Pirelli DP L10 User Manual To The 46a717de 424b 44a6 A65d 74cb19a7b649

User Manual: Pirelli DP-L10 to the manual

Open the PDF directly: View PDF .
Page Count: 131 [warning: Documents this large are best viewed by clicking the View PDF Link!]

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Network Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Shared Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Access codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

1. Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

1.1 Installing the SIM Card and the Battery. . . . . . . . . . . . . . . . . . . . . . .17

1.2 Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

1.3 Power on / off the Phone Device. . . . . . . . . . . . . . . . . . . . . . . . . . . .19

1.4 Installation and use of the CHARGER CRADLE. . . . . . . . . . . . . . . .20

1.5 Alphabetic and numeric keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

1.6 Camera Lens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

1.7 MMS, WAP and E-mail SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

1.8 How to select the preferred network . . . . . . . . . . . . . . . . . . . . . . . . .26

1.9 Keypad basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

1.10 Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

1.11 How to Use Scroll and Direction Keys. . . . . . . . . . . . . . . . . . . . . . . .28

1.12 How to input text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

1.13 Phone USER INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

1.13.1 Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

1.14 Popup windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

2. Idle Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2.1 Status indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

2.2 Signal bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

2.3 Mobile operator name and WLAN network name . . . . . . . . . . . . . . .34

2.4 Soft notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

2.5 Active profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

2.6 Time & Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

2.7 Soft keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

2.8 Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

2.9 Power Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

3. Call Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3.1 Making A Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

3.1.1 Making A Call Using the Contacts . . . . . . . . . . . . . . . . . . . . .38

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents0

3.1.2 Last Number Redialing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

3.1.3 Calling Your Voice Mailbox . . . . . . . . . . . . . . . . . . . . . . . . . .38

3.2 Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

3.2.1 Navigation Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

3.3 Answering or rejecting an incoming call . . . . . . . . . . . . . . . . . . . . . .39

3.3.1 Single call connected mode. . . . . . . . . . . . . . . . . . . . . . . . . .39

3.3.2 Multi call connected mode . . . . . . . . . . . . . . . . . . . . . . . . . . .40

3.4 Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

3.5 Multi Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

4. Menu Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

4.1 Accessing A Menu Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

4.1.1 By Navigating the Direction Key. . . . . . . . . . . . . . . . . . . . . . .45

4.1.2 By Using a shortcut (camera, name) . . . . . . . . . . . . . . . . . . .45

4.2 List of Menu Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

4.2.1 Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4.2.2 Call History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

4.2.3 Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

4.2.4 WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

4.2.5 WAP Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4.2.6 Voice Mail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4.2.7 Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4.2.8 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4.2.9 Organizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4.2.10 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4.2.11 Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

5. Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.1 Short Message Service (SMS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

5.1.1 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

5.1.2 Writing and Sending Messages . . . . . . . . . . . . . . . . . . . . . . .53

5.1.3 Draft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

5.1.4 Outbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

5.1.5 Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

5.1.6 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

5.1.7 Memory Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

5.2 Multimedia Message Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

5.2.1 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

5.2.2 Write Message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

5.2.3 Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

5.2.4 Sent items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

5.2.5 Draft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

5.2.6 MMS Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

5.2.6.1 Change active settings. . . . . . . . . . . . . . . . . . . . . . .60

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents

5.2.7 Memory Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

5.3 E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

5.3.1 Configuring a new E-mail account . . . . . . . . . . . . . . . . . . . . .63

5.4 Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

5.4.1 Dial Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

5.4.2 Set Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

5.5 Cell broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

5.5.1 Inbox settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

5.5.2 Reading messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

5.5.3 Add a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

5.5.4 Channel lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

6. Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

6.1 Missed Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

6.2 Received Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

6.3 Dialed Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

6.4 Delete all call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

6.5 Call timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

7. Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

7.1 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

7.2 Add New Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

7.3 Group Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

7.4 Speed Dial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

7.5 Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

7.6 My Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

8. WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.1 WLAN status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

8.2 WLAN settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

8.2.1 Select WLAN Profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

8.2.2 WLAN Access Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

8.2.3 WLAN profile rename. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

8.3 SIP status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

8.4 SIP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

8.5 NAT Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

8.5.1 RPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

8.5.2 STUN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82

9. WAP Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

9.1 Configuring a new WAP account. . . . . . . . . . . . . . . . . . . . . . . . . . . .84

10. Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents0

10.1 Dial Voice Mail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

10.2 Set Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

11. Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

12. Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

12.1 Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

12.2 Preferred Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

12.3 Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

12.4 GPRS setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

12.4.1 GPRS Attached . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

12.4.2 Data Count. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

12.4.3 GPRS Attach or Detach. . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

12.5 Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

12.5.1 Ring Tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

12.5.2 SMS and Alarm tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

12.5.3 Keypad tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

12.5.4 Power On/Off, WLAN, Battery alert . . . . . . . . . . . . . . . . . . . .92

12.6 Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

12.6.1 Wallpaper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

12.6.2 Backlight Timer and Backlight Level . . . . . . . . . . . . . . . . . . .93

12.7 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

12.8 Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

12.8.1 Answering mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

12.8.2 Auto redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

12.8.3 Incall timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

12.8.4 Call summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

12.9 Network Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

12.9.1 Call Divert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

12.9.2 Call Barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

12.9.3 Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

12.9.4 Network Select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

12.9.5 Band Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

12.9.6 Number Transmitted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

12.10 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

12.11 Auto Key Guard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

12.12 Restore Factory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

13. Organizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

13.1 Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

13.2 When the alarm time expires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

13.3 Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

13.4 To-do list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents

13.5 Scheduled Power on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

14. Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

14.1 Games. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

14.1.1 Launch a game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

14.1.2 Tone and Background Music . . . . . . . . . . . . . . . . . . . . . . . .106

14.2 Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

14.3 Currency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107

14.4 Stop watch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107

14.5 Count Down. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

14.6 World Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

15. Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

16. Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . 111

16.1 Information on the batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

16.2 Product care guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

17. Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

17.1 Certification information (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . .116

FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

A.1 Frequently Asked Questions and Troubleshooting Guide. . . . . . . .117

A.2 Configuration troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Table of Contents0

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Introduction

Please read the following notices before installing or using your mobile device.

Read the installation instructions before connecting the system to the power

source.

Icons shown in this document have the following meaning:

Warning:

Remind you to be very cautious when you use certain functions or make

certain setup for they may cause harm if you are not handling it with care.

Forbidden:

Do not do it. It is extremely dangerous.

Information:

Additional information or tips to certain functions are provided to help you learn

more about the products.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter0

Safety Information

Medical devices

Operation of any radio transmitting equipment, including wireless phones, may

interfere with the functionality of inadequately protected medical devices.

Consult a physician or the manufacturer of the medical device to determine if

they are adequately shielded from external RF energy or if you have any

questions. Switch off your device in health care facilities when any regulations

posted in these areas instruct you to do so. Hospitals or health care facilities

may be using equipment that could be sensitive to external RF energy.

Warning:

Ultimate disposal of this product should be handled according to the applicable

national laws and regulations.

Do not work on the system or connect or disconnect cables during periods of

lightning activity.

There is the danger of explosion if the battery is replaced incorrectly. Replace

the battery only with the same or equivalent type recommended by the

manufacturer. Dispose of used batteries according to the manufacturer’s

instructions.

Before using the telephone, carefully read the “warnings” contained in Care

and maintenance chapter. Contact the Client Assistance Center nearer to you

for further information.

Do not place credit cards or other magnetic storage media near the device,

because information stored on them may be erased.

Your phone may cause TV or radio interference (for example, when using a

telephone in close proximity to receiving equipment). The FCC or Industry

Canada can require you to stop using your telephone if such interference

cannot be eliminated. If you require assistance, contact you local service

provider.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 15.3

centimeters (6 inches) be maintained between a wireless phone and a

pacemaker to avoid potential interference with the pacemaker. Persons with

pacemakers should do the following:

•Always keep the device more than 15.3 centimeters (6 inches) from the

pacemaker

•Not carry the device in a breast pocket

•Hold the device to the ear opposite the pacemaker to minimize the poten-

tial for interference.

•If you suspect interference, switch off your device, and move the device

away.

Hearing aids

Some digital wireless devices may interfere with some hearing aids. If

interference occurs, consult your service provider.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic

systems in motor vehicles such as electronic fuel injection systems, electronic

antiskid (antilock) braking systems, electronic speed control systems, and air

bag systems. For more information, check with the manufacturer, or its

representative, of your vehicle or any equipment that has been added.

Only qualified personnel should service the device, or install the device in a

vehicle. Faulty installation or service may be dangerous and may invalidate

any warranty that may apply to the device. Check regularly that all wireless

device equipment in your vehicle is mounted and operating properly. Do not

store or carry flammable liquids, gases, or explosive materials in the same

compartment as the device, its parts, or enhancements. For vehicles equipped

with an air bag, remember that air bags inflate with great force. Do not place

objects, including installed or portable wireless equipment in the area over the

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter0

air bag or in the air bag deployment area. If in-vehicle wireless equipment is

improperly installed, and the air bag inflates, serious injury could result.

Potentially explosive environments

Switch off your device when in any area with a potentially explosive

atmosphere, and obey all signs and instructions. Potentially explosive

atmospheres include areas where you would normally be advised to turn off

your vehicle engine. Sparks in such areas could cause an explosion or fire

resulting in bodily injury or even death. Switch off the device at refueling points

such as near gas pumps at service stations. Observe restrictions on the use

of radio equipment in fuel depots, storage, and distribution areas; chemical

plants; or where blasting operations are in progress. Areas with a potentially

explosive atmosphere are often, but not always, clearly marked. They include

below deck on boats, chemical transfer or storage facilities, vehicles using

liquefied petroleum gas (such as propane or butane), and areas where the air

contains chemicals or particles such as grain, dust, or metal powders.

Children

Do not allow children to play with the device or its accessories. The device and

its accessories contain small parts that may detach and become a choking

hazard.

Emergency calls

Note: some networks may require that a valid SIM card is properly inserted in

the device.

EXPORT restrictions

This device may contain technology or software subject to export laws and

regulations from the US and other countries. Diversion contrary to law is

prohibited.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

General Information

This WLAN/ GSM Dual mode phone supports both GSM 900/1800/1900 and

VoIP call via Wi-Fi 802.11b/g (WLAN at 2.4GHz).

The Dual mode phone allows users to make or receive phone calls as long as

they are in the coverage of IEEE 802.11b or 11g wireless Access Points.

The Dual mode phone described in this guide is approved for use on the GSM

900/1800/1900 network. Contact your service provider if you wish to learn

more about the networks.

Network Service

To use the phone you must have service from a wireless service provider.

Many of the features in this phone depend on features in the wireless network

to function. These network services may not be available on all networks or

you may need to make special arrangements with your service provider before

you can use the network services. Your service provider may need to give you

additional instructions for their use and explain what charges will apply. Some

networks may have limitations that affect how you can use Network Services.

For example, some networks may not support all language-dependent

characters and services.

Your service provider may request that certain features be disabled or not

activated in your device. If so, they will not appear in your device menu.

Contact your service provider for further information.

The Dual mode phone described in this guide is approved for use on the GSM

900/1800/1900 network. Tri-band is a network-dependent feature. Check with

your local service provider if you can subscribe to and use this feature.

This phone supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP

protocols. Some features of this phone, such as MMS (Multimedia Messaging

Service), browsing, e-mail, instant messages, and music downloading via

browser or over MMS, require network support for these technologies.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter0

Shared Memory

The following features in this device may share memory: contacts, text

messages (SMS and MMS), WAP (download and cache), ring tones, calendar,

and gallery (camera images, sounds, and misc.). Use of one or more of these

features may reduce the memory available for the remaining features sharing

memory. Your phone may display a message that the memory is full when you

try to use a shared memory feature. In this case, delete some of the

information or entries stored in the shared memory features before continuing.

Get Help

If you need help, Customer Service Center is available for assistance. Before

contacting us, please have your Internal Mobile Identification Number (IMEI)

available so that we may retrieve relevant information to help you. You may

find the IMEI label in the battery compartment or on the giftbox label.

Access codes

1 PIN and PIN2 codes (4 to 8 digits)

•The PIN (Personal Identification Number) code protects your SIM card

against unauthorized use.

•The PIN code is usually supplied with the SIM card. Set the phone to

request the PIN code each time the phone is switched on.

•The PIN2 code may be supplied with the SIM card (GSM phase II).

This code controls access to some of the more advanced features of

the phone (for example: fixed dialing lists a restricted list of numbers

the phone can call, which is handy if you lend the phone to a kid). The

default code is set by the service provider, but you are able to change

this code.

If you key in an incorrect PIN code three times in succession, the phone may

display PIN blocked or PIN code blocked, for example, and ask you to enter

the PUK code. You will need to require a PUK code from your network/service

provider before you can resume the receiving/making calls and reading text

functions.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

2 PUK and PUK2 codes (8 digits)

PUK stands for Personal Unblocking Key. If you have entered your PIN code

incorrectly 3 times, your SIM card will be blocked and you will be unable to

make and receive calls/text. The PUK code is required to change a blocked

PIN, and the PUK2 code is required to change a blocked PIN2 code. If the

codes are not supplied with the SIM card, contact your local service provider

for the codes. If the PUK code is entered 10 times incorrectly, the card is

permanently disabled and the SIM card has to be changed.

3 Barring password

The 4-digit barring password is required when using the Call barring service.

You can obtain the password from your service provider.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter0

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

1. Getting started

1.1 Installing the SIM Card and the Battery

Keep all miniature SIM cards out of the reach of small children.

The SIM card and its contacts can easily be damaged by scratches or bending,

so be careful when handling, inserting or removing the card.

Before installing the SIM card, always make sure that the phone is switched

off and disconnected from any enhancement and then remove the battery.

