Operation Manual

DVD AV RECEIVER

AVH-P5100DVD

English

<CRB2972-A/N> <1>

Thank you for purchasing this PIONEER product.

Please read through this manual before using the product for the first time, to en-

sure proper use. After reading, please keep the manual in a safe and accessible place

for future reference.

Be sure to read this

!Playable discs 9

!DVD video disc region numbers 9

!When an operation is prohibited 14

Precautions

IMPORTANT SAFEGUARDS 6

To ensure safe driving 6

–Parking brake interlock 7

–When using a display connected to

REAR MONITOR OUTPUT 7

–When using a rear view camera 7

To avoid battery exhaustion 7

Before You Start

Information to User 8

For Canadian model 8

About this unit 8

–Playable discs 9

–DVD video disc region numbers 9

About this manual 10

After-sales service for Pioneer products 10

Visit our website 10

Features 11

–About WMA 12

–About MP3 12

–About AAC 12

–About DivX 13

–About the SAT RADIO READY

mark 13

To protect the LCD screen 13

For viewing the LCD comfortably 13

–Changing the wide screen size 13

–Changing the picture adjustment 14

What the marks on DVDs indicate 14

–When an operation is prohibited 14

Protecting your unit from theft 14

–Removing the front panel 14

–Attaching the front panel 14

Resetting the microprocessor 15

Feature demo mode 15

Operating this unit

What’s what 16

–Head unit 16

–Optional remote control 16

Basic Operations 17

–Power ON/OFF 17

–Selecting a source 17

–Adjusting the volume 18

–Touch panel key basic operation 18

–Opening and closing the LCD

panel 19

Radio 20

–Basic Operations 20

–Storing and recalling broadcast

frequencies 21

–Introduction to advanced

operations 21

–Storing the strongest broadcast

frequencies 21

–Tuning in strong signals 21

Built-in DVD player 22

–Basic Operations 22

–Basic playback controls 23

–Switching the media file type 23

–Operating the DVD menu 23

–PBC playback 24

–Playing DivX® VOD content 24

–Skipping back or forward to another

title 24

–CM skip/CM back 25

–Resume playback (Bookmark) 25

–Searching for the part you want to

play 25

–Changing audio language during

playback (Multi-audio) 26

–Changing the subtitle language during

playback (Multi-subtitle) 26

–Changing the viewing angle during

playback (Multi-angle) 26

Contents

–Frame-by-frame playback 27

–Slow motion playback 27

–Return to the specified scene 27

–Automatic playback of DVDs 27

–Text information 27

–Selecting tracks from the track list 28

–Selecting files from the file name

list 28

–Introduction to advanced

operations 28

–Repeating play 28

–Playing tracks in random order 29

–Scanning tracks or folders 29

–Selecting audio output 29

–Using compression 30

Playing songs on iPod 30

–Basic Operations 30

–Playing video 31

–Browsing for a song/video 31

–Displaying text information on

iPod 32

–Repeating play 32

–Playing songs in a random order

(shuffle) 32

–Playing all songs in a random order

(shuffle all) 32

–Operating this unit’s iPod function

from your iPod 32

–Pausing a song 33

–Selecting songs from album list of

currently playing artist 33

–Changing audiobook speed 33

Playing songs on USB portable audio player/

USB memory 33

–Basic Operations 33

–Pausing compressed audio

playback 34

–Introduction to advanced

operations 34

–Displaying text information of an audio

file 34

–Selecting files from the file name

list 34

Audio Adjustments 35

–Introduction of audio adjustments 35

–Using balance adjustment 35

–Using the equalizer 35

–Adjusting loudness 36

–Using subwoofer output 36

–Boosting the bass 37

–Using the high pass filter 37

–Adjusting source levels 37

Setting up the DVD player 38

–Introduction of DVD setup

adjustments 38

–Setting the subtitle language 38

–Setting the audio language 38

–Setting the menu language 39

–Switching the assist subtitle on or

off 39

–Setting the angle icon display 39

–Setting the aspect ratio 39

–Setting the parental lock 40

–Setting the DivX subtitle file 41

–Displaying your DivX® VOD

registration code 41

–Setting for digital output 41

Initial Settings 42

–Adjusting initial settings 42

–Switching the auxiliary setting 42

–Setting the rear output and subwoofer

controller 42

–Changing languages for CAUTION 43

–Switching the sound muting/

attenuation 43

–Switching the warning tone 43

–Entering PIN code for Bluetooth

wireless connection 43

–Correcting distorted sound 44

–Resetting the audio functions 44

Other Functions 45

En 3

Contents

–Introduction of system

adjustments 45

–Changing the wide screen mode 45

–Changing the picture adjustment 45

–Selecting the background display 46

–Setting the AV input 46

–Setting the clock 47

–Setting for rear view camera (back up

camera) 47

–Adjusting the LCD panel slide

position 47

–Setting the automatic open

function 48

–Switching the iPod charge setting 48

–Selecting the OSD color 48

–Selecting the illumination color 48

–Adjusting the response positions of the

touch panels (Touch Panel

Calibration) 49

–Using the AUX source 49

–Using the external unit 50

–Using the PGM button 51

Available accessories

XM tuner 52

–Basic Operations 52

–Storing and recalling broadcast

stations 52

–Switching the XM channel select

mode 53

–Selecting an XM channel directly 53

–Using the MyMix function 53

–Displaying the Radio ID 54

–Switching the XM display 55

SIRIUS Satellite Radio tuner 55

–Basic Operations 55

–Storing and recalling broadcast

stations 56

–Selecting the SIRIUS channel select

mode 56

–Selecting a SIRIUS channel

directly 57

–Using the MyMix function 57

–Using the Game Alert function 58

–Displaying the Radio ID 59

–Switching the SIRIUS display 59

–Using Instant Replay function 59

Bluetooth Audio 60

–Basic Operations 60

–Pausing playback 61

–Introduction to advanced

operations 61

–Connecting a Bluetooth audio

player 61

–Disconnecting a Bluetooth audio

player 61

–Displaying BD (Bluetooth Device)

address 61

Bluetooth Telephone 62

–Basic Operations 62

–Setting up for hands-free phoning 63

–Making a phone call 63

–Taking a phone call 63

–Introduction to advanced

operations 64

–Connecting a cellular phone 64

–Disconnecting a cellular phone 64

–Registering a connected cellular

phone 65

–Deleting a registered phone 65

–Connecting to a registered cellular

phone 65

–Using the phone book 65

–Using the call history 67

–Using preset numbers 67

–Making a call by entering phone

number 68

–Clearing memory 68

–Setting automatic answering 68

–Setting automatic rejecting 68

–Switching the ring tone 68

–Echo canceling and noise

reduction 69

Contents

–Displaying BD (Bluetooth Device)

address 69

Multi-CD Player 69

–Basic Operations 69

–Selecting a disc 70

–Pausing CD playback 70

–Introduction to advanced

operations 70

–Using CD TEXT functions 70

DVD Player 71

–Basic Operations 71

–Selecting a disc 71

–Selecting a folder 71

–Pausing disc playback 71

–Introduction to advanced

operations 72

TV tuner 73

–Basic Operations 73

–Storing and recalling broadcast

stations 73

–Storing the strongest broadcast

stations sequentially 74

Digital Signal Processor 74

–Introduction of DSP adjustments 74

–Using the sound field control 75

–Using the position selector 75

–Using balance adjustment 76

–Adjusting source levels 76

–Using the dynamic range control 76

–Using the down-mix function 77

–Using the direct control 77

–Using the Dolby Pro Logic II 77

–Setting the speaker setting 78

–Adjusting the speaker output

levels 79

–Selecting a cross-over frequency 79

–Adjusting the speaker output levels

using a test tone 79

–Using the time alignment 80

–Using the equalizer 81

–Using the auto-equalizer 82

–Auto TA and EQ (auto-time alignment

and auto-equalizing) 82

Additional Information

Troubleshooting 85

Error messages 87

Understanding auto TA and EQ error

messages 89

Handling guideline of discs and player 90

DVD discs 90

DVD-R/DVD-RW discs 90

AVCHD recorded discs 90

CD-R/CD-RW discs 90

Dual Discs 91

Compressed audio files on the disc 91

–Example of a hierarchy 91

–Compressed audio compatibility 92

USB audio player/USB memory 92

–USB audio player/USB memory

compatibility 92

–USB audio player/USB memory 92

–Compressed audio compatibility 93

DivX video files 94

–DivX compatibility 94

About handling the iPod 94

–About iPod settings 94

Using the display correctly 94

–Handling the display 95

–Liquid crystal display (LCD) screen 95

–Keeping the display in good

condition 95

–Small fluorescent tube 95

Language code chart for DVD 97

Terms 98

Specifications 101

Index 103

En 5

Contents

IMPORTANT SAFEGUARDS

Please read all of these instructions regarding

your display and retain them for future refer-

ence.

1Read this manual fully and carefully be-

fore operating your display.

2Keep this manual handy as a reference for

operating procedures and safety informa-

tion.

3Pay close attention to all warnings in this

manual and follow the instructions care-

fully.

4Do not allow other persons to use this sys-

tem until they have read and understood

the operating instructions.

5Do not install the display where it may (i)

obstruct the driver’s vision, (ii) impair the

performance of any of the vehicle’s oper-

ating systems or safety features, includ-

ing air bags, hazard lamp buttons or (iii)

impair the driver’s ability to safely oper-

ate the vehicle.

6Do not operate this display if doing so in

any way will divert your attention from

the safe operation of your vehicle. Always

observe safe driving rules and follow all

existing traffic regulations. If you experi-

ence difficulty in operating the system or

reading the display, park your vehicle in a

safe location and make necessary adjust-

ments.

7Please remember to wear your seat belt at

all times while operating your vehicle. If

you are ever in an accident, your injuries

can be considerably more severe if your

seat belt is not properly buckled.

8Never use headphones while driving.

9To promote safety, certain functions are

disabled unless the parking brake is on,

and the vehicle is not in motion.

10 Never set the volume of your display so

high that you cannot hear outside traffic

and emergency vehicles.

WARNING

!Do not attempt to install or service your

display by yourself. Installation or servi-

cing of the display by persons without

training and experience in electronic

equipment and automotive accessories

may be dangerous and could expose you

to the risk of electric shock or other

hazards.

To ensure safe driving

WARNING

!LIGHT GREEN LEAD AT POWER CON-

NECTOR IS DESIGNED TO DETECT

PARKED STATUS AND MUST BE CON-

NECTED TO THE POWER SUPPLY SIDE

OF THE PARKING BRAKE SWITCH. IM-

PROPER CONNECTION OR USE OF

THIS LEAD MAY VIOLATE APPLICABLE

LAW AND MAY RESULT IN SERIOUS IN-

JURY OR DAMAGE.

!To avoid the risk of damage and injury and the

potential violation of applicable laws, this unit

is not for use with a video screen that is visible

to the driver.

!To avoid the risk of accident and the potential

violation of applicable laws, the front DVD or

TV (sold separately) feature should never be

used while the vehicle is being driven. Also,

rear displays should not be in a location

where they are visibly distracting to the driver.

!In some countries or states the viewing of

images on a display inside a vehicle even by

persons other than the driver may be illegal.

Where such regulations apply, they must be

obeyed and this unit’s DVD features should

not be used.

When you attempt to watch a DVD, Video CD

or TV while driving, the warning Viewing of

front seat video source while driving is

strictly prohibited. will appear on the front

display.

Precautions

Section

To watch a DVD, Video CD or TV on the front

display, park your vehicle in a safe place and

apply the parking brake.

Parking brake interlock

Certain functions (DVD/TV viewing and certain

touch panel keys) offered by this unit could be

dangerous and/or unlawful if used while driv-

ing. To prevent such functions from being

used while the vehicle is in motion, there is an

interlock system that senses when the parking

brake is set. If you attempt to use the functions

described above while driving, they will be-

come disabled until you stop the vehicle in a

safe place, and (1) apply the parking brake, (2)

release the parking brake, and then (3) apply

the parking brake again. Please keep the

brake pedal pushed down before releasing the

parking brake.

When using a display connected

to REAR MONITOR OUTPUT

This unit’sREAR MONITOR OUTPUT is for

connection of a display to enable passengers

in the rear seats to watch the DVD or TV.

WARNING

NEVER install the rear display in a location that

enables the driver to watch the DVD or TV while

driving.

When using a rear view camera

With an optional rear view camera, you are

able to use this unit as an aid to keep an eye

on trailers, or backing into a tight parking

spot.

WARNING

!SCREEN IMAGE MAY APPEAR RE-

VERSED.

!USE INPUT ONLY FOR REVERSE OR

MIRROR IMAGE REAR VIEW CAMERA.

OTHER USE MAY RESULT IN INJURY

OR DAMAGE.

CAUTION

!The rear view camera function is to be used

as an aid to keep an eye on trailers, or while

backing up. Do not use for entertainment pur-

poses.

!Please note that the edges of the rear view

camera images may differ slightly according

to whether full screen images are displayed

when backing up, and whether the images are

used for checking the rear when the vehicle is

moving forward.

To avoid battery exhaustion

Be sure to run the vehicle engine while using

this unit. Using this unit without running the

engine can result in battery drainage.

!When no power is supplied to this unit be-

cause of a replacement of the vehicle bat-

tery or for some similar reason, the

microcomputer of this unit is returned to

its initial condition. We recommend that

you transcribe the audio adjustment data.

WARNING

Do not use with vehicles that do not feature an

ACC position.

Precautions

En 7

Section

Precautions

Information to User

Alteration or modifications carried out without

appropriate authorization may invalidate the

user’s right to operate the equipment.

For Canadian model

This Class B digital apparatus complies with

Canadian ICES-003.

About this unit

The tuner frequencies on this unit are allo-

cated for use in North America. Use in other

areas may result in poor reception.

WARNING

Handling the cord on this product or cords asso-

ciated with accessories sold with the product

may expose you to chemicals listed on proposi-

tion 65 known to the State of California and other

governmental entities to cause cancer and birth

defects or other reproductive harm. Wash hands

after handling.

Before You Start

Section

CAUTION:

USE OF CONTROL OR ADJUSTMENT OR

PERFORMANCE OF PROCEDURES

OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION

EXPOSURE.

CAUTION:

THE USE OF OPTICAL INSTRUMENTS

WITH THIS PRODUCT WILL INCREASE

EYE HAZARD.

CAUTION

!Do not allow this unit to come into contact

with liquids. Electrical shock could result.

Also, damage to this unit, smoke, and over-

heating could result from contact with liquids.

!Keep this manual handy as a reference for op-

erating procedures and precautions.

!Always keep the volume low enough so that

you can hear sounds from outside the vehicle.

!Protect this unit from moisture.

!If the battery is disconnected or discharged,

the preset memory will be erased and must be

reprogrammed.

Important (Serial number)

The serial number is located on the bottom of

this unit. For your own security and convenience,

be sure to record this number on the enclosed

warranty card.

Playable discs

DVD, Video CD and CD discs that display the

logos shown below can be played back on this

player.

DVD video

Video CD

Notes

!is a trademark of DVD Format/Logo

Licensing Corporation.

!This player can only play back discs bearing

the marks shown above.

DVD video disc region numbers

DVD video discs that have incompatible region

numbers cannot be played on this player. The

region number of the player can be found on

the bottom of this unit and in this manual

(refer to Specifications on page 101).

Before You Start

En 9

Section

Before You Start

The illustration below shows the regions and

corresponding region numbers.

About this manual

This unit features a number of sophisticated

functions ensuring superior reception and op-

eration. All the functions have been designed

for the easiest possible use, but many are not

self-explanatory. This operation manual will

help you benefit fully from this unit’s potential

and to maximize your listening enjoyment.

We recommend that you familiarize yourself

with the functions and their operation by read-

ing through the manual before you begin

using this unit. It is especially important that

you read and observe WARNINGs and CAU-

TIONs in this manual.

After-sales service for

Pioneer products

Please contact the dealer or distributor from

where you purchased this unit for after-sales

service (including warranty conditions) or any

other information. In case the necessary infor-

mation is not available, please contact the

companies listed below:

Please do not ship your unit to the companies

at the addresses listed below for repair without

advance contact.

U.S.A.

Pioneer Electronics (USA) Inc.

CUSTOMER SUPPORT DIVISION

P.O. Box 1760

Long Beach, CA 90801-1760

800-421-1404

CANADA

Pioneer Electronics of Canada, Inc.

CUSTOMER SATISFACTION DEPARTMENT

300 Allstate Parkway

Markham, Ontario L3R 0P2

1-877-283-5901

905-479-4411

For warranty information please see the Lim-

ited Warranty sheet included with this unit.

Visit our website

Visit us at the following site:

http://www.pioneerelectronics.com

1 Register your product. We will keep the details

of your purchase on file to help you refer to

this information in the event of an insurance

claim such as loss or theft.

2 Receive updates on the latest products and

technologies.

3 Download owner’s manuals, order product

catalogues, research new products, and

much more.

4 Your feedback is important in our continual ef-

fort to design and build the most advanced,

consumer-focused product in the industry.

Serial number

Before You Start

Section

Features

Touch panel key operation

It is possible to operate this unit by using

touch panel key.

DVD-R/RW compatibility

It is possible to play back DVD-R/RW discs re-

corded with the video format. (Refer to DVD-R/

DVD-RW discs on page 90.)

Video CDs featuring PBC compatibility

It is possible to play back Video CDs featuring

PBC (playback control).

WMA, MP3 and AAC compatibility

Refer to Compressed audio compatibility on

page 92.

DivX®video compatibility

Refer to DivX compatibility on page 94.

Dolby Digital/DTS compatibility

When using this unit with a Pioneer multi-

channel processor, you can enjoy the atmo-

sphere and excitement provided by DVD movie

and music software featuring 5.1 channel re-

cordings.

!Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic, and the dou-

ble-D symbol are trademarks of Dolby

Laboratories.

!Manufactured under license under U.S. Pa-

tent #: 5,451,942 & other U.S. and world-

wide patents issued & pending. DTS and

DTS Digital Out are registered trademarks

and the DTS logos and Symbol are trade-

Portable audio player compatibility

!Make inquiries to the manufacturer about

your USB portable audio player/USB mem-

ory.

This unit corresponds to the following.

—USB MSC (Mass Storage Class) compliant

portable audio player and memory

—WMA, MP3, AAC and WAV file playback

For details about the compatibility, refer to

Compressed audio compatibility on page 93.

iPhone

iPhone is a trademark of Apple Inc.

iTunes

iTunes is a trademark of Apple Inc., registered

in the U.S. and other countries.

iPod

iPod is a trademark of Apple Inc., registered in

the U.S. and other countries.

Before You Start

En 11

Section

Before You Start

iPod compatibility

This unit can control and listen to songs on an

iPod.

!This unit supports only the following iPods.

Supported iPod software versions are

shown below. Older versions of iPod soft-

ware may not be supported.

—iPod third generation (software version

2.3.0)

—iPod fourth generation (software version

3.1.1)

—iPod photo (software version 1.2.1)

—iPod fifth generation (software version

1.3.0)

—iPod mini (software version 1.4.1)

—iPod nano first generation (software ver-

sion 1.3.1)

—iPod nano second generation (software

version 1.1.3)

—iPod nano third generation (software

version 1.1.3)

—iPod classic (software version 1.1.2)

—iPod touch (software version 2.0)

!Music files on iPod touch can be

played back.

—iPhone (software version 2.0)

!When using an iPod, Interface Cable for

iPod (e.g., CD-IU205V) is required.

!Operations may vary depending on the soft-

ware version of iPod.

Note

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual prop-

erty rights owned by Macrovision Corporation

and other rights owners. Use of this copyright

protection technology must be authorized by

Macrovision Corporation, and is intended for

home and other limited viewing uses only unless

otherwise authorized by Macrovision Corporation.

Reverse engineering or disassembly is prohibited.

About WMA

The Windows Media™logo printed on the box

indicates that this unit can play back WMA

data.

!Windows Media and the Windows logo are

trademarks or registered trademarks of

Microsoft Corporation in the United States

and/or other countries.

!This unit may not operate correctly depend-

ing on the application used to encode

WMA files.

!This product includes technology owned by

Microsoft Corporation and cannot be used

or distributed without a license from

Microsoft Licensing, Inc.

About MP3

Supply of this product only conveys a license

for private, non-commercial use and does not

convey a license nor imply any right to use

this product in any commercial (i.e. revenue-

generating) real time broadcasting (terrestrial,

satellite, cable and/or any other media), broad-

casting/streaming via internet, intranets and/

or other networks or in other electronic con-

tent distribution systems, such as pay-audio or

audio-on-demand applications. An indepen-

dent license for such use is required. For de-

tails, please visit

http://www.mp3licensing.com.

About AAC

This unit plays back AAC files encoded by

iTunes.

Before You Start

Section

About DivX

DivX is a compressed digital video format cre-

ated by the DivX®video codec from DivX, Inc.

This unit can play DivX video files recorded on

CD-R/RW/ROM and DVD-R/RW/ROM discs.

Keeping the same terminology as DVD video,

individual DivX video files are called “Titles”.

When naming files/titles on a CD-R/RW or a

DVD-R/RW disc prior to burning, keep in mind

that by default they will be played in alphabeti-

cal order.

Official DivX®Certified product

Plays all versions of DivX®video (including

DivX®6) with standard playback of DivX®

media files

!DivX, DivX Certified, and associated logos

are trademarks of DivX, Inc. and are used

under license.

About the SAT RADIO READY mark

The SAT RADIO READY mark indicates that

the Satellite Radio Tuner for Pioneer (i.e., XM

tuner and Sirius satellite tuner which are sold

separately) can be controlled by this unit.

Please inquire to your dealer or nearest

authorized Pioneer service station regarding

the satellite radio tuner that can be connected

to this unit. For satellite radio tuner operation,

please refer to the satellite radio tuner owner’s

manual.

!The system will use direct satellite-to-recei-

ver broadcasting technology to provide lis-

teners in their cars and at home with

crystal-clear sound seamlessly from coast

to coast. Satellite radio will create and

package over 100 channels of digital-quality

music, news, sports, talk and children’s

programming.

!“SAT Radio”, the SAT Radio logo and all re-

lated marks are trademarks of Sirius Satel-

lite Radio inc., and XM Satellite Radio

Inc.

To protect the LCD screen

!Do not allow direct sunlight to fall on the

display when this unit is not being used.

Extended exposure to direct sunlight can

result in LCD screen malfunction due to

the resulting high temperatures.

!When using a cellular phone, keep the an-

tenna of the cellular phone away from the

display to prevent disruption of the video by

the appearance of spots, colored stripes,

etc.

!Never touch the screen with anything be-

sides your finger when operating the touch

panel function. The screen can scratch

easily.

For viewing the LCD

comfortably

Due to its construction, the viewing angle of

the screen size is limited. You can adjust it by

changing either screen size or picture adjust-

ment.

Changing the wide screen size

By changing the screen size from 4:3 to 16:9,

you can adjust the screen so that the screen

can fit to the video image you are playing.

For details concerning operation, refer to

Changing the wide screen mode on page 45.

Before You Start

En 13

Section

Before You Start

Changing the picture adjustment

You can make the best adjustment to the pic-

ture display by the BRIGHTNESS,CONTRAST,

COLOR and HUE. You can also dim or bright-

en the overall picture the DIMMER.

For details concerning operation, refer to

Changing the picture adjustment on page

45.

What the marks on DVDs

indicate

The marks below may be found on DVD disc

labels and packages. They indicate the type of

images and audio recorded on the disc, and

the functions you can use.

Mark Meaning

2Indicates the number of audio sys-

tems.

2Indicates the number of subtitle lan-

guages.

3Indicates the number of viewing an-

gles.

16 : 9 LB Indicates the picture size (aspect ratio:

screen width-to-height ratio) type.

ALL

Indicates the number of the region

where playback is possible.

When an operation is prohibited

When you are watching a DVD and attempt to

perform an operation, it may not be performed

because of the programming on the disc.

When this happens, the icon appears on

the screen.

!The icon may not appear with certain

discs.

Protecting your unit from

theft

The front panel can be detached to deter theft.

!If the front panel is not detached from the

head unit within four seconds of turning off

the ignition, a warning tone will sound.

!You can turn off the warning tone. Refer to

Switching the warning tone on page 43.

Important

!Handle gently when removing or attaching

the front panel.

!Avoid subjecting the front panel to excessive

shock.

!Keep the front panel out of direct sunlight and

high temperatures.

!If removed, replace the front panel on the unit

before starting up your vehicle.

Removing the front panel

1 Press DETACH to release the front

panel.

2 Grab the front panel and remove.

Take care not to grip it too tightly or to drop

the front panel and protect it from contact

with water or other fluids to prevent perma-

nent damage.

Attaching the front panel

%Replace the front panel by clipping it

into place.

Before You Start

Section

Resetting the microprocessor

Pressing RESET lets you reset the micropro-

cessor to its initial settings without changing

the bookmark information.

The microprocessor must be reset under the

following conditions:

!Prior to using this unit for the first time

after installation

!If the unit fails to operate properly

!When strange or incorrect messages ap-

pear on the display

1 Turn the ignition switch OFF.

2 Press RESET with a pen tip or other

pointed instrument.

RESET button

Note

After completing connections or when you want

to erase all memorized settings or return the unit

to its initial (factory) settings, switch your engine

ON or set the ignition switch to ACC ON before

pressing RESET.

Feature demo mode

The feature demo automatically starts when

you select the source OFF. The demo con-

tinues while the ignition switch is set to ACC

or ON. To cancel the feature demo, press and

hold VOLUME/MUTE. To restart the feature

demo, press and hold VOLUME/MUTE again.

Remember that if the feature demo continues

operating when the car engine is turned off, it

may drain battery power.

Important

The red lead (ACC) of this unit should be con-

nected to a terminal coupled with ignition switch

on/off operations. If this is not done, the vehicle

battery may be drained.

Before You Start

En 15

Section

Before You Start

What’s what

Head unit

1VOLUME/MUTE button

Rotate it to increase or decrease the vo-

lume.

Press to cut the sound.

2Disc loading slot

Insert a disc to play.

