization bits

The number of quantization bits is one factor

in the overall sound quality; the higher the

“bit-depth”, the better the sound quality. How-

ever, increasing the bit-depth also increases

the amount of data and therefore storage

space required.

Packed PCM

A lossless compression system that enables

more PCM audio to be stored on a DVD audio

disc than would otherwise be possible.

Packet write

This is a general term for a method of writing

on CD-R, etc., at the time required for a file,

just as is done with files on floppy or hard

discs.

Parental lock

Some DVD video discs with violent or adult-or-

iented scenes feature parental lock which pre-

vents children from viewing such scenes. With

this kind of disc, if you set the unit’s parental

lock level, playback of scenes inappropriate for

children will be disabled, or these scenes will

be skipped.

Additional Information

En 139

Appendix

Additional Information

Playback control (PBC)

This is a playback control signal recorded on

Video CDs (Version 2.0). Using menu displays

provided by Video CDs with PBC lets you enjoy

playback of simple interactive software and

software with search functions. You can also

enjoy viewing high- and standard-resolution

still images.

Region number

DVD players and DVD discs feature region

numbers indicating the area in which they

were purchased. Playback of a DVD is not pos-

sible unless it features the same region num-

ber as the DVD player. This unit’s region

number is displayed on the bottom of the unit.

Slideshow

A feature of some DVD discs in which still pic-

tures recorded on the disc cycle automatically

while the audio is played back.

Title

DVD video discs have high data capacity, en-

abling recording of multiple movies on a sin-

gle disc. If, for example, one disc contains

three separate movies, they are divided into

title 1, title 2 and title 3. This lets you enjoy the

convenience of title search and other func-

tions.

VBR

VBR is short for variable bit rate. Generally

speaking CBR (constant bit rate) is more

widely used. But by flexibly adjusting the bit

rate according to the needs of audio compres-

sion, it is possible to achieve compression-

priority sound quality.

WMA

WMA is short for Windows Media™Audio

and refers to an audio compression technol-

ogy that is developed by Microsoft Corpora-

tion. WMA data can be encoded by using

Windows Media Player version 7 or later.

Windows Media and the Windows logo are tra-

demarks or registered trademarks of Microsoft

Corporation in the United States and/or other

countries.

Additional Information

140

Appendix

Specifications

General

Power source ............................. 14.4 V DC (10.8 V to 15.1 V

allowable)

Grounding system ................... Negative type

Head unit:

Max. current consumption

........................................... 3.7 A

Dimensions (W × H × D):

DIN

Chassis ..................... 178 × 50 × 160 mm

(7 × 2 × 6-1/4 in.)

Nose ........................... 188 × 58 × 36 mm

(7-3/8 × 2-1/4 × 1-3/8 in.)

Chassis ..................... 178 × 50 × 165 mm

(7 × 2 × 6-1/2 in.)

Nose ........................... 170 × 46 × 31 mm

(6-3/4 × 1-3/4 × 1-1/4 in.)

Weight ................................ 2.5 kg (5.5 lbs)

Hideaway unit:

Max. current consumption

........................................... 21.5 A

Dimensions (W × H × D)

........................................... 280 × 37 × 171 mm

(11 × 1-1/2 × 6-3/4 in.)

Weight ................................ 1.4 kg (3.1 lbs)

Display

Screen size/aspect ratio ....... 7 inch wide/15:9

(effective display area: 152.4

× 91.44 mm)

Pixels ............................................. 1 152 000 (800 × 480 × 3)

Type ................................................ TFT active matrix, transmis-

sive type

Color system .............................. NTSC compatible

Storage temperature range

..................................................... –4 °F to +176 °F

Angle adjustment .................... 50° to 110°

(initial settings: 90°)

Audio

Maximum power output ....... 50 W × 8

Continuous power output ... 22 W × 8 (50 Hz to 15 000

Hz, 5% THD, 4 Wload, both

channels driven)

Load impedance ...................... 4 W(4 Wto 8 Wallowable)