To remove the back cover of the

phone: With the back of the phone

facing you, push the back cover

release button.

The SIM card and its contents can be

easily damaged by scrathes or in case

it is bent. So, be careful when slide the

back cover to remove it from the

phone.

Remove the battery by lifting it as

shown.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

Insert the SIM card into the SIM card

holder. Make sure that the SIM card is

properly inserted and that the golden

contact area on the card is facing

downwards.

To release the SIM card, simply pull it

out from the holder.

Replace the battery (7).

Slide the back cover into its place (8).

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

1.2 Charging the battery

Connect the lead from the charger to

the mini USB port on the bottom of

your phone.

Connect the charger to an AC wall

socket. If the battery is completely flat,

it may take a few minutes before the

charging indicator appears on the

display or before any calls can be

made.

The charging time depends on the

charger and the battery used. It takes

approximately two hours while the

phone is in idle mode. It requires at

least 8 hours if the battery is first

charged.

You can use the phone while the

charger is connected.

If included in the package, you can use

the cradle accessory to keep the

phone constantly under charge.

1.3 Power on / off the Phone Device

Press the red key and hold it for 5

seconds to switch on the phone

device. To turn off, follow the same

step.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

1.4 Installation and use of the CHARGER CRA-

DLE

If included in your package, the cradle accessory can be used to keep the

phone constantly under charge.

Cradle charger: front view Cradle charger: rear view

Plug the power adapter’s mini-USB male connector into the female connector

on the back of the cradle as shown in the figure below.

When placing the handset into the cradle, slide the phone fully downwards

until the handset remain firmly blocked (this indicates that the phone connector

is fully mated inside the cradle, and the “Charging” message is displayed); if

this is not the case, the phone may not be charged.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

To detach the handset from the cradle, keep the cradle in place with one hand

and gently pull the handset with the other hand.

Warning:

Do not tilt or flex the handset when inserting / extracting it from the cradle

because this could damage the handset’s connector.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

Phone Device and Key Pad

1.5 Alphabetic and numeric keys

Nr. Key name Ic. Descrip.

1 Receiver

2 Screen

3Right soft key

4Red Key Power

on/off;

Cancel;

5Alphabetic

and numeric

keys

6 Microphone

7 Scroll up and

down key, shift

right and left key

8OK Key Confirma-

tion OK;

Middle soft

key

9 Green Key Answer

10 Left soft key

Recorder sign 2

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

Bell sign

+ sign

Keylock sign

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

* input method change sequence: abc, ABC, Zi-Abc, Zi-abc, Zi-ABC, and 123

Short press sequence Long press

Green key Answer calls, dial

numbers, access

dialed number list

Red key Exit menu to idle mode, end calls Power on/off;

Cancel

Short press

(Idle Mode)

Short press

sequence

(lower case)

Short press

sequence

(capital case)

Long press

(Idle mode)

1. , ' ? ! & / @ : 1

2a, b, c, 2, ä, à, â, ã,

á, ç A, B, C, 2, Ä, À, Â,

Ã, Á, Ç

3d, e, f, 3, €, è, é, ë, ê D, E, F, 3, €, È, É, Ë,

4g, h, i, 4, ï, î, ì, í G, H, I, 4, Ï, Î, Ì, Í

5j, k, l, 5, £ J, K, L, 5, £

6m, n, o, 6, ö, ô, ò, ó,

ñM, N, O, 6, Ö, Ô, Ò,

Ó, Ñ

7p, q, r, s, 7, $, ß P, Q, R, S, 7, $, ß

8t, u, v, 8, ü, û, ù, ú T, U, V, 8, Ü, Û, Ù, Ú

9w, x, y, z, 9 W, X, Y, Z, 9

*. , ? ! @ : ; - + # * ( ) '

" _ & % / < > = $ £ € Mute/

unmute

00 <space> +

# # <input method

change> Keypad lock/

unlock

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

1.6 Camera Lens

Camera lens is on the back of the

phone device.

The mirror is useful to take a picture of

yourself.

1.7 MMS, WAP and E-mail SETUP

To utilize the data services of MMS, WAP and E-mail, the phone needs to be

configured with parameters that are specific for each mobile service provider.

The phone already includes a number of pre-set configurations related to the

prevalent mobile operators’ service profiles. To find and select the one

corresponding to your subscription, look for it through the following sequence:

For MMS:

OK Key (Menu) > OK Key (Messages) > Scroll down > OK

Key (MMS) > Scroll up (two times) > OK Key (MMS Settings)

>OK Key (Connection Settings) > OK Key (Active Settings)

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Press Select to activate the service profile corresponding to your subscription.

If your subscription profile is not among the pre-set ones, please make sure

you get the necessary parameters values from your mobile service provider

and refer to chapter 5 of this guide to configure your specific settings.

For E-MAIL:

OK Key (Menu) > OK Key (Messages) > Scroll down (two

times) > OK Key (E-mail) > Scroll up > OK Key (Settings) >

OK Key (Active Settings)

Press Select to activate the service profile corresponding to your subscription.

If your subscription profile is not among the pre-set ones, please make sure

you get the necessary parameters values from your mobile service provider

and refer to chapter 5 of this guide to configure your specific settings.

For WAP:

OK Key (Menu) > Scroll down > Shift right > OK Key

(WAP) > Scroll up (Settings) > OK Key (Profile) > OK Key

(Active Settings)

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

Press Select to activate the service profile corresponding to your subscription.

If your subscription profile is not among the pre-set ones, please make sure

you get the necessary parameters values from your mobile service provider

and refer to page of this guide to configure your specific settings.

1.8 How to select the preferred network

The preferred network setting allows you to select the network, WLAN or

GSM.

OK Key (Menu) > Scroll down (two times) > Shift right > OK Key

(Settings) > Scroll down > OK Key (Preferred Network)

•GSM only - the next call will go via GSM. Call will not be dialed out if GSM

network is not available.

•WLAN only - the next call will go via WLAN. Call will not be dialed out if

WLAN network is not available.

•GSM preferred - the next outgoing call will go via GSM network unless

you manually select call via WLAN for the call.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

•WLAN preferred - the next outgoing call will go via WLAN unless you

manually select call via GSM for the call.

1.9 Keypad basics

This guide uses certain terms for the steps that you are asked to perform:

•“Press” means to press and release a key quickly. For example, press 5

means press the key on the keypad that is marked with the number 5 and

the letters “JKL” ( ).

•Press the numeric key once to enter the first character on a key. Press it

twice to enter the second character and so on and so forth.

•“Press and hold” means to press and hold a key for 2-3 seconds, then

release the key.

•: Soft keys are used to select a menu option. To select an option,

press the soft key below the menu item on the phone screen.

•: This 4-way navigation key includes left, right, up and down four

directions. The 4-way navigation and soft key is also used to move the

cursor up and down, left and right when writing text, using the calendar,

and in some game applications.

• : Press the Green key to place a call or to answer an incoming call.

• : Press the Red key to end a call or press and hold to return to the

idle screen.

•When creating messages, press pound key to switch between

uppercase, lowercase, digit, and Zi text (smart entry modes). The sign of

different mode appears at the top-left corner of the screen to indicate the

mode.

•To enter space between characters, press .

•Press start to display the symbol table. Use the four-way directions

to select the desired symbol and press OK Key to insert the symbol

into your text.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

1.10 Menus

Features of the phone are grouped according to the functions and are

accessed through the main menus. Each main menu contains submenus,

which you can make use of and customize your own features. You can access

these menus and submenus by using the scroll and direction keys.

1.11 How to Use Scroll and Direction Keys

•At the start screen, press OK key key to enter into the “Menu”. Press

the scroll and direction key to browse through each submenu.

•When you arrive at a submenu, press OK key to enter into the sub-

menu.

•Press right select key from the submenu level to return to the previ-

ous menu. Keep pressing right select key to return to the start

screen.

1.12 How to input text

The text input modes can be categorized into alphabetical mode and

numerical mode. Alphabetical modes are used to input characters and

numerical mode is used to input numbers. There are two ways to input

characters: Traditional multi-tap method and predictive input (Zi).

You can change the key-in method (options from ABC, Zi text, 123, to Symbol)

by pressing the pound key. The keypad of stands for space bar

while keying in message.

The text editor can be classified according to the purpose and input mode:

•Message editor

- Full screen with background picture.

- With input method indicator.

- A small area for displaying scroll bar is reserved beyond the editor

area at the right of screen.

- Show scroll bar if input content length is over one page.

- Examples: write SMS, E-Mail letter, and MMS .

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

•Non-scroll editor

- Full screen with background picture.

- With input method indicator.

- No space is reserved for scroll bar; the whole window body is reserved

for editor.

- The input content is not allowed to overstep one page.

- Examples: input filename, input mobile phone number in phonebook.

VoIP settings.

•Hidden input editor (password)

- Not full screen, normally within one page; the size of rectangle

depends on the expected length of input.

- The input is hidden.

- Example: PIN/PIN 2 code, PUK/PUK 2 code.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

1.13 Phone USER INTERFACE

1.13.1 Icons

Icon Definition

Battery low. Remind you the phone is running out of

power.

Power charge OK.

Power is charging. The icons show when the phone

is charging power. When the power is fully charged,

the power charge OK icon as shown above

appears.

Battery level. The higher the bar, the more power is

left in the battery.

Alarm Clock

Alarm is set.

GPRS function is activated.

Keylock. The phone keypad is locked.

MMS. Multimedia message service.

Short Message Service. Remind you have got a

short message in the SMS inbox.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Voice mail. Remind you have got a voice message

in the voice mailbox.

Confirm

Error

Incoming short message

Information

Invalid card

Missed call

SMS, MMS or e-mail sending in progress.

Requesting for network service.

Warning, wrong operation or Memory is full.

The phone is using GSM-based network.

The phone is using WLAN-based network.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter1

1.14 Popup windows

It uses the pop-up notes to inform the user the current activities of the phone,

network, or mobile service without requiring any user action, with exception of

a user response note. Notes typically disappear automatically after 2 seconds

timeout period except waiting notes, progressing notes, and confirmation

notes.

There are several types of popup window:

•Error Notes:

Inform the user something is wrong.

•Waiting Notes:

Inform the user to wait until an operation is completed. User is able to

cancel the operation by pressing red key . The waiting note should

be displayed if the processing time is more than 2 seconds.

•Warning Notes:

Inform the user about an error event, or a situation that may cause harm

to the user, for example, “Call failed”, “Battery low”.

•Information Notes:

Inform the user about the state of the phone, network, or application, e.g.,

“Call timer: x”, “Call cost: x”.

•Confirmation Notes:

Notify the user of successful actions if there is no other indication about

the accomplished operation, e.g., “Keypad is unlocked”.

•Permanent Notes:

They cannot be interrupted by the user with key presses. They stay on the

display until dismissed by the phone, e.g., “Invalid card”.

•Confirm Queries:

A Confirm Query is used when the UI requires the user’s confirmation for

proceeding with an operation. It forces the user to choose between

accepting and declining an operation.

•Progressing:

The progress control shows the user about the progress of the operation,

it provides an option for the user to interrupt the operation. It can be used

for provisioning and downloading.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

2. Idle Mode

When the phone is ready for use, and you have not keyed in any characters,

the phone is in idle mode. The following items appear on the idle screen of the

mobile phone during the idle mode.

2.1 Status indicator

Status icons include:

Call connected

Key-guard is enabled

GPRS indicator

MMS received

SMS received

Stopwatch

Countdown

Alarm ON

Battery

2.2 Signal bar

Signal bar indicates the strength of the received signals. It is represented with

6 levels. (GSM/WLAN) GSM at left side, WLAN at right side. At the bottom of

each signal bar, an icon marked with either G ( ) or W () indicates the

current active network. An active network is the network that the next outgoing

call will go through. It also means that the phone will smartly decide which

network should be “active” depending on the strength of the signal and the

preference of the network set by the user.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter2

WLAN active GSM active

2.3 Mobile operator name and WLAN network

name

Operator and WLAN network name will both display in the idle mode when

user selects GSM preferred or WLAN preferred in Settings/Preferred network.

In WLAN preferred mode, the WLAN network name will be shown above the

GSM operator name. The “active” network will be shown in boldface.

In GSM preferred mode, the GSM operator name will be shown above the

WLAN network name. The “active” network will be shown in boldface.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

En modo WLAN solo o en GSM solo, se muestra una sola barra de señal,

correspondiente al nombre WLAN o al nombre del proveedor de GSM.

GSM only WLAN only

2.4 Soft notifications

In WLAN only or GSM only mode, there will be only one signal bar displayed,

mapping its corresponding WLAN name or GSM operator name.

Missed calls Messages received

2.5 Active profile

The selected profile, General/Silent/Meeting/Outdoor/User1/User2, from

Settings/Profile is show in the middle of the main zone.

2.6 Time & Date

It shows the current time, date and the weekday using the format set in

Settings/Clock/Date display and Time Format.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter2

2.7 Soft keys

The left soft key in idle mode is a shortcut to Camera.

Press OK Key to take a picture. Press left soft key (Options) to enter

Options page, and set the Effect, Size, Quality, Self timer, Shutter sound of the

picture in this page.

OK Key in idle mode is the shortcut key to enter Menu.

The right soft key in idle mode is Names to access the Contacts/

Phonebook.

2.8 Wallpaper

You can select different wallpaper from Settings/Display/Wallpaper, and can

also select images from the Gallery which were captured to set as a wallpaper.

2.9 Power Saving

For power saving, the screen is turned off when no function of the phone has

been used for a certain period of time. You can set the backlight off time (10/

20/30/60 seconds) in Settings/Display/Backlight timer.

Press any key to turn the screen back on.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

3. Call Functions

This chapter explores how to make a call, how to answer/reject a call, and the

functions available during a call.