3EJECT (h) button

Press to eject a disc from this unit.

4EQ button

Press to select various equalizer curves.

5OPEN/CLOSE button

Press to open or close the LCD panel.

Press and hold to turn the LCD panel hori-

zontal temporarily from upright position.

6SRC button

This unit is turned on by selecting a source.

Press to cycle through all the available

sources.

7c/d(TRACK) buttons

Press to do manual seek tuning, fast for-

ward, reverse and track search controls.

8RESET button

Press to return to the factory settings (initial

settings).

9DETACH button

Press to remove the front panel from the

head unit.

Optional remote control

The remote control CD-R55 is sold separately.

For details concerning operations, see the re-

mote control manual.

Operating this unit

Section

Basic Operations

Power ON/OFF

1Source icon

Turning the unit on

%When using the touch panel keys,

touch the source icon and then touch the

desired source name.

The source names are displayed and select-

able ones are highlighted.

%When using the button, press SRC to

turn the unit on.

Turning the unit off

%When using the touch panel keys,

touch the source icon and then touch OFF.

#When the source icon is not displayed, you

can display it by touching the screen.

%When using the button, press SRC and

hold until the unit turns off.

Selecting a source

You can select a source you want to listen to.

To switch to the DVD player, load a disc in the

unit. To switch to the iPod, connect an iPod to

this unit.

%When using the touch panel keys,

touch the source icon and then touch the

desired source name.

The source names are displayed and select-

able ones are highlighted.

!DVD –Built-in DVD player

!RADIO –Radio

!iPod –iPod

!USB –USB portable audio player/USB

memory

!TEL –Bluetooth telephone

!BT-Audio –Bluetooth audio player

!S-DVD –DVD player/multi-DVD player

!MCD –Multi-CD player

!AUX 1 –AUX 1

!AUX 2 –AUX 2

!AV –AV input

!TV –Television

!EXT 1 –External unit 1

!EXT 2 –External unit 2

!XM –XM tuner

!SIRIUS –SIRIUS tuner

!REARVIEW –Rear view camera

!OFF –Turn the unit off

#When the source icon is not displayed, you

can display it by touching the screen.

#While operating the menu, you cannot select

a source by touching the source icon.

#To close source select menu, touch ESC.

#When connecting an iPod, you cannot select

a USB source to this unit.

%When using the button, press SRC re-

peatedly to select a desired source.

Notes

!In the following cases, the sound source will

not change.

—When no unit corresponding to the se-

lected source is connected.

—When there is no disc or magazine in the

player.

—When AUX (auxiliary input) is set to off

(refer to page 42).

—When the AV (AV input) is not set to

VIDEO (refer to page 46).

!AUX1 is set to VIDEO by default. Set the AUX1

to OFF when not in use (refer to Switching the

auxiliary setting on page 42).

!REARVIEW (rear view camera) cannot be se-

lected by pressing SRC.

Operating this unit

En 17

Section

Operating this unit

!Image from rear view camera can be dis-

played automatically when the appropriate

setting is conducted. For details, refer to Set-

ting for rear view camera (back up camera) on

page 47.

!External unit refers to a Pioneer product (such

as ones available in the future) that, although

incompatible as a source, enables control of

basic functions with this unit. Two external

units can be controlled with this unit. When

two external units are connected, the external

unit is automatically allocated to external unit

1 or external unit 2 by this unit.

!When this unit’s blue/white lead is connected

to the vehicle’s auto-antenna relay control

terminal, the vehicle’s antenna extends when

this unit’s source is turned on. To retract the

antenna, turn the source off.

Adjusting the volume

%Use VOLUME/MUTE to adjust the

sound level.

Rotate VOLUME/MUTE to increase or de-

crease the volume.

Touch panel key basic operation

Activating the touch panel keys

1AV MENU key

Touch to display MENU.

2TILT (/ ) keys

Touch to adjust the LCD panel angle.

3Touch panel keys

Touch to do various operations.

1 Touch the screen to activate the touch

panel keys corresponding to each source.

The touch panel keys appear on the display.

#To go to the next group of touch panel keys,

touch NEXT.

#To return to the previous group of touch panel

keys, touch PREV.

2 Touch HIDE to hide the touch panel

keys.

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically when

selecting video sources.

Operating the menu

1FUNCTION MENU key

Touch to select functions for each source.

2AUDIO MENU key

Touch to select various sound quality controls.

3SYSTEM MENU key

Touch to select various setup functions.

4ESC key

Touch to cancel the control mode of func-

tions.

1 Touch AV MENU to display MENU.

The menu names are displayed and operable

ones are highlighted.

#When AV MENU is not displayed, you can dis-

play it by touching the screen.

Operating this unit

Section

2 Touch the desired key to display the

function names you want to operate.

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

3 Touch ESC to return to the display of

each source.

Opening and closing the LCD panel

The LCD panel will be opened or closed auto-

matically with the turning of the ignition

switch on or off. You can turn off the automatic

close/open function. (Refer to page 48.)

!Do not close the LCD panel with hands by

force. That cause malfunction.

!The automatic close/open function will op-

erate the display as follows.

—When the ignition switch is turned OFF

while the LCD panel is opened, the LCD

panel will close after six seconds.

—When the ignition switch is turned ON

again (or turned to ACC), the LCD panel

will be opened automatically.

—Removing or attaching the front panel

will automatically close or open the LCD

panel. (Refer to page 14.)

!When the ignition switch is turned OFF

after the LCD panel has been closed, turn-

ing the ignition switch ON again (or turning

it to ACC) will not open the LCD panel. In

this case, press OPEN/CLOSE to open the

LCD panel.

!When closing the LCD panel, check to

make sure that it has closed completely. If

the LCD panel has stopped halfway, leaving

it like this could result in damage.

CAUTION

Keep hands and fingers clear of the unit when

opening, closing, or adjusting the LCD panel. Be

especially cautious of children’s hands and fin-

gers.

%Press OPEN/CLOSE to open the LCD

panel.

#To close the LCD panel, press OPEN/CLOSE

again.

Adjusting the LCD panel angle

Important

!If you can hear the LCD panel knocking

against your vehicle’s console or dashboard,

touch TILT () to move the LCD panel a little

forward.

!When adjusting the LCD panel angle, be sure

to touch TILT (/ ). Forcibly adjusting the

LCD panel by hand may damage it.

%Touch TILT ( / ) to adjust the LCD

panel to an easily viewable angle.

The LCD panel angle continues changing as

long as you touch TILT (/ ) and hold.

#The adjusted LCD panel angle will be memor-

ized and automatically returned to the next time

the LCD panel is opened.

Turning the LCD panel horizontal

When the LCD panel is upright and it hinders

the operation of the air conditioner, the panel

can be turned horizontal temporarily.

Operating this unit

En 19

Section

Operating this unit

%Press and hold OPEN/CLOSE to turn the

LCD panel horizontal.

#To return to original position, press and hold

OPEN/CLOSE again.

#The LCD panel returns to the original position

automatically with beeping sound 10 seconds

after operation.

Radio

Basic Operations

1Source icon

2Band indicator

3Preset number indicator

4Frequency indicator

5LOCAL indicator

Appears when local seek tuning is on.

65(stereo) indicator

Appears when the selected frequency is being

broadcast in stereo.

1 Touch the source icon and then touch

RADIO to select the radio.

2 Touch BAND to select a band.

Touch BAND until the desired band (FM1,

FM2,FM3 for FM or AM) is displayed.

3 To perform manual tuning, briefly

touch cor d.

#You can also perform manual tuning by press-

ing cor d(TRACK).

4 To perform seek tuning, keep touching

cor dfor about one second and release.

The tuner will scan the frequencies until a

broadcast strong enough for good reception is

found.

#You can cancel seek tuning by briefly touching

either cor d.

#If you keep touching cor dyou can skip sta-

tions. Seek tuning starts as soon as you release

the key.

#You can also perform seek tuning by pressing

and holding cor d(TRACK).

Operating this unit

Section

Note

Listening AM radio while an iPod is charged from

this unit may generate noise. In this case, turn

the iPod charge setting off and noise is disap-

peared. (Refer to Switching the iPod charge setting

on page 48.)

Storing and recalling broadcast

frequencies

You can easily store up to six broadcast fre-

quencies for later recall.

!Up to 18 FM stations, six for each of the

three FM bands, and six AM stations can

be stored in memory.

1 Touch LIST to display the preset list.

2 When you find a frequency that you

want to store in memory keep touching

one of preset tuning keys P1 to P6 until the

beep sounds.

The selected radio station frequency has been

stored in memory.

The next time you touch the same preset tun-

ing key the radio station frequency is recalled

from memory.

3 Touch ESC to return to the ordinary dis-

play.

Note

You can also use aand bto recall radio station

frequencies assigned to preset tuning keys P1 to

P6.

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the frequency

display.

#To return to the previous display, touch BACK.

Storing the strongest broadcast

frequencies

BSM (best stations memory) lets you automa-

tically store the six strongest broadcast fre-

quencies under preset tuning keys P1 to P6

and once stored there you can tune in to those

frequencies with the touch of a key.

!Storing broadcast frequencies with BSM

may replace broadcast frequencies you

have saved using P1 to P6.

%Touch BSM on the function menu to

turn BSM on.

BSM begins to flash. While BSM is flashing

the six strongest broadcast frequencies will be

stored under preset tuning keys P1 to P6 in

order of their signal strength. When finished,

BSM stops flashing.

#To cancel the storage process, touch BSM

again.

Tuning in strong signals

Local seek tuning lets you tune in only those

radio stations with sufficiently strong signals

for good reception.

%Touch LOCAL on the function menu to

set the sensitivity.

Touch LOCAL repeatedly until the desired level

of sensitivity appears in the display.

There are four levels of sensitivity for FM and

two levels for AM:

FM: OFF—LEVEL1—LEVEL2—LEVEL3—

LEVEL4

AM: OFF—LEVEL1—LEVEL2

The LEVEL4 setting allows reception of only

the strongest stations, while lower settings let

you receive progressively weaker stations.

Operating this unit

En 21

Section

Operating this unit

Built-in DVD player

Basic Operations

1Source icon

2Media indicator

Shows the type of disc currently playing.

3Title/Folder number indicator

DVD: shows the title currently playing.

Compressed audio and DivX: shows the folder

currently playing.

4Chapter/track/file number indicator

DVD: shows the chapter currently playing.

Video CD and CD: shows the track currently

playing.

Compressed audio and DivX: shows the file

currently playing.

5Play time indicator

6Variable message area

DVD video: shows the subtitle language,

audio language and viewing angle.

CD TEXT, compressed audio and DivX: shows

the text information of currently playing disc.

1 Insert a disc into the disc loading slot.

Playback will automatically start.

#Be sure to turn up the label side of a disc.

#After a disc has been inserted, use touch

panel keys to select the DVD player.

#When the automatic playback function is on,

this unit will cancel the DVD menu and automati-

cally start playback from the first chapter of the

first title. Refer to Automatic playback of DVDs on

page 27.

#With some DVD discs, a menu may be dis-

played. (Refer to Operating the DVD menu on the

next page.)

#With a Video CD featuring the PBC (playback

control) function, a menu is displayed. (Refer to

PBC playback on page 24.)

#To eject a disc, press h(eject).

2 Touch the screen to display the touch

panel keys.

3 When playing a compressed audio or

DivX, touch aor bto select a folder.

#To return to folder 01 (ROOT), touch and hold

. However, if folder 01 (ROOT) contains no files,

playback commences with folder 02.

is displayed only when the list is operated.

4 To skip back or forward to another

chapter/track, briefly touch oor p.

#You can also skip back or forward to another

chapter/track by pressing cor d(TRACK).

#During PBC playback, a menu may be dis-

played if you perform these operations.

5 To perform fast forward or reverse,

keep touching oor p.

When DVD, DivX disc or Video CD is playing, if

you keep touching oor pfor five sec-

onds, the icon mor nis highlighted.

When this happens, fast reverse/fast forward

continues even if you release oor p.To

resume playback at a desired point, touch

de.

#When playing DVD video or Video CD, fast for-

ward/fast reverse may not be possible at certain

locations on some discs. If this happens, normal

playback automatically resumes.

Notes

!If you do not use the touch panel keys within

30 seconds, they will be hidden automatically

when displaying video image.

!Read the precautions for the player and discs

in the following section. Refer to Handling

guideline of discs and player on page 90.

!If an error message such as ERROR-02-XX is

displayed, refer to Error messages on page 87.

Operating this unit

Section

!If bookmark function is on, DVD playback re-

sumes from the selected point. For more de-

tails, refer to Resume playback (Bookmark) on

page 25.

!If a disc contains a mixture of various media

file types such as DivX and MP3, you can

switch between media file types to play. Refer

to Switching the media file type on this page.

!There is sometimes a delay between starting

up disc playback and the sound being issued.

When being read, FORMAT READ is dis-

played.

!When playing back files recorded as VBR

(variable bit rate) files, the play time will not be

correctly displayed if fast forward or reverse

operations are used.

!When playing back WMA files, album title list

does not appear.

!If the characters recorded on the disc are not

compatible with this unit, those characters

will not be displayed.

Basic playback controls

The table below shows the basic controls for

playing discs. The following chapters cover

other playback features in more details.

Key What it does

de Starts playback, pauses a disc that’s playing or

restarts a paused disc.

gStops playback.

Skips to the start of the current track, chapter

or file, then to previous tracks/chapters/files.

!Performs fast reverse by touching and

holding o.

Skips to the next track, chapter or file.

!Performs fast forward by touching and

holding p.

Note

You may find with some DVD or Video CD discs

that some playback controls do not work in cer-

tain parts of the disc. This is not a malfunction.

Switching the media file type

When playing a disc containing a mixture of

various media file types such as DivX and

MP3, you can switch between media file types

to play.

!This unit allows playback of the following

media file type recorded on CD-R/RW/ROM

discs.

—Audio data (CD-DA)

—Compressed audio files (WMA/MP3/

AAC)

—DivX video files

!In case of DVD-R/RW/ROM, this unit does

not allow playback of audio data (CD-DA).

%Touch MEDIA to switch between media

file types.

Touch MEDIA repeatedly to switch between

the following media file types:

CD (audio data (CD-DA))—WMA/MP3/AAC

(compressed audio)—DivX (DivX video files)

Operating the DVD menu

Some DVDs allow you to select from the disc

contents using a menu.

!This function is available for DVD video.

!You can display the menu by touching

MENU or TOP MENU while a disc is play-

ing. Touching either of these keys again

lets you start playback from the location se-

lected from the menu. For details, refer to

the instructions provided with the disc.

Using DVD menu direct touch control

This function allows you to operate the DVD

menu by touching the menu item directly.

%Touch the desired menu item on the

DVD menu directly.

#Depending on the contents of DVD discs, this

function may not work properly. In this case,

using touch panel keys operate the DVD menu.

Operating this unit

En 23

Section

Operating this unit

Using the touch panel keys

1 Touch to display touch panel keys

to operate the DVD menu.

#When the touch panel keys are not displayed,

you can display them by touching the screen.

#To switch to the DVD menu direct touch con-

trol, touch TOUCH.

2 Touch a,b,cor dto select the desired

menu item.

3 Touch ENTER.

Playback starts from the selected menu item.

#The way to display the menu differs depending

on the disc.

PBC playback

During playback of Video CDs featuring PBC

(Playback Control), PBC ON is displayed. You

can operate PBC menu with 10Key.

!This function is available for Video CD.

1 When PBC menu is displayed, touch

SEARCH and then touch 10Key.

#Depending on the discs, the menu may be

two or more pages long. In such case, touch o

or pto display the next or previous menu.

2 Touch 0 to 9 corresponding to a menu

number and then touch ENTER to start

playback.

Playback starts from the selected menu item.

3 Touch ESC to hide the touch panel keys.

Notes

!You can display the menu by touching

RETURN during PBC playback. For details,

refer to the instructions provided with the

disc.

!PBC playback of Video CD cannot be can-

celed.

!During playback of Video CDs featuring PBC

(Playback Control), PBC ON, search and time

search functions cannot be used nor can you

select the range for repeat play.

Playing DivX®VOD content

Some DivX VOD (video on demand) content

may only be playable a fixed number of times.

When you load a disc containing this type of

DivX VOD content, the remaining number of

plays is shown on-screen and you then have

the option of playing the disc (thereby using

up one of the remaining plays), or stopping. If

you load a disc that contains expired DivX

VOD content (for example, content that has

zero remaining plays), Rental Expired. is dis-

played.

!If your DivX VOD content allows an unlim-

ited number of plays, then you may load

the disc into your player and play the con-

tent as often as you like, and no message

will be displayed.

Important

!In order to play DivX VOD content on this unit,

you first need to register the unit with your

DivX VOD content provider. About your regis-

tration code, refer to Displaying your DivX®

VOD registration code on page 41.

!DivX VOD content is protected by a DRM (Di-

gital Rights Management) system. This re-

stricts playback of content to specific,

registered devices.

%If the message is displayed after load-

ing a disc containing DivX VOD content,

touch PLAY.

Playback of the DivX VOD content will start.

#To skip to the next file, touch NEXT PLAY.

#If you do not want to play the DivX VOD con-

tent, touch STOP.

Skipping back or forward to

another title

!This function is available for DVD.

Operating this unit

Section

%To skip back or forward to another title,

touch aor b.

Touching askips to the start of the next title.

Touching bskips to the start of the previous

title.

Title numbers are displayed for eight seconds.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

CM skip/CM back

This function skips a reproduced image for a

specified time. If the currently playing disc

contains commercials, it is possible to skip

them.

!This function is available for DVD.

%To skip progressively backward or for-

ward, touch or .

Each time you touch or it changes steps

in the following order:

CM back

5 sec.—15 sec.—30 sec.—1.0 min.—2.0

min.—3.0 min.—0 sec.

CM skip

30 sec.—1.0 min.—1.5 min.—2.0 min.—3.0

min.—5.0 min.—10.0 min.—0 sec.

Resume playback (Bookmark)

The Bookmark function lets you resume play-

back from a selected scene the next time the

disc is loaded.

!This function is available for DVD video.

%During playback, touch BOOKMARK at

the point you want to resume playback

next time.

The selected scene will be bookmarked so that

playback resumes from that point next time.

You can bookmark up to five discs. After that,

the oldest bookmark is replaced by the new

one.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#To clear the bookmark on a disc, keep touch-

ing BOOKMARK during playback.

#You can also bookmark a disc by pressing and

holding EJECT at the point you want to bookmark.

Next time you load the disc, playback will resume

from the bookmarked point. Note that you can

only bookmark one disc using this method. To

clear the bookmark on a disc, press EJECT.

Searching for the part you

want to play

You can use the search function to find the

part you want to play.

!This function is available for DVD, DivX

disc and Video CD.

!Chapter search, track search and time

search are not possible when disc playback

has been stopped.

!During playback of Video CDs featuring

PBC (playback control), this function can-

not be operated.

1 Touch SEARCH.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch the desired search option (e.g.,

CHAP.).

#You cannot operate this step during DivX disc

playback.

3 Touch 0 to 9 to input the desired num-

ber.

#To cancel the inputted numbers, touch C.

#In the time search function, to select 1 hour

11 minutes, convert the time into 71 minutes 00

seconds and touch 7,1,0and 0in that order.

4 Touch ENTER.

This starts playback from the selected part.

Note

With DVD discs featuring a menu, you can also

touch MENU or TOP MENU and then make se-

lections from the displayed menu.

Operating this unit

En 25

Section

Operating this unit

Changing audio language

during playback (Multi-audio)

DVDs can provide audio playback with differ-

ent languages and different systems (Dolby Di-

gital, DTS etc.). With DVDs featuring multi-

audio recordings, you can switch between lan-

guages/audio systems during playback.

!This function is available for DVD and DivX

disc.

%Touch AUDIO during playback.

Each time you touch AUDIO it switches be-

tween audio systems.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Notes

!With some DVDs, switching between lan-

guages/audio systems may only be possible

using a menu display.

!You can also switch between languages/audio

systems using DVD SETUP. For details, refer

to Setting the audio language on page 38.

!Only digital output of DTS audio is possible. If

this unit’s optical digital outputs are not con-

nected, DTS audio will not be output, so select

an audio setting other than DTS.

!Display indications such as Dolby D and

5.1ch indicate the audio system recorded on

the DVD. Depending on the setting, playback

may not be with the same audio system as

that indicated.

!Touching AUDIO during fast forward/fast re-

verse, pause or slow motion playback returns

you to normal playback.

Changing the subtitle language

during playback (Multi-subtitle)

With DVDs featuring multi-subtitle recordings,

you can switch between subtitle languages

during playback.

!This function is available for DVD and DivX

disc.

%Touch SUBTITLE during playback.

Each time you touch SUBTITLE it switches be-

tween subtitle languages.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Notes

!With some DVDs, switching between subtitle

languages may only be possible using a menu

display.

!You can also switch between subtitle lan-

guages using DVD SETUP. For details, refer to

Setting the subtitle language on page 38.

!Touching SUBTITLE during fast forward/fast

reverse, pause or slow motion playback re-

turns you to normal playback.

Changing the viewing angle

during playback (Multi-angle)

With DVDs featuring multi-angle (scenes shot

from multiple angles) recordings, you can

switch among viewing angles during play-

back.

!This function is available for DVD video.

!During playback of a scene shot from mul-

tiple angles, the angle icon is dis-

played. Turn angle icon display on or off

using DVD SETUP. For details, refer to Set-

ting the angle icon display on page 39.

%Touch ANGLE during playback of a

scene shot from multiple angles.

Each time you touch ANGLE it switches be-

tween angles.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Note

Touching ANGLE during fast forward/fast reverse,

pause or slow motion playback returns you to

normal playback.

Operating this unit

Section

Frame-by-frame playback

This lets you move ahead one frame at a time

during playback.

!This function is available for DVD and

Video CD.

%Touch rduring playback.

Each time you touch r, you move ahead one

frame.

#To return to normal playback, touch de.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#With some discs, images may be unclear dur-

ing frame-by-frame playback.

Slow motion playback

This lets you slow down playback speed.

!This function is available for DVD and

Video CD.

%Keep touching runtil is displayed

during playback.

The icon is displayed, forward slow motion

playback begins.

#Touching qor rduring slow motion play-

back, you can change the playback speed in four

steps as follows:

1/16—1/8—1/4—1/2

!During DVD playback, only the remote con-

trol can perform this operation.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#To return to normal playback, touch de.

Notes

!There is no sound during slow motion play-

back.

!With some discs, images may be unclear dur-

ing slow motion playback.

!Reverse slow motion playback is not possible.

Return to the specified scene

You can return to the specified scene where

the DVD you are currently playing has been

preprogrammed to return.

!This function is available for DVD video.

%Touch RETURN to return to the speci-

fied scene.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#If a specified scene has not been prepro-

grammed in DVD disc, this function is not possi-

ble.

Automatic playback of DVDs

When a DVD disc with DVD menu is inserted,

this unit will cancel the DVD menu automati-

cally and start playback from the first chapter

of the first title.

!This function is available for DVD video.

!Some DVDs may not operate properly. If

this function is not fully operated, turn this

function off and start playback.

%Touch AUTO PLAY to turn automatic

playback on.

#To turn automatic playback off, touch

AUTO PLAY again.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

#When the automatic playback is on, you can-

not operate repeating play of DVD disc (refer to

Repeating play on the next page).

Text information

Text information recorded on a disc can be dis-

played. Text information is displayed on vari-

able message area.

!This function is available for CD TEXT, com-

pressed audio disc and DivX disc.

Operating this unit

En 27

Section

Operating this unit

Displaying text information

%Touch INFO.

Touch INFO repeatedly to switch between the

following settings:

For CD TEXT discs

: disc title—: disc artist name—: track

title—: track artist name

For compressed audio discs

: folder name—: file name—: album

title—: track title—: artist name

For DivX discs

: folder name—: file name

Notes

!Some discs have certain information encoded

on the disc during manufacture. These discs

may contain such information as the CD title,

track title, artist’s name and playback time

and are called CD TEXT discs.

!If specific information has not been recorded

on a CD TEXT disc, No XXXX will be displayed

(e.g., No name).

!If specific information has not been recorded

on a compressed audio disc, No XXXX will be

displayed (e.g., NO name).

!When playing back WMA files, album title is

not displayed.

Selecting tracks from the track list

Track list lets you see the list of tracks on a

disc and select one of them to play back.

When playing a CD TEXT disc, track titles are

displayed.

!This function is available for CD.

1 Touch LIST.

2 Touch or to switch between the

lists of tracks.

3 Touch your favorite track.

That selection will begin to play.

4 Touch ESC to return to the ordinary dis-

play.

Selecting files from the file

name list

File name list lets you see the list of file names

(or folder names) and select one of them to

playback.

!This function is available for compressed

audio disc and DivX disc.

1 Touch LIST.

2 Touch or to switch between the

lists of titles.

3 Touch your favorite file name (or folder

name).

That selection will begin to play.

#When you have selected a folder, a list of the

names of the files (or the folders) in it can be

viewed. Repeat steps 2 and 3 to select the desired

file name.

#To return to the previous list (the folder one

level higher), touch .

#To return to folder 01 (ROOT), touch and hold

. However, if folder 01 (ROOT) contains no files,

playback commences with folder 02.

4 Touch ESC to return to the ordinary dis-

play.

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch BACK.

Repeating play

Tracks in a play range are played repeatedly.

Play range varies depending on the media.

Operating this unit

Section

For DVD, play range can be selected from

DISC (disc repeat), TITLE (title repeat) and

CHAPTER (chapter repeat).

For Video CD and CD, play range can be se-

lected from DISC (disc repeat) and TRACK

(track repeat).

For compressed audio and DivX, play range

can be selected from DISC (disc repeat),

FOLDER (folder repeat) and FILE (file repeat).

!During playback of Video CDs featuring

PBC (playback control), this function can-

not be operated.

%Touch REPEAT on the function menu to

select the repeat range.

