DVD Player

DV-585A-S

DV-585A-K

Operating Instructions

DV585A WY_Mid.book Page 1 Tuesday, April 5, 2005 6:35 PM

WARNING

To prevent a fire hazard, do not place any naked

flame sources (such as a lighted candle) on the

equipment.

D3-4-2-1-7a_A_En

Operating Environment

Operating environment temperature and humidity:

+5 ºC – +35 ºC (+41 ºF – +95 ºF); less than 85 %RH

(cooling vents not blocked)

Do not install this unit in a poorly ventilated area, or in

locations exposed to high humidity or direct sunlight (or

strong artificial light)

D3-4-2-1-7c_A_En

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

"dangerous voltage" within the product's

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT

D3-4-2-1-1_En-A

WARNING

This equipment is not waterproof. To prevent a fire

or shock hazard, do not place any container filed

with liquid near this equipment (such as a vase or

flower pot) or expose it to dripping, splashing, rain

or moisture.

D3-4-2-1-3_A_En

CAUTION

This product is a class 1 laser product, but this

product contains a laser diode higher than Class 1.

To ensure continued safety, do not remove any covers

or attempt to gain access to the inside of the product.

Refer all servicing to qualified personnel.

The following caution label appears on your unit.

Location: inside of the unit

CLASS 1

LASER PRODUCT

D3-4-2-1-8_A_En

VORSICHT

: SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG,WENNABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!

CAUTION

: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

ADVARSEL

: SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING UNDGÅ UDSÆTTELSE FOR STRÀLING.

VARO!

: AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.

VARNING : SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.

7260000356 SH

CUIDADO : RADIACIÓN LÁSER VISIBLE E INVISIBLE AL ESTAR ABIERTO. EVITAR EXPOSICIÓN AL RAYO.

This product complies with the Low Voltage Directive

(73/23/EEC, amended by 93/68/EEC), EMC Directives

(89/336/EEC, amended by 92/31/EEC and

93/68/EEC). D3-4-2-1-9a_En

)

WARNING

Slots and openings in the cabinet are provided for

ventilation to ensure reliable operation of the

product, and to protect it from overheating. To

prevent fire hazard, the openings should never be

blocked or covered with items (such as newspapers,

table-cloths, curtains) or by operating the

equipment on thick carpet or a bed.

D3-4-2-1-7b_A_En

When disposing of used batteries, please comply

with governmental regulations or

environmental public instruction’s rules that

apply in your country/area. D3-4-2-3-1_En

DV585A WY_Mid.book Page 2 Tuesday, April 5, 2005 6:35 PM

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and other

rights owners. Use of this copyright protection

technology must be authorized by Macrovision

Corporation, and is intended for home and other

limited viewing uses only unless otherwise

authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

This product is for general household purposes. Any

failure due to use for other than household purposes

(such as long-term use for business purposes in a res-

taurant or use in a car or ship) and which requires repair

will be charged for even during the warranty period.

K041_En

This product includes FontAvenue® fonts

licenced by NEC corporation. FontAvenue is a

registered trademark of NEC Corporation.

Do not connect either wire to the earth terminal of a

three pin plug.

NOTE

After replacing or changing a fuse, the fuse cover in

the plug must be replaced with a fuse cover which

corresponds to the colour of the insert in the base

of the plug or the word that is embossed on the

base of the plug, and the appliance must not be

used without a fuse cover. If lost replacement fuse

covers can be obtained from your dealer.

Only 5 A fuses approved by B.S.I or A.S.T.A to

B.S.1362 should be used.

D3-4-2-1-2-2_En

The wires in this mains lead are coloured in

accordance with the following code:

Blue : Neutral

Brown : Live

If the plug provided is unsuitable for your socket

outlets, the plug must be cut off and a suitable plug

fitted.

IMPORTANT

FOR USE IN THE UNITED

KINGDOM

The cut-off plug should be disposed of and must

not be inserted into any 13 amp socket as this can

result in electric shock. The plug or adaptor or the

distribution panel should be provided with 5 A fuse.

As the colours of the wires in the mains lead of this

appliance may not correspond with coloured

markings identifying the terminals in your plug,

proceed as follows ;

The wire which is coloured blue must be connected

to the terminal which is marked with the letter N or

coloured black.

The wire which is coloured brown must be

connected to the terminal which is marked with the

letter L or coloured red.

Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified

service personnel.

WARNING

The voltage of the available power supply differs

according to country or region. Be sure that the

power supply voltage of the area where this unit

will be used meets the required voltage (e.g., 230V

or 120V) written on the rear panel. D3-4-2-1-4_A_En

Before plugging in for the first time, read the following

section carefully.

POWER-CORD CAUTION

Handle the power cord by the plug. Do not pull out the

plug by tugging the cord and never touch the power

cord when your hands are wet as this could cause a

short circuit or electric shock. Do not place the unit, a

piece of furniture, etc., on the power cord, or pinch the

cord. Never make a knot in the cord or tie it with other

cords. The power cords should be routed such that they

are not likely to be stepped on. A damaged power cord

can cause a fire or give you an electrical shock. Check

the power cord once in a while. When you find it

damaged, ask your nearest PIONEER authorized

service center or your dealer for a replacement.

S002_En

CAUTION

The POWER switch on this unit will not completely

shut off all power from the AC outlet. Since the

power cord serves as the main disconnect device for

the unit, you will need to unplug it from the AC outlet

to shut down all power. Therefore, make sure the

unit has been installed so that the power cord can

be easily unplugged from the AC outlet in case of an

accident. To avoid fire hazard, the power cord should

also be unplugged from the AC outlet when left

unused for a long period of time (for example, when

on vacation).

D3-4-2-2-2a_A_En

If the AC plug of this unit does not match the AC

outlet you want to use, the plug must be removed

and appropriate one fitted. Replacement and

mounting of an AC plug on the power supply cord of

this unit should be performed only by qualified

service personnel. If connected to an AC outlet, the

cut-off plug can cause severe electrical shock. Make

sure it is properly disposed of after removal.

The equipment should be disconnected by removing

the mains plug from the wall socket when left

unused for a long period of time (for example, when

on vacation).

D3-4-2-2-1a_A_En

DV585A WY_Mid.book Page 3 Tuesday, April 5, 2005 6:35 PM

Contents

01 Contents

01 Before you start

Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . 5

What’s in the box

. . . . . . . . . . . . . . . . . . . . 6

Hints on installation

. . . . . . . . . . . . . . . . . . 6

Disc / content format playback

compatibility

. . . . . . . . . . . . . . . . . . . . . . . 7

02 Connecting up

Easy connections

. . . . . . . . . . . . . . . . . . . 10

Connecting using a SCART AV cable

. . . . 11

Connecting using the S-video output

. . . . 11

Connecting using the component video

output

. . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting to an AV receiver

. . . . . . . . . . 13

03 Controls and displays

Front panel

. . . . . . . . . . . . . . . . . . . . . . . . 15

Remote control

. . . . . . . . . . . . . . . . . . . . 16

04 Getting started

Switching on

. . . . . . . . . . . . . . . . . . . . . . 17

Using the on-screen displays

. . . . . . . . . . 17

Setting up the player for your TV

. . . . . . . . 18

Setting the language of this player’s

on-screen displays

. . . . . . . . . . . . . . . . . . 18

Playing discs

. . . . . . . . . . . . . . . . . . . . . . 19

05 Playing discs

Scanning discs

. . . . . . . . . . . . . . . . . . . . 23

Playing in slow motion

. . . . . . . . . . . . . . . 23

Frame advance/frame reverse

. . . . . . . . . 24

Viewing a JPEG slideshow

. . . . . . . . . . . . 24

Browsing DVD or Video CD/Super VCD

disc with the Disc Navigator

. . . . . . . . . . . 24

Browsing WMA, MP3, DivX video and

JPEG files with the Disc Navigator

. . . . . . 25

Looping a section of a disc

. . . . . . . . . . . . 26

Using repeat play

. . . . . . . . . . . . . . . . . . . .27

Using random play

. . . . . . . . . . . . . . . . . .27

Creating a program list

. . . . . . . . . . . . . . .28

Searching a disc

. . . . . . . . . . . . . . . . . . . .29

Switching subtitles

. . . . . . . . . . . . . . . . . .30

Switching audio language/channels

. . . . .30

Zooming the screen

. . . . . . . . . . . . . . . . . .30

Switching camera angles

. . . . . . . . . . . . .31

Displaying disc information

. . . . . . . . . . . .31

06 Audio Settings and Video Adjust

menus

Audio Settings menu

. . . . . . . . . . . . . . . . .32

Video Adjust menu

. . . . . . . . . . . . . . . . . .33

07 Initial Settings menu

Using the Initial Settings menu

. . . . . . . . .34

Digital Audio Out settings

. . . . . . . . . . . . .34

Video Output settings

. . . . . . . . . . . . . . . .35

Language settings

. . . . . . . . . . . . . . . . . . .36

Display settings

. . . . . . . . . . . . . . . . . . . . .36

Options settings

. . . . . . . . . . . . . . . . . . . .37

Parental Lock

. . . . . . . . . . . . . . . . . . . . . .37

Speakers settings

. . . . . . . . . . . . . . . . . . .40

08 Additional information

Taking care of your player and discs

. . . . .44

Screen sizes and disc formats

. . . . . . . . . .45

Setting the TV system

. . . . . . . . . . . . . . . .46

Resetting the player

. . . . . . . . . . . . . . . . . .46

DVD-Video regions

. . . . . . . . . . . . . . . . . .46

Selecting languages using the language

code list

. . . . . . . . . . . . . . . . . . . . . . . . . . .47

Language code list . . . . . . . . . . . . . . . . . . 48

Country/Area code list . . . . . . . . . . . . . . . .48

Troubleshooting . . . . . . . . . . . . . . . . . . . .49

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Specifications . . . . . . . . . . . . . . . . . . . . . . 54

DV585A WY_Mid.book Page 4 Tuesday, April 5, 2005 6:35 PM

Before you start 01

Chapter 1

Before you start

Features

• DVD-Audio and SACD compatible

Experience the super high-quality audio perfor-

mance of DVD-Audio and Super Audio CD

(SACD).

• Super VCD compatible

This player supports the IEC’s Super VCD stan-

dard. Compared to the Video CD standard,

Super VCD offers superior picture quality, and

allows two stereo soundtracks to be recorded.

Super VCD also supports the widescreen size.

• 24-bit/192kHz compatible DAC

The on-board 24-bit/192kHz DAC means that

this player is fully compatible with high

sampling-rate discs, capable of delivering

exceptional sound quality in terms of dynamic

range, low-level resolution and high-frequency

detail.

• Built-in Dolby

Digital and DTS

decoding with multichannel outputs

This player features multichannel analog

outputs for connection to an AV amplifier to

give you stunning surround sound from Dolby

Digital, DTS and multichannel DVD-Audio

discs.

• PureCinema Progressive Scan video

When connected to a progressive scan-

compatible TV or monitor using the

component video outputs, you can enjoy

extremely stable, flicker free images, with the

same frame refresh rate as the original movie.

• New Disc Navigator with moving

pictures

The new Disc Navigator enables you play the

first few seconds of each title or chapter in a

thumbnail image on screen.

• DSP effects for enhanced playback

See

Audio Settings and Video Adjust menus

page 32.

• Picture zoom

See

Zooming the screen

on page 30.

• MP3 and WMA compatibility

See

Compressed audio compatibility

on page 8.

• JPEG compatibility

See

JPEG file compatibility

on page 9.

• DivX video compatibility

See

DivX video compatibility

on page 9.

• Energy saving design

An auto power-off function switches the player

into standby if not used for about 30 minutes.

Manufactured under license from Dolby

Laboratories. “Dolby” and the double-D symbol

are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Surround” are

registered trademarks of Digital Theater

Systems Inc.

DV585A WY_Mid.book Page 5 Tuesday, April 5, 2005 6:35 PM

Before you start01

What’s in the box

Please confirm that the following accessories

are in the box when you open it.

• Remote control

• AA/R6P dry cell batteries x2

• Audio/video cable (red/white/yellow plugs)

• Power cable

• Operating instructions

• Warranty card

Putting the batteries in the remote

• Open the battery compartment cover

and insert the batteries as shown.

Use two AA/R6P batteries and follow the

indications (





) inside the compartment.

Close the cover when you’re finished.

Important

Incorrect use of batteries can result in hazards

such as leakage and bursting. Please observe

the following:

• Don’t mix new and old batteries together.

• Don’t use different kinds of battery

together—although they may look similar,

different batteries may have different

voltages.

•Make sure that the plus and minus ends of

each battery match the indications in the

battery compartment.

• Remove batteries from equipment that

isn’t going to be used for a month or more.

