Pismolabs Technology P1121 WLAN 802.11b/g/n Module User Manual N21 User s Manual with product spec 0

Pismo Labs Technology Limited WLAN 802.11b/g/n Module N21 User s Manual with product spec 0

Contents

UserMan_U8G-P1121

BroadbandPossibilities1
Copyright@2010Pepwave
PismolabsNSeries
PismoN21miniͲPCI
HighPower2x2802.11nMIMO
IndustrialGradeOperatingTemperature
HardwareSpecification
CoreComponent
WiͲFiChipsetAtherosAR9220
Radio2x2MIMO802.11b/g/n
Interface32ͲbitminiͲPCI
MMCXConnector2
Operation
PowerConsumption54Mbps(4.8W),MCS0(4.8W),MCS15(6W)[ContinuousTXmode]
Temperature Ͳ40ȗCto65ȗC
Humidity15to95%
FormFactor&Misc
PCB80mmx60mmx1.0mm
CertificationFCC,CE(100mWlimited),RoHS
TransmitPower,EVMReceiveSensitivity
802.11b/g
27dBm@1Ͳ24Mbps,EVM<Ͳ16dB
26dBm@36Mbps,EVM<Ͳ19dB
25dBm@48Mbps,EVM<Ͳ22dB
24dBm@54Mbps,EVM<Ͳ25dB
(+/Ͳ2.0dB)
Ͳ92dBm@1Mbps
Ͳ89dBm@11Mbps
Ͳ92dBm@6Mbps
Ͳ88dBm@24Mbps
Ͳ84dBm@36Mbps
Ͳ80dBm@48Mbps
Ͳ78dBm@54Mbps
(+/Ͳ2.0dB)
2.4GHz
802.11nHT20
27dBm@MCS0/8,EVM<Ͳ5dB
27dBm@MCS1/9,EVM<Ͳ10dB
27dBm@MCS2/10,EVM<Ͳ13dB
27dBm@MCS3/11,EVM<Ͳ16dB
26dBm@MCS4/12,EVM<Ͳ19dB
25dBm@MCS5/13,EVM<Ͳ22dB
24dBm@MCS6/14,EVM<Ͳ25dB
23dBm@MCS7/15,EVM<Ͳ28dB
(+/Ͳ2.0dB)
Ͳ93dBm@MCS0/8
Ͳ92dBm@MCS1/9
Ͳ90dBm@MCS2/10
Ͳ86dBm@MCS3/11
Ͳ83dBm@MCS4/12
Ͳ78dBm@MCS5/13
Ͳ77dBm@MCS6/14
Ͳ75dBm@MCS7/15
(+/Ͳ2.0dB)
RadioSpecification
BroadbandPossibilities2
Copyright@2010Pepwave
2.4GHz
802.11nHT40
27dBm@MCS0/8,EVM<Ͳ5dB
27dBm@MCS1/9,EVM<Ͳ10dB
27dBm@MCS2/10,EVM<Ͳ13dB
27dBm@MCS3/11,EVM<Ͳ16dB
26dBm@MCS4/12,EVM<Ͳ19dB
25dBm@MCS5/13,EVM<Ͳ22dB
24dBm@MCS6/14,EVM<Ͳ25dB
23dBm@MCS7/15,EVM<Ͳ28dB
(+/Ͳ2.0dB)
Ͳ90dBm@MCS0/8
Ͳ89dBm@MCS1/9
Ͳ87dBm@MCS2/10
Ͳ84dBm@MCS3/11
Ͳ80dBm@MCS4/12
Ͳ75dBm@MCS5/13
Ͳ74dBm@MCS6/14
Ͳ72dBm@MCS7/15
(+/Ͳ2.0dB)
Broadband Possibilities 3 Copyright @ 2010 Pepwave
U.S. Regulatory Wireless Notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Broadband Possibilities 4 Copyright @ 2010 Pepwave
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and
users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for
2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to
the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However,
the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain
laptop configurations or co-location with another transmitter), then the FCC authorization is no
longer considered valid and the FCC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed
such that 20 cm may be maintained between the antenna and users. The final end product must
be labeled in a visible area with the following: “Contains FCC ID: U8G-P1121”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