!TITLE –Repeat the current title

!CHAPTER –Repeat the current chapter

!TRACK –Repeat the current track

!FILE –Repeat just the current file

!FOLDER –Repeat the current folder

!DISC –Play through the current disc

Notes

!If you perform chapter search or fast forward/

reverse, the repeat play range changes to

DISC.

!If you select another folder during repeat play,

the repeat play range changes to DISC.

!When playing back compressed audio or

DivX, if you perform track search or fast for-

ward/reverse during FILE, the repeat play

range changes to FOLDER.

!When playing back Video CD or CD, if you per-

form track search or fast forward/reverse dur-

ing TRACK, the repeat play range changes to

DISC.

!When FOLDER is selected, it is not possible to

play back a subfolder of that folder.

!When playing discs with compressed audio

and audio data (CD-DA), repeat play performs

within the currently playing data type even if

DISC is selected.

Playing tracks in random order

Tracks in a selected repeat range are played in

random order.

!This function is available for CD and com-

pressed audio disc.

1 Select the repeat range.

Refer to Repeating play on the previous page.

2 Touch RANDOM on the function menu

to turn random play on.

Tracks will play in a random order within the

previously selected repeat range.

#To turn random play off, touch RANDOM

again.

Scanning tracks or folders

Scan play lets you hear the first 10 seconds of

each track on the CD.

When playing the compressed audio disc, the

first 10 seconds of each track of the current

folder (or the first track of each folder) is

played.

!This function is available for CD and com-

pressed audio disc.

1 Select the repeat range.

Refer to Repeating play on the previous page.

2 Touch SCAN on the function menu to

turn scan play on.

The first 10 seconds of each track is played.

3 When you find the desired track (or

folder) touch SCAN again.

Note

After track or folder scanning is finished, normal

playback of the tracks will begin again.

Selecting audio output

When playing DVD video discs recorded with

LPCM audio, you can switch the audio output.

When playing Video CD discs, you can switch

between stereo and monaural audio output.

Operating this unit

En 29

Section

Operating this unit

!This function is available for DVD and

Video CD.

!This function is not possible when disc

playback has been stopped.

!If you select Linear PCM, when playing a

disc recorded on a dual mono mode, you

can operate this function. (Refer to Setting

for digital output on page 41.)

%Touch L/R SELECT on the function menu

to select the audio output.

Touch L/R SELECT repeatedly until the desired

audio output appears in the display.

!L+R –left and right

!LEFT –left

!RIGHT –right

!MIX –mixing left and right

Note

Depending on the disc and the playback location

on the disc, the function may not be selectable,

indicating that operating this function is not pos-

sible.

Using compression

Using the COMP (compression) function lets

you adjust the sound playback quality of this

unit.

%Touch COMPRESSION on the function

menu to select your favorite setting.

OFF—COMP1—COMP2

Playing songs on iPod

Basic Operations

You can use this unit to control an iPod by

using a cable (e.g., CD-IU205V), which is sold

separately.

1Source icon

2Repeat indicator

Shows when repeat range is set to ONE or

ALL.

3Song number indicator

4Title indicator

5Shuffle indicator

Shows when random play is set to SONGS or

ALBUMS.

6Play time indicator

7Song information

Shows detailed information of currently play-

ing song.

8Battery charging indicator

Shows when the battery charge setting is on.

1 Connect the iPod to this unit.

Playback will automatically start.

While connected to this unit, PIONEER,Acces-

sory Attached or (check mark) is displayed

on the iPod.

#Before connecting the dock connector of this

unit to the iPod, disconnect the headphones from

the iPod.

#Depending on the model of iPod or the data

size in the iPod, there may be a delay to start play-

ing after connection.

#After the iPod has been connected to this

unit, use touch panel keys to select the iPod.

Operating this unit

Section

#When removing the iPod from this unit, this

unit is turned off.

2 To skip back or forward to another

song, touch oor p.

#You can also skip back or forward to another

song by pressing cor d(TRACK).

3 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by pressing and holding cor d(TRACK).

4 When playing a file with chapter, touch

oor pto select a chapter.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Notes

!Read the precautions for iPod in the following

section. Refer to page 94.

!If an error message or icon such as ERROR-11

or is displayed, refer to Error messages on

page 87.

!Connect directly the dock connector cable to

the iPod so that this unit works properly.

!When the ignition switch is set to ACC or ON,

the iPod’s battery is charged while the iPod is

connected to this unit.

!While the iPod is connected to this unit, the

iPod cannot be turned on or off.

!The iPod is turned off about two minutes after

the ignition switch is set to OFF.

Playing video

This unit can play video if an iPod with video

capabilities is connected.

!To pause video playback, touch MENU.

!This unit can play back “Movies”,“Music vi-

deos”,“Video Podcast”and “TV show”

which are downloaded from iTunes store.

!Change the video setting on the iPod so

that the iPod can output the video to an ex-

ternal device, before you display the video

screen.

!For details, refer to the iPod’s manuals.

1 Touch Video.

#To return to the music operation screen, touch

Music.

2 Play video on the iPod.

Browsing for a song/video

Operations to control an iPod with this unit is

designed to be as close to the iPod as possible

to make operation and song/video search

easy.

!If the characters recorded on the iPod are

not compatible with this unit, those charac-

ters are not displayed.

1 Touch MENU to display iPod menus.

2 Touch one of the categories in which

you want to search for a song/video.

When browsing for a song

!PLAYLISTS (playlists)

!ARTISTS (artists)

!ALBUMS (albums)

!SONGS (songs)

!PODCASTS (podcasts)

!GENRES (genres)

!COMPOSERS (composers)

!AUDIOBOOKS (audiobooks)

When browsing for a video

!V.PLAYLISTS (video playlists)

!Movies

!Music videos

!Video podcasts

!TV shows

#To switch between groups of categories, touch

PREV or NEXT.

3 Touch a list title that you want to play.

Repeat this operation until you find the de-

sired song/video.

#You can start playback throughout the se-

lected list by touching and holding desired list

title.

#You can start a playback of all the songs in the

selected list (GENRES,ARTISTS,COMPOSERS or

ALBUMS). To do this, touch ALL.

Operating this unit

En 31

Section

Operating this unit

#You can start a playback of all the videos in

the selected list (Music videos or TV shows). To do

this, touch ALL.

#To switch between the lists of titles, touch or

#To return to the previous menu, touch MENU.

4 Touch ESC to return to the ordinary dis-

play.

Displaying text information on

iPod

%Touch INFO to select the desired text in-

formation.

: song title—: artist name—: album title

#If the characters recorded on the iPod are not

compatible with this unit, those characters are

not displayed.

Repeating play

For playback of the songs on the iPod, there

are two repeat play ranges: ONE (repeat one

song) and ALL (repeat all songs in the list).

!While repeat play range is set to ONE, you

cannot select the other songs. However,

you can select other songs while browsing.

1 Touch NEXT.

2 Touch to select the repeat range.

!ONE –Repeat just the current song

!ALL –Repeat all songs in the selected list

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Playing songs in a random

order (shuffle)

For playback of songs on the iPod, there are

two random play methods: SONGS (play back

songs in a random order) and ALBUMS (play

back albums in a random order).

%Touch to select the random play

method.

!SONGS –Play back songs in the selected

list in random order.

!ALBUMS –Play back songs from a ran-

domly selected album in order.

#To cancel the random play, touch repeat-

edly until the shuffle icon is turned off.

Playing all songs in a random

order (shuffle all)

This method plays all songs on the iPod ran-

domly.

%Touch to turn shuffle all on.

All songs on the iPod play randomly.

Operating this unit’s iPod

function from your iPod

This unit’s iPod function can be operated from

your iPod. Sound can be heard from the car’s

speakers, and operation can be conducted

from your iPod.

!While this function is in use, even if the

ignition key is turned off, the iPod will not

be turned off. To turn off power, operate the

iPod.

1 Touch to switch the control mode.

#Touching switches the control mode to

this unit.

#While using this function, play time and titles

are not displayed on this unit.

#Even if this function is performed, track up/

down, chapter up/down and fast forward/reverse

can be operated from this unit.

#While using this function, browse function

cannot be operated from this unit.

2 Operate the connected iPod to select a

song/video and play.

Operating this unit

Section

Pausing a song

%Touch de during playback.

#To resume playback at the same point that you

turned pause on, touch de again.

Selecting songs from album list

of currently playing artist

Album list of the currently selected artist is

displayed. You can select an album or song

from the artist name.

!This function is not available for video files.

!Depending on the number of files in the

iPod, there may be a delay when displaying

a list.

1 Touch NEXT.

2 Touch LINK SEARCH to turn link search

on.

Searches albums of the artist and displays the

list.

3 Touch a list title that you want to play.

For more details about the selecting operation,

please see Step 3 of the following section.

Refer to Browsing for a song/video on page 31.

Note

If link search is aborted, NOT FOUND is dis-

played.

Changing audiobook speed

While listening to an audiobook on iPod, play-

back speed can be changed.

%Touch A.Book to select your favorite

setting.

!FASTER –Playback faster than normal

speed

!NORMAL –Playback in normal speed

!SLOWER –Playback slower than normal

speed

#To switch between groups of touch panel keys,

touch NEXT or PREV.

Playing songs on USB portable

audio player/USB memory

Basic Operations

For details about the supported device, refer to

Portable audio player compatibility on page 11.

1Source icon

2Media indicator

Shows the type of file currently playing.

3Folder number indicator

4File number indicator

5Title indicator

6Play time indicator

7Song information

Shows detailed information of currently play-

ing song.

1 Touch the source icon and then touch

USB to select the USB.

#When the source icon is not displayed, you

can display it by touching the screen.

2 Touch aor bto select a folder.

#To return to folder 01 (ROOT), touch and hold

. However, if folder 01 (ROOT) contains no files,

playback commences with folder 02.

is displayed only when the list is operated.

#You cannot select a folder that does not have

a compressed audio file recorded in it.

3 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by pressing and holding cor d(TRACK).

Operating this unit

En 33

Section

Operating this unit

4 To skip back or forward to another

compressed audio file, briefly touch oor

#You can also skip back or forward to another

audio file by pressing cor d(TRACK).

Notes

!Optimum performance of this unit may not be

obtained depending on the connected USB

portable audio player/USB memory.

!If folder 01 (ROOT) contains no files, playback

commences with folder 02.

!When the USB portable audio player having

battery charging function is connected to this

unit and the ignition switch is set to ACC or

ON, the battery is charged.

!You can disconnect the USB portable audio

player/USB memory anytime you want to fin-

ish listening to it.

Pausing compressed audio

playback

%Touch de during playback.

#To resume playback at the same point that you

turned pause on, touch de again.

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch BACK.

Function and operation

REPEAT,RANDOM and SCAN operations are

basically the same as that of the built-in DVD

player.

Function name Operation

REPEAT

Refer to Repeating play on page 28.

However, the repeat play ranges

you can select are different from

that of the built-in DVD player. The

repeat play ranges of the USB por-

table audio player/USB memory

are:

!FILE –Repeat just the current

file

!FOLDER –Repeat the current

folder

!ALL –Repeat all files

RANDOM Refer to Playing tracks in random

order on page 29.

SCAN Refer to Scanning tracks or folders

on page 29.

Notes

!If you select another folder during repeat play,

the repeat play range changes to ALL.

!If you perform track search or fast forward/re-

verse during FILE, the repeat play range

changes to FOLDER.

!When FOLDER is selected, it is not possible to

play back a subfolder of that folder.

!After file or folder scanning is finished, nor-

mal playback of the files begins again.

Displaying text information of

an audio file

The operation is the same as that of the built-

in DVD player.

Refer to Text information on page 27.

!If the characters recorded on the audio file

are not compatible with this unit, those

characters will not be displayed.

Selecting files from the file

name list

The operation is the same as that of the built-

in DVD player.

Refer to Selecting files from the file name list

on page 28.

Operating this unit

Section

Audio Adjustments

Introduction of audio adjustments

1Audio display

Shows the audio adjustment status.

Important

If the multi-channel processor (DEQ-P8000) is

connected to this unit, the audio function will be

changed to the multi-channel processor’s audio

menu. For details, refer to Introduction of DSP ad-

justments on page 74.

1 Touch AV MENU and then touch

AUDIO MENU to display the audio function

names.

The audio function names are displayed and

operable ones are highlighted.

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

#When selecting FM and Bluetooth telephone

as the source, you cannot switch to SLA.

2 Touch ESC to return to the ordinary dis-

play.

#To return to the previous display, touch BACK.

Using balance adjustment

You can change the fader/balance setting so

that it can provide the ideal listening environ-

ment in all occupied seats.

1 Touch FADER/BALANCE on the audio

function menu.

#When the rear output setting is S.W,

BALANCE will be displayed instead of

FADER/BALANCE. Refer to Setting the rear output

and subwoofer controller on page 42.

2 Touch aor bto adjust front/rear

speaker balance.

Each time you touch aor bit moves the

front/rear speaker balance towards the front or

the rear.

FRONT:15 to REAR:15 is displayed as the

front/rear speaker balance moves from front to

rear.

#FR: 0 is the proper setting when only two

speakers are used.

#When the rear output setting is S.W, you can-

not adjust front/rear speaker balance. Refer to

Setting the rear output and subwoofer controller

on page 42.

3 Touch cor dto adjust left/right speak-

er balance.

Each time you touch cor dit moves the left/

right speaker balance towards the left or the

right.

LEFT:15 to RIGHT:15 is displayed as the left/

right speaker balance moves from left to right.

Using the equalizer

The equalizer lets you adjust the equalization

to match the car’s interior acoustic character-

istics as desired.

Recalling equalizer curves

There are six stored equalizer curves which

you can easily recall at any time. Here is a list

of the equalizer curves.

Display Equalizer curve

POWERFUL Powerful

NATURAL Natural

VOCAL Vocal

CUSTOM Custom

Operating this unit

En 35

Section

Operating this unit

FLAT Flat

SUPER BASS Super bass

!CUSTOM is an adjusted equalizer curve

that you create. If you make adjustments to

an equalizer curve, the equalizer curve set-

ting is memorized in CUSTOM.

!When FLAT is selected, no supplement or

correction is made to the sound. This is

useful to check the effect of the equalizer

curves by switching alternatively between

FLAT and a set equalizer curve.

%Press EQ to select the equalizer.

Press EQ repeatedly to switch between the fol-

lowing equalizers:

POWERFUL—NATURAL—VOCAL—CUSTOM

—FLAT—SUPER BASS

Adjusting equalizer curves

You can adjust the center frequency and the Q

factor (curve characteristics) of each currently

selected curve band (LOW/MID/HIGH).

!The actual range of the adjustments are dif-

ferent depending on which equalizer curve

is selected.

Level (dB)

Center frequency

Q=2N Q=2W

Frequency (Hz)

1 Touch PARAMETRIC EQ on the audio

function menu.

2 Touch cor dnext to EQ SELECT to se-

lect an equalizer curve.

POWERFUL—NATURAL—VOCAL—CUSTOM

—FLAT—SUPER BASS

3 Touch cor dnext to BAND to select

the equalizer band to adjust.

LOW (low)—MID (mid)—HIGH (high)

4 Touch cor dnext to FREQUENCY to se-

lect the frequency to adjust.

Low: 40Hz—80Hz—100Hz—160Hz

Mid: 200Hz—500Hz—1kHz—2kHz

High: 3.15kHz—8kHz—10kHz—12.5kHz

5 Touch cor dnext to Q.FACTOR to se-

lect the Q factor.

2W—1W—1N—2N

6 Touch aor bto adjust the level of the

equalizer band.

+12dB to -12dB is displayed as the level is in-

creased or decreased.

#You can then select another band and adjust

the level.

Adjusting loudness

Loudness compensates for deficiencies in the

low- and high-sound ranges at low volume.

1 Touch LOUDNESS on the audio function

menu.

2 Touch dto turn loudness on.

#To turn loudness off, touch c.

3 Touch cor dto select a desired level.

LOW (low)—MID (mid)—HIGH (high)

Using subwoofer output

This unit is equipped with a subwoofer output

which can be turned on or off.

!When the subwoofer output is on, you can

adjust the cut-off frequency and the output

level of the subwoofer.

1 Touch SUB WOOFER on the audio func-

tion menu.

2 Touch dnext to SUB WOOFER to turn

subwoofer output on.

#To turn subwoofer output off, touch c.

Operating this unit

Section

3 Touch cor dnext to PHASE to select

the phase of subwoofer output.

Touch dto select normal phase and

NORMAL appears in the display. Touch cto

select reverse phase and REVERSE appears in

the display.

4 Touch cor dnext to LEVEL to adjust

the output level of the subwoofer.

+6 to –24 is displayed as the level is increased

or decreased.

5 Touch cor dnext to FREQUENCY to se-

lect cut-off frequency.

Each time you touch cor dselects cut-off fre-

quencies in the following order:

50Hz—63Hz—80Hz—100Hz—125Hz

Only frequencies lower than those in the se-

lected range are outputted from the subwoo-

fer.

Boosting the bass

Bass boost function boosts the bass level of

sound.

1 Touch BASS BOOSTER on the audio

function menu.

2 Touch cor dto select a desired level.

0to +6 is displayed as the level is increased or

decreased.

Using the high pass filter

When you do not want low sounds from the

subwoofer output frequency range to play

from the front or rear speakers, turn on the

HPF (high pass filter). Only frequencies higher

than those in the selected range are output

from the front or rear speakers.

1 Touch HPF on the audio function menu.

2 Touch dnext to HPF to turn high pass

filter on.

#To turn high pass filter off, touch c.

3 Touch cor dnext to FREQUENCY to se-

lect cut-off frequency.

Each time you touch cor dselects cut-off fre-

quencies in the following order:

50Hz—63Hz—80Hz—100Hz—125Hz

Only frequencies higher than those in the se-

lected range are output from the front or rear

speakers.

Adjusting source levels

SLA (source level adjustment) lets you adjust

the volume level of each source to prevent ra-

dical changes in volume when switching be-

tween sources.

!Settings are based on the FM volume level,

which remains unchanged.

1 Compare the FM volume level with the

level of the source you wish to adjust.

2 Touch NEXT on the audio function

menu.

3 Touch SLA.

4 Touch cor dto adjust the source vo-

lume.

Each time you touch cor dit increases or de-

creases the source volume.

+4 to –4is displayed as the source volume is

increased or decreased.

Notes

!The AM volume level can also be adjusted

with source level adjustments.

!Video CD, CD, compressed audio and DivX

are set to the same source level adjustment

volume automatically.

!External unit 1 and external unit 2 are set to

the same source level adjustment volume

automatically.

Operating this unit

En 37

Section

Operating this unit

Setting up the DVD player

Introduction of DVD setup

adjustments

You can use this menu to change audio, subti-

tle, parental lock and other DVD settings.

1DVD setup menu display

Shows the DVD setup menu names.

1 Touch g.

SETUP will be displayed instead of MENU.

2 Touch SETUP.

The DVD setup function names are displayed.

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

3 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch BACK.

Setting the subtitle language

You can set a desired subtitle language. If the

selected subtitle language is recorded on the

DVD, subtitles are displayed in that language.

1 Touch SUB TITLE LANGUAGE on the

DVD setup menu.

A subtitle language menu is displayed.

2 Touch the desired language.

A subtitle language is set.

#To switch to the second language select

menu, touch NEXT.

#To return to the first language select menu,

touch PREV.

#If you have selected OTHERS, refer to When

you select OTHERS on this page.

Notes

!If the selected language is not recorded on

the disc, the language specified on the disc is

displayed.

!You can also switch the subtitle language by

touching SUBTITLE during playback. (Refer to

Changing the subtitle language during play-

back (Multi-subtitle) on page 26.)

!Even if you use SUBTITLE during playback to

switch the subtitle language, this does not af-

fect the settings here.

When you select OTHERS

When you select OTHERS, a language code

input display is shown. Please see the follow-

ing section to input the four-digit code of the

desired language. Refer to Language code

chart for DVD on page 97.

1 Touch 0 to 9 to input the language

code.

#To cancel the inputted numbers, touch C.

2 Touch ENTER.

Setting the audio language

You can set the preferred audio language.

1 Touch AUDIO LANGUAGE on the DVD

setup menu.

An audio language menu is displayed.

2 Touch the desired language.

The audio language is set.

#To switch to the second language select

menu, touch NEXT.

#To return to the first language select menu,

touch PREV.

#If you have selected OTHERS, refer to When

you select OTHERS on this page.

Operating this unit

Section

Notes

!If the selected language is not recorded on

the disc, the language specified on the disc is

outputted.

!You can also switch the audio language by

touching AUDIO during playback. (Refer to

Changing audio language during playback

(Multi-audio) on page 26.)

!Even if you use AUDIO during playback to

switch the audio language, this does not af-

fect the settings here.

Setting the menu language

You can set the preferred language for dis-

plays of menus recorded on a disc.

1 Touch MENU LANGUAGE on the DVD

setup menu.

A menu language menu is displayed.

2 Touch the desired language.

The menu language is set.

#To switch to the second language select

menu, touch NEXT.

#To return to the first language select menu,

touch PREV.

#If you have selected OTHERS, refer to When

you select OTHERS on the previous page.

Note

If the selected language is not recorded on the

disc, the language specified on the disc is dis-

played.

Switching the assist subtitle on

or off

If assist subtitles are recorded on a DVD disc,

you can display them by turning the assist

subtitle function on.

You can turn assist subtitles on or off as de-

sired.

%Touch ASSIST SUBTITLE on the DVD

setup menu to turn assist subtitles on.

#To turn the assist subtitle off, touch

ASSIST SUBTITLE again.

Setting the angle icon display

You can set it up so that the angle icon ap-

pears on scenes where the angle can be

switched.

!Initially, this function is set to on.

%Touch MULTI ANGLE on the DVD setup

menu to turn angle icon display on.

#To turn the angle icon display off, touch

MULTI ANGLE again.

Setting the aspect ratio

There are two kinds of display. A wide screen

display has a width-to-height ratio (TV aspect)

of 16:9, while a regular display has a TV aspect

of 4:3. Be sure to select the correct TV aspect

for the display connected to REAR MONITOR

OUTPUT.

!When using a regular display, select either

LETTER BOX or PAN SCAN. Selecting

16 : 9 may result in an unnatural picture.

!If you select the TV aspect, the unit’s dis-

play changes to the same setting.

%Touch TV ASPECT on the DVD setup

menu to select the TV aspect.

Touch TV ASPECT repeatedly until the desired

TV aspect appears in the display.

!16 : 9 –Wide screen picture (16:9) is dis-

played as it is (initial setting)

!LETTER BOX –The picture is the shape of a

letterbox with black bands at the top and

bottom of the screen

!PAN SCAN –The picture is cut short at the

right and left of the screen

Operating this unit

En 39

Section

Operating this unit

Notes

!When playing discs that do not specify

PAN SCAN, playback is with LETTER BOX

even if you select PAN SCAN setting. Confirm

whether the disc package bears the 16 : 9 LB

mark. (Refer to page 14.)

!Some discs do not enable changing of the TV

aspect. For details, refer to the disc’s instruc-

tions.

Setting the parental lock

Some DVD video discs let you use parental

lock to restrict children from viewing violent

and adult-oriented scenes. You can set the par-

ental lock to your desired level.

!When you set a parental lock level and then

play a disc featuring parental lock, code

number input indications may be dis-

played. In this case, playback will begin

when the correct code number is input.

Setting the code number and level

You need to have registered a code number for

playing back discs with parental lock.

1 Touch NEXT on the DVD setup menu.

2 Touch PARENTAL.

3 Touch 0 to 9 to input a four digit code

number.

#To cancel the inputted numbers, touch C.

4 Touch ENTER.

The code number is set, and you can now set

the level.

5 Touch any of 1 to 8 to select the desired

level.

The parental lock level is set.

!LEVEL 8 –Playback of the entire disc is pos-

sible (initial setting)

!LEVEL 7 to LEVEL 2 –Playback of discs for

children and non-adult-oriented discs is

possible

!LEVEL 1 –Playback of discs for children

only is possible

Notes

!We recommend to keep a record of your code

number in case you forget it.

!The parental lock level is recorded on the disc.

Look for the level indication written at the disc

package, included literature or on the disc it-

self. Parental lock of this unit is not possible if

a parental lock level is not recorded in the

disc.

!With some discs, the parental lock may be ac-

tive only on the scenes with certain levels. The

playback of those scenes will be skipped. For

details, refer to the instruction manual that

came with the discs.

Changing the level

You can change the set parental lock level.

1 Touch NEXT on the DVD setup menu.

2 Touch PARENTAL.

3 Touch 0 to 9 to input the registered

code number.

4 Touch ENTER.

This enters the code number, and you can now

change the level.

#If you input an incorrect code number, the

icon is displayed. Touch Cand input the cor-

rect code number.

#If you forget your code number, refer to If you

forget your code number on this page.

5 Touch any of 1 to 8 to select the desired

level.

The new parental lock level is set.

If you forget your code number

Please see the following section, and touch C

10 times. Refer to Changing the level on this

page. The registered code number is canceled,

letting you register a new one.

Operating this unit

Section

Setting the DivX subtitle file

You can select whether to display DivX exter-

nal subtitles or not.

!The DivX subtitles will be displayed even

when CUSTOM is selected if no DivX exter-

nal subtitle files exist.

1 Touch NEXT on the DVD setup menu.

2 Touch DivX SUB TITLE to select the de-

sired subtitle setting.

!ORIGINAL –Display the DivX subtitles

!CUSTOM –Display the DivX external subti-

tles

Notes

!Up to 42 characters can be displayed on one

line. If more than 42 characters are set, the

line breaks and the characters are displayed

on the next line.

!Up to 126 characters can be displayed on one

screen. If more than 126 characters are set,

the excess characters will not be displayed.

Displaying your DivX®VOD

registration code

In order to play DivX VOD (video on demand)

content on this unit, you first need to register

the unit with your DivX VOD content provider.

You do this by generating a DivX VOD registra-

tion code, which you submit to your provider.

1 Touch NEXT on the DVD setup menu.

2 Touch DivX VOD.

Your 8-digit registration code is displayed.

!Make a note of the code as you will need it

when you register with a DivX VOD provider.