Preout max output level/output impedance

..................................................... 5.0 V × 9/100 W

Decoder ........................................ Linear PCM, Dolby Digital,

Dolby Digital EX, Dolby EX,

Dolby Pro Logic II, DTS,

DTS-CD, DTS-ES (matrix,

discrete), DTS 96/24, DTS

Neo:6, AAC

Sound setting

Position ........................................ Front left/Front right/Front/

All/Off

Parametric equalizer (multi-channel mode):

Band .................................... 3 band

Frequency .......................... 40/50/63/80/100/125/160/

200/250/315/400/500/630/

800/1k/1.25k/1.6k/2k/2.5k/

3.15k/4k/5k/6.3k/8k/10k/

12.5k Hz

Q Factor .............................. 1.2/3.6

Gain ...................................... ±12dB (2 dB/step)

Graphic equalizer (2-channel mode):

Band .................................... 13 band

Frequency .......................... 50/80/125/200/315/500/800/

1.25k/2k/3.15k/5k/8k/12.5k

Q Factor .............................. 5.0

Gain ...................................... ±12dB (2 dB/step)

Speaker setting:

Front ..................................... Large/Small

Front center ...................... Large/Small/Off

Rear ...................................... Large/Small/Off

Rear center ....................... Large/Small/Off

Subwoofer ......................... On/Off

Time alignment ........................ 0 inch to 200 inch (1 inch/

step)

Speaker level .............................. –24 dB to +10 dB (1 dB/

step)

Cut-off frequency

Front (L/R independent) (Standard mode):

HPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... –6/–12/–18 dB/oct

Mute .................................... On/Off

Front (L/R independent) (Network mode):

High HPF:

Frequency ................ 1.25/1.6/2/2.5/3.15/4/5/6.3/8/

10/12.5 kHz

Slope .......................... –6/–12 dB/oct

Additional Information

En 141

Appendix

Additional Information

Low LPF:

Frequency ................ 1.25/1.6/2/2.5/3.15/4/5/6.3/8/

10/12.5 kHz

Slope .......................... 0 (Pass)/–6/–12 dB/oct

Low HPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... –6/–12/–18 dB/oct

Mute .................................... On/Off

Front center:

HPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... –6/–12/–18 dB/oct

Mute .................................... On/Off

Rear (L/R independent):

HPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... –6/–12/–18 dB/oct

Mute .................................... On/Off

Rear center:

HPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... –6/–12/–18 dB/oct

Mute .................................... On/Off

Subwoofer:

LPF:

Frequency ................ 50/63/80/100/125/160/200

Slope .......................... 0 (Pass)/–6/–12/–18 dB/oct

Phase ........................ Normal/Reverse

Mute .................................... On/Off

DVD Player

System .......................................... DVD audio, DVD video,

Video CD, CD, MP3, WMA,

AAC, DivX, JPEG system

Usable discs .............................. DVD audio, DVD video,

Video CD, dtsCD, CD, CD-R/

RW, DVD-R/RW

Region number ........................ 1

Signal format:

Sampling frequency ..... 16/22.05/24/44.1/48/88.2/96/

176.4/192 kHz

Number of quantization bits

........................................... 16/20/24; linear

Frequency response ............... 5 Hz to 96 000 Hz (with DVD,

at sampling frequency 192

kHz)

Signal-to-noise ratio ............... 102 dB (1 kHz) (IHF-A net-

work)

(CD: 102 dB (1 kHz) (IHF-A

network))

Dynamic range ......................... 100 dB (1 kHz)

(CD: 98 dB (1 kHz))

Distortion ..................................... 0.008 % (1 kHz)

Output level:

Video .................................... 1.0 Vp-p/75 W(±0.2 V)

Audio ................................... 1.1 V (1 kHz, 0 dB)

Number of channels .............. 2 (stereo), Digital 6 ch

MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3

WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10 (2ch

audio)

(Windows Media Player)