• When disposing of used batteries, please

comply with governmental regulations or

environmental public instruction’s rules

that apply in your country or area.

Hints on installation

We want you to enjoy using this product for

years to come, so please use the following

guidelines when choosing a suitable location:

Do...

• Use in a well-ventilated room.

•Place on a solid, flat, level surface, such as

a table, shelf or stereo rack.

Don’t...

• Use in a place exposed to high

temperatures or humidity, including near

radiators and other heat-generating

appliances.

•Place on a window sill or a place where the

player will be exposed to direct sunlight.

• Use in an excessively dusty or damp

environment.

• Place directly on top of an amplifier, or

other component in your stereo system

that becomes hot in use.

•Use near a television or monitor as you may

experience interference—especially if the

television uses an indoor antenna.

• Use in a kitchen or other room where the

player may be exposed to smoke or steam.

• Use on a thick rug or carpet, or cover with

cloth—this may prevent proper cooling of

the unit.

•Place on an unstable surface, or one that is

not large enough to support all four of the

unit’s feet.

DV585A WY_Mid.book Page 6 Tuesday, April 5, 2005 6:35 PM

Before you start 01

Disc / content format playback

compatibility

This player is compatible with a wide range of

disc types (media) and formats. Playable discs

will generally feature one of the following logos

on the disc and/or disc packaging. Note

however that some disc types, such as

recordable CD and DVD, may be in an

unplayable format—see below for further

compatibility information.

Please also note that recordable discs cannot be

recorded using this player.

•

is a trademark of DVD Format/Logo

Licensing Corporation.

• is a trademark of Fuji Photo Film Co. Ltd.

• Also compatible with KODAK Picture CD

This player supports the IEC’s Super VCD stan-

dard. Compared to the Video CD standard,

Super VCD offers superior picture quality, and

allows two stereo soundtracks to be recorded.

Super VCD also supports the widescreen size.

CD-R/RW compatibility

• Compatible formats: CD-Audio, Video CD/

Super VCD, ISO 9660 CD-ROM* containing

MP3, WMA, JPEG or DivX video files

ISO 9660 Level 1 or 2 compliant. CD

physical format: Mode1, Mode2 XA Form1.

Romeo and Joliet file systems are both

compatible with this player.

• Multi-session playback: No

• Unfinalized disc playback: No

•File structure (may differ): Up to 299 folders

on a disc; up to 648 folders and files

(combined) within each folder

DVD-R/RW compatibility

• Compatible formats: DVD-Video, Video

Recording (VR)*

Edit points may not play exactly as edited;

screen may go momentarily blank at edited

points.

• Unfinalized playback: No

• WMA/MP3/JPEG file playback on DVD-R/

RW: No

DVD-Video DVD-R DVD-RW

Video CDAudio CD CD-R CD-RW

DVD-Audio

Super Audio CD

Fujicolor CD

Super VCD

DV585A WY_Mid.book Page 7 Tuesday, April 5, 2005 6:35 PM

Before you start01

Compressed audio compatibility

•Compatible formats: MPEG-1 Audio Layer 3

(MP3), Windows Media Audio (WMA)

• Sampling rates: 32, 44.1 or 48kHz

• Bit-rates: Any (128Kbps or higher

recommended)

• VBR (variable bit rate) MP3 playback: No

• VBR WMA playback: No

• WMA lossless encoding compatible: No

• DRM (Digital Rights Management)

compatible: Yes (DRM-protected audio

files will

not

play in this player—see also

DRM

in the

Glossary

on page 52)

•File extensions: .mp3, .wma (these must be

used for the player to recognize MP3 and

WMA files – do not use for other file types)

About WMA

The Windows Media

logo printed on the box

indicates that this player can playback

Windows Media Audio content.

WMA is an acronym for Windows Media Audio

and refers to an audio compression technology

developed by Microsoft Corporation. WMA

content can be encoded by using Windows

Media

Player version 7, 7.1, Windows Media

Player for Windows

XP, or Windows Media

Player 9 Series.

Microsoft, Windows Media, and the Windows

logo are trademarks, or registered trademarks of

Microsoft Corporation in the United States and/

or other countries.

About DivX

DivX is a compressed digital video format

created by the DivX

video codec from

DivXNetworks, Inc. This player can play DivX

video files burned on CD-R/RW/ROM discs.

Keeping the same terminology as DVD-Video,

individual DivX video files are called "Titles".

When naming files/titles on a CD-R/RW disc

prior to burning, keep in mind that by default

they will be played in alphabetical order.

Displaying DivX subtitle files

The font sets listed below are available for DivX

external subtitle files. You can see the proper

font set on-screen by setting the

Subtitle

Language

(in

Language settings

on page 36)

to match the subtitle file.

This player supports the following language

groups:

Group 1:

Albanian (sq), Basque (eu), Catalan (ca),

Danish (da), Dutch (nl), English (en), Faroese (fo),

Finnish (fi), French (fr), German (de), Icelandic (is), Irish

(ga), Italian (it), Norwegian (no), Portuguese (pt), Rhaeto-

Romanic (rm), Scottish (gd), Spanish (es), Swedish (sv)

Group 2:

Albanian (sq), Croatian (hr), Czech (cs),

Hungarian (hu), Polish (pl), Romanian (ro), Slovak (sk),

Slovenian (sl)

Group 3:

Bulgarian (bg), Byelorussian (be), Macedonian

(mk), Russian (ru), Serbian (sr), Ukrainian (uk)

Group 4:

Hebrew (iw), Yiddish (ji)

Group 5:

Turkish (tr)

DivX, DivX Certified, and associated logos are

trademarks of DivXNetworks, Inc. and are used

under license.

• Some external subtitle files may be

displayed incorrectly or not at all.

• For external subtitle files the following

subtitle format filename extensions are

supported (please note that these files are

not shown within the disc navigation

menu): .srt, .sub, .ssa, .smi

• The filename of the movie file has to be

repeated at the beginning of the filename

for the external subtitle file.

DV585A WY_Mid.book Page 8 Tuesday, April 5, 2005 6:35 PM

Before you start 01

•The number of external subtitle files which

can be switched for the same movie file is

limited to a maximum of 10.

DivX video compatibility

• Official DivX

Certified product.

•Plays DivX

5, DivX

4, DivX

3 and DivX

VOD video content (in compliance with

DivX

Certified technical requirements).

• File extensions: .avi and .divx (these must

be used for the player to recognize DivX

video files).

Note that all files with the .avi

extension are recognized as MPEG4, but not

all of these are necessarily DivX video files

and therefore may not be playable on this

player.

DivX, DivX Certified, and associated logos are

trademarks of DivXNetworks, Inc. and are used

under license.

JPEG file compatibility

• Compatible formats: Baseline JPEG and

EXIF 2.2* still image files up to a resolution

of 3072 x 2048.

File format used by digital still cameras

• Progressive JPEG compatible: No

• File extensions: .jpg (must be used for the

player to recognize JPEG files – do not use

for other file types)

PC-created disc compatibility

Discs recorded using a personal computer

may not be playable in this unit due to the

setting of the application software used to

create the disc. In these particular instances,

check with the software publisher for more

detailed information.

Discs recorded in packet write mode (UDF

format) are not compatible with this player.

Check the DVD-R/RW or CD-R/RW software

disc boxes for additional compatibility

information.

DV585A WY_Mid.book Page 9 Tuesday, April 5, 2005 6:35 PM

Connecting up02

Chapter 2

Connecting up

Easy connections

The setup described here is a basic setup that allows you to play discs using just the cables

supplied with the player. In this setup, stereo audio is played through the speakers in your TV.

Important

•This player is equipped with copy protection technology. Do not connect this player to your TV

via a VCR using audio/video or S-video cables, as the picture from this player will not appear

properly on your TV. (This player may also not be compatible with some combination TV/VCRs

for the same reason; refer to the manufacturer for more information.)

S-VIDEO OUT

AUDIO OUT (5.1ch)

COMPONE NT VIDEO OUT

AUDIO OUT

(2ch)

COAXIAL

AUDIO OUT

OPTICAL

DIGITAL

VIDEO OUT

SR SW

AC IN

To power

outlet

AV CONNECTOR (RGB) TV/ AV Receiver

Yellow

White

Red

A/V IN

DV585A WY_Mid.book Page 10 Tuesday, April 5, 2005 6:35 PM

Connecting up 02

1 Connect the VIDEO OUT and AUDIO

OUT (2ch) jacks to a set of A/V inputs on

your TV.

Use the supplied audio/video cable,

connecting the red and white plugs to the

audio outputs and the yellow plug to the video

output. Make sure you match up the left and

right audio outputs with their corresponding

inputs for correct stereo sound.

See below if you want to use a component or

S-video cable for the video connection.

2Connect the supplied AC power cable to

the AC IN inlet, then plug into a power

outlet.

Note

• Before unplugging the player from the

power outlet, make sure you first switch it

into standby using either the front panel



STANDBY/ON

button, or the remote

control, and wait of the

-OFF-

message to

disappear from the player’s display.

• For the above reasons, do not plug this

player into a switched power supply found

on some amplifiers and AV receivers.

Connecting using a SCART AV

cable

A SCART-type AV connector is provided for

connection to a TV or AV receiver. The video

output is switchable between ordinary

composite, S-video and RGB. See

AV Connector

Out

on page 35 for how to set it.

The SCART AV connector also outputs analog

audio, so there is no need to also connect the

AUDIO OUT L/R

jacks.

1 Use a SCART cable (not supplied) to

connect the AV CONNECTOR (RGB) output

to a SCART AV input on your TV (or AV

receiver).

Connecting using the S-video

output

If your TV (or other equipment) has an S-video

(S1) input, you can use the S-video output on

this player instead of the standard (composite)

output for a better quality picture.

• Use an S-video cable (not supplied) to

connect the S-VIDEO OUT to an S-video

input on your TV (or monitor or AV

receiver).

Line up the small triangle above the jack with

the same mark on the plug before plugging in.

COAXIAL

AUDIO OUT

OPTICAL

DIGITAL

AC IN

AV CONN ECTOR (RGB) TV/AV Receiver

SCART

DV585A WY_Mid.book Page 11 Tuesday, April 5, 2005 6:35 PM

Connecting up02

Connecting using the

component video output

You can use the component video output

instead of the standard video out jack to

connect this player to your TV (or other

equipment). This should give you the best

quality picture from the three types of video

output available.

• Use a component video cable (not

supplied) to connect the COMPONENT

VIDEO OUT jacks to a component video

input on your TV, monitor or AV receiver.

Watching progressive scan video

from the component video outputs

This player can output progressive scan video

from the component video output. Compared

to interlace video, progressive scan video

effectively doubles the scanning rate of the

picture, resulting in a very stable, flicker-free

image.

To set up the player for use with a progressive

scan TV, see

Video Output settings

on page 35.

When the player is set to output progressive

scan video, the

PRGSVE

indicator lights in the

front panel display.

Important

• If you connect a TV that is not compatible

with a progressive scan signal and switch

the player to progressive, you will not be

able to see any picture at all. In this case,

switch everything off and reconnect using

the supplied video cable (see

Easy

connections

on page 10), then switch back

Interlace

(see below).

Switching the video output to interlace

using the front panel controls

Switch the player to standby then, using the

front panel controls, press



STANDBY/ON

while pressing



to switch the player back to

Interlace

S-VIDEO OUT

AUDIO OUT (5.1ch)

COMPONENT VIDEO OUT

AUDIO OUT

(2ch)

VIDEO OUT

SR SW

S-VIDEO

S-VIDEO OUT

AUDIO OUT (5.1ch)

COMPONENT VIDEO OUT

AUDIO OUT

(2ch)

VIDEO OUT

SR SW

COMPONENT

VIDEO IN

STANDBY/ON

   

 STANDBY/ON



DV585A WY_Mid.book Page 12 Tuesday, April 5, 2005 6:35 PM

Connecting up 02

Compatibility of this player with

progressive-scan and high-definition TVs

This player is compatible with progressive

video Macro Vision System Copy Guard.

Consumers should note that not all high-

definition television sets are fully compatible

with this product and may cause artifacts to be

displayed in the picture. In case of 525/625

progressive scan picture problems, it is

recommended that the user switch the

connection to the ‘standard definition’ output

(Interlace). If there are questions regarding our

TV set compatibility with this model, please

contact our customer service center.

This player is compatible with the following

Pioneer displays and monitors:

PDP-505HDE, PDP-435HDE

Connecting to an AV receiver

You can connect this player to your AV receiver

using the multichannel analog outputs or one

of the digital outputs.

In addition to these connections, you should

also connect the 2 channel analog outputs for

compatibility with all discs.

You’ll probably also want to connect a video

output to your AV receiver. You can use any of

the video outputs available on this player (the

illustration shows a standard (composite)

connection).