Setting for digital output

Audio which is outputted from digital output

of this unit can be selected. Normally, set to

STREAM. If this unit’s digital output is not

used, there is no need to change settings.

!Selecting Linear PCM enables you to

switch the output channel if playing the fol-

lowing type of discs. (Refer to Selecting

audio output on page 29.)

—Dual mono mode DVD video discs

1 Touch NEXT on the DVD setup menu.

2 Touch DIGITAL OUTPUT to select the de-

sired digital output setting.

!STREAM –The Dolby Digital/DTS signal is

output as it is (initial setting)

!Linear PCM –The Dolby Digital/DTS signal

is converted to and output as a linear PCM

signal

Operating this unit

En 41

Section

Operating this unit

Initial Settings

Adjusting initial settings

Using the initial settings, you can customize

various system settings to achieve optimal per-

formance from this unit.

1Function display

Shows the function names.

1 Touch the source icon and then touch

OFF to turn this unit off.

2 Touch the screen to display the touch

panel keys.

3 Touch AV MENU and then touch

INITIAL MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

4 Touch ESC to return to the ordinary dis-

play.

#To return to the previous display, touch BACK.

Switching the auxiliary setting

Auxiliary devices connected to this unit can be

activated individually. Set each AUX source to

ON when using. For more information about

connecting or using auxiliary devices, refer to

Using the AUX source on page 49.

Switching the auxiliary 1 setting

%Touch AUX1 on the initial menu to se-

lect desired setting.

!VIDEO –an iPod with video capabilities

connected with 4-pole mini plug cable (e.g.,

CD-V150M)

!AUDIO –auxiliary device connected with a

stereo mini plug cable

!OFF –No auxiliary device is connected

Switching the auxiliary 2 setting

%Touch AUX2 on the initial menu to turn

auxiliary 2 setting on.

#To turn auxiliary 2 setting off, touch AUX2

again.

Setting the rear output and

subwoofer controller

This unit’s rear output (rear speaker leads out-

put and RCA rear output) can be used for full-

range speaker (FULL) or subwoofer (S.W) con-

nection. If you switch the rear output setting

to S.W, you can connect a rear speaker lead

directly to a subwoofer without using an auxili-

ary amp.

Initially, the unit is set for rear full-range speak-

er connection (FULL). When rear output is

connected to full range speakers (when FULL

is selected), you can connect other full range

speakers (REAR) or a subwoofer (S.W) to the

RCA rear output.

!When the multi-channel processor (DEQ-

P8000) is connected to this unit, you can-

not operate this function.

1 Touch REAR SP on the initial menu.

2 Touch cor dnext to REAR SP to switch

the rear output setting.

Touch cto select full-range speaker and FULL

appears in the display. Touch dto select sub-

woofer and S.W appears in the display.

#When no subwoofer is connected to the rear

output, select FULL (full-range speaker).

Operating this unit

Section

#When a subwoofer is connected to the rear

output, select S.W (subwoofer).

#When the rear output setting is S.W, you can-

not operate the following procedure.

3 Touch cor dnext to PREOUT to switch

the subwoofer output or rear output.

Touching cor dwill switch between S.W and

REAR and that status will be displayed.

Notes

!Even if you change this setting, there is no

output unless you turn the subwoofer output

on (refer to Using subwoofer output on page

36).

!If you change this setting, subwoofer output

in the audio menu will return to the factory

settings.

!Both rear speaker lead outputs and RCA rear

output are switched simultaneously in this

setting.

Changing languages for CAUTION

Some operations on this unit are prohibited

while driving or needs to be paid a careful at-

tention when operating. In such case, a cau-

tion appears on the display. You can change

the language of the cautions at this setting.

%Touch CAUTION LANGUAGE on the in-

itial menu to select your desired language.

Each time you touch CAUTION LANGUAGE it

selects languages for CAUTION in the follow-

ing order:

ENGLISH—ESPAÑOL—FRANÇAIS

Switching the sound muting/

attenuation

Sound from this system is muted or attenu-

ated automatically when the signal from the

equipment with mute function is received.

!Sound from this system returns to normal

when the muting or attenuation is can-

celed.

%Touch TEL to select any of the muting,

attenuation or off.

Touch TEL until the desired setting appears in

the display.

!MUTE –Muting

!ATT-20dB –Attenuation (ATT-20dB has a

stronger effect than ATT-10dB)

!ATT-10dB –Attenuation

!OFF –Turn the sound muting/attenuation

off

Notes

!The sound is turned off, MUTE is displayed

and no audio adjustments are possible.

!The sound is attenuated, ATT is displayed and

no audio adjustments, except volume control,

are possible.

!Operation returns to normal when the phone

connection is ended.

Switching the warning tone

If the front panel is not detached from the

head unit within four seconds of turning off

the ignition, a warning tone sounds. You can

turn off the warning tone.

1 Touch NEXT on the initial menu.

2 Touch DT.WARNING to turn warning

tone on.

#To turn warning tone off, touch DT.WARNING

again.

Entering PIN code for Bluetooth

wireless connection

To connect your cellular phone to this unit via

Bluetooth wireless technology, you need to

enter PIN code on your phone to verify the

connection. The default code is 0000, but you

can change this in this function.

!With some Bluetooth audio players, you

may be required to enter the Bluetooth

audio player PIN code in advance to set

this unit for a connection.

Operating this unit

En 43

Section

Operating this unit

!You can only operate this function when

Bluetooth adapter (e.g. CD-BTB200) is con-

nected to this unit.

1 Touch NEXT on the initial menu.

2 Touch PINCODE INPUT.

PIN code input display appears.

3 Touch 0 to 9 to input the PIN code of

your Bluetooth audio player.

#To cancel the inputted numbers, touch C.

4 After inputting PIN code (up to 16 di-

gits), touch ENTER.

The PIN code you entered is stored in this sys-

tem.

Correcting distorted sound

You can minimize distortion that may be

caused by the equalizer curve settings.

Setting an equalizer level high can cause dis-

tortion. If high sound is crippled or distorted,

try switching to LOW. Normally, leave the set-

ting at HIGH to ensure quality sound.

!Only when the multi-channel processor

(DEQ-P8000) is connected to this unit, you

can operate this function.

1 Touch NEXT on the initial menu.

2 Touch DIGITAL ATT to switch the digital

attenuator setting.

Touch DIGITAL ATT repeatedly until the de-

sired setting appears in the display.

!HIGH –High quality sound

!LOW –Minimize distortion sound

Resetting the audio functions

You can reset all audio functions except vo-

lume.

!Only when the multi-channel processor

(DEQ-P8000) is connected to this unit, you

can operate this function.

1 Touch NEXT on the initial menu.

2 Touch AUDIO RESET.

3 Touch RESET.

4 Touch RESET again to reset audio func-

tions.

#To cancel resetting the audio functions, touch

CANCEL.

Operating this unit

Section

Other Functions

Introduction of system

adjustments

1System menu display

Shows the system function names.

1 Touch AV MENU and then touch

SYSTEM MENU to display the system func-

tion names.

The system function names are displayed and

operable ones are highlighted.

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

2 Touch ESC to return to the display of

each source.

#To return to the previous display, touch BACK.

Changing the wide screen mode

You can select a desired mode for enlarging a

4:3 picture to a 16:9 one.

1 Touch WIDE MODE on the system

menu.

2 Touch the desired wide mode setting.

3 Touch ESC to hide the touch panel keys.

FULL (full)

A 4:3 picture is enlarged in the horizontal direc-

tion only, giving you a 4:3 TV picture (normal pic-

ture) without any omissions.

JUST (just)

The picture is enlarged slightly at the center and

the amount of enlargement increases horizontally

to the ends, enabling you to enjoy a 4:3 picture

without sensing any disparity even on a wide

screen.

CINEMA (cinema)

The picture is enlarged by the same proportion as

FULL or ZOOM in the horizontal direction and by

an intermediate proportion between FULL and

ZOOM in the vertical direction; ideal for a cine-

ma-sized picture (wide screen picture) where cap-

tions lie outside.

ZOOM (zoom)

A 4:3 picture is enlarged in the same proportion

both vertically and horizontally; ideal for a cine-

ma-sized picture (wide screen picture).

NORMAL (normal)

A 4:3 picture is displayed as it is, giving you no

sense of disparity since its proportions are the

same as that of the normal picture.

Notes

!Different settings can be memorized for each

video source.

!When video is viewed in a wide screen mode

that does not match its original aspect ratio, it

may appear different.

!Remember that using the wide mode feature

of this system for commercial or public view-

ing purposes may constitute an infringement

on the author’s rights protected by the Copy-

right Law.

!The video image will appear coarser when

viewed in CINEMA or ZOOM mode.

Changing the picture adjustment

You can adjust the BRIGHTNESS (brightness),

CONTRAST (contrast), COLOR (color) and

HUE (hue) for each source and rear view cam-

era.

!You cannot adjust COLOR or HUE for the

audio source.

Operating this unit

En 45

Section

Operating this unit

1 Touch PICTURE ADJUSTMENT on the

system menu.

The adjustment function names are displayed.

2 Touch any of the following touch panel

keys to select the function to be adjusted.

!BRIGHTNESS –Adjusts the black intensity

!CONTRAST –Adjusts the contrast

!COLOR –Adjusts the color saturation

!HUE –Adjusts the tone of color (red is em-

phasized or green is emphasized)

!DIMMER –Adjust the brightness of display

!REAR VIEW/SOURCE –Switch the picture

adjustment modes

#You cannot adjust the picture adjustment for

rear view camera when CAMERA POLARITY is

set to OFF. (Refer to Setting for rear view camera

(back up camera) on the next page.)

#With some rear view cameras, picture adjust-

ment may not be possible.

3 Touch cor dto adjust the selected

item.

Each time you touch cor dit increases or de-

creases the level of selected item. +24 to –24

is displayed as the level is increased or de-

creased.

4 Touch ESC to hide the touch panel keys.

Adjusting the dimmer

To prevent the display from being too bright at

night, the display is automatically dimmed

when the car’s headlights are turned on. You

can turn the dimmer on or off.

1 Touch PICTURE ADJUSTMENT on the

system menu.

The adjustment function names are displayed.

2 Touch DIMMER.

3 Touch cor dto adjust the brightness.

Each time you touch cor dit moves cursor

towards the left or the right.

The level indicates the brightness of the

screen being adjusted. The farther the cursor

moves to the right, the brighter the screen be-

comes.

4 Touch ESC to hide the touch panel keys.

Selecting the background display

You can switch background displays while lis-

tening to each source.

!You can enjoy AV (AV input) as the back-

ground video image while you are listening

to audio source such as radio or CD.

%Touch BACKGROUND on the system

menu to select the desired background dis-

play.

Audio source

BGP1 (background picture 1)—BGP2 (back-

ground picture 2)—BGP3 (background picture

3)—AV (AV input)

Video source

OFF (off)—BGP1 (background picture 1)—

BGP2 (background picture 2)—BGP3 (back-

ground picture 3)—AV (AV input)

#When the AV (AV input) is not set to VIDEO,

AV cannot be selected. (Refer to this page.)

Setting the AV input

You can switch the setting according to the

connected component.

!Select VIDEO to watch video of a con-

nected component as AV source.

!Select S-DVD to watch video of a con-

nected DVD player as S-DVD source.

!Select EXT-VIDEO to watch video of a con-

nected video unit as EXT source.

!Select TV to watch TV pictures from a con-

nected TV tuner as TV source.

%Touch AV INPUT on the system menu to

select the AV input setting.

!OFF –No video component connected

!VIDEO –External video component (such

as portable video player)

!S-DVD –DVD player connected with RCA

cable

Operating this unit

Section

!EXT-VIDEO –External video unit (such as

Pioneer products available in the future)

!TV –TV tuner connected with RCA cable

Setting the clock

Use these instructions to set the clock.

1 Touch CLOCK ADJ on the system menu.

2 Touch ON/OFF to turn the clock display

on.

#To turn the clock display off, touch ON/OFF

again.

3 Touch cor dto select the segment of

the clock display you wish to set.

Each time you touch cor dit will select one

segment of the clock display:

Hour—Minute

As you select segments of the clock display

the segment selected will be highlighted.

4 Touch aor bto put a clock right.

Notes

!You can match the clock to a time signal by

touching JUST.

—If 00 to 29, the minutes are rounded down.

(e.g., 10:18 becomes 10:00.)

—If 30 to 59, the minutes are rounded up.

(e.g., 10:36 becomes 11:00.)

!Even when the sources are off, the clock dis-

play appears on the display.

Setting for rear view camera

(back up camera)

CAUTION

Pioneer recommends the use of a camera

which outputs mirror reversed images, other-

wise screen image may appear reversed.

This unit features a function that automatically

switches to the rear view camera video (REAR

CAMERA IN jack) when a rear view camera is

installed on your vehicle. When the gear shift

is in REVERSE (R) position, the video auto-

matically switches to a rear view camera

video. (For more details, consult your dealer.)

!After you set up the rear view camera set-

ting, move the gear shift in REVERSE (R)

and confirm if a rear view camera video

can be shown on the display.

!If the display should be switched to a rear

view camera video by error while you are

driving forward, change the rear view cam-

era setting.

!To end watching a rear view camera video

and return to the source display, press and

hold VOLUME/MUTE.

!Even while driving, rear view camera image

can be displayed. To do this, touch

REARVIEW source icon. In this case, touch

REARVIEW again to turn off the rear view

camera. For details, refer to Selecting a

source on page 17.

%Touch CAMERA POLARITY on the sys-

tem menu to select an appropriate setting.

!BATTERY –When the polarity of the con-

nected lead is positive while the gear shift

is in REVERSE (R) position

!GROUND –When the polarity of the con-

nected lead is negative while the gear shift

is in REVERSE (R) position

!OFF –When a rear view camera is not con-

nected to this unit

Adjusting the LCD panel slide

position

You can adjust the LCD panel slide position so

that the panel is set back or forward.

1 Touch NEXT on the system menu.

2 Touch FLAP SET BACK to turn the set

back on.

The LCD panel slides to the back.

#Touch FLAP SET BACK again to turn the set

back off and the LCD panel slides to the front.

Operating this unit

En 47

Section

Operating this unit

Setting the automatic open

function

To prevent the display from hitting the shift

lever of an automatic vehicle when it is in P

(park) position, or when you do not wish the

display to open/close automatically, you can

set the automatic open function in the manual

mode.

1 Touch NEXT on the system menu.

2 Touch AUTO FLAP to select the display

to open/close automatically or manually.

Each time you touch AUTO FLAP it switches

between the following settings:

!ON –The LCD panel will be opened or

closed automatically with the turning of the

ignition switch on or off

!OFF –You have to press OPEN/CLOSE to

open/close the LCD panel

Switching the iPod charge setting

You can turn the iPod charge setting on or off

while listening to an iPod.

!Listening AM radio while an iPod is

charged from this unit may generate noise.

In this case, turn the iPod charge setting

off and noise is disappeared.

!Initially, this function is set to on.

1 Touch NEXT on the system menu.

2 Touch iPod CHARGE to turn the iPod

charge setting on.

#To turn the iPod charge setting off, touch

iPod CHARGE again.

Note

For maximum performance, we recommend that

you use the latest version of the iPod software.

Selecting the OSD color

You can change the OSD color.

1 Touch NEXT on the system menu.

2 Touch OSD COLOR to select the desired

color.

BLUE (blue)—RED (red)—AMBER (amber)—

GREEN (green)—VIOLET (violet)

Selecting the illumination color

This unit is equipped with multiple-color illu-

mination. You can select a desired color from

112 different types of color.

Direct selection from preset

illumination color

You can select an illumination color from the

color list.

1 Touch ILLUMI COLOR to display the set-

ting menu.

2 Touch one of the color list.

You can select one from the following list.

!BLUE (blue)

!RED (red)

!AMBER (amber)

!GREEN (green)

!VIOLET (violet)

!SCAN (scanning all colors)

Note

SCAN setting cycles continuously through all the

colors.

Customizing the illumination color

1 Touch ILLUMI COLOR to display the set-

ting menu.

2 Touch to display the customizing

menu.

3 Rotate VOLUME/MUTE to customize

the color.

Operating this unit

Section

4 To store the customized color in mem-

ory, touch and hold one of preset keys

() 1 to 3 until the beep sounds.

The customized color has been stored in mem-

ory.

The next time you touch the same preset key,

the color is recalled from memory.

Adjusting the response

positions of the touch panels

(Touch Panel Calibration)

If you feel that the touch panel keys on the

screen deviate from the actual positions that

respond to your touch, adjust the response po-

sitions of the touch panel. There are two ad-

justment methods: 4-point adjustment, in

which you touch four corners of the screen;

and 16-point adjustment, in which you make

fine-adjustments on the entire screen.

!Make sure to use the supplied pen for ad-

justment, and gently touch the screen. If

you press the touch panel forcefully, the

touch panel may be damaged. Do not use

a sharp pointed tool such as ballpoint pen

or a mechanical pen. Otherwise the screen

is damaged.

!If touch panel adjustment cannot be per-

formed properly, consult your local Pioneer

dealer.

1 Touch the source icon and then touch

OFF to turn this unit off.

#When the source icon is not displayed, you

can display it by touching the screen.

2 Press and hold EJECT (h).

The 4-point touch panel adjustment screen ap-

pears.

3 Touch each of the arrows on the four

corners of the screen with the touch panel

adjustment pen.

#To cancel the adjustment, press and hold

VOLUME/MUTE.

4 Press EQ to complete the 4-point ad-

justment.

The adjusted position data is saved.

#Do not turn off the engine while saving the ad-

justed position data.

5 Press EQ to proceed to the 16-point ad-

justment.

The 16-point touch panel adjustment screen

appears.

#To cancel the adjustment, press and hold

VOLUME/MUTE.

6 Gently touch the center of the + mark

displayed on the screen with the touch

panel adjustment pen.

After you touch all the marks, the adjusted po-

sition data is saved.

#Do not turn off the engine while saving the ad-

justed position data.

7 Press and hold VOLUME/MUTE to com-

plete the adjustment.

Using the AUX source

A separately sold auxiliary device such as VCR

or portable device can be connected to this

unit. When connected, auxiliary device is auto-

matically recognized as AUX source and as-

signed to AUX.

About AUX connection method

You have two methods to connect auxiliary de-

vice to this unit.

Mini pin plug cable (AUX 1)

When connecting auxiliary device using a mini

plug cable

iPod and portable audio/video player can be

connected to this unit via mini plug cable.

!If an iPod with video capabilities is con-

nected to this unit via 3.5 mm plug (4 pole)

cable (e.g., CD-V150M), you can enjoy the

video contents of the iPod.

Operating this unit

En 49

Section

Operating this unit

!It is possible to connect a portable audio/

video player by using a 3.5 mm plug (4

pole) to RCA cable, which is sold sepa-

rately. However, depending on the cable, re-

verse connection between red (right side

audio) cable and yellow (video) cable is re-

quired. Otherwise, audio and video may not

be correctly reproduced.

%Insert the mini plug into the AUX input

jack on this unit.

For more details, refer to What’s what on page

16.

IP-BUS-RCA interconnector (AUX 2)

When connecting auxiliary device using an IP-

BUS-RCA Interconnector (sold separately)

%Use an IP-BUS-RCA Interconnector such

as the CD-RB20/CD-RB10 (sold separately)

to connect this unit to auxiliary device fea-

turing RCA output.

For more details, refer to the IP-BUS-RCA Inter-

connector owner’s manual.

#You can only make this type of connection if

the auxiliary device has RCA outputs.

Selecting AUX as the source

%Touch the source icon and then touch

AUX 1/AUX 2 to select AUX as the source.

#If the auxiliary setting is not turned on, AUX

cannot be selected. For more details, refer to

Switching the auxiliary setting on page 42.

Setting the AUX title

The title displayed for the AUX source can be

changed.

!Each title can be up to 10 characters long.

1 After you have selected AUX as the

source, touch AV MENU and

FUNCTION MENU and then touch

NAME EDIT.

#When the touch panel keys are not displayed,

you can display them by touching the screen.

2 Touch ABC to select the desired charac-

ter type.

Touch ABC repeatedly to switch between the

following character types:

Alphabet (upper case)—Alphabet (lower case)

—European letters, such as those with ac-

cents (e.g., á,à,ä,ç)

#You can select to input numbers and symbols

by touching 123.

3 Touch aor bto select a letter of the al-

phabet.

4 Touch dto move the cursor to the next

character position.

5 Touch OK to store the entered title in

memory.

6 Touch ESC to return to the ordinary dis-

play.

Using the external unit

External unit refers to a Pioneer product (such

as ones available in the future) that, although

incompatible as a source, enables control of

basic functions with this unit. Two external

units can be controlled with this unit. When

two external units are connected, the external

unit is automatically allocated to external unit

1 or external unit 2 by this unit.

Basic operations of the external unit are ex-

plained below. Allocated functions are differ-

ent depending on the connected external unit.

For details concerning functions, refer to exter-

nal unit’s owner’s manual.

Selecting the external unit as the source

%Touch the source icon and then touch

EXT 1/EXT 2 to select external unit as the

source.

Operating this unit

Section

Basic operation

Functions allocated to the following opera-

tions are different depending on the con-

nected external unit. For details concerning

functions, refer to the connected external

unit’s owner’s manual.

%Touch BAND.

%Keep touching BAND.

%Touch cor d.

%Keep touching cor d.

%Touch aor b.

Using the functions allocated to 1 to

6 keys

1 Touch NEXT.

2 Touch any of 1 to 6 to select a function.

Advanced operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

!FUNC1 (function 1)

!FUNC2 (function 2)

!FUNC3 (function 3)

!FUNC4 (function 4)

!AUTO/MANUAL (auto/manual)

2 Touch ESC to return to the ordinary dis-

play.

#To return to the previous display, touch BACK.

Using the PGM button

You can operate the preprogrammed functions

for each source by using PGM.

!Only the optional remote control (e.g., CD-

R55) can operate this function.

%Press PGM to turn pause on when se-

lecting the following sources:

!DVD –Built-in DVD player

!iPod –iPod

!USB –USB portable audio player/USB

memory

!S-DVD –DVD player/multi-DVD player

!MCD –Multi-CD player

!BT Audio –Bluetooth audio player

#To turn pause off, press PGM again.

%Press PGM and hold to turn BSM on

when selecting RADIO as the source.

Press PGM and hold until the BSM turns on.

#To cancel the storage process, press PGM

again.

%Press PGM and hold to turn BSSM on

when selecting TV as the source.

Press PGM and hold until the BSSM turns on.

#To cancel the storage process, press PGM

again.

%Press PGM to select the desired channel

select setting when selecting XM or SIRIUS

as the source.

Press PGM repeatedly to switch between the

following channel select settings:

CH-NUMBER (channel number select setting)

—CATEGORY (channel category select

setting)

Operating this unit

En 51

Section

Operating this unit

XM tuner

Basic Operations

You can use this unit to control an XM satellite

digital tuner (GEX-P920XM), which is sold

separately.

For details concerning operation, refer to the

XM tuner’s operation manuals. This section

provides information on XM operations with

this unit which differs from that described in

the XM tuner’s operation manual.

!This unit does not have the text scroll

function.

!With this unit, you can operate one addi-

tional function: XM channel direct

selection.

1Source icon

2XM band indicator

3XM channel category

4XM channel select setting indicator

Shows what channel select setting has been

selected.

5XM preset number indicator

6XM channel number indicator

7Detail information

Shows the detail information of the broadcast

channel currently being received.

1 Touch the source icon and then touch

XM to select the XM.

2 Touch BAND to select an XM band.

Touch BAND repeatedly until the desired XM

band is displayed, XM1,XM2 or XM3.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

3 Touch cor dto select a desired

channel.

The channels move up or down step by step.

Channels that cannot currently be selected

are skipped, and the next channel is selected.

#If you touch and hold cor d, you can in-

crease or decrease the channel number con-

tinuously.

#You can also select a channel by pressing c

or d(TRACK).

#You can also perform tuning from a desired

channel category. (Refer to Selecting a channel in

the channel category on the next page.)

Storing and recalling broadcast

stations

You can easily store up to six broadcast sta-

tions for later recall.

!Up to 18 stations, six for each of three XM

bands can be stored in memory.

1 Select the channel that you want to

store in memory.

2 Touch LIST to display the preset list.

3 Touch and hold a preset tuning key

P1 (PRESET1) to P6 (PRESET6) until the beep

sounds.

The selected station has been stored in mem-

ory.

The next time you touch the same preset tun-

ing key P1 (PRESET1) to P6 (PRESET6) the sta-

tion is recalled from memory.

4 Touch ESC to return to the ordinary dis-

play.

Note

You can also use aand bto recall stations as-

signed to preset tuning keys P1 (PRESET1) to

P6 (PRESET6) when the CH-NUMBER mode is

selected.

Available accessories

Section

Switching the XM channel

select mode

You have two methods for selecting a channel:

by number and by category. When selecting

by number, channels in any category can be

selected. Select by category to narrow your

search down to only channels in a particular

category.

%Touch MODE to select the desired chan-

nel select mode.

Touch MODE repeatedly to switch between

the following channel select modes:

CH-NUMBER (channel number select setting)

—CATEGORY (channel category select

setting)

Selecting a channel in the channel

category

Channels are organized into various program

categories, e.g. Rock, Classic, Jazz. You can

specify channels by selecting the desired

category.

1 Touch MODE to select the channel cate-

gory select mode.

Touch MODE repeatedly to switch between

the following channel select modes:

CH-NUMBER (channel number select setting)

—CATEGORY (channel category select

setting)

2 Touch aor bto select the desired chan-

nel category.

3 Touch cor dto select the desired chan-

nel in the selected channel category.

Available accessories

Section

Selecting a SIRIUS channel directly

You can select a SIRIUS channel directly by

entering the desired channel number.

1 Touch DIRECT.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch 0 to 9 to input the desired chan-

nel number.

#To cancel the input numbers, touch C.

3 Touch ENTER.

The SIRIUS channel of entered number is

selected.