3.1 Making A Call

To make a phone call, key in the phone number, including the area code, and

press green Key to call the number. If you key in an incorrect character,

press right soft key (Delete) to delete it.

For international calls, press the international access code (it varies according

to the service provider) and then key in the country code, the area code without

the leading 0, if necessary, and the phone number, and then press green Key

to call the number.

Press red Key to end a call or to cancel the call attempt.

You can always use the left soft key (Options) to select the network for

the outgoing call if both GSM and WLAN network are available and you wish

to use the network other than the preferred one.

•In the following case, WLAN mode is active, the next outgoing call will be

out via WLAN.

•Digit number entry. Press Green key .

•You can press left soft key (Options) to select “Call via GSM” to

route the outgoing call to GSM network.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter3

Digit number Select “Options” Outgoing call

3.1.1 Making A Call Using the Contacts

To search for a name/phone number that you have saved in Contacts, press

right soft key (Names) to quick access the phonebook and select the one

you want to call, and press Green key to call the number using the active

network, or select left soft key (Options) to select the network to use if

both GSM and WLAN are available. See Contact chapter for more information.

3.1.2 Last Number Redialing

In idle mode, press Green key once to access the list of numbers you last

called or attempted to call. Scroll to the number or name you want, and press

Green key to call the number.

3.1.3 Calling Your Voice Mailbox

In idle mode, long press keypad to call the voice mailbox. If the phone

asks to set voice mail, please key in the voice mail box number provided by

service provider and press OK key .

3.2 Speed Dialing

Before you can use speed dialing, assign a phone number, from to

, to one of the speed-dialing keys. Call the number in either of the

following ways: is reserved for voice mail, while to can

be set up for speed dialing.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

If Speed dialing is set to on, press and hold a speed-dialing key until the call

is started.

3.2.1 Navigation Key

By default, the Left navigation key is the shortcut to SMS message writing.

Press it and you are directly led to the text writing screen under Message

>SMS> Write Message.

The Right navigation key is the shortcut for connecting to WLAN AP.

The Down navigation key is the shortcut for the phone book access.

Press the key to directly search for the contact person you want.

Press Up navigation key is the shortcut for WAP service directly.

For more information on how to set up the speed dial function, see Contacts >

Speed Dial.

3.3 Answering or rejecting an incoming call

Press Green key or OK key to answer an incoming call, and press

Red key to end the call.

Press Red key to reject an incoming call.

If a compatible headset supplied with the headset key is connected to the

phone, you can answer and end a call by pressing the key.

There are two cases in call connected, single call connected and multi call

connected.

3.3.1 Single call connected mode

a) Single in GSM, GSM active and GSM currently connected

b) Single in GSM, WLAN active and GSM currently connected

c) Single in WLAN, WLAN active

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter3

(a) (b) (c)

In the single connected mode, there are 4 elements in the main zone, including

signal bar, call state icon, name / number of the remote side, and call timer.

On line Hold Muted

In the single call connected mode, you can press left soft key (Options)

to hold or mute the call: by holding the call, the two remote sides can’t hear

each other (middle picture above); by muting the call, you can hear the remote

side while the remote side can’t hear you.

3.3.2 Multi call connected mode

During a call, the user can accept another incoming call or make another

outgoing call. In this case, the screen will be in multi-connected mode. As in

the following example, with one call active, and the other on hold, the user can

also combine two GSM calls into one conference call, as shown in later

section.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

A connected call can accept any incoming calls; the user can also make a new

call in connected mode. DP-L10 would auto make 2 calls into multi-connected

mode, one call is on line, another on hold, unless user makes two GSM calls

into one conference call.

a) Two GSM calls in multi mode

A GSM connected call > Alan incoming > 2 GSM > multi-call > Green key

to Swap call >mute

Reject a call will show the Call end on Pop-up window

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter3

b) Two GSM calls merged into one conference call (please note that your

service provider may not support this service).

1. User can merge two GSM calls to a conference call by selecting “start

conference” in the options lists.

2 GSM calls swap the call conference call

2. User can also privatize any call from either call in a conference, by

selecting “Private Calls”:

Information:

1. If the loud speaker is already turned on, and a new incoming call is

accepted, the phone would still keep loud speaker on.

2. The newly accepted call will be the activated one and the first call will be

put on hold.

3. If a third incoming call is accepted, the third call will make the active call

hang on in multi-call. On hold call will be still on hold. The current “active

call” will be terminated, the call on hold will still be on hold and the third

incoming call will be the active call.

4. The active call will be terminated if the user presses the “End key”.

Pressing ”End key” in multi-call, the active call will be hung on.

5. If the user wants to swap the “active” and the “on hold” calls, the user can

simply press “Send key”, or select the swap item in Options. Within 2 calls,

only press “ Send key” to swap them, or select swap item in options lists.

6. In muted mode, the user still can do call control, like swap or hold.

7. In call connected mode, if user presses “end all calls”, DP-L10 will notify

the user of the call time of the last call, then it will go back to Idle mode.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

A conference Private call

c) A GSM conference and a WLAN call (Different net)

d) 1 GSM call and 1 WiFi WLAN call on line

In this case if any new GSM or WLAN incoming call is accepted by the

user, the active call will be terminated.

Case 01: Accept Incoming number via GSM

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter3

Case 02: Accept Incoming call via WiFi

3.4 Call Waiting

During a call, press Green key to answer the waiting call. The first call is

put on hold. Press Green key to swap the active/on-hold calls. Press Red

key to end the active call.

To activate the Call waiting function, see Settings > Network Service > Call

Waiting

3.5 Multi Calls

During a call, press Green key to answer the waiting call. The first call is

put on hold. Press Green key to swap the active/on-hold calls. Press Red

key to end the active call.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

4. Menu Functions

The phone offers you an extensive range of functions, which are grouped into

menus. Before you get into each of the functions of the menu, we will first

describe how to access each menu function.

4.1 Accessing A Menu Function

You can access a menu function by either scrolling the navigation direction

key, or pressing a key that has been setup as a shortcut.

4.1.1 By Navigating the Direction Key

•To access the menu, press OK key that represents the Menu.

•Scroll through the menu and select, for example, Message by pressing

OK key .

• If the menu contains submenus, scroll to the one that you want, for exam-

ple SMS, and press OK key .

•If the selected submenu contains further submenus, repeat step 3. Select

the next submenu, for example Write Message.

•Select the setting of your choice.

•Press right soft key (Back) to return to the previous menu level.

4.1.2 By Using a shortcut (camera, name)

•The right soft key (Names) is the shortcut to “Contacts” – same as

OK key > right navigation key (two times) > OK key

•The left soft key Camera is the shortcut to “Camera” – same as OK

key > down navigation key (two times) > OK key

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter4

4.2 List of Menu Functions

4.2.1 Messages

SMS MMS

•Inbox

•Write Message

•Draft

•Outbox

•Templates

•Settings

•Memory status

•Inbox

•Write message

•Outbox

•Sent items

•Draft

•MMS settings

•Memory status

E-mail Voice mail

•Create e-mail

•Retrieve

•Disconnect

•Inbox

•Other folders

•Memory status

•Settings

•Dial Voice Mail

•Set Voice Mail

Cell broadcast

•Receiving settings

•Read broadcast

•Add channel

•Channel list

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

4.2.2 Call History

4.2.3 Contacts

Missed calls Received calls

Dialed calls Delete all calls

•Missed calls

•Received calls

•Dialed calls

•Delete all

Call timers

•Last Call

•All Incoming

•All Outgoing

Search Add new

•Save to SIM

•Save to Phone

Group settings Speed Dial

Memory Status My number

•GSM

•VoIP

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter4

4.2.4 WLAN

WLAN status WLAN settings

•Active settings

•Edit act. settings

SIP status SIP settings

•User name

•Password

•Domain name

•Local port

•Proxy server

•Proxy port

•Register server

•Register port

•Register period

•Outbound server

•Outbound port

•RTP audio port

•RTP pkt. period

•Preferred codec

NAT settings

•RPORT

•STUN

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

4.2.5 WAP Service

4.2.6 Voice Mail

4.2.7 Camera

Homepage Bookmarks

Download links Go To Address

•http://www.

•http://wap.

•Other

Service inbox Settings

•Profile

•Security Settings

•Service Inbox

•Immage display

•Cache

•Cookies

Dial voice mail Set voice mail

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter4

4.2.8 Settings

Profile Preferred Network

•General

•Silent

•Home

•Outdoor

•User Def 1

•User Def 2

•GSM only

•WLAN only

•GSM preferred

•WLAN preferred

Language GPRS setup

•GPRS attached

•Data count

•GPRS attach

•GPRS detach

Tones Display

•Ring tone

•SMS tone

•Alarm tone

•Keypad tone

•Power on/off

•WLAN alert

•Battery alert

•Wallpaper

•Backlight timer

•Backlight level

Clock

•Set date

•Set time

•Date display

•Time format

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Call settings Network service

•Answering mode

•Auto redial

•Incall timer

•Call summary

•Call divert

•Call barring

•Call waiting

•Network select

•Band mode

•Number transmitted

Security Auto key guard

•Enable PIN

•Change PIN

•Change PIN2

•Handset code

•Fixed dialing

•On

•Off

Restore factory

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter4

4.2.9 Organizer

4.2.10 Applications

4.2.11 Gallery

Alarm Calendar

To-do list Scheduled on/off

•Power on

•Power off

Games Calculator

Currency Stop watch

Count down World time

Images Sound

Misc. Memory status

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

5. Messages

Message is the first option of the Menu. There are five sub-menus under the

Message menu: SMS, MMS (Multimedia message), Email, Voice Mail, and

Call Broadcast.

You can read, write, send and save text, multimedia, SMS (short message

service) and e-mail messages. All messages are organized into folders.

Before you can send a message, you need to save some message settings.

To select the language for reading and writing messages, go to Settings >

language, and select the language you want to use. For Detail, see chapter

“Settings”.

5.1 Short Message Service (SMS)

You can send and receive multi-part messages, which consist of several ordi-

nary text messages (network service) by using the SMS (Short Message Ser-

vice).

The text messages function uses shared memory. Using any such features

may reduce the memory available for any features sharing memory. This is

especially true with heavy use of any of the features.

There are seven sub-menus under the SMS menus: Inbox, Write Message,

Draft, Outbox, Templates, Settings and Memory status.

5.1.1 Inbox

All the incoming messages are stored in Inbox folder with detailed date, time

and sender of each message shown. You can use left soft key (Options)

to reply, call (via GSM or WLAN), and delete the selected message, or delete

all messages in the Inbox.

5.1.2 Writing and Sending Messages

The message text area can accommodate 160 characters. To write a mes-

sage, follow the steps below:

a) Press OK key to access Menu > Messages > SMS, and scroll to

Write Message.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

b) Key in a message. You can change the key-in method (options from ABC,

Zitext, 123) key #, and you can also input the symbols by pressing the star

key when writing message. The keypad of digit 0 stands for

space bar while keying in message.

c) You can press left soft key to elaborate the message. There are four

options: Group send, Save, Insert template and Cancel.

-Group send refers to the receivers’ names you are about to key in, or

the ones you’ve set up previously. You can also select the list from

your phonebook for the message you are currently keying in. Press

OK key to enter new names, or to search names from phone-

book.

-Save refers to save the text you just keyed in and keep it in the Draft

until next time you send it out.

-Insert Template means insert the text you created before to save time.

This applies to certain GENERAL INFORMATIONS, which can be

reused and suits many different occasions and people. Press OK key

to enter and scroll up and down to select the proper template.

Press left soft key to enter new template, edit existing templates,

or delete templates. Press OK key to save the changes after

done.

-Exit editor means exit the message you just wrote, by using this func-

tion, the message will not saved in automatic draft.

5.1.3 Draft

Draft is the place where the messages in process are kept. Message is put in

the Draft when you save the text you just keyed in. The message is kept In

the Draft until it is sent out. Sent messages are kept in the Outbox.

Information:

To start writing messages quickly, press left navigation key in idle mode.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

5.1.4 Outbox

Outbox is the place where the messages sent out are saved. The time the

message was sent out and the receiver information are shown to remind you.

5.1.5 Templates

This function allows you to add your text to save time...

5.1.6 Settings

It is where you set up message reply path (setting up which ISP is used

to send message. On means you want to use the caller’s ISP, while off

means you will use your own network to send out message), save the

phone number of service center, check the status of the messages,

and decide to save the messages in the phone or in the SIM card. It

covers Service Center, Validity Period, Status Report, Long Message, SMS

Storage, and Reply Path. Scroll up and down by pressing the navigation

key and press OK key to enter the option you are after.

5.1.7 Memory Status

This function shows memory usage for SIM and phone.

Information:

When sending messages via the SMS network service, your phone

may display the words Message sent. This is an indication that the

message has been sent by your phone to the message center number

programmed into your phone. This is not an indication that the

message has been received at the intended destination. For more

details about SMS services, check with your service provider.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

5.2 Multimedia Message Service

A multimedia message can contain text, sound and a picture or a video clip.

The phone supports multimedia messages that are up to 100 kB in size. If the

maximum size is exceeded, the phone may not be able to receive the

message. Depending on the network, you may receive a text message that

includes an Internet address where you can view the multimedia message.

If the message contains a picture, the phone scales it down to fit the display

area.

Dual Mode telephone supports the following formats: JPEG, GIF, WBMP,

BMP, MIDI, WAV and AMR.

The phone does not necessarily support all variations of the afore-

mentioned file formats. If a received message contains any unsup-

ported elements, they may be replaced with the file name and the text

Object format not supported.

Note that you are not able to receive any multimedia messages if you have a

call in progress, a game or another Java application running, or an active

browsing session over GSM data. Because delivery of multimedia messages

can fail for a variety of reasons, do not rely solely upon them for essential

communications.

The function provided by the MMS feature include: Inbox, Write mes-

sage, Outbox, Sent items, Draft, MMS settings, Memory status.