1 Connect the analog AUDIO OUT 2ch

and VIDEO OUTPUT jacks on this player to

a set of analog audio and video inputs on

your AV receiver.

2Connect the AV receiver’s video output

to a video input on your TV.

The diagram shows standard video connec-

tions, but you can alternatively use the S-Video

or component video connections if they’re avail-

able.

You can use the SCART AV connector, or the S-

video or component video jacks to connect to

the AV receiver if you prefer.

Tip

•You usually have to connect the same kind

of video cable between your DVD player

and AV receiver, and between your AV

receiver and TV.

S-VIDEO OUT

AUDIO OUT (5.1ch)

COMPONENT VIDEO OUT

AUDIO OUT

(2ch)

VIDEO OUT

SR SW

AV receiver

AUDIO/

VIDEO IN

DV585A WY_Mid.book Page 13 Tuesday, April 5, 2005 6:35 PM

Connecting up02

Connecting the multichannel analog

outputs

If your AV receiver has 5.1 channel analog

inputs, we recommend connecting this player

to it using the multichannel analog outputs.

Doing this will ensure that you can enjoy all

kinds of disc, including Dolby Digital and DTS

DVD-Video discs, as well as high sampling rate

and multichannel DVD-Audio and SACD discs.

• Connect the MULTICHANNEL AUDIO

outputs on this player to the multi-channel

audio inputs on your AV receiver.

It’s convenient to use three stereo audio

cables; one for the

FRONT

, one for the

SURROUND

and one for the

CENTER

and

SUBWOOFER

channels.

You can use the SCART AV connector, or the S-

video or component video jacks to connect to

the AV receiver if you prefer.

Tip

•After connecting up and switching on, you

should change the

Audio Output Mode

setting in the Initial Setup menu from the

default

2 Channel

5.1 Channel

. See

also

Audio Output Mode

on page 40.

Connecting the digital output

This player has both optical and coaxial-type

digital audio outputs for connection to an AV

receiver. Connect whichever is convenient.

Depending on the capabilities of your AV

receiver, you might have to set up this player to

output only digital audio in a compatible

format. See

Digital Audio Out settings

page 34 and refer to the operating instructions

that came with your AV receiver.

Note that SACD audio is not output through

these jacks, so this connection should be in

addition to, rather than instead of, a 5.1

channel analog connection.

•Connect one of the DIGITAL AUDIO OUT

jacks on this player to a digital input on

your AV receiver.

For an optical connection, use an optical cable

(not supplied) to connect the

OPTICAL

DIGITAL AUDIO OUT

jack to an optical input

on your AV receiver.

For a coaxial connection, use a coaxial cable

(similar to the supplied video cable) to connect

the

COAXIAL DIGITAL AUDIO OUT

jack to a

coaxial input on your AV receiver.

S-VIDEO OUT

AUDIO OUT (5.1ch)

COMPONENT VIDEO OUT

AUDIO OUT

(2ch)

VIDEO OUT

SR SW

AV receiver MULTI-

CH. INPUTS

COAXIAL

AUDIO OUT

OPTICAL

DIGITAL

AC IN

AV CONN ECTOR (RGB) TV/AV Receiver

AV receiver

DIGITAL IN

(OPTICAL)

DIGITAL IN

(COAXIAL)

DV585A WY_Mid.book Page 14 Tuesday, April 5, 2005 6:35 PM

Controls and displays 03

Chapter 3

Controls and displays

Front panel



STANDBY/ON

(page 17)

2 Disc tray



(page 20)



(page 20)



and



(page 20, 21)



OPEN/CLOSE

(page 19)

7 Remote control sensor

(page 16)

8 Display



(page 20)

10 RW Compatible

(page 7)

STANDBY/ON

    



6 87 93 4 5

AUDIO /VIDEO

DV585A WY_Mid.book Page 15 Tuesday, April 5, 2005 6:35 PM

Controls and displays03

Remote control



STANDBY/ON

(page 17)

2 AUDIO

(page 30)

3 SUBTITLE

(page 30)

4 Number buttons

(page 20)

5 TOP MENU

(page 21)

6 ENTER & cursor buttons

(page 17)

7 HOME MENU

(page 17)



and

/

(page 20, 23)



(page 20)



(page 20)



(page 20)

12 PLAY MODE

(page 26)

13 SURROUND

(page 32)



OPEN/CLOSE

(page 19)

15 ANGLE

(page 31)

16 CLEAR

(page 28)

17 ENTER

(page 17)

18 MENU

(page 21)

19 RETURN

(page 17)



and

/

(page 20, 23)



(page 20)



(page 20)

23 DISPLAY

(page 31)

24 ZOOM

(page 30)

Using the remote control

Keep in mind the following when using the

remote control:

• Make sure that there are no obstacles

between the remote and the remote sensor

on the unit.

• The remote has a range of about 7m.

• Remote operation may become unreliable

if strong sunlight or fluorescent light is

shining on the unit’s remote sensor.

• Remote controllers for different devices

can interfere with each other. Avoid using

remotes for other equipment located close

to this unit.

• Replace the batteries when you notice a

fall off in the operating range of the remote.

123

456

789

CLEAR

ENTER

ANGLEAUDIO

TOP MENU

HOME

SUBTITLE

PLAY MODE SURROUND

ZOOM DISPLAY

RETURN

ENTER

STANDBY/ON OPEN/CLOSE





/ /













1 14

11 22

DV585A WY_Mid.book Page 16 Tuesday, April 5, 2005 6:35 PM

Getting started 04

Chapter 4

Getting started

Switching on

After making sure that everything is connected

properly and that the player is plugged in,

press



STANDBY/ON

on the front panel or

remote control to switch the player on.

Also, switch on your TV and make sure that it is

set to the input you connected the DVD player

to.

FAQ

• My DVD player switches on but there is

nothing displayed on my TV.

Make sure that the TV is set to the correct

video input (not a TV channel). For

example, if you connected this player to the

VIDEO 1

inputs on your TV, switch your TV

VIDEO 1

Note

•This player features a screen saver and an

auto power off function. If the player is

stopped and no button is pressed for

around five minutes, the screen saver

starts. If the disc tray is closed but no disc

is playing and no control is pressed for

about 30 minutes, the player automatically

goes into standby.

Using the on-screen displays

For ease of use, this player makes extensive

use of graphical on-screen displays (OSDs).

All the screens are navigated in basically the

same way, using the cursor buttons (

///



) to change the highlighted item and

pressing

ENTER

to select it.

Note

• From here on in this manual, the word

‘select’ generally means use the cursor

buttons to highlight an item on-screen,

then press

ENTER

STANDBY/ON

   

 STANDBY/ON

Button What it does

HOME

Display/exit the on-screen display.

///

Changes the highlighted menu

item.

ENTER

Selects the highlighted menu

item (both

ENTER

buttons on the

remote work in exactly the same

way).

RETURN

Returns to the main menu

without saving changes.

ENTER

GUIDE

RETURN

ENTER

HOME

RETURN

DV585A WY_Mid.book Page 17 Tuesday, April 5, 2005 6:35 PM

Getting started04

Setting up the player for your

If you have a widescreen (16:9) TV, you should

setup the player so that the picture will be

presented correctly. If you have a conventional

(4:3) TV, you can leave the player on the default

setting and move on to the next section.

1 Press HOME MENU and select ‘Initial

Settings’.

2 Select ‘TV Screen’ from the ‘Video

Output’ settings.

3 If you have a widescreen (16:9) TV,

select ‘16:9 (Wide)’.

If you have a conventional (4:3) TV, you can

change the setting from

4:3 (Letter Box)

4:3

(Pan & Scan)

if you prefer. See

Video Output

settings

on page 35 for more details.

4 Press HOME MENU to exit the menu

screen.

Setting the language of this

player’s on-screen displays

This sets the language of the player’s on-

screen displays.

1 Press HOME MENU and select ‘Initial

Settings’.

2 Select ‘OSD Language’ from the

‘Display’ settings.

3 Select a language.

The on-screen language will change according

to your selection.

4 Press HOME MENU to exit the menu

screen.

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Speakers

TV Screen

Component Out

AV Connector Out

4:3 (Letter Box)

4:3 (Pan&Scan)

16:9 (Wide)

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Speakers

OSD Language

Angle Indicator

English

français

Deutsch

Italiano

Español

Initial Settings

DV585A WY_Mid.book Page 18 Tuesday, April 5, 2005 6:35 PM

Getting started 04

Playing discs

The basic playback controls for playing DVD,

CD, SACD, Video CD/Super VCD, DivX video

and MP3/WMA discs are covered here. Further

functions are detailed in the next chapter.

For details on playing JPEG picture discs, see

Viewing a JPEG slideshow

on page 24.

Important

• Throughout this manual, the term ‘DVD’

means DVD-Video, DVD-Audio and DVD-R/

RW. If a function is specific to a particular

kind of DVD disc, it is specified.

1 If the player isn’t already on, press



STANDBY/ON to switch it on.

If you’re playing a DVD, disc containing DivX

video files or Video CD/Super VCD, also turn on

your TV and make sure that it is set to the

correct video input.

2 Press



OPEN/CLOSE to open the disc

tray.

3 Load a disc.

Load a disc with the label side facing up, using

the disc tray guide to align the disc (if you’re

loading a double-sided DVD disc, load it with

the side you want to play face down).

4 Press



(play) to start playback.

If you’re playing a DVD or Video CD/Super VCD,

an on-screen menu may appear. See

DVD disc

menus

on page 21 and

Video CD/Super VCD

PBC menus

on page 21 for more on how to

navigate these.

• If you’re playing a containing DivX video

files or MP3/WMA audio files, it may take a

few seconds before playback starts, etc.

This is normal.

Note

• You may find with some DVD discs that

some playback controls don’t work in

certain parts of the disc. This is not a

malfunction.

• If a disc contains a mixture of DivX video

and other media file types (MP3, for

example), first select whether to play the

DivX video files (

DivX

)or the other media

file types (

MP3 / WMA / JPEG

) from the

on-screen display.

123

456

789

STANDBY/ON

OPEN/CLOSE

ENTER





/ /













DV585A WY_Mid.book Page 19 Tuesday, April 5, 2005 6:35 PM

Getting started04

Basic playback controls

The table below shows the basic controls on

the remote for playing discs. The following

chapter covers other playback features in more

detail.

Resume and Last Memory

With the exception of DVD-Audio and SACD

discs, when you stop playback of a DVD, CD,

Video CD/Super VCD or DivX video discs,

RESUME

is shown in the display indicating

that you can resume playback again from that

point.

If the disc tray is not opened, the next time you

start playback the display shows

RESUME

and

playback resumes from the resume point. (If

you want to clear the resume point, press



(stop) while

RESUME

is displayed.)

With DVDs and Video CD/Super VCDs, if you

take the disc out of the player after stopping

playback, the last play position is stored in

memory. If the next disc you load is the same

one, the display shows

LAST MEM

and

playback will resume. For DVD-Video discs,

the player stores the play position of the last

five discs. When one of these discs is next

loaded, you can resume playback.

Note

• The Last Memory function doesn’t work

with VR format DVD-RW, DVD-Audio or

SACD discs.

Button What it does



Starts playback.

If the display shows

RESUME

LAST MEM

playback starts from the

resume or last memory point (see

also

Resume and Last Memory

below.)



Pauses a disc that’s playing, or

restarts a paused disc.



Stops playback.

more on disc compatibility.

•I have a widescreen TV so why are there

black bars at the top and bottom of the

screen when I play some discs?

Some movie formats are such that even

when played on a widescreen TV, black

bars are necessary at the top and bottom of

the screen. This is not a malfunction.

•I have a standard (4:3) TV and set the player

to show widescreen DVDs in pan & scan

format, so why do I still get black bars top

and bottom with some discs?

Some discs override the display

preferences of the player, so even if you

have

4:3 (Pan & Scan)

selected, those

discs will still be shown in letter box format.

This is not a malfunction.

• My AV receiver is definitely compatible with

96/88.2kHz Linear PCM audio, but it doesn’t

seem to work with this player. What’s

wrong?

For digital copy-protection purposes, some

96/88.2kHz DVD discs only output digital

audio downsampled to 48/44.1kHz. This is

not a malfunction.

To fully take advantage of the high

sampling rate audio, connect the analog

audio outputs to your amplifier/receiver.

• Why can’t I hear SACD audio through the

digital outputs?

SACD audio is only available through the

analog outputs. This is not a malfunction.

Some DVD-Audio discs too only output

audio through the analog outputs.

• Is it better to listen to DVD-Audio discs

through the analog outputs?

Some DVD-Audio discs do not output

anything through the digital outputs, and

multichannel discs are downmixed to

stereo for the digital output. In addition,

high sampling rate DVD-Audio discs

(higher than 96kHz) automatically

downsample audio output from the digital

outputs.