Using the MyMix function

The MyMix function allows you to make the

MyMix song playlist. When the song in the

MyMix playlist is being broadcast on a station

other than the one you are listening to, you

will be alerted, and you can tune to the station

to listen to that song.

!This function is available for CD-SB10/SIR-

PNR2/SIR-PNR2C.

!A track itself is NOT downloaded BUT only

the song title and the artist name are mem-

orized.

Making the MyMix playlist

You can add a song that is being broadcast to

the MyMix playlist. When it is added, the song

title and its artist name is memorized to this

unit. The MyMix function will start on the song

that matches the song title and its artist name

in the MyMix playlist.

%When a desired song is broadcast,

touch and hold MEMO.

The song title and artist name of the song you

are listening to are memorized, and a confir-

mation message appears.

#The song title and artist name of up to 10

tracks can be memorized. When you try to save

more than 10 tracks, FULL is displayed and that

song being broadcast cannot be saved.

#You cannot memorize the song title or the ar-

tist name of the channel 000.

#It is possible that the memorized title is not

displayed correctly.

When the song in the MyMix playlist

is broadcast

As soon as the memorized song starts broad-

cast on a different station, a song alert is dis-

played. Touch JUMP to switch to that station,

and you can listen to that track.

!If you would rather not to tune to that sta-

tion, touch STAY.

!If an alert for the song in the MyMix playlist

is set up to off, no alert will be provided

even when the song is broadcast. Refer to

Setting up a song alert on the next page.

!If there is slight difference between the

memorized title and the title of the song

being broadcast, no alert will be provided

even though they are the same song.

Turning the MyMix function on or off

You can turn the MyMix function off and stop

this unit to alert you for all the songs in the

MyMix playlist. To restart, turn this function

on.

!The MyMix function is on at the default

setting.

1 Touch MEMO EDIT.

The display is switched to the memo edit

mode.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch ALERT OFF to turn the MyMix

function off.

The MyMix function is now off.

#To turn the MyMix function on, touch

ALERT ON.

Available accessories

En 57

Section

Available accessories

Setting up a song alert

You can set up an alert on or off by each song

in the MyMix playlist. First, display the MyMix

playlist and then change each alert setting.

Set up an alert to on so you can receive the

alert when the song is broadcast, or set it up

to off to stop the alert for that song.

1 Touch MEMO EDIT.

The display is switched to the memo edit

mode.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch PREV or NEXT to select the song

title that you want to turn the alert off.

3 Touch ON/OFF to turn the alert off.

The alert for the song is turned off.

Deleting the song from the MyMix

playlist

You can delete each song in the MyMix

playlist.

1 Touch MEMO EDIT.

The song title in the MyMix playlist is dis-

played.

#To switch between groups of touch panel keys,

touch NEXT or PREV.

2 Touch PREV or NEXT to select the song

title that you want to delete.

3 Touch DELETE.

4 A message will appear asking you to

confirm to delete it. Touch YES.

The selected song is deleted.

#To cancel the deleting, touch CANCEL.

Using the Game Alert function

This system can alert you when games invol-

ving your favorite teams are about to start. To

use this function you need in advance to set

up a game alert for the teams.

!This function is available for CD-SB10/SIR-

PNR2/SIR-PNR2C.

Selecting teams for Game Alert

1 Touch TEAM SET.

2 Touch PREV or NEXT next to LEAGUE to

select a desired league.

League names are switched in the display.

3 Touch PREV or NEXT next to TEAM to

select a desired team.

Teams in the selected category are switched in

the display.

4 Touch ON/OFF to store the selected

team in memory.

ON is displayed with the selected team, and

the Game Alert function will start on that

team.

#To turn the Game Alert off of the selected

team, touch ON/OFF again.

#When you have already made 12 team selec-

tions, FULL is displayed and additional team se-

lection is not possible. In this case, first delete

the team selection and then try again.

5 Repeat these steps for selecting other

teams.

Up to 12 teams can be selected.

Switching the Game Alert on or off

Once you made team selections, you need to

turn the Game Alert function on.

!The Game Alert function is on at the default

setting.

1 Touch TEAM SET.

2 Touch ALERT ON to turn the Game Alert

on.

The Game Alert function is now on.

#To turn the Game Alert function off, touch

ALERT OFF.

Available accessories

Section

When the game of the selected team

starts

When a game of the selected team is about to

start (or is currently playing) on a different sta-

tion, a game alert is displayed. Touch JUMP to

switch to that station, and you can listen to

that game.

!If you would rather not to tune to that sta-

tion, touch STAY.

Displaying game information

If games of your selected teams are currently

playing, you can display information of the

games and tune to the broadcast channel.

1 Touch GAME INFO.

The game information of your selected team is

displayed.

2 Touch PREV or NEXT to select a game.

The game is displayed, followed by more de-

tailed game information.

!Game score will be updated automatically.

3 Touch Tune TO to switch to that station

to listen to the game.

Notes

!If you have not made any team selections,

NOT SET is displayed.

!When games involving your favorite teams are

not currently playing, NO GAME is displayed.

Displaying the Radio ID

If you select CH000, the ID code is displayed.

%Touch cor dto select CH000.

#To select CH000, set the channel select setting

to CH-NUMBER. About the channel select set-

ting, refer to Selecting the SIRIUS channel select

mode on page 56.

Switching the SIRIUS display

!This function is available for SIR-PNR1.

%Touch INFO to switch the SIRIUS display.

Channel name—Artist name/feature—Song/

program title—Channel category

Using Instant Replay function

Following functions can be operated during

the Instant Replay mode.

!To use this function, Pioneer SIRIUS bus in-

terface (e.g. CD-SB10) is required.

!To use this function, SIRIUS plug-and-play

unit with Instant Replay Function is re-

quired.

!For details, refer to SIRIUS plug-and-play

unit’s manuals.

%Touch NEXT.

%Touch INSTANT REPLAY.

Instant Replay mode is displayed. Now, Instant

Replay mode can be performed.

#In the following conditions, tuner exits from

the Instant Replay mode.

—When LIVE is touched

—When another source is selected

%Select a track

Touch cor d.

%Pause and play

Touch de.

%Fast forward or reverse

Touch and hold cor dfor about one second

and release.

Available accessories

En 59

Section

Available accessories

Bluetooth Audio

Basic Operations

If you connect a Bluetooth adapter (e.g. CD-

BTB200) to this unit, you can control Bluetooth

audio players via Bluetooth wireless technology.

!In some countries, CD-BTB200 is not sold

on the market.

Important

!Depending on the Bluetooth audio player con-

nected to this unit, the operations available

with this unit are limited to the following two

levels:

—A2DP profile (Advanced Audio Distribution

Profile): Only playing back songs on your

audio player is possible.

—AVRCP profile (Audio/Video Remote Con-

trol Profile): Playing back, pausing, select-

ing songs, etc., are possible.

!Since there are a number of Bluetooth audio

players available on the market, operations

with your Bluetooth audio player using this

unit vary extensively. Refer to the instruction

manual that came with your Bluetooth audio

player as well as this manual while operating

your player on this unit.

!Information about songs (e.g. the elapsed

playing time, song title, song index, etc.) can-

not be displayed on this unit.

!While you are listening to songs on your Blue-

tooth audio player, refrain from using on your

cellular phone as much as possible. If you use

your cellular phone, the signal from your cel-

lular phone may cause noise on the song play-

back.

!When you are talking on a cellular phone con-

nected to this unit via Bluetooth wireless tech-

nology, song playback from your Bluetooth

audio player connected to this unit is muted.

!Even if you are listening to a song on your

Bluetooth audio player and you switch to an-

other source, song playback continues.

For details concerning operation, refer to the

Bluetooth adapter’s operation manual. This

section provides brief information on Blue-

tooth audio player operations with this unit,

which slightly differs or is abbreviated from

that described in the Bluetooth adapter’s op-

eration manual.

!Even though your audio player does not

contain a Bluetooth module, you can still

control it from this unit via Bluetooth wire-

less technology. To control your audio

player using this unit, connect a product

featuring Bluetooth wireless technology

(available on the market) to your audio

player and connect the Bluetooth adapter

(e.g. CD-BTB200) to this unit.

1Source icon

2Device name

Shows the device name of the connected

Bluetooth audio player (or Bluetooth adapter).

3Connection indicator

Shows the Bluetooth wireless connection sta-

tus.

1 Touch the source icon and then touch

BT Audio to select the Bluetooth audio

source.

#For this unit to control your Bluetooth audio

player it needs to establish a Bluetooth wireless

connection. (Refer to Connecting a Bluetooth

audio player on the next page.)

2 Touch d.

Playback starts.

3 To skip back or forward to another

track, briefly touch oor p.

4 To perform fast forward or reverse,

keep touching oor p.

Available accessories

Section

5 To stop playback, touch g.

Pausing playback

%Touch eduring playback.

#To resume playback at the same point that you

turned pause on, touch d.

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the ordinary dis-

play.

#To return to the previous display, touch BACK.

Connecting a Bluetooth audio

player

%Touch CONNECTION OPEN on the func-

tion menu to turn the connection open on.

CONNECTION WAITING is displayed. This

unit is now on standby for connection from

Bluetooth audio player.

If your Bluetooth audio player is set ready for

Bluetooth wireless connection, connection to

this unit is automatically established.

Note

Before you can use audio players you may need

to enter the PIN code into this unit. If your player

requires a PIN code to establish a connection,

look for the code on the player or in its accompa-

nying documentation. Refer to Entering PIN code

for Bluetooth wireless connection on page 43.

Disconnecting a Bluetooth

audio player

%Touch DISCONNECT on the function

menu.

After the disconnection is completed,

NO CONNECTION is displayed.

Displaying BD (Bluetooth

Device) address

%Touch DEVICE INFO on the function

menu to display the BD address.

Various information regarding the Bluetooth

wireless technology are displayed.

!DEVICE NAME (device name of this sys-

tem)

!BD ADDRESS (address of Bluetooth device)

!SYSTEM VERSION (system version)

!BT MODULE VERSION (version of Blue-

tooth module)

Available accessories

En 61

Section

Available accessories

Bluetooth Telephone

Basic Operations

If you use a Bluetooth adapter (e.g. CD-

BTB200), you can connect a cellular phone fea-

turing Bluetooth wireless technology to this

unit for hands-free, wireless calls, even while

driving.

!In some countries, CD-BTB200 is not sold

on the market.

Important

!Since this unit is on standby to connect with

your cellular phone via Bluetooth wireless

technology, using this unit without running

the engine can result in battery drainage.

!Advanced operations that require your atten-

tion such as dialing numbers on the monitor,

using phone book, etc., are prohibited while

you are driving. When you need to use these

advanced operations, stop your vehicle in a

safe place.

For details concerning operation, refer to the

Bluetooth adapter’s operation manual. This

section provides brief information on the

hands-free phoning operations with this unit

which slightly differs or is cut short from that

described in the Bluetooth adapter’s operation

manual.

!This unit is not compatible with registration

for guest phone.

!This unit does not have the name edit func-

tion of a Phone Book entry.

1Source icon

2User number indicator

Shows the registration number of the cellular

phone.

3Device name

Shows the device name of the cellular phone.

4Phone number

Shows the phone number you selected.

5Voice recognition indicator

Shows when the voice recognition function is

on (for more details, refer to Voice recognition

on the next page).

6Incoming call notice indication

Shows when an incoming call has been re-

ceived and not checked yet.

!Incoming call notice is not displayed for

calls made when your cellular phone is

disconnected from this unit.

7Automatic answering/Automatic rejecting in-

dicator

Shows when the automatic answering func-

tion is on (for more details, refer to Setting

automatic answering on page 68).

Shows when the automatic rejecting function

is on (for more details, refer to Setting auto-

matic rejecting on page 68).

8Battery strength indicator

Shows the battery strength of cellular phone.

!The level shown on the indicator may

differ from the actual battery strength.

!If the battery strength is not available,

nothing is displayed in the battery

strength indicator area.

9Signal level indicator

Shows the signal strength of cellular phone.

!The level shown on the indicator may

differ form the actual signal level.

!Depending on the cellular phones fea-

turing Bluetooth wireless technology,

radio field intensity is not available. In

this case, the signal level indicator does

not appear.

!If your cellular phone is out of service,

is displayed.

aTelephone indicator

Available accessories

Section

Shows when a phone connection using Blue-

tooth wireless technology is established (for

more details, refer to Connecting a cellular

phone on the next page).

!While connecting automatically, tele-

phone indicator is flashing.

%Touch the source icon and then touch

TEL to select the telephone.

Note

Equalizer curve for the phone source is fixed.

When selecting the phone source, you cannot op-

erate the equalizer function. Refer to Recalling

equalizer curves on page 35.

When the multi-channel processor is connected

to this unit, you can operate the equalizer func-

tion even when selecting the phone source. Refer

to Recalling equalizer curves on page 81.

Setting up for hands-free phoning

Before you can use the hands-free phoning

function you must set up the unit for use with

your cellular phone. This entails establishing a

Bluetooth wireless connection between this

unit and your phone, registering your phone

with this unit, and adjusting the volume level.

1 Connection

For detailed instructions on connecting your

phone to this unit via Bluetooth wireless tech-

nology, refer to Connecting a cellular phone on

the next page.

#Your phone should now be temporarily con-

nected. However, to make best use of the technol-

ogy, we recommend you register the phone to

this unit.

2 Registration

To register your temporarily connected phone,

refer to Registering a connected cellular phone

on page 65.

3 Volume adjustment

Adjust the earpiece volume on your cellular

phone for comfort. When adjusted, the volume

level is recorded in this unit as the default set-

ting.

#Caller’s voice volume and ring volume may

vary depending on the type of cellular phone.

#If the difference between the ring volume and

caller’s voice volume is big, overall volume level

may become unstable.

#Before disconnecting the cellular phone from

this unit, make sure to adjust the volume to a

proper level. If the volume is muted (zero level) on

your cellular phone, the volume level of your cel-

lular phone remains muted even after the cellular

phone is disconnected.

Making a phone call

Voice recognition

1 Touch VOICE to turn the voice recogni-

tion function on.

Voice dial icon appears on the information bar.

Voice recognition function is now ready.

#To cancel the voice recognition function,

touch VOICE again.

2 Pronounce the name of your contact.

Taking a phone call

Answering an incoming call

1 When a call comes in, touch .

#You can also perform this operation by press-

ing c(TRACK).

#If private mode is selected on the cellular

phone, hands-free phoning may not be per-

formed.

2 To end the call, touch .

#You can also perform this operation by press-

ing d(TRACK).

Rejecting an incoming call

%When a call comes in, touch .

The call is rejected.

Available accessories

En 63

Section

Available accessories

Answering a call waiting

1 Touch to answer a call waiting.

2 Touch to end all calls.

#The caller you have been talking to is now on

hold. To end the call, both you and your caller

need to hang up the phone.

#While your callers hold the line, touching

switches between callers.

Rejecting call waiting

%Touch to reject a call waiting.

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the telephone

standby display.

#To return to the previous display, touch BACK.

Connecting a cellular phone

Searching for available cellular phones

1 Touch PHONE CONNECT on the function

menu.

2 Touch SEARCH to search for available

cellular phones.

While searching, SEARCHING flashes. When

available cellular phones featuring Bluetooth

wireless technology are found, device name or

Name Not Found (if names cannot be ob-

tained) is displayed.

#If this unit fails to find any available cellular

phones, NOT FOUND is displayed.

#You can display the BD address by touching

BD ADDR. To return to the device name, touch

PHONE NAME.

3 Touch the device name you want to

connect.

While connecting, CONNECTING flashes. To

complete the connection, check the device

name (Pioneer BT unit2) and enter the link

code on your cellular phone. If the connection

is established, CONNECTED is displayed.

#PIN code is set to 0000 as the default. You

can change this code in the initial setting. Refer

to Entering PIN code for Bluetooth wireless con-

nection on page 43.

Using a cellular phone to initiate a

connection

1 Touch PHONE CONNECT on the function

menu.

2 Touch CONNECTION OPEN.

CONNECTION WAITING flashes and the unit

is now on standby for connection from a cellu-

lar phone.

3 Use cellular phone to connect to this

unit.

#To cancel this function, touch

CONNECTION OPEN again.

#PIN code is set to 0000 as the default. You

can change this code in the initial setting. Refer

to Entering PIN code for Bluetooth wireless con-

nection on page 43.

Disconnecting a cellular phone

1 Touch PHONE CONNECT on the function

menu.

2 Touch DISCONNECT to disconnect the

currently connected cellular phone from

this unit.

After disconnection is completed,

NO CONNECTION is displayed.

Available accessories

Section

Registering a connected

cellular phone

1 Touch PHONE REGISTER on the function

menu.

Registration assignments for user phone 1, 2

and 3 appear on the display.

2 Touch and hold one of the registration

assignments to register the currently con-

nected phone.

If the registration is succeeded, the device

name of the connected phone is displayed in

the selected assignment.

#If the assignment is empty, the device name is

not displayed. If the assignment is already taken,

the device name appears. To replace an assign-

ment with a new phone, first delete the current

assignment. For more detailed instructions, see

Deleting a registered phone on this page.

#If the registration failed, device name of the

connected phone is not displayed in the selected

assignment. In this case, return to step 1 and try

again.

Deleting a registered phone

1 Touch PHONE REGISTER on the function

menu.

2 Touch DELETE next to the device name

you want to delete.

A confirmation display appears. Touch OK to

delete the phone.

#To cancel deleting a registered phone, touch

CANCEL.

Connecting to a registered

cellular phone

Connecting to a registered phone

manually

1 Touch PHONE CONNECT on the function

menu.

2 Touch DIRECT CONNECT.

3 Touch the device name you want to

connect.

While connecting, CONNECTING is flashing.

If the connection is established, CONNECTED

is displayed.

Connecting to a registered phone

automatically

1 Touch NEXT on the function menu.

2 Touch AUTO CONNECT to turn the

Automatic Connection function on.

If your cellular phone is ready for Bluetooth

wireless connection, connection to this unit is

automatically established.

#To turn automatic connection off, touch

AUTO CONNECT again.

Using the phone book

Transferring entries to the phone book

The Phone Book can hold a total of 500 en-

tries. 300 from User 1, 150 from User 2, and 50

from User 3.

1 Touch PHONE BOOK TRANSFER on the

function menu.

2 Touch START to turn the Phone Book

Transfer function on.

The Phone Book Transfer is now on standby.

3 Use the cellular phone to perform

phone book transfer.

Perform phone book transfer using the cellu-

lar phone. For detailed instructions, refer to

the instruction manual that came with your

cellular phone.

#The display indicates how many entries have

been transferred and the total number to be

transferred.

#To cancel the transferring process, touch

STOP.

4 When you are done transferring Phone

Book entries, touch ESC.

Available accessories

En 65

Section

Available accessories

Note

When the phone book transfer is complete, the

connection to your cellular phone is off. To use

the Phone Book, connect to your cellular phone

once again, referring to Connecting to a registered

cellular phone on the previous page.

Changing the phone book display order

%Touch PHONE BOOK NAME VIEW on

the function menu to change the name

view order.

INVERTED is displayed and the name view

order is changed.

#To change to the original order (ORIGINAL),

touch PHONE BOOK NAME VIEW again.

Calling a number in the phone book

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

1 Touch PHONE BOOK to display the

Phone Book.

2 Touch aor bto select the first letter of

the name you are looking for.

Touching aor bchanges alphabetical letters.

3 Touch ENTER to show entries starting

with the letter you chose.

The display shows the first six Phone Book en-

tries starting with that letter (e.g. “Ben”,

“Brian”and “Burt”when “B”is selected).

#Touch or to display other phone book en-

tries.

#To refine the search with a different letter,

touch CLEAR.

4 Touch a Phone Book entry you want to

call.

The display is switched to the Phone Book de-

tail display.

5 Touch phone number of the Phone

Book entry you want to call.

If several phone numbers are entered to an

entry, touch one you want to call.

The display returns to the normal display and

the Phone Book entry you selected is dis-

played on the information bar.

6 Touch to make a call.

#For an international call, touch add “+”to add

+to the phone number.

7 To end the call, touch .

Editing phone numbers

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

You can edit the numbers of Phone Book en-

tries. Each phone number can be up to 24 di-

gits long.

1 Touch PHONE BOOK to display the

Phone Book.

2 Select a Phone Book entry you want to

edit.

Please see Steps 2 to 4 of the following section

for how to do this. Refer to Calling a number in

the phone book on this page.

3 Touch EDIT next to the phone number

you want to edit.

The display is changed to the Phone Book dial

edit display.

4 Touch 0 to 9 to input numbers.

#For an international call, touch add “+”to add

+to the phone number.

#Touch CLEAR to delete the number. Touch and

hold CLEAR to delete all the input numbers.

5 Touch OK to store the new number.

Available accessories

Section

Clearing a phone book entry

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

1 Touch PHONE BOOK to display the

Phone Book.

2 Select a Phone Book entry you want to

delete.

Please see Steps 2 to 4 of the following section

for how to do this. Refer to Calling a number in

the phone book on the previous page.

3 Touch DELETE to delete the Phone Book

entry.

A confirmation display appears. Touch YES to

delete the entry.

#If you do not want to clear a Phone Book entry

that you have selected, touch NO.

Using the call history

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

The 6 most recent calls made (dialed), re-

ceived and missed, are stored in the Call His-

tory. You can browse the Call History and call

numbers from it.

1 Touch LOG to display the Call History.

2 Touch LOG repeatedly to switch the call

histories.

MISSED CALL LIST (missed call)—

DIALED CALL LIST (dialed call)—

RECEIVED CALL LIST (received call)

#You can switch between phone number and

name (if entered) by touching ABC/123.

#If no phone numbers have been stored in the

selected list, nothing is displayed.

3 Touch a phone number or name (if en-

tered) you want to call.

The display returns to the normal display and

the phone number you selected is displayed

on the information bar.

4 Touch to make a call.

#For an international call, touch add “+”to add

+to the phone number.

5 To end the call, touch .

Using preset numbers

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

Assigning preset numbers

Numbers that you dial frequently can be as-

signed to presets for quick recall.

You can assign up to 6 frequently called phone

numbers to number presets.

1 Select a desired phone number from

the phone book or the call history. Or di-

rectly enter a desired phone number.

To select a desired phone number from the

Phone Book or the Call History, see the in-

structions explained in previous pages. To di-

rectly enter a desired phone number, please

see the following section. Refer to Making a

call by entering phone number on the next

page.

The display should now be the normal display

and the selected phone number is displayed

on the information bar.

2 Touch LIST to display preset assign-

ments.

Preset assignments appear in the display (if

not displayed yet).

3 Keep touching one of preset assign-

ments to store the phone number.

The phone number you selected is stored in

presets.

Available accessories

En 67

Section

Available accessories

#No Data is displayed for empty assignment.

Even if the assignment is taken, you can replace

it to the new one by keeping touching the assign-

ment.

Recalling preset numbers

1 Touch LIST to display preset assign-

ments.

Preset assignments appear in the display (if

not displayed yet).

2 Touch one of preset assignments.

The selected phone number should now be

displayed on the information bar.

3 Touch to make a call.

4 To end the call, touch .

Making a call by entering

phone number

Important

Be sure to park your vehicle and apply the park-

ing brake when performing this operation.

1 Touch DIRECT to display the direct dial

display.

2 Touch 0 to 9 to input numbers.

#For an international call, touch add “+”to add

+to the phone number.

#Touch CLEAR to delete the number. Touch and

hold CLEAR to delete all the input numbers.

#Up to 24 digits can be entered.

#If you want to store the entered phone number

to preset assignment, touch SET here. The display

returns to the normal display and the phone num-

ber you entered is selected.

3 When you completed entering the

number, touch to make a call.

4 To end the call, touch .

Clearing memory

1 Touch CLEAR MEMORY on the function

menu.

2 Touch CLEAR next to the item you want

to delete from the memory.

Select from the following:

!PHONE BOOK (phone book)

!DIALED CALLS (dialed call history)

!RECEIVED CALLS (received call history)

!MISSED CALLS (missed call history)

!DIAL PRESET (preset phone numbers)

After selecting a desired item, a confirmation

display appears. Touch OK to delete the mem-

ory.

#If you do not want to clear memory that you

have selected, touch CANCEL.

#If you want to clear all the Phone Book, dia-

led/received/missed call history list and preset

phone number, touch CLEAR ALL.

Setting automatic answering

%Touch AUTO ANSWER on the function

menu to turn the automatic answer on.

#To turn the automatic answer off, touch

AUTO ANSWER again.

Setting automatic rejecting

1 Touch NEXT on the function menu.

2 Touch REFUSE ALL CALLS to turn the

automatic call rejection on.

#To turn the automatic call rejection off, touch

REFUSE ALL CALLS again.

Switching the ring tone

1 Touch NEXT on the function menu.

2 Touch RING TONE to turn the ring tone

on.

#To turn the ring tone off, touch RING TONE

again.

Available accessories

Section

Echo canceling and noise reduction

1 Touch NEXT on the function menu.

2 Touch ECHO CANCEL to turn Echo Can-

cel function on.

#To turn echo canceling off, touch

ECHO CANCEL again.

Displaying BD (Bluetooth

Device) address

Displaying BD address of this system

1 Touch NEXT on the function menu.

2 Touch DEVICE INFO to display the BD

address.

Various information regarding the Bluetooth

wireless technology are displayed.

!DEVICE NAME (device name of this sys-

tem)

!BD ADDRESS (address of Bluetooth device)

!SYSTEM VERSION (version of this unit’s

microprocessor)

!BT MODULE VERSION (version of Blue-

tooth module)

Displaying BD address of your

cellular phone

1 Touch PHONE CONNECT on the function

menu.

2 Touch BD ADDRESS to display the BD

address.

12-digit hexadecimal string is displayed.

#To return to the device name, touch

PHONE NAME.

Multi-CD Player

Basic Operations

You can use this unit to control a multi-CD

player, which is sold separately.

!This unit does not have ITS playlist, disc title

and track title list functions.

!Only functions described in this manual are

supported by 50-disc multi-CD players.

!This unit is not designed to operate disc title

list functions with a 50-disc multi-CD player.