After you select the MMS menu, the system will check first whether the set-

tings for GPRS are complete. If not, system will pop up a window to notify

User. User can still edit mail information.

Information:

This function can be used only if it is supported by your network

operator or service provider. Only phones that offer compatible

multimedia message features can receive and display multimedia

messages.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

5.2.1 Inbox

There are “Read” and “Unread” MMS in the “Inbox”. The unread MMSs have

higher priority than read MMSs. The ordering sequence of unread MMS is that

the latter have higher priority. Once an unread MMS is retrieved, it will be put

as the first one in read MMS.

5.2.2 Write Message

Press OK key to start creating multimedia message. The left soft key

(Options) offers you options to elaborate the message. The option

includes Insert, Delete, Subject, Preview, Slide list, Slide timing, Message

Type, Save, and Exit Editor.

-Insert allows you to include picture (from camera or gallery) or sound

(from gallery) into the message you are editing..

-Delete allows you to remove the picture or sound from the message you

are editing.

-Subject is the title of the message. Enter the subject and press OK key

to save it.

-Preview allows you to see how the MMS is edited and you can check

page by slide or a specific slide.

-Slide List refers to adding/deleting slide to the message, go to which slide

of the message (if it contains more than one slide).

-Slide Timing To edit slide timing.

-Message Type defines the nature of the message. There are four types:

Personal, Advertisement, Informational and Automatic.

-Save is to save the messages and pages you edited.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

5.2.3 Outbox

Outbox records the messages you ever sent out. The time the message was

sent out and the receiver information are shown to remind you.

Equivalent to the outbox in PC email. All mail placed in outbox will be sent out

by the system automatically.

The MMSs in the Outbox can be in the following states.

a) After User finishes editing and press OK key (Send), the system will

put the MMS in the Outbox and send it out in the background.

b) When an MMS is successfully sent, system will pop up a window to notify

User with ”1 MMS message has been sent”, the mail will then be removed

from Outbox to Sent items, indicating such email has been sent out.

c) MMS being transmitted out cannot be edited in the Outbox.

d) When MMS cannot be sent out due to setting of GPRS not complete,

system will pop up a window to notify User that GPRS are not complete.

MMS will be put in Outbox if GPRS setting is not complete.

e) There are three retry in the Outbox. If an MMS is not sent out after three

retries, system will notify User with a pop-up window, and such MMS will

be marked w/ an Icon, until User enters Outbox to take actions.

The ordering sequence in Outbox is that the earliest going out will appear as

the first.

Icon indicators include:

MMS in transmission, there will be Icon showing in the Title bar or Status

bar.

MMS waiting to be sent

MMS failing in sending

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

5.2.4 Sent items

MMS being sent successfully will be moved to Sent items if “Save sent

messages” setting is enabled. The latest sent MMS will appear as the first one.

5.2.5 Draft

The message that you have worked on it but is yet to finish is stored in Draft.

Or you can create drafts for different occasions for future MMS editing. The

MMS saved last is on the first line of the List menu.

5.2.6 MMS Settings

MMS-Settings is used to set up a variety of delivery relevant features. There

are Connection settings, Read reports, Delivery report, Save sent messages,

Sender visibility, Expiry time, Automatic download, Filter, and SMIL Layout.

-Connection settings gives you options for delivering the MMS.

-Read Report provides you the information when receivers receive your

messages. Turn on Send Report to agree the system to send the “Read

report” to the sender whenever the sender requests. A pop-up message

will show up to confirm sending “Read report” even if this setting is set to

“On”. Turn on Request Report to request receivers to send a “Read

report” back.

-If Delivery Report is on, you will receive a delivery report once the MMS is

sent.

- Turn on the Save Sent Message feature and your phone will automatically

save the MMS you just sent to Sent items.

- If you select Hide in Select visibility feature, the receiver of your MMS will

not know who sent the MMS from.

-Expiry time allows you five sets of effectiveness time frames of the MMS

you wish to send. If it surpasses the selected time frame, the MMS will be

disabled and it will not be sent out. The options are 1 Hour, 12 Hours, 24

Hours, 1 Week and Maximum.

- If the Automatic download feature is turned on, your phone will download

automatically any MMS received. If Home only is chosen, the phone will

download any MMS received only while you are in the home network, no

download while roaming.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

-Filter will bar the MMS that you do not want to receive from being sent to

you. You can choose to deny Advertisement MMS or Anonymous MMS.

-SMIL Layout allows you to decide whether you want the image you

included in the MMS to be located on Top or Bottom of the text.

5.2.6.1 Change active settings

Through this menu you can set a new service profile based on the parameters

provided by your service provider:

Setting’s name: can be set as desired (it is suggested you use the service

provider’s name)

Homepage: this is the default MMS homepage specified by your provider

(e.g. ‘ http://mms.vodafone.it/servlets/mms’)

Connection type: this is specified by your provider (typically ‘Proxy‘)

Proxy address: this is the proxy IP address for WAP service (e.g. ‘

10.128.201.076 ‘)

Data bearer: set GPRS if only GSM network is available, choose WLAN if

under WLAN coverage: this will allow highest connectivity speed.

Bearer settings

Access point: this is the service access node (e.g. ‘ wap.vodafone.it)

Authentication type (e.g. ‘ Normal ‘)

Username: (normally empty, unless provided by the service provider)

Password: (normally empty, unless provided by the service provider)

5.2.7 Memory Status

The memory status of Inbox, Outbox, Draft, and Sent Items are shown here.

You can delete used or undesired MMS to accommodate more new ones.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

5.3 E-mail

The Dual Mode phone supports E-mail function via GPRS and WLAN. By set-

ting your Dual Mode phone, you can send E-mail to your E-mail account into

Internet even if you are not in your home or office. You can edit, send and

read E-mail by using your Dual Mode phone, and can also use PC to save or

delete your E-mail, the Dual Mode phone supports POP3 and IMAP4 E-Mail

Server.

Before sending and downloading an E-Mail, you need first do the followed

operation:

Apply for a new E-mail account or use your present E-mail account (Please

consult with your E-mail service provider.).

Please consult with your Internet operator or E-mail service provider about the

correct E-mail setting. You can also set by the E-mail configuration received in

the configuration message.

Then you can do the E-mail settings in your phone according to configuration

information provided by your E-mail service provider.

The E-mail functions include the following submenus:

Create e-mail

You can first edit E-mail and then connect the E-Mail server; and also can first

connect the E-mail server then write or send the mail.

1. OK key (two times) (Messages) > Scroll down (two times) (E-

mail) > OK key (Create E-mail)

2. Input the recipient mail address and subject, and input Cc and Bcc mail

address if want to send the mail to others.

Information:

This function can be used only if it is supported by your network operator or

service provider. Only phones that offer compatible E-Mail feature can the

phone send or receive the e-mail normally.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

Press left soft key (Options) to input the mail content, add new recipient,

add Cc and Bcc.

After message editing, press Ok key (Menu), you can choose to send

now or send later.

Retrieve

You can download the e-mail from server manually or automatically by setting

the polling intervals. If leave copy on is set, the mail will be kept in the server

after download; otherwise, it will be deleted from the server after download.

Disconnect

You can always disconnect the link when downloading or sending mail by

using this function.

Inbox

When you have downloaded mail form your mail account, the mail will be

saved in Inbox. Enter Inbox to view the mail, press left soft key to reply

or delete the mail if you want.

Other folders

Other folders include Draft, Archive, Outbox and Sent items. All of the 4

folders’ maximum storage is 20.

-Draft saved the mail that was not sent out successfully

-Archive arranges and stores the mail

-Outbox stored the mail that was not sent out at present

-Sent items memorize the mail that was sent out already.

Memory satus

Display shows the memory status of the 4 folders. Always check the memory

status after sending or downloading the mail and be aware of the memory of

the each folder left for use.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Settings

Active settings: Select and set the profile. You can also clear the profile in the

Options page by selecting Clear profile.

5.3.1 Configuring a new E-mail account

Through this menu you can set a new service account based on the

parameters provided by your service provider:

Mailbox name: can be set as desired

E-mail address: input here the e-mail address (e.g. Mark@yahoo.com)

My name: Input the name before @, e.g. Mark

Out SMTP server: the SMTP server address for outgoing mail; (e.g.

smtp.yahoo.com)

In POP3 serve: the POP3 server address for incoming mail; (e.g.

POP3.yahoo.com)

POP3 user name: typically coincides with the e-mail address or with

the user part of the address

POP3 password: input the password for mail access (appears as

‘******’)

Leave copy: <on> leaves a copy of the downloaded mails on the

server fo rsuccessive access (e.g. from a PC); <off> disables this

option. Warning: all mails downloaded to the phone will only be

readable via the phone menu.

Polling interval: ‘manual’ enables the manual retrieve of mails

‘5 minutes’ (automatic retrieve every 5 min)

‘30 minutes’ (automatic retrieve every 30 min)

‘60 minutes’ (automatic retrieve every 60 min)

‘2 hours’ (automatic retrieve every 2 hours)

‘3 hours’ (automatic retrieve every 3 hours)

‘4 hours’ (automatic retrieve every 4 hours)

‘12 hours’ (automatic retrieve every 12 hours)

Other settings

Incl. Signature

Use SMTP auth: (<yes> enables authentication on the SMTP server)

SMTP user name: (to be input if <yes> was selected in the previous

menu)

SMTP password: (to be input if <yes> was selected in the previous

menu)

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

Out (SMTP) port: TCP port of the mail server – default = 25

In (POP3) port: TCP port of the mail server – default = 110

Reply-to address

Retrive e-mails (default = 10)

Data bearer: ‘GPRS’ enables connection over GPRS; ‘WLAN

only’enables connection over WLAN

Bearer settings

Access point

Authentication type (‘Normal’ or ‘ Secure’)

Username (input only if ‘Secure’ authentication type is selected)

Password (input only if ‘Secure’ authentication type is selected))

SMPT Connection settings

POP3 Connection settings

5.4 Voice Mail

Your service provider will provide you with a voice mailbox if you subscribe to

this specific service. When a voice message is received, your phone will notify

you by beeping, displaying a message on the idle screen, or both.

5.4.1 Dial Voice Mail

Your service provider may have already saved your voice mailbox number to

your phone and notified you when you first subscribed. If so, dial the assigned

number to listen to the voice message in idle mode. Or select Menu >

Message > Voice Mail > Dial Voice Mail and press OK key to check.

5.4.2 Set Voice Mail

Default short cut for accessing the voice mail is long press on . After

entering into this function, dial the number that your service provider set for

Warning:

the E-mail may contain virus or other elements that will be harmful to your PC

or cellular phone, if you do not certain the sender’s identity, please do not open

the accessories.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

voice mail to listen the voice mail. If you do not save the number, you will have

to redial it every time the phone is switched on.

5.5 Cell broadcast

Your cellular telephone uses this function for sending information to clients in

this section. The information is classified according to type. For this reason the

data is transmitted through various channels. If the cell broadcast feature is

activated this telephone can be used to receive these types of messages.

5.5.1 Inbox settings

By scrolling either up to down you can choose whether or not to activate

certain functions (Active/Not Active); press the OK Key to activate a

function.

5.5.2 Reading messages

Messages that have been received can be saved.

5.5.3 Add a channel

Enter the new ID channel that you wish to add. Press the OK Key to save

the new entry.

5.5.4 Channel lists

All of the channels that you have viewed and memorized are listed. Press the

OK Key to view the available channels and press the OK Key to

eliminate the channels you no longer need.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter5

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

6. Call History

The phone registers the phone numbers of missed, received and dialed calls,

and the approximate length of your calls.

The phone registers missed and received calls only if the network supports

these functions, and the phone is switched on and within the network’s service

area.

When you press Options in the Missed Calls, Received Calls and Dialed Calls

menu, you can, for example, call the number, save the number in Contacts, or

delete the phone number from the list.

6.1 Missed Calls

Press OK key (Menu), select Call History and select Missed Calls to view

the last 20 calls that someone tried to reach you. The caller name and time of

all the missed calls are shown here. The number at the end of the (name or)

phone number indicates the amount of call attempts from that caller.

6.2 Received Calls

Press OK Key (Menu), select Call History and select Received Calls to

view the list of the last 20 phone numbers from which you have most recently

accepted calls/network service.

6.3 Dialed Calls

This feature allows you to view the list of the 20 phone numbers that you have

most recently called or attempted to call. Press OK key (Menu), select

Call History and select Dialed Calls to view the list.

Information:

When a note about missed calls is displayed, press OK key to access the

list of missed call phone numbers. Scroll to the number you would like to call

back and press to call.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter6

6.4 Delete all call

Press OK key (Menu), select Call History and select Call Timer to the

missed calls, received calls, dialed calls, or delete all calls.

6.5 Call timers

Press OK key (Menu), select Call History and select Call Timer to check

the time of last call, all incoming calls and all outgoing calls take. You may

delete the record by pressing OK key to reset the timer.

Information:

In idle mode, press OK key once to access the list of dialed numbers.

Scroll to the number or name you want, and press to call the number.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

7. Contacts

You can save names and phone numbers in the phone’s memory and in the

SIM card’s memory. Contacts use shared memory.

The phone’s memory may save up to 500 names with numbers and text notes

about each name. You can also save an image (photos or downloaded image)

for all the contacts. The number of names that can be saved depends on the

length of the names, and the number and length of the phone numbers and

text items.

The phone supports SIM cards that can save up to 100 (up to 250 names for

some network operators’ SIM card) names and phone numbers. Names and

numbers saved in the SIM card’s memory.

There are 6 sub-menus under Contacts: Search, Add new, Group settings,

Speed dial, Memory status and My Number.

7.1 Search

Press Ok key (Menu) and select Contacts and Search, or to quickly find

a contact name, press right soft key in idle mode.