Using the multichannel analog audio

outputs for DVD-Audio have none of these

limitations.

•My DVD-Audio disc starts playing, but then

suddenly stops!

The disc may have been illegally copied.



Displays the previous menu page

(if there is one).



Displays the next menu page (if

there is one).

Button What it does

DV585A WY_Mid.book Page 22 Tuesday, April 5, 2005 6:35 PM

Playing discs 05

Chapter 5

Playing discs

Note

• Many of the functions covered in this

chapter apply to DVD and SACD discs,

Video CDs/Super VCDs, CDs, DivX video

and WMA/MP3 JPEG discs, although the

exact operation of some varies slightly with

the kind of disc loaded.

• Some DVDs restrict the use of some

functions (random or repeat, for example)

in some or all parts of the disc. This is not a

malfunction.

•When playing Video CD/Super VCDs, some

of the functions are not available during

PBC playback. If you want to use them,

start the disc playing using a number

button to select a track.

Scanning discs

You can fast-scan discs forward or backward at

four different speeds (DivX video only one

speed).

1 During playback, press





start scanning.

• There is no sound while scanning DVDs

(including DVD-Audio), DivX video and

Video CD/Super VCDs.

2 Press repeatedly to increase the

scanning speed.

• The scanning speed is shown on-screen.

3 To resume normal playback, press



(play).

• When scanning a Video CD/Super VCD

playing in PBC mode or a WMA/MP3 track,

playback automatically resumes at the end

or beginning of the track.

• Depending on the disc, normal playback

may automatically resume when a new

chapter is reached on a DVD disc.

Playing in slow motion

You can play DVD-Videos and DVD-R/RW at

four different slow motion speeds, forwards

and backwards. Video CD/Super VCDs and

DivX video can be played at four different

forward slow motion speeds.

1 During playback, press



(pause).

2 Press and hold

/

/

until

slow motion playback starts.

• The slow motion speed is shown on-

screen.

• There is no sound during slow motion

playback.

3 Press repeatedly to change the slow

motion speed.

4 To resume normal playback, press



(play).

• Depending on the disc, normal playback

may automatically resume when a new

chapter is reached.

DV585A WY_Mid.book Page 23 Tuesday, April 5, 2005 6:35 PM

Playing discs05

Frame advance/frame reverse

You can advance or back up DVD-Video and

DVD-R/RW discs frame-by-frame. With Video

CD/Super VCDs and DivX video file you can

only use frame advance.

1 During playback, press



(pause).

2 Press

/

/

to reverse or

advance a frame at a time.

3 To resume normal playback, press



(play).

• Depending on the disc, normal playback

may automatically resume when a new

chapter is reached.

Viewing a JPEG slideshow

After loading a CD/CD-R/RW containing JPEG

picture files, press



(play) to start a slideshow

from the first folder/picture on the disc. The

player displays the pictures in each folder in

alphabetical order.

Pictures are automatically adjusted so that

they fill as much of the screen as possible (if

the aspect ratio of the picture is different to

your TV screen you may notice black bars at the

sides, or at the top and bottom of the screen).

While the slideshow is running:

Note

•The time it takes for the player to load a file

increases with large file sizes.

Browsing DVD or Video CD/

Super VCD disc with the Disc

Navigator

Use the Disc Navigator to browse through the

contents of a DVD-Video,DVD-RW or Video CD/

Super VCD disc to find the part you want to

play.

Important

• You can’t use the Disc Navigator with

Video CD/Super VCDs in PBC mode.

1 During playback, press HOME MENU

and select ‘Disc Navigator’ from the on-

screen menu.

Button What it does



Pauses the slideshow; press again to

restart.



Displays the previous picture.



Displays the next picture.

/

Pauses the slideshow and rotates the

displayed picture 90º (counter)

clockwise. (Press



(play) to restart

slideshow.)

/

Pauses the slideshow and ﬂips the

displayed picture horizontally or

vertically. (Press



(play) to restart

slideshow.)

ZOOM

Pauses the slideshow and zooms the

picture. Press again to toggle

between 1x, 2x and 4x zoom. (Press



(play) to restart slideshow.)

Displays the Disc Navigator screen

(see below).

Button What it does

Disc Navigator

DV585A WY_Mid.book Page 24 Tuesday, April 5, 2005 6:35 PM

Playing discs 05

2 Select a view option.

The options available depend on the kind of

disc loaded and whether the disc is playing or

not, but include:

•

Title

– Titles from a DVD-Video disc.

•

Chapter

– Chapters from the current title

of a DVD-Video disc.

•

Track

– Tracks from a Video CD/Super VCD

disc.

•

Time

– Thumbnails from a Video CD/Super

VCD disc at 10 minute intervals.

•

Original: Title

– Original titles from a VR

mode DVD-RW disc.

•

Playlist: Title

– Playlist titles from a VR

mode DVD-RW disc.

•

Original: Time

– Thumbnails from the

Original content at 10 minute intervals.

•

Playlist: Time

– Thumbnails from the

Playlist at 10 minute intervals.

The screen shows up to six moving thumbnail

images displayed one after another. To display

the previous/next six thumbnails, press





(you don’t have to wait for all the

thumbnails to finish playing to display the

previous/next page).

3 Select the thumbnail image for what

you want to play.

You can use either the cursor buttons (

//

/

) and

ENTER

to select a thumbnail, or the

number buttons.

To select using the number buttons, enter a

two-digit number then press

ENTER

Tip

•Another way to find a particular place on a

disc is to use one of the search modes. See

Searching a disc

on page 29.

Browsing WMA, MP3, DivX

video and JPEG files with the

Disc Navigator

Use the Disc Navigator to find a particular file

or folder by filename. Note that if there are

other types of files on the same disc, these will

not be displayed in the Disc Navigator.

1 Press HOME MENU and select ‘Disc

Navigator’ from the on-screen menu.

2 Use the cursor buttons (

///

)

and ENTER to navigate.

Use the cursor up/down buttons (

/

) to

move up and down the folder/file list.

Use the cursor left button (



) to return to the

parent folder.

Use

ENTER

or cursor right (



) to open a

highlighted folder.

•You can also return to the parent folder by

going to the top of the list to the ‘

’ folder,

then pressing

ENTER

Disc Navigator

Title

Chapter

Disc Navigator: Title

01- 49: - -

00:00/ 00:00 0kbps

Folder1

Folder2

Folder3

Folder4

DV585A WY_Mid.book Page 25 Tuesday, April 5, 2005 6:35 PM

Playing discs05

• When a JPEG file is highlighted, a

thumbnail image is displayed on the right.

3 To play the highlighted track or DivX

video file or display the highlighted JPEG

file, press ENTER.

•When a WMA/MP3 or DivX video file is

selected, playback begins, starting with the

selected file, and continues until the end of

the folder.

• When a JPEG file is selected, a slideshow

begins, starting with that file, and

continues to the end of the folder.

Tip

• To play the contents of the whole disc

rather than just the current folder, exit the

Disc Navigator and start playback using

the



(play) button.

Looping a section of a disc

The A-B Repeat function allows you to specify

two points (A and B) within a track (CD, Video

CD/Super VCD) or title (DVD-Video and DVD-

RW) that form a loop which is played over and

over.

•You can’t use A-B Repeat with DVD-Audio,

SACD, Video CD/Super VCDs in PBC

mode, or WMA/MP3/DivX video files.

1During playback, press PLAY MODE and

select ‘A-B Repeat’ from the list of

functions on the left.

2 Press ENTER on ‘A(Start Point)’ to set

the loop start point.

3Press ENTER on ‘B(End Point)’ to set the

loop end point.

After pressing

ENTER

, playback jumps back to

the start point and plays the loop.

4To resume normal playback, select ‘Off’

from the menu.

File1

File2

File3

File4

File5

Folder2

00:00/ 00:00 0kbps

A(Start Point)

B(End Point)

Off

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

DV585A WY_Mid.book Page 26 Tuesday, April 5, 2005 6:35 PM

Playing discs 05

Using repeat play

There are various repeat play options,

depending on the kind of disc loaded. It’s also

possible to use repeat play together with

program play to repeat the tracks/chapters in

the program list (see

Creating a program list

page 28).

Important

• You can’t use Repeat play with Video CD/

Super VCDs in PBC mode, or with WMA/

MP3 discs.

• You can’t use repeat and random play at

the same time.

1During playback, press PLAY MODE and

select ‘Repeat’ from the list of functions on

the left.

2 Select a repeat play option.

If program play is active, select

Program

Repeat

to repeat the program list, or

Repeat

Off

to cancel.

The repeat options available depend on the

kind of disc loaded. For example, for DVD-

Video and DVD-RW discs, you can select

Title

Repeat

Chapter Repeat

(or

Repeat Off

• For DVD-Audio discs, select

Group

Repeat

Track Repeat

(or

Repeat Off

•For SACDs,CDs and Video CD/Super

VCDs, select

Disc Repeat

Track Repeat

(or

Repeat Off

• For DivX video discs, select

Title

Repeat

(or

Repeat Off

Using random play

Use the random play function to play titles or

chapters (DVD-Video), Groups (DVD-Audio), or

tracks (DVD-Audio, SACD, CD, Video CD/

Super VCD) at random. (Note that the same

track/title/chapter may play more than once.)

You can set the random play option when a

disc is playing or stopped.

Important

• Random play remains in effect until you

select

Random Off

from the random play

menu options.

•You can’t use random play with VR format

DVD-RW discs, Video CD/Super VCDs

playing in PBC mode, WMA/MP3 discs,

DivX video discs, or while a DVD disc menu

is being displayed.

• You can't use random play together with

program or repeat play.

1 Press PLAY MODE and select ‘Random’

from the list of functions on the left.

Title Repeat

Chapter Repeat

Repeat Off

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

Title Repeat

Chapter Repeat

Repeat Off

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

Random Title

Random Chapter

Random Off

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

DV585A WY_Mid.book Page 27 Tuesday, April 5, 2005 6:35 PM

Playing discs05

2 Select a random play option.

The random play options available depend on

the kind of disc loaded. For example, for DVD-

Video discs, you can select

Random Title

Random Chapter

(or

Random Off

• For DVD-Audio discs, select

Random

Group

Random Track

, (or

Random

Off

•For CDs, SACDs and Video CD/Super

VCDs, select

Off

to switch random

play on or off.

Tip

• Use the following controls during random

play:

Creating a program list

This feature lets you program the play order of

titles/chapters/groups/tracks on a disc.

Important

•You can’t use Program play with VR format

DVD-RW discs, Video CD/Super VCDs

playing in PBC mode, WMA/MP3 discs,

DivX video discs, or while a DVD disc menu

is being displayed.

1Press PLAY MODE and select ‘Program’

from the list of functions on the left.

2 Select ‘Create/Edit’ from the list of

program options.

3 Use the cursor buttons and ENTER to

select a title, chapter or track for the

current step in the program list.

For a DVD-Video disc, you can add a title or a

chapter to the program list.

•For a DVD-Audio disc, you can add a whole

group, or a track within a group to the

program list.

•For a CD, SACD or Video CD/Super VCD,

select a track to add to the program list.

Button What it does



Selects a new track/title/chapter

at random.



Returns to the beginning of the

current track/title/chapter;

further presses select another

random track/title/chapter.

Random Title

Random Chapter

Random Off

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

Create/Edit

Playback Start

Playback Stop

Program Delete

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

Program Step

01. 01

02.

03.

04.

05.

06.

07.

08.

Title 1~38

Title 01

Title 02

Title 03

Title 04

Title 05

Title 06

Title 07

Title 08

Chapter 1~004

Chapter 001

Chapter 002

Chapter 003

Chapter 004

Program

DV585A WY_Mid.book Page 28 Tuesday, April 5, 2005 6:35 PM

Playing discs 05

After pressing

ENTER

to select the title/

chapter/group/track, the step number

automatically moves down one.

4Repeat step 3 to build up a program list.

A program list can contain up to 24 titles/

chapters/tracks.

• You can insert steps into the middle of a

program list by just highlighting the

position where you want the new step to

appear and entering a title/chapter/group/

track number.

• To delete a step, highlight it and press

CLEAR

5To play the program list, press



(play).

Program play remains active until you turn off

program play (see below), erase the program

list (see below), eject the disc or switch off the

player.

Tip

•Use the following controls during program

play:

Other functions available from the

program menu

There are a number of other options in the

program menu in addition to Create/Edit.

•

Playback Start

– Starts playback of a

saved program list

•

Playback Stop

– Turns off program play,

but does not erase the program list

•

Program Delete

– Erases the program list

and turns off program play

Searching a disc

You can search DVD-Video discs by title or

chapter number, or by time; DVD-Audio discs

can be searched by group or track number;

SACDs by track number, CDs and Video CD/

Super VCDs by track number or time; DivX

video discs by time.