1Source icon

2Disc number indicator

3Disc title indicator

Shows the title of the currently playing disc

only when playing CD TEXT discs.

4Track number indicator

5Play time indicator

1 Touch the source icon and then touch

MCD to select the multi-CD player.

2 Touch aor bto select a disc.

3 To skip back or forward to another

track, briefly touch oor p.

#You can also skip back or forward to another

track by pressing cor d(TRACK).

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by pressing and holding cor d(TRACK).

Notes

!When multi-CD player completes preparatory

operations, READY is displayed.

Available accessories

En 69

Section

Available accessories

!If an error message such as ERROR-02-XX is

displayed, refer to the multi-CD player owner’s

manual.

!If there are no discs in the multi-CD player ma-

gazine, NO DISC is displayed.

Selecting a disc

1 Touch LIST.

2 Touch your favorite disc.

Selectable discs are highlighted.

3 Touch ESC to return to the ordinary dis-

play.

Pausing CD playback

%Touch de during playback.

#To resume playback at the same point that you

turned pause on, touch de again.

Introduction to advanced

operations

You can only use these functions with a multi-

CD player that supports them.

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch BACK.

Function and operation

REPEAT,RANDOM,SCAN and

COMPRESSION operations are basically the

same as that of the built-in DVD player.

Function name Operation

REPEAT

Refer to Repeating play on page 28.

However, the repeat play ranges

you can select are different from

that of the built-in DVD player. The

repeat play ranges of the multi-CD

player are:

!MULTI-CD –Repeat all discs in

the multi-CD player

!TRACK –Repeat just the cur-

rent track

!DISC –Repeat the current disc

RANDOM Refer to Playing tracks in random

order on page 29.

SCAN Refer to Scanning tracks or folders

on page 29.

COMPRESSION

Refer to Using compression on

page 30.

Multi-CD player has COMP (com-

pression) and DBE (dynamic bass

emphasis) functions.

The settings can be switched as

below:

OFF—COMP1—COMP2—OFF—

DBE 1—DBE 2

Notes

!If you select other discs during repeat play,

the repeat play range changes to MULTI-CD.

!If you perform track search or fast forward/re-

verse during TRACK, the repeat play range

changes to DISC.

!After track or disc scanning is finished, nor-

mal playback of the tracks begins again.

!If the multi-CD player does not support

COMP/DBE, you cannot operate this function.

Using CD TEXT functions

You can use these functions only with a CD

TEXT compatible multi-CD player.

The operation is the same as that of the built-

in DVD player.

Refer to Text information on page 27.

Available accessories

Section

DVD Player

Basic Operations

You can use this unit to control a DVD player or

multi-DVD player, which is sold separately.

For details concerning operation, refer to the

DVD player’s or multi-DVD player’s operation

manual. This section provides information on

DVD operations with this unit which differs

from that described in the DVD player’sor

multi-DVD player’s operation manual.

!This unit does not have ITS playlist and disc

title functions.

1Source icon

2Media indicator

3Disc number indicator

Shows the number of the disc currently play-

ing when using a multi-DVD player.

4Title/Folder number indicator

5Chapter/track number indicator

6Play time indicator

7Variable message area

Shows the text information of disc currently

playing when playing a compressed audio

disc.

!This unit cannot display the text infor-

mation recorded on a CD TEXT disc

playing on the optional DVD player.

1 Touch the source icon and then touch

S-DVD to select the DVD player.

#When the source icon is not displayed, you

can display it by touching the screen.

2 Touch the screen to display the touch

panel keys.

3 To skip back or forward to another

chapter/track, briefly touch oor p.

#You can also skip back or forward to another

chapter/track by pressing cor d(TRACK).

4 To perform fast forward or reverse,

keep touching oor p.

#You can also perform fast reverse/fast forward

by pressing and holding cor d(TRACK).

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically when

playing DVD video or Video CD.

Selecting a disc

!You can operate this function only when a

multi-DVD player is connected to this unit.

1 Touch LIST.

2 Touch your favorite disc.

Selectable discs are highlighted.

3 Touch ESC to return to the ordinary dis-

play.

Note

You can also select a disc by keeping touching a

or b.

Selecting a folder

!You can operate this function only when a

DVD player compatible with compressed

audio playback is connected to this unit.

%Touch aor bto select a folder.

Pausing disc playback

%Touch de during playback.

#To resume playback at the same point that you

turned pause on, touch de again.

Available accessories

En 71

Section

Available accessories

Introduction to advanced

operations

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

The function names are displayed and oper-

able ones are highlighted.

2 Touch ESC to return to the playback dis-

play.

#To return to the previous display, touch BACK.

Function and operation

REPEAT,RANDOM and SCAN operations are

basically the same as that of the built-in DVD

player.

Function name Operation

REPEAT

Refer to Repeating play on page 28.

But the repeat play range that you

can select is vary depending on

the type of disc or system. The re-

peat play ranges of the DVD

player/multi-DVD player are as

below:

During PBC playback of Video

CDs, this function cannot be oper-

ated.

!DISC –Repeat the current disc

!FOLDER –Repeat the current

folder

!TITLE –Repeat just the current

title

!CHAPTER –Repeat just the

current chapter

!TRACK –Repeat the current

track

RANDOM Refer to Playing tracks in random

order on page 29.

SCAN Refer to Scanning tracks or folders

on page 29.

Notes

!If you select other discs during repeat play,

the repeat play range changes to DISC.

!When playing back Video CD or CD, if you per-

form track search or fast forward/reverse dur-

ing TRACK, the repeat play range changes to

DISC.

!When playing back compressed audio, if you

select another folder during repeat play, the

repeat play range changes to DISC.

!When playing back compressed audio, if you

perform track search or fast forward/reverse

during TRACK, the repeat play range changes

to FOLDER.

Displaying text information of an

audio file

The operation is the same as that of the built-

in DVD player.

Refer to Text information on page 27.

!If the characters recorded on the audio file

are not compatible with this unit, those

characters will not be displayed.

Selecting files from the file name list

!You can operate this function only when a

DVD player compatible with compressed

audio playback is connected to this unit.

1 Touch LIST to display the disc list.

2 Touch LIST repeatedly to switch the

lists.

DISC LIST (disc list)—FOLDER&FILE LIST

(folder and file list)

3 Select the desired file name (or folder

name).

The operation is the same as that of the built-

in DVD player.

Refer to Selecting files from the file name list

on page 28.

Available accessories

Section

TV tuner

Important

This manual describes analog TV tuner operation.

If you are already using a Pioneer analog TV

tuner, such as the GEX-P5700TV, read this section.

However, please read the important information

below.

!Pioneer stopped selling analog TV tuners in

the U.S. in 2006, and analog TV tuners are

also no longer available in Canadian markets.

Pioneer does not sell a digital TV tuner in the

U.S. or in Canada.

!In the U.S., the switch from analog TV to digi-

tal TV broadcasting is planned for February 17,

2009.

!In Canada, the switch from analog TV to digi-

tal TV broadcasting is planned for August 31,

2011.

!THIS MEANS THAT AFTER THE DATES SPECI-

FIED ABOVE (SUBJECT TO CHANGE), YOU

CAN NO LONGER USE THIS UNIT WITH AN

ANALOG TV TUNER TO WATCH ALMOST ALL

TV PROGRAMMING BROADCAST OVER-THE-

AIR.

Basic Operations

You can use this unit to control a TV tuner (e.g.

GEX-P5700TV), which is sold separately.

For details concerning operation, refer to the

TV tuner’s operation manual. This section pro-

vides information on TV operations with this

unit, which differs from that described in the

TV tuner’s operation manual.

1Source icon

2Band indicator

3Preset number indicator

4Channel indicator

1 Touch the source icon and then touch

TV to select the TV.

#When the source icon is not displayed, you

can display it by touching the screen.

2 Touch the screen to display the touch

panel keys.

3 Touch BAND to select a band.

Touch BAND repeatedly until the desired band

is displayed, TV1 or TV2.

4 To perform manual tuning, briefly

touch cor d.

#You can also perform manual tuning by press-

ing cor d(TRACK).

5 To perform seek tuning, keep touching

cor dfor about one second and release.

The tuner will scan the channels until a broad-

cast strong enough for good reception is

found.

#You can cancel seek tuning by briefly touching

either cor d.

#If you keep touching cor dyou can skip

broadcasting channels. Seek tuning starts as

soon as you release the keys.

#You can also perform seek tuning by pressing

and holding cor d(TRACK).

Note

If you do not use the touch panel keys within 30

seconds, they will be hidden automatically.

Storing and recalling broadcast

stations

If you touch any of the preset tuning keys P01

to P12 you can easily store up to 12 broadcast

stations for later recall with the touch of a key.

!Up to 24 stations, 12 for each of two TV

bands, can be stored in memory.

Available accessories

En 73

Section

Available accessories

1 Touch LIST to display the preset list.

#When the touch panel keys are not displayed,

you can display them by touching the screen.

2 When you find a station that you want

to store in memory, keep touching one of

preset tuning keys P01 to P12 until the

beep sounds.

The next time you touch the same preset tun-

ing key the station is recalled from memory.

#To switch between P01 to P06 and P07 to P12,

touch PREV or NEXT.

3 Touch ESC to return to the ordinary dis-

play.

Note

You can also use aand bto recall stations as-

signed to preset tuning keys P01 to P12.

Storing the strongest broadcast

stations sequentially

1 Touch AV MENU and then touch

FUNCTION MENU to display the function

names.

2 Touch BSSM on the function menu to

turn BSSM on.

BSSM begins to flash. While BSSM is flashing

the 12 strongest broadcast stations will be

stored in order from the lowest channel up.

When finished, BSSM stops flashing.

#To cancel the storage process, touch BSSM

again.

3 Touch ESC to return to the TV picture.

#To return to the previous display, touch BACK.

Note

Storing broadcast stations with BSSM may re-

place broadcast stations you have saved using

P01 to P12.

Digital Signal Processor

Introduction of DSP adjustments

You can use this unit to control multi-channel

processor (DEQ-P8000), which is sold sepa-

rately.

!Some functions may differ depending on the

multi-channel processor connected to this

unit.

Important

When a multi-channel processor and an optional

DVD player are connected to this unit, be sure to

use an optical cable (e.g. CD-AD600).

1DSP display

Shows the DSP function names.

By carrying out the following settings/adjust-

ments in the order shown, you can create a fi-

nely-tuned sound field effortlessly.

1Setting the speaker setting

2Using the position selector

3Auto TA and EQ (auto-time alignment and auto-

equalizing)

4Adjusting the time alignment

5Adjusting the speaker output levels using a

test tone

6Selecting a cross-over frequency

7Adjusting the speaker output levels

8Adjusting 3-band parametric equalizer

1 Touch AV MENU and then touch

DSP MENU to display the DSP function

names.

The DSP function names are displayed and

operable ones are highlighted.

Available accessories

Section

#To go to the next group of function names,

touch NEXT.

#To return to the previous group of function

names, touch PREV.

#When playing discs recorded with more than

96 kHz sampling frequency, you cannot use audio

functions. Also, equalizer curve setting,

POSITION,AUTO EQ and AUTO TA will be can-

celed.

#When playing discs recorded with more than

96 kHz sampling frequency, audio is outputted

from front speakers only.

#When selecting FM as the source, you cannot

switch to SLA.

#When playing other than the DVD disc, you

cannot switch to DYNAMIC RANGE CONTROL.

#When neither FRONT-L nor FRONT-R is se-

lected in POSITION, you cannot switch to

TIME ALIGNMENT.

#When both the center speaker and the rear

speaker are set to OFF in the speaker setting, you

cannot switch to DOLBY PRO LOGIC II.

2 Touch ESC to return to the ordinary dis-

play.

#To return to the previous display, touch BACK.

Using the sound field control

The SFC function creates the sensation of a

live performance.

!The acoustics of different performance en-

vironments are not the same and depend

on the extent and contour of space through

which sound waves move and on how

sounds bounce off the stage, walls, floors

and ceilings. At a live performance you

hear music in three stages: direct sound,

early reflections, and late reflections, or re-

verberations. Those factors are programed

into the SFC circuitry to recreate the acous-

tics of various performance settings.

1 Press EQ and hold to switch to SFC

function.

#To switch to equalizer function, press EQ and

hold again.

2 Press EQ to select the desired SFC

mode.

MUSICAL (musical)—DRAMA (drama)—

ACTION (action)—JAZZ (jazz)—HALL (hall)—

CLUB (club)—OFF (off)

Note

If the source is a 2-channel LPCM audio or a 2-

channel Dolby Digital audio and you select SFC

effects that are most applicable for 5.1-channel

audio (i.e., MUSICAL,DRAMA or ACTION), we

recommend turning Dolby Pro Logic II on. On the

other hand, when selecting SFC effects that are

intended for use with 2-channel audio (i.e., JAZZ,

HALL or CLUB), we recommend turning Dolby

Pro Logic II off.

Using the position selector

One way to assure a more natural sound is to

accurately position the stereo image, putting

you right in the center of the sound field. The

position selector function lets you automati-

cally adjust the speaker output levels and in-

serts a delay time to match the number and

position of occupied seats. When used in con-

junction with the SFC, the feature will make

the sound image more natural and offer a pa-

noramic sound that envelops you.

1 Touch POSITION on the DSP function

menu.

2 Touch c/d/a/bto select a listening po-

sition.

Touch one of these, c/d/a/b, to select a lis-

tening position as listed in the table.

Key Display Position

cFRONT-L Front seat left

dFRONT-R Front seat right

aFRONT Front seats

bALL All seats

#To cancel the selected listening position,

touch the same key again.

Available accessories

En 75

Section

Available accessories

Note

When you make adjustments to the listening po-

sition, the speaker outputs are automatically set

for appropriate levels. You can tailor the levels

more precisely referring to Adjusting the speaker

output levels using a test tone or Adjusting the

speaker output levels.

Using balance adjustment

You can change the fader/balance setting so

that it can provide the ideal listening environ-

ment in all occupied seats.

1 Touch FADER/BALANCE on the DSP

function menu.

2 Touch aor bto adjust front/rear

speaker balance.

Each time you touch aor bit moves the

front/rear speaker balance towards the front or

the rear.

FRONT:25 to REAR:25 is displayed as the

front/rear speaker balance moves from front to

rear.

#FR: 0 is the proper setting when only two

speakers are used.

3 Touch cor dto adjust left/right speak-

er balance.

Each time you touch cor dit moves the left/

right speaker balance towards the left or the

right.

LEFT:25 to RIGHT:25 is displayed as the left/

right speaker balance moves from left to right.

Adjusting source levels

SLA (source level adjustment) lets you adjust

the volume level of each source to prevent ra-

dical changes in volume when switching be-

tween sources.

!Settings are based on the FM volume level,

which remains unchanged.

1 Compare the FM volume level with the

level of the source you wish to adjust.

2 Touch SLA on the DSP function menu.

3 Touch cor dto adjust the source vo-

lume.

Each time you touch cor dit increases or de-

creases the source volume.

+4 to –4is displayed as the source volume is

increased or decreased.

Notes

!The AM volume level can also be adjusted

with source level adjustments.

!Video CD, CD, compressed audio and DivX

are set to the same source level adjustment

volume automatically.

!DVD and the optional DVD player are set to

the same source level adjustment volume

automatically.

!External unit 1 and external unit 2 are set to

the same source level adjustment volume

automatically.

!AUX (auxiliary input) and AV (AV input) are set

to the same source level adjustment volume

automatically.

Using the dynamic range control

The dynamic range refers to the difference be-

tween the largest and softest sounds. The dy-

namic range control compresses this

difference so that you can clearly hear sounds

even at low volume levels.

!The dynamic range control is effective only

on Dolby Digital sounds.

!When playing other than the DVD disc, you

cannot switch to

DYNAMIC RANGE CONTROL.

1 Touch DYNAMIC RANGE CONTROL on

the DSP function menu.

2 Touch dto turn the dynamic range con-

trol on.

#To turn dynamic range control off, touch c.

Available accessories

Section

Using the down-mix function

The down-mix function allows you to play back

multi-channel audio in 2 channels.

1 Touch DOWN MIX on the DSP function

menu.

2 Touch cor dto select the desired level.

!Lo/Ro –Stereo mix the original audio that

do not contain channel modes such as sur-

round components.

!Lt/Rt –Down mix so that the surround

components can be restored (decoded).

Using the direct control

You can override audio settings to check for ef-

fectiveness of your audio settings.

!All audio functions are locked out when the

direct control is on except VOLUME/MUTE

and DOLBY PRO LOGIC II.

1 Touch DIGITAL DIRECT on the DSP func-

tion menu.

2 Touch dto turn the direct control on.

#To turn direct control off, touch c.

Using the Dolby Pro Logic II

Dolby Pro Logic II creates five full-bandwidth

output channels from two-channel sources to

achieve high-purity matrix surround.

!Dolby Pro Logic II supports up to 48 kHz

sampling rate stereo source and has no ef-

fect on other types of source.

!When both the center speaker and the rear

speaker are set to OFF in the speaker set-

ting, you cannot switch to

DOLBY PRO LOGIC II.

1 Touch NEXT on the DSP function menu.

2 Touch DOLBY PRO LOGIC II.

3 Touch any of the following touch panel

keys to select the desired mode.

!MOVIE –The Movie mode suitable for

movie playback

!MUSIC –The Music mode suitable for

music playback

!MATRIX –The Matrix mode for when FM

radio reception is weak

!OFF –Turn Dolby Pro Logic II off

!MUSIC ADJUST –Adjust the Music mode

#You can operate MUSIC ADJUST only when

MUSIC has been selected.

Adjusting the Music mode

You can adjust the Music mode with the fol-

lowing three controls.

!Panorama (PANORAMA) extends the front

stereo image to include the surround

speakers for an exciting “wraparound”ef-

fect.

!Dimension (DIMENSION) allows you to

gradually adjust the sound field either to-

wards the front or the rear.

!Center Width Control (CENTER WIDTH) al-

lows center-channel sounds to be posi-

tioned between the center speaker and the

left/right speakers. It improves the left-cen-

ter-right stage presentation for both the dri-

ver and the front passenger.

1 Touch NEXT on the DSP function menu.

2 Touch DOLBY PRO LOGIC II.

3 Touch MUSIC and then touch

MUSIC ADJUST.

#You can operate MUSIC ADJUST only when

MUSIC has been selected.

4 Touch aor bto select PANORAMA (pa-

norama).

Each time you touch aor bselects the item

in the following order:

PANORAMA (panorama)—DIMENSION (di-

mension)—CENTER WIDTH (center width)

5 Touch dto turn the panorama control

on.

#To turn the panorama control off, touch c.

Available accessories

En 77

Section

Available accessories

6 Touch bto select DIMENSION and then

touch cor dto adjust front/surround

speaker balance.

Each time you touch cor dit moves the

sound towards the front or the surrounds.

+3 to –3is displayed as the front/rear speaker

balance moves from front to surrounds.

7 Touch bto select CENTER WIDTH and

then touch cor dto adjust the center

image.

Each time you touch cor dit gradually

spreads the center channel sound into the

front left and right speakers over a range 0to

3is the default and it’s recommended for

most recordings. 0places all center sound in

the center speaker. 7places all center sound

equally in the left/right speakers.

Setting the speaker setting

You need to make with/without (or yes/no) and

size (bass reproducing capacity) selection/ad-

justments depending on the installed speak-

ers. The size needs to be set to LARGE (large)

if the speaker is capable of reproducing

sounds of about 100 Hz or below. Otherwise

select SMALL (small).

!Low frequency range is not output if the

subwoofer is set to OFF and the front and

rear speakers set to SMALL or OFF.

!It is imperative that non-installed speakers

be set to OFF.

!Set the front or rear speaker to LARGE if

the speaker is capable of reproducing bass

content, or if no subwoofer is installed.

1 Touch NEXT on the DSP function menu.

2 Touch SPEAKER SETTING.

3 Touch aor bto select the speaker to

be adjusted.

Each time you touch aor bselects the speak-

er in the following order:

FRONT (front speakers)—CENTER (center

speaker)—REAR (rear speakers)—

SUB WOOFER (subwoofer)—PHASE (subwoo-

fer setting)

#You can switch to PHASE only when the sub-

woofer has been set to ON.

4 Touch cor dto select the correct size

for the selected speaker.

Each time you touch cor dselects the size in

the following order:

OFF (off)—SMALL (small)—LARGE (large)

#You cannot select OFF, when FRONT (front

speakers) have been selected.

#You can select ON or OFF, when

SUB WOOFER (subwoofer) has been selected.

#You can switch REVERSE (reverse phase) or

NORMAL (normal phase), when PHASE (subwoo-

fer setting) has been selected.

Correcting the subwoofer’s phase

If trying to boost the bass output of the sub-

woofer doesn’t do much or rather makes you

feel that the bass gets more murky, this may

indicate that the subwoofer’s output and bass

content you hear over other speakers cancel

each other out. To remove this problem, try

changing the phase setting for the subwoofer.

1 Touch NEXT on the DSP function menu.

2 Touch SPEAKER SETTING.

3 Touch aor bto select SUB WOOFER

(subwoofer).

Each time you touch aor bselects the speak-

er in the following order:

FRONT (front speakers)—CENTER (center

speaker)—REAR (rear speakers)—

SUB WOOFER (subwoofer)—PHASE (subwoo-

fer setting)

4 Touch dto turn subwoofer output on.

#To turn subwoofer output off, touch c.

5 Touch band then touch cor dto se-

lect the phase of subwoofer output.

Touch dto select normal phase and

NORMAL appears in the display. Touch cto

select reverse phase and REVERSE appears in

the display.

Available accessories

Section

Note

When playing a 2-channel mono source with Pro

Logic turned on, there may be occasions when

the following will occur:

!No audio is outputted if the center speaker

setting is SMALL or LARGE and no center

speaker is installed.

!Audio is heard only over the center speaker if

installed and the center speaker setting is

SMALL or LARGE.

Adjusting the speaker output

levels

Speaker level can be adjusted finely by listen-

ing to an audio output. First, use test tone to

adjust the approximate speaker level, and then

use this function to adjust finely.

1 Touch NEXT on the DSP function menu.

2 Touch SPEAKER LEVEL.

3 Touch aor bto select the speaker to

be adjusted.

Each time you touch aor bselects the speak-

er in the following order:

FRONT L (front speaker left)—CENTER (center

speaker)—FRONT R (front speaker right)—

REAR R (rear speaker right)—REAR L (rear

speaker left)—SUB WOOFER (subwoofer)

#You cannot select speakers whose size is set

to OFF. (Refer to Setting the speaker setting on

the previous page.)

4 Touch cor dto adjust the speaker out-

put level.

Each time you touch cor dincreases or de-

creases the speaker output level. +10 to –10 is

displayed as the level is increased or de-

creased.

Note

To adjust the speaker output levels in this mode is

the same as making the speaker output levels at

TEST TONE. Both provide the same results.

Selecting a cross-over frequency

You can select a frequency, under which

sounds are reproduced through the subwoo-

fer. If the installed speakers include one whose

size has been set to SMALL, you can select a

frequency, under which sounds are repro-

duced through a LARGE speaker or subwoo-

fer.

1 Touch NEXT on the DSP function menu.

2 Touch CROSS OVER.

3 Touch aor bto select the speaker to

be adjusted.

Each time you touch aor bselects the speak-

er in the following order:

FRONT (front speakers)—CENTER (center

speaker)—REAR (rear speakers)—

SUB WOOFER (subwoofer)

4 Touch cor dto select cross-over fre-

quency.

Each time you touch cor dselects cross-over

frequencies in the following order:

63Hz—80Hz—100Hz—125Hz—160Hz—

200Hz

Note

Selecting a cross-over frequency is to set a cross-

over frequency of the subwoofer’s L.P.F. (low-pass

filter) and that of the SMALL speaker H.P.F. (high-

pass filter). The cross-over frequency setting has

no effect if the subwoofer is set to OFF and other

speakers are set to LARGE or OFF.

Adjusting the speaker output

levels using a test tone

This function allows you to easily get the over-

all balance right among the speakers.

1 Touch NEXT on the DSP function menu.

2 Touch TEST TONE.

Available accessories

En 79

Section

Available accessories

3 Touch START to start the test tone out-

put.

The test tone is outputted. It rotates from

speaker to speaker in the following sequence

at intervals of about two seconds. The current

settings for the speaker over which you hear

the test tone are shown in the display.

FRONT L (front speaker left)—CENTER (center

speaker)—FRONT R (front speaker right)—

REAR R (rear speaker right)—REAR L (rear

speaker left)—SUB WOOFER (subwoofer)

Check each speaker output level. If no adjust-

ments are needed, perform step 5 to stop the

test tone.

#The settings do not appear for speakers

whose size is set to OFF. (Refer to Setting the

speaker setting on page 78.)

4 Touch cor dto adjust the speaker out-

put level.

Each time you touch cor dincreases or de-

creases the speaker output level. +10 to –10 is

displayed as the level is increased or de-

creased.

#The test tone rotates to the next speaker after

about two seconds from the last operation.

5 Touch STOP to stop the test tone out-

put.

Notes

!If needed, select speakers and adjust their ‘ab-

solute’output levels. (Refer to Adjusting the

speaker output levels on the previous page.)

!To adjust the speaker output levels in this

mode is the same as making the speaker out-

put levels at SPEAKER LEVEL (speaker output

level). Both provide the same results.

Using the time alignment

The time alignment lets you adjust the dis-

tance between each speaker and the listening

position.

1 Touch NEXT on the DSP function menu.

2 Touch TIME ALIGNMENT.

3 Touch any of the following touch panel

keys to select the time alignment.

!INITIAL –Initial time alignment (factory set-

ting)

!AUTO TA –Time alignment created by auto

TA and EQ. (Refer to Auto TA and EQ (auto-

time alignment and auto-equalizing) on

page 82.)

!CUSTOM –Adjusted time alignment that

you can create for yourself

!OFF –Turn the time alignment off

!ADJUSTMENT –Adjust the time alignment

as desired

#You cannot select AUTO TA if auto TA and EQ

has not been carried out.