To search for a contact number, press OK key to decide you want to

search by name or by position. After decided, key in the first characters of the

name you are searching for in the pop-up window.

Press the up /down navigation key to scroll through the names in

the list, and left /right navigation key to move the cursor in the pop-up

window.

Scroll to the contact name you want, and press left soft key (Options)

(left soft key) to view how you want to react to the selected contact. The

options include send a message, edit the selected contact’s information, call

the contact, copy the contact’s information to the phone, delete its information,

set up a specific ring tone for the contact, and select a photo for it.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter7

Scroll to the option you want and press OK key to enter.

The figures below show the options.

7.2 Add New Entry

Whenever you have a new contact, select if you want to save it to SIM card or

phone before entering the contact’s information.

Select Save to SIM or Save to Phone, and press OK key to enter the

name and the number. While Save to Phone, you can record the contact’s

name, mobile phone number, home number, office number, IP phone number

and e-mail address, and home address whereas while Save to SIM, you can

only record contact’s name and mobile phone number. Press OK key to

key in the information and then press OK key again to save the change.

Save to SIM or Phone

7.3 Group Setting

You can group the contacts into groups and give each group with different

names.

Press Contact > Group Setting. There is no group created in your phone by

default, so press OK key (Add new) to name a group and press OK key

to save it. Press OK key to set the melody (from factory melody or

My Music) and SMS tone (from factory melody or My Music) for this group

Once you named the group, you can start picking up group members from the

contacts.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

a) Press OK key (Edit) to enter into the group and scroll down to

“Member” and press OK key (Change).

b) Press OK key (Add new) to select the members for this group from

your phone book.

c) Repeat this move until you finish selecting. Press OK key to save

and right soft key to back to the previous level.

Once the group is set, you can press left soft key (Options) to add new

entry or clear the whole group.

7.4 Speed Dial

Digit 2 to 9 are reserved for speed dial. Press Contacts > Speed Dial to enter

into this feature, and press OK key (Edit) to select the ones you want to

set up as speed dial member from the phone book.

7.5 Memory Status

It shows how many contacts are saved to the phone and to the SIM card, which

reminds you the left available memory both phone and SIM card still possess.

7.6 My Number

Shows your GSM and VoIP numbers for reference purpose.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter7

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

8. WLAN

The Dual mode phone has been pre-configured to work with any open wireless

network. The phone will obtain an IP address automatically once it recognizes

and connects to the WLAN network.

Any modifications made to the internal configuration of this device, not

expressly approved by your service provider will void the warranty of this

device.

The WLAN settings interface allows you to check WLAN network status, and

set profiles. It includes five functions, WLAN status, WLAN settings, SIP

status, SIP settings, and NAT settings.

8.1 WLAN status

You can fast set up when it is ready in idle mode, see which network displayed

when select the corresponding wireless network (GSM and WLAN).

•Telephone MAC: MAC address of Dual Mode telephone

•SSID: connected WLAN names (WLAN Modem, Access-Point)

•Auth. type: protection used (WEP, WPA, WPA2 or none)

•BSSID: MAC Address ofconnected WLAN Modem (Access-points)

•Channel: channel used. Available values 1-13; it depends on the WLAN

Modem.

•Signal lenght

•IP Telephone

•Subnet mask

•Gateway

•DHCP Server

•Main DNS Server

•Sec. DNS Server

•WMMstatus

Example 1: the bar that above the G-symbol (1) left displays the GSM

network’s strength. To make the network usable, there should be at least three

bars displayed on the screen.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter8

In the middle, it displays the corresponding network supplier (2) name.

Example 2: the bar above the W-symbol (3) right displays the WLAN AP/

Router signal strength. To make the network usable, there should be at least

3 bars displayed.

Only when W-symbol (3) right is displayed, the WLAN access to will be

recognized, and the phone will be registered.

WLAN status shows the MAC address of the phone and SSID.

Information:

If there is no links/access from the fitted and suitable profile, all the wireless

information in the phone will be recognized as “Not Available”.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

8.2 WLAN settings

To use the Dual mode phone, you can use different WLAN profiles. To setup

the profile with security rule used, the corresponding WLAN-AP (access point)

information should be given. When you are in the WLAN area and have a

predefined profile, select the profile, DP-L10 will register to the WLAN

automatically.

8.2.1 Select WLAN Profile

Before you set the access to WLAN network, select a profile, and check if the

profile is set and active.

A WLAN network can be added either when the network is detected (the

Network Indicator icon is showing in the idle screen) or manually by entering

setting information.

1. Press OK key (Menu) > Scroll down (WLAN) > OK key >

Scroll down (WLAN Settings)

2. Press OK key (Active settings) to select a profile

All Profile: The submenu set the All Profile from Active settings.

-Home: when you set a WLAN in house, use this profile and save the

Home-WLAN info.

-Office: when you set a WLAN in office, use this profile and save the

Office-WLAN info.

-Hotspot: Set the WLAN in the Hotspot when you have the operator of the

Hotspot.

-Profile 4 to 5: you can still take 2 more profile in use. Press OK key.

You can change the profile title/name, read the Chapter WLAN Profile

Rename.

Information:

Use this profile only when you want DP-L10 to select the profile automatically.

When you want to set one profile for one AP, do not select the profile (All

profile).

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter8

8.2.2 WLAN Access Setup

You can set up the access to WLAN via any broadband access device (DSL,

Cable, or company LAN) as long as the network is reliable.

-SSID: (Service Set Identifier) the name of the network, it is expressed by

the alphanumeric characters.

a) Set SSID by site survey

1. Press Menu > WLAN > WLAN settings > Edit act. settings > SSID &

security > SSID > Site survey

The display shows a list of all APs which are found nearby with good signal

strength.

2. Select the AP’s SSID

b) Set SSID manually

1. Press Menu > WLAN > WLAN settings > Edit act. settings > SSID &

security > SSID > Manual

2. Input SSID in the SSID edit window

-Security Setting: for WLAN security and encryption setting

a) Set security

1. Press Menu > WLAN > WLAN settings > Edit act. settings > SSID &

security > SSID > Security

The display shows the security items to be set.

Open:= It sets no encryption.

WEP:= WEP encryption, for WEP key settings. The key must be entered in

hexadecimal or ASCII format: A-F and 0-9. On the right top corner, a counter

decrements and reaches zero as all characters have been entered.

Information:

Activate the WLAN network only when it has searched AP/Routers in the

wireless area. This would save your consumption of battery power.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

WPA-PSK TKIP= WPA key setting

WPA2-PSK AES=.WPA2 key setting

2. Select WEP key 1/2/3/4, depth of the encryption, and input the key until it

is done.

3. Select WPA or WPA2 key for input.

4. Press Red key to end the WLAN settings. If all inputs are completed,

you will see the display of WLAN signal strength and “VoIP unregistered”

in the idle mode.

-IP address: IP address of the phone. To assign a static IP address turn

the DHCP off

You can choose the Automatic option to let the phone receive addressing from

the AP, or choose the Manual to set the IP address by hand.

Please refer to your Service Provider for further information.

Press Menu > WLAN > WLAN settings > Edit act. settings > IP settings >

Manual

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter8

It will display the setting of different IP-info.

Press UP/Down key to select the items in the menu page.

8.2.3 WLAN profile rename

You can rename the WLAN-Profile and to do it, you must first activate the

Profile.

Before you rename a profile, please read the chapter: Select WLAN profile.

If you have activated the renamed profile, the display will appear and display

in the idle mode.

1. Select WLAN Status > WLAN settings > Edit act. settings > Rename

2. Press OK key

3. In the input area locate the profile name for activating. You can delete the

profile name by pressing the right soft key . Input a new profile name.

4. If have input the Name, press OK key .

8.3 SIP status

SIP status shows the SIP registry information. You can view the registry status

of your terminal via this feature.

8.4 SIP settings

SIP is a VoIP signaling protocol and is used for setting up communications

sessions such as conferencing, telephony, and instant messaging on the

Internet.

Press Menu, and select WLAN and SIP Settings.

Information:

When completing the settings, a bar above the W-Symbol should be displayed.

If not, check that your broadband connection is active and repeat the previous

steps.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

To make the phone ready for VoIP call, you will need the following information

from your service provider for your broadband device:

Username User name used in

the name field of the

SIP URI for the IP

phone and for

registering the

phone at the

registrar.

max. 30 characters,

numeric or

alphabetic

Password Password used to

with the SIP proxy.

Passwords are

encrypted and display

as asterisks when

entering.

max. 12 characters,

numeric or

alphabetic

Auth. name Depends on specific

service

implementation.

Domain name The corresponding

SIP domain name. e.g. sip.Pirelli.com

Local port The port number of

the local SIP server Default: 5060

Proxy server IP address of the

SIP proxy server. Up

to 64 alphanumeric

characters.

e.g. sip.Pirelli.com

Proxy port SIP proxy server’s

port number. Default: 5060

Up to 64 alphanumeric

characters.

e.g. sip.Pirelli.com

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter8

1. From the idle mode, press OK key (Menu) > Scroll down

(WLAN) > OK key > Scroll down (four times) (SIP settings) >

OK key

2. Enter Username, Password, and all the information provided by your

service provider.

When all the settings are correct, and the DP-L10 successfully registers to the

network, the bold VoIP indication will remain displayed.

number. Default: 5060

Outbound server The IP address of

the outbound proxy

server

You can use either a

dotted IP address or

a DNS name

Outbound port The port number of

the outbound proxy

server.

The default is 5060.

RTP audio port The Real-Time

Transport Protocol

port base configured

for the IP phone.

Default: 9000

RTP pkt.period Default:20

Preferred codec Voice codec:

G.711U

G.711A

G.726-32

G.726-16

G.729 (this codec may

be available in

alternative to G.726;

please check with your

service provider).

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

If you encounter any problems, make sure that your IP Router or ISP is not

blocking any traffic, specifically on the RTP ports. Also ensure that the router

is not blocking UDP traffic. You can contact your network administrator or ISP

for more information.

For additional assistance please refer to your Service Provider’s Help Desk.

8.5 NAT Settings

These settings are relevant to the ability of the phone to traverse the AP’s NAT

(Network Address Translation function).

PAT (Port Address Translation function).

8.5.1 RPORT

Select from the main menu with the Up / Down / Left / Right :

WLAN Status > NAT Settings

1. From the idle mode, press OK key (Menu) > Scroll down

(WLAN) > OK key > Scroll up (NAT settings) > OK key

(Rport)

2. Select Enable/Disable

3. Press Right soft key to end the Rport settings.

Information:

If VoIP is not displayed when all the settings are completed, please repeat the

above steps.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter8

8.5.2 STUN

1. From idle mode, press the OK key (Menu) > Scroll down

(WLAN) > OK key > Scroll up (NAT settings) > OK key >

Scroll down > OK key (STUN)

2. Enter the Enable, it will display the STUN options menu, select these

items with the arrow key UP / Down .

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

9. WAP Service

WAP (Wireless Application Protocol) is an open and standard protocol for

wireless application. It is mainly used to provide digital mobile phone and other

wireless terminal devices with wireless communication and information

service for.

This phone supports WAP protocols that run on TCP/IP protocols. Some

features of this device, such as multimedia messages and Web browser

require network support for these technologies.

The device is able to receive service messages sent by your service provider.

Service messages are notifications of, for example, news headlines, and they

may contain a text message or the address of a WAP service.

The WAP service can be available via GPRS or WLAN.

Homepage

You can set Homepage in Settings, e.g. http:// www.yahoo.com. By setting

the homepage, you can open the homepage by press OK key , and press

the arrow key to view the web browser.

Bookmarks

•You can have the Bookmarks opened from the main menu or in the

options menu. Press the arrow key UP / Down in the book-

marks to select the site that you want to visit.

•You can have the page info, edit page, edit address, delete, and send

function in the options page.

Download Links

•This function will allow you to enter some websites, you can input any

websites you want in this menu, e.g. you can input http://www.yahoo.com

and press OK key to enter.

Go To Address

You can use this feature when you want to visit certain websites.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter9

Service Inbox

Your phone will sometimes receive some service message from the service

provider, an indication tone will have if received, and also “1 WAP message

received “ icon displayed on Idle, the service message will be saved

automatically in Service Inbox, enter Service Inbox, you can view the message

content.

Settings

1. Profile

•Active settings

•Edit active settings

2. Security settings: Enter: Settings > Security settings, you can find a

Certificate List, select OK key in order to display the lists.

3. Inbox Service

4. Image display

5. Cache

6. Cookies: select On/Off or press OK key to select Clear cookies.

9.1 Configuring a new WAP account

Through this menu you can set a new service profile based on the parameters

provided by your service provider:

Setting’s name can be set as desired (it is suggested you use the service

provider’s name).

Homepage: this is the default WAP homepage specified by your provider

(e.g. ‘http://wap.yahoo.com’)

Connection type: this is specified by your provider (typically ‘Proxy‘)

Proxy address: this is the proxy IP address for WAP service (e.g. ‘

10.128.201.076 ‘)

Port: the port number (e.g. ‘80‘)

Data bearer: set GPRS if only GSM network is available, choose WLAN if

under WLAN coverage: this will allow highest connectivity speed.

Bearer settings. Access point: this is the service access node (e.g.

‘wap.providername.it‘)

Access point: access service (for ex. wap.providername.it)

Authentication type (e.g. ‘ Normal ‘)

Username: (normally empty, unless provided by the service provider)

Password: (normally empty, unless provided by the service provider)

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

10. Voice Mail

10.1 Dial Voice Mail

Dial to your voice box.

10.2 Set Voice Mail

You might contact your service providers for the number of voice mail.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter10

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

11. Camera

You can take photos with the phone’s built-in camera. The camera lens is on

the back of the phone, and the display of the phone works as a viewfinder. The

camera produces pictures in JPEG format. If there is not enough memory to

take a new photo, you need to free some by deleting old photos

Press OK key (Menu) > Scroll down (two times) (Camera) >

OK key .