Important

• Search functions are not available with

Video CD/Super VCDs in PBC mode, or

with WMA/MP3 discs.

1 Press PLAY MODE and select ‘Search

Mode’ from the list of functions on the left.

2 Select a search mode.

The search options available depend on the

kind of disc loaded.

• The disc must be playing in order to use

time search.

3Use the number buttons to enter a title,

chapter or track number, or a time.

• For a time search, enter the number of

minutes and seconds into the currently

playing title (DVD/ DivX video) or track (CD/

Video CD/Super VCD) you want playback to

resume from. For example, press

to have playback start from 45 minutes into

the disc. For 1 hour, 20 minutes and 30

seconds, press

Button What it does

PLAY

MODE

Save the program list and exit

the program edit screen without

starting playback (

HOME MENU

does the same).



Skip to the next step in the

program list.

0 0 1

Title Search

Chapter Search

Time Search

Input Chapter

A-B Repeat

Repeat

Random

Program

Search Mode

Play Mode

DV585A WY_Mid.book Page 29 Tuesday, April 5, 2005 6:35 PM

Playing discs05

• Some DVD-Audio discs feature pages of

browsable pictures. Enter the page

number you want.

4 Press ENTER to start playback.

Switching subtitles

Some DVD-Video and DivX video discs have

subtitles in one or more languages; the disc

box will usually tell you which subtitle

languages are available. You can switch

subtitle language during playback.

1 Press SUBTITLE repeatedly to select a

subtitle option.

Note

• Some discs only allow you to change

subtitle language from the disc menu.

Press

TOP MENU

to access.

• To set subtitle preferences, see

Subtitle

Language

on page 36.

• See

Displaying DivX subtitle files

on page 8

for more on DivX subtitles.

Switching audio language/

channels

When playing a DVD-Video and DivX video disc

recorded with dialog in two or more languages,

you can switch audio language during

playback.

When playing a VR format DVD-RW disc

recorded with dual-mono audio, you can

switch between the main, sub, and mixed

channels during playback.

When playing a DVD-Audio disc, you may be

able to switch channels—see the disc box for

details. (When you change the audio channel,

playback restarts from the beginning of the

current track.)

When playing a Video CD/Super VCD, you can

switch between stereo, just the left channel or

just the right channel.

1 Press AUDIO repeatedly to select an

audio language/channel option.

The language/channel information is shown

on-screen.

Note

•Some DVD discs only allow you to change

audio language from the disc menu. Press

TOP MENU

to access.

• To set DVD audio language preferences,

see

Language settings

on page 36.

Zooming the screen

Using the zoom feature you can magnify a part

of the screen by a factor of 2 or 4, while

watching a DVD, DivX video title or Video CD/

Super VCD or playing a JPEG disc.

1During playback, use the ZOOM button

to select the zoom factor (Normal, 2x or

4x).

• Since DVD, Video CD/Super VCD, DivX

video title and JPEG pictures have a fixed

resolution, picture quality will deteriorate,

especially at 4x zoom. This is not a

malfunction.

2 Use the cursor buttons to change the

zoomed area.

You can change the zoom factor and the

zoomed area freely during playback.

• If the navigation square at the top of the

screen disappears, press

ZOOM

again to

display it.

Subtitle English1/2

Current / Total

DV585A WY_Mid.book Page 30 Tuesday, April 5, 2005 6:35 PM

Playing discs 05

Switching camera angles

Some DVD discs feature scenes shot from two

or more angles—check the disc box for details.

When a multi-angle scene is playing, a

icon appears on screen to let you know that

other angles are available (this can be

switched off if you prefer—see

Display settings

on page 36).

1 During playback (or when paused),

press ANGLE to switch angle.

Displaying disc information

Various track, chapter and title information,

such as the elapsed and remaining playing

time can be displayed on-screen while a disc is

playing.

1 To show/switch/hide the information

displayed, press DISPLAY repeatedly.

• When a disc is playing, the information

appears at the top of the screen. Keep

pressing

DISPLAY

to change the displayed

information.

DV585A WY_Mid.book Page 31 Tuesday, April 5, 2005 6:35 PM

Audio Settings and Video Adjust menus06

Chapter 6

Audio Settings and Video

Adjust menus

Audio Settings menu

The Audio Settings menu offers features for

adjusting the way discs sound.

1 Press HOME MENU and select ‘Audio

Settings’ from the on-screen display.

2Select and change settings using the

/

//

(cursor) buttons, and ENTER.

Audio DRC

• Settings:

High

Medium

Low

Off

(default)

When watching Dolby Digital DVDs at low

volume, it’s easy to lose the quieter sounds

completely—including some of the dialog.

Switching Audio DRC (Dynamic Range

Control) to on can help by bringing up the

quieter sounds, while controlling loud peaks.

How much of a difference you hear depends on

the material you’re listening to. If the material

doesn’t have wide variations in volume, you

may not notice much change.

Note

• Audio DRC is only effective with Dolby

Digital audio sources.

• Audio DRC is only effective through the

digital output when

Digital Out

is set to

, and

Dolby Digital Out

is set to

Dolby

Digital > PCM

(see

Digital Audio Out

settings

on page 34).

• The effect of Audio DRC also depends on

your speakers and AV receiver settings.

Virtual Surround

• Settings:

Off

(default)

Switch on Virtual Surround to enjoy realistic

surround sound effects from just two speakers.

Tip

• You can also use the

SURROUND

button

on the remote control to switch Virtual

Surround on.

Note

• 96kHz linear PCM audio is automatically

downsampled to 48kHz if Virtual Surround

is switched on.

• The

Audio Output Mode

(see page 40)

must be set to

2 Channel

in order to be

able to use Virtual Surround.

Audio Settings

Virtual Surround

Audio DRC

Dialog

Off

DV585A WY_Mid.book Page 32 Tuesday, April 5, 2005 6:35 PM

Audio Settings and Video Adjust menus 06

• If the player is outputting Dolby Digital,

DTS or MPEG bitstream audio (in other

words, no conversion to PCM), Virtual

Surround has no effect on the audio from

the digital output. See

Digital Audio Out

settings

on page 34 for how to set up the

digital output formats.

•How good the surround effect is varies with

the disc.

Dialog

• Settings:

High

Medium

Low

Off

(default)

The Dialog feature is designed to make the

dialog stand out from other background

sounds in the soundtrack.

Video Adjust menu

From the Video Adjust screen you can adjust

various settings that affect how the picture is

presented.

1 Press HOME MENU and select ‘Video

Adjust’ from the on-screen display.

2 Make settings using the

///

(cursor) buttons, and ENTER.

You can adjust the following picture quality

settings:

•

Sharpness

– Adjusts the sharpness of

edges in the picture (

Fine

Standard

(default)

Soft

•

Brightness

– Adjusts the overall

brightness (

–20

+20

•

Contrast

– Adjusts the contrast between

light and dark (

–16

+16

•

Gamma

– Adjusts the ‘warmth’ of the

picture (

High

Medium

Low

Off

(default)

•

Hue

– Adjusts the red/green balance

(

Green 9

Red 9

•

Chroma Level

– Adjusts how saturated

colors appear (

–9

•

BNR

– Switches on/off block noise

reduction (

Off

(default)

Adjust the Brightness, Contrast, Hue and

Chroma Level settings using the

/

(cursor

left/right) buttons.

3 Press ENTER to return to the Video

Adjust screen, or HOME MENU to exit.

Video Adjust

Sharpness

Brightness

Contrast

Gamma

Hue

Chroma Level

BNR

Standard

Off



Video Adjust

Brightness min max 0

DV585A WY_Mid.book Page 33 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu07

Chapter 7

Initial Settings menu

Using the Initial Settings menu

The Initial Settings menu provides audio and

video output settings, parental lock settings,

and display settings, among others.

If an option is grayed out it means that it

cannot be changed at the current time. This is

usually because a disc is playing. Stop the

disc, then change the setting.

1 Press HOME MENU and select ‘Initial

Settings’.

2 Use the cursor buttons and ENTER to

select the setting and option you want to

set.

All the settings and options are explained on

the following pages.

Note

• In the table below, the default setting is

shown in

bold

: other settings are shown in

italics

•The Digital Audio Out settings only need to

be set if you have connected the digital

output of this player to an AV receiver, or

other equipment.

• Check the operating instructions supplied

with your other equipment to see which

digital audio formats it’s compatible with.

•Some settings, such as

TV Screen

Audio

Language

and

Subtitle Language

may be

overridden by the DVD disc. Often these

settings can also be made from the DVD

disc menu.

Digital Audio Out settings

Initial Settings

Setting Option What it means

Digital Out On

Digital audio is output from the digital outputs.

Note that there is no digital output when playing SACDs and

DVD-Audio discs regardless of this setting.

Off

No digital audio output.

Dolby Digital Out Dolby Digital

Dolby Digital encoded digital audio is output when playing a

Dolby Digital DVD disc.

Dolby Digital > PCM

Dolby Digital audio is converted to PCM audio before being

output.

DTS Out DTS

DTS encoded digital audio is output when playing a DTS disc.

(Noise will be output if your amplifier/receiver is not compatible

with DTS audio.)

DTS > PCM

No digital audio is output when playing a DTS disc.DTS audio

is converted to PCM audio before being output.

DV585A WY_Mid.book Page 34 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu 07

Video Output settings

Linear PCM Out Down Sample On

96kHz digital audio is converted to 48kHz for digital output.

Note that High sampling rate DVD-Audio discs (192kHz or

176.4kHz) automatically output down-sampled audio through

the digital outputs.

Down Sample Off

96kHz digital audio is output as is at 96kHz.

MPEG Out MPEG > PCM

MPEG encoded digital audio is converted to PCM audio for

digital output.

MPEG

MPEG encoded digital audio is output as is.

Setting Option What it means

TV Screen

(See also

Screen sizes

and disc formats

page 45.)

4:3 (Letter Box)

Set if you have a conventional 4:3 TV. Widescreen movies are

shown with black bars top and bottom.

4:3 (Pan & Scan)

Set if you have a conventional 4:3 TV. Widescreen movies are

shown with the sides cropped so that the image fills the screen.

16:9 (Wide)

Set if you have a widescreen TV.

Component Out Interlace

Set if your TV is not compatible with progressive scan video.

Progressive

Set if your TV is compatible with progressive scan video (see

your TV’s instruction manual for details). See also

Switching

the video output to interlace using the front panel controls

page 12.

Note that progressive scan video is only output from the

component video jacks.

AV Connector Out Video

Ordinary (composite) video output, compatible with all TVs.

RGB

If your TV is compatible, this setting gives the best picture

quality.

Note that there is no output from the component jacks when

this setting selected.

Setting Option What it means

DV585A WY_Mid.book Page 35 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu07

Language settings

Display settings

Setting Option What it means

Audio Language English

If there is an English soundtrack on the disc then it will be

played.

Languages as displayed

If there is the language selected on the disc, then it will be

played.

Other Language

Select to choose a language other than the ones displayed (see

page 47).

Subtitle Language

(See also

Displaying

DivX subtitle files

page 8.)

English

If there are English subtitles on the disc then they will be

displayed.

Languages as displayed

If there is the subtitle language selected on the disc, then it will

be displayed.

Other Language

Select to choose a language other than the ones displayed (see

page 47).

DVD Menu

Language

w/Subtitle Lang.

DVD disc menus will be displayed in the same language as

your selected subtitle language, if possible.

Languages as displayed

DVD disc menus will be displayed in the selected language, if

possible.

Other Language

Select to choose a language other than the ones displayed (see

page 47).

Subtitle Display On

Subtitles are displayed according to your selected subtitle

language (see above).

Off

Subtitles are always off by default when you play a DVD disc

(note that some discs override this setting).

Setting Option What it means

OSD Language English

On-screen displays of the player are in English.

Languages as displayed

On-screen displays are shown in the language selected.

Angle Indicator On

A camera icon is displayed on-screen during multi-angle

scenes on a DVD disc.

Off

No multi-angle indication is shown.

DV585A WY_Mid.book Page 36 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu 07

Options settings

Parental Lock

•Default level:

Off

; Default password:

none

;

Default Country/Area code:

us (2119)

To give you some control over what your

children watch on your DVD player, some DVD-

Video discs feature a Parental Lock level. If

your player is set to a lower level than the disc,

the disc won’t play.

Some discs also support the Country/Area

Code feature. The player does not play certain

scenes on these discs, depending on the

Country/Area Code you set.

Note

• Not all discs use Parental Lock, and will

play without requiring the password first.

• If you forget your password, you’ll need to

reset the player to register a new password.