#You cannot select ADJUSTMENT when

neither FRONT-L nor FRONT-R is selected in

POSITION.

Adjusting the time alignment

You can adjust the distance between each

speaker and the selected position.

!An adjusted time alignment is memorized

in CUSTOM.

1 Touch NEXT on the DSP function menu.

2 Touch TIME ALIGNMENT and then

touch ADJUSTMENT.

#You cannot select ADJUSTMENT when

neither FRONT-L nor FRONT-R is selected in

POSITION.

3 Touch aor bto select the speaker to

be adjusted.

Each time you touch aor bselects the speak-

er in the following order:

FRONT L (front speaker left)—CENTER (center

speaker)—FRONT R (front speaker right)—

REAR R (rear speaker right)—REAR L (rear

speaker left)—SUB WOOFER (subwoofer)

#You cannot select speakers whose size is set

to OFF. (Refer to Setting the speaker setting on

page 78.)

Available accessories

Section

4 Touch cor dto adjust the distance be-

tween the selected speaker and the listen-

ing position.

Each time you touch cor dincreases or de-

creases the distance. 0.0inch to 200.0inch is

displayed as the distance is increased or de-

creased.

Using the equalizer

The equalizer lets you adjust the equalization

to match the car’s interior acoustic character-

istics as desired.

Recalling equalizer curves

There are seven stored equalizer curves which

you can easily recall at any time. Here is a list

of the equalizer curves.

Display Equalizer curve

POWERFUL Powerful

NATURAL Natural

VOCAL Vocal

FLAT Flat

CUSTOM1 Custom 1

CUSTOM2 Custom 2

SUPER BASS Super bass

!CUSTOM1 and CUSTOM2 are adjusted

equalizer curves.

!When FLAT is selected, no supplement or

correction is made to the sound. This is

useful to check the effect of the equalizer

curves by switching alternatively between

FLAT and a set equalizer curve.

%Press EQ repeatedly to switch between

the following equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—SUPER BASS

Adjusting 3-band parametric equalizer

For CUSTOM1 and CUSTOM2 equalizer

curves, you can adjust the front, rear and cen-

ter equalizer curves separately by selecting a

center frequency, an equalizer level and a Q

factor for each band.

!A separate CUSTOM1 curve can be cre-

ated for each source.

!ACUSTOM2 curve can be created com-

mon to all sources.

!The center speaker largely determines the

sound image and getting the balance right

isn’t easy. We recommend reproducing a 2-

ch. audio (a CD for example) and getting

the balance right among the speakers ex-

cept for the center, and then reproducing a

5.1-ch. audio (Dolby Digital or DTS) and ad-

justing the center speaker output to the

balance you have already got among the

other speakers.

1 Touch NEXT twice on the DSP function

menu.

2 Touch PARAMETRIC EQ.

3 Touch aor bto select the desired item.

Each time you touch aor bselects the item

in the following order:

EQ (equalizer)—SP-SELECT (speakers)—

BAND (bands)—FREQUENCY (center fre-

quency)—LEVEL (equalizer level)—

Q. FACTOR (Q factor)

4 Touch dto select the equalizer.

Touch drepeatedly to switch between the fol-

lowing equalizers:

POWERFUL—NATURAL—VOCAL—FLAT—

CUSTOM1—CUSTOM2—SUPER BASS

5 Touch band then touch cor dto se-

lect the speaker to be adjusted.

Touch cor duntil the desired speaker ap-

pears in the display.

REAR (rear speakers)—CENTER (center speak-

er)—FRONT (front speakers)

#You cannot select speakers whose size is set

to OFF. (Refer to Setting the speaker setting on

page 78.)

6 Touch band then touch cor dto se-

lect the equalizer band to be adjusted.

Each time you touch cor dselects equalizer

bands in the following order:

Available accessories

En 81

Section

Available accessories

LOW (low)—MID (mid)—HIGH (high)

7 Touch band then touch cor dto se-

lect the center frequency of selected band.

Touch cor duntil the desired frequency ap-

pears in the display.

40Hz—50Hz—63Hz—80Hz—100Hz—125Hz

—160Hz—200Hz—250Hz—315Hz—400Hz—

500Hz—630Hz—800Hz—1kHz—1.25kHz—

1.6kHz—2kHz—2.5kHz—3.15kHz—4kHz—

5kHz—6.3kHz—8kHz—10kHz—12.5kHz

8 Touch band then touch cor dto ad-

just the equalizer level.

Each time you touch cor dit increases or de-

creases the equalizer level. +12 to –12 is dis-

played as the level is increased or decreased.

9 Touch band then touch cor dto se-

lect the desired Q factor.

Each time you touch cor dswitches between

the following Q factor:

NARROW (narrow)—WIDE (wide)

#You can adjust parameters for each band of

the other speakers in the same way.

Note

You can select a center frequency for each band.

You can change the center frequency in 1/3-oc-

tave steps, but you cannot select frequencies that

have intervals shorter than 1 octave among the

center frequencies of the three bands.

Using the auto-equalizer

The auto-equalizer is the equalizer curve cre-

ated by auto TA and EQ (refer to Auto TA and

EQ (auto-time alignment and auto-equalizing)

on this page).

You can turn the auto-equalizer on or off.

1 Touch NEXT twice on the DSP function

menu.

2 Touch AUTO EQ.

#You cannot use this function if auto TA and

EQ has not been carried out.

3 Touch dto turn the auto-equalizer on.

#To turn auto-equalizer off, touch c.

Auto TA and EQ (auto-time

alignment and auto-equalizing)

The auto-time alignment is automatically ad-

justed for the distance between each speaker

and the listening position.

The auto-equalizer automatically measures

the car interior acoustic characteristics, and

then creates the auto-equalizer curve based

on that information.

WARNING

To prevent accidents, never carry out auto TA and

EQ while driving. When this function measures

the car interior acoustic characteristics to create

an auto-equalizer curve, a loud measurement

tone (noise) may be outputted from the speakers.

CAUTION

!Carrying out auto TA and EQ under the follow-

ing conditions may damage the speakers. Be

sure to check the conditions thoroughly be-

fore carrying out auto TA and EQ.

—When speakers are incorrectly connected.

(e.g., When a rear speaker is connected to

a subwoofer output.)

—When a speaker is connected to a power

amp delivering output higher than the

speaker’s maximum input power capabil-

ity.

!If the microphone is placed in an unsuitable

position the measurement tone may become

loud and measurement may take a long time,

resulting in a drain on battery power. Be sure

to place the microphone in the specified loca-

tion.

Available accessories

Section

Before operating the auto TA and EQ

function

!Carry out auto TA and EQ in as quiet a

place as possible, with the car engine and

air conditioning switched off. Also cut

power to car phones or portable telephones

in the car, or remove them from the car be-

fore carrying out auto TA and EQ. Sounds

other than the measurement tone (sur-

rounding sounds, engine sound, tele-

phones ringing etc.) may prevent correct

measurement of the car interior acoustic

characteristics.

!Be sure to carry out auto TA and EQ using

the supplied microphone. Using another

microphone may prevent measurement, or

result in incorrect measurement of the car

interior acoustic characteristics.

!When front speaker is not connected, auto

TA and EQ cannot be carried out.

!When this unit is connected to a power

amp with input level control, auto TA and

EQ may not be possible if you lower power

amp input level. Set the power amp’s input

level to the standard position.

!When this unit is connected to a power

amp with an LPF, turn off the LPF on the

power amp before carrying out auto TA and

EQ. In addition, the cut-off frequency for

built-in LPF of an active subwoofer should

be set to the highest frequency.

!The time alignment value calculated by

auto TA and EQ may differ from the actual

distance in the following circumstances.

However, the distance has been calculated

by computer to be the optimum delay to

give accurate results for the circum-

stances, so please continue to use this

value.

—When the reflected sound within a vehi-

cle is strong and delays occur.

—When delays occur for low sounds due

to the influence of the LPF on active

subwoofers or external amps.

!Auto TA and EQ changes the audio settings

as below:

—The fader/balance settings return to the

center position. (Refer to page 76.)

—The equalizer curve switches to FLAT.

(Refer to page 81.)

—It will be adjusted automatically to high

pass filter setting for front, center and

rear speaker.

!If you carry out auto TA and EQ when a pre-

vious setting of this already exists, the set-

ting will be replaced.

Carrying out auto TA and EQ

1 Stop the car in a place that is as quiet

as possible, close all doors, windows and

the sun roof, and then turn the engine off.

If the engine is left running, engine noise may

prevent correct auto TA and EQ.

2 Fix the supplied microphone in the cen-

ter of the headrest of the driver’s seat, fa-

cing forward, using the belt (sold

separately).

The auto TA and EQ may differ depending on

where you place the microphone. If desired,

place the microphone on the front passenger

seat to carry out auto TA and EQ.

3 Turn the ignition switch to ON or ACC.

If the car’s air conditioner or heater is turned

on, turn it off. Noise from the fan in the air

conditioner or heater may prevent correct auto

TA and EQ.

#Press SRC to turn the source on if this unit is

turned off.

Available accessories

En 83

Section

Available accessories

4 Select the position for the seat on

which the microphone is placed.

Refer to Using the position selector on page

75.

#If no position is selected before you start auto

TA and EQ, FRONT-L is selected automatically.

5 Press SRC and hold until the unit turns

off.

6 Press and hold EQ to enter the auto TA

and EQ measurement mode.

7 Plug the microphone into the micro-

phone input jack on the multi-channel pro-

cessor.

For details concerning operation, refer to the

multi-channel processor’s operation manual.

8 Touch START to start the auto TA and

EQ.

9 Get out of the car and close the door

within 10 seconds when the 10-second

count-down starts.

The measurement tone (noise) is outputted

from the speakers, and auto TA and EQ be-

gins.

#When all speakers are connected, auto TA

and EQ is completed in about nine minutes.

#To stop auto TA and EQ, touch STOP.

#To cancel auto TA and EQ on the way, touch

BACK or ESC.

10 When auto TA and EQ is completed,

Complete is displayed.

When correct measurement of car interior

acoustic characteristics is not possible, an

error message is displayed. (Refer to Under-

standing auto TA and EQ error messages on

page 89.)

11 Touch ESC to cancel the auto TA and EQ

mode.

12 Store the microphone carefully in the

glove compartment.

Store the microphone carefully in the glove

compartment or any other safe place. If the

microphone is subjected to direct sunlight for

an extended period, high temperatures may

cause distortion, color change or mal-

function.

Available accessories

Section

Troubleshooting

Common

Symptom Cause Action (See)

Power doesn’t turn on.

The unit doesn’t operate.

Leads and connectors are incor-

rectly connected.

Confirm once more that all connections are

correct.

The fuse is blown. Rectify the reason for the fuse blowing, then

replace the fuse. Be very sure to install a fuse

with the same rating.

Noise and other factors are causing

the built-in microprocessor to oper-

ate incorrectly.

Press RESET. (Page 15)

Operation with the remote con-

trol isn’t possible.

The unit does not operate cor-

rectly even when the appropriate

remote control buttons are

pressed.

The remote control operation mode

is incorrect.

Switch to the correct remote control mode.

The remote control code is incor-

rect.

Make sure the remote control selection

switch setting and code type setting are the

same.

Battery power is low. Load new battery.

Some operations are prohibited

with certain discs.

Check by using another disc.

Playback is not possible. The disc is dirty. Clean disc. (Page 90)

The loaded disc is a type this unit

cannot play.

Check what type the disc is.

Non compatible video system disc

is loaded.

Change to a disc compatible to your video

system.

No sounds are heard.

The volume level will not rise.

Cables are not connected correctly. Connect the cables correctly.

The unit is performing still, slow mo-

tion or frame-by-frame playback.

There is no sound during still, slow motion or

frame-by-frame playback.

There is no picture. The parking brake cord is not con-

nected.

Connect a parking brake cord, and apply the

parking brake.

The parking brake is not applied. Connect a parking brake cord, and apply the

parking brake.

The icon is displayed, and op-

eration is not possible.

The operation is prohibited for the

disc.

This operation is not possible.

The operation is not compatible

with the disc’s organization.

This operation is not possible.

The picture stops (pauses) and

the unit cannot be operated.

Reading of data has become impos-

sible during playback.

After stopping playback once, start playback

once more.

There is no sound.

Volume level is low.

The volume level is low. Adjust the volume level.

The attenuator is on. Turn the attenuator off.

There is audio and video skip-

ping.

The unit is not firmly secured. Secure the unit firmly.

The picture is stretched, the as-

pect is incorrect.

The aspect setting is incorrect for

the display.

Select the appropriate setting for your display.

(Page 39)

When the ignition switch is

turned ON (or turned to ACC),

the motor sounds.

The unit is confirming whether a

disc is loaded or not.

This is a normal operation.

Additional Information

En 85

Appendix

Additional Information

Nothing is displayed.

The touch panel keys cannot be

used.

The rear view camera is not con-

nected.

CAMERA POLARITY is at incorrect

setting.

Connect a rear view camera.

Press and hold VOLUME/MUTE to return to

the source display and then select the correct

setting for CAMERA POLARITY. (Page 47)

Problems during DVD playback

Symptom Cause Action (See)

Playback is not possible. The loaded disc has a different re-

gion number from this unit.

Replace the disc with one featuring the same

region number as this unit. (Page 9, Page

100)

A parental lock message is dis-

played and playback is not pos-

sible.

Parental lock is on. Turn parental lock off or change the level.

(Page 40)

Parental lock cannot be can-

celed.

The code number is incorrect. Input the correct code number. (Page 40)

You have forgotten your code num-

ber.

Touch C10 times to cancel the code number.

(Page 40)

Dialog language (and subtitle

language) cannot be switched.

The DVD playing does not feature

multiple language recordings.

You cannot switch among multiple languages

if they are not recorded on the disc.

You can only switch between items

indicated in the disc menu.

Switch using the disc menu.

No subtitles are displayed. The DVD playing does not feature

subtitles.

Subtitles are not displayed if they are not re-

corded on the disc.

You can only switch between items

indicated in the disc menu.

Switch using the disc menu.

Playback is not with the audio

language and subtitle language

settings selected in DVD SETUP.

The DVD playing does not feature

dialog or subtitles in the language

selected in DVD SETUP.

Switching to a selected language is not possi-

ble if the language selected in DVD SETUP is

not recorded on the disc.

Switching the viewing angle is

not possible.

The DVD playing does not feature

scenes shot from multiple angles.

You cannot switch between multiple angles if

the DVD does not feature scenes recorded

from multiple angles.

You are trying to switch to multiple

angle viewing of a scene that is not

recorded from multiple angles.

Switch between multiple angles when watch-

ing scenes recorded from multiple angles.

The picture is extremely unclear/

distorted and dark during play-

back.

The disc features a signal to prohibit

copying. (Some discs may have

this.)

Since this unit is compatible with the copy

guard analog copy protect system, when play-

ing a disc that has a signal prohibiting copy-

ing, the picture may suffer from horizontal

stripes or other imperfections when viewed

on some displays. This does not mean this

unit is malfunctioning.

Problems during Video CD playback

Symptom Cause Action

The PBC (playback control)

menu display cannot be called

up.

The Video CD playing does not fea-

ture PBC.

This operation is not possible with Video CDs

not featuring PBC.

Repeat play and track/time

search are not possible.

The Video CD playing features PBC. This operation is not possible with Video CDs

featuring PBC.

Additional Information

Appendix

Problems during iPod playback

Symptom Cause Action

iPod doesn’t operate correctly. Cables are incorrectly connected. Disconnect the cable from iPod. Once iPod

main menu is displayed, connect the cable

again.

Reset the iPod.

The iPod version is old. Update the iPod version.

Problems during multi-channel processor connection

Symptom Cause Action (See)

No sounds are heard.

The volume level will not rise.

Optical cables are not connected

correctly.

Connect the cables correctly.

Even if multi-channel audio is

selected, 2-channel audio is out-

put.

Digital output setting is set to Line-

ar PCM.

Normally, set the digital output setting to

STREAM. (Page 41)

Error messages

When you contact your dealer or your nearest Pioneer Service Center, be sure to have the error

message recorded.

Built-in DVD player

Message Cause Action

DIFFERENT REGION DISC (R

ERROR)

The disc does not have the same re-

gion number as this unit

Replace the DVD video with one bearing the

correct region number.

ERROR-02-XX Dirty disc Clean disc.

Scratched disc Replace disc.

The disc is loaded upside down Check that the disc is loaded correctly.

Electrical or mechanical Press RESET.

NON-PLAYABLE DISC (NON-

PLAY)

This type of disc cannot be played

by this unit

Replace the disc with one this unit can play.

The inserted disc does not contain

any files that can be played back

Replace disc.

PROTECT All the files on the inserted disc are

secured by DRM

Replace disc.

SKIPPED The inserted disc contains WMA

files that are protected by DRM

Replace disc.

TEMP The temperature of this unit is out-

side the normal operating range

Wait until the unit’s temperature returns to

within normal operating limits.

Additional Information

En 87

Appendix

Additional Information

USB audio player/USB memory

Message Cause Action

NO AUDIO No songs Transfer the audio files to the USB portable

audio player/USB memory and connect.

USB memory with security enabled

is connected

Follow the USB memory instructions to dis-

able the security.

NO DEVICE The USB storage device is not con-

nected to the USB port of this unit.

Connect a compatible USB storage device.

SKIPPED The connected USB portable audio

player/USB memory contains WMA

files that are protected by Windows

Media™DRM 9/10

Play an audio file not protected by Windows

Media DRM 9/10.

PROTECT All the files on the connected USB

portable audio player/USB memory

are protected by Windows Media

DRM 9/10

Transfer audio files not protected by Windows

Media DRM 9/10 to the USB portable audio

player/USB memory and connect.

N/A USB The USB device connected to is not

supported by this unit.

Connect a USB portable audio player or USB

memory that is USB Mass Storage Class

compliant.

CHECK USB The USB connector or USB cable is

short-circuited.

Confirm that the USB connector or USB

cable is not caught in something or da-

maged.

The connected USB portable audio

player/USB memory consumes

more than 500 mA (maximum allow-

able current).

Disconnect the USB portable audio player/

USB memory and do not use it. Turn the igni-

tion switch to OFF, then to ACC or ON and

then connect the compliant USB portable

audio player/USB memory.

ERROR-19 Communication failure Perform one of the following operations.

–Turn the ignition switch OFF and back ON.

–Disconnect the USB portable audio player/

USB memory.

–Change to a different source.

Then, return to the USB portable audio

player/USB memory.

ERROR-23 USB device is not formatted with

FAT16 or FAT32

USB device should be formatted with FAT16

or FAT32.

iPod

Message Cause Action

ERROR-11 Communication failure Disconnect the cable from iPod. Once iPod

main menu is displayed, connect the cable

again.

Reset the iPod.

ERROR-21 Old version of iPod Update the iPod version.

ERROR-30 iPod failure Reset the iPod.

STOP No songs in the current list Select a list that contains the songs.

No songs Transfer the songs to iPod.

Additional Information

Appendix

iPod is not charged but operates

correctly

Check if the connection cable for iPod

shorted out (e.g., not caught in metal ob-

jects). After checking, turn the ignition switch

OFF and back ON or disconnect the iPod and

connect again.

The connected USB portable audio

player/USB memory consumes

more than 500 mA (maximum allow-

able current).

Check if the connection cable for iPod

shorted out (e.g., not caught in metal ob-

jects). After checking, turn the ignition switch

OFF and back ON or disconnect the iPod and

connect again.

Error has occurred when connect-

ing the iPod to this unit

Reconnect the iPod.

Turn the ignition switch to OFF, then to ACC

or ON.

Update the iPod version.

Understanding auto TA and EQ error messages

When correct measurement of car interior acoustic characteristics is not possible using the auto

TA and EQ, an error message may appear on the display. If an error message appears, refer to the

table below to see what the problem is and the suggested method of correcting the problem. After

checking, try again.

Message Cause Action

Error. Please check MIC. Microphone is not connected. Plug the supplied microphone securely into

the jack.

Error. Please check front SP.,

Error. Please check FL SP.,

Error. Please check FR SP.,

Error. Please check center SP.,

Error. Please check rear SP.,

Error. Please check RL SP.,

Error. Please check RR SP.,

Error. Please check subwoofer

The microphone cannot pick up the

measuring tone of a speaker.

!Confirm that the speakers are connected

correctly.

!Correct the input level setting of the power

amp connected to the speakers.

!Set the microphone correctly.

Error. Please check noise. The surrounding noise level is too

high.

!Stop your car in a place that is as quiet as

possible, and switch off the engine, air condi-

tioner or heater.

!Set the microphone correctly.

Additional Information

En 89

Appendix

Additional Information

Handling guideline of discs

and player

!Use only conventional, fully circular discs.

Do not use shaped discs.

!Use 12-cm or 8-cm disc. Do not use an

adapter when playing 8-cm discs.

!Do not insert anything other than a disc

into the disc loading slot. Discs which can

be played back are listed in the following

section. Refer to Playable discs on page 9.

!Do not use cracked, chipped, warped, or

otherwise damaged discs as they may da-

mage the player.

!Do not touch the recorded surface of the

discs.

!Store discs in their cases when not in use.

!Avoid leaving discs in excessively hot envir-

onments including under direct sunlight.

!Do not attach labels, write on or apply che-

micals to the surface of the discs.

!To clean a disc, wipe the disc with a soft

cloth outward from the center.

!Condensation may temporarily impair the

player’s performance. Leave it to adjust to

the warmer temperature for about one

hour. Also, wipe any dump discs with a soft

cloth.

!Playback of discs may not be possible be-

cause of disc characteristics, disc format,

recorded application, playback environ-

ment, storage conditions, and so on.

!Road shocks may interrupt disc playback.

!Read the precautions for discs before

using them.

DVD discs

!With some DVD video discs, it may not be

possible to use certain functions.

!It may not be possible to play back some

DVD video discs.

!It is not possible to play back DVD-ROM/

DVD-RAM discs.

DVD-R/DVD-RW discs

!Unfinalized DVD-R/-RW discs which have

been recorded with the Video format (video

mode) cannot be played back.

!DVD-R/-RW discs which have been re-

corded with the Video Recording format

(VR mode) cannot be played back.

!For more information about recording

mode, please contact manufacture of DVD

recorder or application.

AVCHD recorded discs

!This unit is not compatible with discs re-

corded in AVCHD (Advanced Video Codec

High Definition) format. Do not insert

AVCHD discs. If inserted, the disc may not

be ejected.

CD-R/CD-RW discs

!When CD-R/CD-RW discs are used, play-

back is possible only for discs which have

been finalized.

!It may not be possible to play back CD-R/

CD-RW discs recorded on a music CD re-

corder or a personal computer because of

disc characteristics, scratches or dirt on

the disc, or dirt, condensation, etc., on the

lens of this unit.

!Playback of discs recorded on a personal

computer may not be possible, depending

on the application settings and the environ-

ment. Please record with the correct for-

mat. (For details, contact the manufacturer

of the application.)

Additional Information

Appendix

!Playback of CD-R/CD-RW discs may be-

come impossible in case of direct exposure

to sunlight, high temperatures, or the sto-

rage conditions in the vehicle.

!Titles and other text information recorded

on a CD-R/CD-RW disc may not be dis-

played by this unit (in the case of audio

data (CD-DA)).

!Read the precautions with CD-R/CD-RW

discs before using them.

Dual Discs

!Dual Discs are two-sided discs that have a

recordable CD for audio on one side and a

recordable DVD for video on the other.

!Playback of the DVD side is possible with

this unit. However, since the CD side of

Dual Discs is not physically compatible

with the general CD standard, it may not be

possible to play the CD side with this unit.

!Frequent loading and ejecting of a Dual

Disc may result in scratches on the disc.

Serious scratches can lead to playback pro-

blems on this unit. In some cases, a Dual

Disc may become stuck in the disc loading

slot and will not eject. To prevent this, we

recommend you refrain from using Dual

Disc with this unit.

!Please refer to the information from the

disc manufacturer for more detailed infor-

mation about Dual Discs.

Compressed audio files on

the disc

!Depending on the version of Windows

Media™Player used to encode WMA files,

album names and other text information

may not be correctly displayed.

!There may be a slight delay when starting

playback of audio files encoded with image

data.

!ISO 9660 Level 1 and 2 compliant. Romeo

and Joliet file systems are both compatible

with this player.

!Multi-session playback is possible.

!Compressed audio files are not compatible

with packet write data transfer.

!Only 64 characters from the beginning can

be displayed as a file name (including the

extension such as .wma or .mp3) or a folder

name.

!Folder selection sequence or other opera-

tion may be altered depending on the en-

coding or writing software.

!Regardless of the length of blank section

between the songs of original recording,

compressed audio discs play with a short

pause between songs.

!File extensions such as .wma, .mp3 or .m4a

must be used properly.

Example of a hierarchy

: Folder

: Compressed audio file

l 1 L

l 2 L

l 3 L

l 4

!This unit assigns folder numbers. The user

cannot assign folder numbers.

!It is possible to play back up to 255 folders

on one disc.

Additional Information

En 91

Appendix

Additional Information

Compressed audio compatibility

WMA

!Compatible format: WMA encoded by

Windows Media Player

!Bit rate: 5 kbps to 320 kbps (CBR), VBR

!Sampling frequency: 8 kHz to 48 kHz

!Windows Media Audio 9 Professional, Loss-

less, Voice: No

MP3

!Bit rate: 8 kbps to 320 kbps (CBR), VBR

!Sampling frequency: 8 kHz to 48 kHz (8 kHz

to 48 kHz for emphasis)

!Compatible ID3 tag version: 1.0, 1.1, 2.2, 2.3

(ID3 tag Version 2.x is given priority than

Version 1.x.)

!M3u playlist: No

!MP3i (MP3 interactive), mp3 PRO: No

AAC

!Compatible format: AAC encoded by iTunes

!Bit rate: 8 kbps to 320 kbps (CBR)

!VBR: No

!Sampling frequency: 8 kHz to 44.1 kHz

!Apple Lossless: No

USB audio player/USB memory

compatibility

!USB version: 2.0, 1.1 and 1.0

!USB data transfer rate: full speed

!USB Class: MSC (Mass Storage Class) de-

vice

!Protocol: bulk

!Minimum amount of memory: 250 MB

!Maximum amount of memory: 250 GB

!File system: FAT32 and FAT16

!Supply current: 500 mA

Notes

!Partitioned USB memory is not compatible

with this unit.