Press Capture when taking a photo, a shutter sound is heard. Press OK key

to save the photo, and you will be led to the screen that requires you to

key in the name of the photo. Enter the name and press OK key to save

the name for the photo. You can take another photo by press left soft key

(Back).

There are six options under Camera: Gallery, Effect, Size, Quality, Self Timer,

and Shutter sound.

Press left soft key Options and enter Gallery to view photo saved in the

Gallery menu. Under the Gallery’s option, you may Set the photos as

Wallpaper, Delete the photo, Rename the photo, and check the Details (width,

height and size) of the photo.

Press left soft key (Options) and Scroll down (Effect) to select

different effect for your photo.

Information:

Obey all local laws governing the taking of pictures. Do not use this feature

illegally.

Information:

Left soft key allows quick access to Camera.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter11

Press left soft key (Options) and Scroll down (Size) to select the

photo size.

Press left soft key (Options) and Scroll down (Quality) to select

High, Mid or Low. High provides the best image quality but occupies more

memory.

Press left soft key (Options) and Scroll up (Self Timer) to turn On or

Off. While the self-timer is running, it produces a beeping sound. The live

image appears on the display, and you can use the display as a viewfinder.

Press Options and Shutter sound to tone to On or Off.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

12. Settings

Settings provide various functional settings of the phone itself. The tone, the

language, the wireless connection, the screen display, clock, answering mode,

etc. are set up in this menu.

12.1 Profile

Your phone has various setting profiles, for which you can customize the

phone tones for different events and environments. Initially, personalize the

profiles to your own like and then you only need to activate a profile to use it.

Available profiles are General, Silent, Home, Outdoor, UserDef 1, and

UserDef 2.

UserDef 1 and UserDef 2 are for you to define a proper name for the specific

situation.

Press Ok key (Menu) > Scroll down (two times) > Shift right key

(Settings) > Ok key (Profiles). Scroll to a profile and press Ok key

to activate the selected profile.

You can Personalize the profile you activated by selecting different Ring tone,

SMS tone, Alarm tone, Keypad tone, and Power on/off Alert, WAN alert, and

Battery alert.

Press left soft key (Options) and select Personalize. Scroll up and down

to select the one you want to change.

You may also Rename the profile by pressing the left soft key (Options)

and scroll down to Rename. Enter the new name you wish and press Ok key

to save the change.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter12

12.2 Preferred Network

Select your preferred network for your phone. Press OK key (Menu) >

Scroll down (two times) > Shift right key (Settings) > OK key >

Scroll down (Preferred network).

Select one from the four networks that you prefer and press OK key to

activate it.

12.3 Language

This phone device provides you with the default language option: English.

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll down (two times) (Language).

Scroll to a language and press OK key to confirm.

12.4 GPRS setup

The General Packet Radio Service (GPRS) provides users with packet data

services (similar to the Internet) using the GSM digital radio network. It is used

to support the connection with WAP and MMS services.

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll down (three times) (GPRS setup).

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

12.4.1 GPRS Attached

Select GPRS Attached and press OK key to enter to this feature. Choose

Any time or When needed based on your actual need.

The difference between Any time or When needed lies in that Any time is

connected to GPRS whenever you switch on the phone, while When needed

means you connect to GPRS only when you want to use this function.

12.4.2 Data Count

The data of incoming and outgoing messages are shown here.

12.4.3 GPRS Attach or Detach

The third and fourth option is attach to or detach from the GPRS connection,

respectively. Scroll and press OK key to activate the desired option.

12.5 Tones

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll down (four times) (Tones).

Note that the settings you make will change the settings in the active profile.

There are sub-menus under the Tones. They are Ring tone, SMS Tone, Alarm

tone, Keypad tone, and Power on/off, WLAN alert, and Battery alert.

12.5.1 Ring Tone

Select Ring tone to choose how the phone notifies you of an incoming voice

call. The options are Alert type, melody, My music, and volume.

The Alert Type provides you with options of Ringing, Vibrating, Vibrate then

ring, Vibrate and ring, and silent. Scroll up and down to select the one that suits

you most. Press right soft key (Back) to return to upper level.

The factory default offers 25 pieces of Melody for your choice.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter12

My Music is the melody you created or downloaded. You may contact your

service providers for download information.

Press right navigation key to increase the Volume and the left navigation

key to decrease the Volume.

12.5.2 SMS and Alarm tone

SMS tone and alarm Tone have the identical options and operational method

as Ring Tone does. Refer to Ring tone to use these two features.

12.5.3 Keypad tone

The keypad tone is also set up here under the Settings menu. Scroll up and

down to select the keypad tone from Off (Silent), Click, DTMF (every key has

its unique sound).

12.5.4 Power On/Off, WLAN, Battery alert

It is the melody that sounds when you switch on/off the phone, out of WLAN

range, or when battery is low.

12.6 Display

This submenu provides different background images for your phone during the

idle mode and the light level you want your phone screen to display.

Select Display and press OK key to enter this feature.

12.6.1 Wallpaper

Select Wallpaper to set up your phone to display a background image, known

as wallpaper, when the phone is in idle mode.

Scroll to Select wallpaper to select wallpaper from Gallery or the pre-installed

wallpaper. .

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

Scroll to Select gallery enter into Gallery. Select Images to display a list of the

pictures you took using the phone’s camera. Scroll up and down to choose

your wallpaper from the list and press OK key to activate your soft.

Scroll to on/off to turn on/off the display of the wallpaper you selected.

12.6.2 Backlight Timer and Backlight Level

Backlight is the light that helps you to read the screen with ease, but it

consumes the battery power. Backlight timer defines the duration the backlight

stays on from the last activity. You may select the timer that satisfies your need

and save the power. You have the options of 10 seconds, 20 seconds, 30

seconds and 60 seconds. Press OK key to activate your soft after done.

Backlight level feature controls how luminous you want the screen to display.

Select Backlight level and press right navigation key to increase the

backlight from level one to level five. Press left navigation key to darken

the backlight.

12.7 Clock

The time and the date are setup under this submenu.

First setup the date by enter the current date. Key in the digits representing

today’s date and press navigation key to move to left or right. Press OK key

to activate the changes.

Date display allows you to select different date format that you want to be

shown on the idle mode screen. Scroll up and down to pick your choice from

the three options.

The setup method of Time setting is identical to Set date and Date display,

only that it is for time. Follws the step above to set the time.

Time format allows you to change the time format as 12 hours or 24 hours.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter12

12.8 Call Settings

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll up (Call Setting).

12.8.1 Answering mode

The first sub-menu is Answering mode, which is to decide what key you press

in order to answer the phone. Choose from Normal answer, Any key answer,

or Auto answer. Press OK key to activate the setting.

Normal Answer is to answer the phone using or Green key, while Any

Key Answer is to answer the phone using any key on the keypad. Auto Answer

means the phone will automatically answer the incoming call after 5 seconds.

12.8.2 Auto redial

The second sub-menu Auto Redial is to activate or not the auto-redial function.

12.8.3 Incall timer

Incall Timer is to set On or Off the timer when the phone is in use. Select On

or Off and press OK key to activate the setting.

12.8.4 Call summary

Call summary is to set On or Off the call summary after the phone call.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

12.9 Network Service

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll up (four times) (Network Service).

12.9.1 Call Divert

With Call Divert, you can direct your incoming calls to another number, for

example, to your voice mailbox number, a fax number or another phone

number. Divert options not supported by your SIM card or your network

operator may not be shown.

Select the divert option you want from If not reachable, If busy, if no reply to

divert voice calls when your number is busy or when you reject an incoming

call.

To set the divert setting to on, select one from the three options mentioned

above and then select whether the call is diverted to Voice, Fax, or Data, if this

is available for the divert option. After you made the decision of call divert

destination, press OK key to Set Divert, meaning activating the divert

destination. You may also scroll to Check Status and press OK key to

check if this function is set on or not. Several divert options may be active at

the same time.

To set the divert setting to off, select Cancel Divert to check whether call divert

is activated or not.

If you activate All Calls, it means the phone will not filter any incoming calls and

divert them all to your selected destination.

Cancel All will disable the divert All Calls function. Follow the previous

paragraph to operate the two functions.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter12

12.9.2 Call Barring

Call barring service (network service) to restrict incoming calls to and outgoing

calls from your phone, including both domestic and international calls. A

barring password is required.

Scroll from the softs and press OK key to enter into this soft. You can

Check Status, Set Bar, or Cancel the call barring by pressing OK key .

12.9.3 Call Waiting

Activate this function and the network will notify you of an incoming call while

you have a call in progress.

Select Call waiting and press OK key to enter into this soft. You can then

Check status to see if this function is set on, Activate, or Cancel the call waiting

by pressing OK key .

12.9.4 Network Select

This feature is to select the GSM Service Provider. Select Network select and

press OK key to choose from Automatic or Manual.

If you select Automatic, your phone will automatically search any available

network that helps send and receive signals. Note that not all available

networks can be connected and you are recommended to select Automatic.

If you select Manual, the system will search for all available networks in your

area. Select your option and press OK key to confirm.

12.9.5 Band Mode

This feature is to set up the band that your phone network is operating on. You

can select from Automatic, 900&1800, 900, 1800, or 1900. Select your option

and press OK key to confirm.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

12.9.6 Number Transmitted

Select On or Automatic and press OK key to confirm if you do not want

the receivers to know your phone number, otherwise, select No.

12.10 Security

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll up (three times) (Security).

Enable PIN: you are required to enter the phone password when you switch

the phone on.

Change PIN: This feature allows you to change your current PIN to a new one,

provided that the PIN Check feature is enabled. You must enter the current

PIN before you can specify a new one. Once you have entered a new PIN, you

are asked to confirm it by entering it again.

Change PIN2: The Change PIN2 feature allows you to change your current

PIN2 to a new one. You must enter the current PIN2 before you can specify a

new one. Once you have entered a new PIN2, you are asked to confirm it by

entering it again.

Handset code: When the Phone Lock feature is enabled, the phone is locked

and you must enter the 4-digit phone password each time the phone is

Information:

When security features that restrict calls are in use (call barring), calls may be

possible to certain emergency numbers in some networks (e.g. 112, 911 or

other official emergency numbers).

Information:

Not all SIM cards have a PIN2. If your SIM card does not, this menu option is

not displayed.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter12

switched on. The password is factory set to 0000. To change the phone

password, once the correct password has been entered, you can use the

phone until you switch it off.

Fixed dialing: To restrict your outgoing calls and text messages to selected

phone numbers if this function is supported by your SIM card. The PIN2 code

is required. When the fixed dialing is on, GPRS connections are not possible

except while sending text messages over a GPRS connection. In this case, the

recipient’s phone number and the message center number have to be

included on the fixed dialing list.

12.11 Auto Key Guard

Key Guard allows you to keep the phone in your pocket or purse without the

worry of accidentally dialing a number.

Press OK key (Menu) > Scroll down (two times) > Shift right key

(Settings) > OK key > Scroll up (two times) (Auto key guard).

Select On to activate the automatic key guard. Select Off to deactivate this

function. .

12.12 Restore Factory

To reset some of the menu settings to their original values, press OK key

(Menu) > Scroll down (two times) > Shift right key (Settings) > OK

key > Scroll up (Restore factory). Before you are allowed to restore

the factory setting, you are asked to enter the handset code. Enter handset

code and confirm if you want to reset the configuration.

Information:

Note that the data you have keyed in or downloaded, for example, the names

and phone numbers saved in contacts are not deleted.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

13. Organizer

The Organizer menu has the following features:

1. Set the alarm so that the phone rings at a specific time, such as to remind

you of an appointment.

2. View the calendar and organize your schedule.

3. Define a list of things to do.

4. Setup the time for the phone to ring on specific time or switch on the

phone automatically when it was switched off.

13.1 Alarm

This feature allows you to set up to five alarms. You can:

1. Set the alarm to ring at a specific time.

2. Set the phone to switch on automatically and ring the alarm even if the

phone is switched off.

The following options are available:

a) Daily: the alarm rings every day at the same time.

b) Weekdays: the alarm rings on Monday to Friday at the same time.

c) Weekend: the alarm rings only on weekend at the same time.

d) Given date: the alarm rings only once then deactivated.

Press OK key (Menu) > Scroll down (two times) > Shift right key

(two times) (Organizer) > OK key (Alarm).

Press OK key (Select) to start setting. The first item is to choose the

frequency of the alarm from Once, Daily, Week Day or Weekend. Press OK

key to enter into the four sub-options and scroll up and down to select

one that suits your need.

Once the daily alarm is set up, press the downward navigation key and

press OK key to enter into the second item: time setting. Key in the time

and press OK key to save the change. Follow these steps to set up the

third option, date of alarm setting, and alarm On or Off.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

100

Chapter13

You have to choose on for the alarm On or Off item, or all the settings will not

work.

To set the alarm tone, press OK key (Menu) > Scroll down (two

times) > Shift right key (Settings) > OK key > Scroll down (four

times) (tone) > OK key > Scroll down (two times) (alarm).

13.2 When the alarm time expires

The phone will sound an alert tone, and shows Alarm and the time and the

current time on the display.

Press Stop to stop the alarm or press Snooze to reschedule the alarm in next

10 minutes.

If the alarm time is reached while the phone is switched off, the phone switches

itself on and starts sounding the alarm tone. If you press Stop, the phone asks

whether you want to switch the phone on. Press No to keep the phone

switched-off or Yes to make phone switch-on.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

101

13.3 Calendar

With the Calendar feature, you can:

1. Consult the calendar.

2. Write memos to keep track of your schedule.

3. Set an alarm to act as a reminder, if necessary.

Press OK key (Menu) > Scroll down (two times) > Tecla de

navegación hacia la derecha (two times) (Organizer) > OK key >

Scroll down > OK key (Calendar).