(see

Resetting the player

on page 46)

Registering a new password

You must register a password before you can

change the Parental Lock level or enter a

Country code.

1 Select ‘Options’, then ‘Password’.

2 Use the number buttons to enter a 4-

digit password.

The numbers you enter show up as asterisks

(*) on-screen.

3 Press ENTER to register the password.

You will return to the Options menu screen.

Setting Option What it means

Parental Lock –

See

Parental Lock

on page 37.

DVD Playback

Mode

DVD-Audio

All material on a DVD-Audio disc is playable.

DVD-Video

Only the DVD-Video part of a DVD-Audio disc is playable.

SACD Playback 2ch Area

Selects the 2 channel (strereo) SACD audio area of the disc

for playback.

Multi-ch Area

Selects the multi-channel SACD audio area of the disc for

playback.

CD Area

Selects the standard CD audio area of an SACD/CD hybrid

disc for playback.

DTS Downmix Stereo

Downmixes DTS for 2 channel output to regular stereo. (See

also

DTS Downmix

on page 38.)

Lt/Rt

Downmixes DTS for 2 channel output to be compatible with

Dolby Surround matrix decoders. (See also

DTS Downmix

page 38.)

DivX VOD Display

See

About DivX® VOD content

on page 39.

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Parental Lock

DVD Playback Mode

SACD Playback

DTS Downmix

DivX VOD

Password

Level Change

Country Code

Initial Settings

DV585A WY_Mid.book Page 37 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu07

Changing your password

To change your password, confirm your

existing password then enter a new one.

1 Select ‘Password Change’.

2 Use the number buttons to enter your

existing password, then press ENTER.

3Enter a new password and press ENTER.

This registers the new password and you will

return to the Options menu screen.

Setting/changing the Parental Lock

1 Select ‘Level Change’.

2 Use number buttons to enter your

password, then press ENTER.

3 Select a new level and press ENTER.

• Press



(cursor left) repeatedly to lock

more levels (more discs will require the

password); press



(cursor right) to

unlock levels. You can’t lock level 1.

This sets the new level and you will return to the

Options menu screen.

Setting/changing the Country/Area

code

You can find the

Country/Area code list

page 48.

1 Select ‘Country Code’.

2 Use number buttons to enter your

password, then press ENTER.

3 Select a Country/Area code and press

ENTER.

There are two ways you can do this:

•Select by code letter: Use

/

(cursor up/

down) to change the Country/Area code.

• Select by code number: Press



(cursor

right) then use the number buttons to enter

the 4-digit Country/Area code.

The new Country/Area code is set and you will

return to the Options menu screen. Note that

the new Country/Area code doesn’t take effect

until the next disc is loaded (or the current disc

is reloaded).

DTS Downmix

• Default setting:

Stereo

If you’ve selected

DTS > PCM

DTS Out

page 34 or

2 Channel

Audio Output Mode

page 40, you can choose the way the signal is

downmixed to PCM audio.

Stereo

will

downmix the DTS signal to 2-channel stereo,

whereas

Lt/Rt

will downmix to a 2-channel

signal compatible with Dolby surround matrix

decoders. (This allows you to hear surround

sound if your AV receiver or amplifier has Dolby

Pro Logic capability.)

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Stereo

Lt/Rt

Initial Settings

Parental Lock

DVD Playback Mode

SACD Playback

DTS Downmix

DivX VOD

DV585A WY_Mid.book Page 38 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu 07

About DivX

VOD content

In order to play DivX VOD (video on demand)

content on this player, you first need to register

the player with your DivX VOD content

provider. You do this by generating a DivX VOD

registration code, which you submit to your

provider.

Important

• DivX VOD content is protected by a DRM

(Digital Rights Management) system. This

restricts playback of content to specific,

registered devices.

• If you load a disc that contains DivX VOD

content not authorized for your player, the

message

Authorization Error

is displayed

and the content will not play.

• Resetting the player (as described in

Resetting the player

in the main Operating

Instructions) will not cause you to lose your

registration code.

Displaying your DivX VOD

registration code

1 Press HOME MENU and select ‘Initial

Settings’.

2 Select ‘Options’, then ‘DivX VOD’.

3 Select ‘Display’.

Your 8-digit registration code is displayed.

Make a note of the code as you will need it

when you register with a DivX VOD provider.

Playing DivX

VOD content

Some DivX VOD content may only be playable

a fixed number of times. When you load a disc

containing this type of DivX VOD content, the

remaining number of plays is shown on-screen

and you then have the option of playing the

disc (thereby using up one of the remaining

plays), or stopping. If you load a disc that

contains expired DivX VOD content (for

example, content that has zero remaining

plays), the message

Rental Expired

displayed.

If your DivX VOD content allows an unlimited

number of plays, then you may load the disc

into your player and play the content as often

as you like, and no message will be displayed.

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Parental Lock

DVD Playback Mode

SACD Playback

DTS Downmix

DivX VOD

Display

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Initial Settings

DivX VOD Registration Code

0 1 2 3 4 5 6 7

DV585A WY_Mid.book Page 39 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu07

Speakers settings

Audio Output Mode

• Default setting:

2 Channel

If you connected this player to your amplifier

using the 5.1 channel analog outputs (front,

surround, center and subwoofer outs), set this

5.1 Channel

; if you connected only the

stereo outs, set to

2 Channel

Note

•Even if you set

Audio Output Mode

5.1

Channel

, you’ll only get sound from all

speakers when playing a 5.1 channel multi-

channel disc.

• When set to

5.1 Channel

, only the front

left/right channels are output from the

AUDIO OUT (2ch)

jacks. Change to

Channel

if you want to listen to downmixed

stereo audio (for example, because you are

listening through the TV’s built-in

speakers).

•When set to

5.1 Channel

there is no digital

output when playing DVD-Audio.

•If you set to

2 Channel

, Dolby Digital, DTS

and MPEG audio is mixed down to two

channels so you still hear all the audio

recorded on the disc. With DTS encoded

audio, you can choose how the signal is

downmixed to PCM audio. See

DTS

Downmix

on page 38 to change the

downmix setting.

• Some DVD-Audio discs don’t allow down-

mixing of audio. These discs always output

multi-channel audio regardless of the

setting made here.

Setting Option What it means

Audio Output

Mode

2 Channel

The player outputs analog audio in stereo only. See also

Audio Output Mode

below.

5.1 Channel

The player outputs 5.1 channel analog audio. See also

Audio

Output Mode

below.

Speaker

Installation

–

Specify the number and size of speakers in your system. See

also

Speaker Installation

on page 43.

Speaker Distance –

Specify the distance of your speakers from your listening

position.

Speaker Distance

on page 42.

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Audio Output Mode

Speaker Distance

Speaker Installation

2 Channel

5.1 Channel

Initial Settings

DV585A WY_Mid.book Page 40 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu 07

About the audio output settings

The table below shows how the audio settings you make in the Initial Settings menu (see page 34)

affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital

outputs with various types of disc.

When

Audio Output Mode

is set to

2 Channel

, the

AUDIO OUT (5.1ch) FRONT L / R

jacks act as a second pair

of stereo audio outputs.

Dolby Digital > PCM

MPEG > PCM

DTS > PCM

setting (pages 34–35)

Dolby Digital

MPEG

DTS

setting (pages 34–35)

Discs that prohibit downmixing will be output as 5.1 channel even if

2 Channel

is selected as the

Audio Output

Mode

setting (see page 40).

Discs that prohibit downmixing also mute the digital output.

When

Audio Output Mode

is set to

5.1 Channel

, mono sources are heard from the center speaker only.

Disc audio format Player setting

Front L / R

–

––

Surround L/R,

Center, SW

Surround L/R,

Center, SW

Surround L/R,

Center, SW

Surround L/R,

Center, SW

Surround L/R,

Center, SW

Surround L/R,

Center, SW

–

Front L / R

Left / Right Left / Right

Left / Right*6

Left / Right

2ch downmix

2ch downmix*4

2ch downmix

Front L / R

2ch downmix

Front L / R

2ch downmix

2 Ch

5.1 Ch

2 Ch

5.1 Ch

Front L/R

analog outputs*1

Surround L/R

Center, SW, outputs*1

Digital outputs

PCM convert*2 Bitstream*3

Dolby Digital

karaoke

2 Ch / 5.1 Ch

Linear PCM

2 Ch

5.1 Ch

DTS

MPEG

2 Ch

5.1 Ch

DVD-Audio

2 Ch

5.1 Ch

Super Audio CD

2 Ch

5.1 Ch

DTS CD

Video CD

DVD-RW

(VR mode)

DVD

Dolby Digital

–

2ch downmix

2ch downmix*5 2ch downmix*5

DTS

Dolby Digital

Left / Right

Left / Right Left / Right

Dolby Digital

MPEG or PCM

MPEG

DV585A WY_Mid.book Page 41 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu07

Speaker Distance

• Default settings: all speakers

3.0 m

You only need to make this setting if you

connected this player to your amplifier using the

5.1 channel analog outputs.

These settings do not affect any digital audio

output.

To get the best surround sound from your

system, you should set up the speaker

distances from your listening position.

1Use the

/

(cursor up/down) to select

a speaker.

• The

and

speakers are paired; you can’t

set them differently.

2 Press



(cursor right) to change the

speaker distance for the highlighted

speaker.

3 Use the

/

(cursor up/down) to

change the distance.

•When you change the distance settings of

the front left (

) or front right (

) speakers,

all the other speaker distances change

relative to it.

•Front left/right (

) speaker distances can

be set from 30 cm to 9 m in 30 cm incre-

ments.

•The center speaker (

) can be set from –2.1

m to 0.0 m relative to the front left/right

speakers.

• Surround left/right (

) speakers can

be set from –6.0 m to 0.0 m relative to the

front left/right speakers.

•You can’t set the subwoofer (

) distance.

4 Press



(cursor left) to go back to the

speaker list if you want to modify another

speaker, or press ENTER to exit the Speaker

Distance screen.

Note

During playback of SACD and MPEG-audio

DVD-Video discs, the effective

and

speaker distance settings are –0.9m to 0.0m

relative to the front left/right speakers.

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Audio Output Mode  5.1 Channel

Speaker Distance

Speaker Installation

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Speakers

3.0m

Initial Settings

DV585A WY_Mid.book Page 42 Tuesday, April 5, 2005 6:35 PM

Initial Settings menu 07

Speaker Installation

•Default settings:

L/R: Large

C: Large

SL/

SR: Large

SW: On

You only need to make this setting if you

connected this player to your amplifier using the

5.1 channel analog outputs.

This setting does not affect digital audio output.

Use the Speaker Installation screen to tell the

player what kinds of speakers you have

connected.

1Use the

/

(cursor up/down) buttons

to select a speaker.

• The

and

, and

and

speakers are

paired; you can’t set them differently.

2 Press



(cursor right) to modify the

selected speaker.

3Use the

/

(cursor up/down) buttons

to change the current setting.

• You can see the effect of your changes in

the room graphic on the right of the screen.

• Except for the subwoofer, you can set

speaker size to

Large

Small

. If the main

speaker cone in the speaker is 12cm or

more, set to

Large

, otherwise set to

Small

(or

Off

if you don’t have that speaker).

• If you set the front

and

speakers to

Small

, the center and surround speakers

are automatically set to

Small

and the

subwoofer to

• The subwoofer can only be set to

Off

4 Press



(cursor left) to go back to the

speaker list if you want to modify another

speaker, or press ENTER to exit the Speaker

Installation screen.

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Audio Output Mode  5.1 Channel

Speaker Distance

Speaker Installation

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Speakers

Large

Initial Settings

DV585A WY_Mid.book Page 43 Tuesday, April 5, 2005 6:35 PM

Additional information08

Chapter 8

Additional information

Taking care of your player and

discs

General

Hold discs by the edge or by the center hole

and edge.

When you're not using a disc, return it to its

case and store upright. Avoid leaving discs in

excessively cold, humid, or hot environments

(including under direct sunlight).

Don't glue paper or put stickers on to discs. Do

not use a pencil, ball-point pen or other sharp-

tipped writing instrument to write on the disc.

Don’t use self-adhesive disc labels on discs as

these can cause the disc to warp slightly

during playback causing distortion in the

picture and/or sound.

Damaged and shaped discs

Do not use cracked, chipped, warped, or

otherwise damaged discs as they may damage

the player.

This player is designed to be used only with

conventional, fully circular discs. Do not use

shaped discs. Pioneer disclaims all liability

arising in connection with the use of shaped

discs.

Cleaning discs

Fingerprints and dust on discs can affect

playback performance. Clean using a soft, dry

cloth, wiping the disc lightly from the center to

the outside edge as shown below.