AAC decoding format ............ iTunes®Ver. 4.6

FM tuner

Frequency range ...................... 87.9 MHz to 107.9 MHz

Usable sensitivity ..................... 8 dBf (0.7 µV/75 W, mono,

S/N: 30 dB)

50 dB quieting sensitivity ..... 10 dBf (0.9 µV/75 W, mono)

Signal-to-noise ratio ............... 75 dB (IHF-A network)

Distortion ..................................... 0.3 % (at 65 dBf, 1 kHz,

stereo)

0.1 % (at 65 dBf, 1 kHz,

mono)

Frequency response ............... 30 Hz to 15 000 Hz (±3 dB)

Stereo separation .................... 45 dB (at 65 dBf, 1 kHz)

Selectivity .................................... 80 dB (±200 kHz)

Three-signal intermodulation (desired signal level)

..................................................... 30 dBf (two undesired sig-

nal level: 100 dBf)

AM tuner

Frequency range ...................... 530 kHz to 1 710 kHz (10

kHz)

Usable sensitivity ..................... 18 µV (S/N: 20 dB)

Signal-to-noise ratio ............... 65 dB (IHF-A network)

Note

Specifications and the design are subject to pos-

sible modifications without notice due to im-

provements.

Additional Information

142

Appendix

Angle icon ................................................37,.113

Aspect ratio ...........................................113,.137

Audio language .................................36,.51,.112

Bonus group ..................................................137

Bookmark .........................................................35

Brightness ......................................................119

Browsable pictures .......................................137

Chapter ...........................................................137

Code number .................................................114

Color ...............................................................119

Contrast ..........................................................119

DivX .................................................................137

DivX Certified .................................................137

Dolby Digital ..................................................137

Dolby Digital EX ......................................12,.137

Dolby Pro Logic II .........................................137

DTS .................................................................137

DTS 96/24 .......................................................137

DTS Neo:6 ......................................................138

DTS-ES ......................................................12,.138

Dynamic range control ................................138

EXIF .................................................................138

Group ..............................................................138

Hue .................................................................119

JPEG ...............................................................138

Language code chart ...................................134

Linear PCM (LPCM) ......................................139

Menu language .............................................113

MPEG ..............................................................139

Multi-angle ...............................................37,.139

Multi-audio .........................................36,.51,.139

Multi-subtitle ......................................37,.51,.139

Packed PCM ..................................................139

Parental lock ..........................................114,.139

PBC (playback control) ..................................40

Playback control (PBC) ................................140

Region number .......................................10,.140

Slideshow .......................................................140

Subtitle language ..............................37,.51,.112

Title .................................................................140

TV aspect ........................................................113

Video CD ..........................................................10

Wide screen mode ........................................119

Index

En 143

PIONEER CORPORATION

4-1, MEGURO 1-CHOME, MEGURO-KU, TOKYO 153-8654, JAPAN

PIONEER ELECTRONICS (USA) INC.

P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.

TEL: (800) 421-1404

PIONEER EUROPE NV

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium

TEL: (0) 3/570.05.11

PIONEER ELECTRONICS ASIACENTRE PTE. LTD.

253 Alexandra Road, #04-01, Singapore 159936

TEL: 65-6472-7555

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

178-184 Boundary Road, Braeside, Victoria 3195, Australia

TEL: (03) 9586-6300

PIONEER ELECTRONICS OF CANADA, INC.

300 Allstate Parkway, Markham, Ontario L3R OP2, Canada

TEL: 1-877-283-5901

PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.

Blvd.Manuel Avila Camacho 138 10 piso

Col.Lomas de Chapultepec, Mexico, D.F. 11000

TEL: 55-9178-4270

先鋒股份有限公司

總公司:台北市中山北路二段44號13樓

電話: (02) 2521-3588

先鋒電子（香港）有限公司

香港九龍尖沙咀海港城世界商業中心

9樓901-6室

電話: (0852) 2848-6488

Published by Pioneer Corporation.

Printed in Japan

<CRB2232-B> UC