On the Calendar menu, you will see the calendar of current month and the

current day is marked in red. Select the day and press OK key to view

the day notes.

You may edit, delete or add a note. On the Calendar note screen, press left

soft key (Options) if you want to add a new note or remove a note. On the

Calendar note screen, press OK key to edit the time, date and ringer on/

off for the notes you already entered.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

102

Chapter13

13.4 To-do list

This feature allows you to enter a list of tasks to be completed.

Press OK key

(Menu) > Scroll down (two times) > Shift right key

(two times) (Organizer) > OK key > Scroll down (two times) >

OK key (To-do List).

Press OK key to key in a note and press OK key to save the entry.

Press OK key to edit a note you entered and press OK key to save

it. You may press left soft key (Options) to add a new note or delete the

existing notes.

13.5 Scheduled Power on/off

This feature allows you to:

1. Set the power On or Off at a specific time.

2. Set the phone to switch on or off automatically and ring the alarm even if

the phone is switched off.

Press OK key (Menu) > Scroll down (two times) > Shift right key

(two times) (Organizer) > Tecla OK > Scroll down (three times) >

Tecla OK (Scheduled on/off).

Select power on or power off and press OK key to continue set up the

schedule of power on/off time.

There are four options for power on/off schedule:

Daily: the power is turned on or off every day at the scheduled time.

Week Day: the power is turned on or off only on Monday to Friday at the

scheduled time.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

103

Weekend: the power is turned on or off only during weekend at the scheduled

time.

Given day: the power is turned on or off once and it is then disabled.

Press OK key to select one for your preference and press OK key

to confirm, then key in the time and press OK key for confirmation. Select

On or Off to set alarm action.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

104

Chapter13

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

105

14. Applications

The Applications menu enables you to:

1. Play the game

2. Use the phone as a calculator for basic mathematical equations.

3. Identify currency exchange rates.

4. Measure time.

5. Count down time.

6. Watch the current date and time in different countries.

14.1 Games

Your phone software includes some games specially designed for this phone.

14.1.1 Launch a game

Press OK key (Menu) > Scroll up (Applications) > OK key

(Game).

Scroll to the desired game and press OK key .

Select New Game and OK key to launch a game, if you would like to stop

the game press right soft key .

Select Help shows how to play the game and functions for the game.

Flash Game Over and key in your name press OK key .

Scroll to Clear all scores and press OK key to clear the score.

Information:

Note that running the games may consume the phone’s battery faster (and you

may need to connect the phone to the charger).

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

106

Chapter14

14.1.2 Tone and Background Music

Select Game tone and press OK key to turn the game tone On or Off.

Select Background Music and OK key to turn On or Off.

14.2 Calculator

Press OK key (Menu) > Scroll up (Applications) > OK key >

Scroll down (Calculator).

When ’0’ is displayed on the screen, key in the first number in the calculation,

and select Add(+), Subtract(-), Multiply(x) or, Divide(÷) using the navigation

key. Key in the second number, for a total, press Equal (OK key).

To start a new calculation, press and hold right soft key (Clear).

Left soft key (Dot) stands for a decimal point.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

107

14.3 Currency

Press OK key (Menu) > Scroll up (Applications) > OK key >

Scroll down (two times) (Currency).

Key in the exchange rate and press OK key to enter. Press the left soft

key if you want to enter dot.

The exchange rate remains in the memory until you replace it with another

one. To perform the currency conversion, key in the amount to be converted

and press OK key .

14.4 Stop watch

You can measure time consuming by using this feature. During timing, you can

use the other functions of the phone simultaneously.

Press OK key (Menu) > Scroll up (Applications) > OK key >

Scroll down (three times) (Stop watch).

Press Start to start the time measurement.

Press Split every time you want to separate every session of time measured.

The intermediate times are listed below the running time on the display screen.

Press Stop to stop the measurement. Select Reset to clear the record.

Information:

Using the stopwatch consumes the battery and the phone's operating time will

be reduced.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

108

Chapter14

14.5 Count Down

Press OK key (Menu) > Scroll up (Applications) > OK key >

Scroll down (four times) (Count Down).

Key in the time in hour, minute and second and press OK key to save the

entry. Press Start to start the countdown timer. To stop the timer, press Stop.

If the countdown time is up when the phone is in idle mode, the phone sounds

a tone and flashes any note text that has been set or otherwise the screen

shows Countdown time up. Stop the alarm by pressing any key. If no key is

pressed, the alarm automatically stops within 30 seconds.

14.6 World Time

This phone device provides the current time of 51 major cities around the

world.

Press OK key (Menu) > Scroll up (Applications) > OK key >

Scroll up (World Time).

Press Navigation key left or right to browse time of different countries.

Select your city and Press OK key to set up local zone.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

109

15. Gallery

Gallery is where you save the pictures you take using this phone and the music

you download.

The files stored in Gallery use a memory that is shared by phone book, SMS,

MMS, and camera gallery etc. If your phone displays a message that the

memory is full, delete some of the files in Gallery before continuing. The phone

will notify if you store more than 100 piece of image or melody.

Press OK key (Menu) > Scroll up > Shift right key (Gallery).

A list of folders is shown: Images, Sound, Misc., and Memory Status.

Select Images to enter. You will see the list of pictures you’ve taken. Scroll up

and down to choose and press OK key to view the chosen photo.

If you press Options, you can further manage the pictures. The options are:

Details, Rename, Delete, Set as wallpaper, Create MMS, and Activate key’s

list.

Press left soft key (Options) to either view details of photo size, edit photo

name, delete photo, set the picture as wallpaper, create MMS.

Select Sound and press OK key to view list of music you downloaded.

Select Memory Status and press OK key to view memory status. It shows

how much space is used for image and sounds and how much space is free

for more photos and music.

Information:

Your phone must be switched on to use this function. Do not switch the phone

on when wireless phone use is prohibited or it may cause interference or

danger.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

110

Chapter15

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

111

16. Care and Maintenance

Dear customer,

Please dispose batteries according to local regulations. Please recycle when

possible. Do not dispose as household waste.

Thank you

16.1 Information on the batteries

Use only Pirelli approved batteries, and recharge your battery only with Pirelli

approved chargers designated for this device.

Information:

Dispose of the batteries in the special containers only when empty.

Information:

For precaution, insulate the lythium battery terminals using cellotape to avoid

short-circuiting.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

112

Chapter16

Warning:

Leaving a fully charged battery connected to a charger, may shorten its

lifetime.

Do not short-circuit the battery. Accidental short-circuiting can occur when a

metallic object causes direct connection of the positive (+) and negative (-)

terminals of the battery. Do not invert the the positive (+) and negative (-)

terminals. Do not force the connection if you are not able to connect the battery

block terminals to the telephone easily. Check polarity.

The battery block is equipped with in-built safety/protection devices. Do not

dismount or modify the battery block. Do not use in places where the static

voltage exceeds the voltage indicated in the manafacturer’s warranty.

Do not transport or store the battery block together with metal objects such as

necklaces, hair pins etc. Otherwise shart-circuiting shall occur, the battery will

be overloaded leading to acid leakage from the battery block, overheating,

release of smoke, explosion and / or ignation or metal objects like wires,

necklaces and hair pins might generate heat.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

113

Do not dispose of the battery block in flames or heat it. In addition, do not use

it or leave it near sources of heat such as flames or heating devices (60°C or

above). The temperature range within which charging is guaranteed is

between 0 and 40°C. Do not charge the battery block near flames or in

extremely hot environments. Do not use the battery block exposing it to strong

solar radiation or to hot temperatures, for instance in a car when it is hot.

Do not dip the battery block in water or in sea water and and keep it away from

water.

Store the battery block away from children’s reach.

Do not damage the battery block with nails or sharp objects, do not hit it with a

hammer, trample on it or hurl it. Do not use an openly damaged or deformed

battery block. Do not join the battery block directly.

Do not connect the battery block to a socket, to a car cigarette lighter, etc. Use

the battery block only for the indicated purposes.

In case of leakage from the battery block and the electrolyte gets into contact

with the eyes, do not rub but wash under running water and immediately seek

a doctor's advice. In case some acid drips from the battery block and gets into

contact with your skin or clothes, wash them immediately under running water.

In case charging operations fail though the charging time has expired,

immediately stop all charging operations.

Do not put the battery block into a microwave or into a pressurised container.

In case the battery block releases odour or heat, loses colour or gets

deformed, or else if it seems abnormal during use, charging or when it gets

used, remove it from the equipment or battery block charger immediately and

do not use it any more.

Leaving the battery in hot or cold places (below 15°C or above 25°C), will

reduce the capacity and lifetime of the battery.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

114

Chapter16

16.2 Product care guidelines

Warning:

•Keep the device dry. Precipitation, humidity, and all types of liquids or

moisture can contain minerals that will corrode electronic circuits. If your

device does get wet, remove the battery, and allow the device to dry com-

pletely before replacing it.

•Do not use or store the device in dusty, dirty areas. Its moving parts and

electronic components can be damaged.

•Do not store the device in hot areas. High temperatures can shorten the

life of electronic devices, damage batteries, and warp or melt certain plas-

tics.

•Do not store the device in cold areas. When the device returns to its nor-

mal temperature, moisture can form inside the device and damage elec-

tronic circuit boards.

•Do not attempt to open the device other than as instructed in this guide.

•Do not drop, knock, or shake the device. Rough handling can break inter-

nal circuit boards and fine mechanics.

•Do not use harsh chemicals, cleaning solvents, or strong detergents to

clean the device.

•Do not paint the device. Paint can clog the moving parts and prevent

proper operation.

•Use a soft, clean, dry cloth to clean any lenses, such as camera lenses.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Chapter

115

17. Certifications

DECLARATION OF CONFORMITY

We, Pirelli Broadband Solutions S.p.A. declare under our sole responsibility

that the product is in conformity with the provisions of the following Council

Directive:

1999/5/EC.

Applicable standards:

EN 55022:1998 / A1:2000 / A2:2003

EN 301 489-01 V1.4.1

EN 301 489-07 V1.2.1

EN 301 489-17 V1.2.1

EN 301 511 V9.0.2

EN 300 328 V1.6.1

EN 50360: 2001

EN 60950-1:2001 / A11:2004

EN 61000-3-2:2000

EN 61000-3-3:1995 / A1:2001

A copy of the Declaration of Conformity can be found from www.pirelli.com/

The crossed-out wheeled bin means that within the European Union the

product must be taken to separate collection at the product end-of-life.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

116

Chapter17

17.1 Certification information (SAR)

This mobile device meets guidelines for exposure to radio waves.

The exposure guidelines for mobile devices employ a unit of measurement

known as the Specific Absorption Rate or SAR. The SAR limit stated in the

ICNIRP guidelines is 2.0 watts/kilogram (W/kg) averaged over 10 grams of

tissue. The highest SAR value under the ICNIRP guidelines for use of the

device at the ear is 0.5 W/kg.

Use of device accessories and enhancements may result in different SAR

values. SAR values may vary depending on national reporting and testing

requirements and the network band.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

FAQ

117

FAQ

A.1 Frequently Asked Questions and Troubles-

hooting Guide

1) The phone does not turn on

•Verify the battery charge; eventually you need to charge it

•To turn on the phone the user has to maintain pushed the turn on but-

ton (red one ) for 5 seconds at least

2) What is the charging time?

•The typical charging time is 2.5h

3) What are the DP-L10 characteristics in terms of battery duration?

•Talking Time

•240 mins under GSM mode

•160 mins under WiFi mode

•Standby Time

•180 Hrs under GSM mode based

•150 Hrs under WiFi mode based on no periodic scan for roaming

•WiFi or GSM Preferred Mode:

•150 Hours for GSM and connected WiFi (typical Home Scenario

•30 Hours for GSM and searching for WiFi (typical out of home Sce-

nario))

4) Does DP L10 support a memory card?

•No, it doesn’t.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

118

FAQA

5) Without SIM card inserted the phone goes on asking me to insert pin

code. Is it possible to use the phone as a simple Wi-Fi phone?

•Yes, it is but you have not to configure the phone in ‘network settings’

as GSM only. Every other different setting will allow the user not to

insert the SIM card.

•In this case please insert a SIM into the phone, then power on it and

change the ‘network setting’ (e.g. WiFi preferred or GSM preferred).

After that, power off the phone and remove the SIM; now you can use

DP-L10 without SIM card on the WiFi network.

6) How many phone numbers is the phone provided with?

•DP-L10 is able to manage two (2) different voice calls via GSM and

via VoIP so 2 different phone numbers have to be supplied

•Number <1234> for GSM network

•Number <5678> for WiFi network

7) What GSM bands does the DP-L10 support?

•It supports GSM 900/1800/1900MHz bands

8) Does the DP-L10 support the GPRS?

•Yes, it does.

9) Does the DP-L10 support the UMTS?

•No, it does not.

10)What Access Point types does the DP-L10 support?

•It support Access Point 802.11b and 802.11g (channels at 2.4GHz)

11) What WiFi encryption types does the DP-L10 support?

•It supports open method, WEP, WPA-PSK TKIP and WPA2-PSK AES.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

FAQ

119

12)Does the DP-L10 support the roaming between GSM and WiFi

network?

•No roaming between GSM and Wi-Fi is supported during the call. If

the network connection (GSM or WiFi) is lost when a call is running,

the call will be interrupted and you need to restart it; the phone auto-

matically will choose the network still available if GSM preferred or

WiFi preferred settings have been selected in network profile.

13)How can the user understand if he/she is using VoIP or GSM

Network?