If necessary, use a cloth soaked in alcohol, or a

commercially available CD/DVD cleaning kit to

clean a disc more thoroughly. Never use

benzine, thinner or other cleaning agents,

including products designed for cleaning vinyl

records.

Cleaning the unit’s exterior

Unplug the unit before cleaning.

Use a dry cloth to wipe off dust and dirt. If the

surfaces are very dirty, wipe with a soft cloth

dipped in some neutral cleanser diluted five or

six times with water and wrung out well, then

wipe again with a dry cloth.

Do not use furniture wax or cleaners. Never

use thinners, benzine or insecticide sprays or

other chemicals on or near this unit.

DV585A WY_Mid.book Page 44 Tuesday, April 5, 2005 6:35 PM

Additional information 08

If you use a chemical-impregnated cleaning

cloth, read the instructions carefully before

use. These cloths may leave smear marks on

half-mirror finish surfaces; if this happens,

finish with a dry cloth.

Cleaning the pickup lens

The DVD player’s lens should not become dirty

in normal use, but if for some reason it should

malfunction due to dust or dirt, consult your

nearest Pioneer-authorized service center. We

do not recommend using commercially

available lens cleaners for CD players.

Condensation

Condensation may form inside the player if it is

brought into a warm room from outside, or if

the temperature of the room rises quickly.

Although the condensation won’t damage the

player, it may temporarily impair its

performance. Leave it to adjust to the warmer

temperature for about an hour before

switching on.

Moving the player

If you need to move the player, first press



STANDBY/ON

on the front panel to turn the

player off. Wait for

-OFF-

to disappear from the

display, then unplug the power cable. Never lift

or move the unit during playback—discs rotate

at a high speed and may be damaged.

Screen sizes and disc formats

DVD-Video discs come in several different

screen aspect ratios, ranging from TV

programs, which are generally 4:3, to

CinemaScope widescreen movies, with an

aspect ratio of up to about 7:3.

Televisions, too, come in different aspect

ratios; ‘standard’ 4:3 and widescreen 16:9.

Widescreen TV users

If you have a widescreen TV, the

TV Screen

setting (page 35) of this player should be set to

16:9 (Wide)

When you watch discs recorded in 4:3 format,

you can use the TV controls to select how the

picture is presented. Your TV may offer various

zoom and stretch options; see the instructions

that came with your TV for details.

Please note that some movie aspect ratios are

wider than 16:9, so even though you have a

widescreen TV, these discs will still play in a

‘letter box’ style with black bars at the top and

bottom of the screen.

Standard TV users

If you have a standard TV, the

TV Screen

setting (page 35) of this player should be set to

4:3 (Letter Box)

4:3 (Pan&Scan)

depending on which you prefer.

Set to

4:3 (Letter Box)

, widescreen discs are

shown with black bars top and bottom.

Set to

4:3 (Pan&Scan)

, widescreen discs are

shown with the left and right sides cropped.

Although the picture looks larger, you don’t

actually see the whole picture.

Please note that many widescreen discs

override the player’s settings so that the disc is

shown in letter box format regardless of the

setting.

DV585A WY_Mid.book Page 45 Tuesday, April 5, 2005 6:35 PM

Additional information08

Note

• Using the

16:9 (Wide)

setting with a

standard 4:3 TV, or either of the 4:3 settings

with a widescreen TV, will result in a

distorted picture.

Setting the TV system

The default setting of this player is

AUTO

, and

unless you notice that the picture is distorted

when playing some discs, you should leave it

set to

AUTO

. If you experience picture distor-

tion with some discs, set the TV system to

match your country or region’s system. Doing

this, however, may restrict the kinds of disc you

can watch. The table below shows what kinds

of disc are compatible with each setting

(

AUTO

PAL

and

NTSC

1 If the player is on, press



STANDBY/

ON to switch it to standby.

2 Using the front panel controls, hold

down



then press



STANDBY/ON to

switch the TV system.

The TV system changes as follows:

•

AUTO



NTSC

•

NTSC



PAL

•

PAL



AUTO

Note

• You have to switch the player into standby

(press



STANDBY/ON

) before each

change.

Resetting the player

Use this procedure to reset all the player’s

settings to the factory default.

1 Switch the player into standby.

2 Using the front panel buttons, hold

down the



(stop) button and press



STANDBY/ON to switch the player back

on.

All the player’s settings are now reset.

DVD-Video regions

All DVD-Video discs carry a region mark on the

case somewhere that indicates which

region(s) of the world the disc is compatible

with. Your DVD player also has a region mark,

which you can find on the rear panel. Discs

from incompatible regions will not play in this

player. Discs marked

ALL

will play in any

player.

The diagram below shows the various DVD

regions of the world.

Disc Player setting

Type Format NTSC PAL AUTO

DVD/Super

VCD/Video CD/

DivX Video

NTSC NTSC PAL NTSC

PAL NTSC PAL PAL

CD/MP3/WMA/

JPEG

no disc

—NTSC PAL NTSC

or PAL

DV585A WY_Mid.book Page 46 Tuesday, April 5, 2005 6:35 PM

Additional information 08

Selecting languages using the

language code list

Some of the language options (such as ‘DVD

Language’ in the Setup Navigator) allow you to

set your preferred language from any of the 136

languages listed in the language code list on

page 48.

1 Select ‘Other Language’.

2Use the

/

(cursor left/right) buttons

to select either a code letter or a code

number.

3Use the

/

(cursor up/down) buttons

to select a code letter or a code number.

See

Language code list

on page 48 for a

complete list of languages and codes.

DV585A WY_Mid.book Page 47 Tuesday, April 5, 2005 6:35 PM

Additional information08

Language code list

Language (Language code letter),

Language code

Country/Area code list

Country/Area,

Country/Area code

Country/Area code letter

Japanese (ja),

1001

English (en),

0514

French (fr),

0618

German (de),

0405

Italian (it),

0920

Spanish (es),

0519

Chinese (zh),

2608

Dutch (nl),

1412

Portuguese (pt),

1620

Swedish (sv),

1922

Russian (ru),

1821

Korean (ko),

1115

Greek (el),

0512

Afar (aa),

0101

Abkhazian (ab),

0102

Afrikaans (af),

0106

Amharic (am),

0113

Arabic (ar),

0118

Assamese (as),

0119

Aymara (ay),

0125

Azerbaijani (az),

0126

Bashkir (ba),

0201

Byelorussian (be),

0205

Bulgarian (bg),

0207

Bihari (bh),

0208

Bislama (bi),

0209

Bengali (bn),

0214

Tibetan (bo),

0215

Breton (br),

0218

Catalan (ca),

0301

Corsican (co),

0315

Czech (cs),

0319

Welsh (cy),

0325

Danish (da),

0401

Bhutani (dz),

0426

Esperanto (eo),

0515

Estonian (et),

0520

Basque (eu),

0521

Persian (fa),

0601

Finnish (fi),

0609

Fiji (fj),

0610

Faroese (fo),

0615

Frisian (fy),

0625

Irish (ga),

0701

Scots-Gaelic (gd),

0704

Galician (gl),

0712

Guarani (gn),

0714

Gujarati (gu),

0721

Hausa (ha),

0801

Hindi (hi),

0809

Croatian (hr),

0818

Hungarian (hu),

0821

Armenian (hy),

0825

Interlingua (ia),

0901

Interlingue (ie),

0905

Inupiak (ik),

0911

Indonesian (in),

0914

Icelandic (is),

0919

Hebrew (iw),

0923

Yiddish (ji),

1009

Javanese (jw),

1023

Georgian (ka),

1101

Kazakh (kk),

1111

Greenlandic (kl), 1112

Cambodian (km), 1113

Kannada (kn), 1114

Kashmiri (ks), 1119

Kurdish (ku), 1121

Kirghiz (ky), 1125

Latin (la), 1201

Lingala (ln), 1214

Laothian (lo), 1215

Lithuanian (lt), 1220

Latvian (lv), 1222

Malagasy (mg), 1307

Maori (mi), 1309

Macedonian (mk), 1311

Malayalam (ml), 1312

Mongolian (mn), 1314

Moldavian (mo), 1315

Marathi (mr), 1318

Malay (ms), 1319

Maltese (mt), 1320

Burmese (my), 1325

Nauru (na), 1401

Nepali (ne), 1405

Norwegian (no), 1415

Occitan (oc), 1503

Oromo (om), 1513

Oriya (or), 1518

Panjabi (pa), 1601

Polish (pl), 1612

Pashto, Pushto (ps), 1619

Quechua (qu), 1721

Rhaeto-Romance (rm), 1813

Kirundi (rn), 1814

Romanian (ro), 1815

Kinyarwanda (rw), 1823

Sanskrit (sa), 1901

Sindhi (sd), 1904

Sangho (sg), 1907

Serbo-Croatian (sh), 1908

Sinhalese (si), 1909

Slovak (sk), 1911

Slovenian (sl), 1912

Samoan (sm), 1913

Shona (sn), 1914

Somali (so), 1915

Albanian (sq), 1917

Serbian (sr), 1918

Siswati (ss), 1919

Sesotho (st), 1920

Sundanese (su), 1921

Swahili (sw), 1923

Tamil (ta), 2001

Telugu (te), 2005

Tajik (tg), 2007

Thai (th), 2008

Tigrinya (ti), 2009

Turkmen (tk), 2011

Tagalog (tl), 2012

Setswana (tn), 2014

Tonga (to), 2015

Turkish (tr), 2018

Tsonga (ts), 2019

Tatar (tt), 2020

Twi (tw), 2023

Ukrainian (uk), 2111

Urdu (ur), 2118

Uzbek (uz), 2126

Vietnamese (vi), 2209

Volapük (vo), 2215

Wolof (wo), 2315

Xhosa (xh), 2408

Yoruba (yo), 2515

Zulu (zu), 2621

Argentina, 0118, ar

Australia, 0121, au

Austria, 0120, at

Belgium, 0205, be

Brazil, 0218, br

Canada, 0301, ca

Chile, 0312, cl

China, 0314, cn

Denmark, 0411, dk

Finland, 0609, fi

France, 0618, fr

Germany, 0405, de

Hong Kong, 0811, hk

India, 0914, in

Indonesia, 0904, id

Italy, 0920, it

Japan, 1016, jp

Korea, Republic of, 1118, kr

Malaysia, 1325, my

Mexico, 1324, mx

Netherlands, 1412, nl

New Zealand, 1426, nz

Norway, 1415, no

Pakistan, 1611, pk

Philippines, 1608, ph

Portugal, 1620, pt

Russian Federation, 1821, ru

Singapore, 1907, sg

Spain, 0519, es

Sweden, 1905, se

Switzerland, 0308, ch

Taiwan, 2023, tw

Thailand, 2008, th

United Kingdom, 0702, gb

USA, 2119, us

DV585A WY_Mid.book Page 48 Tuesday, April 5, 2005 6:35 PM

Additional information 08

Troubleshooting

Incorrect operation is often mistaken for trouble or malfunction. If you think that there is

something wrong with this component, check the points below. Sometimes the trouble may lie in

another component. Inspect the other components and electrical appliances being used. If the

trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized

service center or your dealer to carry out repair work.

Problem Remedy

The disc won’t play or is

automatically ejected

after loading.

• Make sure the disc is free from dirt and dust and is not damaged

(page 44).

• Make sure the disc is loaded with the label side face-up and aligned

properly in the disc tray guide.

• Incompatible region number: If the region number on a DVD-Video

disc does not match the number on the player, the disc cannot be

used (page 46).

• Condensation inside the player: Allow time for condensation to

evaporate. Avoid using the player near an air-conditioning unit.

• Disc is loaded upside down: Reload the disc with the label side face

up.

• A Super VCD that does not conform with the IEC standards might

not play normally.

DVD-Audio playback

stops.

• The disc may have been illegally copied.

Picture playback stops

and the operation

buttons cannot be used.

• Press



, then start playback again (



• Press and hold the front panel



STANDBY/ON

button for about 10

seconds to switch the unit off, then press again to switch back on.

• Switch the power off once, unplug from the wall socket, then plug

back in and switch on again using the front panel



STANDBY/ON

button.

New settings made in the

Setup screen menus while

a disc is playing are

ineffective.

• Some settings can be changed while a disc is playing, but are not

effective until the disc is stopped then restarted: Press



, then start

playback again (



Settings are canceled.

• When the power is cut due to power failure or by unplugging the

power cord, settings will be canceled: Press



STANDBY/ON

on the

front panel to turn the player off. Wait for

--OFF--

to disappear from

the display, then unplug the power cord.

The remote control

doesn't seem to work.

• The remote control is too far from the player, or the angle with the

remote sensor is too wide: Use the remote within its operating range

(page 16).

• The batteries are exhausted: Put in new ones (page 6).

DV585A WY_Mid.book Page 49 Tuesday, April 5, 2005 6:35 PM

Additional information08

No picture/No color.