!Depending on the kind of USB portable audio

player/USB memory you use, this unit may

not recognize the USB audio player/USB

memory or audio files may not be played back

properly.

!This unit can play back files in the USB porta-

ble audio player/USB memory that is USB

Mass Storage Class. However, copyright pro-

tected files that are stored in above-mentioned

USB devices cannot be played back.

!You cannot connect a USB portable audio

player/USB memory to this unit via a USB

hub.

USB audio player/USB memory

!Do not leave the USB portable audio

player/USB memory in direct sunlight for

extended amounts of time. Extended expo-

sure to direct sunlight can result in USB

portable audio player/USB memory mal-

function due to the resulting high tempera-

ture.

!Do not leave the USB portable audio

player/USB memory in high temperature.

!Firmly secure the USB portable audio

player/USB memory when driving. Do not

let the USB portable audio player/USB

memory fall onto the floor, where it may be-

come jammed under the brake or accelera-

tor pedal.

!There may be a slight delay when starting

playback of audio files encoded with image

data.

!Depending on the USB devices connected

to this unit, it may generate noise in the

radio.

!Only 22 characters from the beginning can

be displayed as a file name (including the

extension) or a folder name when USB por-

table audio player/USB memory is selected

as a source.

!The text information of some audio files

may not be correctly displayed.

!File extensions must be used properly.

!Up to 15 000 files on a USB portable audio

player/USB memory can be played back.

!Up to 500 folders on a USB portable audio

player/USB memory can be played back.

Additional Information

Appendix

!Up to eight tiers directory on a USB porta-

ble audio player/USB memory can be

played back.

!There may be a slight delay when starting

playback of audio files on a USB portable

audio player/USB memory with numerous

folder hierarchies.

!Do not connect anything other than the

USB portable audio player/USB memory.

!Operations may vary depending on the

kind of USB audio player and a USB mem-

ory.

The sequence of audio files on USB

memory

For USB portable audio players, the sequence is

different from that of USB memory and de-

pends on the player.

Example of a hierarchy

: Folder

: Compressed audio file

l 1 L

l 2 L

l 3 L

l 4

!01 to 05 represent assigned folder num-

bers. 1to 6represent the playback se-

quence. The user cannot assign folder

numbers and specify the playback se-

quence with this unit.

!Playback sequence of the audio file is the

same as recorded sequence in the USB de-

vice.

!To specify the playback sequence, the fol-

lowing method is recommended.

1 Create the file name including numbers

that specify the playback sequence (e.g.,

001xxx.mp3 and 099yyy.mp3).

2 Put those files into a folder.

3 Record the folder containing files into the

USB device.

However, depending on the system environ-

ment, you cannot specify the file playback

sequence.

Compressed audio compatibility

WMA

!Compatible format: WMA encoded by

Windows Media Player

!Bit rate: 48 kbps to 320 kbps (CBR), 48 kbps

to 384 kbps (VBR)

!Sampling frequency: 32 kHz to 48 kHz

!Windows Media Audio 9 Professional, Loss-

less, Voice: No

MP3

!Bit rate: 8 kbps to 320 kbps

!Sampling frequency: 16 kHz to 48 kHz (32,

44.1, 48 kHz for emphasis)

!Compatible ID3 tag version: 1.0, 1.1, 2.2,

2.3, 2.4 (ID3 tag Version 2.x is given priority

than Version 1.x.)

!M3u playlist: No

!MP3i (MP3 interactive), mp3 PRO: No

AAC

!Compatible format: AAC encoded by iTunes

!Sampling frequency: 11.025 kHz to 48 kHz

!Transmission rate: 16 kbps to 320 kbps

!Apple Lossless: No

WAV

!Compatible format: Linear PCM (LPCM),

MS ADPCM

!Quantization bits: 8 and 16 (LPCM), 4 (MS

ADPCM)

!Sampling frequency: 16 kHz to 48 kHz

(LPCM), 22.05 kHz to 44.1 kHz (MS AD-

PCM)

Additional Information

En 93

Appendix

Additional Information

DivX video files

!Depending on the file information composi-

tion such as the number of audio stream,

there may be a slight delay in the start of

playback on discs.

!Some special operation may be prohibited

because of the composition of DivX files.

!DivX files downloaded only from DivX part-

ner site are guarantee of proper operation.

Unauthorized DivX file may not operate

properly.

!DRM rental file cannot be operated until

starting playing back.

!This unit corresponds to a DivX file display

up to 1 590 minutes 43 seconds. Also,

search operation beyond this time limit is

prohibited.

!If a file contains more than 4 GB, playback

is stopped on the way.

!DivX VOD file playback requires ID code of

this unit to DivX VOD provider. About ID

code, refer to Displaying your DivX®VOD re-

gistration code on page 41.

!File extensions such as .avi or .divx must be

used properly.

!For more details about DivX, visit the follow-

ing site:

http://www.divx.com/

DivX compatibility

!Compatible format: DivX video format im-

plemented in relation to DivX standards

!DivX Ultra format: No

!DivX files without video data: No

!Compatible audio codec: MP2, MP3, Dolby

Digital

!LPCM: No

!Bit rate: 8 kbps to 320 kbps (CBR), VBR

!Sampling frequency: 8 kHz to 48 kHz

!Compatible external subtitle file extension:

.srt

About handling the iPod

CAUTION

!Pioneer accepts no responsibility for data lost

on the iPod even if that data is lost while

using this unit.

!Do not leave the iPod in direct sunlight for ex-

tended amounts of time. Extended exposure

to direct sunlight can result in iPod malfunc-

tion due to the resulting high temperature.

!Do not leave the iPod in a high temperature.

!Firmly secure the iPod when driving. Do not

let the iPod fall onto the floor, where it may be-

come jammed under the brake or accelerator

pedal.

For details, refer to the iPod’s manuals.

About iPod settings

!You cannot operate the iPod Equalizer on

Pioneer products. We recommend that you

set the iPod Equalizer to off, before con-

necting to this unit.

!You cannot set Repeat to off on the iPod

when using this unit. Even if you set Repeat

to off on the iPod, Repeat is automatically

changed to All when connecting the iPod

to this unit.

Using the display correctly

CAUTION

!If liquid or foreign matter should get inside

this unit, turn off the power immediately and

consult your dealer or the nearest authorized

PIONEER Service Station. Do not use the unit

in this condition because doing so may result

in fire, electric shock, or other failure.

!If you notice smoke, a strange noise or smell,

or any other abnormal signs from the display,

turn off the power immediately and consult

your dealer or the nearest authorized

PIONEER Service Station. Using this unit in

this condition may result in permanent da-

mage to the system.

Additional Information

Appendix

!Do not disassemble or modify this unit, as

there are high-voltage components inside

which may cause electric shock. Be sure to

consult your dealer or the nearest authorized

PIONEER Service Station for internal inspec-

tion, adjustments, or repairs.

Handling the display

!When the display is subjected to direct sun-

light for a long period of time, it will be-

come very hot resulting in possible

damage to the LCD screen. When not

using this unit, close the display and avoid

exposing it to direct sunlight.

!The display should be used within the tem-

perature ranges shown below.

Storage temperature range: -4 °F to +176 °F

At temperatures higher or lower than the

operating temperature range, the display

may not operate normally.

!The LCD screen is exposed in order to in-

crease its visibility within the vehicle.

Please do not press strongly on it as this

may damage it.

!Do not place anything on the display when

it is opened. Also, do not attempt to carry

out angle adjustment, or open/close the

display by hand. Applying strong force to

the display may damage it.

!Do not push the LCD screen forcefully as

this may scratch it.

!Be careful not to place anything between

the display and the main body when the

display is opening or closing. If an object

gets between the display and main body,

the display may stop working.

!Be careful of fingers, long hair, and loose

articles of clothing which could possibly

get caught between the display and the

main body and cause serious injury.

Liquid crystal display (LCD) screen

!If the display is near the vent of an air con-

ditioner when it is opened, make sure that

air from the air conditioner is not blowing

on it. Heat from the heater may damage

the LCD screen, and cool air from the cool-

er may cause moisture to form inside the

display resulting in possible damage. Also,

if the display is cooled down by the cooler,

the screen may become dark, or the life

span of the small fluorescent tube used in-

side the display may be shortened.

!Small black dots or white dots (bright dots)

may appear on the LCD screen. These are

due to the characteristics of the LCD

screen and do not indicate a problem with

the display.

!At low temperatures, the LCD screen may

be dark for a while after the power is turned

on.

!The LCD screen will be difficult to see if it is

exposed to direct sunlight.

!When using a portable phone, keep the an-

tenna of the portable phone away from the

display to prevent disruption of the video by

the appearance of spots, colored stripes,

etc.

Keeping the display in good

condition

!When removing dust from the screen or

cleaning the display, first turn the system

power off, then wipe with a soft dry cloth.

!When wiping the screen, take care not to

scratch the surface. Do not use harsh or

abrasive chemical cleaners.

Small fluorescent tube

!A small fluorescent tube is used inside the

display to illuminate the LCD screen.

—The fluorescent tube should last for ap-

proximately 10 000 hours, depending on

operating conditions. (Using the display

at low temperatures reduces the service

life of the fluorescent tube.)

Additional Information

En 95

Appendix

Additional Information

—When the fluorescent tube reaches the

end of its useful life, the screen will be

dark and the image will no longer be

projected. If this happens, consult your

dealer or the nearest authorized

PIONEER Service Station.

Additional Information

Appendix

Language code chart for DVD

Language (code), input code Language (code), input code Language (code), input code

Japanese (ja), 1001 Guarani (gn), 0714 Pashto, Pushto (ps), 1619

English (en), 0514 Gujarati (gu), 0721 Quechua (qu), 1721

French (fr), 0618 Hausa (ha), 0801 Rhaeto-Romance (rm), 1813

Spanish (es), 0519 Hindi (hi), 0809 Kirundi (rn), 1814

German (de), 0405 Croatian (hr), 0818 Romanian (ro), 1815

Italian (it), 0920 Hungarian (hu), 0821 Kinyarwanda (rw), 1823

Chinese (zh), 2608 Armenian (hy), 0825 Sanskrit (sa), 1901

Dutch (nl), 1412 Interlingua (ia), 0901 Sindhi (sd), 1904

Portuguese (pt), 1620 Interlingue (ie), 0905 Sangho (sg), 1907

Swedish (sv), 1922 Inupiak (ik), 0911 Serbo-Croatian (sh), 1908

Russian (ru), 1821 Indonesian (in), 0914 Sinhalese (si), 1909

Korean (ko), 1115 Icelandic (is), 0919 Slovak (sk), 1911

Greek (el), 0512 Hebrew (iw), 0923 Slovenian (sl), 1912

Afar (aa), 0101 Yiddish (ji), 1009 Samoan (sm), 1913

Abkhazian (ab), 0102 Javanese (jw), 1023 Shona (sn), 1914

Afrikaans (af), 0106 Georgian (ka), 1101 Somali (so), 1915

Amharic (am), 0113 Kazakh (kk), 1111 Albanian (sq), 1917

Arabic (ar), 0118 Greenlandic (kl), 1112 Serbian (sr), 1918

Assamese (as), 0119 Cambodian (km), 1113 Siswati (ss), 1919

Aymara (ay), 0125 Kannada (kn), 1114 Sesotho (st), 1920

Azerbaijani (az), 0126 Kashmiri (ks), 1119 Sundanese (su), 1921

Bashkir (ba), 0201 Kurdish (ku), 1121 Swahili (sw), 1923

Byelorussian (be), 0205 Kirghiz (ky), 1125 Tamil (ta), 2001

Bulgarian (bg), 0207 Latin (la), 1201 Telugu (te), 2005

Bihari (bh), 0208 Lingala (ln), 1214 Tajik (tg), 2007

Bislama (bi), 0209 Laothian (lo), 1215 Thai (th), 2008

Bengali (bn), 0214 Lithuanian (lt), 1220 Tigrinya (ti), 2009

Tibetan (bo), 0215 Latvian (lv), 1222 Turkmen (tk), 2011

Breton (br), 0218 Malagasy (mg), 1307 Tagalog (tl), 2012

Catalan (ca), 0301 Maori (mi), 1309 Setswana (tn), 2014

Corsican (co), 0315 Macedonian (mk), 1311 Tonga (to), 2015

Czech (cs), 0319 Malayalam (ml), 1312 Turkish (tr), 2018

Welsh (cy), 0325 Mongolian (mn), 1314 Tsonga (ts), 2019

Danish (da), 0401 Moldavian (mo), 1315 Tatar (tt), 2020

Bhutani (dz), 0426 Marathi (mr), 1318 Twi (tw), 2023

Esperanto (eo), 0515 Malay (ms), 1319 Ukrainian (uk), 2111

Estonian (et), 0520 Maltese (mt), 1320 Urdu (ur), 2118

Basque (eu), 0521 Burmese (my), 1325 Uzbek (uz), 2126

Persian (fa), 0601 Nauru (na), 1401 Vietnamese (vi), 2209

Finnish (fi), 0609 Nepali (ne), 1405 Volapük (vo), 2215

Fiji (fj), 0610 Norwegian (no), 1415 Wolof (wo), 2315

Faroese (fo), 0615 Occitan (oc), 1503 Xhosa (xh), 2408

Frisian (fy), 0625 Oromo (om), 1513 Yoruba (yo), 2515

Irish (ga), 0701 Oriya (or), 1518 Zulu (zu), 2621

Scots-Gaelic (gd), 0704 Panjabi (pa), 1601

Galician (gl), 0712 Polish (pl), 1612

Additional Information

En 97

Appendix

Additional Information

Terms

AAC

AAC is short for Advanced Audio Coding and

refers to an audio compression technology

standard used with MPEG 2 and MPEG 4.

Aspect ratio

This is the width-to-height ratio of a TV screen.

A regular display has an aspect ratio of 4:3.

Wide screen displays have an aspect ratio of

16:9, providing a bigger picture for exceptional

presence and atmosphere.

Bit rate

This expresses data volume per second, or bps

(bits per second) units. The higher the rate,

the more information is available to reproduce

the sound. Using the same encoding method

(such as MP3), the higher the rate, the better

the sound.

Chapter

DVD titles are in turn divided into chapters

which are numbered in the same way as the

chapters of a book. With DVD video discs fea-

turing chapters, you can quickly find a desired

scene with chapter search.

DivX

DivX is a popular media technology created by

DivX, Inc. DivX media files contain highly com-

pressed video with high visual quality that

maintains a relatively small file size. DivX files

can also include advanced media features like

menus, subtitles, and alternate audio tracks.

Many DivX media files are available for down-

load online, and you can create your own

using your personal content and easy-to-use

tools from DivX.com.

DivX Certified

DivX Certified products are officially tested by

the creators of DivX and guaranteed to play all

versions of DivX video, including DivX 6.

Dolby Digital

Dolby Digital provides multi-channel audio

from up to 5.1 independent channels. This is

the same as the Dolby Digital surround sound

system used in theaters.

Dolby Pro Logic II

Dolby Pro Logic II can create five full-band-

width output channels from two-channel

sources. This new technology enables a dis-

crete 5-channel playback with 2 front chan-

nels, 1 center channel, and 2 rear channels. A

music mode is also available for 2-channel

sources in addition to the movie mode.

DTS

This stands for Digital Theater Systems. DTS is

a surround system delivering multi-channel

audio from up to 6 independent channels.

Dynamic range control

Dolby Digital has a function for compressing

the difference between the loudest and softest

sounds: Dynamic range control. This control

ensures sounds with an increased dynamic

range are heard clearly even at low volume le-

vels.

ID3 tag

This is a method of embedding track-related

information in an MP3 file. This embedded in-

formation can include the track title, the ar-

tist’s name, the album title, the music genre,

the year of production, comments and other

data. The contents can be freely edited using

software with ID3 Tag editing functions.

Although the tags are restricted as to the num-

ber of characters, the information can be

viewed when the track is played back.

ISO9660 format

This is the international standard for the for-

mat logic of CD-ROM folders and files. For the

ISO9660 format, there are regulations for the

following two levels.

Level 1:

The file name is in 8.3 format (the name con-

sists of up to 8 characters, half-byte English

capital letters and half-byte numerals and the

“_”sign, with a file-extension of three charac-

ters).

Additional Information

Appendix

Level 2:

The file name can have up to 31 characters (in-

cluding the separation mark “.”and a file ex-

tension). Each folder contains less than 8

hierarchies.

Extended formats

Joliet:

File names can have up to 64 characters.

Romeo:

File names can have up to 128 characters.

Linear PCM (LPCM)/Pulse code

modulation

This stands for linear pulse code modulation,

which is the signal recording system used for

music CDs and DVDs. Generally, DVDs are re-

corded with higher sampling frequency and

bit rate than CDs. Therefore, DVDs can provide

higher sound quality.

m3u

Playlists created using the “WINAMP”soft-

ware have a playlist file extension (.m3u).

MP3

MP3 is short for MPEG Audio Layer 3. It is an

audio compression standard set by a working

group (MPEG) of the ISO (International Stan-

dards Organization). MP3 is able to compress

audio data to about 1/10th the level of a con-

ventional disc.

MPEG

This stands for Moving Pictures Experts

Group, and is an international video image

compression standard. Some DVDs feature di-

gital audio compressed and recorded using

this system.

Multi-angle

With regular TV programs, although multiple

cameras are used to simultaneously shoot

scenes, only images from one camera at a

time are transmitted to your TV. Some DVDs

feature scenes shot from multiple angles, let-

ting you choose your viewing angle as desired.

Multi-audio (Multilingual dialog)

Some DVDs feature dialog recorded in multi-

ple languages. Dialog in up to 8 languages

can be recorded on a single disc, letting you

choose as desired.

Multi-session

Multi-session is a recording method that al-

lows additional data to be recorded later.

When recording data on a CD-ROM, CD-R or

CD-RW, etc., all data from beginning to end is

treated as a single unit or session. Multi-ses-

sion is a method of recording more than 2 ses-

sions on one disc.

Multi-subtitle

Subtitles in up to 32 languages can be re-

corded on a single DVD, letting you choose as

desired.

Optical digital output/input

By transmitting and receiving audio signals in

a digital signal format, the chance of sonic

quality deteriorating in the course of transmis-

sion is minimized. An optical digital output/

input is designed to transmit and receive digi-

tal signals optically.

Packet write

This is a general term for a method of writing

on CD-R, etc., at the time required for a file,

just as is done with files on floppy or hard

discs.

Parental lock

Some DVD video discs with violent or adult-or-

iented scenes feature parental lock which pre-

vents children from viewing such scenes. With

this kind of disc, if you set the unit’s parental

lock level, playback of scenes inappropriate for

children will be disabled, or these scenes will

be skipped.

Additional Information

En 99

Appendix

Additional Information

Playback control (PBC)

This is a playback control signal recorded on

Video CDs (Version 2.0). Using menu displays

provided by Video CDs with PBC lets you enjoy

playback of simple interactive software and

software with search functions. You can also

enjoy viewing high- and standard-resolution

still images.

Region number

DVD players and DVD discs feature region

numbers indicating the area in which they

were purchased. Playback of a DVD is not pos-

sible unless it features the same region num-

ber as the DVD player.

Title

DVD video discs have high data capacity, en-

abling recording of multiple movies on a sin-

gle disc. If, for example, one disc contains

three separate movies, they are divided into

title 1, title 2 and title 3. This lets you enjoy the

convenience of title search and other func-

tions.

VBR

VBR is short for variable bit rate. Generally

speaking CBR (constant bit rate) is more

widely used. But by flexibly adjusting the bit

rate according to the needs of audio compres-

sion, it is possible to achieve compression-

priority sound quality.

WMA

WMA is short for Windows Media™Audio

and refers to an audio compression technol-

ogy that is developed by Microsoft

Corporation. WMA data can be encoded by

using Windows Media Player version 7 or

later.

Windows Media and the Windows logo are tra-

demarks or registered trademarks of Microsoft

Corporation in the United States and/or other

countries.

Additional Information

100

Appendix

Specifications

General

Power source ............................. 14.4 V DC (10.8 V to 15.1 V

allowable)

Grounding system ................... Negative type

Max. current consumption

..................................................... 10.0 A

Dimensions (W × H × D):

DIN

Chassis ..................... 180 mm × 50 mm × 165

(7-1/8 in. × 2 in. × 6-1/2 in.)

Nose ........................... 188 mm × 58 mm × 33 mm

(7-3/8 in.× 2-1/4 in.× 1-1/4

in.)

Chassis ..................... 178 mm × 50 mm × 165

(7 in.× 2 in.× 6-1/2 in.)

Nose ........................... 170 mm × 46 mm × 28 mm

(6-3/4 in.× 1-3/4 in.× 1-1/8

in.)

Weight .......................................... 2.4 kg (5.3 lbs)

Display

Screen size/aspect ratio ....... 7.0 inch wide/16:9

(effective display area: 154

× 87 mm)

Pixels ............................................. 336 960 (1 440 × 234)

Display method ........................ TFT active matrix, transmis-

sive type

Color system .............................. NTSC

Durable temperature range (power off)

..................................................... -4 °F to +176 °F

Angle adjustment .................... 50° to 110°

(initial settings: 90°)

Audio

Maximum power output ....... 50 W × 4

50 W × 2/4 W+ 70 W × 1/2

W(for subwoofer)

Continuous power output ... 22 W × 4 (50 Hz to 15 000

Hz, 5 % THD, 4 Wload, both

channels driven)

Load impedance ...................... 4 Wto 8 W×4

4Wto 8 W×2+2W×1

Preout max output level ....... 4.0 V

Equalizer (3-Band Parametric Equalizer):

Low

Frequency ................ 40/80/100/160 Hz

Q Factor .................... 0.35/0.59/0.95/1.15 (+6 dB

when boosted)

Gain ............................ ±12 dB

Mid

Frequency ................ 200/500/1k/2k Hz

Q Factor .................... 0.35/0.59/0.95/1.15 (+6 dB

when boosted)

Gain ............................ ±12 dB

High

Frequency ................ 3.15k/8k/10k/12.5k Hz

Q Factor .................... 0.35/0.59/0.95/1.15 (+6 dB

when boosted)

Gain ............................ ±12 dB

HPF:

Frequency .......................... 50/63/80/100/125 Hz

Slope .................................... –12 dB/oct

Subwoofer (mono):

Frequency .......................... 50/63/80/100/125 Hz

Slope .................................... –18 dB/oct

Gain ...................................... +6 dB to –24 dB

Phase .................................. Normal/Reverse

Bass boost:

Gain ...................................... +12 dB to 0 dB

DVD Player

System .......................................... DVD video, Video CD, CD,

WMA, MP3, AAC, DivX sys-

tem

Usable discs .............................. DVD video, Video CD, CD,

CD-R/RW, DVD-R/RW/RDL

Region number ........................ 1

Frequency response ............... 5 Hz to 44 000 Hz (with DVD,

at sampling frequency 96

kHz)

Signal-to-noise ratio ............... 96 dB (1 kHz) (IHF-A net-

work) (RCA level)

Output level:

Video .................................... 1.0 Vp-p/75 W(±0.2 V)

Number of channels .............. 2 (stereo)

MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3

WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11 (2ch

audio)

(Windows Media Player)

AAC decoding format ............ MPEG-4 AAC (iTunes en-

coded only) (.m4a)

(Ver. 8.0 and earlier)

DivX decoding format ............ Home Theater Ver. 3, 4, 5.2

(.avi, .divx)

USB

USB standard specification

..................................................... USB 2.0 full speed

Maximum current supply .... 500 mA

USB Class ................................... MSC (Mass Storage Class)

File system .................................. FAT16, FAT32

MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3

Additional Information

En 101

Appendix

Additional Information

WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11 (2ch

audio)

(Windows Media Player)

AAC decoding format ............ MPEG-4 AAC (iTunes en-

coded only) (.m4a)

(Ver. 8.0 and earlier)

WAV signal format .................. Linear PCM & MS ADPCM

(Non-compressed)

FM tuner

Frequency range ...................... 87.9 MHz to 107.9 MHz

Usable sensitivity ..................... 9 dBf (0.7 µV/75 W, mono,

S/N: 30 dB)

Signal-to-noise ratio ............... 72 dB (IHF-A network)

AM tuner

Frequency range ...................... 530 kHz to 1 710 kHz (10

kHz)

Usable sensitivity ..................... 25 µV (S/N: 20 dB)

Signal-to-noise ratio ............... 62 dB (IHF-A network)

CEA2006 Specifications

Power output ............................. 14 W RMS × 4 Channels (4

Wand ≦1 % THD+N)

S/N ratio ....................................... 91 dBA (reference: 1 W into

4W)

Note

Specifications and the design are subject to mod-

ifications without notice due to improvements.

Additional Information

102

Appendix

Angle icon ..................................................26,.39

Aspect ratio ...............................................39,.98

Audio language .........................................26,.38

Bookmark .........................................................25

Brightness ........................................................45

Chapter .............................................................98

Code number ...................................................40

Color .................................................................45

Contrast ............................................................45

DivX ...................................................................98

DivX Certified ...................................................98

Dolby Digital ..............................................11,.98

Dolby Pro Logic II ...........................................98

DTS .............................................................11,.98

Dynamic range control ..................................98

Hue ...................................................................45

Language code chart .....................................97

Linear PCM (LPCM) ........................................99

Menu language ...............................................39

MPEG ................................................................99

Multi-angle .................................................26,.99

Multi-audio .................................................26,.99

Multi-subtitle ..............................................26,.99

Optical digital output/input ...........................99

Parental lock ..............................................40,.99

PBC (playback control) ..................................22

Playback control (PBC) ................................100

Region number .........................................9,.100

Subtitle language ......................................26,.38

Title .................................................................100

TV aspect ..........................................................39

Video CD ............................................................9

Wide screen mode ..........................................45

Index

En 103