•The phone displays two (2) different bars – GSM (G) on the left side of

the display and Wi-Fi (W) on the right. When the User is calling by

GSM after having dialed the number the only GSM bar will appear oth-

erwise only the wireless bar

14)How can the user understand if he/she is connected to the Access

Point

•On the phone display check the WiFi bar on the right. See Configura-

tion troubleshooting for more details.

15)How can the user understand if he/she is registered to a VoIP SIP

proxy server

•On the phone display ‘VoIP’ will appear. See Configuration trouble-

shooting for more details.

16)In a public Hot spot the phone is not able to acquire a Wi-Fi account

or be VoIP registered?

•It is possible that a public hot spot user acceptance page is required or

that the HOT SPOT ISP is not able to support SIP ALG for NAPT tra-

versal purposes.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

120

FAQA

17)How can I manage the association to two different Access Points?

(Eg. One at home and another in my office?)

•It is possible by setting one profile for any environment where the

phone has to work in, and set “ALL PROFILES” in WLAN configura-

tion session

18)Does DP L10 support WAP 2.0 protocol?

•Yes, it supports wap 2.0 (http, ssl) TCP-IP based. Anyway certain

functions wap related as e-mail, fast download or MMS require the

Network support to become effective.

19)Does DP L10 support the e-mail functionality?

•Yes, it does. It supports protocols POP3 and SMTP.

20)The user has problems with your client e-mail

•Check the e-mail client configuration (username, password, e-mail

address, incoming and outcoming server port…)

21) Can the user synchronize the Outlook Address book with the DP-

L10 phonebook?

•Yes, he/she can. The PC utility tool lets to synchronize with Windows

Outlook Express and Outlook 2003 Address book.

22)Does DP L10 support WAP 2.0 protocol?

•Yes, it supports wap 2.0 (http, ssl) TCP-IP based. Anyway certain

functions wap related as e-mail, fast download or MMS require the

Network support to become effective.

23)Does DP L10 support MMS?

•Yes, it supports SMS, LMS and MMS.

24)The user is not able to access to Internet via WAP?

•Check the WAP configuration in the WAP profile setting.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

FAQ

121

25)It is not possible to enter the SIP configuration session menu

•This happens when the WLAN configuration menu is set to “ALL PRO-

FILES”. It is necessary to chose one profile and then the menu

becomes accessible for configuration.

26)Does the DP-L10 support the mute call?

•Yes it does. Access from ‘*’ key with bell signal; long press to enable/

disable.

27)Does the DP-L10 support access to phonebook during the call?

•Yes it does for both GSM and WiFi calls. You can also add a new entry

in the phonebook.

28)Does the DP-L10 support the call notification?

•Yes it does for both GSM and WiFi calls.

29)Does the DP-L10 support the call hold?

•Yes it does for both GSM and WiFi calls.

30)Does the DP-L10 support the conference call?

•Yes it does. Up to 6 GSM parties; for WiFi conference, please check

with your service provider for availability.

31)Does the DP-L10 support the emergency call?

•Yes it does. The emergency calls are always sent via GSM network.

32)What size does the camera support?

•The camera supports size 640x480, 320x240, 160x120, 128x96 and

64x48. 128x128 for Wallpaper.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

122

FAQA

A.2 Configuration troubleshooting

1) WiFi connection problems

No WiFi connection is available; check the wifi connection status in ‘Menu’ >

‘WLAN’ > ‘WLAN status’.

•Not available

bGeneral WLAN connection error, e.g. the SSID does not exist.

wWorkaround: Check the WLAN configuration parameters in the

WLAN profile (‘Menu’ > ‘WLAN’ > ‘WLAN settings’ > ‘Active Set-

tings’ and ‘Edit Active Setting’)

•Time out

bAssociation response exceeds timeout value, e.g. signal is weak,

or Access Point is busy.

wWorkaround: retry the WiFi connection (press the right arrow in the

scrolling keypad); eventually reduce the distance respect to the

Access Point

•Association refused

bDP-L10 refused by Access Point during association phase, e.g. AP

is resource-constrained.

wWorkaround: wait for some minutes, then retry the WiFi connection

(press the right arrow in the scrolling keypad)

•Authentication refused

bRefused by AP during authentication phase, e.g. incorrect key, fil-

tered by AP’s ACL

wWorkaround:

•Check the encryption type on the DP-L10 (open, WEP, WPA-

PSK TKIP, WPA2-PSK AES) is according to the one on the

Access Point. If you don’t know if the Access Point is using

encryption, check on ‘Menu’ > ‘WLAN’ > ‘WLAN settings’ >

‘edit act. Settings’ > ‘SSID security’ > ‘SSID’, ‘Site survey’ >

‘SSID list’. Read the options of your SSID and check ‘Security’

field.

•‘None’ no security is required. Set ‘open’ in ‘Menu’ >

‘WLAN’ > ‘WLAN settings’ > ‘edit act. Settings’ > ‘SSID

security’ > ‘Security’.

•‘WEP’ > WEP key is required. Set ‘WEP’ in ‘Menu’ >

‘WLAN’ > ‘WLAN settings’ > ‘edit act. Settings’ > ‘SSID

security’ > ‘Security’. Then select ‘WEP key 1’ with your

WEP key value.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

FAQ

123

•Apply the same instructions for WPA-PSK TKIP and WPA2-

PSK AES.

If you know the connection is open set ‘open’ in ‘Menu’ >

‘WLAN’ > ‘WLAN settings’ > ‘edit act. Settings’ > ‘SSID secu-

rity’ > ‘Security’.

•If you know the connection is encrypted set ‘WEP’ in ‘Menu’ >

‘WLAN’ > ‘WLAN settings’ > ‘edit act. Settings’ > ‘SSID secu-

rity’ > ‘Security’. Then set the ‘WEP key 1’ with your WEP key

value.

•Re-type the encryption on the DP-L10

•Check if the Access Point is enabling filtering policy (Access

Control List). In this case you need to include your DP-L10 in

the Access Point ACL (please contact the service provider)

•IP not valid

bThe IP address appears as 0.0.0.0

wWorkaround: the problem concerns your access point configura-

tion. Set ‘Automatic’ in ‘Menu’ > ‘WLAN’ > ‘WLAN settings’ > ‘edit

act. Settings’ > ‘IP settings’ and retry the connection.

wCheck your Access Point configuration: if it does not support the

DHCP server functionality, set ‘Manual’ in ‘Menu’ > ‘WLAN’ >

‘WLAN settings’ > ‘edit act. Settings’ > ‘IP settings’ and insert an IP

address included in Access Point subnet mask; retry the connec-

tionn

2) VoIP connection problems

The WiFi connection is available but the VoIP service is not available: check

the ‘Register server’ value in ‘Menu’ > ‘WLAN’ > ‘SIP status’.

Note: to change the SIP configuration parameters the WLAN profile must be

different from ‘All profiles’ (‘Menu’ > ‘WLAN’ > ‘WLAN settings’ > ‘Active

Settings’)

•SIP not ready

bVoIP initialization failed, e.g. phone didn’t get IP address, DNS

resolving failed.

wWorkaround: wait for some minutes and retry the connection

Check the SIP configuration parameters in ‘Menu’ > ‘WLAN’ > ‘SIP

settings’ the following field:

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

124

FAQA

•‘Register Server’ should be the IP or the URL of your Register

Server

•‘Domain name’ should be the registration domain of your sip

proxy

•‘Username’ should be the user name of your account

•‘Password’ should be the password linked to the user name of

your account

•‘Outbound Proxy’ if you don’t use an outbound proxy, the field

should be empty.

For example for the following account info:

SIP Username and Auth Name: 15579

SIP Password: 02486

Proxy and Registar Server: sip.prova.com

Domain: domain.prova.com

The configuration shall be:

‘Register Server’ = sip.prova.com

‘Domain name’ = domain.prova.com

‘Username’ = 13579

‘Password’ = 02486

Retry the connection.

•Server no response

bRegistration response exceeds timeout value, e.g. the network

can’t reach registration server.

wWorkaround: wait for some minutes, then retry the connection;

eventually check with the service provider the server status

•Authentication fail

bRegistration refused by registrar server, e.g. password incorrect.

wWorkaround: check the SIP configuration parameters in ‘Menu’ >

‘WLAN’ > ‘SIP settings’ the following field:

•‘Register Server’ should be the IP or the URL of your Register

Server

•‘Domain name’ should be the registration domain of your sip

proxy

•‘Username’ should be the user name of your account

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

FAQ

125

•‘Password’ should be the password linked to the user name of

your account

•‘Outbound Proxy’ if you don’t use an outbound proxy, the field

should be empty.

For example for the following account info:

SIP Username and Auth Name: 15579

SIP Password: 02486

Proxy and Registar Server: sip.prova.com

Domain: domain.prova.com

The configuration shall be:

‘Register Server’ = sip.prova.com

‘Domain name’ = domain.prova.com

‘Username’ = 13579

‘Password’ = 02486

Retry the connection.

•Not found

bUsername not found.

wWorkaround: check the SIP configuration parameters; check with

the service provider your account

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

126

FAQA

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Glossary

127

Glossary

Term Description

Dual Mode

Telephone Telephone that operates with two standard

elements: GSM and Wifi

Protection Messages that are sent as protected mes-

sages can only be read by certain people.

Messages sent to a portable telephone by a

digital telephone are often protected if oper-

ated wirelessly.

IMEI The identification number for GSM tele-

phones. This number can be used to block

stolen cellular telephones.

ISP A company that offers special services.

GPRS Allows users to more quickly access and

send data from a cellular telephone.

GSM Internationally recognised element for digi-

tal communication with a field of 800 MHz,

1800 MHz and 1900 MHz. It was introduced

in 1991 and is used predominantly in Asia

and Europe but not in the USA. GSM tele-

phones use a SIM card that contains the

user’s information. Every GSM is pro-

grammed immediately after the SIM card is

assigned, a feature that makes GSM tele-

phones easy to rent or loan to others. The

GSM offers an SMS service for sending text

messages of up to 160 characters to other

telephones that also operate with a SIM

card.

MMS MMS allows users to communicate multi-

media data such as images, voice mes-

sages and video clips.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

128

GlossaryB

PIN This code (from 4 to 8 characters) protects

the SIM card from unauthorised users. The

PIN code is usually assigned with the SIM

card.

PIN2 This code (from 4 to 8 characters) is

assigned with the SIM card. It is useful for

special functions and telephone security.

Proxy The proxyserver is a secondary server that

is active between the host server and the

user server.

PUK This code (8 characters) is an additional

safety code. (making it useful for unblocking

a telephone in the event that a wrong PIN

code is entered.)

Roaming Roaming allows a cellular telephone users

to make telephone calls and send and

receive data, in addition to other services,

even if the user is found outside of their

area of network coverage as defined in their

user contract, by using the network that ser-

vices the area where they are currently

located. Use of the telephone outside of the

country depends on the network operator’s

number of roaming contracts and on the

characteristics of the telephone.

SAR Indicates the amount of frequency energy

absorbed by human tissue through the

transmission of radio waves. The admissi-

ble level differs by country.

Term Description

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Glossary

129

SIM card This removable card is a chip located inside

a GSM telephone that contains information

such as the user’s telephone number, the

list of telephone numbers and other infor-

mation related to the owner of the tele-

phone.

SIP The real-time communication protocol for

VoIP.

SMS (short message service) This text messag-

ing service is used in the majority of mobile

telephone systems.

USB A device that allows the telephone to inter-

face with a PC through a PC- tool.)

Voicemail Calls are transferred to Voicemail if the user

is cannot be reached or if the telephone is

turned off. The telephone informs the user if

they have received a message.

VoIP VoIP is a group of technologies that com-

presses the voice, enters it into “packages”

and then transmits it via internet.

WAP Element that helps to create internet appli-

cations that can be used by special cellular

telephones.

WLAN A network that allows various users located

in the same building with intranet access to

connect with each other. Normally operates

below the 802.11 Norm. The sog.Hub hard-

ware component operates like a common

connection interface, making it possible to

transmit data located inside the data pro-

cessing network to others.

Term Description

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

130

GlossaryB

802.11 Standard for mobile telephone communica-

tion that uses the frequency spectrum of

2.4GHz and allows for high-speed transmis-

sion up to 54Mbps.

Term Description

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

131

This document contains Pirelli proprietary and confidential information. No

part of this document may be copied, reprinted or reproduced in any material

form or electronically, whether wholly or in part, and no information contained

herein may be used or disclosed to third parties unless under a previous writ-

ten agreement with Pirelli Broadband Solutions setting forth relevant terms

and conditions

Pirelli operates a policy of ongoing development and reserves the right to

make change to any of the products described in this document without prior

notice.

Users must take full responsibility for their applications of any products speci-

fied in this document. The information in this document is proprietary to Pirelli.

Pirelli does not assume any liability that may occur due to the use or applica-

tion of the product(s) described herein.s.

All of the terms used in the present document that are recognised as brands

of products or services are identified accordingly. Pirelli cannot certify to the

exactness of these identifications. The names of other products or companies

used in the present document, which may indicate brands of products or ser-

vices, or brands that distinguish them from other companies, are used without

any intention for counterfeiting. The use of a term in the present document is

not intended to discredit the validity of brands, products or services.

This publication may be modified without prior notice. Pirelli reserves the right

to make changes to the description of the system or its components due to

technological developments, changes in the manufacturing methods or other

circumstances.

The present document is for informational purposes only. For the permitted

uses see the provisions specified above. This document does not constitute a

contract with the user nor is it a guarantee for Pirelli products described

herein. This document is not be intended as a license concession nor does it

give related rights to intellectual property associated with the information or

materials included, or to those referred to in the present document. Pirelli

does not provide guarantees, explicit or implied, for the information contained

in the present document.

VoIPon Solutions www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0) 1245 600560

Pirelli DP L10 User Manual To The 46a717de 424b 44a6 A65d 74cb19a7b649

Navigation menu

Versions of this User Manual:

Views

Navigation