• Incorrect video connections: Check that connections are correct

and that plugs are inserted fully. Also check the video cable for

damage.

• TV/monitor or AV amplifier settings are incorrect: Check the

instruction manual of the connected equipment.

• The video output is set to progressive but your TV/monitor is not

compatible with progressive scan: See page 12 for how to set to

interlace.

Screen is stretched or

aspect does not change.

• The

TV Screen

setting in the Initial Settings menu is incorrect. See

page 45 for how to set it correctly for your TV/monitor.

Picture disturbance

during playback or the

picture is dark.

• This player is compatible with Macro-Vision System copy guard.

Some discs include a copy prevention signal, and when this type of

disc is played back, stripes etc., may appear on some sections of the

picture depending on the TV. This is not a malfunction.

• Due to the player’s copy protection circuits, connection of this

device through a VCR or an AV selector may prevent recording or

cause picture problems. This is not a malfunction.

No audio, or audio is

distorted.

• No audio is output during slow motion playback or when scanning

discs other than audio CDs and SACDs.

• Some DVD discs do not output digital audio: Switch your amplifier

to the player's analog outputs.

• Check that the disc is free from dust and dirt, and that it is not

damaged (page 44).

• Check that all interconnects are firmly inserted.

• Check that the plugs and terminals are free of dirt, oxide, etc. and

clean if necessary. Also check the cable for damage.

• Make sure the player's output is not connected to the amplifier's

phono (turntable) inputs.

• Check your amplifier/receiver’s settings (volume, input function,

speaker settings, etc.).

The analog audio is OK,

but there appears to be

no digital audio signal.

• Make sure that the

Digital Out

setting is set to

(page 34).

• Check that the Dolby Digital, DTS and MPEG out settings

(pages 34–35) are suitable for your amplifier/receiver—check the

instruction manual that came with your amplifier/receiver.

• SACDs and DVD-Audio discs do not output digital audio. Listen

through the player’s analog audio outputs.

Noticeable difference in

DVD and CD volume.

• This is due to differences in the audio format and is not a

malfunction.

Problem Remedy

DV585A WY_Mid.book Page 50 Tuesday, April 5, 2005 6:35 PM

Additional information 08

Cannot play multi-

channel audio

• Make sure that

Audio Output Mode

is set to

5.1 Channel

(page 40).

• Check that the Dolby Digital, DTS and MPEG Out settings

(pages 34–35) are suitable for your amplifier/receiver—check the

instruction manual that came with your amplifier/receiver.

• DVD-Audio and SACDs do not output multichannel digital audio.

Listen through the player’s analog outputs.

• Check that the settings in the Speaker Installation screen are

correct (page 43).

• Check the audio options available from the disc menu.

Cannot listen to high-

sampling rate audio

through the digital

output.

• Make sure that

Linear PCM Out

is set to

Downsample Off

(page 35).

• As a copy-protection measure, some DVDs do not output 96kHz

audio. In this case, even if set to

Downsample Off

, the player

automatically outputs the audio at 48 kHz. This is not a malfunction.

Cannot output 192kHz or

176.4kHz digital audio.

• The player does not output digital audio at these sampling rates. The

digital output is automatically downsampled.

Cannot output 96kHz or

88.2kHz digital audio.

• Check that

Linear PCM Out

is set to

Downsample Off

(page 35).

• Some discs are digital copy protected and do not output high

sampling rate digital audio. In this case the output is automatically

downsampled.

No DTS audio output.

• If this unit is connected to a non-DTS compatible amplifier or

decoder using a digital audio cable, set

DTS Out

DTS

PCM

(page 34). If you do not do this, noise will be output when you play a

DTS disc.

• If this unit is connected to a DTS-compatible amplifier or decoder

using a digital audio cable, check the amplifier settings, and that the

cable is properly connected.

Audio mix does not

sound right or sounds

incomplete (for example,

inaudible dialog).

• Make sure that

Audio Output Mode

is set to

2 Channel

if you've

connected to the stereo inputs on your amplifier or TV (page 40).

The audio recorded on a

Super VCD disc is not

output properly.

• If the audio is switched to

[2]

when playing a Super VCD that

contains only one stereo soundtrack, there may be no sound at all.

Press

AUDIO

to change the soundtrack.

Can’t hear effect of

Virtual Surround

• Virtual Surround does not work with SACD or DVD-Audio.

• The Virtual Surround effect is only output through the

AUDIO OUT

(2ch)

analog audio outputs.

• Make sure that

Audio Output Mode

is set to

2 Channel

(page 40).

• The effectiveness of Virtual Surround varies with the disc.

Problem Remedy

DV585A WY_Mid.book Page 51 Tuesday, April 5, 2005 6:35 PM

Additional information08

Note

• Static electricity or other external influences may cause malfunctioning of this unit. In this

case, unplug the power cord and then plug back in. This will usually reset the unit for proper

operation. If this does not correct the problem, please consult your nearest Pioneer service

center.

Glossary

Analog audio

Direct representation of sound by an

electrical signal. See also

Digital audio

Aspect ratio

The width of a TV screen relative to its

height. Conventional TVs are 4:3;

widescreen models are 16:9.

Bonus Group

(DVD-Audio

only)

An ‘extra’ group on some DVD-Audio

discs that requires a key number to

access.

Browsable

pictures

(DVD-Audio

only)

A feature of some DVD-Audio discs in

which the user can browse still pictures

recorded on the disc as the audio is

played. See also

Slideshow

Digital audio

Indirect representation of sound using

numbers. See also

Sampling frequency

and

Analog audio

Dolby

Digital

A multi-channel audio encoding system

developed by Dolby Laboratories that

enables far more audio to be stored on a

disc than PCM encoding. See also

PCM

(Pulse Code Modulation)

DRM ((

((

WMA)

DRM (Digital Rights Management) copy

protection is a technology designed to

prevent unauthorized copying by

restricting playback, etc. of material on

devices other the PC (or other WMA

recording equipment) used to record it.

For detailed information, please see the

instruction manuals or help files that

came with your PC (or other WMA

recording equipment) and/or software.

DTS

A multi-channel audio encoding system

developed by Digital Theater Systems

that enables far more audio to be stored

on a disc than PCM encoding. See also

PCM (Pulse Code Modulation)

EXIF

(Exchangeable

Image File)

A file format developed by Fuji Photo

Film for digital still cameras. Digital

cameras from various manufacturers

use this compressed file format which

carries date, time and thumbnail

information, as well as the picture data.

File

extension

A tag added to the end of a filename to

indicate the type of file. For example,

“.mp3” indicates an MP3 file.

ISO 9660

format

International standard for the volume

and file structure of CD-ROM discs.

JPEG

A standard file format used for still

images. JPEG files are identified by the

file extension “.jpg”.

MP3

MP3 (MPEG1 audio layer 3) is a

compressed stereo audio file format.

Files are recognized by their file

extension “.mp3”.

MPEG audio

An audio format used on Video CD/

Super VCDs and some DVD discs.

Packed PCM

(DVD-Audio

only)

A lossless compression system that

enables more PCM audio to be stored

on a DVD-Audio disc than would

otherwise be possible.

PBC

(PlayBack

Control)

A system of navigating a Video CD/

Super VCD through on-screen menus

recorded onto the disc.

PCM

(Pulse Code

Modulation)

Digital audio encoding system found on

CDs. Good quality, but requires a lot of

data compared to Dolby Digital, DTS

and MPEG encoded audio. See also

Digital audio

DV585A WY_Mid.book Page 52 Tuesday, April 5, 2005 6:35 PM

Additional information 08

Manufactured under license from Dolby

Laboratories. “Dolby” and the double-D symbol

are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Surround” are

registered trademarks of Digital Theater

Systems, Inc.

Progressive

scan video

All the lines that make up a video

picture are updated in one pass

(compared to interlace which takes two

passes to update the whole picture).

Regions

(DVD-Video

only)

These associate DVD-Video discs and

players with particular areas of the

world. See

DVD-Video regions

page 46 for more information.

Sampling

frequency

The rate at which sound is measured to

be turned into digital audio data. The

higher the rate, the better the sound

quality. CD is 44.1 kHz; DVD can be up

to 96 kHz. See also

Digital audio

WMA

WMA is short for Windows Media Audio

and refers to an audio compression

technology developed by Microsoft

Corporation. Files are recognized by

their file extension “.wma”.

Microsoft, Windows Media, and the

Windows logo are trademarks, or

registered trademarks of Microsoft

Corporation in the United States and/or

other countries.

Super Audio

CD (SACD)

Super Audio CD is a high quality audio

disc format that can accommodate high

sampling rate stereo and multi-channel

audio, as well as conventional CD audio

all on the same disc.

DV585A WY_Mid.book Page 53 Tuesday, April 5, 2005 6:35 PM

Additional information08

Specifications

General

System . . . . . . . . . . . . . . . . . . . . . . . . . DVD player

Power requirements . . . AC 220–240 V, 50/60 Hz

Power consumption . . . . . . . . . . . . . . . . . . . .8 W

Power consumption (standby) . . . . . . . . 0.85 W

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 kg

Dimensions

. . . . . . . . . .420 (W) x 49.5 (H) x 214.9 (D) mm

Operating temperature . . . . . . . .+5°C to +35°C

Operating humidity. . . . . . . . . . . . . . . 5% to 85%

(no condensation)

AV connector output

AV Connector (21-pin connector assignment)

AV connector output . . . . . . . . 21-pin connector

This connector provides the video and audio

signals for connection to a compatible colour TV

or monitor.

PIN no.

1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .Audio 2/R out

3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . Audio 1/L out

4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GND

7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B out

8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Status

11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G out

15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .R out

17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GND

19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Video out

21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GND

Component video output

Y (luminance) - Output level. . . . . . 1 Vp-p (75

Ω

)

(color) - Output level . . . . . . . . 0.7 Vp-p (75

Ω

)

(color) - Output level . . . . . . . . 0.7 Vp-p (75

Ω

)

Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA

S-video output

Y (luminance) - Output level . . . . . . 1 Vp-p (75

Ω

)

C (color) - Output level. . . . . . . 286 mVp-p (75

Ω

)

Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video

Video output

Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75

Ω

)

Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA

Audio output (1 stereo pair)

Output level . . . . . . . . . . . . .During audio output

200 mVrms (1 kHz, –20 dB)

Number of channels . . . . . . . . . . . . . . . . . . . . . . 2

Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA

Audio output (multi-channel / L, R, C, SW,

SL, SR)

Output level . . . . . . . . . . . . .During audio output

200 mVrms (1 kHz, –20 dB)

Number of channels . . . . . . . . . . . . . . . . . . . . . . 6

Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack

Digital audio characteristics

Frequency response . . . . . . . . . . . 4 Hz to 44 kHz

(DVD fs: 96 kHz)

4 Hz to 48 kHz (DVD-Audio fs: 192 kHz)

S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . 115 dB

Dynamic range. . . . . . . . . . . . . . . . . . . . . . 101 dB

Total harmonic distortion . . . . . . . . . . . 0.0023 %

Wow and flutter . . . . . . . . Limit of measurement

(±0.001% W. PEAK) or lower

Digital output

Coaxial digital output. . . . . . . . . . . . . . . RCA jack

Optical digital output. . . . . . . Optical digital jack

Accessories

Audio/video cable . . . . . . . . . . . . . . . . . . . . . . . . 1

Power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1

AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2

Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Operating Instructions

DV585A WY_Mid.book Page 54 Tuesday, April 5, 2005 6:35 PM

Additional information 08

The specifications and design of this product are subject to

change without notice, due to improvement.

Published by Pioneer Corporation.

DV585A WY_Mid.book Page 55 Tuesday, April 5, 2005 6:35 PM

PIONEER CORPORATION

4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS (USA) INC.

P.O. BOX 1540, Long Beach, California 90810-1540, U.S.A. TEL: (800) 421-1404

PIONEER ELECTRONICS OF CANADA, INC.

300 Allstate Parkway, Markham, Ontario L3R OP2, Canada TEL: 1-877-283-5901

PIONEER EUROPE NV

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 03/570.05.11

PIONEER ELECTRONICS ASIACENTRE PTE. LTD.

253 Alexandra Road, #04-01, Singapore 159936 TEL: 65-6472-7555

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: (03) 9586-6300

PIONEER ELECTRONICS DE MEXICO S.A. DE C.V.

Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico,D.F. 11000 TEL: 55-9178-4270

K002_A_En

<TPTZZ> Printed in Thailand <VRB1360-B>

Published by Pioneer Corporation.

If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used

electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Private households in the 25 member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to

designated collection facilities or to a retailer (if you purchase a similar new one).

For countries not mentioned above, please contact your local authorities for the correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential

negative effects on the environment and human health.
